The application relates to a power converter (10) for exchanging electrical power, with safeguarding against ground faults, between a three-phase AC voltage grid (12) and a battery (14), wherein: the power converter (10) has an AC connection (ACA), a DC connection (DCA), a bridge circuit (16) and a DC-to-DC converter (20); the AC connection (ACA) is provided for connection to the AC voltage grid (12), and the DC connection (DCA) is provided for connection to the battery (14); a DC link (18) is arranged between the DC-to-DC converter (20) and the DC connection (DCA), and a bridge intermediate circuit (22) is arranged between the DC-to-DC converter (20) and the bridge circuit (16); the DC-to-DC converter (20) has clocked semiconductor switches (30.1-30.4, 40.1-40.3, 50.1-50.4, 60.1-60.4, 70.1-70.4) which are configured to produce a voltage transmission ratio between the DC link (18) and the bridge intermediate circuit (22) during the exchange of electrical power; and the DC-to-DC converter (20) has at least one further semiconductor switch (24, 26, 28, 32, 34) which is configured to produce a connection between the DC link (18) and the bridge intermediate circuit (22) during the exchange of electrical power and to break this connection in the event of a ground fault (EF1, EF2, EF3, EF4). The application also relates to methods for exchanging electrical power with safeguarding against ground faults, and to a use of the power converter (10).
H02M 3/158 - Conversion of DC power input into DC power output without intermediate conversion into AC by static converters using discharge tubes with control electrode or semiconductor devices with control electrode using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only with automatic control of output voltage or current, e.g. switching regulators including plural semiconductor devices as final control devices for a single load
H02M 1/32 - Means for protecting converters other than by automatic disconnection
H02M 7/5387 - Conversion of DC power input into AC power output without possibility of reversal by static converters using discharge tubes with control electrode or semiconductor devices with control electrode using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only, e.g. single switched pulse inverters in a bridge configuration
2.
METHOD FOR STARTING AN ELECTROLYSIS SUPPLY SYSTEM HAVING PARALLEL CONVERTERS AND REDUCED PRE-CHARGING UNIT
The application relates to a method for starting an electrical supply unit (10) which has a first power transformer (22), a second power transformer (24) and a rectifier unit (26) and is intended to supply a DC connection (DCA) with electrical energy from an AC network (12), wherein at least one DC connection unit (14, 15, 16) is connected to the DC connection (DCA) and the AC network (12) is connected to an AC connection (ACA) of the supply unit (10). The method comprises: pre-charging a first DC link of the first power transformer and a second DC link of the second power transformer (22 and 24) via an AC pre-charging circuit (18) from the AC network (12); and constructing an AC island network through the second power transformer (24), wherein the DC connection (DCA) is supplied with electrical energy from the AC island network via the rectifier unit (26) during the construction of the AC island network. The application further relates to an electrical supply unit (10) and to an electrolysis supply system (40).
H02M 1/36 - Means for starting or stopping converters
H02M 7/12 - Conversion of AC power input into DC power output without possibility of reversal by static converters using discharge tubes with control electrode or semiconductor devices with control electrode
H02M 7/23 - Conversion of AC power input into DC power output without possibility of reversal by static converters using discharge tubes with control electrode or semiconductor devices with control electrode using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only arranged for operation in parallel
H02M 5/458 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases with intermediate conversion into DC by static converters using discharge tubes or semiconductor devices to convert the intermediate DC into AC using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only
DC,k∆κΔΔ∆kΔΔ) when setting the individual power flow that flows through the individual converter (20.k). The application also describes a method for operating such a converter (30).
H02M 5/458 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases with intermediate conversion into DC by static converters using discharge tubes or semiconductor devices to convert the intermediate DC into AC using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only
H02M 7/493 - Conversion of DC power input into AC power output without possibility of reversal by static converters using discharge tubes with control electrode or semiconductor devices with control electrode the static converters being arranged for operation in parallel
H02M 1/12 - Arrangements for reducing harmonics from AC input or output
H02M 7/23 - Conversion of AC power input into DC power output without possibility of reversal by static converters using discharge tubes with control electrode or semiconductor devices with control electrode using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only arranged for operation in parallel
4.
METHOD FOR AUTOMATICALLY ASSIGNING IDENTIFIERS TO CONTROLLED NODES OF A FIELDBUS NETWORK
A method for automatically assigning identifiers to controlled nodes of a fieldbus network, the controlled nodes comprising a plurality of electric motor drive systems, IO devices and/or feedback sensors, wherein the method includes the steps of setting the fieldbus network into a service mode; scanning the fieldbus network; decomposing the fieldbus network into linear branches and switches; scanning each linear branch; and assigning unique identifiers to the controlled nodes of the fieldbus network, wherein the identifiers include the relative positions of the controlled nodes in the fieldbus network and a node number. The disclosure is further directed at a fieldbus network including a plurality of controlled nodes, preferably electric motor drive systems, wherein the fieldbus network is provided for performing the method for automatically assigning identifiers.
S,DiffSS being exceeded, if the earth fault persists after expiry of the delay time T. The application also describes a method for monitoring fault currents for such a plant.
H02H 3/16 - Emergency protective circuit arrangements for automatic disconnection directly responsive to an undesired change from normal electric working condition, with or without subsequent reconnection responsive to fault current to earth, frame or mass
G01R 31/52 - Testing for short-circuits, leakage current or ground faults
H02H 3/33 - Emergency protective circuit arrangements for automatic disconnection directly responsive to an undesired change from normal electric working condition, with or without subsequent reconnection responsive to difference between voltages or between currentsEmergency protective circuit arrangements for automatic disconnection directly responsive to an undesired change from normal electric working condition, with or without subsequent reconnection responsive to phase angle between voltages or between currents involving comparison of the voltage or current values at corresponding points in different conductors of a single system, e.g. of currents in go and return conductors using summation current transformers
H02H 5/12 - Emergency protective circuit arrangements for automatic disconnection directly responsive to an undesired change from normal non-electric working conditions with or without subsequent reconnection responsive to undesired approach to, or touching of, live parts by living beings
H02H 7/20 - Emergency protective circuit arrangements specially adapted for specific types of electric machines or apparatus or for sectionalised protection of cable or line systems, and effecting automatic switching in the event of an undesired change from normal working conditions for electronic equipment
The disclosure relates to a method for establishing a defined state in an electrochemical system connected to an AC/DC converter via a switch disconnector to exchange electric power. At least one DC connection of the electrochemical system is connected to the AC/DC converter via the disconnecting switch. The method includes, in a first operating state, closing a first switch to establish an electric connection between the DC connections of the electrochemical system. The application additionally relates to a disconnecting device, a power converter, and to an assembly.
The invention relates to a converter assembly (1) for transmitting electric power between phases of a three-phase or multi-phase network (4) and a DC bus (5). The converter assembly comprises a DC/AC converter (2) which can be connected to the network (4) via a sine filter (7) and to the DC bus (5) via a split DC-side intermediate circuit, wherein a converter bridge (8) of the DC/AC converter (2) is connected to a central point (M) of the intermediate circuit, and a rectifier (3) which is connected in parallel with the DC/AC converter (2). The DC/AC converter (2) has a controller (10) which is designed to operate the DC/AC converter (2) in an over-modulation mode if the voltage values of the DC bus (5) are less than double the amplitude of one of the phase voltages of the network (4).
H02M 7/48 - Conversion of DC power input into AC power output without possibility of reversal by static converters using discharge tubes with control electrode or semiconductor devices with control electrode
H02M 7/483 - Converters with outputs that each can have more than two voltage levels
H02M 7/493 - Conversion of DC power input into AC power output without possibility of reversal by static converters using discharge tubes with control electrode or semiconductor devices with control electrode the static converters being arranged for operation in parallel
H02M 1/12 - Arrangements for reducing harmonics from AC input or output
H02M 1/44 - Circuits or arrangements for compensating for electromagnetic interference in converters or inverters
The disclosure relates to a method for increasing the lifetime of converter switches in a system having an energy source connected to a DC bus and a DC-to-DC converter having the converter switches. The method includes determining a system state in which electrical power of the energy source is available for which no transmission via the DC-to-DC converter and no output to further participants of the DC bus is provided, and operating the DC-to-DC converter during the determined system state such that power dissipation is generated in the DC-to-DC converter without power being transmitted via the DC-to-DC converter. A system having an energy source and a DC-to-DC converter having the converter switches is disclosed, as well as an energy-generating system having such a system.
H02M 3/158 - Conversion of DC power input into DC power output without intermediate conversion into AC by static converters using discharge tubes with control electrode or semiconductor devices with control electrode using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only with automatic control of output voltage or current, e.g. switching regulators including plural semiconductor devices as final control devices for a single load
H02J 3/32 - Arrangements for balancing the load in a network by storage of energy using batteries with converting means
H02J 3/38 - Arrangements for parallelly feeding a single network by two or more generators, converters or transformers
H02M 1/32 - Means for protecting converters other than by automatic disconnection
A busbar terminal slider assembly for connecting a cable to a power converter includes a slider screw assembly with at least one connection portion, the connection portion includes a terminal slidable along a slider, a busbar with a mounting hole portion and a screw for pressing the cable against the busbar, wherein the screw and the busbar are at least partially arranged within the terminal. The disclosure further discloses a power converter including at least one busbar terminal slider and a method for connecting a cable to a busbar terminal slider assembly, the method includes the steps of inserting a cable into the terminal; sliding the terminal along the cable; and screwing the screw into the terminal and against the cable.
The invention relates to a supply unit (20) for a DC load (50). The supply unit (20) comprises: - a DC terminal (21) for connecting to the DC load (50), - a first AC terminal (22) which is connected to a DC bus (26) via a first AC/DC converter (24), - a second AC terminal (23) which is designed for connecting to a second AC voltage (U2) and which is connected to the DC terminal (21) via a second AC/DC converter (25), - an energy storage device (29) which is connected to the DC bus (26) via a first DC/DC converter (27), - a second DC/DC converter (28) which connects the DC bus (26) to the DC terminal (21) and which can be operated so as to provide the current with respect to the DC terminal (21), and - a control unit (30) for controlling the supply unit (20). The supply unit is characterized in that - the first DC/DC converter (27) is designed in the form of a bidirectional DC/DC converter, and the control unit (30) is designed to operate the first DC/DC converter (27) so as to provide the voltage with respect to the DC bus (26), and - the first AC/DC converter (24) is designed in the form of a bidirectional AC/DC converter, and the control unit (30) is designed to operate the first AC/DC converter (24) so as to provide the voltage with respect to the first AC terminal (22). The invention additionally relates to an operating and starting method and to an electrolysis system comprising such a supply unit (20).
A housing of an electrical device for converting electrical power has a main body with a rear wall, side walls and a cover. The cover and body define a an interior space. Components of the electrical device are arranged in the interior space. The cover is connected to the body by a cover closure that includes a fastening structure and a closure housing. The fastening structure is retained in the closure housing, which is fastened to the cover. The body includes a pin that extends from the rear wall of the housing to the cover. A connection between the cover and pin is releasable by turning the fastening structure using a guide peg of the pin and a helically encircling guide groove of the fastening structure.
The application relates to a method for operating an inverter (10), wherein the inverter (10) has an H4 bridge circuit having a first half-bridge (20) and a second half-bridge (22) for converting an input-side direct voltage into an output-side alternating voltage and is configured for supplying an electric power of a direct voltage source with varying potential relation to an earth potential (30), in particular of a photovoltaic generator (12) with a leakage capacitance (18) with respect to the earth potential (30), to an alternating current grid (14). The method comprises: - unipolar pulse-width modulated clocking for each of the two half bridges (20, 22) for half-wave-wise generation of substantially sinusoidal half-bridge voltages, - modifying the clocking of the half-bridges (20, 22) in a transition region (B) around a zero crossing of the output-side alternating voltage to damp a leakage current (IA) which flows through the leakage capacitance (18) towards earth. The application also relates to an inverter (10) and to a computer program product.
H02M 1/12 - Arrangements for reducing harmonics from AC input or output
H02M 7/5387 - Conversion of DC power input into AC power output without possibility of reversal by static converters using discharge tubes with control electrode or semiconductor devices with control electrode using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only, e.g. single switched pulse inverters in a bridge configuration
H02M 7/539 - Conversion of DC power input into AC power output without possibility of reversal by static converters using discharge tubes with control electrode or semiconductor devices with control electrode using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only, e.g. single switched pulse inverters with automatic control of output wave form or frequency
H02M 1/44 - Circuits or arrangements for compensating for electromagnetic interference in converters or inverters
