A cushioning part for cushioning an article to be packaged in an outer packaging has a mat-shaped base layer, from which at least one hollow support body protrudes above a base cross section cutout on the top side. In order to improve the damping of the article to be packaged by the cushioning part, the invention proposes that the support body is designed in the form of an arcuate bridge which spans the base cross section cut out of the support body.
B65D 81/02 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents specially adapted to protect contents from mechanical damage
A cushioning part for cushioning an article to be packaged in an outer packaging has a mat-shaped base layer, from which at least one hollow support body protrudes above a base cross section cutout on the top side. In order to improve the damping of the article to be packaged by the cushioning part, the invention proposes that the support body is designed in the form of an arcuate bridge which spans the base cross section cut out of the support body.
A package cushioning for padding an article to be packaged in an outer box includes a base body in the form of a downwardly open half tube. On the outside thereof are attached opposing hump-shaped support members, which protrude beyond the half-tube on the upper side of the base body. Opposing surfaces of the support members and their transitions each form an upwardly open channel section on the package cushioning. The entire package cushioning is made in one piece with an average wall thickness W from a waste paper fiber material. A low point on the inside of the upwardly open channel section is spaced by the distance from the high point on the inside of the downwardly open half tube, the distance being greater than the simple wall thickness.
B65D 81/05 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents specially adapted to protect contents from mechanical damage maintaining contents at spaced relation from package walls, or from other contents
A package cushioning for padding an article to be packaged in an outer box includes a base body in the fomi of a downwardly open half tube. On the outside thereof are attached opposing hump-shaped support members, which protrude beyond the half-tube on the upper side of the base body. Opposing surfaces of the support members and their transitions each fomi an upwardly open channel section on the package cushioning. The entire package cushioning is made in one piece with an average wall thickness W from a waste paper fiber material. A low point on the inside of the upwardly open channel section is spaced by the distance from the high point on the inside of the downwardly open half tube, the distance being greater than the simple wall thickness.
B65D 81/02 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents specially adapted to protect contents from mechanical damage
A packaging part (1) for securing an item to be packaged in an outer packaging, has at least one supporting body (2, 16) that acts as a decoupling element. The supporting body is formed as a hollow body and projects from a bearing base. The supporting body (2, 16) has a base with a relatively large cross-section in the area of the bearing base and tapers in a direction away from the bearing base. The supporting body (2, 16) further has in its shell surface at least one line of weakness (14) that divides the supporting body into an upper part and a lower part. The upper part of the supporting body (2, 16) can be pressed along the line of weakness (14), preferably completely, into the lower part under load.
B65D 81/05 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents specially adapted to protect contents from mechanical damage maintaining contents at spaced relation from package walls, or from other contents
14.
Packaging part for securing an item to be packed in an outer packaging
A packaging part (1) for securing an item to be packaged in an outer packaging, has at least one supporting body (2, 16) that acts as a decoupling element. The supporting body is formed as a hollow body and projects from a bearing base. The supporting body (2, 16) has a base with a relatively large cross-section in the area of the bearing base and tapers in a direction away from the bearing base. The supporting body (2, 16) further has in its shell surface at least one line of weakness (14) that divides the supporting body into an upper part and a lower part. The upper part of the supporting body (2, 16) can be pressed along the line of weakness (14), preferably completely, into the lower part under load.
B65D 81/05 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents specially adapted to protect contents from mechanical damage maintaining contents at spaced relation from package walls, or from other contents
15.
PACKAGING PART FOR SECURING AN ITEM TO BE PACKAGED IN AN OUTER PACKAGE
MIP ref NIX-035 ABSTRACT A packaging part for securing an item to be packaged in an outer packaging, has at least one supporting body that acts as a decoupling element. The supporting body is formed as a hollow body and projects from a bearing base. The supporting body has a base with a relatively large cross-section in the area of the bearing base and tapers in a direction away from the bearing base. The supporting body further has in its shell surface at least one line of weakness that divides the supporting body into an upper part and a lower part. The upper part of the supporting body can be pressed along the line of weakness, preferably completely, into the lower part under load. Date Recue/Date Received 2021-01-12
B65D 67/00 - Kinds or types of packaging elements not otherwise provided for
B65D 81/107 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents specially adapted to protect contents from mechanical damage maintaining contents at spaced relation from package walls, or from other contents using blocks of shock-absorbing material
B65D 81/127 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents specially adapted to protect contents from mechanical damage maintaining contents at spaced relation from package walls, or from other contents using rigid or semi-rigid sheets of shock-absorbing material
16.
Packaging for an article and method of packaging an article
A packaging for an object and a method of packaging the object are disclosed The packaging comprises a sealable outer box and at least one padded part for insertion into the interior of the outer box. The padded part comprises shaped cushioning parts on its periphery for supporting the padded part on the inside against the side walls of the outer box so as to be secured against displacement. The padded part also includes a recess for the precisely fitting accommodation of the packaged object. Finally, the packaging in accordance with the invention comprises a support insert that, together with the padded part, defines a packaging space for the packaged object within the outer box, wherein the support insert extends at a distance from the side walls of the outer box and forms at least part of a side wall of the packaging space.
B65D 81/113 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents specially adapted to protect contents from mechanical damage maintaining contents at spaced relation from package walls, or from other contents using blocks of shock-absorbing material of a shape specially adapted to accommodate contents
B65D 5/50 - Internal supporting or protecting elements for contents
B65D 81/05 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents specially adapted to protect contents from mechanical damage maintaining contents at spaced relation from package walls, or from other contents
17.
PACKAGING FOR AN ARTICLE AND METHOD FOR PACKAGING AN ARTICLE
A packaging for an object and a method of packaging the object are disclosed The packaging comprises a sealable outer box and at least one padded part for insertion into the interior of the outer box. The padded part comprises shaped cushioning parts on its periphery for supporting the padded part on the inside against the side walls of the outer box so as to be secured against displacement. The padded part also includes a recess for the precisely fitting accommodation of the packaged object. Finally, the packaging in accordance with the invention comprises a support insert that, together with the padded part, defines a packaging space for the packaged object within the outer box, wherein the support insert extends at a distance from the side walls of the outer box and forms at least part of a side wall of the packaging space.
B65B 5/00 - Packaging individual articles in containers or receptacles, e.g. bags, sacks, boxes, cartons, cans, jars
B65B 23/00 - Packaging fragile or shock-sensitive articles other than bottlesUnpacking eggs
B65D 81/05 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents specially adapted to protect contents from mechanical damage maintaining contents at spaced relation from package walls, or from other contents
