In example implementations, a locking mechanism is provided. The locking mechanism includes a movable lever arm coupled to a moving component to be locked, a spring-loaded activating lever, wherein the movable lever arm interacts with the spring-loaded activating lever when the moving component moves to move the spring-loaded activating lever between a first position and a second position, and a locking member coupled to the spring-loaded activating lever, wherein the locking member moves into a locking position when the spring-loaded activating lever is in the first position and an unlocking position when the spring-loaded activating lever is in a second position.
In example implementations, a panel is provided. The panel includes a first metal skin, a second metal skin, wherein the first metal skin and the second metal skin comprise at least one cut out and the first metal skin is coupled to the second metal skin to form a body of the panel such that the at least one cut out is located within a same area of the body of the panel, a back frame inserted through the at least one cut-out, an electronic component placed on the back frame, a front frame coupled to the back frame to secure the electronic component to the back frame and within the at least one cut-out, and a conductive path located inside of the body to electrically connect the electronic component to a power supply.
E06B 3/26 - Compound frames, i.e. one frame within or behind another
B32B 15/04 - Layered products essentially comprising metal comprising metal as the main or only constituent of a layer, next to another layer of a specific substance
B32B 17/06 - Layered products essentially comprising sheet glass, or fibres of glass, slag or the like comprising glass as the main or only constituent of a layer, next to another layer of a specific substance
E05F 15/668 - Power-operated mechanisms for wings using electrical actuators using rotary electromotors for vertically-sliding wings for overhead wings
06 - Common metals and ores; objects made of metal
35 - Advertising and business services
40 - Treatment of materials; recycling, air and water treatment,
Goods & Services
(1) Metal rolling doors and grilles, metal sliding doors and grilles, metal side folding accordion doors, panels and partitions, metal curtains, metal panels, annunciators, and operators, control stations, and obstruction sensors to control same; metal counter doors; metal shutters; metal security grilles; metal side folding accordion doors, panels and partitions for emergency. (1) Wholesale distributorships featuring overhead door and closure products in the nature of rolling and coiling doors, fire rated door systems, counter doors and shutters, security grilles and side folding accordion products for emergency response, code compliance, access control, security and environmental separation; wholesale store services featuring overhead door and closure products in the nature of rolling and coiling doors, fire rated door systems, counter doors and shutters, security grilles and side folding accordion products for emergency response, code compliance, access control, security and environmental separation.
(2) Custom manufacturing of overhead door and closure products in the nature of rolling and coiling doors, fire rated door systems, counter doors and shutters, security grilles and side folding accordion products for emergency response, code compliance, access control, security and environmental separation.
06 - Common metals and ores; objects made of metal
35 - Advertising and business services
40 - Treatment of materials; recycling, air and water treatment,
Goods & Services
(1) Metal rolling doors and grilles, metal sliding doors and grilles, metal side folding accordion doors, panels and partitions, metal curtains, metal panels, annunciators, and operators, control stations, and obstruction sensors to control same; metal counter doors; metal shutters; metal security grilles; metal side folding accordion doors, panels and partitions for emergency. (1) Wholesale distributorships featuring overhead door and closure products in the nature of rolling and coiling doors, fire rated door systems, counter doors and shutters, security grilles and side folding accordion products for emergency response, code compliance, access control, security and environmental separation; wholesale store services featuring overhead door and closure products in the nature of rolling and coiling doors, fire rated door systems, counter doors and shutters, security grilles and side folding accordion products for emergency response, code compliance, access control, security and environmental separation.
(2) Custom manufacturing of overhead door and closure products in the nature of rolling and coiling doors, fire rated door systems, counter doors and shutters, security grilles and side folding accordion products for emergency response, code compliance, access control, security and environmental separation.
42 - Scientific, technological and industrial services, research and design
Goods & Services
Providing on-line non-downloadable software for use by dealers and installers which creates an item number and saves order information for re-orders of overhead doors and components for overhead doors
In example implementations, an end cap for a panel of a vertically stacking panel door is provided. The end cap includes a body to be coupled to an end of a panel of a vertically stacking panel door, a first track wheel coupled to the body, a second track wheel coupled to the body, and a vertical stability roller coupled to the body, wherein the first track wheel, the second track wheel, and the vertical stability roller are arranged along a vertical line, wherein the first track wheel is located vertically above the second track wheel and the vertical stability roller is located between the first track wheel and the second track wheel.
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E05D 15/16 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane
A closure system including a curtain configured to seal an opening, a wireless network having a plurality of channels, at least one transmitter coupled to the curtain and configured to communicate over the plurality of channels, and an operator operatively coupled to the curtain and configured to communicate over the plurality of channels, the operator and the at least one transmitter configured to communicate with each other over a selected one of the plurality of channels based upon communication interference detected on one or more channels.
A track of a vertically stacking door includes a vertical track, a first curved track portion, a second curved track portion, a first horizontal track portion coupled to the first curved track portion, and a second horizontal track portion coupled to the second curved track portion. The first curved track portion and the second curved track portion are split off from the vertical track and the first curved track portion and the second curved track portion each comprises multiple radii of curvature.
E06B 3/92 - Doors or windows extensible when set in position
E05D 15/20 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane movable out of one plane into a second parallel plane
In one embodiment, a closure system comprises a guide assembly having a channel defined by a first guide wall and a second guide wall. The closure system may include a retention bar extending into the channel from the first guide wall and a plurality of slats. Each slat of the plurality of slats may be configured to interlock with another of the plurality of slats. Each slat may have a retention groove with at least one sidewall configured and dimensioned to engage the retention bar to retain the slat within the channel.
E06B 9/86 - Safety measures against dropping or unauthorised openingBraking or immobilising devicesDevices for limiting unrolling automatic against unauthorised opening
Examples of the present disclosure provide an overhead door panel. The overhead door panel includes a pair of parallel glass panes, a metal frame with parallel lateral stiles oriented perpendicular to the pair of parallel glass panes, a first seal system located at a first lateral stile, and a second seal system located at a second lateral stile, wherein the first seal system and the second seal system engage with at least one glass pane of the pair of parallel glass panes and a lateral stile of the parallel lateral stiles of the metal frame such that the first seal system and the second seal system are between the at least one glass pane and the lateral stile.
E05D 15/16 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E05F 15/668 - Power-operated mechanisms for wings using electrical actuators using rotary electromotors for vertically-sliding wings for overhead wings
E06B 7/28 - Other arrangements on doors or windows, e.g. door-plates, windows adapted to carry plants, hooks for window cleaners
G09F 13/04 - Signs, boards, or panels, illuminated from behind the insignia
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
In example implementations, a slat for a rolling steel door is provided. The slat includes a front slat fabricated from steel, a back slat fabricated from plastic having a thickness between 0.02 inches and 0.1 inches, wherein the back slat is coupled to the front slat to form an interior volume, and a mineral wool insulation to substantially fill the interior volume.
In example implementations, a cable carrier assembly for a sectional door is provided. The cable carrier assembly includes a cable carrier track coupled to a track of the sectional door, a sectional cable carrier guide coupled to a panel of the sectional door, and a cable carrier, wherein a first end of the cable carrier is coupled to the cable carrier track and a second end of the cable carrier is coupled to the sectional cable carrier guide.
In example implementations, a power hinge for panels of a sectional door is provided. The power hinge includes a first hinge leaf, a second hinge leaf, a rod, a first hinge cover, and a second hinge cover. The first hinge leaf includes a body portion comprising at least one opening to receive a mechanical coupling and an electrical wire opening and opposing sides coupled to the body portion. The second hinge leaf includes a body portion comprising at least one opening to receive a mechanical coupling and an electrical wire opening and opposing sides coupled to the body portion, wherein the opposing sides of the first hinge leaf are inserted between and aligned with the opposing sides of the second hinge leaf. The rod is coupled to the first hinge leaf and the second hinge leaf through the opposing sides of the first hinge leaf and the second hinge leaf.
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E05D 7/00 - Hinges or pivots of special construction
E05D 11/00 - Additional features or accessories of hinges
In example implementations, a power plug for panels of a sectional door is provided. The power plug includes a first end comprising a first plug, a second end comprising a second plug, and a flexible housing coupled to the first end and the second end, wherein the flexible housing encloses electrical wiring connecting the first plug and the second plug.
E06B 3/48 - Wings connected at their edges, e.g. foldable wings
E05D 15/16 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E05D 15/38 - Suspension arrangements for wings moving along slide-ways so arranged that one guide member of the wing moves in a direction substantially perpendicular to the movement of another guide member for upwardly-moving wings, e.g. up-and-over doors
E05D 15/16 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E05D 15/38 - Suspension arrangements for wings moving along slide-ways so arranged that one guide member of the wing moves in a direction substantially perpendicular to the movement of another guide member for upwardly-moving wings, e.g. up-and-over doors
E06B 3/48 - Wings connected at their edges, e.g. foldable wings
23.
SECTIONAL DOOR WITH INTEGRATED ELECTRICAL COMPONENTS
E06B 3/48 - Wings connected at their edges, e.g. foldable wings
E06B 7/02 - Special arrangements or measures in connection with doors or windows for providing ventilation, e.g. through double windowsArrangement of ventilation roses
E06B 7/28 - Other arrangements on doors or windows, e.g. door-plates, windows adapted to carry plants, hooks for window cleaners
E06B 7/098 - Louvre doors, windows, or grilles with rotatable lamellae interconnected for concurrent movement with weather seal
E06B 7/16 - Sealing arrangements on wings or parts co-operating with the wings
E06B 7/18 - Sealing arrangements on wings or parts co-operating with the wings by means of movable edgings, e.g. draught sealings additionally used for bolting
E06B 7/22 - Sealing arrangements on wings or parts co-operating with the wings by means of elastic edgings, e.g. elastic rubber tubesSealing arrangements on wings or parts co-operating with the wings by means of resilient edgings, e.g. felt or plush strips, resilient metal strips
E06B 7/23 - Plastic, sponge rubber, or like strips or tubes
In example implementations, a panel of a sectional door is provided. The panel includes a panel housing, an opening in the panel housing, an edge-lit light emitting diode (LED) panel in the opening, and a constant power source electrically connected to the edge-lit LED panel. The edge-lit LED panel may provide privacy and a desired aesthetic look when activated for the sectional door.
In example implementations, a back-lit light emitting diode (LED) panel for a panel of a sectional door is provided. The back-lit LED panel includes a frame comprising a back side, a top side, a bottom side, a left side, and a right side, at least one LED array coupled to the back side of the frame, and a diffuser coupled to the top side, the bottom side, the left side, and the right side of the frame to enclose the at least one LED array, wherein the back-lit LED panel is less than 2 inches thick to fit into an opening of the panel of the sectional door.
G09F 13/04 - Signs, boards, or panels, illuminated from behind the insignia
E05D 15/16 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E05F 15/668 - Power-operated mechanisms for wings using electrical actuators using rotary electromotors for vertically-sliding wings for overhead wings
E06B 7/28 - Other arrangements on doors or windows, e.g. door-plates, windows adapted to carry plants, hooks for window cleaners
In example implementations, a retractable cord assembly for a sectional door is provided. The retractable cord assembly includes a retractable cord housing, a wire retainer to be coupled to an axle of a roller of the sectional door, and a power cord, wherein a first end of the power cord is coupled to an interior axle of the retractable cord housing and a second end of the power cord is fed through the wire retainer and into a panel of the sectional door.
In example implementations, a panel of a sectional door is provided. The panel includes a panel housing, an integrated electrical component located within a body of the panel housing, and a constant power source electrically connected to the integrated electrical component. The integrated electrical component is located within an interior volume of the body of the panel housing or in the body of the panel housing.
E06B 7/02 - Special arrangements or measures in connection with doors or windows for providing ventilation, e.g. through double windowsArrangement of ventilation roses
E06B 7/00 - Special arrangements or measures in connection with doors or windows
E06B 7/28 - Other arrangements on doors or windows, e.g. door-plates, windows adapted to carry plants, hooks for window cleaners
In example implementations, a guide for a fire shutter is provided. The guide includes a first bracket to be coupled to a wall, a second bracket coupled to the first bracket, wherein the first bracket and the second bracket form a channel to receive a curtain of the fire shutter, and a fixed guide brush seal permanently affixed to the second bracket during manufacture of the second bracket.
E06B 7/16 - Sealing arrangements on wings or parts co-operating with the wings
E06B 7/18 - Sealing arrangements on wings or parts co-operating with the wings by means of movable edgings, e.g. draught sealings additionally used for bolting
E06B 7/22 - Sealing arrangements on wings or parts co-operating with the wings by means of elastic edgings, e.g. elastic rubber tubesSealing arrangements on wings or parts co-operating with the wings by means of resilient edgings, e.g. felt or plush strips, resilient metal strips
E06B 7/23 - Plastic, sponge rubber, or like strips or tubes
In example implementations, a method executed by a processor of a controller of a rolling door system is provided. The method includes receiving an alarm signal, determining a type of alarm associated with the alarm signal, and transmitting a control signal to operate a motor to open or close a rolling door in response to the type of alarm that is determined.
In example implementations, a method executed by a processor of a controller of a rolling door system is provided. The method includes receiving an alarm signal, determining a type of alarm associated with the alarm signal, and transmitting a control signal to operate a motor to open or close a rolling door in response to the type of alarm that is determined.
E05F 15/72 - Power-operated mechanisms for wings with automatic actuation responsive to emergency conditions, e.g. fire
E05F 15/668 - Power-operated mechanisms for wings using electrical actuators using rotary electromotors for vertically-sliding wings for overhead wings
E05F 15/73 - Power-operated mechanisms for wings with automatic actuation responsive to movement or presence of persons or objects
35.
COMMUNICATION INTERFACE DEVICE FOR WIRELESS DOOR CONTROLLERS
In example implementations, an apparatus is provided. The apparatus includes a connection interface, a LAN interface, a WAN interface, and a processor. The connection interface is to connect to a PCB of a door controller. The LAN interface is to communicate with a plurality of door sensors. The WAN interface is to communicate with a remote server of a service provider. The processor is communicatively coupled to the connection interface, the LAN interface, and the WAN interface. The processor is to receive door data from the plurality of door sensors via the LAN interface, transmit the door data to the remote server for analysis, receive a correction action from the remote server in response to the door data that is transmitted, and execute the corrective action on a door of the plurality of doors via the LAN interface.
In one embodiment, a guide system includes a first member configured to be fixed to a structure. A coupling element is fixed to the first member. A second member is moveable relative to the first member. The second member is configured to receive the coupling element to couple the first member to the second member. There is a channel between the first member and the second member when the first member is coupled to the second member. The channel is configured to receive a portion of a closure.
In example implementations, a vertical stacking door includes an end cap that is coupled to a panel. The end cap includes a body portion, a cam lever to rotate around an axis to generate a lift force to lift and separate an adjacent panel of a plurality of panels of the vertical stacking door, a first track wheel, a second track wheel, and a third track wheel.
E05D 15/22 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane allowing an additional movement
E06B 3/50 - Arrangements of wings characterised by the manner of movementArrangements of movable wings in openingsFeatures of wings or frames relating solely to the manner of movement of the wing with more than one kind of movement
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
E06B 3/48 - Wings connected at their edges, e.g. foldable wings
38.
Vertical stability roller for vertically stacking panels
In example implementations, an end cap for a panel of a vertically stacking panel door is provided. The end cap includes a body to be coupled to an end of a panel of a vertically stacking panel door, a first track wheel coupled to the body, a second track wheel coupled to the body, and a vertical stability roller coupled to the body, wherein the first track wheel, the second track wheel, and the vertical stability roller are arranged along a vertical line, wherein the first track wheel is located vertically above the second track wheel and the vertical stability roller is located between the first track wheel and the second track wheel.
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E05D 15/16 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane
In example implementations, a bead saddle attachment component for a curtain is provided. The bead saddle attachment component includes a body, a plurality of bead saddle features on an exterior side of the body, a spacer bracket receiving feature on the exterior side of the body, and an alignment feature on the exterior side of the body.
In example implementations, a bead saddle attachment component for a curtain is provided. The bead saddle attachment component includes a body, a plurality of bead saddle features on an exterior side of the body, a spacer bracket receiving feature on the exterior side of the body, and an alignment feature on the exterior side of the body.
In example implementations, a door monitoring sensor is provided. The door monitoring sensor includes a communication interface to transmit an alarm when a door operates outside of operational parameters of the door, an angular sensor to measure rotational movement of the a door, a movement sensor to detect movement along an x-y-z coordinate plane, a radar sensor to detect an object, a rechargeable power supply to provide power to the angular sensor, the movement sensor, and the radar sensor, and a processor. The processor is communicatively coupled to the communication interface, the angular sensor, the movement sensor, and the radar sensor. The processor is to determine that the door is moving outside of the operational parameters of the door and generate the alarm that is transmitted by the communication interface in response to determination that the door is moving outside of the operational parameters of the door.
G08B 13/08 - Mechanical actuation by opening, e.g. of door, of window, of drawer, of shutter, of curtain, of blind
E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
E06B 5/11 - Doors, windows, or like closures for special purposesBorder constructions therefor for protection against air-raid or other war-like actionDoors, windows, or like closures for special purposesBorder constructions therefor for other protective purposes against burglary
G08B 25/00 - Alarm systems in which the location of the alarm condition is signalled to a central station, e.g. fire or police telegraphic systems
43.
DOOR OPERATOR SENSOR AND LOGIC FOR VERTICALLY STACKING PANEL DOOR SYSTEMS
In example implementations, a vertically stacking panel door system is provided. The vertically stacking panel door system includes a horizontal door guide, a panel interface zone, a vertical door guide, a plurality of panels to move from a horizontally stacked position in the horizontal door guide to a vertically stacked position in the vertical door guide, a counterbalance system comprising a motor to move the plurality of panels, and a sensor to detect a gap between two adjacent panels of the plurality of panels as the plurality of panels are moved from the horizontally stacked position to the vertically stacked position, wherein the sensor is to transmit a signal to the motor when the gap is detected.
E05D 13/00 - Accessories for sliding or lifting wings, e.g. pulleys, safety catches
E05D 15/06 - Suspension arrangements for wings for wings sliding horizontally more or less in their own plane
E05D 15/16 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E06B 3/00 - Window sashes, door leaves, or like elements for closing openingsLayout of fixed or moving closures, e.g. windowsFeatures of rigidly-mounted outer frames relating to the mounting of wing frames
E06B 3/50 - Arrangements of wings characterised by the manner of movementArrangements of movable wings in openingsFeatures of wings or frames relating solely to the manner of movement of the wing with more than one kind of movement
G01L 3/12 - Rotary-transmission dynamometers wherein the torque-transmitting element comprises a torsionally-flexible shaft involving electric or magnetic means for indicating involving photoelectric means
44.
DOOR OPERATOR SENSOR AND LOGIC FOR VERTICALLY STACKING PANEL DOOR SYSTEMS
In example implementations, a vertically stacking panel door system is provided. The vertically stacking panel door system includes a horizontal door guide, a panel interface zone, a vertical door guide, a plurality of panels to move from a horizontally stacked position in the horizontal door guide to a vertically stacked position in the vertical door guide, a counterbalance system comprising a motor to move the plurality of panels, and a sensor to detect a gap between two adjacent panels of the plurality of panels as the plurality of panels are moved from the horizontally stacked position to the vertically stacked position, wherein the sensor is to transmit a signal to the motor when the gap is detected.
E05D 13/00 - Accessories for sliding or lifting wings, e.g. pulleys, safety catches
E05D 15/06 - Suspension arrangements for wings for wings sliding horizontally more or less in their own plane
E05D 15/16 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E06B 3/00 - Window sashes, door leaves, or like elements for closing openingsLayout of fixed or moving closures, e.g. windowsFeatures of rigidly-mounted outer frames relating to the mounting of wing frames
E06B 3/50 - Arrangements of wings characterised by the manner of movementArrangements of movable wings in openingsFeatures of wings or frames relating solely to the manner of movement of the wing with more than one kind of movement
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
G01L 3/12 - Rotary-transmission dynamometers wherein the torque-transmitting element comprises a torsionally-flexible shaft involving electric or magnetic means for indicating involving photoelectric means
In example implementations, a braking system for a vertical stacking panel door is provided. The braking system includes a first rod, a strap coupled to the first rod, a second rod movably coupled to the first rod, wherein the second rod is to engage a linear ratchet when moved from a disengaged position to an engaged position, and a torsion spring coupled to the first rod and the second rod, wherein tension from the strap moves the second rod into the disengaged portion and the torsion spring moves the second rod into the engaged position when tension is lost on the strap.
In example implementations, a vertically stacking panel door system is provided. The vertically stacking panel door system includes a horizontal door guide, a panel interface zone, a vertical door guide, a plurality of panels to move from a horizontally stacked position in the horizontal door guide to a vertically stacked position in the vertical door guide, a counterbalance system comprising a motor to move the plurality of panels, and a sensor to detect a gap between two adjacent panels of the plurality of panels as the plurality of panels are moved from the horizontally stacked position to the vertically stacked position, wherein the sensor is to transmit a signal to the motor when the gap is detected.
E05F 15/70 - Power-operated mechanisms for wings with automatic actuation
E05D 15/20 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane movable out of one plane into a second parallel plane
In example implementations, a braking system for a vertical stacking panel door is provided. The braking system includes a first rod, a strap coupled to the first rod, a second rod movably coupled to the first rod, wherein the second rod is to engage a linear ratchet when moved from a disengaged position to an engaged position, and a torsion spring coupled to the first rod and the second rod, wherein tension from the strap moves the second rod into the disengaged portion and the torsion spring moves the second rod into the engaged position when tension is lost on the strap.
In example implementations, a braking system for a vertical stacking panel door is provided. The braking system includes a first rod, a strap coupled to the first rod, a second rod movably coupled to the first rod, wherein the second rod is to engage a linear ratchet when moved from a disengaged position to an engaged position, and a torsion spring coupled to the first rod and the second rod, wherein tension from the strap moves the second rod into the disengaged portion and the torsion spring moves the second rod into the engaged position when tension is lost on the strap.
In example implementations, a method is provided. The method includes determining, by a processor, that a vehicle is approaching a door of a building based on a velocity vector of the vehicle, calculating, by the processor, a time of arrival of the vehicle at the door based on the velocity vector of the vehicle and a distance of the vehicle from the door, and controlling, by the processor, the door to begin opening at a time based on the time of arrival and an amount of time for the door to open such that the door is opened when the vehicle arrives at the door.
In example implementations, an end cap for a panel of a vertically stacking panel door is provided. The end cap includes a body to be coupled to an end of a panel of a vertically stacking panel door, a first track wheel coupled to the body, a second track wheel coupled to the body, and a vertical stability roller coupled to the body, wherein the first track wheel, the second track wheel, and the vertical stability roller are arranged along a vertical line, wherein the first track wheel is located vertically above the second track wheel and the vertical stability roller is located between the first track wheel and the second track wheel.
E05D 15/20 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane movable out of one plane into a second parallel plane
E05D 15/22 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane allowing an additional movement
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
58.
VERTICAL STABILITY ROLLER FOR VERTICALLY STACKING PANELS
In example implementations, an end cap for a panel of a vertically stacking panel door is provided. The end cap includes a body to be coupled to an end of a panel of a vertically stacking panel door, a first track wheel coupled to the body, a second track wheel coupled to the body, and a vertical stability roller coupled to the body, wherein the first track wheel, the second track wheel, and the vertical stability roller are arranged along a vertical line, wherein the first track wheel is located vertically above the second track wheel and the vertical stability roller is located between the first track wheel and the second track wheel.
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
E05D 15/20 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane movable out of one plane into a second parallel plane
E05D 15/22 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane allowing an additional movement
59.
Vertical stability roller for vertically stacking panels
In example implementations, an end cap for a panel of a vertically stacking panel door is provided. The end cap includes a body to be coupled to an end of a panel of a vertically stacking panel door, a first track wheel coupled to the body, a second track wheel coupled to the body, and a vertical stability roller coupled to the body, wherein the first track wheel, the second track wheel, and the vertical stability roller are arranged along a vertical line, wherein the first track wheel is located vertically above the second track wheel and the vertical stability roller is located between the first track wheel and the second track wheel.
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E05D 15/16 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane
60.
VERTICALLY STACKING PANEL DOOR WITH IMPROVED CURVED TRACK PORTIONS
In example implementations, a track of a vertically stacking door is provided. The track includes a vertical track, a first curved track portion, a second curved track portion, a first horizontal track portion coupled to the first curved track portion, and a second horizontal track portion coupled to the second curved track portion. The first curved track portion and the second curved track portion are split off from the vertical track and the first curved track portion and the second curved track portion each comprises multiple radii of curvature.
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
E05D 15/26 - Suspension arrangements for wings for folding wings
E06B 3/48 - Wings connected at their edges, e.g. foldable wings
In example implementations, a track of a vertically stacking door is provided. The track includes a vertical track, a first curved track portion, a second curved track portion, a first horizontal track portion coupled to the first curved track portion, and a second horizontal track portion coupled to the second curved track portion. The first curved track portion and the second curved track portion are split off from the vertical track and the first curved track portion and the second curved track portion each comprises multiple radii of curvature.
E06B 3/48 - Wings connected at their edges, e.g. foldable wings
E06B 9/04 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary of wing type, e.g. revolving or sliding
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
In example implementations, a header seal for a vertical stacking panel door is provided. The header seal includes a header channel and a seal plate. The header channel includes a body portion comprising a plurality of openings to receive a mechanical fastener and a lip portion coupled to the body portion. The seal plate includes a bracket comprising a plurality of openings to receive a mechanical fastener to connect the bracket to the top most vertical panel and a flexible member to contact the lip portion to form a seal against the lip of the header channel when the vertically stacking panel door is in a closed position.
E06B 3/48 - Wings connected at their edges, e.g. foldable wings
E06B 7/16 - Sealing arrangements on wings or parts co-operating with the wings
E06B 7/21 - Sealing arrangements on wings or parts co-operating with the wings by means of movable edgings, e.g. draught sealings additionally used for bolting automatically withdrawn when the wing is opened with sealing strip movable in plane of wing
E06B 7/22 - Sealing arrangements on wings or parts co-operating with the wings by means of elastic edgings, e.g. elastic rubber tubesSealing arrangements on wings or parts co-operating with the wings by means of resilient edgings, e.g. felt or plush strips, resilient metal strips
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
E06B 9/15 - Roller shutters with closing members formed of slats or the like
In example implementations, a header seal for a vertical stacking panel door is provided. The header seal includes a header channel and a seal plate. The header channel includes a body portion comprising a plurality of openings to receive a mechanical fastener and a lip portion coupled to the body portion. The seal plate includes a bracket comprising a plurality of openings to receive a mechanical fastener to connect the bracket to the top most vertical panel and a flexible member to contact the lip portion to form a seal against the lip of the header channel when the vertically stacking panel door is in a closed position.
E06B 3/48 - Wings connected at their edges, e.g. foldable wings
E06B 7/16 - Sealing arrangements on wings or parts co-operating with the wings
E06B 9/15 - Roller shutters with closing members formed of slats or the like
E06B 7/21 - Sealing arrangements on wings or parts co-operating with the wings by means of movable edgings, e.g. draught sealings additionally used for bolting automatically withdrawn when the wing is opened with sealing strip movable in plane of wing
E06B 7/22 - Sealing arrangements on wings or parts co-operating with the wings by means of elastic edgings, e.g. elastic rubber tubesSealing arrangements on wings or parts co-operating with the wings by means of resilient edgings, e.g. felt or plush strips, resilient metal strips
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
64.
Vertically stacking panel door with improved curved track portions
A track of a vertically stacking door includes a vertical track, a first curved track portion, a second curved track portion, a first horizontal track portion coupled to the first curved track portion, and a second horizontal track portion coupled to the second curved track portion. The first curved track portion and the second curved track portion are split off from the vertical track and the first curved track portion and the second curved track portion each comprises multiple radii of curvature.
E05D 15/20 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane movable out of one plane into a second parallel plane
In example implementations, a header seal for a vertical stacking panel door is provided. The header seal includes a header channel and a seal plate. The header channel includes a body portion comprising a plurality of openings to receive a mechanical fastener and a lip portion coupled to the body portion. The seal plate includes a bracket comprising a plurality of openings to receive a mechanical fastener to connect the bracket to the top most vertical panel and a flexible member to contact the lip portion to form a seal against the lip of the header channel when the vertically stacking panel door is in a closed position.
In example implementations, a track of a vertically stacking door is provided. The track includes a vertical track, a track coupling coupled to the vertical track, a first curved track portion coupled to the track coupling, a second curved track portion coupled to the track coupling, and a ramp coupled to the vertical track before the track coupling.
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
67.
VERTICALLY STACKING PANEL DOOR WITH CAM LEVERS AND IMPROVED RAMPS
In example implementations, a track of a vertically stacking door is provided. The track includes a vertical track, a track coupling coupled to the vertical track, a first curved track portion coupled to the track coupling, a second curved track portion coupled to the track coupling, and a ramp coupled to the vertical track before the track coupling.
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
In an example an overhead door track is provided. The overhead door track includes a vertical track section having an opening to receive a roller of a panel of an overhead door and to guide movement of the roller within the opening and a single solid polymer based vibration isolator coupled to the vertical track section to reduce vibration of the vertical track section caused by movement of the roller within the opening.
E05D 15/22 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane allowing an additional movement
F16F 15/08 - Suppression of vibrations of non-rotating, e.g. reciprocating, systemsSuppression of vibrations of rotating systems by use of members not moving with the rotating system using elastic means with rubber springs
In an example an overhead door track is provided. The overhead door track includes a vertical track section having an opening to receive a roller of a panel of an overhead door and to guide movement of the roller within the opening and a single solid polymer based vibration isolator coupled to the vertical track section to reduce vibration of the vertical track section caused by movement of the roller within the opening.
E06B 9/42 - Parts or details of roller blinds, e.g. suspension devices, blind boxes
E04B 1/00 - Constructions in generalStructures which are not restricted either to walls, e.g. partitions, or floors or ceilings or roofs
E04B 1/98 - Protection against other undesired influences or dangers against vibrations or shocksProtection against other undesired influences or dangers against mechanical destruction, e.g. by air-raids
In an example an overhead door track is provided. The overhead door track includes a vertical track section having an opening to receive a roller of a panel of an overhead door and to guide movement of the roller within the opening and a single solid polymer based vibration isolator coupled to the vertical track section to reduce vibration of the vertical track section caused by movement of the roller within the opening.
E04B 1/98 - Protection against other undesired influences or dangers against vibrations or shocksProtection against other undesired influences or dangers against mechanical destruction, e.g. by air-raids
E06B 1/56 - Fastening frames to the border of openings
In an example an overhead door track is provided. The overhead door track includes a vertical track section having an opening to receive a roller of a panel of an overhead door and to guide movement of the roller within the opening and a single solid polymer based vibration isolator coupled to the vertical track section to reduce vibration of the vertical track section caused by movement of the roller within the opening.
F16F 15/08 - Suppression of vibrations of non-rotating, e.g. reciprocating, systemsSuppression of vibrations of rotating systems by use of members not moving with the rotating system using elastic means with rubber springs
Examples of the present disclosure provide an overhead door panel. The overhead door panel includes a pair of parallel glass panes, a metal frame with parallel lateral stiles oriented perpendicular to the pair of parallel glass panes, a first seal system located at a first lateral stile, and a second seal system located at a second lateral stile, wherein the first seal system and the second seal system engage with at least one glass pane of the pair of parallel glass panes and a lateral stile of the parallel lateral stiles of the metal frame such that the first seal system and the second seal system are between the at least one glass pane and the lateral stile.
In example implementations, an adjustable speed operator governor release for a rolling fire shutter is provided. The adjustable speed operator governor release includes a shaft coupled to the rolling fire shutter, a gear on a first end of the shaft to engage a spring-loaded clutch during a fire, wherein the spring-loaded clutch is moved to disengage from a drive assembly and to engage the gear of the adjustable speed governor to operate the rolling fire shutter, and a linear speed adjusting mechanism coupled to the shaft and the gear to control a speed of free fall of the rolling fire shutter during the fire.
E06B 9/84 - Safety measures against dropping or unauthorised openingBraking or immobilising devicesDevices for limiting unrolling automatic against dropping
74.
IMPROVED OPERATOR GOVERNOR RELEASE FOR FIRE SHUTTERS
In example implementations, an adjustable speed operator governor release for a rolling fire shutter is provided. The adjustable speed operator governor release includes a shaft coupled to the rolling fire shutter, a gear on a first end of the shaft to engage a spring-loaded clutch during a fire, wherein the spring-loaded clutch is moved to disengage from a drive assembly and to engage the gear of the adjustable speed governor to operate the rolling fire shutter, and a linear speed adjusting mechanism coupled to the shaft and the gear to control a speed of free fall of the rolling fire shutter during the fire.
E06B 9/84 - Safety measures against dropping or unauthorised openingBraking or immobilising devicesDevices for limiting unrolling automatic against dropping
In example implementations, an adjustable speed operator governor release for a rolling fire shutter is provided. The adjustable speed operator governor release includes a shaft coupled to the rolling fire shutter, a gear on a first end of the shaft to engage a spring-loaded clutch during a fire, wherein the spring-loaded clutch is moved to disengage from a drive assembly and to engage the gear of the adjustable speed governor to operate the rolling fire shutter, and a linear speed adjusting mechanism coupled to the shaft and the gear to control a speed of free fall of the rolling fire shutter during the fire.
In example implementations, a guide member is provided. The guide member includes a first portion to receive a first fastener to a second guide member to form a guide assembly having a gap, wherein an endlock of a fire shutter is positioned within the gap, a second portion to receive a second fastener to a wall, a third portion folded against the second portion, a fourth portion bent at 90-degrees or greater to the third portion.
In example implementations, a guide member is provided. The guide member includes a first portion to receive a first fastener to a second guide member to form a guide assembly having a gap, wherein an endlock of a fire shutter is positioned within the gap, a second portion to receive a second fastener to a wall, a third portion folded against the second portion, a fourth portion bent at 90-degrees or greater to the third portion.
G01N 15/02 - Investigating particle size or size distribution
G01N 15/14 - Optical investigation techniques, e.g. flow cytometry
C12Q 1/04 - Determining presence or kind of microorganismUse of selective media for testing antibiotics or bacteriocidesCompositions containing a chemical indicator therefor
In example implementations, a guide member is provided. The guide member includes a first portion to receive a first fastener to a second guide member to form a guide assembly having a gap, wherein an endlock of a fire shutter is positioned within the gap, a second portion to receive a second fastener to a wall, a third portion folded against the second portion, a fourth portion bent at 90-degrees or greater to the third portion.
In example implementations, an apparatus is provided. The apparatus includes a connection interface, a LAN interface, a WAN interface, and a processor. The connection interface is to connect to a PCB of a door controller. The LAN interface is to communicate with a plurality of door sensors. The WAN interface is to communicate with a remote server of a service provider. The processor is communicatively coupled to the connection interface, the LAN interface, and the WAN interface. The processor is to receive door data from the plurality of door sensors via the LAN interface, transmit the door data to the remote server for analysis, receive a correction action from the remote server in response to the door data that is transmitted, and execute the corrective action on a door of the plurality of doors via the LAN interface.
In example implementations, a method is provided. The method includes determining, by a processor, that a vehicle is approaching a door of a building based on a velocity vector of the vehicle, calculating, by the processor, a time of arrival of the vehicle at the door based on the velocity vector of the vehicle and a distance of the vehicle from the door, and controlling, by the processor, the door to begin opening at a time based on the time of arrival and an amount of time for the door to open such that the door is opened when the vehicle arrives at the door.
In example implementations, a method is provided. The method includes determining, by a processor, that a vehicle is approaching a door of a building based on a velocity vector of the vehicle, calculating, by the processor, a time of arrival of the vehicle at the door based on the velocity vector of the vehicle and a distance of the vehicle from the door, and controlling, by the processor, the door to begin opening at a time based on the time of arrival and an amount of time for the door to open such that the door is opened when the vehicle arrives at the door.
In some embodiments, a nesting grille may include an alpha link having a top alpha link grommet, a beta link, and a plurality of cross members. In some embodiments, each of the plurality of cross members are coupled to at least one of the alpha link and the beta link. In one embodiment, the top alpha link grommet is configured to receive one of the plurality of cross members. In one embodiment, the grille is configured to be moveable between an extended state and a retracted state, the grille coiled about itself with the alpha link disposed inside of the beta link when the grille is in the retracted state.
E06B 5/11 - Doors, windows, or like closures for special purposesBorder constructions therefor for protection against air-raid or other war-like actionDoors, windows, or like closures for special purposesBorder constructions therefor for other protective purposes against burglary
In example implementations, a door monitoring sensor is provided. The door monitoring sensor includes a communication interface to transmit an alarm when a door operates outside of operational parameters of the door, an angular sensor to measure rotational movement of the a door, a movement sensor to detect movement along an x-y-z coordinate plane, a radar sensor to detect an object, a rechargeable power supply to provide power to the angular sensor, the movement sensor, and the radar sensor, and a processor. The processor is communicatively coupled to the communication interface, the angular sensor, the movement sensor, and the radar sensor. The processor is to determine that the door is moving outside of the operational parameters of the door and generate the alarm that is transmitted by the communication interface in response to determination that the door is moving outside of the operational parameters of the door.
G08B 13/08 - Mechanical actuation by opening, e.g. of door, of window, of drawer, of shutter, of curtain, of blind
E06B 5/11 - Doors, windows, or like closures for special purposesBorder constructions therefor for protection against air-raid or other war-like actionDoors, windows, or like closures for special purposesBorder constructions therefor for other protective purposes against burglary
E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
G08B 25/00 - Alarm systems in which the location of the alarm condition is signalled to a central station, e.g. fire or police telegraphic systems
A roll-up door including a flexible curtain having a front surface, a back surface, a first end coupled to a shaft, a second end opposite the first end, and first and second side edges extending between the first end and the second end, the flexible curtain being moveable between a retracted position wherein the flexible curtain is coiled around the shaft and a deployed position wherein the flexible curtain is uncoiled from the shaft. A first retention band is mounted along at least a portion of the first side edge of the flexible curtain, the first retention band including an inner surface at least partially facing towards the flexible curtain, an outer surface opposite the inner surface, a fixed edge attached to the flexible curtain generally parallel to the first side edge, and a free edge opposite the fixed edge and movable relative to the fixed edge.
In example implementations, a door monitoring sensor is provided. The door monitoring sensor includes a communication interface to transmit an alarm when a door operates outside of operational parameters of the door, an angular sensor to measure rotational movement of the a door, a movement sensor to detect movement along an x-y-z coordinate plane, a radar sensor to detect an object, a rechargeable power supply to provide power to the angular sensor, the movement sensor, and the radar sensor, and a processor. The processor is communicatively coupled to the communication interface, the angular sensor, the movement sensor, and the radar sensor. The processor is to determine that the door is moving outside of the operational parameters of the door and generate the alarm that is transmitted by the communication interface in response to determination that the door is moving outside of the operational parameters of the door.
E06B 5/11 - Doors, windows, or like closures for special purposesBorder constructions therefor for protection against air-raid or other war-like actionDoors, windows, or like closures for special purposesBorder constructions therefor for other protective purposes against burglary
G08B 13/08 - Mechanical actuation by opening, e.g. of door, of window, of drawer, of shutter, of curtain, of blind
In example implementations, a door monitoring sensor is provided. The door monitoring sensor includes a communication interface to transmit an alarm when a door operates outside of operational parameters of the door, an angular sensor to measure rotational movement of the a door, a movement sensor to detect movement along an x-y-z coordinate plane, a radar sensor to detect an object, a rechargeable power supply to provide power to the angular sensor, the movement sensor, and the radar sensor, and a processor. The processor is communicatively coupled to the communication interface, the angular sensor, the movement sensor, and the radar sensor. The processor is to determine that the door is moving outside of the operational parameters of the door and generate the alarm that is transmitted by the communication interface in response to determination that the door is moving outside of the operational parameters of the door.
G08B 13/08 - Mechanical actuation by opening, e.g. of door, of window, of drawer, of shutter, of curtain, of blind
E06B 5/11 - Doors, windows, or like closures for special purposesBorder constructions therefor for protection against air-raid or other war-like actionDoors, windows, or like closures for special purposesBorder constructions therefor for other protective purposes against burglary
In example implementations, a door monitoring sensor is provided. The door monitoring sensor includes a communication interface to transmit an alarm when a door operates outside of operational parameters of the door, an angular sensor to measure rotational movement of the a door, a movement sensor to detect movement along an x-y-z coordinate plane, a radar sensor to detect an object, a rechargeable power supply to provide power to the angular sensor, the movement sensor, and the radar sensor, and a processor. The processor is communicatively coupled to the communication interface, the angular sensor, the movement sensor, and the radar sensor. The processor is to determine that the door is moving outside of the operational parameters of the door and generate the alarm that is transmitted by the communication interface in response to determination that the door is moving outside of the operational parameters of the door.
G08B 13/08 - Mechanical actuation by opening, e.g. of door, of window, of drawer, of shutter, of curtain, of blind
E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
E06B 5/11 - Doors, windows, or like closures for special purposesBorder constructions therefor for protection against air-raid or other war-like actionDoors, windows, or like closures for special purposesBorder constructions therefor for other protective purposes against burglary
G08B 25/00 - Alarm systems in which the location of the alarm condition is signalled to a central station, e.g. fire or police telegraphic systems
In example implementations, a track system of a vertically stacking door includes a vertical track, a track coupling coupled to the vertical track, a first curved track portion coupled to the track coupling, a second curved track portion coupled to the track coupling, and a ramp coupled to the vertical track. The ramp interacts with a cam lever to separate adjacent panels of the vertically stacking door.
E05D 15/16 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E05D 13/00 - Accessories for sliding or lifting wings, e.g. pulleys, safety catches
E05D 15/06 - Suspension arrangements for wings for wings sliding horizontally more or less in their own plane
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
E05F 15/681 - Power-operated mechanisms for wings using electrical actuators using rotary electromotors for vertically-sliding wings for overhead wings operated by flexible elongated pulling elements, e.g. belts
06 - Common metals and ores; objects made of metal
07 - Machines and machine tools
19 - Non-metallic building materials
Goods & Services
(1) Metal sectional garage doors for use in buildings
(2) Electric garage door openers and closers
(3) Glass structured sectional garage door panels for use in buildings
In example implementations, a horizontal door guide for a vertically stacking door is provided. The horizontal door guide includes a first track and a second track to vertically stack panels of a door along a horizontal line, a drive shaft coupled to a bottom most panel to lift the door vertically, a Geneva drive shaft coupled to the drive shaft, and a lifting cam coupled to the Geneva drive shaft, wherein the lifting cam comprises a rotating lever to separate and lift adjacent panels of the door as the door is opened in a vertical direction by the drive shaft and to push panels into the first track and the second track.
E05D 15/16 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane
E05F 15/665 - Power-operated mechanisms for wings using electrical actuators using rotary electromotors for vertically-sliding wings
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
F16H 27/06 - Mechanisms with driving pins in driven slots, e.g. Geneva drives
In example implementations, a horizontal door guide for a vertically stacking door is provided. The horizontal door guide includes a first track and a second track to vertically stack panels of a door along a horizontal line, a drive shaft coupled to a bottom most panel to lift the door vertically, a Geneva drive shaft coupled to the drive shaft, and a lifting cam coupled to the Geneva drive shaft, wherein the lifting cam comprises a rotating lever to separate and lift adjacent panels of the door as the door is opened in a vertical direction by the drive shaft and to push panels into the first track and the second track.
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
Examples of the present disclosure provide an overhead door panel. The overhead door panel includes a pair of parallel glass panes, a metal frame with parallel lateral stiles oriented perpendicular to the pair of parallel glass panes, a first seal system located at a first lateral stile, and a second seal system located at a second lateral stile, wherein the first seal system and the second seal system engage with at least one glass pane of the pair of parallel glass panes and a lateral stile of the parallel lateral stiles of the metal frame such that the first seal system and the second seal system are between the at least one glass pane and the lateral stile.
In example implementations, a horizontal door guide for a vertically stacking door is provided. The horizontal door guide includes a first track and a second track to vertically stack panels of a door along a horizontal line, a drive shaft coupled to a bottom most panel to lift the door vertically, a Geneva drive shaft coupled to the drive shaft, and a lifting cam coupled to the Geneva drive shaft, wherein the lifting cam comprises a rotating lever to separate and lift adjacent panels of the door as the door is opened in a vertical direction by the drive shaft and to push panels into the first track and the second track.
E05F 15/686 - Power-operated mechanisms for wings using electrical actuators using rotary electromotors for vertically-sliding wings for overhead wings operated by flexible elongated pulling elements, e.g. belts by cables or ropes
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
In example implementations, an end cap is provided. The end cap includes a body portion comprising a top end, a bottom end, a front side, a back side, an inner side, and an outer side, a plurality of openings aligned between the inner side and the outer side to receive a mechanical fastener to connect to an end of the panel, a cam lever coupled to the top end, wherein the cam lever is to rotate around an axis to generate a lift force to lift and separate an adjacent panel, and a plurality of wheels coupled to the inner side, wherein the panel moves along a horizontal track via the plurality of wheels aligned with the horizontal track.
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E06B 3/00 - Window sashes, door leaves, or like elements for closing openingsLayout of fixed or moving closures, e.g. windowsFeatures of rigidly-mounted outer frames relating to the mounting of wing frames
E05D 15/26 - Suspension arrangements for wings for folding wings
In example implementations, an end cap is provided. The end cap includes a body portion comprising a top end, a bottom end, a front side, a back side, an inner side, and an outer side, a plurality of openings aligned between the inner side and the outer side to receive a mechanical fastener to connect to an end of the panel, a cam lever coupled to the top end, wherein the cam lever is to rotate around an axis to generate a lift force to lift and separate an adjacent panel, and a plurality of wheels coupled to the inner side, wherein the panel moves along a horizontal track via the plurality of wheels aligned with the horizontal track.
E05D 15/24 - Suspension arrangements for wings for wings sliding vertically more or less in their own plane consisting of parts connected at their edges
E05D 15/26 - Suspension arrangements for wings for folding wings
E06B 3/00 - Window sashes, door leaves, or like elements for closing openingsLayout of fixed or moving closures, e.g. windowsFeatures of rigidly-mounted outer frames relating to the mounting of wing frames
E06B 9/06 - Shutters, movable grilles, or other safety closing devices, e.g. against burglary collapsible or foldable, e.g. of the bellows or lazy-tongs type
Examples of the present disclosure provide an overhead door panel. The overhead door panel includes a pair of parallel glass panes, a metal frame with parallel lateral stiles oriented perpendicular to the pair of parallel glass panes, a first seal system located at a first lateral stile, and a second seal system located at a second lateral stile, wherein the first seal system and the second seal system engage with at least one glass pane of the pair of parallel glass panes and a lateral stile of the parallel lateral stiles of the metal frame such that the first seal system and the second seal system are between the at least one glass pane and the lateral stile.
Examples of the present disclosure provide an overhead door panel. The overhead door panel includes a pair of parallel glass panes, a metal frame with parallel lateral stiles oriented perpendicular to the pair of parallel glass panes, a first seal system located at a first lateral stile, and a second seal system located at a second lateral stile, wherein the first seal system and the second seal system engage with at least one glass pane of the pair of parallel glass panes and a lateral stile of the parallel lateral stiles of the metal frame such that the first seal system and the second seal system are between the at least one glass pane and the lateral stile.
