A system for displaying a driving scene to a passenger in a vehicle includes first and second cameras for capturing images of the driving scene; a processor that receives the images from the first and second cameras, applies noise filtering to the received images to at least partially remove occlusions from the images of the driving scene received from the first and second cameras related to a weather condition; and a display that receives the filtered images from the processor after application of the filtering operation and displays the filtered images of the driving scene.
A wiper blade may include a central connection device having an upper passage and a lower passage. An upper beam may be provided in the upper passage and a lower beam may be provided in the lower passage. The lower beam may also support a wiper strip. In use, the upper beam may forcibly contact the lower beam. A cover may be provided, and the cover may have an airfoil cross-sectional profile. A wiper blade assembly is also disclosed utilizing an embodiment of a wiper blade with a connector for connecting the wiper blade with a wiper arm of a vehicle.
A windshield wiper connector is disclosed for connecting a variety of wiper arms with a wiper blade. The connector may include a pivotable cover. The connector may also include a pin passage for receiving a pin-type wiper arm as well as a gaps in the connector positioned around an elevated plateau for receiving a slot-type wiper arm.
A windshield wiper connector is disclosed for connecting a variety of wiper arms with a wiper blade. The connector may include a rotating cap as well as an adapter. The adapter may be inserted into a trapezoidal groove, and the adapter may have a pin passage for receiving a pin from a wiper arm. The groove may receive a trapezoidal roller from a wiper arm. The connector may include a channel, and a bayonet style wiper arm may be secured in the channel as well as by the cap and by a pillar projecting from the channel. Other similar wiper arms may be connected with a wiper blade using the disclosed inventive concepts. A wiper blade assembly having a wiper strip, a force distribution structure, and a connector is also disclosed.
12 - Land, air and water vehicles; parts of land vehicles
Goods & Services
(1) Windshield wiper blades for vehicles; windshield wiper blade connection system comprised of connectors to attach the wiper blade to the wiper arm sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade element made of rubber for repelling water sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade cover made of plastic sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade rubber element sold as an integral component of windshield wiper blades for vehicles; windshield wiper blade technology system comprised of primary, secondary and tertiary flexors sold as an integral component of windshield wiper blades for vehicles
12 - Land, air and water vehicles; parts of land vehicles
Goods & Services
(1) Windshield wiper blades for vehicles; windshield wiper blade connection system comprised of connectors to attach the wiper blade to the wiper arm sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade element made of rubber for repelling water sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade cover made of plastic sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade rubber element sold as an integral component of windshield wiper blades for vehicles; windshield wiper blade technology system comprised of primary, secondary and tertiary flexors sold as an integral component of windshield wiper blades for vehicles
12 - Land, air and water vehicles; parts of land vehicles
Goods & Services
(1) Windshield wiper blades for vehicles; windshield wiper blade connection system comprised of connectors to attach the wiper blade to the wiper arm sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade element made of rubber for repelling water sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade cover made of plastic sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade rubber element sold as an integral component of windshield wiper blades for vehicles; windshield wiper blade technology system comprised of primary, secondary and tertiary flexors sold as an integral component of windshield wiper blades for vehicles
12 - Land, air and water vehicles; parts of land vehicles
Goods & Services
(1) Windshield wiper blade connection system comprised of connectors to attach the wiper blade to the wiper arm sold as an integral component of windshield wiper blades for vehicles.
12 - Land, air and water vehicles; parts of land vehicles
Goods & Services
(1) Windshield wiper blades for vehicles; windshield wiper blade connection system comprised of connectors to attach the wiper blade to the wiper arm sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade element made of rubber for repelling water sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade cover made of plastic sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade rubber element sold as an integral component of windshield wiper blades for vehicles; windshield wiper blade technology system comprised of primary, secondary and tertiary flexors sold as an integral component of windshield wiper blades for vehicles
12 - Land, air and water vehicles; parts of land vehicles
Goods & Services
(1) Windshield wiper blade technology system comprised of primary, secondary and tertiary flexors sold as an integral component of windshield wiper blades for vehicles; windshield wiper blade system comprised of primary, secondary and tertiary flexors to control movement, contact and connection for the wiper blade sold as an integral component of windshield wiper blades for vehicles
12 - Land, air and water vehicles; parts of land vehicles
Goods & Services
(1) Windshield wiper blades for vehicles; windshield wiper blade connection system comprised of connectors to attach the wiper blade to the wiper arm sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade element made of rubber for repelling water sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade cover made of plastic sold as an integral component of windshield wiper blades for vehicles; Windshield wiper blade rubber element sold as an integral component of windshield wiper blades for vehicles; windshield wiper blade technology system comprised of primary, secondary and tertiary flexors sold as an integral component of windshield wiper blades for vehicles
A connector for a windshield wiper, and a wiper blade assembly including same, that accommodates slotted receiving portions of windshield wiper arms. The connector for connecting a windshield wiper assembly to a wiper arm may have a peripheral wall having at least two opposing peripheral side walls and a top surface extending from one of the two opposing peripheral side walls to the other. The opposing peripheral side walls may each have a guide pin aligned with one another and sized to be capable of slidably engaging slots of windshield wiper arm.
A connector for a windshield wiper, and a wiper blade assembly including same, that accommodates slotted receiving portions of windshield wiper arms. The connector for connecting a windshield wiper assembly to a wiper arm may have a peripheral wall having at least two opposing peripheral side walls and a top surface extending from one of the two opposing peripheral side walls to the other. The opposing peripheral side walls may each have a guide pin aligned with one another and sized to be capable of slidably engaging slots of windshield wiper arm.
A wiper blade connector including a body member having a first side wall, a second wall, and a top surface extending between the first and second side walls and a connector securing structure, which may include a rivet passage and an arcuate rivet clip, the arcuate rivet clip extending substantially perpendicular to the rivet passage, and a wiper blade incorporating same.
Embodiments of a windshield wiper assembly may include a support structure, a wiper blade connector assembly for connecting the support structure with a wiper arm of a vehicle, a wiper blade cover fittable over the wiper blade connector assembly, and a wiper blade strip secured to the underside of the support structure. The connector assembly may include a wiper blade connector, a wiper blade connector cover connected to the wiper blade connector and pivotable between an open position and a closed position, and a wiper blade connector adapter securable between the wiper blade connector and the wiper blade connector cover. The various embodiments of a wiper blade connector assembly permit the embodiments of the wiper blade assembly to be connected with a plurality of wiper arm types.
Embodiments of a windshield wiper assembly may include a support structure, a wiper blade connector assembly for connecting the support structure with a wiper arm of a vehicle, a wiper blade cover fittable over the wiper blade connector assembly, and a wiper blade strip secured to the underside of the support structure. The connector assembly may include a wiper blade connector, a wiper blade connector cover connected to the wiper blade connector and pivotable between an open position and a closed position, and a wiper blade connector adapter securable between the wiper blade connector and the wiper blade connector cover. The various embodiments of a wiper blade connector assembly permit the embodiments of the wiper blade assembly to be connected with a plurality of wiper arm types.
A windshield wiper assembly may include a wiper strip, and a force distribution structure securing the wiper strip comprising. The force distribution structure may include a primary frame structure, and a secondary frame structure. The primary frame structure may include a central base portion, a leg extending from the central base portion to its end, and a first boss connecting structure. The secondary frame structure may include a first complementary connecting structure such that the first boss connecting structure and the first complementary connecting structure pivotally engage one another.
Embodiments of a windshield wiper assembly may include a support structure, a wiper blade connector assembly for connecting the support structure with a wiper arm of a vehicle, a wiper blade cover fittable over the wiper blade connector assembly, and a wiper blade strip secured to the underside of the support structure. The connector assembly may include a wiper blade connector, a wiper blade connector cover connected to the wiper blade connector and pivotable between an open position and a closed position, and a wiper blade connector adapter securable between the wiper blade connector and the wiper blade connector cover. The various embodiments of a wiper blade connector assembly permit the embodiments of the wiper blade assembly to be connected with a plurality of wiper arm types.
Embodiments of a windshield wiper assembly may include a support structure, a wiper blade connector assembly for connecting the support structure with a wiper arm of a vehicle, a wiper blade cover fittable over the wiper blade connector assembly, and a wiper blade strip secured to the underside of the support structure. The connector assembly may include a wiper blade connector, a wiper blade connector cover connected to the wiper blade connector and pivotable between an open position and a closed position, and a wiper blade connector adapter securable between the wiper blade connector and the wiper blade connector cover. The various embodiments of a wiper blade connector assembly permit the embodiments of the wiper blade assembly to be connected with a plurality of wiper arm types.
40 - Treatment of materials; recycling, air and water treatment,
42 - Scientific, technological and industrial services, research and design
Goods & Services
manufacturing to the order and specification of others in the field of vehicle bake hardware and replacement parts Design, engineering, research, development and testing services in the field of vehicle bake hardware and replacement parts
09 - Scientific and electric apparatus and instruments
Goods & Services
(1) Battery jump start systems for vehicles comprised of portable batteries and battery jump starters; portable batteries used to jump start vehicles; protective covers for batteries and battery jump starters; jumper cables; all for the use in the automotive industry
A wiper blade is presented having a wiper strip, a force distribution structure having opposite ends, the wiper strip connected to the force distribution structure, and a cover, wherein the cover is made from a hydrophobic material, a material exhibiting hydrophobic properties, or a material having a water contact angle that is greater than 90 degrees.
A windshield wiper connector having a peripheral wall having at least two opposing peripheral side walls, a top surface extending from one of the two opposing peripheral side walls to the other; and a channel formed in the top surface, and extending longitudinally along the top of the connector. The connector including a groove near to the proximal end of the connector and sized to be capable of engaging a trapezoidal roller of a wiper arm. The opposing peripheral side walls having a retaining pin aperture aligned with one another and sized to be capable of accepting a retaining pin of at least one pin-type windshield wiper arm. The channel on the top of the connector sized to be capable of accepting a bayonet style wiper arm. A wiper blade assembly having a wiper strip, a force distribution structure, and a connector as described above.
A connector assembly and wiper blade incorporating same having a base connector, having two longitudinal side walls, a first and second end, and a top surface extending therebetween, wherein the top surface has a pair of cantilevered beams, each provided with a locking tab, extending from a central portion towards each respective end of the base connector. The locking tabs are capable of engaging and securing an aperture in cap or wiper arm. The base connector further has a central recessed portion capable of receiving and securing a top wall of a side adapter. The base connector may further include a base support structure capable of securing the base connector to a wiper blade.
A wiper blade having a wiper strip having a wide portion and a lip, and an elongate backing element. The backing element having a top portion, and two opposing legs that descend from the top portion, such that each opposing leg has a claw which extends towards the other opposing leg. A gap formed between the claws that is narrower than a width of the wide portion of the wiper strip. The claws, legs, and top portion define a wiper strip cavity sized to receive the wide portion wiper strip.
A connector for a windshield wiper, and a wiper blade assembly including same, that accommodates multiple pin-type windshield wiper arms having varying pin lengths and locking mechanisms. The connector for connecting a windshield wiper assembly to a wiper arm may have a peripheral wall having at least two opposing peripheral side walls and a top surface extending from one of the two opposing peripheral side walls to the other. The opposing peripheral side walls may each have one or more retaining pin apertures aligned with one another and sized to be capable of slideably accepting a retaining pin of at least one pin-type and/or pin- plus-locking-arm windshield wiper arm.
A connector for a windshield wiper, and a wiper blade assembly including same, that accommodates slotted receiving portions of windshield wiper arms. The connector for connecting a windshield wiper assembly to a wiper arm may have a peripheral wall having at least two opposing peripheral side walls and a top surface extending from one of the two opposing peripheral side walls to the other. The opposing peripheral side walls may each have a guide pin aligned with one another and sized to be capable of slidably engaging slots of windshield wiper arm.
A wiper blade including an elongate wiper strip, an elastic backing element and a mounting base. The wiper strip including a lip, a wide portion, and narrower intermediate portion between the lip and the wide portion. The backing element having a top portion from which two legs descend, such that each leg includes a claw that extends towards the opposite leg and has ends that define a gap sized to receive the intermediate portion of the wiper strip. The top portion, legs and claws of defining a wiper strip cavity where the wide portion of the wiper strip is disposed. The mounting base disposed on a section of the backing element and capable of connecting the wiper blade to a wiper arm and receiving force from same, such that the mounting base applies the force from the wiper arm to the backing element, which distributes same along the wiper strip.
A wiper blade connector releasably secures a wiper blade to a wiper arm, thereby forming a windshield wiper blade assembly. The wiper blade connector comprises an elongate body member having opposite facing side walls, a front end, and a rear end. The opposite facing sidewalls include means for receiving and releasably securing to the mounting base on a wiper blade. At the front end of the elongate body member, a first tongue receiving opening is sized to receive the corresponding front tongue of a wiper arm. At the rear end of the elongate body member, a second tongue receiving opening is sized to receive the corresponding rear tongue of a wiper arm. A locking mechanism, such as a slidable cap provided proximate to the front end of the elongate body member, releasably locks the wiper blade member to the wiper arm.
A novel wiper strip is presented having a wiper lip made of a first material, a base strip, a neck connecting the wiper lip to the base strip, and a wiper lip insert made of a second material. The second material may be harder than the first material. Additionally, the wiper lip insert may further include a lip portion that is embedded in the wiper lip. A wiper blade having a mounting base, a force distribution structure and a wiper strip consistent with the description above is also presented.
A novel wiper strip is presented having a wiper lip made of a first material, a base strip, a neck connecting the wiper lip to the base strip, and a wiper lip insert made of a second material. The second material may be harder than the first material. Additionally, the wiper lip insert may further include a lip portion that is embedded in the wiper lip. A wiper blade having a mounting base, a force distribution structure and a wiper strip consistent with the description above is also presented.
A wiper blade is presented having a wiper strip, a primary frame (20), and a pair of secondary frames (30). The primary frame (20) having a connection device (10) capable of connecting the wiper blade to a wiper arm disposed on a top side of the primary frame (20), and a connection structure disposed, on opposite ends of the primary frame (20). The pair of secondary frame (30), each have a central pivot connection portion and two leg portions extending from the central pivot connection portion (31), a pivot structure disposed on the central pivot connection portion (31) of the secondary frames wherein the pivot structure of the secondary frames (30) are connected to the connection structures on the ends of the primary frame (20). A wiper blade is also presented having a wiper strip, a force distribution structure having opposite ends, and a cover (60, 70).
A wiper blade is presented having a wiper strip, a primary frame (20), and a pair of secondary frames (30). The primary frame (20) having a connection device (10) capable of connecting the wiper blade to a wiper arm disposed on a top side of the primary frame (20), and a connection structure disposed, on opposite ends of the primary frame (20). The pair of secondary frame (30), each have a central pivot connection portion and two leg portions extending from the central pivot connection portion (31), a pivot structure disposed on the central pivot connection portion (31) of the secondary frames wherein the pivot structure of the secondary frames (30) are connected to the connection structures on the ends of the primary frame (20). A wiper blade is also presented having a wiper strip, a force distribution structure having opposite ends, and a cover (60, 70).
A wiper blade is presented having a wiper strip, a primary frame (20), and a pair of secondary frames (30). The primary frame (20) having a connection device (10) capable of connecting the wiper blade to a wiper arm disposed on a top side of the primary frame (20), and a connection structure disposed, on opposite ends of the primary frame (20). The pair of secondary frame (30), each have a central pivot connection portion (31) and two leg portions extending from the central pivot connection portion, a pivot structure disposed on the central pivot connection portion (31) of the secondary frames (30) wherein the pivot structure of the secondary frames (30) are connected to the connection structures on the ends of the primary frame (20). A wiper blade is also presented having a wiper strip, a force distribution structure having opposite ends, and a cover.
A wiper blade having a wiper strip, a primary frame (20) and a pair of secondary frames (30). The primary frame (20) may have a top side and opposite ends, a connection device (10) capable of connecting the wiper blade to a wiper arm disposed on the top side of the primary frame (20), and a connection structure (32) disposed on each of the opposite ends of the primary frame (20). Each secondary frame (30) may have a central pivot connection portion (31) and two leg portions extending from the central pivot connection portion (31), a pivot structure disposed on the central pivot connection portion of the secondary frames. The pivot structure may be a turn-buckle holder (51) comprising two holder halves (52) and a rivet (50) wherein the rivet passes through the two holder halves and holds them together.
A wiper blade having a wiper strip, a primary frame (20) and a pair of secondary frames (30). The primary frame (20) may have a top side and opposite ends, a connection device (10) capable of connecting the wiper blade to a wiper arm disposed on the top side of the primary frame (20), and a connection structure (32) disposed on each of the opposite ends of the primary frame (20). Each secondary frame (30) may have a central pivot connection portion (31) and two leg portions extending from the central pivot connection portion (31), a pivot structure disposed on the central pivot connection portion of the secondary frames. The pivot structure may be a turn-buckle holder (51) comprising two holder halves (52) and a rivet (50) wherein the rivet passes through the two holder halves and holds them together.
A wiper blade is presented having a wiper strip, a primary frame (20), and a pair of secondary frames (30). The primary frame (20) having a connection device (10) capable of connecting the wiper blade to a wiper arm disposed on a top side of the primary frame (20), and a connection structure disposed, on opposite ends of the primary frame (20). The pair of secondary frame (30), each have a central pivot connection portion (31) and two leg portions extending from the central pivot connection portion, a pivot structure disposed on the central pivot connection portion (31) of the secondary frames (30) wherein the pivot structure of the secondary frames (30) are connected to the connection structures on the ends of the primary frame (20). A wiper blade is also presented having a wiper strip, a force distribution structure having opposite ends, and a cover.
A wiper blade connector (10) releasably secures a wiper blade (50) to a wiper arm (60, 70), thereby forming a windshield wiper blade assembly. The wiper blade connector (10) comprises an elongate body member (12) having opposite facing side walls (14a, 14b), a front end, and a rear end. The opposite facing sidewalls (14a, 14b) include means (18) for receiving and releasably securing to the mounting base (40) on a wiper blade (50). At the front end of the elongate body member (12), a first tongue receiving opening (22) is sized to receive the corresponding front tongue (62, 72) of a wiper arm (60, 70). At the rear end of the elongate body member (12), a second tongue receiving opening (24) is sized to receive the corresponding rear tongue (74) of a wiper arm (70). A locking mechanism, such as a partially rotatable door member (30), releasably locks the wiper blade member (50) to the wiper arm (60, 70).
A connector (1) for a windshield wiper, and a wiper blade assembly including same, that accommodates multiple pin-type windshield wiper arms having varying pin lengths and locking mechanisms. The connector for connecting a windshield wiper assembly to a wiper arm may have a peripheral wall (4) having at least two opposing peripheral side walls (17, 18) and a top surface extending from one of the two opposing peripheral side walls to the other. The opposing peripheral side walls (4) may each have a retaining pin aperture aligned with one another and sized to be capable of slidably accepting a retaining pin of at least one pin-type windshield wiper arm.
A connector (1) for a windshield wiper, and a wiper blade assembly including same, that accommodates multiple pin-type windshield wiper arms having varying pin lengths and locking mechanisms. The connector for connecting a windshield wiper assembly to a wiper arm may have a peripheral wall (4) having at least two opposing peripheral side walls (17, 18) and a top surface extending from one of the two opposing peripheral side walls to the other. The opposing peripheral side walls (4) may each have a retaining pin aperture aligned with one another and sized to be capable of slidably accepting a retaining pin of at least one pin-type windshield wiper arm.
A wiper blade connector (10) releasably secures a wiper blade (50) to a wiper arm (60, 70), thereby forming a windshield wiper blade assembly. The wiper blade connector (10) comprises an elongate body member (12) having opposite facing side walls (14a, 14b), a front end, and a rear end. The opposite facing sidewalls (14a, 14b) include means (18) for receiving and releasably securing to the mounting base (40) on a wiper blade (50). At the front end of the elongate body member (12), a first tongue receiving opening (22) is sized to receive the corresponding front tongue (62, 72) of a wiper arm (60, 70). At the rear end of the elongate body member (12), a second tongue receiving opening (24) is sized to receive the corresponding rear tongue (74) of a wiper arm (70). A locking mechanism, such as a partially rotatable door member (30), releasably locks the wiper blade member (50) to the wiper arm (60, 70).
Wiper blade adapter (10) having a mounting portion (20) comprising a wiper blade securing element (23), the wiper securing element (23) being capable of securing a side-saddle portion (30) comprising a con- nector securing element, the connector securing element being ca- pable of securing a connector (5) that is capable of securing a wiper arm.
Wiper blade adapter (10) having a mounting portion (20) comprising a wiper blade securing element (23), the wiper securing element (23) being capable of securing a side-saddle portion (30) comprising a con- nector securing element, the connector securing element being ca- pable of securing a connector (5) that is capable of securing a wiper arm.
