09 - Scientific and electric apparatus and instruments
Goods & Services
Antennas for wireless communication; antenna masts for wireless communication; enclosures for antennas; brackets and holders specially adapted for antennas; wireless high frequency radio transmission devices; microwave communications transmission apparatus; wireless routers; cables, connectors, and electronic components for the foregoing goods
2.
Modular electromagnetic antenna assemblies and methods of assembling and/or disassembling
A modular electromagnetic antenna assembly configured for securement to a structure is provided. The assembly includes an antenna, a radio, and a base. The base has a bracket securable to the structure and the base has at least one feed. The radio and base together form a waveguide that transmits radio waves between the radio and the antenna. The radio is removably secured to the base so as to form a removable mechanical connection to the base and a removable communication connection with the at least one feed through the base.
H01Q 19/12 - Combinations of primary active antenna elements and units with secondary devices, e.g. with quasi-optical devices, for giving the antenna a desired directional characteristic using reflecting surfaces wherein the surfaces are concave
H01Q 1/24 - SupportsMounting means by structural association with other equipment or articles with receiving set
H01P 5/02 - Coupling devices of the waveguide type with invariable factor of coupling
A coupling assembly for a first device having a bayonet is provided. The coupling assembly includes a top plate, a bottom plate, and first fasteners securing the top and bottom plates to one another. The top plate having a slot along a connection axis, where the slot receives the bayonet. The bottom plate has a locking arm in axial alignment with the slot and a biasing arm in a region that is radially offset from the locking arm. The region of the bottom plate receives the bayonet, when in a locked position, with the locking arm preventing the bayonet, by interference with locking arm, from rotating about the connection axis back into alignment with the slot and with the biasing arm preventing the bayonet, by interference with biasing arm, from being withdrawn axially along the connection axis.
A horn-type of electromagnetic dual polarized antenna, having an asymmetric radiation pattern is provided. More specifically, the radiation pattern in the azimuth plane will have a wider beam width while the radiation pattern in the elevation plane will have a narrower beam width, and the radiation patterns for the horizontal and vertical polarizations are substantially equal.
A horn-type of electromagnetic dual polarized antenna, having an asymmetric radiation pattern is provided. More specifically, the radiation pattern in the azimuth plane will have a wider beam width while the radiation pattern in the elevation plane will have a narrower beam width, and the radiation patterns for the horizontal and vertical polarizations are substantially equal.
A modular electromagnetic antenna assembly configured for securement to a structure is provided. The assembly includes an antenna, a radio, and a base. The base has a bracket securable to the structure and the base has at least one feed. The radio and base together form a waveguide that transmits radio waves between the radio and the antenna. The radio is removably secured to the base so as to form a removable mechanical connection to the base and a removable communication connection with the at least one feed through the base.
H01Q 19/12 - Combinations of primary active antenna elements and units with secondary devices, e.g. with quasi-optical devices, for giving the antenna a desired directional characteristic using reflecting surfaces wherein the surfaces are concave
H01Q 1/24 - SupportsMounting means by structural association with other equipment or articles with receiving set
H01P 5/02 - Coupling devices of the waveguide type with invariable factor of coupling
A coupling assembly for a first device having a bayonet is provided. The coupling assembly includes a top plate, a bottom plate, and first fasteners securing the top and bottom plates to one another. The top plate having a slot along a connection axis, where the slot receives the bayonet. The bottom plate has a locking arm in axial alignment with the slot and a biasing arm in a region that is radially offset from the locking arm. The region of the bottom plate receives the bayonet, when in a locked position, with the locking arm preventing the bayonet, by interference with locking arm, from rotating about the connection axis back into alignment with the slot and with the biasing arm preventing the bayonet, by interference with biasing arm, from being withdrawn axially along the connection axis.
An improved antenna ball joint mount is provided that includes a hollow socket mechanically coupled to a spherical member with a locking part. The hollow socket and the spherical member are fully detachable to simplify the installation of an antenna. A user is able to set a position of the antenna to any point on a spherical sector surface within a range of motion allowed by a shape of joint components and rotate the antenna around own axis to adjust a polarization plane and then lock the mount in a predetermined position.
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Antennas for wireless communication; antenna masts for wireless communication; enclosures for antennas; brackets and holders specially adapted for antennas; wireless high frequency Radio Transmission devices: microwave communications Transmission apparatus; wireless Routers; cables, connectors, and electronic components for the foregoing goods. Software as a Service (SAAS) Services, namely, Hosting Software for use by others for use in Management of wireless Routers.
A quick connect coupler assembly for connecting a first waveguide portion to a second waveguide portion is provided. The coupler assembly includes: a first coupler component affixed to the first waveguide portion and a second coupler component affixed to the second waveguide portion. The first coupler component has a plurality of perturbations, while the second coupler component has a plurality of slots and a radially disposed guide or channel. The perturbations align with and pass through the slots into the guide or channel such that the perturbations rotatably move about the guide or channel in a radial direction from an unlocked to a locked position.
H01Q 19/13 - Combinations of primary active antenna elements and units with secondary devices, e.g. with quasi-optical devices, for giving the antenna a desired directional characteristic using reflecting surfaces wherein the surfaces are concave the primary radiating source being a single radiating element, e.g. a dipole, a slot, a waveguide termination
There is provided an antenna that includes (a) an element that emits radiation in a direction, and (b) a structure made of an electrically conductive material. The structure includes (i) a surface situated to a side of the element that is in other than the direction, and (ii) a first wall and a second wall that are situated generally perpendicular to the surface and situated with respect to one another so as to form a trough therebetween.
H01Q 19/10 - Combinations of primary active antenna elements and units with secondary devices, e.g. with quasi-optical devices, for giving the antenna a desired directional characteristic using reflecting surfaces
H01Q 1/24 - SupportsMounting means by structural association with other equipment or articles with receiving set
H01Q 19/02 - Combinations of primary active antenna elements and units with secondary devices, e.g. with quasi-optical devices, for giving the antenna a desired directional characteristic Details
H01Q 21/08 - Arrays of individually energised antenna units similarly polarised and spaced apart the units being spaced along, or adjacent to, a rectilinear path
09 - Scientific and electric apparatus and instruments
Goods & Services
Antennas for wireless communication; antenna masts for wireless communication; enclosures for antennas; brackets and holders specially adapted for antennas; wireless high frequency radio transmission devices; microwave communications transmission apparatus; wireless routers; cables, connectors, and electronic components for the foregoing goods.
There is provided a wireless communication apparatus that includes (a) a printed circuit board, (b) a radio frequency circuit installed on the printed circuit board, and (c) an antenna element that is integrated onto the printed circuit board and electrically coupled to the radio frequency circuit via a printed conductor.
H01Q 19/13 - Combinations of primary active antenna elements and units with secondary devices, e.g. with quasi-optical devices, for giving the antenna a desired directional characteristic using reflecting surfaces wherein the surfaces are concave the primary radiating source being a single radiating element, e.g. a dipole, a slot, a waveguide termination
H01Q 21/28 - Combinations of substantially independent non-interacting antenna units or systems
An improved antenna ball joint mount is provided that includes a hollow socket mechanically coupled to a spherical member with a locking part. The hollow socket and the spherical member are fully detachable to simplify the installation of an antenna. A user is able to set a position of the antenna to any point on a spherical sector surface within a range of motion allowed by a shape of joint components and rotate the antenna around own axis to adjust a polarization plane and then lock the mount in a predetermined position.
09 - Scientific and electric apparatus and instruments
Goods & Services
Antennas for wireless communication; Antenna Masts for wireless communication; Enclosures for Antennas; brackets and holders specially adapted for antennas; Wireless high frequency radio transmission devices; Microwave communications transmission apparatus for delivering radio programs and messages featuring cables connectors and electronic components excluding from the foregoing banking services, payment-related services, payment cards, bank cards, debit cards, credit cards, charge cards, magnetic encoded cards, telephone calling cards, stored value and/or prepaid cards and related services, the marketing, distribution, provision and issuance of such cards or services, Automated Teller Machines ("ATM") and ATM services, electronic card readers, electronic funds and currency transfer services and electronic payment services
09 - Scientific and electric apparatus and instruments
Goods & Services
Universal enclosures for electronic devices, namely, outdoor and indoor enclosures for wireless communication devices for voice, data or image transmission devices and antennas
