Preventing slurry, dirt, and grime from being ejected from a safety cage of a power trowel, and infiltrating the motors, gears, electrical and electronic components of the power trowel is achieved by temporarily installing an isolation assembly comprising one or more plates and associated locking mechanisms.
Multiple floor treatment operations, such as burnishing, polishing, and scrubbing, may be performed using a single floor treatment machine having a motor, the speed of which is governed by a controller that responses to sensor signals indicative of the type of floor treatments pad or pads operatively coupled to the motor.
A47L 11/40 - Parts or details of machines not provided for in groups , or not restricted to one of these groups, e.g. handles, arrangements of switches, skirts, buffers or levers
A47L 11/14 - Floor surfacing or polishing machines motor-driven with rotating tools
A47L 11/282 - Floor-scrubbing machines, motor-driven having rotary tools
G01R 15/20 - Adaptations providing voltage or current isolation, e.g. for high-voltage or high-current networks using galvano-magnetic devices, e.g. Hall-effect devices
G01R 19/00 - Arrangements for measuring currents or voltages or for indicating presence or sign thereof
H02K 7/14 - Structural association with mechanical loads, e.g. with hand-held machine tools or fans
3.
AUTOMATIC DETECTION SYSTEM FOR FLOOR TREATING MACHINES
Multiple floor treatment operations, such as burnishing, polishing, and scrubbing, may be performed using a single floor treatment machine having a motor, the speed of which is governed by a controller that responds to sensor signals indicative of the type of floor treatment pad or pads operatively coupled to the motor.
B24B 49/10 - Measuring or gauging equipment for controlling the feed movement of the grinding tool or workArrangements of indicating or measuring equipment, e.g. for indicating the start of the grinding operation involving electrical means
B24B 7/18 - Single-purpose machines or devices for grinding floorings, walls, ceilings or the like
G06K 7/10 - Methods or arrangements for sensing record carriers by electromagnetic radiation, e.g. optical sensingMethods or arrangements for sensing record carriers by corpuscular radiation
G06K 19/07 - Record carriers with conductive marks, printed circuits or semiconductor circuit elements, e.g. credit or identity cards with integrated circuit chips
4.
Automatic detection system for combination burnisher, polisher, and scrubber
Multiple floor treatment operations, such as burnishing, polishing and scrubbing, may be performed using a single floor treatment machine having a motor, the speed of which is governed by a controller that responds to sensor signals indicative of the type of floor treatments pad or pads operatively coupled to the motor.
A47L 11/40 - Parts or details of machines not provided for in groups , or not restricted to one of these groups, e.g. handles, arrangements of switches, skirts, buffers or levers
B24B 7/18 - Single-purpose machines or devices for grinding floorings, walls, ceilings or the like
B24B 41/047 - Grinding heads for working on plane surfaces
B24B 47/12 - Drives or gearings for grinding machines or devicesEquipment therefor for rotating or reciprocating working-spindles carrying grinding wheels or workpieces by mechanical gearing or electric power
G01B 7/00 - Measuring arrangements characterised by the use of electric or magnetic techniques
01 - Chemical and biological materials for industrial, scientific and agricultural use
02 - Paints, varnishes, lacquers
03 - Cosmetics and toiletries; cleaning, bleaching, polishing and abrasive preparations
07 - Machines and machine tools
Goods & Services
Chemical sealants for the sealing of floors Coatings in the nature of floor finish Floor polish; Floor finishing preparation, namely, floor wax Pads for floor polishing machines
An adapter plate for use with a floor finishing machine for coupling abrasive drive plates to the spider arms of the floor finishing machine which includes a plurality of stamped plate components which when joined together form a polygon on which is mounted a plurality of hub members in which shafts are journaled for rotation in a spherical bearing. The shafts are, in turn, coupled to the abrasive drive plates.
A drive plate attachable to a driven shaft of a floor-finishing machine has a central circular recess and a plurality of radially extending pockets having beveled side edges formed in a surface thereof. Located in the pocket is a rectangular stabilizing bar. The abrasive tool includes a plate sized and shaped to fit into the pockets when inserted from the central recess and having a groove formed therein for receiving the stabilizing bar. On the surface of the tool plate opposite the groove are abrasive members.
B24B 7/18 - Single-purpose machines or devices for grinding floorings, walls, ceilings or the like
B24D 7/06 - Bonded abrasive wheels, or wheels with inserted abrasive blocks, designed for acting otherwise than only by their periphery, e.g. by the front faceBushings or mountings therefor with inserted abrasive blocks, e.g. segmental
13.
Device for attaching drive plates to a powered floor polishing machine
A device for attaching abrasive drive plates to the motor driver, rotatable arms of a floor finishing machine so that it can be used to grind and polish hardened concrete has a polygonal shaped driver member to which is affixed at least one abrasive drive plate using spherical bearings on its or their drive shafts so that it is or they are free to both spin and to tilt relative to a vertical axis. A locking cap containing a radial bearing may be affixed to housings for the radial bearings for constraining the drive plate shafts solely to pure rotation about the vertical axis. A plurality of channel members is affixed to an upper surface of the polygonal shaped driver for coupling it to the arms of the floor finishing machine.
An adapter clip to be used to mate an abrasive support plate to the drive plate of a floor finishing machine used to grind and/or polish concrete and stone flooring is designed with an internal aperture shaped to conform to and clip onto a protuberance on an upper surface of an abrasive support plate and an external shape to mate with a mounting recess formed on the machine's drive plate.
B24D 7/06 - Bonded abrasive wheels, or wheels with inserted abrasive blocks, designed for acting otherwise than only by their periphery, e.g. by the front faceBushings or mountings therefor with inserted abrasive blocks, e.g. segmental
B24B 7/18 - Single-purpose machines or devices for grinding floorings, walls, ceilings or the like
17.
Quick attachment abrasive assembly for power concrete treating machines
For use with a power trowel, an abrasive assembly attachable to a rotatable arm of the power trowel that comprises a circular, rigid plate having a central hub projecting out from a first major surface and affixed to its second major surface is a ring of a resilient material. Adjacent the resilient ring is a molded plastic ring in which a plurality of permanent magnet members are imbedded at regularly spaced intervals. The plastic ring further includes at least, one boss projecting outward from a surface thereof and designed to fit within an aperture disposed in an outermost ring, which is entirely or partially of a ferrous metal and which carries a plurality of abrasive members on its outer surface. The resilient ring is fastened to the rigid plate by internally threaded tubular pins and the plastic ring is secured by screws that pass through the plastic ring into the lumens of the internally threaded tubular pins.
B24B 7/18 - Single-purpose machines or devices for grinding floorings, walls, ceilings or the like
E04F 21/24 - Implements for finishing work on buildings for laying flooring of masses made in situ, e.g. smoothing tools
B24D 5/06 - Bonded abrasive wheels, or wheels with inserted abrasive blocks, designed for acting only by their peripheryBushings or mountings therefor with inserted abrasive blocks, e.g. segmental
A pad driver for a floor treating machine comprises an annular support plate to which is attached a plurality of resilient spoke members that project radially therefrom. The support plate is shock-mounted to a hub used to couple the pad driver to a floor treating machine drive motor shaft. On the free ends of the resilient spokes are connector plates on which abrasive pads are removably secured.
E04G 3/00 - Scaffolds essentially supported by building constructions, e.g. adjustable in height
A47L 11/40 - Parts or details of machines not provided for in groups , or not restricted to one of these groups, e.g. handles, arrangements of switches, skirts, buffers or levers
