Goods & Services

Advertising and marketing; Import-export of machines and machine tools; Business management; Business administration; Office functions; Business representation services; Marketing services for businesses and via e-commerce platforms on the internet relating to tools and machine tools for industrial automation processes.

Abstract

The invention relates to a device and method for cooling flat parts, comprising a first cooling element (2) having a first surface that is in contact with the flat part (16) and a second cooling element (3) having a second surface that is in contact with the flat part. According to the invention, the first (1) and second (2) cooling elements are positioned facing one another, defining a space therebetween for the insertion of the flat part. In addition, the first cooling element (2) comprises a cooling circuit and the second cooling element (3) comprises another cooling circuit, which are distributed uniformly along the first and second surfaces in contact with the flat part and through which a constant flow of cooling liquid flows. The flat part is cooled to the desired temperature, after which it is extracted and stored.

IPC Classes  ?

• B27N 3/00 - Manufacture of substantially flat articles, e.g. boards, from particles or fibres
• B27N 3/18 - Auxiliary operations, e.g. preheating, humidifying, cutting-off
• F25D 1/00 - Devices using naturally-cold air or water
• F25D 1/02 - Devices using naturally-cold air or water using naturally-cold water, e.g. household-tap water
• F25D 17/02 - Arrangements for circulating cooling fluidsArrangements for circulating gas, e.g. air, within refrigerated spaces for circulating liquids, e.g. brine
• B30B 15/06 - Platens or press rams

Abstract

The invention relates to a universal automated stacking device comprising an upstream stacking table (1) and a claw (2). According to the invention, the upstream stacking table (1) comprises at least one supporting assembly (13) and at least one side centring device (14), both connected to a chassis (12), and the claw (2) comprises at least one pair of clamps (3) connected to a frame (7). The at least one supporting assembly (13) is connected to at least one guide belonging to the chassis (12) such that it can move on the guides (20, 21), while the at least one pair of clamps (3) is secured to the frame (7) by means of an arm (4) connected to a cross-member (5) such that it can move on a rail (6) belonging to the frame (7). Moreover, each arm (4) is connected to a runner (8) of the cross-member (5) such that it can move along the runner (8).

IPC Classes  ?

• B65G 57/16 - Stacking of articles of particular shape
• B65G 61/00 - Use of pick-up or transfer devices or of manipulators for stacking or de-stacking articles not otherwise provided for
• B66C 1/42 - Gripping members engaging only the external or internal surface of the articles

Abstract

The object of the invention refers to a universal automated stacking device comprising a pre-stacking table (1) and a claw (2) such that the pre-stacking table (1) comprises at least one support assembly (13) and at least one side centering device (14) attached to a chassis (12), and the claw (2) comprising at least one pair of pliers (3) attached to a frame (7), the at least one support assembly (13) being attached to at least one chassis guide (12) with capacity of displacing over the guides (20, 21), and the at least one pair of pliers (3) being fixed to the frame (7) via an arm (4) which is attached to a crossbar (5) with capacity of displacing over a rail (6) of the frame (7), and each arm (4) being attached to a slide (8) of the crossbar (5) with capacity of displacing through the slide (8).

IPC Classes  ?

• B65G 47/90 - Devices for picking-up and depositing articles or materials
• B65G 57/00 - Stacking of articles
• B65G 61/00 - Use of pick-up or transfer devices or of manipulators for stacking or de-stacking articles not otherwise provided for
• B25J 15/00 - Gripping heads
• B25J 15/02 - Gripping heads servo-actuated
• B65G 57/11 - Stacking of articles by adding to the top of the stack the articles being stacked by direct action of the feeding conveyor
• B65G 15/12 - Conveyors having endless load-conveying surfaces, i.e. belts and like continuous members, to which tractive effort is transmitted by means other than endless driving elements of similar configuration comprising two or more co-operating endless surfaces with parallel longitudinal axes, or a multiplicity of parallel elements, e.g. ropes defining an endless surface with two or more endless belts

Goods & Services

Machines and machine tools; couplings and transmission components (other than for land vehicles). Assembly, installation, repair and maintenance services for machines and machine tools.

Goods & Services

Machines and machine tools for processing, packaging, palletising and storage of plastic, metal and wood raw materials; couplings and transmission components except for land vehicles Assembly, installation, repair and maintenance services for machines and machine tools

Goods & Services

Machines and machine tools for the automation of industrial processes. Assembly, installation, repair and maintenance of machines and machine tools for the automation of industrial processes.

Goods & Services

(1) Saw machines, woodworking machines, stacking machines and feeding machines for plane elements as wood or plastic stripes.

Goods & Services

Machines pour l'industrie du bois, machines pour charger et machines pour empiler des éléments en bois. Services de montage, de réparation et d'entretien de machines pour l'industrie du bois.
