Abstract

The invention provides a switch device including a shell, an operating member, a spring, a movable conductor, a first pin, a second pin, two resistors, and two connecting conductors. The operating member is partially exposed out of the shell, and the movable conductor is displaced when the operating member is operated. One side of the shell is provided with the first pin and the spring, another side is provided with the second pin. The resistors are connected with the second pin and have different resistance values. The connecting conductors are arranged between the two pins. The first pin contacts with the movable conductor. The connecting conductors without disposal of any crossover part therebetween and respectively connected with the resistors. The connecting conductors are arranged at intervals along a displacement path of the movable conductor which contacted one connecting conductor before and after displacement and forming two conductive paths.

IPC Classes  ?

• H01H 13/18 - Operating parts, e.g. push-button adapted for actuation at a limit or other predetermined position in the path of a body, the relative movement of switch and body being primarily for a purpose other than the actuation of the switch, e.g. door switch, limit switch, floor-levelling switch of a lift
• H01H 3/16 - Operating parts, i.e. for operating driving mechanism by a mechanical force external to the switch adapted for actuation at a limit or other predetermined position in the path of a body, the relative movement of switch and body being primarily for a purpose other than the actuation of the switch, e.g. for a door switch, a limit switch, a floor-levelling switch of a lift
• H05K 1/02 - Printed circuits Details
• H01H 9/02 - Bases, casings, or covers

Abstract

A power supply housing adapted to a redundant power module includes a casing, a separation member, two front plates and a back plate. The casing includes four side plates and an installation space defined by the side plates. The separation member divides the installation space into a first sub-space and a second sub-space, and includes two first baffles located in the first sub-space and two second baffles located in the second sub-space. The two first baffles define a first installation region for disposing a redundant power module, and the two second baffles define a second installation region for disposing the redundant power module. The front plates are disposed on one end of the installation space and define a placement opening, serving as an entrance of the first and the second installation region. The back plate is disposed on one end of the installation space not provided with the front plates.

IPC Classes  ?

• G06F 1/00 - Details not covered by groups and
• G06F 1/18 - Packaging or power distribution
• G06F 1/26 - Power supply means, e.g. regulation thereof
• G06F 1/3203 - Power management, i.e. event-based initiation of a power-saving mode

Abstract

A stroke adjustment cover for clip-type micro switch, the stroke adjustment cover comprises a cover body connected to a clip-type micro switch, a stroke adjustment member disposed in the cover body, and an elastic member used to provide the stroke adjustment member with a reciprocating stroke perpendicular to the direction of an actuation stroke of the clip-type micro switch. Through an adjustment section of the stroke adjustment member includes at least one brake portion used for braking the clip-type micro switch to generate the actuation stroke in the reciprocating stroke provided by the elastic member. The present invention not requires modification of the actuation stroke and structure of the clip-type micro switch, while an actuation time of a switching command signal of the clip-type micro switch is extended by the stroke adjustment cover provided with the different reciprocating strokes and being easy to install.

IPC Classes  ?

• H01H 21/04 - CasesCovers
• H01H 21/22 - Operating parts, e.g. handle
• H01H 21/24 - Operating parts, e.g. handle biased to return to original position upon removal of operating force
• H01H 21/86 - Switches with abutting contact carried by operating part, e.g. telegraph tapping key

Abstract

A multi-command trigger switch includes a rotary switch, a rotary casing and a trigger element. The rotary switch includes a base and a rotary disc coupled with the base and movable on a swivel locus against the base. The base and the rotary disc are interposed by a housing space to hold a rotary trigger assembly and a depressing trigger assembly. The rotary trigger assembly outputs a first trigger signal while moving on the swivel locus. The depressing trigger assembly outputs a second trigger signal while moving on a vertical locus. The rotary casing and the rotary switch define a movement space therebetween to hold the trigger element. The base and the depressing trigger assembly confine movement of the depressing trigger assembly through a positioning notch and a confining rib. The depressing trigger assembly and the trigger element include confine the trigger element from rotating against the rotary casing.

IPC Classes  ?

• H01H 9/00 - Details of switching devices, not covered by groups
• H01H 25/04 - Operating part movable angularly in more than one plane, e.g. joystick

Goods & Services

switches, electric; time switches, automatic; wire connectors (electricity); terminals (electricity); computer peripheral devices; computer keyboards; computer hardware.

Abstract

A multi-instruction switch for enhancing electrical insulation is provided. The multi-instruction switch includes a housing, a common pin and a switching pin set. The housing comprises an accommodating space which includes a conductive elastic plate moving back-and-forth and a support rack therein. The conductive elastic plate includes a normal connection section and a switching connection section. The support rack includes a limiting track. The common pin is normally in electrical contact with the normal connection section in the housing. The switching pin set includes a first pin having a contact section and a second pin having a trigger section. The limiting track includes a first insulation plate, a second insulation plate, and an insulation space between the first and second insulation plates. As such, the present invention enhances the insulation effect by the first and second insulation plates and the insulation space located at the limiting track.

IPC Classes  ?

• H01H 13/36 - Snap-action arrangements depending upon deformation of elastic members using flexing of blade springs
• H01H 13/40 - Blade spring with at least one snap-acting leg and at least one separate contactcarrying or contact-actuating leg
• H01H 33/06 - Insulating body insertable between contacts

Abstract

A transformer without coil racks includes a winding set, multiple conductive plates and an insulation mounting sheet. The winding set includes a coil portion and a magnetic core set running through the coil portion. The magnetic core set includes at least one inner magnetic core portion and at least two outer magnetic core portions that are spaced from each other by a gap. Each conductive plate includes a connecting section and two extended arms connected to two ends of the connecting section and running through the gap. The insulation mounting sheet includes multiple retaining slots corresponding to the gap to allow the extended arms to pass through and multiple retaining portions each being formed between two neighboring retaining slots to prevent the extended arms from contacting each other. The conductive plates run through the retaining slots and are confined by the retaining portions from moving.

IPC Classes  ?

• H01F 27/30 - Fastening or clamping coils, windings, or parts thereof togetherFastening or mounting coils or windings on core, casing, or other support
• H01F 27/28 - CoilsWindingsConductive connections

Abstract

An enhanced withstand voltage micro switch includes a base and a cap covering the base. The cap has a press element movable up and down. The base has a conductive member depressed by the press element and a connecting section extended upwards. The base also includes a first contact, and a second contact extended from the connecting section and located above the first contact. The conductive member is swung during up and down movement of the press element to connect with the first or the second contact. The connecting section has an isolation portion jutting sideward between the first and second contacts to prevent generation of a conductive layer caused by connection of the conductive member with the first and second contacts on the connecting section. Thus secured insulation can be formed between the first and second contacts to withstand a higher voltage test.

IPC Classes  ?

• H01H 5/30 - Energy stored by deformation of elastic members by buckling of disc springs

Abstract

An enhanced returning elasticity micro switch includes a base and a cap mounted thereon to form a housing compartment therebetween. The base is run through by a first pin and a second pin. The first pin has an anchor portion in the housing compartment to couple with a conductive member. The conductive member has a lower contact portion and swings when being pressed. The second pin has a first contact in the housing compartment. The first contact has an inclined surface connected to the lower contact portion during swing of the conductive member. The inclined surface is located at an elevation tapered towards the anchor portion. Hence the contact area between the conductive member and second pin increases, and adhesion force between the conductive member and second pin during power transmission decreases. Returning elasticity of the conductive member increases, and resistance against depression of the conductive member decreases.

IPC Classes  ?

• H01H 5/14 - Energy stored by deformation of elastic members by twisting of torsion members

Abstract

A luminous micro-switch mainly includes a case which holds a depressing member and at least a first pin and a second pin inside that are spaced from each other. There is a bridging member interposed between the two pins and the depressing member to form electric connection with the first pin in regular conditions and output a signal when the bridging member is connected to the second pin due to depressing of the depressing member. The depressing member has a depressing end which has a holding trough to hold a lighting element which has two conductive terminals to receive electric power to generate light. By holding the lighting element in the holding trough the size of the micro-switch can be made smaller to be used on smaller electronic devices to overcome the bulky problem of conventional micro-switches caused by disposing the lighting element beneath the depressing member.

IPC Classes  ?

• H01H 9/00 - Details of switching devices, not covered by groups

Abstract

The present invention discloses that a primary and a secondary winding coil are respectively wound around the core and are separated by an insulating layer; and the secondary winding coil has a winding portion wound around the core through at least a circle to define two winding terminals, wherein each winding terminal of the winding portion is connected with an extending section extended to the outside of the transformer and is connected with an electricity connecting section at the rear end thereof. The electricity connecting section has plural pins electrically welded on a circuit board, thereby the extending section that is connected with a rectification switch and increases the contact areas with the air for achieving a heat-dispersing effect and the electricity connecting section are crossing connected between the secondary winding coil and the circuit board to save the space on the circuit board for arranging the secondary winding coil.

IPC Classes  ?

• H01F 27/29 - TerminalsTapping arrangements

Abstract

A watertight switch comprises a cover and a base assembled together to form an accommodating space for mounting a switching module therein. The cover and the base, at the combination interface therebetween, respectively have a first junction interface and a second junction interface, which are inwardly shrunk to form a binding gap, the binding gap is gummed by an adhesive for fixedly combining and positioning the first and the second junction interfaces, and the adhesive will fill the binding gap without flowing over the first and the second junction interfaces.

IPC Classes  ?

• H01H 9/04 - Dustproof, splashproof, drip-proof, waterproof, or flameproof casings

Abstract

A fan voltage regulation control device includes a voltage regulation control unit for providing the power to a heat-dispersing fan, wherein the voltage regulation control unit is connected to a temperature detecting element and a voltage detecting unit. The temperature detecting element may influence the output power from the control unit to the fan, and through the voltage detecting unit, an input current to the fan can be maintained for providing overload and overheated protections.

IPC Classes  ?

• H02P 7/00 - Arrangements for regulating or controlling the speed or torque of electric DC motors
• H02H 7/08 - Emergency protective circuit arrangements specially adapted for specific types of electric machines or apparatus or for sectionalised protection of cable or line systems, and effecting automatic switching in the event of an undesired change from normal working conditions for dynamo-electric motors

Goods & Services

Computer keyboards; card readers; computer mouse; computer printers; computer memories; central processing units; computer disc drivers; electric game device for computer; TV game players; optic fibers; telephones; telephones (cellular); antennas; electric appliance filters; modems; carrier cable devices; computer monitors; transceivers; LAN Adapter (a computer device that can connect computer to network); computer interface boards; switches (electric); plugs; connectors; power supply stabilizers; battery chargers; transformers; voltage regulators; surge generators; electrical dissipating fans; current collectors. Hand held unit for playing electronic games; computer game equipment containing memory game devices; namely computer discs; computer game cartridges; computer game programs. Agencies for import and export services; retailing services via telecommunication network; retailing agents.

Goods & Services

(1) Computer keyboards; magnetic coded card readers; computer mouse; computer printers; computer memories; central processing units; computer disc drivers; TV game players, namely hand held units for playing video games; fiber optics; telephones; telephones (cellular); antennas; electric appliance filters, namely electric circuit boards; modems; carrier cable devices, namely electrical conductors; computer monitors; transceivers; LAN Adapter ( a computer device that can connect computer to network); computer interface boards; switches (electrical); plugs; connectors; power supplies, namely power control boxes, power supply stabilizers, battery chargers, electrical transformers, voltage regulators, surge generators, electrical dissipating fans, current collectors; uninterruptible power supply systems (UPS); hand held unit for playing electronic games; computer game equipment containing memory game devices, namely computer discs, computer game cartridges, computer game programs. (1) Agencies for import and export services.

Goods & Services

COMPUTER KEYBOARDS; MAGNETIC CODED CARD READERS; COMPUTER MOUSE; COMPUTER MEMORIES; CENTRAL PROCESSING UNITS; COMPUTER DISC DRIVES; FIBER OPTICS; TELEPHONES; CELLULAR TELEPHONES; ANTENNAS; ELECTRIC CIRCUIT BOARDS FOR NOISE ISOLATION; MODEMS; ELECTRICAL CONDUCTORS; COMPUTER MONITORS; TRANSCEIVERS; LOCAL AREA NETWORK COMPUTER DEVICES, NAMELY, NETWORK CONTROLLERS AND PRINTED CIRCUIT BOARDS; COMPUTER INTERFACE BOARDS; ELECTRIC SWITCHES; ELECTRIC PLUGS; ELECTRIC CONNECTORS; ELECTRIC POWER SUPPLIES; UNINTERRUPTED ELECTRIC POWER SUPPLIES; BATTERY CHARGERS; ELECTRIC TRANSFORMERS; VOLTAGE REGULATORS FOR ELECTRIC POWER; VOLTAGE SURGE PROTECTORS; ELECTRICAL DISSIPATING FANS; AND CURRENT COLLECTORS

Goods & Services

power supplies; computers and computer peripherals, namely, file servers, disk arrays, external hard and floppy disk drives, external CD-ROMs and tape drives, and monitors; electronic dictionaries; dot matrix and laser printers, computer disk drives; uninterruptible switching power supplies; keyboards

Goods & Services

(1) Switches for electric appliances.

Goods & Services

power supplies; computers and computer peripherals; namely, file servers, disk arrays, external hard and floppy drives, external CD-ROM and tape drives, and monitors; electronic dictionaries; dot matrix and laser printers, computer disk drives; portable computers; and hard disks for computers

Goods & Services

switches of electric appliances
