Goods & Services

Tools for mineworking machines including ground engaging tools; tools for mining machines including ground engaging tools; holding devices for machine tools; buckets for earth moving machines; cutting tips [parts of machines]; cutting tools including teeth being parts of machines; blades for earth moving machines; bits for mining machines; locking components for use with mining and earthmoving equipment; lips for excavating buckets; teeth and jaws for use with earthmoving and mining machines.

Goods & Services

(1) Tools for mineworking machines including ground engaging tools; tools for mining machines including ground engaging tools; holding devices for machine tools; buckets for earth moving machines; cutting tips [parts of machines]; cutting tools including teeth being parts of machines; blades for earth moving machines; bits for mining machines; locking components for use with mining and earthmoving equipment; lips for excavating buckets; teeth and jaws for use with earthmoving and mining machines.

Goods & Services

Tools for mineworking machines including ground engaging tools; tools for mining machines including ground engaging tools; holding devices for machine tools; buckets for earth moving machines; cutting tips [parts of machines]; cutting tools including teeth being parts of machines; blades for earth moving machines; bits for mining machines; locking components for use with mining and earthmoving equipment; lips for excavating buckets; teeth and jaws for use with earthmoving and mining machines.

Abstract

A monitoring system and method for a tool of working equipment, preferably a ground engaging tool comprising wear members such as an excavator bucket, the system/method including one or more sensors mounted on the working equipment and directed towards the tool and a processor configured to: receive data relating to the tool from the one or more sensors, generate a three dimensional representation of at least a portion of the tool using the received data, compare the generated three dimensional representation with a previously generated three dimensional representation, and identify one or more of wear and loss of at least a portion of the tool, preferably a wear member portion, using the comparison of the generated three dimensional representation with the previously generated three dimensional representation.

IPC Classes  ?

• E02F 9/26 - Indicating devices
• E02F 9/28 - Small metalwork for digging elements, e.g. teeth
• G06T 17/00 - 3D modelling for computer graphics
• G06V 10/143 - Sensing or illuminating at different wavelengths
• G06V 10/44 - Local feature extraction by analysis of parts of the pattern, e.g. by detecting edges, contours, loops, corners, strokes or intersectionsConnectivity analysis, e.g. of connected components
• G06V 20/64 - Three-dimensional objects

Goods & Services

Apparatus and instruments for detecting, monitoring, analysing and reporting performance metrics of equipment used in the mining industry; apparatus and instruments, including alarms and radio frequency identification (RFID) sensors and readers for real-time data input and output, for acquiring, transmitting, receiving, storing, processing, converting, reporting and displaying of data for monitoring wear, breakage, performance, maintenance and productivity characteristics of ground engaging tools and their components used in the mining industry. Monitoring, including remote monitoring, of performance metrics, maintenance and productivity of equipment used in the mining industry; preparation and provision of engineering reports relating to performance metrics, maintenance and productivity of equipment used in the mining industry; rental of apparatus and instruments for detecting, monitoring, analysing and reporting performance metrics, maintenance and productivity of equipment used in the mining industry; providing engineering services relating to the provision of apparatus and instruments for detecting, monitoring, analysing and reporting performance metrics, maintenance and productivity of equipment used in the mining industry; advisory and consultancy services relating to all the aforesaid services.

Abstract

An excavator wear member is disclosed. The excavator wear member has a socket cavity opening at a rear end of the wear member. The socket cavity is at least partially defined by a top wall, a bottom wall, opposed side walls and a front bearing face. The excavator wear member has tertiary fit faces extending laterally between each opposed side wall and one of the top wall or the bottom wall. Each of the tertiary fit faces also extends rearwardly substantially in a plane within the socket cavity from the front bearing face to a rear end of the socket cavity.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

Disclosed is an equipment identification system, the equipment preferably, although not exclusively, in the form of a truck, the system comprising a sensor located on the truck, the sensor configured to sense movement of the truck and generate movement data associated with the truck; a transmitter configured to transmit truck identification data associated with the truck and the movement data; a receiver in communication with the transmitter, the receiver configured to receive the truck identification data and the movement data from the transmitter; and a management system in communication with the receiver, the management system configured to identify the truck and also determine whether the truck is currently being loaded by an excavator based on the truck identification data and the movement data.

IPC Classes  ?

• G07C 5/00 - Registering or indicating the working of vehicles
• E02F 9/26 - Indicating devices
• G01G 19/08 - Weighing apparatus or methods adapted for special purposes not provided for in groups for incorporation in vehicles
• G06Q 10/0631 - Resource planning, allocation, distributing or scheduling for enterprises or organisations
• G07C 5/02 - Registering or indicating driving, working, idle, or waiting time only
• G08C 17/02 - Arrangements for transmitting signals characterised by the use of a wireless electrical link using a radio link
• H04L 67/12 - Protocols specially adapted for proprietary or special-purpose networking environments, e.g. medical networks, sensor networks, networks in vehicles or remote metering networks

Goods & Services

(1) Apparatus and instruments for detecting, monitoring, analysing and reporting performance metrics of equipment used in the mining industry; apparatus and instruments, including alarms and radio frequency identification (RFID) sensors and readers for real-time data input and output, for acquiring, transmitting, receiving, storing, processing, converting, reporting and displaying of data for monitoring wear, breakage, performance, maintenance and productivity characteristics of ground engaging tools and their components used in the mining industry. (1) Monitoring, including remote monitoring, of performance metrics, maintenance and productivity of equipment used in the mining industry; preparation and provision of engineering reports relating to performance metrics, maintenance and productivity of equipment used in the mining industry; rental of apparatus and instruments for detecting, monitoring, analysing and reporting performance metrics, maintenance and productivity of equipment used in the mining industry; providing engineering services relating to the provision of apparatus and instruments for detecting, monitoring, analysing and reporting performance metrics, maintenance and productivity of equipment used in the mining industry; advisory and consultancy services relating to all the aforesaid services.

Goods & Services

Apparatus and instruments for detecting, monitoring, analysing and reporting performance metrics of equipment used in the mining industry; apparatus and instruments, including alarms and radio frequency identification (RFID) sensors and readers for real-time data input and output, for acquiring, transmitting, receiving, storing, processing, converting, reporting and displaying of data for monitoring wear, breakage, performance, maintenance and productivity characteristics of ground engaging tools and their components used in the mining industry. Monitoring, including remote monitoring, of performance metrics, maintenance and productivity of equipment used in the mining industry; preparation and provision of engineering reports relating to performance metrics, maintenance and productivity of equipment used in the mining industry; rental of apparatus and instruments for detecting, monitoring, analysing and reporting performance metrics, maintenance and productivity of equipment used in the mining industry; providing engineering services relating to the provision of apparatus and instruments for detecting, monitoring, analysing and reporting performance metrics, maintenance and productivity of equipment used in the mining industry; advisory and consultancy services relating to all the aforesaid services.

Goods & Services

Cutting parts of machines, namely, cutting edges, teeth and blades for excavating, quarrying, mining, open-cast mining, dredging, and earth moving equipment

Abstract

An excavator wear member is disclosed. The excavator wear member has a socket cavity opening at a rear end of the wear member. The socket cavity is at least partially defined by a top wall, a bottom wall, opposed side walls and a front bearing face. The excavator wear member has tertiary fit faces extending laterally between each opposed side wall and one of the top wall or the bottom wall. Each of the tertiary fit faces also extends rearwardly substantially in a plane within the socket cavity from the front bearing face to a rear end of the socket cavity.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

An excavator wear member is disclosed. The excavator wear member has a socket cavity opening at a rear end of the wear member. The socket cavity is at least partially defined by a top wall, a bottom wall, opposed side walls and a front bearing face. The excavator wear member has tertiary fit faces extending laterally between each opposed side wall and one of the top wall or the bottom wall. Each of the tertiary fit faces also extends rearwardly substantially in a plane within the socket cavity from the front bearing face to a rear end of the socket cavity.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

Disclosed is an equipment identification system, the equipment preferably, although not exclusively, in the form of a truck, the system comprising a sensor located on the truck, the sensor configured to sense movement of the truck and generate movement data associated with the truck; a transmitter configured to transmit truck identification data associated with the truck and the movement data; a receiver in communication with the transmitter, the receiver configured to receive the truck identification data and the movement data from the transmitter; and a management system in communication with the receiver, the management system configured to identify the truck and also determine whether the truck is currently being loaded by an excavator based on the truck identification data and the movement data.

IPC Classes  ?

• B60P 1/04 - Vehicles predominantly for transporting loads and modified to facilitate loading, consolidating the load, or unloading with a tipping movement of load supporting or containing element
• E02F 3/43 - Control of dipper or bucket positionControl of sequence of drive operations
• E02F 9/20 - DrivesControl devices
• G01G 19/08 - Weighing apparatus or methods adapted for special purposes not provided for in groups for incorporation in vehicles
• G01P 15/00 - Measuring accelerationMeasuring decelerationMeasuring shock, i.e. sudden change of acceleration
• G06Q 50/02 - AgricultureFishingForestryMining
• G07C 5/02 - Registering or indicating driving, working, idle, or waiting time only
• H04W 4/80 - Services using short range communication, e.g. near-field communication [NFC], radio-frequency identification [RFID] or low energy communication

Abstract

Disclosed is an equipment identification system, the equipment preferably, although not exclusively, in the form of a truck, the system comprising a sensor located on the truck, the sensor configured to sense movement of the truck and generate movement data associated with the truck; a transmitter configured to transmit truck identification data associated with the truck and the movement data; a receiver in communication with the transmitter, the receiver configured to receive the truck identification data and the movement data from the transmitter; and a management system in communication with the receiver, the management system configured to identify the truck and also determine whether the truck is currently being loaded by an excavator based on the truck identification data and the movement data.

IPC Classes  ?

• B60P 1/04 - Vehicles predominantly for transporting loads and modified to facilitate loading, consolidating the load, or unloading with a tipping movement of load supporting or containing element
• E02F 3/43 - Control of dipper or bucket positionControl of sequence of drive operations
• H04W 4/80 - Services using short range communication, e.g. near-field communication [NFC], radio-frequency identification [RFID] or low energy communication
• G06Q 50/02 - AgricultureFishingForestryMining
• G07C 5/02 - Registering or indicating driving, working, idle, or waiting time only
• G01G 19/08 - Weighing apparatus or methods adapted for special purposes not provided for in groups for incorporation in vehicles
• G01P 15/00 - Measuring accelerationMeasuring decelerationMeasuring shock, i.e. sudden change of acceleration
• E02F 9/20 - DrivesControl devices

Abstract

a first actuator connected to the gripper and the body, to apply a force to the gripper, to urge the gripper to move relative to the body, such that, when the bracing member bears against the ground engaging surface, movement of the gripper relative to the body removes the wear member from the ground engaging surface.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth
• B25J 15/00 - Gripping heads

Abstract

A monitoring system and method for a tool of working equipment, preferably a ground engaging tool comprising wear members such as an excavator bucket, the system/method including one or more sensors mounted on the working equipment and directed towards the tool and a processor configured to: receive data relating to the tool from the one or more sensors, generate a three dimensional representation of at least a portion of the tool using the received data, compare the generated three dimensional representation with a previously generated three dimensional representation, and identify one or more of wear and loss of at least a portion of the tool, preferably a wear member portion, using the comparison of the generated three dimensional representation with the previously generated three dimensional representation.

IPC Classes  ?

• E02F 9/26 - Indicating devices
• E02F 9/28 - Small metalwork for digging elements, e.g. teeth
• G06T 17/00 - 3D modelling for computer graphics

Abstract

A device (40) for removing a wear member (26) from a ground engaging surface (20), the device (40) comprising: a body (42) having cavity (44) and a wear member engaging portion (46) to engage the wear member (26) when the wear member (26) extends into the cavity (44); a gripper (50) movable relative to the body (42), the gripper (50) having a bracing member (52) adapted to bear against a portion of the ground engaging surface (20) to thereby provide a load path from the ground engaging surface (20) to the wear member engaging portion (46); and a first actuator (56) connected to the gripper (50) and the body (42), to apply a force to the gripper (50), to urge the gripper (50) to move relative to the body (42), such that, when the bracing member (52) bears against the ground engaging surface (20), movement of the gripper (50) relative to the body (42) removes the wear member (26) from the ground engaging surface (20).

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A device (40) for removing a wear member (26) from a ground engaging surface (20), the device (40) comprising: a body (42) having cavity (44) and a wear member engaging portion (46) to engage the wear member (26) when the wear member (26) extends into the cavity (44); a gripper (50) movable relative to the body (42), the gripper (50) having a bracing member (52) adapted to bear against a portion of the ground engaging surface (20) to thereby provide a load path from the ground engaging surface (20) to the wear member engaging portion (46); and a first actuator (56) connected to the gripper (50) and the body (42), to apply a force to the gripper (50), to urge the gripper (50) to move relative to the body (42), such that, when the bracing member (52) bears against the ground engaging surface (20), movement of the gripper (50) relative to the body (42) removes the wear member (26) from the ground engaging surface (20).

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A monitoring system and method for a tool of working equipment, preferably a ground engaging tool comprising wear members such as an excavator bucket, the system/method including one or more sensors mounted on the working equipment and directed towards the tool and a processor configured to: receive data relating to the tool from the one or more sensors, generate a three dimensional representation of at least a portion of the tool using the received data, compare the generated three dimensional representation with a previously generated three dimensional representation, and identify one or more of wear and loss of at least a portion of the tool, preferably a wear member portion, using the comparison of the generated three dimensional representation with the previously generated three dimensional representation.

IPC Classes  ?

• E02F 5/14 - Component parts for trench excavators, e.g. indicating devices
• E02F 9/26 - Indicating devices
• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A monitoring system and method for a tool of working equipment, preferably a ground engaging tool comprising wear members such as an excavator bucket, the system/method including one or more sensors mounted on the working equipment and directed towards the tool and a processor configured to: receive data relating to the tool from the one or more sensors, generate a three dimensional representation of at least a portion of the tool using the received data, compare the generated three dimensional representation with a previously generated three dimensional representation, and identify one or more of wear and loss of at least a portion of the tool, preferably a wear member portion, using the comparison of the generated three dimensional representation with the previously generated three dimensional representation.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth
• E02F 9/26 - Indicating devices
• E02F 5/14 - Component parts for trench excavators, e.g. indicating devices

Goods & Services

Non-customised metallic liner plates and panels for protecting mining chutes; non-customised metallic liner plates and panels for protecting conveyor chutes; non-customised metallic liner plates and panels for protecting trays used in mining equipment and mining vehicles; metallic plates for protection against surface wear for use in mining applications. Conveyors for use in the mining industry; scrapers for use in the mining industry; crushing machines for use in the mining industry; draglines and dragline rigging for use in the mining industry; stone dusting machines for use in the mining industry; components for conveyors, draglines, dragline rigging, scrapers, crushing machines, and stone dusting machines used in the mining industry; buckets for draglines; blades for graders; teeth, jaws and wear components for use in machines used in the earth moving, mining, mineral processing and crushing industries; ground engaging tools for use with machinery used in the mining industry; cast metallic lips for use with mining machinery and equipment; locking components for use with mining machinery and equipment; components for front end loaders; electric rope shovels; hydraulic mining shovels. Computer software for improving mining productivity, including software for payload monitors, machinery stress and strain monitors, wear sensors, and coal depth identifiers; computer hardware for improving mining productivity, including payload monitors, machinery stress and strain monitors, and coal depth identifiers; sensors for condition monitoring of mining equipment and protective plates used in the mining industry; data analysis software for use in the mining industry; monitoring software for use in the mining industry. Non-customised, non-metallic liner plates and panels being structural components for protecting mining chutes; non-customised, non-metallic liner plates and panels being structural components for protecting conveyor chutes; non-customised, non-metallic liner plates and panels being structural components for protecting trays used in mining equipment and mining vehicles; non-customised, non-metallic plates and panels being structural components for protection against surface wear for use in mining applications. Maintenance and repair services in relation to mining equipment and machinery; installation services in relation to mining equipment and machinery. Software as a service for improving mining productivity, including software for payload monitors, machinery stress and strain monitors, wear sensors, and coal depth identifiers; software as a service for data analysis purposes in the mining industry; software as a service for monitoring purposes in the mining industry; engineering consultancy to the mining industry; machine equipment and condition monitoring for the mining industry.

Goods & Services

Non-customised metallic liner plates and panels for protecting mining chutes; non-customised metallic liner plates and panels for protecting conveyor chutes; non-customised metallic liner plates and panels for protecting trays used in mining equipment and mining vehicles; metallic plates for protection against surface wear for use in mining applications. Conveyors for use in the mining industry; scrapers for use in the mining industry; crushing machines for use in the mining industry; draglines and dragline rigging for use in the mining industry; stone dusting machines for use in the mining industry; components for conveyors, draglines, dragline rigging, scrapers, crushing machines, and stone dusting machines used in the mining industry; buckets for draglines; blades for graders; teeth, jaws and wear components for use in machines used in the earth moving, mining, mineral processing and crushing industries; ground engaging tools for use with machinery used in the mining industry; cast metallic lips for use with mining machinery and equipment; locking components for use with mining machinery and equipment; components for front end loaders; electric rope shovels; hydraulic mining shovels. Computer software for improving mining productivity, including software for payload monitors, machinery stress and strain monitors, wear sensors, and coal depth identifiers; computer hardware for improving mining productivity, including payload monitors, machinery stress and strain monitors, and coal depth identifiers; sensors for condition monitoring of mining equipment and protective plates used in the mining industry; data analysis software for use in the mining industry; monitoring software for use in the mining industry. Non-customised, non-metallic liner plates and panels being structural components for protecting mining chutes; non-customised, non-metallic liner plates and panels being structural components for protecting conveyor chutes; non-customised, non-metallic liner plates and panels being structural components for protecting trays used in mining equipment and mining vehicles; non-customised, non-metallic plates and panels being structural components for protection against surface wear for use in mining applications. Maintenance and repair services in relation to mining equipment and machinery; installation services in relation to mining equipment and machinery. Software as a service for improving mining productivity, including software for payload monitors, machinery stress and strain monitors, wear sensors, and coal depth identifiers; software as a service for data analysis purposes in the mining industry; software as a service for monitoring purposes in the mining industry; engineering consultancy to the mining industry; machine equipment and condition monitoring for the mining industry.

Goods & Services

Computer software for improving mining productivity, including software for payload monitors, machinery stress and strain monitors, wear sensors, and coal depth identifiers; computer hardware for improving mining productivity, including payload monitors, machinery stress and strain monitors, and coal depth identifiers; sensors for condition monitoring of mining equipment and protective plates used in the mining industry; data analysis software for use in the mining industry; monitoring software for use in the mining industry. Software as a service for improving mining productivity, including software for payload monitors, machinery stress and strain monitors, wear sensors, and coal depth identifiers; software as a service for data analysis purposes in the mining industry; software as a service for monitoring purposes in the mining industry; engineering consultancy to the mining industry; machine equipment and condition monitoring for the mining industry.

Abstract

An article handler for attachment to a front end loader, the article handler comprising a support body and a jaw assembly, the support body comprising a proximal end adapted for attachment to the front end loader, and a distal end adapted for attachment of the jaw assembly. The article handler may be adapted to handle, install, and dismount ground engaging tools (GET), such as teeth for excavating buckets.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth
• B25J 5/00 - Manipulators mounted on wheels or on carriages
• E02F 3/60 - Buckets, scrapers, or other digging elements
• E02F 3/40 - DippersBuckets

Abstract

An article handler for attachment to a front end loader, the article handler comprising a support body and a jaw assembly, the support body comprising a proximal end adapted for attachment to the front end loader, and a distal end adapted for attachment of the jaw assembly. The article handler may be adapted to handle, install and dismount ground engaging tools (GET), such as teeth for excavating buckets.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Goods & Services

(1) Computer software for improving mining productivity, namely software for payload monitors, machinery stress and strain monitors, wear sensors, and coal depth identifiers; computer hardware for improving mining productivity, including payload monitors, machinery stress and strain monitors, and coal depth identifiers; sensors for condition monitoring of mining equipment and protective plates used in the mining industry; data analysis software for use in the mining industry; monitoring software for use in the mining industry. (1) Software as a service for improving mining productivity, namely software for payload monitors, machinery stress and strain monitors, wear sensors, and coal depth identifiers; software as a service for data analysis purposes in the mining industry; software as a service for monitoring purposes in the mining industry; engineering consultancy to the mining industry; machine equipment and condition monitoring for the mining industry.

Goods & Services

(1) Non-customised metallic liner plates and panels for protecting mining chutes; non-customised metallic liner plates and panels for protecting conveyor chutes; non-customised metallic liner plates and panels for protecting trays used in mining equipment and mining vehicles; metallic plates for protection against surface wear for use in mining applications. (2) Conveyors for use in the mining industry; scrapers for use in the mining industry; crushing machines for use in the mining industry; draglines and dragline rigging for use in the mining industry; stone dusting machines for use in the mining industry; components for conveyors, draglines, dragline rigging, scrapers, crushing machines, and stone dusting machines used in the mining industry; buckets for draglines; blades for graders; teeth, jaws and wear components for use in machines used in the earth moving, mining, mineral processing and crushing industries; ground engaging tools for use with machinery used in the mining industry; cast metallic lips for use with mining machinery and equipment; locking components for use with mining machinery and equipment; components for front end loaders; electric rope shovels; hydraulic mining shovels. (3) Computer software for improving mining productivity, namely software for payload monitors, machinery stress and strain monitors, wear sensors, and coal depth identifiers; computer hardware for improving mining productivity, including payload monitors, machinery stress and strain monitors, and coal depth identifiers; sensors for condition monitoring of mining equipment and protective plates used in the mining industry; data analysis software for use in the mining industry; monitoring software for use in the mining industry. (4) Non-customised, non-metallic liner plates and panels being structural components for protecting mining chutes; non-customised, non-metallic liner plates and panels being structural components for protecting conveyor chutes; non-customised, non-metallic liner plates and panels being structural components for protecting trays used in mining equipment and mining vehicles; non-customised, non-metallic plates and panels being structural components for protection against surface wear for use in mining applications. (1) Maintenance and repair services in relation to mining equipment and machinery; installation services in relation to mining equipment and machinery. (2) Software as a service for improving mining productivity, namely software for payload monitors, machinery stress and strain monitors, wear sensors, and coal depth identifiers; software as a service for data analysis purposes in the mining industry; software as a service for monitoring purposes in the mining industry; engineering consultancy to the mining industry; machine equipment and condition monitoring for the mining industry.

Goods & Services

Non-customised metallic liner plates and panels for protecting mining chutes; non-customised metallic liner plates and panels for protecting conveyor chutes; non-customised metallic liner plates and panels for protecting trays used in mining equipment and mining vehicles; metallic plates for protection against surface wear for use in mining applications Conveyors being machines for use in the mining industry and structural component parts thereof; earth moving machines, namely, scrapers for use in the mining industry and structural component parts thereof; mineworking machines in the nature of crushing machines for use in the mining industry and structural component parts thereof; mineworking machines being draglines and dragline rigging for use in the mining industry and structural component parts thereof; mineworking machines in the nature of stone dusting machines for use in the mining industry and structural component parts thereof; structural parts for mineworking machines, namely, buckets for draglines being mineworking machines; structural parts for mineworking and earth moving machines, namely, blades for graders, teeth, jaws and wear components used in the earth moving mining, mineral processing and crushing industries; wear components, namely, cast lips, teeth, and plates forming parts of machines used in the earth moving, mining, mineral processing and crushing industries; ground engaging tools for use with machinery used in the mining industry, namely, ground surface finishing, breaking, digging, and compacting machines; structural mineworking machine parts, namely, cast metallic lips and locking structural component parts; structural component parts for front end loaders; power shovels in the nature of electric rope shovels; mineworking machines in the nature of hydraulic mining shovels Downloadable computer software for improving mining productivity, which monitors payload, monitors machinery stress and strain, monitors wear sensors, and identifies coal depth; computer hardware for improving mining productivity, including payload monitors, machinery stress and strain monitors, and coal depth identifiers; sensors for condition monitoring of mining equipment and protective plates used in the mining industry, namely, sensors for determining position, velocity, acceleration, and temperature, motion sensors, and vibration sensors; downloadable data analysis software for use in the mining industry; downloadable software for monitoring payloads, machinery stress and strain, and equipment wear in the mining industry for use in the mining industry; downloadable software for improving mining productivity, namely, software for optimising load hauls in mining operations; downloadable software for improving mining productivity, namely, digital terrain mapping for use in the mining industry; downloadable software for improving mining productivity, namely, drilling efficiency, productivity, and safety in mining operations Non-customised, non-metallic liner plates and panels being structural components for protecting mining chutes; non-customised, non-metallic liner plates and panels being structural components for protecting conveyor chutes; non-customised, non-metallic liner plates and panels being structural components for protecting trays used in mining equipment and mining vehicles; non-customised, non-metallic plates and panels being structural components for protection against surface wear for use in mining applications Maintenance and repair of mining equipment and machinery; installation of mining equipment and machinery Software as a service featuring software for improving mining productivity, which monitors payload, monitors machinery stress and strain, monitors wear sensors, and identifies coal depth; software as a service featuring software for data analysis purposes in the mining industry; software as a service featuring software for monitoring payloads, machinery stress and strain, and equipment wear in the mining industry; engineering consultancy to the mining industry; electronic monitoring of machine equipment and the condition of the equipment for the mining industry using computers and sensors; monitoring of computer systems by remote access to ensure proper functioning related to machine equipment and the monitoring of the condition of equipment for the mining industry; software as a service featuring software for monitoring payloads, machinery stress and strain, and equipment wear in the mining industry for use in the mining industry; software as a service featuring software for improving mining productivity, namely, software for optimising load hauls in mining operations; software as a service featuring software for improving mining productivity, namely, digital terrain mapping for use in the mining industry; software as a service featuring software for improving mining productivity, namely, drilling efficiency, productivity, and safety in mining operations

Goods & Services

(1) Non-customised metallic liner plates and panels for protecting mining chutes; non-customised metallic liner plates and panels for protecting conveyor chutes; non-customised metallic liner plates and panels for protecting trays used in mining equipment and mining vehicles; metallic plates for protection against surface wear for use in mining applications. (2) Conveyors for use in the mining industry; scrapers for use in the mining industry; crushing machines for use in the mining industry; draglines and dragline rigging for use in the mining industry; stone dusting machines for use in the mining industry; components for conveyors, draglines, dragline rigging, scrapers, crushing machines, and stone dusting machines used in the mining industry; buckets for draglines; blades for graders; teeth, jaws and wear components for use in machines used in the earth moving, mining, mineral processing and crushing industries; ground engaging tools for use with machinery used in the mining industry; cast metallic lips for use with mining machinery and equipment; locking components for use with mining machinery and equipment; components for front end loaders; electric rope shovels; hydraulic mining shovels. (3) Computer software for improving mining productivity, namely software for payload monitors, machinery stress and strain monitors, wear sensors, and coal depth identifiers; computer hardware for improving mining productivity, including payload monitors, machinery stress and strain monitors, and coal depth identifiers; sensors for condition monitoring of mining equipment and protective plates used in the mining industry; data analysis software for use in the mining industry; monitoring software for use in the mining industry. (4) Non-customised, non-metallic liner plates and panels being structural components for protecting mining chutes; non-customised, non-metallic liner plates and panels being structural components for protecting conveyor chutes; non-customised, non-metallic liner plates and panels being structural components for protecting trays used in mining equipment and mining vehicles; non-customised, non-metallic plates and panels being structural components for protection against surface wear for use in mining applications. (1) Maintenance and repair services in relation to mining equipment and machinery; installation services in relation to mining equipment and machinery. (2) Software as a service for improving mining productivity, namely software for payload monitors, machinery stress and strain monitors, wear sensors, and coal depth identifiers; software as a service for data analysis purposes in the mining industry; software as a service for monitoring purposes in the mining industry; engineering consultancy to the mining industry; machine equipment and condition monitoring for the mining industry.

Goods & Services

Downloadable computer software for improving mining productivity, which monitors payload, monitors machinery stress and strain, monitors wear sensors, and identifies coal depth; computer hardware for improving mining productivity, including payload monitors, machinery stress and strain monitors, and coal depth identifiers; sensors for condition monitoring of mining equipment and protective plates used in the mining industry, namely, sensors for determining position, velocity, acceleration, and temperature, motion sensors, and vibration sensors; data analysis software for use in the mining industry; downloadable software for monitoring payloads, machinery stress and strain, and equipment wear in the mining industry for use in the mining industry; downloadable software for improving mining productivity, namely, software for optimising load hauls in mining operations; downloadable software for improving mining productivity, namely digital terrain mapping for use in the mining industry; downloadable software for improving mining productivity, namely, drilling efficiency, productivity, and safety in mining operations Software as a service featuring software for improving mining productivity, which monitors payload, monitors machinery stress and strain, monitors wear sensors, and identifies coal depth; software as a service featuring software for data analysis purposes in the mining industry; software as a service featuring software for monitoring payloads, machinery stress and strain, and equipment wear in the mining industry; engineering consultancy to the mining industry; electronic monitoring of machine equipment and the condition of the equipment for the mining industry using computers and sensors; monitoring of computer systems by remote access to ensure proper functioning related to machine equipment and the monitoring of the condition of equipment for the mining industry; software as a service featuring software for monitoring payloads, machinery stress and strain, and equipment wear in the mining industry for use in the mining industry; software as a service featuring software for improving mining productivity, namely, software for optimising load hauls in mining operations; software as a service featuring software for improving mining productivity, namely digital terrain mapping for use in the mining industry; software as a service featuring software for improving mining productivity, namely, drilling efficiency, productivity, and safety in mining operations

Goods & Services

Non-customised metallic liner plates and panels for protecting mining chutes; non-customised metallic liner plates and panels for protecting conveyor chutes; non-customised metallic liner plates and panels for protecting trays used in mining equipment and mining vehicles; metallic plates for protection against surface wear for use in mining applications Conveyors being machines for use in the mining industry and structural component parts thereof; earth moving machines, namely, scrapers for use in the mining industry and structural component parts thereof; mineworking machines in the nature of crushing machines for use in the mining industry and structural component parts thereof; mineworking machines being draglines and dragline rigging for use in the mining industry and structural component parts thereof; mineworking machines in the nature of stone dusting machines for use in the mining industry and structural component parts thereof; structural parts for mineworking machines, namely, buckets for draglines being mineworking machines; structural parts for mineworking and earth moving machines, namely, blades for graders, teeth, jaws and wear components used in the earth moving mining, mineral processing and crushing industries; wear components, namely, cast lips, teeth, and plates forming parts of machines used in the earth moving, mining, mineral processing and crushing industries; ground engaging tools for use with machinery used in the mining industry, namely, ground surface finishing, breaking, digging, and compacting machines; structural mineworking machine parts, namely, cast metallic lips and locking structural component parts; structural component parts for front end loaders; power shovels in the nature of electric rope shovels; mineworking machines in the nature of hydraulic mining shovels Downloadable computer software for improving mining productivity, which monitors payload, monitors machinery stress and strain, monitors wear sensors, and identifies coal depth; computer hardware for improving mining productivity, including payload monitors, machinery stress and strain monitors, and coal depth identifiers; sensors for condition monitoring of mining equipment and protective plates used in the mining industry, namely, sensors for determining position, velocity, acceleration, and temperature, motion sensors, and vibration sensors; downloadable data analysis software for use in the mining industry; downloadable software for monitoring payloads, machinery stress and strain, and equipment wear in the mining industry for use in the mining industry; downloadable software for improving mining productivity, namely, software for optimising load hauls in mining operations; downloadable software for improving mining productivity, namely, digital terrain mapping for use in the mining industry; downloadable software for improving mining productivity, namely, drilling efficiency, productivity, and safety in mining operation Non-customised, non-metallic liner plates and panels being structural components for protecting mining chutes; non-customised, non-metallic liner plates and panels being structural components for protecting conveyor chutes; non-customised, non-metallic liner plates and panels being structural components for protecting trays used in mining equipment and mining vehicles; non-customised, non-metallic plates and panels being structural components for protection against surface wear for use in mining applications Maintenance and repair of mining equipment and machinery; installation of mining equipment and machinery Software as a service (SAAS) services featuring software for improving mining productivity, which monitors payload, monitors machinery stress and strain, monitors wear sensors, and identifies coal depth; software as a service (SAAS) services featuring software for data analysis purposes in the mining industry; software as a service (SAAS) services featuring software for monitoring payloads, machinery stress and strain, and equipment wear in the mining industry; engineering consultancy to the mining industry; electronic monitoring of machine equipment and the condition of the equipment for the mining industry using computers and sensors; monitoring of computer systems by remote access to ensure proper functioning related to machine equipment and the monitoring of the condition of equipment for the mining industry; software as a service (SAAS) services featuring software for monitoring payloads, machinery stress and strain, and equipment wear in the mining industry for use in the mining industry; software as a service (SAAS) services featuring software for improving mining productivity, namely, software for optimising load hauls in mining operations; software as a service (SAAS) services featuring software for improving mining productivity, namely, digital terrain mapping for use in the mining industry; software as a service (SAAS) services featuring software for improving mining productivity, namely, drilling efficiency, productivity, and safety in mining operations

Abstract

A wear member monitoring system for a ground engaging tool, the system including: a measuring assembly having: an emitting device configured to emit a measurement signal towards a wear member of the ground engaging tool; a detecting device configured to detect a reflected measurement signal in response to the measurement signal emitted towards the wear member; and a processor configured to: analyse the reflected measurement signal with a two dimensional reference model; and determine a condition of the wear member based on the analysis of the reflected measurement signal with the two dimensional reference model.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth
• E02F 9/26 - Indicating devices
• G01B 11/16 - Measuring arrangements characterised by the use of optical techniques for measuring the deformation in a solid, e.g. optical strain gauge

Abstract

A lock assembly for an excavator wear assembly, the lock assembly a locking pin having at least one dowel extending outwardly therefrom. The lock assembly also includes a retaining member having a seat and a cavity and a biasing member located within the cavity of the retaining member. The biasing member is adapted to exert a biasing force on the dowel to releasably retain the dowel within the seat of the retaining member.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth
• E02F 3/32 - DredgersSoil-shifting machines mechanically-driven with digging tools mounted on a dipper- or bucket-arm, e.g. dippers, buckets with a dipper-arm pivoted on a cantilever beam working downwardly and towards the machine, e.g. with backhoes

Abstract

A system of estimating fatigue in a lifting member, the system including: a first sensor configured to measure a first load related to a ram, the ram being connected to the lifting member; and a calculating device configured to: determine an actuator load based on the first load; determine a first force based on the actuator load; estimate a unit of fatigue life based on the first force; and estimate a fraction of total fatigue life consumed for a portion of the lifting member based on the unit of fatigue life and a fatigue life adjustment value.

IPC Classes  ?

• E02F 9/24 - Safety devices
• E02F 9/26 - Indicating devices
• E02F 9/22 - Hydraulic or pneumatic drives
• G07C 5/02 - Registering or indicating driving, working, idle, or waiting time only

Abstract

A wear member monitoring system for a ground engaging tool, the system including: a measuring assembly having: an emitting device configured to emit a measurement signal towards a wear member of the ground engaging tool; a detecting device configured to detect a reflected measurement signal in response to the measurement signal emitted towards the wear member; and a processor configured to: analyse the reflected measurement signal with a two dimensional reference model; and determine a condition of the wear member based on the analysis of the reflected measurement signal with the two dimensional reference model.

IPC Classes  ?

• E02F 3/26 - Safety or control devices
• E02F 9/24 - Safety devices

Abstract

A wear member monitoring system for a ground engaging tool, the system including: a measuring assembly having: an emitting device configured to emit a measurement signal towards a wear member of the ground engaging tool; a detecting device configured to detect a reflected measurement signal in response to the measurement signal emitted towards the wear member; and a processor configured to: analyse the reflected measurement signal with a two dimensional reference model; and determine a condition of the wear member based on the analysis of the reflected measurement signal with the two dimensional reference model.

IPC Classes  ?

• E02F 9/24 - Safety devices
• E02F 3/26 - Safety or control devices

Abstract

A system of identifying a payload destination, the system including: one or more sensors; and an identifying module configured to: receive a plurality of inputs from the one or more sensors, the plurality of inputs being associated with payload delivery from a lifting machine; define a plurality of input destination identifiers based on the plurality of inputs; compare the plurality of input destination identifiers with stored identifiers in order to establish one or more destination match estimates; and identify the payload destination based on the one or more destination match estimates.

IPC Classes  ?

• E02F 9/26 - Indicating devices
• G08B 21/18 - Status alarms
• G01G 19/12 - Weighing apparatus or methods adapted for special purposes not provided for in groups for incorporation in vehicles having electrical weight-sensitive devices
• G01G 19/08 - Weighing apparatus or methods adapted for special purposes not provided for in groups for incorporation in vehicles

Abstract

A system of calculating a payload weight, the system including: a first sensor configured to measure a first load associated with a first member of a lifting machine; a second sensor configured to measure a second load associated with a second member of the lifting machine; and a calculating device configured to calculate the payload weight being carried by the lifting machine based on the first load and the second load.

IPC Classes  ?

• G01G 19/08 - Weighing apparatus or methods adapted for special purposes not provided for in groups for incorporation in vehicles
• E02F 9/26 - Indicating devices
• E02F 9/24 - Safety devices
• E02F 3/32 - DredgersSoil-shifting machines mechanically-driven with digging tools mounted on a dipper- or bucket-arm, e.g. dippers, buckets with a dipper-arm pivoted on a cantilever beam working downwardly and towards the machine, e.g. with backhoes
• G01G 19/10 - Weighing apparatus or methods adapted for special purposes not provided for in groups for incorporation in vehicles having fluid weight-sensitive devices

Abstract

A heavy duty excavator bucket is constructed with an exoskeletal structure comprising coupled cast components including a lip member, opposed wing members, junction members locatable between floor and side walls and side and rear walls and a cap rail structure extending between opposed wing members about the upper periphery of the bucket to form an integral structure. Steel plate floor, side wall and rear wall members extend between adjacent exoskeletal regions. The bucket may include a cast arch member extending between opposed wing members and a cast reinforcing member extending between opposed junction members adjacent said rear wall.

IPC Classes  ?

• E02F 3/40 - DippersBuckets
• E02F 3/60 - Buckets, scrapers, or other digging elements

Abstract

A wear assembly having an adaptor with a spigot portion is disclosed. The spigot portion has a transverse dimension. The wear assembly also has a wear member releasably mountable on the adaptor. The wear member has a body with a socket cavity and the socket cavity is adapted to receive the spigot portion of the adaptor. The wear member also has a pair of mounting ears extending from the body. Each of the mounting ears has a transverse dimension. The transverse dimension of each mounting ear is in the range 0.25 to 0.4 of the transverse dimension of the spigot portion.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth
• E02F 3/32 - DredgersSoil-shifting machines mechanically-driven with digging tools mounted on a dipper- or bucket-arm, e.g. dippers, buckets with a dipper-arm pivoted on a cantilever beam working downwardly and towards the machine, e.g. with backhoes

Abstract

A system of estimating fatigue in a lifting member, the system including: a first sensor configured to measure a first load related to a ram, the ram being connected to the lifting member; and a calculating device configured to: determine an actuator load based on the first load; determine a first force based on the actuator load; estimate a unit of fatigue life based on the first force; and estimate a fraction of total fatigue life consumed for a portion of the lifting member based on the unit of fatigue life and a fatigue life adjustment value.

IPC Classes  ?

• E02F 9/26 - Indicating devices

Abstract

A system of identifying a payload destination, the system including: one or more sensors; and an identifying module configured to: receive a plurality of inputs from the one or more sensors, the plurality of inputs being associated with payload delivery from a lifting machine; define a plurality of input destination identifiers based on the plurality of inputs; compare the plurality of input destination identifiers with stored identifiers in order to establish one or more destination match estimates; and identify the payload destination based on the one or more destination match estimates.

IPC Classes  ?

• E02F 9/26 - Indicating devices
• G01G 19/08 - Weighing apparatus or methods adapted for special purposes not provided for in groups for incorporation in vehicles
• G08G 1/01 - Detecting movement of traffic to be counted or controlled

Abstract

A system of calculating a payload weight, the system including: a first sensor configured to measure a first load associated with a first member of a lifting machine; a second sensor configured to measure a second load associated with a second member of the lifting machine; and a calculating device configured to calculate the payload weight being carried by the lifting machine based on the first load and the second load.

IPC Classes  ?

• E02F 9/26 - Indicating devices
• G01G 19/00 - Weighing apparatus or methods adapted for special purposes not provided for in groups

Abstract

A system of calculating a payload weight, the system including: a first sensor configured to assist in determining an actuator load associated with a ram, the ram being connected to a lifting member; and a calibration module configured to retrieve a calibration factor based on movement of the ram, the calibration factor being applied to the actuator load to thereby provide an adjusted actuator load; wherein the payload weight is calculated based on the adjusted actuator load.

IPC Classes  ?

• E02F 9/26 - Indicating devices
• G01G 19/00 - Weighing apparatus or methods adapted for special purposes not provided for in groups

Abstract

A system of calculating a payload weight, the system including: a first sensor configured to measure a first load associated with a first member of a lifting machine; a second sensor configured to measure a second load associated with a second member of the lifting machine; and a calculating device configured to calculate the payload weight being carried by the lifting machine based on the first load and the second load.

IPC Classes  ?

• G01G 19/00 - Weighing apparatus or methods adapted for special purposes not provided for in groups
• E02F 9/26 - Indicating devices

Abstract

A system of calculating a payload weight, the system including: a first sensor configured to assist in determining an actuator load associated with a ram, the ram being connected to a lifting member; and a calibration module configured to retrieve a calibration factor based on movement of the ram, the calibration factor being applied to the actuator load to thereby provide an adjusted actuator load; wherein the payload weight is calculated based on the adjusted actuator load.

IPC Classes  ?

• G01G 19/00 - Weighing apparatus or methods adapted for special purposes not provided for in groups
• E02F 9/26 - Indicating devices

Abstract

A system of estimating fatigue in a lifting member, the system including: a first sensor configured to measure a first load related to a ram, the ram being connected to the lifting member; and a calculating device configured to: determine an actuator load based on the first load; determine a first force based on the actuator load; estimate a unit of fatigue life based on the first force; and estimate a fraction of total fatigue life consumed for a portion of the lifting member based on the unit of fatigue life and a fatigue life adjustment value.

IPC Classes  ?

• E02F 9/26 - Indicating devices

Abstract

A system of identifying a payload destination, the system including: one or more sensors; and an identifying module configured to: receive a plurality of inputs from the one or more sensors, the plurality of inputs being associated with payload delivery from a lifting machine; define a plurality of input destination identifiers based on the plurality of inputs; compare the plurality of input destination identifiers with stored identifiers in order to establish one or more destination match estimates; and identify the payload destination based on the one or more destination match estimates.

IPC Classes  ?

• G01G 19/08 - Weighing apparatus or methods adapted for special purposes not provided for in groups for incorporation in vehicles
• G08G 1/01 - Detecting movement of traffic to be counted or controlled
• E02F 9/26 - Indicating devices

Abstract

An excavator wear assembly comprising a mounting nose having a rear bearing face, a forward bearing face, an upper bearing face disposed at an angle between the rear bearing face and the forward bearing face, a front face substantially perpendicular to the forward bearing face and a rib extending over at least part of the upper bearing face, forward bearing face and front face; and a wear member having a rearwardly opening socket adapted to receive the mounting nose, the socket being at least partially defined by a top wall and a front wall, the wear member having a recess formed in the top wall and front wall adapted to receive at least part of the rib.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A heavy duty excavator bucket is constructed with an exoskeletal structure comprising coupled cast components including a lip member, opposed wing members, junction members locatable between floor and side walls and side and rear walls and a cap rail structure extending between opposed wing members about the upper periphery of the bucket to form an integral structure. Steel plate floor, side wall and rear wall members extend between adjacent exoskeletal regions. The bucket may include a cast arch member extending between opposed wing members and a cast reinforcing member extending between opposed junction members adjacent said rear wall.

IPC Classes  ?

• E02F 3/40 - DippersBuckets
• E02F 3/60 - Buckets, scrapers, or other digging elements

Abstract

A lock assembly, and wear assemblies including wear parts incorporating the lock assembly, having a locking pin with a dowel extending outwardly that is received in a slot of a retaining member. The slot of the retaining member has a narrowed section which is narrowed to a width that is less than the cross sectional dimension of the part of the dowel that is received in the narrowed section. In use, the locking pin is rotated and the dowel traverses the slot of the retaining member including passing through, or at least being received by, the narrowed section of the slot. The slot may optionally have a seat that receives the dowel after passing through the narrowed section.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

An excavator wear assembly comprising a mounting nose having a rear bearing face, a forward bearing face, an upper bearing face disposed at an angle between the rear bearing face and the forward bearing face, a front face substantially perpendicular to the forward bearing face and a rib extending over at least part of the upper bearing face, forward bearing face and front face; and a wear member having a rearwardly opening socket adapted to receive the mounting nose, the socket being at least partially defined by a top wall and a front wall, the wear member having a recess formed in the top wall and front wall adapted to receive at least part of the rib.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

An excavator wear assembly comprising a mounting nose having a rear bearing face, a forward bearing face, an upper bearing face disposed at an angle between the rear bearing face and the forward bearing face, a front face substantially perpendicular to the forward bearing face and a rib extending over at least part of the upper bearing face, forward bearing face and front face; and a wear member having a rearwardly opening socket adapted to receive the mounting nose, the socket being at least partially defined by a top wall and a front wall, the wear member having a recess formed in the top wall and front wall adapted to receive at least part of the rib.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A lock assembly to lock two members together, typically an excavator wear member, such as a tooth, on to an adaptor. The lock assembly has a locking pin with a flange portion and a retaining assembly that receives the locking pin. The retaining assembly includes a locking member, in the form of a locking ring, which deforms radially when a tapered portion of the locking pin is inserted into the retaining assembly. In the locked position, the locking ring engages with the flange portion of the locking pin to prevent withdrawal of the locking pin from the retaining assembly.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Goods & Services

Excavation equipment; excavator buckets; buckets for draglines; components for dragline buckets; lips for excavating buckets; plate ground engaging teeth for excavator buckets; loader buckets for excavators; buckets for earthmoving machines; attachments for excavators and earthmoving equipment; loader buckets for draglines; teeth, jaws and wear components for use in earth moving, mining, mineral processing and crushing industries.

Abstract

A lock assembly to lock two members together, typically an excavator wear member, such as a tooth, on to an adaptor. The lock assembly has a locking pin with a flange portion and a retaining assembly that receives the locking pin. The retaining assembly includes a locking member, in the form of a locking ring, which deforms radially when a tapered portion of the locking pin is inserted into the retaining assembly. In the locked position, the locking ring engages with the flange portion of the locking pin to prevent withdrawal of the locking pin from the retaining assembly.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A lock assembly to lock two members together, typically an excavator wear member, such as a tooth, on to an adaptor. The lock assembly has a locking pin with a flange portion and a retaining assembly that receives the locking pin. The retaining assembly includes a locking member, in the form of a locking ring, which deforms radially when a tapered portion of the locking pin is inserted into the retaining assembly. In the locked position, the locking ring engages with the flange portion of the locking pin to prevent withdrawal of the locking pin from the retaining assembly.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Goods & Services

(1) Excavators; excavator parts, namely excavator buckets, buckets for dragline, parts for dragline buckets, lips for excavating buckets, plate ground engaging teeth for excavator buckets, loader buckets for excavators; attachments, namely, buckets, grapple buckets, blades, ground engaging tools for excavators and earthmoving equipment, loader buckets for draglines, and teeth, jaws and wear parts for use in earth moving, mining, mineral processing and crushing industries.

Goods & Services

[ Excavation machines; excavation machine parts, namely, excavator buckets, buckets for draglines, component parts for dragline buckets, ] lips for excavating buckets, plate ground engaging teeth for excavator buckets, [ loader buckets for excavators, buckets for earthmoving machines, attachments, namely, grapple buckets, blades, ] ground engaging tools for excavators and earthmoving equipment, [ loader buckets for draglines, and teeth, jaws and ] wear component parts for use in earth moving, mining, mineral processing and crushing industries

Abstract

A lock assembly for an excavator wear assembly, the lock assembly comprising an engagement member having a tensioning aperture passing through a body thereof and an inclined bearing face, and a tensioning member having a threaded portion at a first end which is received in the tensioning aperture, wherein the engagement member further comprises a slot extending through a side wall thereof and opening into the tensioning aperture.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A lock assembly for an excavator wear assembly is provided, the lock assembly having a locking pin and a retaining member that engage with each other to retain an excavator wear member, such as a tooth, to an adaptor. The retaining member has a tapered aperture that receives and retains a threaded portion of the locking pin therein.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A lock assembly, and wear assemblies including wear parts incorporating the lock assembly, having a locking pin with a dowel extending outwardly that is received in a slot of a retaining member. The slot of the retaining member has a narrowed section which is narrowed to a width that is less than the cross sectional dimension of the part of the dowel that is received in the narrowed section. In use, the locking pin is rotated and the dowel traverses the slot of the retaining member including passing through, or at least being received by, the narrowed section of the slot. The slot may optionally have a seat that receives the dowel after passing through the narrowed section.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Goods & Services

Earth moving machines and parts therefor; conveyors and parts therefor; components for draglines, scrapers, crushing machines; buckets for draglines; blades for graders; teeth, jaws and wear components for use in earth moving, mining, sugar processing, mineral processing and crushing industries; conveyors; conveyor belts and replacement parts therefor, especially for use in the mining, processing, sugar and earth moving industries; replacement parts for excavators, blade plowers, dozers, graders, scrapers and loaders; replacement parts used in the mining and earth moving industries; pumps and parts therefore; concrete pumps; concrete pump pistons; paper mill rolls; tungsten carbide components for mining and crushing machines; cast crushing components for crushing machines; machine parts, namely cyclones, impact pads, cable covers, cable pullers, ripper pads, pulleys, idler rollers and general rollers; grinding and crushing equipment; pump impellers and liners; flotation cell equipment; scraper blades; components of earth moving machines including chute and bucket linings, chocky bars, wear buttons and donuts, wear plates, star plates, skid bars, weld overlay wear resistant plates; hammer tips for shredders and grinders; printing rolls; rollers for machines and conveyor belts; agitators; bushes being parts of motors and machines; bushes for rigging on excavation equipment; underground coal mining stone dusting equipment; machine components, namely, screening mats and modular screening systems, including screening components for use in the minerals processing, coal mining and quarrying industries; machines components, namely, polyurethane components and polyurethane coated components for the minerals processing and mining extraction industries, polyurethane parts for wear applications; conveyor skirting, rubber lining material; conveyor pulley lagging in ceramic, rubber, and polyurethane; casting ladles. Machinery installation, maintenance and repair; vehicle maintenance and repair; installation, maintenance and repair of conveyor systems especially for use in mining, earth moving, sugar and crushing industries; maintenance and repair of excavators, blade plowers, dozers, graders, scrapers, loaders and crushers; consultancy services to the earthmoving industry in relation to machinery installation, maintenance and repair; repair of earthmoving, earth conditioning, material handling, construction, mining, agricultural, crushing and sugar industry machineries, engines and parts therefor. Foundry services, including casting and moulding in all materials, including polyurethane, to produce goods suitable for the mining and earth moving industries. Engineering consultancy services; mining engineering consultancy services; mechanical engineering consultancy services; testing and inspection of engines and machinery; testing, control, and diagnosis of earth moving, earth conditioning, material handling, construction, mining, agricultural, crushing and sugar industry machinery, engines and parts therefor.

Abstract

A wear assembly for an excavator bucket comprises a cast lip, a lower wing shroud and a retaining member. The cast lip includes two upstanding wing plates. Each wing plate has a wing face on a side of the wing plate and a plate retaining formation formed on the wing face. The plate retaining formation has a plate retaining face. The wing shroud is mounted to the wing plate. The wing shroud includes a shroud retaining formation having a shroud retaining face. The retaining member includes a first bearing formation having a first face opposing and engaging the shroud retaining face, and a second bearing formation having a second face opposing and engaging the plate retaining face. The retaining member has a longitudinal axis extending between the first bearing formation and the second bearing formation. The longitudinal axis is located in a plane substantially parallel to the wing face.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A wear assembly having an adaptor with a spigot portion is disclosed. The spigot portion has a transverse dimension. The wear assembly also has a wear member releasably mountable on the adaptor. The wear member has a body with a socket cavity and the socket cavity is adapted to receive the spigot portion of the adaptor. The wear member also has a pair of mounting ears extending from the body. Each of the mounting ears has a transverse dimension. The transverse dimension of each mounting ear is in the range 0.25 to 0.4 of the transverse dimension of the spigot portion.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A lock assembly for an excavator wear assembly, the lock assembly a locking pin having at least one dowel extending outwardly therefrom. The lock assembly also includes a retaining member having a seat and a cavity and a biasing member located within the cavity of the retaining member. The biasing member is adapted to exert a biasing force on the dowel to releasably retain the dowel within the seat of the retaining member.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth
• E02F 3/32 - DredgersSoil-shifting machines mechanically-driven with digging tools mounted on a dipper- or bucket-arm, e.g. dippers, buckets with a dipper-arm pivoted on a cantilever beam working downwardly and towards the machine, e.g. with backhoes

Abstract

A lock for an excavator wear assembly, the lock comprising: a first member having a retaining member, the retaining member having at least one first bearing face; a second member having a retaining recess, the retaining recess having at least one second bearing facing; the retaining recess adapted to releasably receivable the retaining member of the first member so that the first bearing face bears against the second bearing face; wherein the at least one first bearing face and the at least one second bearing face are inclined with respect to a longitudinal axis that extends through the first member and the second member when the retaining member of the first member is received within the retaining recess of the second member.

IPC Classes  ?

• E02F 3/36 - Component parts
• E21C 35/193 - Means for fixing picks or holders using bolts as main fixing elements

Goods & Services

(1) Earth moving machines and parts therefor; conveyors and parts therefor; components for earth moving machines, being draglines, scrapers, crushing machines; buckets for draglines; blades for graders; teeth, jaws and wear components for use in earth moving, mining, sugar processing, mineral processing and crushing industries, namely adaptors, teeth, jaws, shrouds and wing shrouds; conveyors; conveyor belts and replacement parts therefor, especially for use in the mining, processing, sugar and earth moving industries; replacement parts for earth moving machines, being excavators, blade plowers, dozers, graders, scrapers and loaders; concrete pumps; concrete pump pistons; concrete stamps; paper mill rolls; tungsten carbide components for mining and crushing machines; cast crushing components for crushing machines; machine parts, namely cyclones, impact pads, cable covers, cable pullers, ripper pads, pulleys, idler rollers and general rollers; pump impellers and liners; flotation cell equipment; components of earth moving machines namely chute and bucket linings, chocky bars, wear buttons, and donuts,wear plates, star plates, skid bars, weld overlay wear resistant plates; hammer tips for shredders and grinders; printing rolls; rollers for machines and conveyor belts; agitators; bushes being parts of motors and machines; bushes for rigging on excavation equipment; underground coal mining stone dusting equipment; screening mats and modular screening systems, namely screening components for use in the minerals processing, coal mining and quarrying industries; polyurethane components and polyurethane coated components for the minerals processing and mining extraction industries, namely screens, screening systems, lagging, protective liners, pump liners, chute and bucket liners, rotors, stators, dart valves, couplings, rope protectors; components for conveyors, namely conveyor skirting; conveyor pulley lagging in ceramic, rubber, and polyurethane; casting ladles; hydraulic seals; rubber liners and sleeves for protecting valves of machines; rubber and ceramic wear liners. (1) Machinery installation, maintenance and repair; vehicle maintenance and repair; installation maintenance and repair of conveyor systems especially for use in mining, earth moving, sugar and crushing industries; maintenance and repair of excavators, blade plowers, dozers, graders, scrapers, loaders and crushers; consultancy services to the earthmoving industry in relation to machinery installation, maintenance and repair; repair of earthmoving, earth conditioning, material handling, construction, mining, agricultural, crushing and sugar industry machineries, engines and parts therefor; foundry services, including casting and moulding in all materials, including polyurethane, to produce goods suitable for the mining and earth moving industries; technical consulting in the field of mining engineering; mining engineering consultancy services; mechanical engineering consultancy services; civil engineering consultancy services; testing and inspection of engines and machinery; testing, control, and diagnosis of earth moving, earth conditioning, material handling, construction, mining, agricultural, crushing and sugar industry machinery, engines and parts therefor.

Abstract

An excavation retention assembly is provided for mounting a tooth to an excavating apparatus. The assembly in one embodiment includes a tooth and an adaptor end of a working member of an excavating apparatus. The tooth includes a cavity for mating with an end of the adaptor, an opening for receiving a fastening member and a fastening receptacle in the cavity opposite the opening in the tooth for receiving the fastening member. The adaptor includes a passage which aligns with the opening in the tooth and the fastening member. The fastening member passes through the aligned opening of the tooth, the passage of the adaptor and into the fastening receptacle for securing the tooth to the adaptor.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth
• E02F 3/40 - DippersBuckets
• E02F 3/60 - Buckets, scrapers, or other digging elements
• E02F 3/65 - Component parts, e.g. drives, control devices

Goods & Services

Earth moving machines and parts therefor; conveyors and parts therefor; components for draglines, scrapers, crushing machines; buckets for draglines; blades for graders; teeth, jaws and wear components for use in earth moving, mining, sugar processing, mineral processing and crushing industries; conveyors; conveyor belts and replacement parts therefor, especially for use in the mining, processing, sugar and earth moving industries; replacement parts for excavators, blade plowers, dozers, graders, scrapers and loaders; replacement parts used in the mining and earth moving industries; pumps and parts therefor; concrete pumps; concrete pump pistons; concrete stamps; paper mill rolls; tungsten carbide components for mining and crushing machines; cast crushing components for crushing machines; machine parts, namely cyclones, impact pads, cable covers, cable pullers, ripper pads, pulleys, idler rollers and general rollers; grinding and crushing equipment; pump impellers and liners; flotation cell equipment; scraper blades; chute and bucket linings being components of earth moving machines; chocky bars being components of earth moving machines; wear buttons and donuts being components of earth moving machines; wear plates being components of earth moving machines; star plates being components of earth moving machines; skid bars being components of earth moving machines; hammer tips for shredders and grinders; printing rolls; rollers for machines and conveyor belts; agitators; bushes being parts of motors and machines; bushes for rigging on excavation equipment; underground coal mining stone dusting equipment; weld overlay wear resistant plates being components of earth moving machines; screening mats and modular screening systems, including screening components for use in the minerals processing, coal mining and quarrying industries; polyurethane components and polyurethane coated components for the minerals processing and mining extraction industries, polyurethane parts for wear applications; conveyor skirting, rubber lining material; conveyor pulley lagging in ceramic, rubber, and polyurethane; casting ladles. Hydraulic seals; rubber liners/sleeves for protecting valves of machines; rubber/ceramic wear liners; rubber adhesives. Machinery installation, maintenance and repair; vehicle maintenance and repair; installation maintenance and repair of conveyor systems especially for use in mining, earth moving, sugar and crushing industries; maintenance and repair of excavators, blade plowers, dozers, graders, scrapers, loaders and crushers; repair of earthmoving, earth conditioning, material handling, construction, mining, agricultural, crushing and sugar industry machineries, engines and parts therefor. Foundry services, including casting and moulding in all materials, including polyurethane, to produce goods suitable for the mining and earth moving industries. Engineering consultancy services; mining engineering consultancy services; mechanical engineering consultancy services; testing and inspection of engines and machinery; testing, control and diagnosis of earth moving, earth conditioning, material handling, construction, mining, agricultural, crushing and sugar industry machinery, engines and parts therefor; civil engineering consultancy services.

Abstract

A lock for an excavator wear assembly. The lock has a first member a key way located on an internal face of the first member. The lock also has a second member having a key located on an internal face of the second member such that the key is receivable within the keyway of the first member. Furthermore, the lock has a fastening member receivable within the first member and the second member to thereby releasably secure the first member to the second member.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth
• F16B 19/02 - Bolts or sleeves for positioning of machine parts, e.g. notched taper pins, fitting pins, sleeves, eccentric positioning rings
• F16B 37/00 - Nuts or like thread-engaging members

Abstract

An excavator bucket comprising a generally rectangular floor. The excavator bucket also has a side wall extending from each of opposed sides of the generally rectangular floor. The excavator bucket also has a rear wall extending from a rear end of the generally rectangular floor. One or more apertures extend through each of the side walls.

IPC Classes  ?

• E02F 3/14 - BucketsChainsGuides for buckets or chainsDrives for chains
• E02F 3/58 - Component parts
• E02F 3/60 - Buckets, scrapers, or other digging elements

Abstract

An excavator rigging socket that is adapted to releasably secure a cable to a rigging component is disclosed. The excavator rigging socket has an elongate body portion where the elongate body portion having opposed sidewalls. The excavator rigging socket also includes a cradle extending longitudinally of the elongate body portion to a rear abutment face at an end of the cradle. The cradle has at least two pairs of cable retaining apertures spaced longitudinally of the elongate body portion, each pair of cable retaining apertures has a cable retaining aperture extending through a respective opposed sidewall of elongate body portion, said cradle tapers inwardly toward the rear abutment face.

IPC Classes  ?

• E02F 3/58 - Component parts
• E02F 3/48 - Drag-lines
• F16G 11/00 - Means for fastening cables or ropes to one another or to other objectsCaps or sleeves for fixing on cables or ropes

Abstract

A wear assembly for mounting to a structure comprises a base, a wear plate and a lock formation. A longitudinal axis extends from a rear end to a front end of the base. The base includes two or more male formations having inclined bearing faces which are inclined relative to the underside of the base in a direction from the rear end to the front end. The male formations are located spaced from each other on either side of the longitudinal axis. The wear plate includes female formations having bearing faces releasably engaged with the inclined bearing faces by displacement of the wear plate in a direction inclined to the underside of the base. The lock formation comprises a rigid part and a resilient part. The rigid part opposes a wall of the base and a wall of the wear plate to lock the wear plate to the base.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth
• B65G 11/16 - Interior surfacesLinings
• E02F 3/36 - Component parts
• E02F 3/58 - Component parts
• E02F 9/00 - Component parts of dredgers or soil-shifting machines, not restricted to one of the kinds covered by groups

Abstract

A wear assembly for an excavator bucket comprises a cast lip, a lower wing shroud and a retaining member. The cast lip includes two upstanding wing plates. Each wing plate has a wing face on a side of the wing plate and a plate retaining formation formed on the wing face. The plate retaining formation has a plate retaining face. The wing shroud is mounted to the wing plate. The wing shroud includes a shroud retaining formation having a shroud retaining face. The retaining member includes a first bearing formation having a first face opposing and engaging the shroud retaining face, and a second bearing formation having a second face opposing and engaging the plate retaining face. The retaining member has a longitudinal axis extending between the first bearing formation and the second bearing formation. The longitudinal axis is located in a plane substantially parallel to the wing face.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A lock assembly for an excavator wear assembly, the lock assembly a locking pin having at least one dowel extending outwardly therefrom. The lock assembly also includes a retaining member having a seat and a cavity and a biasing member located within the cavity of the retaining member. The biasing member is adapted to exert a biasing force on the dowel to releasably retain the dowel within the seat of the retaining member.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A wear assembly having an adaptor with a spigot portion is disclosed. The spigot portion has a transverse dimension. The wear assembly also has a wear member releasably mountable on the adaptor. The wear member has a body with a socket cavity and the socket cavity is adapted to receive the spigot portion of the adaptor. The wear member also has a pair of mounting ears extending from the body. Each of the mounting ears has a transverse dimension. The transverse dimension of each mounting ear is in the range 0.25 to 0.4 of the transverse dimension of the spigot portion.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A lock assembly for an excavator wear assembly, the lock assembly a locking pin having at least one dowel extending outwardly therefrom. The lock assembly also includes a retaining member having a seat and a cavity and a biasing member located within the cavity of the retaining member. The biasing member is adapted to exert a biasing force on the dowel to releasably retain the dowel within the seat of the retaining member.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

An excavator wear member includes a body, a side wall having a mounting ear extending rearwardly of the body, a socket cavity extending into the body, a locking aperture extending through the side wall of the excavator wear member, the locking aperture having a receiving passage and a retaining recess, the retaining recess being larger in cross sectional area relative to the receiving passage; wherein, the receiving passage extends inwardly from an outer face of the side wall and the retaining recess is located on an inner face of the side wall such that the receiving passage terminates at the retaining recess, and wherein a planar locking face is located at an end of the retaining recess proximal the receiving passage, and wherein at least part of the locking aperture extends through the mounting ear.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A wear member assembly for a lip of an earth excavating device comprises a first wear member, a second wear member and a retaining pin. The first wear member is mounted to the lip. The first wear member includes a boss extending outwardly from one of its opposite sides. The second wear member is mounted adjacent the first wear member. The second wear member includes a socket in one of its sides. The socket is adapted to receive the boss of the first wear member. The second wear member includes a retaining pin passage in communication with the socket. The retaining pin is removably located in the retaining pin passage. The retaining pin has a first bearing face adapted to oppose and engage a face of the boss received in the socket and a second bearing face which bears against a load bearing face of the retaining pin passage.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

An excavator tooth assembly comprises a first wear member and a second wear member. The second wear member is releasably mountable on the first wear member. The first wear member has a lock face. The second wear member also has a lock face. The lock face of the first wear member opposes the lock face of the second wear to define a lock passage therebetween when the second wear member is mounted on the first wear member. The excavator tooth assembly includes a lock pin which is adapted to be received in the lock passage to releasably secure the second wear member to the first wear member.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A wear assembly having an adaptor with a spigot portion is disclosed. The spigot portion has a transverse dimension. The wear assembly also has a wear member releasably mountable on the adaptor. The wear member has a body with a socket cavity and the socket cavity is adapted to receive the spigot portion of the adaptor. The wear member also has a pair of mounting ears extending from the body. Each of the mounting ears has a transverse dimension. The transverse dimension of each mounting ear is in the range 0.25 to 0.4 of the transverse dimension of the spigot portion.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A rigging assembly for a dragline excavator where the rigging assembly has a first upper hoist link and a second upper hoist link. The rigging assembly also has an equalization member extending between the first upper hoist link and the second upper hoist link. The equalization member is formed from a flexible material.

IPC Classes  ?

• B66C 1/12 - Slings comprising chains, wires, ropes, or bandsNets
• E02F 3/48 - Drag-lines

Abstract

A rigging assembly for a dragline excavator where the rigging assembly has a first upper hoist link and a second upper hoist link. The rigging assembly also has an equalization member extending between the first upper hoist link and the second upper hoist link. The equalization member is formed from a flexible material.

IPC Classes  ?

• E02F 3/48 - Drag-lines
• B66C 1/12 - Slings comprising chains, wires, ropes, or bandsNets

Goods & Services

(1) Earth moving machines and parts therefor; conveyors and parts therefor; components for earth moving machines, namely draglines, scrapers, crushing machines; buckets for draglines; blades for graders; teeth, jaws and wear components for use in earth moving, mining, sugar processing, mineral processing and crushing industries, namely adapters, teeth, jaws, shrouds and wing shrouds; conveyors; conveyor belts and replacement parts therefor, especially for use in the mining, processing, sugar and earth moving industries; replacement parts for earth moving machines, namely excavators, blade plowers, dozers, graders, scrapers and loaders; concrete pumps; concrete pump pistons; concrete stamps; paper mill rolls; tungsten carbide components for mining and crushing machines; cast crushing components for crushing machines; machine parts, namely cyclones, impact pads, cable covers, cable pullers, ripper pads, pulleys, idler rollers and general rollers; pump impellers and liners; flotation cell equipment; chute and bucket linings; chocky bars; components of earth moving machines namely wear buttons and donuts; wear plates; star plates; skid bars; hammer tips for shredders and grinders; trammel wheels; printing rolls; lined pipes in ferrous and non-ferrous; rollers for machines and conveyor belts; agitators; parts of motors and machines namely bushes; bushes for rigging on excavation equipment; pipeline pigs and valve seat rings; underground coal mining stone dusting equipment; weld overlay wear resistant plate; screening mats and modular screening systems, namely screening components for use in the minerals processing, coal mining and quarrying industries; polyurethane components and polyurethane coated components for the minerals processing and mining extraction industries, namely screens, screening systems, lagging, perfective liners, pump liners, chute and bucket liners, rotors, stators, dart valves, couplings, rope protectors; rubber and ceramic wear liners; rubber adhesives, conveyor skirting; conveyor pulley lagging in ceramic, rubber, and polyurethane; cast ladles; hydraulic seals; liners for protecting valves of machines. (1) Machinery installation, maintenance and repair; vehicle maintenance and repair; installation, maintenance and repair of conveyor systems especially for use in mining, earth moving, sugar and crushing industries; maintenance and repair of excavators, blade plowers, dozers, graders, scrapers, loaders and crushers; consultancy services to the earthmoving industry in relation to machinery installation, maintenance and repair; repair of earthmoving, earth conditioning, material handling, construction, mining, agricultural, crushing and sugar industry machineries, engines and parts therefor; civil engineering consultancy services; foundry services, namely casting and moulding in all materials, including polyurethane, to produce goods suitable for the mining and earth moving industries; technical consulting in the field of mining engineering; mining engineering consultancy services; civil and mechanical engineering consultancy services; consultancy services to the earth moving industry in relation to machinery installation, maintenance and repair; testing and inspection of engines and machinery; testing control, diagnosis and repair of earth moving, earth conditioning, material handling, construction, mining, agricultural, crushing and sugar industry machinery, engines and parts therefor.

Goods & Services

(1) Excavation buckets; components for excavation buckets and dragline buckets in particular including bucket lips; fixing pins, ground engaging teeth; mounting assemblies all for use on excavation buckets; excavators; buckets for draglines; mounting assemblies for ground engaging teeth.

Goods & Services

(1) Excavator buckets; buckets for draglines; components for dragline buckets; lips for excavator buckets; plate ground engaging teeth for excavator buckets; loader buckets for excavators; buckets for earthmoving machines; loader buckets for draglines; wear parts for attachment to excavator bucket lips namely adaptors, teeth, shrouds and wing shrouds; components for fastening wear parts to excavator bucket lips; teeth, jaws and wear components for use in earth moving, mining, mineral processing and crushing industries.

Abstract

A grader blade assembly comprising a grader blade having a grader body and at least one projection extending outwardly from the grader body to form at least one pick aperture; at least one pick located in the at least one pick aperture; and at least one lock attached to the grade blade body; wherein the lock abuts the at least one pick to prevent removal of the at least one pick from the at least one pick aperture.

IPC Classes  ?

• E02F 3/815 - BladesLevelling tools
• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A mounting pin assembly having a retaining member which includes a locating surface and a boss extending from the locating surface. The mounting pin assembly also has a locating member slidably mountable upon the locating surface of the retaining member. The locating member also has an enlarged portion defined by an outwardly divergent face. The mounting pin assembly also has a tensioning member extending between and coupling the boss of said retaining member and the locating member. The tensioning member is configured to cause relative contraction of the mounting pin assembly such that the locating member is drawn upon the locating surface of the retaining member towards the boss when a tensile force is applied to the tensioning member.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A retaining pin assembly for an excavator tooth assembly. The retaining pin assembly has opposable locating members each having a shank portion able to be slidably insertable via a respective retaining pin aperture on opposite sides of a wear member into a transversely extending mounting aperture of a mounting nose of an excavator. Each locating member also has an enlarged inwardly convergent tapered wedge portion adjacent a normally outer end. The retaining pin assembly also has a tensionable retaining member extending between the locating members from one side of the retaining pin assembly. When tension is applied to the retaining member relative contraction of the locating members occurs to urge the wear member into engagement with the mounting nose by wedging engagement between each of the wedge portions and a rear wall of respective retaining pin apertures.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A lock for an excavator wear assembly. The lock has a first member a key way located on an internal face of the first member. The lock also has a second member having a key located on an internal face of the second member such that the key is receivable within the keyway of the first member. Furthermore, the lock has a fastening member receivable within the first member and the second member to thereby releasably secure the first member to the second member.

IPC Classes  ?

• E02F 9/28 - Small metalwork for digging elements, e.g. teeth

Abstract

A wear resistant screen plate comprising a carrier plate having a plurality of apertures and a wear resistant layer formed on the carrier plate such that the plurality of apertures remain substantially unobscured. The wear resistant layer comprises a plurality of wear plates arranged such that a plurality of portions of the carrier plate remain exposed.

IPC Classes  ?

• B07B 1/46 - Constructional details of screens in generalCleaning or heating of screens

Abstract

A heavy duty excavator bucket is constructed with an exoskeletal structure comprising coupled cast components including a lip member, opposed wing members, junction members locatable between floor and side walls and side and rear walls and a cap rail structure extending between opposed wing members about the upper periphery of the bucket to form an integral structure. Steel plate floor, side wall and rear wall members extend between adjacent exoskeletal regions. The bucket may include a cast arch member extending between opposed wing members and a cast reinforcing member extending between opposed junction members adjacent said rear wall.

IPC Classes  ?

• E02F 3/40 - DippersBuckets

Abstract

A locking pin system (10) comprises a pin in the form of a shaft (12), and retaining assemblies (14) at opposite ends of the shaft (12). The ends of the shaft (12) are captively held in locating apertures of a lug (21) of a shackle (20). The lug (21) has aligned opposite recesses (26) in which the retaining assemblies (14) are fixed. The retaining assemblies (14) each include a barrier locatable adjacent the respective locating aperture of the lug (21) to close off the locating aperture, thereby preventing the shaft (12) from being ejected through the locating aperture. The barrier includes a lock formation operable to engage a locating formation associated with the shackle (20) to releasably lock the barrier in position.

IPC Classes  ?

• F16G 15/06 - Shackles designed for attachment by joint pins to chain elements, e.g. D-shackles
• F16B 21/07 - Releasable fastening devices with snap action in which the socket has a resilient part
• F16G 15/04 - Quickly-detachable chain couplingsShackles
• F16B 21/06 - Releasable fastening devices with snap action
• F16B 41/00 - Measures against loss of bolts, nuts, or pinsMeasures against unauthorised operation of bolts, nuts, or pins

Abstract

A rigging device (40) is used in upper hoist dragline rigging. The rigging device (40) comprises: a hitch (52); two spaced hoist sockets (42); an equalization bar (44) extending between the hoist sockets (42); and a ball-and-socket joint (46) connecting the hitch (52) to the equalization bar (44). The ball of the ball-and-socket joint (46) is integrally formed with the equalization bar (44). The socket (50) of the ball-and-socket joint (46) is integrally formed with the hitch (52). The ball-and-socket joint (46) provides for articulation between the hitch (52) and the equalization bar (44).

IPC Classes  ?

• E02F 3/48 - Drag-lines
• E02F 9/00 - Component parts of dredgers or soil-shifting machines, not restricted to one of the kinds covered by groups
• E02F 3/58 - Component parts
• F16C 11/06 - Ball-jointsOther joints having more than one degree of angular freedom, i.e. universal joints
