A device for clamping and unclamping tools in a collet comprises a tool holder, a collet and a movable tensioner. The tool holder has a machine side and a tool side that is configured to accommodate a tool shank of a tool. The collet is arranged for clamping the tool shank inside the collet, the collet having a conical outer surface, which rests against a correspondingly shaped inner surface of the tool holder. The tensioner is configured to effect an axial movement of the collet with respect to the tool holder when the tool holder is thermally expanded, for clamping and unclamping the collet with the tool shank therein. The tensioner is arranged inside the tool holder on the machine side of the collet. A method is used to clamp tools in a collet of a tool holder.
The invention relates to a device for clamping and unclamping tools in a collet (14), comprising: a collet (14), which has a conical outer surface, which lies against a correspondingly shaped inner surface of a tool holder (10), the tool holder having a machine side and a tool side; - a tightener (20) for tightening and relaxing the collet (14), the tightener being axially movable in the tool holder (10) and being disposed on the machine side; wherein a heating apparatus (44) for heating the tool holder (10) in the region of the collet (14) is preferably provided.
B23P 11/02 - Connecting or disconnecting metal parts or objects by metal-working techniques, not otherwise provided for by first expanding and then shrinking or vice versa, e.g. by using pressure fluidsConnecting or disconnecting metal parts or objects by metal-working techniques, not otherwise provided for by making force fits
B23B 31/117 - Retention by friction only, e.g. using springs, resilient sleeves, tapers
B23B 31/20 - Longitudinally-split sleeves, e.g. collet chucks
09 - Scientific and electric apparatus and instruments
Goods & Services
Machine-driven tools and power-driven tools and parts
thereof, in particular clamping devices, adjusting devices
and changing devices, clamping sleeves, clamping chucks,
extensions for clamping chucks, shrink-fit clamping chucks,
collet chucks, setting sleeves, drill chucks, thread-cutting
chucks, bolt screw-in chucks, chuck inserts, quick-change
inserts, devices for clamping and releasing of tools in
clamping chucks, in particular shrink-fit machines for
thermal shrink-fit clamping of tools, thread-cutting devices
configured as machine parts, auxiliary devices for
machine-driven tools and power-driven tools, machine-driven
balancing devices, machine-driven assembly ratchets,
compressed air pistols and compressed air couplings. Hand-driven tools; clamping and adjusting devices;
hand-driven assembly ratchets. Measuring, recognition, and monitoring instruments, devices
and controllers for monitoring of tools and tool holders, in
particular electric, mechanical and pneumatic test probes,
signal transmitters, signal receivers and signal evaluation
devices; software stored on data carriers of any kind for
controlling, monitoring and evaluating afore-mentioned goods
in classes 7 and 9.
Disclosed is a tool system including a drive for driving a tool holder including an electromagnetic generator for generating electrical energy from inertial energy of the tool holder. The tool holder may be driven in rotation, wherein the electromagnetic generator comprises a rotor part, which is rotatably mounted on the tool holder, and a stator part on the tool holder cooperating with each other for generating a voltage by electromagnetic induction. Alternatively, an axially movable inertial mass can be used for utilization of an oscillating linear movement.
09 - Scientific and electric apparatus and instruments
Goods & Services
Power operated, machine driven tools and parts therefore, namely, clamps and clamping sleeves, tapping adjustment devices, quick connect devices for tool changing applications, clamping sleeves, clamping chucks, extensions for clamping chucks, shrink-fit clamping chucks, collet chucks, setting sleeves, drill chucks, thread-cutting chucks, bolt screw-in chucks, chuck inserts and quick-change chuck inserts; power operated, machine driven devices for clamping and releasing tools in clamping chucks, in particular shrink-fit machines for thermal shrink-fit clamping of tools; thread-cutting devices configured as machine parts; power operated, machine-driven balancing devices for the aforementioned clamping of tools; machine-driven assembly ratchets for use on machines; compressed air guns and quick connect couplings used in connection therewith Hand operated tools, namely, clamps and clamp adjusting devices; hand driven ratchets Measuring, recognition, and monitoring instruments, devices and controllers, namely, electric, mechanical and pneumatic test probes, signal transmitters, signal receivers and signal evaluation devices for monitoring power operated, machine-driven tools and tool holders; software stored on prerecorded, magnetic data carriers for controlling, monitoring and evaluating power-operated, machine driven tools
6.
TOOL WITH AN RFID CHIP AND METHOD FOR FASTENING SAME TO A TOOL
A tool, in particular for machining metal workpieces, is specified, having a cartridge (20) in which an RFID chip is accommodated in an encapsulated manner, said cartridge (20) being held in a blind hole (14) in the tool (12), wherein the cartridge (20) is held in the blind hole by means of a housing (18) which encloses the cartridge (20) and preferably consists of plastics material. The housing (18) having the cartridge (20) can either be inserted directly into the blind hole (14) and preferably be held by an oversize or held in the blind hole (14) of the tool (10) using an enclosing plastics ring in accordance with the plug principle.
A tapping chuck for synchronous tapping is disclosed, having a receiving part (12) for being driven by a machine, and having a clamping means (14) for a screw tap (16), between which receiving part and clamping means there is arranged an intermediate part (18), wherein the intermediate part (18) is connected in flexible fashion to the receiving part (12) in an axial direction by way of at least one elastomer element (48), wherein at least one first ball for transmitting torque between the receiving part (12) and the intermediate part (18) is received with play in a direction of rotation and in the axial direction, and wherein at least one second ball (44) is received, movably in the radial direction, in the receiving part (12), which at least one second ball is coupled by way of the elastomer element (48) to the clamping means (14) such that flexibility, spring-cushioned by way of the elastomer element (48), in the axial direction and in the direction of rotation is realized.
The invention relates to a tool holder, comprising: a main part (12) for coupling to a drive spindle which can be rotatingly driven, on which main part a chuck (18) for clamping a tool is received; and a damping element (42) between the main part (12) and the chuck (18), said damping element (42) consisting of a material with a modulus of elasticity which differs from the modulus of elasticity of the material of the chuck (18) by at least 50%, and the chuck (18) being connected, preferably bonded, to the main part (12) only via the damping element (42).
B23Q 11/00 - Accessories fitted to machine tools for keeping tools or parts of the machine in good working condition or for cooling workSafety devices specially combined with or arranged in, or specially adapted for use in connection with, machine tools
F16F 15/124 - Plastics springs, e.g. made of rubber
B23B 31/08 - Chucks holding tools or work yieldably
B23B 31/117 - Retention by friction only, e.g. using springs, resilient sleeves, tapers
B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
Described is a tool holder for receiving the tool shaft (18) of a tool (16), said tool holder having a receiving bore (14) for receiving the tool shaft (18) in a predefined axial position, having a seal (28) at the inner end of the receiving bore (14), having a machine-side coolant supply in a bore (44) of the tool shaft (18), the seal (28) having an at least partially elastically deformable sealing element (36).
The invention discloses a tool clamping system comprising a tool holder for clamping a tool, said tool holder being configured for being driven rotatingly; a tool secured to the tool holder; a tool shaft carried by the tool; at least one cutting edge carried by the tool; at least one piezo element for generating a voltage from mechanical vibration energy of the rotating tool clamping system; and at least one delay element selected form the group consisting of an inductor and a capacitor being connected to the at least one piezo element so as to form an electrical oscillating circuit, wherein the oscillating circuit is configured for monitoring at least one operating parameter of the tool clamping system.
09 - Scientific and electric apparatus and instruments
Goods & Services
Tool holders and Tool changing equipment, clamping equipment, setting equipment, in particular clamping sleeves, setting sleeves, Drill chucks, Tapping chucks, Chucks for screwing in studs, chuck inserts, quick-change inserts, all the aforesaid goods for mechanical tools; Tapping apparatus being parts of machines; Thermal shrinkage machines, shrinkage apparatus and shrink-fit chucks for reversibly clamping tools; Mechanical balancing equipment. Tool monitoring systems for wireless and wired monitoring of tool holders, drill chucks, tapping chucks, chucks for screwing in studs, chuck inserts, quick-change inserts, tapping inserts.
The invention relates to a tool clamping system (20) having a rotationally driven tool holder (22) for clamping a tool (10), in which a device (14,16,28,29) is provided for generating electrical energy from mechanical or thermal energy of the tool clamping system (20).
The invention relates to a tool system with a mechanically drivable tool holder (12) which comprises a device (17) for generating electrical energy from the inertial energy of the tool clamping system (10), wherein the device (17) is preferably designed as a voltage generator on the tool holder (12), comprising a rotor (18), which is rotatably mounted on the tool holder (12), and a stator part (22) on the tool holder (12) for voltage generation by electromagnetic induction. Alternatively, an axially movable inertial mass can be used for exploiting an oscillating linear movement.
The invention relates to a tool clamping system (10) for clamping a tool (14), comprising a tool holder (12), a unit for generating electrical energy from mechanical or thermal energy of the tool clamping system (10) being provided, which unit comprises preferably at least one Seebeck element (26) for generating a voltage from the thermal energy of the tool clamping system (10).
A quick-change system for a tool holder comprises a machine-side receiving fixture having a hollow-cylindrical extension on which a switching sleeve is displaceably held. Automatic angular alignment of the tool holder upon introduction into the hollow-cylindrical extension of the receiving fixture is enabled by an alignment of the points of the star-shaped end face on the cylindrical holding portion of the tool holder, upon impact against a first set of three balls angularly spaced 120° apart. Once the tool holder has aligned itself in this way, then the first balls make their way into the longitudinal grooves of the cylindrical holding portion, whereby a rotationally fixed coupling is achieved. Upon the further insertion into the hollow-cylindrical extension, an axial securement finally occurs when a second set of three balls are displaced radially inward into associated depressions on the cylindrical holding portion.
The invention relates to a tool head having a shrink-fit chuck (10) that has an axial receiving hole (22), and having a tool (12) that is insertable by way of its cylindrical tool shank (24) into the receiving hole (22), which is open at the front end of the shrink-fit chuck (10), and is fixable therein by thermal shrinking of the shrink-fit chuck (10). According to the invention, it is proposed that the shrink-fit chuck (10) has, in its front end portion, an annular recess (30) that radially widens the receiving hole (22) and is open at the end side, and that a function ring (14) is positioned on the tool shank (24), wherein, in the shrink-fitted state, the tool shank (24) is frictionally fixed in the receiving hole (22) and the function ring (14) sits at least partially in the annular recess (30).
09 - Scientific and electric apparatus and instruments
Goods & Services
(1) Tool holders, tool setting fixtures and gages and tool changing attachments for changing tools on drilling machines, clamping sleeves, setting sleeves, drilling chucks, tapping chucks, chucks for driving studs, quick change inserts for machine tools and bolts, screws and nuts; tapping attachments (machine parts); thermal shrinking machines and shrinking chucks for reversible clamping of tools; balancing machines; ratchets for use on machines; compressed-air pistols and couplings.
(2) Ratchets worked by hand.
(3) High frequency surveillance systems, essentially composed of built-in transmitters on tool holders and receivers and processors; controlling devices, namely testing calipers.
