Abstract

In a motor current optimization control method and system, while the motor runs steadily at a set speed, one d-axis current command value of the input current is set to 0. Then, the d-axis current command value is step-wisely increased by an increment at least twice. At least three real-time feedback current values can be collected from detecting a feedback current of an AC power. When an instant detected is smaller than the previous detected, the d-axis current command value is increased. When the instant detected is greater than the previous detected, the d-axis current command value corresponding to the previous detected is a minimum feedback current value and is defined as the optimized d-axis current command value. The optimized d-axis current command value is set as the d-axis current command value of the input current to control the motor to keep running steadily at the set speed.

IPC Classes  ?

• H02P 21/00 - Arrangements or methods for the control of electric machines by vector control, e.g. by control of field orientation
• H02P 21/22 - Current control, e.g. using a current control loop

Abstract

A cooling motor includes a motor device having a motor casing, a motor assembly arranged in the motor casing, and a centrifugal fan, and a cooling device having first and second cooling components. The first cooling component includes a first cold plate jacket and a first heat circulation pipeline. The first cold plate jacket is sleeved on the motor assembly and thermally connected to a stator, and the first cold plate jacket includes first cold plates. The first thermal circulation pipeline filled with a first working fluid passes through the first cold plate jacket. The second cooling component includes a second cold plate jacket and a second heat circulation pipeline. The second cold plate jacket, sleeving the first cold plate jacket in an insulation manner, includes second cold plates and cooling fins. The second thermal circulation pipeline filled with a second working fluid passes through the second cold plate jacket.

IPC Classes  ?

• H02K 9/20 - Arrangements for cooling or ventilating for machines with closed casing and closed-circuit cooling using a liquid cooling medium, e.g. oil wherein the cooling medium vaporises within the machine casing
• H02K 5/20 - Casings or enclosures characterised by the shape, form or construction thereof with channels or ducts for flow of cooling medium
• H02K 9/22 - Arrangements for cooling or ventilating by solid heat conducting material embedded in, or arranged in contact with, the stator or rotor, e.g. heat bridges

Abstract

In a refrigerator storage temperature control method, according to a target temperature (Ts), a regulated temperature upper limit value (T1) and an allowable temperature upper limit value (T2) are defined. According to T1 and T2, an adjustment interval, an allowable temperature interval and a convergent cooling interval are defined. A detection temperature is periodically detected and updated with a detection period, the detection temperature in the previous detection period is a previous temperature, and the detection temperature in the instant detection period is a current temperature. A control module performs RPS-m for a compressor when the current temperature falls within the adjustment interval, RPS+0 when the current temperature falls within the allowable temperature interval, and RPS+o when the current and previous temperatures fall within the convergent cooling interval and the allowable temperature interval, respectively. Detection, judgment and control are repeated until the current temperature falls within the allowable temperature interval.

IPC Classes  ?

• F25D 29/00 - Arrangement or mounting of control or safety devices
• G05B 15/02 - Systems controlled by a computer electric

Abstract

A horizontal assembly method for permanent magnet motor is mainly to firstly dispose the first bracket and the second bracket on the motor assembly platform, then fix the stator assembly on the sliding carrier so as to move with the sliding carrier to sleeve over the fixed thimble to engage the first bracket, then position the rotor assembly between the fixed thimble and the movable thimble so as to fix the rotor assembly by the protruding movable thimble, then control the sliding carrier to assemble the stator assembly and the first bracket to the rotor assembly so that the one end of the rotational shaft can be supported by the first bracket, and finally assemble the second bracket to the stator assembly so as to support another end of the rotational shaft. Thereupon, the permanent magnet motor can be produced.

IPC Classes  ?

• H02K 15/00 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines

Abstract

A rotor structure includes a rotor body and a plurality of magnets. The rotor body has a plurality of surrounding magnet-setting areas, and each magnet setting area has a first magnet slot and a second magnet slot symmetrically arranged to a centripetal axis. A first outer end of the first magnet slot and a second outer end of the second magnet slot are close to the centripetal axis and rotor's outer edge. A first outer end of the first magnet slot and a second outer end of the second magnet slot are distant to the centripetal axis and rotor's outer edge. The outer edge has a plurality of notches intersected by the corresponding centripetal axes. The magnets are respectively fixed to the first magnet slots and the second magnet slots of the magnet-setting areas.

IPC Classes  ?

• H02K 1/27 - Rotor cores with permanent magnets
• H02K 1/278 - Surface mounted magnetsInset magnets

Abstract

An apparatus for assembling a permanent magnet motor rotor includes a first-end positioning assembly, a plurality of connectors, and a second-end positioning assembly. The first-end positioning assembly is utilized to fix a first-end rotor core. The second-end positioning assembly is utilized to fix a second-end rotor core. The connectors are utilized to connect and fix the first-end positioning assembly with the second-end positioning assembly. Each first longitudinal axis of each first positioning element of the first end positioning assembly is different from each second longitudinal axis of each second positioning element of the second end positioning assembly. In addition, a method for assembling a permanent magnet motor rotor is also provided.

IPC Classes  ?

• H02K 15/02 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines of stator or rotor bodies
• H02K 15/03 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines of stator or rotor bodies having permanent magnets
• H02K 1/27 - Rotor cores with permanent magnets

Abstract

An automated guided vehicle control system includes a commodity database, a historical shopping information acquisition module, a purchase-item prediction module, an automated guided vehicle database, an automated guided vehicle dispatch demand assessment module and an automated guided vehicle dispatch module. The historical shopping information acquisition module is utilized to retrieve the historical shopping information related to the customer, further to locate the instant predicted commodity to be purchased, and thereby to dispatch the suitable automated guided vehicle to the waiting area of the customer. Further, the historical shopping information is evaluated to provide the commodity type options for the customer to select, to locate the commodity type to be purchased, and thereby to organize the automated navigation path for the automated guided vehicle to travel along to reach the assigned commodity display area.

IPC Classes  ?

• B60W 10/00 - Conjoint control of vehicle sub-units of different type or different function
• B60W 50/00 - Details of control systems for road vehicle drive control not related to the control of a particular sub-unit
• B60W 60/00 - Drive control systems specially adapted for autonomous road vehicles
• G01C 21/20 - Instruments for performing navigational calculations
• G06Q 10/0631 - Resource planning, allocation, distributing or scheduling for enterprises or organisations
• G06Q 10/087 - Inventory or stock management, e.g. order filling, procurement or balancing against orders
• G06Q 20/20 - Point-of-sale [POS] network systems
• G06Q 30/0202 - Market predictions or forecasting for commercial activities
• G06Q 30/0601 - Electronic shopping [e-shopping]
• G07C 9/00 - Individual registration on entry or exit

Abstract

A method includes: forming a sand core including a main portion and core-head members connecting the main portion; applying a casting process to produce a frame casting having a first end, a first-end inner wall, a second end, a second-end inner wall, a closed water channel between the first-end inner wall and the second-end inner wall, a water inlet, a water outlet and sand-expelling holes at the first end; shaking the frame casting to have part of the sand core to leave the closed water channel via the water inlet, the water outlet and the sand-expelling holes; pressurizing a fluid into the closed water channel via the water inlet to carry the rest of the sand core to leave the closed water channel via the sand-expelling holes and the water outlet; and applying screw bolts to lock the sand-expelling holes to manufacture a closed-type liquid-cooling motor frame.

IPC Classes  ?

• H02K 15/00 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines
• H02K 15/14 - CasingsEnclosuresSupports
• H02K 15/02 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines of stator or rotor bodies
• B22D 19/00 - Casting in, on, or around, objects which form part of the product
• H02K 9/19 - Arrangements for cooling or ventilating for machines with closed casing and closed-circuit cooling using a liquid cooling medium, e.g. oil

Abstract

A mobile device includes a mobile platform, a spray generating assembly, an ultraviolet light-emitting module, a scanning module and a controlling module. The spray generating assembly is to generate a disinfecting and sterilizing spray for a spraying, disinfecting and sterilizing operation in the working area. The ultraviolet light-emitting module is configured to generate ultraviolet beams for performing a radiating, disinfecting and sterilizing operation onto a ground surface of the working area. The scanning module defined with an entire scan range is configured to generate a warning signal upon a human in the entire scan range. The controlling module, electrically connected with the scanning module and the spray generating assembly, is configured to control the spray generating assembly to stop generating the disinfecting and sterilizing sprays upon receiving the warning signal, so as to prevent the human from inhaling excessive sprays.

IPC Classes  ?

• A61L 2/24 - Apparatus using programmed or automatic operation
• A61L 2/10 - Ultraviolet radiation
• A61L 2/22 - Phase substances, e.g. smokes, aerosols
• G05D 1/00 - Control of position, course, altitude or attitude of land, water, air or space vehicles, e.g. using automatic pilots
• G05D 1/10 - Simultaneous control of position or course in three dimensions

Abstract

A heat-dissipation frame assembly includes a motor frame, an air-guide shield and an airflow-driving device. The motor frame includes a main frame and annular heat-dissipation fins. Each of the annular heat-dissipation fins has an outer edge, and an average radial distance is defined between the outer edge and the central axis. The average radial distances of the annular heat-dissipation fins are decreased gradually in the longitudinal direction from the first end portion to the second end portion, and an external annular channel is formed between any neighboring two annular heat-dissipation fins. The airflow-driving device, disposed at the second end portion of the main frame, is used for generating at least one heat-dissipating airflow. The air-guide shield, connected with the motor frame, surrounds and covers the plurality of annular heat-dissipation fins, such that the at least one heat-dissipating airflow is guided into the plurality of external annular channels.

IPC Classes  ?

• H02K 5/18 - Casings or enclosures characterised by the shape, form or construction thereof with ribs or fins for improving heat transfer
• H02K 9/04 - Arrangements for cooling or ventilating by ambient air flowing through the machine having means for generating a flow of cooling medium
• H02K 5/20 - Casings or enclosures characterised by the shape, form or construction thereof with channels or ducts for flow of cooling medium

Abstract

A rotor assembly includes a rotor body having two rotor ends, a rotating shaft penetrating the two rotor ends, and two rotor end plates. The two rotor end plates are pressed to fit correspondingly the two rotor ends, and each rotor end plate includes an inner ring structure and an outer ring structure. The inner ring structure, made of an iron-based material and used to sleeve the rotating shaft, has a first outer-ring peripheral surface and a first thickness. The outer ring structure, made of an aluminum-based material, includes a first radial segment and a second radial segment. The first radial segment, wrapping the first outer-ring peripheral surface, has a second outer-ring peripheral surface and a second thickness larger than the first thickness. The second radial segment, wrapping integrally the second outer-ring peripheral surface as a unique piece, has a third thickness larger than the second thickness.

IPC Classes  ?

• H02K 1/27 - Rotor cores with permanent magnets
• H02K 5/16 - Means for supporting bearings, e.g. insulating supports or means for fitting bearings in the bearing-shields
• H02K 5/15 - Mounting arrangements for bearing-shields or end plates

Abstract

A defogging control system includes a plurality of first heating wires, a plurality of second heating wires, an electrical sensor and driver, a timer, an environment sensing module, and a control module. The electrical sensor and driver is utilized to generate a start signal or a stop signal, corresponding to a controller of a refrigeration storage apparatus. The timer is utilized to count a real-time operation time and record a previous operation time. The environment sensing module is utilized to sense a temperature and a humidity. The control module is utilized to control the first heating wires and the second heating wires by the real-time operation time, the previous operation time, the temperature, and the humidity. Further, a defogging control method is also provided.

IPC Classes  ?

• F25B 49/02 - Arrangement or mounting of control or safety devices for compression type machines, plants or systems
• F25D 23/02 - DoorsCovers
• F25D 21/00 - DefrostingPreventing frostingRemoving condensed or defrost water
• F25D 21/04 - Preventing the formation of frost or condensate
• F25D 21/08 - Removing frost by electric heating
• F25B 47/02 - Defrosting cycles
• A47F 3/04 - Showcases or show cabinets air-conditioned, refrigerated

Abstract

An auxiliary positioning system includes a mobile platform and a plurality of reflective stickers. The reflective stickers are disposed in a navigation space. The mobile platform includes a map-establishing module, a positioning module, a laser scan and analysis module, a coordinate-processing module, a comparison module and a calibration module. The map-establishing module is utilized to generate a global map. The positioning module is utilized to locate a position coordinate. The laser scan and analysis module is utilized to scan the navigating space to generate a scan direction and distance vector. The coordinate-processing module is utilized to generate a position direction and distance vector. The comparison module is utilized to compare the scanning coordinate with the mapping coordinate. The calibration module is utilized to calibrate the position coordinate.

IPC Classes  ?

• G01S 17/00 - Systems using the reflection or reradiation of electromagnetic waves other than radio waves, e.g. lidar systems
• G01S 17/74 - Systems using reradiation of electromagnetic waves other than radio waves, e.g. IFF, i.e. identification of friend or foe
• G01S 7/48 - Details of systems according to groups , , of systems according to group

Abstract

An apparatus for assembling a permanent magnet motor rotor includes a first-end positioning assembly, a plurality of connectors, and a second-end positioning assembly. The first-end positioning assembly is utilized to fix a first-end rotor core. The second-end positioning assembly is utilized to fix a second-end rotor core. The connectors are utilized to connect and fix the first-end positioning assembly with the second-end positioning assembly. Each first longitudinal axis of each first positioning element of the first end positioning assembly is different from each second longitudinal axis of each second positioning element of the second end positioning assembly. In addition, a method for assembling a permanent magnet motor rotor is also provided.

IPC Classes  ?

• H02K 15/00 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines
• H02K 15/03 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines of stator or rotor bodies having permanent magnets
• H02K 1/27 - Rotor cores with permanent magnets

Abstract

A system is applied for calibrating a map data configured for a mobile platform to generate a calibration map after an impact, and includes a map-generating module, a positioning module, an impact-detecting module, an image-analyzing module, a coordinate-reconstructing module and a map data-calibrating module. The map-generating module generates a global map with a first coordinate system. The positioning module positions a mobile platform before the impact. The impact detecting module generates a reconstructing signal after the impact upon the mobile platform is detected. The image-analyzing module searches and analyzes an image of a feature object. The coordinate-reconstructing module re-establishes a second coordinate system, and the map data-calibrating module calibrates the global map to generate the calibration map after the impact.

IPC Classes  ?

• G06T 7/70 - Determining position or orientation of objects or cameras
• G01C 21/00 - NavigationNavigational instruments not provided for in groups
• G05D 1/02 - Control of position or course in two dimensions
• G05D 1/00 - Control of position, course, altitude or attitude of land, water, air or space vehicles, e.g. using automatic pilots

Abstract

A rotor with a pressure-deviation generating assembly includes a main body having a plurality of tunnels extending longitudinally, a first pressure-deviation generating assembly, and a second pressure-deviation generating assembly. The first pressure-deviation generating assembly generates a plurality of first high-pressure regions and first low-pressure regions. The second pressure-deviation generating assembly generates a plurality of second high-pressure regions and second low-pressure regions. At least one first flow flows through some of the tunnels from the first high-pressure regions to the second low-pressure regions, and at least one second flow flows through the rest of the tunnels from the second high-pressure regions to the first low-pressure regions. Thereupon, a bi-directional air flow pattern inside the tunnels can be built to promote the heat dissipation of the rotor.

IPC Classes  ?

• H02K 1/32 - Rotating parts of the magnetic circuit with channels or ducts for flow of cooling medium
• H02K 9/22 - Arrangements for cooling or ventilating by solid heat conducting material embedded in, or arranged in contact with, the stator or rotor, e.g. heat bridges

Abstract

A method and a device are used to generate a control command. A resolution base value and a resolution-tick corresponding function are created. A first operation frequency value, a minimal tick value and a resolution value are received to calculate a resolution ratio and a second operation frequency. A conversional tick value is calculated. If or not the conversional tick value is greater than or equal to the minimal tick value is determined. If the conversion tick value is smaller than the minimal tick value, the minimal tick value, the conversional tick value and the second operation frequency are used to calculate a conversional operation frequency. A conversional resolution ratio is calculated according to the first operation frequency and the conversional operation frequency, and also a modified tick value is calculated. The control command is output according to the modified tick value, the first operation frequency and the conversion operation frequency.

IPC Classes  ?

• G05B 11/01 - Automatic controllers electric
• G05B 19/29 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by positioning or contouring control systems, e.g. to control position from one programmed point to another or to control movement along a programmed continuous path using an absolute digital measuring device for point-to-point control
• G05B 19/33 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by positioning or contouring control systems, e.g. to control position from one programmed point to another or to control movement along a programmed continuous path using an analogue measuring device

Abstract

A control command resolution adjustment method and a command generation device are disclosed in present invention. The control command resolution adjustment method is used to adjust a control command form the command generation device. A calculation frequency value via the command generation device is analyzed. The control command is received and a transform frequency value via the control command is analyzed. A first resolution value is calculated from the calculation frequency value and the transform frequency value. The first resolution value is distinguished greater than or equal to a minimum resolution value. When the first resolution value less than the minimum resolution value, an added calculation frequency value is calculated from the calculation frequency value and a frequency added value. A second resolution value is calculated from the added calculation frequency value and the transform frequency value. When the second resolution value greater than or equal to the minimum resolution value, the control command via the second resolution value is outputted.

IPC Classes  ?

• G05B 13/02 - Adaptive control systems, i.e. systems automatically adjusting themselves to have a performance which is optimum according to some preassigned criterion electric

Abstract

A patrol-type preventive inspection system is provided for an inspection personnel to perform a patrol-type inspections upon a plurality of electromechanical devices located along a patrol path. In the patrol-type preventive inspection system, a portable inspection-device kit and a portable communication device are carried by the inspection personnel to a to-be-inspected position of a to-be-inspected electromechanical device out of the electromechanical devices along the patrol path, so as to perform a patrol-type inspection upon the to-be-inspected electromechanical device for obtaining at least one inspection data. When the inspection data complies with at least one preventive inspection standard, the portable communication device is provided for the inspection user to perform an interactive operation to generate a real rapid-screening result, further to generate a preliminary treatment suggestion, and to re-plan the patrol path.

IPC Classes  ?

• G05B 23/00 - Testing or monitoring of control systems or parts thereof
• G05B 23/02 - Electric testing or monitoring
• G07C 1/20 - Checking timed patrols, e.g. of watchman
• G06Q 10/00 - AdministrationManagement

Goods & Services

(1) Electric motors for machines; motors used in industrial applications; electric starter motors, other than for land vehicles; motors for boats; pumps are parts of machines, engines and motors; rotary pumps; starters for motors and engines; variable frequency drives for motors and engines; medium voltage motors; low voltage motors; gear motors; variable frequency drives for motors, other than for land vehicles; washing machines; magnetic starters for motors and engines; direct online starters for motors and engines (2) Magnetic contactors, electric; circuit breakers; relays, electric; electronic overload relays; thermal overload relays; DC/AC inverters; inverters for power supply; electronic controllers used to reduce power consumption; electric control panels; programmable logical controllers, namely an industrial digital computer designed for the control of manufacturing processes for industrial automation; power amplifiers; signal amplifiers; electronic signal conditioning modules for use in the field of Industrial machines; electric timers; electric power converters; power distribution and power control switchboards; power adapters for computers; electronic servo motor controllers; touch screens; touch computer monitors

Abstract

A system includes a control module, a velocity-detecting module and a state-analyzing module. The control module generates a control command to control the servo drive system, and bases on the control command to define angular-acceleration standard ranges with respect to detection times. The velocity-detecting module detects output angular-velocity values of the servo motor with respect to detection times upon when the servo motor is driven. The state-analyzing module includes a processing unit and an abnormal-state judging unit. The processing unit stores the output angular-velocity values, and bases on the output angular-velocity values to calculate output angular-acceleration values with respect to the detection times. The abnormal-state judging unit determines whether or not each of the output angular-acceleration values with respect to each of the corresponding detection times is within the respective angular-acceleration standard range and thereby to generate corresponding comparison results.

IPC Classes  ?

• H02P 29/10 - Arrangements for regulating or controlling electric motors, appropriate for both AC and DC motors for preventing overspeed or under speed
• G05B 23/02 - Electric testing or monitoring

Abstract

A motor with self power generation includes a motor body, at least one magnetic element, a shield case, an induction element, a transfer circuit board and a working module. The motor body includes a shaft member. The at least one magnetic element, located at the shaft member, is to generate a dynamic electromagnetic induction space while the shaft member rotates. The shield case, located close to the shaft member, is to shield the shaft member. The induction element, fixed at the shield case, has a portion located inside the dynamic electromagnetic induction space to generate an induction power while the shaft member rotates. The transfer circuit board has a transfer circuit electrically coupled with the induction element to receive the induction power to further generate a working power. The working module, electrically coupled with the transfer circuit, is to receive the working power to execute a default work.

IPC Classes  ?

• H02K 53/00 - Alleged dynamo-electric perpetua mobilia
• H02K 47/20 - Motor/generators
• H02K 11/00 - Structural association of dynamo-electric machines with electric components or with devices for shielding, monitoring or protection
• H02K 9/06 - Arrangements for cooling or ventilating by ambient air flowing through the machine having means for generating a flow of cooling medium with fans or impellers driven by the machine shaft
• H02K 7/18 - Structural association of electric generators with mechanical driving motors, e.g.with turbines

Abstract

A rotor structure of synchronous reluctance motor which includes at least one rotor sheet is provided in the present invention. The rotor sheet has a center hole and includes a plurality of reluctance units surrounded the center hole. The reluctance units have an inner through-hole pair and an outer through-hole pair. In an inner through hole of the inner through-hole pair and an outer through hole of the outer through-hole pair, an inner tangent extension and an outer tangent extension are extended along a tangent extension direction. Two oblique extensions are extended from the inner tangent extension and the outer tangent extension along a turning direction which is oblique to the tangent extension direction respectively. An oblique included angle of the outer through hole is smaller than an oblique included angle of the inner through hole.

IPC Classes  ?

• H02K 1/22 - Rotating parts of the magnetic circuit
• H02K 1/24 - Rotor cores with salient poles
• H02K 19/02 - Synchronous motors

Abstract

A method includes steps of: preparing first and second plates, each first plate having surrounding apertures, each aperture including a first accommodation portion and an outer necking portion, each second plate having surrounding accommodation portions; stacking the first plates by aligning necking portions to form band gaps extending linearly and parallel to each other; stacking two second plates to two opposing terminal portions of the stacked first plates; penetrating metal bars into the aligned first and second accommodation portions by exposing both ends of each metal bar; beetling the necking portions at each band gap so as to locate firmly the corresponding metal bar; positioning a first mold and a second mold to clamp the stacked plate structure; injecting metal slurries into the first and second molds and then solidifying the metal slurries to form two end rings; and, removing the first and second molds to complete a rotor structure.

IPC Classes  ?

• H02K 15/02 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines of stator or rotor bodies
• H02K 15/12 - Impregnating, moulding insulation, heating or drying of windings, stators, rotors or machines
• B23P 15/00 - Making specific metal objects by operations not covered by a single other subclass or a group in this subclass
• H02K 15/00 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines
• B23P 11/00 - Connecting or disconnecting metal parts or objects by metal-working techniques, not otherwise provided for

Abstract

A system for managing real-time work information of a motor fitting provides a sensor set at the motor fitting to transmit the real-time work information to a processing module. A processing unit of the processing module sends type information and a real-time work parameter according to the real-time work information. When a detection unit determines the real-time work parameter is fallen outside a normal work parameter according to a lookup table stored in a database and the type information, the detection unit generates an abnormal-notification signal for transmission. When an application procedure of the application-processing unit is triggered, the application-processing unit activates a play unit to play the normal work parameter, and further the activated play unit plays notification information upon receiving the abnormal-notification signal.

IPC Classes  ?

• G06F 19/00 - Digital computing or data processing equipment or methods, specially adapted for specific applications (specially adapted for specific functions G06F 17/00;data processing systems or methods specially adapted for administrative, commercial, financial, managerial, supervisory or forecasting purposes G06Q;healthcare informatics G16H)
• G06F 19/26 - for data visualisation, e.g. graphics generation, display of maps or networks or other visual representations
• G05B 19/406 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by monitoring or safety
• G05B 19/19 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by positioning or contouring control systems, e.g. to control position from one programmed point to another or to control movement along a programmed continuous path
• H02P 29/04 - Arrangements for regulating or controlling electric motors, appropriate for both AC and DC motors by means of a separate brake
• H02P 6/08 - Arrangements for controlling the speed or torque of a single motor
• H02P 6/182 - Circuit arrangements for detecting position without separate position detecting elements using back-emf in windings

Abstract

A side winding motor stator includes a plurality of stator structures, a plurality of winding structures and a plurality of winding rolls. The stator structures are assembled to form a stator module. Each of the stator structures includes a stator tooth and an insulated frame. The stator tooth is configured into the insulated frame. The insulated frame has a gap. The winding structures, each of which has a plurality of lateral slots, are engaged through the gap. The winding rolls are engaged in the lateral slots.

IPC Classes  ?

• H02K 3/28 - Layout of windings or of connections between windings
• H02K 3/18 - Windings for salient poles
• H02K 3/52 - Fastening salient pole windings or connections thereto

Goods & Services

Motors, generators, pumps, compressors, wind-powered generators, solar-powered generators, washing machines, vacuum cleaners, starters for motors, servo-drives, magnetic motor starters, direct on-line starters and direct on-line magnetic motor starters, engines and motors for the generation of electricity. Motor drives, magnetic switches, magnetic contactor, circuit breakers, inverters [electricity], programmable controller, human machine interface, transformers, electronic and overload relays, electrical switch timers, switchgear [electric], voltage regulators. Air conditioners, dehumidifiers, ventilators, household air cleaners, air-circulators, water coolers, electric toasters, microwave ovens [cooking apparatus], electromagnetic ovens, electric coffee pots, refrigerators.

Goods & Services

Engines and motors for the generation of electricity; Windmills for generating electricity; Wind-powered generators; solar-powered generators; water-powered generators; Wind turbines; blades of wind power generator; mill towers and masts. Photovoltaic cells and modules; solar panels for production of electricity; Photovoltaic inverters; Solar cells; electrical power converters; wind- solar hybrid modules; power distribution and power control switchboards.

Goods & Services

Generator for land vehicles;  fuel filters for vehicles. Fuel economizers. Motors for land vehicles; electric motors for land vehicles; driver for land vehicles; engine for land vehicles;  brake hardware for vehicles;  electric starting components of the engine for vehicles use; coupling of automobiles; torque converters for land vehicles; electric vehicles; electric bicycles; motor cars; motorcycles; gasoline, diesel, hybrid vehicles; transmissions for land vehicles; power transmissions for land vehicles; energy accumulating and discharging motors for vehicles (for charging or discharging energy); all the aforesaid goods included in class 12.

Goods & Services

[ Automobiles and structural parts thereof, ] [ electric cars, electric bicycles, ] [ motor cars for transport on land, motorcycles, ] motors and engines for land vehicles, electric motors for land vehicles, electric drive transmissions for land vehicles, transmissions for automobiles, power transmissions for land vehicles [ and replacement parts thereof, ] energy accumulating and discharging motors for land vehicles [, brake hardware for vehicles, coupling of automobiles, torque converters for land vehicles ]

Goods & Services

Motor starters, magnetic motor starters and direct on-line magnetic motor starters Programmable logic controllers, inverters, magnetic contactors, electrical thermal overload relay, timers, electronic overload relay, indoor and outdoor circuit breakers

Abstract

An electronic type protective relay integrates the mechanical structure into a single operation rod to protect electric machinery. The electronic type protective relay includes an insulating shell, a tripping rod, a magnetic-force device and an operation device. The tripping rod is pivoted in the inner part of the insulating shell and conducts two pairs of connection pins. The tripping rod includes a control magnetic core. The magnetic-force device includes a tripping electromagnet, a reset electromagnet, and a permanent magnet installed between the tripping electromagnet and the reset electromagnet. The operation device includes an auxiliary rod located on one side of the tripping rod, an operation rod installed between the tripping rod and the auxiliary rod and protruding beyond the insulating shell. The operation rod can be located at four locations and in cooperation with the auxiliary rod to stop or reset.

IPC Classes  ?

• H01H 75/00 - Protective overload circuit-breaking switches in which excess current opens the contacts by automatic release of mechanical energy stored by previous operation of power reset mechanism

Goods & Services

Electric generators, pumps, namely compressed air pumps, electric pumps, water pumps for use in motors and engines; compressors, namely air compressors, compressors for air conditioners, compressors for machines; electric motors for machines, generators and pumps (except for land vehicles), engine generators, machines for washing dishes, washing machines, food processors, bread makers, machine couplings and beltings (except for land vehicles), large size agricultural implements, namely fertilizer spreaders; electric blenders for household purposes, vacuum cleaners, electric juicers Fax machines, television sets, television sets with plasma display screens, high-definition television sets, laser compact disk players, stereo sets, namely microphones, amplifiers, stereo speakers, stereo receivers; radios, video camera recorders, high fidelity loudspeakers, audio amplifiers, audio speakers, audio tape players/recorders, digital video disc players/recorders, computer terminals, blank floppy disks, hard disk drives, electric irons, steam irons, computer printers, computers and personal computers, wireless telephones, cell phones, earphones, cathode-ray tubes (CRT), scanners, digital cameras, liquid crystal displays, inverters, electric hair curlers, home theater audio systems, namely, radios and televisions; projection televisions Exhaust fans, clothes dryers, air conditioners, ventilators, air curtains, electric fans, electric rice cookers, dehumidifiers, ventilators, ventilation apparatus, namely air cleaners; microwave ovens for cooking, hair dryers, refrigerators, refrigeration apparatus, namely combination refrigerators and freezers; freezers, air cleaners, electric portable domestic heaters, air-circulators, cooling installations and machines, namely air conditioners; water filters, toasters, deep fryers, coffee makers, electromagnetic ovens, cooking apparatus and installations, namely electric ovens, barbecue grills; water heaters, electric roasters
