A spiral conveyor system may include a cage associated with a motor; a conveyor belt traveling helically about the cage; the cage including a plurality of drive elements formed of vertically oriented cage bars; a cage bar cap mounted on at least one of the cage bars; the cage bar cap including a vertically oriented rib extending radially from a surface of the cage bar cap; wherein the rib includes at least one drive face; wherein the conveyor belt includes at least one belt surface configured to engage the at least one drive face; wherein the cage includes a ring that extends between the terminus of the rib and the entrance end of the cage; wherein the surface of the cage bar cap from which the rib extends defines a first diameter; and wherein the ring has a ring diameter that is larger than the first diameter.
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
B65G 21/18 - Supporting or protective framework or housings for endless load-carriers or traction elements of belt or chain conveyors for conveyors having endless load-carriers movable in curved paths in three-dimensionally curved paths
B65G 23/06 - Drums, rollers, or wheels with projections engaging abutments on belts or chains, e.g. sprocket wheels
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Conveyor belt equipment monitoring system, namely,
downloadable computer software used to monitor and report on
conveyor belt equipment performance and diagnose problems
with conveyor belt equipment; electronic monitoring
apparatus for conveyor belt systems comprised of computer
hardware and operating software, electric sensors,
transmitters of electronic signals and alarm monitoring
systems used to monitor equipment, diagnose problems with
the system, and transmit electronic messages and data via
communications network. Providing temporary use of online non-downloadable computer
software used to monitor and track conveyor belt equipment
and systems, to produce reports and alerts relating to
system operation and performance, and to transmit electronic
messages and data via communications networks; remote
monitoring of the functioning and use of electrical
equipment, namely, conveyor belt equipment for system
performance, maintenance issues and breakdowns.
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
(1) Conveyor belt equipment monitoring system, namely, downloadable computer software used to monitor and report on conveyor belt equipment performance and diagnose problems with conveyor belt equipment; electronic monitoring apparatus for conveyor belt systems comprised of computer hardware and operating software, electric sensors, transmitters of electronic signals and alarm monitoring systems used to monitor equipment, diagnose problems with the system, and transmit electronic messages and data via communications network. (1) Providing temporary use of online non-downloadable computer software used to monitor and track conveyor belt equipment and systems, to produce reports and alerts relating to system operation and performance, and to transmit electronic messages and data via communications networks; remote monitoring of the functioning and use of electrical equipment, namely, conveyor belt equipment for system performance, maintenance issues and breakdowns.
A spiral conveyor system may include a cage associated with a motor; a conveyor belt traveling helically about the cage; the cage including a plurality of drive elements formed of vertically oriented cage bars; a cage bar cap mounted on at least one of the cage bars; the cage bar cap including a vertically oriented rib extending radially from a surface of the cage bar cap; wherein the rib includes at least one drive face; wherein the conveyor belt includes at least one belt surface configured to engage the at least one drive face; wherein the cage includes a ring that extends between the terminus of the rib and the entrance end of the cage; wherein the surface of the cage bar cap from which the rib extends defines a first diameter; and wherein the ring has a ring diameter that is larger than the first diameter.
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
B65G 21/18 - Supporting or protective framework or housings for endless load-carriers or traction elements of belt or chain conveyors for conveyors having endless load-carriers movable in curved paths in three-dimensionally curved paths
B65G 23/06 - Drums, rollers, or wheels with projections engaging abutments on belts or chains, e.g. sprocket wheels
A spiral conveyor system may include a drum and a conveyor belt traveling helically about the drum from an entrance end to an exit end of the drum, and a rib associated with the drum, wherein the rib extends radially from a surface of the drum. A length of the rib extends along the length of the drum from a first end of the rib to a terminus of the rib proximate the entrance end of the drum. In addition, a height of the rib above of the surface of the drum varies along the length of the rib. Further, the rib includes at least one drive face, wherein the conveyor belt includes at least one belt surface configured to engage the at least one drive face, and wherein the drum includes a smooth ribless portion between the terminus of the rib and the entrance end of the drum.
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
B65G 21/18 - Supporting or protective framework or housings for endless load-carriers or traction elements of belt or chain conveyors for conveyors having endless load-carriers movable in curved paths in three-dimensionally curved paths
B65G 23/06 - Drums, rollers, or wheels with projections engaging abutments on belts or chains, e.g. sprocket wheels
37 - Construction and mining; installation and repair services
42 - Scientific, technological and industrial services, research and design
Goods & Services
conveyor machinery; conveyor belts [machines]; chains for conveyors; overlays for conveyors; parts of the aforementioned products. installation, reparation, maintenance, reparation, replacement and upgrading services in relation to conveyor machinery, conveyor belts, conveyor chains and other conveyor equipment and parts thereof; consultancy services in relation to the aforementioned services. technical advice in the field of transport conveyor systems, conveyor equipment, belt selection; design and development of conveyor systems, conveyor equipment, belts [machines], chains; scientific and technical research in the field of conveyor equipment, conveyor belts and chains; evaluation and testing of conveyor systems and parts thereof.
A spiral conveyor system may include a drum associated with a motor, wherein the drum extends from a drum bottom to a drum top. In addition, the system may include a conveyor belt traveling helically about the drum from an entrance end of the drum to an exit end of the drum. Further, the system may include a rib associated with the drum, wherein the rib extends radially from a surface of the drum, and at least one drive face positioned on the rib. The conveyor belt may include at least one belt surface configured to engage the at least one drive face. The length of the rib extends along the length of the drum from a first end of the rib to a terminus of the rib proximate the entrance end of the drum. In addition, the drum includes a ring that extends between the terminus of the rib and the entrance end of the drum.
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
B65G 21/18 - Supporting or protective framework or housings for endless load-carriers or traction elements of belt or chain conveyors for conveyors having endless load-carriers movable in curved paths in three-dimensionally curved paths
B65G 23/06 - Drums, rollers, or wheels with projections engaging abutments on belts or chains, e.g. sprocket wheels
A spiral overlay for a conveyor belt includes a plurality of wire spirals assembled together in intermeshing relationship on connecting rods to provide a conveying surface and an opposing surface with a belt thickness extending in the vertical direction. Each of said wire spirals formed of a single length of wire and forming a helix extending laterally across the belt, said spiral comprising opposed arcuate linking bends at a forward end and a rearward end along the longitudinal axis, and at least one intermediate loop formed between said opposed arcuate linking bends and disposed within the belt thickness, said spirals arranged relative to one another such that said linking bends of one spiral are intermeshed with linking bends of an immediately adjacent one of said spirals and said intermeshed linking bends of adjacent spirals are adapted to receive one of the connecting rods to operatively connect said spirals.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
42.
CONVEYOR BELT SPIRAL OVERLAY HAVING INTERMEDIATE LOOPS
A spiral overlay for a conveyor belt includes a plurality of wire spirals assembled together in intermeshing relationship on connecting rods to provide a conveying surface and an opposing surface with a belt thickness extending in the vertical direction. Each of said wire spirals formed of a single length of wire and forming a helix extending laterally across the belt, said spiral comprising opposed arcuate linking bends at a forward end and a rearward end along the longitudinal axis, and at least one intermediate loop formed between said opposed arcuate linking bends and disposed within the belt thickness, said spirals arranged relative to one another such that said linking bends of one spiral are intermeshed with linking bends of an immediately adjacent one of said spirals and said intermeshed linking bends of adjacent spirals are adapted to receive one of the connecting rods to operatively connect said spirals.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
43.
Conveyor belt spiral overlay having intermediate loops
A spiral overlay for a conveyor belt includes a plurality of wire spirals assembled together in intermeshing relationship on connecting rods to provide a conveying surface and an opposing surface with a belt thickness extending in the vertical direction. Each of said wire spirals formed of a single length of wire and forming a helix extending laterally across the belt, said spiral comprising opposed arcuate linking bends at a forward end and a rearward end along the longitudinal axis, and at least one intermediate loop formed between said opposed arcuate linking bends and disposed within the belt thickness, said spirals arranged relative to one another such that said linking bends of one spiral are intermeshed with linking bends of an immediately adjacent one of said spirals and said intermeshed linking bends of adjacent spirals are adapted to receive one of the connecting rods to operatively connect said spirals.
B65G 15/54 - Endless load-carriers made of interwoven ropes or wires
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
A spiral conveyor system with a positive drive system includes a rotating drum with at least one rib that is attached to drum. The rib includes a drive face for engaging a conveyor belt. The height of the rib above of the surface of the drum varies along a length of the drive element. The rib may be directly attached to the drum or may be a part of a drive element attached to the drum. The conveyor belt includes at least one belt surface configured to engage the at least one drive face, such as a protruding tab with a flat surface.
B65G 21/18 - Supporting or protective framework or housings for endless load-carriers or traction elements of belt or chain conveyors for conveyors having endless load-carriers movable in curved paths in three-dimensionally curved paths
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
B65G 23/06 - Drums, rollers, or wheels with projections engaging abutments on belts or chains, e.g. sprocket wheels
46.
System and method for anticipating low-speed bearing failure
A system for anticipating low-speed bearing failure triggers a notification when a noise generated by the low-speed bearing exceeds a threshold. The system predicts failure far in advance of the actual failure. The system includes an accelerometer for detecting the noise generated by the bearing. The signal produced by the accelerometer is processed using a band pass filter, an amplifier/rectifier, an averaging filter, and a voltage to current converter. The signal and raw data are transmitted to a remote monitoring system, such as a computer. The signal is further analyzed, such as to produce a best-fit line. When the signal exceeds a predetermined threshold, such as when the amount or the slope of the best-fit line exceeds a value, the remote system notifies a monitor to schedule maintenance.
B65G 21/18 - Supporting or protective framework or housings for endless load-carriers or traction elements of belt or chain conveyors for conveyors having endless load-carriers movable in curved paths in three-dimensionally curved paths
B65G 43/00 - Control devices, e.g. for safety, warning or fault-correcting
A system for anticipating low-speed bearing failure triggers a notification when a noise generated by the low-speed bearing exceeds a threshold. The system predicts failure far in advance of the actual failure. The system includes an accelerometer for detecting the noise generated by the bearing. The signal produced by the accelerometer is processed using a band pass filter, an amplifier/rectifier, an averaging filter, and a voltage to current converter. The signal and raw data are transmitted to a remote monitoring system, such as a computer. The signal is further analyzed, such as to produce a best-fit line. When the signal exceeds a predetermined threshold, such as when the amount or the slope of the best-fit line exceeds a value, the remote system notifies a monitor to schedule maintenance.
A conveyor belt includes a self-supporting linkage assembly and a plurality of transverse elements configured to travel along a longitudinal direction. The transverse elements are interconnected by the linkage assembly. The conveyor belt also includes a biasing member. The linkage assembly includes a first link and a second link. The first and second links are configured to move relative to each other between an engaged position and a disengaged position. The biasing member is configured to bias the first and second links toward the engaged position. The first and second links, when in the engaged position, are constrained against rotation relative to each other. The first and second links, when in the disengaged position, are configured to rotate relative to each other.
A conveyor belt includes a self-supporting linkage assembly and a plurality of transverse elements configured to travel along a longitudinal direction. The transverse elements are interconnected by the linkage assembly. The conveyor belt also includes a biasing member. The linkage assembly includes a first link and a second link. The first and second links are configured to move relative to each other between an engaged position and a disengaged position. The biasing member is configured to bias the first and second links toward the engaged position. The first and second links, when in the engaged position, are constrained against rotation relative to each other. The first and second links, when in the disengaged position, are configured to rotate relative to each other.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Conveyor belt equipment monitoring system, namely, downloadable computer software used to monitor and report on conveyor belt equipment performance and diagnose problems with conveyor belt equipment; electronic monitoring apparatus for conveyor belt systems comprised of computer hardware and operating software, electric sensors, transmitters of electronic signals and alarm monitoring systems used to monitor equipment, diagnose problems with the system, and transmit electronic messages and data via communications network Providing temporary use of online non-downloadable computer software used to monitor and track conveyor belt equipment and systems, to produce reports and alerts relating to system operation and performance, and to transmit electronic messages and data via communications networks; remote monitoring of the functioning and use of electrical equipment, namely, conveyor belt equipment for system performance, maintenance issues and breakdowns
A spiral conveyor system with a positive drive system includes a rotating drum with at least one rib that is attached to drum. The rib includes a drive face for engaging a conveyor belt. The height of the rib above of the surface of the drum varies along a length of the drive element. The rib may be directly attached to the drum or may be a part of a drive element attached to the drum. The conveyor belt includes at least one belt surface configured to engage the at least one drive face, such as a protruding tab with a flat surface.
B65G 21/18 - Supporting or protective framework or housings for endless load-carriers or traction elements of belt or chain conveyors for conveyors having endless load-carriers movable in curved paths in three-dimensionally curved paths
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
B65G 17/30 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface - Details; Auxiliary devices
B65G 17/38 - Chains or like traction elements; Connections between traction elements and load-carriers
A spiral conveyor system with a positive drive system includes a rotating drum with at least one rib that is attached to drum. The rib includes a drive face for engaging a conveyor belt. The height of the rib above of the surface of the drum varies along a length of the drive element. The rib may be directly attached to the drum or may be a part of a drive element attached to the drum. The conveyor belt includes at least one belt surface configured to engage the at least one drive face, such as a protruding tab with a flat surface.
B65G 21/18 - Supporting or protective framework or housings for endless load-carriers or traction elements of belt or chain conveyors for conveyors having endless load-carriers movable in curved paths in three-dimensionally curved paths
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
A conveyor belt includes a first link having a first protrusion with a first mating surface that is curved. The first protrusion is disposed proximate a first rod receiving aperture of the first link. The belt also includes a second link having a second protrusion with a second mating surface that is curved. The second protrusion is disposed proximate a second rod receiving aperture of the second link. The first mating surface receives and abuts the second mating surface. The second link is restrained against movement in less than three orthogonal directions relative to the first link due to abutment of the first and second mating surfaces. The first and second rod receiving apertures are aligned when the first and second mating surfaces abut. Additionally, the belt includes a connecting rod extending through the first and second rod receiving apertures.
B65G 15/32 - Belts or like endless load-carriers made of rubber or plastics
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
B65G 17/38 - Chains or like traction elements; Connections between traction elements and load-carriers
An electropolishing or electroplating system and method for metal conveyor belts is described. As opposed to conventional polishing processes in which the product is guided around rollers which direct the product into and out of an electrolyte bath, embodiments of the present invention pass the product through a housing supplied with a continuous directional flow of electrolyte. Thus, the electroplating or electropolishing can be targeted to specific areas of the product, such as the edges and/or the center of a conveyor belt, and straight products can pass through the housing without deformation.
An electropolishing or electroplating system and method for metal conveyor belts is described. As opposed to conventional polishing processes in which the product is guided around rollers which direct the product into and out of an electrolyte bath, embodiments of the present invention pass the product through a housing supplied with a continuous directional flow of electrolyte. Thus, the electroplating or electropolishing can be targeted to specific areas of the product, such as the edges and/or the center of a conveyor belt, and straight products can pass through the housing without deformation.
An electropolishing or electroplating system and method for metal conveyor belts is described. As opposed to conventional polishing processes in which the product is guided around rollers which direct the product into and out of an electrolyte bath, embodiments of the present invention pass the product through a housing supplied with a continuous directional flow of electrolyte. Thus, the electroplating or electropolishing can be targeted to specific areas of the product, such as the edges and/or the center of a conveyor belt, and straight products can pass through the housing without deformation.
C25D 5/02 - Electroplating of selected surface areas
C25D 7/00 - Electroplating characterised by the article coated
C25D 17/00 - Constructional parts, or assemblies thereof, of cells for electrolytic coating
C25F 7/00 - Constructional parts, or assemblies thereof, of cells for electrolytic removal of material from objects; Servicing or operating
B65G 49/02 - Conveying systems characterised by their application for specified purposes not otherwise provided for for conveying workpieces through baths of liquid
57.
APPARATUS FOR STORING, TRANSPORTING AND DISPENSING CONVEYOR BELTS
A hub assembly for storing and transporting rolled material, in particular conveyor belts, the hub assembly comprising an axle (910) and a first hub (950) attached to said axle, wherein a perimeter of said first hub comprises minimum and maximum radii and a step between the minimum and maximum radii.
B65D 19/44 - Elements or devices for locating articles on platforms
B65D 85/66 - Containers, packaging elements or packages, specially adapted for particular articles or materials for rolls of floor covering
B65D 85/672 - Containers, packaging elements or packages, specially adapted for particular articles or materials for web or tape-like material wound in flat spiral form on cores
A conveyor belt includes a first link having a first protrusion with a first mating surface that is curved. The first protrusion is disposed proximate a first rod receiving aperture of the first link. The belt also includes a second link having a second protrusion with a second mating surface that is curved. The second protrusion is disposed proximate a second rod receiving aperture of the second link. The first mating surface receives and abuts the second mating surface. The second link is restrained against movement in less than three orthogonal directions relative to the first link due to abutment of the first and second mating surfaces. The first and second rod receiving apertures are aligned when the first and second mating surfaces abut. Additionally, the belt includes a connecting rod extending through the first and second rod receiving apertures.
B65G 15/32 - Belts or like endless load-carriers made of rubber or plastics
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
B65G 17/38 - Chains or like traction elements; Connections between traction elements and load-carriers
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
Components for conveyor belts and conveyor belt systems, namely, wagon drives and parts and fittings therefor, and ball drives and parts and fittings therefor
A link member having a curved bearing surface and a conveyor belt comprising a link member having a curved bearing surface are described. The link member can be comprised in any type of conveyor belt, including a grid-type conveyor belt, a smaller-radius grid-type conveyor belt or a flat-wire conveyor belt. The link member eliminates the objectionable noise caused by pivot rods jumping the corner of conventional links having curved bearing surfaces. According to one embodiment, the link member comprises a pair of leg portions, each leg portion comprising a first opening at a distal end and a second opening at a proximal end, and a connecting portion that connects the pair of leg portions, the connecting portion comprising a curved bearing surface between first and second side surfaces. The first and second side surfaces extend in a direction toward the proximal end of the leg portions.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
A link member having a curved bearing surface and a conveyor belt comprising a link member having a curved bearing surface are described. The link member can be comprised in any type of conveyor belt, including a grid-type conveyor belt, a smaller-radius grid-type conveyor belt or a flat-wire conveyor belt. The link member eliminates the objectionable noise caused by pivot rods jumping the corner of conventional links having curved bearing surfaces. According to one embodiment, the link member comprises a pair of leg portions, each leg portion comprising a first opening at a distal end and a second opening at a proximal end, and a connecting portion that connects the pair of leg portions, the connecting portion comprising a curved bearing surface between first and second side surfaces. The first and second side surfaces extend in a direction toward the proximal end of the leg portions.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
A link member (100, 300, 500, 600) having a replaceable wear component (180, 280, 380, 480, 580, 680, 780, 880) and a conveyor belt (800) comprising a link member having a replaceable wear component are described. One aspect of the present invention provides a sacrificial or replaceable wear component that is attached to a conveyor belt. The conveyor belt can be any type of conveyor belt, such as a grid-type or flat-wire conveyor belt. The wear component is attached by mechanical or other means to allow its removal after a certain wear limit has been achieved. A new component can be installed to bring the conveyor belt to nearly new condition. This will extend belt life because only the wear component needs to be replaced, rather than the entire belt.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
A link member (100, 300, 500, 600) having a replaceable wear component (180, 280, 380, 480, 580, 680, 780, 880) and a conveyor belt (800) comprising a link member having a replaceable wear component are described. One aspect of the present invention provides a sacrificial or replaceable wear component that is attached to a conveyor belt. The conveyor belt can be any type of conveyor belt, such as a grid-type or flat-wire conveyor belt. The wear component is attached by mechanical or other means to allow its removal after a certain wear limit has been achieved. A new component can be installed to bring the conveyor belt to nearly new condition. This will extend belt life because only the wear component needs to be replaced, rather than the entire belt.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
A link member having a replaceable wear component and a conveyor belt comprising a link member having a replaceable wear component are described. One aspect of the present invention provides a sacrificial or replaceable wear component that is attached to a conveyor belt. The conveyor belt can be any type of conveyor belt, such as a grid-type or flat-wire conveyor belt. The wear component is attached by mechanical or other means to allow its removal after a certain wear limit has been achieved. A new component can be installed to bring the conveyor belt to nearly new condition. This will extend belt life because only the wear component needs to be replaced, rather than the entire belt.
B65G 17/38 - Chains or like traction elements; Connections between traction elements and load-carriers
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
A conveyor belt configured to contact a drive surface is disclosed including a substantially U-shaped link having an outermost portion with a contact surface configured to face the drive surface. The outermost portion of the link may be more resistant to wear due to contact with the drive surface than other portions of the link.
B65G 15/52 - Endless load-carriers consisting of a series of parallel ropes or belt strips interconnected by transverse slats
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
F16G 3/00 - Belt fastenings, e.g. for conveyor belts
A conveyor belt configured to contact a drive surface is disclosed including a substantially U-shaped link having an outermost portion with a contact surface configured to face the drive surface. The outermost portion of the link may be more resistant to wear due to contact with the drive surface than other portions of the link.
B65G 15/52 - Endless load-carriers consisting of a series of parallel ropes or belt strips interconnected by transverse slats
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
F16G 3/00 - Belt fastenings, e.g. for conveyor belts
A conveyor belt configured to contact a drive surface is disclosed including a substantially U-shaped link having an outermost portion with a contact surface configured to face the drive surface. The outermost portion of the link may be more resistant to wear due to contact with the drive surface than other portions of the link.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
B65G 23/06 - Drums, rollers, or wheels with projections engaging abutments on belts or chains, e.g. sprocket wheels
A link for a modular conveyor belt may include a supporting structure and a bearing structure covering at least a portion of the supporting structure. The supporting structure may have a tensile strength that is higher than the bearing structure, and the bearing structure may be more resistant to wear than the supporting structure.
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
A link for a modular conveyor belt may include a supporting structure and a bearing structure covering at least a portion of the supporting structure. The supporting structure may have a tensile strength that is higher than the bearing structure, and the bearing structure may be more resistant to wear than the supporting structure.
A link for a modular conveyor belt may include a supporting structure and a bearing structure covering at least a portion of the supporting structure. The supporting structure may have a tensile strength that is higher than the bearing structure, and the bearing structure may be more resistant to wear than the supporting structure.
An apparatus for storing, transporting and dispensing conveyor belts is described. The apparatus, in the form of a crate, has top and bottom conventional pallets, allowing for easy handling and strength for additional stacked crates. The center of the crate holds a hub assembly that moves rotationally, and allows smooth transition from consecutive layers of the conveyor belt wrapped thereon. During shipment, the roll of conveyor belt lies on its side. In one embodiment, a center pipe axle of the spool passes through holes in the top and bottom pallets. Alternatively, the center pipe axle passes through channels created between planks of the top and bottom pallets. These configurations secure the roll in the crate, and allow it to turn freely when loaded or unloaded.
B65B 63/04 - Auxiliary devices, not otherwise provided for, for operating on articles or materials to be packaged for folding or winding articles, e.g. gloves or stockings
B65D 19/38 - Pallets or like platforms, with or without side walls, for supporting loads to be lifted or lowered - Details or accessories
B65D 19/44 - Elements or devices for locating articles on platforms
B65D 85/672 - Containers, packaging elements or packages, specially adapted for particular articles or materials for web or tape-like material wound in flat spiral form on cores
A conveyor belt is provided that includes a link having a leg formed of a link leg material, wherein the leg includes an outer link surface configured to face the drive surface, the link leg being configured to receive a rod. The conveyor belt may include an aperture extending through the leg, wherein the rod is disposed within the aperture. Also, the conveyor belt may include a first weld that attaches the free end of the rod to the outer link surface, the first weld comprising a first weld material and a second weld made of a second weld material, wherein the second weld covers at least a portion of the first weld and forms an outermost surface of the conveyor belt. The second weld material may be different from the first weld material, and may be more resistant to wear than the first weld material.
A conveyor belt is provided that includes a link having a leg formed of a link leg material, wherein the leg includes an outer link surface configured to face the drive surface, the link leg being configured to receive a rod. The conveyor belt may include an aperture extending through the leg, wherein the rod is disposed within the aperture. Also, the conveyor belt may include a first weld that attaches the free end of the rod to the outer link surface, the first weld comprising a first weld material and a second weld made of a second weld material, wherein the second weld covers at least a portion of the first weld and forms an outermost surface of the conveyor belt. The second weld material may be different from the first weld material, and may be more resistant to wear than the first weld material.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
A conveyor belt is provided that includes a link having a leg formed of a link leg material, wherein the leg includes an outer link surface configured to face the drive surface, the link leg being configured to receive a rod. The conveyor belt may include an aperture extending through the leg, wherein the rod is disposed within the aperture. Also, the conveyor belt may include a first weld that attaches the free end of the rod to the outer link surface, the first weld comprising a first weld material and a second weld made of a second weld material, wherein the second weld covers at least a portion of the first weld and forms an outermost surface of the conveyor belt. The second weld material may be different from the first weld material, and may be more resistant to wear than the first weld material.
An electropolishing or electroplating system and method for metal conveyor belts is described. In some embodiments, the system has a metal conveyor belt held in constant tension; a tank for holding an electrolytic fluid, the tank having an interior space suitable to contain the fluid, a metal plate and the metal conveyor belt; and an electrical current supply. In an electropolishing application, the current passes from the metal conveyor belt, through the fluid and into the metal plate. In an electroplating application, the current passes from the metal plate, through the fluid and into the metal conveyor belt.
An electropolishing or electroplating system and method for metal conveyor belts is described. In some embodiments, the system has a metal conveyor belt held in constant tension; a tank for holding an electrolytic fluid, the tank having an interior space suitable to contain the fluid, a metal plate and the metal conveyor belt; and an electrical current supply. In an electropolishing application, the current passes from the metal conveyor belt, through the fluid and into the metal plate. In an electroplating application, the current passes from the metal plate, through the fluid and into the metal conveyor belt.
A conveyor belt is provided that includes a first link having a first protrusion. The first protrusion may include a first mating surface and may be disposed proximate a first rod receiving aperture extending through the first link. The conveyor belt includes a second link having a second protrusion extending a second distance from a surface of the second link. The second protrusion may include a second mating surface, wherein the second protrusion is disposed proximate a second rod receiving aperture extending through the second link. The first mating surface of the first protrusion may be disposed in a mating relationship with the second mating surface of the second protrusion. The first link and/or second link may be substantially U-shaped. The conveyor belt may include a connecting rod extending through the first rod receiving aperture of the first link and the second rod receiving aperture of the second link.
The present disclosure is directed to a pitch for a modular conveyor belt. In some embodiments, the pitch may include a link having a first leg, including an opening formed in the first leg. The opening may be defined by a first edge, a second edge opposite the first edge, a first side edge, and a second side edge opposite the first side edge. In addition, the pitch may include a projection associated with the first edge. In a first position, the projection may extend substantially perpendicularly away from the first edge towards the second edge so that a free end of the projection is positioned proximate the second edge. Also, the projection may be configured to deflect to a second position, in which the free end of the projection is deflected within the opening towards one of the first side edge and the second side edge.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
A conveyor belt is provided that may include a first link having a first protrusion. The first protrusion may include a first mating surface and may be disposed proximate a first rod receiving aperture extending through the first link. The conveyor belt may include a second link having a second protrusion extending a second distance from a surface of the second link. The second protrusion may include a second mating surface, wherein the second protrusion is disposed proximate a second rod receiving aperture extending through the second link. The first mating surface of the first protrusion may be disposed in a mating relationship with the second mating surface of the second protrusion. Further, the conveyor belt may include a connecting rod extending through the first rod receiving aperture of the first link and the second rod receiving aperture of the second link.
The present disclosure is directed to a pitch for a modular conveyor belt. In some embodiments, the pitch may include a link having a first leg, including an opening formed in the first leg. The opening may be defined by a first edge, a second edge opposite the first edge, a first side edge, and a second side edge opposite the first side edge. In addition, the pitch may include a projection associated with the first edge. In a first position, the projection may extend substantially perpendicularly away from the first edge towards the second edge so that a free end of the projection is positioned proximate the second edge. Also, the projection may be configured to deflect to a second position, in which the free end of the projection is deflected within the opening towards one of the first side edge and the second side edge.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
A conveyor belt is provided that may include a first link having a first protrusion. The first protrusion may include a first mating surface and may be disposed proximate a first rod receiving aperture extending through the first link. The conveyor belt may include a second link having a second protrusion extending a second distance from a surface of the second link. The second protrusion may include a second mating surface, wherein the second protrusion is disposed proximate a second rod receiving aperture extending through the second link. The first mating surface of the first protrusion may be disposed in a mating relationship with the second mating surface of the second protrusion. Further, the conveyor belt may include a connecting rod extending through the first rod receiving aperture of the first link and the second rod receiving aperture of the second link.
The present disclosure is directed to a pitch for a modular conveyor belt. In some embodiments, the pitch may include a link having a first leg, including an opening formed in the first leg. The opening may be defined by a first edge, a second edge opposite the first edge, a first side edge, and a second side edge opposite the first side edge. In addition, the pitch may include a projection associated with the first edge. In a first position, the projection may extend substantially perpendicularly away from the first edge towards the second edge so that a free end of the projection is positioned proximate the second edge. Also, the projection may be configured to deflect to a second position, in which the free end of the projection is deflected within the opening towards one of the first side edge and the second side edge.
The present disclosure is directed to a pitch for a modular conveyor belt. In some embodiments, the pitch may include a link having a first leg, including an opening formed in the first leg. The opening may be defined by a first edge, a second edge opposite the first edge, a first side edge, and a second side edge opposite the first side edge. In addition, the pitch may include a projection associated with the first edge. In a first position, the projection may extend substantially perpendicularly away from the first edge towards the second edge so that a free end of the projection is positioned proximate the second edge. Also, the projection may be configured to deflect to a second position, in which the free end of the projection is deflected within the opening towards one of the first side edge and the second side edge.
The present disclosure is directed to a pitch for a modular conveyor belt. In some embodiments, the pitch may include a link having a first leg, including an opening formed in the first leg. The opening may be defined by a first edge, a second edge opposite the first edge, a first side edge, and a second side edge opposite the first side edge. In addition, the pitch may include a projection associated with the first edge. In a first position, the projection may extend substantially perpendicularly away from the first edge towards the second edge so that a free end of the projection is positioned proximate the second edge. Also, the projection may be configured to deflect to a second position, in which the free end of the projection is deflected within the opening towards one of the first side edge and the second side edge.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
A conveyor belt is provided that may include a first link having a first protrusion. The first protrusion may include a first mating surface and may be disposed proximate a first rod receiving aperture extending through the first link. The conveyor belt may include a second link having a second protrusion extending a second distance from a surface of the second link. The second protrusion may include a second mating surface, wherein the second protrusion is disposed proximate a second rod receiving aperture extending through the second link. The first mating surface of the first protrusion may be disposed in a mating relationship with the second mating surface of the second protrusion. Further, the conveyor belt may include a connecting rod extending through the first rod receiving aperture of the first link and the second rod receiving aperture of the second link.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
87.
Apparatus for storing, transporting and dispensing conveyor belts
An apparatus for storing, transporting and dispensing conveyor belts is described. The apparatus, in the form of a crate, has top and bottom conventional pallets, allowing for easy handling and strength for additional stacked crates. The center of the crate holds a hub assembly that moves rotationally, and allows smooth transition from consecutive layers of the conveyor belt wrapped thereon. During shipment, the roll of conveyor belt lies on its side. In one embodiment, a center pipe axle of the spool passes through holes in the top and bottom pallets. Alternatively, the center pipe axle passes through channels created between planks of the top and bottom pallets. These configurations secure the roll in the crate, and allow it to turn freely when loaded or unloaded.
An apparatus for storing, transporting and dispensing conveyor belts is described. The apparatus, in the form of a crate, has top (210a) and bottom (210b) conventional pallets, allowing for easy handling and strength for additional stacked crates. The center of the crate holds a hub assembly that moves rotationally, and allows smooth transition from consecutive layers of the conveyor belt wrapped thereon. During shipment, the roll of conveyor belt lies on its side. In one embodiment, a center pipe axle (240) of the spool passes through holes (220a, 220b) in the top and bottom pallets. Alternatively, the center pipe axle passes through channels created between planks of the top and bottom pallets. These configurations secure the roll in the crate, and allow it to turn freely when loaded or unloaded.
B65D 19/44 - Elements or devices for locating articles on platforms
B65D 85/66 - Containers, packaging elements or packages, specially adapted for particular articles or materials for rolls of floor covering
B65D 85/672 - Containers, packaging elements or packages, specially adapted for particular articles or materials for web or tape-like material wound in flat spiral form on cores
89.
APPARATUS FOR STORING, TRANSPORTING AND DISPENSING CONVEYOR BELTS
An apparatus for storing, transporting and dispensing conveyor belts is described. The apparatus, in the form of a crate, has top (210a) and bottom (210b) conventional pallets, allowing for easy handling and strength for additional stacked crates. The center of the crate holds a hub assembly that moves rotationally, and allows smooth transition from consecutive layers of the conveyor belt wrapped thereon. During shipment, the roll of conveyor belt lies on its side. In one embodiment, a center pipe axle (240) of the spool passes through holes (220a, 220b) in the top and bottom pallets. Alternatively, the center pipe axle passes through channels created between planks of the top and bottom pallets. These configurations secure the roll in the crate, and allow it to turn freely when loaded or unloaded.
B65D 19/44 - Elements or devices for locating articles on platforms
B65D 85/66 - Containers, packaging elements or packages, specially adapted for particular articles or materials for rolls of floor covering
B65D 85/672 - Containers, packaging elements or packages, specially adapted for particular articles or materials for web or tape-like material wound in flat spiral form on cores
The invention relates to a conveyor assembly, such as a stacker, comprising: a vertically arranged drum having a substantially smooth peripheral surface; a conveyor belt, at least one full turn wound along the peripheral surface of the drum, said belt comprising support elements to support portions of the belt on top of each other; wherein the bottom part of the drum widens outwardly and the remaining part of the drum is cylindrical.
A conveyor belt is made with a series of spaced apart buttonless rods. The buttonless rods are connected to each other with a plurality of links. The buttonless ends of the rods are welded or otherwise affixed to the links so that the ends of the rods are substantially coplanar with the outer surface of the links. This forms a relatively smooth link surface, which is readily cleaned and sanitized. Additionally, wear and tear is reduced on driving grip surfaces that frictionally grab onto the links.
A conveyor belt including a plurality of link elements, and a pivot rod with a button head at one end. The button head is sized to pass through an outer opening and be received in a first edge extension when in a particular orientation. The pivot rod is retained with the button head received in the first edge extension by rotating the button head so that the button head is misaligned with respect to the first dimension of the outer opening. A method for assembling a conveyor belt is also provided.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
A conveyor belt (10) including a plurality of link elements (12, 13) and a pivot rod (16) with a button head (40) at one end. The button head (40) is sized to pass through an outer opening (22) and be received in a first edge extension (20) when in a particular orientation. The pivot rod (16) is retained with the button head (40) received in the first edge extension (20) by rotating the button head (40) so that the button head (40) is misaligned with respect the first dimension of the outer opening (22).
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
B65G 17/38 - Chains or like traction elements; Connections between traction elements and load-carriers
A conveyor belt including a plurality of link elements, and a pivot rod with a button head at one end. The button head is sized to pass through an outer opening and be received in a first edge extension when in a particular orientation. The pivot rod is retained with the button head received in the first edge extension by rotating the button head so that the button head is misaligned with respect to the first dimension of the outer opening. A method for assembling a conveyor belt is also provided.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
B65G 17/26 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface comprising a series of co-operating units, e.g. interconnected by pivots
B65G 17/38 - Chains or like traction elements; Connections between traction elements and load-carriers
A conveyor belt (10) including a plurality of link elements (12, 13) and a pivot rod (16) with a button head (40) at one end. The button head (40) is sized to pass through an outer opening (22) and be received in a first edge extension (20) when in a particular orientation. The pivot rod (16) is retained with the button head (40) received in the first edge extension (20) by rotating the button head (40) so that the button head (40) is misaligned with respect the first dimension of the outer opening (22).
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
B65G 17/38 - Chains or like traction elements; Connections between traction elements and load-carriers
A conveyor belt and method for assembling a conveyor belt, the conveyor belt including a plurality of link elements and a plurality of pivot rods. Each link element includes a plurality of intermeshing extensions and at least one edge extension at a peripheral edge thereof. The plurality of intermeshing extensions form receiving compartments adapted to receive intermeshing extensions of an adjacent link element, and include transverse rod openings. The plurality of pivot rods are received in the transverse rod openings of the plurality of intermeshing extensions thereby interlinking adjacent link elements together. The edge extensions include an entry aperture sized to allow insertion of a pivot rod, and a rod receiving compartment to retain an end of the pivot rod.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
B65G 17/08 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms the surface being formed by the traction element
99.
LINK FOR THE CONNECTION OF RODS OF A CONVEYOR BELT SPIRALLY WOUND AROUND A DRIVEN DRUM, CONVEYOR BELT AND CONVEYING SYSTEM WITH SUCH CONNECTIVE LINKS
The invention relates to a connective link (4) for a conveyor belt, which comprises legs (6) extending in a longitudinal direction from a lateral cross- member (7) at a closed first end (8) and to an open second end (9), and defining laterally aligned first apertures (10) on each of said legs (6) at said closed end (8) for reception of a rod (3), and laterally aligned second apertures (11) at said open end (9) for reception of a rod (3), wherein at least one leg (6) is extended in longitudinal direction over a distance from the second aperture (11). The invention further relates to a conveyor belt comprising said connective links.
B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriers; Endless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
B65G 21/18 - Supporting or protective framework or housings for endless load-carriers or traction elements of belt or chain conveyors for conveyors having endless load-carriers movable in curved paths in three-dimensionally curved paths
