The present invention is capable of reducing man-hours required for registering identification information of a wireless communication device in a web server via a high-order terminal. A high-order terminal 2 includes: a device search unit 211 that searches for a low-order terminal 1 capable of wireless communication and acquires from the low-order terminal 1 identification information of the found low-order terminal 1; and an identification information registration processing unit 212 that transmits the acquired identification information to a management device 3 and registers the identification information in response to the acquisition of the identification information of the low-order terminal 1 by the device search unit 211 under a predetermined condition. The identification information acquired from the low-order terminal 1 under the predetermined conditions by the device search processing of the high-order terminal 2 is automatically transmitted from the high-order terminal 1 to the management device 3 and registered, thereby eliminating the need for a user to select identification information to be registered in the management device 3 from among one or more pieces of identification information acquired from the low-order terminal 1 and to perform an operation of instructing execution of registration one by one.
To provide an inexpensive printer that suppresses the occurrence of paper jams.
To provide an inexpensive printer that suppresses the occurrence of paper jams.
A printer includes: a platen roller configured to feed linerless label paper having an adhesive surface on a side opposite to a printing surface on which printing is to be performed, the adhesive surface being coated with an adhesive; a print head configured to perform printing on the linerless label paper being fed by the platen roller; and a cutting device having a fixed blade and a movable blade. The movable blade 621 advances from the adhesive surface side of the linerless label paper toward the fixed blade, and a surface of the movable blade on a downstream side in a paper feed direction faces a surface of the fixed blade on an upstream side in the paper feed direction.
B41J 11/70 - Applications of cutting devices cutting perpendicular to the direction of paper feed
B41J 3/407 - Typewriters or selective printing or marking mechanisms characterised by the purpose for which they are constructed for marking on special material
A printer having good operability is provided. This printer 1 in which a storage space SP for rotatably storing roll paper RP is formed comprises: a printer body 2 having an opening 2C communicating with the storage space SP; a cover 3 attached to the printer body 2 and capable of changing position by rotating between an opening position for exposing the opening 2C and a closing position for closing the opening 2C; a roller 32 that is in contact with an outer peripheral surface of the roll paper RP stored in the storage space SP; and a roller-moving mechanism 33 that places the roller 32 at a projection position where the roller 32 projects from the cover 3 toward the storage space SP when the cover 3 is at the closing position, and places the roller 32 at a retreat position where the roller 32 has retreated to the cover 3 side when the cover 3 is at the opening position.
An information processing system is configured such that a printer is connected through USB to a host device that executes a web application, and a BCR is also connected to the printer through USB. The information processing system is configured to: perform serial communication between the host device and the printer via a virtual serial port; and using, as a trigger, when the printer receives, from the BCR, acquisition data acquired by the BCR; and transmit the peripheral device acquisition data from the printer to the host device via the virtual serial port. This enables the printer to actively transmit the peripheral device acquisition data to the host device with no time lag at the time when the printer receives the peripheral device acquisition data from the BCR.
An inventory index value acquisition unit acquires an inventory index value, which is an index value relating to the inventory status of a product, a sales index value acquisition unit that acquires a sales index value, which is an index value relating to the sales status of the product, and an inventory identification unit that identifies, as dead stock, inventory of a product for which the inventory index value is on a low evaluation side of an inventory threshold and the sales index value is on a low evaluation side of a sales threshold. By identifying the status of the inventory based on the logical product of the perspectives of whether the inventory index value and the sales index value are on the low evaluation side of the thresholds, respectively, dead stock that needs to be dealt with preferentially can be identified within the inventory.
A machine tool includes: a tool spindle to which a long tool having a length that is at least a predetermined length, and a normal tool shorter than the predetermined length, can be interchangeably attached; a tool storage device capable of storing both the long tool and the normal tool; a tool exchange device having a first tool gripping unit and a second tool gripping unit, the tool exchange device configured to exchange the long tool or the normal tool stored in the tool storage device with an attached tool attached to the tool spindle; and an exchange operation control unit configured to determine an operation pattern to be used in a tool exchange operation performed using the tool exchange device, on the basis of whether the attached tool is the long tool or the normal tool and whether a next attached tool to be attached to the tool spindle next is the long tool or the normal tool.
The machine tool includes: a first spindle that includes a collet chuck that grips a workpiece; a first headstock that rotatably supports the first spindle; an air cylinder that generates a driving force for changing a state of the collet chuck between a gripping state for gripping the workpiece and a release state for releasing the grip of the workpiece; a non-rotary transmitting member that transmits the driving force received from the air cylinder; a rotary transmitting member that rotates together the first spindle and transmits to the collet chuck the driving force received from the non-rotary transmitting member; strain detection means that is attached to the non-rotary transmitting member and detects a strain of the non-rotary transmitting member produced when the driving force is transmitted from the air cylinder to the collet chuck, and a deriving unit that derives the gripping force of the collet chuck based on a detection result of the strain detection means.
B23B 31/20 - Longitudinally-split sleeves, e.g. collet chucks
8.
Information Terminal, Peripheral Device Communicable with Information Terminal, Program Executed by Information Terminal, and Connection Information Transmission Method Using Information Terminal
To provide an information terminal and others that reduce the burden of work of setting connection information.
To provide an information terminal and others that reduce the burden of work of setting connection information.
An information terminal is wirelessly communicable with a peripheral device using a first communication method. The information terminal is configured to acquire an indicator according to a distance between the information terminal and the peripheral device by using the first communication method. The information terminal is configured to transmit, to the peripheral device, connection information required for the peripheral device to connect to a network using a second communication method, based on the indicator reaching a predetermined value.
To provide a machine tool that improves convenience when removing burrs.
To provide a machine tool that improves convenience when removing burrs.
A deburring tool that cuts a periphery of a hole in an orientation intersecting a spindle axis in a workpiece is attached to a tool post of a machine tool and the tool post rotates the deburring tool around a deburring tool center axis. A control unit of the machine tool acquires a command (CM1 to CM4) for instructing the deburring tool to either perform, on the periphery, down-cutting in which a cutting direction by the rotating deburring tool is opposite to a relative movement direction of the deburring tool or to perform, on the periphery, up-cutting in which the cutting direction and the relative movement direction are the same, and performs control to cut the periphery so as to maintain the cut instructed by the command (CM1 to CM4) at a cutting position.
B23B 13/04 - Arrangements for automatically conveying, chucking or guiding stock for turning machines for turning-machines with a plurality of working-spindles
B23B 5/16 - Turning-machines or devices specially adapted for particular workAccessories specially adapted therefor for bevelling, chamfering, or deburring the ends of bars or tubes
In the present invention, without a manual, a user can appropriately perform initial setting of an electronic device without confusion. When the power source of an electronic device 1 is turned off in a state where a first guide image regarding initial setting is displayed on an electronic paper 14 and at least a second guide image is stored in a nonvolatile memory 12a, and then, the power source is turned on at the start of the first use of the electronic device 1, the second guide image is read from the nonvolatile memory 12a and the second guide image is displayed on the electronic paper 14 instead of the first guide image remained displayed when the power source was turned off. In this manner, when a user unpacks and takes out the electronic device 1, the user can confirm, without a manual, what to do first according to the first guide image that remains displayed, and also can confirm what to do next according to the second guide image displayed after the power source is turned on.
The present invention makes it possible to easily identify identification information corresponding to a target device when one or more pieces of identification information found by device search processing are presented as a list. A device search unit 211 of an upper-level terminal 2 searches for a surrounding lower-level terminal 1 capable of wireless communication, and executes device search processing for presenting, as a list, identification information about the found lower-level terminal 1. At that time, a list presentation unit 211c associates a specific lower-level terminal 1 with the identification information about the specific lower-level terminal 1 on the basis of operation information about hardware included in the specific lower-level terminal 1, and presents the list in such a manner that the identification information included in response data including operation information indicating that the hardware of the lower-level terminal 1 has been operated can be distinguished from other identification information. Thus, the identification information about the target lower-level terminal 1 can be easily identified.
The present invention provides a mechanism by which a plurality of upper-level terminals do not redundantly register identification information about the same device in a communication system. The plurality of upper-level terminals 2 store, as shared information, the identification information about a lower-level terminal 1 registered in a management apparatus 3, and among the pieces of identification information acquired from one or more lower-level terminals 1 by device search processing in the management apparatus 3, register, in the management apparatus 3, the pieces of identification information about the lower-level terminals 1 other than the lower-level terminal 1 indicated by the shared information. Thus, among the pieces of identification information about the one or more lower-level terminals 1 found by the device search processing, the upper-level terminal 2 makes it possible to recognize the pieces of identification information registered in the management apparatus 3 and register only the other pieces of identification information in the management apparatus 3.
H04W 8/02 - Processing of mobility data, e.g. registration information at HLR [Home Location Register] or VLR [Visitor Location Register]Transfer of mobility data, e.g. between HLR, VLR or external networks
An NC lathe 1 for machining a work W includes a housing 11, a chip bucket 8 that is placed inside of the housing 11 in order to receive chips produced when the work W is machined, an opening formation portion 112 that is provided in the housing 11 and has an opening 1121formed therein through which the chip bucket 8 can be pulled out to the outside of the housing 11, and an opening cover 15 that is detachably attached to the housing 11 so as to close the opening 1121 in an attached state attached to the housing 11, wherein the opening formation portion 112 has a slit 1122 that is formed continuously with the opening 1121 so as to extend in a width direction of the opening 1121, and that allows the opening cover 15 removed from the housing 11 to be inserted into the housing 11.
B23Q 11/00 - Accessories fitted to machine tools for keeping tools or parts of the machine in good working condition or for cooling workSafety devices specially combined with or arranged in, or specially adapted for use in connection with, machine tools
B23Q 11/08 - Protective coverings for parts of machine toolsSplash guards
14.
MACHINE TOOL AND METHOD OF DETERMINING CONTROL POSITION THEREOF
A control unit of a machine tool: acquires a value (CD) representing a diameter corresponding to a periphery when a hole is viewed from a direction of a machining center axis (X-axis direction) and a value (OD) representing a diameter corresponding to a circumference passing through the periphery around a spindle axis on a cross section perpendicular to the spindle axis; determines a straight axis coordinate corresponding to a cutting position that changes along the periphery on a straight axis (Z-axis) and a rotation angle corresponding to the cutting position on a rotation axis (C-axis) based on the value (CD) and the value (OD); and controls a relative positional relationship in the direction of the spindle axis (Z-axis direction) to the straight axis coordinate and controls rotation of a spindle to the rotation angle so that the cutting position changes along the periphery.
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Personal digital assistants for customers to place orders at
restaurants; tablet computers for customers to place orders
at restaurants; personal digital assistants for customer
service management; tablet computers for customer service
management; electronic display units; display monitors;
tablet monitors; tablet computer terminals; tablet
computers; computer peripheral devices; paging apparatus;
computer network hubs; telecommunication machines and
apparatus; personal digital assistants; sensors [measurement
apparatus], other than for medical use; battery charge
devices; electric cables; interactive touchscreen terminals
for customers to check their order status, cooking progress,
and delivery using a barcode at restaurants; computer
software for controlling interactive touchscreen terminals
for customers to check their order status, cooking progress,
and delivery using a barcode at restaurants; computer
software for controlling transmission and display of images
on wireless or internet-connected devices; computer software
for storing, managing, tracking, analyzing and reporting on
images displayed on wireless or internet-connected devices;
computer software, recorded; computer software,
downloadable; computer hardware; data processing apparatus;
interfaces for computers; readers [data processing
equipment]; central processing units [processors]. Software as a service [SaaS] for controlling transmission
and display of images on wireless or internet-connected
devices; software as a service [SaaS] for storing, managing,
tracking, analyzing and reporting on images displayed on
wireless or internet-connected devices; software as a
service [SaaS]; providing computer programs on data
networks; design, programming and maintenance of computer
software; providing temporary use of on-line
non-downloadable operating software for accessing and using
a cloud computing network; programming of operating software
for accessing and using a cloud computing network; platform
as a service [PaaS].
Provided is a machine tool that prevents a tool spindle unit from turning when the machine tool is stopped. A machine tool 1 comprises: a brake disk 651; a brake piston 652 movable in a direction to be brought into contact with and separated from the brake disk 651; a hydraulic device 653 that moves the brake piston 652 to change the state between a turning prevention state in which a tool spindle unit 7 is prevented from turning and a turning permission state in which the tool spindle unit 7 is permitted to turn, and maintains the changed state; and a biasing member 654 that presses the brake member 652 against the brake disk 651 to prevent the tool spindle unit 7 from turning when the hydraulic device 653 is stopped.
B23B 19/02 - Working-spindlesFeatures relating thereto, e.g. supporting arrangements
B23Q 1/52 - Movable or adjustable work or tool supports using particular mechanisms with rotating pairs only a single rotating pair
B23Q 11/00 - Accessories fitted to machine tools for keeping tools or parts of the machine in good working condition or for cooling workSafety devices specially combined with or arranged in, or specially adapted for use in connection with, machine tools
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
(1) Personal digital assistants for customers to place orders at restaurants; tablet computers for customers to place orders at restaurants; personal digital assistants for customer service management; tablet computers for customer service management; electronic display units; display monitors; tablet monitors; tablet computer terminals; tablet computers; computer peripheral devices; paging apparatus; computer network hubs; telecommunication machines and apparatus; personal digital assistants; sensors [measurement apparatus], other than for medical use; battery charge devices; electric cables; interactive touchscreen terminals for customers to check their order status, cooking progress, and delivery using a barcode at restaurants; computer software for controlling interactive touchscreen terminals for customers to check their order status, cooking progress, and delivery using a barcode at restaurants; computer software for controlling transmission and display of images on wireless or internet-connected devices; computer software for storing, managing, tracking, analyzing and reporting on images displayed on wireless or internet-connected devices; computer software, recorded; computer software, downloadable; computer hardware; data processing apparatus; interfaces for computers; readers [data processing equipment]; central processing units [processors]. (1) Software as a service [SaaS] for controlling transmission and display of images on wireless or internet-connected devices; software as a service [SaaS] for storing, managing, tracking, analyzing and reporting on images displayed on wireless or internet-connected devices; software as a service [SaaS]; providing computer programs on data networks; design, programming and maintenance of computer software; providing temporary use of on-line non-downloadable operating software for accessing and using a cloud computing network; programming of operating software for accessing and using a cloud computing network; platform as a service [PaaS].
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Personal digital assistants for customers to place orders at restaurants; tablet computers for customers to place orders at restaurants; personal digital assistants for customer service management; tablet computers for customer service management; electronic digital display units; computer display monitors; computer tablet monitors; tablet computer terminals; tablet computers; computer peripheral devices; paging apparatus; computer network hubs; telecommunication machines and apparatus, namely, telephone answering machine; personal digital assistants; sensors for measuring temperature, other than for medical use; battery charge devices; electric cables; interactive touchscreen terminals for customers to check their order status, cooking progress, and delivery using a barcode at restaurants; downloadable computer software for controlling interactive touchscreen terminals for customers to check their order status, cooking progress, and delivery using a barcode at restaurants; downloadable computer software for controlling transmission and display of images on wireless or internet-connected devices; downloadable computer software for storing, managing, tracking, analyzing and reporting on images displayed on wireless or internet-connected devices; recorded computer software for data processing; computer software, downloadable, for data processing; computer hardware; data processing apparatus; interfaces for computers; optical readers being data processing equipment; central processing units, all of the foregoing excluding software, hardware, and services for financing and loan services, mental health and patient health assessment and treatment, entertainment live streaming, downloading music, data pipeline monitoring, government, law enforcement, and security services, and photovoltaic and solar, electrical, and renewable energy services Software as a service (SaaS) featuring software for controlling transmission and display of images on wireless or internet-connected devices; software as a service (SaaS) featuring software for storing, managing, tracking, analyzing and reporting on images displayed on wireless or internet-connected devices; software as a service (SaaS) featuring software for data processing; providing temporary use of nondownloadable computer programs on data networks for data processing and storage; design, programming and maintenance of computer software; providing temporary use of on-line non-downloadable operating software for accessing and using a cloud computing network; programming of operating software for accessing and using a cloud computing network; platform as a service (PaaS) services featuring software platforms for the transmission of image files, all of the foregoing excluding software, hardware, and services for financing and loan services, mental health and patient health assessment and treatment, entertainment live streaming, downloading music, data pipeline monitoring, government, law enforcement, and security services, and photovoltaic and solar, electrical, and renewable energy services
20.
METHOD FOR IDENTIFYING GEOMETRIC ERRORS IN MACHINE TOOL
National University Corporation Tokai National Higher Education and Research System (Japan)
Inventor
Katsuoka, Kentaro
Sato, Ryuta
Niwa, Mizuki
Kawai, Ryota
Abstract
A method for identifying geometric errors in a machine tool includes the steps of: positioning a reference sphere so as to align its center with a centerline of a tool spindle; attaching a position measuring device having a gauge head to a rotation unit so as to direct the gauge head toward a rotation centerline of the rotation unit; acquiring displacement data relative to the center of the reference sphere by measuring positions of the reference sphere with the gauge head while rotating a rotation target (the swivel unit or the rotation unit) with the gauge head directed toward the center of the reference sphere, the displacement data being dependent on rotation angles of the rotation target; and identifying the geometric errors by least squares method using a mathematical expression having terms containing the geometric errors and representing displacement dependent on the rotation angles, and the displacement data.
G01B 5/25 - Measuring arrangements characterised by the use of mechanical techniques for measuring angles or tapersMeasuring arrangements characterised by the use of mechanical techniques for testing the alignment of axes for testing the alignment of axes
B23B 13/02 - Arrangements for automatically conveying, chucking or guiding stock for turning machines for turning-machines with a single working-spindle
G01B 5/008 - Measuring arrangements characterised by the use of mechanical techniques for measuring coordinates of points using coordinate measuring machines
A machine tool includes a tool spindle on which a tool for machining a workpiece is mounted exchangeably, a tool housing apparatus having a standard tool magazine in which a plurality of tools to be mounted on the tool spindle are housed, and a tool exchanging apparatus having a tool exchange arm that grips the tool, and a first moving mechanism that uses a Z-axis rack and a pinion meshed to the Z-axis rack to move the tool exchange arm in a +Z direction, wherein the tool exchanging apparatus includes a thin plate part for attaching an extension member that extends a movement stroke of the tool exchange arm in the +Z direction, and the tool housing apparatus includes a rotation shaft projecting portion for attaching an additional tool magazine that increases the number of housed tools to the +Z direction side of the standard tool magazine.
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Scales; electronic metering devices; digital weighing
devices; electronic weighing devices for inventory control;
electronic weighing devices for transportation services;
electronic weighing devices for point-of-sale (POS) systems;
electronic weighing devices for retail store services;
weighing scales; electronic scales; measures; weighing
apparatus and instruments; measuring or testing machines and
instruments; cash registers; machines for counting or
sorting coins; cash drawers for cash registers; automated
teller machines (ATM); burglar alarms; photographic
apparatus and instruments; optical machines and apparatus;
cameras; digital cameras; webcams; digital video cameras;
power distribution or control machines and apparatus;
battery chargers; electrical adapters; electric wires and
cables; electric cables for converting the shape of the
connection terminal; gender changers (cable adapters);
telecommunication apparatus and instruments; buzzers being
acoustic components; electronic buzzers; buzzers; personal
digital assistants; computer programs; computer interface
boards; touch pads; scanners for point-of sale (POS)
systems; 3D scanners; image scanners; scanners (data
processing equipment); scanners; electronic payment
terminals; tablet computers; telecommunications equipment
conforming to short-range wireless communication standards;
radio-frequency identification (RFID) readers; readers (data
processing equipment); display units for point-of-sale (POS)
systems; display monitors; display screens; visual display
units; electronic display units; input devices for
point-of-sale (POS) systems with keypad; keypads for
point-of-sale (POS) systems for entering customer orders and
cooking instructions at restaurants, and for checking orders
after cooking is completed; touch screens for point-of-sale
(POS) systems for entering customer orders and cooking
instructions at restaurants, and for checking orders after
cooking is completed; computer input devices for entering
customer orders and cooking instructions at restaurants, and
for checking orders after cooking is completed; machines and
apparatus for point-of-sale (POS) systems for managing
customer orders, cooking instructions, cooking completion,
order confirmation, and serving at restaurants; portable
manual computer interface devices with input keypad;
interfaces for computers; input devices for computers;
computer keyboards; biometric identification systems;
biometric scanners; point-of-sale (POS) terminals; keyboards
for point-of-sale (POS) systems; bar code readers for
point-of-sale (POS) systems; printers for point-of-sale
(POS) systems; optical readers for point-of-sale (POS)
systems; computers for point-of-sale (POS) systems;
point-of-sale (POS) system equipment and its parts and
fittings; point-of-sale terminals; point-of-sale (POS)
terminals with weighing function; point-of-sale (POS)
terminals with printing function; point-of-sale (POS)
terminals with communication function; printers for use with
computers; card readers; magnetic card readers; chip card
readers; IC card reader/writers; read/write devices for
memory cards; smart card readers; card writers; magnetic
card writers; chip card writers; smart card writers; NFC
readers; RFID readers; NFC writers; RFID writers; credit
card terminals; computer programs, downloadable; computer
monitors; electronic customer displays; card readers for
magnetically encoded cards; bar code readers; 2D barcode
readers; data processing apparatus; tablet computers and
their parts and fittings; electronic pens for visual display
units; ticket printers; ticket dispensing terminals,
electronic; electronic cash registers and their parts and
fittings; computer peripherals for point-of-sale (POS)
systems; computer peripherals; smartphones; mobile phones;
wearable computers; electroacoustic transducers; radio
communication machines and apparatus; video frequency
devices and apparatus; parts and fittings of
telecommunication apparatus and instruments; downloadable
computer programs using artificial intelligence (AI) for use
in software development, machine learning, facial and speech
recognition; downloadable music files; downloadable image
files; game programs for home video game machines; game
programs for portable LCD game machines; downloadable
cloud-computing software for managing virtual machines on a
cloud computing platform. Providing temporary use of online non-downloadable computer
software for printing receipts and order information through
cloud computing; providing temporary use of online
non-downloadable computer software for displaying receipts
and order information on personal digital assistants,
smartphones, tablet computers, and computer terminals
through cloud computing; providing temporary use of online
non-downloadable computer software for control scanners,
cash registers, weighing devices, and speakers through cloud
computing networks; providing temporary use of online
non-downloadable computer software for storing and saving
receipts and order information in the memory and storage of
computer terminals and computer servers through cloud
computing networks; providing temporary use of online
non-downloadable computer software for acquiring,
monitoring, managing, analyzing, controlling, configuring,
and notifying the status information of devices connected to
the cloud computing network through cloud computing
networks; providing temporary use of online non-downloadable
computer software for printing data; providing temporary use
of online non-downloadable software for cloud computing;
software as a service (SaaS); cloud storage services for
electronic data; providing temporary use of online
non-downloadable computer programs; design, development and
programming of computer software.
23.
PRINT DATA GENERATION DEVICE AND PRINT DATA GENERATION METHOD
Print data are generated using a template constituted by commands of the smallest unit not including repetitions, the number of which corresponds to a variable number of print elements, and field data including data of print elements to be inserted into merge fields of API call commands included in the template. A repeat range is specified from the template, a print data generation API is generated by replacing the merge fields, including repeat substitutions within the specified range, with the data of the print elements, and by executing the generated print data generation API, print data including print-related commands into which the data of the print elements have been inserted is generated.
The machine tool system has a spindle that can move in an axial direction of a bar, a guide bush that supports the bar, a first tool post to which a first tool for machining a tip end part of the bar supported by the guide bush is attached, a pusher capable of biasing the bar toward the tip end side of the bar, a first control apparatus that controls operations of the spindle and operations of the first tool post, and a second control apparatus that controls operations of the pusher, wherein the first control apparatus includes a bar retraction mode in which the first tool post is caused to machine the tip end of the bar in a state where the bar is gripped by the spindle, the spindle is retracted and the bar is extracted from the guide bush, and the second control apparatus is caused to release the bias applied by the pusher and release the grip of the spindle on the bar.
B23B 13/02 - Arrangements for automatically conveying, chucking or guiding stock for turning machines for turning-machines with a single working-spindle
B23Q 11/00 - Accessories fitted to machine tools for keeping tools or parts of the machine in good working condition or for cooling workSafety devices specially combined with or arranged in, or specially adapted for use in connection with, machine tools
25.
PRINT DATA GENERATION DEVICE, PRINT DATA GENERATION METHOD, DATA GENERATION DEVICE FOR GENERATING PRINT DATA, AND DATA GENERATION METHOD FOR GENERATING PRINT DATA
The present invention makes it possible to perform merge printing by generating print data including a variable number of print elements without incorporating, into the program code of the application for generating the print data, descriptions necessary to repeatedly generate commands. The print data is generated using both a template composed of minimum unit commands that do not include a number of repetitions corresponding to the number of print elements, which is variable, and field data including data of the print elements to be inserted into the merge field of the generation command included in the template. A repetition range RR is identified from within the template, and the merge field is replaced with the data of the print elements, including replacement of the repetitions in the identified range. Print data including printing-related commands into which print element data is inserted is then generated using a plurality of generation commands including replaced generation commands.
A guide bush apparatus that supports a rod-shaped workpiece so that the workpiece is free to slide in the axis direction of the workpiece includes a guide bush sleeve, a guide bush that is disposed inside the guide bush sleeve, has a bush screw formed thereon, and has an inner diameter that changes in accordance with the relative position thereof relative to the guide bush sleeve in the axis direction, a retraction sleeve which is disposed inside the guide bush sleeve and on which a first screw that engages with the bush screw and a second screw having a different thread pitch from the first screw are formed, and a differential attachment/detachment body on which a differential screw that engages with the second screw is formed, and which can be fixed to and released from the guide bush sleeve.
Provided is a machine tool capable of highly accurately estimating force for gripping a workpiece. The present invention comprises: a first main shaft 4 that has a collet chuck 48 and rotates; an air cylinder 32 that, by supplying air to a first pressure chamber 324 to move a piston 322 to one side, reduces the diameter of the collet chuck 48 and, by supplying air to a second pressure chamber 325 to move the piston 322 to the other side, expands the diameter of the collet chuck 48; a first pressure sensor 3261 that measures a first pressure, which is the pressure of the air supplied to the first pressure chamber 324 when the piston 322 is moved to said one side; a second pressure sensor 3271 that measures a second pressure, which is the pressure of air flowing out from the second pressure chamber 325 when the piston 322 is moved to said one side; and an estimation unit 23 that estimates the gripping force of the collet chuck 48 on the basis of the differential pressure between the first pressure which is measured by the first pressure sensor 3261 and the second pressure which is measured by the second pressure sensor 3271.
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
(1) Scales; electronic metering devices; digital weighing devices; electronic weighing devices for inventory control; electronic weighing devices for transportation services; electronic weighing devices for point-of-sale (POS) systems; electronic weighing devices for retail store services; weighing scales; electronic scales; measures; weighing apparatus and instruments; measuring or testing machines and instruments; cash registers; machines for counting or sorting coins; cash drawers for cash registers; automated teller machines (ATM); burglar alarms; photographic apparatus and instruments; optical machines and apparatus; cameras; digital cameras; webcams; digital video cameras; power distribution or control machines and apparatus; battery chargers; electrical adapters; electric wires and cables; electric cables for converting the shape of the connection terminal; gender changers (cable adapters); telecommunication apparatus and instruments; buzzers being acoustic components; electronic buzzers; buzzers; personal digital assistants; computer programs; computer interface boards; touch pads; scanners for point-of sale (POS) systems; 3D scanners; image scanners; scanners (data processing equipment); scanners; electronic payment terminals; tablet computers; telecommunications equipment conforming to short-range wireless communication standards; radio-frequency identification (RFID) readers; readers (data processing equipment); display units for point-of-sale (POS) systems; display monitors; display screens; visual display units; electronic display units; input devices for point-of-sale (POS) systems with keypad; keypads for point-of-sale (POS) systems for entering customer orders and cooking instructions at restaurants, and for checking orders after cooking is completed; touch screens for point-of-sale (POS) systems for entering customer orders and cooking instructions at restaurants, and for checking orders after cooking is completed; computer input devices for entering customer orders and cooking instructions at restaurants, and for checking orders after cooking is completed; machines and apparatus for point-of-sale (POS) systems for managing customer orders, cooking instructions, cooking completion, order confirmation, and serving at restaurants; portable manual computer interface devices with input keypad; interfaces for computers; input devices for computers; computer keyboards; biometric identification systems; biometric scanners; point-of-sale (POS) terminals; keyboards for point-of-sale (POS) systems; bar code readers for point-of-sale (POS) systems; printers for point-of-sale (POS) systems; optical readers for point-of-sale (POS) systems; computers for point-of-sale (POS) systems; point-of-sale (POS) system equipment and its parts and fittings; point-of-sale terminals; point-of-sale (POS) terminals with weighing function; point-of-sale (POS) terminals with printing function; point-of-sale (POS) terminals with communication function; printers for use with computers; card readers; magnetic card readers; chip card readers; IC card reader/writers; read/write devices for memory cards; smart card readers; card writers; magnetic card writers; chip card writers; smart card writers; NFC readers; RFID readers; NFC writers; RFID writers; credit card terminals; computer programs, downloadable; computer monitors; electronic customer displays; card readers for magnetically encoded cards; bar code readers; 2D barcode readers; data processing apparatus; tablet computers and their parts and fittings; electronic pens for visual display units; ticket printers; ticket dispensing terminals, electronic; electronic cash registers and their parts and fittings; computer peripherals for point-of-sale (POS) systems; computer peripherals; smartphones; mobile phones; wearable computers; electroacoustic transducers; radio communication machines and apparatus; video frequency devices and apparatus; parts and fittings of telecommunication apparatus and instruments; downloadable computer programs using artificial intelligence (AI) for use in software development, machine learning, facial and speech recognition; downloadable music files; downloadable image files; game programs for home video game machines; game programs for portable LCD game machines; downloadable cloud-computing software for managing virtual machines on a cloud computing platform. (1) Providing temporary use of online non-downloadable computer software for printing receipts and order information through cloud computing; providing temporary use of online non-downloadable computer software for displaying receipts and order information on personal digital assistants, smartphones, tablet computers, and computer terminals through cloud computing; providing temporary use of online non-downloadable computer software for control scanners, cash registers, weighing devices, and speakers through cloud computing networks; providing temporary use of online non-downloadable computer software for storing and saving receipts and order information in the memory and storage of computer terminals and computer servers through cloud computing networks; providing temporary use of online non-downloadable computer software for acquiring, monitoring, managing, analyzing, controlling, configuring, and notifying the status information of devices connected to the cloud computing network through cloud computing networks; providing temporary use of online non-downloadable computer software for printing data; providing temporary use of online non-downloadable software for cloud computing; software as a service (SaaS); cloud storage services for electronic data; providing temporary use of online non-downloadable computer programs; design, development and programming of computer software.
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Scales; electronic metering devices, namely, sound level meters and electric meters; digital weighing devices, namely, digital weighing scales, digital weighing machines, and digital weighing apparatus and instruments; electronic weighing devices for inventory control, namely, electronic weighing scales, electronic weighing machines, and electronic weighing apparatus and instruments; electronic weighing devices for transportation services, namely, electronic weighing scales, electronic weighing machines, and electronic weighing apparatus and instruments; electronic weighing devices for point-of-sale (POS) systems, namely, electronic weighing scales, electronic weighing machines, and electronic weighing apparatus and instruments; electronic weighing devices for retail store services, namely, electronic weighing scales, electronic weighing machines, and electronic weighing apparatus and instruments; weighing scales; electronic scales; measures, namely, tape measures, spirit measures, and measuring rulers; weighing apparatus and instruments; measuring and testing machines and instruments, namely, lasers for measuring, pressure measuring apparatus, and semiconductor testing apparatus; cash registers; machines for counting and sorting coins; structural parts of cash registers, namely, cash drawers for cash registers; automated teller machines (ATM); burglar alarms; photographic apparatus and instruments, namely, photographic viewfinders, photographic projectors, and photographic cameras; optical machines and apparatus, namely, optical readers, optical cables, and optical filters; cameras; digital cameras; webcams; digital video cameras; power distribution and control machines and apparatus, namely, power strips, power switches, and power distribution boxes; battery chargers; electrical adapters; electric wires and cables; electric cables for converting the shape of the connection terminal; gender changers, namely, electronic adapter cables and electrical adapters; telecommunication apparatus and instruments, namely, telecommunication cables, telecommunication towers, and telecommunication switches; electric buzzers being acoustic components; electronic buzzers; electric buzzers; personal digital assistants; downloadable and recorded computer programs for use as a spreadsheet and word processing; computer interface boards; touch pads; barcode, optical, and image scanners for point-of sale (pos) systems; 3D scanners; image scanners; barcode, optical, and image scanners being data processing equipment; barcode, optical, and image scanners; electronic payment terminals; tablet computers; telecommunications equipment conforming to short-range wireless communication standards, namely, walkie-talkies; radio-frequency identification (RFID) readers; optical, RFID, and electronic card readers being data processing equipment; display units for point-of-sale (POS) systems, namely, liquid crystal displays, LED monitors, and touchscreen monitors; display monitors, namely, computer display monitors and liquid crystal display (LCD) monitors; computer and flat panel display screens; visual display units, namely, touchscreen monitors; electronic display units, namely, electronic display interfaces; input devices for point-of-sale (POS) systems with keypad, namely, digital input and output scanners; keypads for point-of-sale (POS) systems for entering customer orders and cooking instructions at restaurants and for checking orders after cooking is completed; touch screens for point-of-sale (POS) systems for entering customer orders and cooking instructions at restaurants and for checking orders after cooking is completed; computer input devices for entering customer orders and cooking instructions at restaurants and for checking orders after cooking is completed; machines and apparatus for point-of-sale (POS) systems for managing customer orders, cooking instructions, cooking completion, order confirmation, and serving at restaurants, namely, point-of-sale (POS) terminals and wireless POS (point of service) devices; portable manual computer interface devices with input keypad, namely, computer network interface devices and interfaces for computers; interfaces for computers; input devices for computers; computer keyboards; biometric identification systems consisting of biometric identification apparatus; biometric scanners; point-of-sale (POS) terminals; computer keyboards for point-of-sale (POS) systems; bar code readers for point-of-sale (POS) systems; document printers for point-of sale (POS) systems; optical readers for point-of-sale (POS) systems; computers for point-of-sale (POS) systems; point-of-sale (POS) system equipment and its parts and fittings, namely, point-of-sale (POS) terminals, barcode readers, and barcode scanners; point-of-sale terminals; point-of-sale (POS) terminals with weighing function; point-of-sale (POS) terminals with printing function; point-of-sale (POS) terminals with communication function; document printers for use with computers; chip, electronic, and smart card readers; magnetic encoded card readers; chip card readers; IC card reader and writers, namely, electronic card readers, chip card readers, and bar code printers; read and write devices for memory cards, namely, electronic card readers, chip card readers, and bar code printers; smart card readers; card writers, namely, bar code printers; magnetic card writers, namely, bar code printers; chip card writers, namely, bar code printers; smart card writers, namely, bar code printers; NFC readers, namely, electronic, chip, and smart card readers; RFID readers; NFC writers, namely, bar code printers; RFID writers, namely, bar code printers; credit card terminals; downloadable computer programs for operating electronic point-of-sale (POS) systems from personal digital assistants, smartphones, tablet computers, and computer terminals, displaying order information, placing purchase orders, printing receipts, scanning barcodes, operating electronic cash register systems, recording order and receipt information, printing labels, and calculating shipping costs based on weights of objects, and connecting, operating, and managing networked personal digital assistants, smartphones, tablet computers, computer terminals, and electronic point-of-sale (POS) systems in the internet of things (IoT); computer monitors; electronic customer displays, namely, electronic display interfaces, computer display monitors, and flat panel display screens; card readers for magnetically encoded cards; bar code readers; 2D barcode readers; data processing apparatus; tablet computers and their parts and fittings, namely, structural and replacement parts and computer peripherals; electronic pens for visual display units; ticket printers; ticket dispensing terminals, electronic; electronic cash registers and their parts and fittings, namely, structural and replacement parts and electronic cables; computer peripherals for point-of-sale (POS) systems; computer peripherals; smartphones; mobile phones; wearable computers; electroacoustic transducers; radio communication machines and apparatus, namely, radios, radio receivers, and radio transmitters; video frequency devices and apparatus, namely, video receivers and video processors; parts and fittings of telecommunication apparatus and instruments, namely, telecommunication cables, telecommunication towers, and telecommunication switches; downloadable computer programs using artificial intelligence (AI) for use in software development, machine learning, and facial and speech recognition; downloadable music files; downloadable image files containing product catalogs for point-of-sale (POS) systems and point-of-sale (POS) devices and accessories, images of machine tools for the medical, aviation, and metalworking industries, images of computer printers and scanners, images of computer hardware, branding graphics, product use demonstration screenshots, and infographics related to computer software products; recorded computer, recorded video, and downloadable video game programs for home video game machines; recorded computer, recorded video, and downloadable video game programs for portable LCD game machines; downloadable cloud-computing software for managing virtual machines on a cloud computing platform Providing temporary use of online non-downloadable computer software for printing receipts and order information through cloud computing; providing temporary use of online non-downloadable computer software for displaying receipts and order information on personal digital assistants, smartphones, tablet computers, and computer terminals through cloud computing; providing temporary use of online non-downloadable computer software for control of scanners, cash registers, weighing devices, and speakers through cloud computing networks; providing temporary use of online non-downloadable computer software for storing and saving receipts and order information in the memory and storage of computer terminals and computer servers through cloud computing networks; providing temporary use of online non-downloadable computer software for acquiring, monitoring, managing, analyzing, controlling, configuring, and notifying the status information of devices connected to the cloud computing network through cloud computing networks; providing temporary use of online non-downloadable computer software for printing data; providing temporary use of online non-downloadable software for cloud computing for use in cloud storage of data, database management, and data analysis; software as a service (SaaS) services featuring software for use in database management, for service desk management, and for accounting; cloud storage services for electronic data; providing temporary use of online non-downloadable computer programs for use in database management, for service desk management, and for accounting; design, development and programming of computer software
Provided is a machine tool in which work to replace a collet chuck to suit the outer diameter of a workpiece can be performed easily. An NC lathe 1 machines a workpiece W1 that is being gripped by a first spindle 4. The first spindle 4 comprises a collet chuck 47 which has a chuck body 471 disposed in a tip end part of the first spindle 4 and a gripping portion 472 disposed inside the chuck body 471 to grip the workpiece W1, and a spindle cap 48 which comes into contact with a tip end surface of the chuck body 471 to restrict movement of the chuck body 471 toward the tip end side, wherein: a cap through-hole 48a penetrating in a Z1-axis direction, which is the axial direction of the first spindle 4, is formed in a central part of the spindle cap 48; and the gripping portion 472 is capable of expanding and contracting diametrically in a radial direction perpendicular to the Z1-axis direction and has a rear end side part 472b, positioned on the rear end side of the cap through-hole 48, that is smaller than the cap through-hole 48a, in the radial direction, when the gripping portion is contracted diametrically in the radial direction.
B23B 31/20 - Longitudinally-split sleeves, e.g. collet chucks
31.
MACHINING TIME ESTIMATION DEVICE, MACHINING TIME ESTIMATION METHOD, AND COMPUTER-READABLE NON-TEMPORARY MEDIUM RECORDING MACHINING TIME ESTIMATION PROGRAM FOR LATHE HAVING OPPOSITE SPINDLE
A machining direction determination unit determines a machining direction, i.e., whether to orient a product in a first direction along a material axis or a second direction opposite to the first direction, on the basis of constraint condition data indicating constraint conditions of front machining (first machining) and/or back machining (second machining), and product data. A time estimate output unit calculates a first time estimate required for the front machining and a second time estimate required for the back machining in accordance with the machining direction on the basis of machining condition data indicating machining conditions (including a machining speed) corresponding to tools used respectively for the front machining and the back machining, as well as material data and the product data, and outputs an estimate of a time required to manufacture the product on the basis of the first time estimate and the second time estimate.
G05B 19/4093 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by part programming, e.g. entry of geometrical information as taken from a technical drawing, combining this with machining and material information to obtain control information, named part programme, for the NC machine
B23Q 39/00 - Metal-working machines incorporating a plurality of sub-assemblies, each capable of performing a metal-working operation
The present invention enables a user to confirm the processing progress status of an order without reducing work efficiency in the whole of a restaurant. An information processing device 4 comprises an attachment/detachment detection unit 42 that detects that an order slip 100 has been attached to a slip holder and that the order slip 100 has been removed from the slip holder, and transmits the respective detection information items together with holder position information to a progress management device 5. The progress management device 5 comprises a display control unit 52 that, on the basis of the information transmitted from the information processing device 4, transmits processing progress status information related to attachment/detachment of the order slip 100 to/from the slip holder to a table terminal 1 which corresponds to terminal identification information associated with the holder position information, so as to be displayed thereon. Thus, simply by attaching/detaching, by a kitchen worker, the order slip 100 to/from the slip holder of the information processing device 4 in relation to the processing progress management of the order, the processing progress status information of the order is displayed on the table terminal 1.
The present invention makes it possible to provide useful information for assisting shop staff in performing a task in relation to an order in a shop where orders are managed using paper slips. This task assistance system comprises: an order content recognition unit 52 for recognizing an order content indicated by an order slip 100 attached to a slip holder of an information processing device 4; a reference information generation unit 53 for generating, on the basis of the result of an analysis of the order content, task-related reference information for shop staff of a shop to refer to when performing an order handling task; and a display control unit 54 for displaying the generated task-related reference information on a display of the information processing device 4. Unlike a configuration that simply displays an elapsed time after reception of an order content or an order, by the task assistance system displaying, on the display, the task-related reference information generated on the basis of the result of an analysis of the order content, more useful information can be provided as information for assisting the shop staff in performing a task in relation to the order.
Provided is a machine tool with which the accuracy of a stop position of a drive subject can be improved in a case where semi-closed loop control is performed. The machine tool includes a guide mechanism for guiding at least one drive subject among the tool and the workpiece, a servo motor that moves the drive subject guided by the guide mechanism, and a control unit that performs semi-closed loop control on the servo motor so as to move the drive subject from an initial position to a target position. The control unit performs the semi-closed loop control so as to apply to movement of the drive subject a vibration component with which, from a midway position between the initial position and the target position to the target position, an advancing motion toward the target position and a retreating motion opposite to the advancing motion are performed repeatedly.
G05B 19/4155 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by programme execution, i.e. part programme or machine function execution, e.g. selection of a programme
B23Q 15/007 - Automatic control or regulation of feed movement, cutting velocity or position of tool or work while the tool acts upon the workpiece
Provided is a machine tool with which a load acting on a drive system for driving a drive subject when the drive subject starts to move toward a target position can be reduced. The machine tool includes a guide mechanism for guiding at least one drive subject from among a tool and a workpiece, a servo motor that moves the drive subject guided by the guide mechanism, and a control unit that controls the servo motor so as to move the drive subject from an initial position to the target position. The control unit controls the servo motor so as to apply vibration in which an advancing motion toward the target position and a retreating motion opposite to the advancing motion are performed repeatedly to the drive subject for a set period up to a point at which the drive subject starts to move toward the target position from the initial position.
G05B 19/29 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by positioning or contouring control systems, e.g. to control position from one programmed point to another or to control movement along a programmed continuous path using an absolute digital measuring device for point-to-point control
B23Q 15/12 - Adaptive control, i.e. adjusting itself to have a performance which is optimum according to a preassigned criterion
37.
INVENTORY ANALYSIS DEVICE, INVENTORY ANALYSIS METHOD, AND INVENTORY ANALYSIS SYSTEM
This invention makes it possible to ascertain dead stock that needs to be handled preferentially in the inventory. The present invention is provided with: an inventory index value acquisition unit 12 that acquires an inventory index value, which is an index value pertaining to the inventory status of a product; a sales index value acquisition unit 13 that acquires a sales index value, which is an index value pertaining to the sales status of the product; and an inventory identification unit 14 that identifies, as dead stock, product inventory for which the inventory index value is evaluated to be lower than an inventory threshold value and the sales index value is evaluated to be lower than a sales threshold value. The inventory status is identified on the basis of not only the perspective of whether the inventory index value is evaluated to be lower than the inventory threshold value, but also the logical product thereof with the perspective of whether the sales index value is evaluated to be lower than the sales threshold value, so that it is possible to ascertain the product inventory for which low evaluation values are indicated for both the inventory index value and the sales index value, as dead stock that needs to be handled preferentially in the inventory.
Provided is a printer that is low in maintenance cost. A printer 1 comprises: a printer body 2; a print head 5 that performs printing on a paper sheet PA drawn from a paper roll RP; a movable blade unit 6 mounted to the printer body 2; and a paper sheet sensor 9 that is attached to the movable blade unit 6 and that detects the presence or absence of a paper sheet PA that has passed beyond the print head 5. The paper sheet sensor 9 can be attached to/detached from the movable blade unit 6 in a state where the movable blade unit 6 is mounted to the printer body 2.
An NC lathe includes an energization signal switching unit for switching an energization signal set for each electric device between an energization required state and an energization non-required state, a prohibition signal switching unit for switching an energization prohibition signal set for each electric device between a prohibited state and a permitted state, a signal determination unit that determines whether or not each electric device is in a power saving state in which the energization signal for the electric device is in the energization required state and the energization prohibition signal is in the prohibited state, and a saving calculation unit that determines a cumulative duration of the power saving state, computes a device-specific power saving for each electric device on the basis of the cumulative duration, and calculates a power saving by adding together the device-specific power savings.
A technology capable of improving the accuracy of true-circular machining while avoiding an occurrence of intermittent cutting. A control unit of a machine tool determines an intermediate center position (Pi) in the moving direction for each divided rotation angle (E) smaller than a single rotation of the spindle and an intermediate eccentric radius (ri) around the intermediate center position (Pi) according to an initial position (Po) of the cutting edge in contact with the workpiece in the moving direction, the eccentric center position (Pc), and the eccentric radius (rc) to keep the cutting edge in contact with the workpiece as the moving object moves in the moving direction within a predetermined maximum feed speed (F) until a true-circular machining around the eccentric center position (Pc) is complete on the workpiece.
Provided are a machine tool that inhibits contamination on the exterior of the machine tool, and a chip-taking-out method for the machine tool. An NC lathe 1 for machining a workpiece W comprises: a housing 11; a chip bucket 8 that is placed inside the housing 11 and that receives chips generated through machining of the workpiece W; an opening forming part 112 that is provided at the housing 11 and that has an opening 1121 through which the chip bucket 8 can be drawn out of the housing 11; and an opening cover 15 that is detachably attached to the housing 11 and that covers the opening 1121 in an attached state in which the opening cover 15 is attached to the housing 11. The opening forming part 112 is formed so as to extend continuously to the opening 1121 in the width direction of the opening 1121, and has a slit 1122 through which the opening cover 15 removed from the housing 11 can be inserted into the inside of the housing 11.
B23Q 11/00 - Accessories fitted to machine tools for keeping tools or parts of the machine in good working condition or for cooling workSafety devices specially combined with or arranged in, or specially adapted for use in connection with, machine tools
B23Q 11/08 - Protective coverings for parts of machine toolsSplash guards
In order to improve the machining freedom of a workpiece while suppressing a cost increase, a tool rest for a machine tool includes a cutting tool holder having a plurality of parallel cutting tool fixing grooves to which a shank of a cutting tool can be fixed, and a tool holder that holds a tool for machining a workpiece gripped by a spindle that is capable of rotating about a spindle axis AX0. The tool holder includes a shaft part that is fixed to the cutting tool fixing groove, and a holding part. The holding part holds, as the tool that performs machining about a machining axis AX4, at least one of a rotary tool and a non-rotary tool in which the machining axis AX4 extends along the spindle axis AX0.
A vibration-cutting condition setting device capable of facilitating a selection of a tool and a setting of parameters. The vibration-cutting condition setting device for a machine tool includes a display unit and a control unit. The control unit accepts a setting for controlling an object to be fed with an vibration. The setting includes a feed speed without the vibration (F) of the object, a first parameter (A) regarding a cycle of the vibration, and a second parameter (E) regarding an amplitude of the vibration. The control unit calculates a maximum feed speed (Fmax) of the object according to the feed speed without the vibration (F), the first parameter (A), and the second parameter (E) and then displays a value representing the calculated maximum feed speed (Fmax) on the display unit.
A lathe system includes a spindle capable of gripping a bar and moving back and forth in an axial direction of the bar and a tool post to which a first tool is attached. The lathe system can manufacture a plurality of products having an identical shape from the bar by repeating a machining of the bar, a cutting off of a machined portion of the bar, and a grip change by the spindle, the grip change by the spindle comprising releasing the bar, moving back, and re-gripping the bar at a predetermined gripping position. The lathe system further includes a gripping position selecting unit capable of selecting a special gripping position at which the spindle re-grips the bar when a state of the machine tool system meets a predetermined condition, the special gripping position being different from the predetermined gripping position.
Provided is a machine tool with which a tool exchanging operation is easy. In a machine tool including a spindle that is capable of rotating about a spindle axis CL1 while gripping a workpiece and a tool post, the tool post includes a quadruple rotary tool unit to which one-side rotary tools for machining the workpiece are attached and which is capable of swiveling using, as a swiveling center, a first swiveling axis B1 that extends in a Y1-axis direction orthogonal to the spindle axis CL1, and a swiveling base to which the quadruple rotary tool unit is attached, and the quadruple rotary tool unit is attached to the swiveling base removably.
The present invention provides a machine tool system and a control method for the machine tool system, with which a decrease in machining accuracy is prevented. A lathe system 1 includes a main spindle 25 that grips a rod material W, a correction amount determining unit 20b that determines a correction amount of a relative position between a cutting edge position of a first tool T1 that machines the rod material W gripped by the main spindle 25 and the rod material W, and a machine control unit 20a that corrects the relative position using the correction amount determined by the correction amount determining unit 20b and causes the rod material W to be machined, wherein the correction amount determining unit 20b determines the correction amount as an amount that is reduced in accordance with an amount of change of an element that changes as machining progresses.
B23B 13/00 - Arrangements for automatically conveying, chucking or guiding stock for turning machines
B23B 13/02 - Arrangements for automatically conveying, chucking or guiding stock for turning machines for turning-machines with a single working-spindle
G05B 19/404 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by control arrangements for compensation, e.g. for backlash, overshoot, tool offset, tool wear, temperature, machine construction errors, load, inertia
48.
MACHINE TOOL SYSTEM, AND METHOD FOR CONTROLLING MACHINE TOOL SYSTEM
Provided are a machine tool system and a method for controlling a machine tool system which prevent rod stock from popping out. A lathe system 1 which is equipped with: a main shaft 25 which grips rod stock W so as to be capable of releasing said grip; a first tool holder 27 which is capable of moving in a direction which is perpendicular to the axial direction of the rod stock W, and to which a first machining tool T1 for machining the tip end section of the rod stock W is attached; a feed arrow 44 for biasing the rod stock W toward the tip end side of the rod stock W from the rear end side of the rod stock W in a manner such that the biasing is releasable; and a tool holder movement prevention part 20b for preventing movement in a direction which causes the first tool holder 27 to move away from the rod stock W when in a state in which the feed arrow 44 is biasing the rod stock W and the grip of the main shaft 25 on the rod stock W has been released.
B23B 13/02 - Arrangements for automatically conveying, chucking or guiding stock for turning machines for turning-machines with a single working-spindle
49.
MACHINE TOOL SYSTEM, AND METHOD FOR CONTROLLING MACHINE TOOL SYSTEM
Provided are a machine tool system and a method for controlling a machine tool system with which accidents are not liable to occur. A lathe system 1 for manufacturing a plurality of products from one elongate rod material W by repeating, a plurality of times, machining of a tip end part of the rod material W and cutting off of a machined part that has been machined, comprises: a main spindle 25 which, when re-gripping the rod material W, releases grasping of the rod material W, moves in a Z1 axis direction to a grasping position, and grasps the rod material W; a pusher 44 which moves together with the rod material W in the Z1 axis direction; and a grasping position determining unit 20a which, each time re-gripping occurs, calculates a number N of products that can be machined while the main spindle 25 maintains its grasp of the rod material W, on the basis of a position of the pusher 44, a set movable distance Zp of the main spindle 25 in the Z1 axis direction, and a machining material length L3 required to machine one product, and determines the grasping position corresponding to the number N of products.
B23B 13/02 - Arrangements for automatically conveying, chucking or guiding stock for turning machines for turning-machines with a single working-spindle
B23B 13/00 - Arrangements for automatically conveying, chucking or guiding stock for turning machines
B23B 13/04 - Arrangements for automatically conveying, chucking or guiding stock for turning machines for turning-machines with a plurality of working-spindles
A highly convenient machine tool system is provided. An NC lathe as an example of the machine tool system includes a first tool post to which a first tool for machining a workpiece is attached, a numerical control unit adapted to control a movement of the first tool post according to a numerical control program, and a scanner adapted to measure a position and a shape of the first tool attached to the first tool post brought to a predetermined position under control of the numerical control unit.
A lathe system capable of manufacturing a long product from a bar by performing a grip change by a spindle during a machining cycle, the long product being of a length exceeding a movable range of the spindle, the spindle releasably gripping the bar and moving in a Z1-axis direction of the bar. The lathe system includes a pusher capable of moving in the Z1-axis direction together with the bar. The lathe system further includes a bar length shortage prior determination unit that determines whether the pusher is in a position permitting the grip change to be performed during the machining cycle. The determination is made prior to the start of the machining cycle.
B23B 13/02 - Arrangements for automatically conveying, chucking or guiding stock for turning machines for turning-machines with a single working-spindle
A machine tool system capable of decreasing the operator's burden in setting the parameters. A machine tool system includes a working machine capable of machining a bar and a bar feeder capable of delivering the bar to the working machine according to the machining of the bar. The bar feeder delivers the bar in accordance with a set parameter. The bar feeder updates the parameter according to parameter information transmitted from the working machine.
Provided are a machine tool system and a method for controlling a machine tool system having good operability and capable of eliminating complex work. The machine tool system comprises a main spindle 25 capable of moving a rod material W in an axial direction, a guide bush 26 for supporting the rod material W, a first tool post 27 having attached thereto a first tool T1 for machining a tip end part of the rod material W supported by the guide bush 26, a pusher 44 capable of urging the rod material W toward a tip end side of the rod material W, a first control device 20 for controlling operations of the main spindle 25 and operations of the first tool post 27, and a second control device 40 for controlling operations of the pusher 44, wherein the first control device 20 has a rod material retraction mode for: causing the first tool post 27 to machine a tip end of the rod material W in a state in which the main spindle 25 is gripping the rod material W; causing the main spindle 25 to move back to pull the rod material W out from the guide bush 26; causing the second control device 40 to release the urging of the pusher 44; and causing the gripping of the rod material W by the main spindle 25 to be released.
B23B 13/00 - Arrangements for automatically conveying, chucking or guiding stock for turning machines
B23Q 11/00 - Accessories fitted to machine tools for keeping tools or parts of the machine in good working condition or for cooling workSafety devices specially combined with or arranged in, or specially adapted for use in connection with, machine tools
A machine tool system of the present invention includes a rotatable spindle capable of releasably gripping a bar, a pusher that biases the bar from a rear end thereof toward a front end thereof to be movable together with the bar in a Z1-axis direction thereof, and an abnormality determining unit that determines whether an abnormality occurs by monitoring movement of the pusher in the Z1-axis direction. The spindle is movable in the Z1-axis direction, and the abnormality determining unit determines that a first abnormality occurs when the moving distance of the spindle differs from the moving distance of the pusher in a state that the spindle grips the bar.
The present invention provides a technology that makes it possible to increase convenience in managing products formed by a machine tool. A machine tool (1) comprises: a drive unit (U11, U12) that changes the relative positional relationship between a workpiece (W1) and a tool (TO1); a reception unit (U2) that receives input of information (IN1) for causing a detection device (200) to perform detection; and a control unit (U3). The control unit (U3) causes the drive unit (U1) to change the relative positional relationship to form, in the workpiece (W1) during machining by the tool (TO1), a cut trace (C1) including embedded information (IN2) from which the information (IN1) can be detected by the detection device (200).
Provided is a machine tool and a method for controlling the machine tool capable of precisely determine a success or a failure of a cut-off. An NC lathe performs a cut-off of a workpiece gripped by a first spindle and a second spindle and then performs a separation movement of the second spindle in a direction separating from the first spindle. The NC lathe includes a movement controlling unit adapted to perform a stop control of the first spindle at a command position of the first spindle during the separation movement of the second spindle and a cut-off success or failure determining unit adapted to monitor a positional deviation of the first spindle during the separation movement of the second spindle to determine a success or a failure of the cut-off, the positional deviation being a difference between the command position and an actual position of the first spindle.
B23B 1/00 - Methods for turning or working essentially requiring the use of turning-machinesUse of auxiliary equipment in connection with such methods
G05B 19/402 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by control arrangements for positioning, e.g. centring a tool relative to a hole in the workpiece, additional detection means to correct position
A machine tool capable of facilitating the setting of the vibration cutting conditions. A control unit acquires a feed speed of a object to be fed without a vibration (Fa), a number of rotations of a spindle required for a single cycle of the vibration (K), and a returning amount (R) representing a distance of a returning feed per the single cycle of the vibration. According to the acquired parameters, the control unit decides at least one parameter among a cutting amount (D) representing a distance of a change in a position of the object per the single cycle of the vibration, a cutting feed speed (F) of the object, and a returning feed speed (B) of the object. The control unit controls the position of the object to be fed with the vibration at least according to the decided parameter.
The machine tool includes a second spindle rotatable about a second spindle axis while gripping a cut-off portion of a workpiece, a second tool post to which a rotary tool that machines the cut-off portion of the workpiece gripped by the second spindle is attached, and a second tool post base that supports the second tool post, in which the second tool post includes a power transmission mechanism that transmits a driving force for rotationally driving the rotary tool, a base table, and a tool mounting member to which the rotary tool is attached, the power transmission mechanism is disposed between the base table and the tool mounting member, a back side of the base table faces the second tool post base and the tool mounting member is disposed on a front side of the base table, and the tool mounting member is detachably attached to the base table.
A machine tool capable of preventing production of a defective product. The processing unit determines whether the workpiece exists in the predetermined area. In the event that the workpiece exist in the area, the processing unit execute the top cut process. In the event that the workpiece does not exist in the area, the processing unit determines that the workpiece is in the abnormal position.
G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]
B23Q 15/12 - Adaptive control, i.e. adjusting itself to have a performance which is optimum according to a preassigned criterion
60.
DRAWER CONTROL APPARATUS, DRAWER CONTROL METHOD, AND DRAWER CONTROL SYSTEM
A drawer control apparatus capable of precisely discriminating whether the drawer open state is triggered by the drawer open command process or otherwise. The drawer control apparatus includes a command receiving unit, a drawer connection detecting unit, a command processing unit, a drawer open/closed signal receiving unit, and an open trigger discriminating unit. The command processing unit executes a drawer open command process upon receiving a drawer open command. The drawer open command process includes sending a drawer open signal and setting a process execution flag upon detecting presence of drawer connection. The drawer open command process ends upon detecting absence of drawer connection. The open trigger discriminating unit discriminates whether the drawer open state is triggered by the drawer open command process or otherwise according to a set state of the process execution flag upon receiving a signal representing the drawer open state.
The present invention makes it possible to detect the connection of a USB-mounted apparatus with more combinations. This USB connection detection device comprises: a VBUS monitoring unit 11 which determines whether another USB-mounted apparatus (another machine) is connected, according to the voltage of a VBUS terminal of a USB-C mounted apparatus (host machine) which is of type C and has a port type of source/host; a CC monitoring unit 12 which determines whether another machine is connected, according to the voltage of a CC terminal of the host machine and the other machine; and a port type switching unit 13 which automatically switches the port type of the host machine into a sync device when the connection of the other machine has been detected by the monitoring of the voltage of the VBUS terminal, wherein it is possible to detect the connection of a USB-A mounted apparatus by monitoring the voltage of the VBUS terminal, it is possible to perform power supply and communication by switching the port type into sync/device, and it is possible to detect the connection of a USB-B mounted apparatus or a USB-C mounted apparatus by monitoring the CC terminal.
A printer provided with a storing space for a paper roll having a core hole in the center includes a paper roll holder having a protrusion adapted to fit into the core hole of the paper roll. The paper roll holder is switchable between a protruded state that the protrusion protrudes into the storing space and a retracted state that the protrusion retracts from the storing space. The printer further includes a stopper adapted to engage with the paper roll holder while the paper roll holder is in the protruded state to prevent the protrusion from turning to a predetermined direction. The paper roll holder moves when pushed by the paper roll that is being set into the storing space. Movement of the paper roll holder releases the engagement with the stopper to allow the protrusion to turn to the predetermined direction.
The present invention increases the freedom of processing of a workpiece while suppressing an increase in cost. A tool rest (3) for a machine tool comprises: a turning tool holder 31 including a plurality of parallel turning tool fixing grooves 33 to which a shank 41 of a turning tool 40 can be fixed; and a tool holder 5 for holding a tool 60 for processing a workpiece W1 gripped by a spindle 11 rotatable around a spindle centerline AX0. The tool holder 5 comprises a shaft portion 50 fixed to the turning tool fixing grooves 33, and a holding portion 54. The holding portion 54 holds, as the tool 60 for processing around a processing axis AX4, a rotating tool and/or a non-rotating tool in which the processing axis AX4 is along the spindle centerline AX0.
09 - Scientific and electric apparatus and instruments
Goods & Services
Scales; electronic metering devices; digital weighing
devices; electronic weighing devices for inventory control;
electronic weighing devices for transportation services;
electronic weighing devices for point-of-sale [POS] systems;
electronic weighing devices for retail store services;
weighing scales; electronic scales; measures; weighing
apparatus and instruments; measuring or testing machines and
instruments; robots for use in laboratories; cash registers;
machines for counting or sorting coins; cash drawers for
cash registers; automated teller machines [ATM]; fire
alarms; gas leak alarms; burglar alarms; photographic
apparatus and instruments; optical machines and apparatus;
cameras; digital cameras; webcams; digital video cameras;
power distribution or control machines and apparatus;
battery chargers; electrical adapters; electric wires and
cables; electric cables for converting the shape of the
connection terminal; gender changers [cable adapters];
telecommunication machines and apparatus; buzzers being
acoustic components; electronic buzzers; buzzers; personal
digital assistants; computer programs; electronic control
apparatus for machines; computer software applications,
downloadable; computer peripherals and accessories; touch
pads; scanners for point-of sale [POS] systems; 3D scanners;
image scanners; scanners [data processing equipment];
scanners; electronic payment terminals; tablet computers;
telecommunications equipment conforming to short-range
wireless communication standards; radio-frequency
identification [RFID] readers; readers [data processing
equipment]; display units for point-of-sale [POS] systems;
display monitors; display screens; visual display units;
electronic display units; input devices for point-of-sale
[POS] systems with keypad; keypads for point-of-sale [POS]
systems for entering customer orders and cooking
instructions at restaurants, and for checking orders after
cooking is completed; touch screens for point-of-sale [POS]
systems for entering customer orders and cooking
instructions at restaurants, and for checking orders after
cooking is completed; computer input devices for
point-of-sale [POS] systems for entering customer orders and
cooking instructions at restaurants, and for checking orders
after cooking is completed; machines and apparatus for
point-of-sale [POS] systems for managing customer orders,
cooking instructions, cooking completion, order
confirmation, and serving at restaurants; portable manual
computer interface devices with input keypad; interfaces for
computers; input devices for computers; computer keyboards;
stands adapted for tablet computers; biometric
identification systems; biometric scanners; point-of-sale
[POS] terminals; keyboards for point-of-sale [POS] systems;
bar code readers for point-of-sale [POS] systems; printers
for point-of-sale [POS] systems; optical readers for
point-of-sale [POS] systems; computers for point-of-sale
[POS] systems; point-of-sale [POS] system equipment and its
parts and fittings; point-of-sale terminals; point-of-sale
[POS] terminals with weighing function; point-of-sale [POS]
terminals with printing function; point-of-sale [POS]
terminals with communication function; printers for use with
computers; card readers; magnetic card readers; chip card
readers; IC card reader/writers; read/write devices for
memory cards; smart card readers; card writers; magnetic
card writers; chip card writers; smart card writers; NFC
readers; RFID readers; NFC writers; RFID writers; credit
card terminals; computer programs, downloadable; computer
monitors; customer display screens; electronic customer
displays; card readers for magnetically encoded cards; bar
code readers; 2D barcode readers; data processing apparatus;
tablet computers and their parts and fittings; electronic
pens [visual display units]; ticket printers; ticket
dispensers; electronic cash registers and their parts and
fittings; computer peripherals for point-of-sale [POS]
systems; computer peripherals; smartphones; mobile phones;
wearable computers; electroacoustic transducers; radio
communication machines and apparatus; video frequency
devices and apparatus; parts and fittings for
telecommunication machines and apparatus; humanoid robots
having communication and learning functions for entertaining
(excluding those for industrial, medical, and amusement
purposes); user programmable humanoid robots for
entertainment (excluding those for industrial, medical, and
amusement purposes); learning support and life support
robots with built-in computers (excluding those for
industrial, medical, and amusement purposes); humanoid
bipedal walking robots (excluding those for industrial,
medical, and amusement purposes) for use in scientific
research; computers and other electronic machines and
apparatus with artificial intelligence (including those for
robots) and their parts and fittings; teaching robots;
security surveillance robots; computer software in the field
of artificial intelligence; downloadable music files;
downloadable image files; consumer video game programs;
computer programs for hand-held games with liquid crystal
displays.
65.
Machine tool and method of deciding tool moving path
A controller of a machine tool acquires coordinates of a first machining start point of an eccentric shape in a reference phase of a workpiece around a spindle axis, a second machining start point in an anti-phase, a first machining end point in the reference phase, and a second machining end point in the anti-phase. The controller decides a moving path of the tool in association with rotation of the workpiece at least according to the coordinates of the first start point, the second start point, the first end point, and the second end point to form the eccentric shape around an eccentric axis passing a start point origin between the first start point and the second start point and an end point origin between the first end point and the second end point and thereby controls movement of the tool in association with rotation of the workpiece.
The present invention provides a machine tool which makes tool replacement easy. Provided is a machine tool 1 comprising a main spindle 31 which holds a workpiece W and which is rotatable about a main spindle center line CL1, and a cutting tool rest 5, wherein: the cutting tool rest 5 has a quad rotating tool unit 53 to which is installed a rotating tool 93a on one side that machines the workpiece W and which is capable of turning about a first turning axis line B1 that is along a Y1 axis direction orthogonal to the main spindle center line CL1, and a turning base 52 to which the quad rotating tool unit 53 is attached; and the quad rotating tool unit 53 is detachable from the turning base 52.
A controller of a machine tool determines in accordance with a machining program whether a first tool post is used to machine an unfinished workpiece. When the unfinished workpiece needs machining before terminating a continuous machining and when the controller determines that the first tool post is used to machine the unfinished workpiece W2, the controller simultaneously advances a first system and a second system in accordance with the machining program while preventing machining a workpiece held by the first spindle. When the controller determines that the first tool post is not used to machine the unfinished workpiece, the controller stops the first system and advances the second system in accordance with the machining program.
G05B 19/4155 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by programme execution, i.e. part programme or machine function execution, e.g. selection of a programme
68.
Lathe and method of detecting cut-off tool breakage
A lathe includes a spindle, an opposite spindle, a tool post, a controller, and a contact-type breakage detector. The controller determines whether the cut-off tool is broken according to a control parameter for controlling at least one of the spindle and the opposite spindle at a first detection timing immediately after the cut-off tool cuts off the bar material while the opposite spindle holds the bar material held by the spindle. The controller determines whether the cut-off tool is broken according to a detection result by the contact-type breakage detector at a second detection timing different from the first detection timing.
B23Q 17/09 - Arrangements for indicating or measuring on machine tools for indicating or measuring cutting pressure or cutting-tool condition, e.g. cutting ability, load on tool
B23B 1/00 - Methods for turning or working essentially requiring the use of turning-machinesUse of auxiliary equipment in connection with such methods
Provided is a highly convenient machine tool system. The NC lathe 1, which is an example of the machine tool system according to the present invention, comprises: a first tool rest 5 to which a first tool T1 for processing a workpiece W is attached; a numerical control unit 27 that controls the movement of the first tool rest 5 on the basis of an NC program; and a scanner 9 that measures the position and shape of the first tool T1 attached to the first tool rest 5 which is moved to a predetermined position under the control of the numerical control unit 27.
B23Q 17/24 - Arrangements for indicating or measuring on machine tools using optics
B23B 25/06 - Measuring, gauging, or adjusting equipment on turning-machines for setting-on, feeding, controlling, or monitoring the cutting tools or work
B23Q 17/00 - Arrangements for indicating or measuring on machine tools
B23Q 17/22 - Arrangements for indicating or measuring on machine tools for indicating or measuring existing or desired position of tool or work
G05B 19/18 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form
G05B 19/4069 - Simulating machining process on screen
09 - Scientific and electric apparatus and instruments
Goods & Services
Numerically controlled metalworking lathes; metalworking
lathes, metalworking machines and tools; computer numerical
control [CNC] machine tools for metalworking machines; parts
and fittings for the aforesaid. Software for numerically controlled metalworking lathes and
machines to enable swarf or chips to be broken into shorter
chips; computer software for controlling the operation of
numerically controlled metalworking lathes and machines;
computer software for editing machining programs of
numerically controlled metalworking lathes and machines.
71.
VIBRATION-CUTTING CONDITION SETTING DEVICE FOR MACHINE TOOL
Provided is a vibration-cutting condition setting device that makes it easy to select a tool for vibration cutting and to set a parameter. A vibration-cutting condition setting device 3 for a machine tool 1 comprises a display unit U3, and a control unit U4. The control unit U4 receives, as settings for controlling feeding movement of a driven object to involve vibration, a feed rate (F) when the driven object is not vibrated, a first parameter (A) relating to a cycle of vibration, and a second parameter (E) relating to amplitude of vibration. The control unit U4 calculates a maximum feed rate (Fmax) of the driven object, on the basis of the feed rate (F) when the driven object is not vibrated, the first parameter (A), and the second parameter (E), and displays a value indicating the calculated maximum feed rate (Fmax) on the display unit U3.
G05B 19/409 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by using manual data input [MDI] or by using control panel, e.g. controlling functions with the panelNumerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by control panel details or by setting parameters
G05B 19/4093 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by part programming, e.g. entry of geometrical information as taken from a technical drawing, combining this with machining and material information to obtain control information, named part programme, for the NC machine
A machine tool includes a spindle capable of holding a workpiece and rotatable on a spindle axis and a tool post on which a tool is attachable to machine the workpiece held by the spindle. The tool post includes a first turnable holder turnable on a first turning axis perpendicular to the spindle axis. The first turnable holder has a first tool unit mounting part where a rotary tool is attachable. The tool post further includes a second turnable holder turnable on a second turning axis perpendicular to the spindle axis and different from the first turning axis. The second turnable holder has a second whirling tool mounting part where a thread whirling tool is attachable.
B23B 29/32 - Turrets adjustable by power drive, i.e. turret heads
B23B 13/02 - Arrangements for automatically conveying, chucking or guiding stock for turning machines for turning-machines with a single working-spindle
B23B 27/06 - Profile cutting tools, i.e. forming-tools
B23Q 39/00 - Metal-working machines incorporating a plurality of sub-assemblies, each capable of performing a metal-working operation
B23Q 39/02 - Metal-working machines incorporating a plurality of sub-assemblies, each capable of performing a metal-working operation the sub-assemblies being capable of being brought to act at a single operating station
Provided is a lathe that can eliminate the need for a device dedicated to detection of breakage of a parting tool. A lathe 1 is provided with a spindle (11), a counter spindle (16), a tool rest 30, a stopper 40, a driving unit (31), and a control unit (70). The stopper 40 positions a bar material B1 at an advanced position P1 where the bar material B1 pushed forward by a material feeding machine 20 from the spindle (11) having released the bar material B1 bumps, and is retractable from the advanced position P1. After completion of an operation of cutting off a workpiece W1 by a parting tool TO3 in a state where the stopper 40 is retracted from the advanced position P1, the control unit (70) carries out a control of causing the driving unit (31) to move the stopper 40 to a position (P3) between the bar material B1 grasped by the spindle (11) and the workpiece W1 grasped by the counter spindle (16), and, when a torque generated by the driving unit (31) exceeds reference torque for detecting the bump of the stopper 40 against the bar material B1, carries out a process (S124) for a case in which the parting tool TO3 is broken.
B23B 25/06 - Measuring, gauging, or adjusting equipment on turning-machines for setting-on, feeding, controlling, or monitoring the cutting tools or work
B23B 13/04 - Arrangements for automatically conveying, chucking or guiding stock for turning machines for turning-machines with a plurality of working-spindles
B23Q 17/09 - Arrangements for indicating or measuring on machine tools for indicating or measuring cutting pressure or cutting-tool condition, e.g. cutting ability, load on tool
74.
MACHINE TOOL AND METHOD FOR CONTROLLING MACHINE TOOL
Provided are: a machine tool which can precisely determine whether or not a dinking process has been performed successfully; and a device for controlling the machine tool. An NC lathe 1 performs, in a state where an identical workpiece W is being held by a first main shaft 31 capable of moving in the axial direction and a second main shaft 61 opposing the first main shaft 31, dinking on the workpiece W, and then performs separation movement for moving the second main shaft 61 in a direction that moves away from the first main shaft 31. The NC lathe comprises: a movement control unit 211 which performs control to stop the first main shaft 31 at a command position during the separation movement; and a dinking success/failure determination unit 213 which monitors, during the separation movement, positional deviation representing the difference between the command position and the actual position of the first main shaft 31, and which determines, on the basis of the positional deviation, whether or not the dinking process has been successful.
B23B 25/06 - Measuring, gauging, or adjusting equipment on turning-machines for setting-on, feeding, controlling, or monitoring the cutting tools or work
B23B 3/30 - Turning-machines with two or more working-spindles, e.g. in fixed arrangement
B23B 13/04 - Arrangements for automatically conveying, chucking or guiding stock for turning machines for turning-machines with a plurality of working-spindles
B23B 15/00 - Arrangements for conveying, loading, adjusting, reversing, chucking, or discharging workpieces specially designed for automatic or semi-automatic turning-machines
B23Q 15/24 - Control or regulation of position of tool or workpiece of linear position
B23Q 17/09 - Arrangements for indicating or measuring on machine tools for indicating or measuring cutting pressure or cutting-tool condition, e.g. cutting ability, load on tool
G05B 19/4062 - Monitoring servoloop, e.g. overload of servomotor, loss of feedback or reference
Provided is a machine tool in which a setting for vibration cutting can be easily carried out. A control unit U3 of a machine tool 1 acquires the feed rate (Fa) of a drive object during non-rotation, the rotational speed (K) of a main shaft 11 required for a single cycle of vibration, and a return amount (R) which is the distance of return movement M2 in a single cycle of vibration, determines at least one parameter from among a cutting amount (D) which is the distance by which the position of the drive object changes per cycle of vibration, the speed (F) of the drive object during cutting movement, and the speed (B) of the drive object during return movement on the basis of the feed rate (Fa) of the drive object during non-vibration, the rotational speed (K) of the main shaft, and the return amount (R), and uses at least the determined parameter to control the position of the drive object during feed movement.
B23B 1/00 - Methods for turning or working essentially requiring the use of turning-machinesUse of auxiliary equipment in connection with such methods
G05B 19/4093 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by part programming, e.g. entry of geometrical information as taken from a technical drawing, combining this with machining and material information to obtain control information, named part programme, for the NC machine
G05B 19/4155 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by programme execution, i.e. part programme or machine function execution, e.g. selection of a programme
09 - Scientific and electric apparatus and instruments
Goods & Services
Numerically controlled metalworking lathes; metalworking lathes, metalworking machines and machine tools; computer numerical control [CNC] machine tools for metalworking machines; parts and fittings for the aforesaid Downloadable software for numerically controlled metalworking lathes and machines to enable swarf or chips to be broken into shorter chips; downloadable computer software for controlling the operation of numerically controlled metalworking lathes and machines; downloadable computer software for editing machining programs of numerically controlled metalworking lathes and machines
This invention improves the workability of attaching an ejector pin to the front end of a push rod. A machine tool (1) is provided with a spindle (21), a gripping mechanism (22), a push rod (23), an ejector pin (30), a retaining member (24), and an extruding mechanism (25), wherein the retaining member (24) is provided to the outer side of the push rod (23) and retains the push rod (23) in an axial center position centering on the spindle centerline (AX2); the extruding mechanism (25) applies force in the advancing direction (D1) on the push rod (23) having passed through the retaining member (24), thereby extruding by means of the ejector pin (30) a workpiece (W1) released from the gripping mechanism (22); and as an assembly (31) that includes an ejector pin main unit (40) that can be passed through the retaining member (24), and an abutment member (45) removably attached to the front end (40a) of the ejector pin main unit (40), the ejector pin (30) is attached to the front end (23a) of the push rod (23).
B23B 15/00 - Arrangements for conveying, loading, adjusting, reversing, chucking, or discharging workpieces specially designed for automatic or semi-automatic turning-machines
B23B 31/00 - ChucksExpansion mandrelsAdaptations thereof for remote control
An NC lathe including a first spindle, a second spindle capable of holding a cut-off workpiece delivered from the first spindle, a second tool post on which a plurality of tools are attachable to machine the workpiece held by the second spindle, a product receiver provided on the second tool post, a Y2-axis motor capable of moving at least one of the second tool post and the second spindle in a Y2-axis direction, and an X2-axis motor capable of moving at least one of the second tool post and the second spindle in an X2-axis direction. The second tool post has a plurality of tool mounting parts where the tools are attachable. The tool mounting parts are aligned at intervals in the Y2-axis direction. At least one of the tool mounting parts is arranged in a position overlapping the product receiver with respect to the X2-axis direction.
B23B 3/06 - Turning-machines or devices characterised only by the special arrangement of constructional units
B23Q 39/02 - Metal-working machines incorporating a plurality of sub-assemblies, each capable of performing a metal-working operation the sub-assemblies being capable of being brought to act at a single operating station
Provided is a machine tool with high maintainability. The machine tool is provided with: a second spindle 61 that is rotatable around a second spindle center line CL2 while holding a cut workpiece W2; a second blade table 7 to which a rotating tool T2R, which processes the cut workpiece W2 held by the second spindle 61, is attached; and a second blade table base 70 that supports the second blade table 7. The second blade table 7 includes a power transmission mechanism 74 that transmits driving force for rotationally driving the rotating tool T2R, a base table 71, and a tool attachment member 72 to which the rotating tool T2R is attached. The power transmission mechanism 74 is arranged between the base table 71 and the tool attachment member 72. The base table 71 has a back side facing the second blade table base 70, and a front side on which the tool attachment member 72 is arranged. The tool attachment member 72 is detachably attached to the base table 71.
A lathe includes a spindle rotatable on a spindle axis, a tool post to which a tool is attachable, an X1-axis ball screw extended in an X1-axis direction perpendicular to the spindle axis and capable of moving the tool post in the X1-axis direction, and an X1-axis support bearing provided on an end of the X1-axis ball screw with respect to the X1-axis direction to restrict movement of the X1-axis ball screw in the X1-axis direction. The tool post is provided with an X1-axis ball screw nut engaged with the X1-axis ball screw. The X1-axis ball screw nut is movable in the X1-axis direction according to rotation of the X1-axis ball screw. The direction that the X1-axis ball screw nut approaches the X1-axis support bearing faces the same direction as the direction that the tool cuts into the workpiece.
B23B 3/30 - Turning-machines with two or more working-spindles, e.g. in fixed arrangement
B23B 3/06 - Turning-machines or devices characterised only by the special arrangement of constructional units
B23Q 5/40 - Feeding other members supporting tools or work, e.g. saddles, tool-slides, through mechanical transmission feeding continuously by feed shaft, e.g. lead screw
42 - Scientific, technological and industrial services, research and design
Goods & Services
Providing computer programs in data networks for electronic
point-of-sale systems that generate and issue electronic
receipts; providing computer programs in data networks for
monitoring and controlling the status of printers, machine
tools, and computer peripheral equipment connected to cloud
computing networks; providing computer programs in data
networks for electronic point-of-sale systems that issue and
manage coupons through cloud computing networks; providing
computer programs in data networks for sending printing data
to printers connected to cloud computing networks; providing
computer programs in data networks for managing and
controlling the distribution of data to mobile computer
terminals and computer peripheral equipment connected to
cloud computing networks; monitoring of computer systems by
remote access for printers, machine tools, and computer
peripheral equipment connected to cloud computing networks.
09 - Scientific and electric apparatus and instruments
Goods & Services
Weighing scales for use with electronic point-of-sale (POS) systems; weighing scales; weighing machines; weighing apparatus and instruments; apparatus and instruments for weighing; electronic weighing scales for kitchen use; medical weighing scales; wireless electronic scales; portable digital electronic scales; hand-held electronic scales; scales; computer peripheral devices; electronic data processing apparatus; optical scanners; scanners; image scanners; hand scanner; bar code scanners; bar code readers; optical readers
09 - Scientific and electric apparatus and instruments
Goods & Services
(1) Electronic weighing scale for use at point-of-sale; electronic weighing scales for retail use in grocery stores, laundromats and dry-cleaning stores, fabric stores, farmer's markets, nursery and garden centers, farm supply stores, cannabis dispensaries, jewelry stores, pawn shops; electronic weighing scales for kitchen use; electronic weighing scales for cargo inventory control; electronic weighing scales for medical use; electronic weighing truck scales for shipping use; wireless electronic weighing scales for personal use; computer hardware for data processing; bar code scanners; hand-held electronic scanners; image scanners; optical scanners; bar code readers; USB card readers; smart card readers; radio-frequency identification (RFID) readers; computer software for processing digital images
84.
DRAWER CONTROL APPARATUS, DRAWER CONTROL METHOD, AND DRAWER CONTROL SYSTEM
A drawer control apparatus capable of precisely discriminating whether the drawer open state is triggered by the drawer open command process or otherwise. The drawer control apparatus 1 includes a command receiving unit 12, a drawer connection detecting unit 14, a command processing unit 111, a drawer open/closed signal receiving unit 15, and an open trigger discriminating unit 113. The command processing unit 111 executes a drawer open command process upon receiving a drawer open command. The drawer open command process includes sending a drawer open signal and setting a process execution flag upon detecting presence of drawer connection. The drawer open command process ends upon detecting absence of drawer connection. The drawer open/closed signal receiving unit 15 receives an open/closed signal from the drawer 8. The open trigger discriminating unit 113 discriminates whether the drawer open state is triggered by the drawer open command process or otherwise according to a set state of the process execution flag upon receiving the signal representing the drawer open state.
Provided is a drawer control device for determining with high accuracy whether the opening of a drawer device is due to a drawer-opening command process or is due to another method. This drawer control device 1 is provided with: a command reception unit 12 for receiving commands; a connection detection unit 14 for detecting whether a drawer device 8 connection exists; a command processing unit 111 for beginning a drawer-opening command process upon reception of a drawer-opening command, transmitting a drawer-opening signal for opening the drawer device 8 and setting a process execution flag when the detection result from the connection detection unit 14 indicates that there is connection, and ending the drawer-opening command process when the detection result indicates that there is no connection; an opening/closing signal reception unit 15 for receiving an open/closed signal indicating the open/closed state of the drawer device 8; and an opening cause determination unit 113 for determining, on the basis of whether the process execution flag has been set, whether the drawer device 8 has been opened by the drawer-opening command process, when the open/closed signal indicates an open state.
The printer (10) of the present disclosure is a printer connectable to a network (30) and an information processing terminal (20), including a control section (15) configured to: when obtaining data in accordance with the network class from the information processing terminal (20), extract a first frame based on a first communication standard used for communications between the printer (10) and the network (30), from the data; when determining that destination information included in the first frame specifies the printer (10), extract and interpret print information included in the first frame; and when determining that the destination information included in the first frame does not specify the printer (10), forward the first frame to the network (30).
A machine tool capable of reducing entry of a workpiece chip into a product discharge chute. A controller controls a receipt of a product made of a workpiece held by a first spindle by a product receiver in a product receiving position, movement of the product receiver to a product dropping position and rotation of the product receiver to drop the product to the product discharge chute through an opening of the product discharge chute, and movement of the product receiver to the product receiving position to receive the product again. A second spindle is kept on standby in the product dropping position during which the opening of the product discharge chute is closed by the product receiver.
B23Q 1/70 - Stationary or movable members for carrying working-spindles for attachment of tools or work
B23Q 1/30 - Movable or adjustable work or tool supports characterised by constructional features relating to the co-operation of relatively movable membersMeans for preventing relative movement of such members controlled in conjunction with the feed mechanism
B23Q 7/08 - Arrangements for handling work specially combined with or arranged in, or specially adapted for use in connection with, machine tools, e.g. for conveying, loading, positioning, discharging, sorting by means of slides or chutes
B23Q 15/22 - Control or regulation of position of tool or workpiece
Provided is a machine tool that can further suppress quadrant protrusion. A plurality of drive units U1 include a first drive unit U11 that moves a driven object (20) along a first feed axis F1 and a second drive unit U12 that moves the driven object (20) along a second feed axis F2 that intersects the first feed axis F1. A control unit U2 controls the moving of the driven object (20) by the plurality of drive units U1 and, in order to suppress quadrant protrusion 200 due to reversal of the drive directions of the drive units U1, performs correction by applying a set acceleration amount ΔVi to the drive units U1 over a set acceleration time Ti. The control unit U2, using a value representing torque applied by the drive units U1 to the driven object (20) as a drive torque value TR2i, adjusts the set acceleration amount ΔVi and/or the set acceleration time Ti on the basis of the drive torque value TR2i which has, as a baseline, a baseline torque value TR1i that represents a baseline torque.
G05B 19/404 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by control arrangements for compensation, e.g. for backlash, overshoot, tool offset, tool wear, temperature, machine construction errors, load, inertia
G05B 19/4155 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by programme execution, i.e. part programme or machine function execution, e.g. selection of a programme
B23Q 15/00 - Automatic control or regulation of feed movement, cutting velocity or position of tool or work
42 - Scientific, technological and industrial services, research and design
Goods & Services
(1) Providing computer programs in data networks, namely, providing temporary use of on-line nondownloadable computer program software for electronic point-of-sale systems that generate and issue electronic receipts; providing computer programs in data networks, namely, providing temporary use of on line nondownloadable computer program software for monitoring and controlling the status of printers, machine tools, and computer peripheral equipment connected to cloud computing networks; providing computer programs in data networks, namely, providing temporary use of on-line nondownloadable computer program software for electronic point-of-sale systems that issue and manage coupons through cloud computing networks; providing computer programs in data networks, namely, providing temporary use of on-line nondownloadable computer program software for sending printing data to printers connected to cloud computing networks; providing computer programs in data network, namely, providing temporary use of on-line nondownloadable computer program software for managing and controlling the distribution of data to mobile computer terminals and computer peripheral equipment connected to cloud computing networks; providing temporary use of on-line non-downloadable software for use in remote monitoring of computer systems by remote access to ensure proper functioning, specifically, monitoring of computer systems comprising computer printers, metal working machine tools, and computer peripheral equipment connected to cloud computing networks.
42 - Scientific, technological and industrial services, research and design
Goods & Services
Providing computer programs in data networks, namely, providing temporary use of on-line nondownloadable computer program software for electronic point-of-sale systems that generate and issue electronic receipts; providing computer programs in data networks, namely, providing temporary use of on-line nondownloadable computer program software for monitoring and controlling the status of printers, machine tools, and computer peripheral equipment connected to cloud computing networks; providing computer programs in data networks, namely, providing temporary use of on-line nondownloadable computer program software for electronic point-of-sale systems that issue and manage coupons through cloud computing networks; providing computer programs in data networks, namely, providing temporary use of on-line nondownloadable computer program software for sending printing data to printers connected to cloud computing networks; providing computer programs in data network, namely, providing temporary use of on-line nondownloadable computer program software for managing and controlling the distribution of data to mobile computer terminals and computer peripheral equipment connected to cloud computing networks; monitoring of computer systems by remote access to ensure proper functioning, specifically, monitoring of computer systems comprising printers, machine tools, and computer peripheral equipment connected to cloud computing networks
09 - Scientific and electric apparatus and instruments
Goods & Services
Computer printers, namely, computer printers for printing
documents; computer printers for use in point-of-sales (POS)
systems, namely, document printers for use in point-of sales
(POS) systems; computer printers for use in online ordering
systems, namely, document printers for use in online
ordering systems.
A machine tool capable of restraining dirt on the footstool and improving setup efficiency. The machine tool includes a machine body having a splash guard surrounding a machining area and a door capable of closing an opening of the splash guard. A footstool is kept mounted on the machine body changeably in place with respect to the machine body. The footstool kept mounted on the machine body is capable of being in a place on an outside of the machine body when the door is closed. The footstool kept mounted on the machine body is capable of being brought to a setup place inside the machining area from the outside of the machine body through the opening when the door is open.
B23Q 11/08 - Protective coverings for parts of machine toolsSplash guards
B23B 3/06 - Turning-machines or devices characterised only by the special arrangement of constructional units
B23B 25/04 - Safety guards specially designed for turning-machines
B23Q 11/00 - Accessories fitted to machine tools for keeping tools or parts of the machine in good working condition or for cooling workSafety devices specially combined with or arranged in, or specially adapted for use in connection with, machine tools
09 - Scientific and electric apparatus and instruments
Goods & Services
(1) Computer printers, namely, computer printers for printing documents; computer printers for use in point-of-sales (POS) systems, namely, document printers for use in point-of sales (POS) systems; computer printers for use in online ordering systems, namely, document printers for use in online ordering systems.
09 - Scientific and electric apparatus and instruments
Goods & Services
Computer printers, namely, computer printers for printing documents; computer printers for use in point-of-sales (POS) systems, namely, document printers for use in point-of sales (POS) systems; computer printers for use in online ordering systems, namely, document printers for use in online ordering systems
Provided is a lathe making it easy to adjust the protruding length of a tool without needing to run a simulation. This lathe is provided with: a main shaft stand on which a main shaft for gripping a workpiece is provided; an edged tool stand part on which it is possible to attach a tool for processing the workpiece gripped by the main shaft; a drive unit for causing a drive subject, which is at least one of the main shaft stand and the edged tool stand part, to move in a drive axial direction whereby the distance from the workpiece to the tool changes; a storage unit storing no-entry region information representative of a no-entry region for the drive subject; and a distance display unit. The distance display unit calculates and displays a distance (Lot) at which the drive subject will reach the no-entry region in the drive axial direction, on the basis of the current location (machine coordinates) of the drive subject in the drive axial direction, and the no-entry region information.
A lathe capable of shortening a spindle with respect to a spindle axis direction. A spindle provided with a chuck at the front end thereof is rotatably supported on a support by bearings. A chuck operating apparatus includes a tilt claw and a shifter. A built-in motor is disposed between the bearings to rotate the spindle. The claw is provided outside the spindle and between the bearings. The claw has a movable end whose distance from the spindle axis varies between a first posture to bring the chuck into the opened state and a second posture to bring the chuck into the closed state. The shifter is provided outside the claw and movable in the spindle axis direction to be brought in a first position to bring the claw into the first posture and in a second position to bring the claw into the second posture.
A chuck operating apparatus includes a claw, a shifter, and a shifter drive unit. The rotatable claw has a first posture to bring the chuck into the opened state and a second posture to bring the chuck into the closed state. The rotatable shifter is brought in a first position to bring the claw into the first posture and in a second position to bring the claw into the second posture. The shifter drive unit has a shifter lever having an insertion part provided with a shifter bearing capable of being brought into contact with a side surface of an outward groove of the shifter. A roller is provided on one of the claw and the shifter in a contact position with the other to roll in a spindle axis direction and a groove is formed on the other to receive the roller when the chuck is in the opened state.
B23B 31/16 - Chucks with simultaneously-acting jaws, whether or not also individually adjustable moving radially
B23B 25/00 - Accessories or auxiliary equipment for turning-machines
B23B 31/20 - Longitudinally-split sleeves, e.g. collet chucks
B23B 31/26 - Chucks characterised by features relating primarily to remote control of the gripping means using mechanical transmission through the working-spindle
A lathe capable of facilitating maintenance of a chucking mechanism. A chuck operating apparatus includes a claw and a shifter to open and close a chuck provided on a spindle. The tilt claw provided outside the spindle has a first posture to bring the chuck into the opened state and a second posture to bring the chuck into the closed state. The shifter provided outside the spindle and movable in a spindle axis direction is brought in a first position to bring the claw into the first posture and in a second position to bring the claw into the second posture. A roller is mounted on the shifter in a contact position with the claw to roll in the spindle axis direction.
B23B 31/20 - Longitudinally-split sleeves, e.g. collet chucks
B23B 13/02 - Arrangements for automatically conveying, chucking or guiding stock for turning machines for turning-machines with a single working-spindle
B23B 3/16 - Turret lathes for turning individually-chucked workpieces
A machine tool improving measurement accuracy of a machined workpiece diameter. A machine tool comprises a displacement sensor mounted on at least one of a guide bush and a spindle supporting unit. The machine tool further comprises a calculating unit which calculates a diameter of the machined workpiece based on a measurement value of the machined workpiece by the displacement sensor. The spindle is movable back and forth in an axial direction. The spindle is retracted after machining to bring a machined portion of the workpiece to a predetermined measurement position in the axial direction to allow the displacement sensor to measure the machined portion.
B23B 25/06 - Measuring, gauging, or adjusting equipment on turning-machines for setting-on, feeding, controlling, or monitoring the cutting tools or work
B23Q 17/20 - Arrangements for indicating or measuring on machine tools for indicating or measuring workpiece characteristics, e.g. contour, dimension, hardness
There has been a need for effective measures against heat generated by a motor. This machine tool includes: a screw shaft; a motor that rotates the screw shaft; a ball screw nut that engages the screw shaft and moves along the screw shaft in accordance with the rotation of the screw shaft; a moving table that moves together with the ball screw nut; and an oil-air supply unit that supplies, to the ball screw nut, oil-air obtained by mixing a lubricant oil and air. The ball screw nut is attached to the moving table at a position more toward the motor side than the center of the moving table in the longitudinal direction of the screw shaft.
B23Q 11/12 - Arrangements for cooling or lubricating parts of the machine
B23B 1/00 - Methods for turning or working essentially requiring the use of turning-machinesUse of auxiliary equipment in connection with such methods
B23B 19/02 - Working-spindlesFeatures relating thereto, e.g. supporting arrangements
B23Q 5/40 - Feeding other members supporting tools or work, e.g. saddles, tool-slides, through mechanical transmission feeding continuously by feed shaft, e.g. lead screw
B23Q 5/50 - Feeding other members supporting tools or work, e.g. saddles, tool-slides, through mechanical transmission feeding step by step
