Abstract

A thermal exchange pack (10) for a cooling tower includes a plurality of reticular panels (1), each panel defining a longitudinal plane (1a) and a sagittal plane (1b) normal to the longitudinal plane (1a), crossing at a main axis (1c), and extending on the longitudinal plane (1a) in a corrugated way, making fins (2) recurrent along the main axis (1c), arranged in two rows (1′) symmetrical in respect of said sagittal plane (1b), extending along corresponding secondary axes (2a) transversal to the main axis (1c) and mutually parallel, each including at least a top crest (20) more spaced from the longitudinal plane (1a) in respect of the remnant fin (2), wherein the panels (1) are mutually stacked in the pack (10), so that each longitudinal plane (1a) is spaced from an adjacent longitudinal plane (1a) through the fins (2), and wherein the pack (10) is so configured, that in operation each longitudinal plane (1a) is parallel to a bottom of a water collection basin of a cooling tower.

IPC Classes  ?

• F28D 20/00 - Heat storage plants or apparatus in generalRegenerative heat-exchange apparatus not covered by groups or

Abstract

A reticular panel (1) for a cooling tower defining a longitudinal plane (1a) and a sagittal plane (1b) normal to the longitudinal plane (1a), crossing in a main axis (1c) and developed on the longitudinal plane (1a) in a corrugated mode, making fins (2) recurrent along the main axis (1c), arranged in two rows (1′) symmetrical to said sagittal plane (1b), extending along corresponding secondary axes (2a) transversal to the main axis (1c) and mutually parallel, each row including at least a top crest (20) more spaced from the longitudinal plane (1a) in respect of the rest of the fin (2), wherein each fin (2) includes at least a blade (23) extending parallel to the secondary axis (2a) configured to increase the surface of thermal exchange of the panel (1).

IPC Classes  ?

• F28F 25/08 - Splashing boards or grids, e.g. for converting liquid sprays into liquid filmsElements or beds for increasing the area of the contact surface

Abstract

A reticular panel (1) for a cooling tower is disclosed, defining a longitudinal plane (1a) and a sagittal plane (1b), normal to the longitudinal plane (1a), crossing in a main axis (1c), first end edges (3) extending parallel to the main axis (1c) on opposite sides of panel (1) in respect of the sagittal plane (1b), second central edges (4) extending parallel to the main axis (1c) adjacent to the sagittal plane (1b) on opposite sides of panel (1) in respect of the sagittal plane (1b), wherein the panel extends on the longitudinal plane (1a) in a corrugated way, so as to make fins (2) recurrent along the main axis (1c), arranged in two rows (1′) symmetrical to said sagittal plane (1b), extending along corresponding secondary axes (2a), transversal to the main axis (1c) and mutually parallel, each fin comprising at least a top crest (20) more spaced from the longitudinal plane (1a) when compared with the remnant part of fin (2), and each defining a first end (21) at the first edge (3) and a second end (22) at the second edge (4), wherein each fin (2) comprises a protuberance (5) protruding transversally to the longitudinal plane (1a) starting form the crest (20) at least at each end (21, 22).

IPC Classes  ?

• F28F 25/08 - Splashing boards or grids, e.g. for converting liquid sprays into liquid filmsElements or beds for increasing the area of the contact surface

Abstract

A reticular panel (1) for a cooling tower is disclosed, defining a longitudinal plane (1a)and a sagittal plane (1b), normal to the longitudinal plane (1a), crossing in a main axis5(1c), first end edges (3) extending parallel to the main axis (1c) on opposite sides ofpanel (1) in respect of the sagittal plane (1b), second central edges (4) extendingparallel to the main axis (1c) adjacent to the sagittal plane (1b) on opposite sides ofpanel (1) in respect of the sagittal plane (1b), wherein the panel extends on thelongitudinal plane (1a) in a corrugated way, so as to make fins (2) recurrent along the10main axis (1c), arranged in two rows (1') symmetrical to said sagittal plane (1b),extending along corresponding secondary axes (2a), transversal to the main axis (1c)and mutually parallel, each fin comprising at least a top crest (20) more spaced fromthe longitudinal plane (1a) when compared with the remnant part of fin (2), and eachdefining a first end (21) at the first edge (3) and a second end (22) at the second edge15(4), wherein each fin (2) comprises a protuberance (5) protruding transversally to thelongitudinal plane (1a) starting form the crest (20) at least at each end (21, 22).

IPC Classes  ?

• F28F 25/08 - Splashing boards or grids, e.g. for converting liquid sprays into liquid filmsElements or beds for increasing the area of the contact surface
• B01J 19/32 - Packing elements in the form of grids or built-up elements for forming a unit or module inside the apparatus for mass or heat transfer
• D03D 13/00 - Woven fabrics characterised by the special disposition of the warp or weft threads, e.g. with curved weft threads, with discontinuous warp threads, with diagonal warp or weft

Abstract

A reticular panel (1) for a cooling tower is disclosed, defining a longitudinal plane (1a) and a sagittal plane (1b) normal to the longitudinal plane (1a), crossing in a main axis (1c) and developed on the longitudinal plane (1a) in a corrugated mode, making fins (2) recurrent along the main axis (1c), arranged in two rows (1') symmetrical to said sagittal plane (1b), extending along corresponding secondary axes (2a) transversal to the main axis (1c) and mutually parallel, each row comprising at least a top crest (20) more spaced from the longitudinal plane (1a) in respect of the rest of the fin (2), wherein each 10 fin (2) comprises at least a blade (23) extending parallel to the secondary axis (2a) configured to increase the surface of thermal exchange of the panel (1).

IPC Classes  ?

• F28F 25/08 - Splashing boards or grids, e.g. for converting liquid sprays into liquid filmsElements or beds for increasing the area of the contact surface
• B01J 19/32 - Packing elements in the form of grids or built-up elements for forming a unit or module inside the apparatus for mass or heat transfer
• D03D 13/00 - Woven fabrics characterised by the special disposition of the warp or weft threads, e.g. with curved weft threads, with discontinuous warp threads, with diagonal warp or weft

Abstract

A thermal exchange pack (10) for a cooling tower is disclosed, comprising a plurality of reticular panels (1), each panel defining a longitudinal plane (1a) and a sagittal plane (1b) normal to the longitudinal plane (1a), crossing at a main axis (1c), and extending on the longitudinal plane (1a) in a corrugated way, making fins (2) recurrent along the main axis (1c), arranged in two rows (1') symmetrical inn respect of said sagittal plane(1b), extending along corresponding secondary axes (2a) transversal to the main axis(1c) and mutually parallel, each comprising at least a top crest (20) more spaced from the longitudinal plane (1a) in respect of the remnant fin (2), wherein the panels (1) are mutually stacked in the pack (10), so that each longitudinal plane (1a) is spaced from an adjacent longitudinal plane (1a) through the fins (2), and wherein the pack (10) is so configured, that in operation each longitudinal plane (1a) is parallel to a bottom of a water collection basin of a cooling tower.

IPC Classes  ?

• F28F 25/08 - Splashing boards or grids, e.g. for converting liquid sprays into liquid filmsElements or beds for increasing the area of the contact surface
• B01J 19/32 - Packing elements in the form of grids or built-up elements for forming a unit or module inside the apparatus for mass or heat transfer
• D03D 13/00 - Woven fabrics characterised by the special disposition of the warp or weft threads, e.g. with curved weft threads, with discontinuous warp threads, with diagonal warp or weft
