Hydrogen generators being thermochemical machines for
generating hydrogen. Hydrogen generators being adsorption apparatus for
generating hydrogen and hydrogen purifiers being hydrogen
gas purification machines.
(1) Hydrogen generators being thermochemical machines for generating hydrogen.
(2) Hydrogen generators being adsorption apparatus for generating hydrogen and hydrogen purifiers being hydrogen gas purification machines.
Hydrogen purification devices and their components are disclosed. In some embodiments, the devices include a permeate frame, which may include a perimeter portion and a membrane support portion surrounded by the perimeter portion. The membrane support portion may include opposed first and second surfaces with each of the first and second surfaces having a plurality of grooves. The membrane support portion may be in contact with and support at least one hydrogen selective membrane. The membrane support portion may be integrally formed with the perimeter portion. The permeate frame may additionally include one or more output apertures in at least one of the perimeter portion and the membrane support portion. The permeate frame may further include at least one input aperture in the perimeter portion. The at least one input aperture may be distinct and spaced from the one or more output apertures.
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
C01B 3/56 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification by contacting with solidsRegeneration of used solids
C01B 3/58 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification by contacting with solidsRegeneration of used solids including a catalytic reaction
Hydrogen generation assemblies and methods are disclosed. In one embodiment, the method includes receiving a feed stream in a fuel processing assembly, and heating, via one or more burners, a hydrogen generating region of the fuel processing assembly to at least a minimum hydrogen-producing temperature. The method additionally includes generating an output stream in the heated hydrogen generating region of the fuel processing assembly from the received feed stream, and generating a product hydrogen stream and a byproduct stream in a purification region of the fuel processing assembly from the output stream. The method further includes separating at least a portion of the carbon dioxide gas from the byproduct stream to generate a fuel stream having a carbon dioxide concentration less than the byproduct stream, and feeding the fuel stream to the one or more burners.
C01B 3/56 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification by contacting with solidsRegeneration of used solids
B01J 19/00 - Chemical, physical or physico-chemical processes in generalTheir relevant apparatus
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
C01B 3/52 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification by contacting with liquidsRegeneration of used liquids
H01M 8/0612 - Combination of fuel cells with means for production of reactants or for treatment of residues with means for production of gaseous reactants from carbon-containing material
Hydrogen purification devices and their components are disclosed. In some embodiments, the devices may include at least one foil-microscreen assembly disposed between and secured to first and second end frames. The at least one foil-microscreen assembly may include at least one hydrogen-selective membrane and at least one microscreen structure including a non-porous planar sheet having a plurality of apertures forming a plurality of fluid passages. The planar sheet may include generally opposed planar surfaces configured to provide support to the permeate side. The plurality of fluid passages may extend between the opposed surfaces. The at least one hydrogen-selective membrane may be metallurgically bonded to the at least one microscreen structure. In some embodiments, the devices may include a permeate frame having at least one membrane support structure that spans at least a substantial portion of an open region and that is configured to support at least one foil-microscreen assembly.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
B23K 20/02 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating by means of a press
B23K 20/16 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating with interposition of special material to facilitate connection of the parts, e.g. material for absorbing or producing gas
B23K 20/22 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating taking account of the properties of the materials to be welded
Hydrogen purification devices and their components are disclosed. In some embodiments, the devices include a permeate frame, which may include a perimeter portion and a membrane support portion surrounded by the perimeter portion. The membrane support portion may include opposed first and second surfaces with each of the first and second surfaces having a plurality of grooves. The membrane support portion may be in contact with and support at least one hydrogen selective membrane. The membrane support portion may be integrally formed with the perimeter portion. The permeate frame may additionally include one or more output apertures in at least one of the perimeter portion and the membrane support portion. The permeate frame may further include at least one input aperture in the perimeter portion. The at least one input aperture may be distinct and spaced from the one or more output apertures.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
Hydrogen purification devices and their components are disclosed. In some embodiments, the devices may include feed frame(s) and/or permeate frame(s) each having at least one elongate hole distinct and spaced from an open region, at least one output aperture, and/or at least one input aperture. The elongate hole may be disposed between the open region and the at least one input aperture. The elongate hole may be capable of receiving a portion of the mixed gas stream that leaks from the open region and/or at least one input conduit. The devices may additionally include gasket frames having at least one notch in one or more edges of a perimeter base. The notch may be in fluid communication with a longitudinal end portion of the elongate hole. The devices may further include first and second side plates that collectively enclose a plurality of frames.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
Hydrogen purification devices and their components are disclosed. In some embodiments, the devices may include feed frame(s) and/or permeate frame(s) each having at least one elongate hole distinct and spaced from an open region, at least one output aperture, and/or at least one input aperture. The elongate hole may be disposed between the open region and the at least one input aperture. The elongate hole may be capable of receiving a portion of the mixed gas stream that leaks from the open region and/or at least one input conduit. The devices may additionally include gasket frames having at least one notch in one or more edges of a perimeter base. The notch may be in fluid communication with a longitudinal end portion of the elongate hole. The devices may further include first and second side plates that collectively enclose a plurality of frames.
C01B 3/02 - Production of hydrogen or of gaseous mixtures containing hydrogen
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
C01B 3/24 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of gaseous or liquid organic compounds of hydrocarbons
C01B 3/22 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of gaseous or liquid organic compounds
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
Hydrogen purification devices and their components are disclosed. In some embodiments, the devices may include at least one foil-microscreen assembly disposed between and secured to first and second end frames. The at least one foil-microscreen assembly may include at least one hydrogen-selective membrane and at least one microscreen structure including a non-porous planar sheet having a plurality of apertures forming a plurality of fluid passages. The planar sheet may include generally opposed planar surfaces configured to provide support to the permeate side. The plurality of fluid passages may extend between the opposed surfaces. The at least one hydrogen-selective membrane may be metallurgically bonded to the at least one microscreen structure.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
B23K 20/02 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating by means of a press
B23K 20/16 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating with interposition of special material to facilitate connection of the parts, e.g. material for absorbing or producing gas
B23K 20/22 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating taking account of the properties of the materials to be welded
Hydrogen generators being thermochemical machines for generating hydrogen Hydrogen generators being adsorption apparatus for generating hydrogen and hydrogen purifiers being hydrogen gas purification machines
Hydrogen generation assemblies and methods are disclosed. In one embodiment, the method includes receiving a feed stream in a fuel processing assembly, and heating, via one or more burners, a hydrogen generating region of the fuel processing assembly to at least a minimum hydrogen-producing temperature. The method additionally includes generating an output stream in the heated hydrogen generating region of the fuel processing assembly from the received feed stream, and generating a product hydrogen stream and a byproduct stream in a purification region of the fuel processing assembly from the output stream. The method further includes separating at least a portion of the carbon dioxide gas from the byproduct stream to generate a fuel stream having a carbon dioxide concentration less than the byproduct stream, and feeding the fuel stream to the one or more burners.
C01B 3/02 - Production of hydrogen or of gaseous mixtures containing hydrogen
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
C01B 3/00 - HydrogenGaseous mixtures containing hydrogenSeparation of hydrogen from mixtures containing itPurification of hydrogen
Hydrogen generation assemblies and methods are disclosed. In one embodiment, the method includes receiving a feed stream in a fuel processing assembly, and heating, via one or more burners, a hydrogen generating region of the fuel processing assembly to at least a minimum hydrogen-producing temperature. The method additionally includes generating an output stream in the heated hydrogen generating region of the fuel processing assembly from the received feed stream, and generating a product hydrogen stream and a byproduct stream in a purification region of the fuel processing assembly from the output stream. The method further includes separating at least a portion of the carbon dioxide gas from the byproduct stream to generate a fuel stream having a carbon dioxide concentration less than the byproduct stream, and feeding the fuel stream to the one or more burners.
C01B 3/56 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification by contacting with solidsRegeneration of used solids
B01J 19/00 - Chemical, physical or physico-chemical processes in generalTheir relevant apparatus
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
C01B 3/52 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification by contacting with liquidsRegeneration of used liquids
H01M 8/0612 - Combination of fuel cells with means for production of reactants or for treatment of residues with means for production of gaseous reactants from carbon-containing material
15.
Hydrogen generation assemblies and hydrogen purification devices
Hydrogen generation assemblies, hydrogen purification devices, and their components, and methods of manufacturing those assemblies, devices, and components are disclosed. In some embodiments, the devices may include an insulation base having insulating material and at least one passage that extends through the insulating material. In some embodiments, the at least one passage may be in fluid communication with a combustion region.
C01B 3/38 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents using catalysts
B01J 8/02 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
B01D 63/00 - Apparatus in general for separation processes using semi-permeable membranes
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
Hydrogen purification devices and their components are disclosed. In some embodiments, the devices may include at least one foil-microscreen assembly disposed between and secured to first and second end frames. The at least one foil- microscreen assembly may include at least one hydrogen-selective membrane and at least one microscreen structure including a non-porous planar sheet having a plurality of apertures forming a plurality of fluid passages. The planar sheet may include generally opposed planar surfaces configured to provide support to the permeate side. The plurality of fluid passages may extend between the opposed surfaces. The at least one hydrogen-selective membrane may be metallurgically bonded to the at least one microscreen structure.
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
C01B 3/56 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification by contacting with solidsRegeneration of used solids
Hydrogen purification devices and their components are disclosed. In some embodiments, the devices may include at least one foil-microscreen assembly disposed between and secured to first and second end frames. The at least one foil-microscreen assembly may include at least one hydrogen-selective membrane and at least one microscreen structure including a non-porous planar sheet having a plurality of apertures forming a plurality of fluid passages. The planar sheet may include generally opposed planar surfaces configured to provide support to the permeate side. The plurality of fluid passages may extend between the opposed surfaces. The at least one hydrogen-selective membrane may be metallurgically bonded to the at least one microscreen structure.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
B23K 20/22 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating taking account of the properties of the materials to be welded
B23K 20/02 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating by means of a press
B23K 20/16 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating with interposition of special material to facilitate connection of the parts, e.g. material for absorbing or producing gas
Hydrogen purification devices and their components are disclosed. In some embodiments, the devices may include at least one foil-microscreen assembly disposed between and secured to first and second end frames. The at least one foil-microscreen assembly may include at least one hydrogen-selective membrane and at least one microscreen structure including a non-porous planar sheet having a plurality of apertures forming a plurality of fluid passages. The planar sheet may include generally opposed planar surfaces configured to provide support to the permeate side. The plurality of fluid passages may extend between the opposed surfaces. The at least one hydrogen-selective membrane may be metallurgically bonded to the at least one microscreen structure. In some embodiments, the devices may include a permeate frame having at least one membrane support structure that spans at least a substantial portion of an open region and that is configured to support at least one foil-microscreen assembly.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
B23K 20/22 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating taking account of the properties of the materials to be welded
B23K 20/02 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating by means of a press
B23K 20/16 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating with interposition of special material to facilitate connection of the parts, e.g. material for absorbing or producing gas
Hydrogen purification devices and their components are disclosed. In some embodiments, the devices may include at least one foil-microscreen assembly disposed between and secured to first and second end frames. The at least one foil-microscreen assembly may include at least one hydrogen-selective membrane and at least one microscreen structure including a non-porous planar sheet having a plurality of apertures forming a plurality of fluid passages. The planar sheet may include generally opposed planar surfaces configured to provide support to the permeate side. The plurality of fluid passages may extend between the opposed surfaces. The at least one hydrogen-selective membrane may be metallurgically bonded to the at least one microscreen structure. In some embodiments, the devices may include a permeate frame having at least one membrane support structure that spans at least a substantial portion of an open region and that is configured to support at least one foil-microscreen assembly.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
B23K 20/22 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating taking account of the properties of the materials to be welded
B23K 20/02 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating by means of a press
B23K 20/16 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating with interposition of special material to facilitate connection of the parts, e.g. material for absorbing or producing gas
Hydrogen generation assemblies, hydrogen purification devices, and their components are disclosed. In some embodiments, the devices may include a permeate frame with a membrane support structure having first and second membrane support plates that are free from perforations and that include a plurality of microgrooves configured to provide flow channels for at least part of the permeate stream. In some embodiments, the assemblies may include a return conduit fluidly connecting a buffer tank and a reformate conduit, a return valve assembly configured to manage flow in the return conduit, and a control assembly configured to operate a fuel processing assembly between run and standby modes based, at least in part, on detected pressure in the buffer tank and configured to direct the return valve assembly to allow product hydrogen stream to flow from the buffer tank to the reformate conduit when the fuel processing assembly is in the standby mode.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
C01B 3/22 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of gaseous or liquid organic compounds
C01B 3/24 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of gaseous or liquid organic compounds of hydrocarbons
C01B 3/34 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents
21.
Hydrogen generation assemblies and hydrogen purification devices
Hydrogen generation assemblies, hydrogen purification devices, and their components, and methods of manufacturing those assemblies, devices, and components are disclosed. In some embodiments, the devices may include an insulation base having insulating material and at least one passage that extends through the insulating material. In some embodiments, the at least one passage may be in fluid communication with a combustion region.
C01B 3/38 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents using catalysts
B01J 8/02 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds
B01D 63/00 - Apparatus in general for separation processes using semi-permeable membranes
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
22.
Refining assemblies and refining methods for rich natural gas
Refining assemblies and methods for refining rich natural gas containing a first methane gas and other hydrocarbons that are heavier than methane gas are disclosed. In some embodiments, the assemblies may include a methane-producing assembly configured to receive at least one liquid-containing feed stream that includes water and rich natural gas and to produce an output stream therefrom by (a) converting at least a substantial portion of the other hydrocarbons of the rich natural gas with the water to a second methane gas, a lesser portion of the water, and other gases, and (b) allowing at least a substantial portion of the first methane gas from the rich natural gas to pass through the methane-producing assembly unconverted. The assemblies may additionally include a purification assembly configured to receive the output stream and to produce a methane-rich stream therefrom having a greater methane concentration than the output stream.
C10L 3/10 - Working-up natural gas or synthetic natural gas
B01J 8/02 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds
Hydrogen purification devices and their components are disclosed. In some embodiments, the devices may include at least one foil-microscreen assembly disposed between and secured to first and second end frames. The at least one foil- microscreen assembly may include at least one hydrogen-selective membrane and at least one microscreen structure including a non-porous planar sheet having a plurality of apertures forming a plurality of fluid passages. The planar sheet may include generally opposed planar surfaces configured to provide support to the permeate side. The plurality of fluid passages may extend between the opposed surfaces. The at least one hydrogen-selective membrane may be metallurgically bonded to the at least one microscreen structure. In some embodiments, the devices may include a permeate frame having at least one membrane support structure that spans at least a substantial portion of an open region and that is configured to support at least one foil-microscreen assembly.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
C01B 3/22 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of gaseous or liquid organic compounds
C01B 3/24 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of gaseous or liquid organic compounds of hydrocarbons
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
C01B 3/34 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
24.
Hydrogen generation assemblies and hydrogen purification devices
Hydrogen generation assemblies, hydrogen purification devices, and their components are disclosed. In some embodiments, the devices may include a permeate frame with a membrane support structure having first and second membrane support plates that are free from perforations and that include a plurality of microgrooves configured to provide flow channels for at least part of the permeate stream. In some embodiments, the assemblies may include a return conduit fluidly connecting a buffer tank and a reformate conduit, a return valve assembly configured to manage flow in the return conduit, and a control assembly configured to operate a fuel processing assembly between run and standby modes based, at least in part, on detected pressure in the buffer tank and configured to direct the return valve assembly to allow product hydrogen stream to flow from the buffer tank to the reformate conduit when the fuel processing assembly is in the standby mode.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
C01B 3/22 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of gaseous or liquid organic compounds
C01B 3/24 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of gaseous or liquid organic compounds of hydrocarbons
C01B 3/34 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents
Hydrogen generation assemblies and methods of generating hydrogen are disclosed. In some embodiments, the method may include receiving a feed stream in a fuel processing assembly of the hydrogen generation assembly; and generating a product hydrogen stream in the fuel processing assembly from the received feed stream. Generating a product hydrogen stream may, in some embodiments, include generating an output stream in a hydrogen generating region from the received feed stream, and generating the product hydrogen stream in a purification region from the output stream. The method may additionally include receiving the generated product hydrogen stream in a buffer tank of the hydrogen generation assembly; and detecting pressure in the buffer tank via a tank sensor assembly. The method may further include stopping generation of the product hydrogen stream in the fuel processing assembly when the detected pressure in the buffer tank is above a predetermined maximum pressure.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
C01B 3/22 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of gaseous or liquid organic compounds
C01B 3/24 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of gaseous or liquid organic compounds of hydrocarbons
C01B 3/34 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents
Hydrogen purification devices and their components are disclosed. In some embodiments, the devices may include at least one foil-microscreen assembly disposed between and secured to first and second end frames. The at least one foil-microscreen assembly may include at least one hydrogen-selective membrane and at least one microscreen structure including a non-porous planar sheet having a plurality of apertures forming a plurality of fluid passages. The planar sheet may include generally opposed planar surfaces configured to provide support to the permeate side. The plurality of fluid passages may extend between the opposed surfaces. The at least one hydrogen-selective membrane may be metallurgically bonded to the at least one microscreen structure. In some embodiments, the devices may include a permeate frame having at least one membrane support structure that spans at least a substantial portion of an open region and that is configured to support at least one foil-microscreen assembly.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
B23K 20/22 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating taking account of the properties of the materials to be welded
B23K 20/02 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating by means of a press
B23K 20/16 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating with interposition of special material to facilitate connection of the parts, e.g. material for absorbing or producing gas
Refining assemblies and methods for refining rich natural gas containing a first methane gas and other hydrocarbons that are heavier than methane gas are disclosed. In some embodiments, the assemblies may include a methane-producing assembly configured to receive at least one liquid-containing feed stream that includes water and rich natural gas and to produce an output stream therefrom by (a) converting at least a substantial portion of the other hydrocarbons of the rich natural gas with the water to a second methane gas, a lesser portion of the water, and other gases, and (b) allowing at least a substantial portion of the first methane gas from the rich natural gas to pass through the methane-producing assembly unconverted. The assemblies may additionally include a purification assembly configured to receive the output stream and to produce a methane-rich stream therefrom having a greater methane concentration than the output stream.
C10L 3/10 - Working-up natural gas or synthetic natural gas
B01J 8/02 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds
Hydrogen generation assemblies, hydrogen purification devices, and their components, and methods of manufacturing those assemblies, devices, and components are disclosed. In some embodiments, the devices may include an insulation base having insulating material and at least one passage that extends through the insulating material. In some embodiments, the at least one passage may be in fluid communication with a combustion region.
C01B 3/38 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents using catalysts
B01J 8/02 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds
B01D 63/00 - Apparatus in general for separation processes using semi-permeable membranes
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
29.
Hydrogen generation assemblies and hydrogen purification devices
Hydrogen generation assemblies, hydrogen purification devices, and their components are disclosed. In some embodiments, the devices may include a permeate frame with a membrane support structure having first and second membrane support plates that are free from perforations and that include a plurality of microgrooves configured to provide flow channels for at least part of the permeate stream. In some embodiments, the assemblies may include a return conduit fluidly connecting a buffer tank and a reformate conduit, a return valve assembly configured to manage flow in the return conduit, and a control assembly configured to operate a fuel processing assembly between run and standby modes based, at least in part, on detected pressure in the buffer tank and configured to direct the return valve assembly to allow product hydrogen stream to flow from the buffer tank to the reformate conduit when the fuel processing assembly is in the standby mode.
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
C01B 3/24 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of gaseous or liquid organic compounds of hydrocarbons
C01B 3/34 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents
Refining assemblies and methods for refining rich natural gas containing a first methane gas and other hydrocarbons that are heavier than methane gas are disclosed. In some embodiments, the assemblies may include a methane-producing assembly configured to receive at least one liquid-containing feed stream that includes water and rich natural gas and to produce an output stream therefrom by (a) converting at least a substantial portion of the other hydrocarbons of the rich natural gas with the water to a second methane gas, a lesser portion of the water, and other gases, and (b) allowing at least a substantial portion of the first methane gas from the rich natural gas to pass through the methane-producing assembly unconverted. The assemblies may additionally include a purification assembly configured to receive the output stream and to produce a methane-rich stream therefrom having a greater methane concentration than the output stream.
B01D 53/14 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by absorption
C10L 3/06 - Natural gasSynthetic natural gas obtained by processes not covered by , or
31.
REFINING ASSEMBLIES AND REFINING METHODS FOR RICH NATURAL GAS
Refining assemblies and methods for refining rich natural gas containing a first methane gas and other hydrocarbons that are heavier than methane gas are disclosed. In some embodiments, the assemblies may include a methane-producing assembly configured to receive at least one liquid-containing feed stream that includes water and rich natural gas and to produce an output stream therefrom by (a) converting at least a substantial portion of the other hydrocarbons of the rich natural gas with the water to a second methane gas, a lesser portion of the water, and other gases, and (b) allowing at least a substantial portion of the first methane gas from the rich natural gas to pass through the methane-producing assembly unconverted. The assemblies may additionally include a purification assembly configured to receive the output stream and to produce a methane-rich stream therefrom having a greater methane concentration than the output stream.
B01D 53/00 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols
F25J 3/06 - Processes or apparatus for separating the constituents of gaseous mixtures involving the use of liquefaction or solidification by partial condensation
F25J 3/08 - Separating gaseous impurities from gases or gaseous mixtures
32.
Refining assemblies and refining methods for rich natural gas
Refining assemblies and methods for refining rich natural gas containing a first methane gas and other hydrocarbons that are heavier than methane gas are disclosed. In some embodiments, the assemblies may include a methane-producing assembly configured to receive at least one liquid-containing feed stream that includes water and rich natural gas and to produce an output stream therefrom by (a) converting at least a substantial portion of the other hydrocarbons of the rich natural gas with the water to a second methane gas, a lesser portion of the water, and other gases, and (b) allowing at least a substantial portion of the first methane gas from the rich natural gas to pass through the methane-producing assembly unconverted. The assemblies may additionally include a purification assembly configured to receive the output stream and to produce a methane-rich stream therefrom having a greater methane concentration than the output stream.
C10L 3/10 - Working-up natural gas or synthetic natural gas
B01J 8/02 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds
33.
Refining assemblies and refining methods for rich natural gas
Refining assemblies and methods for refining rich natural gas containing a first methane gas and other hydrocarbons that are heavier than methane gas are disclosed. In some embodiments, the assemblies may include a methane-producing assembly configured to receive at least one liquid-containing feed stream that includes water and rich natural gas and to produce an output stream therefrom by (a) converting at least a substantial portion of the other hydrocarbons of the rich natural gas with the water to a second methane gas, a lesser portion of the water, and other gases, and (b) allowing at least a substantial portion of the first methane gas from the rich natural gas to pass through the methane-producing assembly unconverted. The assemblies may additionally include a purification assembly configured to receive the output stream and to produce a methane-rich stream therefrom having a greater methane concentration than the output stream.
B01J 8/02 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds
C01B 3/38 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents using catalysts
C10L 3/10 - Working-up natural gas or synthetic natural gas
34.
Refining assemblies and refining methods for rich natural gas
Refining assemblies and methods for refining rich natural gas containing a first methane gas and other hydrocarbons that are heavier than methane gas are disclosed. In some embodiments, the assemblies may include a methane-producing assembly configured to receive at least one liquid-containing feed stream that includes water and rich natural gas and to produce an output stream therefrom by (a) converting at least a substantial portion of the other hydrocarbons of the rich natural gas with the water to a second methane gas, a lesser portion of the water, and other gases, and (b) allowing at least a substantial portion of the first methane gas from the rich natural gas to pass through the methane-producing assembly unconverted. The assemblies may additionally include a purification assembly configured to receive the output stream and to produce a methane-rich stream therefrom having a greater methane concentration than the output stream.
C10L 3/10 - Working-up natural gas or synthetic natural gas
B01J 8/02 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds
Hydrogen generation assemblies and methods of generating hydrogen are disclosed. In some embodiments, the method may include receiving a feed stream in a fuel processing assembly of the hydrogen generation assembly; and generating a product hydrogen stream in the fuel processing assembly from the received feed stream. Generating a product hydrogen stream may, in some embodiments, include generating an output stream in a hydrogen generating region from the received feed stream, and generating the product hydrogen stream in a purification region from the output stream. The method may additionally include receiving the generated product hydrogen stream in a buffer tank of the hydrogen generation assembly; and detecting pressure in the buffer tank via a tank sensor assembly. The method may further include stopping generation of the product hydrogen stream in the fuel processing assembly when the detected pressure in the buffer tank is above a predetermined maximum pressure.
C01B 3/52 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification by contacting with liquidsRegeneration of used liquids
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
36.
Hydrogen generation assemblies and hydrogen purification devices
Hydrogen generation assemblies, hydrogen purification devices, and their components are disclosed. In some embodiments, the devices may include a permeate frame with a membrane support structure having first and second membrane support plates that are free from perforations and that include a plurality of microgrooves configured to provide flow channels for at least part of the permeate stream. In some embodiments, the assemblies may include a return conduit fluidly connecting a buffer tank and a reformate conduit, a return valve assembly configured to manage flow in the return conduit, and a control assembly configured to operate a fuel processing assembly between run and standby modes based, at least in part, on detected pressure in the buffer tank and configured to direct the return valve assembly to allow product hydrogen stream to flow from the buffer tank to the reformate conduit when the fuel processing assembly is in the standby mode.
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
Hydrogen generation assemblies, hydrogen purification devices, and their components, and methods of manufacturing those assemblies, devices, and components are disclosed. In some embodiments, the devices may include frames with membrane support structures and/or may include a microscreen structure configured to prevent intermetallic diffusion.
C01B 3/38 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents using catalysts
B01J 8/02 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds
38.
HYDROGEN GENERATION ASSEMBLIES AND HYDROGEN PURIFICATION DEVICES
Hydrogen generation assemblies, hydrogen purification devices, and their components are disclosed. In some embodiments, the devices may include a permeate frame with a membrane support structure having first and second membrane support plates that are free from perforations and that include a plurality of microgrooves configured to provide flow channels for at least part of the permeate stream. In some embodiments, the assemblies may include a return conduit fluidly connecting a buffer tank and a reformate conduit, a return valve assembly configured to manage flow in the return conduit, and a control assembly configured to operate a fuel processing assembly between run and standby modes based, at least in part, on detected pressure in the buffer tank and configured to direct the return valve assembly to allow product hydrogen stream to flow from the buffer tank to the reformate conduit when the fuel processing assembly is in the standby mode.
B01D 53/22 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by diffusion
39.
Hydrogen generation assemblies and hydrogen purification devices
Hydrogen generation assemblies, hydrogen purification devices, and their components are disclosed. In some embodiments, the devices may include a permeate frame with a membrane support structure having first and second membrane support plates that are free from perforations and that include a plurality of microgrooves configured to provide flow channels for at least part of the permeate stream. In some embodiments, the assemblies may include a return conduit fluidly connecting a buffer tank and a reformate conduit, a return valve assembly configured to manage flow in the return conduit, and a control assembly configured to operate a fuel processing assembly between run and standby modes based, at least in part, on detected pressure in the buffer tank and configured to direct the return valve assembly to allow product hydrogen stream to flow from the buffer tank to the reformate conduit when the fuel processing assembly is in the standby mode.
C01B 3/32 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air
C01B 3/00 - HydrogenGaseous mixtures containing hydrogenSeparation of hydrogen from mixtures containing itPurification of hydrogen
C01B 3/50 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification
Hydrogen generation assemblies and their components are disclosed. In some embodiments, the assemblies may include a pump controller configured to select a flowrate from a plurality of flowrates based on detected pressure, and to operate the pump at the selected flowrate. In some embodiments, the assemblies may include a purge valve assembly configured to allow at least one pressurized gas to flow through a purge conduit from a pressurized gas assembly to a fuel processing assembly when power to the fuel processing assembly is interrupted. In some embodiments, the assemblies may include a damper controller configured to move a damper between fully open and closed positions based, at least in part, on detected temperature in a hydrogen-producing region. In some embodiments, the assemblies may include a reformer controller configured to operate a fuel processing assembly between run and standby modes based, at least in part, on detected pressure.
Hydrogen generation assemblies, hydrogen purification devices, and their components, and methods of manufacturing those assemblies, devices, and components are disclosed. In some embodiments, the assemblies may include a vaporization region with packing material configured to transfer heat from a heated exhaust stream to a liquid-containing feed stream, and/or an insulation base adjacent a combustion region and configured to reduce external temperature of an enclosure. In some embodiments, the assemblies may include a cooling block configured to maintain an igniter assembly in thermal communication with a feed stream conduit, an igniter assembly including a catalytic coating, and/or a fuel stream distribution assembly. In some embodiments, the assemblies may include a heat conducting assembly configured to conduct heat from external heaters to an enclosure portion. In some embodiments, the devices may include frames with membrane support structures and/or may include a microscreen structure configured to prevent intermetallic diffusion.
C01B 3/36 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents using oxygen or mixtures containing oxygen as gasifying agents
C01B 6/24 - Hydrides containing at least two metals, e.g. Li(AlH4)Addition complexes thereof
C01B 3/02 - Production of hydrogen or of gaseous mixtures containing hydrogen
C01B 3/24 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of gaseous or liquid organic compounds of hydrocarbons
B01J 8/02 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds
C01B 3/38 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents using catalysts
