A filter for industrial coating filtration systems that has a housing made up of a peripheral wall extending around a preferably rigid and pleated support backing with filtration media, which peripheral wall may be tapered. The housing is preferably made of a suitably rigid material. The support backing has openings so that gas can flow through without substantial resistance. Filtration media is mounted to or adjacent the support backing, end caps are attached to the ends of the support backing to maintain the pleated configuration, and the assembly is inserted into the housing. Tabs may extend from the support backing into slots in the end caps, and filtration material may be attached to the end caps to reduce or avoid unfiltered air passing through. Additional filtration material may be mounted to the opposite end cap sides to filter air passing between the end caps and the housing.
A filter for industrial coating filtration systems that has a housing made up of a peripheral wall extending around a preferably rigid and pleated support backing with filtration media, which peripheral wall may be tapered. The housing is preferably made of a suitably rigid material. The support backing has openings so that gas can flow through without substantial resistance. Filtration media is mounted to or adjacent the support backing, end caps are attached to the ends of the support backing to maintain the pleated configuration, and the assembly is inserted into the housing. Tabs may extend from the support backing into slots in the end caps, and filtration material may be attached to the end caps to reduce or avoid unfiltered air passing through. Additional filtration material may be mounted to the opposite end cap sides to filter air passing between the end caps and the housing.
B05B 14/43 - Arrangements for collecting, re-using or eliminating excess spraying material for use in spray booths by filtering the air charged with excess material
B05B 14/44 - Arrangements for collecting, re-using or eliminating excess spraying material for use in spray booths using walls specially adapted for promoting separation of the excess material from the air, e.g. baffle plates
3.
MULTI-LAYER, OIL-RESISTANT, ELECTRO-MECHANICAL SYNTHETIC HEPA MEDIA
A composite media alternative to high pressure drop glass microfiber HEPA media for use in applications where HEPA efficiency with an oily aerosol challenge with low resistance are required. The composite media contains two light filtration layers, one or both of which is charged, and the efficiency of the material can be greatly increased over a single layer containing the same weight of material. The composite media contains a backer layer to provide mechanical support to the filtration layers.
A composite media alternative to high pressure drop glass microfiber HEPA media for use in applications where HEPA efficiency with an oily aerosol challenge with low resistance are required. The composite media contains two light filtration layers, one or both of which is charged, and the efficiency of the material can be greatly increased over a single layer containing the same weight of material. The composite media contains a backer layer to provide mechanical support to the filtration layers.
B01D 39/20 - Other self-supporting filtering material of inorganic material, e.g. asbestos paper or metallic filtering material of non-woven wires
B01D 29/00 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor
B01D 35/06 - Filters making use of electricity or magnetism
B01D 29/90 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor having feed or discharge devices for feeding
5.
AIR FILTRATION STRUCTURE TO CONTAIN AND SUPPORT ACTIVATED CARBON WITHIN AN AIRSTREAM
A filter for removing gaseous components from a gas stream. The filter includes a frame with outer members and support members mounted thereto. The filter includes a prefilter layer disposed upstream in the frame and a reactive layer disposed in the frame downstream from the prefilter layer. The reactive layer includes particulate that removes gaseous components from the gas stream. A containment layer is disposed in the frame downstream from the reactive layer. The frame supports the layers from the airstream flowing through the filter. This configuration reduces the quantity of reactive material required and permits significant variability in the reactive materials used on the reactive layers because the different reactive layers have little to no effect on one another.
B01D 53/04 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by adsorption, e.g. preparative gas chromatography with stationary adsorbents
B01D 46/00 - Filters or filtering processes specially modified for separating dispersed particles from gases or vapours
A filtering apparatus having a housing with lateral, upstream and downstream walls, and a top plate disposed at a significant angle to incoming overspray air to accelerate and guide the particulate-laden air. The angle of the top plate directs the air upstream and away from the filters so the larger solids impact the top plate and wall and adhere, removing paint from the air. Larger solids too massive to turn while accelerating through an opening into an entry chamber collect on the upstream sidewall and the highly filtered air flows toward filter units disposed downstream of the entry opening. Lighter solids that flow downstream are removed by the filtration media. An overhang of the angled top plate reduces flow into the filter units of collected solids.
A filtering apparatus having a housing with lateral, upstream and downstream walls, and a top plate disposed at a significant angle to incoming overspray air to accelerate and guide the particulate-laden air. The angle of the top plate directs the air upstream and away from the filters so the larger solids impact the top plate and wall and adhere, removing paint from the air. Larger solids too massive to turn while accelerating through an opening into an entry chamber collect on the upstream sidewall and the highly filtered air flows toward filter units disposed downstream of the entry opening. Lighter solids that flow downstream are removed by the filtration media. An overhang of the angled top plate reduces flow into the filter units of collected solids.
B01D 46/10 - Particle separators, e.g. dust precipitators, using filter plates, sheets or pads having plane surfaces
B01D 46/00 - Filters or filtering processes specially modified for separating dispersed particles from gases or vapours
B01D 46/48 - Removing dust other than cleaning filters
B01D 46/58 - Filters or filtering processes specially modified for separating dispersed particles from gases or vapours with multiple filtering elements, characterised by their mutual disposition connected in parallel
B05B 14/43 - Arrangements for collecting, re-using or eliminating excess spraying material for use in spray booths by filtering the air charged with excess material
B65D 19/06 - Rigid pallets with side walls, e.g. box pallets with bodies formed by uniting or interconnecting two or more components
8.
Surface-modified carbon and sorbents for improved efficiency in removal of gaseous contaminants
A material, and filters and other structures exposed to flowing gas that have the material therein, which removes VOCs, such as formaldehyde, from the gas. The material is a porous sorbent impregnated by a metal oxide, such as manganese oxide (MnOx) nano particles. The sorbent may be activated carbon, and the manganese oxide may catalyze formaldehyde to water and carbon dioxide while the carbon may adsorb formaldehyde, both mechanisms of which remove the VOC from the air to prevent or reduce inhalation of the same by humans. The material may be combined with an untreated sorbent or sorbent treated with ionic alkaline salts.
B01D 53/02 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by adsorption, e.g. preparative gas chromatography
B01D 53/72 - Organic compounds not provided for in groups , e.g. hydrocarbons
B01J 20/02 - Solid sorbent compositions or filter aid compositionsSorbents for chromatographyProcesses for preparing, regenerating or reactivating thereof comprising inorganic material
B01J 20/28 - Solid sorbent compositions or filter aid compositionsSorbents for chromatographyProcesses for preparing, regenerating or reactivating thereof characterised by their form or physical properties
(1) Respiratory masks for medical purposes that filter at least 95 percent of airborne particles; face coverings being sanitary masks for protection against viral infection that filter at least 95 percent of airborne particles
Respiratory masks for medical purposes that filter at least 95 percent of airborne particles; face coverings being sanitary masks for protection against viral infection that filter at least 95 percent of airborne particles
11.
Industrial coating application filter with pleated support
A filter for industrial coating filtration systems. The filter has a housing made up of a peripheral wall extending around the periphery. The housing is preferably made of a suitably rigid material. A preferably rigid support backing is mounted within the housing. The support backing has a planar configuration with openings formed through it so that gas can flow through without substantial resistance. The preferably planar sheet of which the support backing is made is pleated. The pleated support backing defines a series of panels, each of which is angled to a next adjacent panel. Filtration media is mounted to the support backing, end caps are attached to the ends of the support backing to maintain the pleated configuration, and the assembly is inserted into the housing, which can have end flaps to seal using tape or adhesive.
B01D 46/00 - Filters or filtering processes specially modified for separating dispersed particles from gases or vapours
B01D 46/10 - Particle separators, e.g. dust precipitators, using filter plates, sheets or pads having plane surfaces
B01D 46/52 - Particle separators, e.g. dust precipitators, using filters embodying folded material
B05B 14/43 - Arrangements for collecting, re-using or eliminating excess spraying material for use in spray booths by filtering the air charged with excess material
Filter devices for industrial machines, namely, filters made of paper or polyester for paint spray booths; gas filters for dust or aerosol collecting as parts of industrial machines, namely, filters used to capture paint in the exhaust of paint spray booths; filters as part of industrial machines, namely, gas filters used to capture paint in the exhaust of paint spray booths; filters as part of industrial machines, namely, gas filters having multiple stacked filters in a housing used for filtering paint overspray; filters for machines.
Filter devices for industrial machines, namely, filters made of paper or polyester for paint spray booths; Gas filters for dust or aerosol collecting as parts of industrial machines, namely, filters used to capture paint in the exhaust of paint spray booths; Filters as part of industrial machines, namely, gas filters used to capture paint in the exhaust of paint spray booths; Filters as part of industrial machines, namely, gas filters having multiple stacked filters in a housing used for filtering paint overspray
Particulate air filters for heat, ventilation, and air conditioning systems for household, commercial, and industrial use, namely, self-sealing cubes, pocket filters, V-cell filters, rigid box filters, panel filters, pleated air filters and mini-pleated air filters; Air filters for industrial, household and commercial installations made of expanded metal; Air filters for industrial, household and commercial installations made of activated carbon for odor and molecular filtration; Air filters for industrial, household and commercial installations made of aluminum for filtration of grease from air; Water filters made of polymers and activated carbon; Nonwoven polyester filtration medium in the nature of air filtration media for air and paint filtration and for respirator masks; Air filtering installations in the nature of paint overspray filters made of paper; Air filtering installations in the nature of paint overspray filters made of polyester; Activated carbon filtration medium in the nature of air filtration media; Expanded metal filtration media in the nature of air filtration media sold to others
Particulate air filters for heat, ventilation, and air conditioning systems for household, commercial, and industrial use, namely, self-sealing cubes, pocket filters, V-cell filters, rigid box filters, panel filters, pleated air filters and mini-pleated air filters; Air filters for industrial, household and commercial installations made of expanded metal; Air filters for industrial, household and commercial installations made of activated carbon for odor and molecular filtration; Air filters for industrial, household and commercial installations made of aluminum for filtration of grease from air; Water filters made of polymers and activated carbon; Nonwoven polyester filtration medium in the nature of air filtration media for air and paint filtration and for respirator masks; Air filtering installations in the nature of paint overspray filters made of paper; Air filtering installations in the nature of paint overspray filters made of polyester; Activated carbon filtration medium in the nature of air filtration media; Expanded metal filtration media in the nature of air filtration media sold to others
A filter for industrial coating filtration systems. The filter has a housing made up of a peripheral wall extending around the periphery. The housing is preferably made of a suitably rigid material. A preferably rigid support backing is mounted within the housing. The support backing has a planar configuration with openings formed through it so that gas can flow through without substantial resistance. The preferably planar sheet of which the support backing is made is pleated. The pleated support backing defines a series of panels, each of which is angled to a next adjacent panel. Filtration media is mounted to the support backing, end caps are attached to the ends of the support backing to maintain the pleated configuration, and the assembly is inserted into the housing, which can have end flaps to seal using tape or adhesive.
B01D 46/10 - Particle separators, e.g. dust precipitators, using filter plates, sheets or pads having plane surfaces
B01D 46/52 - Particle separators, e.g. dust precipitators, using filters embodying folded material
B01D 46/00 - Filters or filtering processes specially modified for separating dispersed particles from gases or vapours
B05B 14/43 - Arrangements for collecting, re-using or eliminating excess spraying material for use in spray booths by filtering the air charged with excess material
19.
IMPROVED INDUSTRIAL COATING APPLICATION FILTER WITH PLEATED SUPPORT
A filter for industrial coating filtration systems. The filter has a housing made up of a peripheral wall extending around the periphery. The housing is preferably made of a suitably rigid material. A preferably rigid support backing is mounted within the housing. The support backing has a planar configuration with openings formed through it so that gas can flow through without substantial resistance. The preferably planar sheet of which the support backing is made is pleated. The pleated support backing defines a series of panels, each of which is angled to a next adjacent panel. Filtration media is mounted to the support backing, end caps are attached to the ends of the support backing to maintain the pleated configuration, and the assembly is inserted into the housing, which can have end flaps to seal using tape or adhesive.
A collapsible HVAC filter that includes pleated filtration media having side members mounted on opposite sides of the filtration media. The filtration media collapses to reduce filter volume. Supports maintain spacing between the side members when the filtration media is expanded. The supports may extend into openings on the upstream and downstream sides of each of the side members. The collapsed filter occupies little space relative to the expanded filter, and can be expanded to form a completed filter with little effort required by the end user.
A material, and filters and other structures exposed to flowing gas that have the material therein, which removes VOCs, such as formaldehyde, from the gas. The material is a porous sorbent impregnated by a metal oxide, such as manganese oxide (MnOx) nano particles. The sorbent may be activated carbon, and the manganese oxide may catalyze formaldehyde to water and carbon dioxide while the carbon may adsorb formaldehyde, both mechanisms of which remove the VOC from the air to prevent or reduce inhalation of the same by humans. The material may be combined with an untreated sorbent or sorbent treated with ionic alkaline salts.
Air filters for industrial installations; air filters for domestic use [ online retail store and wholesale store services featuring filtration products; providing a website featuring consumer product information about filtration products ]
23.
Industrial coating application filter with pleated support
A filter for industrial coating filtration systems. The filter has a housing made up of a peripheral wall extending around the periphery. The housing is preferably made of a suitably rigid material. A preferably rigid support backing is mounted within the housing. The support backing has a planar configuration with openings formed through it so that gas can flow through without substantial resistance. The preferably planar sheet of which the support backing is made is pleated. The pleated support backing defines a series of panels, each of which is angled to a next adjacent panel. Filtration media is mounted to the support backing, end caps are attached to the ends of the support backing to maintain the pleated configuration, and the assembly is inserted into the housing, which can have end flaps to seal using tape or adhesive.
Humidifier pads specially adapted for residential and commercial humidifiers; air filters for domestic use, namely, residential heating ventilation and air conditioning systems; air filters for domestic use; air filters for domestic use, namely, air filters for portable room air cleaners; air filters for air conditioners in vehicle passenger compartments; air filters for heating, air conditioning and ventilation systems of automobile passenger compartments
A rigid support is disposed in a filtration media element. A first gas-permeable filtration media layer is disposed in an overlapping orientation with a second gas-permeable filtration media layer. The first and second layers define a void in which the support is disposed. The first layer is attached to the second layer near opposing edges of the first and second layers and at an attachment termination point substantially centrally located on the filtration media element. The filtration media element has a first media end and an opposite, second media end. The support has a first support portion that extends from the first media end toward the attachment termination point. The support has second and third support portions that extend from the first support portion toward the second media end with a gap between the second and third support portions in which the attachment termination point is disposed.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
B01D 46/02 - Particle separators, e.g. dust precipitators, having hollow filters made of flexible material
B01D 46/06 - Particle separators, e.g. dust precipitators, having hollow filters made of flexible material with means keeping the working surfaces flat
B01D 46/00 - Filters or filtering processes specially modified for separating dispersed particles from gases or vapours
A filtration media that may be mounted in a frame and placed in a central heating, cooling and/or ventilation system. The media has symmetrical characteristics such that, when mounted in the frame, the resulting filter may be mounted with either one major surface of the filtration media receiving the air flow or the opposite major surface receiving the air flow. Regardless of how the filter is oriented, the performance of the filter is the same due to the symmetrical characteristics of the filtration media mounted therein.
A filter contains fluent particulate, such as carbon granules. The filter is divided into a plurality of cell chambers by walls, including an upper wall. The upper wall has a surface that faces, and is closest to, the top surface of the particles. The upper wall surface is oriented so that, as the particles settle, any gap formed between the top surface of the particles and a portion of the upper wall surface will not extend from the upstream to the downstream sides of the filter. Instead, contact is maintained between the top surface of the particles and the upper wall surface during fluid flow through the filter, and therefore any gas flowing through the frame must flow through, and through spaces around, particles. An angle between the upper wall surface and the flow direction of gas striking the filter is greater than about three degrees.
B01D 53/02 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by adsorption, e.g. preparative gas chromatography
B01J 20/28 - Solid sorbent compositions or filter aid compositionsSorbents for chromatographyProcesses for preparing, regenerating or reactivating thereof characterised by their form or physical properties
B01D 53/04 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by adsorption, e.g. preparative gas chromatography with stationary adsorbents
B01J 20/20 - Solid sorbent compositions or filter aid compositionsSorbents for chromatographyProcesses for preparing, regenerating or reactivating thereof comprising inorganic material comprising free carbonSolid sorbent compositions or filter aid compositionsSorbents for chromatographyProcesses for preparing, regenerating or reactivating thereof comprising inorganic material comprising carbon obtained by carbonising processes
B01D 53/72 - Organic compounds not provided for in groups , e.g. hydrocarbons
B01D 53/82 - Solid phase processes with stationary reactants
28.
APPARATUS AND METHOD FOR AVOIDING FLUID BYPASS IN PARTICULATE FILTERS
A filter contains fluent particulate, such as carbon granules. The filter is divided into a plurality of cell chambers by walls, including an upper wall. The upper wall has a surface that faces, and is closest to, the top surface of the particles. The upper wall surface is oriented so that, as the particles settle, any gap formed between the top surface of the particles and a portion of the upper wall surface will not extend from the upstream to the downstream sides of the filter. Instead, contact is maintained between the top surface of the particles and the upper wall surface during fluid flow through the filter, and therefore any gas flowing through the frame must flow through, and through spaces around, particles. An angle between the upper wall surface and the flow direction of gas striking the filter is greater than about three degrees.
B01D 53/14 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by absorption
29.
Filter medium having ozone and odor removal properties
An ozone and odor removing filter media having a filtration layer and a supporting layer. The supporting layer includes activated carbon fibers or powders, or both, incorporated within the supporting layer. The activated carbon particles can be added to the supporting layer by combining them with binder in a slurry and extending the already-formed supporting layer through the slurry. The wetted layer then extends through opposed rollers to remove all but a desired amount of slurry. Alternatively, the activated carbon particles can be added to the mixture when forming the supporting layer.
B01D 53/02 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by adsorption, e.g. preparative gas chromatography
B01D 53/04 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by adsorption, e.g. preparative gas chromatography with stationary adsorbents
[ Humidifier pads for residential and commercial humidifiers; Air filters for residential and commercial heating ventilation and air conditioning systems ] On-line retail store services featuring air humidifying and purifying products, humidifiers, vacuum cleaner bags, vacuum cleaner filters, and replacement parts for humidifiers
31.
Industrial coating application filter with pleated support
A filter for industrial coating filtration systems. The filter has a housing made up of a peripheral wall extending around the periphery. The housing is preferably made of a suitably rigid material. A preferably rigid support backing is mounted within the housing. The support backing has a planar configuration with openings formed through it so that air can flow through without substantial resistance. The preferably planar sheet of which the support backing is made is pleated. The pleated support backing defines a series of panels, each of which is angled to a next adjacent panel. Filtration media is mounted to the support backing, end caps are attached to the ends of the support backing to maintain the pleated configuration, and the assembly is inserted into the housing, which can have end flaps to seal using tape or adhesive.
A filter for industrial coating filtration systems. The filter has a housing made up of a peripheral wall extending around the periphery. The housing is preferably made of a suitably rigid material. A preferably rigid support backing is mounted within the housing. The support backing has a planar configuration with openings formed through it so that air can flow through without substantial resistance. The preferably planar sheet of which the support backing is made is pleated. The pleated support backing defines a series of panels, each of which is angled to a next adjacent panel. Filtration media is mounted to the support backing, end caps are attached to the ends of the support backing to maintain the pleated configuration, and the assembly is inserted into the housing, which can have end flaps to seal using tape or adhesive.
The invention is a filter for paint booth filtration systems. The filter has a housing made up of a peripheral wall, which extends around the entire periphery of the filter, and opposing filter-retaining screens. The filter-retaining screens form the upstream and downstream faces of the filter. The filtration element may be a frame with lattice and a rigidifying channel therearound combined with a filtration material extended around the frame. The filtration material may be slit and expanded paper that is joined at overlapping edges, or merely overlapped, to form a sleeve. One or more of the filtration elements are mounted in the housing substantially parallel to one another and to the screens.
The invention is a filter for paint booth filtration systems. The filter has a housing made up of a peripheral wall, which extends around the entire periphery of the filter, and opposing filter-retaining screens. The filter-retaining screens form the upstream and downstream faces of the filter. The filtration element may be a frame with lattice and a rigidifying channel therearound combined with a filtration material extended around the frame. The filtration material may be slit and expanded paper that is joined at overlapping edges, or merely overlapped, to form a sleeve. One or more of the filtration elements are mounted in the housing substantially parallel to one another and to the screens.
A collapsible HVAC filter that includes a pleated filter media pack with ends that attach to ends of a planar filter frame member. The structure collapses by folding the filter frame member along score lines and compressing the pleated filter media while the media and frame member are attached. The collapsed components occupy little space relative to the expanded filter, and can be expanded to form a completed filter with little effort required by the end user. Most of the filter media is collapsed in a generally U- shaped channel formed from the folded filter frame member.
A collapsible HVAC filter that includes a pleated filter media pack with ends that attach to ends of a planar filter frame member. The structure collapses by folding the filter frame member along score lines and compressing the pleated filter media while the media and frame member are attached. The collapsed components occupy little space relative to the expanded filter, and can be expanded to form a completed filter with little effort required by the end user. Most of the filter media is collapsed in a generally U-shaped channel formed from the folded filter frame member.
Air filters for industrial applications; air filters for heating ventilation and air conditioning systems; air filters made of polymer fibers for heating ventilation and air conditioning systems
(1) Air filters for heating ventilation and air conditioning systems; air filters made of polymer fibers for heating ventilation and air conditioning systems.
06 - Common metals and ores; objects made of metal
07 - Machines and machine tools
11 - Environmental control apparatus
Goods & Services
(1) Air filters for removing dust, smoke, grease, odours and allergens from air; filtering material for use in air filters for removing gas and odors from the air.
(2) Water filters.
(3) Grease filters for vent hoods; aluminum filter media.
(4) Expanded aluminum filter media for use in the further manufacture of filters.
(5) Particulate air filters for HVAC systems for household, commercial and industrial use; filters made of aluminum for filtration of grease from air; water filters made of polymers and activated carbon; air filters for industrial applications; air filters made of activated carbon for odor filtration for household, commercial and industrial use; grease filters made of expanded metal for trapping grease for use in vent hoods; fibrous filtering material containing activated carbon materials for removing gases and odors from the air.
Air filters for domestic use; air filters for industrial installations; air filters for heating ventilation and air conditioning systems; air filters for heating ventilation and air conditioning systems, sold in a state of disassembly to be assembled by the end user before use
An air filter and frame that cooperate to require alignment of the filter in a desired orientation in order for insertion to occur. At least one edge of the filter is offset from a right angle relative to other edges and the faces of the filter, and an obstruction is formed in the frame so that the filter can be inserted into the frame in only the desired orientation. Preferably two opposing edges of the frame are angled, and obstructions, such as small rails, are mounted in opposing sidewalls of the frame.
06 - Common metals and ores; objects made of metal
11 - Environmental control apparatus
Goods & Services
expanded aluminum filter media for use in the further manufacture of filters particulate air filters for HVAC systems for household, commercial and industrial use; filters made of aluminum for filtration of grease from air; water filters made of polymers and activated carbon; air filters for industrial applications; air filters made of activated carbon for odor filtration for household, commercial and industrial use; grease filters made of expanded metal for trapping grease for use in vent hoods; fibrous filtering material containing activated carbon materials for removing gases and odors from the air
01 - Chemical and biological materials for industrial, scientific and agricultural use
06 - Common metals and ores; objects made of metal
07 - Machines and machine tools
11 - Environmental control apparatus
16 - Paper, cardboard and goods made from these materials
17 - Rubber and plastic; packing and insulating materials
Goods & Services
Chemical filter media in class 01, in particular made of activated carbon. Filter media in class 06, in particular made of expanded metal. Filters in class 07 for motors and machines, in particular water filters and particulate air filters including self-sealing cubes, pocket filters, V-cell filters, rigid box filters, panel filters, pleated air filters and mini-pleated air filters, framed filters made of expanded metal; filters for household vacuum cleaning machines; paint overspray filters for use in painting cabins and spray booths. Filters in class 11, in particular water filters and particulate air filters including self-sealing cubes, pocket filters, V-cell filters, rigid box filters, panel filters, pleated air filters and mini-pleated air filters, framed filters made of expanded metal. Filters and filter media in class 16, in particular made of paper. Filter media in class 17, in particular made of polyester.
01 - Chemical and biological materials for industrial, scientific and agricultural use
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
16 - Paper, cardboard and goods made from these materials
17 - Rubber and plastic; packing and insulating materials
22 - Rope, netting, tents, awnings, sails and sacks; padding and stuffing materials
24 - Textiles and textile goods
Goods & Services
Filtering materials mineral or vegetable. Paint collectors, in particular apparatus and filters for collecting the excess of paint in painting cabins and spray booths. Filters and filter materials (consisting either exclusively of expanse kraft paper or of different layers of kraft paper in combination with reinforcement layers of synthetic fibers, not inweaved), in particular for use as absorbent materials for paint, for example in cabins for pistol painting. Filtering materials on paper basis; filters and filter materials, in particular filters and filter materials made of multiple layers, mainly made of paper and used as absorbent material for paint. Filtering materials on plastic basis. Filtering materials on wadding basis. Filtering materials on textile basis; products to collect paint, in particular filters to contain the excess of painting in paint dispensing cabins.
01 - Chemical and biological materials for industrial, scientific and agricultural use
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
16 - Paper, cardboard and goods made from these materials
17 - Rubber and plastic; packing and insulating materials
22 - Rope, netting, tents, awnings, sails and sacks; padding and stuffing materials
24 - Textiles and textile goods
Goods & Services
Filtering materials mineral or vegetable. Paint collectors, in particular apparatus and filters for collecting the excess of paint in painting cabins and spray booths. Filters and filter materials (consisting either exclusively of expanse kraft paper or of different layers of kraft paper in combination with reinforcement layers of synthetic fibers, not inweaved), in particular for use as absorbent materials for paint, for example in cabins for pistol painting. Filtering materials on paper basis; filters and filter materials, in particular filters and filter materials made of multiple layers, mainly made of paper and used as absorbent material for paint. Filtering materials on plastic basis. Filtering materials on wadding basis. Filtering materials on textile basis; products to collect paint, in particular filters to contain the excess of painting in paint dispensing cabins.
A joined filter media pleat pack assembly comprises at least two filter media pleat packs, wherein each pleat comprises a root and a crown, wherein a seam between each filter media pleat pack is at least one of: (a) structure wherein the pleats, crowns, and roots of one filter media pleat pack are interleaved or nested with the corresponding structure of an adjacent filter media pleat pack or (b) structure wherein at least a portion of the terminal edges of adjacent filter media pleat packs are mitered at complimentary angles and assembled in mating relation.
A filter media and a pleated filter with a first layer of filtration media, a layer of support material and a second layer of filtration media on the opposite side of the support material as the first layer of filter media. All three layers are laminated together and pleated. The support material provides the required stiffness and rigidity for the pleating process. The physical characteristics of the upstream layer of filtration media are contemplated to be different than the characteristics of the downstream layer of filtration media.
B01D 46/10 - Particle separators, e.g. dust precipitators, using filter plates, sheets or pads having plane surfaces
B01D 46/52 - Particle separators, e.g. dust precipitators, using filters embodying folded material
B03C 3/30 - Plant or installations without electricity supply, e.g. using electrets in which electrostatic charge is generated by passage of the gases, i.e. tribo-electricity
B03C 3/60 - Use of special materials other than liquids
A composite filter media having excellent dust-releasing properties provided with a layer of netting formed of a low surface free energy material that is hot calendered to the upstream surface of a supporting layer formed of non-woven synthetic fibers. A filtering layer formed of non-woven synthetic fibers is laminated to the downstream surface of the supporting layer. The filtering layer may include an electrostatic charge to increase filter efficiency at a reduced pressure drop across the composite media.
A humidifier pad made of a plurality of laminated sheets connected together in a stack. Each of the sheets is made of a two layer laminate material made of a first layer of a rigidifying material, such as aluminum, and a second layer made of an absorbent layer, such as paper. The layers of each of the sheets are first laminated together, and then each sheet is slit and expanded in a conventional manner. Subsequently, each sheet is bonded to a next adjacent sheet to form a pad.
A collapsible HVAC filter that includes a pleated filter media pack with ends that attach to ends of a planar filter frame member. The structure collapses by folding the filter frame member along score lines and compressing the pleated filter media while the media and frame member are attached. The collapsed components occupy little space relative to the expanded filter, and can be expanded to form a completed filter with little effort required by the end user. Most of the filter media is collapsed in a generally U- shaped channel formed from the folded filter frame member.
