An article of footwear that includes a sole structure and an upper and defines a widest section, a narrowest section, a toe end, a heel end, a lateral side, and a medial side. The sole structure includes a first midsole directly coupled to the upper that includes a lateral side depression and a medial side depression. The sole structure further includes a sole plate directly coupled to the first midsole, a second midsole directly coupled to the first midsole and the sole plate, and a third midsole directly coupled to the first midsole and the sole plate. A periphery of the third midsole defines a medial lip and a lateral lip. The lateral side depression of the first midsole receives the lateral lip of the third midsole, and the medial side depression of the first midsole receives the medial lip of the third midsole.
An article of footwear includes an upper having a base layer that includes a first layer and a second layer. The second layer is a series of cushioning elements that extend outward from the first layer. The upper also includes a top layer that is partially connected to a perimeter of the base layer such that a void is disposed between the base layer and the top layer, and at least one of the cushioning elements of the series of cushioning elements is located within the void defined between the base layer and the top layer.
A golf club head includes a body including a toe region, a heel region, and a medial region extending between the toe region and the heel region. A core bar is integrally formed with the body at the toe region and the heel region and extends within the medial region along a trailing end. Further, a slot has an upper edge formed along a lower edge of the core bar at the trailing end. A face insert is coupled to the body and an interior cavity is formed between the face insert and the core bar.
A63B 23/04 - Exercising apparatus specially adapted for particular parts of the body for limbs, i.e. upper or lower limbs, e.g. simultaneously for lower limbs
An article of footwear having a sole structure and an upper and defining a widest section, a narrowest section, a toe end, a heel end, a lateral side, and a medial side. The sole structure includes a top midsole directly coupled to the upper, a sole plate directly coupled to the top midsole, a front midsole directly coupled to the top midsole and the sole plate, a rear midsole directly coupled to the top midsole and the sole plate, and an outsole directly coupled to the front midsole and the rear midsole. The top midsole includes an upper side and an underside, and the upper side of the top midsole includes a lip around an outer edge of the upper side. Further, the underside of the top midsole includes a plurality of recesses, and the top midsole includes an aperture that extends from the upper side to the underside.
An article of footwear having an upper and a sole structure that defines a lateral side and a medial side, a forefoot region, a midfoot region and a heel region. The sole structure includes an outsole that defines a notch that extends toward a toe end of the sole structure. The sole structure further includes a first midsole member that defines an opening within the midfoot region that extends into the notch such that the outsole is disposed on the medial side and lateral side of the toe end of the opening. A second a midsole is positioned between the first midsole member and the upper, and a sole plate is disposed within the midfoot region. The second midsole member is visible though the opening from the bottom of the article of footwear and the second midsole member extends into an aperture in the sole plate.
A system to produce a textile component of an article includes a processor and memory configured to determine a strain value in a region of a textile component of a reference article of footwear based on images of the reference article of footwear of a camera in selective communication with the processor and memory, and to generate a strain map based on the strain value. The system includes an additive manufacturing device in selective communication with the processor and memory and configured to apply a reinforcement to a substrate that has a shape of an upper for a custom article of footwear to variably reinforce the textile component based on the strain map and to form the textile component of the custom article of footwear.
A golf club shaft consists of a grip and a 3D printed body. The 3D printed body defines an outer sidewall, and an axis that extends centrally through a top and bottom of the golf club shaft, with an inner surface of the 3D printed body defining a first side and a second side that is located opposite the first side. An uninterrupted volume extends between the first side and the second side along an entire length of the 3D printed body.
An article of footwear includes an upper attached to a sole structure. The sole structure includes a midsole having a foam material. The midsole defines a posterior segment opposite an anterior segment relative to an arch segment in a longitudinal direction. The sole structure includes a first fiber strand within the midsole and extending through at least two of the posterior segment, the anterior segment, and the arch segment. A density of the first fiber strand is between about 1.2 grams per cubic centimeter (g/cm3) and about 2.0 g/cm3.
B29C 64/188 - Processes of additive manufacturing involving additional operations performed on the added layers, e.g. smoothing, grinding or thickness control
A43B 13/12 - Soles with several layers of different materials
B29C 43/00 - Compression moulding, i.e. applying external pressure to flow the moulding materialApparatus therefor
B29C 64/165 - Processes of additive manufacturing using a combination of solid and fluid materials, e.g. a powder selectively bound by a liquid binder, catalyst, inhibitor or energy absorber
A golf club head includes a body defining an internal cavity. The body includes a crown portion, a sole portion, a skirt portion extending along a perimeter of an aft side of the body between the crown portion and the sole portion, and a hosel extending from a heel side of the body. The skirt portion includes a distalmost point along a toe side of the body. The hosel defines a hosel axis that intersects a ground plane at a ground intersection point. The crown portion includes a vertex point adjacent to the hosel that defines vertex height in a direction normal to the ground plane. The vertex height is less than 75% of a maximum height of the body, and a height of the distalmost point in a direction normal to the ground plane is less than 65% of the maximum height of the body.
A process of manufacturing a golf club component. The process includes spreading a layer of metal powder over a build plane defined over a build platform and bonding portions of the layer of metal powder. The golf club component comprises a support structure. The support structure includes a plurality of segments. The support structure defines a plane L1 that forms a build angle A1 with respect to the build plane, and a plane L2 that forms a build angle A2 with respect to the build plane. Each of the plane L1 and the plane L2 is formed by a portion of the plurality of segments that are aligned and orientated at the build angle A1 and the build angle A2, respectively, relative to the build plane. At least one of the build angle A1 or the build angle A2 is greater than or equal to 30 degrees.
B29C 64/153 - Processes of additive manufacturing using only solid materials using layers of powder being selectively joined, e.g. by selective laser sintering or melting
A crownplate for a golf club head includes a shell formed from a first plurality of pre-preg plies and a second plurality of pre-preg plies and defining a first thickness area and a second thickness area. The first plurality of pre-preg plies includes a resin material and a first plurality of fibers and the second plurality of pre-preg plies includes a resin material and a second plurality of fibers. The first plurality of pre-preg plies have a first tensile strength and a first amount of graphene, and the second plurality of pre-preg plies have a second tensile strength and a second amount of graphene. The second plurality of pre-preg plies define an outer periphery of the crownplate.
B29C 43/00 - Compression moulding, i.e. applying external pressure to flow the moulding materialApparatus therefor
B29C 70/34 - Shaping by lay-up, i.e. applying fibres, tape or broadsheet on a mould, former or coreShaping by spray-up, i.e. spraying of fibres on a mould, former or core and shaping or impregnating by compression
B29C 70/46 - Shaping or impregnating by compression for producing articles of definite length, i.e. discrete articles using matched moulds, e.g. for deforming sheet moulding compounds [SMC] or prepregs
B29K 63/00 - Use of epoxy resins as moulding material
B29K 105/08 - Condition, form or state of moulded material containing reinforcements, fillers or inserts of continuous length, e.g. cords, rovings, mats, fabrics, strands or yarns
A golf club head includes a body formed by an additive manufacturing process. The body defines a toe region, a heel region, and a medial region positioned between the toe region and the heel region. A front face extends across the toe region, medial region, and the heel region and is formed of a sintered material. The body further includes a topline along a top side and a sole along a bottom side, each extending in a heel-toe direction. A plurality of grooves are disposed on the front face. The golf club head defines an internal cavity at least partially enclosed by the front face and the body. The internal cavity extends between the topline and the sole. A plurality of voids are defined by a rear surface of the front face.
B29C 64/153 - Processes of additive manufacturing using only solid materials using layers of powder being selectively joined, e.g. by selective laser sintering or melting
A golf club system includes a golf club, a detection unit, and a smart tag. The golf club has a golf club head, a shaft, and a grip. The detection unit is standing on or raised above the ground plane. The smart tag is a computer-readable marking on the golf club. The smart tag is detected by the detection unit when the golf club is positioned within a detection zone associated with a sensor of the detection unit. The detection unit collects data associated with a user swinging the golf club for transmission to a computing device. The sensor defines the detection zone as a volume extending to an extent of a radius R about a reference axis that is perpendicular to the ground plane and extending vertically along the reference axis above the ground plane.
A63B 60/42 - Devices for measuring, verifying, correcting or customising the inherent characteristics of golf clubs, bats, rackets or the like, e.g. measuring the maximum torque a batting shaft can withstand
An article of footwear comprising an upper defining a forefoot region, a midfoot region, and a heel region of the article of footwear, and a sole structure coupled with the upper. The sole structure includes a midsole and an outsole coupled with a bottom surface of the midsole. A void structure is provided within the sole structure, which includes a plurality of voids defining channels that extend through an entire width of the sole structure. The void structure includes a plurality of first voids in the shape of a vertical lemniscate and a plurality of second voids in the shape of a horizontal lemniscate.
A process of manufacturing a golf club component includes the step of spreading a layer of powdered material over a build plane defined over a build platform. Another step includes bonding, using an energy source, portions of the layer of powdered material. A different step includes repeating the spreading and bonding until the golf club component is formed. The process further includes the step of extracting loose powdered material from the golf club component. The build plane is offset from a ground plane between about 5 degrees and about 160 degrees. The ground plane is defined as a horizontal plane parallel to the ground when the golf club component is at address, and the build plane is not a face angle of the golf club component.
B29C 64/153 - Processes of additive manufacturing using only solid materials using layers of powder being selectively joined, e.g. by selective laser sintering or melting
A golf club head includes a body including a toe region, a heel region, and a medial region extending between the toe region and the heel region, and a face insert that is coupled to the body. The face insert and the body combine to form a front face on a front side. A top edge of the face insert is disposed within a face insert cavity and located between a central plane CP and a topline of the body. The face insert extends about 60% or less of a body height defined between the topline and the sole.
An article of footwear includes an upper attached to a sole structure to define an interior cavity and a closure system. The sole structure includes a forefoot region, a midfoot region, and a heel region. The closure system includes a closure mechanism, a securing element and a cord that is operably engaged with the upper of the footwear and the closure mechanism. The closure mechanism is actuated to adjust the footwear from a loosened configuration to a tightened configuration. The securing element extends across the upper from a medial side to a lateral side. The securing element only partially covers a winding region formed by the cord proximate a tongue of the footwear. The securing element has a fixed end that is permanently fastened to the sole structure.
Clothing; footwear; headgear. Preparation of publicity documents, namely publication of
publicity materials and publicity leaflets; outdoor
advertising; banner advertising; advertising, marketing and
promotional consultancy, advisory and assistance services;
computerized business promotion namely on-line promotional
services; direct marketing; direct e-mail advertising
services; retail services in relation to the sale of
clothing, accessories, namely jewelry and watches; retails
services in relation to footwear, headgear, bags, sporting
equipment, sporting articles, cosmetics and glasses; online
retail services in relation to clothing, footwear, headwear,
bags, sporting goods and accessories, eyewear, watches;
marketing; advertising and marketing services provided by
means of social media; providing product information in the
field of social media; promotional and advertising services;
online advertising services; product marketing;
demonstration of goods.
Clothing; footwear; headgear. Preparation of publicity documents, namely publication of
publicity materials and publicity leaflets; outdoor
advertising; banner advertising; advertising, marketing and
promotional consultancy, advisory and assistance services;
computerized business promotion namely on-line promotional
services; direct marketing; direct e-mail advertising
services; retail services in relation to the sale of
clothing, accessories, namely jewelry and watches; retail
services in relation to footwear, headgear, bags, sporting
equipment, sporting articles, cosmetics and glasses; online
retail services in relation to clothing, footwear, headwear,
bags, sporting goods and accessories, eyewear, watches;
marketing; advertising and marketing services provided by
means of social media; providing product information in the
field of social media; promotional and advertising services;
online advertising services; product marketing;
demonstration of goods.
An article of footwear comprising an upper defining a forefoot region, a midfoot region, and a heel region of the article of footwear, and a sole structure coupled with the upper. The sole structure includes a midsole and an outsole coupled with a bottom surface of the midsole. A void structure is provided within the sole structure, which includes a plurality of voids defining channels that extend through an entire width of the sole structure. The void structure includes a plurality of first voids in the shape of a vertical lemniscate and a plurality of second voids in the shape of a horizontal lemniscate.
An article of footwear has a closure mechanism includes a head cap, a rotating spool that defines a first rotational axis and is received in the head cap, a collector spool that defines a second rotational axis and includes an upper portion and a lower portion, a shaft between the upper portion and the lower portion, and a securing element on the lower portion of the collector spool. The securing element includes a pivot joint formed from a stem that extends away from the lower flange. The cylindrical stem is configured to be attached to the shaft of the upper portion so that the upper portion is configured to rotate relative to the lower portion.
An article of footwear includes an upper attached to a sole structure, a forefoot region, a midfoot region, a heel region, a longitudinal axis, a plate, and a gap. The longitudinal axis intersects a toe end and a heel end. The plate includes a top plate and a bottom plate joined at a hinge. The top plate has a first anterior end disposed adjacent a toe end and a first posterior end disposed within the heel region. The bottom plate has a second anterior end disposed adjacent the toe end and a second posterior end disposed in the midfoot region. The gap is defined between the top plate and the bottom plate and extends from the hinge toward the first posterior end. The top plate includes a convex portion in each of the heel region and the forefoot region.
A component for a sole structure of an article of footwear that includes an upper and an insole includes an extrusion that comprises a substrate material and a deposition. The extrusion extends along a path that defines an extrusion array. The deposition includes a first helical portion defined by a first helix angle and a first helix axis.
B29C 64/188 - Processes of additive manufacturing involving additional operations performed on the added layers, e.g. smoothing, grinding or thickness control
A43B 13/12 - Soles with several layers of different materials
B29C 43/00 - Compression moulding, i.e. applying external pressure to flow the moulding materialApparatus therefor
B29C 64/165 - Processes of additive manufacturing using a combination of solid and fluid materials, e.g. a powder selectively bound by a liquid binder, catalyst, inhibitor or energy absorber
An augmented reality system includes an augmented reality device with a first sensor and a user interface having a display screen, a golf club that includes a second sensor, a golf ball with a third sensor, and an online platform in communication with the augmented reality device, the first sensor, the second sensor, and the third sensor. The online platform presents a virtual golf course within a virtual environment. The first sensor captures a first set of data, the second sensor captures a second set of data, and the third sensor captures a third set of data. The first set of data, the second set of data, and the third set of data are communicated to the online platform. A digital response is generated from the first set of data, second set of data, and third set of data within the virtual golf course.
A63F 13/573 - Simulating properties, behaviour or motion of objects in the game world, e.g. computing tyre load in a car race game using trajectories of game objects, e.g. of a golf ball according to the point of impact
A63F 13/65 - Generating or modifying game content before or while executing the game program, e.g. authoring tools specially adapted for game development or game-integrated level editor automatically by game devices or servers from real world data, e.g. measurement in live racing competition
A display system for an article of footwear includes a display device that has an optoelectronic display, a control module that is configured to communicate with the display device, and a power source. The display device is connected to a cable fastening system. The cable fastening system is configured to provide an electrical signal to the display device. The cable fastening system is configured to tighten the article of footwear.
A sole plate for a sole structure of an article of footwear, the sole plate including a forefoot region including a toe end at the distal end of the forefoot region, a midfoot region, and a heel region including a heel end at the distal end of the heel region. The sole plate further including a medial side, a lateral side, a widest section, and a narrowest section. The sole plate defines an outer edge, and the outer edge includes a first plurality of peaks and a first plurality of valleys. The first plurality of peaks and the first plurality of valleys are located on the lateral side of the forefoot region, and the first plurality of peaks and the first plurality of valleys are disposed between the widest section of the sole plate and the toe end of the sole plate.
An article of footwear having a sole structure and an upper, the sole structure comprising a widest section, a narrowest section, a toe end, a heel end, a lateral side, a medial side, a top midsole directly coupled to the upper, a sole plate directly coupled to the top midsole, a front midsole directly coupled to the top midsole and the sole plate between the toe end of the sole structure and the widest section of the sole structure, a rear midsole directly coupled to the top midsole and the sole plate between the heel end of the sole structure and the narrowest section of the sole structure, and an outsole directly coupled to the front midsole and the rear midsole. The front midsole is spaced forward from the rear midsole creating a void, and an underside of the sole plate is exposed in the void.
An article of footwear having a sole structure and an upper, the sole structure comprising a top midsole coupled to the upper, a sole plate coupled to the top midsole, a front midsole coupled to the top midsole and the sole plate, a rear midsole coupled to the top midsole and the sole plate, and an outsole coupled to the front midsole and the rear midsole. The front midsole is spaced forward from the rear midsole creating a cavity, and an underside of the sole plate is exposed in the cavity. The top midsole, the front midsole, and the rear midsole are made of a supercritical foam that includes an organic compound having an open-chain structure.
An article of footwear having an upper and a sole structure includes a top midsole coupled to the upper, a sole plate coupled to the top midsole, and a front midsole coupled to the top midsole. The sole plate is disposed between the toe end and the widest section of the sole structure. A rear midsole is coupled to the top midsole and the sole plate and disposed between the heel end and the narrowest section of the sole structure. An outsole is directly coupled to the front midsole and the rear midsole. A toe end of the outsole extends beyond a toe end of the front midsole, and the toe end of the front midsole extends beyond a toe end of the sole plate. The toe ends of the sole plate, the front midsole, and the outsole extend beyond a toe end of the top midsole.
A method of manufacturing an article of footwear includes forming a sole structure that uses an additive manufacturing system. The sole structure includes a conduit that extends within a region of the sole structure. The conduit includes an end that protrudes outwardly from a surface of the sole structure and a channel defined through the conduit. The method also includes connecting the end of the conduit to an injector and injecting a reinforcement material into the channel of the conduit to form a reinforcement member. The method further includes removing a portion of the end of the conduit.
A golf club including a golf club head formed of metal by an additive manufacturing process, the golf club head including a front side, a rear side, a bottom side, a top side, a toe side, and a heel side, a body that defines a toe region, a heel region, and a medial region, a first plane that extends orthogonal to a ground plane, a second plane that extends orthogonal to the ground plane, a front face, a topline, a sole, a plurality of laterally-extending grooves, a toe portion, a heel portion, a hosel, and a cavity that is enclosed by the front face and the body. The ground plane is a horizontal plane parallel to the ground when the golf club head is at address. The front face and the body are formed of sintered metal. The hosel defines a hosel cavity that is configured to receive a shaft.
B29C 64/153 - Processes of additive manufacturing using only solid materials using layers of powder being selectively joined, e.g. by selective laser sintering or melting
An article of footwear includes an upper and a sole structure coupled with the upper. The sole structure defines a forefoot region, a midfoot region that corresponds with a portion of the article of footwear that is configured to encase an arch of a foot, and a heel region that is proximate and adjoining the midfoot region. The footwear also includes a first foam material and a second foam material within the sole structure. The first foam material has a density that is different than a density of the second foam material. At least one of the first and second materials is directly attached to the upper. The footwear further includes a plurality of ground contacting regions and a heel support plate that extends along a portion of the upper in the heel region.
An article of footwear defines a lateral side, a medial side, a forefoot region, a midfoot region, and a heel region. The article of footwear includes an upper, a first cushioning member directly coupled to the upper in the heel region, a second cushioning member directly coupled to the upper in the forefoot region, and a plate. The plate is configured as a unitary plate that extends continuously from the forefoot region to the heel region. The plate is directly coupled to each of the upper, the first cushioning member, and the second cushioning member. The plate extends through a gap that is defined between the first cushioning member and the second cushioning member.
(1) Clothing, namely, sports and leisure suits, training suits, warm-up suits, all-weather suits, rainwear, pullovers, jerseys, jackets, sweatshirts, shorts, shirts, pants, T-shirts, polo-shirts, hooded tops, crop tops, skirts, socks, wristbands, athletic uniforms, blousons, turtlenecks, camisoles, sweaters, cardigans, coats, dresses, blouses, underwear, tank tops, trousers, tights, bathing suits, neckerchiefs, scarves, belts; footwear, namely, sports and leisure shoes; headwear, namely, berets, ear muffs, hats, caps, sun visors, toques, beanies, headbands. (1) Preparation of publicity documents, namely publication of publicity materials and publicity leaflets; outdoor advertising; banner advertising; advertising, marketing and promotional consultancy, advisory and assistance services; computerized business promotion namely on-line promotional services; direct marketing; direct e-mail advertising services; retail services featuring clothing, accessories, namely jewelry and watches; retail services featuring footwear, headgear, bags, sporting equipment, sporting articles, cosmetics and glasses; online retail services featuring clothing, footwear, headwear, bags, sporting goods and accessories, eyewear, watches; marketing; advertising and marketing services provided by means of social media; providing product information in the field of social media; promoting the sale of goods and services in the field of footwear, apparel, bags, cosmetics, sporting goods and related accessories through the distribution of printed material, digitally through social media, e-mail and websites, and promotional contests; online advertising services; product marketing; demonstration of goods.
(1) Clothing, namely, sports and leisure suits, training suits, warm-up suits, all-weather suits, rainwear, pullovers, jerseys, jackets, sweatshirts, shorts, shirts, pants, T-shirts, polo-shirts, hooded tops, crop tops, skirts, socks, wristbands, athletic uniforms, blousons, turtlenecks, camisoles, sweaters, cardigans, coats, dresses, blouses, underwear, tank tops, trousers, tights, bathing suits, neckerchiefs, scarves, belts; footwear, namely, sports and leisure shoes; headwear, namely, berets, ear muffs, hats, caps, sun visors, toques, beanies, headbands. (1) Preparation of publicity documents, namely publication of publicity materials and publicity leaflets; outdoor advertising; banner advertising; advertising, marketing and promotional consultancy, advisory and assistance services; computerized business promotion namely on-line promotional services; direct marketing; direct e-mail advertising services; retail services featuring clothing, accessories, namely jewelry and watches; retail services featuring footwear, headgear, bags, sporting equipment, sporting articles, cosmetics and glasses; online retail services featuring clothing, footwear, headwear, bags, sporting goods and accessories, eyewear, watches; marketing; advertising and marketing services provided by means of social media; providing product information in the field of social media; promoting the sale of goods and services in the field of footwear, apparel, bags, cosmetics, sporting goods and related accessories through the distribution of printed material, digitally through social media, e-mail and websites, and promotional contests. online advertising services; product marketing; demonstration of goods.
An article of footwear includes an upper and a sole assembly defining a heel region, a midfoot region, and a forefoot region. The sole assembly includes a first component having a plurality of protrusions extending from a first surface thereof, such that the plurality of protrusions extend laterally along the first component and are spaced apart in a heel-toe direction. The sole assembly includes a second component including a plurality of apertures extending into a second surface thereof. Each of the plurality of protrusions is arranged within a corresponding one of the plurality of apertures to mechanically couple the first component to the second component. The plurality of apertures includes a first aperture that defines a variable aperture width measured parallel to the heel to toe direction. The variable aperture width increases between the second surface and a blind end of the first aperture.
An article of footwear includes an upper and a sole structure having a midsole and an outsole. The upper is attached to the sole structure and defines an interior cavity. The midsole is arranged in a forefoot region, a midfoot region, and a heel region of the footwear. The midsole is an anisotropic foam structure having a density in a portion of the forefoot region that is different from a density in a portion of the heel region. The anisotropic foam structure is formed as a single, unitary component by a supercritical foaming process.
A sole structure that includes an outsole having an upper outsole and a lower outsole that is directly coupled with the upper outsole such that the outsole defines a front portion, a middle portion, and a rear portion. The sole structure further includes a front cushioning member that is disposed within a front spacing that is defined between the upper outsole and the lower outsole, a plurality of first ground engaging members that extend from a bottom surface of the upper outsole member, and a plurality of second ground engaging members that extend from a bottom surface of the lower outsole member. The upper outsole and the lower outsole are each configured to engage with a ground surface. The front spacing is provided in the front portion of the outsole.
A43B 13/26 - Soles made slip-preventing or wear-resisting, e.g. by impregnation or spreading a wear-resisting layer by use of insertions projecting beyond the sole surface
A sole structure for an article of footwear includes a first plate, a second plate and a third plate. The first plate has a first anterior end disposed adjacent a toe end of the sole structure and a first posterior end disposed within a heel region of the sole structure. The second plate has a second anterior end disposed adjacent the toe end and a second posterior end disposed in a midfoot region of the sole structure. The third plate has a third anterior end disposed adjacent the toe end and a third posterior end disposed in the midfoot region. A first cushion is arranged between the first plate and the second plate, and wherein the second plate and the third plate are coplanar in the forefoot region.
An article of footwear defines a lateral side, a medial side, a forefoot region, a midfoot region, and a heel region. The article of footwear includes an upper, a first cushioning member directly coupled to the upper in the heel region, a second cushioning member directly coupled to the upper in the forefoot region, and a plate. The plate is configured as a unitary plate that extends continuously from the forefoot region to the heel region. The plate is directly coupled to each of the upper, the first cushioning member, and the second cushioning member. The plate extends through a gap that is defined between the first cushioning member and the second cushioning member.
An article of footwear has a forefoot region, a heel region, a midfoot region, a lateral side, and a medial side and includes an upper and a sole structure coupled to the upper. The sole structure includes a frame coupled to the upper and defines a plurality of apertures along the lateral side and the medial side. The frame has a frame exterior surface and a frame interior surface, opposite the frame exterior surface, that defines a frame internal cavity, a lace received within the plurality of apertures and extends along the frame exterior surface to the frame interior surface in each of the forefoot region, the midfoot region, and the heel region, and a plurality of midsole members disposed within the frame internal cavity. When the lace is in a tightened configuration, the frame is pulled toward the upper to secure the frame to the sole structure.
41 - Education, entertainment, sporting and cultural services
Goods & Services
All-purpose athletic bags and drawstring pouches; All-purpose carrying bags; travelling bags; all-purpose sports bags; net bags for shopping; handbags; clutch bags; clutch purses; duffel bags; backpacks; school bags; shoulder bags; belt bags and hip bags; luggage trunks and travelling cases of synthetic material; wallets; purses; umbrellas Clothing, namely, sports and leisure suits, training suits, warm-up suits, all-weather suits, rainwear, pullovers, jerseys, jackets, sweatshirts, shorts, shirts, pants, T-shirts, polo-shirts, hooded tops, crop tops, skirts, socks, wristbands, athletic uniforms, blousons, turtlenecks, camisoles, sweaters, cardigans, coats, dresses, blouses, underwear, tank tops, trousers, tights, bathing suits, neckerchiefs, scarves, belts; footwear, namely, sports and leisure shoes; headwear, namely, berets, ear muffs, hats, caps, sun visors, toques, beanies, headbands Retail store services featuring clothing and clothing accessories, footwear, headgear, bags, sporting equipment, sporting articles, cosmetics, glasses; marketing services; advertising and marketing services provided by means of social media; Providing consumer product information via social media websites; promotional and advertising services; online advertising services; product marketing, namely, promoting the goods of others; demonstration of goods Entertainment services in the nature of presenting live musical performances; organization and conduction of concerts; Entertainment services in the nature of recording, production and post-production services in the field of music; production of music; organization of sports events
41 - Education, entertainment, sporting and cultural services
Goods & Services
All-purpose athletic bags and drawstring pouches; All-purpose carrying bags; travelling bags; all-purpose sports bags; net bags for shopping; handbags; clutch bags; clutch purses; duffel bags; backpacks; school bags; shoulder bags; belt bags and hip bags; luggage trunks and travelling cases of synthetic material; wallets; purses; umbrellas Clothing, namely, sports and leisure suits, training suits, warm-up suits, all-weather suits, rainwear, pullovers, jerseys, jackets, sweatshirts, shorts, shirts, pants, T-shirts, polo-shirts, hooded tops, crop tops, skirts, socks, wristbands, athletic uniforms, blousons, turtlenecks, camisoles, sweaters, cardigans, coats, dresses, blouses, underwear, tank tops, trousers, tights, bathing suits, neckerchiefs, scarves, belts; footwear, namely, sports and leisure shoes; headwear, namely, berets, ear muffs, hats, caps, sun visors, toques, beanies, headbands Retail store services featuring clothing and clothing accessories, footwear, headgear, bags, sporting equipment, sporting articles, cosmetics, glasses; marketing services; advertising and marketing services provided by means of social media; Providing consumer product information via social media websites; promotional and advertising services; online advertising services; product marketing, namely, promoting the goods of others; demonstration of goods Entertainment services in the nature of presenting live musical performances; organization and conduction of concerts; Entertainment services in the nature of recording, production and post-production services in the field of music; production of music; organization of sports events
An article of footwear includes an upper coupled with a sole structure that defines a forefoot region, a midfoot region, and a heel region. The sole structure includes an upper midsole cushioning member, a lower midsole cushioning member, an outsole coupled to a bottom surface of the lower midsole cushioning member, and a plate positioned between the upper midsole cushioning member and the lower midsole cushioning member. The plate includes a toe segment that extends through the forefoot region, the toe segment defining a first concave curved portion that extends downward from a distal end to a first inflection point disposed within the midfoot region. The plate further includes a middle segment defining a second concave curved portion that extends upward from the first inflection point and toward the heel region before transitioning to a convex curved portion at a second inflection point in the midfoot or heel region.
A method of manufacturing a golf club includes receiving user information and selecting at least one parameter of the golf club by a user that is selected from a plurality of parameters. Additional steps include generating a design model of the golf club based on user information or at least one parameter of the golf club in a design space, generating a 3D lattice environment, inlaying the lattice environment into the design model of the golf club, reorienting a first lattice array of the lattice environment according to the user information, adjusting, based on the user interface, at least a thickness, a shape, or a density of a lattice beam of the first lattice array, customizing the at least one parameter based on at least a swing characteristic or a location of center of gravity of the golf club, and printing using an additive manufacturing device.
A63B 60/02 - Ballast means for adjusting the centre of mass
A63B 60/42 - Devices for measuring, verifying, correcting or customising the inherent characteristics of golf clubs, bats, rackets or the like, e.g. measuring the maximum torque a batting shaft can withstand
A63B 71/06 - Indicating or scoring devices for games or players
An article of footwear including an upper that is attached to a sole, a longitudinal axis that extends between a rear end and a front end of the article of footwear, a midfoot region that is disposed between a forefoot region and a heel region, a heel component disposed adjacent the rear end within the heel region, a fastening system including a fastening mechanism that is operably engaged with a cord, and a panel. The heel component has a midsection that includes padding. The panel includes an edge that is curved, and the cord is laced through a plurality of eyelets arranged on the panel. The cord extends on a lateral side of the upper so that a first segment extends diagonally downward from a top section toward the sole before extending diagonally upwardly toward the top section, and the first segment crosses over a second segment of the cord.
A golf club head that includes a body that has a topline, a sole, and a front face. The front face defines a rear surface that extends along a plane and the body defines a center of gravity plane. The golf club head also includes a lattice structure formed on a portion of the body, layer by layer, via an additive manufacturing process. The portion of the body is bounded by the plane, the center of gravity plane, and an intersection between the plane and the center of gravity plane.
An article of footwear includes an upper and a sole structure coupled to the upper and configured to engage with a ground surface. The sole structure includes a cushioning member and a unitary plate. The unitary plate includes an upper plate and a lower plate that extends from the upper plate. The lower plate is coupled to the upper plate at each of a front coupling point and a rear coupling point, such that a front spacing is defined between the front coupling point and the rear coupling point.
A43B 13/26 - Soles made slip-preventing or wear-resisting, e.g. by impregnation or spreading a wear-resisting layer by use of insertions projecting beyond the sole surface
A golf club head includes a body having a toe region, a heel region, a sole weight bar extending between the toe region and the heel region, and a face insert that is coupled to the body and wraps about the sole weight bar. The golf club head defines a sole having a toe segment, a medial segment, and a heel segment, and the face insert at least partially defines the medial segment of the sole. A gap is disposed between the sole weight bar and the face insert. The gap extends entirely about an outer periphery of the sole weight bar and is disposed between the sole weight bar and each of a face portion of the face insert, a sole portion of the face insert, and a back portion of the medial segment of the sole.
A method including providing a first digital asset having properties, generating a first token representing ownership of the first digital asset, transferring the first token to a first digital wallet, performing a transaction, providing a second digital asset having properties, generating a second token representing ownership of the second digital asset, transferring the second token to the first digital wallet, and breeding the first token with the second token to create a third token including properties associated with a golf product. The transaction includes receiving information of the first digital wallet, confirming a presence of the first token in the first digital wallet, based on a property of the first token, providing a first benefit, and updating the first digital asset with a first data associated with the transaction. The third token is configured to be used to produce a physical product including the properties of the golf product.
G06Q 20/12 - Payment architectures specially adapted for electronic shopping systems
A63F 13/69 - Generating or modifying game content before or while executing the game program, e.g. authoring tools specially adapted for game development or game-integrated level editor by enabling or updating specific game elements, e.g. unlocking hidden features, items, levels or versions
An athletic bra includes a front panel, a rear panel, a first strap, a second strap, and an underband coupled to the front panel and the rear panel. The first strap and the second strap connect the front panel to the rear panel. The front panel includes an outer shell and an inner layer, and a first cup and a second cup are positioned within the front panel. At least one of the first cup and the second cup is coupled to at least one of the outer shell and the inner layer, such that the at least one of the first cup and the second cup is not removable.
B32B 5/02 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by structural features of a layer comprising fibres or filaments
B32B 5/18 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by features of a layer containing foamed or specifically porous material
B32B 5/24 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by the presence of two or more layers which comprise fibres, filaments, granules, or powder, or are foamed or specifically porous one layer being a fibrous or filamentary layer
B32B 7/12 - Interconnection of layers using interposed adhesives or interposed materials with bonding properties
A method for producing a golf club component includes the step of receiving a selection of at least one parameter from a user via a user interface, the at least one parameter being selected from a plurality of parameters. The method further includes the step of generating a design model of the golf club component based on the selected parameter, providing the design model of the golf club component to an additive manufacturing device, and forming the golf club component via the additive manufacturing device.
A sole structure includes a forefoot region, a heel region, and a midfoot region. The sole structure further includes a first cushioning member disposed in the forefoot region, the midfoot region, and the heel region, a second cushioning member disposed below the first cushioning member and in the forefoot region and the midfoot region, and a sole plate. The sole plate includes an upper flange and a lower flange connected at a point such that the upper flange is above the lower flange, the upper flange is between the first cushioning member and the second cushioning member, and the lower flange is below the second cushioning member. The sole structure further includes an outsole disposed along a bottom of the sole structure, below the lower flange. A point at which the upper and lower flanges connect is spaced from the second cushioning member, thereby forming a spacing.
A golf club includes a body defining an internal cavity and includes a toe side, a heel side, a top side, a bottom side, a front side, and a rear side. A first support structure is disposed within the internal cavity and includes a plurality of beams. A second support structure is disposed within an external cavity that is positioned on the rear side of the body and is visible from an exterior of the body. A first pocket and a second pocket are formed on the bottom side. The first pocket is at least partially defined by a first wall and the second pocket is at least partially defined by a second wall. A first aperture and a second aperture are in fluid communication with the internal cavity. The first aperture extends through the first wall and the second aperture extends through the second wall.
Systems and methods for a club head having a weighting system configured to selectively move a front weight vertically within the interior of the club head to raise the center of gravity position of the club head.
A process of manufacturing a golf club head. The process comprises the step of spreading a thin layer of metal powder over a build plane defined over a build platform. The process also comprises the step of selectively depositing droplets of a binding agent over the thin layer of metal powder in order to bond the metal powder. The process further comprises the step of sintering a green part body to form the golf club head. The golf club head comprises a lattice structure positioned within an internal cavity of the golf club head. The build plane is offset from a ground plane by between about 5 degrees and about 160 degrees. The ground plane defined as a horizontal plane parallel to the ground when the golf club head is at address. The build plane is not a face angle of the golf club head.
B29C 64/153 - Processes of additive manufacturing using only solid materials using layers of powder being selectively joined, e.g. by selective laser sintering or melting
An article of footwear includes an upper and a sole structure coupled to the upper. The sole structure defines a ground engaging surface and includes a cushion member and a rigid plate. The cushion member defines a bottom surface that forms a first portion of the ground engaging surface. The rigid plate includes a first segment positioned between the upper and the bottom surface of the cushion member, and a second segment that extends outward from the first segment. The second segment curves to extend along a lateral surface of the cushion member such that the second segment defines a first portion of an outermost lateral surface of the sole structure.
A43B 13/26 - Soles made slip-preventing or wear-resisting, e.g. by impregnation or spreading a wear-resisting layer by use of insertions projecting beyond the sole surface
98.
SYSTEMS AND METHODS FOR MANUFACTURING AN ARTICLE OF FOOTWEAR
A method of manufacturing an article of footwear includes forming an upper that includes a bottom portion, an external medial side, an external lateral side, and an internal cavity. The bottom portion extends underneath a user's foot. The method further includes inserting a last into the internal cavity of the upper, printing a framework onto the bottom portion, and removing the last from the internal cavity. The framework includes a plurality of segments extending along the bottom portion and between the external medial side and the external lateral side of the upper.
A method of fabricating a cork composite material is disclosed herein. The method includes providing a plurality of cork particles, adding a binder material to the cork particles to form a mixture of the cork particles and the binder material, transferring the mixture to a mold, applying energy to the mixture, cooling the mixture, and removing the cork composite material from the mold. Further, the energy includes electromagnetic radiation that fuses the cork particles with the binder material. Cooling the mixture solidifies the mixture, thereby forming a cork composite material.
