The present invention relates to a clutch (100) comprising: a fixed hub (101, 1101) comprising a central coupling hole (301) configured for coupling with a rotating shaft (1200); a movable hub (102, 1102) configured for being mounted along an axial direction onto the fixed hub (101, 1101); a plurality of discs (103) interposed between the fixed hub (101, 1101) and the movable hub (102, 1102). The fixed hub (101, 101) and the movable hub (102, 1102) are shaped so as to rotate jointly with each other and so as to axially slide with each other, getting farther or closer to each other so that the fixed hub (101, 1101) and the movable hub (102, 1102) exert a variable axial load onto the plurality of discs (103), thereby transmitting a torque. The movable hub (102, 1102) comprises a central access hole (302) that is configured for allowing access to said central coupling hole (301) passing internally through the plurality of discs (103) interposed, so as to operate locking means (1201) for the coupling with the rotating shaft (1200). The present invention also relates to a method for mounting a clutch.
F16D 13/56 - Clutches with multiple lamellae with means for increasing the effective force between the actuating sleeve or equivalent member and the pressure member in which the clutching pressure is produced by springs only
F16D 25/0638 - Fluid-actuated clutches in which the fluid actuates a piston incorporated in the clutch the clutch having friction surfaces with clutch members exclusively moving axially with flat friction surfaces, e.g. discs with more than two discs, e.g. multiple lamellae
The present invention relates to a clutch (100) comprising: a rotatable housing (101); a fixed hub (201) internal to the housing (101) and a movable hub (202) axially mounted onto the fixed hub (201); a plurality of discs (204) interposed between the fixed hub (201) and the movable hub (202). The fixed hub (201) and the movable hub (202) axially slide, getting farther or closer so as to transmit a variable axial load onto the discs (204), to selectively transmit a torque. The clutch (100) further comprises a pressure plate assembly (208) for controlling the variable axial load, including a centrifugal assembly (210) comprising: a rotatable mass holder (211) and a plurality of mass elements (212) radially disposed. Each mass element (212) comprises a pivot (301) and is configured for a displacement (1002) by pivoting under centrifugal effects. The mass elements (212) are thus configured for exerting an axial thrust within the pressure plate assembly (208), to bring the movable hub (202) closer to the fixed hub (201), so as to increase the variable axial load and allowing the clutch (100) (automatic) engagement. Each mass element (212) comprises a main body (302) and a column element (303) which connects the pivot (301) with the main body (302).
F16D 13/68 - Attachments of plates or lamellae to their supports
F16D 43/12 - Internally controlled automatic clutches actuated entirely mechanically controlled by angular speed with centrifugal masses actuating axially a movable pressure ring or the like the pressure ring actuating friction plates, cones, or similar axially-movable friction surfaces the centrifugal masses acting on, or forming a part of, an actuating mechanism by which the pressure ring can also be actuated independently of the masses
F16D 43/22 - Internally controlled automatic clutches actuated entirely mechanically controlled by both speed and torque
F16D 13/75 - Features relating to adjustment, e.g. slack adjusters
F16D 13/70 - Pressure members, e.g. pressure plates, for clutch-plates or lamellaeGuiding arrangements for pressure members
F16D 13/54 - Clutches with multiple lamellae with means for increasing the effective force between the actuating sleeve or equivalent member and the pressure member
F16D 43/21 - Internally controlled automatic clutches actuated entirely mechanically controlled by torque, e.g. overload-release clutches, slip-clutches with means by which torque varies the clutching pressure with friction members
3.
CLUTCH, IN PARTICULAR CLUTCH FOR MOTORCYCLES, AND RELATED MOUNTING METHOD
The present invention relates to a clutch (100) comprising: a fixed hub (101, 1101) comprising a central coupling hole (301) configured for coupling with a rotating shaft (1200); a movable hub (102, 1102) configured for being mounted along an axial direction onto the fixed hub (101, 1101); a plurality of discs (103) interposed between the fixed hub (101, 1101) and the movable hub (102, 1102). The fixed hub (101, 101) and the movable hub (102, 1102) are shaped so as to rotate jointly with each other and so as to axially slide with each other, getting farther or closer to each other so that the fixed hub (101, 1101) and the movable hub (102, 1102) exert a variable axial load onto the plurality of discs (103), thereby transmitting a torque. The movable hub(102, 1102) comprisesa central access hole (302) that is configured forallowing access to said central coupling hole(301) passing internally through the plurality of discs (103) interposed, so as to operate locking means (1201) for the coupling with the rotating shaft (1200). The present invention also relates to a method for mounting a clutch.
F16D 13/04 - Friction clutches with means for actuating or keeping engaged by a force derived at least partially from one of the shafts to be connected
F16D 13/56 - Clutches with multiple lamellae with means for increasing the effective force between the actuating sleeve or equivalent member and the pressure member in which the clutching pressure is produced by springs only
A clutch adapted to transmit the motion from a driving shaft to a driven shaft, having an axis of rotation coaxial to the driven shaft and comprising, a ring gear, a first bell integral in rotation with the ring gear and coaxial to the axis of rotation, an axially fixed hub internal to the first bell and coaxial to the axis of rotation, an axially movable pressure assembly including a disk-pusher element, a disk pack, a plurality of elastic elements, and a centrifugal assembly. The clutch comprises at least one first clearance-recovery device of a unidirectional type, adapted to limit the separation of the disk-pusher element from the axially fixed hub and from the disk pack, and a second clearance-recovery device of a unidirectional type, adapted to enable an axial movement of the centrifugal assembly only towards the disk-pusher element.
F16D 13/75 - Features relating to adjustment, e.g. slack adjusters
F16D 43/12 - Internally controlled automatic clutches actuated entirely mechanically controlled by angular speed with centrifugal masses actuating axially a movable pressure ring or the like the pressure ring actuating friction plates, cones, or similar axially-movable friction surfaces the centrifugal masses acting on, or forming a part of, an actuating mechanism by which the pressure ring can also be actuated independently of the masses
