Abstract

An apparatus for stabilizing body joints and/or for supporting sports equipment, comprising: a receptacle, wherein the receptacle is filled with a filling medium, a first body for interacting with the filling medium, wherein the first body is arranged in a displaceable manner in the receptacle, a force transmission body for transmitting an external force to the first body, a second body for interacting with the filling medium, which second body is arranged in a displaceable manner in the receptacle, wherein the second body can be elastically coupled to the first body via a coupling element, wherein at least the first body has at least one passage opening through which the filling medium can flow, wherein the second body is displaceably received within the passage opening of the first body, wherein the first body comprises a valve seat in the region of the passage opening and the second body forms a valve body, so that a flow of the filling medium through the passage opening can be permitted or prevented depending on the valve position.

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Abstract

The invention relates to a device for stabilizing body joints and/or for supporting items of sports equipment. The device comprises a receiving area, said receiving area being filled with a fluid; an active body for interacting with the fluid, said active body being movably mounted in the receiving area; and a force transmission element for transmitting external forces to the interior of the receiving area. The force transmission element extends at least partly through the receiving area and can be moved relative to the receiving area, and the active body is mounted on a first end of the force transmission element. The receiving area has an opening through which the force transmission element extends from outside into the interior of the receiving area, and an attachment element for introducing an external force into the device is mounted on a second end of the force transmission element outside of the receiving area. A flexible chamber adjoins the receiving area in the region of the opening, said flexible chamber extending between the opening and the attachment element, and the force transmission element portion protruding out of the receiving area extends through the flexible chamber. The flexible chamber is fluidically connected to the receiving area via the opening, and the flexible chamber is configured such that when the attachment element moves relative to the receiving area, the flexible chamber is stretched or compressed. The attachment element closes off the flexible chamber, at a first end, from the surroundings in a fluid-tight manner, and the attachment element is characterized by being divided into two parts, wherein a first part has a receiving region, in particular a seat, for the second end of the force transmission element, in particular for receiving the second end of the force transmission element in a force-fitting manner, and a second part which is configured to close the receiving region, in particular in the manner of a cover.

IPC Classes  ?

• A61F 2/50 - Prostheses not implantable in the body
• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• B60G 17/08 - Characteristics of fluid dampers
• F16F 9/32 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details

Abstract

The invention relates to a device (1) for stabilizing body joints and/or for supporting items of sports equipment, comprising a receiving area (20), said receiving area (20) being filled with a filling medium (30); a first element (40) for interacting with the filling medium (30), said first element being movably mounted in the receiving area (20); a force transmission element (50) for transmitting an external force to the first element (40); a second element (60) for interacting with the filling medium (30), said second element being movably mounted in the receiving area (20), wherein the second element can be elastically coupled to the first element (40) via a coupling element (70), the second element (60) and/or the first element (40) has at least one passage opening (64), through which the filling medium (30) can flow, and the first element (40) forms a valve body and the second element (60) forms a valve seat such that a flow of the filling medium (30) through the passage opening (64) can be permitted or inhibited on the basis of the valve position. The device additionally has a third element (80) for positioning the first element (40) and the second element (60) relative to each other, said third element (80) overlapping with the first element (40) at a first region (82) and with the second element (60) at a second region (84) in a relative movement direction VR of the first and second element.

IPC Classes  ?

• A61F 2/50 - Prostheses not implantable in the body
• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• B60G 17/08 - Characteristics of fluid dampers
• F16F 9/32 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details

Abstract

The invention relates to a method for filling an adapter (10) for stabilizing body joints and/or for supporting items of sports equipment with a fluid (20), said adapter (10) comprising: a first chamber (30) and a second chamber (40); at least one channel (51) between the first chamber (30) and the second chamber (40) for establishing a fluidic connection, wherein the transition between the first chamber (30) and/or the second chamber (40) and the channel (51) forms an inlet (52) through which the fluid (20) can flow into the channel (51); a force transmission element (60) for transmitting external forces into the interior of the first chamber (30) and/or the second chamber (40), said force transmission element (60) extending at least partly through the first chamber (30) and the second chamber (40) and being movable relative to the first chamber (30) and the second chamber (40); a seal element (70) for sealing the channel (51) in order to suppress a flow of fluid between the first chamber (30) and the second chamber (40), said seal element (70) being movably mounted in the first chamber (30) or in the second chamber (40); and a driver (80), which is provided on the force transmission element (60), for moving the seal element (70) relative to the first chamber (30) and the second chamber (40).

IPC Classes  ?

• A61F 2/50 - Prostheses not implantable in the body
• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• B60G 17/08 - Characteristics of fluid dampers
• F16F 9/32 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details

Abstract

The present invention relates to a device (1) for limiting and/or damping a foot movement via the ankle joint, comprising: a support assembly (2) for support on a lower limb (112) and/or proximally on the ankle-joint malleolus (114); a holding assembly (3) for holding on a foot (110), preferably on a sole region of a foot (110); and at least one connection element (4), which extends between the support assembly (2) and the holding assembly (3) and is connected to each of the support assembly and the holding assembly. The device also comprises a tightening assembly (5) for tightening the connection element (4), which tightening assembly is designed such that the connection element (4) between the holding assembly (3) and the support assembly (2) can be changed between a loosened state and a tightened state. The invention also relates to a shoe (100) for limiting and/or damping a foot movement via the ankle joint.

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• A43B 7/20 - Ankle-joint supports or holders

Abstract

The present invention relates to an apparatus (1) for stabilizing body joints and/or for supporting items of sports equipment, comprising: a receptacle (20), wherein the receptacle (20) is filled with a filling medium (3), a first body (40) for interacting with the filling medium (30), wherein the first body is displaceably arranged in the receptacle (20), a force transmission body (50) for transmitting an external force to the first body (40), a second body (60) for interacting with the filling medium (30), which is displaceably arranged in the receptacle (20), wherein the second body can elastically be coupled to the first body (40) via a coupling element (70), wherein at least the first body (40) has at least one passage opening (41), through which the filling medium (30) can flow, wherein the second body (60) is displaceably received within the passage opening (41) of the first body (40), wherein the first body (40) has a valve seat (42) in the region of the passage opening (41) and the second body (60) forms a valve body, such that a flow of the filling medium (30) through the passage opening (41) can be permitted or inhibited as a function of the valve position.

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• F16F 9/34 - Special valve constructionsShape or construction of throttling passages

Abstract

An apparatus for stabilizing movements of two parts of a body region and/or of a sports device which are movable relative to one another, comprising a receptacle, which can be fixed to a first part of the region and/or device. An active body arrangement with an active body is received movably in the receptacle and can interact with the filling medium. A force transmission body can be fixed to a second part of the same region and/or device for transmitting an external force to the active body. The active body comprises at least one through-opening through which a filling medium in the receptacle can flow. The active body arrangement has a sealing lip for sealing a gap between an inner side of the receptacle and a lateral region of an outer side of the active body arrangement, the sealing lip being arranged on an outer side of the active body.

IPC Classes  ?

• F16F 9/32 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details
• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• F16F 9/19 - Devices with one or more members, e.g. pistons, vanes, moving to and fro in chambers and using throttling effect involving only straight-line movement of the effective parts with a closed cylinder and a piston separating two or more working spaces therein with a single cylinder
• F16F 9/516 - Special means providing automatic damping adjustment resulting in the damping effects during contraction being different from the damping effects during extension
• F16F 9/58 - Stroke limiting stops, e.g. arranged on the piston rod outside the cylinder

Abstract

A device for stabilizing movements of two parts of a human body region and/or of a sports appliance which are movable relative to each other is provided, the device comprising a receptacle, which is fixable on a first part of a human body region and/or of a sports appliance, wherein the receptacle is filled with a filling medium, and wherein the receptacle comprises a receptacle opening; an interaction element fixable on a second part of the same human body region and/or of the same sports appliance, which is at least partially accommodated displaceably in the receptacle and extends through the receptacle opening, wherein the part of the interaction element that is located in the receptacle is in contact with the filling medium.

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• F16F 9/19 - Devices with one or more members, e.g. pistons, vanes, moving to and fro in chambers and using throttling effect involving only straight-line movement of the effective parts with a closed cylinder and a piston separating two or more working spaces therein with a single cylinder
• A43B 13/14 - SolesSole-and-heel integral units characterised by the constructive form

Goods & Services

Safety, security, protective and signalling equipment as well as safety equipment, security equipment, protective equipment and signalling equipment; head protection; protective helmets for sports; riding helmets. Orthopedic articles; orthopedic and mobility aids; medical and veterinary apparatus and instruments; surgical and wound treating equipment; bandages for orthopaedic purposes; bandages, elastic; walking frames for disabled persons; compression garments; artificial limbs; slings for supporting injured limbs; physical exercise apparatus for medical purposes; orthopaedic bandages for joints; arch supports for footwear; orthopaedic belts; knee bandages, orthopaedic; orthopaedic footwear; orthopaedic soles; slings [support bandages]; supports for flat feet; boots for medical purposes; compression bandages; limb compression instruments; orthopaedic compression supports; corsets for medical purposes; stockings for varices; abdominal belts; robotic exoskeleton suits for medical purposes; wheeled walkers to aid mobility; maternity belts; medical support stockings being compression stockings; hypogastric belts; orthopedic fixation devices; orthopedic support bandages; exercise boots [orthopaedic footwear]; tubular elastic bandages for supporting joints; invalid walkers. Leather; imitation leather; animal skins; fur; travelling trunks; travelling bags; umbrellas; parasols; walking sticks; whips; harnesses; saddlery; handbags; briefcases; bags for campers; bags for climbers; leather ribbons; beach bags; attaché cases; card cases; leather cases; cases from leather cardboard; purses with chain mesh, not of precious metal; poles for umbrellas; poles for parasols; garment bags for travel; handbag frames; hat boxes of leather; key cases; net bags for shopping; pocket wallets; bags, of leather, for packaging; sachets, of leather, for packaging; bags [envelopes, sachets] of leather, for packaging; purses; wallets, not of precious metal; rucksacks; school bags; school satchels; reusable shopping bags; tote bags for toddlers; cases; tool bags of leather, empty; travel sets [leather goods]; cases [travel luggage]; umbrella covers; umbrella handles; umbrella ribs; parasol ribs; umbrella rings; umbrella sticks; make-up bags [not equipped]; shopping bags with wheels attached; none of the above goods including bridoons. Printed textiles; bed linen and table linen; covers for cushions; woollen blankets; felt piece goods, namely, felt cloth, felt pennants, press felt and woven felt; knitted fabric; interior decoration fabrics; pillow shams; place mats from textile material; fabric table runners; doilies of textile; woollen cloth; textiles for furnishing purposes; table covers; table runners of textile; felt cloth. Sportswear; shoes; teddies [underclothing]; insoles; football boots; non-slipping devices for footwear; gymnastic shoes; half-boots; gloves [clothing]; girdles; corsets; welts for footwear; cyclists' clothing; lace boots; shoes; footwear soles; footwear; ski gloves; ski boots; socks; athletics shoes; sports shoes; boots; ankle boots; boot uppers; espadrilles; stockings; knitwear [clothing]; snowboard shoes; basketball sneakers; gym boots; maternity bands; shoe inserts for non-orthopedic purposes; jackets; headgear; coats; caps being headwear; scarves; casual clothing shoes; headbands [clothing]; cardigans; knitwear; outerclothing; rubber shoes and rubber boots [footwear]; pelerines; ponchos; pullovers; tee-shirts; sweat shirts; traditional costumes; shalws [scarfs]; hosiery. Sporting goods and equipment; elbow guards [sports articles]; weight lifting belts [sports articles]; climbers' harness; knee guards [sports articles]; in-line skates; shin guards [sports articles]; ski bindings; ski bindings and parts therefor; skis; snowboards; bindings for snowboards; paddings (protective -) [parts of sports suits]; hand pads for sports use; body protectors for sports use; wrist guards for athletic use; shock absorbtion pads for protection against injury [sporting articles]; playing bags. Education; training; entertainment services; sporting and cultural activities; development of training methods; conducting gymnastics classes; practical training [demonstration]; arranging and conducting of seminars; organization and implementation of training workshops; training of trainers and personnel for strength training or orthopedic rehabilitation centers, as well as maintenance of devices and equipment for these purposes; operation of training and fitness centers; sporting activities; support for training of instructors and personnel for strength training centers and for maintenance of devices and equipment for these purposes; support for the operation of training and fitness centers, as well as devices and equipment for these purposes. Therapy; medical services; therapeutic rehabilitation services.

Goods & Services

Safety, security, protective and signalling equipment as well as safety equipment, security equipment, protective equipment and signalling equipment; head protection; protective helmets for sports; riding helmets. Orthopedic articles; orthopedic and mobility aids; medical and veterinary apparatus and instruments; surgical and wound treating equipment; bandages for orthopaedic purposes; bandages, elastic; walking frames for disabled persons; compression garments; artificial limbs; slings for supporting injured limbs; physical exercise apparatus for medical purposes; orthopaedic bandages for joints; arch supports for footwear; orthopaedic belts; knee bandages, orthopaedic; orthopaedic footwear; orthopaedic soles; slings [support bandages]; supports for flat feet; boots for medical purposes; compression bandages; limb compression instruments; orthopaedic compression supports; corsets for medical purposes; stockings for varices; abdominal belts; robotic exoskeleton suits for medical purposes; wheeled walkers to aid mobility; maternity belts; medical support stockings being compression stockings; hypogastric belts; orthopedic fixation devices; orthopedic support bandages; exercise boots [orthopaedic footwear]; tubular elastic bandages for supporting joints; invalid walkers. Leather; imitation leather; animal skins; fur; travelling trunks; travelling bags; umbrellas; parasols; walking sticks; whips; harnesses; saddlery; handbags; briefcases; bags for campers; bags for climbers; leather ribbons; beach bags; attaché cases; card cases; leather cases; cases from leather cardboard; purses with chain mesh, not of precious metal; poles for umbrellas; poles for parasols; garment bags for travel; handbag frames; hat boxes of leather; key cases; net bags for shopping; pocket wallets; bags, of leather, for packaging; sachets, of leather, for packaging; bags [envelopes, sachets] of leather, for packaging; purses; wallets, not of precious metal; rucksacks; school bags; school satchels; reusable shopping bags; tote bags for toddlers; cases; tool bags of leather, empty; travel sets [leather goods]; cases [travel luggage]; umbrella covers; umbrella handles; umbrella ribs; parasol ribs; umbrella rings; umbrella sticks; make-up bags [not equipped]; shopping bags with wheels attached; none of the above goods including bridoons. Printed textiles; bed linen and table linen; covers for cushions; woollen blankets; felt piece goods, namely, felt cloth, felt pennants, press felt and woven felt; knitted fabric; interior decoration fabrics; pillow shams; place mats from textile material; fabric table runners; doilies of textile; woollen cloth; textiles for furnishing purposes; table covers; table runners of textile; felt cloth. Sportswear; shoes; teddies [underclothing]; insoles; football boots; non-slipping devices for footwear; gymnastic shoes; half-boots; gloves [clothing]; girdles; corsets; welts for footwear; cyclists' clothing; lace boots; shoes; footwear soles; footwear; ski gloves; ski boots; socks; athletics shoes; sports shoes; boots; ankle boots; boot uppers; espadrilles; stockings; knitwear [clothing]; snowboard shoes; basketball sneakers; gym boots; maternity bands; shoe inserts for non-orthopedic purposes; jackets; headgear; coats; caps being headwear; scarves; casual clothing shoes; headbands [clothing]; cardigans; knitwear; outerclothing; rubber shoes and rubber boots [footwear]; pelerines; ponchos; pullovers; tee-shirts; sweat shirts; traditional costumes; shalws [scarfs]; hosiery. Sporting goods and equipment; elbow guards [sports articles]; weight lifting belts [sports articles]; climbers' harness; knee guards [sports articles]; in-line skates; shin guards [sports articles]; ski bindings; ski bindings and parts therefor; skis; snowboards; bindings for snowboards; paddings (protective -) [parts of sports suits]; hand pads for sports use; body protectors for sports use; wrist guards for athletic use; shock absorbtion pads for protection against injury [sporting articles]; playing bags. Education; training; entertainment services; sporting and cultural activities; development of training methods; conducting gymnastics classes; practical training [demonstration]; arranging and conducting of seminars; organization and implementation of training workshops; training of trainers and personnel for strength training or orthopedic rehabilitation centers, as well as maintenance of devices and equipment for these purposes; operation of training and fitness centers; sporting activities; support for training of instructors and personnel for strength training centers and for maintenance of devices and equipment for these purposes; support for the operation of training and fitness centers, as well as devices and equipment for these purposes. Therapy; medical services; therapeutic rehabilitation services.

Abstract

The present invention relates to a device (1) for adaptively stabilizing body-joint movement, preferably ankle-joint movement, comprising a first connection unit (2) for connecting to a body part on a first side of a body joint (140), a second connection unit (3) for connecting to a body part on a second side of the body joint (140), and a damping element (4) between the first connection unit (2) and the second connection unit (3) for damping relative movement between the first connection unit (2) and the second connection unit (3), the device (1) being designed to limit the relative movement of the first connection unit (2) and the second connection unit (3) away from each other starting from a specified distance (AV) between the first connection unit (2) and the second connection unit (3). The present invention also relates to an ankle-joint stabilization device (100) having a device (1) of this type (1).

IPC Classes  ?

• A43B 7/20 - Ankle-joint supports or holders
• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Abstract

The present invention relates to a lacing device (10) for fastening a shoe on a foot, comprising a shoe main body (20) for receiving the foot, at least one lacing element (11, 11') for holding the foot in the shoe main body (20), and at least one adapter (30, 30') for adjusting the degree of lacing of the lacing element (11, 11'), wherein the adapter (30, 30') is coupled to the lacing element (11, 11'), and wherein the adapter (30, 30') is configured to release or lock the lacing element (11, 11') according to the speed of movement of the lacing element relative to the shoe main body (20).

IPC Classes  ?

• A43C 1/06 - Shoe lacing fastenings tightened by draw-strings
• A43C 3/04 - Spring safety-hooks
• A43C 7/00 - Holding-devices for laces
• A43C 7/02 - FlapsPockets
• A43C 7/08 - Clamps drawn tight by laces
• A43C 11/00 - Other fastenings specially adapted for shoes
• A43C 11/02 - Button fastenings
• A43C 11/06 - Snap-button fastenings
• A43C 11/08 - Hook fasteningsRotary hooks
• A43C 11/14 - Clamp fasteningsClamp-buckle fasteningsFastenings with toggle levers
• A43C 11/16 - Fastenings secured by wire, bolts, or the like
• A43C 11/20 - Fastenings with tightening devices mounted on the tongue
• A43C 11/22 - Fastening devices with elastic tightening parts between pairs of eyelets, e.g. clamps, springs, bands
• A43C 7/06 - Elastic bands

Abstract

Disclosed is an apparatus for stabilizing body joints and/or for supporting items of sports equipment, comprising: a receptacle, wherein the receptacle is filled with a filling medium, a first body for interacting with the filling medium, wherein the first body is displaceably arranged in the receptacle, a force transmission body for transmitting an external force to the first body, a second body for interacting with the filling medium, which is displaceably arranged in the receptacle, wherein the second body is elastically coupled to the first body via a coupling element, wherein the second body and/or the first body has at least one passage opening, through which the filling medium can flow, and wherein the first body forms a valve body and the second body forms a valve seat, such that a flow of the filling medium through the passage opening can be permitted or inhibited as a function of the valve position, wherein, in a displacement direction relative to the first body, the second body overlaps therewith.

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• F16F 9/19 - Devices with one or more members, e.g. pistons, vanes, moving to and fro in chambers and using throttling effect involving only straight-line movement of the effective parts with a closed cylinder and a piston separating two or more working spaces therein with a single cylinder
• F16F 9/32 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details
• F16F 9/512 - Means responsive to load action on the damper or fluid pressure in the damper
• F16F 9/516 - Special means providing automatic damping adjustment resulting in the damping effects during contraction being different from the damping effects during extension

Abstract

A foot movement limiting device for limiting a foot movement via the ankle joint, and to a correspondingly configured shoe for limiting a foot movement via the ankle joint. The foot movement limiting device includes a support arrangement for supporting on a lower leg or from proximally on the ankle bone, a retaining arrangement for retention on a foot and at least one attachment element for limiting a relative movement between the support arrangement and the retaining arrangement.

IPC Classes  ?

• A61F 5/00 - Orthopaedic methods or devices for non-surgical treatment of bones or jointsNursing devices
• A43B 7/14 - Footwear with health or hygienic arrangements with foot-supporting parts
• A43B 7/20 - Ankle-joint supports or holders
• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Abstract

A foot movement damper for damping a foot movement via the ankle joint, and to a correspondingly configured shoe for damping a foot movement via the ankle joint. The foot movement damper includes a support arrangement for supporting on a lower leg or from proximally on the ankle bone, a retaining arrangement for retention on a foot, and a damping element for damping a relative movement between the support arrangement and the retaining arrangement.

IPC Classes  ?

• A61F 5/00 - Orthopaedic methods or devices for non-surgical treatment of bones or jointsNursing devices
• A43B 7/14 - Footwear with health or hygienic arrangements with foot-supporting parts
• A43B 7/20 - Ankle-joint supports or holders
• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Abstract

The present invention relates to a device (10) for stabilising movements of two parts of a human body region and/or of a sports appliance which are movable relative to each other, the device (10) comprising the following: a receptacle (12), which is fixable on a first part of a human body region and/or of a sports appliance, the receptacle (12) being filled with a filling medium, and the receptacle (12) comprising a receptacle opening (13); and an interaction element (14), which is fixable on a second part of the same human body region and/or of the same sports appliance, is at least partially accommodated displaceably in the receptacle (12), and extends through the receptacle opening (13), the part of the interaction element (14) which is in the receptacle (12) being in contact with the filling medium. The device further comprises a force transmission element (15), wherein the force transmission element (15) is held pivotably on the end of the interaction element (14) which protrudes out of the receptacle (12), wherein at least one protrusion (16) extends from the receptacle (12) in the region of the receptacle opening (13) in a withdrawal direction (A) of the interaction element (14) in which the interaction element (14) can be displaced in the receptacle, and wherein the protrusion (16) comprises at least one first contact region (17) for making contact with the force transmission element (15).

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• F16F 9/32 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details

Abstract

The present invention relates to an apparatus (1) for stabilising movements of two parts of a body region and/or of a sports device which are movable relative to one another, comprising a receptacle (20) which can be fixed to a first part of a body region and/or of a sports device, said receptacle (20) being filled with a filling medium (30), and at least one active body arrangement with an active body (35) which is received movably in the receptacle (20) and can interact with the filling medium (30), a force transmission body (50) which can be fixed to a second part of the same body region and/or the same sports device for transmitting an external force to the active body (35), the active body (35) comprising at least one through-opening (64) through which the filling medium (30) can flow. The active body arrangement has a sealing lip (33) for sealing a gap (31) between an inner side of the receptacle (20) and a lateral region of an outer side of the active body arrangement, the sealing lip (33) being arranged on an outer side of the active body (35).

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• F16F 9/36 - Special sealings, including sealings or guides for piston-rods
• F16F 9/504 - Inertia-sensitive means

Abstract

A foot movement damper for damping a foot movement via the ankle joint, comprising a support arrangement for bearing on a lower leg and a holder arrangement for holding a foot, wherein a damping arrangement with at least one damping element is provided for damping a relative movement between the support arrangement and the holder arrangement, wherein the damping arrangement has a support binding for binding to the support arrangement and a holder binding for binding to the holder arrangement; and wherein the support arrangement has at least one bearing region and at least one bearing fixture, wherein the support arrangement can bear with the at least one bearing region over the malleolus of the ankle joint, and wherein the at least one bearing fixture is designed to fix the position of the at least one bearing region in a state when applied to the lower leg.

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• A43B 7/20 - Ankle-joint supports or holders
• A61F 5/058 - Splints

Abstract

The present invention relates to a device (1) for braking a rotational movement of a rotation element (10), preferably a wheel (2), particularly preferably a wheel on a rolling device (100), preferably a walking frame, walking aid, pushchair, wheelchair, walker, balance bike or toy, comprising a carrying element (3) for bracing against an axle (20) of a rotation element (10) or against a carrying frame (110) carrying the rotation element (10), a support element (4) that can be rotated about an axis of rotation (22) relative to the carrying element (3) for force-transmitting connection to the rotation element (10), and a damping element (5) extending between the carrying element (3) and the support element (4), wherein the damping element (5) is designed to provide a damping force directed counter to a change in length of the damping element (5), the magnitude of which force is dependent upon the speed of the change in length, wherein a first end (51) of the damping element (5) is supported on the carrying element (3) and a second end (52) of the damping element (5) which is longitudinally displaceable relative to the first end (51) is supported on the support element (4) such that a rotation of the support element (4) about the axis of rotation (22), at least in a predetermined angle segment (54) in the circumferential direction (23) relative to the axis of rotation (22), changes the length of the damping element (5), and a damping force generated in the damping element (5) brakes the rotation of the support element (4). The invention further relates to a rolling device (100).

IPC Classes  ?

• A61G 5/10 - Parts, details or accessories
• B62B 5/04 - Braking mechanismsLocking devices against movement
• B62B 9/08 - Braking mechanismsLocking devices against movement
• A61H 3/04 - Wheeled walking aids for patients or disabled persons

Goods & Services

Security, safety, protective and signalling apparatus, and protective equipment, safety equipment, protective gear and signalling equipment; head protection; helmets (protective -), helmets (protective -) for sports, helmets (riding -). Orthopedic articles; orthopedic and mobility aids; medical and veterinary apparatus and instruments; surgical and wound treating equipment; bandages for orthopaedic purposes; bandages, elastic; walking frames for disabled persons; compression garments; artificial limbs; slings for supporting injured limbs; physical exercise apparatus for medical purposes; bandages for joints, anatomical; arch supports for footwear; belts for orthopaedic purposes; knee bandages, orthopaedic; orthotic footwear; orthopedic soles; artificial limbs; slings [supporting bandages]; supports for flat feet; boots for medical purposes; compression bandages; limb compression instruments; orthopaedic compression supports; corsets for medical purposes; stockings for varices; abdominal belts; robotic exoskeleton suits for medical purposes; wheeled walkers to aid mobility; maternity belts; medical support stockings being compression stockings; maternity belts; hypogastric belts; orthopedic fixation devices; orthopedic support bandages; exercise boots [orthopaedic footwear]; tubular elastic bandages for supporting joints; invalid walkers. Vehicles and conveyances; vehicles for use on land and land transport; parts and fittings for vehicles; wheels and tyres, and continuous tracks for vehicles; mobility conveyances; trailers [vehicles]; trailers for transporting bicycles; cars; brake segments for vehicles; brake pads for automobiles; brake facings for vehicles; vehicle brake discs; electric bicycles; mobility scooters; bicycle trailers (riyakah); brakes for bicycles, cycles; brakes for vehicles; vehicles for locomotion by land, air, water or rail; wheeled vehicles; vans [vehicles]; casters for trolleys [vehicles] [carts (Am.)]; tires (non-skid devices for vehicle -); pet strollers; prams; wheelchairs for transporting invalids; autonomous motor vehicles; safety belts for vehicle seats; safety seats for children, for vehicles; security harness for vehicle seats; pushchairs; suspension shock absorbers for vehicles; shock absorbers for automobiles; shock absorbing springs for vehicles; push scooters [vehicles]. Sportswear; shoes; teddies [underclothing]; insoles; football boots; non-slipping devices for footwear; gymnastic shoes; half-boots; gloves [clothing]; girdles; corsets; welts for footwear; cyclists' clothing; lace boots; shoes; footwear soles; footwear; ski gloves; ski boots; socks; athletics shoes; sports shoes; boots; ankle boots; boot uppers; espadrilles; stockings; knitwear [clothing]; snowboard shoes; basketball sneakers; gym boots; maternity bands; shoe inserts for non-orthopedic purposes. Sporting goods and equipment; elbow guards [sports articles]; weight lifting belts [sports articles]; climbers' harness; knee guards [sports articles]; in line skates; shin guards [sports articles]; ski bindings; ski bindings and parts therefor; skis; snowboards; bindings for snowboards; paddings (protective -) [parts of sports suits]; hand pads for sports use; body protectors for sports use; wrist guards for athletic use; shock absorbtion pads for protection against injury [sporting articles].

Abstract

The present invention relates to an apparatus (1) for stabilising movements of two elements of a body joint and/or of a piece of sports equipment that are movable relative to one another, said apparatus comprising: a receptacle (20) fixable to a first element, the receptacle (20) being filled with a filling medium (30) and the receptacle (20) comprising a receiving opening; and an interaction element (40), which is fixable to a second element and is displaceably received at least in part in the receptacle (20) and extends through the receiving opening, the part of the interaction element (40) that is situated in the receptacle (20) being able to interact with the filling medium (30), and the receptacle comprising a first attachment element (50) for transmitting force between the receptacle (20) and the first body, and the interaction body (40) comprising a second attachment element (60) for transmitting force between the interaction body (40) and the second body, the first attachment element (50) comprising at least one protrusion, which extends from a longitudinal axis (L) of the apparatus, in order to provide an attachment surface for fixing to the first body.

IPC Classes  ?

• F16F 9/54 - Arrangements for attachment

Abstract

The invention relates to an apparatus (1) for stabilizing body joints and/or for supporting items of sports equipment, comprising: a receptacle (20), wherein the receptacle (20) is filled with a filling medium (30), a first body (40) for interacting with the filling medium (30), wherein the first body is displaceably arranged in the receptacle, a force transmission body (50) for transmitting an external force to the first body (40), a second body (60) for interacting with the filling medium (30), which is displaceably arranged in the receptacle (20), wherein the second body is elastically coupled to the first body (40) via a coupling element (70), wherein the second body (60) and/or the first body (40) has at least one passage opening (64), through which the filling medium (30) can flow, and wherein the first body (40) forms a valve body and the second body (60) forms a valve seat, such that a flow of the filling medium (30) through the passage opening (64) can be permitted or inhibited as a function of the valve position, wherein, in a displacement direction relative to the first body, the second body overlaps therewith.

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• A61F 2/50 - Prostheses not implantable in the body
• F16F 9/19 - Devices with one or more members, e.g. pistons, vanes, moving to and fro in chambers and using throttling effect involving only straight-line movement of the effective parts with a closed cylinder and a piston separating two or more working spaces therein with a single cylinder
• F16F 9/512 - Means responsive to load action on the damper or fluid pressure in the damper
• F16F 9/516 - Special means providing automatic damping adjustment resulting in the damping effects during contraction being different from the damping effects during extension
• F16F 9/30 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium with solid or semi-solid material, e.g. pasty masses, as damping medium
• F16F 9/32 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details

Goods & Services

(1) Safety boots; protective boots for protection against accidents or injury; safety clothing for protection against accident or injury; safety footwear for protection against accident or injury; safety glasses; safety harnesses, other than for vehicles or sports purposes; safety helmets; safety life jackets; safety restraints being fall protection equipment for fall restraint and fall arrest, other than sports equipment; helmet safety lights; reflective safety vests; protective safety helmets for use on the job site; head protection for sports; headwear for protection against accidents, irradiation and fire; riding helmets for protection against accident, irradiation or injury; protective sports helmets (2) Orthopedic articles, namely orthopedic braces; orthopedic and mobility aids, namely wheeled walkers to aid mobility; wheeled trolleys adapted for use as walking aid apparatus; bandages for orthopaedic purposes, namely orthopaedic knee bandages, orthopaedic bandages for joints, orthopaedic support bandages, plaster bandages for orthopaedic purposes, supportive bandages; bandages, elastic; walking frames for disabled persons; compression garments; artificial limbs; slings for supporting injured limbs; bandages for joints, anatomical; arch supports for footwear; belts for orthopaedic purposes; knee bandages, orthopaedic; orthotic footwear, namely brace, shoe and boots; orthopedic soles; artificial limbs; slings in the form of supporting bandages; supports for flat feet; medical boots for foot fractures and broken ankles; boots for ankle injury prevention; compression bandages; body limb compression sleeves for athletic use; compression bandages; compression socks for medical or therapeutic use; limb compression instruments, namely compression wraps; orthopaedic compression supports, namely compression bandages, compression gloves, compression cuffs, compression sleeves for arms, elbows, knees, wrists and legs; corsets for medical purposes; stockings for varices; abdominal belts; robotic exoskeleton suits for medical purposes; wheeled walkers to aid mobility; maternity belts; medical support stockings being compression stockings; maternity belts; hypogastric belts; orthopedic fixation devices, namely orthopedic braces; orthopedic support bandages; exercise footwear for medical rehabilitation purposes; tubular elastic bandages for supporting joints; invalid walkers. (3) Trailers for transporting bicycles; cars; brake segments for vehicles; brake pads for automobiles; brake facings for vehicles; vehicle brake discs; electric bicycles; mobility scooters; bicycle trailers (riyakah); brakes for bicycles, cycles; brakes for vehicles; vans [vehicles]; casters for trolleys [vehicles] [carts (Am.)]; tires (non-skid devices for vehicle -); pet strollers; prams; wheelchairs for transporting invalids; safety belts for vehicle seats; safety seats for children, for vehicles; security harness for vehicle seats; pushchairs; suspension shock absorbers for vehicles; shock absorbers for automobiles; shock absorbing springs for vehicles; push scooters [vehicles]. (4) Sportswear; shoes; teddies [underclothing]; insoles; football boots; gymnastic shoes; half-boots; gloves [clothing]; girdles; corsets; welts for footwear; cyclists' clothing; lace boots; shoes; footwear soles; footwear, namely athletic footwear, casual footwear, children's footwear, exercise footwear, footwear for track and field athletics, medical personnel footwear, outdoor winter footwear, shoes, sneakers and insoles for footwear, sports footwear; ski gloves; ski boots; socks; athletics shoes; sports shoes; boots; ankle boots; boot uppers; espadrilles; stockings; knitwear, namely socks and shoes; snowboard shoes; basketball sneakers; gym boots; maternity bands; shoe inserts for non-orthopedic purposes. (5) Sporting goods and equipment, namely baseball gloves; elbow guards [sports articles]; weight lifting belts [sports articles]; climbers' harness; knee guards [sports articles]; in line skates; shin guards [sports articles]; ski bindings; ski bindings and parts therefor; snowboards; bindings for snowboards; protective paddings parts of sports suits, namely knee pads; hand pads for sports use; body protectors for sports use; wrist guards for athletic use; shock absorption pads for protection against injury, namely sporting pads for boxing

Abstract

The present invention relates to a foot movement damping device (1) for damping foot movement via the ankle joint, said device comprising a support arrangement (2) for support on a lower leg or proximally on the ankle joint (110), a retaining arrangement (3) for retention to a foot (100), preferably a foot sole region, and a damping element (4) for damping relative movement between the support arrangement (2) and the retaining arrangement (3), wherein: the retaining arrangement (3) comprises an articulated holder (5); the damping element (4) is retained at one end on the articulated holder (5) and the damping element (4) is connected to the support arrangement (2) via at least one connecting element (6); and the articulated holder (5) is designed such that the damping element (4) is connected to the retaining arrangement (3) so as to be displaceable in a predefined range relative to same. The invention also relates to a shoe comprising such a foot movement damping device.

IPC Classes  ?

• A43B 7/20 - Ankle-joint supports or holders
• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Abstract

The invention relates to a foot movement limiting device (1) for limiting foot movement via the ankle joint, said device comprising a support arrangement (2) for support on a lower leg or proximally on the ankle joint (110), a retaining arrangement (3) for retention to a foot (100), preferably a foot sole region, and at least one connecting element (6) for limiting relative movement between the support arrangement (2) and the retaining arrangement (3), wherein: the at least one connecting element (6) is connected to the support arrangement (2) at two different connection points (7, 7') and the at least one connecting element (6) is held on the retaining arrangement (3) at a point between the two connecting points (7, 7') by means of an articulated holder (5); the articulated holder (5) is designed such that the connecting element (6) is connected to the retaining arrangement (3) so as to be displaceable in a predefined range relative to same; the support arrangement (2) comprises a tensionally rigid region (13) extending from a lateral side from the first connection point (7) posteriorly around at least one medial side to the second connection point (7'), or the support arrangement (2) comprises a tensionally rigid region (13) extending from a lateral side from the first connection point (7) anteriorly around at least one medial side to the second connection point (7'); the tensionally rigid region (13) is connected at its ends by a tensionally elastic region (14); and the tensionally elastic region (14) extends between the first connection point (7) and the second connection point (7') opposite the tensionally rigid region (13). The invention also relates to a shoe comprising such a foot movement limiting device.

IPC Classes  ?

• A43B 7/20 - Ankle-joint supports or holders
• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Abstract

The present invention relates to a device (1) for damping a body movement via a joint, comprising: a first part (2) for attachment to a first body part; a second part (3) which can pivot relative to the first part (2) and is intended for attachment to a second body part which is situated on the other side of the joint from the first body part; a damping element (4) which is fastened to the second part (3); and a connection element that has tensile rigidity, the connection element extending from the first part (2) to the second part (3), and the tensilely rigid connection element being attached to the first part (2) and fastened to the second part (3) via the damping element (4). At least one spacing element (6) is situated between the first part (2) and the second part (3), the spacing element (6) being designed such that, when the first part (2) pivots relative to the second part (3), the spacing element (6) holds the connection element spaced from a centre of revolution (7) of the pivot movement.

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Goods & Services

Safety, security, protection and signalling devices and equipment, namely, video cameras, security cameras, protective clothing for protection against accident or injury, body armour for protection against accident or injury, protective shoes for protection against accident or injury, elbow protectors for protection against accident or injury, spine protectors for protection against accident or injury, knee protectors for protection against accident or injury, shin protectors for protection against accident or injury; head protection, namely, protective helmets; protective helmets; protective helmets for sports, riding helmets Orthopaedic articles, namely, orthopaedic implants; orthopaedic and mobility aids, namely, wheeled walkers to aid mobility; medical and veterinary apparatus and instruments for use in general surgery; surgical and wound treating equipment, namely, medical device for closing wounds; plaster bandages for orthopaedic purposes; bandages, elastic; walking frames for disabled persons; compression garments; artificial limbs; slings for supporting injured limbs; physical exercise apparatus for medical purposes; bandages for joints, anatomical; arch supports for footwear; orthopaedic belts; knee bandages, orthopaedic; orthopaedic footwear; orthopaedic soles; joint protheses; slings in the form of supporting bandages; supports for flat feet; boots for medical purposes; compression bandages; limb compression instruments, namely, therapeutic compression wraps; orthopaedic compression supports; corsets for medical purposes; stockings for varices; abdominal belts; robotic exoskeleton suits for medical purposes; wheeled walkers to aid mobility; maternity belts, namely, maternity support belts for medical purposes; elastic stockings for medical purposes; hypogastric belts for medical purposes; orthopedic fixation devices used in arthroscopy; orthopedic support bandages; exercise boots for medical rehabilitative purposes; tubular elastic bandages for supporting joints; medical devices, namely, invalid walkers Vehicles and conveyances, namely, automobiles, vans, trucks; land vehicles and conveyances, namely, automobiles, vans, trucks; structural parts and fittings for vehicles; wheels and tyres, and continuous tracks for vehicles, being structural parts for land vehicles; mobility conveyances, namely, automated people movers; vehicles, namely, trailers; trailers for transporting bicycles; cars; brake segments for vehicles; brake pads for automobiles; brake linings for vehicles; brake discs for vehicles; electric bicycles; mobility scooters; bicycle trailers; bicycle brakes; brakes for vehicles; vehicles for locomotion by land, air, water or rail, namely, land vehicles, light rail vehicles, trains; vehicle wheels; vehicles, namely, vans; casters for trolleys, namely, wheels; nonskid devices for vehicle tyres, namely, non-skid chains; pet strollers; prams; wheelchairs; self-driving cars; safety belts for vehicle seats; safety seats for children, for vehicles; security harness for vehicle seats; pushchairs; vehicle shock absorbers for automobiles; shock absorbers for automobiles; shock absorbing springs for vehicles; push scooters Sportswear, namely, ankle boots, pants, shorts, shoes, shirt; shoes; teddies being underclothing; inner soles; football shoes; nonslipping devices for footwear, namely, non-slip soles for footwear; gymnastic shoes; half-boots; gloves as clothing; girdles; corsets; underclothing; welts for footwear; cyclists' clothing, namely, pants, shorts, shoes, shirt; lace boots; soles for footwear; footwear; ski gloves; ski boots; socks; boots for sports; sports shoes; boots; ankle boots; boot uppers; esparto shoes or sandals; stockings; knitwear, namely, pants, shorts, shoes, shirt, dresses, sweaters; snowboard shoes; basketball sneakers; gym boots; clothing, namely, maternity bands; shoe inserts for non-orthopaedic purposes Sporting articles and equipment, namely, baseball gloves; sports articles, namely, elbow guards, weight lifting belts, knee guards and shin guards; climbers' harness; in-line skates; ski bindings; ski bindings and parts therefor; skis; snowboards; bindings for snowboards; protective paddings parts of sports suits, namely, knee pads; hand pads for sports use; body protectors for sports use; wrist guards for athletic use; shock absorption pads for protection against injury, namely, sporting pads for boxing

Goods & Services

Security, safety, protective and signalling apparatus, and protective equipment, Safety equipment, protective gear and Signalling equipment; Head protection; helmets (protective —), helmets (protective —) for sports, helmets (riding —). Orthopedic articles; Orthopedic and mobility aids; Medical and veterinary apparatus and instruments; Surgical and wound treating equipment; Bandages for orthopaedic purposes; Bandages, elastic; Walking frames for disabled persons; Compression garments; Artificial limbs; Slings for supporting injured limbs; Physical exercise apparatus for medical purposes; Bandages for joints, anatomical; Arch supports for footwear; Belts for orthopaedic purposes; Knee bandages, orthopaedic; Orthotic footwear; Orthopedic soles; Artificial limbs; Slings [supporting bandages]; Supports for flat feet; Boots for medical purposes; Compression bandages; Limb compression instruments; Orthopaedic compression supports; Corsets for medical purposes; Stockings for varices; Abdominal belts; Robotic exoskeleton suits for medical purposes; Wheeled walkers to aid mobility; Maternity belts; support stockings; Maternity belts; Hypogastric belts; Orthopedic fixation devices; Orthopedic support bandages; Exercise boots [orthopaedic footwear]; Tubular elastic bandages for supporting joints; Invalid walkers. Vehicles and conveyances; Vehicles for use on land and Land transport; Parts and fittings for vehicles; Wheels and tyres, and continuous tracks for vehicles; Mobility conveyances; Trailers [vehicles]; Trailers for transporting bicycles; Cars; Brake segments for vehicles; Brake pads for automobiles; Brake facings for vehicles; Vehicle brake discs; Electric bicycles; Mobility scooters; Bicycle trailers (riyakah); Brakes for bicycles, cycles; Brakes for vehicles; Vehicles for locomotion by land, air, water or rail; Wheeled vehicles; Vans [vehicles]; Casters for trolleys [vehicles] [carts (Am.)]; Tires (Non-skid devices for vehicle -); Pet strollers; Prams; Wheelchairs for transporting invalids; autonomous motor vehicles; Safety belts for vehicle seats; Safety seats for children, for vehicles; Security harness for vehicle seats; Pushchairs; Suspension shock absorbers for vehicles; Shock absorbers for automobiles; Shock absorbing springs for vehicles; Push scooters [vehicles]. Sportswear; Shoes; Teddies [underclothing]; Insoles; Football boots; Non-slipping devices for footwear; Gymnastic shoes; Half-boots; Gloves [clothing]; Girdles; Corsets; Welts for footwear; Cyclists' clothing; Lace boots; Shoes; Footwear soles; Footwear; Ski gloves; Ski boots; Socks; Athletics shoes; Sports shoes; Boots; Ankle boots; Boot uppers; Espadrilles; Stockings; Knitwear [clothing]; Snowboard shoes; Basketball sneakers; Gym boots; Maternity bands; Shoe inserts for non-orthopedic purposes. Sporting goods and equipment; Elbow guards [sports articles]; Weight lifting belts [sports articles]; Climbers' harness; Knee guards [sports articles]; In line skates; Shin guards [sports articles]; Ski bindings; Ski bindings and parts therefor; Skis; Snowboards; Bindings for snowboards; Paddings (Protective -) [parts of sports suits]; Hand pads for sports use; Body protectors for sports use; Wrist guards for athletic use; Shock absorbtion pads for protection against injury [sporting articles].

Abstract

The present invention relates to a shoe (1) for damping a foot movement via the ankle joint, comprising a shoe sole (10), a shoe upper (11) connected to the shoe sole (10), and a damping element (2) for damping a relative movement. A rigid strip (3) extends from a first end (31) of a lateral face (12) of the shoe (1) via a shoe heel region (14) and via a medial face (13) of the shoe (1) again to the lateral face (12) at a second end (32) and is arranged movably between the first and the second end (31, 32) on the upper (11) in the longitudinal direction thereof, the rigid strip (3) being fastened by the first end (31) to the damping element (2) and being fastened by the second end (32) to the upper (11).

IPC Classes  ?

• A43B 7/20 - Ankle-joint supports or holders
• A61F 13/06 - Bandages or dressingsAbsorbent pads specially adapted for feet or legsCorn-padsCorn-rings

Goods & Services

Bandages, elastic; walking frames for disabled persons; compression garments; artificial limbs; physical exercise apparatus for medical purposes; orthopedic articles; orthopedic joint bandages; orthopedic insoles for shoes; orthopedic belts; orthopedic knee bandages; orthopedic footwear; orthopedic soles, prostheses; slings [supporting bandages]; supports for flat feet; boots for medical purposes. Motorists' clothing; sportswear; inner soles; mittens; football shoes; non-slipping devices for footwear; clothing for gymnastics; gymnastic shoes; buskins; gloves [clothing]; slippers; cyclists' clothing; sandals; lace-up boots; shoes [loafers]; shoe soles; sweat-absorbent socks, sweat-absorbent stockings; ski gloves; ski boots; socks; sport shoes; sports shoes [loafers]; boots; ankle boots; boot uppers; espadrilles; cleats for football boots; stockings. Baseball gloves; body-building apparatus; boxing gloves; elbow guards [sports articles]; fencing gauntlets; machines for physical exercises; golf gloves; gloves for games; climbers' harness; knee guards [sports articles]; skating boots with skates attached; roller skates; roller skates; in-line skates; shin guards [sports articles]; batting gloves [accessories for games]; ice skates; snowshoes; protective paddings [parts of sports suits]; ski bindings; skis; snowboards; sporting articles and equipment.

Abstract

The present invention relates to a foot movement damper (1) for damping a foot movement via the ankle joint, comprising a support arrangement (2) for bearing on a lower leg (112) and a holder arrangement (3) for holding a foot (110), wherein a damping arrangement (4) with at least one damping element (40) is provided for damping a relative movement between the support arrangement (2) and the holder arrangement (3), wherein the damping arrangement (4) has a support binding (42) for binding to the support arrangement (2) and a holder binding (41) for binding to the holder arrangement (3); and wherein the support arrangement (2) has at least one bearing region (20, 21) and at least one bearing fixture (22), wherein the support arrangement (2) can bear with the at least one bearing region (20, 21) over the malleolus (114) of the ankle joint, and wherein the at least one bearing fixture (22) is designed to fix the position of the at least one bearing region (20, 21) in a state when applied to the lower leg (112). The present invention moreover relates to a shoe (80) for damping a foot movement via the ankle joint, comprising a sole (82), an upper, and the aforementioned foot movement damper (1).

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Goods & Services

Orthopedic articles. Sportswear. Sporting articles and equipment.

Goods & Services

Orthopedic articles, namely, arch supports for footwear; artificial limbs; anatomical bandages for joints; elastic bandages; boots for medical purposes; compression garments; orthopedic knee bandages; orthopedic belts; orthopedic footwear; orthopedic soles; physical exercise apparatus for medical purpose; slings in the form of supporting bandages; walking frames for disabled persons; orthopedic support bandages; orthopedic joint supports; Orthopedic hip prostheses; orthopedic inner soles incorporating arch supports; medical compression stockings for varices; Wheeled walkers to aid mobility; Elastic stockings for medical purposes; orthopedic braces Sportswear, namely, ankle boots; boot uppers; boots; boots for sports; athletic tops and bottoms as clothing for gymnasts; cycling shoes; cycling shorts; cycling bib shorts; cycling caps; esparto shoes or sandals; football shoes; gloves as clothing; ski gloves; snowboard gloves; motorcycle gloves; gymnastic shoes; half-boots; inner soles; lace boots; mittens; non-slip soles for footwear; sandals; shoes; ski boots; slippers; socks; soles for footwear; sports shoes; stockings; studs for football boots; sweat-absorbent socks; sweat-absorbent stockings Sporting articles and equipment, namely, baseball gloves; body-building apparatus; boxing gloves; elbow pads for athletic use; fencing gauntlets; manually-operated exercise equipment; golf gloves; climbers' harness; knee guards for athletic use; skating boots with skates attached; roller skates; in-line roller skates; shin guards for athletic use; batting gloves; football gloves; in-line skate gloves; ice skates; snowshoes; athletic protective padding for snowboarding, skiing, skateboarding, in-line skating, roller skating, motorcross, motorcycle racing and football; ski bindings; skis; snowboards

Abstract

The present invention relates to a joint stabilizer (1) for adaptive damping of a movement of the body, comprising: - a receptacle (20), wherein the receptacle (20) is filled with a shear-thickening medium (30), a tensioner (40) movable relative to the receptacle (20), wherein the tensioner (40) can be connected to a region of the body of the user that is movable relative to another region of the body of the user on which the receptacle (20) can be secured, a work element (60) which is arranged displaceably in the receptacle (20) for interaction with the shear-thickening medium (30), and a connection element (50) for transmitting forces between the receptacle (20) and the tensioner (40), wherein the receptacle (20), the tensioner(40) and the work element (60) are connected to one another via the connection element (50), wherein the connection element (50) is guided via at least one deflection means (70) in order to divide up the force acting between the receptacle (20) and the tensioner (40).

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Abstract

The present invention relates to a device (1) for stabilising joints, comprising a receptacle (20), wherein the receptacle (20) is filled with a filling medium (30), a first body (40) for interaction with the filling medium (30), wherein the first body is arranged displaceably in the receptacle (20), a force-transmission means (50) for the transmission of an external force onto the first body (40), a second body (60) for interaction with the filling medium (30) which is arranged displaceably in the receptacle (20), wherein the second body is coupled elastically to the first body (40) via a coupling element (70), wherein at least one of the second body (60) and the first body (40) have at least one outlet opening (64) through which the filling medium (30) can flow, and wherein the first body (40) forms a valve body and the second body (60) forms a valve seat so that a flow of the filling medium (30) through the outlet opening (64) can be allowed or prevented as a function of the valve position.

IPC Classes  ?

• F16F 9/19 - Devices with one or more members, e.g. pistons, vanes, moving to and fro in chambers and using throttling effect involving only straight-line movement of the effective parts with a closed cylinder and a piston separating two or more working spaces therein with a single cylinder
• A61F 2/30 - Joints
• F16F 9/516 - Special means providing automatic damping adjustment resulting in the damping effects during contraction being different from the damping effects during extension
• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• F16F 9/512 - Means responsive to load action on the damper or fluid pressure in the damper
• F16F 9/34 - Special valve constructionsShape or construction of throttling passages
• F16F 9/53 - Means for adjusting damping characteristics by varying fluid viscosity, e.g. electromagnetically
• A61F 2/50 - Prostheses not implantable in the body
• F16F 9/30 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium with solid or semi-solid material, e.g. pasty masses, as damping medium
• F16F 9/32 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details

Abstract

A device includes a receptacle body, wherein the receptacle body is filled with a dilatant fluid and the receptacle body extends in an elongated shape from a first end towards a second end, and a tension body for initiating an external force into the device, wherein a compression body, wherein the compression body is arranged in the receptacle body in a relatively movable manner and is connected to the tension body, wherein the compression body divides an interior space of the receptacle body into a first chamber and a second chamber, wherein between the receptacle body and the compression body a passage is provided, wherein the passage connects the first chamber with the second chamber fluid-technically.

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• F16F 9/20 - Devices with one or more members, e.g. pistons, vanes, moving to and fro in chambers and using throttling effect involving only straight-line movement of the effective parts with a closed cylinder and a piston separating two or more working spaces therein with the piston-rod extending through both ends of the cylinder

Abstract

The present invention relates to a device (1) for limiting a movement of a joint arranged between a first body part and a second body part, comprising a receptacle (2) that is held on the first body part by means of a receptacle fastener (29), a shear body (3) that is held on the second body part by means of a shear-body fastener (9) and is movable relative to the receptacle (2), wherein the shear body (3) is introduced at least partially into the receptacle (2) via an introduction opening (20), and a dilatant fluid (4), provided in the receptacle (2), for influencing a relative movement between the shear body (3) and the receptacle (2), wherein the introduction opening (20) of the receptacle (2) is directed away from the shear-body fastener (9).

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Abstract

The invention relates to an orthopedic device (1) for limiting the movement of a joint arranged between a first and a second body region. The orthopedic device comprises at least a receptacle (2) that can be fastened to the first body region and a pull-out body (3) that can be fastened to the second body region and can be moved in relation to the receptacle (2), wherein a passage cross-section filled with a dilatant fluid is provided perpendicularly to a pull-out direction between the receptacle (2) and the pull-out body (3), wherein at least one passage-limiting element (6) is provided for changing the passage cross-section.

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Abstract

An orthopedic device (1) for limiting the movement of a joint arranged between a first and a second region of a body is provided. The device includes at least one receptacle (2) that can be fixed on the first region of the body, and an extension element (3) that can be fixed on the second region of the body and is movable relative to the receptacle (2), wherein a volume filled with a dilatant fluid (4) is provided between the receptacle (2) and the extension element (3).

IPC Classes  ?

• A61F 5/00 - Orthopaedic methods or devices for non-surgical treatment of bones or jointsNursing devices
• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Abstract

The present invention relates to a foot movement
damper (1) for damping a foot movement via the ankle joint,
comprising a support arrangement (2) for bearing on a lower leg (112)
and a holder arrangement (3) for holding a foot (110), wherein a
damping arrangement (4) with at least one damping element (40)
is provided for damping a relative movement between the support
arrangement (2) and the holder arrangement (3), wherein the
damping arrangement (4) has a support binding (42) for binding to the
support arrangement (2) and a holder binding (41) for binding to
the holder arrangement (3); and wherein the support arrangement
(2) has at least one bearing region (20, 21) and at least one bearing
fixture (22), wherein the support arrangement (2) can bear with the
at least one bearing region (20, 21) over the malleolus (114) of the
ankle joint, and wherein the at least one bearing fixture (22) is
designed to fix the position of the at least one bearing region (20, 21)
in a state when applied to the lower leg (112). The present
invention moreover relates to a shoe (80) for damping a foot movement
via the ankle joint, comprising a sole (82), an upper, and the
aforementioned foot movement damper (1).

IPC Classes  ?

• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces

Abstract

The invention relates to an apparatus (1) for stabilizing body joints and/or for supporting items of sports equipment, comprising: a receptacle (20), wherein the receptacle (20) is filled with a filling medium (30), a first body (40) for interacting with the filling medium (30), wherein the first body is displaceably arranged in the receptacle, a force transmission body (50) for transmitting an external force to the first body (40), a second body (60) for interacting with the filling medium (30), which is displaceably arranged in the receptacle (20), wherein the second body is elastically coupled to the first body (40) via a coupling element (70), wherein the second body (60) and/or the first body (40) has at least one passage opening (64), through which the filling medium (30) can flow, and wherein the first body (40) forms a valve body and the second body (60) forms a valve seat, such that a flow of the filling medium (30) through the passage opening (64) can be permitted or inhibited as a function of the valve position, wherein, in a displacement direction relative to the first body, the second body overlaps therewith.

IPC Classes  ?

• A61F 2/50 - Prostheses not implantable in the body
• A61F 5/01 - Orthopaedic devices, e.g. long-term immobilising or pressure directing devices for treating broken or deformed bones such as splints, casts or braces
• F16F 9/19 - Devices with one or more members, e.g. pistons, vanes, moving to and fro in chambers and using throttling effect involving only straight-line movement of the effective parts with a closed cylinder and a piston separating two or more working spaces therein with a single cylinder
• F16F 9/30 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium with solid or semi-solid material, e.g. pasty masses, as damping medium
• F16F 9/32 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details
• F16F 9/512 - Means responsive to load action on the damper or fluid pressure in the damper
• F16F 9/516 - Special means providing automatic damping adjustment resulting in the damping effects during contraction being different from the damping effects during extension
