The present invention relates to a washing method and household appliance for textiles in a household appliance, which offers the benefit of disinfection of clothing, the washing liquid, as well as the components of the washing machine that are in contact with the washing liquid and loading clothes through the use of UV-C radiation. Disinfection can be carried out during the washing and/or rinsing step through a predetermined sequence of turning on and off the radiation source. In addition to disinfection without the need to add temperature to the water at the inlet of the washing machine or inside it, there are the benefits of greater cleaning and less damage to clothing, shorter washing time, lower energy consumption, and avoiding the use of disinfectant additives for more ecological wash cycles.
The present invention relates to a system for disinfecting textiles with UV technology comprising an ultraviolet light assembly comprising a power supply; a housing to contain the light assembly and protect it from any impact; an electronic card that is responsible for switching the ultraviolet light assembly on or off. The system allows disinfecting textiles by up to 99.9%, saving energy and, at the same time, reducing process time and damage to the textiles.
C07H 21/04 - Compounds containing two or more mononucleotide units having separate phosphate or polyphosphate groups linked by saccharide radicals of nucleoside groups, e.g. nucleic acids with deoxyribosyl as saccharide radical
3.
TUNGSTATE- AND MOLYBDATE-BASED CERAMIC COATING FOR PROTECTION OF METAL SURFACES, PREPARATION PROCEDURE AND USE THEREOF
The present invention relates to different inorganic ceramic coatings whose chemical compositions comprise silicates, acids, metallic oxysalts such as tungstates and molybdates, water, and non-metallic oxides such as silicon oxide. Said water-based inorganic ceramic coatings improve the ceramic, anti-corrosive and resistance properties of the metal substrates that are coated with same. Likewise, the present invention relates to a sol-gel process for synthesizing said coatings in which the non-metallic oxide, before being mixed with the rest of the components of the chemical compositions as claimed, can be pre-treated with hydrochloric acid and ammonium hydroxide, or can be sonicated to achieve a particle size in the range from approximately 160 to approximately 180 nm. Finally, the present invention also relates to a method for coating the metal parts with the inorganic ceramic coatings as claimed in the present invention.
The present invention relates to different inorganic ceramic coatings whose chemical compositions comprise silicates, acids, metallic oxysalts such as tungstates and molybdates, water, and non-metallic oxides such as silicon oxide. Said water-based inorganic ceramic coatings improve the ceramic, anti-corrosive and resistance properties of the metal substrates that are coated with same. Likewise, the present invention relates to a sol-gel process for synthesizing said coatings in which the non-metallic oxide, before being mixed with the rest of the components of the chemical compositions as claimed, can be pre-treated with hydrochloric acid and ammonium hydroxide, or can be sonicated to achieve a particle size in the range from approximately 160 to approximately 180 nm. Finally, the present invention also relates to a method for coating the metal parts with the inorganic ceramic coatings as claimed in the present invention.
The present invention relates to the field of washing machines, in particular a domestic washing machine, keeping in mind that the objects to be washed are of different nature, manufacture, materials, geometry and volume, in addition to having different types and levels of dirt. Therefore, different types of washing patterns have been developed in order to wash them effectively, ensuring as little damage and wear as possible; the agitation sequence proposed by the washing method of the present invention is carried out progressively, both incrementally and decrementally, using progressive agitation blocks that comprise a sequence of agitation patterns, wherein according to the user's preferences, laundry load and water level inside the washing machine, the number of agitation blocks is determined, the type of agitation sequences to be used for each agitation block, a first initial agitation pattern, the changes in the variables of arc or paddle stroke length, spm, and agitation period, of the subsequent agitation patterns as well as the number of patterns to be used per progressive agitation block.
D06F 33/36 - Control of operational steps, e.g. optimisation or improvement of operational steps depending on the condition of the laundry of washing
D06F 34/28 - Arrangements for program selection, e.g. control panels thereforArrangements for indicating program parameters, e.g. the selected program or its progress
D06F 35/00 - Washing machines, apparatus, or methods not otherwise provided for
(1) Coating compositions in the nature of paint and heat resistant paint applied to household appliances exposed to heat oxidation; protective coating applied to stainless surfaces of cooking products
(2) Refrigerators; freezers; water coolers and water heaters, namely, gas water heaters, hot water heaters, solar water heaters, water heaters for domestic use; air conditioners, clothes dryers; stoves, namely, gas stoves and electric stoves; microwave ovens
(1) Coating compositions in the nature of paint and heat resistant paint applied to household appliances exposed to heat oxidation; protective coating applied to stainless surfaces of cooking products
(2) Refrigerators; freezers; water coolers and water heaters, namely, gas water heaters, hot water heaters, solar water heaters, water heaters for domestic use; air conditioners, clothes dryers; stoves, namely, gas stoves and electric stoves; microwave ovens
10.
METHOD AND SYSTEM FOR TEXTILES DISINFECTION IN HOUSEHOLD APPLIANCE
The present invention relates to a UVC technology-based system for disinfecting textiles comprising an ultraviolet light source comprising a power supply; a housing to contain the light source and to protect it from any impact; an electronic card responsible for controlling the switching on or off of the ultraviolet light source; a driving means that activates the movement of the drum and an electrical resistance that allows the generation of heat to start the drying cycle inside the household appliance. The system allows disinfecting textiles by up to 99.9%, saving energy and, at the same time, reducing the process time and damage to the textiles.
F26B 3/14 - Drying solid materials or objects by processes involving the application of heat by convection, i.e. heat being conveyed from a heat source to the materials or objects to be dried by a gas or vapour, e.g. air the materials or objects to be dried being moved by gravity
The present invention relates to a water-injection device for an oven comprising a removable water tank in connection with a pressure pump; said pressure pump being in connection with a water injector.
The present invention relates to different inorganic ceramic coatings whose chemical compositions comprise silicates, acids, metallic oxysalts such as tungstates and molybdates, water, and non-metallic oxides such as silicon oxide. Said water-based inorganic ceramic coatings improve the ceramic, anti-corrosive and resistance properties of the metal substrates that are coated with same. Likewise, the present invention relates to a sol-gel process for synthesizing said coatings in which the non-metallic oxide, before being mixed with the rest of the components of the chemical compositions as claimed, can be pre-treated with hydrochloric acid and ammonium hydroxide, or can be sonicated to achieve a particle size in the range from approximately 160 to approximately 180 nm. Finally, the present invention also relates to a method for coating the metal parts with the inorganic ceramic coatings as claimed in the present invention.
Present invention refers to a motorized mechanism, for control panel which allows said control panel to move from a working position to a resting position, such that a fixed frame is found static and coupled to a household appliance such as a stove or an oven, while a mobile frame partially protrudes from said fixed frame to allow for a better view of said control panel.
H05K 5/00 - Casings, cabinets or drawers for electric apparatus
F16M 11/10 - Means for attachment of apparatusMeans allowing adjustment of the apparatus relatively to the stand allowing pivoting around a horizontal axis
F16M 13/02 - Other supports for positioning apparatus or articlesMeans for steadying hand-held apparatus or articles for supporting on, or attaching to, an object, e.g. tree, gate, window-frame, cycle
14.
Washing machine and textile washing and rinsing method
A textile rinsing method in a washing machine, the washing machine including a tub, a rotating basket within the tub and a water spraying device, the method comprising stopping the basket, admitting a predetermined fresh water quantity, storing the predetermined fresh water quantity in the tub, spraying the textiles by means of the water spraying device, draining and centrifuging the remaining liquid in the tub and determining the number of semi-rinses. The method may be carried out in a washing machine including a tub and a rotating basket within the tub, wherein the washing machine comprises a pumping system, and a set of spraying means, including a directional valve, a conduction hose, a tub cover and, be it a hose with a plurality of holes or a nozzle and deflector or dispenser box, wherein by means of the directional valve, the pumping system is capable of leading through the conduction hose a determined quantity of fresh water stored in the tub to the, be it a hose with a plurality of holes or a nozzle and deflector or dispenser box, wherein any of the afore are capable of directing the water towards the basket.
The present invention relates to a sliding system for a drawer comprising a main base which is fixed unto a grill whose front end of the base overlaps from the same; a wire rod base set over the main base by means of a fixed rail, said wire rod base allows for the complete aperture of the drawer; a drawer base which supports the drawers and remains fixed unto the system; a plurality of bushings which decrease the amount of friction, which allows for smooth and silent sliding; a magnet which provides closing force to the drawer which grants the closing sensation when the drawer reaches the bump and extractable drawers which are transportable.
Embodiments are related to the principles and techniques used in the household appliances industry, particularly it refers to a method for performing routine domestic chores in an easier and optimal manner, more particularly it refers to a textiles washing method by means of spinning intervals in order to achieve an optimal wash with low water consumption.
D06F 23/04 - Washing machines with receptacles, e.g. perforated, having a rotary movement, e.g. oscillatory movement, the receptacle serving both for washing and for centrifugally separating water from the laundry and rotating or oscillating about a vertical axis
D06F 13/00 - Washing machines having receptacles, stationary for washing purposes, with agitators therein contacting the articles being washed
D06F 39/08 - Liquid supply or discharge arrangements
D06F 35/00 - Washing machines, apparatus, or methods not otherwise provided for
17.
Intelligent electronic system for previously sensing the dryness condition of a textile clothes load in an automatic electronic clothes dryer machine
An intelligent electronic system for previously sensing the dryness condition of a textile clothes load applicable to an automatic electronic clothes dryer machine is disclosed, which comprises: an electronic integrated circuit of the microcontroller type located in a dryer machine, wherein said microcontroller receives and processes signals coming from a plurality of temperature sensing means and from humidity sensing means in order to make decisions and to inform the dryer machine what action it must execute; as well as a method for previously sensing the dryness condition of a textile clothes load applicable to any automatic electronic clothes dryer machine for home use, wherein said method comprises the steps of: (a) collecting information about air temperature at the drum's outlet and inlet, as well as information on the humidity conditions of the textile clothes load; (b) with the information collected in step a) above determining whether the dryer machine is cold or warm; (c) letting a first period of time to elapse during which measuring of air temperature conditions of the drum's outlet and inlet as well as humidity conditions of said textile clothes load continues; (d) checking whether or not said conduit is obstructed; (e) letting a second period of time to elapse during which measuring of air temperature conditions of the drum's outlet and inlet as well as humidity conditions of said textile clothes load continues; (f) determining whether the textile clothes load is small or large; (g) determining whether the textile clothes load is small or large; and, (h) checking whether or not the large or small textile clothes load is dry, by comparing the humidity conditions of said small or large load against a preset parameter.
An intelligent electronic system for removing wrinkles from a textile clothes load, including an electronic integrated circuit of the microcontroller type placed preferably integrally on the mainboard of the dryer machine located on the control panel, an user interface located preferably on the control panel allowing communications between the user and the dryer machine, and a water-injection means located at the drum's air inlet. A process for removing wrinkles on textile clothes is also disclosed.
F26B 11/02 - Machines or apparatus for drying solid materials or objects with movement which is non-progressive in moving drums or other mainly-closed receptacles
D06F 58/20 - General details of domestic laundry dryers
A refrigerated cabinet having a cabinet, thermal insulation, cover or liner, which help it form a cavity which can house objects to be refrigerated with at least one shelf and one door comprising a vegetable drawer which itself on its lateral and opposite walls having an appendage integrated by a head, an upper crossbar, a lower crossbar, a skate, a hump; which runs within a rail comprising a channel formed by a barrier, a lower bay, a neck in C with a straight which is inclined, a gulf and a stump; with the peculiarity that when the vegetable drawer is found in its resting or closed position, the front wall of said vegetable drawer is in close proximity to the vertical; the head (32) is coupled within the neck in C, the skate is in contact with the upper face of the lower bay, and the barrier is in contact with a portion of the lower face of the lower crossbar; and that when the vegetable drawer is extracted in its final runner position, the vegetable drawer has an α inclination with relation to the horizontal; wherein the head (32) is coupled unto the gulf of the rail, and the barrier is in contact with a lateral face of the skate, as well as with a portion of the lower face of the lower crossbar.
The present relates to washing machines comprising a tub within in which a basket is housed which rotates concentrically within this, driven by a motor mechanically coupled to an agitator and to the basket, a clutch which allows the coupling and uncoupling between basket and agitator, an electronic control which controls actuators by means of drivers, at least one admission valve, one level detector, one spray system, characterized by a wash method comprising: checking the water level, volume determination sequence which comprises determining in which the at least one admission valve remains open; an agitation sequence; a dehydrating sequence; a rinsing sequence which comprises using a determined number of rinsing blocks according to the amount of objects to be washed, introducing a determined amount of water into the basket by means of a nozzle.
D06F 33/02 - Controlling a series of operations in washing machines, e.g. programme-control arrangements for washing and drying cycles electrically
D06F 35/00 - Washing machines, apparatus, or methods not otherwise provided for
D06F 39/08 - Liquid supply or discharge arrangements
D06F 23/04 - Washing machines with receptacles, e.g. perforated, having a rotary movement, e.g. oscillatory movement, the receptacle serving both for washing and for centrifugally separating water from the laundry and rotating or oscillating about a vertical axis
21.
Easy clean coating applied on stainless steel metallic surfaces used in the manufacture of household appliances
The present invention related to a silicon based coating suitable for being applied onto metallic surfaces of a household appliance. The coating of the present invention protects the metallic surfaces of the household appliance against the yellowing or changes in color, through temperatures, among other factors, and eases the cleaning of the same.
C23C 18/00 - Chemical coating by decomposition of either liquid compounds or solutions of the coating forming compounds, without leaving reaction products of surface material in the coatingContact plating
C23C 18/18 - Pretreatment of the material to be coated
C23C 18/12 - Chemical coating by decomposition of either liquid compounds or solutions of the coating forming compounds, without leaving reaction products of surface material in the coatingContact plating by thermal decomposition characterised by the deposition of inorganic material other than metallic material
A door with a window for an appliance, such as a clothes dryer, and a method for assembling such a door in the appliance are provided. A tempered glass pane may be supported by one or more packaging structures disposed on borders of the glass pane. Each packaging structure may accommodate a retainer. The glass pane may be sandwiched between an inner frame and an outer frame coupled to one another to form a joined assembly effective to tightly seal the borders of the glass pane.
A47B 77/06 - Provision for particular uses of compartments or other parts for incorporating sinks, with or without draining boards, splash-backs, or the like
An ice making device with a manually removable water tank is provided. When mounted, this tank has a system for opening a valve that allows dispensing water into an ice making tray of the ice making device. The ice making tray is rotatable so that the ice cubes formed in the tray can be removed. The ice making tray may be rotated by a pair of gears, one of them holds the ice making tray in position and transmits a rotation force to the tray; this gear has a preload spring which generates an appropriate return force. The other gear is part of the lever, giving torsion to the tray and may be operated by a user. When rotating the tray, the ice cubes may fall directly into an ice bucket which can be removed from the system to externally serve ice.
A door with a window for an appliance, such as a clothes dryer, and a method for assembling such a door in the appliance are provided. A tempered glass pane may be supported by one or more packaging structures disposed on borders of the glass pane. Each packaging structure may accommodate a retainer. The glass pane may be sandwiched between an inner frame and an outer frame coupled to one another to form a joined assembly effective to tightly seal the borders of the glass pane.
A47B 77/06 - Provision for particular uses of compartments or other parts for incorporating sinks, with or without draining boards, splash-backs, or the like
A method to compensate drying time in an electric or gas dryer machine, which comprises the steps of: read the operator parameters (dryness level, cycle type, heat level); begin a timer to measure time between beginning and Trtv; determine the load weight and the type of restrictions of the dryer; determine the dryness target voltage and the minimum drying time by means of a table of predetermined values based on the previous data; store the values in a memory; determine that the detected voltage be equal to the target voltage; calculate the additional time as a function of the heat factor and of the data previously determined; compare (Tminimum-Trtv) versus additional time and use the greater; and, add the additional time to the Trtv as compensation time.
In a household washer which contains a tub with a cylindrical wall suspended by means of suspension rods, the tub also is comprised of ears with petals by which the tub is held in one extreme by suspension rods, at least one cylindrical reinforcement which surrounds the cylindrical wall, at least one pair of lobes in a substantially upper area of the tub, and additionally preferably one spout for over-flow in a substantially upper area of the tub.
The present invention relates to a top loading household washer comprising a cabinet supporting a tub which houses a basket being driven by a motor mechanically coupled to an agitator and to said basket, a clutch, an electric control, a level sensor or pressure switch and a rotor position sensor within the motor (preferably a Hall sensor), a spraying system, characterized by a washing method comprising: check on the water level, initiate a load pre-sensing sequence to later initiate a reshuffling of load sequence, act followed by initiating a load sensing sequence, which determines the water level required to admit, once said water level is reached, a normal agitation sequence is begun; once the normal agitation sequence concludes, it is followed by a load reshuffling sequence to continue with the dehydrating and later rinsing.
D06L 1/20 - Dry-cleaning or washing fibres, filaments, threads, yarns, fabrics, feathers or made-up fibrous goods using aqueous solvents combined with mechanical means
D06F 33/00 - Control of operations performed in washing machines or washer-dryers
An electric heater assembly for mounting in an electric clothes dryer supports an electrical heating element. The heater assembly has overlapping arcuate shaped support plates of mica for supporting a zig-zag shaped electrical heating element. The support plates have inner and outer concentrically curved side edge portions having inner and outer notches. A support wall mounted in the clothes dryer supports the support plates by series of inner and outer arcuate spaced apart tab members. The tab members each have a flap member. The flap members are positioned so that the notches of the support plates align with the flaps to permit the support plates to be positioned relative to the housing support wall, and then rotated, so that the flap members overlappingly engage at least one of the support plates to hold the support plates relative to the housing support wall.
A slide system for an appliance is provided. The system may be used with a retractable compartment, such as a drawer, shelf or grill and may be implemented inside a cavity of the appliance having a pair of vertical walls provided with a series of ribs having a recess at their top surfaces, and a movable runner in the recess. The runner may be located over slides that delimit and guide travel of the runner to provide a longer draw-out distance for the retractable compartment, which is conducive to improving storage ability and accessibility to the retractable compartment.
A washing machine clutch to rotate or oscillate an agitator or propeller and selectively rotate a basket, comprising a support member that contains a cover and a second cover, an actuator that contains a piston, a bracket that contains a lever joined to arms, terminals and a protuberance, wherein the terminals and the protuberance are in said arms, a first spring connected between said support member and said bracket, a hollow shaft and a shaft configured to rotate, a mobile clutch containing an upper wall, a groove an internal part and a lower wall, wherein said terminals rest in the groove and in said upper wall, wherein the lower wall contains a plurality of alternating teeth and grooves and wherein the mobile clutch is coupled to the hollow shaft by its internal part, a pulley-clutch containing a plurality of alternating teeth and grooves, and an internal part, wherein the pulley-clutch is coupled to the shaft by means of said pulley-clutch internal part, wherein the mobile clutch couples with the pulley-clutch by means of the activation of said actuator, allowing the arm, terminal, protuberance and mobile clutch movement.
A clothes dryer has a degree of dryness control system that is responsive to moisture level of clothing articles tumbling in a drum and a target moisture value to control the drying cycle of the clothes dryer. The clothes dryer has a load size parameter producing module and an air flow detection parameter module. These modules generate one of two parameter conditions used by the processor to modify or select an appropriate moisture target value. The load size producing parameter module generates one of a small load input parameter and a large load input parameter. The air flow detection module produces one of a first and second air flow parameter to be utilized by the degree of dryness processor. As a result, the processor selects one of four target moisture values from these conditions.
This invention consists of a floating clutch for two concentric shafts. This is achieved by means of a movable body transmitting energy from one shaft to the other via cogs that engage or disengage vertically depending on the presence of fluid; torque of the inner shaft is transmitted to the coupler and from the coupler to the movable body, and in turn, to the fixed cog, and then to the outer shaft, when it is in the clutch position. The invention also consists of a group of chambers and peripheral walls that allow the assembly to operate in optimal conditions, avoiding malfunctions, breakdowns and unhealthy conditions by preventing the buildup of fluff, scale, fibers, sediments, dirt or undesired objects hampering the correct operation of the invention and of a home-type washing machine.
D06F 29/00 - Combinations of a washing machine with other separate apparatus in a common frame or the like, e.g. with rinsing apparatus
D06F 37/24 - Mountings, e.g. resilient mountings, for the rotary receptacle, motor, tub or casingPreventing or damping vibrations in machines with a receptacle rotating or oscillating about a vertical axis
A moisture sensing circuit for a clothes dryer in which clothes tumble during drying has a pair of spaced apart electrode sensors for sensing the electrical resistance of the clothes when the clothes contact the electrodes. The circuit has an active filter for suppressing noise related to the operating line frequency of the clothes dryer to provide a filtered voltage signal representative of voltage drop across the electrode sensors with the line frequency noise suppressed.
