A hard-sided insulated container that has a rigid molded body. It has a latching and seal mechanism. The container assembly has an external wrap that extends around a portion of the girth of the container assembly. The external wrap is insulated. The external wrap provides amounting datum for auxiliary features. The wrap is mounted to the molded container by non-invasive means. That is, the mounting of the wrap is done without puncturing or creating a penetration through the molded plastic body of the container. In one version the latch anchor posts provide mounting points. In another version there are molded corner posts, with a diagonal mounting passageway at the comers to receive suspender loops of the wrap. The wrap may have a deviated form to accommodate such a feature as a drain.
B65D 6/00 - Containers having bodies formed by interconnecting or uniting two or more rigid, or substantially rigid, components made wholly or mainly of metal, plastics, wood or substitutes therefor
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
F25D 3/08 - Movable containers portable, i.e. adapted to be carried personally
A soft sided insulated container assembly includes a first portion having an insulated, soft sided external wall structure, and a substantially rigid molded plastic frame that defines the opening of a receptacle of the soft-sided insulated main body of the container. The frame is removable from the main body. It has a rigid cover structure that includes a reinforcement member for engaging a land region of the molded frame, thereby tending to yield an interface tending to have a sealing relationship. The container is foldable, and has stiffening panels in the front and rear walls to facilitate folding.
B65D 33/02 - Local reinforcements or stiffening inserts, e.g. wires, strings, strips or frames
B65D 43/16 - Non-removable lids or covers hinged for upward or downward movement
B65D 51/18 - Arrangements of closures with protective outer cap-like covers or of two or more co-operating closures
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft sided insulated container assembly includes a first portion having an insulated, soft sided external wall structure, and a substantially rigid molded plastic frame that defines the opening of a receptacle of the soft-sided insulated main body of the container. The frame is removable from the main body. It has a rigid cover structure that includes a reinforcement member for engaging a land region of the molded frame, thereby tending to yield an interface tending to have a sealing relationship. The container is foldable, and has stiffening panels in the front and rear walls to facilitate folding.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
B65D 33/02 - Local reinforcements or stiffening inserts, e.g. wires, strings, strips or frames
B65D 33/10 - Handles formed of similar material to that used for the bag
B65D 43/16 - Non-removable lids or covers hinged for upward or downward movement
A soft sided insulated container assembly includes a first portion having an insulated, soft sided external wall structure, and a substantially rigid molded plastic frame that defines the opening of a receptacle of the soft-sided insulated main body of the container. The frame is removable from the main body. It has a rigid cover structure that includes a reinforcement member for engaging a land region of the molded frame, thereby tending to yield an interface tending to have a sealing relationship. There may be an intermediate third member, whether a rigid liner or a flexible liner having a rigid ring frame. The third member is capture between the lid and body of the container when closed. Where a ring frame is used, the container remains foldable, and has stiffening panels in the front and rear walls to facilitate folding.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft-sided insulated container that has a rigid closure. The rigid closure has a first closure interface that is a passive friction fit in which one part wipes another. The rigid closure has a second closure interface that is an active closure in which a mechanical device, such as a latch or clamp, is used positively to energize a closure between different parts of the closure. The container has a vent. The latch operates to close the vent. The soft-sided insulated container has a soft-sided external casing, and a rigid internal liner that includes a mating rigid lid. There is a releasable securement that holds the liner in engagement with the casing, but that can be released to permit the casing to be extracted from the liner. The releasable securement is a one-way passively engageable securement.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A hard-sided insulated container that has a rigid molded body. It has a latching and seal mechanism. The container assembly has an external wrap that extends around a portion of the girth of the container assembly. The external wrap is insulated. The external wrap provides a mounting datum for auxiliary features. The wrap is mounted to the molded container by non-invasive means. That is, the mounting of the wrap is done without puncturing or creating a penetration through the molded plastic body of the container. In one version the latch anchor posts provide mounting points. In another version there are molded corner posts, with a diagonal mounting passageway at the corners to receive suspender loops of the wrap. The wrap may have a deviated form to accommodate such a feature as a drain.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A container assembly has a soft-sided insulated wall structure. It has an internal chamber in which to place objects, such as foodstuffs, to be kept cool or warm. There is a first closure member that opens and closes to permit objects to be place in, or removed from, the chamber. The wall structure includes one or more accommodations in which to place a warming or cooling element, such as an ice pack. The accommodations are externally accessible without opening the main chamber, and have their own closure. The outside of the accommodation may be insulated; the inside is a thin web through which to transfer heat. The container may be a collapsible foldable bag; a tote bag; back pack or a non-collapsible lunch box. The thermal storage elements may have a flat disk shape. The external access for the thermal storage elements permits them to slide sideways into place.
A cooler insert partition is provided for a container having a hard-walled internal chamber surface. The partition has a spanning matrix and a peripherally extensive margin that defines a dimensionally variable boundary that follows the tapered chamber wall, functions as a wiper, and is deformable in at least one of (a) in-plane compression; and (b) out-of-plane deflection. The margin forms an edge of the spanning matrix. The partition is insulated, and is softer and more flexible than the hard-walled chamber surface. The periphery is thinner in cross-section than the spanning matrix and has a smaller specific flexural modulus. The partition has articulated panel sections. The partition is made from a single polymeric monolith that has been cut and formed. In use the partition is progressively re-positioned in the chamber to minimize dead air space as container contents are removed.
B65D 25/06 - Partitions adapted to be fitted in two or more alternative positions
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A cooler insert partition is provided for a container having a hard-walled internal chamber surface. The partition has a spanning matrix and a peripherally extensive margin that defines a dimensionally variable boundary that follows the tapered chamber wall, functions as a wiper, and is deformable in at least one of (a) in-plane compression; and (b) out-of-plane deflection. The margin forms an edge of the spanning matrix. The partition is insulated, and is softer and more flexible than the hard-walled chamber surface. The periphery is thinner in cross-section than the spanning matrix and has a smaller specific flexural modulus. The partition has articulated panel sections. The partition is made from a single polymeric monolith that has been cut and formed. In use the partition is progressively re-positioned in the chamber to minimize dead air space as container contents are removed.
A soft-side silo container is sized to fit inside larger luggage such as a suitcase. It has a vertical zipper with doubled zipper cars to permit several different opening configurations. It also has a suspension system, namely its hook from which the container's collapsible upstanding peripheral wall is suspended that permits the container to be hung from a hanger rod, or from another container of the same type. The peripheral wall breathes, and is foldable to fit inside a suitcase. It has sub-compartment dividers that function as shelves. It can be used in conjunction with hard sided carry-on luggage or general luggage. Alternatively, it can be used in conjunction with a cascade of soft-sided hanging shelves.
A soft-sided silo container is sized to fit inside larger luggage such as a suitcase. It has a vertical zipper with doubled zipper cars to permit several different opening configurations. It also has a suspension system, namely its hook from which the container's collapsible upstanding peripheral wall is suspended that permits the container to be hung from a hanger rod, or from another container of the same type. The peripheral wall breathes, and is foldable to fit inside a suitcase. It has sub-compartment dividers that function as shelves. It can be used in conjunction with hard sided carry-on luggage or general luggage. Alternatively, it can be used in conjunction with a cascade of soft-sided hanging shelves.
A container assembly has a cup-shaped container, a lid body, a spout, a spout cover, and a spout cover securement, or lock. The lid body has a depending periphery that releasably mounts to the cup-shaped container. The lid body has a matrix extending within the periphery. The spout seat is located eccentrically and inwardly of the periphery. It has a root and a tip. The spout cover is movably mounted to the spout cover seat. When closed, the spout cover seals the spout. The lock moves between a first position and a second positon. In the first position the lock keeps the spout cover sealed to the tip. In the second position the spout cover securement permits motion of said spout cover to open. The lid is stackable on other lids. The container assembly cup comes in several forms, the different forms being mutually stacking.
B65D 47/08 - Closures with discharging devices other than pumps with pouring spouts or tubesClosures with discharging devices other than pumps with discharge nozzles or passages having articulated or hinged closures
13.
Soft-sided insulated container with hard-sided liner
A soft-sided insulated container that has a rigid closure. The rigid closure has a first closure interface that is a passive friction fit in which one part wipes another. The rigid closure has a second closure interface that is an active closure in which a mechanical device, such as a latch or clamp, is used positively to energize a closure between different parts of the closure. The container has a vent. The latch operates to close the vent. The soft-sided insulated container has a soft-sided external casing, and a rigid internal liner that includes a mating rigid lid. There is a releasable securement that holds the liner in engagement with the casing, but that can be released to permit the casing to be extracted from the liner. The releasable securement is a one-way passively engageable securement.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A cooler has a body and a lid that co-operate. The lid is movable between closed and open positions. The lid is a freezable reservoir. A filler port is located inside the lid. The entrance of the filler port into the lid is located at a height part way between the inside and outside walls of the lid. The lid has a downwardly extending hollow peripheral formation. The filler port is spanwise inset from the peripheral formation. The lid has spanwise extending internal formations that stiffen the lid and divide the internal chamber into sub-volumes connected by necks through which liquid can flow. The inside and outside walls of the lid may be connected. The lid is provided with a “fill to” line visible from the filling port to discourage over-filling. The lid may have an insulated cap, and the cooler may have an insulated jacket.
F25D 3/08 - Movable containers portable, i.e. adapted to be carried personally
B65D 51/24 - Closures not otherwise provided for combined with auxiliary devices for non-closing purposes
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
B65D 43/16 - Non-removable lids or covers hinged for upward or downward movement
15.
CONTAINER ASSEMBLY AND LID THEREFOR WITH THERMAL RESERVOIR
A cooler has a body and a lid that co-operate. The lid is movable between closed and open positions. The lid is a freezable reservoir. A filler port is located inside the lid. The entrance of the filler port into the lid is located at a height part way between the inside and outside walls of the lid. The lid has a downwardly extending hollow peripheral fomiation. The filler port is spanwise inset from the peripheral fomiation. The lid has spanwise extending internal fomiations that stiffen the lid and divide the internal chamber into sub-volumes connected by necks through which liquid can flow. The inside and outside walls of the lid may be connected. The lid is provided with a "fill to" line visible from the filling port to discourage over-filling. The lid may have an insulated cap, and the cooler may have an insulated jacket.
B65D 81/18 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents providing specific environment for contents, e.g. temperature above or below ambient
F25D 3/08 - Movable containers portable, i.e. adapted to be carried personally
A soft-side container is sized to fit inside larger luggage such as a suitcase. It has a peripheral zipper that aids in compressing the contents of the container when it is loaded, such as with clothing, thereby tending to take less space in the suitcase. It also has a suspension system permitting the container to be hung from a hanger rod, or from another container of the same type, in a cascade of shelves. To aid in this function, the container has an expanding side wall, and also a form-preserving spreader that tends to cause the container to hold itself in a generally planar configuration to function more effectively as a shelf.
A soft-side container is sized to fit inside larger luggage such as a suitcase. It has a peripheral zipper that aids in compressing the contents of the container when it is loaded, such as with clothing, thereby tending to take less space in the suitcase. It also has a suspension system permitting the container to be hung from a hanger rod, or from another container of the same type, in a cascade of shelves. To aid in this function, the container has an expanding side wall, and also a form-preserving spreader that tends to cause the container to hold itself in a generally planar configuration to function more effectively as a shelf.
A soft-side container is sized to fit inside larger luggage such as a suitcase. It has a peripheral zipper that aids in compressing the contents of the container when it is loaded, such as with clothing, thereby tending to take less space in the suitcase. It also has a suspension system permitting the container to be hung from a hanger rod, or from another container of the same type, in a cascade of shelves. To aid in this function, the container has an expanding side wall, and also a form-preserving spreader that tends to cause the container to hold itself in a generally planar configuration to function more effectively as a shelf.
A soft-side container is sized to fit inside larger luggage such as a suitcase. It has a peripheral zipper that aids in compressing the contents of the container when it is loaded, such as with clothing, thereby tending to take less space in the suitcase. It also has a suspension system permitting the container to be hung from a hanger rod, or from another container of the same type, in a cascade of shelves. To aid in this function, the container has an expanding side wall, and also a form-preserving spreader that tends to cause the container to hold itself in a generally planar configuration to function more effectively as a shelf.
A soft-sided insulated container that has a rigid closure. The rigid closure has a first closure interface that is a passive friction fit in which one part wipes another. The rigid closure has a second closure interface that is an active closure in which a mechanical device, such as a latch or clamp, is used positively to energize a closure between different parts of the closure. The soft-sided insulated container has a soft-sided external casing, and a rigid internal liner that includes a mating rigid lid. There is a releasable securement that holds the liner in engagement with the casing, but that can be released to permit the casing to be extracted from the liner. The releasable securement is a one-way passively engageable securement.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
B65D 43/22 - Devices for holding in closed position, e.g. clips
B65D 43/16 - Non-removable lids or covers hinged for upward or downward movement
A soft-sided insulated container that has a rigid closure. The rigid closure has a first closure interface that is a passive friction fit in which one part wipes another. The rigid closure has a second closure interface that is an active closure in which a mechanical device, such as a latch or clamp, is used positively to energize a closure between different parts of the closure. The soft-sided insulated container has a soft-sided external casing, and a rigid internal liner that includes a mating rigid lid. There is a releasable securement that holds the liner in engagement with the casing, but that can be released to permit the casing to be extracted from the liner. The releasable securement is a one-way passively engageable securement.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
B65D 43/16 - Non-removable lids or covers hinged for upward or downward movement
AbstractA soft-sided insulated container that has a rigid closure. The rigid closure has a first closure interface that is a passive friction fit in which one part wipes another. The rigid closure has a second closure interface that is an active closure in which a mechanical device, such as a latch or clamp, is used positively to energize a closure between different parts of the closure. The soft-sided insulated container has a soft-sided external casing, and a rigid internal liner that includes a mating rigid lid. There is a releasable securement that holds the liner in engagement with the casing, but that can be released to permit the casing to be extracted from the liner. The releasable securement is a one-way passively engageable securement.CA 3066448 2020-01-02
B65D 43/16 - Non-removable lids or covers hinged for upward or downward movement
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
F25D 3/08 - Movable containers portable, i.e. adapted to be carried personally
23.
SOFT-SIDED INSULATED CONTAINER WITH HARD-SIDED LINER
A soft-sided insulated container that has a rigid closure. The rigid closure has a first closure interface that is a passive friction fit in which one part wipes another. The rigid closure has a second closure interface that is an active closure in which a mechanical device, such as a latch or clamp, is used positively to energize a closure between different parts of the closure. The soft-sided insulated container has a soft-sided external casing, and a rigid internal liner that includes a mating rigid lid. There is a releasable securement that holds the liner in engagement with the casing, but that can be released to permit the casing to be extracted from the liner. The releasable securement is a one-way passively engageable securement.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
F25D 3/08 - Movable containers portable, i.e. adapted to be carried personally
A container assembly has a cup-shaped container, a lid body, a spout, a spout cover, and a spout cover securement, or lock. The lid body has a depending periphery that releasably mounts to the cup-shaped container. The lid body has a matrix extending within the periphery. The spout seat is located eccentrically and inwardly of the periphery. It has a root and a tip. The spout cover is movably mounted to the spout cover seat. When closed, the spout cover seals the spout. The lock moves between a first position and a second positon. In the first position the lock keeps the spout cover sealed to the tip. In the second position the spout cover securement permits motion of said spout cover to open. The lid is stackable on other lids. The container assembly cup comes in several forms, the different forms being mutually stacking.
B65D 47/08 - Closures with discharging devices other than pumps with pouring spouts or tubesClosures with discharging devices other than pumps with discharge nozzles or passages having articulated or hinged closures
A container assembly has a cup-shaped container, a lid body, a spout, a spout cover, and a spout cover securement, or lock. The lid body has a depending periphery that releasably mounts to the cup-shaped container. The lid body has a matrix extending within the periphery. The spout seat is located eccentrically and inwardly of the periphery. It has a root and a tip. The spout cover is movably mounted to the spout cover seat. When closed, the spout cover seals the spout. The lock moves between a first position and a second positon. In the first position the lock keeps the spout cover sealed to the tip. In the second position the spout cover securement permits motion of said spout cover to open. The lid is stackable on other lids. The container assembly cup comes in several forms, the different forms being mutually stacking.
A45F 3/18 - Water-bottlesMess-tinsCups of rigid material
B65D 1/02 - Bottles or similar containers with necks or like restricted apertures, designed for pouring contents
B65D 47/06 - Closures with discharging devices other than pumps with pouring spouts or tubesClosures with discharging devices other than pumps with discharge nozzles or passages
A folding container assembly has a soft-sided wall structure that is collapsible from either a fully expanded condition or from a partially expanded condition, wherein the container assembly defines an interior chamber for storing articles, into a carry pouch format wherein the container assembly is folded down on itself such that the interior chamber of the container assembly is not accessible for use. Accordingly, the folding container assembly has a first configuration wherein the container assembly defines a first interior cavity having a first interior volume for storing articles, a second configuration wherein the container assembly defines a second interior cavity having a second interior volume, wherein the second interior volume is less than the first interior volume, and a third configuration wherein the container assembly is folded down on itself into a compact form such that the interior cavity or chamber is not accessible for use.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft-sided insulated container assembly has a generally box-shaped form. The lid of the box defines a work surface on which to place objects such as foodstuffs and beverages. The work surface may be formed in a substantially rigid molded stiffener member, and may be divided into sub-regions with raised retainers to discourage sliding of objects where not precisely level. It may have an upstanding peripheral retainer. The work surface may be sunken relative to the periphery of the lid assembly.
B65D 43/16 - Non-removable lids or covers hinged for upward or downward movement
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
28.
INSULATED CONTAINER ASSEMBLY WITH THERMAL STORAGE ACCOMMODATION
A container assembly has a soft-sided insulated wall structure. It has an internal chamber in which to place objects, such as foodstuffs, to be kept cool or warm. There is a first closure member that opens and closes to permit objects to be place in, or removed from, the chamber. The wall structure includes one or more accommodations in which to place a warming or cooling element, such as an ice pack. The accommodations are externally accessible without opening the main chamber, and have their own closure. The outside of the accommodation may be insulated; the inside is a thin web through which to transfer heat. The container may be a collapsible foldable bag; a tote bag; back pack or a non-collapsible lunch box. The thermal storage elements may have a flat disk shape. The external access for the thermal storage elements permits them to slide sideways into place.
A container assembly has an insulated wall structure and a chamber. The chamber has an opening governed by a closure member that is movable between open and closed positions. The closure may include a hood. The container assembly has a first periphery. The cap has a second periphery defining the opening. A skirt extends between the peripheries. The second periphery is longer than the body of the container assembly. The skirt is foldable. In the closed position the first and second margins being of the second periphery are secured to each other, and the skirt is at least partially folded. In the open position, the skirt is more unfolded than in said closed position, and at least a portion of one of the margins is located more distantly from the chamber, or the wall structure than when closed. The closure has a floating jaw-bone reinforcement arrangement.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
B65D 43/16 - Non-removable lids or covers hinged for upward or downward movement
A soft-sided insulated container assembly has a generally box-shaped form like a school lunch box, having a main body and a lid. The lid is formed of one of the largest panels of the box-structure, and is joined to the main body of the box by a hinge that lets the lid lie flat next to the main body when the box is open. The inside face of the lid then defines a work surface on which to place objects such as foodstuffs and beverages. The work surface may be formed in a substantially rigid molded stiffener member, and may be divided into sub-regions with raised retainers to discourage sliding of objects where not precisely level. The container assembly may include a rigid internal liner with which the lid may mate zipperlessly. The mating portion of the lid may be formed in the same rigid member as the work surface.
A container assembly has a soft-sided insulated wall structure. It has one or more internal chambers in which to place objects to be kept cool or warm. A first closure member governs access to the container assembly. The wall structure includes one or more accommodations in which to place a warming or cooling element, such as an ice pack. The accommodations in the outside walls are externally accessible without opening the main chamber, and have their own closure, and may be insulated. The inside is a thin web through which to transfer heat. An internal partition divides the container assembly into two chambers. The partition may have a thermal storage element. The container may be a collapsible foldable bag; a tote bag; back pack or a non-collapsible lunch box. The thermal storage elements may have a flat disk shape. The disks slide sideways into place in the respective accommodations.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft-sided insulated container assembly has a generally box-shaped form. The lid of the box defines a work surface on which to place objects such as foodstuffs and beverages. The work surface may be formed in a substantially rigid molded stiffener member, and may be divided into sub-regions with raised retainers to discourage sliding of objects where not precisely level. It may have an upstanding peripheral retainer. The work surface may be sunken relative to the periphery of the lid assembly.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
B65B 63/08 - Auxiliary devices, not otherwise provided for, for operating on articles or materials to be packaged for heating or cooling articles or materials to facilitate packaging
35.
Insulated container assembly with thermal storage accommodation
A container assembly has a soft-sided insulated wall structure. It has one or more internal chambers in which to place objects to be kept cool or warm. A first closure member governs access to the container assembly. The wall structure includes one or more accommodations in which to place a warming or cooling element, such as an ice pack. The accommodations in the outside walls are externally accessible without opening the main chamber, and have their own closure, and may be insulated. The inside is a thin web through which to transfer heat. An internal partition divides the container assembly into two chambers. The partition may have a thermal storage element. The container may be a collapsible foldable bag; a tote bag; back pack or a non-collapsible lunch box. The thermal storage elements may have a flat disk shape. The disks slide sideways into place in the respective accommodations.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft-sided insulated container assembly has a generally box-shaped form like a school lunch box, having a main body and a lid. The lid is formed of one of the largest panels of the box-structure, and is joined to the main body of the box by a hinge that lets the lid lie flat next to the main body when the box is open. The inside face of the lid then defines a work surface on which to place objects such as foodstuffs and beverages. The work surface may be formed in a substantially rigid molded stiffener member, and may be divided into sub-regions with raised retainers to discourage sliding of objects where not precisely level. The container assembly may include a rigid internal liner with which the lid may mate zipperlessly. The mating portion of the lid may be formed in the same rigid member as the work surface.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A45F 3/02 - Sacks or packs carried on the body by means of one strap passing over the shoulder
B65D 43/16 - Non-removable lids or covers hinged for upward or downward movement
B65D 43/22 - Devices for holding in closed position, e.g. clips
A45C 7/00 - Collapsible or extensible luggage, bags or the like
A45C 9/00 - Luggage or bags convertible into objects for other use
B65B 1/04 - Methods of, or means for, filling the material into the containers or receptacles
B65B 63/08 - Auxiliary devices, not otherwise provided for, for operating on articles or materials to be packaged for heating or cooling articles or materials to facilitate packaging
A container assembly has a soft-sided insulated wall structure. It has an internal chamber in which to place objects, such as foodstuffs, to be kept cool or warm. There is a first closure member that opens and closes to permit objects to be place in, or removed from, the chamber. The wall structure includes one or more accommodations in which to place a warming or cooling element, such as an ice pack. The accommodations are externally accessible without opening the main chamber, and have their own closure. The outside of the accommodation may be insulated; the inside is a thin web through which to transfer heat. The container may be a collapsible foldable bag; a tote bag; back pack or a non-collapsible lunch box. The thermal storage elements may have a flat disk shape. The external access for the thermal storage elements permits them to slide sideways into place.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
40.
INSULATED CONTAINER ASSEMBLY WITH THERMAL STORAGE ACCOMMODATION
A container assembly has a soft-sided insulated wall structure. It has an internal chamber in which to place objects, such as foodstuffs, to be kept cool or warm. There is a first closure member that opens and closes to permit objects to be place in, or removed from, the chamber. The wall structure includes one or more accommodations in which to place a warming or cooling element, such as an ice pack. The accommodations are externally accessible without opening the main chamber, and have their own closure. The outside of the accommodation may be insulated; the inside is a thin web through which to transfer heat. The container may be a collapsible foldable bag; a tote bag; back pack or a non-collapsible lunch box. The thermal storage elements may have a flat disk shape. The external access for the thermal storage elements permits them to slide sideways into place.
A container assembly has a soft-sided insulated wall structure. It has an internal chamber in which to place objects, such as foodstuffs, to be kept cool or warm. There is a first closure member that opens and closes to permit objects to be place in, or removed from, the chamber. The wall structure includes one or more accommodations in which to place a warming or cooling element, such as an ice pack. The accommodations are externally accessible without opening the main chamber, and have their own closure. The outside of the accommodation may be insulated; the inside is a thin web through which to transfer heat. The container may be a collapsible foldable bag; a tote bag; back pack or a non-collapsible lunch box. The thermal storage elements may have a flat disk shape. The external access for the thermal storage elements permits them to slide sideways into place.
A container assembly has a soft-sided insulated wall structure. It has an internal chamber in which to place objects, such as foodstuffs, to be kept cool or warm. There is a first closure member that opens and closes to permit objects to be place in, or removed from, the chamber. The wall structure includes one or more accommodations in which to place a warming or cooling element, such as an ice pack. The accommodations are externally accessible without opening the main chamber, and have their own closure. The outside of the accommodation may be insulated; the inside is a thin web through which to transfer heat. The container may be a collapsible foldable bag; a tote bag; back pack or a non-collapsible lunch box. The thermal storage elements may have a flat disk shape. The external access for the thermal storage elements permits them to slide sideways into place.
A soft-sided insulated container assembly has a generally box-shaped form like a school lunch box, having a main body and a lid. The lid is formed of one of the largest panels of the box-structure, and is joined to the main body of the box by a hinge that lets the lid lie flat next to the main body when the box is open. The inside face of the lid then defines a work surface on which to place objects such as foodstuffs and beverages. The work surface may be formed in a substantially rigid molded stiffener member, and may be divided into sub-regions with raised retainers to discourage sliding of objects where not precisely level. The container assembly may include a rigid internal liner with which the lid may mate zipperlessly. The mating portion of the lid may be formed in the same rigid member as the work surface.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
B65D 25/00 - Details of other kinds or types of rigid or semi-rigid containers
A soft-sided insulated container assembly has a generally box-shaped form like a school lunch box, having a main body and a lid. The lid is formed of one of the largest panels of the box-structure, and is joined to the main body of the box by a hinge that lets the lid lie flat next to the main body when the box is open. The inside face of the lid then defines a work surface on which to place objects such as foodstuffs and beverages. The work surface may be formed in a substantially rigid molded stiffener member, and may be divided into sub-regions with raised retainers to discourage sliding of objects where not precisely level. The container assembly may include a rigid internal liner with which the lid may mate zipperlessly. The mating portion of the lid may be formed in the same rigid member as the work surface.
A soft-sided insulated container assembly has a generally box-shaped form like a school lunch box, having a main body and a lid. The lid is formed of one of the largest panels of the box-structure, and is joined to the main body of the box by a hinge that lets the lid lie flat next to the main body when the box is open. The inside face of the lid then defines a work surface on which to place objects such as foodstuffs and beverages. The work surface may be formed in a substantially rigid molded stiffener member, and may be divided into sub-regions with raised retainers to discourage sliding of objects where not precisely level. The container assembly may include a rigid internal liner with which the lid may mate zipperlessly. The mating portion of the lid may be formed in the same rigid member as the work surface.
A soft-sided insulated container assembly has a generally box-shaped form, having a main body and a lid. The lid is joined to the main body of the box by a hinge. The front face of the unit may have a mid or partial height work surface. The work surface may be movable between a collapsed or retracted position, and a raised or deployed position. The work surface may be formed in a substantially rigid molded stiffener member, and may be divided into sub-regions with raised retainers to discourage sliding of objects where not precisely level. The container assembly may include a rigid internal liner with which the lid may mate zipperlessly. The mating portion of the lid may be formed in the same rigid member as the work surface. The work surface may be located at a depressed height relative to the main container opening.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
B65D 43/16 - Non-removable lids or covers hinged for upward or downward movement
A45C 13/02 - Interior fittingsMeans for holding or packing articles
A soft-sided insulated container assembly has a generally box-shaped form, having a main body and a lid. The lid is joined to the main body of the box by a hinge. The front face of the unit may have a mid or partial height work surface. The work surface may be movable between a collapsed or retracted position, and a raised or deployed position. The work surface may be formed in a substantially rigid molded stiffener member, and may be divided into sub-regions with raised retainers to discourage sliding of objects where not precisely level. The container assembly may include a rigid internal liner with which the lid may mate zipperlessly. The mating portion of the lid may be formed in the same rigid member as the work surface. The work surface may be located at a depressed height relative to the main container opening.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft-sided insulated container assembly has a generally box-shaped form like a school lunch box, having a main body and a lid. The lid is formed of one of the largest panels of the box-structure, and is joined to the main body of the box by a hinge that lets the lid lie flat next to the main body when the box is open. The inside face of the lid then defines a work surface on which to place objects such as foodstuffs and beverages. The work surface may be formed in a substantially rigid molded stiffener member, and may be divided into sub-regions with raised retainers to discourage sliding of objects where not precisely level. The container assembly may include a rigid internal liner with which the lid may mate zipperlessly. The mating portion of the lid may be formed in the same rigid member as the work surface.
A soft-sided insulated container assembly has a generally box-shaped form like a school lunch box, having a main body and a lid. The lid is formed of one of the largest panels of the box-structure, and is joined to the main body of the box by a hinge that lets the lid lie flat next to the main body when the box is open. The inside face of the lid then defines a work surface on which to place objects such as foodstuffs and beverages. The work surface may be formed in a substantially rigid molded stiffener member, and may be divided into sub-regions with raised retainers to discourage sliding of objects where not precisely level. The container assembly may include a rigid internal liner with which the lid may mate zipperlessly. The mating portion of the lid may be formed in the same rigid member as the work surface.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft sided insulated container assembly includes a first portion having an insulated, soft sided external wall structure, and a second portion that defined a lid co-operable with the first portion. The lid includes an auxiliary access opening and closure member that are smaller than the main opening, and that can be operated one-handed. A rigid work surface is provided, typically immediately adjacent to the secondary closure member, the work surface providing a place for holding or mixing a drink or for preparing a snack. In some embodiments the work surface may be movable relative to the container, whether slidable in a co-planar or parallel planar manner in translation, or folding as in a foldable shelf. The entire container assembly may be foldable or collapsible to a storage condition, and the rigid member, whether fixed or movable, does not impede that folding or collapsing.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft-sided insulated container assembly is made of a flexible wall structure that is movable between a collapsed position and a deployed position. In one variation of the deployed position it resembles a tote-bag; in another variation of folding the deployed position corresponds to a generally box-like shape. The container includes a self-inflating wall structure that has an inner layer or skin, an outer layer or skin, and a resilient, open-cell insulating layer trapped between the two skins. A valve governs the ability to take in or to expel air. The outer layer may be thicker and more robust that the inner layer, the better to resist abrasion or punctures. The inner layer may be reflective. There may be a removable internal liner. That liner may be transparent.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft-sided insulated container assembly has a generally box-shaped form like a school lunch box, having a main body and a lid. The lid is formed of one of the largest panels of the box-structure, and is joined to the main body of the box by a hinge that lets the lid lie flat next to the main body when the box is open. The inside face of the lid then defines a work surface on which to place objects such as foodstuffs and beverages. The work surface may be formed in a substantially rigid molded stiffener member, and may be divided into sub-regions with raised retainers to discourage sliding of objects where not precisely level. The container assembly may include a rigid internal liner with which the lid may mate zipperlessly. The mating portion of the lid may be formed in the same rigid member as the work surface.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
B65D 43/16 - Non-removable lids or covers hinged for upward or downward movement
B65D 43/22 - Devices for holding in closed position, e.g. clips
A45C 7/00 - Collapsible or extensible luggage, bags or the like
B65B 63/08 - Auxiliary devices, not otherwise provided for, for operating on articles or materials to be packaged for heating or cooling articles or materials to facilitate packaging
A45C 9/00 - Luggage or bags convertible into objects for other use
A soft sided insulated container assembly includes a first portion having an insulated, soft sided external wall structure, and a second portion that defined a lid co-operable with the first portion. The lid includes an auxiliary access opening and closure member that are smaller than the main opening, and that can be operated one-handed. A rigid work surface is provided, typically immediately adjacent to the secondary closure member, the work surface providing a place for holding or mixing a drink or for preparing a snack. In some embodiments the work surface may be movable relative to the container, whether slidable in a co-planar or parallel planar manner in translation, or folding as in a foldable shelf. The entire container assembly may be foldable or collapsible to a storage condition, and the rigid member, whether fixed or movable, does not impede that folding or collapsing.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft-sided insulated container assembly is made of a flexible wall structure that is movable between a collapsed position and a deployed position. In one variation of the deployed position it resembles a tote-bag; in another variation of folding the deployed position corresponds to a generally box-like shape. The container includes a self-inflating wall structure that has an inner layer or skin, an outer layer or skin, and a resilient, open-cell insulating layer trapped between the two skins. A valve governs the ability to take in or to expel air. The outer layer may be thicker and more robust that the inner layer, the better to resist abrasion or punctures. The inner layer may be reflective. There may be a removable internal liner. That liner may be transparent.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft-sided insulated container assembly is made of a flexible wall structure that is movable between a collapsed position and a deployed position. In one variation of the deployed position it resembles a tote-bag; in another variation of folding the deployed position corresponds to a generally box-like shape. The container includes a self-inflating wall structure that has an inner layer or skin, an outer layer or skin, and a resilient, open-cell insulating layer trapped between the two skins. A valve governs the ability to take in or to expel air. The outer layer may be thicker and more robust that the inner layer, the better to resist abrasion or punctures. The inner layer may be reflective. There may be a removable internal liner. That liner may be transparent.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
F25D 3/08 - Movable containers portable, i.e. adapted to be carried personally
A soft sided insulated container assembly includes a first portion having an insulated, soft sided external wall structure, and a second portion that defined a lid co-operable with the first portion. The lid includes an auxiliary access opening and closure member that are smaller than the main opening, and that can be operated one-handed. A rigid work surface is provided, typically immediately adjacent to the secondary closure member, the work surface providing a place for holding or mixing a drink or for preparing a snack. In some embodiments the work surface may be movable relative to the container, whether slidable in a co-planar or parallel planar manner in translation, or folding as in a foldable shelf. The entire container assembly may be foldable or collapsible to a storage condition, and the rigid member, whether fixed or movable, does not impede that folding or collapsing.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
F25D 3/08 - Movable containers portable, i.e. adapted to be carried personally
A soft sided insulated container assembly includes a first portion having an insulated, soft sided external wall structure, and a second portion that defined a lid co-operable with the first portion. The lid includes an auxiliary access opening and closure member that are smaller than the main opening, and that can be operated one-handed. A rigid work surface is provided, typically immediately adjacent to the secondary closure member, the work surface providing a place for holding or mixing a drink or for preparing a snack. In some embodiments the work surface may be movable relative to the container, whether slidable in a co-planar or parallel planar manner in translation, or folding as in a foldable shelf. The entire container assembly may be foldable or collapsible to a storage condition, and the rigid member, whether fixed or movable, does not impede that folding or collapsing.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
F25D 3/08 - Movable containers portable, i.e. adapted to be carried personally
A soft sided insulated container assembly includes a first portion having an insulated, soft sided external wall structure, and a second portion that defined a lid co-operable with the first portion. The lid includes an auxiliary access opening and closure member that are smaller than the main opening, and that can be operated one-handed. A rigid work surface is provided, typically immediately adjacent to the secondary closure member, the work surface providing a place for holding or mixing a drink or for preparing a snack. In some embodiments the work surface may be movable relative to the container, whether slidable in a co-planar or parallel planar manner in translation, or folding as in a foldable shelf. The entire container assembly may be foldable or collapsible to a storage condition, and the rigid member, whether fixed or movable, does not impede that folding or collapsing.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft sided insulated container assembly has a first insulated container portion and a second insulated container portion. The second insulated container portion can be collapsed to a flat position, and secured in place. Either of the container portions may have a liner. The liner in the first container portion may be a substantially rigid liner. The assembly may have a lifting member. In one example the second portion may be hingedly mounted to the first portion, and the lifting member may be mounted such that when the assembly is lifted, the hinge is in an up-and-down orientation. In another embodiment, the lifting member may be eccentrically mounted, such that the assembly may possibly sit more comfortably against a carrier's hip. The first container portion may have an auxiliary opening or door, and that door may be more easily opened than the main access of the first insulated container portion.
B65D 30/08 - Sacks, bags or like containers characterised by the material used with laminated or multiple walls in spaced face-to-face relationship, e.g. double walls
B65D 33/02 - Local reinforcements or stiffening inserts, e.g. wires, strings, strips or frames
A45F 3/02 - Sacks or packs carried on the body by means of one strap passing over the shoulder
F25D 3/08 - Movable containers portable, i.e. adapted to be carried personally
69.
Insulated container with asymmetric lifting arrangement
A soft-sided insulated container assembly includes a collapsible cooler body made of insulated panels. The body is to be carried by lifting apparatus that includes asymmetrically arranged fittings. Those fittings may be an inboard shoulder strap or a handle located on an outboard portion of a face of the container body, and may be at a height for engagement by the hand of the user. The assembly may have a liner to contain liquids and an easy access lid. The insulated container may be collapsed, and secured. In one embodiment the asymmetric lifting arrangement includes a shoulder strap attached to the sides of the container in a manner that distributes the load into the sides of the container, and includes a grip or handle located on the lower portion of the front side of the container to pull up on the bottom of the container when used by a person.
A soft sided insulated container assembly has a first insulated container portion and a second insulated container portion. The second insulated container portion can be collapsed to a flat position, and secured in place. Either of the container portions may have a liner. The liner in the first container portion may be a substantially rigid liner. The assembly may have a lifting member. In one example the second portion may be hingedly mounted to the first portion, and the lifting member may be mounted such that when the assembly is lifted, the hinge is in an up-and-down orientation. In another embodiment, the lifting member may be eccentrically mounted, such that the assembly may possibly sit more comfortably against a carrier's hip. The first container portion may have an auxiliary opening or door, and that door may be more easily opened than the main access of the first insulated container portion.
B65D 33/00 - Details of, or accessories for, sacks or bags
B65D 30/08 - Sacks, bags or like containers characterised by the material used with laminated or multiple walls in spaced face-to-face relationship, e.g. double walls
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
35 - Advertising and business services
42 - Scientific, technological and industrial services, research and design
Goods & Services
Insulation bags, insulated drink holders, insulated portable coolers for food and beverages; household or kitchen utensils and containers (not of precious metal or coated therewith); combs and sponges; brushes (except paint brushes); brush-making materials; articles for cleaning purposes; steelwool; unworked or semi-worked glass (except glass used in building); glassware, porcelain and earthenware not included in other classes. Importation, exportation, retail and wholesale of insulated bags, storage pouches, insulated drink holders, backpacks, insulated portable coolers for food and beverages; advertising; business management; business administration; office functions. Design of products including insulated bags, storage pouches, insulated drink holders, backpacks, insulated portable coolers for food and beverages; Scientific and technological services and research and design relating thereto; industrial analysis and research services; design and development of computer hardware and software.
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
[ backpacks ] Thermal insulated bags for food and beverages, thermal insulated storage pouches for food and beverages, [ insulated drink holders, ] insulated portable coolers for food and beverages
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
35 - Advertising and business services
42 - Scientific, technological and industrial services, research and design
Goods & Services
(1) Insulated bags, storage pouches, insulated drink holders, backpacks, insulated portable coolers for food and beverages (1) Operation of a business offering design, importation, exportation, sale and distribution of insulated bags, storage pouches, insulated drink holders, backpacks, insulated portable coolers for food and beverages
A soft sided insulated container assembly includes a first portion having an insulated, soft sided external wall structure, and an internal, substantially rigid molded plastic receptacle mounted therein. It has a cover structure that includes a reinforcement member for engaging a land region of the molded receptacle, thereby tending to yield an interface tending to have a sealing relationship. Both the receptacle and the engaging seal member of the lid may be outwardly splayed. The container may also include a thermal storage element, and the container may have an accommodation for receiving the thermal storage element.
A soft-sided insulated container assembly includes a collapsible cooler body made of insulated panels. The body is to be carried by an arrangement of lifting apparatus that includes asymmetrically arranged fittings. One lifting fitting may be an inboard shoulder strap. Another fitting may an handle located on an outboard portion of face of the container body, and may be at a height for engagement by the hand of the user. The soft-sided insulated container assembly may have a liner to contain liquids. The soft-sided insulated container assembly may have an easy access lid. The insulated container may be collapsed to a flat position, and secured in place. In one embodiment the asymmetric lifting arrangement includes a shoulder strap attached to the sides of the container in a manner that distributes the load into the sides of the container, and a grip, such as a handle, located on the lower portion of the front side of the container. The grip may be attached to the container so as to pull up on the bottom of the container when used by a person.
A soft-sided insulated container assembly includes a collapsible cooler body made of insulated panels. The body is to be carried by an arrangement of lifting apparatus that includes asymmetrically arranged fittings. One lifting fitting may be an inboard shoulder strap. Another fitting may an handle located on an outboard portion of face of the container body, and may be at a height for engagement by the hand of the user. The soft-sided insulated container assembly may have a liner to contain liquids. The soft-sided insulated container assembly may have an easy access lid. The insulated container may be collapsed to a flat position, and secured in place. In one embodiment the asymmetric lifting arrangement includes a shoulder strap attached to the sides of the container in a manner that distributes the load into the sides of the container, and a grip, such as a handle, located on the lower portion of the front side of the container. The grip may be attached to the container so as to pull up on the bottom of the container when used by a person.
A47J 41/00 - Thermally-insulated vessels, e.g. flasks, jugs, jars
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft sided insulated container assembly has a first insulated container portion and a second insulated container portion. The second insulated container portion can be collapsed to a flat position, and secured in place. Either of the container portions may have a liner. The liner in the first container portion may be a substantially rigid liner. The assembly may have a lifting member. In one example the second portion may be hingedly mounted to the first portion, and the lifting member may be mounted such that when the assembly is lifted, the hinge is in an up-and-down orientation. In another embodiment, the lifting member may be eccentrically mounted, such that the assembly may possibly sit more comfortably against a carrier's hip. The first container portion may have an auxiliary opening or door, and that door may be more easily opened than the main access of the first insulated container portion.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
B65D 30/08 - Sacks, bags or like containers characterised by the material used with laminated or multiple walls in spaced face-to-face relationship, e.g. double walls
A soft sided insulated container assembly has a first insulated container portion and a second insulated container portion. The second insulated container portion can be collapsed to a flat position, and secured in place. Either of the container portions may have a liner. The liner in the first container portion may be a substantially rigid liner. The assembly may have a lifting member. In one example the second portion may be hingedly mounted to the first portion, and the lifting member may be mounted such that when the assembly is lifted, the hinge is in an up-and-down orientation. In another embodiment, the lifting member may be eccentrically mounted, such that the assembly may possibly sit more comfortably against a carrier's hip. The first container portion may have an auxiliary opening or door, and that door may be more easily opened than the main access of the first insulated container portion.
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft sided insulated container assembly includes a first portion having an insulated, soft sided external wall structure, and an internal, substantially rigid molded plastic receptacle mounted therein. It has a cover structure that includes a reinforcement member for engaging a land region of the molded receptacle, thereby tending to yield an interface tending to have a sealing relationship. The container may also include a thermal storage element, and the container may have an accommodation for receiving the thermal storage element.
B65D 81/02 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents specially adapted to protect contents from mechanical damage
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
A soft sided insulated container assembly includes a first portion having an insulated, soft sided external wall structure, and an internal, substantially rigid molded plastic receptacle mounted therein. It has a cover structure that includes a reinforcement member for engaging a land region of the molded receptacle, thereby tending to yield an interface tending to have a sealing relationship. Both the receptacle and the engaging seal member of the lid may be outwardly splayed. The container may also include a thermal storage element, and the container may have an accommodation for receiving the thermal storage element.
B65D 25/00 - Details of other kinds or types of rigid or semi-rigid containers
B65D 81/38 - Containers, packaging elements, or packages, for contents presenting particular transport or storage problems, or adapted to be used for non-packaging purposes after removal of contents with thermal insulation
