Abstract

The invention relates to a device for drilling holes for a cam lock connector, comprising two stop plates (1, 2) at a right angle to one another, wherein the stop plate (1) has guide openings (4, 5, 6) which each have the same diameter (D2) and into which a drill (25) having a larger diameter (D2) can be inserted. A sleeve element (20) having an outside diameter corresponding to the diameter (D2) is inserted in one of the guide openings (5). The sleeve element (20) has an inside diameter which has a smaller diameter (D1) for receiving a drill (18) having a small diameter (D1).

IPC Classes  ?

• B23B 47/28 - Drill jigs for workpieces

Abstract

A marking triangle includes two partial triangles connected via a joint and in which, when the marking triangle is folded, a cut-out forms contact flanks which, together with a marking edge of the bottom of the recess, allow for a center to be marked on a workpiece. In addition, a solder body of a plumb line can be inserted in the recess.

IPC Classes  ?

• B25H 7/02 - Plates having a flat surface
• G01B 3/06 - Rulers with scales or marks for direct reading rigid folding
• G01B 3/56 - Gauges for measuring angles or tapers, e.g. conical calipers

Abstract

A contour gauge has an elongated housing, in which a plurality of measuring teeth are arranged so as to move transverse to the extension direction of the housing, and a ruler assembly for measuring a distance to an object spaced apart from the housing in the extension direction of the housing. The ruler assembly has a first ruler which is guided on lateral walls of a guide of the housing, which can be pulled out of the guide from a first storage position within the guide into a first stop position in the extension direction of the housing, and which supports a second ruler which can be moved relative to the first ruler in the extension direction of the housing from a second storage position into a second stop position. Securing elements are provided with which the rulers can be secured to the housing or to one another.

IPC Classes  ?

• G01B 5/20 - Measuring arrangements characterised by the use of mechanical techniques for measuring contours or curvatures
• G01B 3/08 - Rulers with scales or marks for direct reading rigid extensible

Goods & Services

Hand tools, hand-operated; Cramps for use in holding workpieces; Parts and accessories for all the aforesaid goods, included in this class. Gloves for protection of the hands against accident and injury; Parts and accessories for all the aforesaid goods, included in this class. Gloves [clothing]; Parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

Hand tools, hand-operated; Cramps for use in holding workpieces; Parts and accessories for all the aforesaid goods, included in this class.

Abstract

A device for carrying out miter cuts includes two limbs which are secured to a central element in a pivotal manner in each case and so as to be fixable in pivoted positions. Each limb has a stop strip with a contact surface, wherein the contact surface lies opposite a counter contact surface formed by a counter stop. The distance between the contact surface and the counter contact surface can be adjusted by an adjusting element. Furthermore, the limbs and the central element are made of plastic, and a region of the central element from which the guide elements originate and which extends at least over the region between the guide elements has either a metal plate or an exchangeable sacrificial plate.

IPC Classes  ?

• B27G 5/02 - Machines or devices for working mitre joints with even abutting ends for sawing mitre jointsMitre boxes

Abstract

The invention relates to a device which comprises a housing (1) which has an insertion channel (6) extending in the axial direction (6) for inserting a free end of a slide bar (15) of a clamp, wherein the slide bar (15) can be axially secured to the housing (1) by means of a lock element (7) which can be brought into a release position, in which the slide bar (15) can be removed from the device, with a stabilising element (25) having an insertion opening (5) and a stabilising flank arrangement (25) which is adjacent to the insertion opening and is adapted to the cross-section contour of the slide bar (15), for supporting surface portions of the slide bar (15). According to the invention, the stabilising element is fastened to the housing (1) in a rotatable manner and has several angle-offset stabilising flank arrangements (25) which are adapted to the outline contours of different slide bars (15).

IPC Classes  ?

• B25B 5/06 - Arrangements for positively actuating jaws
• B25B 5/16 - Details, e.g. jaws, jaw attachments

Abstract

The invention relates to a device for suctioning cuttings which accumulate during a drilling process, comprising a first housing part (1) which has a negative pressure chamber (3), wherein a first suction channel (7) fluidically connects the negative pressure chamber (3) to a suction connector (14) which has a wall with a circular cross-section for plugging a hose (48), and comprising a second housing part (2, 2', 2'') which has a suction chamber (4), a second suction channel (8) fluidically connecting the suction chamber (4) to the suction connector (14). According to the invention, the wall of the suction connector (14) is formed by walls (15, 16), each of which is formed by one of the housing parts.

IPC Classes  ?

• B23Q 11/00 - Accessories fitted to machine tools for keeping tools or parts of the machine in good working condition or for cooling workSafety devices specially combined with or arranged in, or specially adapted for use in connection with, machine tools

Abstract

The invention relates to a contour gauge having a housing (1), in which a plurality of touch fins (2) movable transversely to the direction of extension of the housing (1) is disposed, wherein: when a clamping device is in an adjustment position, the touch fins (2) can be slid relative to each other; a pressing flank (12) contacts a broad side surface of a first outermost touch fin (2), and a broad side surface, facing away therefrom, of a second outermost touch fin (2) is seated against a counter pressing flank (6); the clamping device can be brought, by rotation of a clamping lever (3) about a clamping-lever rotational axis (7), said clamping lever having an eccentric surface (9) supported on a support flank (5'), into a clamping position, in the case of which the touch fins (2) are clamped between the pressing flank (12) and the counter pressing flank (6) in such a way that the sliding of the touch fins (2) relative to each other is impeded. In order to compensate production tolerances, according to the invention the eccentricity of the eccentric surface (9) can be adjusted relative to the clamping-lever rotational axis (7).

IPC Classes  ?

• G01B 3/00 - Measuring instruments characterised by the use of mechanical techniques
• G01B 3/22 - Feeler-pin gauges, e.g. dial gauges
• G01B 5/207 - Measuring arrangements characterised by the use of mechanical techniques for measuring contours or curvatures using a plurality of fixed, simultaneously operating transducers

Abstract

The invention relates to a device for guiding a tool during the cutting of a workpiece (69), in particular a miter box, comprising guide elements (31) which define a cutting guide line (S), and comprising a base element (1), with which the tool comes into contact once the cut is completed. In order to protect the cutting edge of the tool and a base surface of the base element, one or more bodies (55) are provided, the body or bodies being rotatably arranged on the base element (1) in the cutting guide line and against which body or bodies the cutting edge can bump once the cut is completed. The body can be a rivet or a roller.

IPC Classes  ?

• B23D 51/02 - Sawing machines or sawing devices working with straight blades, characterised only by constructional features of particular partsCarrying or attaching means for tools, covered by this subclass, which are connected to a carrier at both ends of bedsSawing machines or sawing devices working with straight blades, characterised only by constructional features of particular partsCarrying or attaching means for tools, covered by this subclass, which are connected to a carrier at both ends of guiding arrangements for work-tables or saw carriersSawing machines or sawing devices working with straight blades, characterised only by constructional features of particular partsCarrying or attaching means for tools, covered by this subclass, which are connected to a carrier at both ends of frames
• B27G 5/02 - Machines or devices for working mitre joints with even abutting ends for sawing mitre jointsMitre boxes

Abstract

The invention relates to a tension clamp comprising a push/pull rod (1) that can be displaced in a housing (2) in steps and comprising a drive lever (3) that is supported by the housing (1) and displaces a drive element (4), which engages on the push/pull rod (1), forward in a clamping direction (S) relative to the housing (2) during an advancing actuation. The tension clamp has a blocking element (5) which is supported by the housing (1) and which prevents a reverse displacement of the push/pull rod (1) in a release direction (L) opposite the clamping direction (S) in a blocking position and which can be displaced from the blocking position into a release position by actuating a release lever (6) that engages on the blocking element (5), a displacement of the push/pull rod (1) in the release direction (L) being possible in the release position. The tension clamp also comprises a movement limiting element (7) which is struck by the blocking element (4) during a forward displacement of the drive element (4), said forward displacement carrying the push/pull rod (1). In order to improve the efficiency of the movement limiting element (7), the movement limiting element (7) is acted upon by a spring element (9) against the blocking element (5), wherein the movement limiting element (7) is arranged in a pocket (11) of the release lever (6).

IPC Classes  ?

• B25B 5/06 - Arrangements for positively actuating jaws

Goods & Services

Measuring apparatus and instruments; squares for measuring, angle irons for marking; rods (surveying instruments); rulers [measuring instruments] and dial gauges; displacement gauges and protractors (measuring instruments); angle bevels (measuring instruments); gauges, in particular contour gauges; spirit levels; rulers [measuring instruments]; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, cassettes, assortment boxes and magazines; parts, replacement parts and accessories for the aforesaid goods, all the aforesaid goods included in this class. Retailing and wholesaling, including via teleshopping programmes, online and catalogue mail order, in relation to the following goods: construction articles, diy articles, tools, construction articles, trade articles, garden article, measuring apparatus, meters and gauges; presentation of goods on offers, for wholesaling and retailing, in the following field: construction articles, DIY articles, tools, construction articles, trade articles, garden article, measuring apparatus, meters and gauges; publication of printed matter (including in electronic form), for advertising purposes; presentation of goods on communications media for wholesale and retail purposes; auctioneering, including on the internet; arranging of commercial transactions, for others, including within the framework of e-commerce; arranging of contracts for others for the buying and selling of goods.

Goods & Services

Measuring apparatus and instruments; squares for measuring, angle irons for marking; rods (surveying instruments); rulers [measuring instruments] and dial gauges; displacement gauges and protractors (measuring instruments); angle bevels (measuring instruments); gauges, in particular contour gauges; spirit levels; rulers [measuring instruments]; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, cassettes, assortment boxes and magazines; parts, replacement parts and accessories for the aforesaid goods, all the aforesaid goods included in this class. Retailing and wholesaling, including via teleshopping programmes, online and catalogue mail order, in relation to the following goods: construction articles, diy articles, tools, construction articles, trade articles, garden article, measuring apparatus, meters and gauges; presentation of goods on offers, for wholesaling and retailing in the following fields: construction articles, DIY articles, tools, construction articles, trade articles, garden article, measuring apparatus, meters and gauges; publication of printed matter (including in electronic form), for advertising purposes; presentation of goods on communications media for wholesale and retail purposes; auctioneering, including on the Internet; arranging of commercial transactions, for others, including within the framework of e-commerce; arranging of contracts for others for the buying and selling of goods.

Abstract

The invention relates to a marking triangle which consists of two partial triangles (9, 9') connected via a joint (8) and in which, when the marking triangle is folded, a cut-out (2) forms contact flanks (3) which, together with a marking edge (7') of the bottom of the recess, allow for a center to be marked on a workpiece. In addition, a solder body (17) of a plumb line can be inserted in the recess.

IPC Classes  ?

• G01B 3/04 - Rulers with scales or marks for direct reading rigid
• G01B 3/56 - Gauges for measuring angles or tapers, e.g. conical calipers

Abstract

The invention relates to a contour gauge with an elongated housing (1), in which a plurality of measuring teeth (2) are arranged such that they can move transverse to the extension direction of the housing (1), and with a ruler assembly for measuring a distance to an object spaced apart from the housing (1) in the extension direction of same, wherein the ruler assembly has a first ruler (7) which is guided on lateral walls (4) of a guide (3) of the housing (1), which can be pulled out of the guide (3) from a first storage position within the guide (3) into a first stop position in the extension direction of the housing (1), and which supports a second ruler (10) which can be moved relative to the first ruler (7) in the extension direction of the housing (1) from a second storage position into a second stop position. In order to robustly develop a contour gauge of this type, securing means (14, 16) are provided with which the rulers (7, 10) can be secured to the housing or to one another.

IPC Classes  ?

• G01B 3/04 - Rulers with scales or marks for direct reading rigid
• G01B 5/207 - Measuring arrangements characterised by the use of mechanical techniques for measuring contours or curvatures using a plurality of fixed, simultaneously operating transducers
• G01B 3/08 - Rulers with scales or marks for direct reading rigid extensible

Goods & Services

Mechanically operated tools; machines for the construction of machines, apparatus, tools and vehicles and for electrical and structural engineering, metal working, wood working, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock and watchmakers, floor and tile layers, installers and DIY enthusiasts; mechanically operated tools and apparatus for the construction of machines, apparatus, tools and vehicles, for electrical and structural engineering, for metal working, woodworking, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock and watchmakers, floor and tile layers, installers and DIY enthusiasts; hand-held driving machines intended for stationary installation for driving tools, including parts thereof, as included in this class; tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling bits; mechanically operated screwing tools, in particular screwdrivers and screwdriver bits (bits for mechanical tools), and holders therefor; electrically or pneumatically operated drilling machines and hand drills; drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; drill stands and drilling aids for electric drilling machines; drill chucks for mechanical tools; drill stands and drilling aids for electrically or pneumatically operated drilling machines; templates (parts of machines), in particular drilling and milling templates; milling stops; bit stops for drills (parts of machines); milling cutters (mechanical tools); grinding machines and grinding wheels (parts of machines); cut-off grinders, grinding plates, grinding discs, cut-off wheels, ceramic abrasive pencils (parts of machines); electric cutting tools; blades (parts of machines); electric hole cutters; electric tile and laminate cutters; cutting machines; electric strip and edge cutters; saws (machines), in particular hole saws, circular saws and chain saws; saw blades and blades for mechanical tools; chisels for machines; electric chisels; brushes (parts of machines), in particular wire brushes; mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; mechanical clamping, stretching and expanding tools and devices; clamping spindles for mechanical tools; clamping jaws (parts of machines); pneumatic tools (parts of machines); turning lathes and planing machines; electric cartridge guns; pumps (parts of machines or motors and engines); tables for machines; supporting trestles, sawhorses and roller blocks (parts of machines); planing benches and turning lathes (parts of machines), clamping and work tables being parts of machines; electric soldering and welding tools; electric cleaning machines and apparatus; flexible shafts (parts of machines); holders (parts of machines) for all the aforesaid goods; handles for mechanical tools, in particular telescopic handles; parts of machines, namely grinding wheels, grinding plates, abrasive belts, polishing wheels, polishing heads; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; pneumatic fittings for pneumatic tools; packaging of metal adapted for mechanically operated tools; parts, spare parts and accessories for all the aforesaid goods, included in this class. Hand tools (hand-operated); implements (hand-operated) for agricultural, horticultural and forestry purposes, for the construction of machines, apparatus, tools and vehicles and for electrical and structural engineering, metal working, wood working, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock- and watchmakers, floor and tile layers, installers and DIY enthusiasts; tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners (hand tools); vices, clamping jaws for vices; clamps (hand tools), in particular screw clamps, spring clamps, ratchet clamps, mounting clamps, one-handed clamps and glue presses; hand-operated screwing tools, in particular screwdrivers and screwdriver bits (bits for hand-operated tools), and holders therefor; non-electric hand drills; drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; drill stands and drilling aids for hand-operated drills; drill chucks for hand tools; templates, namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; guiding tools (hand-operated) for drills and hole saws; milling cutters (hand tools); sharpening instruments; blade sharpening instruments; hand-operated grinding wheels, grinding plates, cut-off wheels, cut-off grinders and ceramic abrasive pencils; grinders (hand tools), hand-operated grinding apparatus; cutlery; cutting tools; glass cutters; knives (hand tools), carpet knives and scissors; scrapers (hand tools); mitre boxes, edge cutters, cutters; blades (parts of hand tools); hand-operated hole cutters; non-electric tile and laminate cutters; cutting aids (hand tools); non-electric strip and edge cutters; saws (hand tools); saw blades and blades for hand-operated tools; chisels (hand-operated tools), in particular including boring tools; mixers (inserts for hand tools), in particular paint mixers, mortar mixers, adhesive mixers; hand-operated clamping, stretching and expanding tools in particular frame clamps, angle clamps, clamping jaws, quick-release clamps; clamping spindles for hand tools; dowelling tools (hand-operated tools); planes; cartridge guns (hand tools); hand pumps; pull bars; trowels (tools), in particular brick trowels; spattles, hand-operated tackers; mitre boxes; clamps, in particular riveting pliers; rasps and files (hand tools); angles (hand tools); angle bevels (hand tools); spanners (hand tools); spacers (hand tools); hand-operated striking tools, in particular bats; handles for hand tools, in particular telescopic handles; holders for all the aforesaid goods; dies and inserts for all the aforesaid goods; hand tools, namely grinding wheels, grinding plates, abrasive belts, polishing wheels, polishing heads; scribers (tools); storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; wire brushes (hand-operated tools); packaging of metal adapted for hand-operated tools; parts, spare parts and accessories for all the aforesaid goods, included in this class; non-electric soldering and welding tools, parts, spare parts and accessories thereof, and storage containers adapted thereto, in particular cases, bags, boxes, cassettes, assortment boxes and magazines; metal tape tensioners (hand tools), parts, spare parts and accessories thereof, and storage containers adapted thereto, in particular cases, bags, boxes, cassettes, assortment boxes and magazines; tape tensioners (hand tools), not of metal, parts, spare parts and accessories thereof, and storage containers adapted thereto, in particular cases, bags, boxes, cassettes, assortment boxes and magazines. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; measuring apparatus and instruments, in particular levelling rods, rules (measuring instruments) and dial test indicators; displacement gauges and protractors [measuring instruments]; angle bevels (measuring instruments); gauges, in particular contour gauges; spirit levels; rulers (measuring instruments); protective eyewear, welding goggles; protective masks, respiratory masks and protective mouth masks, in particular fine dust masks and half masks; filters for protective masks, respiratory masks and protective mouth masks; protective helmets, protective gloves; protective work clothing, in particular disposable protective and safety clothing and disposable protective overshoes; spectacle cases; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; laminate fitters being measuring instruments; dowel bars being measuring tools; parts, spare parts and accessories for the aforesaid goods, included in this class; downloadable electronic publications. Apparatus for locomotion by land, in particular handling carts, two-wheeled trolleys and push carts; luggage nets for vehicles and vehicle trailers; parts and spare parts for all the aforesaid goods, included in this class. Paper, cardboard; packaging materials of cardboard; plastic materials for packaging (not included in other classes); pouches, envelopes, bags of paper or plastic, for packaging; packaging of paper or plastic adapted for hand-operated and/or mechanically operated tools; cardboard and/or cardboard packaging for presenting goods; paint brushes, paint rollers; painters' brushes; stencils; garden waste bags of plastic; glues for stationery or household purposes; printed matter, in particular catalogues; marking and drawing templates, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; parts, spare parts and accessories for all the aforesaid goods, included in this class. Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches (not of metal), planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); supporting trestles, sawhorses and chopping blocks [tables]; storage racks, not of metal, for storing firewood; display cases for merchandise; showcases for presenting goods; fastening materials, not of metal, fastening and spacer wedges, not of metal; clamps, not of metal; troughs of plastic for mixing mortar; strips of wood for frames; wooden dowels, wooden pegs; empty storage containers, not of metal; empty storage containers (not of metal), in particular cases, boxes, caskets and assortment boxes for tools, tool inserts, ironmongery, small items of metal hardware; packaging containers, not of metal; dowel fixings for marking dowel holes; clips of plastic for cables and plants; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for all the aforesaid goods, included in this class; vice benches of metal, parts, spare parts and accessories thereto. Wholesale and retail services, including by means of teleshopping programmes and online and catalogue mail order, in the fields of construction and DIY articles, tools, construction, craftsmen and garden articles, craft supplies, personal industrial safety equipment and clothing; presentation of goods in the fields of construction and DIY articles and other commodity goods for the professional and DIY sectors, machines, tools and goods of common metal, construction, craftsmen and garden articles, hobby requisites and craft supplies, personal industrial safety equipment and clothing; publication of printed matter (including in electronic form) for advertising purposes; presentation of goods on communication media, for wholesale and retail purposes; auctioneering, including on the Internet; arranging commercial transactions, for others, including within the framework of e-commerce; arranging contracts, for others, for the buying and selling of goods.

Goods & Services

Mechanically operated tools; machines for the construction of machines, apparatus, tools and vehicles and for electrical and structural engineering, metal working, wood working, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock and watchmakers, floor and tile layers, installers and DIY enthusiasts; mechanically operated tools and apparatus for the construction of machines, apparatus, tools and vehicles, for electrical and structural engineering, for metal working, woodworking, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock and watchmakers, floor and tile layers, installers and DIY enthusiasts; hand-held driving machines intended for stationary installation for driving tools, including parts thereof, as included in this class; tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling bits; mechanically operated screwing tools, in particular screwdrivers and screwdriver bits (bits for mechanical tools), and holders therefor; electrically or pneumatically operated drilling machines and hand drills; drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; drill stands and drilling aids for electric drilling machines; drill chucks for mechanical tools; drill stands and drilling aids for electrically or pneumatically operated drilling machines; templates (parts of machines), in particular drilling and milling templates; milling stops; bit stops for drills (parts of machines); milling cutters (mechanical tools); grinding machines and grinding wheels (parts of machines); cut-off grinders, grinding plates, grinding discs, cut-off wheels, ceramic abrasive pencils (parts of machines); electric cutting tools; blades (parts of machines); electric hole cutters; electric tile and laminate cutters; cutting machines; electric strip and edge cutters; saws (machines), in particular hole saws, circular saws and chain saws; saw blades and blades for mechanical tools; chisels for machines; electric chisels; brushes (parts of machines), in particular wire brushes; mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; mechanical clamping, stretching and expanding tools and devices; clamping spindles for mechanical tools; clamping jaws (parts of machines); pneumatic tools (parts of machines); turning lathes and planing machines; electric cartridge guns; pumps (parts of machines or motors and engines); tables for machines; supporting trestles, sawhorses and roller blocks (parts of machines); planing benches and turning lathes (parts of machines), clamping and work tables being parts of machines; electric soldering and welding tools; electric cleaning machines and apparatus; flexible shafts (parts of machines); holders (parts of machines) for all the aforesaid goods; handles for mechanical tools, in particular telescopic handles; parts of machines, namely grinding wheels, grinding plates, abrasive belts, polishing wheels, polishing heads; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; pneumatic fittings for pneumatic tools; packaging of metal adapted for mechanically operated tools; parts, spare parts and accessories for all the aforesaid goods, included in this class. Hand tools (hand-operated); implements (hand-operated) for agricultural, horticultural and forestry purposes, for the construction of machines, apparatus, tools and vehicles and for electrical and structural engineering, metal working, wood working, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock- and watchmakers, floor and tile layers, installers and DIY enthusiasts; tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners (hand tools); vices, clamping jaws for vices; clamps (hand tools), in particular screw clamps, spring clamps, ratchet clamps, mounting clamps, one-handed clamps and glue presses; hand-operated screwing tools, in particular screwdrivers and screwdriver bits (bits for hand-operated tools), and holders therefor; non-electric hand drills; drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; drill stands and drilling aids for hand-operated drills; drill chucks for hand tools; templates, namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; guiding tools (hand-operated) for drills and hole saws; milling cutters (hand tools); sharpening instruments; blade sharpening instruments; hand-operated grinding wheels, grinding plates, cut-off wheels, cut-off grinders and ceramic abrasive pencils; grinders (hand tools), hand-operated grinding apparatus; cutlery; cutting tools; glass cutters; knives (hand tools), carpet knives and scissors; scrapers (hand tools); mitre boxes, edge cutters, cutters; blades (parts of hand tools); hand-operated hole cutters; non-electric tile and laminate cutters; cutting aids (hand tools); non-electric strip and edge cutters; saws (hand tools); saw blades and blades for hand-operated tools; chisels (hand-operated tools), in particular including boring tools; mixers (inserts for hand tools), in particular paint mixers, mortar mixers, adhesive mixers; hand-operated clamping, stretching and expanding tools in particular frame clamps, angle clamps, clamping jaws, quick-release clamps; clamping spindles for hand tools; dowelling tools (hand-operated tools); planes; cartridge guns (hand tools); hand pumps; pull bars; trowels (tools), in particular brick trowels; spattles, hand-operated tackers; mitre boxes; clamps, in particular riveting pliers; rasps and files (hand tools); angles (hand tools); angle bevels (hand tools); spanners (hand tools); spacers (hand tools); hand-operated striking tools, in particular bats; handles for hand tools, in particular telescopic handles; holders for all the aforesaid goods; dies and inserts for all the aforesaid goods; hand tools, namely grinding wheels, grinding plates, abrasive belts, polishing wheels, polishing heads; scribers (tools); storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; wire brushes (hand-operated tools); packaging of metal adapted for hand-operated tools; parts, spare parts and accessories for all the aforesaid goods, included in this class; non-electric soldering and welding tools, parts, spare parts and accessories thereof, and storage containers adapted thereto, in particular cases, bags, boxes, cassettes, assortment boxes and magazines; metal tape tensioners (hand tools), parts, spare parts and accessories thereof, and storage containers adapted thereto, in particular cases, bags, boxes, cassettes, assortment boxes and magazines; tape tensioners (hand tools), not of metal, parts, spare parts and accessories thereof, and storage containers adapted thereto, in particular cases, bags, boxes, cassettes, assortment boxes and magazines. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; measuring apparatus and instruments, in particular levelling rods, rules (measuring instruments) and dial test indicators; displacement gauges and protractors [measuring instruments]; angle bevels (measuring instruments); gauges, in particular contour gauges; spirit levels; rulers (measuring instruments); protective eyewear, welding goggles; protective masks, respiratory masks and protective mouth masks, in particular fine dust masks and half masks; filters for protective masks, respiratory masks and protective mouth masks; protective helmets, protective gloves; protective work clothing, in particular disposable protective and safety clothing and disposable protective overshoes; spectacle cases; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; laminate fitters being measuring instruments; dowel bars being measuring tools; parts, spare parts and accessories for the aforesaid goods, included in this class; downloadable electronic publications. Apparatus for locomotion by land, in particular handling carts, two-wheeled trolleys and push carts; luggage nets for vehicles and vehicle trailers; parts and spare parts for all the aforesaid goods, included in this class. Paper, cardboard; packaging materials of cardboard; plastic materials for packaging (not included in other classes); pouches, envelopes, bags of paper or plastic, for packaging; packaging of paper or plastic adapted for hand-operated and/or mechanically operated tools; cardboard and/or cardboard packaging for presenting goods; paint brushes, paint rollers; painters' brushes; stencils; garden waste bags of plastic; glues for stationery or household purposes; printed matter, in particular catalogues; marking and drawing templates, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; parts, spare parts and accessories for all the aforesaid goods, included in this class. Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches (not of metal), planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); supporting trestles, sawhorses and chopping blocks [tables]; storage racks, not of metal, for storing firewood; display cases for merchandise; showcases for presenting goods; fastening materials, not of metal, fastening and spacer wedges, not of metal; clamps, not of metal; troughs of plastic for mixing mortar; strips of wood for frames; wooden dowels, wooden pegs; empty storage containers, not of metal; empty storage containers (not of metal), in particular cases, boxes, caskets and assortment boxes for tools, tool inserts, ironmongery, small items of metal hardware; packaging containers, not of metal; dowel fixings for marking dowel holes; clips of plastic for cables and plants; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for all the aforesaid goods, included in this class; vice benches of metal, parts, spare parts and accessories thereto. Wholesale and retail services, including by means of teleshopping programmes and online and catalogue mail order, in the fields of construction and DIY articles, tools, construction, craftsmen and garden articles, craft supplies, personal industrial safety equipment and clothing; presentation of goods in the fields of construction and DIY articles and other commodity goods for the professional and DIY sectors, machines, tools and goods of common metal, construction, craftsmen and garden articles, hobby requisites and craft supplies, personal industrial safety equipment and clothing; publication of printed matter (including in electronic form) for advertising purposes; presentation of goods on communication media, for wholesale and retail purposes; auctioneering, including on the Internet; arranging commercial transactions, for others, including within the framework of e-commerce; arranging contracts, for others, for the buying and selling of goods.

Goods & Services

Hand tools (hand-operated); implements (hand-operated) for agricultural, horticultural and forestry purposes, for the construction of machines, apparatus, tools and vehicles and for electrical and structural engineering, metal working, wood working, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock- and watchmakers, floor and tile layers, installers and DIY enthusiasts; tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners; vices, clamping jaws for vices; clamps (hand tools), in particular screw clamps, spring clamps, ratchet clamps, mounting clamps, one-handed clamps and glue presses; hand-operated screwing tools, in particular screwdrivers and screwdriver bits (bits for hand-operated tools), and holders relating thereto; non-electric hand drills; drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; drill stands and drilling aids for hand-operated drills; drill chucks for hand tools; guiding tools (hand-operated) for drills and hole saws; milling cutters (hand tools); sharpening instruments; blade sharpening instruments; hand-operated grinding wheels, grinding plates, cut-off wheels, cut-off grinders and ceramic grinding pencils; grinders (hand tools), hand-operated grinding apparatus; cutlery; cutting tools; glass cutters; knives (hand tools), carpet knives and scissors; scrapers (hand tools); mitre boxes, edge cutters, cutters; blades (parts of hand tools); hand-operated hole cutters; non-electric tile and laminate cutters; non-electric laminate fitters (hand tools); cutting aids (hand tools); non-electric strip and edge cutters; saws (hand tools); saw blades and blades for hand-operated tools; chisels (hand-operated tools), in particular including boring tools; mixers (inserts for hand tools), in particular paint mixers, mortar mixers, adhesive mixers; hand-operated clamping, stretching and expanding tools, in particular belt tensioning tools, frame clamps, angle clamps, clamping jaws, quick-release clamps; clamping spindles for hand tools; dowelling tools; planes; cartridge guns (hand tools); hand pumps; pull bars; trowels (tools), in particular brick trowels; plaster buckets; spattles, tackers; mitre boxes; clamps, in particular riveting pliers; rasps and files (hand tools); angles (hand tools); spanners; hand-operated striking tools, in particular bats; handles for hand tools, in particular telescopic handles; holders for all the aforesaid goods; dies and inserts for all the aforesaid goods; hand tools, namely grinding wheels, grinding plates, abrasive belts, abrasive strips, abrasive sheets, polishing bonnets, polishing wheels, polishing heads; scribers (tools); storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; packaging of metal adapted for hand-operated tools; parts, spare parts and accessories for all the aforesaid goods, included in this class. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signaling, checking (supervision), life-saving and teaching apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; measuring apparatus and instruments, in particular measuring rods, rules (measuring instruments) and dial indicators; measuring apparatus, namely bevels; displacement gauges and goniometers; angle bevels (measuring instruments); gauges, in particular contour gauges; spirit levels; rulers (measuring instruments); protective eyewear, welding goggles; protective masks, respiratory masks and protective mouth masks, in particular fine dust masks and half masks; filters for protective masks, respiratory masks and protective mouth masks; protective helmets, protective gloves; protective work clothing, in particular disposable protective and safety clothing, and disposable protective overshoes; spectacle cases; protective ear coverings, protective ear plugs; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for the aforesaid goods, included in this class; downloadable electronic publications. Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches (not of metal), planning benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); supporting trestles, sawhorses and roller blocks (not being parts of machines); storage racks, not of metal, for storing firewood; goods carrier displays for displaying goods; showcases for presenting goods; guide rails, not of metal; fastening materials, not of metal, namely wood dowels, plastic dowels, plastic hooks; fastening and spacer wedges, not of metal; clamps (cramps), not of metal; troughs of plastic for mixing mortar; strips of wood for frames; wooden dowels, wooden pegs; empty storage containers, not of metal; empty storage containers (not of metal), in particular cases, boxes, caskets, assortment boxes and magazines for tools, tool inserts, ironmongery, small items of metal hardware; suction cups of plastic for changing lighting devices; spacers of wood or plastic for floor layering and for positioning of door frames and window frames; packaging containers, not of metal; dowel bars; clips of plastic for cables and plants; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for all the aforesaid goods, included in this class.

Abstract

The invention relates to a device for carrying out miter cuts, comprising two limbs (2, 2') which are secured to a central element (1) in a pivotal manner in each case and so as to be fixable in pivoted positions. Each limb (2, 2') has a stop strip (5) with a contact surface (5'), wherein the contact surface (5') lies opposite a counter contact surface (6') formed by a counter stop (6). According to the invention, the distance between the contact surface (5') and the counter contact surface (6') can be adjusted by means of an adjusting element (7, 8, 9). Furthermore, the limbs (2, 2') and the central element (1) are made of plastic, and a region of the central element (1) from which the guide elements (31, 32, 33) originate and which extends at least over the region between the guide elements (31, 32, 33) has either a metal plate (38) or an exchangeable sacrificial plate (38).

IPC Classes  ?

• B27G 5/02 - Machines or devices for working mitre joints with even abutting ends for sawing mitre jointsMitre boxes

Goods & Services

Measuring apparatus and instruments; Squares for measuring, Angle irons for marking; Rods (surveying instruments); Rules [measuring instruments] and Dial indicators; Displacement gauges and protractors (measuring instruments); Angle bevels (measuring instruments); Gauges, In particular contour gauges; Spirit levels; Rulers [measuring instruments]; Storage containers adapted for the aforesaid goods, in particular cases, Bags, boxes, Cassettes, Assortment boxes and Magazines; Parts, replacement parts and accessories for the aforesaid goods, All the aforesaid goods included in this class. Retailing and wholesaling, Including via teleshopping programmes, Online and catalogue mail order, in relation to the following goods: Construction articles, DIY articles, Tools, Construction articles, Trade articles, Garden article, Measuring apparatus, Meters and gauges; Presentation of goods offers, in the following fields: Construction articles, DIY articles, Tools, Construction articles, Trade articles, Garden article, Measuring apparatus, Meters and gauges; Publication of printed matter (including in electronic form), for advertising purposes; Presentation of goods on communications media for wholesale and retail purposes; Auctioneering, including on the Internet; Arranging of commercial transactions, for others, includng within the framework of e-commerce; Arranging of contracts for others for the buying and selling of goods.

Goods & Services

Measuring apparatus and instruments; Squares for measuring, Angle irons for marking; Rods (surveying instruments); Rules [measuring instruments] and Dial indicators; Displacement gauges and protractors (measuring instruments); Angle bevels (measuring instruments); Gauges, In particular contour gauges; Spirit levels; Rulers [measuring instruments]; Storage containers adapted for the aforesaid goods, in particular cases, Bags, boxes, Cassettes, Assortment boxes and Magazines; Parts, replacement parts and accessories for the aforesaid goods, All the aforesaid goods included in this class. Retailing and wholesaling, Including via teleshopping programmes, Online and catalogue mail order, in relation to the following goods: Construction articles, DIY articles, Tools, Construction articles, Trade articles, Garden article, Measuring apparatus, Meters and gauges; Presentation of goods offers, in the following fields: Construction articles, DIY articles, Tools, Construction articles, Trade articles, Garden article, Measuring apparatus, Meters and gauges; Publication of printed matter (including in electronic form), for advertising purposes; Presentation of goods on communications media for wholesale and retail purposes; Auctioneering, including on the Internet; Arranging of commercial transactions, for others, includng within the framework of e-commerce; Arranging of contracts for others for the buying and selling of goods.

Abstract

A device for enlarging a hole with a frustoconical base body that can be inserted into a hole of a workpiece, and has an insertion opening for inserting a pilot drill of a hole saw. The frustoconical shell surface of the base body has a self-tapping thread, which can engage into the wall of the hole to be enlarged. A screwdriver is provided to apply the correspondingly large torque.

IPC Classes  ?

• B23B 41/06 - Boring or drilling machines or devices specially adapted for particular workAccessories specially adapted therefor for boring conical holes
• B23B 51/04 - Tools for drilling machines for trepanning

Abstract

A cutting device, including a frame, a cutting blade, which is fastened to the frame for pivoting about a first pivot axis, and a reduction transmission, which converts each forward pivoting movement of a plurality of successively performed forward pivoting movements and backward pivoting movements of a drive arm into a cutting pivoting movement of the cutting blade. A cutting-blade back-pivoting apparatus is provided, by which the cutting blade can be pivoted back from a pivoting end position to an initial position. The back-pivoting apparatus has, in particular, a tension element, which acts on the cutting blade in such a way that a clearance is formed.

IPC Classes  ?

• B26D 1/30 - Cutting through work characterised by the nature or movement of the cutting memberApparatus or machines thereforCutting members therefor involving a cutting member which does not travel with the work having a cutting member moving about an axis with a non-circular cutting member moving about an axis substantially perpendicular to the line of cut with limited pivotal movement to effect cut
• B23D 17/08 - Shearing machines or shearing devices cutting by blades pivoted on a single axis characterised by drives or gearings therefor actuated by hand or foot operated lever mechanism
• B26D 5/10 - Hand or foot actuated means

Goods & Services

Glue for industrial purposes; wood glues. Cleaning, polishing, scouring and abrasive preparations; Cleaning preparations; Abrasive paper, Canvas (abrasive preparations); Buffing compounds. Ironmongery, small items of metal hardware; Storage racks of metal, in particular for storing firewood; Guide rails of metal; Metallic mountings; Screws, nails, clips and staples of metal; Hooks [metal hardware]; Rivets; Cotter pins and spacer wedges of metal; Cramps of metal [crampons]; Strips and spacer strips of metal, Ceiling supports of metal; Metal building materials; Solder wires and welding wires; Empty storage containers of metal, in particular cases, boxes, cassettes, assortment boxes and magazines, all the aforesaid for tools, tool inserts, ironmongery and small items of metal hardware; Packaging containers of metal; Ferrules of metal; Lashing straps and belts of metal for handling loads, including in the form of ratchet straps; Tension bands of metal; Strap-protection plates, of metal, for use in relation to the following goods: lashing straps, Load-bearing straps, Belt tensioners, Tightening straps, Tensioning rubbers and cover expanders; Perforated panel systems, perforated panel hooks and perforated panel holders of metal for the presentation of goods; Dowel strips of metal; Dowel centre points of metal for marking dowel holes; Packaging of metal for hand tools and mechanical tools; Storage containers adapted for the aforesaid goods, In particular cases, Bags, Chests, Coffers, Assortment boxes and magazines; Parts, spare parts and fittings for all the aforesaid goods, included in class 06; Tie-downs of metal, including in the form of ratchet straps and binding strips, and parts, spare parts and accessories therefor, and storage containers adapted therefor, In particular cases, Bags, Chests, Coffers, Assortment boxes and magazines. Mechanical tools; Machines for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Mechanically operated tools and apparatus for mechanical engineering, apparatus construction, tool construction and vehicle construction, electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Hand-operated driving motors intended for stationary installation for driving tools, including accessories (included in class 7); Tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling inserts; Mechanical screwing tools, In particular screwdrivers and screwdriver inserts (bits for mechanical tools), and holders relating thereto; Electrically, pneumatically or compressed-air operated drilling machines and hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; Drill stands and drilling aids for electric drilling machines; Drill chucks for mechanical tools; Drill stands and drilling aids for electric, pneumatic or compressed-air operated drilling machines; Templates (parts of machines), in particular drilling and milling templates; Milling stops; Depth stops for dills (parts of machines); Milling cutters (mechanical tools); Rammers (machines), whetstones (parts of machines); Disc grinders, Backing pads, Grinding wheels, Cut off wheels, Ceramic mounted points (machine parts); Cutting tools being power-operated; Blades [parts of machines]; Electric hole cutters; Electric tile and laminate cutters; Cutters [machines]; Electric strip and edge cutters; Saws (machines), in particular hole saws, circular saws and chain saws; Saw blades and blades for mechanical tools; Chisels for machines; Electric shears; Brushes (parts of machines), in particular wire brushes; Mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; Mechanical clamping, stretching and expanding tools and devices; Mandrels for mechanical tools; Vice clamps (parts of machines); Anchoring aids (parts of machines); Pneumatic tools (parts of machines); Turning and planing machines; electric cartridge guns; Pumps [parts of machines, engines or motors]; Tables for machines; Supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); Planing benches and wood-turning lathes (parts of machines), clamping and work tables being parts of machines; Electric soldering tools, Electrical soldering tools; Cleaning (Machines and apparatus for -), electric; flexible shafts (machine parts); Holders (parts of machines) for all the aforesaid goods; Handles for mechanical tools, in particular telescopic handles; Machine parts, namely abrasive wheels, Backing pads, Abrasive belts, Abrasive strips, sanding pads, Polishing bonnets, Polishers, Rotary cleaning heads; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Compressed-air fittings for air tools; Packaging adapted for mechanically operated tools; Parts, spare parts and fittings for all the aforesaid goods, included in class 07. Manually operated tools; Hand-operated implements for agricultural, horticultural and forestry purposes, for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners (tools); Vices; Clamping jaws for vices; Braces (hand tools), In particular screw clamps, Spring clamps, Ratchet clamps, installation clamps, One-handed bar clamps and Glue presses; Hand-operated screwing tools, In particular screwdrivers and screwdriver inserts (bits for hand-operated tools) and holders relating thereto; Non-electric hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; Drill stands and drilling aids for non-electric drilling machines; Drill chucks for hand tools; Templates, namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Guiding apparatus for drills and hole saws; Milling cutters [hand tools]; Sharpening instruments; Blade sharpening instruments; Hand-operated grinding wheels, grinding plates, cut-off wheels, disc grinders and ceramic mounted points; Grinders (hand tools), Abrading instruments [hand instruments]; Cutlery; Cutting tools [hand tools]; Glass cutters; Blades [hand tools], Box cutters and Scissors; Scrapers [hand tools]; Mitre boxes, Edgers, Cutters; Blades (parts of hand tools); Hand-operated hole cutters; Non-electric tile and laminate cutters; Cutting aids (hand tools); Non-electric strip and edge cutters; Saws [hand tools]; Saw blades and blades for hand-operated tools; Graving tools [hand tools], In particular including bits; Mixers (inserts for hand tools), in particular paint mixers, mortar mixers, adhesive mixers; Hand-operated clamping, stretching and expanding tools and devices, in particular belt tensioners, Frame tensioners, Angle clamps, clamp jaws, Quick-release straps; Expanders for hand tools; Dowelling apparatus and anchoring aids (hand-operated tools); Planes; cartridge guns [hand tools]; Hand pumps; Pulling irons; Trowels (tools), in particular brick trowels; Putty knives, tackers; Mitre boxes [hand tools]; Pliers, in particular riveting pliers; Rasps and files (hand tools); Squares [hand tools]; Angle bevels (hand tools); Spanners [hand tools]; Spacers (hand tools); Hand-operated striking tools, in particular bats; Handles for hand tools, In particular telescopic handles; Holders for all the aforesaid goods; Dies and inserts for all of the aforesaid goods; Hand held tools, Namely abrasive wheels, Backing pads, Grinding belts, Abrasive strips, sanding pads, Polishing bonnets, Polishing and buffing discs, Polishing heads; Scribers (tools); Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Wire brushes [hand-operated tools]; Packaging adapted for hand-operated tools; Parts, spare parts and fittings for all the aforesaid goods, included in class 08; Non-electric welding and soldering tools and parts, spare parts and accessories therefor, and storage containers adapted therefor, In particular suitcases, Spike bags, Boxes, Cassettes, Assortment boxes and magazines; Belt tensioners [hand tools] of metal and parts, spare parts and accessories therefor, and storage containers adapted therefor, In particular suitcases, Spike bags, Boxes, Cassettes, Assortment boxes and magazines; Belt tensioners [hand tools] not of metal, parts, replacement parts and fittings therefor, and storage containers adapted therefor, In particular suitcases, Spike bags, Boxes, Cassettes, Assortment boxes and magazines. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Measuring apparatus and instruments, In particular height gauges, Rules [measuring instruments] and Dial indicators; Displacement gauges and protractors (measuring instruments); Angle bevels (measuring instruments); Gauges, In particular contour gauges; Spirit levels; Rulers [measuring instruments]; Safety goggles, Welding goggles; Protective masks, Respiratory masks and Protective mouth masks, in particular fine dust masks and half-masks; Filters for protective masks, respiratory masks and protective mouth masks; Head protection, Gloves for protection; Protective workwear, In particular disposable protective and safety clothing, and disposable protective overshoes; Spectacle cases; Storage containers adapted for the aforesaid goods, in particular cases, Bags, boxes, Cassettes, Assortment boxes and Magazines; Laminate fitters being measuring instruments; Dowel strips being measuring tools; Parts, replacement parts and accessories for the aforesaid goods, included in class 9; Electronic publications, downloadable. Ear protection devices (ear plugs); Parts, spare parts and accessories for the aforesaid goods included in class 10. Electric torches, especially pocket torches; Suction cups for changing lighting devices; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Parts, spare parts and accessories for all the aforesaid goods, included in class 11. Apparatus for locomotion by land, In particular handling carts, Two-wheeled trolleys and Push trolleys; Luggage nets for vehicles and vehicle trailers; Parts and spare parts for all the aforesaid goods, included in class 12. Paper, Millboard Fiberboard boxes; Plastic materials for packing (not included in other classes); Bags [envelopes, pouches] of paper or plastics, for packaging; Packaging of paper or plastic for hand-operated and/or mechanically operated tools; Cardboard and/or cardboard packaging for presenting goods; Paint brushes, paint rollers; Painters' brushes; Painting templates; Garden waste bags of plastic; Glue for stationery or household purposes; Printed matter, in particular catalogues; Stencil plates, Namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Parts, spare parts and fittings for all the aforesaid goods, included in class 16. Plastic film, not for wrapping; Protective sheaths of plastic films; Adhesive bands, other than stationery and not for medical or household purposes; Slip-resistant, rubber-coated plastic pads being workpiece stops. Bags (empty), in particular tool bags and tool belt bags of textile, plastic, leather or a combination of these materials; Empty cases, in particular tool chests; Empty leather cases; Parts, spare parts and fittings for all the aforesaid goods, included in class 18. Manufactured timber, In particular small parts of wood; Building material (non-metallic); Strips and spacer strips, not of metal; Ceiling supports, not of metal, strips of wood for construction purposes. Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches, not of metal, planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); Supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); Storage racks, not of metal, for storing firewood; Merchandise displays for displaying goods; Showcases for presenting goods; Non-metallic tracks; Fasteners, non-metallic; Cotter pins and spacer wedges, not of metal; Crampons, not of metal (cramps); Troughs of plastic for mixing mortar; Strips of wood for frames; Pegs of wood, Pins of wood; Empty storage containers, not of metal; Empty storage containers, not of metal, in particular cases, boxes, cassettes, assortment boxes and magazines for tools, tool inserts, ironmongery and small items of metal hardware; Packaging containers not of metal; Dowel centre points for marking dowel holes; Clips of plastic for cables and plants; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Plaster mixing bowls, not of metal; Parts, spare parts and fittings for all the aforesaid goods, included in class 20; vice benches of metal, Parts, replacement parts and accessories for the aforesaid goods. Sponges; Steelwool; Hand-operated cleaning implements; Brushes; Electric brushes, except parts of machines; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Parts, spare parts and fittings for the aforesaid goods, included in class 21. Tarpaulins; Lashing straps and belts, not of metal, for handling loads, including in the form of ratchet straps; Tension bands, not of metal; Tensioning rubbers and cover expanders; Strap-protection plates, not of metal, for use in relation to the following goods: Chain hoists, Load-bearing straps, Belt tensioners, Tightening straps, Tensioning rubbers and cover expanders; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Parts, replacement parts and accessories for the aforesaid goods, included in class 22; Tensioning rubbers and parts, spare parts and accessories therefor, and storage containers adapted therefor, in particular cases, bags, chests, cassettes, assortment boxes and magazines; Tie-downs, not of metal, including in the form of ratchet straps and binding strips, and parts, spare parts and accessories therefor, and storage containers adapted therefor, in particular cases, bags, chests, cassettes, assortment boxes and magazines. Baseball caps; Disposable apparel; Clothing, footwear, headgear. Hook-and-loop straps, including self-adhesive, including in particular for fixing, bundling and retaining cables and for tethering plants. Mats, In particular non-slip mats, including for fixing loads. Retailing and wholesaling, Including via teleshopping programmes, Online mail order services, Catalogue mail order services, in relation to the following fields: Construction articles, DIY articles, Tools, Construction articles, Trade articles, Garden article, Craft supplies, Personal occupational safety equipment and clothing; Presentation of offers for goods in the fields of construction and DIY articles and other consumer goods for the professional and DIY sector, machines, tools and goods of metal, construction, craft and garden articles, hobby requisites and craft supplies, personal work safety equipment and clothing; Publication of printed matter (including in electronic form), for advertising purposes; Presentation of goods on communications media for wholesale and retail purposes; Auctioneering, including on the Internet; Arranging of commercial transactions, for others, includng within the framework of e-commerce; Arranging of contracts for others for the buying and selling of goods.

Goods & Services

Ironmongery, small items of metal hardware; Storage racks of metal, in particular for storing firewood; Guide rails of metal; Metallic mountings; Screws, nails, clips and staples of metal; Hooks [metal hardware]; Rivets; Cotter pins and spacer wedges of metal; Cramps of metal [crampons]; Strips and spacer strips of metal, Ceiling supports of metal; Metal building materials; Solder wires and welding wires; Empty storage containers of metal, in particular cases, boxes, cassettes, assortment boxes and magazines, all the aforesaid for tools, tool inserts, ironmongery and small items of metal hardware; Packaging containers of metal; Ferrules of metal; lashing straps and Load-bearing straps, of metal, namely, Ratchet belts, Tightening straps, of metal; Strap-protection plates, of metal, for use in relation to the following goods: lashing straps, Load-bearing straps, Belt tensioners, Tightening straps, Tensioning rubbers and cover expanders; Perforated panel systems, perforated panel hooks and perforated panel holders of metal for the presentation of goods; Dowel strips of metal; Dowel centre points of metal for marking dowel holes; Packaging of metal for hand tools and mechanical tools; Storage containers adapted for the aforesaid goods, In particular cases, Bags, Chests, Coffers, Assortment boxes and magazines; Parts, spare parts and fittings for all the aforesaid goods, included in class 06. Mechanical tools; Machines for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Mechanically operated tools and apparatus for mechanical engineering, apparatus construction, tool construction and vehicle construction, electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Hand-operated driving motors intended for stationary installation for driving tools, including accessories (included in class 7); Tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling inserts; Mechanical screwing tools, In particular screwdrivers and screwdriver inserts (bits for mechanical tools), and holders relating thereto; Electrically, pneumatically or compressed-air operated drilling machines and hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; Drill stands and drilling aids for electric drilling machines; Drill chucks for mechanical tools; Drill stands and drilling aids for electric, pneumatic or compressed-air operated drilling machines; Templates (parts of machines), in particular drilling and milling templates; Milling stops; Depth stops for dills (parts of machines); Milling cutters (mechanical tools); Rammers (machines), whetstones (parts of machines); Machine parts, namely, Disc grinders, Backing pads, Grinding wheels, Cut off wheels, Abrasive pencils of ceramic; Cutting tools being power-operated; Blades [parts of machines]; Electric hole cutters; Electric tile and laminate cutters; Cutters [machines]; Electric strip and edge cutters; Saws (machines), in particular hole saws, circular saws and chain saws; Saw blades and blades for mechanical tools; Chisels for machines; Electric shears; Brushes (parts of machines), in particular wire brushes; Mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; Mechanical clamping, stretching and expanding tools and devices; Mandrels for mechanical tools; Vice clamps (parts of machines); Anchoring aids (parts of machines); Pneumatic tools (parts of machines); Turning and planing machines; electric cartridge guns; Pumps [parts of machines, engines or motors]; Tables for machines; Supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); Planing benches and wood-turning lathes (parts of machines), clamping and work tables being parts of machines; Electric soldering tools, Electrical soldering tools; Cleaning (Machines and apparatus for -), electric; flexible shafts (machine parts); Holders (parts of machines) for all the aforesaid goods; Handles for mechanical tools, in particular telescopic handles; Machine parts, namely abrasive wheels, Backing pads, Abrasive belts, Abrasive strips, sanding pads, Polishing bonnets, Polishers, Rotary cleaning heads; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Compressed-air fittings for air tools; Packaging adapted for mechanically operated tools; Parts, spare parts and fittings for all the aforesaid goods, included in class 07. Manually operated tools; Hand-operated implements for agricultural, horticultural and forestry purposes, for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners (tools); Vices; Clamping jaws for vices; Braces (hand tools), In particular screw clamps, Spring clamps, Ratchet clamps, installation clamps, One-handed bar clamps and Glue presses; Hand-operated screwing tools, In particular screwdrivers and screwdriver inserts (bits for hand-operated tools) and holders relating thereto; Non-electric hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; Drill stands and drilling aids for non-electric drilling machines; Drill chucks for hand tools; Templates, namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Guiding apparatus for drills and hole saws; Milling cutters [hand tools]; Sharpening instruments; Blade sharpening instruments; Hand-operated grinding wheels, grinding plates, cut-off wheels, disc grinders and ceramic mounted points; Grinders (hand tools), Abrading instruments [hand instruments]; Cutlery; Cutting tools [hand tools]; Glass cutters; Blades [hand tools], Box cutters and Scissors; Scrapers [hand tools]; Mitre boxes, Edgers, Cutters; Blades (parts of hand tools); Hand-operated hole cutters; Non-electric tile and laminate cutters; Cutting aids (hand tools); Non-electric strip and edge cutters; Saws [hand tools]; Saw blades and blades for hand-operated tools; Graving tools [hand tools], In particular including bits; Mixers (inserts for hand tools), in particular paint mixers, mortar mixers, adhesive mixers; Hand-operated clamping, stretching and expanding tools and devices, in particular belt tensioners, Frame tensioners, Angle clamps, clamp jaws, Quick-release straps; Expanders for hand tools; Dowelling apparatus and anchoring aids (hand-operated tools); Planes; cartridge guns [hand tools]; Hand pumps; Pulling irons; Trowels (tools), in particular brick trowels; Putty knives, tackers; Mitre boxes [hand tools]; Pliers, in particular riveting pliers; Rasps and files (hand tools); Squares [hand tools]; Angle bevels (hand tools); Spanners [hand tools]; Spacers (hand tools); Hand-operated striking tools, in particular bats; Handles for hand tools, In particular telescopic handles; Holders for all the aforesaid goods; Dies and inserts for all of the aforesaid goods; Hand held tools, Namely abrasive wheels, Backing pads, Grinding belts, Abrasive strips, sanding pads, Polishing bonnets, Polishing and buffing discs, Polishing heads; Scribers (tools); Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Wire brushes [hand-operated tools]; Packaging adapted for hand-operated tools; Parts, spare parts and fittings for all the aforesaid goods, included in class 08; Belt tensioners [hand tools] of metal and parts, spare parts and accessories therefor, and storage containers adapted therefor, In particular suitcases, Spike bags, Boxes, Cassettes, Assortment boxes and magazines; Non-electric welding and soldering tools and parts, spare parts and accessories therefor, and storage containers adapted therefor, In particular suitcases, Spike bags, Boxes, Cassettes, Assortment boxes and magazines. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Measuring apparatus and instruments, In particular height gauges, Rules [measuring instruments] and Dial indicators; Displacement gauges and protractors (measuring instruments); Angle bevels (measuring instruments); Gauges, In particular contour gauges; Spirit levels; Rulers [measuring instruments]; Safety goggles, Welding goggles; Protective masks, Respiratory masks and Protective mouth masks, in particular fine dust masks and half-masks; Filters for protective masks, respiratory masks and protective mouth masks; Head protection, Gloves for protection; Protective workwear, In particular disposable protective and safety clothing, and disposable protective overshoes; Spectacle cases; Storage containers adapted for the aforesaid goods, in particular cases, Bags, boxes, Cassettes, Assortment boxes and Magazines; Laminate fitters being measuring instruments; Dowel strips being measuring tools; Parts, replacement parts and accessories for the aforesaid goods, included in class 9; Electronic publications, downloadable. Apparatus for locomotion by land, In particular handling carts, Two-wheeled trolleys and Push trolleys; Luggage nets for vehicles and vehicle trailers; Parts and spare parts for all the aforesaid goods, included in class 12. Paper, Millboard Fiberboard boxes; Plastic materials for packing (not included in other classes); Bags [envelopes, pouches] of paper or plastics, for packaging; Packaging of paper or plastic for hand-operated and/or mechanically operated tools; Cardboard and/or cardboard packaging for presenting goods; Paint brushes, paint rollers; Painters' brushes; Painting templates; Garden waste bags of plastic; Glue for stationery or household purposes; Printed matter, in particular catalogues; Stencil plates, Namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Parts, spare parts and fittings for all the aforesaid goods, included in class 16. Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches, not of metal, planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); Supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); Storage racks, not of metal, for storing firewood; Merchandise displays for displaying goods; Showcases for presenting goods; Non-metallic tracks; Fasteners, non-metallic; Cotter pins and spacer wedges, not of metal; Crampons, not of metal (cramps); Troughs of plastic for mixing mortar; Strips of wood for frames; Pegs of wood, Pins of wood; Empty storage containers, not of metal; Empty storage containers, not of metal, in particular cases, boxes, cassettes, assortment boxes and magazines for tools, tool inserts, ironmongery and small items of metal hardware; Packaging containers not of metal; Dowel centre points for marking dowel holes; Clips of plastic for cables and plants; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Plaster mixing bowls, not of metal; Parts, spare parts and fittings for all the aforesaid goods, included in class 20; vice benches of metal, Parts, replacement parts and accessories for the aforesaid goods. Tie-downs, not of metal, including in the form of ratchet straps and binding strips, and parts, spare parts and accessories therefor, and storage containers adapted therefor, in particular cases, bags, chests, cassettes, assortment boxes and magazines. Retailing and wholesaling, Including via teleshopping programmes and Online and catalogue mail order, in relation to the following goods: Construction and do-it-yourself articles, Tools, Construction, craft and garden articles, Craft supplies, Personal occupational safety equipment and clothing; Presentation of offers for goods in the fields of construction and DIY articles and other consumer goods for the professional and DIY sector, machines, tools and goods of metal, construction, craft and garden articles, hobby requisites and craft supplies, personal work safety equipment and clothing; Publication of printed matter (including in electronic form), for advertising purposes; Presentation of goods on communications media for wholesale and retail purposes; Auctioneering, including on the Internet; Arranging of commercial transactions, for others, includng within the framework of e-commerce; Arranging of contracts for others for the buying and selling of goods.

Goods & Services

Glue for industrial purposes; wood glues. Cleaning, polishing, scouring and abrasive preparations; Cleaning preparations; Abrasive paper, Canvas (abrasive preparations); Buffing compounds. Ironmongery, small items of metal hardware; Storage racks of metal, in particular for storing firewood; Guide rails of metal; Metallic mountings; Screws, nails, clips and staples of metal; Hooks [metal hardware]; Rivets; Cotter pins and spacer wedges of metal; Cramps of metal [crampons]; Strips and spacer strips of metal, Ceiling supports of metal; Metal building materials; Solder wires and welding wires; Empty storage containers of metal, in particular cases, boxes, cassettes, assortment boxes and magazines, all the aforesaid for tools, tool inserts, ironmongery and small items of metal hardware; Packaging containers of metal; Ferrules of metal; Lashing straps and belts of metal for handling loads, including in the form of ratchet straps; Tension bands of metal; Strap-protection plates, of metal, for use in relation to the following goods: lashing straps, Load-bearing straps, Belt tensioners, Tightening straps, Tensioning rubbers and cover expanders; Perforated panel systems, perforated panel hooks and perforated panel holders of metal for the presentation of goods; Dowel strips of metal; Dowel centre points of metal for marking dowel holes; Packaging of metal for hand tools and mechanical tools; Storage containers adapted for the aforesaid goods, In particular cases, Bags, Chests, Coffers, Assortment boxes and magazines; Parts, spare parts and fittings for all the aforesaid goods, included in class 06; Tie-downs of metal, including in the form of ratchet straps and binding strips, and parts, spare parts and accessories therefor, and storage containers adapted therefor, In particular cases, Bags, Chests, Coffers, Assortment boxes and magazines. Mechanical tools; Machines for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Mechanically operated tools and apparatus for mechanical engineering, apparatus construction, tool construction and vehicle construction, electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Hand-operated driving motors intended for stationary installation for driving tools, including accessories (included in class 7); Tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling inserts; Mechanical screwing tools, In particular screwdrivers and screwdriver inserts (bits for mechanical tools), and holders relating thereto; Electrically, pneumatically or compressed-air operated drilling machines and hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; Drill stands and drilling aids for electric drilling machines; Drill chucks for mechanical tools; Drill stands and drilling aids for electric, pneumatic or compressed-air operated drilling machines; Templates (parts of machines), in particular drilling and milling templates; Milling stops; Depth stops for dills (parts of machines); Milling cutters (mechanical tools); Rammers (machines), whetstones (parts of machines); Machine parts, namely, Disc grinders, Backing pads, Grinding wheels, Cut off wheels, Abrasive pencils of ceramic; Cutting tools being power-operated; Blades [parts of machines]; Electric hole cutters; Electric tile and laminate cutters; Cutters [machines]; Electric strip and edge cutters; Saws (machines), in particular hole saws, circular saws and chain saws; Saw blades and blades for mechanical tools; Chisels for machines; Electric shears; Brushes (parts of machines), in particular wire brushes; Mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; Mechanical clamping, stretching and expanding tools and devices; Mandrels for mechanical tools; Vice clamps (parts of machines); Anchoring aids (parts of machines); Pneumatic tools (parts of machines); Turning and planing machines; electric cartridge guns; Pumps [parts of machines, engines or motors]; Tables for machines; Supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); Planing benches and wood-turning lathes (parts of machines), clamping and work tables being parts of machines; Electric soldering and welding tools; Cleaning (Machines and apparatus for -), electric; flexible shafts (machine parts); Holders (parts of machines) for all the aforesaid goods; Handles for mechanical tools, in particular telescopic handles; Machine parts, namely abrasive wheels, Backing pads, Abrasive belts, Abrasive strips, sanding pads, Polishing bonnets, Polishers, Rotary cleaning heads; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Compressed-air fittings for air tools; Packaging adapted for mechanically operated tools; Parts, spare parts and fittings for all the aforesaid goods, included in class 07. Manually operated tools; Hand-operated implements for agricultural, horticultural and forestry purposes, for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners (tools); Vices; Clamping jaws for vices; Braces (hand tools), In particular screw clamps, Spring clamps, Ratchet clamps, installation clamps, One-handed bar clamps and Glue presses; Hand-operated screwing tools, In particular screwdrivers and screwdriver inserts (bits for hand-operated tools) and holders relating thereto; Non-electric hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; Drill stands and drilling aids for non-electric drilling machines; Drill chucks for hand tools; Templates, namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Guiding apparatus for drills and hole saws; Milling cutters [hand tools]; Sharpening instruments; Blade sharpening instruments; Hand-operated grinding wheels, grinding plates, cut-off wheels, disc grinders and ceramic mounted points; Grinders (hand tools), Abrading instruments [hand instruments]; Cutlery; Cutting tools [hand tools]; Glass cutters; Blades [hand tools], Box cutters and Scissors; Scrapers [hand tools]; Mitre boxes, Edgers, Cutters; Blades (parts of hand tools); Hand-operated hole cutters; Non-electric tile and laminate cutters; Cutting aids (hand tools); Non-electric strip and edge cutters; Saws [hand tools]; Saw blades and blades for hand-operated tools; Graving tools [hand tools], In particular including bits; Mixers (inserts for hand tools), in particular paint mixers, mortar mixers, adhesive mixers; Hand-operated clamping, stretching and expanding tools and devices, in particular belt tensioners, Frame tensioners, Angle clamps, clamp jaws, Quick-release straps; Expanders for hand tools; Dowelling apparatus and anchoring aids (hand-operated tools); Planes; cartridge guns [hand tools]; Hand pumps; Pulling irons; Trowels (tools), in particular brick trowels; Putty knives, tackers; Mitre boxes [hand tools]; Pliers, in particular riveting pliers; Rasps and files (hand tools); Squares [hand tools]; Angle bevels (hand tools); Spanners [hand tools]; Spacers (hand tools); Hand-operated striking tools, in particular bats; Handles for hand tools, In particular telescopic handles; Holders for all the aforesaid goods; Dies and inserts for all of the aforesaid goods; Hand held tools, Namely abrasive wheels, Backing pads, Grinding belts, Abrasive strips, sanding pads, Polishing bonnets, Polishing and buffing discs, Polishing heads; Scribers (tools); Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Wire brushes [hand-operated tools]; Packaging adapted for hand-operated tools; Parts, spare parts and fittings for all the aforesaid goods, included in class 08; Non-electric welding and soldering tools and parts, spare parts and accessories therefor, and storage containers adapted therefor, In particular suitcases, Spike bags, Boxes, Cassettes, Assortment boxes and magazines; Belt tensioners [hand tools] of metal and parts, spare parts and accessories therefor, and storage containers adapted therefor, In particular suitcases, Spike bags, Boxes, Cassettes, Assortment boxes and magazines; Belt tensioners [hand tools] of metal, parts, replacement parts and fittings therefor, and storage containers adapted therefor, In particular suitcases, Spike bags, Boxes, Cassettes, Assortment boxes and magazines. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Measuring apparatus and instruments, In particular height gauges, Rules [measuring instruments] and Dial indicators; Displacement gauges and protractors (measuring instruments); Angle bevels (measuring instruments); Gauges, In particular contour gauges; Spirit levels; Rulers [measuring instruments]; Safety goggles, Welding goggles; Protective masks, Respiratory masks and Protective mouth masks, in particular fine dust masks and half-masks; Filters for protective masks, respiratory masks and protective mouth masks; Head protection, Gloves for protection; Protective workwear, In particular disposable protective and safety clothing, and disposable protective overshoes; Spectacle cases; Storage containers adapted for the aforesaid goods, in particular magazines, Suitcases, Bags, boxes, Cassettes and Assortment boxes; Laminate fitters being measuring instruments; Dowel strips being measuring tools; Parts, replacement parts and accessories for the aforesaid goods, included in class 9; Electronic publications, downloadable. Ear protection devices (ear plugs); Parts, spare parts and accessories for the aforesaid goods included in class 10. Electric torches, especially pocket torches; Suction cups for changing lighting devices; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Parts, spare parts and accessories for all the aforesaid goods, included in class 11. Apparatus for locomotion by land, In particular handling carts, Two-wheeled trolleys and Push trolleys; Luggage nets for vehicles and vehicle trailers; Parts and spare parts for all the aforesaid goods, included in class 12. Paper cardboard; Fiberboard boxes; Plastic materials for packing (not included in other classes); Bags [envelopes, pouches] of paper or plastics, for packaging; Packaging of paper or plastic for hand-operated and/or mechanically operated tools; Cardboard and/or cardboard packaging for presenting goods; Paint brushes, paint rollers; Painters' brushes; Painting templates; Garden waste bags of plastic; Glue for stationery or household purposes; Printed matter, in particular catalogues; Stencil plates, Namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Parts, spare parts and fittings for all the aforesaid goods, included in class 16. Plastic film, not for wrapping; Protective sheaths of plastic films; Adhesive bands, other than stationery and not for medical or household purposes; Slip-resistant, rubber-coated plastic pads being workpiece stops. Bags (empty), in particular tool bags and tool belt bags of textile, plastic, leather or a combination of these materials; Empty cases, in particular tool chests; Empty leather cases; Parts, spare parts and fittings for all the aforesaid goods, included in class 18. Manufactured timber, In particular small parts of wood; Building material (non-metallic); Strips and spacer strips, not of metal; Ceiling supports, not of metal, strips of wood for construction purposes. Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches, not of metal, planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); Supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); Storage racks, not of metal, for storing firewood; Merchandise displays for displaying goods; Showcases for presenting goods; Non-metallic tracks; Fasteners, non-metallic; Cotter pins and spacer wedges, not of metal; Crampons, not of metal (cramps); Troughs of plastic for mixing mortar; Strips of wood for frames; Pegs of wood, Pins of wood; Empty storage containers, not of metal; Empty storage containers, not of metal, in particular cases, boxes, cassettes, assortment boxes and magazines for tools, tool inserts, ironmongery and small items of metal hardware; Packaging containers not of metal; Dowel centre points for marking dowel holes; Clips of plastic for cables and plants; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Plaster mixing bowls, not of metal; Parts, spare parts and fittings for all the aforesaid goods, included in class 20; vice benches of metal, Parts, replacement parts and accessories for the aforesaid goods. Sponges; Steelwool; Hand-operated cleaning implements; Brushes; Electric brushes, except parts of machines; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Parts, spare parts and fittings for the aforesaid goods, included in class 21. Tarpaulins; Lashing straps and belts, not of metal, for handling loads, including in the form of ratchet straps; Tension bands, not of metal; Tensioning rubbers and cover expanders; Strap-protection plates, not of metal, for use in relation to the following goods: Chain hoists, Load-bearing straps, Belt tensioners, Tightening straps, Tensioning rubbers and cover expanders; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Parts, replacement parts and accessories for the aforesaid goods, included in class 22; Tensioning rubbers and parts, spare parts and accessories therefor, and storage containers adapted therefor, in particular cases, bags, chests, cassettes, assortment boxes and magazines; Tie-downs, not of metal, including in the form of ratchet straps and binding strips, and parts, spare parts and accessories therefor, and storage containers adapted therefor, in particular cases, bags, chests, cassettes, assortment boxes and magazines. Baseball caps; Disposable apparel; Clothing, footwear, headgear. Hook-and-loop straps, including self-adhesive, including in particular for fixing, bundling and retaining cables and for tethering plants. Mats, In particular non-slip mats, including for fixing loads. Retailing and wholesaling, Including via teleshopping programmes and Online and catalogue mail order, in relation to the following goods: Construction and do-it-yourself articles, Tools, Construction, craft and garden articles, Craft supplies, Personal occupational safety equipment and clothing; Presentation of offers for goods in the fields of construction and DIY articles and other consumer goods for the professional and DIY sector, machines, tools and goods of metal, construction, craft and garden articles, hobby requisites and craft supplies, personal work safety equipment and clothing; Publication of printed matter (including in electronic form), for advertising purposes; Presentation of goods on communications media for wholesale and retail purposes; Auctioneering, including on the Internet; Arranging commercial transactions, for others, including within the framework of e-commerce; Arranging of contracts for others for the buying and selling of goods.

Goods & Services

Mechanical tools; Machines for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Mechanically operated tools and apparatus for mechanical engineering, apparatus construction, tool construction and vehicle construction, electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Hand-operated driving motors intended for stationary installation for driving tools, including accessories (included in class 7); Tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling inserts; Mechanical screwing tools, In particular screwdrivers and screwdriver inserts (bits for mechanical tools), and holders relating thereto; Electrically, pneumatically or compressed-air operated drilling machines and hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; Drill stands and drilling aids for electric drilling machines; Drill chucks for mechanical tools; Drill stands and drilling aids for electric, pneumatic or compressed-air operated drilling machines; Templates (parts of machines), in particular drilling and milling templates; Milling stops; Depth stops for dills (parts of machines); Milling cutters (mechanical tools); Rammers (machines), whetstones (parts of machines); Disc grinders, Backing pads, Grinding wheels, Cut off wheels, Ceramic mounted points (machine parts); Cutting tools being power-operated; Blades [parts of machines]; Electric hole cutters; Electric tile and laminate cutters; Cutters [machines]; Electric strip and edge cutters; Saws (machines), in particular hole saws, circular saws and chain saws; Saw blades and blades for mechanical tools; Chisels for machines; Electric shears; Brushes (parts of machines), in particular wire brushes; Mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; Mechanical clamping, stretching and expanding tools and devices; Mandrels for mechanical tools; Vice clamps (parts of machines); Anchoring aids (parts of machines); Pneumatic tools (parts of machines); Turning and planing machines; electric cartridge guns; Pumps [parts of machines, engines or motors]; Tables for machines; Supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); Planing benches and wood-turning lathes (parts of machines), clamping and work tables being parts of machines; Electric and non-electric soldering and welding tools; Cleaning (Machines and apparatus for -), electric; flexible shafts (machine parts); Holders (parts of machines) for all the aforesaid goods; Handles for mechanical tools, in particular telescopic handles; Machine parts, namely abrasive wheels, Backing pads, Abrasive belts, Abrasive strips, sanding pads, Polishing bonnets, Polishers, Rotary cleaning heads; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Compressed air fittings being parts of compressed air machines; Packaging adapted for mechanically operated tools; Parts, spare parts and fittings for all the aforesaid goods, included in class 07. Manually operated tools; Hand-operated implements for agricultural, horticultural and forestry purposes, for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners (tools); Vices; Clamping jaws for vices; Braces (hand tools), In particular screw clamps, Spring clamps, Ratchet clamps, installation clamps, One-handed bar clamps and Glue presses; Hand-operated screwing tools, In particular screwdrivers and screwdriver inserts (bits for hand-operated tools) and holders relating thereto; Non-electric hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; Drill stands and drilling aids for non-electric drilling machines; Drill chucks for hand tools; Templates, namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Guiding apparatus for drills and hole saws; Milling cutters [hand tools]; Sharpening instruments; Blade sharpening instruments; Hand-operated grinding wheels, grinding plates, cut-off wheels, disc grinders and ceramic mounted points; Grinders (hand tools), Abrading instruments [hand instruments]; Cutlery; Cutting tools [hand tools]; Glass cutters; Blades [hand tools], Box cutters and Scissors; Scrapers [hand tools]; Mitre boxes, Edgers, Cutters; Blades (parts of hand tools); Hand-operated hole cutters; Non-electric tile and laminate cutters; Cutting aids (hand tools); Non-electric strip and edge cutters; Saws [hand tools]; Saw blades and blades for hand-operated tools; Graving tools [hand tools], In particular including bits; Mixers (inserts for hand tools), in particular paint mixers, mortar mixers, adhesive mixers; Hand-operated clamping, stretching and expanding tools and devices, in particular belt tensioners, Frame tensioners, Angle clamps, clamp jaws, Quick-release clamps, tensioning rubbers, lashing belts, including in the form of ratchet straps, and tensioning straps; Expanders for hand tools; Dowelling apparatus and anchoring aids (hand-operated tools); Planes; cartridge guns [hand tools]; Hand pumps; Pulling irons; Trowels (tools), in particular brick trowels; Putty knives, tackers; Mitre boxes [hand tools]; Pliers, in particular riveting pliers; Rasps and files (hand tools); Squares [hand tools]; Angle bevels (hand tools); Spanners [hand tools]; Spacers (hand tools); Hand-operated striking tools, in particular bats; Handles for hand tools, In particular telescopic handles; Holders for all the aforesaid goods; Dies and inserts for all of the aforesaid goods; Hand held tools, Namely abrasive wheels, Backing pads, Grinding belts, Abrasive strips, sanding pads, Polishing bonnets, Polishing and buffing discs, Polishing heads; Scribers (tools); Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Wire brushes [hand-operated tools]; Packaging adapted for hand-operated tools; Parts and replacement parts for the aforesaid goods, Fittings for the aforesaid goods, The aforesaid goods included in class 8. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Measuring apparatus and instruments, In particular height gauges, Rules [measuring instruments] and Dial indicators; Displacement gauges and protractors (measuring instruments); Angle bevels (measuring instruments); Gauges, In particular contour gauges; Spirit levels; Rulers [measuring instruments]; Safety goggles, Welding goggles; Protective masks, Respiratory masks and Protective mouth masks, in particular fine dust masks and half-masks; Filters for protective masks, respiratory masks and protective mouth masks; Head protection, Gloves for protection; Protective workwear, In particular disposable protective and safety clothing, and disposable protective overshoes; Spectacle cases; Storage containers adapted for the aforesaid goods, in particular cases, Bags, boxes, Cassettes, Assortment boxes and Magazines; Laminate fitters being measuring instruments; Dowel strips being measuring tools; Parts, replacement parts and accessories for the aforesaid goods, included in class 9; Electronic publications, downloadable. Apparatus for locomotion by land, In particular handling carts, Two-wheeled trolleys and Push trolleys; Luggage nets for vehicles and vehicle trailers; Parts and spare parts for all the aforesaid goods, included in class 12. Paper cardboard; Fiberboard boxes; Plastic materials for packing (not included in other classes); Bags [envelopes, pouches] of paper or plastics, for packaging; Packaging of paper or plastic for hand-operated and/or mechanically operated tools; Cardboard and/or cardboard packaging for presenting goods; Paint brushes, paint rollers; Painters' brushes; Painting templates; Garden waste bags of plastic; Glue for stationery or household purposes; Printed matter, in particular catalogues; Stencil plates, Namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Parts, spare parts and fittings for all the aforesaid goods, included in class 16. Bags (empty), in particular tool bags and tool belt bags of textile, plastic, leather or a combination of these materials; Empty cases, in particular tool chests; Empty leather cases; Parts and spare parts for all these goods, Accessories for the foregoing, The aforesaid goods included in class 18. Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches, not of metal, planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); Supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); Storage racks, not of metal, for storing firewood; Merchandise displays for displaying goods; Showcases for presenting goods; Non-metallic tracks; Fasteners, non-metallic; Cotter pins and spacer wedges, not of metal; Crampons, not of metal (cramps); Troughs of plastic for mixing mortar; Strips of wood for frames; Pegs of wood, Pins of wood; Empty storage containers, not of metal; Empty storage containers, not of metal, in particular cases, boxes, cassettes, assortment boxes and magazines for tools, tool inserts, ironmongery and small items of metal hardware; Packaging containers not of metal; Dowel centre points for marking dowel holes; Clips of plastic for cables and plants; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Plaster mixing bowls, not of metal; Parts, spare parts and fittings for all the aforesaid goods, included in class 20. Retail and wholesale services, Including via teleshopping programmes, Online mail order services, Catalogue mail order services, in relation to the following fields: Building articles, DIY articles, Tools, Building articles, Trade articles, Garden article, Craft supplies, Personal occupational safety equipment and clothing; Presentation of offers for goods in the fields of construction and DIY articles and other consumer goods for the professional and DIY sector, machines, tools and goods of metal, construction, craft and garden articles, hobby requisites and craft supplies, personal work safety equipment and clothing; Publication of printed matter (including in electronic form), for advertising purposes; Presentation of goods on communications media for wholesale and retail purposes; Auctioneering, including on the Internet; Arranging of commercial transactions, for others, includng within the framework of e-commerce; Arranging of contracts for others for the buying and selling of goods.

Goods & Services

Mechanical tools; Machines for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Mechanically operated tools and apparatus for mechanical engineering, apparatus construction, tool construction and vehicle construction, electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Hand-operated driving motors intended for stationary installation for driving tools, including accessories (included in class 7); Tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling inserts; Mechanical screwing tools, In particular screwdrivers and screwdriver inserts (bits for mechanical tools), and holders relating thereto; Electrically, pneumatically or compressed-air operated drilling machines and hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; Drill stands and drilling aids for electric drilling machines; Drill chucks for mechanical tools; Drill stands and drilling aids for electric, pneumatic or compressed-air operated drilling machines; Templates (parts of machines), in particular drilling and milling templates; Milling stops; Depth stops for dills (parts of machines); Milling cutters (mechanical tools); Rammers (machines), whetstones (parts of machines); Disc grinders, Backing pads, Grinding wheels, Cut off wheels, Ceramic mounted points (machine parts); Cutting tools being power-operated; Blades [parts of machines]; Electric hole cutters; Electric tile and laminate cutters; Cutters [machines]; Electric strip and edge cutters; Saws (machines), in particular hole saws, circular saws and chain saws; Saw blades and blades for mechanical tools; Chisels for machines; Electric shears; Brushes (parts of machines), in particular wire brushes; Mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; Mechanical clamping, stretching and expanding tools and devices; Mandrels for mechanical tools; Vice clamps (parts of machines); Anchoring aids (parts of machines); Pneumatic tools (parts of machines); Turning and planing machines; electric cartridge guns; Pumps [parts of machines, engines or motors]; Tables for machines; Supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); Planing benches and wood-turning lathes (parts of machines), clamping and work tables being parts of machines; Electric and non-electric soldering and welding tools; Cleaning (Machines and apparatus for -), electric; flexible shafts (machine parts); Holders (parts of machines) for all the aforesaid goods; Handles for mechanical tools, in particular telescopic handles; Machine parts, namely abrasive wheels, Backing pads, Abrasive belts, Abrasive strips, sanding pads, Polishing bonnets, Polishers, Rotary cleaning heads; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Compressed air fittings being parts of compressed air machines; Packaging adapted for mechanically operated tools; Parts, spare parts and fittings for all the aforesaid goods, included in class 07. Manually operated tools; Hand-operated implements for agricultural, horticultural and forestry purposes, for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners (tools); Vices; Clamping jaws for vices; Braces (hand tools), In particular screw clamps, Spring clamps, Ratchet clamps, installation clamps, One-handed bar clamps and Glue presses; Hand-operated screwing tools, In particular screwdrivers and screwdriver inserts (bits for hand-operated tools) and holders relating thereto; Non-electric hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; Drill stands and drilling aids for non-electric drilling machines; Drill chucks for hand tools; Templates, namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Guiding apparatus for drills and hole saws; Milling cutters [hand tools]; Sharpening instruments; Blade sharpening instruments; Hand-operated grinding wheels, grinding plates, cut-off wheels, disc grinders and ceramic mounted points; Grinders (hand tools), Abrading instruments [hand instruments]; Cutlery; Cutting tools [hand tools]; Glass cutters; Blades [hand tools], Box cutters and Scissors; Scrapers [hand tools]; Mitre boxes, Edgers, Cutters; Blades (parts of hand tools); Hand-operated hole cutters; Non-electric tile and laminate cutters; Cutting aids (hand tools); Non-electric strip and edge cutters; Saws [hand tools]; Saw blades and blades for hand-operated tools; Graving tools [hand tools], In particular including bits; Mixers (inserts for hand tools), in particular paint mixers, mortar mixers, adhesive mixers; Hand-operated clamping, stretching and expanding tools and devices, in particular belt tensioners, Frame tensioners, Angle clamps, clamp jaws, Quick-release clamps, tensioning rubbers, lashing belts, including in the form of ratchet straps, and tensioning straps; Expanders for hand tools; Dowelling apparatus and anchoring aids (hand-operated tools); Planes; cartridge guns [hand tools]; Hand pumps; Pulling irons; Trowels (tools), in particular brick trowels; Putty knives, tackers; Mitre boxes [hand tools]; Pliers, in particular riveting pliers; Rasps and files (hand tools); Squares [hand tools]; Angle bevels (hand tools); Spanners [hand tools]; Spacers (hand tools); Hand-operated striking tools, in particular bats; Handles for hand tools, In particular telescopic handles; Holders for all the aforesaid goods; Dies and inserts for all of the aforesaid goods; Hand held tools, Namely abrasive wheels, Backing pads, Grinding belts, Abrasive strips, sanding pads, Polishing bonnets, Polishing and buffing discs, Polishing heads; Scribers (tools); Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Wire brushes [hand-operated tools]; Packaging adapted for hand-operated tools; Parts and replacement parts for the aforesaid goods and Fittings for the aforesaid goods, The aforesaid goods included in class 8. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Measuring apparatus and instruments, In particular height gauges, Rules [measuring instruments] and Dial indicators; Displacement gauges and protractors (measuring instruments); Angle bevels (measuring instruments); Gauges, In particular contour gauges; Spirit levels; Rulers [measuring instruments]; Safety goggles, Welding goggles; Protective masks, Respiratory masks and Protective mouth masks, in particular fine dust masks and half-masks; Filters for protective masks, respiratory masks and protective mouth masks; Head protection, Gloves for protection; Protective workwear, In particular disposable protective and safety clothing, and disposable protective overshoes; Spectacle cases; Storage containers adapted for the aforesaid goods, in particular cases, Bags, boxes, Cassettes, Assortment boxes and Magazines; Laminate fitters being measuring instruments; Dowel strips being measuring tools; Parts, replacement parts and accessories for the aforesaid goods, included in class 9; Electronic publications, downloadable. Apparatus for locomotion by land, In particular handling carts, Two-wheeled trolleys and Push trolleys; Luggage nets for vehicles and vehicle trailers; Parts and spare parts for all the aforesaid goods, included in class 12. Paper cardboard; Fiberboard boxes; Plastic materials for packing (not included in other classes); Bags [envelopes, pouches] of paper or plastics, for packaging; Packaging of paper or plastic for hand-operated and/or mechanically operated tools; Cardboard and/or cardboard packaging for presenting goods; Paint brushes, paint rollers; Painters' brushes; Painting templates; Garden waste bags of plastic; Glue for stationery or household purposes; Printed matter, in particular catalogues; Stencil plates, Namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Parts, spare parts and fittings for all the aforesaid goods, included in class 16. Bags (empty), in particular tool bags and tool belt bags of textile, plastic, leather or a combination of these materials; Empty cases, in particular tool chests; Empty leather cases; Parts and spare parts for all these goods, Accessories for the foregoing, The aforesaid goods included in class 18. Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches, not of metal, planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); Supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); Storage racks, not of metal, for storing firewood; Merchandise displays for displaying goods; Showcases for presenting goods; Non-metallic tracks; Fasteners, non-metallic; Cotter pins and spacer wedges, not of metal; Crampons, not of metal (cramps); Troughs of plastic for mixing mortar; Strips of wood for frames; Pegs of wood, Pins of wood; Empty storage containers, not of metal; Empty storage containers, not of metal, in particular cases, boxes, cassettes, assortment boxes and magazines for tools, tool inserts, ironmongery and small items of metal hardware; Packaging containers not of metal; Dowel centre points for marking dowel holes; Clips of plastic for cables and plants; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Plaster mixing bowls, not of metal; Parts, spare parts and fittings for all the aforesaid goods, included in class 20. Retail and wholesale services, Including via teleshopping programmes, Online mail order services, Catalogue mail order services, in relation to the following fields: Building articles, DIY articles, Tools, Building articles, Trade articles, Garden article, Craft supplies, Personal occupational safety equipment and clothing; Presentation of offers for goods in the fields of construction and DIY articles and other consumer goods for the professional and DIY sector, machines, tools and goods of metal, construction, craft and garden articles, hobby requisites and craft supplies, personal work safety equipment and clothing; Publication of printed matter (including in electronic form), for advertising purposes; Presentation of goods on communications media for wholesale and retail purposes; Auctioneering, including on the Internet; Arranging of commercial transactions, for others, includng within the framework of e-commerce; Arranging of contracts for others for the buying and selling of goods.

Goods & Services

Mechanical tools; Machines for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Mechanically operated tools and apparatus for mechanical engineering, apparatus construction, tool construction and vehicle construction, electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Hand-operated driving motors intended for stationary installation for driving tools, including accessories (included in class 7); Tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling inserts; Mechanical screwing tools, In particular screwdrivers and screwdriver inserts (bits for mechanical tools), and holders relating thereto; Electrically, pneumatically or compressed-air operated drilling machines and hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; Drill stands and drilling aids for electric drilling machines; Drill chucks for mechanical tools; Drill stands and drilling aids for electric, pneumatic or compressed-air operated drilling machines; Templates (parts of machines), in particular drilling and milling templates; Milling stops; Depth stops for dills (parts of machines); Milling cutters (mechanical tools); Rammers (machines), whetstones (parts of machines); Disc grinders, Backing pads, Grinding wheels, Cut off wheels, Ceramic mounted points (machine parts); Cutting tools being power-operated; Blades [parts of machines]; Electric hole cutters; Electric tile and laminate cutters; Cutters [machines]; Electric strip and edge cutters; Saws (machines), in particular hole saws, circular saws and chain saws; Saw blades and blades for mechanical tools; Chisels for machines; Electric shears; Brushes (parts of machines), in particular wire brushes; Mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; Mechanical clamping, stretching and expanding tools and devices; Mandrels for mechanical tools; Vice clamps (parts of machines); Anchoring aids (parts of machines); Pneumatic tools (parts of machines); Turning and planing machines; electric cartridge guns; Pumps [parts of machines, engines or motors]; Tables for machines; Supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); Planing benches and wood-turning lathes (parts of machines), clamping and work tables being parts of machines; Electric and non-electric soldering and welding tools; Cleaning (Machines and apparatus for -), electric; flexible shafts (machine parts); Holders (parts of machines) for all the aforesaid goods; Handles for mechanical tools, in particular telescopic handles; Machine parts, namely abrasive wheels, Backing pads, Abrasive belts, Abrasive strips, sanding pads, Polishing bonnets, Polishers, Rotary cleaning heads; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Compressed air fittings in the form of compressed air apparatus, packaging adapted for mechanically operated tools; Parts, spare parts and fittings for all the aforesaid goods, included in class 07. Manually operated tools; Hand-operated implements for agricultural, horticultural and forestry purposes, for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners (tools); Vices; Clamping jaws for vices; Braces (hand tools), In particular screw clamps, Spring clamps, Ratchet clamps, installation clamps, One-handed bar clamps and Glue presses; Hand-operated screwing tools, In particular screwdrivers and screwdriver inserts (bits for hand-operated tools) and holders relating thereto; Non-electric hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; Drill stands and drilling aids for non-electric drilling machines; Drill chucks for hand tools; Templates, namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Guiding apparatus for drills and hole saws; Milling cutters [hand tools]; Sharpening instruments; Blade sharpening instruments; Hand-operated grinding wheels, grinding plates, cut-off wheels, disc grinders and ceramic mounted points; Grinders (hand tools), Abrading instruments [hand instruments]; Cutlery; Cutting tools [hand tools]; Glass cutters; Blades [hand tools], Box cutters and Scissors; Scrapers [hand tools]; Mitre boxes, Edgers, Cutters; Blades (parts of hand tools); Hand-operated hole cutters; Non-electric tile and laminate cutters; Cutting aids (hand tools); Non-electric strip and edge cutters; Saws [hand tools]; Saw blades and blades for hand-operated tools; Graving tools [hand tools], In particular including bits; Mixers (inserts for hand tools), in particular paint mixers, mortar mixers, adhesive mixers; Hand-operated clamping, stretching and expanding tools and devices, in particular belt tensioners, Frame tensioners, Angle clamps, clamp jaws, Quick-release clamps, tensioning rubbers, lashing belts, including in the form of ratchet straps, and tensioning straps; Expanders for hand tools; Dowelling apparatus and anchoring aids (hand-operated tools); Planes; cartridge guns [hand tools]; Hand pumps; Pulling irons; Trowels (tools), in particular brick trowels; Putty knives, tackers; Mitre boxes [hand tools]; Pliers, in particular riveting pliers; Rasps and files (hand tools); Squares [hand tools]; Angle bevels (hand tools); Spanners [hand tools]; Spacers (hand tools); Hand-operated striking tools, in particular bats; Handles for hand tools, In particular telescopic handles; Holders for all the aforesaid goods; Dies and inserts for all of the aforesaid goods; Hand held tools, Namely abrasive wheels, Backing pads, Grinding belts, Abrasive strips, sanding pads, Polishing bonnets, Polishing and buffing discs, Polishing heads; Scribers (tools); Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Wire brushes [hand-operated tools]; Packaging adapted for hand-operated tools; Parts, spare parts and fittings for all the aforesaid goods, included in class 08. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Measuring apparatus and instruments, In particular height gauges, Rules [measuring instruments] and Dial indicators; Displacement gauges and protractors (measuring instruments); Angle bevels (measuring instruments); Gauges, In particular contour gauges; Spirit levels; Rulers [measuring instruments]; Safety goggles, Welding goggles; Protective masks, Respiratory masks and Protective mouth masks, in particular fine dust masks and half-masks; Filters for protective masks, respiratory masks and protective mouth masks; Head protection, Gloves for protection; Protective workwear, In particular disposable protective and safety clothing, and disposable protective overshoes; Spectacle cases; Storage containers adapted for the aforesaid goods, in particular cases, Bags, boxes, Cassettes, Assortment boxes and Magazines; Laminate fitters being measuring instruments; Dowel strips being measuring tools; Parts, replacement parts and accessories for the aforesaid goods, included in class 9; Electronic publications, downloadable. Apparatus for locomotion by land, In particular handling carts, Two-wheeled trolleys and Push trolleys; Luggage nets for vehicles and vehicle trailers; Parts and spare parts for all the aforesaid goods, included in class 12. Paper cardboard; Fiberboard boxes; Plastic materials for packing (not included in other classes); Bags [envelopes, pouches] of paper or plastics, for packaging; Packaging of paper or plastic for hand-operated and/or mechanically operated tools; Cardboard and/or cardboard packaging for presenting goods; Paint brushes, paint rollers; Painters' brushes; Painting templates; Garden waste bags of plastic; Glue for stationery or household purposes; Printed matter, in particular catalogues; Stencil plates, Namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Parts, spare parts and fittings for all the aforesaid goods, included in class 16. Bags (empty), in particular tool bags and tool belt bags of textile, plastic, leather or a combination of these materials; Empty cases, in particular tool chests; Empty leather cases; Parts, spare parts and fittings for all the aforesaid goods, included in class 18. Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches, not of metal, planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); Supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); Storage racks, not of metal, for storing firewood; Merchandise displays for displaying goods; Showcases for presenting goods; Non-metallic tracks; Fasteners, non-metallic; Cotter pins and spacer wedges, not of metal; Crampons, not of metal (cramps); Troughs of plastic for mixing mortar; Strips of wood for frames; Pegs of wood, Pins of wood; Empty storage containers, not of metal; Empty storage containers, not of metal, in particular cases, boxes, cassettes, assortment boxes and magazines for tools, tool inserts, ironmongery and small items of metal hardware; Packaging containers not of metal; Dowel centre points for marking dowel holes; Clips of plastic for cables and plants; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Plaster mixing bowls, not of metal; Parts, spare parts and fittings for all the aforesaid goods, included in class 20. Retail and wholesale services, Including via teleshopping programmes, Online mail order services, Catalogue mail order services, in relation to the following fields: Building articles, DIY articles, Tools, Building articles, Trade articles, Garden article, Craft supplies, Personal occupational safety equipment and clothing; Presentation of offers for goods in the fields of construction and DIY articles and other consumer goods for the professional and DIY sector, machines, tools and goods of metal, construction, craft and garden articles, hobby requisites and craft supplies, personal work safety equipment and clothing; Publication of printed matter (including in electronic form), for advertising purposes; Presentation of goods on communications media for wholesale and retail purposes; Auctioneering, including on the Internet; Arranging of commercial transactions, for others, includng within the framework of e-commerce; Arranging of contracts for others for the buying and selling of goods.

Abstract

The invention relates to a clamping tool with a device for generating a clamping position, in which two clamping elements (3, 4) apply a clamping force to a workpiece, the counterforce of which is taken up by a connection member (1) connecting the clamping elements (3, 4) to one another, with an element that deforms under generation of the clamping force (K), and with a sensor element (5), which converts the deformation of the deformable element into an electrical signal which can be used to determine the value of the clamping force (K). In accordance with the invention the deformable element is formed by a blocking element (2) which acts as a push-back block and above which one of the clamping elements (4) is supported on the connection member (1) in the clamping position.

IPC Classes  ?

• B25B 5/06 - Arrangements for positively actuating jaws
• B25B 5/16 - Details, e.g. jaws, jaw attachments

Abstract

A piston assembly including a piston for a cartridge discharging device for discharging a pasty compound out of a cartridge which has an inner wall, having a piston and a rear face which can be acted upon by a pressure plate secured to a push rod, a front face opposite the rear face, and a retaining element which secures the pressure plate against the rear face by a retaining protrusion which covers an edge of the pressure plate in a retaining position. The retaining protrusion is secured to the piston in a movable manner into a release position in a direction away from the push rod.

IPC Classes  ?

• B05C 17/005 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure
• B05C 17/01 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure with mechanically or electrically actuated piston or the like
• B65D 83/00 - Containers or packages with special means for dispensing contents

Abstract

The invention relates to a device for enlarging a hole (21), comprising a truncated conical main part (1) which can be inserted into a hole (21) of a workpiece (20) and which has an insertion opening (5) for inserting a pilot bore (19) of a hole saw (17). The aim of the invention is to develop the drilling aid so as to be advantageous for use. This is achieved in that the truncated conical lateral surface (2) of the main part (1) has a self-tapping thread which can engage into the wall of the hole (21) to be enlarged. A screwing tool (9) is provided for applying a torque of a corresponding magnitude.

IPC Classes  ?

• B23B 51/04 - Tools for drilling machines for trepanning
• B23B 49/02 - Boring templates or bushings

Goods & Services

Guide rails of metal; parts and accessories for all the aforesaid goods, included in this class. Tables for machines; supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); work benches and turning lathes [parts of machines]; clamping tables being parts of machines; worktables being parts of machines; working tables being parts of machines; saw benches being parts of machines; stands for mechanical saws; saw guide rails for mechanical saws; parts and accessories for all the aforesaid goods, included in this class. Cupboards; tool cabinets (non-metallic -) [empty]; tables; benches [furniture]; work benches; vice benches [furniture]; work benches and turning lathes [other than parts of machines]; clamping tables and working tables [other than parts of machines]; worktables [other than parts of machines]; saw benches [other than parts of machines]; stands for saws; supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); guide rails for all the aforesaid goods; parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

Guide rails of metal; parts and accessories for all the aforesaid goods, included in this class. Tables for machines; supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); work benches and turning lathes [parts of machines]; clamping tables being parts of machines; worktables being parts of machines; working tables being parts of machines; saw benches being parts of machines; stands for mechanical saws; saw guide rails for mechanical saws; parts and accessories for all the aforesaid goods, included in this class. Saw holders. Cupboards; tool cabinets (non-metallic) [empty]; tables; benches [furniture]; work benches; vice benches [furniture]; work benches and turning lathes [other than parts of machines]; clamping tables and working tables [other than parts of machines]; worktables [other than parts of machines]; saw benches [other than parts of machines]; stands for saws; supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); guide rails for all the aforesaid goods; parts and accessories for all the aforesaid goods, included in this class.

Abstract

The invention relates to a cutting device, comprising a frame (1), a cutting blade (3), which is fastened to the frame for pivoting about a first pivot axis (2), and a reduction transmission (4, 5), which converts each forward pivoting movement of a plurality of successively performed forward pivoting movements and backward pivoting movements of a drive arm (6) into a cutting pivoting movement of the cutting blade (3). In order to improve the ease of handling, a cutting-blade back-pivoting apparatus (20, 21, 22, 23) is provided, by means of which the cutting blade (3) can be pivoted back from a pivoting end position to an initial position. The back-pivoting apparatus has, in particular, a tension element (20), which acts on the cutting blade (3) in such a way that a clearance is formed.

IPC Classes  ?

• B23D 17/08 - Shearing machines or shearing devices cutting by blades pivoted on a single axis characterised by drives or gearings therefor actuated by hand or foot operated lever mechanism
• B26D 1/30 - Cutting through work characterised by the nature or movement of the cutting memberApparatus or machines thereforCutting members therefor involving a cutting member which does not travel with the work having a cutting member moving about an axis with a non-circular cutting member moving about an axis substantially perpendicular to the line of cut with limited pivotal movement to effect cut
• B23D 29/02 - Hand-operated metal-shearing devices

Abstract

The invention relates to a cutting device, comprising a frame (1), a cutting blade (3), which is fastened to the frame for pivoting about a first pivot axis (2), and a reduction transmission (4, 5), which converts each forward pivoting movement of a plurality of successively performed forward pivoting movements and backward pivoting movements of a drive arm (6) into a cutting pivoting movement of the cutting blade (3). In order to improve the ease of handling, a cutting-blade back-pivoting apparatus (20, 21, 22, 23) is provided, by means of which the cutting blade (3) can be pivoted back from a pivoting end position to an initial position. The back-pivoting apparatus has, in particular, a tension element (20), which acts on the cutting blade (3) in such a way that a clearance is formed.

IPC Classes  ?

• B23D 17/08 - Shearing machines or shearing devices cutting by blades pivoted on a single axis characterised by drives or gearings therefor actuated by hand or foot operated lever mechanism
• B23D 29/02 - Hand-operated metal-shearing devices
• B26D 1/30 - Cutting through work characterised by the nature or movement of the cutting memberApparatus or machines thereforCutting members therefor involving a cutting member which does not travel with the work having a cutting member moving about an axis with a non-circular cutting member moving about an axis substantially perpendicular to the line of cut with limited pivotal movement to effect cut

Goods & Services

Guide rails of metal; parts and accessories for all the aforesaid goods, included in this class. Tables for machines; supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); work benches and turning lathes [parts of machines]; clamping tables being parts of machines; worktables being parts of machines; working tables being parts of machines; saw benches being parts of machines; stands for mechanical saws; saw guide rails for mechanical saws; parts and accessories for all the aforesaid goods, included in this class. Cupboards; tool cabinets (non-metallic -) [empty]; tables; benches [furniture]; work benches; vice benches [furniture]; work benches and turning lathes [other than parts of machines]; clamping tables and working tables [other than parts of machines]; worktables [other than parts of machines]; saw benches [other than parts of machines]; stands for saws; supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); guide rails for all the aforesaid goods; parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

Guide rails of metal; parts and accessories for all the aforesaid goods, included in this class. Tables for machines; supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); work benches and turning lathes [parts of machines]; clamping tables being parts of machines; worktables being parts of machines; working tables being parts of machines; saw benches being parts of machines; stands for mechanical saws; saw guide rails for mechanical saws; parts and accessories for all the aforesaid goods, included in this class. Cupboards; tool cabinets (non-metallic -) [empty]; tables; benches [furniture]; work benches; vice benches [furniture]; work benches and turning lathes [other than parts of machines]; clamping tables and working tables [other than parts of machines]; worktables [other than parts of machines]; saw benches [other than parts of machines]; stands for saws; supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); guide rails for all the aforesaid goods; parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

Tables for machines; supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); work benches and turning lathes [parts of machines]; clamping tables being parts of machines; worktables being parts of machines; working tables being parts of machines; saw benches being parts of machines; stands for mechanical saws; saw guide rails for mechanical saws; parts and accessories for all the aforesaid goods, included in this class. Cupboards; tool cabinets (non-metallic -) [empty]; tables; benches [furniture]; work benches; vice benches [furniture]; work benches and turning lathes [other than parts of machines]; clamping tables and working tables [other than parts of machines]; worktables [other than parts of machines]; saw benches [other than parts of machines]; stands for saws; supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); guide rails for all the aforesaid goods; parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

Mechanically operated tools; machines for metal, vehicle, wood, plastics processing and stone working; mechanically operated tools and apparatus for the construction of machines, apparatus, tools and vehicles, for electrical and structural engineering, for metal working, woodworking and stone working, for television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock- and watchmakers, floor and tile layers and DIY enthusiasts; hand-operated driving machines intended for stationary installation for driving tools, including accessories (included in this class), drills, drill bits, milling cutters, rasps, milling drills, bore saws, drill rasps, rasp files, cut-off grinders, grinding plates, grinding discs, ceramic grinding pencils, saw blades, jigsaw blades, hole saws, circular saws, chisels, wire brushes (parts of machines), tile cutters, paint, mortar and adhesive mixers, screwdriver bit inserts, drill stands, clamping jaws, flexible shafts, pumps (parts of machines); drilling and milling templates (parts of machines), pneumatic tools (parts of machines); fixings for hand drills (parts of machines); tables for machines; supporting trestles and roller blocks (parts of machines); wood turning laths (parts of machines); planning machines, storage containers filled with and adapted to the aforesaid goods; working tables as parts of machines; screwdriver bits (bits as parts of machines), saw blades (parts of machines), parts, spare parts and accessories for all the aforesaid goods, included in this class. Hand-operated tools; hand-operated machines for agricultural, horticultural and forestry purposes for the construction of machines, apparatus, tools and vehicles for electrical and structural engineering, for metal working, woodworking and stone working, for television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock- and watchmakers, floor and tile layers and DIY enthusiasts; clamps, pliers, vices, angles, mitre boxes, edge cutters, cutters, grinding discs, grinding apparatus (hand-operated), chisels, screwdrivers and tackers; screwdriver bit inserts (bits for hand-operated tools); bit holders; hand-operated clamping, stretching and expanding tools, inparticular belt tensioning tools, frame clamps, angle clamps,clamping jaws, quick-release clamps; cutlery; knives (hand tools), scissors and blades therefor, carpet knives, saw blades (for hand-operated tools), putty knives, trowels, riveting pincers, milling drills, bore saws, drill rasps, rasp files (for hand-operated tools), wire brushes; storage containers filled with and adapted to the aforesaid goods especially cases and bags; drilling and milling templates (for hand-operated tools); parts, spare parts and accessories for all the aforesaid goods, included in this class. Packaging of paper or plastic adapted for hand-operated and/or mechanically operated tools; parts, spare parts and accessories for all the aforesaid goods, included in this class. Tables, work tables, work benches; clamping tables; working tables for milling, drilling, sawing and polishing services (except machine tables); troughs of plastic for mixing mortar; wooden dowels, wooden pencils; empty storage containers not made of metal; supporting trestles and roller blocks (no parts of machines); parts, spare parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

(1) Guide rails of metal, parts and accessories for all the aforesaid goods, included in this class. (2) Tables for machines, namely workbenches, supporting trestles, work trestles, sawhorses, roller blocks, work benches and turning lathes [parts of machines], machine tools, namely clamping tables, worktables being parts of machines, working tables being parts of machines, saw benches being parts of machines, stands for mechanical saws, saw guide rails for mechanical saws, parts and accessories for all the aforesaid goods, included in this class. (3) Cupboards, non-metal tool cabinets, worktables, furniture benches, work benches, metal and non-metal vice benches being furniture, work benches and turning lathes [other than parts of machines], clamp tables and worktables [other than parts of machines], saw benches [other than parts of machines], stands for saws, trestles for use as table support, work trestles, namely trestle tables, sawhorses, roller blocks, guide rails for all the aforesaid goods, parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

(1) Guide rails of metal, parts and accessories for all the aforesaid goods, included in this class. (2) Tables for machines, namely workbenches, trestles for use as table support, sawhorses, roller blocks, work benches and turning lathes [parts of machines], machine tools, namely clamping tables, worktables being parts of machines, working tables being parts of machines, saw benches being parts of machines, stands for mechanical saws, saw guide rails for mechanical saws, parts and accessories for all the aforesaid goods, included in this class. (3) Saw holders. (4) Cupboards, non-metal tool cabinets, worktables, furniture benches, work benches, metal and non-metal vice benches being furniture, work benches and turning lathes [other than parts of machines], clamp tables, worktables [other than parts of machines], saw benches [other than parts of machines], stands for saws, trestles for use as table support, work trestles, namely trestle tables, sawhorses, roller blocks, guide rails for all the aforesaid goods, parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

(1) Guide rails of metal, parts and accessories for all the aforesaid goods, included in this class. (2) Tables for machines, namely workbenches, trestles for use as table support, sawhorses, roller blocks, work benches and turning lathes [parts of machines], machine tools, namely clamping tables, worktables being parts of machines, working tables being parts of machines, saw benches being parts of machines, stands for mechanical saws, saw guide rails for mechanical saws, parts and accessories for all the aforesaid goods, included in this class. (3) Cupboards, non-metal tool cabinets, worktables, furniture benches, work benches, metal and non-metal vice benches being furniture, work benches and turning lathes [other than parts of machines], clamp tables, worktables [other than parts of machines], saw benches [other than parts of machines], stands for saws, trestles for use as table support, work trestles, namely trestle tables, sawhorses, roller blocks, guide rails for all the aforesaid goods, parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

(1) Tables for machines, namely workbenches, trestles for use as table support, sawhorses, roller blocks, work benches and turning lathes [parts of machines], machine tools, namely clamping tables, worktables being parts of machines, working tables being parts of machines, saw benches being parts of machines, stands for mechanical saws, saw guide rails for mechanical saws, parts and accessories for all the aforesaid goods, included in this class. (2) Cupboards, non-metal tool cabinets, worktables, furniture benches, work benches, metal and non-metal vice benches being furniture, work benches and turning lathes [other than parts of machines], clamp tables, worktables [other than parts of machines], saw benches [other than parts of machines], stands for saws, trestles for use as table support, work trestles, namely trestle tables, sawhorses, roller blocks, guide rails for all the aforesaid goods, parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

(1) Guide rails of metal, parts and accessories for all the aforesaid goods, included in this class. (2) Tables for machines, namely workbenches, trestles for use as table support, sawhorses, roller blocks, work benches and turning lathes [parts of machines], machine tools, namely clamping tables, worktables being parts of machines, working tables being parts of machines, saw benches being parts of machines, stands for mechanical saws, saw guide rails for mechanical saws, parts and accessories for all the aforesaid goods, included in this class. (3) Cupboards, non-metal tool cabinets, worktables, furniture benches, work benches, metal and non-metal vice benches being furniture, work benches and turning lathes [other than parts of machines], clamp tables, worktables [other than parts of machines], saw benches [other than parts of machines], stands for saws, trestles for use as table support, work trestles, namely trestle tables, sawhorses, roller blocks, guide rails for all the aforesaid goods, parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

tables specially adapted to hold powered machinery; supporting trestles tables, work trestles tables, sawhorses and roller blocks tables all being parts of machines; work benches being parts of machines; turning lathes; clamping tables being parts of machines; worktables being parts of machines; working tables being parts of machines; saw benches being parts of machines; stands specially adapted to hold mechanical power saws; saw guide rails being parts of mechanical power saws; stands specially adapted for machines, namely, saws tool cabinets, non-metallic, sold empty; work benches; vice benches being furniture; work benches other than parts of machines; clamping tables and working tables being furniture; worktables being furniture; saw benches being furniture; supporting trestles being furniture, work trestles tables, sawhorses and roller blocks tables, other than being parts of machines; none of the aforementioned goods equipped with casters, glides or cushions

Goods & Services

Glues for industrial purposes; glues for wood. Cleaning, polishing, scouring and abrasive preparations; cleaning preparations; abrasive paper, grit cloth (abrasive preparations); polishing pastes. Ironmongery, small items of metal hardware; guide rails of metal; fastening materials of metal; screws, nails, clamps and tacker clips of metal; hooks of metal; rivets; fastening and spacer wedges of metal; clamps (cramps) of metal; strips and spacer strips of metal, ceiling supports of metal; metal building materials; soldering and welding wire; empty storage containers of metal, in particular cases, boxes, assortment boxes, all for tools, tool inserts, ironmongery, small items of metal hardware; packaging containers of metal; ferrules of metal; lashing straps of metal and straps of metal for handling loads, including in the form of ratchet belts; tension links and tensioning straps of metal; strap protection plates of metal for lashing straps, load-bearing straps, belt tensioners, tensioning straps, tensioning rubbers and cover expanders; perforated panel walls, perforated panel hooks and perforated panel holders of metal for presenting goods; dowel bars of metal; dowel fixings of metal for marking dowel holes; packaging of metal adapted for hand-operated and/or mechanically operated tools; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for all the aforesaid goods, included in this class. Mechanically operated tools; machines for the construction of machines, apparatus, tools and vehicles and for electrical and structural engineering, metal working, wood working, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock and watchmakers, floor and tile layers, installers and DIY enthusiasts; mechanically operated tools and apparatus for the construction of machines, apparatus, tools and vehicles, for electrical and structural engineering, for metal working, woodworking, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock and watchmakers, floor and tile layers, installers and DIY enthusiasts; driving machines intended for stationary installation, including parts thereof; tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling bits; mechanically operated screwing tools, in particular screwdrivers and screwdriver bits (bits for mechanical tools), and holders therefor; electrically or pneumatically operated drilling machines and hand drills; drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; drill stands and drilling aids for electric drilling machines; drill chucks for mechanical tools; drill stands and drilling aids for electrically or pneumatically operated drilling machines; templates (parts of machines), in particular drilling and milling templates; milling stops; bit stops for drills (parts of machines); milling cutters (mechanical tools); grinding machines and grinding wheels (parts of machines); cut-off grinders, grinding plates, grinding discs, cut-off wheels, ceramic abrasive pencils (parts of machines); electric cutting tools; blades (parts of machines); electric hole cutters; electric tile and laminate cutters; cutting machines; electric strip and edge cutters; saws (machines), in particular hole saws, circular saws and chain saws; saw blades and blades for mechanical tools; chisels for machines; electric chisels; brushes (parts of machines), in particular wire brushes; mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; mechanical clamping, stretching and expanding tools and devices; clamping spindles for mechanical tools; clamping jaws (parts of machines); pneumatic tools (parts of machines); turning lathes and planing machines; electric cartridge guns; pumps (parts of machines or motors and engines); tables for machines; supporting trestles, sawhorses and roller blocks (parts of machines); planing benches and turning lathes (parts of machines), clamping and work tables being parts of machines; electric and non-electric soldering and welding tools; electric cleaning machines and apparatus; flexible shafts (parts of machines); holders (parts of machines) for all the aforesaid goods; handles for mechanical tools, in particular telescopic handles; parts of machines, namely grinding wheels, grinding plates, abrasive belts, polishing wheels, polishing heads; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; pneumatic fittings of metal (parts of pneumatic apparatus); packaging of metal adapted for mechanically operated tools; parts, spare parts and accessories for all the aforesaid goods, included in this class. Hand tools (hand-operated); implements (hand-operated) for agricultural, horticultural and forestry purposes, for the construction of machines, apparatus, tools and vehicles and for electrical and structural engineering, metal working, wood working, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock- and watchmakers, floor and tile layers, installers and DIY enthusiasts; tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners (hand tools); vices, clamping jaws for vices; clamps (hand tools), in particular screw clamps, spring clamps, ratchet clamps, mounting clamps, one-handed clamps and glue presses; hand-operated screwing tools, in particular screwdrivers and screwdriver bits (bits for hand-operated tools), and holders therefor; non-electric hand drills; drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; drill stands and drilling aids for hand-operated drills; drill chucks for hand tools; templates, namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; guiding tools (hand-operated) for drills and hole saws; milling cutters (hand tools); sharpening instruments; blade sharpening instruments; hand-operated grinding wheels, grinding plates, cut-off wheels, cut-off grinders and ceramic abrasive pencils; grinders (hand tools), hand-operated grinding apparatus; cutlery; cutting tools; glass cutters; knives (hand tools), carpet knives and scissors; scrapers (hand tools); mitre boxes, edge cutters, cutters; blades (parts of hand tools); hand-operated hole cutters; non-electric tile and laminate cutters; cutting aids (hand tools); non-electric strip and edge cutters; saws (hand tools); saw blades and blades for hand-operated tools; chisels (hand-operated tools), in particular including boring tools; mixers (inserts for hand tools), in particular paint mixers, mortar mixers, adhesive mixers; hand-operated clamping, stretching and expanding tools in particular belt tensioning tools, frame clamps, angle clamps, clamping jaws, quick-release clamps, tensioning rubbers, lashing straps, including in the form of ratchet belts and tensioning straps; clamping spindles for hand tools; dowelling tools; planes; cartridge guns (hand tools); hand pumps; pull bars; trowels (tools), in particular brick trowels; spattles, hand-operated tackers; mitre boxes; clamps, in particular riveting pliers; rasps and files (hand tools); angles (hand tools); angle bevels (hand tools); spanners (hand tools); spacers (hand tools); hand-operated striking tools, in particular bats; handles for hand tools, in particular telescopic handles; holders for all the aforesaid goods; dies and inserts for all the aforesaid goods; hand tools, namely grinding wheels, grinding plates, abrasive belts, polishing wheels, polishing heads; scribers (tools); storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; wire brushes (hand-operated tools); packaging of metal adapted for hand-operated tools; parts, spare parts and accessories for all the aforesaid goods, included in this class. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; measuring apparatus and instruments, in particular levelling rods, rules (measuring instruments) and dial test indicators; displacement gauges and protractors [measuring instruments]; angle bevels (measuring instruments); gauges, in particular contour gauges; spirit levels; rulers (measuring instruments); protective eyewear, welding goggles; protective masks, respiratory masks and protective mouth masks, in particular fine dust masks and half masks; filters for protective masks, respiratory masks and protective mouth masks; protective helmets, protective gloves; protective work clothing, in particular disposable protective and safety clothing and disposable protective overshoes; spectacle cases; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; laminate fitters being measuring instruments; dowel bars being measuring tools; parts, spare parts and accessories for the aforesaid goods, included in this class; downloadable electronic publications. Ear protectors (ear plugs), ear defenders and ear protection apparatus; parts, spare parts and accessories for the aforesaid goods, included in this class. Lamps, in particular pocket torches; suction cups being parts of lighting devices; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for all the aforesaid goods, included in this class. Apparatus for locomotion by land, in particular handling carts, two-wheeled trolleys and push carts; luggage nets for vehicles and vehicle trailers; parts and spare parts for all the aforesaid goods, included in this class. Paper, cardboard; packaging materials of cardboard; plastic materials for packaging (not included in other classes); pouches, envelopes, bags of paper or plastic, for packaging; packaging of paper or plastic adapted for hand-operated and/or mechanically operated tools; cardboard and/or cardboard packaging for presenting goods; paint brushes, paint rollers; painters' brushes; stencils; garden waste bags of plastic; glues for stationery or household purposes; printed matter, in particular catalogues; marking and drawing templates, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; parts, spare parts and accessories for all the aforesaid goods, included in this class. Plastic films, other than for packaging; protective films of plastics, other than for wrapping; adhesive tapes and bands, other than for stationery and not for medical or household purposes; padding materials of plastics, as finished goods. Bags (empty), in particular tool bags and tool belt bags of textile, plastic, leather or a combination of the aforesaid materials; cases (empty), namely tool cases of leather (empty); parts, spare parts and accessories for all the aforesaid goods included in this class. Manufactured timber, particularly small parts made of wood; building material (not made of metal); building materials, namely fitting strips and spacing strips, not made of metal; props, not made of metal; timber mouldings for building purposes. Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches (not of metal), planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); supporting trestles, sawhorses and chopping blocks [tables]; storage racks, not of metal, for storing firewood; display cases for merchandise; showcases for presenting goods; fastening materials, not of metal, fastening and spacer wedges, not of metal; clamps, not of metal; troughs of plastic for mixing mortar; strips of wood for frames; wooden dowels, wooden pegs; empty storage containers, not of metal; empty storage containers (not of metal), in particular cases, boxes, caskets and assortment boxes for tools, tool inserts, ironmongery, small items of metal hardware; packaging containers, not of metal; dowel fixings for marking dowel holes; clips of plastic for cables and plants; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; vice benches of metal; storage racks of metal, in particular for storing firewood; parts, spare parts and accessories for all the aforesaid goods, included in this class. Sponges; steelwool; cleaning instruments, hand-operated; brushes; electric brushes, other than parts of machines; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; plaster buckets, not of metal; parts, spare parts and accessories for the aforesaid goods, included in this class. Tarpaulins; lashing straps and load-bearing straps, not of metal, including in the form of non-metal ratchet belts; tensioning straps, not of metal; tensioning rubbers and cover expanders; strap protection plates (not of metal) for protecting lashing straps, belt tensioners and tensioning straps; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for the aforesaid goods, included in this class. Baseball caps; disposable clothing; clothing, footwear, headgear. Hook and pile fastening tapes, including self-adhesive, in particular including for the fixing, bundling and retaining of cables and for tying plants. Mats, in particular non-slip mats, including for fixing loads. Wholesale and retail services, including by means of teleshopping programmes and online and catalogue mail order, in the fields of construction and DIY articles and other commodity goods for the professional and DIY sectors, machines, tools and goods of common metal, construction, craftsmen and garden articles, hobby requisites and craft supplies, personal industrial safety equipment and clothing; presentation of goods in the fields of construction and DIY articles and other commodity goods for the professional and DIY sectors, machines, tools and goods of common metal, construction, craftsmen and garden articles, hobby requisites and craft supplies, personal industrial safety equipment and clothing; publication of printed matter (including in electronic form) for advertising purposes; presentation or goods on communication media, for wholesale and retail purposes; auctioneering, including on the Internet; arranging commercial transactions, for others, including within the framework of e-commerce; arranging contracts, for others, for the buying and selling of goods.

Goods & Services

Guide rails of metal; Parts and accessories for all the aforesaid goods, included in this class. Tables for machines; Supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); Work benches and turning lathes [parts of machines]; Clamping tables being parts of machines; Worktables being parts of machines; Working tables being parts of machines; Saw benches being parts of machines; Stands for mechanical saws; Saw guide rails for mechanical saws; Parts and accessories for all the aforesaid goods, included in this class. Cupboards; Tool cabinets (non-metallic -) [empty]; Tables; Benches [furniture]; work benches; Vice benches [furniture]; Work benches and turning lathes [other than parts of machines]; Clamping tables and working tables [other than parts of machines]; Worktables [other than parts of machines]; Saw benches [other than parts of machines]; Stands for saws; Supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); Guide rails for all the aforesaid goods; Parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

Tables for machines; Supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); Work benches and turning lathes [parts of machines]; Clamping tables being parts of machines; Worktables being parts of machines; Working tables being parts of machines; Saw benches being parts of machines; Stands for mechanical saws; Saw guide rails for mechanical saws; Parts and accessories for all the aforesaid goods, included in this class. Cupboards; Tool cabinets (non-metallic -) [empty]; Tables; Benches [furniture]; work benches; Vice benches [furniture]; Work benches and turning lathes [other than parts of machines]; Clamping tables and working tables [other than parts of machines]; Worktables [other than parts of machines]; Saw benches [other than parts of machines]; Stands for saws; Supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); Guide rails for all the aforesaid goods; Parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

Guide rails of metal; Parts and accessories for all the aforesaid goods, included in this class. Tables for machines; Supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); Work benches and turning lathes [parts of machines]; Clamping tables being parts of machines; Worktables being parts of machines; Working tables being parts of machines; Saw benches being parts of machines; Stands for mechanical saws; Saw guide rails for mechanical saws; Parts and accessories for all the aforesaid goods, included in this class. Cupboards; Tool cabinets (non-metallic -) [empty]; Tables; Benches [furniture]; work benches; Vice benches [furniture]; Work benches and turning lathes [other than parts of machines]; Clamping tables and working tables [other than parts of machines]; Worktables [other than parts of machines]; Saw benches [other than parts of machines]; Stands for saws; Supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); Guide rails for all the aforesaid goods; Parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

Guide rails of metal; Parts and accessories for all the aforesaid goods, included in this class. Tables for machines; Supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); Work benches and turning lathes [parts of machines]; Clamping tables being parts of machines; Worktables being parts of machines; Working tables being parts of machines; Saw benches being parts of machines; Stands for mechanical saws; Saw guide rails for mechanical saws; Parts and accessories for all the aforesaid goods, included in this class. Cupboards; Tool cabinets (non-metallic -) [empty]; Tables; Benches [furniture]; work benches; Vice benches [furniture]; Work benches and turning lathes [other than parts of machines]; Clamping tables and working tables [other than parts of machines]; Worktables [other than parts of machines]; Saw benches [other than parts of machines]; Stands for saws; Supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); Guide rails for all the aforesaid goods; Parts and accessories for all the aforesaid goods, included in this class.

Goods & Services

(1) Gelatine glues for industrial purposes; glues for wood. (2) All-purpose cleaning, polishing, scouring and abrasive preparations; abrasive paper, grit cloth (abrasive preparations); polishing pastes. (3) Vice benches of metal; storage racks of metal, in particular for storing firewood; guide rails of metal; screws, nails, pipe clamps and tacker clips of metal; hooks of metal, namely metal pegs; metal rivets; fastening and spacer wedges of metal; cramps of metal; spacer strips of metal, in the nature of metal hardware, namely, spacers used in the installation of flooring, ceiling supports of metal; soldering and welding wire; empty storage containers of metal, in particular cases, boxes, caskets, assortment boxes and magazines, all for tools, tool inserts, ironmongery, small items of metal hardware; packaging containers of metal; straps of metal for handling loads; ratchet made of metal with tie-down straps made of textile materials; belt tensioners and tensioning straps of metal; strap protection plates of metal for lashing straps, load-bearing straps, belt tensioners, tensioning straps, tensioning rubbers and cover expanders; perforated panel walls, perforated panel hooks and perforated panel holders of metal for presenting goods; dowel bars of metal; dowel fixings of metal for marking dowel holes; packaging of metal adapted for hand-operated and mechanically operated tools; storage containers of metal, in particular cases, bags, boxes, caskets, assortment boxes and magazines. (4) Metal working machines used for the construction of machines, apparatus, tools and vehicles and for electrical and structural engineering, metal working, wood working, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock and watchmakers, floor and tile layers and installers; mechanically operated tools for the construction of machines, namely metal sawing machines; indexing drive machines and parts thereof; tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling bits; mechanically operated screwing tools, in particular screwdrivers and screwdriver bits (bits for mechanical tools), and holders relating thereto; electrically and pneumatically operated drilling machines and hand drills for metal working; drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; drill stands and drilling aids for electric drilling machines; drill chucks for mechanical tools; drill stands and drilling aids for electrically and pneumatically operated drilling machines; templates (parts of machines), in particular drilling and milling templates; milling stops namely, power tool accessories, namely, cutting guides; bit stops for drills being parts of machines, in the nature of power tool accessories, namely, drilling guides; milling cutters (mechanical tools); grinding machines and grinding wheels (parts of machines); cut-off grinders, grinding plates, grinding discs, cut-off wheels, ceramic grinding pencils (parts of machines); electric cutting tools for metalworking; blades for power saws; electric hole cutters; tile and laminate removal and cutting machines; cutting machines for metalworking; electric strip and edge cutters; saws (machines), in particular hole saws, circular saws and chain saws; saw blades and blades for mechanical tools all in the nature of power saw blades, and machine parts, namely, blades; chisels for machines; electric chisels; brushes, in particular wire brushes; mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; clamping jaws being parts of machines, namely, machine tools, namely, jaws for use in the precision clamping of work pieces; clamping spindles for mechanical tools; clamping jaws (parts of machines); pneumatic tools, namely drills, hammers and milling cutters; electric cartridge guns; pumps being parts of machines, motors and engines; tables for machines, namely workbenches; supporting trestles, sawhorses and roller blocks (parts of machines); planing benches and turning lathes (parts of machines), clamping and work tables being parts of machines; electric and non-electric soldering and welding tools; electric cleaning machines and apparatus namely, machines for cleaning surfaces using high pressure water; flexible shafts being parts of machines in the nature holders used for mounting brushes, drills, milling cutters and rasp files to drill machines; machine tool holders; handles for mechanical tools, in particular telescopic handles; parts of machines, namely grinding wheels, grinding plates, abrasive belts, abrasive strips, abrasive sheets, polishing bonnets, polishing wheels, polishing heads; storage containers for machine tools, in particular cases, bags, boxes, caskets, assortment boxes and magazines; packaging of metal adapted for mechanically operated tools; parts, spare parts and accessories for power tools. (5) Hand tools (hand-operated); tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners (hand tools); vices, clamping jaws for vices; clamps (hand tools), in particular screw clamps, spring clamps, ratchet clamps, mounting clamps, one-handed clamps and glue presses; handoperated screwing tools, in particular screwdrivers and screwdriver bits (bits for hand-operated tools), and holders relating thereto; non-electric hand drills; hand-held drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; drill stands and drilling aids for hand-operated drills; drill chucks for hand tools; cutting guides for use with hand-operated drills and hole saws; hand-operated milling cutters; hand-operated sharpening instruments; hand-operated blade sharpening instruments; hand-operated grinding wheels, grinding plates, cut-off wheels, cut-off grinders and ceramic grinding pencils; hand-operated grinding apparatus, namely all-purpose hand-operated sanders and surface sanders; cutlery; hand-held cutting tools; glass cutters; multi-tool knives, carpet knives and scissors; wall scrapers (hand tools); mitre boxes, edge tools, cutter bars; blades for hand saws; handoperated hole cutters; non-electric tile and laminate cutters; non-electric laminate fitters (hand tools) being measuring instruments namely, instruments for measuring and transferring length all in the nature of instruments for measuring length, and apparatus for recording data for use in the field of transferring data concerning length of objects; non-electric strip and edge cutters; hand saws; saw blades and blades for handoperated tools; chisels (hand-operated tools), in particular boring tools; mixers, namely stirring sticks used as paint mixers, mortar mixers, adhesive mixers; hand-operated clamping, stretching and expanding tools in particular belt tensioning tools, frame clamps, angle clamps, clamping jaws, quick-release clamps; clamping spindles for hand tools; planes; hand tools, namely, cartridge guns in the nature of hand-operated guns for the extrusion of silicon, acrylic, adhesives, glue, sealants and mastics being pressed off a cartridge and applied to surfaces; pull bars namely, crow bars; trowels (tools), in particular brick trowels; spattles, namely putty knives, hand-operated tackers, namely staple guns; mitre boxes; clamps, in particular riveting pliers; rasps and files (hand tools); angles (hand tools), namely, angle bevels (hand tools); spanners (hand tools); handles for hand tools, in particular telescopic handles; holders for hand tools ; dies and inserts for use with hand operated tools ; hand tools, namely grinding wheels, grinding plates, abrasive belts, abrasive strips, abrasive sheets, polishing bonnets, polishing wheels, polishing heads; scribers (tools); storage containers adapted for hand operated tools the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; packaging of metal adapted for hand-operated tools, namely tool holders; parts, spare parts and accessories for hand operated tools. (6) Measuring apparatus and instruments, namely measuring rods in the nature of leveling rods for surveying, rules being measuring instruments in the nature of measuring rulers; measuring apparatus and instruments, in particular levelling rods, rules (measuring instruments); displacement gauges in the nature of level gauges, and goniometers in the nature of measuring apparatus, namely, angle finders; measuring instruments, namely angle bevels; gauges, in particular contour gauges; spirit levels; rulers (measuring instruments); protective eyewear, welding goggles; protective masks, respiratory masks and protective mouth masks, in particular fine dust masks and half masks; filters for protective masks, respiratory masks and protective mouth masks; protective helmets and protective gloves against accidents, dust, noise, irradiation and fire; protective work clothing against accidents, dust, noise, irradiation and fire, in particular disposable protective and safety clothing and disposable protective overshoes; spectacle cases; protective ear coverings, protective ear plugs; storage containers, in particular cases, bags, boxes, caskets, assortment boxes and magazines all being specially adapted containers for holding protective eyewear; dowel bars being measuring tools; downloadable digital content in the form of electronic publications of books, brochures and newsletters. (7) Lamps, in particular pocket torches; suction cups being parts of lamps; parts, spare parts and accessories for all the aforesaid goods; storage containers in particular cases, bags, boxes, caskets, assortment boxes and magazines specially adapted for holding and carrying pocket searchlights. (8) Apparatus for locomotion by land, in particular trolleys, hand trucks and push carts used for luggage, groceries and other goods to be carried, namely building materials; parts and spare parts for all the aforesaid goods; luggage nets for vehicles and vehicle trailers; parts and spare parts for all the aforesaid goods. (9) Paper, cardboard; packaging materials of cardboard; plastic materials for packaging (not included in other classes); pouches, envelopes, bags of paper and of plastic, for packaging; packaging of paper and of plastic adapted for hand-operated and mechanically operated tools; cardboard and cardboard packaging for presenting goods; paint brushes, paint rollers; painters' brushes; stencils; garden waste bags of plastic; glues for stationery or household purposes; printed matter, in particular catalogues; marking and drawing templates, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors. (10) Protective sheets of plastic films, namely, re-closable curtains or hangings all in the nature of barrier curtains in the nature of floating baffles or booms for the containment of pollutants; adhesive tapes, namely duct tape; padding materials of plastics, as finished goods. (11) Bags (empty), in particular tool bags and tool belt bags of textile, plastic, leather or a combination of the aforesaid materials; cases (empty), namely tool cases of leather (empty); parts, spare parts and accessories, namely straps for carrying tool bags. (12) Preserved wood and semi-worked wood and wood parts thereof; wooden rods for building purposes; building materials not made of metal, namely fitting strips and spacing strips for building; props, not made of metal, namely construction props; timber mouldings for building purposes. (13) Furniture, in particular tables, cupboards, shelves, storage racks, furniture benches, work benches, vice benches (not of metal), planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); supporting trestles, sawhorses and roller blocks [not being parts of machines]; storage racks, not of metal, for storing firewood; display cases for merchandise; showcases for presenting goods; fastening materials, not of metal, namely wooden dowels, plastic dowels; fastening and spacer wedges, not of metal; plastic cable clamps; troughs of plastic for mixing mortar; wooden dowels, wooden pegs; empty storage containers, not of metal; empty storage containers (not of metal), namely plastic storage containers in particular cases, boxes, caskets and assortment boxes for tools, tool inserts, ironmongery, small items of metal hardware; packaging containers, not of metal, namely packaging containers of plastic; dowel fixings for marking dowel holes; clips of plastic for cables and plants; vice benches of metal; storage racks of metal, in particular for storing firewood. (14) Scouring sponges; steel wool; hand-operated cleaning instruments, hand-operated; namely washing brushes; electric wire brushes, other than parts of machines; plaster buckets, not of metal; buckets used to mix plaster. (15) Awnings, tarpaulins; lashing straps and load-bearing straps, not of metal, including in the form of non-metal ratchet belts; belt tensioners and tensioning straps, not of metal. (16) Baseball caps; disposable clothing, namely overalls and shoe covers; clothing, namely shirts, pants, overalls, footwear, namely shoes and boots. (17) Hook and pile fastening tapes, in particular for the fixing, bundling and retaining of cables and for tying plants. (18) Mats, in particular non-slip mats for fixing loads. (1) Wholesale and retail services by means of online and catalogue mail order, in the fields of construction and DIY articles and other commodity goods for the professional and DIY sectors, machines, tools and goods of common metal, construction, craft and garden articles, hobby requisites and craft supplies, industrial personal safety equipment and clothing; presentation of goods in the fields of construction and DIY articles and other commodity goods for the professional and DIY sectors, machines, tools and goods of metal, construction, craft and garden articles, hobby requisites and craft supplies, industrial personal safety equipment and clothing; publication of printed matter (including in electronic form) for advertising purposes, namely publication of publicity texts; presentation or goods on communication media, for wholesale and retail purposes; auctioneering on the Internet; arranging commercial transactions, for others within the framework of e-commerce; arranging contracts, for others, for the buying and selling of goods.

Abstract

The invention relates to an apparatus having a guide carriage (5) which can be fitted onto a guide track (1) and is displaceable thereon having position-fixing elements (6, 7) for fixing a tool device (8) on the guide carriage (5), having an adjusting element (10) in order during adjustment of the position-fixing elements (6, 7) to bring a tool (9) of the tool unit (8) into a defined position. In order to simplify the position fixing of a tool device (8), in particular a handheld circular saw, on the guide carriage (5), the adjusting element (10) has an adjusting stop (13) against which the tool (9), in particular a saw blade, can be placed.

IPC Classes  ?

• B25H 1/00 - Work benchesPortable stands or supports for positioning portable tools or work to be operated on thereby
• B23Q 9/00 - Arrangements for supporting or guiding portable metal-working machines or apparatus
• B27B 9/04 - Guiding equipment, e.g. for cutting panels

Goods & Services

(1) Gelatine glues for industrial purposes; glues for wood. (2) All-purpose cleaning, polishing, scouring and abrasive preparations; abrasive paper, grit cloth (abrasive preparations); polishing pastes. (3) Guide rails of metal; fittings of metal for furniture; screws, nails, pipe clamps and tacker clips of metal; metal pegs; metal rivets; fastening and spacer wedges of metal; cramps of metal; spacer strips of metal, in the nature of metal hardware, namely, spacers used in the installation of flooring; ceiling supports of metal; soldering and welding wire; empty storage containers of metal, in particular cases, boxes, assortment boxes, all for tools, tool inserts; packaging containers of metal; ferrules of metal; lashing straps of metal and straps of metal for handling loads, in the form of ratchet belts; tension links and tensioning straps of metal; strap protection plates of metal for lashing straps, load-bearing straps, belt tensioners, tensioning straps, tensioning rubbers and cover expanders; perforated panel walls, perforated panel hooks and perforated panel holders of metal for presenting goods; dowel bars of metal; dowel fixings of metal for marking dowel holes; packaging of metal adapted for hand-operated and mechanically operated tools; storage containers of metal, in particular cases, bags, boxes, caskets, assortment boxes and magazines. (4) Metal working machines used for the construction of machines, apparatus, tools and vehicles and for electrical and structural engineering, metal working, wood working, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock and watchmakers, floor and tile layers and installers; mechanically operated tools for the construction of machines, namely metal sawing machines; tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling bits; mechanically operated screwing tools, in particular screwdrivers and screwdriver bits (bits for mechanical tools), and holders therefor; electrically and pneumatically operated drilling machines and hand drills for metal working; drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; drill stands and drilling aids for electric drilling machines; drill chucks for mechanical tools; drill stands and drilling aids for electrically and pneumatically operated drilling machines; templates (parts of machines), in particular drilling and milling templates; milling stops, namely, power tool accessories, namely, cutting guides; bit stops for drills being parts of machines, in the nature of power tool accessories, namely, drilling guides; milling cutters (mechanical tools); grinding machines and grinding wheels (parts of machines); cut-off grinders, grinding plates, grinding discs, cut-off wheels, ceramic abrasive pencils (parts of machines); electric cutting tools for metalworking; blades for power saws; electric hole cutters; tile and laminate removal and cutting machines; cutting machines for metalworking; electric strip and edge cutters; saws (machines), in particular hole saws, circular saws and chain saws; saw blades and blades for mechanical tools all in the nature of power saw blades, and machine parts, namely, blades; chisels for machines; electric chisels; brushes, in particular wire brushes; mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; clamping jaws being parts of machines, namely, machine tools, namely, jaws for use in the precision clamping of work pieces; clamping spindles for mechanical tools; clamping jaws (parts of machines); pneumatic tools, namely drills, hammers and milling cutters; electric cartridge guns; pumps being parts of machines, motors and engines; tables for machines, namely workbenches; supporting trestles, sawhorses and roller blocks (parts of machines); planing benches and turning lathes (parts of machines), clamping and work tables being parts of machines; electric and nonelectric soldering and welding tools; electric cleaning machines and apparatus namely, machines for cleaning surfaces using high pressure water; flexible shafts being parts of machines in the nature holders used for mounting brushes, drills, milling cutters and rasp files to drill machines; machine tool holders; handles for mechanical tools, in particular telescopic handles; parts of machines, namely grinding wheels, grinding plates, abrasive belts, polishing wheels, polishing heads; storage containers for machine tools, in particular cases, bags, boxes, caskets, assortment boxes and magazines; packaging of metal adapted for mechanically operated tools; parts, spare parts and accessories for power tools. (5) Hand tools (hand-operated); tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners (hand tools); vices, clamping jaws for vices; clamps (hand tools), in particular screw clamps, spring clamps, ratchet clamps, mounting clamps, one-handed clamps and glue presses; handoperated screwing tools, in particular screwdrivers and screwdriver bits (bits for hand-operated tools), and holders therefor; non-electric hand drills; hand-held drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; drill stands and drilling aids for hand-operated drills; drill chucks for hand tools; templates, namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; cutting guides for use with hand-operated drills and hole saws; hand-operated milling cutters; hand-operated sharpening instruments; hand-operated blade sharpening instruments; handoperated grinding wheels, grinding plates, cut-off wheels, cut-off grinders and ceramic abrasive pencils; hand-operated grinding apparatus, namely all-purpose hand-operated sanders and surface sanders; cutlery; hand-held cutting tools; glass cutters; multi-tool knives, carpet knives and scissors; wall scrapers (hand tools); mitre boxes, edge tools, cutter bars; blades for hand saws; hand-operated hole cutters; non-electric tile and laminate cutters; non-electric strip and edge cutters; hand saws; saw blades and blades for handoperated tools; chisels (hand-operated tools), in particular boring tools; mixers, namely stirring sticks used as paint mixers, mortar mixers, adhesive mixers; hand-operated clamping, stretching and expanding tools in particular belt tensioning tools, frame clamps, angle clamps, clamping jaws, quick-release clamps, tensioning rubbers, lashing straps, in the form of ratchet belts and tensioning straps; clamping spindles for hand tools; planes; hand tools, namely, cartridge guns in the nature of hand-operated guns for the extrusion of silicon, acrylic, adhesives, glue, sealants and mastics being pressed off a cartridge and applied to surfaces; pull bars namely, crow bars; trowels (tools), in particular brick trowels; spattles, namely putty knives, hand-operated tackers, namely staple guns; mitre boxes; clamps, in particular riveting pliers; rasps and files (hand tools); angle bevels (hand tools); spanners (hand tools); handles for hand tools, in particular telescopic handles; holders for hand tools; dies and inserts for use with hand operated tools; hand tools, namely grinding wheels, grinding plates, abrasive belts, polishing wheels, polishing heads; scribers (tools); storage containers adapted for hand operated tools, in particular cases, bags, boxes, caskets, assortment boxes and magazines; packaging of metal adapted for hand-operated tools, namely tool holders; parts, spare parts and accessories for hand-operated tools. (6) Measuring apparatus and instruments, namely measuring rods in the nature of leveling rods for surveying, rules being measuring instruments in the nature of measuring rulers; displacement gauges in the nature of level gauges, and goniometers in the nature of measuring apparatus, namely, angle finders; measuring instruments, namely angle bevels; gauges, in particular contour gauges; spirit levels; rulers (measuring instruments); protective eyewear, welding goggles; protective masks, respiratory masks and protective mouth masks, in particular fine dust masks and half masks; filters for protective masks, respiratory masks and protective mouth masks; protective helmets and protective gloves against accidents, irradiation, dust, noise and fire; protective work clothing against accidents, dust, noise, irradiation and fire, in particular disposable protective and safety clothing and disposable protective overshoes; spectacle cases; storage containers, in particular cases, bags, boxes, caskets, assortment boxes and magazines all being specially adapted containers for holding protective eyewear; laminate fitters being measuring instruments namely, instruments for measuring and transferring length all in the nature of instruments for measuring length, and apparatus for recording data for use in the field of transferring data concerning length of objects; dowel bars being measuring tools; downloadable digital content in the form of electronic publications of books, brochures and newsletters. (7) Ear protectors (ear plugs), ear defenders and ear protection apparatus namely, ear plugs and headphones for soundproofing and protecting users from loud sounds; parts, spare parts and accessories for the aforesaid goods. (8) Lamps, in particular pocket torches; suction cups being parts of lamps; parts, spare parts and accessories for all the aforesaid goods; storage containers in particular cases, bags, boxes, caskets, assortment boxes and magazines specially adapted for holding and carrying pocket searchlights. (9) Apparatus for locomotion by land, in particular handling carts, two-wheeled trolleys and push carts used for luggage, groceries and other goods to be carried, namely building materials; parts and spare parts for all the aforesaid goods; luggage nets for vehicles and vehicle trailers; parts and spare parts for all the aforesaid goods. (10) Paper, cardboard; packaging materials of cardboard; plastic materials for packaging (not included in other classes); pouches, envelopes, bags of paper and of plastic, for packaging; packaging of paper and of plastic adapted for hand-operated and mechanically operated tools; cardboard and cardboard packaging for presenting goods; paint brushes, paint rollers; painters' brushes; stencils; garden waste bags of plastic; glues for stationery or household purposes; printed matter, in particular catalogues; marking and drawing templates, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors. (11) Protective sheets of plastic films, namely, re-closable curtains or hangings all in the nature of barrier curtains in the nature of floating baffles or booms for the containment of pollutants; adhesive tapes, namely duct tape; padding materials of plastics, as finished goods. (12) Bags (empty), in particular tool bags and tool belt bags of textile, plastic, leather or a combination of the aforesaid materials; cases (empty), namely tool cases of leather (empty); parts, spare parts and accessories, namely straps for carrying tool bags. (13) Manufactured timber, particularly small parts made of wood; building materials not made of metal, namely fitting strips and spacing strips for building; props, not made of metal, namely construction props; timber mouldings for building purposes. (14) Furniture, in particular tables, cupboards, shelves, storage racks, furniture benches, work benches, vice benches (not of metal), planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); supporting trestles, sawhorses and chopping blocks [tables]; storage racks, not of metal, for storing firewood; display cases for merchandise; showcases for presenting goods; fastening materials, not of metal, namely window and door fasteners, fastening and spacer wedges, not of metal; plastic cable clamps; troughs of plastic for mixing mortar; wooden dowels, wooden pegs; empty storage containers, not of metal; empty storage containers (not of metal), namely plastic storage containers in particular cases, boxes, caskets and assortment boxes for tools, tool inserts, ironmongery, small items of metal hardware; packaging containers, not of metal, namely packaging containers of plastic; dowel fixings for marking dowel holes; clips of plastic for cables and plants; vice benches of metal; storage racks of metal, in particular for storing firewood. (15) Scouring sponges; steel wool; hand-operated cleaning instruments, namely washing brushes; electric wire brushes, other than parts of machines; plaster buckets, not of metal. (16) Tarpaulins; lashing straps and load-bearing straps, not of metal, in the form of non-metal ratchet belts; tensioning straps, not of metal; tensioning rubbers and cover expanders; strap protection plates (not of metal) for protecting lashing straps, belt tensioners and tensioning straps. (17) Baseball caps; disposable clothing, namely overalls and shoe covers; clothing, namely shirts, pants, overalls, footwear, namely shoes and boots. (18) Hook and pile fastening tapes, in particular for the fixing, bundling and retaining of cables and for tying plants. (19) Mats, in particular non-slip mats, including for fixing loads. (1) Wholesale and retail services, including by means of online and catalogue mail order, in the fields of construction and DIY articles and other commodity goods for the professional and DIY sectors, machines, tools and goods of common metal, construction, craftsmen and garden articles, hobby requisites and craft supplies, personal industrial safety equipment and clothing; presentation of goods in the fields of construction and DIY articles and other commodity goods for the professional and DIY sectors, machines, tools and goods of common metal, construction, craftsmen and garden articles, hobby requisites and craft supplies, personal industrial safety equipment and clothing; publication of printed matter (including in electronic form) for advertising purposes, namely publication of publicity texts; presentation or goods on communication media, for wholesale and retail purposes; auctioneering, including on the Internet; arranging commercial transactions, for others, including within the framework of e-commerce; arranging contracts, for others, for the buying and selling of goods.

Goods & Services

Glues for industrial purposes Cleaning, polishing, scouring and abrasive preparations; cleaning preparations; abrasive paper; grit cloth in the nature of abrasive cloth; abrasive preparations in the nature of abrasive paste; polishing pastes in the nature of polishing preparations Guide rails of metal; screws of metal; nails; metal clamps and tacker clips of metal in the nature of metal clips for general use; hooks of metal; rivets of metal; mechanical fastening elements of metal and spacer wedges of metal in the nature of metal spacer brackets; clamps being cramps of metal; spacer strips of metal, in the nature of metal hardware, namely, spacers used in the installation of flooring; ceiling supports of metal; soldering and welding wire; empty storage containers of metal, in particular, cases, boxes, caskets, assortment boxes and magazines, all for tools, tool inserts, ironmongery, small items of metal hardware all in the nature of metal tool boxes and containers of metal for storage of goods; industrial packaging containers of metal; metal clamps; lashing straps of metal and straps of metal for handling loads, including in the form of ratchet tie-downs all in the nature of straps of metal for load handling and belts of metal for handling loads; belt tensioners and tensioning straps of metal all in the nature of tension links of metal; strap protection plates of metal for lashing straps, load-bearing straps, belt tensioners, tensioning straps, tensioning rubbers and cover expanders all in the nature of mechanical fastening elements of metal; perforated panel walls in the nature of wall panels of metal for use in the field of presenting goods; perforated panel hooks in the nature of metal hooks for use in the field of presenting goods; perforated panel holders of metal in the nature of brackets of metal for building for use in the field of presenting goods; dowel bars of metal; packaging of metal adapted for hand-operated and/or mechanically operated tools in the nature of industrial packaging containers of metal; storage containers adapted for the aforesaid goods, in particular, cases, bags, boxes, caskets, assortment boxes and magazines all in the nature of containers of metal for storage of goods; supporting trestles in the nature of metal trestles for use as table supports, not for use in construction Apparatus, tools and vehicles and for electrical and structural engineering, metal working, wood working, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock and watchmakers, floor and tile layers, installers and DIY enthusiasts all in the nature of metal working machines; mechanically operated tools and apparatus for the construction of machines, namely, metal sawing machines; inserts for power-operated tools, namely, electric hammers and pneumatic hammers; power drill bits; milling bits being tool bits for machines; mechanically operated screwing tools, in particular, electric screwdrivers and screwdriver bits in the nature of tool bits for machines, and holders relating thereto in the nature of machine tool holders; electrically and pneumatically operated drilling machines and hand drills; power drills; drill buckets, namely, hollow annular power drill bits; milling cutters; milling drills, namely, power drill bits with the function of mill or a saw; drill rasps in the nature of power drill bit extensions; rasp files in the nature of power drill bit extensions; power tools, namely, countersinks, specifically adapted for use with power-operated drills and drilling machines; power-operated bore saws and power-operated hole saws for mechanical tools, specifically adapted for use with power-operated drills and drilling machines; drill stands being stands for machines and drilling aids for electric drilling machines being metal clamps used for holding piece parts on machine tool tables; drill chucks for mechanical tools, namely, chucks for power drills; drill stands being stands for machines and drilling aids for electrically and pneumatically operated drilling machines being metal clamps used for holding piece parts on machine tool tables; templates, in particular, drilling and milling templates in the nature of power tool accessories, namely, drilling guides being parts of milling-drilling machine; milling stops, namely, power tool accessories, namely, cutting guides; bit stops for drills being parts of machines, in the nature of power tool accessories, namely, drilling guides; milling cutters being mechanical tool, namely, milling cutters for milling machines; rotary grinding machines and grinding wheels being parts of machines in the nature of machine wheels; cut-off grinders, namely, rotary grinding machines; grinding plates in the nature of grinding tools for grinding machines; grinding discs in the nature of grinding tools for grinding machines; cut-off wheels in the nature of machine wheels; ceramic grinding pencils parts of machines, namely, grinding tools for grinding machines; machine parts, namely, blades; cutting machines; saw blades and blades for mechanical tools all in the nature of power saw blades, and machine parts, namely, blades; chisels for machines; electric chisels in the nature of chisels for machines; brushes being parts of machines, in particular, wire brushes; mixers in the nature of parts for mixing machines, namely, paint mixers, mortar mixers, adhesive mixers for craftsmen and DIY use; clamping spindles for mechanical tools in the nature of machine parts, namely, mandrels; clamping jaws being parts of machines, namely, machine tools, namely, jaws for use in the precision clamping of work pieces; turning and planing machines all in the nature of power operated metalworking machine tools, namely, turning tools, woodworking machines and planing machines; electric cartridge guns in the nature of a hand tool powered by electricity, with which silicon, acrylic, adhesives, glue, sealants and hot adhesives are pressed off a cartridge and applied to surfaces; pumps as parts of machines, motors and engines; tables for machines, namely, tables specially adapted to hold powered machinery; planing benches and turning lathes all being parts of machines; clamping and work tables being parts of machines all in the nature of tables specially adapted to hold powered machinery; electric cleaning machines and apparatus, namely, machines for cleaning surfaces using high pressure water; flexible shafts being parts of machines in the nature holders used for mounting brushes, drills, milling cutters and rasp files to drill machines; machine tool holders; parts of machines, namely, grinding wheels in the nature of power-operated grinding wheels, grinding plates in the nature of grinding tools for grinding machines, abrasive belts for power-operated sanders, abrasive strips in the nature of abrasive belts for power-operated sanders, abrasive sheets in the nature of abrasive disks for power-operated sanders, polishing bonnets in the nature of pads for polishing machines which polish high-gloss painted surfaces, non-ferrous metal surfaces, and stainless steel surfaces with grinding and polishing pastes, and polishing wheels, namely, polishing disks being parts of surface polishing machines in the nature of pads for polishing highgloss painted surfaces, non-ferrous metal surfaces, and stainless steel surfaces with grinding and polishing pastes; storage containers adapted for the aforesaid goods, in particular, cases, bags, boxes, caskets, assortment boxes and magazines all in the nature of machine tool holders; power tool accessories, namely, cutting guides in the nature of guide rails used as accessories for saws and other cutting devices to assist users in making precise, straight and long cuts in wood and other materials; adhesive bands, other than stationery and not for medical or household purposes, in the nature of adhesive bands for pulleys Hand tools, namely, glass cutters, scrapers, edge cutters, and cutters all being manually-operated hand tools for woodworking, plastics working and metal working, blades for manually-operated tools, non-electric strip and edge cutters, scissors, saws, saw blades and blades all for hand-operated tools, chisels, and boring tools in the nature of manual drills; knives and blades being hand tools, namely, trapezium blade knives being working knives, safety knives being working knives, cutters, snap-off blade knives being working knives, knives for insulating materials being working knives, fixed-blade knives, cable knives being working knives, circle cutters being working knives, precision knives being working knives, rolling knives being working knives, outdoor knives being working knives, folding knives, leisure knives being knives for hobby use, and carpet knives; hand tools, namely, non-electric tile and laminate cutters; mixers in the nature of stirring sticks for mixing paint, mortar, and adhesives, all being manually-operated hand tools; tool inserts for use with hand-operated tools, in particular, bit inserts and inserts for spanners being hand tools all in the nature of bit drivers for hand tools; clamping jaws for vices, namely, hand-operated metal vice jaws for use in the precision clamping of work pieces; hand tools, namely, clamps, in particular, screw clamps, spring clamps, ratchet clamps, mounting clamps, one-handed clamps and glue presses; hand-operated screwing tools, in particular, hand tools being screwdrivers, and screwdriver bits being bits drivers for hand-operated tools, and holders relating thereto in the nature of tool holders; non-electric hand drills; manual drills; drill bits for hand drills; hand tools, namely, milling cutters; milling drills, namely, drill bits for hand drills; rasp files in the nature of hand tools, namely, files; rasp files in the nature of hand tools, namely, rasps; countersinks, namely, hand countersinks being hand tools; bore saws and hole saws for hand tools all in the nature of hand tools, namely, saws; drill chucks for hand tools, namely, chucks for hand-operated tools; templates, namely, screwing and drilling templates, and templates for marking holes, in particular, for marking holes for electric switch boxes and sockets on ceilings, walls and floors all in the nature of hand tools, namely, manually-operated guides for drills; hand-operated guiding tools for drills and hole saws in the nature of hand tools, namely, manually-operated guides for drills; hand tools in the nature of milling cutters; hand-operated sharpening instruments; hand-operated blade sharpening instruments; hand-operated grinding wheels in the nature of hand tools being manually-operated grinding wheels; grinding plates in the nature of hand tools being manually-operated grinding wheels; cut-off wheels in the nature of hand tools being manually-operated grinding wheels; cut-off grinders in the nature of hand tools being manually-operated grinding wheels, and ceramic grinding pencils in the nature of grinding tips for hand-operated grinding wheels; grinders in the nature of all-purpose hand-operated sanders and surface sanders; hand tools in the nature of clamps, namely, frame clamps, angle clamps, clamping jaws, quick-release clamps; planes; hand tools, namely, cartridge guns in the nature of hand-operated guns for the extrusion of silicon, acrylic, adhesives, glue, sealants and mastics being pressed off a cartridge and applied to surfaces; pull bars, namely, crow bars; trowels being tools, in particular, brick trowels; spattles, in the nature of putty knives; tackers in the nature of hand-powered staple guns; mitre boxes; clamps, in particular, riveting plier in the nature of riveters being hand tools; hand tools, namely, rasps and files; spanners being hand tools; hand-operated striking tools, in particular, bats and tools shaped specifically for positioning and arranging laminate from the front side, and designed to enable gentle handling of laminates tongue and groove; handles for hand tools, in particular, telescopic handles, namely, handles for hand-operated hand tools; holders for all the aforesaid goods, namely, tool holders; dies and inserts for all the aforesaid goods all in the nature of dies for use with hand-operated tools and bit drivers for hand tools; hand tools, namely, manually-operated grinding wheels, grinding plates in the nature of manually-operated grinding wheels, abrasive belts in the nature of hand-operated sanders, abrasive strips in the nature of hand-operated sanders, abrasive sheets in the nature of hand-operated sanders; scribers being manually operated hand tools for woodworking, paper working, foil working, plastic working and leather working; storage containers adapted for the aforesaid goods, in particular, cases, bags, boxes, caskets, assortment boxes and magazines all in the nature of tool holders; packaging of metal adapted for hand-operated tools, namely, tool holders; bags sold empty, in particular, tool belt bags of textile, plastic, either or a combination of the aforesaid materials, all in the nature of tool pouches for attachment to tool belts; hand tool accessories, namely, cutting guides in the nature of guide rails used as accessories for saws, knives and other cutting devices to assist users in making precise, straight and long cuts in wood and other materials; hand tools, namely, sponges in the nature of sanding sponges used to smooth surfaces; dowel fixings of metal in the nature of hand tools, namely, manually-operated guides for marking dowel holes Measuring apparatus and instruments, in particular, measuring rods in the nature of leveling rods for surveying, rules being measuring instruments in the nature of measuring rulers; displacement gauges in the nature of level gauges, and goniometers in the nature of measuring apparatus, namely, angle finders; measuring instruments, namely, angle bevels; gauges, in particular, contour gauges in the nature of profile gauges; spirit levels; rulers being measuring instruments; protective eyewear; welding goggles; protective masks not for medical purposes; respiratory masks and protective mouth masks, in particular, fine dust masks and half masks all in the nature of respiratory masks for non-medical purposes, and dust masks; filters for protective masks, respiratory masks and protective mouth masks all in the nature of non-medical respiratory mask filters; protective helmets; protective work gloves; protective work clothing, in particular, disposable protective overshoes all for protection against accidents; spectacle cases; storage containers adapted for the aforesaid goods, in particular, cases, bags, boxes, caskets, assortment boxes and magazines all being specially adapted containers for holding protective eyewear; laminate fitters being measuring instruments, namely, instruments for measuring and transferring length all in the nature of instruments for measuring length, and apparatus for recording data for use in the field of transferring data concerning length of objects; dowel bars being measuring tools in the nature of instruments for measuring length Ear protectors, ear defenders and ear protection apparatus, namely, ear plugs and headphones for soundproofing and protecting users from loud sounds and loud environments; parts, spare parts and accessories for the aforesaid goods, namely, cases for ear plugs for soundproofing Lamps, in particular pocket torches, namely, pocket searchlights; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines, bags and cases specially adapted for holding or carrying pocket searchlights Apparatus for locomotion by land, in particular trolleys, hand trucks and push carts; luggage nets for vehicles and vehicle trailers Paper, cardboard; packaging materials of cardboard; plastic materials for packaging, namely, plastic sheets for packaging, plastic films for packaging and blister packs being plastic packaging materials consisting of a transparent, moulded piece of plastic sealed to a sheet of cardboard for packaging and displaying merchandise; pouches, envelopes, bags of paper and plastic, for packaging; packaging of paper or plastic, namely, paper envelopes and plastic bags, for packaging adapted for hand-operated and/or mechanically operated tools; cardboard and cardboard packaging for presenting goods; paint brushes; paint rollers; painters' brushes; stencils; garden waste bags of plastic in the nature of plastic garbage bags; glues for stationery or household purposes; printed matter, in particular catalogues in the field of tools and other products for DIY purposes; marking and drawing templates, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors Protective sheets of plastic films, namely, re-closable curtains or hangings all in the nature of barrier curtains in the nature of floating baffles or booms for the containment of pollutants, that provide access to a work area, and provide a means to seal doors and other structural openings to prevent dust and other particles from moving from one room to another; adhesive tapes and bands, other than stationery and not for medical or household purposes in the nature of adhesive tape for industrial and commercial use Tool bags sold empty, in particular tool bags of textile, plastic, leather either or a combination of the aforesaid materials; cases, namely, tool cases of leather in the nature of tool bags, sold empty; tool pouches sold empty; parts, spare parts and accessories for all the aforesaid goods all in the nature of straps for carrying tool bags Furniture, in particular, tables, cupboards, shelves, storage racks, benches, work benches, vice benches being furniture and not of metal, industrial work tables and work tables for DIY purposes; furniture, in particular, industrial work tables designed for use while operating turning lathes and for clamping, and industrial work tables designed for use while operating milling, drilling, sawing, grinding and polishing machines, all the foregoing not being tables specially adapted to hold powered machinery; supporting trestles in the nature of non-metal trestles for supporting tables, saw horses and roller blocks being industrial work tables, not for use in construction; storage racks, not of metal, for storing firewood; goods carrier displays for displaying goods in the nature of furniture for displaying goods; showcases for presenting goods in the nature of furniture, namely, showcases; fastening materials, not of metal, in the nature of non-metal threaded fasteners; spacer wedges, not of metal, in the nature of non-metal hardware, namely, spacer used in the installation of flooring and door frames and window frames; clamps being cramps, not of metal in the nature of non-metal clamps; troughs of plastic for mixing mortar; wooden dowels in the nature of dowels not of metal; wooden pegs; empty storage containers, not of metal, namely, plastic storage containers for commercial or industrial use; empty storage containers, not of metal, in particular, cases, boxes, caskets, assortment boxes and magazines for tools, tool inserts, ironmongery, small items of metal hardware all in the nature of plastic storage containers for commercial or industrial use; packaging containers, not of metal, namely, packaging containers of plastic; storage containers adapted for the aforesaid goods, in particular, cases, bags, boxes, caskets, assortment boxes and magazines all in the nature of plastic storage containers for commercial or industrial use; vice benches of metal, namely, vice benches being furniture; storage racks of metal, in particular, for storing firewood steelwool; brushes, namely, wire brushes, not being machine parts; drill buckets, namely, buckets comprising a tool bucket organizer in the nature of an organizer specially adapted for affixation to the bucket for holding tools; plaster buckets, not of metal in the nature of plastic buckets for storing plaster tarpaulins; lashing straps and load-bearing straps, not of metal, including in the form of non-metal ratchet belts all in the nature of belts, not of metal, for handling loads; belt tensioners and tensioning straps, not of metal all in the nature of polypropylene straps for securing bundles; tensioning rubber bands and cover expanders, namely, elastic wrapping or binding cordage to hold down or store cargo; accessories for lashing straps, belt tensioners and tensioning straps, namely, strap protection plates not of metal in the nature of protective liners of flexible vinyl for securing bundles, and belt tensioners and tensioning straps in the nature of polypropylene straps for securing bundles; tensioning rubbers, lashing straps, including in the form of ratchet belts and tensioning straps all in the nature of nylon strapping or tie downs Baseball caps; disposable clothing, namely, overalls and shoe covers for use when wearing shoes; footwear; headwear Hook-and-loop strips, namely, hook-and-loop fasteners for the fixing, bundling, and retaining of cables and for tying in plants; straps and fastening tapes, including self-adhesive, in particular, including for the fixing, bundling and retaining of cables and for tying in plants all in the nature of hook and pile fastening tapes; dowel fixings for marking dowel holes, namely, center points in the nature of marking pins for marking dowel holes Wholesale and retail store services, including by means of teleshopping programs and online and catalogue mail order, in the fields of construction and DIY articles and other commodity goods for the professional and DIY sectors, machines, tools and goods of common metal, construction, craft and garden articles, hobby requisites and craft supplies, industrial personal safety equipment and clothing; publication of printed matter, including in electronic form, for advertising purposes; presentation of goods on communication media, for wholesale and retail purposes; auctioneering, including on the Internet; arranging commercial transactions, for others, including within the framework of e-commerce; arranging contracts, for others, for the buying and selling of goods

Goods & Services

Glue for industrial purposes; wood glues. Cleaning, polishing, scouring and abrasive preparations; Furbishing preparations; Abrasive paper, Canvas (abrasive preparations); Polishing paste. Vice benches of metal; Ironmongery, small items of metal hardware; Storage racks of metal, in particular for storing firewood; Guide rails of metal; Metallic mountings; Screws, nails, clips and staples of metal; Metal hooks; Rivets; Cotter pins and spacer wedges of metal; Cramps of metal; Strips and spacer strips of metal, Ceiling supports of metal; Metal building materials; Solder wires and welding wires; Empty storage containers of metal, in particular cases, boxes, cassettes, assortment boxes and magazines, all the aforesaid for tools, tool inserts, ironmongery and small items of metal hardware; Packaging containers of metal; Ferrules of metal; Lashing straps and belts of metal for handling loads, including in the form of ratchet straps; Belt tensioners and tensioning straps of metal; Strap protection plates of metal for lashing straps, belts for handling loads, belt tensioners, Tightening straps, Tensioning rubbers and cover expanders; Perforated panel systems, perforated panel hooks and perforated panel holders of metal for the presentation of goods; Dowel strips of metal; Dowel centre points of metal for marking dowel holes; Packaging of metal for hand-operated and/or mechanically operated tools, storage containers adapted for the aforesaid goods, in particular cases, bags, Chests, Coffers, Assortment boxes and Magazines; Parts, spare parts and fittings for all the aforesaid goods, included in class 6. Mechanical tools; Machines for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Mechanically operated tools and apparatus for mechanical engineering, apparatus construction, tool construction and vehicle construction, electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Hand-operated driving motors intended for stationary installation for driving tools, including accessories (included in class 7); Tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling inserts; Mechanically-driven screwdrivers, In particular screwdrivers and screwdriver inserts (bits for mechanical tools), and holders relating thereto; Electrically, pneumatically or compressed-air operated drilling machines and hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; Drill stands and drilling aids for electric drilling machines; Drill chucks for mechanical tools; Drill stands and drilling aids for electric, pneumatic or compressed-air operated drilling machines; Templates (parts of machines), in particular drilling and milling templates; Milling stops; Depth stops for dills (parts of machines); Milling cutters (mechanical tools); Rammers (machines), whetstones (parts of machines); Disc grinders, Backing pads, Grinding wheels, Cut off wheels, Ceramic mounted points (machine parts); Cutting tools being power-operated; Blades [parts of machines]; Electric hole cutters; Electric tile and laminate cutters; Cutters [machines]; Electric strip and edge cutters; Saws (machines), in particular hole saws, circular saws and chain saws; Saw blades and blades for mechanical tools; Chisels for machines; Electric shears; Brushes (parts of machines), in particular wire brushes; Mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; Mechanical clamping, stretching and expanding tools and devices; Mandrels for mechanical tools; Vice clamps (parts of machines); Anchoring aids (parts of machines); Pneumatic tools (parts of machines); Turning and planing machines; electric cartridge guns; Pumps [parts of machines, engines or motors]; Tables for machines; Supporting trestles, work trestles, sawhorses and roller blocks (parts of machines); Planing benches and wood-turning lathes (parts of machines), clamping and work tables being parts of machines; Electric and non-electric soldering and welding tools; Cleaning (Machines and apparatus for -), electric; flexible shafts (machine parts); Holders (parts of machines) for all the aforesaid goods; Handles for mechanical tools, in particular telescopic handles; Machine parts, namely abrasive wheels, Backing pads, Abrasive belts, Abrasive strips, sanding pads, Polishing bonnets, Polishers, Rotary cleaning heads; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Compressed air fittings in the form of compressed air apparatus, packaging adapted for mechanically operated tools; Parts, spare parts and fittings for all the aforesaid goods, included in class 07. Manually operated tools; Hand-operated implements for agricultural, horticultural and forestry purposes, for mechanical engineering, apparatus construction, tool construction and vehicle construction, and for electrical and construction engineering, metal, wood, plastic and stone processing, television, radio and car repair, plumbing, masonry, upholstering, painting, carpentry, watchmaking, floor laying and tiling, installations, and DIY; Tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners (tools); Vices; Clamping jaws for vices; Braces (hand tools), In particular screw clamps, Spring clamps, Ratchet clamps, installation clamps, One-handed bar clamps and Glue presses; Screwdrivers (hand-operated), In particular screwdrivers and screwdriver inserts (bits for hand-operated tools) and holders relating thereto; Non-electric hand drills; Drills, drilling bits, conduit hole saws, milling cutters, burrs, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; Drill stands and drilling aids for non-electric drilling machines; drill chucks (hand tools); Templates, namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Guiding apparatus for drills and hole saws; Milling cutters [hand tools]; Sharpening instruments; Blade sharpening instruments; Hand-operated grinding wheels, grinding plates, cut-off wheels, disc grinders and ceramic mounted points; Grinders (hand tools), Abrading instruments [hand instruments]; Cutlery; Cutting tools [hand tools]; Glass cutters; Blades [hand tools], Box cutters and Scissors; Scrapers [hand tools]; Mitre boxes, Edgers, Cutters; Blades (parts of hand tools); Hand-operated hole cutters; Non-electric tile and laminate cutters; Cutting aids (hand tools); Non-electric strip and edge cutters; Saws [hand tools]; Saw blades and blades for hand-operated tools; Graving tools [hand tools], In particular including bits; Mixers (inserts for hand tools), in particular paint mixers, mortar mixers, adhesive mixers; Hand-operated clamping, stretching and expanding tools and devices, in particular belt tensioners, Frame tensioners, Angle clamps, clamp jaws, Quick-release clamps, tensioning rubbers, lashing belts, including in the form of ratchet straps, and tensioning straps; Expanders (hand tools); Dowelling apparatus and anchoring aids (hand-operated tools); Planes; cartridge guns [hand tools]; Hand pumps; Pulling irons; Trowels (tools), in particular brick trowels; Putty knives, tackers; Mitre [miter (Am.)] boxes [hand tools]; Pliers, in particular riveting pliers; Rasps and files (hand tools); Squares [hand tools]; Angle bevels (hand tools); Spanners; Spacers (hand tools); Hand-operated striking tools, in particular bats; Handles for hand tools, In particular telescopic handles; Holders for all the aforesaid goods; Dies and inserts for all of the aforesaid goods; Hand held tools, Namely abrasive wheels, Backing pads, Grinding belts, Abrasive strips, sanding pads, Polishing bonnets, Polishing and buffing discs, Polishing heads; Scribers (tools); Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Wire brushes [hand-operated tools]; Packaging adapted for hand-operated tools; Parts, spare parts and accessories for the aforesaid goods, included in class 8. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Measuring apparatus and instruments, In particular height gauges, Rules [measuring instruments] and Dial indicators; Displacement gauges and protractors (measuring instruments); Angle bevels (measuring instruments); Gauges, In particular contour gauges; Bubble levels; Rulers [measuring instruments]; Safety goggles, Welding goggles; Protective masks, Respiratory masks and Protective mouth masks, in particular fine dust masks and half-masks; Filters for protective masks, respiratory masks and protective mouth masks; Head protection, Gloves for protection; Protective workwear, In particular disposable protective and safety clothing, and disposable protective overshoes; Spectacle cases; Storage containers adapted for the aforesaid goods, in particular cases, Bags, boxes, Cassettes, Assortment boxes and Magazines; Laminate fitters being measuring instruments; Dowel strips being measuring tools; Parts, replacement parts and accessories for the aforesaid goods, included in class 9; Electronic publications, downloadable. Ear protection devices (ear plugs); Parts, spare parts and accessories for the aforesaid goods included in class 10. Electric torches, especially pocket torches; Suction cups for changing lighting devices; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Parts, spare parts and accessories for all the aforesaid goods, included in class 11. Apparatus for locomotion by land, In particular handling carts, Sack trucks and Push trolleys; Luggage nets for vehicles and vehicle trailers; Parts and spare parts for all the aforesaid goods, included in class 12. Paper cardboard; Fiberboard boxes; Plastic materials for packing (not included in other classes); Bags [envelopes, pouches] of paper or plastics, for packaging; Packaging of paper or plastic for hand-operated and/or mechanically operated tools; Cardboard and/or cardboard packaging for presenting goods; Paint brushes, paint rollers; Painters' brushes; Painting templates; Garden waste bags of plastic; Pastes and other adhesives for stationery or household purposes; Printed matter, in particular catalogues; Stencil plates, Namely screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; Parts, spare parts and fittings for all the aforesaid goods, included in class 16. Plastic film, not for wrapping; Protective sheaths of plastic films; Adhesive bands, other than stationery and not for medical or household purposes; Supports of plastic being finished products. Bags (empty), in particular tool bags and tool belt bags of textile, plastic, leather or a combination of these materials; Empty cases, in particular tool chests; Empty leather cases; Parts, replacement parts and accessories for the aforesaid goods, included in class 18. Manufactured timber, In particular small parts of wood; Building material (non-metallic); Strips and spacer strips, not of metal; Ceiling supports, not of metal, strips of wood for construction purposes. Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches, not of metal, planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); Supporting trestles, work trestles, sawhorses and roller blocks (other than being parts of machines); Storage racks, not of metal, for storing firewood; Merchandise displays for displaying goods; Showcases for presenting goods; Non-metallic tracks; Fasteners, non-metallic; Cotter pins and spacer wedges, not of metal; Crampons, not of metal (cramps); Troughs of plastic for mixing mortar; Strips of wood for frames; Pegs of wood, Pins of wood; Empty storage containers, not of metal; Empty storage containers, not of metal, in particular cases, boxes, cassettes, assortment boxes and magazines for tools, tool inserts, ironmongery and small items of metal hardware; Packaging containers not of metal; Dowel centre points for marking dowel holes; Clips of plastic for cables and plants; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Plaster mixing bowls, not of metal; Parts, spare parts and fittings for all the aforesaid goods, included in class 20. Sponges; Steelwool; Hand-operated cleaning implements; Brushes; Brushes (Electric -), except parts of machines; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Parts, spare parts and fittings for the aforesaid goods, included in class 21. Tarpaulins; Lashing straps and belts, not of metal, for handling loads, including in the form of ratchet straps; Belt tensioners and tensioning straps, not of metal; Tensioning rubbers and cover expanders; Strap protection plates, not of metal, for lashing straps, Load-bearing straps, Belt tensioners, Tightening straps, Tensioning rubbers and cover expanders; Storage containers adapted for the aforesaid goods, in particular suitcases, bags, boxes, cassettes, assortment boxes and magazines; Parts, replacement parts and accessories for the aforesaid goods, included in class 22. Baseball caps; Disposable apparel; Clothing, footwear, headgear. Hook-and-loop straps, including self-adhesive, including in particular for fixing, bundling and retaining cables and for tethering plants. Mats, In particular non-slip mats, including for fixing loads. Wholesaling and retailing, including by means of teleshopping programmes and online and catalogue mail order, in the fields of construction and DIY articles and other consumer goods for the professional and DIY sector, machines, tools and goods of metal, construction, craft and garden articles, hobby requisites and craft supplies, personal work safety equipment and clothing; Presentation of offers for goods in the fields of construction and DIY articles and other consumer goods for the professional and DIY sector, machines, tools and goods of metal, construction, craft and garden articles, hobby requisites and craft supplies, personal work safety equipment and clothing; Publication of printed matter (including in electronic form), for advertising purposes; Presentation of goods on communications media for wholesale and retail purposes; Auctioneering, including on the Internet; arranging commercial transactions for third parties, also within the framework of e-commerce; Arranging of contracts for others for the buying and selling of goods.

Abstract

The invention relates to a piston assembly comprising a piston for a cartridge discharging device (1) for discharging a pasty compound out of a cartridge (9) which has an inner wall (10), having a piston (11) and a rear face (12) which can be acted upon by a pressure plate (8) secured to a push rod (7), a front face (13) opposite the rear face, and a retaining element (16) which secures the pressure plate (8) against the rear face (12) by means of a retaining protrusion (18) which covers an edge (8') of the pressure plate (8) in a retaining position. The aim of the invention is to develop such a piston assembly comprising a piston for a cartridge discharging device so as to be advantageous for use. According to the invention, this is achieved in that the retaining protrusion (18) is secured to the piston (11) in a movable manner into a release position in a direction away from the push rod (7).

IPC Classes  ?

• B05C 17/005 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure
• B65D 83/00 - Containers or packages with special means for dispensing contents
• B05C 17/01 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure with mechanically or electrically actuated piston or the like

Abstract

The invention relates to a tool comprising a shaft (1) that can be driven about an axis of rotation (A) and a rotatably operating tool head (3) that is connected to said shaft and has a working section (8) extending over an axial distance, a depth limiter (12) that can be fixed to the shaft (1) in different axial positions by means of a radially movable restraining element comprising an abutment surface (21) lying in the axial positions in the working section (8). The shaft (1) has a plurality of positioning recesses (10) arranged on a spiral load curve (9) and the restraining element a tip (15) that selectively engages in one of the plurality of positioning recesses (10). The axial distance (b) between the centres of two directly adjacent positioning recesses (10) is less than the diameter (D) of the positioning recess (10).

IPC Classes  ?

• B23B 49/005 -
• B23B 49/00 - Measuring or gauging equipment on boring machines for positioning or guiding the drillDevices for indicating failure of drills during boringCentring devices for holes to be bored
• B23B 51/00 - Tools for drilling machines
• B23B 51/10 - Bits for countersinking

Abstract

The invention relates inter alia to a device for fixing to an end of a measuring rod (1), comprising a housing (9, 12) forming a stop (7), against which an end edge (2) of the measuring rod (1) can be applied, fixing means for restraining the housing (9, 12) to the measuring rod (1), and a scribing edge (6) for applying a knife or a scribing means (14). The scribing edge (6) is formed by an inner edge of a peripherally enclosed window (5) of a leaf (4) that protrudes transversely from the housing (9, 12) with respect to extension direction of the measuring rod (1).

IPC Classes  ?

• G01B 3/10 - Measuring tapes
• G01B 3/06 - Rulers with scales or marks for direct reading rigid folding

Abstract

The invention relates to a hole saw comprising a holding element (2) that can be made to rotate by the rotation of a clamping shaft (1) about an axis (A) and that has, on its side facing away from the clamping shaft (1), fastening pockets (6, 7) which extend radially to the axis (A), at least one of the fastening pockets (6, 7) being associated with a saw element (8), and said saw element (8) having a fastening element (9) that rests on a bottom surface (6'') of the fastening pocket (6, 7). Two lateral faces (9') of the fastening element (9) lie on respective lateral flanks (6', 7') of the fastening pocket (6, 7). The fastening element (9) is screwed into a slide block (13) having an internal screw thread (13) from the side of the fastening element (9) by means of a screw (12), said slide block being radially movable, guided by guide surfaces (14). The radially extending fastening pockets (6, 7) are arranged about the axis (A) evenly distributed over the circumference and their bottom surfaces (6'', 7'') have round holes (15) and slotted holes (15'). The edges of said slots form stops for the threaded shanks (12') and are arranged such that the saw teeth (11) of at least three saw elements (8) can be arranged jointly about the axis (A) on circular lines of different diameters.

IPC Classes  ?

• B23B 51/05 - Tools for drilling machines for trepanning for cutting discs from sheet

Abstract

The invention relates to a cartridge press with an actuating housing (1), comprising a lever (2), the movement thereof relative to the actuating housing (1) in an actuating direction moving a push rod (4), that is mounted such that it can be displaced in the actuator housing (1), in a push direction, and comprising receiving means (10) for receiving a pasty mass (29) that can be pressed out from a pipe or a cartridge by moving the push rod (4). The receiving means (10) is mounted so as to rotate on the actuator housing (1), wherein a securing base (11) comprising an opening (12) through which the push rod (4) passes protrudes into a securing opening (13) and is fixed, axially in relation to the push rod (4) by a positive-locking fastening means. According to the invention, the positive-locking means is formed by a securing disk (15) which is inserted into a radial shaft (14) and which engages by means of a locking flange (17) in an annular groove (16) of the securing base (11).

IPC Classes  ?

• B05C 17/01 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure with mechanically or electrically actuated piston or the like
• B05C 17/005 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure
• B65D 83/00 - Containers or packages with special means for dispensing contents

Goods & Services

Glues for commercial purposes Cleaning, polishing, scouring and abrasive preparations; cleaning preparations; abrasive preparations, namely, abrasive paper and abrasive canvas; polishing pastes Screws, nails, clamps and tacker clips of metal; fastening and spacer wedges of metal; clamps and cramps of metal; spacer strips of metal, ceiling supports of metal; soldering and welding wire; empty storage containers of metal, in particular general purpose cases and caskets, boxes, assortment boxes and general purpose storage magazines for hardware, all for tools, tool inserts, ironmongery, small items of metal hardware; clamps of metal; lashing straps and load-bearing straps of metal, including in the form of ratchet belts; perforated panel walls of metal for use in hanging walls; perforated panel hooks and perforated panel holders of metal for presenting goods Tool inserts for use with mechanically operated tools, namely, drill bits and milling bits for power-operated milling, boring and drilling machines; mechanically operated screwing tools, in particular power-operated screwdrivers and bits for power-operated screwdrivers, and holders relating thereto; electrically or pneumatically operated drilling machines and hand drills; drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws, all specifically for use with power-operated drills and drilling machines; drill stands and drilling aids for electric drilling machines; drill chucks for power-operated mechanical tools; drill stands and drilling aids for electrically or pneumatically operated drilling machines; templates being parts of milling machines and drilling machines; milling stops being parts of milling machines; bit stops for drills being parts of drilling machines; power-operated milling cutters; grinding wheels being parts of grinding machines; cut-off grinders, grinding plates, being parts of grinding machines, grinding discs for use with cut-off grinders, cut-off wheels for use with cut-off grinders, ceramic grinding pencils being part of grinders; blades for use with power-operated saws; electric tile and laminate cutters; saw blades and blades for mechanical tools all for use with power-operated saws; chisels for machines; electric chisels; brushes being parts of machines, in particular wire brushes; mixers being parts of machines, in particular paint mixers, mortar mixers, adhesive mixers; power-operated mechanical clamping, stretching and expanding tools; clamping spindles for power-operated mechanical tools; clamping jaws being parts of machines; dowelled joint auxiliary apparatus being parts of machines; turning and planing machines; electric cartridge guns in the nature of a hand tool powered by electricity, with which silicon, acrylic, adhesives, sealants and other materials are pressed off a cartridge and applied to surfaces; pumps being parts of machines or motors and engines; tables, specially adapted to hold powered machinery; planing benches and turning lathes being parts of machines; flexible shafts being parts of machines; machine tool holders; parts of machines, namely, grinding wheels, grinding plates, abrasive belts, abrasive strips, abrasive sheets, polishing bonnets, polishing wheels, polishing heads; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines all specially adapted for holding power-operated drills and bits; power tool accessories, namely, cutting guides in the nature of guide rails used as accessories for saws and other cutting devices to assist users in making precise, straight and long cuts in wood and other materials; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines, all being containers specially adapted for holding bits for power drilling machines and power operated screwdrivers Tool inserts for use with hand-operated tools, in particular bit inserts for manually-operated bit drivers and inserts for spanners; vices; clamping jaws for vices; clamps being hand tools, in particular screw clamps, spring clamps, ratchet clamps, mounting clamps, one-handed clamps and glue presses; hand-operated screwing tools, in particular screwdrivers and screwdriver bits for hand-operated tools, and bit holders relating thereto; manually-operated hand tools and parts thereof, namely, drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; drill chucks for manually-operated hand tools; templates, namely, screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors all specifically designed for use with manually-operated drills and screwdrivers; guiding apparatus, namely, manually-operated guides for drills and hole saws; hand tools, namely, milling cutters; hand-operated sharpening instruments; hand-operated blade sharpening instruments; hand-operated sharpening instruments in the nature of grinding wheels, grinding plates, cut-off wheels, cut-off grinders and ceramic grinding pencils; grinders in the nature of allpurpose sanders, surface sanders, abrasives in the nature of sanding and polishing discs, handheld sanders, sanding discs for use in corners, abrasives in the nature of sanding paper and sanding blocks made of cork, plaster and fibers, and sanding sheets used as a handheld grinder for wood, steel and plastic; hand-operated grinding apparatus; cutting tools, namely, trapezium blade knives, safety knives, cutters, snap-off blade knives, knives for insulating materials, fixed-blade knives, cable knives, circle cutters, precision knives, rolling knives, outdoor knives, folding and leisure knives; glass cutters; knives being hand tools, namely, trapezium blade knives, safety knives, cutters, snap-off blade knives, knives for insulating materials, fixed-blade knives, cable knives, circle cutters, precision knives, rolling knives, outdoor knives, folding and leisure knives, carpet knives and scissors; scrapers being hand tools; mitre boxes, edge cutters, and cutters all being manually-operated hand tools for woodworking, plastics working and metal working; blades for manually-operated tools; hand tools, namely, non-electric tile and laminate cutters; hand tools, namely, non-electric laminate fitters; non-electric strip and edge cutters; saws being hand tools; saw blades and blades all for hand-operated tools; chisels being hand-operated tools, in particular including boring tools; mixers, in particular paint mixers, mortar mixers, adhesive mixers, all being manually-operated hand tools; hand-operated clamping, stretching and expanding tools, in particular belt tensioners, frame clamps, angle clamps, clamping jaws, quickrelease clamps, tensioning rubbers, lashing straps, including in the form of ratchet belts and tensioning straps, all being manually-operated hand tools for woodworking, plastics working and metal working; Hand tools, namely, planes; cartridge guns, namely, handheld devices used to apply silicone, acrylic, adhesives, sealants, bitumen and other substances to surfaces by way of applying pressure to cartridges filled with those substances; pull bars, namely, crow bars; trowels, in particular brick trowels; spattles, in the nature of putty knives; tackers, in the nature of hand-powered staple guns; mitre boxes; clamps, in particular hand-operated riveting pliers; rasps and files being hand tools; spanners; hand-operated striking tools, in particular bats and tools shaped specifically for positioning and arranging laminate from the front side, and designed to enable gentle handling of laminates tongue and groove; handles for hand-operated hand tools, in particular telescopic handles; holders for all the aforesaid goods, namely, tool holders for hand tools; parts for manually-operated hand tools, namely, grinding wheels, grinding plates, abrasive belts, abrasive strips, abrasive sheets, polishing bonnets, polishing wheels, polishing heads; scribers being manually operated hand tools for woodworking, paper working, foil working, plastic working and leather working; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines, all being specially adapted for holding manually-operated hand drills and bits therefor; vice benches of metal; suction cups for changing lighting devices, namely, hand-operated tools for installing and removing light bulbs; hand tool accessories, namely, cutting guides in the nature of guide rails used as accessories for saws, knives and other cutting devices to assist users in making precise, straight and long cuts in wood and other materials; hand tools, namely, sanding sponges used to smooth surfaces Measuring apparatus and instruments, in particular measuring rods for surveying, graduated rulers; displacement gauges and goniometers; angle bevels being measuring instruments; gauges, in particular contour gauges; spirit levels; rulers being measuring instruments; protective eyewear, welding goggles; protective masks, respiratory masks and protective mouth masks, in particular fine dust masks and half masks all for non-medical purposes; filters for protective masks, respiratory masks and protective mouth masks all for non-medical purposes; protective helmets, protective gloves for industrial use, for protection against accidents; protective work clothing, in particular disposable protective and safety clothing, and disposable protective overshoes all for protection against accidents; spectacle cases; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines all being specially adapted containers for holding protective eyewear; measuring apparatus, namely, angle bevels; marking gauges for joinery purposes in the nature of dowel fixings of metal for marking dowel holes, namely, center points of metal drilled into one piece of wood to mark the exact position on the second piece of wood where holes can be drilled, after which the dowel fixings are removed so both pieces of wood can be held together with dowels ear protectors, ear defenders and ear protection apparatus, namely, ear plugs and headphones for soundproofing and protecting users from loud sounds and loud environments; parts, spare parts and accessories for the aforesaid goods, namely, cases for ear plugs for soundproofing lamps, in particular electric pocket torches apparatus for locomotion by land, in particular trolleys, hand trucks and push carts; luggage nets for vehicles and vehicle trailers Paper, cardboard and goods made from these materials, namely, cardboard boxes; packaging materials of cardboard; plastic materials, namely, plastic film, plastic sheets for packaging; pouches, envelopes, bags of paper or plastic, for packaging; packaging of paper or plastic, namely, paper envelopes and plastic bags, for packaging adapted for hand-operated and/or mechanically operated tools; cardboard and/or cardboard packaging in the nature of presentation folders for presenting goods; paint brushes, paint rollers; painters' brushes; stencils; garden waste bags of plastic; glues for stationery or household purposes; printed matter, in particular catalogues in the field of tools and other products for DIY purposes; marking templates, namely, screwing and drilling templates, and templates for marking holes, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; glues for wood for household use and DIY use protective sheaths of plastic films, namely, re-closable curtains or hangings that provide access to a work area, and provide a means to seal doors and other structural openings to prevent dust and other particles from moving from one room to another; adhesive tapes and bands, other than stationery and not for medical or household purposes wooden rods for building purposes Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches, planing benches; Furniture, in particular work tables for turning lathes and for clamping, work tables for milling, drilling, sawing, grinding and polishing; supporting trestles, namely, stand-alone structures, workstands and roller stands on which construction materials can be placed and worked on; sawhorses; roller blocks, namely, rollers on which construction materials can be placed to work; storage racks, not of metal, for storing firewood, namely, a rack consisting of two long horizontal bars with a space in between, turned up at both corners, and used to store cut logs; supporting pads of plastic being points of support for base structures, namely, plastic support pads placed under deck boards to create distance between a foundation and deck joists, and to prevent waterlogging; furniture, namely, goods display units for displaying goods; furniture, namely, showcases for presenting goods; fastening and spacer wedges, not of metal; clamps, not of metal; troughs of plastic for mixing mortar; wooden dowels, wooden pegs; packaging containers, not of metal, for commercial use; storage racks of metal, in particular for storing firewood; mats, in particular non-metallic non-slip or anti-skid mats for use as load support surfaces in the fields of construction, shipping and cargo transport Steelwool; brushes, in particular wire handheld brushes; plaster buckets Awnings of textile; tarpaulins; lashing straps and load-bearing straps made of polyester fibre, in the form of ratchet belts; belt tensioners and tensioning straps made of polyester fibre; tensioning rubber bands and cover expanders, namely, elastic wrapping or binding cordage to hold down or store cargo, tie down tarpaulins, or related uses; storage containers adapted for the aforesaid goods, in particular fitted cases for storing tarpaulins Baseball caps; disposable clothing, namely, overalls and shoe covers for use when wearing shoes; footwear hook-and-loop bands, including self-adhesive, in particular including for the fixing, bundling and retaining of cables and for tying in plants Wholesale and retail store services, including by means of teleshopping programs and online and catalogue mail order, in the fields of construction and DIY articles and other commodity goods for the professional and DIY sectors, machines, tools and goods of common metal, construction, craft and garden articles, hobby requisites and craft supplies, industrial personal safety equipment and clothing; publication of printed matter, including in electronic form, for advertising purposes; presentation of goods on communication media, for wholesale and retail purposes; auctioneering, including on the Internet; arranging commercial transactions, for others, including within the framework of e-commerce; arranging contracts, for others, for the buying and selling of goods

Abstract

The invention relates to a transport device, in particular for furniture, with at least two identically configured transport elements (1) which each have a rectangular carrying plate (3) carried by at least two, preferably three or four running elements (2), wherein paired opposite edges (5-8) of the carrying plate (3) have coupling projections (25, 35, 35', 37, 37', 39) and coupling recesses (24, 24', 34, 36, 38, 38') which intermesh in a form-fitting manner when two transport elements (1) are connected. The coupling projections are teeth which extend in the plane of extent of the carrying plate (3) and, by means of a mere horizontal shifting of at least two transport elements (1) relative to each other, engage in the tooth gaps which are formed by the coupling recesses and extend in the plane of extent of the carrying plate (3). The two transport elements (1) are fastened to each other by means of connecting elements (4).

IPC Classes  ?

• B62B 5/00 - Accessories or details specially adapted for hand carts
• B62B 5/06 - Hand moving equipment, e.g. handle bars

Abstract

The invention relates to a transport device, in particular for furniture, comprising two transport elements (1, 1'), which have in each case a support plate (3) supported by at least two running members (2), and connecting members (4), by which the transport elements (1, 1') can be connected to each other in different arrangements, wherein, in a parallel arrangement, two longitudinal edges (5, 7) of the support plates (3) bear against one another. The support plates (3) can be attached to the connecting members (4, 4', 22) also in a V position, for which purpose the connecting members (4, 4') have two spaced-apart fastening points (15) which can be fastened at different fastening points (14, 14', 16) on one of the support plates (3).

IPC Classes  ?

• B62B 5/00 - Accessories or details specially adapted for hand carts
• B62B 5/06 - Hand moving equipment, e.g. handle bars
• B62B 3/00 - Hand carts having more than one axis carrying transport wheelsSteering devices thereforEquipment therefor

Abstract

A tile cutter having a base frame with a base plate and a guide which is disposed above the base plate and along which a slide carrying a cutting tool is displaceable in order to produce a score on the surface of a tile resting on the base plate, and having a breaker jaw device which is gear-coupled to the slide and is lowered onto the surface of the tile in the end phase of the displacement of the slide in order to break the tile along the score. The breaker jaw device and the slide interact with one another via a control flank arrangement in order to lower the breaker jaw device.

IPC Classes  ?

• B28D 1/22 - Working stone or stone-like materials, e.g. brick, concrete, not provided for elsewhereMachines, devices, tools therefor by cutting, e.g. incising

Abstract

A detachable blocking device, in particular on a clamping tool, having a blocking element, which blocks the displacement capability of a rod in at least one detachment direction in a blocking position, and a detachment member, which displaces the blocking element into a release position when moved from a default position into a detachment position, in which release position the rod can be displaced at least in the detachment direction. A brake element, in a braking position, acts on the rod so that the rod can only be displaced after neutralization of a braking force acting against the displacement direction of the rod, which braking force does not have to be neutralized in a sliding position of the brake element. The brake element has a brake lever and/or can be brought into its sliding position by pivoting an arm of the detachment member having a detachment lever.

IPC Classes  ?

• B25B 5/16 - Details, e.g. jaws, jaw attachments
• B25B 5/06 - Arrangements for positively actuating jaws
• F16B 2/18 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening using cams, levers, eccentrics, or toggles

Abstract

A device for connecting two clamps, each of which has a rail, including a housing that has two insertion openings, which point away from each other and each of which has an adjoining insertion channel, for inserting a respective rail. The device also includes at least one adapter piece which can be inserted into one of the insertion openings and which reduces the free opening cross section of the insertion channel in order to insert a rail with a different cross-sectional area. The adapter piece has a lining which adjoins a collar. The lining rests against the wall of the insertion channel at least in some regions and forms an insertion channel with a reduced cross section in the inserted state, and the collar rests on an end face of the housing.

IPC Classes  ?

• B25B 5/00 - Clamps
• B25B 5/06 - Arrangements for positively actuating jaws
• B25B 5/10 - Arrangements for positively actuating jaws using screws

Abstract

The invention relates to a tile cutter having a frame (1) with a base plate (2) and a guide (3) which is arranged above the base plate (2) and along which a slide (4) that carries a cutting tool (5) is movable in order to produce a score on the surface of a tile resting on the base plate (2), and having a breaker jaw device (6) which is gear-coupled to the slide (4) and is lowered onto the surface of the tile in the end phase of the movement of the slide (4) in order to break the tile along the score. As a development which is advantageous for use, it is proposed that the breaker jaw device (6) and the slide (4) interact with one another via a control flanker arrangement in order to lower the breaker jaw device (6).

IPC Classes  ?

• B28D 1/22 - Working stone or stone-like materials, e.g. brick, concrete, not provided for elsewhereMachines, devices, tools therefor by cutting, e.g. incising

Abstract

The invention firstly relates to a detachable blocking device, in particular on a clamping tool, e.g. on a clamp, comprising a blocking element (10), which inhibits the displacement capability of a rod (1) in at least one detachment direction (L) in a blocking position, and a detachment member (7), which displaces the blocking element (10) into a release position when moved from a default position into a detachment position, in which release position the rod (1) can be displaced at least in detachment direction. A braking element (25) is disclosed, which acts upon the rod (1) in a braking position such that the rod (1) can be displaced only after a braking force acting against the direction of displacement of the rod (1) has been neutralised, which braking force may not be neutralised in a sliding position of the braking element (25), wherein the braking element (25) has a braking lever, and/or the braking element can be brought into its sliding position by pivoting an arm (11) of the detachment member (7) which has a detachment lever.

IPC Classes  ?

• B25B 5/06 - Arrangements for positively actuating jaws

Goods & Services

Glues for industrial purposes; glues for wood. Cleaning, polishing, scouring and abrasive preparations; cleaning preparations; abrasive paper, grit cloth (abrasive preparations); polishing pastes. Vice benches of metal; ironmongery, small items of metal hardware; storage racks of metal, in particular for storing firewood; guide rails of metal; screws, nails, clamps and tacker clips of metal; hooks of metal; rivets; fastening and spacer wedges of metal; clamps (cramps) of metal; strips and spacer strips of metal, ceiling supports of metal; metal building materials; soldering and welding wire; empty storage containers of metal, in particular cases, boxes, caskets, assortment boxes and magazines, all for tools, tool inserts, ironmongery, small items of metal hardware; packaging containers of metal; clamps; straps of metal for handling loads; ratchet belts of metal; belt tensioners and tensioning straps of metal; lashing straps of metal; strap protection plates of metal for lashing straps, load-bearing straps, belt tensioners, tensioning straps, tensioning rubbers and cover expanders; perforated panel walls, perforated panel hooks and perforated panel holders of metal for presenting goods; dowel bars of metal; dowel fixings of metal for marking dowel holes; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for all the aforesaid goods, included in this class. Mechanically operated tools; machines for the construction of machines, apparatus, tools and vehicles and for electrical and structural engineering, metal working, wood working, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock and watchmakers, floor and tile layers, installers and DIY enthusiasts; mechanically operated tools and apparatus for the construction of machines, apparatus, tools and vehicles, for electrical and structural engineering, for metal working, woodworking, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock and watchmakers, floor and tile layers, installers and DIY enthusiasts; hand-operated driving machines intended for stationary installation for driving tools, including accessories (included in this class), namely milling motors and grinding motors; tool inserts for use with mechanically operated tools, in particular plug-in tools for electric hammers and pneumatic hammers, drill bits and milling bits; mechanically operated screwing tools, in particular screwdrivers and screwdriver bits (bits for mechanical tools), and holders relating thereto; electrically or pneumatically operated drilling machines and hand drills; drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for mechanical tools; drill stands and drilling aids for electric drilling machines; drill chucks for mechanical tools; drill stands and drilling aids for electrically or pneumatically operated drilling machines; templates (parts of machines), in particular drilling and milling templates; milling stops; bit stops for drills (parts of machines); milling cutters (mechanical tools); grinding machines and grinding wheels (parts of machines); cut-off grinders, grinding plates, grinding discs, cut-off wheels, ceramic grinding pencils (parts of machines); electric cutting tools; blades (parts of machines); electric hole cutters; electric tile and laminate cutters; cutting machines; electric strip and edge cutters; saws (machines), in particular hole saws, circular saws and chain saws; saw blades and blades for mechanical tools; chisels for machines; electric chisels; brushes (parts of machines), in particular wire brushes; mixers (parts of machines), in particular paint mixers, mortar mixers, adhesive mixers; mechanical clamping, stretching and expanding tools and devices; clamping spindles for mechanical tools; clamping jaws (parts of machines); pneumatic tools (parts of machines); turning and planing machines; electric cartridge guns; pumps (parts of machines or motors and engines); tables for machines; supporting trestles, sawhorses and roller blocks (parts of machines); planing benches and turning lathes (parts of machines), clamping and work tables being parts of machines; electric and non-electric soldering and welding tools; electric cleaning machines and apparatus; flexible shafts (parts of machines); holders (parts of machines) for all the aforesaid goods; handles for mechanical tools, in particular telescopic handles; parts of machines, namely grinding wheels, grinding plates, abrasive belts, abrasive strips, abrasive sheets, polishing bonnets, polishing wheels, polishing heads; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; pneumatic fittings of metal (parts of machines); packaging of metal adapted for mechanically operated tools; parts, spare parts and accessories for all the aforesaid goods, included in this class. Hand tools (hand-operated); implements (hand-operated) for agricultural, horticultural and forestry purposes, for the construction of machines, apparatus, tools and vehicles and for electrical and structural engineering, metal working, wood working, plastics processing and stone working, television, radio and vehicle repair, for plumbers, bricklayers, paper hangers, painters, carpenters, clock- and watchmakers, floor and tile layers, installers and DIY enthusiasts; tool inserts for use with hand-operated tools, in particular bit inserts and inserts for spanners; vices, clamping jaws for vices; clamps (hand tools), in particular screw clamps, spring clamps, ratchet clamps, mounting clamps, one-handed clamps and glue presses; hand-operated screwing tools, in particular screwdrivers and screwdriver bits (bits for hand-operated tools), and holders relating thereto; non-electric hand drills; drills, drill bits, drill buckets, milling cutters, milling drills, drill rasps, rasp files, countersinks, bore saws and hole saws for hand tools; drill stands and drilling aids for hand-operated drills; drill chucks for hand tools; guiding tools (hand-operated) for drills and hole saws; milling cutters (hand tools); sharpening instruments; blade sharpening instruments; hand-operated grinding wheels, grinding plates, cut-off wheels, cut-off grinders and ceramic grinding pencils; grinders (hand tools), hand-operated grinding apparatus; cutlery; cutting tools; glass cutters; knives (hand tools), carpet knives and scissors; scrapers (hand tools); mitre boxes, edge cutters, cutters; blades (parts of hand tools); hand-operated hole cutters; non-electric tile and laminate cutters; non-electric laminate fitters (hand tools); cutting aids (hand tools); non-electric strip and edge cutters; saws (hand tools); saw blades and blades for hand-operated tools; chisels (hand-operated tools), in particular including boring tools; mixers (inserts for hand tools), in particular paint mixers, mortar mixers, adhesive mixers; hand-operated clamping, stretching and expanding tools, in particular belt tensioning tools, frame clamps, angle clamps, clamping jaws, quick-release clamps; clamping spindles for hand tools; dowelling tools; planes; cartridge guns (hand tools); hand pumps; pull bars; trowels (tools), in particular brick trowels; plaster buckets; spattles, tackers; mitre boxes; clamps, in particular riveting pliers; rasps and files (hand tools); angles (hand tools); spanners; hand-operated striking tools, in particular bats; handles for hand tools, in particular telescopic handles; holders for all the aforesaid goods; dies and inserts for all the aforesaid goods; hand tools, namely grinding wheels, grinding plates, abrasive belts, abrasive strips, abrasive sheets, polishing bonnets, polishing wheels, polishing heads; scribers (tools); storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; packaging of metal adapted for hand-operated tools; parts, spare parts and accessories for all the aforesaid goods, included in this class. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; measuring apparatus and instruments, in particular measuring rods, rules (measuring instruments) and dial indicators; measuring apparatus, namely bevels; displacement gauges and goniometers; angle bevels (measuring instruments); gauges, in particular contour gauges; spirit levels; rulers (measuring instruments); protective eyewear, welding goggles; protective masks, respiratory masks and protective mouth masks, in particular fine dust masks and half masks; filters for protective masks, respiratory masks and protective mouth masks; protective helmets, protective gloves; protective work clothing, in particular disposable protective and safety clothing, and disposable protective overshoes; spectacle cases; protective ear coverings, protective ear plugs; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for the aforesaid goods, included in this class; downloadable electronic publications. Lamps, in particular pocket torches; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for all the aforesaid goods, included in this class. Apparatus for locomotion by land, in particular trolleys, hand trucks and push carts; luggage nets for vehicles and vehicle trailers; parts and spare parts for all the aforesaid goods, included in this class. Paper, cardboard and goods made from these materials, included in this class; packaging materials of cardboard; plastic materials for packaging (not included in other classes); pouches, envelopes, bags of paper or plastic, for packaging; packaging of paper or plastic adapted for hand-operated and/or mechanically operated tools; cardboard and/or cardboard packaging for presenting goods; paint brushes, paint rollers; painters' brushes; stencils; garden waste bags of plastic; glues for stationery or household purposes; printed matter, in particular catalogues; marking and drawing templates, in particular for marking holes for electric switch boxes and sockets on ceilings, walls and floors; parts, spare parts and accessories for all the aforesaid goods, included in this class. Plastic films, other than for packaging; protective sheaths of plastic films; adhesive tapes and bands, other than stationery and not for medical or household purposes. Bags (empty), in particular tool bags and tool belt bags of textile, plastic, leather or a combination of the aforesaid materials; cases (empty), namely tool cases of leather (empty); tool pouches sold empty; parts, spare parts and accessories for all the aforesaid goods included in this class. Preserved wood and semi-worked wood and wood parts thereof; building material (not made of metal); rods and spacing strips, not made of metal; props, not made of metal; wooden rods for building purposes; plastic pads for use in construction (support for base structures). Furniture, in particular tables, cupboards, shelves, racks, benches, work benches, vice benches (not of metal), planing benches and turning lathes, clamping and work tables, work tables for milling, drilling, sawing, grinding and polishing (other than tables for machines); supporting trestles, sawhorses and roller blocks (not being parts of machines); storage racks, not of metal, for storing firewood; goods carrier displays for displaying goods; showcases for presenting goods; guide rails, not of metal; fastening materials, not of metal, namely wood dowels, plastic dowels, plastic hooks; fastening and spacer wedges, not of metal; clamps (cramps), not of metal; troughs of plastic for mixing mortar; strips of wood for frames; wooden dowels, wooden pegs; empty storage containers, not of metal; empty storage containers (not of metal), in particular cases, boxes, caskets, assortment boxes and magazines for tools, tool inserts, ironmongery, small items of metal hardware; suction cups of plastic for changing lighting devices; spacers of wood or plastic for floor layering and for positioning of door frames and window frames; packaging containers, not of metal; dowel bars; clips of plastic for cables and plants; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for all the aforesaid goods, included in this class. Sponges; steelwood; cleaning instruments, hand-operated; brushes, in particular metal brushes; electric brushes, other than parts of machines; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for the aforesaid goods, included in this class. Awnings, tarpaulins; lashing straps and load-bearing straps, not of metal, including in the form of non-metal ratchet belts; belt tensioners and tensioning straps, not of metal; bungee cords; accessories for lashing straps, belt tensioners and tensioning straps, namely strap protection plates (not of metal) for protecting lashing straps, belt tensioners and tensioning straps; storage containers adapted for the aforesaid goods, in particular cases, bags, boxes, caskets, assortment boxes and magazines; parts, spare parts and accessories for the aforesaid goods, included in this class. Baseball caps; disposable clothing; clothing, footwear, headgear. Hook-and-loop strips, straps and fastening tapes, including self-adhesive, in particular including for the fixing, bundling and retaining of cables and for tying in plants. Mats, in particular non-slip mats, including for fixing loads. Wholesale and retail services, including by means of teleshopping programmes and online and catalogue mail order, in the fields of construction and DIY articles and other commodity goods for the professional and DIY sectors, machines, tools and goods of common metal, construction, craft and garden articles, hobby requisites and craft supplies, industrial personal safety equipment and clothing; presentation of goods in the fields of construction and DIY articles and other commodity goods for the professional and DIY sectors, machines, tools and goods of common metal, construction, craft and garden articles, hobby requisites and craft supplies, industrial personal safety equipment and clothing; publication of printed matter (including in electronic form) for advertising purposes; presentation of goods on communication media, for wholesale and retail purposes; auctioneering, including on the Internet; arranging commercial transactions, for others, including within the framework of e-commerce; arranging contracts, for others, for the buying and selling of goods.

Abstract

The invention relates to a device for connecting two clamps, each of which has a rail (1, 2), comprising a housing (3) that has two insertion openings (6), which point away from each other and each of which comprises an adjoining insertion channel (7), for inserting a respective rail (2). The device also comprises at least one adapter piece (4) which can be inserted into one of the insertion openings (6) and which reduces the free opening cross section of the insertion channel (7) in order to insert a rail (1) with a different cross-sectional area. The adapter piece (4) has a lining (5) which adjoins a collar (10), said lining (5) resting against the wall of the insertion channel (7) at least in some regions and forming an insertion channel (9) with a reduced cross section in the inserted state, and the collar (10) rests on an end face of the housing (3).

IPC Classes  ?

• B25B 5/00 - Clamps
• B25B 5/06 - Arrangements for positively actuating jaws
• B25B 5/10 - Arrangements for positively actuating jaws using screws

Goods & Services

Vice benches of metal; Parts, replacement parts and accessories for the aforesaid goods. Tables for machines; Parts, replacement parts and accessories for the aforesaid goods. Computer software (recorded); Computer programs [downloadable software]; Electronic publications, downloadable. Furniture, in particular work benches, work tables and shelves; Perforated walls and hooks therefor; Parts, replacement parts and accessories for the aforesaid goods. Wholesaling and retailing, including by means of teleshopping programmes and online and catalogue mail order, in the field of furniture and workshop equipment; Publication of printed matter (including in electronic form) for advertising purposes; Presentation of goods on communications media for wholesale and retail purposes; Auctioneering, including on the Internet; Arranging of commercial transactions, for others, includng within the framework of e-commerce; Arranging of contracts, for others, for the buying and selling of goods. Providing electronic, non-downloadable software online, in particular for the planning and configuration of furniture and workshop equipment.

Abstract

The invention relates to a cutting device comprising a cutting blade (10) which is pivotably fixed to a stand (1), the cutting edge (12) of said cutting blade (10) descending into an entry slot (6) between two supporting members (2) during the cutting process in order to press out a strip of material (9') from a panel-shaped workpiece (9) placed on the supporting members (2). The width of the entry slot (6) is adjusted to the material thickness of the cutting blade (10) in such a way that, when the cutting blade (10) is positioned in the centre of the entry slot (6), a gap remains, at least in the region of the cutting edge (12), between each of the two supporting member edges (4') or slot walls (4) and the broad faces (11) of the cutting blade (10), lying opposite said supporting member edges (4') or slot walls (4). In order for floor coverings consisting of synthetic material, rubber or of another tough or elastic material to be cut with sufficiently high cutting quality on the cutting device, it is proposed that the size of the gap distance (11, 4') be adjustable.

IPC Classes  ?

• B26D 1/30 - Cutting through work characterised by the nature or movement of the cutting memberApparatus or machines thereforCutting members therefor involving a cutting member which does not travel with the work having a cutting member moving about an axis with a non-circular cutting member moving about an axis substantially perpendicular to the line of cut with limited pivotal movement to effect cut
• B26D 7/20 - Cutting beds
• B23D 17/08 - Shearing machines or shearing devices cutting by blades pivoted on a single axis characterised by drives or gearings therefor actuated by hand or foot operated lever mechanism
• B28D 1/22 - Working stone or stone-like materials, e.g. brick, concrete, not provided for elsewhereMachines, devices, tools therefor by cutting, e.g. incising

Abstract

The invention relates to a cutting device, as well as to the use of a cutting device, comprising a cutting blade (10) which is pivotably fixed to a stand (1), the cutting edge (12) of said cutting blade (10) descending into an entry slot (6) between two supporting members (2) during the cutting process in order to press out a strip of material (91) from a panel-shaped workpiece (9) placed on the supporting members (2). The width of the entry slot (6) is adjusted to the material thickness of the cutting blade (10) in such a way that, when the cutting blade (10) is positioned in the centre of the entry slot (6), a gap remains, at least in the region of the cutting edge (12), between each of the two supporting member edges (4') or slot walls (4) and the broad faces (11) of the cutting blade (10), said broad faces (11) lying opposite the supporting member edges (4') or slot walls (4). In order for panels or tiles, in particular floor coverings or roof shingles consisting of synthetic material, rubber or of another tough or elastic material to be cut with sufficiently high cutting quality on the cutting device, it is proposed that the gap (11, 4') measure no more than 0.7 mm for cutting panels or tiles between 1mm and 5mm thick, in particular floor coverings or roof shingles consisting of synthetic material, rubber or of another tough or elastic material.

IPC Classes  ?

• B26D 1/30 - Cutting through work characterised by the nature or movement of the cutting memberApparatus or machines thereforCutting members therefor involving a cutting member which does not travel with the work having a cutting member moving about an axis with a non-circular cutting member moving about an axis substantially perpendicular to the line of cut with limited pivotal movement to effect cut
• B26D 7/20 - Cutting beds
• B23D 17/08 - Shearing machines or shearing devices cutting by blades pivoted on a single axis characterised by drives or gearings therefor actuated by hand or foot operated lever mechanism
• B28D 1/22 - Working stone or stone-like materials, e.g. brick, concrete, not provided for elsewhereMachines, devices, tools therefor by cutting, e.g. incising

Abstract

The invention first relates to a tile cutter, comprising a base plate (1) for accommodating a tile (8), which base plate extends in the horizontal direction in the usage position of the tile cutter, and a slide (3) that can be moved in the horizontal direction along a guide (2) above the base plate (1), on which slide a cutting element carrier (4), in particular a cutting wheel carrier, is articulated, which cutting element carrier bears a cutting element (5), in particular a cutting wheel, wherein the cutting element carrier (4) is supported on a stop (6) by means of a counter stop (7) when the slide (3) is moved along the guide (2) in a cutting direction (S), and so force is applied to the cutting element (5) downward in the vertical direction in order to produce a notch in the tile (8). In order to further develop the tile cutter in a manner that is advantageous to use, the cutting element carrier (4) is articulated on the slide (3) in such a way that the cutting element carrier slides or rolls across the tile (8) substantially without vertical force application when the slide (3) is moved in a direction opposite the cutting direction (S).

IPC Classes  ?

• B28D 1/22 - Working stone or stone-like materials, e.g. brick, concrete, not provided for elsewhereMachines, devices, tools therefor by cutting, e.g. incising
• B28D 7/04 - Accessories specially adapted for use with machines or devices of the other groups of this subclass for supporting or holding work

Abstract

The patent application relates to a saw horse having at least two stand elements, each stand element (1) having a base (4) and two vertical braces (2) which in each case leave an interspace (5) between one another for accommodating wood (21) to be sawed or the like, and which project upwardly from the base (4). One vertical brace (2) of one stand element (1) is connected to a vertical brace (2) of the other stand element (1) via a connecting element (6) in such a way that the interspaces (5) of the two stand elements (1) are aligned with one another in an operating position in which the connecting elements (6) extend parallel to one another. In order to achieve a refinement that is advantageous for use, it is proposed that the connecting elements (6) are pivotably secured to the vertical braces (2) so that the saw horse may be folded up in a parallelogram-like manner from its operating position, in which the connecting elements (6) are spaced at a maximum distance from one another, into a storage position in which the connecting elements (6) are spaced at a minimum distance from one another.

IPC Classes  ?

• A47B 43/00 - Cabinets, racks or shelf units, characterised by features enabling folding of the cabinet or the like
• A47B 47/00 - Cabinets, racks or shelf units, characterised by features related to dismountability or building-up from elements
• A47B 57/00 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions
• A47F 7/00 - Show stands, hangers, or shelves, adapted for particular articles or materials

Abstract

A strip clamping device having a strip to be clamped (1), a clamping mechanism (3) provided with a winding body (2) for the strip to be clamped (1), a toothed locking wheel (4) which is associated with the winding body (2) and has a locking toothed wheel work (5) in which a pawl (8) and a driving ratchet (7) associated with a driving lever (6) engage in order to rotate the winding body (2) in a defined direction by repeated pivoting of the driving lever (6). The winding body (2) has a spring accumulator (9) acting in the winding direction, and is a storage spool receiving essentially the entire length of the strip (1), one end of the strip being connected to the winding body (2) in a fixed manner.

IPC Classes  ?

• B25B 25/00 - Implements for fastening, connecting, or tensioning of wire or strip

Abstract

In order to simplify laying planks parallel to each other, the invention provides an auxiliary device having a placement body (5) to be placed on the visible face of a plank (2) to be attached, which lies adjacent to a plank (3) that is already attached to the support beam (1) by means of screws (7) threaded into bores (6) in the visible face thereof, having at least one mark for marking a bore (6) or a guide opening (8, 9) for guiding a drill (10) for drilling a bore (6) in the visible face of the plank (2) to be attached. Said hole lies in a straight line to a bore (6) in the plank (3) already mounted and has a contact flank (11) for contacting a longitudinal side (2') in particular of the plank (2) to be attached, wherein the placement body (5) defines a theoretical alignment line (12) running transverse to the direction of extension of the contact flank (11) and on which lie the mark or guide opening (8, 9) and an aligner (13) that can be brought across the visible face of the plank (3) already attached.

IPC Classes  ?

• B23B 47/28 - Drill jigs for workpieces
• B25H 7/02 - Plates having a flat surface
• E04F 21/22 - Implements for finishing work on buildings for laying flooring of single elements, e.g. flooring cramps

Abstract

The invention relates to a device for discharging a mass, particularly a pasty mass, from a substantially cylindrical cartridge by driving a plunger (2) in a cartridge tube (1) forward in the direction of an outlet opening (4), comprising a base (21), on which the end (11) of the cartridge tube (1) opposite the outlet opening can be fitted, and comprising clamping pieces (31), which press against the outer wall of the end (1') of the cartridge tube (1) under spring force (29) level with the base (21). To develop the device in a functionally advantageous manner, it is proposed that the clamping pieces (31) engage the cartridge tube at two diagonally opposite points and actuating levers (27) that are urged into a clamping position by a spring (29) be attached at the ends.

IPC Classes  ?

• B05C 17/01 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure with mechanically or electrically actuated piston or the like

Abstract

The invention relates to a device for cutting a workpiece (8) having the shape of a plate, in particular a laminate floor tile, comprising a frame (1), a support (9) formed by the frame (1) for placing the workpiece (8) thereon, and a cutting knife (2) fastened to the frame, which knife can be pivoted about a pivot axis (3) from an open position into a closed position and enters into the workpiece (8) with an edge (18, 19, 20) thereof. In order to further develop the device in an advantageous manner for use, a pivot axis displacement device (5, 6) is proposed, by which the pivot axis (3), during the pivoting of the cutting knife (2), is displaced substantially parallel to the extension direction of the support (9) such that each cutting point passes perpendicularly through the workpiece.

IPC Classes  ?

• B26D 1/30 - Cutting through work characterised by the nature or movement of the cutting memberApparatus or machines thereforCutting members therefor involving a cutting member which does not travel with the work having a cutting member moving about an axis with a non-circular cutting member moving about an axis substantially perpendicular to the line of cut with limited pivotal movement to effect cut
• B26D 7/01 - Means for holding or positioning work

Abstract

The invention relates to a device for discharging a cartridge (23) comprising a telescopic plunger arrangement (3 - 6), consisting of threaded parts (3 - 4) nested in one another, for the linear displacement of a plunger (2), and comprising a drive motor (11) for the rotary driving of a threaded drive part (3) of the telescopic plunger arrangement. As a functionally advantageous development, an externally visible indicator (28) that moves synchronously with the plunger (2) is proposed.

IPC Classes  ?

• B05C 17/005 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure

Abstract

The invention relates to a device for fastening a floor board (3) of a floor comprising a plurality of floor boards (3) lying in parallel next to each other to one or more supporting beams (4) in the form of an elongated spacer body (1, 2), which can be fastened to the bottom side (3') of the floor board (3) and forms a fastening section (5) at one end, a fastening section (7) at the other end, and an intermediate section (6) arranged between the two fastening sections (5, 7). In order to develop such a spacer strip in a manner that is advantageous for use, it is proposed that the fastening sections (5, 7) be interconnected in the area of the intermediate section (6) by means of a predetermined breaking point (8).

IPC Classes  ?

• E04F 15/04 - Flooring or floor layers composed of a number of similar elements only of wood, e.g. with wooden connecting members
• E04F 21/22 - Implements for finishing work on buildings for laying flooring of single elements, e.g. flooring cramps

Abstract

The invention relates to a device for cutting a porous, substantially flexurally stiff board (1), in particular a laminate floor board, comprising a frame (2), a support (3) for the board (1) that is formed by the frame (2), a plunge slit (4) associated with the support (3), and a cutting blade (6) that is fastened to the frame (2) so as to be able to swivel about a swivel axis (A) formed by a swivel bearing (5, 9) and in such a way that the cutting edge (7) of the cutting blade plunges into the plunge slit (4) when the cutting blade (6) is swiveled from an open position to a closed position, wherein a cutting point (8) lying in the swivel plane between the support (3) and the cutting edge (7) moves from the proximal side of the support (3) with respect to the swivel bearing (5, 9) to the distal side of the support (3) with respect to the swivel bearing (5, 9) while the cutting blade (6) is closed. For development that is advantageous in regard to use, a holder (60) is proposed that loads the board (1) in the direction of the support (3) when the cutting blade (6) is swiveled from the closed position in the direction of the open position.

IPC Classes  ?

• B26D 1/30 - Cutting through work characterised by the nature or movement of the cutting memberApparatus or machines thereforCutting members therefor involving a cutting member which does not travel with the work having a cutting member moving about an axis with a non-circular cutting member moving about an axis substantially perpendicular to the line of cut with limited pivotal movement to effect cut
• B26D 7/01 - Means for holding or positioning work
• B23D 17/08 - Shearing machines or shearing devices cutting by blades pivoted on a single axis characterised by drives or gearings therefor actuated by hand or foot operated lever mechanism

Abstract

The patent application relates to a saw horse having at least two stand elements, each stand element (1) having a base (4) and two vertical braces (2) which in each case leave an interspace (5) between one another for accommodating wood (21) to be sawed or the like, and which project upwardly from the base (4). One vertical brace (2) of one stand element (1) is connected to a vertical brace (2) of the other stand element (1) via a connecting element (6) in such a way that the interspaces (5) of the two stand elements (1) are aligned with one another in an operating position in which the connecting elements (6) extend parallel to one another. In order to achieve a refinement that is advantageous for use, it is proposed that the connecting elements (6) are pivotably secured to the vertical braces (2) so that the saw horse may be folded up in a parallelogram-like manner from its operating position, in which the connecting elements (6) are spaced at a maximum distance from one another, into a storage position in which the connecting elements (6) are spaced at a minimum distance from one another.

IPC Classes  ?

• B27B 17/00 - Chain sawsEquipment therefor

Abstract

The invention relates to a saw horse having at least two stand elements, wherein each stand element (1) comprises a base (4) and two vertical braces (2) leaving in each case between themselves an intermediate space (5) for accommodating wood (21) to be sawed or the like and protruding upward from the base (4), wherein one vertical brace (2) of one stand element (1) is connected to a vertical brace (2) of the other stand element (1) by way of a connecting element (6) such that the intermediate spaces (5) of the two stand elements (1) are aligned with each other in an operating position in which the connecting elements (6) run parallel to each other. In order to achieve a refinement that is advantageous for use, it is proposed that the connecting elements (6) are attached rotatably to the vertical braces (2) such that the saw horse can be folded from the operating position thereof, in which the connecting elements (6) are arranged at the maximum distance from each other, in a parallelogram-like manner into a storage position, in which the connecting elements (6) are arranged at the minimum distance from each other.

IPC Classes  ?

• B27B 17/00 - Chain sawsEquipment therefor

Abstract

The invention relates to a clamp, having a drive housing (1) through which a tie rod (2) projects, which can be shifted into a clamping position (S) by means of an indexing mechanism (3, 4, 5) in such a way as to be locked against reverse pressure by a reverse-pressure lock (6, 7), wherein the reverse-pressure lock has a locking element which acts on the tie rod (2) in a reverse-pressure locking position and which, for releasing the reverse-pressure-locking effect, can be brought into a release position by pivoting a release lever (8), in which release position the tie rod (2) can be displaced against the clamping direction (S), and which locking element (6), by further pivoting of the release lever (8), can be shifted against the tension of a return spring (7) beyond the release position into an end position, from which the locking element (6) is shifted back by the spring (7), with the tie rod (2) being carried along, wherein the two-armed release lever (8) is pivotably mounted in the drive housing (1) about a fulcrum (9, 10) and has a power arm (8') and a load arm (8'') acting on the locking element (6) at an engagement point (11). In order to develop a tool of the type in question so as to be able to use it advantageously, it is proposed that that the release lever (8), during its pivoting movement from the reverse-pressure position into its end position, rotates about fulcrums (9, 10) which are at different distances from the engagement point (11).

IPC Classes  ?

• B25B 5/06 - Arrangements for positively actuating jaws

Abstract

The invention relates to a dolly comprising a supporting frame (1) that is provided with a side facing the load, a side facing away from the load, a load section (2), and a handle section (3). A plate (4) protrudes substantially at a right angle from the side facing the load at the end of the load section (2) while two rollers sit on the side facing away from the load. In order to further develop said dolly so as to be able to use the same advantageously, one or several supports protrude from the side of the load section (2) facing away from the load while the handle section (3) is pivotable relative to the load section (2) and can be fixed in an extended position or at least in an obtuse-angled position relative to the load section (2).

IPC Classes  ?

• B62B 5/06 - Hand moving equipment, e.g. handle bars
• B62B 1/12 - Hand carts having only one axis carrying one or more transport wheelsEquipment therefor in which the load is intended to be transferred totally to the wheels involving parts being adjustable, collapsible, attachable, detachable, or convertible
• B62B 1/20 - Hand carts having only one axis carrying one or more transport wheelsEquipment therefor in which the load is disposed between the wheel axis and the handles, e.g. wheelbarrows involving parts being collapsible, attachable, detachable or convertible

Abstract

The invention relates to a foldable frame (1) for oscillating saws or the like with an elongated support body (2), to which the oscillating saw is mountable, and to which, at each one of its two respective ends, are connected two legs (6,7), the latter being swivelable from a storage configuration in which they extend essentially parallel to the support body (2) to an operative configuration in which they extend essentially perpendicular from the support body (2). In order to improve the usefulness of the above-described foldable frame, it is proposed that the support body (2) be configured as two support body sections (3, 4), which are connected to one another by a hinge (5), which in the storage configuration lie parallel to each other, and which by swivelling movement through 180° can be brought into the operative configuration.

IPC Classes  ?

• B25B 1/00 - Vices

Abstract

The invention relates to a clamping holder with a housing (1), through which a push/pull bar (2) reaches, with a fixed clamping jaw (3), which is fixedly disposed on the housing (1) on one side of the push/pull bar (2), and a movable clamping jaw (4), which is mounted on the push/pull bar (2) and can be displaced with respect to the fixed clamping jaw by a drive mechanism disposed in the housing (1) by pivoting of a drive lever (8), which is disposed on the housing together with a gripping handle (7), fixed to the housing, on the other side of the push/pull bar (2), the spacings (A) of the free ends (7"', 8"') of the gripping handle (7) and of the drive lever (8) from the push/pull bar (2) being approximately equal and the contour lines of the backs (7', 8'), facing away from each other, of the gripping handle (7) and of the drive lever (8) being convexly rounded along the direction of their extent and respectively running on an imaginary arcuate line (24, 25). Pertinent is that the contour lines are delimited radially outward over the entire gripping zone up to the free ends (7"', 8"') by the arcuate lines (24, 25) and, in the region of the free ends (7 "', 8"'), leave the imaginary arcuate line (24, 25) toward their center points (24', 25'), the length of the radii of the arcuate lines (24', 25') being at least 70% of the spacing (A) and at most 200% of the spacing (A).

IPC Classes  ?

• B25B 5/06 - Arrangements for positively actuating jaws

Abstract

The invention relates to a foldable frame (1) for oscillating saws or the like with an elongated support body (2), to which the oscillating saw is mountable, and to which, at each one of its two respective ends, are connected two legs (6,7), the latter being swivelable from a storage configuration in which they extend essentially parallel to the support body (2) to an operative configuration in which they extend essentially perpendicular from the support body (2). In order to improve the usefulness of the above-described foldable frame, it is proposed that the support body (2) be configured as two support body sections (3, 4), which are connected to one another by a hinge (5), which in the storage configuration lie parallel to each other, and which by swivelling movement through 180.degree. can be brought into the operative configuration.

IPC Classes  ?

• B23D 47/02 - Sawing machines or sawing devices working with circular saw blades, characterised only by constructional features of particular parts of framesSawing machines or sawing devices working with circular saw blades, characterised only by constructional features of particular parts of guiding arrangements for work-table or saw-carrier
• B23D 51/03 - Sawing machines or sawing devices working with straight blades, characterised only by constructional features of particular partsCarrying or attaching means for tools, covered by this subclass, which are connected to a carrier at both ends of bedsSawing machines or sawing devices working with straight blades, characterised only by constructional features of particular partsCarrying or attaching means for tools, covered by this subclass, which are connected to a carrier at both ends of guiding arrangements for work-tables or saw carriersSawing machines or sawing devices working with straight blades, characterised only by constructional features of particular partsCarrying or attaching means for tools, covered by this subclass, which are connected to a carrier at both ends of frames with extensible or collapsible frames
• B27B 21/00 - Hand saws without power driveEquipment for hand sawing, e.g. saw horses

Abstract

The invention pertains to a drilling guide for making angulated bores for a two-workpiece (1, 2), flat, mutual juxtaposition pair of connection surfaces (1', 2') with mutually joining screws (3), with a contact surface (5) applicable to a wide side surface (1") of a first workpiece (1), the wide side surface (1") extending essentially perpendicular to the connection surface, in which contact surface at least one guiding channel (6) for a drill bit opens acutely, and with adjustment elements in order to position the contact surface (5) with various spacings from the opening (6') of the at least one guiding channel (6) as far as the connecting surface (1') limiting edge (8) of the contact surface (1"). It is important that the contact surface (1") have a carriage support (9) on which a carriage (10), displaceable parallel to the contact surface (1"), and lockable in various positions, has the said at least one guiding channel (6).

IPC Classes  ?

• B23B 49/00 - Measuring or gauging equipment on boring machines for positioning or guiding the drillDevices for indicating failure of drills during boringCentring devices for holes to be bored
