3.
INTEGRATED SWITCHING DEVICE AND MOTOR CONTROL SYSTEM
Provided are an integrated switching device and a motor control system. The integrated switching device includes main body housing, button mechanism, steering rod mechanism, and circuit board mechanism, wherein the button mechanism and the steering rod mechanism are matched and mounted on the main body housing, and a first rotation space and a second rotation space are arranged on a side surface of the button mechanism; the steering rod mechanism is provided with a locking plug, and the locking plug is unlocked by toggling the steering rod mechanism and is oriented towards the first rotation space or the second rotation space, so as to select a driven direction of an electric motor and to release safety locking, so that the button mechanism is able to slide downwardly; and the circuit board mechanism is mounted on the main body housing, and the button mechanism is matched to the circuit board mechanism.
The present disclosure provides an angle displacement sensing device and a measurement system, relating to the technical field of measurement, specifically. The angle displacement sensing device includes a main housing body, an induction circuit board, and a rotor assembly; the main housing body is provided with a rotor assembly accommodating cavity, and the induction circuit board is arranged inside the main housing body; the rotor assembly includes a rotor body and a magnet, the rotor body is rotatably mounted in the rotor assembly accommodating cavity, the magnet is arranged between the rotor body and the induction circuit board, and the magnet is fixedly mounted at one end of the rotor body. The angle displacement sensing device can achieve the technical effects of simplifying design and reducing costs.
G01D 5/14 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing the magnitude of a current or voltage
The present application relates to a non-contact control assembly using a magnetic sensor, including a control assembly housing; a magnetic sensor; a magnetic element; an actuator; a connection port, for establishing a power and signal connection with a motor control module; and a magnetic shielding shell, operably connected to the actuator, and the magnetic element being mounted to the actuator and located in the magnetic shielding shell. The magnetic shielding shell includes a three-dimensional closed loop structure having two open surfaces, in response to the movement of the actuator relative to the control assembly housing, the magnetic sensor is able to enter an interior of the magnetic shielding shell through one of the open surfaces of the magnetic shielding shell and move towards the other of the open surfaces of the magnetic shielding shell relative to the magnetic element in the interior of the magnetic shielding shell.
H02P 23/14 - Estimation or adaptation of motor parameters, e.g. rotor time constant, flux, speed, current or voltage
G01D 5/14 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing the magnitude of a current or voltage
G01D 5/16 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing the magnitude of a current or voltage by varying resistance
G01D 5/34 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using optical means, i.e. using infrared, visible or ultraviolet light with attenuation or whole or partial obturation of beams of light the beams of light being detected by photocells
H02P 23/20 - Controlling the acceleration or deceleration
Disclosed is an electrical switch unit for an electrical device, including a shell and a signaling module. The shell accommodates an actuator movably installed in the shell. The signaling module includes a circuit board, including a first region provided with a variable resistor element, the variable resistor element having a contact surface of the variable resistor element; a film, including a first film contact surface and a second film contact surface, the first film contact surface of the film having a first conducting layer and the conducting layer of the first film contact surface being spaced from the contact surface of the variable resistor element through a spacer element; and a moving component operably connected to the actuator and capable of promoting the conducting layer of the first film contact surface to form contact with the contact surface of the variable resistor element in a plurality of contact point structures.
An electrical switch unit for use with a variable speed electrical device includes a housing for a pair of electrical switching contacts, and an actuator operably connected with one of those contacts. A signaling module is associated with the electrical switch unit, and has signaling circuitry for sensing the movement of the actuator and outputting a signaling module signal indicative of the sensed movement or position of the actuator. A power module with a power switching device controllably supplies power from the DC power source to the DC motor at a speed corresponding to the sensed movement or position of the actuator. A control module receives the signaling module signal, and outputs a control module signal to control the power module.
H02P 7/29 - Arrangements for regulating or controlling the speed or torque of electric DC motors for regulating or controlling an individual DC dynamo-electric motor by varying field or armature current by master control with auxiliary power using discharge tubes or semiconductor devices using semiconductor devices controlling armature supply only using pulse modulation
B25F 5/00 - Details or components of portable power-driven tools not particularly related to the operations performed and not otherwise provided for
H02P 1/18 - Arrangements for starting electric motors or dynamo-electric converters for starting dynamo-electric motors or dynamo-electric converters for starting an individual DC motor
H02P 6/08 - Arrangements for controlling the speed or torque of a single motor
H03K 17/0412 - Modifications for accelerating switching without feedback from the output circuit to the control circuit by measures taken in the control circuit
H03K 17/687 - Electronic switching or gating, i.e. not by contact-making and -breaking characterised by the use of specified components by the use, as active elements, of semiconductor devices the devices being field-effect transistors
8.
MOTOR ENCODER WITH PROGRAMMABLE AND TACTILE FEEDBACK AND OPERATION METHOD THEREOF
The present invention provides a motor encoder with a programmable and tactile feedback and an operation method thereof. The encoder includes: a rotary knob; a motor for providing virtual stopping, virtual termination and virtual elastic loading when the knob is turned, and generating a tactile feedback and resistance in different events; a position sensor for providing position information when the knob is started and in a movement process; a controller with a motor driver, wherein the controller is electrically connected with the motor and the position sensor respectively and used for obtaining a position feedback from the position sensor and driving the motor to form closed-loop torque feedback control; and an input interface electrically connected with the controller and used for inputting instruction information to the controller.
H02K 11/21 - Devices for sensing speed or position, or actuated thereby
G01D 5/347 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using optical means, i.e. using infrared, visible or ultraviolet light with attenuation or whole or partial obturation of beams of light the beams of light being detected by photocells using displacement encoding scales
H02P 6/04 - Arrangements for controlling or regulating the speed or torque of more than one motor
9.
MOTOR ENCODER WITH PROGRAMMABILITY AND HAPTIC FEEDBACK AND OPERATION METHOD THEREFOR
The present invention provides a motor encoder with programmability and haptic feedback and an operation method therefor. The encoder comprises a rotatable knob; a motor used for providing virtual stop, virtual termination and virtual elastic loading when the knob is rotated, and generating haptic feedback and resistance in different events; a position sensor used for providing position information when the knob is started and in the motion process; a controller with a motor driver, electrically connected to the motor and the position sensor respectively and used for obtaining position feedback from the position sensor and driving the motor to form closed-loop torque feedback control; and an input interface electrically connected to the controller and used for inputting instruction information to the controller. Compared with conventional encoders, the motor encoder of the present invention provides excellent user experience and improved functions, and can also program to provide various haptic feedback configuration files, so that more intuitive and customizable user experience is realized.
G01D 5/347 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using optical means, i.e. using infrared, visible or ultraviolet light with attenuation or whole or partial obturation of beams of light the beams of light being detected by photocells using displacement encoding scales
The present invention relates to a linkage structure of a key switch. A second key and a fourth key share one bridge and are connected by a first connecting rod. When the second key or the fourth key is pressed down, the first connecting rod is pushed, so that a first bridge metal dome deforms and is connected to a common contact piece for conduction. A third key and a fifth key share one bridge and are connected by a second connecting. When the third key or the fifth key is pressed down, the second connecting rod is pushed, so that a second bridge metal dome deforms and is connected to the common contact piece for conduction. An input terminal is connected in series to a fuse, and the second key and the fourth key are connected in series to a diode so as to output a rectification half-wave.
H01H 9/26 - Interlocking, locking, or latching mechanisms for interlocking two or more switches
H01H 13/70 - Switches having rectilinearly-movable operating part or parts adapted for pushing or pulling in one direction only, e.g. push-button switch having a plurality of operating members associated with different sets of contacts, e.g. keyboard
The present application provides an air purifier comprising a main body, wherein the main body comprises: a housing, wherein an interior of the housing is hollow, an air inlet is formed at one end of the housing, an air outlet is formed at the other end of the housing, and positions of the air inlet and the air outlet are interchangeable; a fan mounted in the housing and used for sucking outside air from one end of the housing or for sucking outside air from the other end of the housing; a photocatalyst member mounted in the housing; and ultraviolet light-emitting members mounted in the housing, so that ultraviolet light emitted by the ultraviolet light-emitting members can effectively irradiate the photocatalyst member.
F24F 8/15 - Treatment, e.g. purification, of air supplied to human living or working spaces otherwise than by heating, cooling, humidifying or drying by separation, e.g. by filtering by chemical means
F24F 8/22 - Treatment, e.g. purification, of air supplied to human living or working spaces otherwise than by heating, cooling, humidifying or drying by sterilisation using UV light
Air purification units; Disinfectant apparatus for medical purposes; Electric air deodorizing apparatus; Filters and filtering devices for air and gas conditioning; Germicidal lamps for purifying air; Heating units for industrial purposes; LED (light emitting diode) lighting fixtures; Lighting installations; Lighting installations for vehicles; Multicookers
Balers for industrial use; Dishwashing machines; Electric food grinders for domestic use; Electric hand-held drills; Electrical drills; Electrical juice extractors for fruit; Metal working machines; Mixing machines; Pneumatic hand-held drills; Speed governors for machines, engines and motors
09 - Scientific and electric apparatus and instruments
Goods & Services
Apparatus and instruments for conveying, distributing, transforming, storing, regulating or controlling electric current; Burglar alarms; Computer mouse; Electric sensors; Electric switch plates; Lighting panel control boards; Piezoelectric switches; Remote control telemetering machines and apparatus; Voltage regulators; Wearable activity trackers
The present disclosure provides a switching device, which includes an electricity leading member, a power transmission member, and a conductive connecting member. The first end of the electricity leading member is configured to be electrically connected with the power supply terminal, and the second end of the electricity leading member is provided with a first contact portion; the power transmission member is provided with a second contact portion, and the second contact portion is configured to contact and be electrically connected with the first contact portion; one end of the conductive connecting member is connected with the electricity leading member, the other end is connected with the power transmission member, the electricity leading member is electrically connected with the power transmission member through the conductive connecting member.
A control assembly for use in controlling a speed of operation of an electric device, the control assembly including: a control assembly housing; a magnetic sensor; a magnetic element; an actuator that is configured for movement relative to the control assembly housing wherein responsive to said movement of the actuator relative to the control assembly housing, the magnetic sensor and magnetic element move relative to each other between at least one of a first position and a second position such that the magnetic sensor senses a first magnetic field reading when in the first position and senses a second magnetic field reading when in the second position; and, a control module operably connected to the magnetic sensor and configured for controlling the electric device to operate in at least one of a first speed and a second speed by reference to an output of the magnetic sensor indicative of the sensed first magnetic field reading and the second magnetic field reading respectively.
09 - Scientific and electric apparatus and instruments
Goods & Services
Microcontrollers; Batteries, electric; Computer joystick peripherals; Computer keyboards; Computer mouse; Computer peripherals; Computer terminals; Electric sensors; Electronic controllers for servo motors; Electronic controllers for vehicles; Input devices for computers; Joysticks for use with computers, other than for video games; Mouse mats; Mouse scanners; Power controllers; Programmable logic controllers; Remote control telemetering machines and apparatus; Remote controls for televisions; Replacement mouse feet; Switches, electric; Wireless computer mice; Wireless computer peripherals
09 - Scientific and electric apparatus and instruments
Goods & Services
Microcontrollers; Batteries, electric; Computer joystick peripherals; Computer keyboards; Computer mouse; Computer peripherals; Computer terminals; Electric sensors; Electronic controllers for servo motors; Electronic controllers for vehicles; Input devices for computers; Joysticks for use with computers, other than for video games; Mouse mats; Mouse scanners; Power controllers; Programmable logic controllers; Remote control telemetering machines and apparatus; Remote controls for televisions; Replacement mouse feet; Switches, electric; Wireless computer mice; Wireless computer peripherals
20.
Control assembly for use in operation of an electric device
A control assembly for controlling a speed or torque of operation of an electric device includes a control assembly housing, a magnetic sensor, a magnetic element; and an actuator. The actuator moves relative to the control assembly and, responsive to that movement, the magnetic sensor and magnetic element are moved relative to each other between a first position and a second position so that the magnetic sensor senses a first magnetic field reading when in the first position and senses a second magnetic field reading when in the second position. A control module is operably connected to the magnetic sensor and configured for controlling the electric device, and a magnetic shielding element is positioned within the control assembly housing to alleviate a magnetic signal source external to the control assembly from interfering with the sensing by the magnetic sensor.
G01D 5/14 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing the magnitude of a current or voltage
G01R 33/00 - Arrangements or instruments for measuring magnetic variables
Multicookers; Air-conditioning apparatus and installations; Air-conditioning installations; Air cooling apparatus; Air purifying apparatus and machines; Disinfectant apparatus; Electric air deodorizing apparatus; Electric food warmers; Electric radiators; Heating units for industrial purposes
09 - Scientific and electric apparatus and instruments
Goods & Services
Apparatus and instruments for conveying, distributing, transforming, storing, regulating or controlling electric current; Burglar alarms; Electric control panels; Electric installations for the remote control of industrial operations; Electric sensors; Electric switch plates; Medical weighing scales; Switches, electric; Voltage regulators for electric power; Wearable activity trackers
An snap-action type switch unit includes a switch housing; an actuator plunger configured for depressible movement via an aperture in the switch housing from a first position to a second position; a snap-action switch assembly which is operably-connected with the actuator plunger and responsive to the depressible movement of the actuator plunger so as to effect snap-action type movement of at least one movable contact between a normally opened position and a normally closed position with respect to at least one stationary contact in order to effect switching of electric power; and a signaling signaling assembly which is operably-connected with the actuator plunger and responsive to the depressible movement of the actuator plunger so as to effect movement of at least one movable conductive element of the signaling assembly amongst a plurality of different electrical contact point configurations with respect to at least one stationary conductive element of the signaling assembly.
H01H 5/00 - Snap-action arrangements, i.e. in which during a single opening operation or a single closing operation energy is first stored and then released to produce or assist the contact movement
H01H 3/38 - Driving mechanisms, i.e. for transmitting driving force to the contacts using spring or other flexible shaft coupling
H01H 5/06 - Energy stored by deformation of elastic members by compression or extension of coil springs
An electrical switch device including a switch housing having first and second compartments separated by a partition; an electrical switch assembly disposed in the second compartment; a control knob configured for seating adjacent to the first compartment, and having a user engagement portion and a plunger configured to extend from user engagement portion from the first compartment in to the second compartment via an opening in the partition separating the first and second compartments when the control knob is seated, and said plunger being configured for movable interaction with the electrical switch assembly; and a sealing member including a base portion configured for securing of the sealing member to the housing, and, a tubular portion extending from the base portion and configured to surround the plunger so as to alleviate ingress of liquid from the first compartment in to the second compartment via the opening in the partition.
H01H 23/28 - Tumbler or rocker switches, i.e. switches characterised by being operated by rocking an operating member in the form of a rocker button with three operating positions
Multicookers; Air-conditioning installations; Air purifying apparatus and machines; Disinfectant apparatus; Electric air deodorizing apparatus; Germicidal lamps for purifying air; Heating units for industrial purposes; LED (light emitting diode) lighting fixtures; Lighting apparatus for vehicles; Lighting apparatus, namely, lighting installations
09 - Scientific and electric apparatus and instruments
Goods & Services
Apparatus and instruments for conveying, distributing, transforming, storing, regulating or controlling electric current; Burglar alarms; Computer mouse; Electric control panels; Electric installations for the remote control of industrial operations; Electric sensors; Electric switch plates; Interactive touch screen terminals; Switches, electric; Wearable activity trackers
A sterilization mask, comprising: a mask body (100) and a sterilization component (200). The mask body (100) is provided with a sterilization chamber. The sterilization component (200) is provided in the sterilization chamber, and is configured to be capable of eliminating germs that enter the sterilization chamber. The sterilization component (200) is placed into the sterilization chamber in the mask body (100), and sterilization substances generated by the sterilization component (200) are used to eliminate microorganisms such as bacteria and virus that enter the sterilization chamber, which solves the technical problem in the prior art of the risk of being easy to become contaminated due to the fact that the traditional mask cannot protect against microorganisms such as bacteria and virus, and achieves the technical effect of improving the protective performance of the mask.
An electrical switch including a switch housing, a switch circuit disposed within the switch housing. The switch circuit including includes a movable contact member mounted on a contact lever and a stationary contact member. The contact lever is configured for operable-interaction with an actuator. The actuator is configured for movement along an actuator movement axis relative to the contact lever between at least one of an OFF position whereby the contact lever is configured for arrangement in to the first configuration whereby the switch circuit is opened, and, an ON position in which the contact lever is configured for arrangement in to the second configuration whereby the switch circuit is closed.
An electrical switch unit for use in controlling operation of an electrical device, the electrical switch unit including: an electrical switch unit housing for housing at least a pair of electrical switching contacts of the electrical switch unit, said electrical switch unit housing including a first housing member and a second housing member that are configured for attachment together at peripheral regions of the first and second housing members so as to cooperatively form an enclosed space for housing the pair of electrical switching contacts therein; an actuator member operably-connected with at least one of the pair of electrical switching contacts, the actuator being configured for movement relative inwardly and outwardly of an opening in the electrical switch unit housing so as to arrange the pair of electrical switching contacts into at least one of a closed configuration wherein power is able to be supplied from a power source to motor or other electrically-operable element of the electrical device via the pair of electrical switching contacts, and, an opened configuration wherein power is not able to be supplied from the power source to the motor or other electrically-operable element of the electrical device via the pair of electrical switching contacts; and an sealing element including an elastically-resilient polymeric material, said sealing element being configured for location between the first and second housing members and extending about the peripheral regions of the attached first and second housing members so as to occlude passage and ingress of particulates and water into the electrical switch unit housing.
A trigger switch assembly for use with an electrical device, including: a switch housing; a switch circuit disposed within the switch housing; an actuator rod configured for operable-interaction with a contact lever of the switch circuit; a trigger member having an actuator rod engagement recess configured for receiving a first end of the actuator rod therein, and, a finger-engagement portion configured for engagement by a user's finger so as to urge the actuator rod along the movement axis from the OFF position in to its ON position; and a lock-off mechanism.
B25F 5/02 - Construction of casings, bodies or handles
H01H 13/52 - Switches having rectilinearly-movable operating part or parts adapted for pushing or pulling in one direction only, e.g. push-button switch having a single operating member the contact returning to its original state immediately upon removal of operating force, e.g. bell push switch
34.
Variable-speed control assembly for an electric device
A variable-speed control assembly for use in controlling speed of an electric motor of an electric device, the variable-speed control assembly including: a housing; a speed signaling circuit module located within the housing including a pair of spaced-apart electrically-conductive stationary contact members and a movable electrically-conductive contact member configured for movement relative to the pair of stationary contact members between at least one of an OFF position in which the movable contact member does not electrically connect the pair of stationary contact members, and, a plurality of ON positions in which the movable contact member electrically connects the pair of stationary contact members such that an electric current supplied to the speed signaling circuit module from a power supply of the electric device is able to flow between the pair of stationary contact members via the movable contact member; wherein the movable contact member includes an elastically-deformable material configured for deforming in to a plurality of different deformed configurations when arranged in each of the plurality of ON positions such that a contact area between the movable contact member and the pair of stationary contact members will vary in each of the plurality of ON positions resulting in an amount of electrical resistance across the movable contact member varying when arranged in each of the plurality of ON positions relative to the pair of stationary contact members; and whereby said speed signaling circuit module is configured for producing different output electrical signals configured for use in controlling speed of operation of the electric motor by reference to the variable electrical resistance across the movable contact member when arranged in each of the ON positions.
A food processor for use in processing food matter, the food processor including: a receptable configured for holding food matter; an electric motor; a blade configured for being rotatably driven by the electric motor so that the blade is able to blend, mix, stir, agitate or chop the food matter within the receptacle; and a pulsing mode module configured for effecting pulsed operation of the food processor with variable speed or variable torque during blending, mixing, stirring, agitating or chopping of the food matter in the receptacle.
A47J 43/07 - Parts or details, e.g. mixing tools, whipping tools
A47J 43/046 - Machines for domestic use not covered elsewhere, e.g. for grinding, mixing, stirring, kneading, emulsifying, whipping or beating foodstuffs, e.g. power-driven with tools driven from the bottom side
A touch LED component and a touch device, and the touch LED component includes a metal cap, a touch button sheathed on an inner wall of the metal cap, and an LED lamp bead coupled to an inner wall of the touch button, a first through hole formed at the top of the metal cap, an induction pin installed at the bottom of the touch button, and an anode pin and a cathode pin installed on both sides of the bottom of the LED lamp bead respectively. The touch device includes a touch panel, a circuit board, and plural touch LED components. The touch LED component with high integration can be packaged by carrier tapes to facilitate automatic plug-ins and simplify production and assembling processes for mass production. The touch device has the features of simple structure, high reliability, good effect and long life.
An electrical switch unit for use with a variable speed electrical device includes a housing for a pair of electrical switching contacts, and an actuator operably connected with one of those contacts. A signaling module is associated with the electrical switch unit, and has signaling circuitry for sensing the movement of the actuator and outputting a signaling module signal indicative of the sensed movement or position of the actuator. A power module with a power switching device controllably supplies power from the DC power source to the DC motor at a speed corresponding to the sensed movement or position of the actuator. A control module receives the signaling module signal, and outputs a control module signal to control the power module.
H02P 7/29 - Arrangements for regulating or controlling the speed or torque of electric DC motors for regulating or controlling an individual DC dynamo-electric motor by varying field or armature current by master control with auxiliary power using discharge tubes or semiconductor devices using semiconductor devices controlling armature supply only using pulse modulation
H02P 1/18 - Arrangements for starting electric motors or dynamo-electric converters for starting dynamo-electric motors or dynamo-electric converters for starting an individual DC motor
H03K 17/0412 - Modifications for accelerating switching without feedback from the output circuit to the control circuit by measures taken in the control circuit
H03K 17/687 - Electronic switching or gating, i.e. not by contact-making and -breaking characterised by the use of specified components by the use, as active elements, of semiconductor devices the devices being field-effect transistors
B25F 5/00 - Details or components of portable power-driven tools not particularly related to the operations performed and not otherwise provided for
B25D 16/00 - Portable percussive machines with superimposed rotation
B23B 45/02 - Hand-held or like portable drilling machines, e.g. drill gunsEquipment therefor driven by electric power
B25F 5/00 - Details or components of portable power-driven tools not particularly related to the operations performed and not otherwise provided for
H01H 3/20 - Operating parts, i.e. for operating driving mechanism by a mechanical force external to the switch wherein an auxiliary movement thereof, or of an attachment thereto, is necessary before the main movement is possible or effective, e.g. for unlatching, for coupling
H01H 9/06 - Casing of switch constituted by a handle serving a purpose other than the actuation of the switch, e.g. by the handle of a vacuum cleaner
39.
Lock-off assembly for use in locking-off a trigger of an electrical device
A trigger assembly for an electrical device that includes a main body having a housing within which an electrical switch unit is disposed. The trigger assembly may include a trigger member having an engagement portion that is hingedly connected to the main body so that the trigger member is rotatable about a hinge relative to the main body. The trigger assembly may include an actuator member operably-connected to the trigger member that is movable between an OFF position and an ON position. The trigger assembly may include a lock-off mechanism including a lock-off member that is selectively operable to restrict movement of the trigger member towards the main body and to thereby restrict movement of the actuator member from the OFF position into the ON position, and, to not restrict movement of the trigger member toward the main body.
A control stick includes a control portion, a first electrical contact portion and a second electrical contact portion. The control portion has plural first moving contact points, the first electrical contact portion has a control board and plural first static contact points corresponding to the first moving contact points respectively, and a gap exists between the first moving contact point and the respective first static contact point. The first static contact points are electrically connected with the control board. When the control portion swings towards one of the first moving contact points, the first moving contact point is contacted and conducted with the first static contact point. This control stick is capable of achieving the control of a multiple of variables to meet the requirements of controlling a multiple variable in some occasions.
G06F 3/033 - Pointing devices displaced or positioned by the userAccessories therefor
G05G 9/047 - Manually-actuated control mechanisms provided with one single controlling member co-operating with two or more controlled members, e.g. selectively, simultaneously the controlling member being movable in different independent ways, movement in each individual way actuating one controlled member only in which movement in two or more ways can occur simultaneously the controlling member being movable by hand about orthogonal axes, e.g. joysticks
A covering for a trigger assembly of an electrical device, said covering being configured for at least partially covering a torsion spring of the trigger assembly so as to alleviate ingress of dust, water and other particulates in to contact with the torsion spring.
Disclosed is a rotary bridge micro-switch. The rotary bridge micro-switch comprises an insulating base, wherein a first terminal, a second terminal and a third terminal are arranged on the insulating base and are spaced from one another by the insulating base; and the insulating base is rotatably connected to a conducting plate having one end abutting against the first terminal. The rotary bridge micro-switch further comprises a spring having two ends respectively connected to the other end of the conducting plate and the insulating base. When the spring is not compressed, the first terminal is connected to the second terminal through the other end of the conducting plate. When the spring is compressed, the first terminal is connected to the third terminal. The rotary bridge micro-switch can be pressed to realize switching between two circuits.
H01H 13/52 - Switches having rectilinearly-movable operating part or parts adapted for pushing or pulling in one direction only, e.g. push-button switch having a single operating member the contact returning to its original state immediately upon removal of operating force, e.g. bell push switch
43.
Control knob with motion sensing for controlling operation of a machine
A control knob for controlling operation of a machine, the control knob including: an attachment surface configured for attaching the control knob to a surface of the machine; a display member comprising an electronic display module disposed thereon; a motion sensor configured for sensing motion of the user's hand, said sensor being operably-connected to the display member such that, responsive to the motion sensor sensing motion of the user's hand, the display member is configured to switch operation from a sleep mode into an active mode; an operational mode display controller for controlling display of operational modes of the machine upon the electronic display module, said operational mode display controller being configured for rotational movement around the electronic display module amongst a plurality of rotational positions, said operational mode display controller being operably connected with the electronic display module such that, responsive to the rotational movement of the operational mode display controller amongst the plurality of rotational positions, the electronic display module is configured to display a plurality of operational modes of the machine corresponding to the plurality of rotational positions; and an operational mode selector for controlling selection of one of the plurality of operational modes of the machine when said one of the plurality of operational modes is displayed on the electronic display module, the operational mode selector being configured for depressible movement to actuate selection of the operational mode displayed on the electronic display module.
G06F 3/0362 - Pointing devices displaced or positioned by the userAccessories therefor with detection of 1D translations or rotations of an operating part of the device, e.g. scroll wheels, sliders, knobs, rollers or belts
G06F 3/01 - Input arrangements or combined input and output arrangements for interaction between user and computer
G06F 3/041 - Digitisers, e.g. for touch screens or touch pads, characterised by the transducing means
G06F 3/04847 - Interaction techniques to control parameter settings, e.g. interaction with sliders or dials
G06F 3/04883 - Interaction techniques based on graphical user interfaces [GUI] using specific features provided by the input device, e.g. functions controlled by the rotation of a mouse with dual sensing arrangements, or of the nature of the input device, e.g. tap gestures based on pressure sensed by a digitiser using a touch-screen or digitiser, e.g. input of commands through traced gestures for inputting data by handwriting, e.g. gesture or text
A touch control human-machine interface for use in controlling operation of a machine, said interface including: an interface housing; a cover plate disposed on an outer-surface of the housing, said cover plate having a first electrically-conductive portion configured for touch interaction by a user's finger; a circuit assembly disposed within the housing, said circuit assembly including a circuit board having a second electrically-conductive portion and a light illumination module operably-connected thereto; a spacer element disposed between and separating the first conductive portion from the second conductive portion such that the first conductive portion, the second conductive portion and the spacer element are configured to form a capacitor device that is operably-connected with the circuit assembly; said first electrically-conductive portion being configured for deformation by the user's finger so as to cause a change in capacitance across the capacitor device, and whereby responsive to said change in capacitance, the circuit assembly is configured for generating a control signal for controlling operation of the machine, and, for controlling the light illumination module to propagate a light emission from the circuit assembly through the housing and cover plate so as to be visible externally of the housing.
G06F 3/02 - Input arrangements using manually operated switches, e.g. using keyboards or dials
G06F 3/044 - Digitisers, e.g. for touch screens or touch pads, characterised by the transducing means by capacitive means
G06F 3/0481 - Interaction techniques based on graphical user interfaces [GUI] based on specific properties of the displayed interaction object or a metaphor-based environment, e.g. interaction with desktop elements like windows or icons, or assisted by a cursor's changing behaviour or appearance
45.
Locking system for use with a trigger assembly of an electrical device
A trigger assembly having: a housing with a switch; a trigger; an actuator movable from OFF wherein the switch is operably-opened, towards ON wherein the switch is operably-closed; a lock-on mechanism including a first locking member mounted proximate the trigger and a second locking member mounted proximate the housing; when the actuator is ON, said locking members are movable relative to each other into a locked configuration; a lock-off mechanism including a lock-off member that is movable about a rotation axis between locked-off-position, which restricts movement of the trigger and the actuator is restricted from movement, and non-locked-off-position, which does not restrict movement of the trigger and the actuator member is not restricted from movement; and a shaped-portion disposed proximate the housing that abuts the lock-off member when the trigger is moved towards the housing with the lock-off member in the locked-off-position, whereby the actuator is restricted from movement.
B25F 5/02 - Construction of casings, bodies or handles
H01H 3/20 - Operating parts, i.e. for operating driving mechanism by a mechanical force external to the switch wherein an auxiliary movement thereof, or of an attachment thereto, is necessary before the main movement is possible or effective, e.g. for unlatching, for coupling
H01H 9/06 - Casing of switch constituted by a handle serving a purpose other than the actuation of the switch, e.g. by the handle of a vacuum cleaner
H01H 19/36 - Switches operated by an operating part which is rotatable about a longitudinal axis thereof and which is acted upon directly by a solid body external to the switch, e.g. by a hand the operating part having only two operative positions, e.g. relatively displaced by 180°
H01H 9/20 - Interlocking, locking, or latching mechanisms
46.
Control knob for controlling operation of a machine
A control knob for operating a machine including: a member for attaching the knob to the machine, a display member including an electronic display module, an operational mode display controller for controlling display of operational modes upon the display module and configured for rotational movement around the display module amongst rotational positions. The display controller operably connected with the display module such that, responsive to the rotational movement of the display controller amongst the rotational positions, the display module is configured to display operational modes of the machine corresponding to the rotational positions. The control knob including an operational mode selector for selection of one of the operational modes of the machine when the one operational mode is displayed on the display module. The operational mode selector configured for movement between a first position and a second position to actuate selection of the operational mode displayed on the display module.
G06F 3/0362 - Pointing devices displaced or positioned by the userAccessories therefor with detection of 1D translations or rotations of an operating part of the device, e.g. scroll wheels, sliders, knobs, rollers or belts
G06F 3/041 - Digitisers, e.g. for touch screens or touch pads, characterised by the transducing means
A snap-action switch including: a housing in which a plurality of fixed contacts and a plurality of movable contacts are disposed therein, a plunger configured for depressible movement via an aperture in the housing from a first position in which the plunger is relatively extended outwardly of the housing via the aperture, into, a second position in which the plunger is relatively retracted inwardly of the housing via the aperture; and a snap-action assembly operably-connected with the plunger, the snap-action assembly being responsive to depressible movement of the plunger so as to effect snap-action type movement of the plurality of movable contacts between normally opened and normally closed positions with respect to the fixed contacts; a sealing element configured for arrangement around the plunger to occlude ingress of particulates, dust and water from entering the housing via the aperture, the sealing element including a flanged portion; and a securement element configured for arrangement around the sealing element, wherein the securement element is shaped and dimensioned for interference fitting or snap-fitting with a rim of the aperture whereby the flanged portion of the sealing element is secured between the securement element and the rim of the aperture so as to restrict removal of the sealing element from the housing.
H01H 13/50 - Switches having rectilinearly-movable operating part or parts adapted for pushing or pulling in one direction only, e.g. push-button switch having a single operating member
48.
Control knob for controlling operation of a machine
A control button for controlling operation a machine including: an attachment member for attaching the control button to the machine; a display member including an electronic display module; an operational mode display controller for controlling display of operational modes of the machine upon the electronic display module, the operational mode display controller being operably connected with the electronic display module so that, in response to the operational mode display controller, the electronic display module is configured to display a plurality of operational modes of the machine; and an operational mode selector for controlling selection of one of the operational modes of the machine when one of the operational modes are displayed on the electronic display module, the operational mode selector being configured for movement between at least a first position and a second position to actuate selection of the operational mode displayed on the electronic display module.
B60K 37/06 - Arrangement of fittings on dashboard of controls, e.g. control knobs
G06F 3/0362 - Pointing devices displaced or positioned by the userAccessories therefor with detection of 1D translations or rotations of an operating part of the device, e.g. scroll wheels, sliders, knobs, rollers or belts
H01H 25/06 - Operating part movable both angularly and rectilinearly, the rectilinear movement being along the axis of angular movement
H01H 9/18 - Distinguishing marks on switches, e.g. for indicating switch location in the darkAdaptation of switches to receive distinguishing marks
G06F 3/038 - Control and interface arrangements therefor, e.g. drivers or device-embedded control circuitry
G06F 3/0354 - Pointing devices displaced or positioned by the userAccessories therefor with detection of 2D relative movements between the device, or an operating part thereof, and a plane or surface, e.g. 2D mice, trackballs, pens or pucks
G06F 3/0482 - Interaction with lists of selectable items, e.g. menus
G06F 3/0488 - Interaction techniques based on graphical user interfaces [GUI] using specific features provided by the input device, e.g. functions controlled by the rotation of a mouse with dual sensing arrangements, or of the nature of the input device, e.g. tap gestures based on pressure sensed by a digitiser using a touch-screen or digitiser, e.g. input of commands through traced gestures
H01H 13/52 - Switches having rectilinearly-movable operating part or parts adapted for pushing or pulling in one direction only, e.g. push-button switch having a single operating member the contact returning to its original state immediately upon removal of operating force, e.g. bell push switch
G06F 3/01 - Input arrangements or combined input and output arrangements for interaction between user and computer
A control system for use in controlling operation of an electrical appliance, including: an electrical appliance housing having a control module; and a power source; a control knob including: an attachment element configured for releasably attaching the control knob to an outer surface of the housing; and an input/output module; a wireless power transfer system configured for wirelessly transferring power from the power source through the electrical appliance housing and to the input/output module for use in powering the input/output module; and a wireless control signaling module configured for wirelessly communicating a control signal from the control knob through the housing to the control module within the electrical appliance housing, said control signal received by the control module being indicative of an operational position/state of the control knob, and whereby said control module is configured for controlling operation of the electrical appliance by reference to the received wireless control signal.
H02J 3/14 - Circuit arrangements for ac mains or ac distribution networks for adjusting voltage in ac networks by changing a characteristic of the network load by switching loads on to, or off from, network, e.g. progressively balanced loading
G05B 15/02 - Systems controlled by a computer electric
G05B 19/042 - Programme control other than numerical control, i.e. in sequence controllers or logic controllers using digital processors
A warning device for use with a computerised warning system, the warning device including: a securement mechanism configured for arrangement between at least one of a secured configuration wherein the securement mechanism is configured to secure the warning device to a person's body, or to an item of clothing or accessory worn or carried on the person's body, and, an unsecured configuration wherein the securement mechanism is configured to allow release of the warning device from securement to the person's body, or to the item of clothing or accessory worn or carried on the person's body; a sensor module configured for sensing when the securement mechanism has been arranged in to the unsecured configuration, and, for sensing at least one type of interaction with the warning device when the securement mechanism has been arranged in the unsecured configuration; and a communication module communicably-connected with a computer server of the computerised system and configured for communicating information to the computer server indicative of the securement mechanism being arranged in to the unsecured configuration and indicative of the at least one type of interaction with the warning device that is sensed by the sensor module, and whereby in response to receiving the information form the communication module, the computer server is configured for communicating a predetermined warning message corresponding to the received information.
G08B 25/01 - Alarm systems in which the location of the alarm condition is signalled to a central station, e.g. fire or police telegraphic systems characterised by the transmission medium
51.
Control system and device for use in controlling operation of an electrical appliance
A control system for use in controlling operation of an electrical appliance, the system including: a processor module disposed inside of a housing of the electrical appliance, the processor module including at least one contactless-type sensor operably-connected with the processor module; an input control module including: an attachment element configured for releasably attaching the input control module to an outer surface of the housing; and at least one sensor-readable element configured for contactless-interaction with the contactless-type sensor.
G06F 3/0362 - Pointing devices displaced or positioned by the userAccessories therefor with detection of 1D translations or rotations of an operating part of the device, e.g. scroll wheels, sliders, knobs, rollers or belts
G06F 3/044 - Digitisers, e.g. for touch screens or touch pads, characterised by the transducing means by capacitive means
G06F 3/0338 - Pointing devices displaced or positioned by the userAccessories therefor with detection of limited linear or angular displacement of an operating part of the device from a neutral position, e.g. isotonic or isometric joysticks
G06F 3/0482 - Interaction with lists of selectable items, e.g. menus
52.
Locking system for use with a trigger assembly of an electrical device
A trigger assembly for use with an electrical device, including a trigger member, an actuator member operably-connected to the trigger member, and a lock-on mechanism for selectably restricting movement of the trigger member relative to the housing.
B25F 5/02 - Construction of casings, bodies or handles
H01H 21/10 - Casing of switch constituted by a handle serving a purpose other than the actuation of the switch
H01H 19/03 - Means for limiting the angle of rotation of the operating part
H01H 9/06 - Casing of switch constituted by a handle serving a purpose other than the actuation of the switch, e.g. by the handle of a vacuum cleaner
H01H 3/20 - Operating parts, i.e. for operating driving mechanism by a mechanical force external to the switch wherein an auxiliary movement thereof, or of an attachment thereto, is necessary before the main movement is possible or effective, e.g. for unlatching, for coupling
H01H 19/635 - Contacts actuated by rectilinearly-movable member linked to operating part, e.g. by pin and slot
A knob with a display function includes a chassis with a knob ring and a rotary sensor. A display screen, a control circuit board, a reset device and a functional connection board are sequentially installed onto the chassis. A circuit board bracket is installed between the display screen and the control circuit board. The functional connection board has a confirm button, a connection terminal disposed on the back of the functional connection board. The reset device has a through hole for extending the confirm button to the outside, an end abutting and connecting the control circuit board and the other end abutting and connecting the functional connection board. This invention has the features of simple structure and reasonable design and selects a function by turning the knob ring. With the reset device, the application of the invention has high reliability and provides easy identification.
H01H 19/06 - Dustproof, splashproof, drip-proof, waterproof, or flameproof casings
H01H 19/02 - Switches operated by an operating part which is rotatable about a longitudinal axis thereof and which is acted upon directly by a solid body external to the switch, e.g. by a hand Details
54.
Detection circuit module for use in detecting an operational status of a household appliance door
A detection circuit module for use with a household appliance door to detect when the door is closed and/or locked, the detection circuit module having a first and a second contact configured for electrical connection with the household appliance door so as to be operable with the household appliance door, the detection circuit module including: a door closing switch arranged electrically in series between the first connecting contact and an actuator; a door locking switch arranged electrically in series between the actuator member and the second connecting contact; and a diode arranged in series with the actuator and the second connecting contact and the diode being arranged electrically in parallel with the door locking switch.
H01H 47/00 - Circuit arrangements not adapted to a particular application of the relay and designed to obtain desired operating characteristics or to provide energising current
E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
H01H 47/22 - Circuit arrangements not adapted to a particular application of the relay and designed to obtain desired operating characteristics or to provide energising current for supplying energising current for relay coil
D06F 39/14 - Doors or coversSecuring means therefor
G01R 31/50 - Testing of electric apparatus, lines, cables or components for short-circuits, continuity, leakage current or incorrect line connections
D06F 37/42 - Safety arrangements, e.g. for stopping rotation of the receptacle upon opening of the casing door
D06F 33/00 - Control of operations performed in washing machines or washer-dryers
55.
Control assembly for use in operation of an electric device
A control assembly for use in controlling a speed of operation of an electric device, the control assembly including: a control assembly housing; a magnetic sensor; a magnetic element; an actuator that is configured for movement relative to the control assembly housing wherein responsive to said movement of the actuator relative to the control assembly housing, the magnetic sensor and magnetic element move relative to each other between at least one of a first position and a second position such that the magnetic sensor senses a first magnetic field reading when in the first position and senses a second magnetic field reading when in the second position; and, a control module operably connected to the magnetic sensor and configured for controlling the electric device to operate in at least one of a first speed and a second speed by reference to an output of the magnetic sensor indicative of the sensed first magnetic field reading and the second magnetic field reading respectively.
An electrical switch unit for use with an electrical device to control operation of a DC motor of the electrical device, the electrical switch unit comprising: a housing which houses a pair of electrical switching contacts, and, an actuator operably connected with at least one of the pair of electrical switching contacts, the actuator being configured for movement relative to the pair of electrical switching contacts so as to arrange the pair of electrical switching contacts into at least one of a closed configuration wherein power is able to be supplied from the DC power source to the DC motor via the pair of electrical switching contacts, and, an opened configuration wherein power is not able to be supplied from the DC power source to the DC motor via the pair of electrical switching contacts; a signaling module associated with the electrical switch unit comprising signaling circuitry for sensing the movement of the actuator and outputting a signaling module signal indicative of the sensed movement or position of the actuator; a power module comprising at least one power switching device for controllably supplying power from the DC power source to the DC motor; a control module comprising control circuitry for receiving the signaling module signal, and responsive to the received signaling module signal, outputting a control module signal to control the at least one power switching transistor device of the power module wherein the at least one power switching device controllably supplies power from the DC power source to the DC motor to allow operation of the DC motor at a speed corresponding to the sensed movement or position of the actuator; and wherein, the signaling module is integrally connected to a first end of the control module that is located within the electrical switch unit housing to allow relatively direct electrical communication between the pair of electrical switching contacts and the control module, and, whereby the control module is configured to extend outwardly of the electrical switch housing so as to terminate at a distal second end.
H02P 7/29 - Arrangements for regulating or controlling the speed or torque of electric DC motors for regulating or controlling an individual DC dynamo-electric motor by varying field or armature current by master control with auxiliary power using discharge tubes or semiconductor devices using semiconductor devices controlling armature supply only using pulse modulation
H02P 1/18 - Arrangements for starting electric motors or dynamo-electric converters for starting dynamo-electric motors or dynamo-electric converters for starting an individual DC motor
H03K 17/0412 - Modifications for accelerating switching without feedback from the output circuit to the control circuit by measures taken in the control circuit
H03K 17/687 - Electronic switching or gating, i.e. not by contact-making and -breaking characterised by the use of specified components by the use, as active elements, of semiconductor devices the devices being field-effect transistors
B25F 5/00 - Details or components of portable power-driven tools not particularly related to the operations performed and not otherwise provided for
A transducer device including: a base platform; an annular support member mounted on a surface of the base platform, the annular support member having a first opening positioned adjacent the surface of the base platform and a second opening positioned away from the surface of the base platform along a rotation axis; an inner shaft mounted relative to the base platform and configured to extend away from the second opening of the annular support member and rotate relative to the annular support member about the rotation axis; an inner shaft detent mechanism located at least partially within the annular support member configured for releasably securing the inner shaft in a plurality of rotational positions corresponding to each of a plurality of detent positions of the inner shaft detent mechanism as the inner shaft is rotated about the rotation axis; an outer shaft including a passage extending along an elongate axis thereof configured for receiving the inner shaft therein so that the inner shaft and outer shaft are arranged to rotate concentrically relative to each other about the rotation axis, the outer shaft further including a flanged portion configured for seating upon an outer surface of the annular support member; a PCB unit disposed on the surface of the base platform comprising: a first transducer circuit unit operably coupled to the inner shaft and responsive to rotational movement of the inner shaft about the rotation axis so that the first transducer circuit unit outputs a first electrical signal that is indicative of a rotational position of the inner shaft about the rotational axis; a second transducer circuit unit operably coupled to the outer shaft and responsive to rotational movement of the outer shaft about the rotation axis so that the second transducer circuit unit will output a second electrical signal that is indicative of a rotational position of the outer shaft about the rotational axis; a housing configured for enclosing the first and second transducer circuit units therein and having an opening disposed in a wall of the housing via which ends of the inner and outer shafts may extend outwardly of the housing along the rotation axis; and an outer shaft detent mechanism located between the outer shaft and an inner surface of the housing configured for releasably securing the outer shaft in a plurality of rotational positions corresponding to each of a plurality of detent positions of the outer shaft detent mechanism as the outer shaft is rotated about the rotation axis.
G05G 5/06 - Means for preventing, limiting or returning the movements of parts of a control mechanism, e.g. locking controlling member for holding members in one or a limited number of definite positions only
G05G 1/10 - Details, e.g. of discs, knobs, wheels or handles
H01H 19/54 - Switches operated by an operating part which is rotatable about a longitudinal axis thereof and which is acted upon directly by a solid body external to the switch, e.g. by a hand the operating part having at least five or an unspecified number of operative positions
G05G 1/08 - Controlling members for hand-actuation by rotary movement, e.g. hand wheels
58.
Contact lever for use in an electrical switch assembly
A contact lever for use in an electrical switch assembly so as to allow selectable movement within the switch assembly of a contact lever contact member from electrical connection with a first stationary contact member into electrical connection with a second stationary contact member, the contact lever including: first and second lever arms that are connected at respective first ends to the contact lever contact member; said first and second lever arms having respective second ends, and, said first and second lever arms being configured to extend away from the contact member and to terminate at their respective second ends; a gap disposed between the first and second lever arms which separates the first and second lever arms as they extend away from the contact member, and wherein the gap is configured to allow movement of a spring element of the switch assembly therethrough; and a bridge member configured for connection with the first and second lever arms so as to traverse the gap separating the first and second lever arms.
A variable-speed controller for use with an electric device including: a variable resistor element having a variable resistor element contact surface; a membrane including a first membrane contact surface spaced-apart from the variable resistor element contact surface by a spacer element, and, a second membrane contact surface; a slider configured for slidable movement along the second membrane contact surface wherein responsive to the slider slidably moving along the second membrane contact surface, the first membrane contact surface is able to be urged into contact with the variable resistor element contact surface in a plurality of contact point configurations whereby the effective resistance of the variable resistor element is configured to change in response to the first membrane contact surface being urged into contact with the variable resistor element contact surface in each of the plurality of contact point configurations.
H02P 7/06 - Arrangements for regulating or controlling the speed or torque of electric DC motors for regulating or controlling an individual DC dynamo-electric motor by varying field or armature current
H01C 10/38 - Adjustable resistors the contact sliding along resistive element the contact moving along a straight path
H01C 10/30 - Adjustable resistors the contact sliding along resistive element
H02P 6/06 - Arrangements for speed regulation of a single motor wherein the motor speed is measured and compared with a given physical value so as to adjust the motor speed
H02P 7/29 - Arrangements for regulating or controlling the speed or torque of electric DC motors for regulating or controlling an individual DC dynamo-electric motor by varying field or armature current by master control with auxiliary power using discharge tubes or semiconductor devices using semiconductor devices controlling armature supply only using pulse modulation
H02P 9/14 - Arrangements for controlling electric generators for the purpose of obtaining a desired output by variation of field
60.
Battery pack system for electrically connecting a battery pack to a machine
A battery pack system for use in connecting a battery pack to a battery pack receiving member of a machine so that the battery pack is operable to supply a suitable amount of power to the machine for operation of the machine via an electrical circuit path that is configurable for electrically connecting the battery pack to the machine, the system including: a first electrical connector member disposed along a first region of the electrical circuit path; and a second electrical connector member; wherein, responsive to the battery pack being connected to the battery pack receiving member of the machine, the second electrical connector member is configured for movement relative to the first electrical connector member to cooperatively form a first configuration which electrically closes the electrical circuit path via which the suitable amount of power is able to be supplied from the battery pack to the machine; and wherein, responsive to the battery pack being disconnected from the battery pack receiving member of the machine, the second electrical connector member is configured for movement relative to the first electrical connector member to cooperatively form a second configuration which electrically opens the electrical circuit path via which the suitable amount of power is not able to be supplied from the battery pack to the machine.
H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries
B25F 5/02 - Construction of casings, bodies or handles
H01M 2/10 - Mountings; Suspension devices; Shock absorbers; Transport or carrying devices; Holders
H02H 7/18 - Emergency protective circuit arrangements specially adapted for specific types of electric machines or apparatus or for sectionalised protection of cable or line systems, and effecting automatic switching in the event of an undesired change from normal working conditions for batteriesEmergency protective circuit arrangements specially adapted for specific types of electric machines or apparatus or for sectionalised protection of cable or line systems, and effecting automatic switching in the event of an undesired change from normal working conditions for accumulators
H01M 2/34 - Current-conducting connections for cells with provision for preventing undesired use or discharge
61.
Control knob for controlling operation of a machine
A control knob for controlling operation of a machine, the control knob including: an attachment member configured for attaching the control knob to a surface of the machine so that the control knob is operably connectable with the machine to control operation thereof; a display member comprising an electronic display module disposed thereon; an operational mode display controller for controlling display of operational modes of the machine upon the electronic display module, said operational mode display controller being configured for rotational movement around the electronic display module amongst a plurality of rotational positions, said operational mode display controller being operably connected with the electronic display module such that, responsive to the rotational movement of the operational mode display controller amongst the plurality of rotational positions, the electronic display module is configured to display a plurality of operational modes of the machine corresponding to the plurality of rotational positions; and an operational mode selector for controlling selection of one of the plurality of operational modes of the machine when said one of the plurality of operational modes is displayed on the electronic display module, the operational mode selector being configured for movement between at least a first position and a second position to actuate selection of the operational mode displayed on the electronic display module.
G06F 3/0362 - Pointing devices displaced or positioned by the userAccessories therefor with detection of 1D translations or rotations of an operating part of the device, e.g. scroll wheels, sliders, knobs, rollers or belts
H01H 25/06 - Operating part movable both angularly and rectilinearly, the rectilinear movement being along the axis of angular movement
H01H 9/18 - Distinguishing marks on switches, e.g. for indicating switch location in the darkAdaptation of switches to receive distinguishing marks
G06F 3/038 - Control and interface arrangements therefor, e.g. drivers or device-embedded control circuitry
G06F 3/0354 - Pointing devices displaced or positioned by the userAccessories therefor with detection of 2D relative movements between the device, or an operating part thereof, and a plane or surface, e.g. 2D mice, trackballs, pens or pucks
G06F 3/0482 - Interaction with lists of selectable items, e.g. menus
G06F 3/0488 - Interaction techniques based on graphical user interfaces [GUI] using specific features provided by the input device, e.g. functions controlled by the rotation of a mouse with dual sensing arrangements, or of the nature of the input device, e.g. tap gestures based on pressure sensed by a digitiser using a touch-screen or digitiser, e.g. input of commands through traced gestures
H01H 13/52 - Switches having rectilinearly-movable operating part or parts adapted for pushing or pulling in one direction only, e.g. push-button switch having a single operating member the contact returning to its original state immediately upon removal of operating force, e.g. bell push switch
G06F 3/01 - Input arrangements or combined input and output arrangements for interaction between user and computer
A sealing assembly for prevention of ingress of particulates and water into an electrical switch includes an engagement element with a rigid first abutment portion for circumscribing an aperture extending through the outer surface of the switch housing and a rigid first retention portion. Also included is a sealing element being slidingly engageable with the engagement element that includes a first complementary abutment portion. The sealing element is formed from an elastically resilient polymeric material so that sealing engagement with the engagement element occludes passage and ingress of external particulates, dust and water.
Provided is a waterproof toggle switch, which includes a panel, a shift lever, a fixed contact and an elastic element. The panel is provided with an opening portion, with the opening portion running through the panel, between a front wall surface and a rear wall surface of the panel. The shift lever is rotatably held in the opening portion of the panel, and the shift lever includes a rotation center portion, a driving portion and an operation portion. A fit clearance between the rotation center portion and the opening portion ranges from 0.02 mm to 0.2 mm. By providing the panel with the opening portion and providing the shift lever with the rotation center portion, and by controlling the fit clearance between the opening portion and the rotation center portion, a waterproof toggle switch having superperformance and a low cost is provided.
A lockable trigger mechanism for an electrical device, comprising: a housing; a trigger for biased movement relative to the housing; an actuator movably mounted to the housing such that in response to operation of the trigger, the actuator is movable along a movement axis from an OFF position inwardly of the housing towards an ON position, and movable along the movement axis from the ON position in a direction outwardly of the housing towards the OFF position; an electrical switch unit mounted to the housing for activation in response to movement of the actuator along the movement axis between its ON and OFF positions to close and open an electrical circuit of the electrical device respectively; and a locking mechanism comprising a first locking member, a second locking member and a biasing member configured for biasing movement of the first locking member relative to the second locking member.
H01H 3/20 - Operating parts, i.e. for operating driving mechanism by a mechanical force external to the switch wherein an auxiliary movement thereof, or of an attachment thereto, is necessary before the main movement is possible or effective, e.g. for unlatching, for coupling
H01H 13/08 - Casing of switch constituted by a handle serving a purpose other than the actuation of the switch
H01H 13/56 - Switches having rectilinearly-movable operating part or parts adapted for pushing or pulling in one direction only, e.g. push-button switch having a single operating member the contact returning to its original state upon the next application of operating force
H01H 9/06 - Casing of switch constituted by a handle serving a purpose other than the actuation of the switch, e.g. by the handle of a vacuum cleaner
An electrical switch includes a fixed electrical contact; a movable electrical contact which is moveable relative to thereto between an ON position in contact with and, an OFF position out of contact with, the fixed electrical contact; a contact mover movably coupled to a terminal member moveable relative thereto so as to move the movable electrical contact between the ON and OFF positions; a biasing member coupling the contact mover and the terminal member together such that said biasing member acts upon the contact mover as the contact mover moves the movable electrical contact relative to the fixed electrical contact between the ON and OFF positions; wherein in the ON position, electrical current flows along a path comprising the terminal member, contact mover and movable electrical contact in series, and, an electrical insulation member arranged in series with the biasing member between the contact mover and the terminal member.
H01H 3/38 - Driving mechanisms, i.e. for transmitting driving force to the contacts using spring or other flexible shaft coupling
H02H 3/08 - Emergency protective circuit arrangements for automatic disconnection directly responsive to an undesired change from normal electric working condition, with or without subsequent reconnection responsive to excess current
66.
Push-button switch capable of adjusting output power
A push-button switch capable of adjusting output power includes a housing. The housing includes a contact assembly and a power adjustment assembly therein. The contact assembly includes an upper terminal, a lower terminal and a connecting elastic plate below the upper terminal. A support seat is provided in the housing. An upper end of the support seat is provided with a first bracket. The first bracket is inserted through the connecting elastic plate. The first bracket is provided with a first slot. One end of the connecting elastic plate is fixedly connected to the upper terminal. Another end of the connecting elastic plate is engaged with the first slot. A drive mechanism is provided above the connecting elastic plate for driving the connecting elastic plate downward. The push-button switch has an ergonomic design.
H01H 13/26 - Snap-action arrangements depending upon deformation of elastic members
H01H 13/38 - Single blade moved across dead-centre position
H01H 13/42 - Blade spring with at least one snap-acting leg and at least one separate contactcarrying or contact-actuating leg having three legs
H01H 13/50 - Switches having rectilinearly-movable operating part or parts adapted for pushing or pulling in one direction only, e.g. push-button switch having a single operating member
H03K 17/965 - Switches controlled by moving an element forming part of the switch
A speed control switch includes a base. An upper end of the base is provided with a switch assembly. A side of the base is provided with a PCB board and a slide terminal. The PCB board is provided with a first contact plate. The slide terminal is slidably connected with the first contact plate. The base is provided with a trigger assembly for driving the slide terminal to slide along the first contact plate and to close the switch assembly. The speed control switch can regulate the speed of a motor precisely. The structure is compact to reduce the size of the switch, so that it is convenient for operation.
H01H 13/18 - Operating parts, e.g. push-button adapted for actuation at a limit or other predetermined position in the path of a body, the relative movement of switch and body being primarily for a purpose other than the actuation of the switch, e.g. door switch, limit switch, floor-levelling switch of a lift
An electrical switch has a switch body, actuators, and switch contacts, and at least one moving contact member having first and second ends. Elongate cam sliders extend side-by-side in the switch body, between the actuators and the moving contact member, for sliding lengthwise by the actuators to cause pivotal movement of the moving contact member about the first end such that the second end is moved into and out of contact with at least one of the switch contacts. The first and second ends of the moving contact member lie in a plane extending parallel to the longitudinal extent of the cam sliders, or extend parallel to the length of the cam sliders.
