An anti-blockage pipeline structure includes a connection pipe and a flow controller. The connection pipe includes inflow and outflow passages and an accommodation part that is located therebetween and has upper and lower flow chambers in fluid communication with each other, first and second inlet channels and an outlet channel. The first inlet channel is in fluid communication with the inflow passage and the upper flow chamber, and has an opening size increasing from the inflow passage. The second inlet channel is in fluid communication with the inflow passage and the lower flow chamber, and has an opening size greater than that of the first inlet channel. The outlet channel is in fluid communication with the lower flow chamber and the outflow passage. The flow controller enables or interrupts fluid communications between the upper and lower flow chambers and between the second inlet channel and the lower flow chamber.
F16K 31/126 - Operating meansReleasing devices actuated by fluid the fluid acting on a diaphragm, bellows, or the like
F16K 1/00 - Lift valves, i.e. cut-off apparatus with closure members having at least a component of their opening and closing motion perpendicular to the closing faces
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
Nozzles for sprinkler hose; Nozzles for watering hose; Hose nozzles; Sprayer nozzles for garden hoses; Shut-off valves for water sprinkler nozzles; Horticultural, plastic buckets hanging from free standing platform incorporating a micro-drip irrigation system for use in growing any type of vegetable, plant or shrub; Shower racks; Sprinkler heads for lawn sprinklers; Sprinklers for watering flowers and plants; Plastic spray nozzles; Lawn sprinklers; Grass sprinklers; Spray nozzles for garden hoses; Sprinkling devices in the form of perforated stakes that connect to hoses to deliver water to the roots of trees, shrubs, and plants; Sprayers attached to garden hoses; Garden hose sprayers; Sprayer wands for garden hoses
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
sprinkling devices; roses for watering hose; nozzles for watering hose; roses for watering cans; sprinklers for watering flowers and plants; watering cans.
A water spray gun includes a main body, an operating member and a switch part. The main body includes a handle portion and a tube portion extended from the handle portion and provided with a spray head. A control assembly is enclosed in the main body for control of water outflow and adjustment of the amount of the water outflow. The operating member is pivotally connected to the position where the handle portion meets the tube portion. The switch part is arranged at the operating member and is engaged with the control assembly. The amount of water outflow is controlled by relative movement between the switch part and the operating member.
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
sprinkling devices, namely, garden hose sprayers, sprinklers to attach to hoses for watering plants, shut-off valves for water sprinkler nozzles, lawn sprinklers and sprinkler heads for lawn sprinklers; roses for watering hose; nozzles for watering hose; roses for watering cans; sprinklers for watering flowers and plants; watering cans
9.
Water spray gun for control of outflow of water and adjustment of outflow
A water spray gun for control of an outflow of water and adjustment of the amount of the outflow is revealed. The water spray gun includes a handle portion, a pipe portion connected to the handle portion and used for spraying water, and a control device arranged at the position where the pipe portion meets the handle portion. The control device comprises a press part and a rotary control member. The amount of the water outflow is controlled by the rotary control member. The amount of the outflow sprayed out from the pipe portion at respective stages is continuously controlled and regulated by the control device.
B05B 12/00 - Arrangements for controlling deliveryArrangements for controlling the spray area
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
A coupler, adapted for being assembled and connected with a water sprayer, includes a sleeve and a coupling member adapted for being assembled and connected with the water sprayer. The coupling member and the sleeve are sleeved with each other and respectively have a first corresponding end and a second corresponding end which correspond to each other. The first corresponding end and the second corresponding end are adapted to be engaged with each other, so that the sleeve and the coupling member are capable of being mutually locked and into a non-rotatable state through the engagement and rotation meshing operation. The sleeve can be disengaged with the coupling member through axially moving the sleeve so that the sleeve is allowed to be axially rotatable.
F16L 19/00 - Joints in which sealing surfaces are pressed together by means of a member, e.g. a swivel nut, screwed on, or into, one of the joint parts
F16L 27/08 - Adjustable jointsJoints allowing movement allowing adjustment or movement only about the axis of one pipe
F16L 37/34 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in each of two pipe-end fittings at least one of two lift valves being opened automatically when the coupling is applied at least one of the lift valves being of the sleeve type, i.e. a sleeve being telescoped over an inner cylindrical wall
F16L 37/24 - Couplings of the quick-acting type in which the connection is made by inserting one member axially into the other and rotating it to a limited extent, e.g. with bayonet-action
A sprinkler includes a base, a tubular body disposed on the base, at least one control assembly mounted to the tubular body, and at least one nozzle set which has a plurality of nozzles aligned in a row and is disposed on the tubular body. The control assembly includes at least one push portion mounted with at least one connecting member which is pivotally connected to at least one guiding member with a plurality of sliding slots. The sliding slots are inserted by the nozzles for allowing the nozzles to be moved back and forth selectively. By movement of the push portion in an axial direction of the tubular body caused by manual operation, the guiding member is also moved radially to drive at least one of the nozzles to incline in turn.
B05B 15/652 - Mounting arrangements for fluid connection of the spraying apparatus or its outlets to flow conduits whereby the jet can be oriented
B05B 3/02 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
B05B 15/625 - Arrangements for supporting spraying apparatus, e.g. suction cups designed to be placed on the ground
A sprinkler including a base, a tubular body disposed on the base, and at least one control assembly mounted to the tubular body is revealed. At least one nozzle set formed by a plurality of nozzles aligned in a row is disposed on the tubular body. The control assembly includes at least one push portion mounted with at least one connecting member which is pivotally connected to at least one guiding member with a plurality of sliding slots. The sliding slots are inserted by the nozzles for allowing the nozzles to be moved back and forth selectively. By movement of the push portion in an axial direction of the tubular body caused by manual operation, the guiding member is also moved radially to drive at least one of the nozzles to incline in turn.
B05B 3/14 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with oscillating elementsSpraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with intermittent operation
B05B 3/16 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with oscillating elementsSpraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with intermittent operation driven or controlled by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
A sprayer for mixed solution and water is revealed. The sprayer can be used for cleaning objects, spraying mixed solution for agricultural purposes, and so on. The mixed solution is formed by liquid mixed with water, while the liquid can be fertilizers, pesticides, detergents, and etc. The sprayer can selectively spray out the mixed solution or water only.
B05B 7/12 - Spray pistolsApparatus for discharge designed to control volume of flow, e.g. with adjustable passages
B05B 7/24 - Spraying apparatus for discharge of liquids or other fluent materials from two or more sources, e.g. of liquid and air, of powder and gas with means, e.g. a container, for supplying liquid or other fluent material to a discharge device
B05B 7/04 - Spray pistolsApparatus for discharge with arrangements for mixing liquids or other fluent materials before discharge
14.
Sprayer able to adjust flow of mixed solution and water
A sprayer able to adjust a flow of mixed solution and water is revealed. The sprayer can be used for cleaning objects, spraying mixed solution for agricultural purposes, and so on. The mixed solution is formed by liquid mixed with water while the liquid can be fertilizers, pesticides, detergents, and etc. The sprayer not only can spray out the mixed solution or water selectively, but also can adjust concentration and flow of the liquid.
A sprayer for mixed solution and clear water is revealed. The sprayer can be used for clearing objects or to spray mixed solution for agricultural purposes. The mixed solution is formed by liquid mixed with clear water while the liquid can be fertilizers, pesticides, or detergents. The sprayer can selectively spray out the mixed solution or clear water only.
B05B 7/28 - Apparatus in which liquids or other fluent materials from different sources are brought together before entering the discharge device in which one liquid or other fluent material is fed or drawn through an orifice into a stream of a carrying fluid
B05B 12/00 - Arrangements for controlling deliveryArrangements for controlling the spray area
16.
SPRAYER ABLE TO ADJUST FLOW OF MIXED SOLUTION AND CLEAR WATER
ABSTRACT A sprayer able to adjust a flow of mixed solution and clear water is revealed. The sprayer can be used for clearing objects or to spray mixed solution for agricultural purposes. The mixed solution is formed by liquid mixed with clear water while the liquid can be fertilizers, pesticides, or detergents. The sprayer not only can spray out the mixed solution or clear water selectively, but also can adjust concentration and flow of the liquid. Date Recue/Date Received 2021-05-13
B05B 7/28 - Apparatus in which liquids or other fluent materials from different sources are brought together before entering the discharge device in which one liquid or other fluent material is fed or drawn through an orifice into a stream of a carrying fluid
B05B 12/00 - Arrangements for controlling deliveryArrangements for controlling the spray area
A rotor nozzle structure has a chamber deployed with a rotor connecting to the water outlet and an adjusting element, wherein the rotor nozzle is capable of generating a directing stream and a wide-angle swirl stream, and the adjusting element is switchable by a rotational means for driving the rotor in a rotation or static status in the chamber.
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
A faucet diverter is revealed. The faucet diverter is coupled to a faucet and composed of a coupling part, a first assembly part, a second assembly part, a spray part and a control part. A water flow from the coupling part is redirected to the first assembly part, the second assembly part, or the spray part by operating the control part.
E03C 1/02 - Plumbing installations for fresh water
E03C 1/048 - Water-basin installations specially adapted to wash-basins or baths supplying water through two or more openings around or along one side of the water-basin
E03C 1/08 - Jet regulators, e.g. anti-splash devices
A spray unit of a watering device is equipped with a structure of rotor nozzle, the spray unit is composed of a mounting member and a housing for defining a chamber, a rotor deployed inside the chamber; wherein, at least one stopper set on the inner side of the chamber near the water outlet side is correspondingly matched to multiple guide members on one end of the water outlet of the rotor, and it can be employable to the handy watering device.
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
B05B 1/02 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to produce a jet, spray, or other discharge of particular shape or nature, e.g. in single drops
B05B 1/12 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means capable of producing different kinds of discharge, e.g. either jet or spray
B05B 1/16 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening having selectively-effective outlets
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
Pipe fittings with a filter contain a body, a filter valve, and two seal gaskets. The body includes a first connection pipe and a second connection pipe, a receiving orifice, and at least one guide slot. The filter valve includes a driven section and an operation portion. The two seal gaskets are accommodated in the first peripheral groove and the second peripheral groove respectively. The driven section has a first peripheral groove, a second peripheral groove, and a filtration orifice defined between the first peripheral groove and the second peripheral groove and communicating with the driven section, and at least one fixing bolt mounted between the operation portion and the first peripheral groove and extending outward from the driven section. The at least one fixing bolt slides into the at least one guide slot respectively so that the filter valve is accommodated in the receiving orifice.
F16L 37/252 - Couplings of the quick-acting type in which the connection is made by inserting one member axially into the other and rotating it to a limited extent, e.g. with bayonet-action the coupling being co-axial with the pipe the male part having lugs on its periphery penetrating into the corresponding slots provided in the female part
A water spray gun includes a main body, an operating member and a switch part. The main body includes a handle portion and a tube portion extended from the handle portion and provided with a spray head. A control assembly is enclosed in the main body for control of water outflow and adjustment of the amount of the water outflow. The operating member is pivotally connected to the position where the handle portion meets the tube portion. The switch part is arranged at the operating member and is engaged with the control assembly. The amount of water outflow is controlled by relative movement between the switch part and the operating member.
A water spray gun includes a main body, an operating member and a switch part. The main body includes a handle portion and a tube portion extended from the handle portion and provided with a spray head. A control assembly is enclosed in the main body for control of water outflow and adjustment of the amount of the water outflow. The operating member is pivotally connected to the position where the handle portion meets the tube portion. The switch part is arranged at the operating member and is engaged with the control assembly. The amount of water outflow is controlled by relative movement between the switch part and the operating member.
B05B 1/16 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening having selectively-effective outlets
A water spray gun for control of an outflow of water and adjustment of the amount of the outflow is revealed. The water spray gun includes a handle portion, a pipe portion connected to the handle portion and used for spraying water, and a control device arranged at the position where the pipe portion meets the handle portion. The control device comprises a press part and a rotary control member. The amount of the water outflow is controlled by the rotary control member. The amount of the outflow sprayed out from the pipe portion at respective stages is continuously controlled and regulated by the control device.
B05B 12/00 - Arrangements for controlling deliveryArrangements for controlling the spray area
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
24.
WATER SPRAY GUN FOR CONTROL OF OUTFLOW OF WATER AND ADJUSTMENT OF OUTFLOW
AB STRACT A water spray gun for control of an outflow of water and adjustment of the amount of the outflow is revealed. The water spray gun includes a handle portion, a pipe portion connected to the handle portion and used for spraying water, and a control device arranged at the position where the pipe portion meets the handle portion. The control device consists of a press part and a rotary control member. The amount of the water outflow is controlled by the rotary control member. The amount of the outflow sprayed out from the pipe portion at respective stages is continuously controlled and regulated by the control device. Date Recue/Date Received 2020-05-20
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
B05B 1/34 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to influence the nature of flow of the liquid or other fluent material, e.g. to produce swirl
An oscillating range adjusting module with modular design for being mounted into a sprinkler is revealed. The oscillating range adjusting module which includes a first adjusting unit and a second adjusting unit is located between a water-in control module and an oscillation driving module. During assembly, the first adjusting unit is fitted on an inlet tube of a water-in control module. After an O-ring being connected to the first adjusting unit, the second adjusting unit is mounted on the inlet tube and connected to the first adjusting unit by at least one fastener of the second adjusting unit engaged with at least one connection surface of the first adjusting unit. Lastly a water inlet of the oscillation driving module is connected to the second adjusting unit. Thereby, a modular assembly of the oscillating range adjusting module between the oscillation driving module and the water-in control module is achieved.
B05B 3/14 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with oscillating elementsSpraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with intermittent operation
B05B 12/00 - Arrangements for controlling deliveryArrangements for controlling the spray area
A rotor nozzle structure has a chamber deployed with a rotor connecting to the water outlet and an adjusting element, wherein the rotor nozzle is capable of generating a directing stream and a wide-angle swirl stream, and the adjusting element is switchable by a rotational means for driving the rotor in a rotation or static status in the chamber.
B05B 1/12 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means capable of producing different kinds of discharge, e.g. either jet or spray
A structure of rotor nozzle is equipped with a spray unit of a watering device, the spray unit is composed of a mounting member and a housing for defming a chamber, a rotor deployed inside the chamber; wherein, at least one stopper set on the inner side of the chamber near the water outlet side is correspondingly matched to multiple guide members on one end of the water outlet of the rotor, and it can be employable to the handy watering device.
B05B 1/12 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means capable of producing different kinds of discharge, e.g. either jet or spray
A rotor nozzle structure has a chamber deployed with a rotor connecting to the water outlet and an adjusting element, wherein the rotor nozzle is capable of generating a directing stream and a wide-angle swirl stream, and the adjusting element is switchable by a rotational means for driving the rotor in a rotation or static status in the chamber.
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
A rotatable sprinkler comprises a base with a continuous curved surface and a rotation element disposed rotatably and relatively to the base. The rotation element has an outlet that connects to a water source. A decorative unit is disposed on a support, part of which is located on the rotation element and the free end of which is in contact with the continuous curved surface of the base. Therefore, the decorative unit may rotate relatively to the base, or move up and down when the free end of the support is pressed against the continuous curved surface.
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
B05B 1/14 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening
B05B 15/625 - Arrangements for supporting spraying apparatus, e.g. suction cups designed to be placed on the ground
A63H 23/10 - Other water toys, floating toys, or like buoyant toys
B05B 1/20 - Perforated pipes or troughs, e.g. spray boomsOutlet elements therefor
B05B 15/74 - Arrangements for moving spray heads automatically to or from the working position using hydraulic or pneumatic means driven by the discharged fluid
A gardening fluid connection device contains a body including multiple retainers, a resilient element, and a fitting sleeve including multiple spaced engagement teeth. The resilient element abuts against the body and the fitting sleeve. The body includes a stop rib, and the multiple spaced engagement teeth are pushed by the resilient element to abut against the stop rib. The body includes at least one retaining element, each retaining element is located on a first side of each spaced engagement tooth, and a width of each spaced engagement tooth is equal to a rotation distance of the fitting sleeve, hence the fitting sleeve is rotated reciprocatingly to open or close of the gardening fluid coupling device by using the stop rib, each retaining element, each spaced engagement tooth and the resilient element, and each retaining element is stopped when moving to a second side of each spaced engagement tooth.
F16L 37/10 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using a rotary external sleeve or ring on one part
F16L 37/138 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members using an axially movable sleeve
F16L 37/12 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members
B05B 15/65 - Mounting arrangements for fluid connection of the spraying apparatus or its outlets to flow conduits
A hangtag includes a foldable flap and a rubber ring girdling around at least one pore of the foldable flap, the rubber ring having a connecting element shaped into column, a hanging portion and a mounting portion being individually deployed on the opposite ends of the connecting element, the hanging portion and the connecting element passing through the pore and the mounting portion which leads the mounting portion to tie a knot; in such a way that the user may easily turn around the hangtag and spread out the foldable flap for reading.
12 - Land, air and water vehicles; parts of land vehicles
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
Anti-splash tap nozzles; Mixer taps for water pipes; Ornamental fountains; Watering installations, automatic; Watering machines for agricultural purposes. Hose carts. Gardening gloves; Nozzles for sprinkler hose; Nozzles for watering cans; Roses for watering cans; Spouts; Sprinklers; Sprinklers for watering flowers and plants; Sprinkling devices; Syringes for watering flowers and plants; Watering devices.
A control structure capable of adjusting water volume and controlling water supply contains: a body, a fixer, a valve stem, an adjuster, and a controller. The body includes a water outflow segment for connecting with a watering tool, an accommodation groove for accommodating the fixer and the valve stem. The fixer includes a flexible retaining rib, and the valve stem includes an inlet communicating with the water outflow segment, a fixing rib, an opening communicating with the inlet, and a guiding column. The guiding column has a seal ring. The fixing rib retains with the flexible retaining rib so as to limit a rotation of the adjuster along the body. The adjuster includes a threaded orifice screwing with a screwing section of the controller, an inflow aperture fitting with the guiding column, and a shoulder formed beside the inflow aperture. The controller is coupled with a water supply pipe.
F16K 31/50 - Mechanical actuating means with screw-spindle
B05B 1/32 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages in which a valve member forms part of the outlet opening
A gardening fluid connection device contains a body including multiple retainers, a resilient element, and a fitting sleeve including multiple spaced engagement teeth. The resilient element abuts against the body and the fitting sleeve. The body includes a stop rib, and the multiple spaced engagement teeth are pushed by the resilient element to abut against the stop rib. The body includes at least one retaining element, each retaining element is located on a first side of each spaced engagement tooth, and a width of each spaced engagement tooth is equal to a rotation distance of the fitting sleeve, hence the fitting sleeve is rotated reciprocatingly to open or close of the gardening fluid coupling device by using the stop rib, each retaining element, each spaced engagement tooth and the resilient element, and each retaining element is stopped when moving to a second side of each spaced engagement tooth.
F16L 37/10 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using a rotary external sleeve or ring on one part
F16L 37/138 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members using an axially movable sleeve
F16L 37/12 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members
B05B 15/65 - Mounting arrangements for fluid connection of the spraying apparatus or its outlets to flow conduits
A gardening fluid connection device contains a body including multiple retainers, a resilient element, and a fitting sleeve including multiple spaced engagement teeth. The resilient element abuts against the body and the fitting sleeve. The body includes a stop rib, and the multiple spaced engagement teeth are pushed by the resilient element to abut against the stop rib. The body includes at least one retaining element, each retaining element is located on a first side of each spaced engagement tooth, and a width of each spaced engagement tooth is equal to a rotation distance of the fitting sleeve, hence the fitting sleeve is rotated reciprocatingly to open or close of the gardening fluid coupling device by using the stop rib, each retaining element, each spaced engagement tooth and the resilient element, and each retaining element is stopped when moving to a second side of each spaced engagement tooth.
F16L 37/086 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members combined with automatic locking by means of latching members pushed radially by spring-like elements
F16L 37/098 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members combined with automatic locking by means of flexible hooks
F16L 37/10 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using a rotary external sleeve or ring on one part
A sprinkler structure contains: an accommodation tube, multiple water outflow zones, multiple grooved partitions, multiple first water gathering zones, and multiple second water gathering zones. Each first water gathering zone has a first inlet, and each second water gathering zone has a second inlet, the accommodation tube includes multiple first guide orifices and multiple second guide orifices. Each first guide orifice communicates with the accommodation tube, .and each second guide orifice communicates with the accommodation tube, hence a control bar is rotatably connected and horizontally moves in each first guide orifice and each second guide orifice. The control bar further includes an inflow chamber and a receiving portion for housing a stop element, such that the stop element abuts against each first water gathering zone and each second water gathering zone. The control bar further includes two seal rings, and the accommodation tube further includes an elongated lid.
B05B 3/14 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with oscillating elementsSpraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with intermittent operation
A sprinkler structure contains: an accommodation tube, multiple water outflow zones, multiple grooved partitions, multiple first water gathering zones, and multiple second water gathering zones. Each first water gathering zone has a first inlet, and each second water gathering zone has a second inlet, the accommodation tube includes multiple first guide orifices and multiple second guide orifices. Each first guide orifice communicates with the accommodation tube, and each second guide orifice communicates with the accommodation tube, hence a control bar is rotatably connected and horizontally moves in each first guide orifice and each second guide orifice. The control bar further includes an inflow chamber and a receiving portion for housing a stop element, such that the stop element abuts against each first water gathering zone and each second water gathering zone. The control bar further includes two seal rings, and the accommodation tube further includes an elongated lid.
B05B 1/16 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening having selectively-effective outlets
B05B 1/20 - Perforated pipes or troughs, e.g. spray boomsOutlet elements therefor
B05B 3/02 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements
A faucet connector comprises a pipe set having one or more branch pipes connected to a main connecting pipe. The faucet connector also comprises one or more valves each disposed with a water stoppage mechanism and a driving element. A casing set is disposed with one or more than one rotational base. One or more knobs each has a handle and a driving element and respectively and rotationally fits onto the corresponding rotational base. The driving element of each of the knobs is respectively linked to the driving element of the corresponding valve, and a pivot of each of the knobs is inclined at an angle with a pivot of the corresponding valve.
F16K 31/53 - Mechanical actuating means with toothed gearing
F16K 5/04 - Taps or cocks comprising only cut-off apparatus having at least one of the sealing faces shaped as a more or less complete surface of a solid of revolution, the opening and closing movement being predominantly rotary with plugs having cylindrical surfacesPackings therefor
F16L 41/03 - Branch units, e.g. made in one piece, welded, riveted comprising junction pieces for four or more pipe members
F16K 11/22 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid with two or more closure members not moving as a unit operated by separate actuating members with an actuating member for each valve, e.g. interconnected to form multiple-way valves
F16K 11/20 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid with two or more closure members not moving as a unit operated by separate actuating members
E03C 1/02 - Plumbing installations for fresh water
A single or dual sided direction-controllable sprinkler comprises two rotatable trigger portions slidably disposed on a main body. When one trigger portion is limited by a fastener, the two trigger portions have the same rotational position, and when the one trigger portion is not limited by the fastener, the rotational positions of the two trigger portions are controlled independently. The fastener is selectively connected to allow the user to selectively control one of the trigger portions or both of the trigger portions together so that various water sprinkling modes are available.
B05B 3/14 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with oscillating elementsSpraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with intermittent operation
51.
Single or dual sided direction-controllable sprinkler
A single or dual sided direction-controllable sprinkler comprises two rotatable trigger portions slidably disposed on a main body. When one trigger portion is limited by a fastener, the two trigger portions have the same rotational position, and when the one trigger portion is not limited by the fastener, the rotational positions of the two trigger portions are controlled independently. The fastener is selectively connected to allow the user to selectively control one of the trigger portions or both of the trigger portions together so that various water sprinkling modes are available.
B05B 1/00 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
B05B 15/652 - Mounting arrangements for fluid connection of the spraying apparatus or its outlets to flow conduits whereby the jet can be oriented
A nozzle adjustment member for a sprinkler is revealed. A plurality of nozzle tubes aligned in at least one row is positioned on a wall of a hollow pipe. A top end of the nozzle tube is projecting to an outside of the hollow pipe. At least one pivot support is disposed on the outside of the hollow pipe. Each pivot support is pivoted with an adjustment piece having a plurality of guiding openings. The guiding openings are positioned over the plurality of nozzle tubes correspondingly. A nozzle cover is connected with the outside of the hollow pipe for covering the adjustment piece. A plurality of long through holes for mounting the corresponding nozzle tubes is arranged at the nozzle cover. Around a pivot hole, the adjustment piece swings so as to drive the plurality of nozzle tubes moving at an angle and different water distribution patterns are provided.
B05B 1/00 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means
B05B 1/16 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening having selectively-effective outlets
B05B 15/68 - Arrangements for adjusting the position of spray heads
B05B 15/652 - Mounting arrangements for fluid connection of the spraying apparatus or its outlets to flow conduits whereby the jet can be oriented
B05B 1/14 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening
B05B 1/28 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with integral means for shielding the discharged liquid or other fluent material, e.g. to limit area of sprayNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with integral means for catching drips or collecting surplus liquid or other fluent material
B05B 3/00 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements
B05B 3/02 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements
A water dispensing apparatus includes a main body having an inlet channel, an outlet channel and a throughpath provided therebetween, a pivot valve mounted pivotally through the throughpath, which includes a water sealing portion and a water passing portion opposite to each other, and a first sheltering member and a second sheltering member coupled respectively at two sides of the main body, and an actuation member extended operatively between the first sheltering member and the second sheltering member of the pivot valve.
F16K 5/04 - Taps or cocks comprising only cut-off apparatus having at least one of the sealing faces shaped as a more or less complete surface of a solid of revolution, the opening and closing movement being predominantly rotary with plugs having cylindrical surfacesPackings therefor
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
B05B 1/16 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening having selectively-effective outlets
The present invention provides a switching structure of water dispensing apparatus, which is a switch pivotingly coupled in a lateral channel between an inlet channel and an outlet channel of a main body of the water dispensing apparatus. The switch includes a pivot valve, wherein the pivot valve is mounted in the lateral channel of the water dispensing apparatus. Two sides of the pivot valve are assemblingly connecting to an actuation member. The actuation member is arranged to pivotally move the pivot valve so as to bring the pivot valve to pivot and to therefore control the outlet opening between an open state and a close state. The pivot valve has a water sealing portion for closing the inlet opening. Accordingly, when the water sealing portion is misaligned with the inlet opening, the water dispensing apparatus is turned into an open state. When the water sealing portion is relatively seal on the inlet opening, the water dispensing apparatus is turned into an close state.
B05B 1/32 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages in which a valve member forms part of the outlet opening
A water dispensing apparatus includes a dispensing body including a nozzle, a control valve including a water sealing member and a pusher member, an actuation member coupled to the pusher member, and a control unit to drive the control valve to rotate. When the control valve is driven to rotate, the pusher member is driven to move correspondingly to reciprocatingly move the actuation member at different locations of the nozzle not only for switching on-and-off the control valve but also for controllably shifting different water spraying patterns of the nozzle. Therefore, is able to easily control different operations of the water dispensing apparatus in one single continuous action of the control unit.
B05B 1/32 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages in which a valve member forms part of the outlet opening
A water dispensing apparatus includes a dispensing body including a nozzle, a control valve including a water sealing member and a pusher member, an actuation member coupled to the pusher member, and a control unit to drive the control valve to rotate. When the control valve is driven to rotate, the pusher member is driven to move correspondingly to reciprocatingly move the actuation member at different locations of the nozzle not only for switching on-and-off the control valve but also for controllably shifting different water spraying patterns of the nozzle. Therefore, is able to easily control different operations of the water dispensing apparatus in one single continuous action of the control unit.
B05B 1/12 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means capable of producing different kinds of discharge, e.g. either jet or spray
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
B05B 12/00 - Arrangements for controlling deliveryArrangements for controlling the spray area
B05B 15/06 - Mountings, supporting or holding means, or rests for spray heads or other outlets when in use or out of use (B05B 15/10 takes precedence)
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
automatic lawn sprinklers, automatic grass sprinklers, automatic lawn sprinkler heads, automatic grass sprinkler heads, spray nozzles for watering hoses, spray lances for attachment to water hoses, automatic grass sprinklers for gardening use, automatic lawn sprinklers for gardening use, garden syringes, sprinkler heads for lawn sprinklers; spray nozzles for garden hoses; sprinkler heads for lawn sprinklers for watering plants and lawns; spray nozzles for watering hoses for gardening and washing cars; spray lances for attachment to water hoses for gardening and washing cars; parts and fittings for the aforesaid
A sprinkler includes a housing having a tubular axle, a control device including a base coupled at the housing, a bridge upwardly extended from the tubular axle, a first cover including a top platform and an assembling unit downwardly extended from the top platform, and a second cover, having a center through hole, coupled at a top rim of the base. The bridge has two or more bridge ribs and the assembly unit has two or more corresponding windows. The first cover is coupled at the second cover at a position that the assembling unit is downwardly extended through the center through hole until the in center through hole is covered by the top platform, such that the bridge ribs of the bridge are engaged with the windows of the assembling unit of the first cover to securely couple the control device with the housing in a screw-less manner.
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
B05B 1/16 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening having selectively-effective outlets
An irrigation sprinkler includes an engagement component connecting a cap component to a base by a converging movement. The base includes a holding member; the cap component includes an anchor member; and the engagement component includes a first male member and a first female member mating with each other. The first male member is alternatively arranged on the holding member and the anchor member, and the first female member is arranged on the other. Therefore, the first male member non-releasably couples with the first female member by a movement toward each other, and the first engagement component connects the cap component to the base. An indication component couples with the cap component offers visual recognition of the selected one of nozzles.
B05B 3/00 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
B05B 1/16 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening having selectively-effective outlets
An above ground sprinkler is revealed. The ground sprinkler includes a channel controller, a housing with a driving member mounted therein, an adjustment part, a locking plate, a first cover, and a second cover. A tube is extended to form two plates with a retaining groove therebetween. A rib is disposed on an outer side of the plate. The first cover includes a column part with an insertion part while the second cover includes a tongue part. Locking parts are disposed on the insertion part. The insertion part is fitted over the plates while the ribs of the plates are locked with the locking parts. When the second cover is covered over the first cover, the tongue part is mounted into the retaining groove so that the two plates are leaning against and locked by the locking parts tightly, unable to be released.
A62C 11/00 - Portable extinguishers with manually-operated pumps
A01G 25/00 - Watering gardens, fields, sports grounds or the like
B05B 1/16 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening having selectively-effective outlets
B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
An above ground sprinkler is revealed. The ground sprinkler includes a channel controller, a housing with a driving member mounted therein, an adjustment part, a locking plate, a first cover, and a second cover. A tube is extended to form two plates with a retaining groove therebetween. A rib is disposed on an outer side of the plate. The first cover includes a column part with an insertion part while the second cover includes a tongue part. Locking parts are disposed on the insertion part. The insertion part. is fitted over the plates while the ribs of the plates are locked with the locking parts. When the second cover is covered over the first cover, the tongue part is mounted into the retaining groove so that the two plates are leaning against and locked by the locking parts tightly, unable to be released.
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
A sprinkler includes a housing having a tubular axle, a control device including a base coupled at the housing, a bridge upwardly extended from the tubular axle, a first cover including a top platform and an assembling unit downwardly extended from the top platform, and a second cover, having a center through hole, coupled at a top rim of the base. The bridge has two or more bridge ribs and the assembly unit has two or more corresponding windows. The first cover is coupled at the second cover at a position that the assembling unit is downwardly extended through the center through hole until the center through hole is covered by the top platform, such that the bridge ribs of the bridge are engaged with the windows of the assembling unit of the first cover to securely couple the control device with the housing in a screw-less manner.
A01G 25/02 - Watering arrangements located above the soil which make use of perforated pipe-lines or pipe-lines with dispensing fittings, e.g. for drip irrigation
An irrigation controller is revealed. The irrigation controller includes a user interface presenting information to users, easily-operated by buttons and allowing users to program irrigation related information directly. The user interface is composed of a round display, a plurality of program keys, and a selective key. An indicator and programmable information zones are shown on the round display. There are at least six programmable information zones. The information zone is selected by a single selective key. The indicator is moved in one direction in a circular path.
17 - Rubber and plastic; packing and insulating materials
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
watering hose; Watering hoses for indoors and outdoors. Automatic sprinklers; sprinklers; syringes for watering flowers and plants; sprinklers for watering flowers and plants; watering devices; watering cans; spouts; nozzles for watering hose; nozzles for watering cans; roses for watering cans; aerosol dispensers, not for medical purposes; sprinklers head; spray guns (for watering hoses); spray lances (for attachment to hose pipes for water purposes).
A coupler for connection and assembly of an irrigation system is revealed. The coupler includes a base, a connecting portion and a retaining member. The base is for mounting the connecting portion and the retaining member. The connecting portion is arranged with a first channel and a second channel. The second channel is used to receive an insert that is connected to sprayers or hoses. The coupler features on that the second channel above the retaining member is arranged with a seal ring. While the insert is pressed downward axially, the insert is first against the seal ring so as to prevent water flow from being sprayed out of a gap of the second channel between an inner diameter of the connecting portion and an outer diameter of the insert.
F16L 37/42 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in only one of two pipe-end fittings with a lift valve being opened automatically when the coupling is applied the valve having an axial bore communicating with lateral apertures
A nozzle adjustment member for a sprinkler is revealed. A plurality of nozzle tubes aligned in at least one row is positioned on a wall of a hollow pipe. A top end of the nozzle tube is projecting to an outside of the hollow pipe. At least one pivot support is disposed on the outside of the hollow pipe. Each pivot support is pivoted with an adjustment piece having a plurality of guiding openings. The guiding openings are positioned over the plurality of nozzle tubes correspondingly. A nozzle cover is connected with the outside of the hollow pipe for covering the adjustment piece. A plurality of long through holes for mounting the corresponding nozzle tubes is arranged at the nozzle cover. Around a pivot hole, the adjustment piece swings so as to drive the plurality of nozzle tubes moving at an angle and different water distribution patterns are provided.
B05B 15/00 - Details of spraying plant or spraying apparatus not otherwise provided forAccessories
B05B 1/14 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening
B05B 15/06 - Mountings, supporting or holding means, or rests for spray heads or other outlets when in use or out of use (B05B 15/10 takes precedence)
B05B 15/08 - Means for adjusting position of spray heads
B05B 1/28 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with integral means for shielding the discharged liquid or other fluent material, e.g. to limit area of sprayNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with integral means for catching drips or collecting surplus liquid or other fluent material
B05B 3/00 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements
A sprinkler adjustment member includes a plurality of nozzle tubes aligned in a sprinkler base. An adjustment piece is assembled with the sprinkler base. The adjustment piece controls and guide the plurality of nozzle tubes correspondingly and the adjustment piece swings so as to drive the plurality of nozzle tubes moving at an angle and different water distribution patterns are provided. The sprinkler base is pivotally disposed on a receiving member and for adjustment angle with a pendulum movement. A place base is connected with the receiving member and the receiving member is capable of pivoting on the place base, such that the sprinkler moves and tilts at multi-angles and multi-directions for providing various sprinkling patterns.
B05B 3/00 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements
B05B 1/14 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening
B05B 15/652 - Mounting arrangements for fluid connection of the spraying apparatus or its outlets to flow conduits whereby the jet can be oriented
B05B 15/68 - Arrangements for adjusting the position of spray heads
A faucet diverter is revealed. The faucet diverter includes at least one outlet and a control part for switching direction of water flow discharged. The faucet diverter is connected to a faucet.
A supporter for connecting and positioning irrigation devices is revealed. The supporter for connecting and positioning irrigation devices includes a conical body and a connecting device. The conical body consists of a sharp end and a connecting end. The sharp end is mounted into the ground for positioning. The connecting device is composed of a receiving portion, assembly portions, and a switch portion. The assembly portions are used for connection to hoses and water flow guidance while the switch portion is used to control on/off of the water flow in the connecting device. The connecting device is set on the connecting end of the conical body so as to connect to hoses and position the hoses on the ground by the conical body.
A62C 31/22 - Nozzles specially adapted for fire-extinguishing specially adapted for piercing walls, heaped materials, or the like
A01G 25/02 - Watering arrangements located above the soil which make use of perforated pipe-lines or pipe-lines with dispensing fittings, e.g. for drip irrigation
F16L 35/00 - Special arrangements used in connection with end fittings of hoses, e.g. safety or protecting devices
F16L 41/02 - Branch units, e.g. made in one piece, welded, riveted
F16L 3/127 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets substantially surrounding the pipe, cable or protective tubing comprising a member substantially surrounding the pipe, cable or protective tubing and extending away from the attachment surface
A sprinkler with adjustable fan angle of water sprayed is revealed. The adjustable fan angle of water sprayed means a fan area of the water sprayed is adjusted and changed. The sprinkler includes a housing, a receiving seat and a sprinkler head. The sprinkler head consists of a base seat, a collar member and an adjustment member. The fan angle of the water sprayed can be manually operated and changed by rotating the adjustment member.
B05B 1/32 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages in which a valve member forms part of the outlet opening
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
B05B 1/28 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with integral means for shielding the discharged liquid or other fluent material, e.g. to limit area of sprayNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with integral means for catching drips or collecting surplus liquid or other fluent material
83.
SUPPORTER FOR CONNECTING AND POSITIONING IRRIGATION DEVICE
A supporter for connecting and positioning irrigation devices is revealed. The supporter for connecting and positioning irrigation devices includes a conical body and a connecting device. The conical body consists of a sharp end and a connecting end. The sharp end is mounted into the ground for positioning. The connecting device is composed of a receiving portion, assembly portions, and a switch portion. The assembly portions are used for connection to hoses and water flow guidance while the switch portion is used to control on/off of the water flow in the connecting device. The connecting device is set on the connecting end of the conical body so as to connect to hoses and position the hoses on the ground by the conical body.
A sprinkler with adjustable fan angle of water sprayed is revealed. The adjustable fan angle of water sprayed means a fan area of the water sprayed is adjusted and changed. The sprinkler includes a housing, a receiving seat and a sprinkler head. The sprinkler head consists of a base seat, a collar member and an adjustment member. The fan angle of the water sprayed can be manually operated and changed by rotating the adjustment member.
A water timer is revealed. The water timer includes a base assembly, a valve assembly and a display module. The base assembly consists of a first housing and a second housing. The valve assembly having a conducting tube and a valve member is for turning on or off water supply. The display module is composed of a first space, a circuit board, an input member, and a rectangular column connected to t first space and used for receiving a battery box. The water timer features on that the display module is arranged with an integrated rectangular column used for receiving a battery box and the display module is locked on the first housing.
An automatic water sprinkler regulator is provided to control sprinkler coverage and times for water cycles. The regulator comprises control interface, series of control buttons, water inlet part, water outlet part, control processor. An improvement made in the present invention focuses on rendering a control interface with multiple approaches to control times for water cycles to make for a controller interface that can be set for irrigating by way of a series of control buttons.
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
(1) Automatic sprinklers for gardening use, syringes for gardening use, spray guns for gardening use, namely hand-pumped sprayers for applying herbicide, watering cans for gardening use, nozzles for sprinkler hoses for gardening use, nozzles for watering cans, water timer, micro-drip irrigation systems, pop-up sprinklers for gardening use, lawn sprinklers, oscillating sprinklers for gardening use, garden hose spray nozzles, water wands for gardening use
Disclosed is a drizzle type spray apparatus, especially a wetting drizzle spray apparatus, that is configured to attach an adjustable member onto an erectable ground-based tube, the adjustable member is made of adjustable units having rotatable angles, and works to operatively make up a sprinkle head, so as to allow change in the spray direction of the sprinkle head.
B05B 1/32 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages in which a valve member forms part of the outlet opening
B05B 3/02 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements
B05B 3/06 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet by jet reaction
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
B05B 15/06 - Mountings, supporting or holding means, or rests for spray heads or other outlets when in use or out of use (B05B 15/10 takes precedence)
B05B 1/12 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means capable of producing different kinds of discharge, e.g. either jet or spray
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
A47L 15/42 - Washing or rinsing machines for crockery or table-ware Details
A47L 15/23 - Rotary spraying devices moved by means of the sprays
A01G 25/02 - Watering arrangements located above the soil which make use of perforated pipe-lines or pipe-lines with dispensing fittings, e.g. for drip irrigation
A01G 25/00 - Watering gardens, fields, sports grounds or the like
A01M 7/00 - Special adaptations or arrangements of liquid-spraying apparatus for purposes covered by this subclass
B08B 9/093 - Cleaning of containers, e.g. tanks by the force of jets or sprays
A finger-operated switch is revealed. The finger-operated switch includes a main body and a switch. The main body includes an intake channel, a turning channel and an outlet channel connected sequentially. On end of the outlet channel near the turning channel is arranged with an outlet and mounted with a waterproof gasket. The switch including a rotating shaft and a waterproof spacer is set on the rotating shaft. There is a certain distance between the turning channel and the rotating shaft mounted therein. The waterproof spacer is floatable in and moving synchronously with the rotating shaft. While adjusting the rotating shaft, the waterproof spacer is driven to close or open the outlet of the waterproof gasket. When the outlet is closed, a pushing force is produced toward the outlet because water pressure in the turning channel presses the waterproof spacer. A watertight effect is achieved.
A finger-operated switch is revealed. The finger-operated switch includes a main body and a switch. The main body includes an intake channel, a turning channel and an outlet channel connected sequentially. On end of the outlet channel near the turning channel is arranged with an outlet and mounted with a waterproof gasket. The switch including a rotating shaft and a waterproof spacer is set on the rotating shaft. There is a certain distance between the turning channel and the rotating shaft mounted therein. The waterproof spacer is floatable in and moving synchronously with the rotating shaft. While adjusting the rotating shaft, the waterproof spacer is driven to close or open the outlet of the waterproof gasket. When the outlet is closed, a pushing force is produced toward the outlet because water pressure in the turning channel presses the waterproof spacer. A watertight effect is achieved.
A magnetic control valve is to block an outlet end of a water inflow passage and an inlet end of a water outflow passage of a connection pipe by using a rubber ring. A valve of the rubber ring is opened or closed by a magnetic control switch. The magnetic control switch mainly takes a valve rod carrying permanent magnetic force that completely controls direction of electromagnetic pole as a power source for moving. When a valve plug at an end of the valve rod seals the valve, a metal plate capable of being sucked by magnetic force is combined with the rubber ring to allow both to generate magnetic sucking effect, thereby firmly closing.
A nozzle assembly for a sprinkler is revealed. The nozzle assembly includes a main channel having a water inlet on one end and a water outlet on the other end thereof The nozzle assembly features on that: an adjustment member for control of water flow is disposed on the main channel, located between the water inlet and the water outlet. The adjustment member is arranged around the main channel. The displacement direction of the adjustment member and the water flow direction of the main channel are not along the same axis, or not parallel to each other. Thus when the nozzle assembly is applied to underground sprinklers; it is hidden from view and is able to prevent others from changing outlet water flow purposely.
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
B05B 1/26 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with means for mechanically breaking-up or deflecting the jet after discharge, e.g. with fixed deflectorsBreaking-up the discharged liquid or other fluent material by impinging jets
B05B 15/06 - Mountings, supporting or holding means, or rests for spray heads or other outlets when in use or out of use (B05B 15/10 takes precedence)
B05B 15/10 - Arrangements for moving spray heads automatically to or from the working position
A nozzle adjustment member for a sprinkler is revealed. A plurality of nozzle tubes aligned in at least one row is positioned on a wall of a hollow pipe. A top end of the nozzle tube is projecting to an outside of the hollow pipe. At least one pivot support is disposed on the outside of the hollow pipe. Each pivot support is pivoted with an adjustment piece having a plurality of guiding openings. The guiding openings are positioned over the plurality of nozzle tubes correspondingly. A nozzle cover is connected with the outside of the hollow pipe for covering the adjustment piece. A plurality of long through holes for mounting the corresponding nozzle tubes is arranged at the nozzle cover. Around a pivot hole, the adjustment piece swings so as to drive the plurality of nozzle tubes moving at an angle and different water distribution patterns are provided.
B05B 3/16 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with oscillating elementsSpraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with intermittent operation driven or controlled by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
B05B 1/14 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening
B05B 15/06 - Mountings, supporting or holding means, or rests for spray heads or other outlets when in use or out of use (B05B 15/10 takes precedence)
B05B 15/08 - Means for adjusting position of spray heads
A nozzle adjustment member for a sprinkler is revealed. A plurality of nozzle tubes aligned in at least one row is positioned on a wall of a hollow pipe. A top end of the nozzle tube is projecting to an outside of the hollow pipe. At least one pivot support is disposed on the outside of the hollow pipe. Each pivot support is pivoted with an adjustment piece having a plurality of guiding openings. The guiding openings are positioned over the plurality of nozzle tubes correspondingly. A nozzle cover is connected with the outside of the hollow pipe for covering the adjustment piece. A plurality of long through holes for mounting the corresponding nozzle tubes is arranged at the nozzle cover. Around a pivot hole, the adjustment piece swings so as to drive the plurality of nozzle tubes moving at an angle and different water distribution patterns are provided.
A spray switch for spray gun includes an elastic wire buckled to a main pipe of the spray gun. The elastic wire has symmetric lateral portions and symmetric guide pins on two ends thereof. A press handle pivoted to a main body of the spray gun is capable of controlling a flow of water. The press handle has an open slot for slidly arranging the spray switch. The spray switch is assembled by a guide block and a buckle unit. The guide block has symmetric guides and recesses on two lateral sides for guiding and holding the guide pins. The spray switch can be switched up and down along the open slot to switch the guide block for engaging or ignoring the guide pins so as to switch the spray gun between modes of auto spray and manual spray.
B05B 1/14 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening
An improved sprinkler has a flow altering device to change water direction and control the direction of a blade wheel. A gear set causes a sprinkler head's repetitive rotation. The sprinkler head includes a set of corresponding upper plate and lower plate to divide an interior chamber of the sprinkler head to two chambers: a control chamber and a gear chamber. A water inlet pipe connects only with the control chamber to provide water to enter the control chamber. The upper plate and the lower plate form a filtering channel interconnecting between the control chamber and the gear chamber. The water from the control chamber can flow into the gear chamber through the filtering channel. The filtering channel filters the large/coarser particle debris in the water and the water flowing into the gear chamber can lubricate and cool the gear set in the gear chamber.
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
An oscillating sprinkler includes two adjustment plate rotatably mounted on a hollow tube of the body of the sprinkler and nozzles extend through the hollow tube and guide slots defined through the adjustment plates. Each of the two adjustment plates has two control members on two sides thereof so as to pivot the adjustment plate individually relative to the hollow tube. A top cover is mounted to the adjustment plates and has multiple guide holes, the nozzles extend through the guide holes.
B05B 3/16 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with oscillating elementsSpraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with intermittent operation driven or controlled by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
A multi-functional sprinkling apparatus structure comprises an outlet mount with support lugs to fix on top of a water motor, and a water-guiding member transversely mounted to assembly holes of the support lugs. The assembly holes have water ducts fluidly connected to water-inlet passages of the water- guiding member. A rotary member with a channel and a water shield with actuation holes are pivotally mounted to the middle section of the water-guiding member. The channel of the rotary member has multiple outlets with spray nozzles attached thereto to generate various sprays, and recesses to engage with a movable elastic element mounted to the water-guiding member. The rotary member can be switched to change the outlet matching to a water-discharge orifice of the water-guiding member for a certain spray. The water shield can be bent to one side to adjust the angle of the water-guiding member and the rotary member for sprinkling.
A01G 25/00 - Watering gardens, fields, sports grounds or the like
B05B 3/16 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with oscillating elementsSpraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with intermittent operation driven or controlled by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
A multi-functional sprinkling apparatus structure comprises an outlet mount with support lugs to fix on top of a water motor, and a water-guiding member transversely mounted to assembly holes of the support lugs. The assembly holes have water ducts fluidly connected to water-inlet passages of the water-guiding member. A rotary member with a channel and a water shield with actuation holes are pivotally mounted to the middle section of the water-guiding member. The channel of the rotary member has multiple outlets with spray nozzles attached thereto to generate various sprays, and recesses to engage with a movable elastic element mounted to the water-guiding member. The rotary member can be switched to change the outlet matching to a water-discharge orifice of the water-guiding member for a certain spray. The water shield can be bent to one side to adjust the angle of the water-guiding member and the rotary member for sprinkling.
B05B 3/04 - Spraying or sprinkling apparatus with moving outlet elements or moving deflecting elements with rotating elements driven by the liquid or other fluent material discharged, e.g. the liquid actuating a motor before passing to the outlet
