A cyclone manifold system (1) has a cyclone feed distributor (2) equipped with a modular port extender (32) therein. The modular port extender (32) is configured to be separated from and secured to the cyclone feed distributor (2) and is constructed with a tube (56), a proximal flange (57), distal flange (54) and a distal insertion portion (64) defined between the distal flange (54) and its distal end (66). The distal insertion portion (64) is configured to be received within an aperture/opening (47) of a mount (30) provided to the cyclone feed distributor (2) at one of its ports (15). The distal end (66) of the modular port extender (32) may be protected with a liner (58) and configured to extend through the mount (30) and exposed to a distribution chamber (35) within the cyclone feed distributor (2).
B04C 5/28 - Multiple arrangement thereof for parallel flow
B04C 5/13 - Construction of the overflow ducting, e.g. diffusing or spiral exits formed as a vortex finder and extending into the vortex chamberDischarge from vortex finder otherwise than at the top of the cycloneDevices for controlling the overflow
B01D 53/06 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by adsorption, e.g. preparative gas chromatography with moving adsorbents
B01D 53/08 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by adsorption, e.g. preparative gas chromatography with moving adsorbents according to the "moving bed" method
B01D 53/12 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by adsorption, e.g. preparative gas chromatography with moving adsorbents with dispersed adsorbents according to the "fluidised technique"
2.
ECCENTRIC HAVING NOVEL OIL DELIVERY CHANNELS, METHOD OF ITS FABRICATION, AND CRUSHER INCLUDING THE SAME
An eccentric (10) for a crusher (1) is disclosed. The eccentric may have a body (28) having an outer peripheral surface portion (30), an upper surface portion or top surface or top surface portion (17), and a lower surface portion or undersurface or bottom surface portion (18). At least one oil drain hole or oil delivery channel (12) extends through the body (28). A distance separates all portions of the at least one oil drain hole or oil delivery channel (12) from the outer peripheral surface (30) of the body (28). The at least one oil drain hole or oil delivery channel (12) also extends from the upper surface portion or top surface or top surface portion (17) to the lower surface portion or undersurface or bottom surface portion (18) without intersecting the outer peripheral surface (30) of the body (28).
An aeration assembly (29) for a self-aspirated flotation cell (100) may have a standpipe (11). A lower inside diameter (42) of the standpipe (11) may be measured to be within ± 25% of an upper inside diameter (41) of a draft tube (106) or collar (108). The aeration assembly (29) may have an upper gap (37) that extends between a rotor (15) and standpipe (11) and a lower gap (36) that extends between the rotor (15) and draft tube (106) or collar (108), wherein the upper gap (37) may be measured to be within ± 25% of the lower gap (36). In some embodiments, the rotor (15) extends into the standpipe (11) for an upper vertical rotor depth (39) and the rotor (15) extends into the standpipe (11) for a lower vertical rotor depth (40), wherein the upper vertical rotor depth (39) is measured to be within ±25% of the lower vertical rotor depth (40).
An apparatus (1) and process for wear monitoring can include scanning a wearable component (5) and providing scan data for analysis and evaluation. An evaluation device (11) can evaluate the scan data to monitor the wear experienced by the scanned component and provide an indication identifying when the component may need to be replaced, providing an output via an output device that can indicate a projected replacement time period for replacement of the component and/or scheduling a replacement for the component.
B02C 17/18 - Disintegrating by tumbling mills, i.e. mills having a container charged with the material to be disintegrated with or without special disintegrating members such as pebbles or balls Details
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Screens being parts of machines for sorting of materials; screening machines for sorting of materials including modular panels, polyurethane screens, rubber screens, wire screens and composite screens; screening media, trommel media, and industrial screens for use in mining, including, mechanical and non-metal screens, trommel screens, and vibratory screens for separating, sorting, and processing mined materials; machines and apparatus for screening, sizing, sorting and separating minerals and ores; replacement parts and accessories for screens, screening media, trommel media, and industrial screens used in mining including screen rails, pins, mounting components and retaining assemblies. Measuring, monitoring, signaling and control apparatus and instruments, including data recording devices and sensors for monitoring, measuring and recording the performance of mining equipment, namely, screens, screening media, trommel media, and industrial screens; downloadable and recorded software for monitoring, analyzing, and optimizing the performance of mining equipment, namely, screens, screening media,trommel media, and industrial screens; downloadable database, including computer database containing performance data for screening and separation equipment in the mining industry. Engineering, design and technical consultancy services relating to screening equipment, screening media for the mining and mineral processing industries; design, development and customization of screening solutions and machine components; software design, development and maintenance for monitoring, controlling and optimizing industrial screening and processing equipment; technical support, testing, analysis and performance evaluation of screening systems and related equipment.
6.
CORNER BLOCK SEGMENT FOR A ROLL OF A COMMINUTION DEVICE
The invention relates to a corner block segment (2) for attachment to a cylindrical roll body (104) of a roll (102) of a comminution device (100), the corner block segment (2) having a base body (4), a segment outer side (8), a segment end face (12), a corner region (10) between the segment outer side (8) and the segment end face (12) to form a roll edge (110) of the roll (102), and a receiving side (14), wherein the receiving side (14) corresponds to a segment receptacle (106) of the roll body (104) and is arranged facing away from the corner region (10), wherein the segment outer side (8) is curved and is arranged facing away from an imaginary reference axis (16), and wherein in the longitudinal section through the reference axis (16), the corner region (10) has a radius (18) of at least 5 mm.
A launder (1) for collecting slurry discharged from a cyclone pack (31) containing cyclones (32) may be characterized in that it has a specially-configured discharge region. The discharge region of the launder (1) may have two lateral extension facets or wall portions (8), each extending outwardly and/or projecting from respective adjacent portions of a first outer annular sloped wall (4). Each of the two lateral extension facets or wall portions (8) may be provided on opposite sides of the discharge outlet (6). An extension portion (9) of the outer annular wall (2) may be provided near (and at least partially above) the discharge outlet (6). The outer annular wall (2) may extend further downwardly than other lower portions of the outer annular wall (2).
B03B 5/62 - Washing granular, powdered or lumpy materialsWet separating by hydraulic classifiers, e.g. of launder, tank, spiral or helical chute concentrator type
B03B 7/00 - Combinations of wet processes or apparatus with other processes or apparatus, e.g. for dressing ores or garbage
B03B 9/00 - General arrangement of separating plant, e.g. flow sheets
B03B 11/00 - Feed or discharge devices integral with washing or wet-separating equipment
The present invention relates to method and apparatus for recycling composite mill liners. This invention is preferably concerned with an optimized method of recycling worn out composite mill liners by effectively disassembling the composite into metal and rubber parts that can be reused, as well as a mobile apparatus for carrying out the method.
A fluidized bed separator (1) includes a feed section (4) between an upper separation chamber (19) and a main separation chamber (6). The feed section (4) has one or more feed pipes (11) extending horizontally and transversely with respect to a body wall (10) of the fluidized bed separator (1). The one or more feed pipes (11) are positioned completely and entirely underneath the inclined plates (17). An external oversize protection apparatus (3) which is separate from and external to the body wall (10) may be operatively coupled to the one or more feed pipes (11). One or more lamella cartridges (49) may be provided within channels (18) of the upper separation chamber (19), and one or more breakaway plates (54, 55) may be inserted within channels (18) to prevent sanding and facilitate insertion and extraction of the lamella cartridges (49).
B03B 5/48 - Washing granular, powdered or lumpy materialsWet separating by mechanical classifiers
B01D 21/00 - Separation of suspended solid particles from liquids by sedimentation
B01D 21/24 - Feed or discharge mechanisms for settling tanks
B03B 5/62 - Washing granular, powdered or lumpy materialsWet separating by hydraulic classifiers, e.g. of launder, tank, spiral or helical chute concentrator type
10.
METHOD FOR DETERMINING THE PARTICLE SIZE DISTRIBUTION OF GRANULAR MATERIAL IN A DELIVERY FLOW, AND MEASURING DEVICE
42 - Scientific, technological and industrial services, research and design
Goods & Services
(1) Machine parts and components for mining and aggregates equipment, namely, bushings, bowl assemblies, adjustment ring assemblies, head assemblies, main frame assemblies, feed plate assemblies, liners, hopper components, socket assemblies, eccentric assemblies, countershaft assemblies, and hydraulic components; replacement parts, wear parts, consumables, and fittings for mining and aggregates equipment, namely, crushers (1) Engineering and design services relating to mining and aggregates machines, namely crushers and replacement parts therefor; product development services in the field of crusher components; technological consulting in the field of mining equipment and machine part design
12.
APPARATUS AND PROCESS FOR FILTER CAKE BREAKTHROUGH DETECTION
A filtration apparatus can be configured to utilize a control system to detect sufficient dewatering of filter cake for facilitating quicker operation for improved output. Some embodiments can include a control device that can monitor pressure upstream and downstream of a pressurization fluid feed valve to detect a condition during pressurization of filter cakes for dewatering to indicate that sufficient dewatering has occurred for subsequent processing.
B01D 25/00 - Filters formed by clamping together several filtering elements or parts of such elements
B01D 25/127 - Filter presses, i.e. of the plate or plate and frame type with one or more movable filter bands arranged to be clamped between the press plates or between a plate and a frame during filtration, e.g. zigzag endless filter bands
B01D 25/28 - Leaching or washing filter cakes in the filter
13.
A COMMINUTION APPARATUS, A GRATE SEGMENT FOR A DISCHARGE GRATE OF THE COMMINUTION APPARATUS, AND A PROCESS FOR COMMINUTION OF MATERIAL
A comminution apparatus can include a discharge grate that is configured to have openings sized to permit comminuted material of a pre-selected size range to pass through openings of the grate. The grate can be structured to permit movement of the grate so that the size of the openings of the grate may vary during operations so that comminution media utilized in a comminution chamber that may become lodges in the openings can be dislodged for passing through the opening or being directed back into the chamber to avoid blockages of the openings. Some embodiments can utilize openings that are also tapered such that the discharge sides of the openings are wider than the comminution chamber side of the openings.
B02C 17/18 - Disintegrating by tumbling mills, i.e. mills having a container charged with the material to be disintegrated with or without special disintegrating members such as pebbles or balls Details
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
37 - Construction and mining; installation and repair services
Goods & Services
Anti-pollution devices for motors and engines, namely,
mechanical systems for particulate removal; particulate
filters [parts of engines]. Electrical and electronic control systems, including
controllers, automatic control apparatus, sensors, and power
supplies for industrial flue gas treatment systems;
automated monitoring and control apparatus for industrial
air pollution control. Equipment for environmental treatment of industrial flue
gases, namely semi-dry scrubbers, filtration devices, dust
collection systems, and gas treatment installations; all
aforementioned for removal of particulates or harmful
substances from industrial emissions; electrostatic
precipitators for cleaning air; machines, machine
components, and mechanical parts for industrial flue gas
cleaning and pollution control; air pollution control
machines; flue gas treatment systems, namely, gas scrubbers
[parts of gas installations]. Construction, maintenance, and repair of industrial air
pollution control systems, including electrostatic
precipitators and semi-dry scrubbers for flue gas treatment.
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
37 - Construction and mining; installation and repair services
Goods & Services
Anti-pollution devices for motors and engines, namely,
mechanical systems for particulate removal; particulate
filters [parts of engines]. Electrical and electronic control systems, including
controllers, automatic control apparatus, sensors, and power
supplies for industrial flue gas treatment systems;
automated monitoring and control apparatus for industrial
air pollution control. Equipment for environmental treatment of industrial flue
gases, namely semi-dry scrubbers, filtration devices, dust
collection systems, and gas treatment installations; all
aforementioned for removal of particulates or harmful
substances from industrial emissions; electrostatic
precipitators for cleaning air; machines, machine
components, and mechanical parts for industrial flue gas
cleaning and pollution control; air pollution control
machines; flue gas treatment systems, namely, gas scrubbers
[parts of gas installations]. Construction, maintenance, and repair of industrial air
pollution control systems, including electrostatic
precipitators and semi-dry scrubbers for flue gas treatment.
16.
SYSTEM AND METHOD FOR MITIGATING NEGATIVE IMPACTS CAUSED BY VOLATILE ELEMENTS PRESENT WITHIN MATERIALS PROCESSED OR CONSUMED DURING A CALCINATION PROCESS
A process or method for reducing concentrations of a volatile element (or a circulating load containing a volatile element), and/or for reducing or mitigating buildup formations of volatile elements in a calcining operation is disclosed. A calciner system, plant, flowsheet, or apparatus configured to perform the method is also disclosed. A quenching chamber, a filter, and/or de-dusting circuit may be employed. Hot process gasses containing volatiles in a vapor form or phase are mixed with a cooler gas in a quenching chamber to precipitate out volatiles. The cooler gas comprise preheater circuit off-gas. An advantage offered by embodiments, is less buildup of volatiles on wall surfaces within components of the calciner system.
09 - Scientific and electric apparatus and instruments
Goods & Services
Screening media, trommel media, and industrial screens for
use in mining, namely, mechanical and non-metal screens,
trommel screens, and vibratory screens for separating,
sorting, and processing mined materials; replacement parts
and accessories for screening media, trommel media, and
industrial screens used in mining including screen rails,
pins, mounting components and retaining assemblies. Measuring, signaling and control apparatus and instruments,
including data recording devices and sensors for use in
monitoring, measuring and recording the performance of
mining equipment, namely, screening media, trommel media,
and industrial screens; downloadable and recorded software
for monitoring, analyzing, and optimizing the performance of
mining equipment, namely, screening media, trommel media,
and industrial screens; downloadable database, including
computer database containing performance data for screening
and separation equipment in the mining industry.
122), and in doing so accelerates increasing further sealing water velocity and/or inducing a cyclonic barrier that protects the seal compression packing rings (8) from solid particles contamination more effectively than conventional lantern ring designs. This may reduce seal water consumption and/or improve pump reliability.
F04D 7/04 - Pumps adapted for handling specific fluids, e.g. by selection of specific materials for pumps or pump parts of centrifugal type the fluids being viscous or non-homogeneous
09 - Scientific and electric apparatus and instruments
Goods & Services
Screening media, trommel media, and industrial screens for use in mining, namely, mechanical and non-metal screens, trommel screens, and vibratory screens for separating, sorting, and processing mined materials; replacement parts and accessories for screening media, trommel media, and industrial screens used in mining including screen rails, pins, mounting components and retaining assemblies. Measuring, signaling and control apparatus and instruments, including data recording devices and sensors for use in monitoring, measuring and recording the performance of mining equipment, namely, screening media, trommel media, and industrial screens; downloadable and recorded software for monitoring, analyzing, and optimizing the performance of mining equipment, namely, screening media, trommel media, and industrial screens; downloadable database, including computer database containing performance data for screening and separation equipment in the mining industry.
09 - Scientific and electric apparatus and instruments
Goods & Services
(1) Screening media, trommel media, and industrial screens for use in mining, namely, mechanical and non-metal screens, trommel screens, and vibratory screens for separating, sorting, and processing mined materials; replacement parts and accessories for screening media, trommel media, and industrial screens used in mining including screen rails, pins, mounting components and retaining assemblies.
(2) Measuring, signaling and control apparatus and instruments, including data recording devices and sensors for use in monitoring, measuring and recording the performance of mining equipment, namely, screening media, trommel media, and industrial screens; downloadable and recorded software for monitoring, analyzing, and optimizing the performance of mining equipment, namely, screening media, trommel media, and industrial screens; downloadable database, including computer database containing performance data for screening and separation equipment in the mining industry.
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machine parts and components for mining machines and aggregates being sand, gravel, and stone working machines, namely, bushings, bowl assemblies, adjustment ring assemblies, head assemblies, main frame assemblies, feed plate assemblies, liners, hopper components, socket assemblies, eccentric assemblies, countershaft assemblies, and hydraulic components; replacement parts, wear parts, and consumables and fittings being parts for mining and aggregates equipment in the nature of crushing machines for industrial purposes Engineering and product design services relating to mining and aggregates machines in the nature of crushers and replacement parts therefor; product development services in the field of crusher components; technological consulting in the field of mining equipment and machine part design
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Downloadable software applications for use with smartphones
and mobile devices, for monitoring and managing the
operation and performance of mining equipment and mineral
processing equipment; mobile application software for
real-time data processing, visualization, and remote
monitoring and management of mining equipment operation and
performance; data processing apparatus and instruments for
analysing machinery performance in mining operations. Software as a service for asset management in mining plants;
software as a service for data analysis and maintenance in
mining operations; remote monitoring of mining equipment for
operational insights; design and development of computer
software for machinery diagnostics; predictive analytics
services for equipment health management in mining plants;
engineering services relating to the optimization of
industrial machinery; platform as a service featuring
computer software platforms for machinery monitoring and
management; technological consulting services in the field
of mining machinery performance optimization; provision of
online non-downloadable software for real-time equipment
monitoring in mining plants.
A rail conveyor system may include carriages with multiple cradles that are configured to support a carry belt. The carriages may be supported by and may travel along guide rails that extend along a longitudinal path. The guide rails may be supported by discrete frame modules that are longitudinally spaced apart. The frame modules may include at least slidable frame modules that are slidably attached to footings and expansion frame modules that include expansion gaps that permit the guide rails to thermally expand and contract longitudinally. The carriage may also include an anti-derailment device that greatly minimizes the risk of derailment.
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
37 - Construction and mining; installation and repair services
Goods & Services
Machines, machine components, and mechanical parts for industrial flue gas cleaning and pollution control; air pollution control machines; mechanical systems for particulate removal; industrial mechanical gas treatment systems. Electrostatic precipitators; electrical and electronic control systems, including controllers, automation units, sensors, and power supplies for industrial flue gas treatment systems and electrostatic precipitators; automated monitoring and optimization systems for industrial air pollution control. Equipment for environmental treatment of industrial flue gases, namely semi-dry scrubbers, filtration devices, dust collection systems, and gas treatment installations; all aforementioned for removal of particulates or harmful substances from industrial emissions. Construction, maintenance, and repair of industrial air pollution control systems, including electrostatic precipitators and semi-dry scrubbers for flue gas treatment.
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
37 - Construction and mining; installation and repair services
Goods & Services
Machines, machine components, and mechanical parts for industrial flue gas cleaning and pollution control; air pollution control machines; mechanical systems for particulate removal; industrial mechanical gas treatment systems. Electrostatic precipitators; electrical and electronic control systems, including controllers, automation units, sensors, and power supplies for industrial flue gas treatment systems and electrostatic precipitators; automated monitoring and optimization systems for industrial air pollution control. Equipment for environmental treatment of industrial flue gases, namely semi-dry scrubbers, filtration devices, dust collection systems, and gas treatment installations; all aforementioned for removal of particulates or harmful substances from industrial emissions. Construction, maintenance, and repair of industrial air pollution control systems, including electrostatic precipitators and semi-dry scrubbers for flue gas treatment.
An exciter apparatus for a vibrating machine having an exciter body being configured to accommodate a lubricant. The exciter apparatus further has a first bearing comprising an inner bearing portion and an outer bearing portion separated by a number of rollers located in a gap between the inner bearing portion and outer bearing portion. A first shaft is rotatably connected to the exciter body by means of the first bearing. The first shaft has eccentric masses. The first bearing seat and the outer bearing portion comprising a through hole allowing a fluid to flow through the first bearing seat and the outer bearing portion into the gap, The exciter apparatus further comprising a lubricant provision means configured to provide a lubricant from the lubrication zone to the through hole.
F16C 35/04 - Rigid support of bearing unitsHousings, e.g. caps, covers in the case of ball or roller bearings
B06B 1/16 - Processes or apparatus for generating mechanical vibrations of infrasonic, sonic or ultrasonic frequency making use of mechanical energy operating with systems involving rotary unbalanced masses
B07B 1/28 - Moving screens not otherwise provided for, e.g. swinging, reciprocating, rocking, tilting, or wobbling screens
B07B 1/42 - Drive mechanisms, regulating or controlling devices, or balancing devices, specially adapted for screens
F16C 19/26 - Bearings with rolling contact, for exclusively rotary movement with bearing rollers essentially of the same size in one or more circular rows, e.g. needle bearings for radial load mainly with a single row of rollers
F16C 33/66 - Special parts or details in view of lubrication
Machine parts and replacement parts for mining machines,
namely, mill liners, shell liners, head liners, head plates,
grate discharge liners, crusher liners, feeder liners, wear
liners, and wear plates; parts and fittings for mills,
crushers, and feeders, namely, steel liners, rubber liners,
and composite liners; liners for grinding mills including
SAG mills, AG mills, Rod mills, and Ball mills; liners for
crushers including cone crushers, jaw crushers, gyratory
crushers, and impact crushers; liners for vibrating screens,
vibrating feeders, belt feeders, apron feeders, and
reciprocating feeders.
29.
SYSTEM AND METHOD FOR CONTROLLING OR REMOVING HARD DEPOSITS ON ELECTROWINNING CATHODES
Electrowinning circuits and methods of electrowinning are disclosed. Embodiments may be characterized in that that they promote the removal of hard cathode deposits from cathodes. Embodiments may also be characterized in that they promote softer deposits of precious metals onto cathodes during the electrowinning process. An advantage of practicing disclosed embodiments is that precious metal deposits on cathodes may be more easily recovered and the cathodes may be re-used in the electrowinning process. Thus, cathode destruction via smelting to recover precious metal deposits can be avoided.
Various embodiments of a process and device for the decarbonation of limestone, dolomite or other carbonated materials are disclosed. The process and device may involve heating particles of carbonated materials (6) in a reactor (8) of a first circuit (2) to obtain decarbonated particles (16) comprising CaO and/or MgO; transferring the decarbonated particles (16) to one or more cooling sections (22, 22′) in which the conveyed decarbonated particles (16) release a portion of their thermal energy to second (14) and/or third gases (14′); and providing substantially pure oxygen to the reactor (8) at an oxygen entrance point which is preferably located below one or more fuel entrance points. Waste heat and/or vented gas may be recovered and re-used within the process by virtue of unique configurations of the device and provision of novel apparatus to the device.
A scroll assembly (1) for a centrifuge (100) may be characterised in that it includes at least one lamellae pack assembly (11) proximate the first end (9) of the scroll (2). The lamellae pack assembly (11) may have a plurality of lamella plates (11d) and be positioned upstream of a weir (31) or an effluent exit port (4) that permits a liquid fraction (33) of said infeed slurry to discharge from the centrifuge (100). The lamella plates (11d) are preferably configured and arranged to bias fine solids (35) entrained within the liquid fraction (33) radially-outwardly or at least hinder their radially-inwardly migration as the liquid fraction (33) passes through the lamella plates (11d) and before the liquid fraction passes the weir (31) or effluent exit port (4), in order to produce discharged clarified liquids (36) which are substantially-free of the fine solids (35).
B04B 3/04 - Centrifuges with rotary bowls in which solid particles or bodies become separated by centrifugal force and simultaneously sifting or filtering discharging solid particles from the bowl by a conveying screw co-axial with the bowl axis and rotating relatively to the bowl
B04B 1/20 - Centrifuges with rotary bowls provided with solid jackets for separating predominantly liquid mixtures with or without solid particles discharging solid particles from the bowl by a conveying screw coaxial with the bowl axis and rotating relatively to the bowl
32.
DUST SEALING SYSTEM AND METHOD OF INSTALLING DUST SEALING SYSTEM IN CRUSHER
A dust sealing system (210) for a crusher (100) which includes a plurality of sealing members (220) at least partly received within an annular groove (222) defined in a head center (150) of the crusher (100). The dust sealing system (210) further includes an actuating mechanism (600) for moving the plurality of sealing members (220) from a non-operating position to an operating position. The plurality of sealing members (220) together forms a dust seal ring (300) in the operating position and abuts a dust collar (202) of the crusher (100). A tolerance (C1) defined between the plurality of sealing members (220) and the dust collar (202) at the non-operating position is greater than a target tolerance (C2) defined between the plurality of sealing members (220) and the dust collar (202) at the operating position.
B02C 2/00 - Crushing or disintegrating by gyratory or cone crushers
B02C 2/04 - Crushing or disintegrating by gyratory or cone crushers eccentrically moved with vertical axis
B02C 23/00 - Auxiliary methods or auxiliary devices or accessories specially adapted for crushing or disintegrating not provided for in groups or not specially adapted to apparatus covered by one only of groups
A guiding tool (300) and a method (500) for installing a head nut (160) of a crusher (100) using the guiding tool (300) is provided. The guiding tool (300) includes a cylindrical body (302) having a center hole (308) for inserting over a main shaft (120) of the crusher (100), and a first thread portion (310) defined at an outer circumference (312) of the cylindrical body (302) in conformance with a thread portion (202) of the head nut (160). The first thread portion (310) of the cylindrical body (302) aligns with a second thread portion (206) associated with the main shaft (120), engages with the head nut (160), and allows the head nut (160) to threadably move and engage with the second thread portion (206) to secure a mantle (154) disposed on the main shaft (120).
B02C 2/04 - Crushing or disintegrating by gyratory or cone crushers eccentrically moved with vertical axis
B02C 2/06 - Crushing or disintegrating by gyratory or cone crushers eccentrically moved with vertical axis and with top bearing
B02C 2/00 - Crushing or disintegrating by gyratory or cone crushers
B02C 23/00 - Auxiliary methods or auxiliary devices or accessories specially adapted for crushing or disintegrating not provided for in groups or not specially adapted to apparatus covered by one only of groups
09 - Scientific and electric apparatus and instruments
Goods & Services
Screening media, trommel media, and industrial screens for use in mining, namely, mechanical and non-metal screens, trommel screens, and vibratory screens for separating, sorting, and processing mined materials; replacement parts and accessories for screening media, trommel media, and industrial screens used in mining including screen rails, pins, mounting components and retaining assemblies. Measuring, signaling and control apparatus and instruments, including data recording devices and sensors for use in monitoring, measuring and recording the performance of mining equipment, namely, screening media, trommel media, and industrial screens; downloadable and recorded software for monitoring, analyzing, and optimizing the performance of mining equipment, namely, screening media, trommel media, and industrial screens; downloadable database, including computer database containing performance data for screening and separation equipment in the mining industry.
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
(1) Downloadable software applications for use with smartphones and mobile devices, for monitoring and managing the operation and performance of mining equipment and mineral processing equipment; mobile application software for real-time data processing, visualization, and remote monitoring and management of mining equipment operation and performance; data processing apparatus and instruments for analysing machinery performance in mining operations. (1) Software as a service for asset management in mining plants; software as a service for data analysis and maintenance in mining operations; remote monitoring of mining equipment for operational insights; design and development of computer software for machinery diagnostics; predictive analytics services for equipment health management in mining plants; engineering services relating to the optimization of industrial machinery; platform as a service featuring computer software platforms for machinery monitoring and management; technological consulting services in the field of mining machinery performance optimization; provision of online non-downloadable software for real-time equipment monitoring in mining plants.
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Downloadable software applications for use with smartphones and mobile devices, for monitoring and managing the operation and performance of mining equipment and mineral processing equipment; mobile application software for real-time data processing, visualization, and remote monitoring and management of mining equipment operation and performance; data processing apparatus and instruments for analysing machinery performance in mining operations. Software as a service for asset management in mining plants; software as a service for data analysis and maintenance in mining operations; remote monitoring of mining equipment for operational insights; design and development of computer software for machinery diagnostics; predictive analytics services for equipment health management in mining plants; engineering services relating to the optimization of industrial machinery; platform as a service featuring computer software platforms for machinery monitoring and management; technological consulting services in the field of mining machinery performance optimization; provision of online non-downloadable software for real-time equipment monitoring in mining plants.
37.
BUSHING ASSEMBLY AND A DRIVE MECHANISM FOR AN ECCENTRIC CRUSHING MACHINE
A bushing assembly (50) for an eccentric machine such as a gyratory crusher (1). The bushing assembly (50) comprising a first bushing (51) having a center axis (105) and a first cavity (53) being coaxial with a first eccentric axis (106). A second bushing (61) having a second center axis (205) is accommodated in the first cavity (53). The second bushing (61) having a second cavity (65) being coaxial with a second eccentric axis (206). The first bushing (51) and second bushing (61) are configured to rotate individually with different relative velocities whereby the distance between the second center axis and the first eccentric axis varies.
An apparatus configured to detect wear experienced by a component of a comminution device can be adapted to provide a reliable approach for detecting wear non-invasively to help monitor wear and/or indicate that component may need to be replaced to help facilitate improved maintenance operations that can reduce equipment downtime. Some embodiments can be configured to monitor the wear that may be experienced by a central screw of a tower mill and/or its wear liner in a non-invasive way to provide a real-time monitoring of the wear experienced by that component, for example. The wear detection, or wear monitoring, can be performed while the comminution device is operated to comminute material.
B02C 19/22 - Crushing mills with screw-shaped crushing means
B02C 17/18 - Disintegrating by tumbling mills, i.e. mills having a container charged with the material to be disintegrated with or without special disintegrating members such as pebbles or balls Details
B02C 17/16 - Mills in which a fixed container houses stirring means tumbling the charge
39.
FROTH WASHING APPARATUS FOR INFLATABLE FLOTATION MACHINE FROTH CROWDERS
Means (102) for cleaning froth (9) in a flotation machine (1) are disclosed. The means (102) may be integrally, or separately provided to an inflatable froth crowder apparatus (100) or to another component (2, 4, 100) of a flotation machine (1), such as to a froth crowder (7) or upper inner rim of a tank (2), without limitation. A method for cleaning froth (9) during a process of flotation using a flotation machine (1), using the novel means (102) for cleaning froth (9), is also disclosed.
ELECTROWINNING CELL, SYSTEM, AND METHOD FOR PRODUCING SOFT DEPOSITS ON ELECTROWINNING CATHODES AND FOR AUTOMATICALLY CLEANING AND REMOVING HARD AND SOFT DEPOSITS
C25C 7/08 - Separating of deposited metals from the cathode
41.
ELECTROWINNING CELL, SYSTEM, AND METHOD FOR PRODUCING SOFT DEPOSITS ON ELECTROWINNING CATHODES AND FOR AUTOMATICALLY CLEANING AND REMOVING HARD AND SOFT DEPOSITS
An electrowinning system (1) may comprise a filter (11) for filtering barren solution (38), an electrowinning cell (100) configured for "self-cleaning", an electrode support hanger (123) configured for slidably receiving electrodes (121, 122), a discharge cleaning nozzle (138) for moving product/sludge (43) to a lower discharge (130), a wash system (108) which may distribute filtered barren solution (38) for cleaning one or more electrodes (121, 122), and/or a lifting system (107) for mechanically raising and/or lowering electrodes (121, 122) in relation to a tank (111) Other novel improvements include a sloped floor (19) for a barren solution return tank (5), a unique (e.g., 3-way) valve (16) arrangement for recycling barren solution (38) to one or more portions of the electrowinning system (1) and inlets (117) which allow side removal and installation of novel spray bars (147) from the tank (111).
F16K 3/02 - Gate valves or sliding valves, i.e. cut-off apparatus with closing members having a sliding movement along the seat for opening and closing with flat sealing facesPackings therefor
F16K 27/04 - Construction of housingsUse of materials therefor of sliding valves
43.
VALVE SLEEVE APPARATUS FOR WIDE- OR OPEN- BODY KNIFE GATE VALVES
A valve sleeve (1) for a knife or gate valve is characterized in that it has an annular reinforcing member (8) located entirely within a proximal half of the body (30); an annular indentation (16, 22) that extends radially into the inner sleeve surface (32) and/or into the outer sleeve surface (33) in a region more adjacent the proximal surface (31) than the distal surface (34); and/or a radially outermost surface portion (5) proximal to the distal flange (4) that follows a taper angle (N) with respect to a central axis of the valve sleeve (1).
F16K 3/02 - Gate valves or sliding valves, i.e. cut-off apparatus with closing members having a sliding movement along the seat for opening and closing with flat sealing facesPackings therefor
F16K 27/04 - Construction of housingsUse of materials therefor of sliding valves
44.
SENSING APPARATUS FOR A CRUSHER AND METHODS THEREOF
A sensing apparatus configured for detecting, measuring, or monitoring operational or physical changes within a crusher The sensing apparatus being attachable to a first portion of a fastening mechanism of a crusher. The sensing apparatus comprising a second portion of a fastening mechanism. The sensing apparatus further comprising a sensor unit configured to detecting, measuring, or monitoring operational or physical changes occurring within the crusher in a field of view. The sensing apparatus is configured to substantially occlude an inspection port of the crusher. The sensing apparatus has at least two configurations including a deployed and retracted position.
B02C 2/04 - Crushing or disintegrating by gyratory or cone crushers eccentrically moved with vertical axis
B02C 4/32 - Adjusting, applying pressure to, or controlling the distance between, milling members
B02C 23/00 - Auxiliary methods or auxiliary devices or accessories specially adapted for crushing or disintegrating not provided for in groups or not specially adapted to apparatus covered by one only of groups
B02C 25/00 - Control arrangements specially adapted for crushing or disintegrating
G01B 11/00 - Measuring arrangements characterised by the use of optical techniques
G01N 29/00 - Investigating or analysing materials by the use of ultrasonic, sonic or infrasonic wavesVisualisation of the interior of objects by transmitting ultrasonic or sonic waves through the object
45.
SENSING APPARATUS FOR A CRUSHER AND METHODS THEREOF
The present invention relates to an eccentric roller crusher 10 with a crusher housing 60, a drive shaft 20, a roller 30 supported eccentrically and rotatably on the drive shaft 20, and a rocker 40, characterised in that between the drive shaft 20 and the roller 30 or between the roller 30 and the crusher housing 60, a retardation device is arranged.
The invention relates to novel pipe support bracket for supporting cooler pipes along the inner circumference of the rotary cooler. The cooler pipes mounted on to the inner periphery of the rotary cooler are secured to the outer wall of the cooler by means of newly designed pipe support bracket that allows for thermal expansion in lateral and liner directions thereby preventing the thermal stress on the support bracket.
Liners being parts of grinding and milling machines including SAG milling machines, AG milling machines, Rod milling machines, and Ball milling machines; liners being parts of crushing machines including cone crushing machines, jaw crushing machines, gyratory crushing machines, and impact crushing machines; liners being parts of vibrating feed mixing machines, belt feed mixing machines, apron feed mixing machines, and reciprocating feed mixing machines.
(1) Machine parts and replacement parts for mining machines, namely, mill liners, shell liners, head liners, head plates, grate discharge liners, crusher liners, feeder liners, wear liners, and wear plates; parts and fittings for mills, crushers, and feeders, namely, steel liners, rubber liners, and composite liners; liners for grinding mills including SAG mills, AG mills, Rod mills, and Ball mills; liners for crushers including cone crushers, jaw crushers, gyratory crushers, and impact crushers; liners for vibrating screens, vibrating feeders, belt feeders, apron feeders, and reciprocating feeders.
51.
METHOD OF SAMPLING AND ANALYZING PROPERTIES OF DISCHARGED FILTER CAKE AND APPARATUS THEREOF
A filter cake analyser (1) is disclosed. The analyser (1) may include a probe (7) configured to extend into a path of filter cake (6) (or other material) and convey a sample amount of filter cake (6) from a catch basin (9) to a probe discharge (11). A sample cup (17) of an indexable cup assembly (16) is filled with the sample amount of filter cake (6). A rotational actuator (22) supporting the cup assembly (16) indexes the cup assembly (16) between three cup assembly positions. A dryer (15) of the filter cake analyser (1) dries the contents of the sample cup (17), and a load cell (28) intermittently engages and disengages with the cup assembly (16) via an actuator (26) to obtain dry and wet mass measurement values to calculate moisture content of the sample amount of filter cake (6).
G01N 5/04 - Analysing materials by weighing, e.g. weighing small particles separated from a gas or liquid by removing a component, e.g. by evaporation, and weighing the remainder
41 - Education, entertainment, sporting and cultural services
Goods & Services
Training; training consultancy; training courses;
computerized training; education; workshops; training and
education services; seminars; online training and education
services; certification programs (term considered too vague
by the International Bureau pursuant to Rule 13 (2) (b) of
the Regulations).
Provided is a low-alloy steel having a chemical composition comprising, in terms of % by mass, 0.6 – 0.8 C, 0.4 – 0.6 Si, 0.8 – 1.3 Mn, 2.0 – 3.0 Cr, 0.45 – 0.20 Ni, 0.45 – 0.65 Mo, 0.001 – 0.045 Ti, 0.015 – 0.05 Ce, 0.0002 – 0.007 B, and at least one of the compounds, in terms of % by mass, selected from 0.10 – 0.45 V, 0.15 – 0.50 W, and/or 0.05 – 0.35 Nb, and the remainder being of iron (Fe) and inevitable impurities.
A separator device (100) includes a separation chamber (107) defined at its lower end by a fluidization fluid panel (111). The separation chamber (107) receives incoming slurry (113) via a slurry inlet (102). The separator device may be characterized in that means (122) for supplying pre-sheared aerated fluidization fluid is provided above the fluidization fluid panel (111). The means (122) for supplying pre-sheared aerated fluidization fluid includes a novel sparger (119) comprising a flexible perforated membrane which is configured to supplementally shear the pre-sheared aerated fluidization fluid and uniformly distribute microbubbles (129) throughout the separation chamber (107).
A flotation circuit (1) is characterised in that it comprises a sparger (8) having a sparging mix conduit or chamber (45); and a tube (31) comprising a flexible perforated membrane disposed within the sparging mix conduit or chamber (45). The tube (31) is configured to receive an aerated fluid (27) comprising a combination of sparger water (13), reagent (17), and sparger air or gas (21) therein, shear the aerated fluid (27) upon passing of the aerated fluid (27) through the flexible perforated membrane of the tube (31), and disperse sheared aerated fluid (27) into the sparging mix conduit or chamber (45) where it is combined with incoming feed slurry (2) or diluted incoming feed slurry (4) moving within the sparging mix conduit or chamber (45) to form reagentized aerated slurry (29) for feeding a flotation apparatus (30).
The invention relates to a method for regulating a main roller drive (24) and an auxiliary roller drive (26) of a roller pair (14) of a roller crusher (10). The method comprises specifying a target speed (32) for the roller pair (14) with a control (28) in normal mode, regulating the main roller drive (24) to the target speed (32), regulating the auxiliary roller drive (26) to the target speed (32), determining a speed difference (84) of the actual speeds (46, 48) of the two roller drives, switching to compensation mode in the event that the speed difference (84) is above a first difference threshold value (90), specifying a compensation target speed (108) and regulating the auxiliary roller drive (26) to the compensation target speed (108). The invention further relates to a control, a computer program product and a roller crusher system with a control.
A discharge grate (200) for an internal discharge end (3) of a mill (1) may be characterized in that it has at least one dynamic variable sieve opening (206) defined between two adjacent floating screen bars (202). The floating screen bars (202) may be configured to a least temporarily move with respect to one another and/or with respect to a holding frame (201) receiving the floating screen bars (202). Temporary expansion of the at least one dynamic variable sieve opening (206) may permit undersized media to pass to the discharge chute (8) and reduce or eliminate pegging.
B02C 17/18 - Disintegrating by tumbling mills, i.e. mills having a container charged with the material to be disintegrated with or without special disintegrating members such as pebbles or balls Details
The invention relates to a cone crusher (1) for comminuting lumpy feed material (material to be crushed), with a crushing cone (6) supported on an axial bearing, inclined to the axis of rotation (R) and driven by an eccentric bushing (12), wherein the eccentric bushing (12) rotates in radial guidance around a fixed axle journal (10). The invention is characterized in that a central axis (Z) of the crushing cone (6) is aligned skewed to the axis of rotation (R) of the eccentric bushing (12). The invention further relates to an eccentric bushing (12) and a method.
The disclosure relates to novel components of a gyratory crusher (1) which aim to promote self-alignment of a mainshaft assembly (2) upon introduction of the mainshaft assembly (2) into the gyratrory crusher (1) by lowering the mainshaft assembly (2) from above the gyratory crusher (1) into the gyratory crusher (1). The novel components may include a dust bonnet (9) having a plurality of guides (15), an end plate (32) having a lower alignment chamfer (36), and/or a counterweight (13) having an alignment chamfer (41). Each of the novel components may be configured to bias a lower mainshaft (26) of the mainshaft assembly (2) of the gyratory crusher (1) into concentric alignment with a bore (56) of the eccentric (11) or eccentric liner (12).
The invention relates to a pitot tube (1) of a shaft furnace (102) for conveying filling material, comprising an inlet (2), an outlet (4) and a sensor device (6) for detecting a filling level of the filling material in the pitot tube (1) The sensor device (6) comprises a first sensor unit (8) for non-contact detection of a filling level of the filling material in the pitot tube (1). According to the invention, the first sensor unit is set up to detect a distance between a surface (13) of the filling material and the first sensor unit (8). The invention further relates to methods for filling level monitoring in a pitot tube (1), a control system (200) and a shaft furnace installation.
A variable geometry infeed shelf (23) is configured to be installed within a tank pump (1) and provides supplemental internal rigid stationary fluid boundary surfaces within a cylindrical tank assembly (7) of the tank pump (1). The variable geometry infeed shelf (23) promotes uniform distribution of feeding flow around the entire volume of the tank, favouring retention time and reducing bypassing and local peak vertical velocities of a tank infeed flow path (45) in a vertical direction (Z1) within the tank assembly (7). By virtue of its design, the variable geometry infeed shelf (23) reduces stagnation zones, air entrainment and turbulence within the tank assembly (7), thereby improving pumping efficiency of a centrifugal pump (20) operating within the tank assembly (7).
The invention relates to a method for controlling a chemical clinker quality in a cement factory, said method comprises the steps of measuring a temperature in a calciner and preheating tower and kiln; measuring and recording flow rates of raw meal, primary fuel and alternative fuel in said preheating tower, calciner and kiln; utilizing said recorded flow rates of raw meal, primary fuel and alternative fuel to estimate an alternative fuel's calorific value; utilizing said calorific value of alternative fuel to estimate chemical characteristics of said alternative fuel's ash; calculating a new ratio between a raw meal feed and said primary and alternative fuel feeds such that a chemical clinker quality target is obtained while maintaining a calorie feed to said calciner and to said kiln.
The invention relates to a roller grate system (10) for screening and/or conveying bulk material, having a frame (11) extending in a longitudinal direction (v) and a plurality of segment shafts (12) arranged in the frame (11) for conveying the bulk material, each of which are rotatably mounted by at least two bearing blocks (13) and are spaced apart from one another transversely to their longitudinal axes (a) in such a way that a gap (s) is formed between two of the segment shafts (12). The roller grate system has at least one adjusting device (14) for variable gap adjustment.
Segment shaft (10) for a roller grate system with at least one base shaft (11), a plurality of transport disks (12) and a plurality of spacer elements (13), wherein the transport disks (12) and the spacer elements (13) are arranged in a rotationally fixed manner on the base shaft (11), whereby at least one of the spacer elements (13) is arranged between two adjacent transport disks (12), wherein the segment shaft (10) has at least one wear display device (14) which is at least partially arranged on and/or in the base shaft (11) and adapted thereto, to visually display at least one degree of wear of the segment shaft (10) and/or to output an electrical signal characterizing the degree of wear.
B07B 1/15 - Roller screens using corrugated, grooved or ribbed rollers
66.
DEVICE FOR CRUSHING ROCK, IN PARTICULAR GYRATORY CRUSHER, CONE CRUSHER, JAW CRUSHER OR ECCENTRIC ROLLER CRUSHER, AS WELL AS ASSEMBLY AND MAINTENANCE PROCEDURES
The invention relates to a device for crushing rock, in particular gyratory crusher (100), cone crusher, jaw crusher or eccentric roller crusher, with a crusher chamber (10) and a movable crushing actuator (12), wherein the crusher chamber (10) has an inner surface (11) which is lined with crushing plates (13), wherein sensors and/or optical position markers for automatically determining the position of the crushing plates (13) are arranged below the crushing plates (13) on the inner surface (11).
The invention relates to a device for crushing rock with a crusher housing (10) and a crushing cone (11) which is arranged in the crusher housing (10) and can be set into a wobbling rotational movement via an eccentric. It is characterized in that the crushing cone has a cone axis (12) which is mounted in an eccentric bearing (13) of the eccentric, wherein a dust seal is arranged between the eccentric and the crushing cone (11), and wherein within the crusher housing (10), in particular in the interior of a housing (14) of the dust seal, a plurality of monitoring devices are provided for monitoring the position of the cone axis (12) during assembly of the same in the crusher housing (10).
06 - Common metals and ores; objects made of metal
Goods & Services
Metallic liner plates and panels for protection against wear
for use in mining, mineral processing, cement production and
material handling equipment; metallic liner plates and
panels for protecting chutes and hoppers in mining industry;
metal panels; linings (metal) for use in construction;
panels of metal for sidewalls.
06 - Common metals and ores; objects made of metal
Goods & Services
Common metals and their alloys for use in mining, mineral
processing, cement production and material handling
equipment; building materials, namely composite panels
composed primarily of metal; castings of metal or metal
alloys; cladding panels of metal; linings (metal) for use in
construction; masts of metal; metal panels; metal mouldings;
metal cladding; metal brackets; metallic liner plate and
panels; panels of metal for sidewalls; wall tiles of metal;
wall platings of metal.
A wear liner assembly / system (1) may comprise a backing panel (2) having therein a plurality of apertures (3); a wear liner (6) comprising a threaded bore (6a); and a fastener (7) disposed in threaded engagement with the threaded bore (6a) of the wear liner (6). The fastener (7) may comprise a head (7c) having an undersurface (7d) at a first end (7a), and a torque transfer surface feature (7g, 7h) at a second end (7b) opposite the first end (7a). The plurality of apertures (3) are sized and configured to allow the head (7c) to pass therethrough. The undersurface (7d) of the head (7c) is configured to engage the backing panel (2) upon rotation of the fastener (7) in relation to the threaded bore (6a) of the wear liner (6) to secure the wear liner (6) to the backing panel (2).
The invention relates to a method for controlling a comminution plant 12. The plant can be designed for the secondary and tertiary crushing of rock with a plurality of circuits and control variables. The method is advantageous for process monitoring of the plant 12 in that the expert system 10 can recognize the most common error states based on the recorded, real operating data 18 in conjunction with the simulation 14. In this way, suitable indicators can be identified to warn an operator at an early stage.
A wear liner assembly (3) may be composed of a wear liner (4) and a 2D wear sensor (5). The wear liner (4) may be provided with a first distal end (10), a second distal end (11) opposite the first distal end (10), and a first recess (9) in at least the first distal end (10). The 2D wear sensor (5) may be disposed within the first recess (9). The 2D wear sensor (5) may comprise a core or body (6) (e.g., a printed circuit board (PCB)) containing a plurality of 1D wear sensors (7). Each of the 1D wear sensors (7) may be spaced from one another, and may, in some embodiments, be oriented to extend in substantially the same direction and/or within substantially the same plane.
The invention relates to a crushing jaw set (50) for a crusher (1), comprising a first crushing jaw unit (52) for a first working unit (8) and a second crushing jaw unit (54), wherein between the first and the second working unit (8, 4) a crushing chamber (9) is defined, wherein the first crushing jaw unit (52) comprises at least a first and second crushing jaw (61, 62), wherein the first and second crushing jaws (61, 62) are separated at a first jaw parting plane (BE1), which is aligned transversely to a material flow direction of the crusher (1) wherein at least the first crushing jaw (61) is formed from two or more first crushing jaw segments (72a-72h), each of which is separated at a segment parting plane (SE) which is perpendicular to the first (BE1). The invention further relates to a crusher (1) and a maintenance method.
The invention relates to a comminution device (2), in particular an eccentric roll crusher, for comminuting material to be comminuted, the comminution device (2) having a housing (4) with two opposite side walls (10), a crushing jaw (14) between the side walls (10), and a roll (20) arranged at least in sections between the side walls (10) for comminuting the material to be comminuted on the crushing jaw (14), wherein the roll (20) is rotatably mounted about an axis of rotation (22) in the side walls (10) by means of a bearing (24) of the roll (20), wherein the side walls (10) run transverse to the axis of rotation (22) and/or parallel to each other, and wherein at least one of the side walls (10) has or is formed from a stacked composite (26) of at least two plate elements (28)
A stackable wear panel (1) for use within a modular stackable wear-resistant panel system (11) is configured to be removably affixed to a wall (10A) or surface of equipment (10) to be protected. The stackable wear panel (1) is also configured to be alternatively removably affixed to a top surface (2A) of another stackable wear panel (1) within a stacked wear panel arrangement (1′, 1″). The stackable wear panel (1) is formed by a matrix (2) having a top surface (2A), a bottom surface (2B) opposite said top surface (2) and a central bore (4) extending through the top (2A) and bottom (2B) surfaces. The central bore (4) is configured to receive either one of a fastener (5) or a spacing adapter (6) therein, and/or support a portion (5A, 5B) of the fastener (5) or a lower outer surface portion (6E) of the spacing adapter (6).
B32B 3/24 - Layered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a discontinuous layer, i.e. apertured or formed of separate pieces of material characterised by an apertured layer, e.g. of expanded metal
B02C 13/282 - Shape or inner surface of mill-housings
B32B 3/26 - Layered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a particular shape of the outline of the cross-section of a continuous layerLayered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a layer with cavities or internal voids
B32B 3/30 - Layered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a particular shape of the outline of the cross-section of a continuous layerLayered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a layer with cavities or internal voids characterised by a layer formed with recesses or projections, e.g. grooved, ribbed
B32B 7/08 - Interconnection of layers by mechanical means
78.
CORNER BLOCK SEGMENT FOR A ROLL OF A COMMINUTION DEVICE
The present invention relates to method and apparatus for recycling composite mill liners. This invention is preferably concerned with an optimized method of recycling worn out composite mill liners by effectively disassembling the composite into metal and rubber parts that can be reused, as well as a mobile apparatus for carrying out the method.
The invention relates to an anti-shooting device for deaccelerating of fluidized material, said anti-shooting device comprising a frame; a plurality of elongated attachment element extending lateral across said frame; restriction means attached to said attachment elements and extending vertical oriented to flow direction substantially transvers to the direction of said attachment element, and a reverse flow preventer arranged such that fluidized material can flow through said attachment elements and said restrictions means; said anti-shooting device arranged such that fluidized material is directed in a direction substantially transvers to said attachment element, said restriction means arranged such that when said fluidized material engages with said restriction means said material is deaccelerated.
The invention relates to a corner block segment (2) for attachment to a cylindrical roll body (104) of a roll (102) of a comminution device (100), the corner block segment (2) having a base body (4), a segment outer side (8), a segment end face (12), a corner region (10) between the segment outer side (8) and the segment end face (12) to form a roll edge (110) of the roll (102), and a receiving side (14),wherein the receiving side (14) corresponds to a segment receptacle (106) of the roll body (104) and is arranged facing away from the corner region (10), wherein the segment outer side (8) is curved and is arranged facing away from an imaginary reference axis (16), and wherein in the longitudinal section through the reference axis (16), the corner region (10) has a radius (18) of at least 5 mm.
An activation system (1, 101, 201) and a method of activating a solid Supplementary Cementitious Material (SCM) precursor is provided.. The activation system (1, 101, 201) comprising a first subsystem (2, 102, 202) comprising and inlet (21,121), electric heating means (23, 123, 223), an activation vessel (22,122), a fluid outlet (26, 126, 226), and a separation means (24, 124) configured to separate an activated solid SCM material from a fluid. The first subsystem (2, 102, 202) further comprising means to provide the activated solid SCM material to a second subsystem (3, 103, 203). The second subsystem (3, 103, 203) comprising cooling means (31a, 31b, 31c, 131a, 131b, 131c).
The invention relates to a processing plant (1) for comminution of ROM material (6) to a particle size of <1mm, comprising a primary loading unit (10) for loading ROM material (6); a crusher (12) as a primary stage (2) for comminuting the ROM material (6) to a mill particle size (14) suitable for being fed to a mill (16); a mill (16) as a secondary stage (4) for comminuting the material (14) with mill particle size to a ground particle size of <1mm; and a conveyor device (18) which connects the crusher (12) on the output side to the mill (16) on the input side for feeding the material (14) crushed to the mill particle size to the mill (16), and a withdrawal unit (39) used to withdraw ground material (8) from the mill (16). The invention also relates to a method for comminution of ROM material (6).
A crusher (1) having a wear sensing system (9) and one or more unique liner assemblies (6) within a wear surface (3) is disclosed. A liner segment (7) may be configured to receive a wear sensor (8). The wear sensing system has a receiver (4) equipped with an antenna (4a) and an antenna (8b) (preferably a directional antenna) provided to the wear sensor (8). The wear sensing system (9) is configured to communicate directional signals (5) between the wear sensor (8) and the receiver (4) such that there is no radio interference with components of the crusher (1), such as a spider (2) or portions of liner segments (7) defining a wear surface (3) of the crusher (1). In preferred embodiments, the antenna (8b) is situated in a gap between adjacent liner segments (7).
06 - Common metals and ores; objects made of metal
Goods & Services
Common metals and their alloys for use in mining, mineral processing, cement production and material handling equipment; building materials, namely composite panels composed primarily of metal; castings of metal or metal alloys; cladding panels of metal; metal linings for use in building construction; masts of metal; metal panels for protection against wear for use in mining, mineral processing, cement production and material handling equipment; metal cladding for construction and building; metal brackets for building; metallic liner plate and panels for protection against wear for use in mining, mineral processing, cement production and material handling equipment; panels of metal for sidewalls; wall tiles of metal; wall platings of metal
06 - Common metals and ores; objects made of metal
Goods & Services
(1) Metallic liner plates and panels for protection against wear for use in mining, mineral processing, cement production and material handling equipment; metallic liner plates and panels for protecting chutes and hoppers in mining industry; metal panels; linings (metal) for use in construction; panels of metal for sidewalls.
06 - Common metals and ores; objects made of metal
Goods & Services
Metallic liner plates and panels for protection against wear for use in mining, mineral processing, cement production and material handling equipment; metallic liner plates and panels for protecting chutes and hoppers in mining industry; metal linings for use in building construction; panels of metal for sidewalls.
The invention relates to a roll crusher (1) with a machine frame (2), with a rotatable roll (4), with a rocker (8) mounted on a rocker axle (6) on the machine frame (2), with a crushing chamber (9) between roll (4) and rocker (8), wherein an adjustable crushing gap (BS) between roll (4) and rocker (8) is formed at a lower end of the crushing chamber. The roll (4) is loosely mounted on the machine frame (2). The roll crusher (1) has a roll adjustment device (30) for adjusting the roll (4) perpendicular to its axis of rotation (5) in the direction of the rocker (8) for adjusting the crushing gap (BS). The invention also relates to a method.
B02C 1/08 - Jaw crushers or pulverisers with jaws coacting with a rotating roller
B02C 4/12 - Crushing or disintegrating by roller mills with a roller co-operating with a stationary member in the form of a plate
B02C 4/34 - Adjusting, applying pressure to, or controlling the distance between, milling members in mills wherein a roller co-operates with a stationary member
B02C 1/08 - Jaw crushers or pulverisers with jaws coacting with a rotating roller
B02C 4/12 - Crushing or disintegrating by roller mills with a roller co-operating with a stationary member in the form of a plate
B02C 4/34 - Adjusting, applying pressure to, or controlling the distance between, milling members in mills wherein a roller co-operates with a stationary member
The invention relates to a method for incineration of combustible waste during the manufacture of cement clinker. The waste is incinerated in a separate compartment, the exhaust gases produced during the waste incineration process being vented to the preheater for heating the cement raw meal, the waste is introduced via a waste inlet onto a supporting surface incorporated in the compartment and in that, during incineration, the waste is transported through the compartment to the outlet of the compartment along a circular path, characterized in that the compartment is arranged at a distance from said calciner or a preheater tower by means of a material chute, said material chute enters a downward sloping duct, said duct carries exit gas from said compartment and non-combustible material from waste fuel firing in said compartment down into the calciner or preheater tower.
F23G 5/26 - Methods or apparatus, e.g. incinerators, specially adapted for combustion of waste or low-grade fuels with combustion in a vertical, substantially cylindrical, combustion chamber having rotating bottom
F23G 5/28 - Methods or apparatus, e.g. incinerators, specially adapted for combustion of waste or low-grade fuels with combustion in a vertical, substantially cylindrical, combustion chamber having raking arms
The invention relates to a comminution device (2) for comminuting material to be comminuted, having - a crusher housing (6), - a comminution tool (8) with an eccentrically movably mounted cone (10) and with an outer crusher tool (9) surrounding the cone (10), - an input shaft (28) for driving a bevel pinion (22), - a bevel pinion (22) for driving a bevel gear (20), - a bevel gear (20) operatively connected to the comminution tool (8), - a countershaft (24) with the bevel pinion (22) which can be driven via the input shaft (28), and - an opening (4) for passing through an endoscopic camera (50), wherein the opening (4) extends from external surroundings (A) on the countershaft (24) along and/or through the countershaft (24) to a bevel gear toothing (21) of the bevel gear (20) and/or a bevel pinion toothing (23) of the bevel pinion (22).
B02C 2/04 - Crushing or disintegrating by gyratory or cone crushers eccentrically moved with vertical axis
B02C 23/00 - Auxiliary methods or auxiliary devices or accessories specially adapted for crushing or disintegrating not provided for in groups or not specially adapted to apparatus covered by one only of groups
94.
METHOD AND PLANT FOR MANUFACTURING A CEMENTITOUS MATERIAL
222 gas and a decarbonized material. A portion of the decarbonized material is provided to the carbonizing device and another portion is provided to the further device. The material is further sintered and cooled to provide a cementitious material.
222 gas and a decarbonized material. A portion of the decarbonized material is provided to the carbonizing device and another portion is provided to the further device. The material is further sintered and cooled to provide a cementitious material.
41 - Education, entertainment, sporting and cultural services
Goods & Services
Training services in the field of mining technology, mining machinery, mining operations, safety protocols, machinery operations, machinery maintenances and machinery process; business training consultancy services in the mining technology; arranging and conducting of training courses in the field of mining technology, mining machinery, mining operations, safety protocols, machinery operations, machinery maintenances and machinery process; computerized training services in the field of mining technology, mining machinery, mining operations, safety protocols, machinery operations, machinery maintenances and machinery process; training and educational services, namely, arranging, conducting, providing classes, seminars, and workshops in the fields of mining technology, mining machinery, mining operations, safety protocols, machinery operations, machinery maintenances and machinery process; online training and educational services, namely, providing webinars, online courses, and virtual workshops in the fields of mining technology, mining machinery, mining operations, safety protocols, machinery operations, machinery maintenances and machinery process; providing training for certification in the field of mining technology, mining machinery, mining operations, safety protocols, machinery operations, machinery maintenances and machinery process.
A self-aspirated froth flotation cell 100 may include a slurry vortex stabilizer 166 having an annular body 234 with an upper annular edge 176 and an aperture 180 extending through a central region of the annular body 234. The aperture 180 may have an inner surface 182 bounded between an upper inner edge 178 and a lower inner edge 200 that is configured to allow the drive shaft 142 to rotate freely therein in close proximity to the inner surface 182. The slurry vortex stabilizer 166 may have an annular undersurface 210 configured with a inner first portion 212, a second portion 236 provided around the first portion 212, and an annular intersection, transition, or inflection 214 therebetween. A sloped upper surface 242 which tapers downwardly towards the central region of the annular body 234 as it approaches the aperture 180 forms a lower fluid surface boundary within a standpipe 152 of the self-aspirated froth flotation cell 100.
The invention relates to a method for monitoring a color of a processed material, such as a cementitious material, the method comprising the steps of passing at least a part of said processed material through a measuring zone within an electrical and/or magnetic field; introducing an effect to said electrical and/or magnetic field, said effect that can be measured depending on the nature of said processed material passing through said measuring zone and measuring a change in the effect caused by said processed material passing through said measuring zone.
A froth transport system (100) and de-aeration apparatus (200) is disclosed. Each comprise a first holding tank or sump (201) and a froth pump (203) for transporting aerated slurry from the sump 201 to one or more hydrocyclones (204). Overflow of the one or more hydrocyclones (204) containing fines and gas (114) may be recycled to the first holding tank or sump (201), or back to an inlet manifold (206) feeding the one or more hydrocyclones (204). The froth transport system (100) and/or de- aeration apparatus (200) may comprise a second holding tank or sump (202). De- aerated slurry (106) may be transferred from the second holding tank or sump (202) to one or more centrifugal pumps (107) to move the same to a downstream process step (108).
A rail conveyor system may include carriages with multiple cradles that are configured to support a carry belt. The carriages may be supported by and may travel along guide rails that extend along a longitudinal path. The guide rails may be supported by discrete frame modules that are longitudinally spaced apart. The frame modules may include at least slidable frame modules that are slidably attached to footings and expansion frame modules that include expansion gaps that permit the guide rails to thermally expand and contract longitudinally. The carriage may also include an anti-derailment device that greatly minimizes the risk of derailment.
B65G 15/08 - Conveyors having endless load-conveying surfaces, i.e. belts and like continuous members, to which tractive effort is transmitted by means other than endless driving elements of similar configuration the load-carrying surface being formed by a concave or tubular belt, e.g. a belt forming a trough
B65G 17/02 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriersEndless-chain conveyors in which the chains form the load-carrying surface comprising a load-carrying belt attached to, or resting on, the traction element
B65G 21/22 - Rails or the like engaging sliding elements or rollers attached to load-carriers or traction elements
B65G 39/20 - Arrangements of rollers attached to moving belts or chains
