Abstract

A flexible dry fire protection sprinkler includes an inlet seal assembly sealing an inlet orifice, an inlet release unit to release the seal assembly, a flexible tube connected to the inlet release unit, a flexible linkage extending through the flexible tube, having an inlet end connected to the inlet release unit, an outlet biasing portion connected to an outlet end of the flexible tube and the flexible linkage, to displace the outlet end of the linkage upon activation, a sprinkler body connected to the outlet biasing portion, and an outlet seal assembly to seal an outlet orifice of the body until a predetermined temperature is reached. When reached, the outlet seal assembly releases from an outlet orifice of the body, and the outlet biasing portion displaces the linkage, causing the inlet end of the linkage to operate the inlet release unit, releasing the inlet seal assembly from the inlet orifice.

IPC Classes  ?

• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing
• A62C 31/28 - Accessories for delivery devices, e.g. supports
• A62C 33/04 - Supports or clamps for fire hoses
• A62C 35/58 - Pipe-line systems
• A62C 37/14 - Releasing means, e.g. electrically released heat-sensitive with frangible vessels
• A62C 37/42 - Control of fire-fighting equipment an actuating signal being generated by a sensor separate from an outlet device by both sensor and actuator, e.g. valve, being in the danger zone with mechanical connection between sensor and actuator, e.g. rods, levers

Abstract

A method of protecting an occupancy, using a pendent fire protection sprinkler arrangement to be mounted in a ceiling, includes providing a plurality of pendent fire protection sprinklers, each having a sprinkler body having an inlet and an outlet defining a fluid passage and a sprinkler axis, and threads for connection to system piping of the occupancy. A pair of frame arms projects downwardly from the outlet and meet to form a junction. A plug seals a fluid passage, and a thermally responsive element between the plug and the junction retains the plug in the fluid passage. A deflector is mounted to the junction and includes a planar central portion extending outwardly from the sprinkler axis along a plane perpendicular to the sprinkler axis and first, second, third, and fourth angled portions bent away from the frame arms in the outlet direction from the plane of the planar central portion.

IPC Classes  ?

• A62C 31/02 - Nozzles specially adapted for fire-extinguishing
• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive
• B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets

Abstract

A fire protection sprinkler system includes a horizontal barrier that covers two adjacent racks, and the vertical flue space between the racks. The horizontal barrier is provided at a predetermined height, and has a width that is at least equal to a width of the rack, and a depth that is at least equal to a sum of a depth of the rack, a depth of the other rack, and a depth of the vertical flue space. In addition, the horizontal barrier is a sheet having one or more apertures. The system also includes a rack level fire protection sprinkler connected to a fluid supply conduit, and being disposed in the vertical flue space below the horizontal barrier. The rack level sprinkler has a K-factor of 11.2 gpm/(psi)1/2 or greater, and is vertically spaced from commodities stored on the rack and the other rack covered by the horizontal barrier.

IPC Classes  ?

• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 3/06 - Fire prevention, containment or extinguishing specially adapted for particular objects or places of highly inflammable material, e.g. light metals, petroleum products
• A62C 35/58 - Pipe-line systems
• A62C 35/68 - Details, e.g. of pipes or valve systems

Abstract

A cover plate is configured to be releasably connected to a fire protection sprinkler to conceal the fire protection sprinkler. The cover plate includes a first layer of metal on a first side of the cover plate that faces the concealed fire protection sprinkler, and a second layer of metal on a second side of the cover plate, the second side being opposite to the first side. The second layer of metal is bonded to the first layer and is more resistant to corrosion than is the first layer. In addition, the first layer is more thermally conductive than is the second layer. The fire protection sprinkler is configured to activate upon activation of a thermally responsive element. The thermally responsive element is a bulb or a soldered link.

IPC Classes  ?

• B32B 15/01 - Layered products essentially comprising metal all layers being exclusively metallic
• A62C 37/09 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers telescopic or adjustable
• A62C 37/12 - Releasing means, e.g. electrically released heat-sensitive with fusible links

Abstract

A fire protection nozzle includes a body having inlet and outlet orifices defining a body axis, and a flow passage for a fluid that flows through the body in an output direction, frame arms having proximal ends connected to the outlet orifice and distal ends, the frame arms defining a frame arm plane, a junction formed by the frame arms distal ends at a distance from the outlet orifice, the junction including a central bore and an outer wall, and body deflectors extending from each of the frame arms in the frame arm plane at an angle relative to the body axis. Each of the body deflectors has an inner planar surface facing the junction. The nozzle also includes a planar member deflector to be mounted to the nozzle body. The deflector includes a planar member having a plurality of slots on a periphery that define a plurality of tines.

IPC Classes  ?

• A62C 37/12 - Releasing means, e.g. electrically released heat-sensitive with fusible links
• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive
• B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets

Abstract

A fire protection nozzle includes (A) a body having a flow passage for a fluid that flows through the body in an output direction, frame arms having proximal ends connected to an outlet orifice and distal ends, the frame arms defining a frame arm plane, and a junction formed by the distal ends of the frame arms at a distance from the outlet orifice, the junction including a central bore and an outer wall, and (B) a planar member deflector configured to be mounted to the body. The deflector includes a planar member having a plurality of slots on a periphery of the planar member that define a plurality of tines. The plurality of slots include at least first slots, second slots, third slots, and fourth slots.

IPC Classes  ?

• A62C 37/12 - Releasing means, e.g. electrically released heat-sensitive with fusible links
• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive
• B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets

Abstract

A dry sprinkler has a casing tube having an inlet orifice and an outlet orifice. When the sprinkler is in a non-actuated state, an inlet seal assembly operatively seals the inlet orifice and an outlet seat assembly operatively seals the outlet orifice. A translating member extends through the casing tube between an inlet and an outlet. The translating member axially translates from a first position, in which the translating member retains the inlet seal assembly in a sealed state, to a second position, in which the translating member releases the inlet seal assembly, toward the outlet when the outlet seat assembly is released. The sprinkler has a nominal K-factor greater than 17 gpm/(psi)1/2. A difference between a cross-sectional area of the casing tube and a cross-sectional area bounded by an outer perimeter of the translating member is more than 30% of the cross-sectional area of the casing tube.

IPC Classes  ?

• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 37/12 - Releasing means, e.g. electrically released heat-sensitive with fusible links

Abstract

A fire protection sprinkler system and related method for a storage area for one or more commodities or high energy commodities, the storage area having one or more racks that each includes one or more bays. The fire protection sprinkler system includes a piping network supplied by a source of fire protection fluid. The fire protection system includes a plurality of horizontal sidewall sprinklers. Each of the plurality of horizontal sidewall sprinklers has a K- factor of 11.2 gpm/(psi)1/2 or greater and is positioned horizontally at a perimeter of the racks to direct the fire protection fluid into the bays. Each of the plurality of horizontal sidewall sprinklers includes a deflector that distributes the fire protection fluid to a coverage area. The fire protection sprinkler system can also include vertical sidewall sprinklers positioned vertically and include a deflector that directs the fire protection fluid horizontally into the bays.

IPC Classes  ?

• A62C 3/06 - Fire prevention, containment or extinguishing specially adapted for particular objects or places of highly inflammable material, e.g. light metals, petroleum products
• A62C 3/02 - Fire prevention, containment or extinguishing specially adapted for particular objects or places for area conflagrations, e.g. forest fires, subterranean fires
• A62C 37/12 - Releasing means, e.g. electrically released heat-sensitive with fusible links
• A62C 35/58 - Pipe-line systems
• B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets

Abstract

A ceiling-only fire protection sprinkler system for a storage area having a storage height up to forty-three feet (thirteen and one tenth meters) and a ceiling height exceeding forty-five feet (thirteen and seven tenths meters). The storage area includes floor storage or rack storage that has aisle widths less than six feet (one and eight tenths meters) and transverse flue spaces less than six inches (one hundred fifty millimeters). The system includes fire suppression sprinklers that each includes a deflector positioned at a height that is at least three feet (nine tenths meters) greater than the storage height and at least one foot (three tenths meters) below the ceiling. Activated sprinklers have a coverage area greater than sixty-four square feet (five and nine tenths square meters) and up to one hundred square feet (nine and three tenths square meters) per each activated sprinkler.

IPC Classes  ?

• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places

Abstract

A ceiling-only fire protection sprinkler system for a storage area having a storage height up to forty -three feet (thirteen and one tenth meters) and a ceiling height exceeding forty -five feet (thirteen and seven tenths meters). The storage area includes floor storage or rack storage that has aisle widths less than six feet (one and eight tenths meters) and transverse flue spaces less than six inches (one hundred fifty millimeters). The system includes fire suppression sprinklers that each includes a deflector positioned at a height that is at least three feet (nine tenths meters) greater than the storage height and at least one foot (three tenths meters) below the ceiling. Activated sprinklers have a coverage area greater than sixty -four square feet (five and nine tenths square meters) and up to one hundred square feet (nine and three tenths square meters) per each activated sprinkler.

IPC Classes  ?

• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 35/60 - Pipe-line systems wet, i.e. containing extinguishing material even when not in use
• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive

Abstract

1/2 or greater, and is vertically spaced from commodities stored on the rack and the other rack covered by the horizontal barrier.

IPC Classes  ?

• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 35/58 - Pipe-line systems
• A62C 3/06 - Fire prevention, containment or extinguishing specially adapted for particular objects or places of highly inflammable material, e.g. light metals, petroleum products

Abstract

A sprinkler guard includes at least one plate centered relative to a central axis of the sprinkler guard. A plurality of legs includes first and second legs that are attached to one plate, and third and fourth legs that are attached to another plate. A circular ring is attached to lower ends of the first to fourth legs, a center of the circular ring coinciding with the central axis, and the first to fourth legs being spaced apart about the circumference of the circular ring. First and second arms are attached to the first and second legs, respectively. In addition, a cross bar can be attached to the circular ring and extend across a diameter of the circular ring.

IPC Classes  ?

• B05B 15/16 - Arrangements for preventing or controlling structural damage to spraying apparatus or its outlets, e.g. for breaking at desired placesArrangements for handling or replacing damaged parts for preventing non-intended contact between spray heads or nozzles and foreign bodies, e.g. nozzle guards
• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing

Abstract

A flexible dry sprinkler has an inlet having an inlet orifice, an outlet, a flexible tube having a first end attached to the inlet and a second end attached to the outlet, an inlet seal for sealing the inlet orifice, whereby, when the inlet seal releases, fluid is permitted to flow from the inlet orifice to the outlet through the flexible tube, and a yoke positioned in the inlet, the yoke having a plurality of spaced-apart legs that permit the fluid to flow passed the yoke toward the outlet.

IPC Classes  ?

• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 35/58 - Pipe-line systems
• A62C 31/28 - Accessories for delivery devices, e.g. supports
• A62C 33/04 - Supports or clamps for fire hoses
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing
• A62C 37/14 - Releasing means, e.g. electrically released heat-sensitive with frangible vessels
• A62C 37/42 - Control of fire-fighting equipment an actuating signal being generated by a sensor separate from an outlet device by both sensor and actuator, e.g. valve, being in the danger zone with mechanical connection between sensor and actuator, e.g. rods, levers

Abstract

1/2 or greater, and is vertically spaced from commodities stored on the rack and the other rack covered by the horizontal barrier.

IPC Classes  ?

• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 35/58 - Pipe-line systems
• A62C 3/06 - Fire prevention, containment or extinguishing specially adapted for particular objects or places of highly inflammable material, e.g. light metals, petroleum products

Abstract

A fire protection nozzle includes a body having two frame arms having proximal ends connected to an outlet of the body, and distal ends, the two frame arms defining a frame arm plane, and a junction formed by the distal ends of the frame arms, the junction including a central bore and an outer wall. A deflector is mounted to the body, and includes a planar member having a mounting hole in a center of the planar member to receive the outer wall of the junction, and a plurality of slots on a periphery of the planar member. The plurality of slots includes first slots, second slots, third slots, and fourth slots.

IPC Classes  ?

• A62C 37/12 - Releasing means, e.g. electrically released heat-sensitive with fusible links
• B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets
• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive

Abstract

A sprinkler with a push-in connection includes a sprinkler frame, an operating element, and a sealing cap. The sprinkler also includes one or more sealing gaskets and a retainer. Each such sealing gasket is located at least partially within a groove in the sprinkler frame. The retainer is also at least partially located within a groove in the sprinkler frame. The retainer connects to an internal bore of an outlet of a fluid supply conduit when the sprinkler is installed in the outlet. The one or more gaskets seal against the internal bore of the outlet when the sprinkler is installed in the outlet. The retainer is a spring mechanism so that the diameter of the retainer is reduced when the sprinkler is inserted into the internal bore of the outlet, and the retainer maintains pressure against the outlet internal bore.

IPC Classes  ?

• F16L 37/133 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members using flexible hooks
• F16L 37/138 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members using an axially movable sleeve
• E03C 1/02 - Plumbing installations for fresh water
• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers

Abstract

A cover plate is configured to be releasably connected to a concealed fire protection sprinkler to conceal the fire protection sprinkler. The cover plate includes a first layer of metal on a first side of the cover plate that faces the concealed fire protection sprinkler, and a second layer of metal on a second side of the cover plate, the second side being opposite to the first side. The second layer of metal is more resistant to corrosion than the first layer, and is bonded to the first layer. In addition, the first layer is more thermally conductive than the second layer.

IPC Classes  ?

• A62C 37/09 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers telescopic or adjustable
• B32B 15/01 - Layered products essentially comprising metal all layers being exclusively metallic
• A62C 37/12 - Releasing means, e.g. electrically released heat-sensitive with fusible links

Abstract

A fire protection sprinkler with a push-in connection includes a sprinkler body having an input orifice for receiving fluid and an output orifice for outputting the fluid, the body having a push-in connection at the input end and a base portion. The push-in connection is adapted to be connected to a pipe fitting by insertion and has a plurality of recesses, a first recess having a first gasket, a second recess having a second gasket, and a third recess having a retaining clip. A frangible element is held in place by a set screw and a stopper. The frangible element is designed to fail at a predetermined temperature to release the stopper. A deflector is positioned on the base portion and configured to direct the output fluid toward the output end, upon activation of the sprinkler by failure of the frangible element at the predetermined temperature.

IPC Classes  ?

• F16L 37/133 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members using flexible hooks
• E03C 1/02 - Plumbing installations for fresh water
• F16L 37/138 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members using an axially movable sleeve

Abstract

A dry sprinkler includes a flexible tube section that maintains a pressurized fluid, such as a liquid antifreeze solution, between a first end and a second end. A first seal prevents fluid from a supply line from entering the flexible tube section. The first seal is maintained in a sealed position by a pressure of the pressurized fluid. A sprinkler head is coupled to the second end of the flexible tube section, and includes a frame, an output orifice, a deflector, a second seal that seals the output orifice, and a thermally responsive element configured to maintain the second seal in a sealed position when the thermally responsive element is in a non-responsive state. A differential pressure controller maintains a ratio between the pressure of the pressurized fluid in the flexible tube section and a pressure of a supply fluid in the supply line to at least a certain ratio.

IPC Classes  ?

• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive
• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 37/14 - Releasing means, e.g. electrically released heat-sensitive with frangible vessels
• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 35/60 - Pipe-line systems wet, i.e. containing extinguishing material even when not in use

Goods & Services

Fire extinguishing apparatus; sprinkler systems for fire protection; components for the foregoing goods, including sprinklers, valves, sprinkler connections, and hoses; accessories for the foregoing goods; software for the foregoing goods.

Abstract

A sprinkler guard includes at least one plate centered relative to a central axis of the sprinkler guard. A plurality of legs includes first and second legs that are attached to one plate, and third and fourth legs that are attached to another plate. A circular ring is attached to lower ends of the first to fourth legs, a center of the circular ring coinciding with the central axis, and the first to fourth legs being spaced apart about the circumference of the circular ring. First and second arms are attached to the first and second legs, respectively. In addition, a cross bar can be attached to the circular ring and extend across a diameter of the circular ring.

IPC Classes  ?

• B05B 15/16 - Arrangements for preventing or controlling structural damage to spraying apparatus or its outlets, e.g. for breaking at desired placesArrangements for handling or replacing damaged parts for preventing non-intended contact between spray heads or nozzles and foreign bodies, e.g. nozzle guards
• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing

Abstract

A fire protection nozzle includes a body having two frame arms having proximal ends connected to an outlet of the body, and distal ends, the two frame arms defining a frame arm plane, and a junction formed by the distal ends of the frame arms, the junction including a central bore and an outer wall. A deflector is mounted to the body, and includes a planar member having a mounting hole in a center of the planar member to receive the outer wall of the junction, and a plurality of slots on a periphery of the planar member. The plurality of slots includes first slots, second slots, third slots, and fourth slots.

IPC Classes  ?

• A62C 37/12 - Releasing means, e.g. electrically released heat-sensitive with fusible links
• B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets
• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive

Abstract

A dry fire protection sprinkler has an inlet seal assembly to seal an inlet orifice. A spring seal compresses in response to a load. An inlet release unit releases the inlet seal assembly. A flexible tube has an inlet end connected to the inlet release unit. A flexible linkage extends through the flexible tube, and has an inlet end connected to the inlet release. An outlet biasing portion is connected to an outlet end of the tube and an outlet end of the linkage, which displaces upon activation of the sprinkler. A sprinkler body is connected to the outlet biasing portion, with an outlet seal assembly to seal its outlet orifice. When ambient reaches a predetermined temperature, the outlet seal assembly releases from the outlet orifice, and the outlet biasing portion displaces the linkage, causing the inlet of the linkage to operate the inlet release unit, releasing the inlet seal.

IPC Classes  ?

• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 35/58 - Pipe-line systems
• A62C 31/28 - Accessories for delivery devices, e.g. supports
• A62C 33/04 - Supports or clamps for fire hoses
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing
• A62C 37/14 - Releasing means, e.g. electrically released heat-sensitive with frangible vessels
• A62C 37/42 - Control of fire-fighting equipment an actuating signal being generated by a sensor separate from an outlet device by both sensor and actuator, e.g. valve, being in the danger zone with mechanical connection between sensor and actuator, e.g. rods, levers

Abstract

A sprinkler with a push-in connection includes a sprinkler frame, an operating element, and a sealing cap. The sprinkler also includes one or more sealing gaskets and a retainer. Each such sealing gasket is located at least partially within a groove in the sprinkler frame. The retainer is also at least partially located within a groove in the sprinkler frame. The retainer connects to the internal bore of a welded outlet or a mechanical outlet when the sprinkler is installed in the outlet. The one or more gaskets seal against the internal bore of a welded outlet or a mechanical outlet when the sprinkler is installed in the outlet. The retainer is a spring mechanism so that the diameter of the retainer is reduced when the sprinkler is inserted into the internal bore of the outlet, and the retainer maintains pressure against the outlet internal bore.

IPC Classes  ?

• F16L 37/133 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members using flexible hooks
• F16L 37/138 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members using an axially movable sleeve
• E03C 1/02 - Plumbing installations for fresh water
• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers

Goods & Services

(1) Fire extinguishing apparatus; sprinkler systems for fire protection; components for the foregoing goods, including sprinklers, valves, sprinkler connections, and hoses; accessories for the foregoing goods; software for the foregoing goods

Goods & Services

(1) Fire extinguishing apparatus; sprinkler systems for fire protection; components for the foregoing goods, including sprinklers, valves, sprinkler connections, and hoses; accessories for the foregoing goods

Goods & Services

(1) Fire extinguishing apparatus; sprinkler systems for fire protection; components for the foregoing goods, including sprinklers, valves, sprinkler connections, and hoses; accessories for the foregoing goods; software for the foregoing goods

Goods & Services

Fire extinguishing apparatus; sprinkler systems for fire protection; components for the foregoing goods, including sprinklers, valves, sprinkler connections, and hoses; accessories for the foregoing goods; software for the foregoing goods.

Goods & Services

Fire extinguishing apparatus; sprinkler systems for fire protection; components for the foregoing goods, including sprinklers, valves, sprinkler connections, and hoses; accessories for the foregoing goods.

Goods & Services

Fire extinguishing apparatus; sprinkler systems for fire protection; component replacement parts of fire extinguishing apparatus and sprinkler systems for fire protection, namely, sprinklers, valves, sprinkler connections, and hoses; accessories specially adapted for fire extinguishing apparatus and sprinkler systems for fire protection, namely, brackets, adapters, and fire sprinkler hose fittings

Goods & Services

Fire extinguishing apparatus; sprinkler systems for fire protection; component replacement parts of fire extinguishing apparatus and sprinkler systems for fire protection, namely, sprinklers, valves, sprinkler connections, and hoses; accessories specially adapted for fire extinguishing apparatus and sprinkler systems for fire protection, namely, brackets, adapters, and fire sprinkler hose fittings

Goods & Services

Fire extinguishing apparatus; component replacement parts of sprinkler systems for fire protection, namely, sprinkler connections and hoses; accessories specially adapted for fire extinguishing apparatus, namely, brackets, adapters, and fire sprinkler hose fittings

Abstract

1/2 or greater, and are vertically spaced from commodities stored on the racks. Each horizontal barrier covers one rack level sprinkler, of the at least two rack level sprinklers.

IPC Classes  ?

• A62C 3/06 - Fire prevention, containment or extinguishing specially adapted for particular objects or places of highly inflammable material, e.g. light metals, petroleum products
• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 35/58 - Pipe-line systems
• A62C 35/68 - Details, e.g. of pipes or valve systems

Abstract

A sprinkler guard includes two or more plates centered relative to a central axis of the sprinkler guard. A plurality of legs includes first and second legs that are attached to one plate, and third and fourth legs that are attached to another plate. A circular ring is attached to lower ends of the first to fourth legs, a center of the circular ring coinciding with the central axis, and the first to fourth legs being spaced apart about the circumference of the circular ring. First and second swing arms are rotatably attached to the first and second legs, respectively, and are configured to be snap fit into indents on the third and fourth legs, respectively. In addition, a cross bar is attached to the circular ring and extends across a diameter of the circular ring.

IPC Classes  ?

• B05B 15/16 - Arrangements for preventing or controlling structural damage to spraying apparatus or its outlets, e.g. for breaking at desired placesArrangements for handling or replacing damaged parts for preventing non-intended contact between spray heads or nozzles and foreign bodies, e.g. nozzle guards
• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing

Abstract

1/2 or greater, and is vertically spaced from commodities stored on the rack and the other rack covered by the horizontal barrier.

IPC Classes  ?

• A62C 3/06 - Fire prevention, containment or extinguishing specially adapted for particular objects or places of highly inflammable material, e.g. light metals, petroleum products
• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 35/58 - Pipe-line systems
• A62C 35/68 - Details, e.g. of pipes or valve systems

Abstract

A flexible dry sprinkler includes an inlet, an inlet seal assembly having a spring seal that compresses in response to a longitudinal load, and an inlet release unit. A flexible tube has an inlet end and an outlet end, and a flexible linkage extends through the flexible tube, and is connected to the inlet release unit. An outlet release unit is connected to the outlet end of the flexible tube and to an outlet end of the flexible linkage, and displaces the outlet end of the flexible linkage upon activation of the flexible dry fire protection sprinkler. A sprinkler body is connected to the outlet release unit, and has an outlet orifice sealed by an outlet seal assembly until ambient temperature reaches a predetermined temperature. When the ambient temperature reaches the predetermined temperature, translation of the flexible linkage in an outlet direction causes release of the inlet seal assembly.

IPC Classes  ?

• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 35/58 - Pipe-line systems
• A62C 31/28 - Accessories for delivery devices, e.g. supports
• A62C 33/04 - Supports or clamps for fire hoses
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing
• A62C 37/14 - Releasing means, e.g. electrically released heat-sensitive with frangible vessels
• A62C 37/42 - Control of fire-fighting equipment an actuating signal being generated by a sensor separate from an outlet device by both sensor and actuator, e.g. valve, being in the danger zone with mechanical connection between sensor and actuator, e.g. rods, levers

Abstract

1/2.

IPC Classes  ?

• A62C 37/12 - Releasing means, e.g. electrically released heat-sensitive with fusible links
• B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets
• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive

Goods & Services

Sprinkler heads for fire sprinklers; Sprinkler systems for fire protection; Fire sprinklers

Abstract

A support bracket for use in installing a sprinkler fitting for a fire protection sprinkler in a building. The support bracket includes a support beam and a center bracket. The center bracket has a body that defines an opening to receive a sprinkler fitting, and a closure assembly, including a closure member having a first end rotatably connected to the body, and a second end having a handle. The closure assembly is movable between an open position and a closed position. When in the closed position, the closure assembly presses the sprinkler fitting against one of the body and the support beam, thereby urging the center bracket against the support beam to maintain the center bracket stationary relative to the support beam. In addition, the closure assembly includes a lock that engages with the closure assembly when the closure member moves from the open position to the closed position, and that prevents the closure member from returning from the closed position to the open position.

IPC Classes  ?

• F16L 3/00 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets
• A62C 35/68 - Details, e.g. of pipes or valve systems
• B05B 15/62 - Arrangements for supporting spraying apparatus, e.g. suction cups
• F16L 3/10 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets substantially surrounding the pipe, cable or protective tubing divided, i.e. with two members engaging the pipe, cable or protective tubing
• F16L 3/24 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets with special member for attachment to profiled girders
• B05B 15/63 - Handgrips

Abstract

To install a sprinkler fitting for a fire protection sprinkler in a building, a support bracket includes a support beam, end brackets, and center bracket. The center bracket includes a body having an upper portion and a lower portion, each having an arcuate slot defining an opening to receive a sprinkler fitting, and a closure assembly having a first pin and a closure member having a first end rotatably mounted to the body, between the upper portion and the lower portion, by the first pin, and a second end that includes a handle. When the closure member is in a closed position, and the sprinkler fitting is received in the opening, the closure assembly presses the sprinkler fitting against at least one of the body and the support beam, and urges the center bracket against the support beam to maintain the center bracket stationary relative to the support beam.

IPC Classes  ?

• F16L 3/00 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets
• A62C 35/68 - Details, e.g. of pipes or valve systems
• B05B 15/63 - Handgrips
• F16L 3/10 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets substantially surrounding the pipe, cable or protective tubing divided, i.e. with two members engaging the pipe, cable or protective tubing
• F16L 3/24 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets with special member for attachment to profiled girders
• B05B 15/62 - Arrangements for supporting spraying apparatus, e.g. suction cups

Abstract

A pressure maintenance device is connected to a fire protection sprinkler system having downstream piping that is exposed to freezing temperatures, and supplies a pressurized fluid to the downstream piping when the sprinkler system is in an inactivated state. When an outlet pressure sensor near an outlet of the pressure maintenance device detects that a pressure of the pressurized fluid downstream of an outlet regulator falls below a first predetermined pressure, the pressure maintenance device supplies the pressurized fluid in a primary supply mode or a secondary supply mode. The pressure maintenance device automatically switches from the primary supply mode to the secondary supply mode if a supply pressure sensor detects that a pressure of the pressurized fluid downstream of a first pressurized fluid valve, and upstream of the outlet pressure regulator, falls below a second predetermined pressure.

IPC Classes  ?

• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 35/64 - Pipe-line systems pressurised
• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places

Abstract

A pendent fire protection sprinkler includes a sprinkler body having an inlet and an outlet that define a fluid passage and a sprinkler axis, a pair of frame arms that form a junction, a plug that seals the fluid passage, and a thermally responsive element provided between the plug and the junction, and configured to maintain the plug in the fluid passage prior to actuation of the sprinkler. A deflector, mounted to the junction, includes an annular, planar central portion extending along a plane that is perpendicular to the sprinkler axis, as well as a first angled portion, a second angled portion, a third angled portion, and a fourth angled portion, each angled portion extending outwardly from the planar central portion. In addition, each of the first to fourth angled portions is bent away from the frame arms in the outlet direction from the plane of the planar central portion.

IPC Classes  ?

• B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets
• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing

Abstract

1/2. In addition, a difference between a cross-sectional area of the casing tube and a cross-sectional area bounded by an outer perimeter of the translating member is more than 30% of the cross-sectional area of the casing tube.

IPC Classes  ?

• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 37/12 - Releasing means, e.g. electrically released heat-sensitive with fusible links

Abstract

A flexible dry sprinkler includes an inlet, an inlet seal assembly having a spring seal that compresses in response to a longitudinal load, and an inlet release unit. A flexible tube has an inlet end and an outlet end, and a flexible linkage extends through the flexible tube, and is connected to the inlet release unit. An outlet release unit is connected to the outlet end of the flexible tube and to an outlet end of the flexible linkage, and displaces the outlet end of the flexible linkage upon activation of the flexible dry fire protection sprinkler. A sprinkler body is connected to the outlet release unit, and has an outlet orifice sealed by an outlet seal assembly until ambient temperature reaches a predetermined temperature. When the ambient temperature reaches the predetermined temperature, translation of the flexible linkage in an outlet direction causes release of the inlet seal assembly.

IPC Classes  ?

• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 35/58 - Pipe-line systems
• A62C 31/28 - Accessories for delivery devices, e.g. supports
• A62C 33/04 - Supports or clamps for fire hoses
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing
• A62C 37/14 - Releasing means, e.g. electrically released heat-sensitive with frangible vessels
• A62C 37/42 - Control of fire-fighting equipment an actuating signal being generated by a sensor separate from an outlet device by both sensor and actuator, e.g. valve, being in the danger zone with mechanical connection between sensor and actuator, e.g. rods, levers

Abstract

A flexible dry sprinkler includes an inlet, an inlet seal assembly, and an inlet release unit. A flexible tube has an inlet end and an outlet end, and a flexible linkage extends through the flexible tube, and is connected to the inlet release unit. An outlet release unit is connected to the outlet end of the flexible tube and to an outlet end of the flexible linkage, and displaces the outlet end of the flexible linkage upon activation of the flexible dry fire protection sprinkler. A sprinkler body is connected to the outlet release unit, and has an outlet orifice sealed by an outlet seal assembly until ambient temperature reaches a predetermined temperature. When the ambient temperature reaches the predetermined temperature, displacement of the flexible linkage in an outlet direction causes release of the inlet seal assembly.

IPC Classes  ?

• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 35/58 - Pipe-line systems
• A62C 31/28 - Accessories for delivery devices, e.g. supports
• A62C 33/04 - Supports or clamps for fire hoses
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing
• A62C 37/14 - Releasing means, e.g. electrically released heat-sensitive with frangible vessels
• A62C 37/42 - Control of fire-fighting equipment an actuating signal being generated by a sensor separate from an outlet device by both sensor and actuator, e.g. valve, being in the danger zone with mechanical connection between sensor and actuator, e.g. rods, levers

Abstract

A dry sprinkler includes a flexible tube section that maintains a pressurized fluid, such as a liquid antifreeze solution, between a first end and a second end. A first seal prevents fluid from a supply line from entering the flexible tube section. The first seal is maintained in a sealed position by a pressure of the pressurized fluid. A sprinkler head is coupled to the second end of the flexible tube section, and includes a frame, an output orifice, a deflector, a second seal that seals the output orifice, and a thermally responsive element configured to maintain the second seal in a sealed position when the thermally responsive element is in a non-responsive state. A differential pressure controller maintains a ratio between the pressure of the pressurized fluid in the flexible tube section and a pressure of a supply fluid in the supply line to at least a certain ratio.

IPC Classes  ?

• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive
• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 35/60 - Pipe-line systems wet, i.e. containing extinguishing material even when not in use
• A62C 37/14 - Releasing means, e.g. electrically released heat-sensitive with frangible vessels
• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use

Abstract

A flexible dry sprinkler includes a flexible tube, an inlet attached to an inlet end of the flexible tube, an inlet seal assembly configured to seal an inlet orifice of the inlet, and an inlet release unit configured to release the inlet seal assembly. The inlet release unit includes a frangible member configured to support the inlet seal assembly in the inlet orifice. An outlet is attached to the outlet end of the flexible tube, and includes an outlet orifice sealed by an outlet seal assembly having a thermally responsive element and an outlet seal. A flexible linkage extends between the inlet and the outlet through the flexible tube, and translates, when the outlet seal is released, a predetermined distance to operate the inlet release unit.

IPC Classes  ?

• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 35/58 - Pipe-line systems
• A62C 31/28 - Accessories for delivery devices, e.g. supports
• A62C 33/04 - Supports or clamps for fire hoses
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing
• A62C 37/14 - Releasing means, e.g. electrically released heat-sensitive with frangible vessels
• A62C 37/42 - Control of fire-fighting equipment an actuating signal being generated by a sensor separate from an outlet device by both sensor and actuator, e.g. valve, being in the danger zone with mechanical connection between sensor and actuator, e.g. rods, levers

Abstract

A fire protection nozzle includes a body having two frame arms having proximal ends connected to an outlet of the body, and distal ends, the two frame arms defining a frame arm plane, and a junction formed by the distal ends of the frame arms, the junction including a central bore and a cylindrical outer wall. A circular deflector is mounted to the body, and includes a planar disk having a mounting hole in a center of the planar disk to receive the cylindrical outer wall of the junction, and a plurality of slots on a periphery of the circular planar disk. The plurality of slots includes four radial first slots, four radial second slots, eight radial third slots, and eight fourth slots. The nozzle has a K-factor of at least 28 gpm/(psi)1/2.

IPC Classes  ?

• A62C 31/02 - Nozzles specially adapted for fire-extinguishing
• A62C 35/00 - Permanently-installed equipment
• B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets

Abstract

A fire protection sprinkler includes a sprinkler body having a boss including a circumferential portion having flat edges, and including a cavity on one of the flat edges, a closure element configured to be held in an output orifice to seal a flow of fluid from the output orifice, and a clip. The clip has a first portion that is engaged with the closure element, and a second portion configured to be inserted into the cavity on the one of the flat edges of the circumferential portion of the boss of the sprinkler body, and configured to contact the cavity such that, upon actuation of the fire protection sprinkler, the clip rotates about an axis passing through two points of contact between the cavity and the second portion, and moves the closure element moves away from the sprinkler body to permit the flow of fluid from the output orifice.

IPC Classes  ?

• A62C 31/28 - Accessories for delivery devices, e.g. supports
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing
• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive
• F16K 17/38 - Safety valvesEqualising valves actuated in consequence of extraneous circumstances, e.g. shock, change of position of excessive temperature

Abstract

A cover plate is provided which is releasably connected to a concealed fire protection sprinkler configured to conceal the fire protection sprinkler. The cover plate includes a first layer of metal on a first side of the cover plate facing the concealed fire protection sprinkler, and a second layer of metal on a second side of the cover plate. The second layer of metal is more resistant to corrosion than the first layer of metal. The second layer is bonded to the first layer, and the first side is opposite the second side. The first layer is more thermally conductive than the second layer.

IPC Classes  ?

• A62C 37/12 - Releasing means, e.g. electrically released heat-sensitive with fusible links
• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers
• A62C 37/09 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers telescopic or adjustable
• A62C 37/10 - Releasing means, e.g. electrically released
• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive
• B32B 15/01 - Layered products essentially comprising metal all layers being exclusively metallic

Abstract

A pendent sprinkler arrangement comprises a sprinkler body having a water passage and a sprinkler axis, a pair of frame arms projecting downwardly from the sprinkler body at one end and forming a junction at the other end, a plug sealing the passage, a thermally responsive element for retaining the plug in the passage, and a deflector coupled to the distal end of the junction. The deflector comprises a planar central portion extending outward along a plane perpendicular to the sprinkler axis, and a first angled portion, a second angled portion, a third angled portion, and a fourth angled portion, each angled portion extending outward from the planar central portion in a first direction, a second direction, a third direction, and a fourth direction, respectively, and each bending away from the frame arms in a downward direction from the plane of the planar central portion.

IPC Classes  ?

• A62C 31/02 - Nozzles specially adapted for fire-extinguishing
• A62C 35/58 - Pipe-line systems
• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets

Abstract

A method of protecting commodities stored in a plurality of adjoining racks, having a vertical flue space provided between a set of racks of the plurality of adjoining racks, includes covering a rack, of the plurality of adjoining racks, and the vertical flue space with one or more solid horizontal barriers provided at a predetermined height. Each solid horizontal barrier has a width that is at least equal to a width of the rack and a depth that is at least equal to a sum of a depth of the rack and a depth of the vertical flue space. The method also includes providing one or more rack-level fire protection sprinklers in the vertical flue space below a solid horizontal barrier, of the one or more solid horizontal barriers, each rack-level sprinkler being vertically spaced from the commodities stored on the rack that is covered by the solid horizontal barrier.

IPC Classes  ?

• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 35/58 - Pipe-line systems
• A62C 3/06 - Fire prevention, containment or extinguishing specially adapted for particular objects or places of highly inflammable material, e.g. light metals, petroleum products
• A62C 35/68 - Details, e.g. of pipes or valve systems

Abstract

A dry sprinkler is provided including a casing tube having a first end and a second end, an inlet attached to the first end, the inlet defining an inlet orifice operatively sealed by an inlet seal assembly, and an outlet attached to the second end, the outlet defining an outlet orifice operatively sealed by an outlet seat assembly. The dry sprinkler also includes a translating member extending between the inlet and the outlet through the casing tube. The translating member is constructed to operatively release the inlet seal assembly responsive to axial translation of the translating member from a first position to a second position. The translating member is supported by the outlet seat assembly in the first position and the translating member is constructed to axially translate toward the outlet when the outlet seat assembly is released. According to one example embodiment, the dry sprinkler has a nominal K-factor greater than 17 GPM/(PSI)1/2.

IPC Classes  ?

• A62C 37/10 - Releasing means, e.g. electrically released
• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 35/58 - Pipe-line systems
• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers
• A62C 37/14 - Releasing means, e.g. electrically released heat-sensitive with frangible vessels

Abstract

A fire protection sprinkler is provided, including a body having an output orifice, a closure element or seal cap to seal a flow of fluid from the output orifice, and a thermally-responsive element positioned to releasably retain the seal cap. A clip, having a first portion and a second portion, is provided, the first portion being engaged with the closure element, and the second portion being in contact with the sprinkler body such that upon actuation of the fire protection sprinkler, the closure element rotates about a pre-determined axis and moves away from the sprinkler body to permit flow of fluid from the output orifice. In particular, the portion of the sprinkler body which the clip contacts is a detent provided on the wrench boss of the sprinkler.

IPC Classes  ?

• A62C 37/11 - Releasing means, e.g. electrically released heat-sensitive
• A62C 31/28 - Accessories for delivery devices, e.g. supports
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing

Abstract

A horizontal sidewall sprinkler is provided which includes a sprinkler body having an inlet passage for supply of a fluid and an outlet, the outlet being closed by a scaling assembly prior to actuation of the sprinkler. The sprinkler further includes a sleeve body secured to the sprinkler body and a yoke substantially spanning a width of the sleeve body, the yoke urging a load screw against a surface of the sealing assembly facing an occupancy, and being held in place prior to actuation of the sprinkler by two levers that are joined by a soldered link. A slide plate is located near an inner wall of the sprinkler body facing the occupancy prior to actuation of the sprinkler. According to one example embodiment, a frame or two guide pins are provided for bearing and supporting a deflector.

IPC Classes  ?

• A62C 37/09 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers telescopic or adjustable

Goods & Services

Automatic fire sprinkler devices.

Abstract

A bracket has a length of bar stock, with end brackets that fit over a rail or bar that forms part of a suspended ceiling or the like. The end brackets may be secured permanently to the bar stock, or their location along the bar stock may be adjustable. A central bracket is mounted on, and can preferably slide along the length of, the bar stock. The central bracket defines a bay in front of the bar stock in which a sprinkler fitting is received, and a hinged lever at the front of the central bracket can be swung shut and locked, to secure the sprinkler in place. Preferably closing the lever also presses the fitting against the bar stock, and secures the central bracket in its location along the bar stock.

IPC Classes  ?

• B05B 15/06 - Mountings, supporting or holding means, or rests for spray heads or other outlets when in use or out of use (B05B 15/10 takes precedence)
• F16B 2/18 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening using cams, levers, eccentrics, or toggles
• F16L 3/00 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets

Goods & Services

Hand tools, namely, wrenches for use in the installation of fire sprinklers fire sprinklers; dry-pipe and deluge valves as parts of fire sprinkler systems; cabinets specially adapted for containing fire sprinklers

Goods & Services

automatic fire sprinklers

Abstract

A flexible dry sprinkler includes a flexible tube having a first end and a second end, an inlet, an inlet seal assembly, and an inlet release unit. An outlet is attached to the second end of the flexible tube, and is sealed by an outlet seal assembly. A flexible linkage extends between the inlet and the outlet through the flexible tube. When the outlet seal assembly is released, the flexible linkage translates from a first position to a second position, and the flexible linkage operates the inlet release unit to release the inlet seal assembly.

IPC Classes  ?

• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use
• A62C 35/58 - Pipe-line systems
• A62C 31/28 - Accessories for delivery devices, e.g. supports
• A62C 33/04 - Supports or clamps for fire hoses
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing
• A62C 37/14 - Releasing means, e.g. electrically released heat-sensitive with frangible vessels
• A62C 37/42 - Control of fire-fighting equipment an actuating signal being generated by a sensor separate from an outlet device by both sensor and actuator, e.g. valve, being in the danger zone with mechanical connection between sensor and actuator, e.g. rods, levers

Abstract

A fire protection sprinkler system includes one or more solid horizontal barriers that cover a rack, of a plurality of adjoining racks, and a vertical flue space between adjacent racks. Each barrier is provided at a predetermined height, and has a width that is at least equal to a width of the rack and a depth that is at least equal to a sum of a depth of the rack and a depth of the vertical flue space. In addition, one or more rack-level fire protection sprinklers are connected to a fluid supply conduit, and are disposed in the vertical flue space above or below a solid horizontal barrier. Each of the one or more rack-level sprinklers is vertically spaced from the commodities stored on a rack, of the plurality of adjoining racks, that is covered by the solid horizontal barrier.

IPC Classes  ?

• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 3/02 - Fire prevention, containment or extinguishing specially adapted for particular objects or places for area conflagrations, e.g. forest fires, subterranean fires
• A62C 3/00 - Fire prevention, containment or extinguishing specially adapted for particular objects or places
• A62C 35/58 - Pipe-line systems
• A62C 3/06 - Fire prevention, containment or extinguishing specially adapted for particular objects or places of highly inflammable material, e.g. light metals, petroleum products

Goods & Services

Automatic fire suppression systems and components of automatic fire suppression systems, namely fire sprinkler devices, valves, and sprinkler heads.

Goods & Services

(1) Automatic fire suppression systems and components of automatic fire suppression systems, namely, fire sprinkler devices and sprinkler heads.

Abstract

A fire protection sprinkler system is provided for the protection of commodities including Class I-IV hazards, Group A cartoned and exposed plastics (expanded and unexpanded), flammable liquids, tires, roll paper, and aerosols, stored in a plurality of adjoining racks having a longitudinal flue space between the racks. The system includes at least one fluid supply conduit in fluid communication with a source of a fire protection fluid. The system also includes at least one solid horizontal barrier covering each rack and the longitudinal flue space at a predetermined vertical spacing. The system further includes one or more rack-level fire protection sprinklers in fluid communication with the fluid supply. The sprinklers are disposed in the vertical flue space between adjacent horizontal barriers, and each sprinkler is spaced vertically from the commodities stored between adjacent horizontal barriers.

IPC Classes  ?

• B65G 1/00 - Storing articles, individually or in orderly arrangement, in warehouses or magazines

Abstract

A fire protection sprinkler system includes one or more solid horizontal barriers that cover a rack, of a plurality of adjoining racks, and a vertical flue space between adjacent racks. Each barrier is provided at a predetermined height, and has a width that is at least equal to a width of the rack and a depth that is at least equal to a sum of a depth of the rack and a depth of the vertical flue space. In addition, one or more rack-level fire protection sprinklers are connected to a fluid supply conduit, and are disposed in the vertical flue space above or below a solid horizontal barrier. Each of the one or more rack-level sprinklers is vertically spaced from the commodities stored on a rack, of the plurality of adjoining racks, that is covered by the solid horizontal barrier.

IPC Classes  ?

• A62C 35/68 - Details, e.g. of pipes or valve systems

Abstract

A fire protection sprinkler includes a body having an input end and an output end, the body having an output orifice at the output end. The sprinkler includes a frame extending from the body in the output direction and a deflector supported by the frame positioned opposite the output orifice. Also, the sprinkler includes a seal assembly which seals the output orifice. The seal assembly has a first side and a second side, the first side bearing identifying indicia associated with the orientation of the seal assembly. When the first side is oriented in the input direction, a portion of the indicia is visible from the input end, to indicate a correct assembly. However, when the first side is oriented in the output direction, none of the indicia is visible from the input end, indicating incorrect assembly.

IPC Classes  ?

• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers

Abstract

A flexible dry sprinkler includes a flexible tube having an inlet attached to a first end, the inlet defining an inlet orifice operatively sealed by an inlet seal assembly. An outlet is attached to the second end of the flexible tube, and defines an outlet orifice operatively sealed by an outlet seal assembly. A flexible linkage extends from the inlet to the outlet through the flexible tube, and is constructed to operatively release the inlet seal assembly responsive to axial translation of the flexible linkage from a first position to a second position. The flexible linkage is supported by the outlet seal assembly in the first position and wherein the flexible linkage is constructed to axially translate toward the outlet when the outlet seal assembly is released.

IPC Classes  ?

• A62C 35/62 - Pipe-line systems dry, i.e. empty of extinguishing material when not in use

Goods & Services

Automatic fire suppression systems and components of automatic fire suppression systems, namely, fire sprinkler devices, and sprinkler heads

Abstract

A fire prevention sprinkler system that has a warming jacket through which a warming medium, preferably water, is circulated, at a temperature sufficient to prevent freezing of those portions of the sprinkler system that contain water or another freezable liquid at times when the sprinklers are not actually spraying water to control or extinguish a fire. The warming medium is preferably heated by radiant heating, and circulation is preferably initiated by a thermostatic control whenever the temperature in the protected premises drops below a predetermined value.

IPC Classes  ?

• A62C 35/00 - Permanently-installed equipment

Abstract

A fire protection sprinkler is provided. The sprinkler includes a body having an output orifice and a flange; a seal cap to seal a flow of fluid from the output orifice; and a thermally-responsive element positioned to releasably retain the seal cap and constructed to separate into a plurality of portions upon exposure to a predetermined temperature. The sprinkler also includes at least one deflector support member, a deflector connected to the deflector support member, and at least one arm extending from each of the deflector support members. Each of the arms has a free end positioned in spaced relation to the thermally-responsive element to contact the portions of the thermally-responsive element upon separation thereof. In another embodiment, the sprinkler includes at least one arm extending from the flange, and the arms may be formed as a bracket.

IPC Classes  ?

• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers

Abstract

A fluid distribution system is provided including a fluid supply, at least one conduit in fluid communication with the fluid supply, and at least one mountable fitting fluidly coupled to the conduit. The mountable fitting includes a body and a mounting base. The body defines a cavity having a plurality of ports in fluid communication with the cavity and the conduit, at least one port of the plurality of ports having a connection portion configured to fluidly couple to at least the fluid conduit. The mounting base extends a fixed distance from the body configured to be mounted to a structure to space the body a fixed distance from the structure.

IPC Classes  ?

• A62C 35/68 - Details, e.g. of pipes or valve systems

Abstract

A horizontal sidewall fire protection sprinkler has a deflector having a vertical face, transverse to the fluid flow from the output orifice, and a horizontal shelf positioned above and perpendicular to the vertical face. A portion of the horizontal shelf extends in the fluid flow direction by a first length, with respect to the vertical face, and this first length is less than about half of the total length of the horizontal shelf in the fluid flow direction. The sprinkler may be installed in a support cup having a raised mounting platform configured to receive the sprinkler body and a cylindrical outer surface. A horizontal or pendent fire protection sprinkler has a body having an output orifice and a flange and a seal cap to seal a flow of fluid from the output orifice and a thermally-responsive element positioned to releasably retain the seal cap.

IPC Classes  ?

• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers

Abstract

a fire-prevention sprinkler (100) that can be used with a dual -use or multipurpose supply may have a sprinkler body (110), an inlet to admit water into the sprinkler body and an outlet (130) by which the water can exit the sprinkler body upon actuation of the sprinkler, as well as a deflector (145) to direct the water in a desired pattern as the water exits the sprinkler outlet, and an actuation device, that opens at least the sprinkler outlet upon detection of a fire condition. The entire inner surface of the water passage is made of a material such as will protect the water in the sprinkler from absorbing lead. The entire sprinkler body may be made of that same substance, as well, and the seal (s) may be made of the same material, or of another having the mentioned property. Such materials are preferably metals, but may be plastic or vitreous.

IPC Classes  ?

• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers

Abstract

1/2, and is connected to a piping network at a height greater than the storage height. When each sprinkler is activated, a fluid is supplied to the sprinkler from the piping network at a pressure of at least 30 pounds per square inch, and is delivered to a coverage area of greater than 110 and up to and including 196 square feet per sprinkler. A design operating area of the sprinkler system is up to six sprinklers or 1200 square feet.

IPC Classes  ?

• A62C 3/02 - Fire prevention, containment or extinguishing specially adapted for particular objects or places for area conflagrations, e.g. forest fires, subterranean fires

Goods & Services

Automatic fire suppression systems and components of automatic fire suppression systems, namely fire sprinkler devices, valves, and sprinkler heads.

Abstract

A method of using a residential fire protection sprinkler. The method includes providing a fluid supply conduit extending along a ceiling, having a pitch up to 12/12, at a predetermined distance relative to the ceiling and connected to a source of fluid having a predetermined source pressure. The method also includes connecting at least two residential fire protection sprinklers to the fluid supply conduit such that the sprinklers are spaced at least eight feet (8') apart from one another, wherein the sprinklers have a K- factor of at least 2.8. A residential fire protection sprinkler system is also provided. The system includes a fluid supply conduit extending along a ceiling, having a pitch of up to 12/12, at a predetermined distance relative to the ceiling and connected to a source of fluid having a predetermined source pressure. The system also includes at least two residential fire protection sprinklers connected to the fluid supply conduit such that the sprinklers are at least eight feet apart from one another, wherein the sprinklers have a K-factor of at least 2.8.

IPC Classes  ?

• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers

Goods & Services

Automatic fire suppression systems and components of automatic fire suppression systems, namely, fire sprinkler devices, valves, and sprinkler heads

Goods & Services

Automatic fire suppression systems and components of automatic fire suppression systems, namely, fire sprinkler devices, valves, and sprinkler heads

Abstract

An attic fire protection system is provided. The system comprises a fluid supply manifold for supplying a fluid, positioned at an effective height below and parallel to the underside of a roof having a non-zero pitch angle. The system contains a plurality of fittings each having at least one exit port for directing the flow of the fluid, the fittings being spaced within at most a maximum effective distance apart from each other and being connected to receive fluid from the supply manifold, wherein the exit ports are structured to supply the fluid in a direction parallel to the underside of the roof. Most broadly, however, the fittings are structured or arranged to supply the fluid in a direction forming an oblique angle with the horizontal and the vertical, which may or may be exactly the same as the pitch angle of the roof. The system also includes a plurality of horizontal sidewall sprinklers each connected to a respective exit port of one or another of the fittings.

IPC Classes  ?

• A62C 37/10 - Releasing means, e.g. electrically released
• A62C 35/58 - Pipe-line systems
• A62C 35/68 - Details, e.g. of pipes or valve systems

Abstract

A fire protection method is provided that comprises providing at least one special application control mode extended coverage sprinkler for storage applications having a K-factor of at least 14 that is connectable to a piping network to protect commodity hazards including class one through four and cartoned unexpanded plastics, as defined in National Fire Protection Association Standard 13 and FM Global Property Loss Prevention Data Sheets 8-1 and 8-9, stored in a storage area defined by a storage height of at least 25 feet, and a building height of at least 30 feet, wherein the sprinkler provides coverage to an area of at least 144 square feet. The method also includes connecting the at least one sprinkler to the overhead piping network at a height at least equal to the storage height, activating the sprinkler in the event of a fire condition sensed by the sprinkler head, and delivering a fluid fed to the sprinkler to a coverage area of at least 144 square feet.

IPC Classes  ?

• A62C 35/68 - Details, e.g. of pipes or valve systems
• A62C 31/02 - Nozzles specially adapted for fire-extinguishing

Abstract

A pendent residential fire protection sprinkler includes a sprinkler body having an inlet and an outlet, a seal that releasably seals the outlet, and a release mechanism that maintains the seal in the outlet until occurrence of a predetermined condition. A frame structure extends from the sprinkler body, and forms a hub into which a set-screw that supports the release mechanism is inserted. A deflector is mounted to the hub of the frame structure with the set-screw. The deflector has a central portion and a peripheral portion that includes a first plurality of slots, each having a uniform width, and a second plurality of slots, each having a first portion near an open end portion at the periphery of the deflector and has a width that varies, and a second portion between the first portion and a closed end portion, and the second portion has a uniform width.

IPC Classes  ?

• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers

Abstract

An enhanced protection extended coverage pendent fire protection sprinkler has a body including a fluid passage and an output orifice sealed with a seal cap, two amis extending from the body and meeting at a hub, a release mechanism with a thermally-responsive element positioned between the seal cap and the hub, and a deflector positioned on the hub and facing the output orifice. The deflector includes a pair of aligned slots, aligned with a plane of the arms, and a pair of perpendicular slots, perpendicular to the aligned slots and having a width that is less than that of the aligned slots. The deflector further includes a pair of corner slots, positioned between the aligned slots and the perpendicular slots. Angled slots are positioned between the aligned slots and the corner slots and between the perpendicular slots and the corner slots.

IPC Classes  ?

• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers

Abstract

A dry/deluge valve for an automatic sprinkler system. The valve includes a main chamber having an input port for receiving fluid from a supply line and an output port. A clapper assembly is installed in the main chamber for sealing the input port. The clapper assembly includes a threaded valve seat configured to be screwed into a wall of the main chamber, so as to be in communication with the input port. The assembly further includes a collar configured to receive the valve seat, wherein the collar is held in position by the valve seat. A clapper configured to seal the input port, in cooperation with the valve seat, is hinged to the collar, and a lever also is hinged to the collar and is movable between a first position in which the clapper is held closed by the lever and a second position in which the clapper is allowed to open. The dry pipe/deluge valve further includes a sensing chamber having components responsive to a control pressure of the sensing chamber, the components being in communication with the lever to move the lever between the first position and the second position.

IPC Classes  ?

• A62C 35/00 - Permanently-installed equipment

Abstract

A pendent fire protection sprinkler for storage applications, having a body including a fluid passage and an output orifice sealed with a seal cap, two arms extending from the body and meeting at a hub, a release mechanism with a thermally-responsive element positioned between the seal cap and the hub, and a deflector positioned on the hub and facing the output orifice. The deflector has aligned slots at about 90° from each other, corner slots located between the aligned slots, and angled slots located between the aligned slots and the corner slots.

IPC Classes  ?

• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers
• A62C 37/36 - Control of fire-fighting equipment an actuating signal being generated by a sensor separate from an outlet device
• A62C 37/12 - Releasing means, e.g. electrically released heat-sensitive with fusible links
• B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets

Abstract

A sidewall fire protection sprinkler including a deflector having a central portion curved about a transverse axis from an output direction of the sprinkler. End portions extend along the transverse axis outwardly from the central portion. The end portions have an upper part and a lower part separated by a gap. Planar portions extend in the output direction from a top edge of the end portions.

IPC Classes  ?

• A62C 37/08 - Control of fire-fighting equipment comprising an outlet device containing a sensor, or itself being the sensor, i.e. self-contained sprinklers

Goods & Services

(1) Automatic fire sprinkler devices.
