Abstract

Vegetation such as a weed (45) may be controlled by generating a foam comprising air and an aqueous solution comprising a surfactant; dispensing the foam so as to coat at least a base part of the weed that is to be controlled; and then injecting hot water into the foam (46) so as to contact the weed (45) below or within the coating of foam (46) The hot water causes the weed (45) to wilt and die, while the foam (46) suppresses heat loss from the hot water. The method may be carried out using a portable tool (10) which includes an air blower (14), a container (20) of a concentrate for the aqueous solution, a foam-generating tube (24) ending in an open-topped chute (26). The hot water may be provided through a flexible hose (22) from an external boiler (23), and after being used to produce the foam (46), the hot water be sprayed onto the top end of the chute (26).

IPC Classes  ?

• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity
• B05B 7/00 - Spraying apparatus for discharge of liquids or other fluent materials from two or more sources, e.g. of liquid and air, of powder and gas

Goods & Services

Garden weeding tool, namely, a garden weeding tool consisting of a hand operated sprayer with a nozzle for dispensing steam and foam used to spray weeds.

Abstract

A system (10) for providing a stream of water that includes a surfactant, comprising a source (14) of water, means (32) to cause water to flow along a water supply duct (34), and a venturi injector (36) within the water supply duct. The venturi injector (36) communicates with an inlet duct (77) to supply surfactant; and the system comprises a surfactant supply duct (80, 83) that communicates between the inlet duct (77) and a surfactant container (18), the surfactant supply duct comprising a first portion that incorporates an on/off valve (38) and a second portion (83) that incorporates a check valve (84) to control flow. A plurality of surfactant containers (18) may be connected to the inlet duct (77) in this way; and each surfactant container 18 may be mounted within an open-topped chamber (68) to which hot water may be provided to heat the contents of the surfactant container (18).

IPC Classes  ?

• B67D 3/00 - Apparatus or devices for controlling flow of liquids under gravity from storage containers for dispensing purposes
• A01M 7/00 - Special adaptations or arrangements of liquid-spraying apparatus for purposes covered by this subclass
• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity

Abstract

A system (10) for providing a stream of water that includes a surfactant, comprising a source (14) of water, means (32) to cause water to flow along a water supply duct (34), and a venturi injector (36) within the water supply duct. The venturi injector (36) communicates with an inlet duct (77) to supply surfactant; and the system comprises a surfactant supply duct (80, 83) that communicates between the inlet duct (77) and a surfactant container (18), the surfactant supply duct comprising a first portion that incorporates an on/off valve (38) and a second portion (83) that incorporates a check valve (84) to control flow. A plurality of surfactant containers (18) may be connected to the inlet duct (77) in this way; and each surfactant container 18 may be mounted within an open-topped chamber (68) to which hot water may be provided to heat the contents of the surfactant container (18).

IPC Classes  ?

• A01M 7/00 - Special adaptations or arrangements of liquid-spraying apparatus for purposes covered by this subclass
• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity

Abstract

A system (10) for providing a stream of water that includes a surfactant, comprising a source (14) of water, means (32) to cause water to flow along a water supply duct (34), and a venturi injector (36) within the water supply duct. The venturi injector (36) communicates with an inlet duct (77) to supply surfactant; and the system comprises a surfactant supply duct (80, 83) that communicates between the inlet duct (77) and a surfactant container (18), the surfactant supply duct comprising a first portion that incorporates an on/off valve (38) and a second portion (83) that incorporates a check valve (84) to control flow. A plurality of surfactant containers (18) may be connected to the inlet duct (77) in this way; and each surfactant container 18 may be mounted within an open-topped chamber (68) to which hot water may be provided to heat the contents of the surfactant container (18).

IPC Classes  ?

• A01M 7/00 - Special adaptations or arrangements of liquid-spraying apparatus for purposes covered by this subclass
• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity

Goods & Services

Chemicals for use in agriculture, gardening and road and estate management, for control of weeds, namely, foam-forming surfactants for use in killing weeds. Machines for use in agriculture, gardening and road and estate management, for control of weeds, namely, power operated sprayers that generate steam and foam used to spray weeds; and structural parts and fittings therefore. Garden weeding tools, namely, garden weeding tools consisting of a hand operated sprayer with a nozzle for dispensing steam and foam used to spray weeds. Maintenance and servicing of machines for use in agriculture, gardening and road and estate management; maintenance and servicing of machines for use in killing weeds.

Goods & Services

(1) Chemicals for use in agriculture, gardening and road and estate management, for control of weeds, namely, foamforming chemicals for use in killing weeds (2) Machines for use in agriculture, gardening and road and estate management, for control of weeds, namely, power operated sprayers that generate steam and foam used to spray weeds; and structural parts and fittings therefore (3) Garden weeding tools, namely, garden weeding tools consisting of a hand operated sprayer with a nozzle for dispensing steam and foam used to spray weeds (1) Maintenance and servicing of machines for use in agriculture, gardening and road and estate management for use in killing weeds, namely, power operated sprayers that generate steam and foam used to spray weeds; maintenance and servicing of machines for use in killing weeds

Goods & Services

Chemicals for use in agriculture, gardening, and facilities management; chemicals for use in street cleaning. Chemicals for use in killing weeds. Machines for use in agriculture, gardening, and facilities management; machines for use in killing weeds; street cleaning machines (hand-propelled); street cleaning machines (self-propelled); attachments, parts, fittings and accessories for the aforesaid goods. Garden weeding tools; steam-generating garden weeding tools; steam-generating street cleaning tools [hand tools]. Street cleaning vehicles.

Goods & Services

(1) Chemicals for use in agriculture, gardening, and facilities management, namely surfactants and detergents for industrial use; chemicals for use in street cleaning, namely surfactants and detergents for industrial use (2) Chemicals for use in killing weeds. (3) Machines for use in agriculture and gardening, namely weed killing machines; machines for use in facilities management, namely, floor cleaning machines, machines for use in killing weeds, hand-propelled street cleaning machines, self-propelled street cleaning machines, and street cleaning vehicles; attachments, parts, fittings and accessories, namely, high-pressure pumps, water boilers, and nozzles, for weed killing machines, machines for use in facilities management, namely, floor cleaning machines, machines for use in killing weeds, hand-propelled street cleaning machines, self-propelled street cleaning machines, and street cleaning vehicles. (4) Garden weeding tools; steam-generating garden weeding tools; steam-generating street cleaning tools [hand tools]. (1) Maintenance and servicing of machines for use in agriculture, gardening, and facilities management; maintenance and servicing of machines for use in killing weeds; maintenance and servicing of machines for use in street cleaning.

Goods & Services

Chemicals for use in agriculture, gardening, and facilities management, namely, surfactants and detergents for industrial use; chemicals for use in street cleaning, namely, surfactants and detergents for industrial use Chemicals for use in killing weeds Machines for use in agriculture and gardening, namely, a steam and foam generating weeding machine; machines for use in facilities management, namely, a steam and foam generating cleaning machine; hand-propelled street cleaning machines; self-propelled street cleaning machines; attachments, parts, and accessories for the aforesaid goods, namely, structural attachments, replacement parts, and accessories, namely, dispensing nozzles and liquid storage tanks Street cleaning land vehicles

Goods & Services

Chemicals for use in agriculture, gardening and road and estate management, for control of weeds, namely, foam-forming chemicals for use in killing weeds. Machines for use in agriculture, gardening and road and estate management, for control of weeds, namely, power operated sprayers that generate steam and foam used to spray weeds; and structural parts and fittings therefore.

Goods & Services

Chemicals for use in agriculture, gardening and road and estate management, for control of weeds, namely, foam-forming chemicals for use in killing weeds Machines for use in agriculture, gardening and road and estate management, for control of weeds, namely, power operated sprayers that generate steam and foam used to spray weeds; and structural parts and fittings therefore

Abstract

Vegetation such as a weed (45) may be controlled by generating a foam comprising air and an aqueous solution comprising a surfactant, dispensing the foam so as to coat at least a base part of the weed that is to be controlled, and then injecting hot water into the foam (46) so as to contact the weed (45) below or within the coating of foam (46) The hot water causes the weed (45) to wilt and die, while the foam (46) suppresses heat loss from the hot water The method may be carried out using a portable tool (10) which includes an air blower (14), a container (20) of a concentrate for the aqueous solution, a foam-generating tube (24) ending in an open-topped chute (26) The hot water may be provided through a flexible hose (22) from an external boiler (23), and after being used to produce the foam (46), the hot water be sprayed onto the top end of the chute (26)

IPC Classes  ?

• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity
• A01G 11/00 - Sterilising soil by steam

Abstract

Vegetation such as a weed (45) may be controlled by generating a foam comprising air and an aqueous solution comprising a surfactant; dispensing the foam so as to coat at least a base part of the weed that is to be controlled; and then injecting hot water into the foam (46) so as to contact the weed (45) below or within the coating of foam (46) The hot water causes the weed (45) to wilt and die, while the foam (46) suppresses heat loss from the hot water. The method may be carried out using a portable tool (10) which includes an air blower (14), a container (20) of a concentrate for the aqueous solution, a foam-generating tube (24) ending in an open-topped chute (26). The hot water may be provided through a flexible hose (22) from an external boiler (23), and after being used to produce the foam (46), the hot water be sprayed onto the top end of the chute (26).

IPC Classes  ?

• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity

Abstract

An apparatus (10) comprises a water storage tank (14), a heater (16), a pump (38) and an outlet duct (70) to convey heated water to a plurality of lances (24) through hoses (22). The heater (16) is arranged to heat the water in at least two successive stages (66, 67), to an intermediate and then to a final temperature, at least the second stage (67) of the heater being activated in pulses, the frequency and/or duration of the pulses being adjustable to control the resultant temperature. Foaming agent is introduced (18, 40) into the water. Upstream of each hose (22) is a diversion valve (85) connecting to a water return circuit (54) leading back to the water storage tank (14); and the water return circuit (54) includes a heat exchanger (55, 56). The heater (16) may be liquid fuelled. The apparatus can be mobile, for example on a motor-vehicle (12), and it enables a number of people to control weeds separately, using separate lances (24), from the same apparatus (10).

IPC Classes  ?

• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity

Abstract

An apparatus (10) comprises a water storage tank (14), a heater (16), a pump (38) and an outlet duct (70) to convey heated water to a plurality of lances (24) through hoses (22). The heater (16) is arranged to heat the water in at least two successive stages (66, 67), to an intermediate and then to a final temperature, at least the second stage (67) of the heater being activated in pulses, the frequency and/or duration of the pulses being adjustable to control the resultant temperature. Foaming agent is introduced (18, 40) into the water. Upstream of each hose (22) is a diversion valve (85) connecting to a water return circuit (54) leading back to the water storage tank (14); and the water return circuit (54) includes a heat exchanger (55, 56). The heater (16) may be liquid fuelled. The apparatus can be mobile, for example on a motor-vehicle (12), and it enables a number of people to control weeds separately, using separate lances (24), from the same apparatus (10).

IPC Classes  ?

• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity

Abstract

An apparatus (10) comprises a water storage tank (14), a heater (16), a pump (38) and an outlet duct (70) to convey heated water to a plurality of lances (24) through hoses (22). The heater (16) is arranged to heat the water in at least two successive stages (66, 67), to an intermediate and then to a final temperature, at least the second stage (67) of the heater being activated in pulses, the frequency and/or duration of the pulses being adjustable to control the resultant temperature. Foaming agent is introduced (18, 40) into the water. Upstream of each hose (22) is a diversion valve (85) connecting to a water return circuit (54) leading back to the water storage tank (14); and the water return circuit (54) includes a heat exchanger (55, 56). The heater (16) may be liquid fuelled. The apparatus can be mobile, for example on a motor-vehicle (12), and it enables a number of people to control weeds separately, using separate lances (24), from the same apparatus (10).

IPC Classes  ?

• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity

Goods & Services

(1) Chemicals for use in killing weeds; chemicals for use in agriculture, gardening and facilities management, namely, surfactants for use in agricultural sprays (2) Machines for use in agriculture, gardening and facilities management for killing weeds, namely, power operated sprayers that generate hot water and foam used to spray weeds; and structural parts and fittings for such machines

Abstract

An apparatus suitable for controlling vegetation which apparatus comprises a hot-liquid reservoir (28), release means (38) connected to the hot-liquid reservoir (28) and at least one nozzle (74), for applying a stream of foam that contains steam, connected to the reservoir through the release means. The apparatus includes a heating means (34) to keep the liquid hot so the pressure is above atmospheric pressure. The liquid may be pumped by a pump (36) through the hot-water reservoir (28), the water being heated on demand by heaters (34) within the reservoir (28). The apparatus is either propelled by or mounted on a vehicle; and during use of the apparatus to control vegetation the vehicle provides power (24) to the heating means.

IPC Classes  ?

• A01M 7/00 - Special adaptations or arrangements of liquid-spraying apparatus for purposes covered by this subclass
• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity

Abstract

An apparatus suitable for controlling unwanted vegetation which apparatus comprises a reservoir (2), release means (6) connected to the reservoir (2), and a nozzle (10) for applying a stream of foam including steam, connected to the reservoir (2) through the release means (6). A liquid is heated in the reservoir (2) to an elevated pressure, the liquid comprising water and a surfactant, i.e. a foaming agent, and forms a foam when discharged through the nozzle (10). The foam contains steam, and is effective at killing the foliage.

IPC Classes  ?

• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity

Abstract

An apparatus suitable for controlling vegetation which apparatus comprises a hot-liquid container (28), release means (38) connected to the hot-liquid container (28) and at least one nozzle assembly (100), for applying a stream of foam that contains steam, connected to the container through the release means. The nozzle assembly (100) includes a shroud (102) defining an enclosure around a spraying duct (104) within which are a flow-restricting aperture (113), a primary mixing chamber (114) and a secondary mixing chamber (116) linked by a duct of varying cross-section, and with a turbulence-enhancing structure (124) at an outlet (134) from the secondary mixing chamber. Inlet holes (118) communicate between the primary mixing chamber and the enclosure, so air and steam are sucked into the water stream, and foam is produced. The apparatus is either propelled by or mounted on a vehicle; and during use of the apparatus to control vegetation the vehicle provides power (24) to the heating means.

IPC Classes  ?

• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity
• B05B 7/00 - Spraying apparatus for discharge of liquids or other fluent materials from two or more sources, e.g. of liquid and air, of powder and gas

Goods & Services

Chemicals for use in agriculture, gardening and road and estate management, for control of weeds, namely, foam-forming chemicals for use in killing weeds. Machines for use in agriculture, gardening and road and estate management, for control of weeds, namely, power operated sprayers that generate steam and foam used to spray weeds; and structural parts and fittings therefore. Garden weeding tool, namely, a garden weeding tool consisting of a hand operated sprayer with a nozzle for dispensing steam and foam used to spray weeds. Maintenance and servicing of machines for use in agriculture, gardening and road and estate management; maintenance and servicing of machines for use in killing weeds.

Goods & Services

Garden weeding tool, namely, a garden weeding tool consisting of a hand operated sprayer with a nozzle for dispensing steam and foam used to spray weeds.

Abstract

An apparatus suitable for controlling unwanted vegetation which apparatus comprises a reservoir (2), release means (6) connected to the reservoir (2), and a nozzle (10) for applying a stream of foam including steam, connected to the reservoir (2) through the release means (6). A liquid is heated in the reservoir (2) to an elevated pressure, the liquid comprising water and a surfactant, i.e. a foaming agent, and forms a foam when discharged through the nozzle (10). The foam contains steam, and is effective at killing the foliage.

IPC Classes  ?

• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity

Abstract

An apparatus suitable for controlling vegetation which apparatus comprises a hot-liquid reservoir (28), release means (38) connected to the hot-liquid reservoir (28) and at least one nozzle (74), for applying a stream of foam that contains steam, connected to the reservoir through the release means. The apparatus includes a heating means (34) to keep the liquid hot so the pressure is above atmospheric pressure. The liquid may be pumped by a pump (36) through the hot-water reservoir (28), the water being heated on demand by heaters (34) within the reservoir (28). The apparatus is either propelled by or mounted on a vehicle; and during use of the apparatus to control vegetation the vehicle provides power (24) to the heating means.

IPC Classes  ?

• A01M 21/04 - Apparatus for destruction by steam, chemicals, burning, or electricity

Goods & Services

Chemicals for use in agriculture, gardening and facilities management. Chemicals for use in killing weeds. Machines for use in agriculture, gardening and facilities management; machines for use in killing weeds; attachments, parts, fittings and accessories for the aforesaid goods. Garden weeding tool; steam generating garden weeding tool. Maintenance and servicing of machines for use in agriculture, gardening and facilities management; maintenance and servicing of machines for use in killing weeds.

Goods & Services

(1) Foam-forming chemicals for use in killing weeds, such foam-forming chemicals being for use in agriculture, for use in gardening, for use in road and estate management and for control of weeds; and garden weeding tool; steam generating garden weeding tool.

Goods & Services

Chemicals for use in agriculture, gardening and facilities management, namely, surfactants for use in agricultural sprays excluding agricultural fungicides, herbicides, insecticides and parasiticides Machines for use in agriculture, gardening and facilities management, namely, lawn and garden tilling machines, power operated lawn and garden string trimmers, power operated lawn and garden edgers; Machines for use in agriculture, gardening and facilities management, namely, power operated sprayers that generate steam and foam used to spray weeds and structural parts and fittings therefor Maintenance and servicing of machines for use in agriculture, gardening and facilities management; maintenance and servicing of machines for use in killing weeds

Goods & Services

Agricultural and horticultural machines, machine tools, and implements including garden implements; machines for controlling vegetation and/or killing weeds; parts and fittings in this class for all the foregoing. Retail and wholesale services in relation to agricultural and horticultural machines, garden implements, machine tools and implements, machines for controlling vegetation and/or killing weeds and associated parts and fittings; business services and business affairs associated with the workings and management of a commercial undertaking in relation to agricultural and horticultural machines, machine tools and implements including garden implements and machines for controlling vegetation and/or killing weeds; business management; office functions and business administration; advisory, promotional advertising and organisational services included in this class; business information services and promotional services for the sale of goods and services, all relating to agricultural and horticultural machines, machine tools and implements including garden implements and machines for controlling and/or killing weeds; franchising services. Agricultural, horticultural, gardening and forestry services including the control of vegetation and/or weed killing; rental of agricultural, horticultural, forestry and garden machines, tools and equipment.
