A cutting tool, system, method and computer program product for increasing traceability of at least a first cutting edge of a cutting tool. The method includes detecting at least a first identification marker on the cutting tool, reading the at least first identification marker, decoding the at least first identification marker to determine at least a first cutting edge information data included in the machine readable code of the at least first identification marker, generating a first cutting tool identification data based on at least the at least first cutting edge information data, and storing at least any of the at least first cutting tool identification data and the at least first cutting edge information data in a memory.
B23B 27/14 - Cutting tools of which the bits or tips are of special material
B23B 27/16 - Cutting tools of which the bits or tips are of special material with exchangeable cutting bits, e.g. able to be clamped
B23C 5/20 - Milling-cutters characterised by physical features other than shape with removable cutter-bits or teeth
B23Q 17/09 - Arrangements for indicating or measuring on machine tools for indicating or measuring cutting pressure or cutting-tool condition, e.g. cutting ability, load on tool
A face milling cutter includes a tool body, at least two cutting inserts for forming a milled flat surface on a workpiece and mounted in a respective insert seat in the tool body, each cutting insert having a secondary cutting edge that constitutes the axially foremost cutting edge of the cutting insert, and several burnishing assemblies with a respective spring-loaded burnishing element arranged in the tool body. The number of the burnishing assemblies in the tool body is the same as the number of insert seats, wherein the insert seats and the burnishing assemblies are alternately arranged in the circumferential direction of the tool body such that each one of the insert seats is followed by an associated one of the burnishing assemblies as seen in the intended direction of rotation of the tool body.
23233 layer ranges from 0.3 to 4 µm wherein the thickness of the second Ti(C,N) layer ranges from 2 to 12 µm; and wherein the layers of i), ii), and iii) are arranged in the mentioned order counted from the substrate.
C23C 30/00 - Coating with metallic material characterised only by the composition of the metallic material, i.e. not characterised by the coating process
C23C 16/02 - Pretreatment of the material to be coated
C23C 16/08 - Chemical coating by decomposition of gaseous compounds, without leaving reaction products of surface material in the coating, i.e. chemical vapour deposition [CVD] processes characterised by the deposition of metallic material from metal halides
C23C 28/04 - Coating for obtaining at least two superposed coatings either by methods not provided for in a single one of main groups , or by combinations of methods provided for in subclasses and only coatings of inorganic non-metallic material
The present invention relates to a press tool for forming, by compacting a powder, a cutting insert green body (8). The press tool comprises a punch device (3), which comprises an axially extending front section with a front end at a cavity, which front section is operable to assume a start orientation and a target orientation, and an axially extending rear section, which is connected with and located axially rearward of the front section. The press tool further comprises a movably arranged spacer element (10), wherein the spacer element (10) is operable to translate from a start position to a target position, and an arm member (17), which extends axially along the rear section (14) at a distance therefrom. A joint unit (18), which connects the arm member (17) and the rear section such that the distance from the rear section (14) to the arm member (17), in a position axially in front of the joint unit (18), is adjustable. The spacer element (10) is arranged and configured to engage the arm member (17) via an arm contact point (19) and the rear section via a rear contact point (20). When the spacer element (10) is in the start position, as seen in an axial projection on an axial plane, the distance from the arm contact point (19) to the rear contact point (20) is a rear start distance, whereby the joint unit (18) is in a start state and the front section (11) is in the start orientation. When the spacer element (10) is in the target position, as seen in an axial projection on an axial plane, the distance from the arm contact point (19) to the rear contact point (20) is a rear target distance (24), whereby the joint unit (18) is in a target state biased toward the start state and the front section (11) is in the target orientation.
B28B 3/02 - Producing shaped articles from the material by using pressesPresses specially adapted therefor wherein a ram exerts pressure on the material in a moulding spaceRam heads of special form
B30B 11/02 - Presses specially adapted for forming shaped articles from material in particulate or plastic state, e.g. briquetting presses or tabletting presses using a ram exerting pressure on the material in a moulding space
B30B 11/00 - Presses specially adapted for forming shaped articles from material in particulate or plastic state, e.g. briquetting presses or tabletting presses
B30B 15/02 - DiesInserts therefor or mountings thereofMoulds
B22F 5/00 - Manufacture of workpieces or articles from metallic powder characterised by the special shape of the product
B28B 3/08 - Producing shaped articles from the material by using pressesPresses specially adapted therefor wherein a ram exerts pressure on the material in a moulding spaceRam heads of special form with two or more rams per mould
The invention relates to a method of additively manufacturing an object of a maraging steel by laser powder bed fusion (L-PBF) of a powder, said powder being composed of i) Ni in an amount ranging from 10 to 15 wt% ii) Co in an amount ranging from 12 to 16 wt% iii) Mo in an amount ranging from 8 to 12 wt% iv) Ti in an amount of up to 0.2 wt% v) Al in an amount of up to 0.1 wt% vi) C in an amount of up to 0.03 wt%; and balance Fe; wherein the amount in wt% is based on the total weight of the powder; said method comprising i) depositing a layer of said powder on a build surface ii) melting at least a part of said layer by means of a laser source, iii) subjecting the layer to solidification and cooling iv) depositing a further layer on at least the part of the previous layer that was subjected to melting, solidification and cooling according to steps ii) and iii) v) melting, solidification and cooling of at least a part of the further layer deposited in step iv) vi) repeating steps iv) and v), wherein the deposition of said further layer is performed after an interlayer time of at least 25 seconds. The invention also relates to a tool and an object which can be obtained by the method.
B22F 7/06 - Manufacture of composite layers, workpieces, or articles, comprising metallic powder, by sintering the powder, with or without compacting of composite workpieces or articles from parts, e.g. to form tipped tools
B22F 7/08 - Manufacture of composite layers, workpieces, or articles, comprising metallic powder, by sintering the powder, with or without compacting of composite workpieces or articles from parts, e.g. to form tipped tools with one or more parts not made from powder
B22F 10/28 - Powder bed fusion, e.g. selective laser melting [SLM] or electron beam melting [EBM]
C23C 28/04 - Coating for obtaining at least two superposed coatings either by methods not provided for in a single one of main groups , or by combinations of methods provided for in subclasses and only coatings of inorganic non-metallic material
C23C 16/02 - Pretreatment of the material to be coated
C23C 16/30 - Deposition of compounds, mixtures or solid solutions, e.g. borides, carbides, nitrides
C23C 30/00 - Coating with metallic material characterised only by the composition of the metallic material, i.e. not characterised by the coating process
7.
CUTTING TOOL WITH DOUBLE-SIDED TANGENTIAL CUTTING INSERT
A cutting tool comprising a tool body (2) with at least one insert seat (10), and a double-sided tangential cutting insert (30) with four different working positions releasably mountable in said insert seat. A support member (15) with an auxiliary support surface (16) is formed in said insert seat (10), wherein the auxiliary support surface (16) is configured to face a mating surface on an end face of the cutting insert (30) that faces a tangential support surface (13a, 13b) in the insert seat when the cutting insert is mounted in the insert seat in any of its four working positions. The cutting insert (30) and said support member (15) are so adapted to each other that there is a play of 0.01-0.04 mm between the auxiliary support surface (16) and said mating surface when the cutting insert is mounted in the insert seat in any of its four working positions with the tool body (2) in a brand new condition.
B23C 5/06 - Face-milling cutters, i.e. having only or primarily a substantially flat cutting surface
B23C 5/20 - Milling-cutters characterised by physical features other than shape with removable cutter-bits or teeth
B23C 5/22 - Securing arrangements for bits or teeth
8.
SYSTEM AND METHOD FOR DETERMINING WHEN A PROCESS OF REMOVAL OF ORGANIC ADDITIVES FROM A GREEN BODY DURING MANUFACTURING OF A CUTTING ELEMENT IS FINISHED
The invention relates to a system for determining when a process of removal of organic additives from a green body (102) during manufacturing of a cutting element is finished, wherein the system (100) comprises a sintering furnace (110) having a pressure regulating valve (112), wherein the pressure regulating valve (112) has an adjustable flow transmittance F, wherein the system (100) further comprises at least one information unit (122), wherein the information unit (122) is configured to generate an information signal (124) comprising information regarding the flow transmittance F as a function of time t, and wherein the system (100) further comprises an analysis unit (130), wherein the analysis unit (130) is configured to determine when the flow transmittance F has reached a steady state, and to determine that the process of removal of organic additives from a green body (102) is finished when the flow transmittance F has reached the steady state The invention also relates to a method (200) for determining when a process of removal of organic additives from a green body (102) during manufacturing of a cutting element is finished.
A drill body of an indexable insert drill includes at least two chip flutes separated from each other in the circumferential direction of the drill body by intermediate ribs, each chip flute and each rib extending in a helically curved path. An insert seat is located at a transition between each chip flute and a front face of the drill body. Coolant ducts are arranged in and extending along a respective one of the ribs. Each coolant duct extends in a helically curved path and has an upstream end with an inlet opening and a downstream end with an outlet opening. Each coolant duct has a cross-sectional area that varies in the axial direction of the coolant duct, such that it has a smaller cross-sectional area at its outlet opening than at its inlet opening.
A double-sided tangential cutting insert, having eight different working positions, includes two opposite end faces serving as leading and trailing faces of the cutting insert, two opposite major side faces, two opposite minor side faces, a through hole extending between the two major side faces, cutting edges distributed along a periphery of each end face, and four abutment surfaces arranged on each end face in a grid-like pattern with two first arrays, each of which have two consecutive abutment surfaces that extend between the two major side faces, and two second arrays, each of which have two consecutive abutment surfaces and extend between the two minor side faces. Each abutment surface are inclined inwards in the cutting insert such that each two consecutive abutment surfaces in each array are inclined towards each other.
End mill tool for metal cutting. The cutting head (2) comprises a plurality of cutting teeth (7), which each has a cutting edge formed at an intersection of a respective rake surface (8) and a respective clearance surface (9). Each cutting edge comprises a front cutting edge (10) extending radially outward at the front end (3) and a transition cutting edge (11) extending from the front cutting edge (10) to a side cutting edge (14). The clearance surface (9) along the transition cutting edge (11), in a direction of the extension of the transition cutting edge (11), is convex. Along the transition cutting edge (11), the axial rake angle 0 of the rake surface (8) is positive, and equal or less than the helix angle a at the front end of the chip flute (13).
A face milling cutter comprising: • - a tool body (2) with insert seats (10), each of which having an internal wall with three support surfaces (21-23) that are distributed about a reference axis (RA) and inclined in order to form a cone-like guiding for a cutting insert; • - indexably mountable, cutting inserts (30) each cutting insert having first and second major faces (31, 32) on opposite sides of the cutting insert and a peripheral surface with several abutment surfaces (37); and • - fastening screws (7) for securing the cutting inserts in the insert seats. The cutting inserts (30) and the insert seats (10) are so adapted to each other that the second major face (32) of each cutting insert is located at a distance from a bottom surface (11) of the associated insert seat when the cutting insert is mounted to the insert seat in any of its working positions.
A system for automated mounting and dismounting of at least one cutting insert on a tool body with a screwing tool is provided. The cutting insert includes a top surface, a bottom surface, a circumferential side surface connecting the top and bottom surfaces, and a through hole extending from the top surface to the bottom surface for receiving the shaft of a fastening screw. A carrier device is arranged to pick up and release the cutting insert with the fastening screw. The carrier device has a body having a front surface, a rear surface, a circumferential side surface connecting the front and rear surfaces, and a channel extending from a front end opening in the front surface to a rear end opening in the rear surface. A method for automated mounting of a cutting insert with a fastening screw on a tool body is also provided.
B23P 15/28 - Making specific metal objects by operations not covered by a single other subclass or a group in this subclass cutting tools
B23B 27/14 - Cutting tools of which the bits or tips are of special material
B23P 19/00 - Machines for simply fitting together or separating metal parts or objects, or metal and non-metal parts, whether or not involving some deformationTools or devices therefor so far as not provided for in other classes
14.
SYSTEM AND A METHOD FOR DETERMINING CONTACT BETWEEN A CUTTING TOOL AND AN ELECTRICALLY CONDUCTIVE WORKPIECE
A system and method for determining contact between a cutting tool and an electrically conductive workpiece is provided. The cutting tool includes a toolholder and a plurality of cutting inserts mounted in the toolholder. Each of the cutting inserts has an electrically conductive surface layer and are electrically insulated from the toolholder. Each of the cutting inserts are connected in parallel to a first pole of an electric power source via a respective first connection unit and a second connection unit is connected to a second pole of the electric power source and electrically connected to the electrically conductive workpiece. A measuring unit is operatively connected to an analysis unit and is configured to measure an electrical voltage over each of the first connection units. The analysis unit is configured to determine a contact between the cutting tool and an electrically conductive workpiece based on the measured electrical voltages.
A cutting tool including a tool body with an insert seat and an associated clamp pocket, a cutting insert releasably mountable in the insert seat, a clamp received in the clamp pocket and a screw that extends with play through a through hole in the clamp and is engaged in a hole at the bottom of the clamp pocket, is provided. Upon tightening of the screw, the clamp will slide against an inclined guide surface in the slide pocket via a slide surface on the clamp, which will force the clamp to move transversally to the screw shaft towards the cutting insert such that a clamp protrusion on the clamp is moved into a recess in the cutting insert and clamping surfaces on the clamp are pressed tightly against corresponding contact surfaces on the cutting insert.
A cutting insert for use in face milling and turnable into different working positions. The cutting insert comprises a peripheral surface (10) extending around the cutting insert between a rake face (2) and an opposite abutment face (3), wherein a part of the peripheral surface is provided with ridges (11) and intermediate valleys (12) such that a peripheral edge (20) between the rake face and the peripheral surface has a shape of a toothed ring with external teeth (21). A major cutting edge (30), a surface-wiping cutting edge (31) and a minor corner cutting edge (32) are provided along each tooth (21), wherein the major cutting edge (30) has an entering angle of 75° or more in at least one point along its extension. Each tooth (21) is asymmetric in relation to a reference line that extends perpendicularly to the surface-wiping cutting edge (31) of the tooth and intersects a centre of the surface-wiping cutting edge halfway between two opposite end points thereof.
A double-sided cutting insert (1) for use in a helical milling cutter with rectangular basic shape and four different working positions. A peripheral surface (10) extends around the cutting insert between two major faces (2, 3) and has two longer main side faces (11, 12) and two shorter main side faces (13, 14). A main cutting edge (31-34) is formed at an intersection between each longer main side face (11, 12) and each major face (2, 3). An inclined chip guiding surface (41-44) extends between each shorter main side face (13, 14) and each major face (2, 3). Each chip guiding surface intersects an abutment surface (5a, 5b) of the adjacent major face on both sides of a longitudinal centre plane of the cutting insert. The invention also relates to a helical milling cutter comprising a plurality of such cutting inserts.
A processing tool includes a tool body having a front end surface, a rear end surface, at least one side surface connecting the front end surface and the rear end surface, and a first coupling part extending between a first end and a second end. The first end is disposed at the rear end surface, the first coupling part being one of a female coupling part and a male coupling part. The first coupling part includes a first identification marker having identification information of the processing tool. A processing tool assembly is also provided, wherein the first coupling part is arranged to be coupled to a second coupling part. The first identification marker is positioned at the first coupling part such that it is positioned in an interface between the first coupling part and the second coupling part when the first coupling part is coupled to the second coupling part.
A sintered polycrystalline cubic boron nitride (PCBN) body includes between 40 and 85 vol % of cubic boron nitride (cBN) particles and between 15 and 60 vol % of a binder phase. The binder phase has at least one metal oxide and at least one metal nitride. The metal oxide includes between 20 and 100 vol % of zirconium oxide (ZrO2) and up to 80 vol % of alumina (Al2O3) counted as a volume percentage of the total metal oxide content of the binder phase. The metal nitride includes aluminium nitride (AlN) and at least one metal nitride selected from the group consisting of vanadium nitride (VN), niobium nitride (NbN) and hafnium nitride (HfN). The content of the selected metal nitride selected is at least 10 vol % of the total binder phase, and the content of the metal oxide is at least 10 vol % of the total binder phase.
C04B 35/5831 - Shaped ceramic products characterised by their compositionCeramic compositionsProcessing powders of inorganic compounds preparatory to the manufacturing of ceramic products based on non-oxides based on borides, nitrides or silicides based on boron nitride based on cubic boron nitride
C04B 35/626 - Preparing or treating the powders individually or as batches
C04B 35/63 - Preparing or treating the powders individually or as batches using additives specially adapted for forming the products
Disclosed is a detachable build plate (100) for additive manufacturing adapted to be inserted into a recess (210) of a bottom plate (200), wherein the detachable build plate (100) comprises a build area (110) for additively manufacturing thereon.
B33Y 30/00 - Apparatus for additive manufacturingDetails thereof or accessories therefor
B22F 10/14 - Formation of a green body by jetting of binder onto a bed of metal powder
B22F 10/28 - Powder bed fusion, e.g. selective laser melting [SLM] or electron beam melting [EBM]
B29C 64/153 - Processes of additive manufacturing using only solid materials using layers of powder being selectively joined, e.g. by selective laser sintering or melting
B29C 64/165 - Processes of additive manufacturing using a combination of solid and fluid materials, e.g. a powder selectively bound by a liquid binder, catalyst, inhibitor or energy absorber
A milling tool body (2) for a milling tool (1), the milling tool body (2) comprising: - an axial front end surface (3), - an axial rear end surface (4), - a peripheral mantle surface (10) extending between the axial front end surface (3) and the axial rear end surface (4), - a front end (2a), - a rear end (2b) being configured for attachment of the milling tool (1) to a machine, - at least two insert seats (20) and associated chip pocket being entirely provided in the front end (2a), wherein a cooling duct system (50) contained in the milling tool body (2) is extending from at least one coolant inlet (30) arranged in a first ring-shaped section (11) of the peripheral mantle surface (10) to at least one coolant outlet (40) arranged in a second ring-shaped section (12) of the peripheral mantle surface. The first and the second ring-shaped section are flanked by sealing surfaces formed as surfaces of revolution, preferably as circular cylindrical surfaces.
The invention is related to a cutting insert (100) comprising a first main surface (102), a second main surface (104), and at least one side surface (106) connecting the first main surface (102) and the second main surface (104), wherein the cutting insert (100) comprises at least one abutment surface (110,112) configured to abut a support surface (204,206,208) in a toolholder (200) or a clamping surface (302) at a fastening element (300), wherein the cutting insert (100) further comprises a through hole (130) extending from the first main surface (102) to the second main surface (104), wherein the cutting insert (100) further comprises at least one identification marker (114,116) in form of a one-dimensional or two-dimensional optical machine-readable code, wherein the at least one identification marker (114,116) has a polygonal shape, wherein the at least one abutment surface (110,112) comprises at least one recess (118,120) comprising a bottom surface (122,124) located a distance d from the abutment surface (110,112) in a direction perpendicular to the abutment surface (110,112), and wherein the at least one identification marker (114,116) is engraved or imprinted in the bottom surface (122,124). The invention also relates to a cutting tool (400) comprising such a cutting insert (100).
The present invention relates to a sintering furnace (100) for sintering of green compacts comprising a retort (9); and i) an inlet for furnace atmosphere gas at one end of the retort (9); ii) a stack of sintering trays (1, 2, 3, 4, 5, 6) comprising central openings (11) arranged in the interior of the retort (9), said central openings (11) having an area A for transfer of the furnace atmosphere gas introduced through the inlet, wherein neighbouring sintering trays of said stack are spaced apart at a predetermined distance from one another whereby an interspace (16) is provided between said neighbouring sintering trays, said interspace (16) being enclosed by a peripheral wall (15) provided with distributed holes (10) for transfer of the furnace atmosphere gas between the interspace (16) interior of the peripheral wall (15) and the space exterior to the peripheral wall (15), wherein the ratio of the area A of each individual central opening (11) to the total area of the distributed holes (10) between each individual pair of neighbouring sintering trays ranges from 1:10 to 10:1; iii) an outlet for withdrawal of the furnace atmosphere gas at an end of the retort (9) opposite to the end of the inlet, said inlet and outlet being arranged at opposite ends of the stack of sintering trays (1, 2, 3, 4, 5, 6). The invention also relates to a method for sintering green compacts in the sintering furnace (100) and to sintered compacts obtainable by the method.
F27B 5/16 - Arrangements of air or gas supply devices
F27D 5/00 - Supports, screens or the like for the charge within the furnace
B22F 3/00 - Manufacture of workpieces or articles from metallic powder characterised by the manner of compacting or sinteringApparatus specially adapted therefor
A tool includes a cemented carbide part and a steel part joined by brazing, where the steel part has an average hardness of between 390 and 510 HV30. The braze joint includes Ti and a TiC layer, with a thickness of between 0.03 and 5 μm, adjoining to the cemented carbide part. The tool provides a strong braze joint and a steel part that have an even hardness.
A cutting tool insert has an optimal hardness and high toughness for demanding cutting operations in hardened steel and cast iron. The cutting tool includes a substrate of cemented carbide where the cemented carbide has hard constituents of tungsten carbide (WC) and a (Co) binder phase, chromium (Cr) and at least one additional element from the group: Vanadium (V), Niobium (Nb), Molybdenum (Mo) and Iron (Fe). The cemented carbide further has a Co-content of 3.50-4.20 wt % of the cemented carbide, a Cr-content of 0.31-0.38 wt % of the cemented carbide, a WC-content of at least 95.22 wt % of the cemented carbide and wherein the cemented carbide has a coercivity of 26-32 kA/m
B22F 5/00 - Manufacture of workpieces or articles from metallic powder characterised by the special shape of the product
B22F 3/16 - Both compacting and sintering in successive or repeated steps
B22F 9/02 - Making metallic powder or suspensions thereofApparatus or devices specially adapted therefor using physical processes
B22F 9/04 - Making metallic powder or suspensions thereofApparatus or devices specially adapted therefor using physical processes starting from solid material, e.g. by crushing, grinding or milling
B23B 27/14 - Cutting tools of which the bits or tips are of special material
C22C 1/051 - Making hard metals based on borides, carbides, nitrides, oxides or silicidesPreparation of the powder mixture used as the starting material therefor
C22C 29/06 - Alloys based on carbides, oxides, borides, nitrides or silicides, e.g. cermets, or other metal compounds, e. g. oxynitrides, sulfides based on carbides or carbonitrides based on carbides, but not containing other metal compounds
C22C 29/08 - Alloys based on carbides, oxides, borides, nitrides or silicides, e.g. cermets, or other metal compounds, e. g. oxynitrides, sulfides based on carbides or carbonitrides based on carbides, but not containing other metal compounds based on tungsten carbide
C23C 14/06 - Coating by vacuum evaporation, by sputtering or by ion implantation of the coating forming material characterised by the coating material
33.
A CUTTING TOOL COMPRISING A CUTTING EDGE AND A METHOD FOR INDEXING SUCH A CUTTING EDGE
The invention is related to a cutting tool (100) comprising a toolholder body (110), a cutting unit (120), a clamp (160) having a clamping surface (162), and a fastening element (180), wherein the cutting unit (120) is secured in the toolholder body (110) by the fastening element (180) which is adjustable to generate a clamping force acting on the clamp (160) to press the clamping surface (162) toward the cutting unit (120). The cutting unit (120) comprises a circular cutting edge (124) comprising a plurality of cutting edge portions (126). The cutting tool (100) is configured to be shifted between an operation state and an indexing state by adjusting the fastening element (180) to provide a corresponding clamping force, wherein the cutting tool (100) further comprises a resilient element (190) connecting the clamp (160) with the toolholder body (110), wherein the resilient element (190) is configured to generate a biasing force acting on the clamp (160) to press the clamping surface (162) towards the cutting unit top surface (130), wherein ‐in the operation state, the clamping force is larger than the biasing force, ‐in the indexing state, the clamping force is smaller than the biasing force. The invention also relates to a method (200) for indexing the cutting edge (124) in the cutting tool (100).
A coated cutting tool and a method to manufacture, and the use of the same is provided. The coated cutting tool includes of a substrate and a coating including a physical vapor deposition (PVD) deposited Ti,Al-based nitride layer having a thickness of at least 1.0 μm. The PVD deposited Ti,Al-based nitride layer has at least one layer of TiAlN. The coating further includes a CVD deposited layer of TiN located between the substrate and the PVD deposited Ti,Al-based nitride layer. The CVD deposited layer of TiN is in contact with both the substrate and the PVD deposited Ti,Al-based nitride layer. The method for manufacturing a coated cutting tool includes growing a TiN layer by CVD on the substrate, and growing a Ti,Al-based nitride layer by PVD on the TiN layer.
C23C 28/04 - Coating for obtaining at least two superposed coatings either by methods not provided for in a single one of main groups , or by combinations of methods provided for in subclasses and only coatings of inorganic non-metallic material
B23B 27/14 - Cutting tools of which the bits or tips are of special material
C23C 14/06 - Coating by vacuum evaporation, by sputtering or by ion implantation of the coating forming material characterised by the coating material
C23C 14/32 - Vacuum evaporation by explosionVacuum evaporation by evaporation and subsequent ionisation of the vapours
A cutting insert includes a first and a second pair of opposing side surfaces. As seen towards a first side surface, a first axial relief face and a first axial abutment face form part of a first surface grouping on a first side of a longitudinal plane. As seen towards a second side surface, a second axial relief face and a second axial abutment face form part of a second surface grouping on the first side of the longitudinal plane. The first axial abutment face forms a substantially flat surface and extends perpendicularly to a median plane of the insert. The second axial abutment face forms a substantially flat surface and extends perpendicularly to the median plane. A second side surface of the first pair of opposing side surfaces has a first and a second radial abutment face.
The present invention relates to a moulding tool assembly (5) for powder injection moulding a component (1), a method for manufacturing a component (1), and the component obtainable therefrom, wherein the moulding tool assembly (5) comprises i) at least a first and a second tool part (21, 22, 22a, 22b, 23, 24) arranged to define a mould cavity (25) for forming a component (1) ii) an inlet channel (30) for filling the mould cavity (25) with moulding material (3), the inlet channel (30) extending through an opening in the first tool part (21) to the mould cavity (25) and comprising an outlet end (33) having an outlet opening (34) for discharging the moulding material (3) from the inlet channel (30) into the mould cavity (25); iii) a core pin (40) extending through an opening in the second tool part (22, 22a, 22b), the core pin (40) being movable between a rear end position and a front end position along a horizontal axis extending through the centre of the core pin (40) and the centre of the inlet channel (30), the core pin (40) comprising an end portion (41) having an end surface (42) facing the outlet opening (34); the core pin (40) being configured to seal the opening in the second tool part (22, 22a, 22b) with the end portion (41) thereof when the core pin (40) is positioned in its rear end position; and wherein the core pin (40) in its front end position is positioned such that moulding material (3) entering the mould cavity (25) impinges on it; and iv) a power source (43) configured to maintain the core pin (40) in its front end position until a predetermined pressure threshold is exceeded during filling of the mould cavity (25) moving the core pin (40) to the rear end position; or v) a power source (43) configured to maintain the core pin (40) in its front end position a predetermined time and to move the core pin (40) to the rear end position after the predetermined time.
B22D 17/10 - Cold chamber machines, i.e. with unheated press chamber into which molten metal is ladled with horizontal press motion
B22D 17/20 - AccessoriesPressure die casting or injection die casting, i.e. casting in which the metal is forced into a mould under high pressure Details
B22D 17/22 - DiesDie platesDie supportsCooling equipment for diesAccessories for loosening and ejecting castings from dies
B22D 17/24 - Accessories for locating and holding cores or inserts
B22D 46/00 - Controlling, supervising, not restricted to casting covered by a single main group, e.g. for safety reasons
B22F 3/22 - Manufacture of workpieces or articles from metallic powder characterised by the manner of compacting or sinteringApparatus specially adapted therefor for producing castings from a slip
B28B 1/24 - Producing shaped articles from the material by injection moulding
B28B 13/02 - Feeding the unshaped material to moulds or apparatus for producing shaped articles
B22F 5/00 - Manufacture of workpieces or articles from metallic powder characterised by the special shape of the product
C22C 29/02 - Alloys based on carbides, oxides, borides, nitrides or silicides, e.g. cermets, or other metal compounds, e. g. oxynitrides, sulfides based on carbides or carbonitrides
A face milling cutter includes a tool body, several primary cutting inserts mounted in a respective primary insert seat, a reference insert mounted in a reference insert seat, and a finishing insert mounted in a finishing insert seat. The reference and primary cutting inserts are configured to be detachably mounted in their insert seats in a fixed position as seen in the axial direction of the tool body. The reference insert seat is arranged more forwardly in the tool body than the primary insert seats such that the reference insert projects forwards from the tool body beyond the axially foremost point of each primary cutting insert. The position of the finishing insert is adjustable by an adjustment mechanism to allow it to be positioned with its axially foremost point substantially in level with or more forwardly than the axially foremost point of the reference insert.
A thread milling tool includes a tool body with at least one pair of insert seats including of a first insert seat and a second insert seat, which are angularly and axially offset from each other, and several double-sided thread milling inserts. Each thread milling inserts is adapted to the first and second insert seats such that it is mountable in the first insert seat in one single working position with a first group of cutting edges on a first side of the thread milling insert in an active cutting position, and mountable in the second insert seat in one single working position with a second group of cutting edges on an opposite second side of the thread milling insert in an active cutting position. A thread milling insert suitable for use in such a thread milling tool is also provided.
111. The insert pocket (220) comprises at least one pocket support element (226) being any of: • a protrusion engaging with the indention in the second main surface (304), or • an indention engaging with the protrusion at the second main surface (304), wherein the insert support element (308) comprises an insert support surface (332), and wherein the pocket support element (226) comprises a pocket support surface (228), wherein the insert support surface (332) is in contact with the pocket support surface (228), wherein the insert support surface (332) contacts the pocket support surface (228) in a plurality of contact regions (230,232,234,236), wherein each contact region (230,232,234,236) is separated from the other contact regions.
The present invention realties to a boring head for holding a boring tool for metal cutting. The boring head comprises a main body, which comprises a support surface (25) and a scale surface. The boring head further comprises a piston (6) comprising a boring tool interface for fixedly carrying the boring tool, wherein the piston (6) is movably arranged in the main body along the positioning axis (y), and a micrometer screw (19). The micrometer screw (19) is arranged in the main body and coupled to the piston (6), such that, when the micrometer screw (19) is rotated, the piston (6) is moved along the positioning axis to one of the protracted positions or the retracted position. The micrometer screw (19) comprises a head (21) abutting against the support surface (25), which head (21) comprises a radially outer head surface (26) provided with first graduation marks (23). The scale surface is provided with second graduation marks (29), which second graduation marks (29) align with the first graduation marks (23) to provide a reading of the axial position of the piston (6). The scale surface is a convexly rounded bevel surface (28) with an arc-shaped edge (32) at the head surface (26).
The invention is related to a toolholder (100) for use with a cutting element (200) in a cutting process, wherein the toolholder (100) comprises at least one sensor (114) for detecting an environmental condition; wherein the toolholder (100) comprises a control unit (116) operatively connected to the at least one sensor (114), wherein the control unit (116) comprises a crossbar array (118) of resistive memory devices, and a power source (120) operatively connected to the crossbar array (118), wherein the crossbar array (18) comprises a neural network stored thereon, and wherein the neural network is adapted to determine a condition of the cutting element (200) or of the cutting process based on the environmental condition detected by the at least one sensor (114). The invention also relates to a cutting tool (300) and to a cutting tool assembly (500).
B23Q 17/09 - Arrangements for indicating or measuring on machine tools for indicating or measuring cutting pressure or cutting-tool condition, e.g. cutting ability, load on tool
G05B 19/406 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by monitoring or safety
A double-sided cutting insert for milling includes first and second major faces, a peripheral surface arranged between the major faces and including a first main side face, a first main cutting edge formed at an intersection between the first main side face and the first major face, a second main cutting edge formed at an intersection between the first main side face and the second major face, first and second inclined side surfaces, which are formed on the first main side face and which are inclined towards each other to form a depression on the first main side face, and a chip deflecting member formed on the first main side face as a protrusion across the depression and which includes a chip deflecting surface configured to deflect chips, which hit the first main side face, away from the depression.
The disclosure relates to a method, computer program product and system for decreasing the risk of erroneously handling a tool in a machine operation. The system includes a reader device for reading a machine readable code arranged at a tool part and an electronic device having a processing circuitry configured to cause the system to receive desired operation data indicative of a tool part to be used during the machine operation. The method includes the steps of receiving desired operation data indicative of the tool part to be used during the machine operation, detecting the identification marker at the tool part, reading, by the reader device, the machine readable code of the identification marker, identifying the tool part, and determining if the identified tool part corresponds to the tool part according to the desired operation data, the identification marker being a machine readable code associated with the tool part.
A method and a system for controlling a machining process of a workpiece is provided. First, information regarding a first set of cutting parameters used during the machining process of the workpiece is obtained. Thereafter, imaging data of at least one chip produced during the machining process of the workpiece is obtained. A chip type of the at least one chip is determined based on the obtained imaging data, and a relation between cutting parameters and chip type is determined based on the used first set of cutting parameters and determined chip type. The relation between cutting parameters and chip type is used to control a subsequent machining process of a workpiece.
G05B 19/401 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by control arrangements for measuring, e.g. calibration and initialisation, measuring workpiece for machining purposes
A face milling cutter (1) comprising: • a tool body (2); • at least two cutting inserts (20) for forming a milled flat surface on a workpiece and mounted in a respective insert seat (10) in the tool body, each cutting insert having a secondary cutting edge (22) that constitutes the axially foremost cutting edge of the cutting insert; and • several burnishing assemblies (30) with a respective springloaded burnishing element (31) arranged in the tool body. The number of the burnishing assemblies (30) in the tool body (2) is the same as the number of insert seats (10), wherein the insert seats and the burnishing assemblies are alternately arranged in the circumferential direction of the tool body such that each one of the insert seats (10) is followed by an associated one of the burnishing assemblies (30) as seen in the intended direction of rotation of the tool body.
09 - Scientific and electric apparatus and instruments
35 - Advertising and business services
37 - Construction and mining; installation and repair services
40 - Treatment of materials; recycling, air and water treatment,
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
45 - Legal and security services; personal services for individuals.
Goods & Services
Machine tools; tools for machine tools for cutting,
machining, drilling, turning, milling, reaming and thread
cutting; indexable inserts for machine tools and cutting
tools [parts of machines] with indexable inserts; machine
tools holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the
aforesaid goods; computer software and programs; databases;
electronic databases; mobile apps; smart tags (or
transponders); bar code readers; computer hardware; data
communications hardware; downloadable software in the nature
of a mobile application, in particular for inventory
management, user support, and collecting and reporting
product information; data transmitting and receiving
apparatus and equipment for use with bar codes and/or all
optical identification systems. Commercial and industrial management assistance; advisory
services for business management; business management and
organization consultancy; advertising services; business
consultancy services relating to the selection of metal
working machines and tools; inventory control; business
consultancy; data processing services; business analysis,
research and information services; collection and
systematization of business data; provision of wholesale and
retail services, including such services being provided
online, related to products used in the metal working
industries; online retail services, namely, the provision
and operation of an online marketplace for buyers and
sellers of products for use within the metal working
industries; provision of e-commerce services for products
for use within the metal working industries, namely, the
provision and operation of an online marketplace for buyers
and sellers of products for use within the metal working
industries; e-commerce services, being business management
services relating to e-commerce in the metal working
industries; online ordering services; sales administration;
provision of customer support services and information
related to products for use within the metal working
industries; information, advisory, support and consultancy
services relating to the aforesaid; provision of an online
marketplace for buyers and sellers of downloadable digital
collectibles authenticated by non-fungible tokens (NFTs);
retail store services featuring virtual goods, namely,
metalworking machine tools and inserts, metalworking
machines, inventory management machines, electronic controls
and publications for use in online virtual worlds. Repair, maintenance, assembly and installation services in
the field of metal working industries; rebuild,
refurbishment, upgrade and custom engineering services of
products within the metal working industries; rental and
hire of products for use within the metal working
industries; rental of machine tools; repair of tools;
information, advisory, support and consultancy services
relating to the aforesaid. Grinding; providing material treatment information;
recycling of steel and other materials and products;
material treatment information; regrinding and recoating of
tools and machines; custom manufacture of power-operated
automation equipment; custom manufacturing of parts and
component made from common metals and their alloys;
information, advisory, support and consultancy services
relating to the aforesaid. Education; providing of training; education and training,
including online or virtual training, in the technical
field; education and training, including online training,
relating to product development, manufacturing and
inspection; training services, including online or virtual
training services, provided in relation to the metal working
industries; training services, including online or virtual
training services, provided in relation to products for use
within the metal working industries; practical training,
including online or virtual training, in the fields of
engineering and design; training services, including online
or virtual training services, in the fields of engineering
and design provided via simulators; training services,
including online or virtual training services, related to
use of software, hardware, equipment and tools for the metal
working industries; publication services for the metal
working industries; information, advisory, support and
consultancy services relating to the aforesaid;
entertainment services, namely, providing on-line,
non-downloadable files of virtual goods, namely,
metalworking machine tools and inserts, metalworking
machines, inventory management machines, publications and
artwork for use in virtual environments created for
entertainment purposes; providing on-line digital
publications, namely, digital art authenticated by
non-fungible tokens (nfts). Scientific and technological services and research and
design relating thereto; industrial analysis, industrial
research and industrial design services; quality control and
authentication services; design and development of computer
hardware and software; scientific and technological
services, namely, research and design in the field of tools
and tooling systems for industrial metal cutting, equipment
and tools; industrial research in the field of tools and
tooling systems for industrial metal cutting; computer
hardware and software design; computer software development;
testing, analysis, and evaluation of the goods of others to
assure compliance with industry standards; consulting
services in the field of design and development of
engineering processes; consumer product safety testing
consultation; measurement services; remote monitoring
services; chemical research and analysis; Software as a
Service (SaaS) and Platform as a Service (PaaS) services
featuring computer software platforms for a tool library;
technical support services for computer software for use in
the field of the metal working industries; services for
monitoring industrial processes; consulting services in the
field of cloud computing; technological consulting services,
namely, providing services related to geometrical
inspection, measurement, and analysis of industrial,
medical, and aerospace components parts and components;
hosting services; Software as a Service (SaaS) and Platform
as a Service (PaaS) services provided in relation to the
calculation of data for machine tools; providing temporary
use of on-line non-downloadable computer software, Software
as a Service (SaaS) and Platform as a Service (PaaS)
services provided in relation to the controlling of cutting
machines; providing temporary use of on-line
non-downloadable computer software, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to the nesting and programming of CNC cutting
machines; providing temporary use of on-line
non-downloadable computer software, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to the provision of engineering design and
engineering drafting services; providing temporary use of
on-line non-downloadable computer software, Software as a
Service (SaaS) and Platform as a Service (PaaS) services
provided in relation to the machine tool industry;
non-downloadable (on-line) software, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to products for use within the metal working
industries; providing automatic updates to applications and
software as a service (SaaS); updating of computer software
for others; updating and maintaining cloud-based computer
software through on-line updates, enhancements and patches;
performance monitoring services in the field of the metal
working industries; information, advisory, support and
consultancy services relating to the aforesaid; services for
minting [creation] non-fungible tokens [NFTs] using
blockchain technology; software as a service featuring
virtual products and marketplaces. Licensing; licensing of wireless communication systems;
licensing of intellectual property; licensing of computer
software; licensing of databases; licensing of technology.
09 - Scientific and electric apparatus and instruments
35 - Advertising and business services
36 - Financial, insurance and real estate services
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machine tools; tools for machine tools for cutting,
machining, drilling, turning, milling, reaming and thread
cutting; indexable inserts for tools for machine tools and
cutting tools [parts of machines] with indexable inserts;
machine tool holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the
aforesaid good; computer software and programs; databases;
electronic databases; mobile apps; smart tags (or
transponders); bar code readers; computer hardware; data
communications hardware; downloadable software in the nature
of a mobile application, in particular for inventory
management, user support, and collecting and reporting
product information; apparatus and equipment for use with
bar codes and/or all optical identification systems. Commercial and industrial management assistance; advisory
services for business management; business management and
organization consultancy; advertising services; business
consultancy services relating to the selection of metal
working machines and tools; inventory control; business
consultancy; data processing services; business analysis,
research and information services; collection and
systematization of business data; provision of wholesale and
retail services, including such services being provided
online, related to products used in the metal working
industries; online retail services, namely, the provision
and operation of an online marketplace for buyers and
sellers of products for use within the metal working
industries; provision of e-commerce services for products
for use within the metal working industries, namely, the
provision and operation of an online marketplace for buyers
and sellers of products for use within the metal working
industries; e-commerce services, being business management
services relating to e-commerce in the metal working
industries; online ordering services; sales administration;
provision of customer support services and information
related to products for use within the metal working
industries; information, advisory, support and consultancy
services relating to the aforesaid; provision of an online
marketplace for buyers and sellers of downloadable digital
collectibles authenticated by non-fungible tokens (NFTs);
retail store services featuring virtual goods, namely,
metalworking machine tools and inserts, metalworking
machines, inventory management machines, electronic controls
and publications for use in online virtual worlds. Issuance of tokens of value. Education; providing of training; education and training,
including online or virtual training, in the technical
field; education and training, including online training,
relating to product development, manufacturing and
inspection; training services, including online or virtual
training services, provided in relation to the metal working
industries; training services, including online or virtual
training services, provided in relation to products for use
within the metal working industries; practical training,
including online or virtual training, in the fields of
engineering and design; training services, including online
or virtual training services, in the fields of engineering
and design provided via simulators; training services,
including online or virtual training services, related to
use of software, hardware, equipment and tools for the metal
working industries; publication services for the metal
working industries; information, advisory, support and
consultancy services relating to the aforesaid;
entertainment services, namely, providing on-line,
non-downloadable files of virtual goods, namely,
metalworking machine tools and inserts, metalworking
machines, inventory management machines, publications and
artwork for use in virtual environments created for
entertainment purposes; providing on-line digital
publications, namely, digital art authenticated by
non-fungible tokens (NFTs). Scientific and technological services and research and
design relating thereto; industrial analysis, industrial
research and industrial design services; quality control and
authentication services; design and development of computer
hardware and software; scientific and technological
services, namely, research and design in the field of tools
and tooling systems for industrial metal cutting, equipment
and tools; industrial research in the field of tools and
tooling systems for industrial metal cutting; computer
hardware and software design; computer software development;
testing, analysis, and evaluation of the goods of others to
assure compliance with industry standards; consulting
services in the field of design and development of
engineering processes; consumer product safety testing
consultation; measurement services; remote monitoring
services; chemical research and analysis; Software as a
Service (SaaS) and Platform as a Service (PaaS) services
featuring computer software platforms for a tool library;
operational support services in the field of the metal
working industries; services for monitoring industrial
processes; consulting services in the field of cloud
computing; technological consulting services, namely,
providing services related to geometrical inspection,
measurement, and analysis of industrial, medical, and
aerospace components parts and components; hosting services;
Software as a Service (SaaS) and Platform as a Service
(PaaS) services provided in relation to the calculation of
data for machine tools; provision of online non-downloadable
software being application service provider, Software as a
Service (SaaS) and Platform as a Service (PaaS) services
provided in relation to the controlling of cutting machines;
provision of online non-downloadable software being
application service provider, Software as a Service (SaaS)
and Platform as a Service (PaaS) services provided in
relation to the nesting and programming of CNC cutting
machines; provision of online non-downloadable software
being application service provider, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to the provision of engineering design and
engineering drafting services; provision of online
non-downloadable software being application service
provider, Software as a Service (SaaS) and Platform as a
Service (PaaS) services provided in relation to the machine
tool industry; provision of online non-downloadable software
being application service provider, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to products for use within the metal working
industries; providing automatic updates to applications and
software as a service (SaaS); updating of computer software
for others; updating and maintaining cloud-based computer
software through on-line updates, enhancements and patches;
performance monitoring services in the field of the metal
working industries; information, advisory, support and
consultancy services relating to the aforesaid; services for
minting [creation] non-fungible tokens [NFTs] using
blockchain technology; software as a service featuring
virtual products and marketplaces.
09 - Scientific and electric apparatus and instruments
35 - Advertising and business services
37 - Construction and mining; installation and repair services
40 - Treatment of materials; recycling, air and water treatment,
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
45 - Legal and security services; personal services for individuals.
Goods & Services
Machine tools; tools for machine tools for cutting,
machining, drilling, turning, milling, reaming and thread
cutting; indexable inserts for tools for machine tools and
cutting tools [parts of machines] with indexable inserts;
machine tool holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the
aforesaid good; computer software and programs; databases;
electronic databases; mobile apps; smart tags (or
transponders); bar code readers; computer hardware; data
communications hardware; downloadable software in the nature
of a mobile application, in particular for inventory
management, user support, and collecting and reporting
product information; apparatus and equipment for use with
bar codes and/or all optical identification systems. Commercial and industrial management assistance; advisory
services for business management; business management and
organization consultancy; advertising services; business
consultancy services relating to the selection of metal
working machines and tools; inventory control; business
consultancy; data processing services; business analysis,
research and information services; collection and
systematization of business data; provision of wholesale and
retail services, including such services being provided
online, related to products used in the metal working
industries; online retail services, namely, the provision
and operation of an online marketplace for buyers and
sellers of products for use within the metal working
industries; provision of e-commerce services for products
for use within the metal working industries, namely, the
provision and operation of an online marketplace for buyers
and sellers of products for use within the metal working
industries; e-commerce services, being business management
services relating to e-commerce in the metal working
industries; online ordering services; sales administration;
provision of customer support services and information
related to products for use within the metal working
industries; information, advisory, support and consultancy
services relating to the aforesaid; provision of an online
marketplace for buyers and sellers of downloadable digital
collectibles authenticated by non-fungible tokens (NFTs);
retail store services featuring virtual goods, namely,
metalworking machine tools and inserts, metalworking
machines, inventory management machines, electronic controls
and publications for use in online virtual worlds. Repair, maintenance, assembly and installation services in
the field of metal working industries; rebuild,
refurbishment and maintenance services of products within
the metal working industries; rental and hire of products
for use within the metal working industries; rental of
machine tools; repair of tools; information, advisory,
support and consultancy services relating to the aforesaid. Grinding; providing material treatment information;
recycling of steel and other materials and products;
material treatment information; regrinding and recoating of
tools and machines; custom manufacture of power-operated
automation equipment; custom manufacturing of parts and
component made from common metals and their alloys;
information, advisory, support and consultancy services
relating to the aforesaid. Education; providing of training; education and training,
including online or virtual training, in the technical
field; education and training, including online training,
relating to product development, manufacturing and
inspection; training services, including online or virtual
training services, provided in relation to the metal working
industries; training services, including online or virtual
training services, provided in relation to products for use
within the metal working industries; practical training,
including online or virtual training, in the fields of
engineering and design; training services, including online
or virtual training services, in the fields of engineering
and design provided via simulators; training services,
including online or virtual training services, related to
use of software, hardware, equipment and tools for the metal
working industries; publication services for the metal
working industries; information, advisory, support and
consultancy services relating to the aforesaid;
entertainment services, namely, providing on-line,
non-downloadable files of virtual goods, namely,
metalworking machine tools and inserts, metalworking
machines, inventory management machines, publications and
artwork for use in virtual environments created for
entertainment purposes; providing on-line digital
publications, namely, digital art authenticated by
non-fungible tokens (NFTs). Scientific and technological services and research and
design relating thereto; industrial analysis, industrial
research and industrial design services; quality control and
authentication services; design and development of computer
hardware and software; scientific and technological
services, namely, research and design in the field of tools
and tooling systems for industrial metal cutting, equipment
and tools; industrial research in the field of tools and
tooling systems for industrial metal cutting; computer
hardware and software design; computer software development;
testing, analysis, and evaluation of the goods of others to
assure compliance with industry standards; consulting
services in the field of design and development of
engineering processes; consumer product safety testing
consultation; measurement services; remote monitoring
services; chemical research and analysis; Software as a
Service (SaaS) and Platform as a Service (PaaS) services
featuring computer software platforms for a tool library;
operational support services in the field of the metal
working industries; services for monitoring industrial
processes; consulting services in the field of cloud
computing; technological consulting services, namely,
providing services related to geometrical inspection,
measurement, and analysis of industrial, medical, and
aerospace components parts and components; hosting services;
Software as a Service (SaaS) and Platform as a Service
(PaaS) services provided in relation to the calculation of
data for machine tools; provision of online non-downloadable
software being application service provider, Software as a
Service (SaaS) and Platform as a Service (PaaS) services
provided in relation to the controlling of cutting machines;
provision of online non-downloadable software being
application service provider, Software as a Service (SaaS)
and Platform as a Service (PaaS) services provided in
relation to the nesting and programming of CNC cutting
machines; provision of online non-downloadable software
being application service provider, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to the provision of engineering design and
engineering drafting services; provision of online
non-downloadable software being application service
provider, Software as a Service (SaaS) and Platform as a
Service (PaaS) services provided in relation to the machine
tool industry; provision of online non-downloadable software
being application service provider, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to products for use within the metal working
industries; providing automatic updates to applications and
software as a service (SaaS); updating of computer software
for others; updating and maintaining cloud-based computer
software through on-line updates, enhancements and patches;
performance monitoring services in the field of the metal
working industries; information, advisory, support and
consultancy services relating to the aforesaid; services for
minting [creation] non-fungible tokens [NFTs] using
blockchain technology; software as a service featuring
virtual products and marketplaces; custom engineering
services of products within the metal working industries. Licensing; licensing of wireless communication systems;
licensing of intellectual property; licensing of computer
software; licensing of databases; licensing of technology.
49.
Tool part, system, method, and a computer program for determining a dimension of the tool part
A system for utilizing an identification marker on a tool part for determining a dimension thereof. The system includes a reader device for reading a machine readable code, and an electronic device connected to the reader device. The electronic device has a processing circuitry that causes the system to detect with the reader device, an identification marker at a tool part, wherein the identification marker is a unique machine readable code read by the reader device, and the unique machine readable code of the identification marker, and obtain from the unique machine readable code, individual dimension information data including at least one individually measured dimension of the tool part measured when manufacturing the tool part. A method and a computer program product for utilizing an identification marker on a tool part to be used for determining a dimension of the tool part and to a tool part is also provided.
G05B 19/12 - Programme control other than numerical control, i.e. in sequence controllers or logic controllers using record carriers
G06K 7/10 - Methods or arrangements for sensing record carriers by electromagnetic radiation, e.g. optical sensingMethods or arrangements for sensing record carriers by corpuscular radiation
50.
DRILL BODY OF AN INDEXABLE INSERT DRILL AND INDEXABLE INSERT DRILL COMPRISING SUCH A DRILL BODY
A drill body (2) of an indexable insert drill comprising: - at least two chip flutes (10a, 10b) separated from each other in the circumferential direction of the drill body by intermediate ribs (12a, 12b), each chip flute and each rib extending in a helically curved path; - an insert seat located at a transition between each chip flute and a front face of the drill body; and - coolant ducts (20a, 20b) arranged in and extending along a respective one of said ribs (12a, 12b), each coolant duct extending in a helically curved path and having an upstream end (21) with an inlet opening (24a, 24b) and a downstream end (22) with an outlet opening (25a, 25b). Each coolant duct has a cross-sectional area that varies in the axial direction of the coolant duct such that it has a smaller cross-sectional area at its outlet opening than at its inlet opening.
A nozzle is arranged to provide coolant fluid to a cutting edge of a metal cutting tool. The nozzle includes at least one internal inlet coolant channel and at least one internal outlet coolant channel. The internal inlet coolant channel is connected to a coolant inlet and the at internal outlet coolant channel is connected to a coolant outlet for directing the coolant fluid to the cutting edge. The nozzle further includes a plenum chamber having at least one inlet opening connecting the internal inlet coolant channel and the plenum chamber and at least one outlet opening connecting the internal outlet channel and the plenum chamber. Each of the inlet openings have a cross-sectional area A1i and each of the outlet openings have a cross-sectional area A2i, wherein—Σi=1nA1i>Σi=1mA2i, where i is an integer, n is the number of inlet openings, and m is the number of outlet openings.
The disclosure relates to a tool part for a cutting tool having an identification marker arranged at the tool part, wherein the identification marker is a unique machine readable code associated with individual dimension information data. The individual dimension information data includes at least one individually measured dimension of the tool part as measured when manufacturing the tool part that will change while wearing the tool part. The disclosure further relates to a system, a method and computer program product for utilizing an identification marker on a tool part for a cutting tool, for determining a tool wear of the tool part.
G06K 7/14 - Methods or arrangements for sensing record carriers by electromagnetic radiation, e.g. optical sensingMethods or arrangements for sensing record carriers by corpuscular radiation using light without selection of wavelength, e.g. sensing reflected white light
B23B 49/00 - Measuring or gauging equipment on boring machines for positioning or guiding the drillDevices for indicating failure of drills during boringCentring devices for holes to be bored
G06K 19/06 - Record carriers for use with machines and with at least a part designed to carry digital markings characterised by the kind of the digital marking, e.g. shape, nature, code
A double-sided tangential cutting insert with eight different working positions comprising: - two opposite end faces (2, 3) serving as leading and trailing faces of the cutting insert; - two opposite major side faces (5, 6); - two opposite minor side faces (7, 8); - a through hole (14) extending between the two major side faces (5, 6); - cutting edges distributed along a periphery of each end face (2, 3); - four abutment surfaces (41-44) arranged on each end face in a grid-like pattern with two first arrays, each of which comprising two consecutive abutment surfaces and extending between the two major side faces (5, 6), and two second arrays (A2), each of which comprising two consecutive abutment surfaces and extending between the two minor side faces (7, 8), each abutment surface being inclined inwards in the cutting insert such that each two consecutive abutment surfaces in each array (A1, A2) are inclined towards each other.
The disclosure relates to a method, an electronic device and a computer program product for reducing a carbon dioxide footprint associated with a production process. The carbon dioxide footprint has at least an amount of carbon dioxide emitted during the production process. The method includes the step of obtaining a parameter indicative of a selected cutting feature for production by a cutting tool, the step of obtaining a parameter indicative of a selected work-piece material for production by a cutting tool, the step of determining a set of cutting tools for production based on the obtained parameters, and the step of determining a cutting tool for production from the determined set of cutting tools based on carbon dioxide emission information data associated with each cutting tool in the determined set of cutting tools.
G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]
An anvil for a cutting tool includes an anvil body. A curved passage extends from an inlet opening in the anvil body to an outlet opening in the anvil body. The anvil body can be made by an additive manufacturing process. The anvil body includes a top surface, a bottom surface, and a side surface between the top surface and the bottom surface. The side surface includes at least three side surface portions and at least three corner portions. Each corner portion is disposed between respective pairs of the side surface portions. At least one corner portion includes a surface that extends radially outward from a central axis of the anvil relative to extensions of a respective pair of side surface portions. The central axis extends between the top and bottom surfaces, wherein the extensions of the respective pair of side surface portions intersect within the periphery of the anvil.
Machine tools; tools for machine tools for cutting,
machining, drilling, turning, milling, reaming and thread
cutting; indexable inserts for tools for machine tools and
cutting tools [parts of machines] with indexable inserts;
machine tools holders; parts for the aforesaid goods. Commercial and industrial management assistance; advisory
services for business management; business management and
organization consultancy; advertising services; business
consultancy services relating to the selection of metal
working machines and tools; inventory control; business
consultancy; data processing services; business analysis,
research and information services; collection and
systematization of business data; e-commerce services, being
business management services relating to e-commerce in the
metal working industries; online ordering services; sales
administration; provision of customer support services and
information related to products for use within the metal
working industry.
57.
A SYSTEM AND A METHOD FOR DETERMINING A SETTING OF A CUTTING TOOL
The invention relates to a system (100,200,300) for determining a setting of a cutting tool (102,202,302). The cutting tool (102,202,302) comprises a first tool part (103,203,303) and a second tool part (104,204,304). The first tool part (103,203,303) is a non-adjustable tool part, and the second tool part (104,204,304) is radially and/or axially adjustable relative the first tool part (103,203,303). The system (100,200,300) comprises a processing circuit (109,209,309) configured to cause the system to obtain first position data comprising information regarding a first position (107,207,307) at the first tool part (103,203,303), and second position data comprising information regarding a second position (108,208,308) at the second tool part (104,204,304). The system (100,200,300) is further configured to determine a distance and a direction between the first position (107,207,307) and the second position (108,208,308). The system (100,200,300) is configured to determine a setting of the cutting tool (102,202,302) based at least on the determined distance and direction between the first position (107,207,307) and the second position (108,208,308). The invention also relates to a method (400) for determining a setting of a cutting tool (102,202,302).
B23C 5/24 - Securing arrangements for bits or teeth adjustable
G05B 19/4093 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by part programming, e.g. entry of geometrical information as taken from a technical drawing, combining this with machining and material information to obtain control information, named part programme, for the NC machine
G05B 19/401 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by control arrangements for measuring, e.g. calibration and initialisation, measuring workpiece for machining purposes
58.
Rotary cutting tool with continuous major flutes and discontinuous minor flutes intersecting to form quadrilateral-shaped face portions
Rotary cutting tool (100) having plurality of major flutes (130) arranged helically opposite to plurality of discontinuous minor flutes (135) and intersecting to form plurality of teeth. Each tooth includes a first cutting edge formed with the major flute and a second cutting edge formed with the minor flute, the first and second cutting edges meeting at an apex and form part of a periphery of a quadrilateral-shaped face portion. The face portion has non-planar surfaces extending from the respective first and second cutting edges that define a relief surface of each cutting edge. First and second cutting edges are arranged on an imaginary cylinder having a center axis coaxial with the axis of rotation of the tool and respective relief surfaces are radially inward of a surface of the imaginary cylinder such that the first and second cutting edges each have a clearance in a rotational direction of the tool.
The invention relates to a system for determining contact between a cutting tool (10) and an electrically conductive workpiece (20). The cutting tool (10) comprises a toolholder (11) and n cutting inserts (12,13,14,15) mounted in the toolholder (11), wherein n is an integer ≥ 2, 5 wherein each of the n cutting inserts (12,13,14,15) comprises an electrically conductive surface layer. Each of the n cutting inserts (12,13,14,15) are electrically insulated from the toolholder (11). The system further comprises an electric power source (31) and each of the n cutting inserts (12,13,14,15) are connected in parallel to a first pole (48) of the electric power source (31) via a respective first connection unit (32, 33, 34, 35) comprising a resistor 10 (44, 45, 46, 47). The system further comprises a second connection unit (49) connected to a second pole of the electric power source (31). The second connection unit (49) being configured to be electrically connected to an electrically conductive workpiece (20). The system further comprises a measuring unit (60) being operatively connected to an analysis unit (70). The measuring unit (60) is configured to measure an electrical voltage (UR44, UR45, UR46, UR47) over each of the first connection units (32, 33, 34, 35), and the analysis unit (70) is configured to determine a contact between the cutting tool (10) and an electrically conductive workpiece (20) based on the measured electrical voltages (UR44, UR45, UR46, UR47). The invention also relates to a method for determining contact between a cutting tool (10) and an electrically conductive workpiece (20).
A cutting tool comprising: • - a tool body (2) with an insert seat (10) and an associated clamp pocket (20); • - a cutting insert (30) releasably mountable in the insert seat; • - a clamp (40) received in the clamp pocket; and • - a screw (60) that extends with play through a through hole (47) in the clamp and is engaged in a hole (22) at the bottom of the clamp pocket. Upon tightening of the screw, the clamp will slide against an inclined guide surface (26) in the slide pocket via a slide surface (46) on the clamp, which will force the clamp to move transversally to the screw shaft (61) towards the cutting insert such that a clamp protrusion (45) on the clamp is moved into a recess (37) in the cutting insert and clamping surfaces on the clamp are pressed tightly against corresponding contact surfaces on the cutting insert.
(1) Machine tools; tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts; machine tools holders; parts for the aforesaid goods. (1) Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business analysis, research and information services; collection and systematization of business data; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services; sales administration; provision of customer support services and information related to products for use within the metal working industry.
09 - Scientific and electric apparatus and instruments
35 - Advertising and business services
36 - Financial, insurance and real estate services
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
Goods & Services
(1) Machine tools; tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts; machine tool holders; parts for the aforesaid goods.
(2) Electric and electronic machine tool controls; parts for the aforesaid good; computer software and programs; databases; electronic databases; mobile apps; smart tags (or transponders); bar code readers; computer hardware; data communications hardware; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information; apparatus and equipment for use with bar codes and/or all optical identification systems. (1) Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business analysis, research and information services; collection and systematization of business data; provision of wholesale and retail services, including such services being provided online, related to products used in the metal working industries; online retail services, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; provision of e-commerce services for products for use within the metal working industries, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services; sales administration; provision of customer support services and information related to products for use within the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and publications for use in online virtual worlds.
(2) Issuance of tokens of value.
(3) Education; providing of training; education and training, including online or virtual training, in the technical field; education and training, including online training, relating to product development, manufacturing and inspection; training services, including online or virtual training services, provided in relation to the metal working industries; training services, including online or virtual training services, provided in relation to products for use within the metal working industries; practical training, including online or virtual training, in the fields of engineering and design; training services, including online or virtual training services, in the fields of engineering and design provided via simulators; training services, including online or virtual training services, related to use of software, hardware, equipment and tools for the metal working industries; publication services for the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, publications and artwork for use in virtual environments created for entertainment purposes; providing on-line digital publications, namely, digital art authenticated by non-fungible tokens (NFTs).
(4) Scientific and technological services and research and design relating thereto; industrial analysis, industrial research and industrial design services; quality control and authentication services; design and development of computer hardware and software; scientific and technological services, namely, research and design in the field of tools and tooling systems for industrial metal cutting, equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services; remote monitoring services; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for a tool library; operational support services in the field of the metal working industries; services for monitoring industrial processes; consulting services in the field of cloud computing; technological consulting services, namely, providing services related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components parts and components; hosting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the calculation of data for machine tools; provision of online non-downloadable software being application service provider, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the controlling of cutting machines; provision of online non-downloadable software being application service provider, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the nesting and programming of CNC cutting machines; provision of online non-downloadable software being application service provider, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the provision of engineering design and engineering drafting services; provision of online non-downloadable software being application service provider, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the machine tool industry; provision of online non-downloadable software being application service provider, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to products for use within the metal working industries; providing automatic updates to applications and software as a service (SaaS); updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; performance monitoring services in the field of the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; services for minting [creation] non-fungible tokens [NFTs] using blockchain technology; software as a service featuring virtual products and marketplaces.
09 - Scientific and electric apparatus and instruments
35 - Advertising and business services
37 - Construction and mining; installation and repair services
40 - Treatment of materials; recycling, air and water treatment,
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
45 - Legal and security services; personal services for individuals.
Goods & Services
(1) Metalworking machine tools; Tools for machine tools for machining in the nature of machining centers for metalworking; metalworking power-operated tools for machine tools for cutting, drilling, turning, milling, reaming and thread cutting; indexable inserts for power operated thread milling cutter machine tools used with other machine tools; machine tools in the nature of thread milling cutters with indexable inserts; Machine tool holders used for machine tool interfaces in the field of metal working tools; replacement parts for the aforesaid goods, namely, metalworking machine parts; equipment in relation to the metal working industries, namely, metalworking machines;
(2) Computer hardware; replacement parts for the aforesaid goods, namely, electric circuit switches; downloadable and recorded computer software and programs for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; downloadable and recorded databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable electronic databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable computer mobile applications for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; transponders in the nature of smart radio frequency identification (RFID) tags; bar code readers; computer hardware; computer hardware for data communications; downloadable software and mobile application for inventory management, user support, collecting and reporting product information; apparatus and equipment for use with bar codes and optical identification systems, namely, bar code readers and fingerprint scanners; (1) Commercial and industrial management assistance relating to the selection of metal working machines and tools; advisory services for business management; business management and organization consultancy; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy services relating to the selection of metal working machines and tools; business data analysis, business failure analysis services, business management analysis; collection and systematic integration for business data of market analysis and research; provision of wholesale and retail store services, featuring products used in the metal working industries; provision of an online marketplace for buyers and sellers within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services featuring of products for use within the metal working industries; sales administration in the nature of business administration services for processing sales made on the Internet; provision of customer support services, namely, responding to customers inquiries for others in the field of metal working via telephone or other electronic means; provision of an online marketplace for buyers and sellers of downloadable digital collectibles authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, downloadable image files of metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and downloadable educational publications in the nature of manuals about metalworking machines, all for use in online virtual worlds;
(2) Repair, maintenance, assembly and installation of metal working machines in the field of metal working industries; rebuilding and refurbishment of metal working machines used in the metal working industries; Rental and hire of metal working machines in the field of metal working industries; repair of metalworking tools;
(3) Grinding of tools and machines; providing information relating to material treatment; recycling of steel and carbide materials; regrinding and recoating of tools and machines; custom manufacture of poweroperated automation metalworking machines and power-operated automation machine tools for metal processing; custom manufacturing of semi-finished casting products of common metals and their alloys;
(4) Educational services, namely, providing online non-downloadable videos and non-downloadable webinars in the field of engineering and design and distribution of course materials in connection therewith; Training in the field of engineering and engineering design; providing educational classes, training, online training, and virtual training, all in the technical field of operating metalworking machines and machine tools; Providing educational classes, training and online training, all in the field of product development, manufacturing and inspection of metalworking machines and machine tools; practical training, online and virtual training, all in the fields of engineering and design of products for use within the metal working industries; training services, online and virtual training services, all in the fields of engineering and design of operating machines and machine tools for the metal working industries provided via simulators; Providing training and online training, all in the field of software and hardware related to metalworking machines and machine tools; providing online non-downloadable educational publications in the nature of training manuals about operation and use of equipment used in the metalworking industries; entertainment services, namely, providing on-line, nondownloadable files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, publications and artwork for use in virtual environments created for entertainment purposes; providing on-line digital publications, namely, digital art authenticated by non-fungible tokens (nfts).
(5) Scientific and technological services, namely, scientific research and design in the field of metal working industries; industrial analysis of products for use within the metal working industries to assure compliance with computer, construction industry standards, industrial research in the field of products within the metal working industries, and industrial design services; quality control for others and authentication in the field of metal working industries; design and development of computer hardware and software; research and technological research, namely research in the field of tools and tooling systems for industrial metal cutting, equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services, namely, measurement evaluations in the metal working industry; remote monitoring of the functioning and use of electrical equipment, namely, generators; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for database management of a tool library; technical support services for computer software for use in the field of the metal working industries; services for monitoring industrial metalworking processes to ensure proper functioning; consulting services in the field of cloud computing; technological consulting services, namely, providing services related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components parts and components; hosting services, namely, hosting the web sites of others; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the calculation of wear data for machine tools; providing on-line non-downloadable software for evaluating wear and performance of metalworking products used within the metal working industries; providing temporary use of on-line non-downloadable computer software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the nesting and programming of CNC cutting machines; providing temporary use of on-line non-downloadable computer software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the provision of engineering design and engineering drafting services; providing temporary use of on-line non-downloadable computer software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the machine tool industry; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for evaluating wear and performance of metalworking products used within the metal working industries; updating of computer software for others by providing automatic updates to computer software applications and software as a service (SaaS) software; updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; computer hardware performance monitoring services in the field of the metal working industries; providing online non-downloadable computer software for minting non-fungible tokens (NFTs) using blockchain technology; software as a service (SAAS) services featuring software for accessing virtual marketplaces offering downloadable virtual goods for use in online virtual environments;
(6) Licensing of industrial property rights; licensing of industrial property rights in the field of wireless communication systems; licensing of intellectual property; licensing of computer software; licensing of databases; licensing of industrial property rights for technology;
09 - Scientific and electric apparatus and instruments
35 - Advertising and business services
36 - Financial, insurance and real estate services
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
Goods & Services
Metalworking machine tools; metalworking power-operated tools for machine tools for cutting, drilling, turning, milling, reaming and thread cutting; tools for machine tools for machining in the nature of machining centers for metalworking; indexable inserts for power-operated thread milling cutter machine tools used with other machine tools; and machine tools in the nature of thread milling cutters with indexable inserts; machine tool holders; replacement parts for the aforesaid goods, namely, metalworking machine parts in the nature of collets, toolholders for metalworking machines, and non-electric adapters for power-operated drills for machine tools for use in joining extensions and power drill bits; equipment in relation to the metal working industries, namely, metalworking machines Electric and electronic machine tool controls; and replacement parts for the aforesaid goods, namely, electric circuit switches; downloadable and recorded computer software and programs for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; downloadable and recorded databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable electronic databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable computer mobile applications for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; transponders in the nature of smart radio frequency identification (RFID) tags; bar code readers; computer hardware; computer hardware for data communications; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information; apparatus and equipment for use with bar codes and optical identification systems, namely, bar code readers and fingerprint scanners; downloadable educational publications in the nature of training manuals about operation and use of equipment used in the metal working industries; digital collectibles in the nature of downloadable multimedia files containing artwork in the field of metalworking machines authenticated by non-fungible tokens (NFTs) Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business data analysis, business failure analysis services, business management analysis; business research and information services; collection and systematization of business data; provision of wholesale and retail store services, including such store services being provided online, all featuring products used in the metal working industries; online retail services, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; provision of ecommerce services for products for use within the metal working industries, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services featuring of products for use within the metal working industries; sales administration in the nature of business administration services for processing sales made on the Internet; provision of customer support services, namely, responding to customers inquiries for others in the field of metal working via telephone or other electronic means; providing pricing information about the products of others within the metal working industries; information, advisory, and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles in the nature of downloadable image files of metalworking machines authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, downloadable image files of metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and downloadable educational publications in the nature of manuals about metalworking machines, all for use in online virtual worlds Issuing pre-paid vouchers exchangeable for goods or services Educational services, namely, providing online non-downloadable videos and non-downloadable webinars in the field of engineering and design and distribution of course materials in connection therewith; Training in the field of engineering and engineering design; providing educational classes, training, online training, and virtual training, all in the technical field of operating metalworking machines and machine tools; providing educational classes, training, and online training, all in the fields of product development, manufacturing and inspection; training services, online and virtual training services, all in the fields of operating machines and machine tools for the metal working industries; training services, online and virtual training services all of the foregoing about products for use within the metal working industries; practical training, online and virtual training, all in the fields of engineering and design of products for use within the metal working industries; training services, online and virtual training services, all in the fields of engineering and design of operating machines and machine tools for the metal working industries provided via simulators; training services, online and virtual training services, all of the foregoing related to use of software, hardware, equipment and tools for the metal working industries; providing online non-downloadable educational publications in the nature of training manuals about operation and use of equipment used in the metalworking industries; information, advisory, and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable image files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, artwork and non-downloadable multimedia files of publications being magazines about metalworking, all for use in virtual environments created for entertainment purposes; hosting services, namely, hosting social entertainment events in the nature of conferences, for others Custom engineering services of products within the metal working industries; Scientific and technological services, namely, scientific research and design relating thereto, all in the field of metal working industries; industrial analysis of products for use within the metal working industries to assure compliance with computer, construction industry standards, industrial research in the field of products within the metal working industries, and industrial design services; quality control for others and authentication in the field of metal working industries; design and development of computer hardware and software; scientific and technological services, namely, scientific research and design in the field of tools and tooling systems for industrial metal cutting equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services, namely, measurement evaluations in the metal working industry; remote monitoring of the functioning and use of electrical equipment, namely, generators; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for database management of a tool library; operational support services in the nature of technical advice relating to operation of computers in the field of the metal working industries; services for monitoring industrial metalworking processes to ensure proper functioning; consulting services in the field of cloud computing; technological quality control consulting for others related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components and component parts; hosting services, namely, hosting the web sites of others; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the calculation of wear data for machine tools; providing on-line non-downloadable software for the controlling of cutting machines; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the controlling of cutting machines; providing on-line nondownloadable software for nesting and programming of CNC (computer numerical control) cutting machines; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the nesting and programming of CNC (computer numerical control) cutting machines; providing online non-downloadable software for the provision of engineering design and engineering drafting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the provision of engineering design and engineering drafting services; providing on-line non-downloadable software for accessing machine tool performance data for the machine tool industry; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for accessing machine tool performance data for the machine tool industry; providing on-line non-downloadable software for evaluating wear and performance of metalworking products used within the metal working industries; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for evaluating wear and performance of metalworking products used within the metal working industries; updating of computer software for others by providing automatic updates to computer software applications and software as a service (SaaS) software; updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; computer hardware performance monitoring services in the field of the metal working industries; information, advisory, and consultancy services relating to the aforesaid; providing online non-downloadable computer software for minting non-fungible tokens (NFTs) using blockchain technology; software as a service (SAAS) services featuring software for accessing virtual marketplaces offering downloadable virtual goods for use in online virtual environments.
40 - Treatment of materials; recycling, air and water treatment,
09 - Scientific and electric apparatus and instruments
35 - Advertising and business services
37 - Construction and mining; installation and repair services
Goods & Services
Custom manufacture of power-operated automation equipment; custom manufacturing of parts and components for metalworking machines made from common metals and their alloys; information, advisory, and consultancy services relating to the aforesaid Electric and electronic machine tool controls; and replacement parts for the aforesaid goods, namely, electric circuit switches; transponders in the nature of smart radio frequency identification (RFID) tags; bar code readers; computer hardware; computer hardware for data communications; apparatus and equipment for use with bar codes and optical identification systems, namely, bar code readers and fingerprint scanners; downloadable educational publications in the nature of training manuals about operation and use of equipment used in the metal working industries; digital collectibles in the nature of downloadable multimedia files containing artwork in the field of metalworking machines authenticated by non-fungible tokens (NFTs) Provision of wholesale and retail store services, including such store services being provided online, all featuring products used in the metal working industries; online retail services, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; provision of ecommerce services for products for use within the metal working industries, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries Repair, maintenance, assembly and installation of metal working machines in the field of metal working industries; rebuilding and refurbishment of metal working machines used in the metal working industries; upgrading of computer hardware used in the metal working industries; rental and hire of metalworking machines for use within the metal working industries; rental of machine tools; repair of metalworking tools; information, advisory, and consultancy services relating to the aforesaid; recoating in the nature of applying protective coatings to tools and machines
40 - Treatment of materials; recycling, air and water treatment,
09 - Scientific and electric apparatus and instruments
35 - Advertising and business services
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
45 - Legal and security services; personal services for individuals.
Goods & Services
Grinding; providing information relating to material treatment; recycling of steel and other materials and products; regrinding of tools and machines; recoating in the nature of applying protective coatings to metal tools and machines by means of galvanization Downloadable and recorded computer software and programs for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; downloadable and recorded databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable electronic databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable computer mobile applications for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business data analysis, business failure analysis services, business management analysis; business research and information services; collection and systematization of business data; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services featuring of products for use within the metal working industries; sales administration in the nature of business administration services for processing sales made on the Internet; provision of customer support services, namely, responding to customers inquiries for others in the field of metal working via telephone or other electronic means; providing pricing information about the products of others within the metal working industries; information, advisory, and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles in the nature of downloadable image files of metalworking machines authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, downloadable image files of metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and downloadable educational publications in the nature of manuals about metalworking machines, all for use in online virtual worlds Educational services, namely, providing online non-downloadable videos and non-downloadable webinars in the field of engineering and design and distribution of course materials in connection therewith; Training in the field of engineering and engineering design; providing educational classes, training, online training, and virtual training, all in the technical field of operating metalworking machines and machine tools; providing educational classes, training, and online training, all in the fields of product development, manufacturing and inspection; training services, online and virtual training services, all in the fields of operating machines and machine tools for the metal working industries; training services, online and virtual training services all of the foregoing about products for use within the metal working industries; practical training, online and virtual training, all in the fields of engineering and design of products for use within the metal working industries; training services, online and virtual training services, all in the fields of engineering and design of operating machines and machine tools for the metal working industries provided via simulators; training services, online and virtual training services, all of the foregoing related to use of software, hardware, equipment and tools for the metal working industries; providing online non-downloadable educational publications in the nature of training manuals about operation and use of equipment used in the metalworking industries; information, advisory, and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable image files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, artwork and non-downloadable multimedia files of publications being magazines about metalworking, all for use in virtual environments created for entertainment purposes; hosting services, namely, hosting social entertainment events in the nature of conferences, for others Custom engineering services of products within the metal working industries; Scientific and technological services, namely, scientific research and design relating thereto, all in the field of metal working industries; industrial analysis of products for use within the metal working industries to assure compliance with computer, construction industry standards, industrial research in the field of products within the metal working industries, and industrial design services; quality control for others and authentication in the field of metal working industries; design and development of computer hardware and software; scientific and technological services, namely, scientific research and design in the field of tools and tooling systems for industrial metal cutting equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services, namely, measurement evaluations in the metal working industry; remote monitoring of the functioning and use of electrical equipment, namely, generators; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for database management of a tool library; services for monitoring industrial metalworking processes to ensure proper functioning; consulting services in the field of cloud computing; technological quality control consulting for others related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components and component parts; hosting services, namely, hosting the web sites of others; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the calculation of wear data for machine tools; providing on-line non-downloadable software for the controlling of cutting machines; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the controlling of cutting machines; providing on-line nondownloadable software for nesting and programming of CNC (computer numerical control) cutting machines; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the nesting and programming of CNC (computer numerical control) cutting machines; providing on-line non-downloadable software for the provision of engineering design and engineering drafting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the provision of engineering design and engineering drafting services; providing on-line nondownloadable software for accessing machine tool performance data for the machine tool industry; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for accessing machine tool performance data for the machine tool industry; providing on-line non-downloadable software for evaluating wear and performance of metalworking products used within the metal working industries; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for evaluating wear and performance of metalworking products used within the metal working industries; updating of computer software for others by providing automatic updates to computer software applications and software as a service (SaaS) software; updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; computer hardware performance monitoring services in the field of the metal working industries; information, advisory, and consultancy services relating to the aforesaid; providing online non-downloadable computer software for minting non-fungible tokens (NFTs) using blockchain technology; software as a service (SAAS) services featuring software for accessing virtual marketplaces offering downloadable virtual goods for use in online virtual environments; Operational support services in the nature of technical advice relating to operation of computers in the field of the metal working industries Licensing of industrial property rights; licensing of industrial property rights in the field of wireless communication systems; licensing of intellectual property; licensing of computer software; licensing of computer software being databases; licensing of industrial property rights for technology
Metalworking machine tools; metalworking power-operated tools for machine tools for cutting, drilling, turning, milling, reaming and thread cutting; tools for machine tools for machining in the nature of machining centers for metalworking; indexable inserts for power-operated thread milling cutter machine tools used with other machine tools; and machine tools in the nature of thread milling cutters with indexable inserts; machine tool holders; replacement parts for the aforesaid goods, namely, metalworking machine parts in the nature of metal grounding bushings, and toolholders for metalworking machines; equipment in relation to the metal working industries, namely, metalworking machines
Metalworking machine tools; metalworking power-operated tools for machine tools for cutting, drilling, turning, milling, reaming
and thread cutting, namely, drills being machine parts, power drill bits, drilling heads being parts of machines, milling cutters being
parts of machines, notchers being machine tools for cutting notches, reamers being machine tools, end-mills, drill taps being
machine parts; tools for machine tools for machining in the nature of machining centers for metalworking; indexable inserts for
power-operated thread milling cutter machine tools used with other machine tools; and machine tools in the nature of thread
milling cutters with indexable inserts; machine tool holders; replacement parts for the aforesaid goods, namely, indexable cutting
tool inserts, power drill chucks, machine parts in the nature of drill sleeves for drilling bits, blade holders being parts of machines,
blades being parts of machines; all the foregoing excluding 3D printers and Router bits Commercial and industrial management assistance; advisory services for business management; business management and
organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines
and tools; inventory control; business consultancy; data processing services; business data analysis, business failure analysis
services, business management analysis; business research and information services; collection and systematization of business
data; e-commerce services, being business management services relating to e-commerce in the metal working industries; online
ordering services featuring metalworking power-operated tools for machine tools for cutting, drilling, turning, milling, reaming and
thread cutting; sales administration in the nature of business administration services for processing sales made on the Internet
A cutting insert for a cutting tool includes a body having a cutting edge, a rake face, and micro channels provided on the rake face adjacent the cutting edge. The micro channels define a grid pattern of micro channels that intersect each other in a region of the rake face where contact between a chip and the rake face is assumed to occur during cutting with the cutting insert.
09 - Scientific and electric apparatus and instruments
35 - Advertising and business services
36 - Financial, insurance and real estate services
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machine tools; tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts; machine tools holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the aforesaid good; computer software and programs; databases; electronic databases; mobile apps; smart tags (or transponders); bar code readers; computer hardware; data communications hardware; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information; apparatus and equipment for use with bar codes and/or all optical identification systems. Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business analysis, research and information services; collection and systematization of business data; provision of wholesale and retail services, including such services being provided online, related to products used in the metal working industries; online retail services, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; provision of e-commerce services for products for use within the metal working industries, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services; sales administration; provision of customer support services and information related to products for use within the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and publications for use in online virtual worlds. Issuance of tokens of value. Education; providing of training; education and training, including online or virtual training, in the technical field; education and training, including online training, relating to product development, manufacturing and inspection; training services, including online or virtual training services, provided in relation to the metal working industries; training services, including online or virtual training services, provided in relation to products for use within the metal working industries; practical training, including online or virtual training, in the fields of engineering and design; training services, including online or virtual training services, in the fields of engineering and design provided via simulators; training services, including online or virtual training services, related to use of software, hardware, equipment and tools for the metal working industries; Publication services for the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, publications and artwork for use in virtual environments created for entertainment purposes; providing on-line digital publications, namely, Digital Art authenticated by non-fungible tokens (NFTs). Scientific and technological services and research and design relating thereto; industrial analysis, industrial research and industrial design services; quality control and authentication services; design and development of computer hardware and software; scientific and technological services, namely, research and design in the field of tools and tooling systems for industrial metal cutting, equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services; remote monitoring services; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for a tool library; operational support services in the field of the metal working industries; services for monitoring industrial processes; consulting services in the field of cloud computing; technological consulting services, namely, providing services related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components parts and components; hosting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the calculation of data for machine tools; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the controlling of cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the nesting and programming of CNC cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the provision of engineering design and engineering drafting services; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the machine tool industry; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to products for use within the metal working industries; providing automatic updates to applications and software as a service (SaaS); updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; performance monitoring services in the field of the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; services for minting [creation] non-fungible tokens [NFTs] using blockchain technology; software as a service featuring virtual products and marketplaces.
09 - Scientific and electric apparatus and instruments
35 - Advertising and business services
37 - Construction and mining; installation and repair services
40 - Treatment of materials; recycling, air and water treatment,
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
45 - Legal and security services; personal services for individuals.
Goods & Services
Machine tools; tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts; machine tools holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the aforesaid good; computer software and programs; databases; electronic databases; mobile apps; smart tags (or transponders); bar code readers; computer hardware; data communications hardware; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information; apparatus and equipment for use with bar codes and/or all optical identification systems. Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business analysis, research and information services; collection and systematization of business data; provision of wholesale and retail services, including such services being provided online, related to products used in the metal working industries; online retail services, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; provision of e-commerce services for products for use within the metal working industries, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services; sales administration; provision of customer support services and information related to products for use within the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and publications for use in online virtual worlds. Repair, maintenance, assembly and installation services in the field of metal working industries; rebuild, refurbishment, upgrade and custom engineering services of products within the metal working industries; rental and hire of products for use within the metal working industries; rental of machine tools; repair of tools; information, advisory, support and consultancy services relating to the aforesaid. Grinding; providing material treatment information; recycling of steel and other materials and products; material treatment information; regrinding and recoating of tools and machines; custom manufacture of power-operated automation equipment; custom manufacturing of parts and component made from common metals and their alloys; information, advisory, support and consultancy services relating to the aforesaid. Education; providing of training; education and training, including online or virtual training, in the technical field; education and training, including online training, relating to product development, manufacturing and inspection; training services, including online or virtual training services, provided in relation to the metal working industries; training services, including online or virtual training services, provided in relation to products for use within the metal working industries; practical training, including online or virtual training, in the fields of engineering and design; training services, including online or virtual training services, in the fields of engineering and design provided via simulators; training services, including online or virtual training services, related to use of software, hardware, equipment and tools for the metal working industries; Publication services for the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, publications and artwork for use in virtual environments created for entertainment purposes; providing on-line digital publications, namely, Digital Art authenticated by non-fungible tokens (NFTs). Scientific and technological services and research and design relating thereto; industrial analysis, industrial research and industrial design services; quality control and authentication services; design and development of computer hardware and software; scientific and technological services, namely, research and design in the field of tools and tooling systems for industrial metal cutting, equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services; remote monitoring services; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for a tool library; operational support services in the field of the metal working industries; services for monitoring industrial processes; consulting services in the field of cloud computing; technological consulting services, namely, providing services related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components parts and components; hosting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the calculation of data for machine tools; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the controlling of cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the nesting and programming of CNC cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the provision of engineering design and engineering drafting services; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the machine tool industry; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to products for use within the metal working industries; providing automatic updates to applications and software as a service (SaaS); updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; performance monitoring services in the field of the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; services for minting [creation] non-fungible tokens [NFTs] using blockchain technology; software as a service featuring virtual products and marketplaces. Licensing; licensing of wireless communication systems; licensing of intellectual property; licensing of computer software; licensing of databases; licensing of technology.
09 - Scientific and electric apparatus and instruments
35 - Advertising and business services
36 - Financial, insurance and real estate services
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machine tools; tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts; machine tools holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the aforesaid good; computer software and programs; databases; electronic databases; mobile apps; smart tags (or transponders); bar code readers; computer hardware; data communications hardware; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information; apparatus and equipment for use with bar codes and/or all optical identification systems. Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business analysis, research and information services; collection and systematization of business data; provision of wholesale and retail services, including such services being provided online, related to products used in the metal working industries; online retail services, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; provision of e-commerce services for products for use within the metal working industries, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services; sales administration; provision of customer support services and information related to products for use within the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and publications for use in online virtual worlds. Issuance of tokens of value. Education; providing of training; education and training, including online or virtual training, in the technical field; education and training, including online training, relating to product development, manufacturing and inspection; training services, including online or virtual training services, provided in relation to the metal working industries; training services, including online or virtual training services, provided in relation to products for use within the metal working industries; practical training, including online or virtual training, in the fields of engineering and design; training services, including online or virtual training services, in the fields of engineering and design provided via simulators; training services, including online or virtual training services, related to use of software, hardware, equipment and tools for the metal working industries; Publication services for the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, publications and artwork for use in virtual environments created for entertainment purposes; providing on-line digital publications, namely, Digital Art authenticated by non-fungible tokens (NFTs). Scientific and technological services and research and design relating thereto; industrial analysis, industrial research and industrial design services; quality control and authentication services; design and development of computer hardware and software; scientific and technological services, namely, research and design in the field of tools and tooling systems for industrial metal cutting, equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services; remote monitoring services; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for a tool library; operational support services in the field of the metal working industries; services for monitoring industrial processes; consulting services in the field of cloud computing; technological consulting services, namely, providing services related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components parts and components; hosting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the calculation of data for machine tools; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the controlling of cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the nesting and programming of CNC cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the provision of engineering design and engineering drafting services; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the machine tool industry; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to products for use within the metal working industries; providing automatic updates to applications and software as a service (SaaS); updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; performance monitoring services in the field of the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; services for minting [creation] non-fungible tokens [NFTs] using blockchain technology; software as a service featuring virtual products and marketplaces.
Machine tools; tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts; machine tools holders; parts for the aforesaid goods. Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business analysis, research and information services; collection and systematization of business data; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services; sales administration; provision of customer support services and information related to products for use within the metal working industry.
09 - Scientific and electric apparatus and instruments
35 - Advertising and business services
37 - Construction and mining; installation and repair services
40 - Treatment of materials; recycling, air and water treatment,
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
45 - Legal and security services; personal services for individuals.
Goods & Services
Machine tools; tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts; machine tools holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the aforesaid good; computer software and programs; databases; electronic databases; mobile apps; smart tags (or transponders); bar code readers; computer hardware; data communications hardware; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information; apparatus and equipment for use with bar codes and/or all optical identification systems. Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business analysis, research and information services; collection and systematization of business data; provision of wholesale and retail services, including such services being provided online, related to products used in the metal working industries; online retail services, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; provision of e-commerce services for products for use within the metal working industries, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services; sales administration; provision of customer support services and information related to products for use within the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and publications for use in online virtual worlds. Repair, maintenance, assembly and installation services in the field of metal working industries; rebuild, refurbishment, upgrade and custom engineering services of products within the metal working industries; rental and hire of products for use within the metal working industries; rental of machine tools; repair of tools; information, advisory, support and consultancy services relating to the aforesaid. Grinding; providing material treatment information; recycling of steel and other materials and products; material treatment information; regrinding and recoating of tools and machines; custom manufacture of power-operated automation equipment; custom manufacturing of parts and component made from common metals and their alloys; information, advisory, support and consultancy services relating to the aforesaid. Education; providing of training; education and training, including online or virtual training, in the technical field; education and training, including online training, relating to product development, manufacturing and inspection; training services, including online or virtual training services, provided in relation to the metal working industries; training services, including online or virtual training services, provided in relation to products for use within the metal working industries; practical training, including online or virtual training, in the fields of engineering and design; training services, including online or virtual training services, in the fields of engineering and design provided via simulators; training services, including online or virtual training services, related to use of software, hardware, equipment and tools for the metal working industries; publications services for the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, publications and artwork for use in virtual environments created for entertainment purposes; providing on-line digital publications, namely, Digital Art authenticated by non-fungible tokens (NFTs). Scientific and technological services and research and design relating thereto; industrial analysis, industrial research and industrial design services; quality control and authentication services; design and development of computer hardware and software; scientific and technological services, namely, research and design in the field of tools and tooling systems for industrial metal cutting, equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services; remote monitoring services; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for a tool library; operational support services in the field of the metal working industries; services for monitoring industrial processes; consulting services in the field of cloud computing; technological consulting services, namely, providing services related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components parts and components; hosting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the calculation of data for machine tools; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the controlling of cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the nesting and programming of CNC cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the provision of engineering design and engineering drafting services; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the machine tool industry; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to products for use within the metal working industries; providing automatic updates to applications and software as a service (SaaS); updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; performance monitoring services in the field of the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; services for minting [creation] non-fungible tokens [NFTs] using blockchain technology; software as a service featuring virtual products and marketplaces. Licensing; licensing of wireless communication systems; licensing of intellectual property; licensing of computer software; licensing of databases; licensing of technology.
This disclosure relates to a high cBN content polycrystalline cubic boron nitride, PCBN, material. The binder matrix material comprises 19 to 50 wt. % chromium, or a compound thereof.
C04B 35/5831 - Shaped ceramic products characterised by their compositionCeramic compositionsProcessing powders of inorganic compounds preparatory to the manufacturing of ceramic products based on non-oxides based on borides, nitrides or silicides based on boron nitride based on cubic boron nitride
B23B 27/14 - Cutting tools of which the bits or tips are of special material
C04B 35/478 - Shaped ceramic products characterised by their compositionCeramic compositionsProcessing powders of inorganic compounds preparatory to the manufacturing of ceramic products based on oxides based on titanium oxides or titanates based on titanates based on aluminium titanates
C04B 35/58 - Shaped ceramic products characterised by their compositionCeramic compositionsProcessing powders of inorganic compounds preparatory to the manufacturing of ceramic products based on non-oxides based on borides, nitrides or silicides
The invention relates to a processing tool (100, 200) comprising a tool body (110,210). The tool body (110,210) comprising a front end surface (115,215), a rear end surface (116,216),at least one side surface (117,217) connecting the front end surface (115,215) and the rear end surface (116,216), and a first coupling part (130,230) extending between a first end (118,218) and a second end (119,219), wherein the first end (118,218) is disposed at the rear end surface (116,216), wherein the first coupling part (130,230) being one of a female coupling part (230) and a male coupling part (130); wherein the first coupling part (130,230) comprises a first identification marker (140,240) comprising identification information of the processing tool (100,200). The invention also relates to a processing tool assembly (300), wherein the first coupling part (130,230) is adapted to be coupled to a second coupling part (430), wherein the first identification marker (140,240) is positioned at the first coupling part (130,230) such that it is positioned in an interface between the first coupling part (130,230) and the second coupling part (430) when the first coupling part (130,230) is coupled to the second coupling part (430).
The invention relates to a processing tool (100,200) comprising a tool body (110,210) and a first coupling part (130,230), wherein the first coupling part (130,230) being one of a female coupling part (230); and a male coupling part (130), wherein the first coupling part (130,230) is adapted to be coupled to a second coupling part (430), and wherein the first coupling part (130,230) comprises a first identification marker (140,240) comprising first identification information of the processing tool (100,200), and wherein the first identification marker (140,240) is positioned at the first coupling part (130,230) such that it is unexposed to the exterior of the processing tool (100,200) when the first coupling part (130,230) is coupled to the second coupling part (430); and wherein the tool body (110,210) comprises a second identification marker (150,250) comprising second identification information of the processing tool (100,200), which is arranged such that it is exposed to the exterior of the processing tool (100,200), when the first coupling part (130,230) is coupled to the second coupling part (430). The invention also relates to a processing tool assembly (300).
A cutting tool assembly includes a first tool part and a second tool part. The first tool part has a forward end portion including a cutting edge and a rearward end portion having a conical section and an engagement section. The second tool part includes a conical recess and a clamping device rearwards the conical recess. The clamping device is provided in a transversal cavity of the second tool part and has a first clamp block, a second clamp block and a differential screw engaging the first and second clamp blocks. The first and second clamp blocks engage the engagement section of the first tool part to pull the first tool part into the conical recess when the first and second clamp blocks are moved towards each other by the differential screw protruding rearwards from the first and second clamp blocks.
2233) counted as a volume percentage of the total metal oxide content of the binder phase, the at least one metal nitride comprises aluminium nitride (AlN) and at least one metal nitride selected from the group consisting of vanadium nitride (VN), niobium nitride (NbN) and hafnium nitride (HfN), and wherein the content of said at least one metal nitride selected from the group consisting of vanadium nitride (VN), niobium nitride (NbN) and hafnium nitride (HfN) is at least 10 vol% of the total binder phase, and wherein the content of said at least one metal oxide is at least 10 vol% of the total binder phase.
C04B 35/5831 - Shaped ceramic products characterised by their compositionCeramic compositionsProcessing powders of inorganic compounds preparatory to the manufacturing of ceramic products based on non-oxides based on borides, nitrides or silicides based on boron nitride based on cubic boron nitride
B23B 27/14 - Cutting tools of which the bits or tips are of special material
The present invention relates to a tool comprising a cemented carbide part and a steel part joined by brazing where the steel part has an average hardness of between 390 and 510 HV30. The braze joint comprises Ti and a TiC layer with a thickness of between 0.03 and 5 µm adjoining to the cemented carbide part. The tool provides a strong braze joint and a steel part that have an even hardness.
C21D 9/22 - Heat treatment, e.g. annealing, hardening, quenching or tempering, adapted for particular articlesFurnaces therefor for drillsHeat treatment, e.g. annealing, hardening, quenching or tempering, adapted for particular articlesFurnaces therefor for milling cuttersHeat treatment, e.g. annealing, hardening, quenching or tempering, adapted for particular articlesFurnaces therefor for machine cutting tools
C22C 5/08 - Alloys based on silver with copper as the next major constituent
C22C 29/00 - Alloys based on carbides, oxides, borides, nitrides or silicides, e.g. cermets, or other metal compounds, e. g. oxynitrides, sulfides
C22C 32/00 - Non-ferrous alloys containing at least 5% by weight but less than 50% by weight of oxides, carbides, borides, nitrides, silicides or other metal compounds, e.g. oxynitrides, sulfides, whether added as such or formed in situ
C22C 38/02 - Ferrous alloys, e.g. steel alloys containing silicon
C22C 38/04 - Ferrous alloys, e.g. steel alloys containing manganese
C22C 38/22 - Ferrous alloys, e.g. steel alloys containing chromium with molybdenum or tungsten
C22C 38/34 - Ferrous alloys, e.g. steel alloys containing chromium with more than 1.5% by weight of silicon
C22C 38/38 - Ferrous alloys, e.g. steel alloys containing chromium with more than 1.5% by weight of manganese
B24D 3/00 - Physical features of abrasive bodies, or sheets, e.g. abrasive surfaces of special natureAbrasive bodies or sheets characterised by their constituents
B23K 101/00 - Articles made by soldering, welding or cutting
The invention relates to a cutting tool insert with optimal hardness and high toughness for demanding cutting operations in hardened steel and cast iron. The cutting tool comprises a substrate (2) of cemented carbide where the cemented carbide comprises hard constituents of tungsten carbide (WC) and a (Co) binder phase (4), chromium (Cr) and at least one additional element from the group: Vanadium (V), Niobium (Nb), Molybdenum (Mo) and Iron (Fe). The cemented carbide further has a Co-content of 3.50-4.20 wt% of the cemented carbide, a Cr-content of 0.31-0.38 wt % of the cemented carbide, a WC-content of at least 95.22 wt% of the cemented carbide and where the cemented carbide has a coercivity of 26-32 kA/m.
B22F 7/08 - Manufacture of composite layers, workpieces, or articles, comprising metallic powder, by sintering the powder, with or without compacting of composite workpieces or articles from parts, e.g. to form tipped tools with one or more parts not made from powder
C22C 29/06 - Alloys based on carbides, oxides, borides, nitrides or silicides, e.g. cermets, or other metal compounds, e. g. oxynitrides, sulfides based on carbides or carbonitrides based on carbides, but not containing other metal compounds
C22C 29/08 - Alloys based on carbides, oxides, borides, nitrides or silicides, e.g. cermets, or other metal compounds, e. g. oxynitrides, sulfides based on carbides or carbonitrides based on carbides, but not containing other metal compounds based on tungsten carbide
B22F 1/00 - Metallic powderTreatment of metallic powder, e.g. to facilitate working or to improve properties
A milling cutter includes a front end part and a back end part. The front end part includes a disc-shaped cutter body having a front side, a rear side, a central axis, and a number of insert seats. A primary holding member extends from the rear side. The back end part includes a secondary holding member, which engages the primary holding member when the front and back end parts are mounted to each other. The disc-shaped cutter body has a central cylindrical aperture extending coaxially with the central axis and including an inner cylindrical surface. An outer cylindrical surface is provided on a front portion of the secondary holding member. The inner cylindrical surface abuts the outer cylindrical surface in an abutting region between the front and the rear sides to center the front and back end parts.
A coated cutting tool includes a rake face, a flank face, and a cutting edge region between and adjoining the flank face and the rake face in a nose area of a cutting tool insert. The cutting edge region is intersected by an edge line and defines a cutting edge sector that defines an cutting edge radius, re. The coated cutting tool includes a substrate with a coating having a thickness between 1 μm and 40 μm, where the coating includes an α-Al2O3 layer and an MTCVD TiCN layer located between the substrate and the α-Al2O3 layer. The α-Al2O3 layer exhibits a texture coefficient TC(hkl), as measured by X-ray diffraction using CuKa radiation and θ-2θ scan, defined according to Harris formula
A coated cutting tool includes a rake face, a flank face, and a cutting edge region between and adjoining the flank face and the rake face in a nose area of a cutting tool insert. The cutting edge region is intersected by an edge line and defines a cutting edge sector that defines an cutting edge radius, re. The coated cutting tool includes a substrate with a coating having a thickness between 1 μm and 40 μm, where the coating includes an α-Al2O3 layer and an MTCVD TiCN layer located between the substrate and the α-Al2O3 layer. The α-Al2O3 layer exhibits a texture coefficient TC(hkl), as measured by X-ray diffraction using CuKa radiation and θ-2θ scan, defined according to Harris formula
T
C
(
h
k
l
)
=
I
(
hkl
)
I
0
(
h
k
l
)
[
1
n
∑
n
=
1
n
I
(
hkl
)
I
0
(
h
k
l
)
]
-
1
A coated cutting tool includes a rake face, a flank face, and a cutting edge region between and adjoining the flank face and the rake face in a nose area of a cutting tool insert. The cutting edge region is intersected by an edge line and defines a cutting edge sector that defines an cutting edge radius, re. The coated cutting tool includes a substrate with a coating having a thickness between 1 μm and 40 μm, where the coating includes an α-Al2O3 layer and an MTCVD TiCN layer located between the substrate and the α-Al2O3 layer. The α-Al2O3 layer exhibits a texture coefficient TC(hkl), as measured by X-ray diffraction using CuKa radiation and θ-2θ scan, defined according to Harris formula
T
C
(
h
k
l
)
=
I
(
hkl
)
I
0
(
h
k
l
)
[
1
n
∑
n
=
1
n
I
(
hkl
)
I
0
(
h
k
l
)
]
-
1
where I(hkl) is the measured integrated area intensity of the (hkl) reflection with corresponding reference intensity I0(hkl), and n is the number of reflections used in the calculation.
An electronic device, a method and computer program product for managing traceability of at least a first cutting tool in a manufacturing process. The method includes the steps of obtaining information related to at least a first identification marker; decoding the at least first cutting tool identification marker to determine at least first cutting tool identification data; obtaining information related to at least a first carrier identification marker of at least a first carrier in the manufacturing process; decoding the at least first carrier identification marker to determine at least first carrier identification data; and generating a first association data indicative of the at least first cutting tool identification data and the at least first carrier identification data.
G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]
The invention relates to a system for automated mounting and dismounting of at least one cutting insert (4) on a tool body (10) with a screwing tool (14). The system comprises: - at least one fastening screw (8) having a shaft (56) and a head (16), the shaft (56) having an end point (50) opposite to the head (16); - at least one cutting insert (4) comprising a top surface (26), a bottom surface (44), and a circumferential side surface (62) connecting the top surface (26) and the bottom surface (44), the cutting insert (4) further comprises a through hole (6), having a longitudinal axis (A), extending from the top surface (26) to the bottom surface (44) for receiving the shaft (56) of the fastening screw (8); and - a carrier device (2) being able to pick up and release the at least one cutting insert (4) with the therein placed fastening screw (8), the carrier device (2) comprises a body having a front surface (32), a rear surface (24), and a circumferential side surface (58) connecting the front surface (32) and the rear surface (24), wherein the carrier device (2) comprises a channel (12), having a longitudinal axis (B), extending from a front end opening (54) in the front surface (32) to a rear end opening (52) in the rear surface (24), wherein the channel (12) has a length L. The invention also relates to a method for automated mounting of at least one cutting insert (4) with a fastening screw (8) on a tool body (10).
B23P 19/06 - Screw or nut setting or loosening machines
B23P 19/00 - Machines for simply fitting together or separating metal parts or objects, or metal and non-metal parts, whether or not involving some deformationTools or devices therefor so far as not provided for in other classes
B23P 15/28 - Making specific metal objects by operations not covered by a single other subclass or a group in this subclass cutting tools
B23C 5/20 - Milling-cutters characterised by physical features other than shape with removable cutter-bits or teeth
B23C 9/00 - Details or accessories so far as specially adapted to milling machines or cutters
B23B 27/14 - Cutting tools of which the bits or tips are of special material
99.
System and method for tracing the use of a cutting edge
A system, method and computer program product arranged for managing the operation of a machine and tracing the use of a cutting edge of a cutting tool used in the operation of the machine. The method includes the steps of reading an identification marker of a cutting edge of a cutting tool inserted into the machine, decoding the identification marker to determine a cutting edge information data associated with the cutting edge, obtaining machine operation data associated with the operation of the machine from the machine, and generating a first association data indicative of the cutting edge information data and the machine operation data.
B23B 27/14 - Cutting tools of which the bits or tips are of special material
B23B 27/16 - Cutting tools of which the bits or tips are of special material with exchangeable cutting bits, e.g. able to be clamped
B23C 5/20 - Milling-cutters characterised by physical features other than shape with removable cutter-bits or teeth
B23Q 17/09 - Arrangements for indicating or measuring on machine tools for indicating or measuring cutting pressure or cutting-tool condition, e.g. cutting ability, load on tool
A face milling cutter comprising: - a tool body (2); - several primary cutting inserts (60) mounted in a respective primary insert seat (30); and - a reference insert (50) mounted in a reference insert seat (20); - a finishing insert (40) mounted in a finishing insert seat (10). The reference and primary cutting inserts (50, 60) are configured to be detachably mounted in their insert seats in a fixed position as seen in the axial direction of the tool body. The reference insert seat (20) is arranged more forwardly in the tool body than the primary insert seats (30) such that the reference insert projects forwards from the tool body beyond the axially foremost point of each primary cutting insert. The position of the finishing insert (40) is adjustable by means of an adjustment mechanism (70) to allow it to be positioned with its axially foremost point substantially in level with or more forwardly than the axially foremost point of the reference insert (50).
