The communication system includes a display card, a display processing module, a display-card connector, a power supply, a power processing module, a signal transmission element, a display-end connector, and a configuration unit. The display-card connector includes a display-card first terminal set involving 6 terminals, a display-card second terminal set involving another 6 terminals, and a display-card signal terminal set including two function terminals and two detection terminals. Each function terminal allows at least one user-defined function regarding a signal to be monitored from the power supply. The display processing module, therefore, may monitor and control the power supply through the function terminals.
The present invention includes a power supply unit composed of a casing and a current conversion unit, a slotted wall, a fan device composed of a fan and a fan support, a chamber, and a slant rim. The fan device is detachably joined to the casing for convenient maintenance and replacement. The fan is housed in the fully open chamber for reduced impedance and noise. The slant rim tapers toward the chamber and facilitates airflow for enhanced heat dissipation performance.
A power adapter includes a housing, at least one conductive bar, a first electrical connector, and a fixing assembly. The conductive bar is disposed in the housing. The first electrical connector is movably disposed on one side of the housing and includes at least one electrical contact portion extending into the housing. The fixing assembly is movably disposed on the housing and includes two clamping members and an actuating member. The actuating member is configured to move the clamping members toward each other, so as to make the conductive bar and the electrical contact portion to abut against each other.
A suspension type supporting device includes a wire, a first fixing member, an adjusting member, and a second fixing member. The first fixing member is connected to a first portion of the wire and configured to be fixed to a first object. The adjusting member is connected to a second portion of the wire and adjustably connected to a third portion of the wire located between the first portion and the second portion. The second fixing member is movably connected to a fourth portion of the wire located between the second portion and the third portion, and is configured to be fixed to a second object.
F16M 13/02 - Other supports for positioning apparatus or articlesMeans for steadying hand-held apparatus or articles for supporting on, or attaching to, an object, e.g. tree, gate, window-frame, cycle
5.
Graphics card firmware updating system and updating method thereof for fast startup setting of windows computer operating system after replacing graphics card
A graphics card firmware updating system and an updating method thereof for fast startup setting of a Windows computer operating system after replacing the graphics card comprise an electronic device, a replaced graphics card, and a comparison unit, the electronic device receives a boot signal to execute a Windows fast startup program, the electronic device has a storage unit comprising an original graphics processing unit identification code, the replaced graphics card is installed in the electronic device and comprises a microcontroller, the microcontroller comprises a microcontroller identification code and a firmware version, the comparison unit comparing whether the microcontroller identification code of the replaced graphics card being the same as an original microcontroller identification code read from the storage unit during the Windows fast startup setting, and executing a firmware updating process or a rebooting process on the electronic device according to whether the comparison being the same.
An external graphics method for an external graphics system is provided. The external graphics system includes a host device at least having a first graphics processing unit that generates a first video stream signal, and an external graphics device for connecting to the host device. The external graphics device at least includes a second graphics processing unit that generates a second video stream signal, and a TBT interface unit electrically connected to the host device. The method mainly includes: when the host device determining a graphics processing performed by the second graphics processing unit not exceeding a load-carrying capacity threshold, displaying an image frame corresponding to a TBT signal; and when determining the graphics processing performed by the second graphics processing unit exceeding the load-carrying capacity threshold, computing the TBT signal and the first video stream signal in sum, and displaying the corresponding image frame accordingly.
G06F 15/16 - Combinations of two or more digital computers each having at least an arithmetic unit, a program unit and a register, e.g. for a simultaneous processing of several programs
G06T 1/20 - Processor architecturesProcessor configuration, e.g. pipelining
G09G 5/36 - Control arrangements or circuits for visual indicators common to cathode-ray tube indicators and other visual indicators characterised by the display of individual graphic patterns using a bit-mapped memory
7.
Asynchronous temperature control integrated device
An asynchronous temperature control integrated device includes a graphics card body including a graphics processor and a power supply circuit, at least one external fan connection port, a first heat dissipation device, at least one first temperature sensor, a second heat dissipation device, a plurality of second temperature sensors, a plurality of light emission elements, and a control device including an externality control member, a high-power drive module, and a scenario database. Thus, two groups of heat dissipation device and temperature sensor are provided to respectively detect the temperatures of two major heat sources on the graphics card body, and the heat dissipation performances of the two heat dissipation devices are individually controllable to make timely and efficient operations of the heat dissipation devices, and also to collaboratively drive an external fan to thereby enhance overall airflow, reduce system internal temperature, and achieve bettered conditions of temperature control.
H05K 7/20 - Modifications to facilitate cooling, ventilating, or heating
G08B 5/36 - Visible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electric transmissionVisible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electromagnetic transmission using visible light sources
The present invention provides a smart overclocking method for a computer device with a multi-core CPU and abasic input/output system (BIOS) where an overclocking database is stored therein, which comprises: booting the computer device, logging in the BIOS and performing an overclocking function; acquiring overclocking parameters from the overclocking database; conducting adjustment/settlement of the clock rate and the voltage of the multi-core CPU based on the overclocking parameters; conducting a Heavy Load Testing (HLT) on the multi-core CPU; reading out working results data of the multi-core CPU and determining whether any of them have exceeded limits. Hence, overclocking can be completed within 10 min. or less, without causing shut down of the computer device, and without causing working temperature or working voltage of multi-core CPU to be higher than 90° C. or 1500 mV during Heavy Load Testing (HLT).
A mouse device and a computer control system thereof, comprising a mouse and an optical sensing module. The mouse has electrically connected press buttons, light-emitting component and mouse processing unit set with an initial setting command. The optical sensing module is disposed on the mouse and electrically connected to the mouse processing unit, and has a light source emitting unit generating a sensing signal, and a light source receiving unit. The mouse processing unit transmits the sensing signal to a host processing unit of a host computer. Thereby, the optical sensing module senses a user approaches the mouse or generation of gestures to generate the sensing signal. The mouse processing unit drives the light-emitting component to generate an initial light source. The host processing unit generates an advanced control signal to drive the light-emitting component, an operation unit and peripheral devices to generate advanced actions of an advanced setting command.
G09G 1/00 - Control arrangements or circuits, of interest only in connection with cathode-ray tube indicators
G06F 3/038 - Control and interface arrangements therefor, e.g. drivers or device-embedded control circuitry
G06F 3/03 - Arrangements for converting the position or the displacement of a member into a coded form
G06F 3/0354 - Pointing devices displaced or positioned by the userAccessories therefor with detection of 2D relative movements between the device, or an operating part thereof, and a plane or surface, e.g. 2D mice, trackballs, pens or pucks
An audio information processing method, comprising: providing a computer device having a sound effect processing unit, and the computer device being further disposed with a sound effect generating unit and a signal connection interface; the sound effect generating unit receiving an audio information and generating a sound effect signal and transmitting the signal to the sound effect processing unit; the sound effect processing unit analyzing the sound effect signal and generating a position identification signal and transmitting the signal to the signal connection interface; the signal connection interface transmitting the position identification signal to a control circuit of a peripheral device; and the control circuit having a processing unit for processing the position identification signal and generating at least one control signal and controlling at least one light-emitting unit to generate a light source.
A63F 13/422 - Processing input control signals of video game devices, e.g. signals generated by the player or derived from the environment by mapping the input signals into game commands, e.g. mapping the displacement of a stylus on a touch screen to the steering angle of a virtual vehicle automatically for the purpose of assisting the player, e.g. automatic braking in a driving game
A63F 13/25 - Output arrangements for video game devices
A63F 13/54 - Controlling the output signals based on the game progress involving acoustic signals, e.g. for simulating revolutions per minute [RPM] dependent engine sounds in a driving game or reverberation against a virtual wall
A63F 13/24 - Constructional details thereof, e.g. game controllers with detachable joystick handles
A63F 13/215 - Input arrangements for video game devices characterised by their sensors, purposes or types comprising means for detecting acoustic signals, e.g. using a microphone
H05B 47/12 - Controlling the light source in response to determined parameters by determining the presence or movement of objects or living beings by detecting audible sound
12.
Headphone structure for extending and enhancing resonance
The present invention provides a headphone structure for extending and enhancing resonance comprising a main body, a cover and a shield. The main body has an accommodating portion for accommodating a speaker, a plurality of master sound guiding holes are penetrated in the accommodating portion and a plurality of side sound guiding holes are penetrated in the main body. A rear cavity space is formed between the cover and the main body, and the shield forms a rear cavity extending space to communicate with the side sound guiding holes and the rear cavity space. Thereby, the headphone structure can reduce air damping through the rear cavity extending space communicating with the rear cavity space, so as to achieve effects of increasing stroke displacement of the speaker and reducing air suppression of sound.
H04R 1/28 - Transducer mountings or enclosures designed for specific frequency responseTransducer enclosures modified by provision of mechanical or acoustic impedances, e.g. resonator, damping means
The present invention provides a replaceable water-cooled radiating device, comprising a water-cooling module and a light-emitting module, the water-cooling module is provided with a control circuit, and the control circuit is provided with at least one electrical connector. The light-emitting module is disposed on a top of the water-cooling module and is provided with a driving circuit, the driving circuit is provided with at least one light-emitting component and at least one electrical conductive component, and the electrical conductive component is electrically connected to the electrical connector. Thereby the light-emitting module is electrically connected to the electrical connector and the control circuit via the electrical conductive component to conductibly emit light, and the light-emitting module can be directly detachably mounted on the water-cooling module to achieve the efficacy of the water-cooling module mounted with the replaceable light-emitting module.
A water-cooling heat dissipation device suitable for computer includes a pump housing, an upper cover, a motor module and a heat exchange member. The pump housing forms a pump chamber. A side of the upper cover has at least one positioning portion. A side of the motor module has at least one assembly portion that is correspondingly disposed with respect to the positioning portion. A stator set is received in the interior of the motor module. The heat exchange member is correspondingly combined with the pump housing. The heat exchange member forms a heat exchange chamber, and the heat exchange chamber is in communication with the pump chamber.
A light-emitting chassis structure comprising a plate, a plurality of transparent shafts, and at least one side plate, the plate has a plurality of plate conductive portions for assembling with conductive assembling portions of the transparent shafts respectively, inside the transparent shaft is disposed with at least one light-emitting member, and the side plate and the plate are assembled with the light-emitting shafts disposing in between. Thereby, a light source generated by the electrically conducted light-emitting member can be guided by the transparent shaft, so that the light-emitting chassis structure can generate the light source to enhance the overall visual effects. The light-emitting chassis structure is formed with the side plate and the plate, and computer accessories can be disposed at positions of two side surfaces of the plate according to requirements, which are not limited by the metal casing to achieve the effect of adjusting the configuration space conveniently.
09 - Scientific and electric apparatus and instruments
25 - Clothing; footwear; headgear
35 - Advertising and business services
41 - Education, entertainment, sporting and cultural services
Goods & Services
Application software for smart phones; Computer software applications, downloadable; Game software; Handheld computers; Computer operating programs; Downloadable computer software; Computer hardware; Touch panels; Computer motherboards; Graphics accelerators; Graphics cards; sound cards; Plotters; Smartphones; wearable video display monitors; Display monitors; motherboards; Electronic power supplies. Clothes; Ready-made clothing; Smocks; Jackets; Tee-shirts; Undershirts; Sportswear; Vests; Shoes; Scarfs; Neckties; caps; Sports caps; Socks; Gloves; Winter gloves; Belts [clothing]. Presentation of goods on communication media, for retail purposes; Goods or services price quotations; Systemization of information into computer databases; Updating and maintenance of data in computer databases; Updating and maintenance of information in registries; Conducting marketing studies; Auctioneering; Auctioneering services provided via telecommunication networks; Providing online marketplaces for sellers of goods and or services; Exhibitions (Arranging -) for advertising purposes; Exhibitions (Arranging -) for commercial purposes; Auctioning via telecommunication networks; commercial information and advice for consumers in the choice of products and services; Retail services in relation to computer software; Retail services in relation to computer hardware. providing online electronic publications, not downloadable; Publishing services for periodical and non-periodical publications, other than publicity texts; Instruction; Entertainment services; Entertainment information; game services provided online from a computer network; Organization of competitions [education or entertainment]; Organization of seminars; Organisation of recreational activities; Film production.
A pipe fixation apparatus includes a main body and a first receiving portion, a second receiving portion, a bending portion, a first fixation portion, a second fixation portion and an attachment portion formed on the main body. During the use the pipe fixation apparatus, the first receiving portion and the second receiving portion of the main body are able to receive a pipe having a flexible portion in order to use the first fixation portion and the second fixation portion for securing the pipe. In addition, the bending portion allows the flexible portion of the pipe to form a bending shape. The attachment portion can be used to allow more than two main bodies to be attached onto each other. Accordingly, the pipe fixation apparatus of the present invention is convenient to use and is able to achieve a neat and appealing arrangement of pipes.
F16L 3/22 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets specially adapted for supporting a number of parallel pipes at intervals
A computer case cooling structure, including: a case body; at least one control element, configured on a long edge side of the case body; a partition plate, configured inside the case body, thereby dividing the inside of the case body into a first cooling space and second cooling space; a cover body, coupled pivotally to one side of the cover body, thereby rotatable around a shot edge side of the case body; a cooling door assembly, configured movably on the case body; a first fan assembly, configured on the case body and corresponding to the first cooling space; and a second fan assembly, configured on the case body and corresponding to the second cooling space. Whereby, the heat generated from interface cards can be discharged through the first cooling space, and the heat generated from a central processing unit the second cooling space, achieving independent cooling without interference.
A wireless graphics card monitoring device includes a graphics card, which includes a control element in information connection with the graphics card to control hardware status data of the graphics card and mobile control software loaded in a mobile device and in wireless information connection with the control element ton control and display the hardware status data. The control element is operable to control the hardware status data, such as an operation temperature of the graphics card, a rotational speed of a fan, or a processing frequency. The mobile control software controls and displays the hardware status data. As such, a user may use the mobile control software of the mobile device to establish wireless connection with the control element to monitor and control the hardware status data of the graphics card.
G05B 15/02 - Systems controlled by a computer electric
F24F 11/70 - Control systems characterised by their outputsConstructional details thereof
G09G 3/04 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of a single character by selection from a plurality of characters, or by composing the character by combination of individual elements, e.g. segments
G09G 3/36 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix by control of light from an independent source using liquid crystals
A display device of an addin card generally includes, in structure, an addin card, a display device, a control board, and control software. The addin card is in information connection with the display device and the control board. The control software is loaded in the control board and is in information connection with the addin card. The display device access and reads hardware status data of the addin card, such as an operation temperature, a fan rotational speed, and a processing frequency. As such, in an attempt to observe the current hardware status data of the addin card, a user is allowed to make direct observation of the data on the display device without activating the control software. To change the operation performance of the addin card, the user may operate the control software to control the addin card, without entering BIOS, this being very convenient for the user.
A multi-directional cooling structure for an interface card includes: a first cooling plate, configured on the interface card; a second cooling plate, configured at one side of the first cooling plate; at least one heat conduction element, configured on the first cooling plate and second cooling plate, and including a first heat conduction portion positioned on the first cooling plate and a second heat conduction portion in connection with the first heat conduction portion and positioned on the second cooling plate; and at least one cooling fin set, configured on one side of the heat conduction element away from the first and second cooling plates, and in direct contact with the heat conduction element. Therefore, the heat can be conducted not only to one side through the heat conduction element but to the cooling fin sets above, advantageously achieving multi-directional heat dissipation.
An interlaced heat dissipation structure of an addin card generally includes an addin card, a plurality of heat dissipation fins arranged on the addin card, at least one receiving space defined between the heat dissipation fins, a plurality of cooling pipes extending through the heat dissipation fins, and a plurality of heat dissipative elements arranged in the receiving space in a manner of being interlaced with the cooling pipes. As such, the heat dissipation fins, the cooling pipes, and the heat dissipative elements help cool down the addin card to keep the operation of the addin card stable. The interlaced arrangement of the cooling pipes and the heat dissipative elements in the receiving space defined between the heat dissipation fins makes it possible to maximize the total effective heat dissipation area.
A display card protection circuit monitoring structure includes: a display card body; at least one protection circuit module, configured on the display card body, and adapted to generate an open-circuit state when the display card body is abnormal; at least one monitoring device, configured on the display card body and in electric connection with the protection circuit module, and adapted to monitor a use state of the protection circuit module; at least one power supply, respectively in electric connection with and supplying power to the protection circuit module and monitoring device; and at least one warning module, in electric connection with the monitoring device, and driven by the monitoring device to issue warning when the open-circuit state happens. Whereby, the protection circuit module is used to prevent the abnormality or damage of the display card body, and the motoring device can drive the warning module to issue warning.
A simulation switching device of computer control chips is disclosed, including an addin card body, a plurality of computer control chips having different operation frequencies arranged on the addin card body, a graphics processing device in information connection with each of the computer control chips, an operation control device in information connection with each of the computer control chips and the graphics processing device, and an inspection module in information connection with the operation control device. To use, the operation control device detects a voltage of the graphics processing device. If the voltage is in an unstable condition, then the inspection module performs simulation to inspect a condition that will be generated by driving another one of the computer control chips that has a relatively high operation frequency, and automatic switching is made to the computer control chip having the relatively high operation frequency to make the voltage stable.
G06F 30/367 - Design verification, e.g. using simulation, simulation program with integrated circuit emphasis [SPICE], direct methods or relaxation methods
G06F 1/3296 - Power saving characterised by the action undertaken by lowering the supply or operating voltage
An extended control device of a graphics card includes a graphics card body, a reader module, and a control module. The reader module and the control module are provided on the graphics card body. The control module is operable in combination with the reader module. As such, when the reader module reads a situation that the graphics card body has an abnormal status or a user attempts to make adjustment by himself or herself, the user is allowed to directly control and adjust an operation mode of an electronic element directly through the control module provided on the graphics card body so that there is no need to install a control module in each electronic element for individual and independent control and the user can use the control module of the graphics card body to completely control the operation status of each electronic element in the entire area.
A heat dissipation structure is provided for arrangement on an addin card and includes a plurality of heat dissipation fins arranged on the addin card, at least one bent section formed at one side of the heat dissipation fins and located on the addin card, at least one gap section formed between each bent section, and at least one first through-hole section formed in the heat dissipation fins. The heat dissipation fins allow heat to be dissipated from the addin card. The gap section and the first through-hole section of the heat dissipation fins allow air to flow therethrough and ventilate so as to enhance the effect of heat dissipation.
A fixing device for a card fluid cooling structure of an interface includes: a water cooling device, adapted to cool an interface card; a cold drainage tube, configured on the water cooling device; a hot drainage tube, configured on the water cooling device and positioned at one side of the cold drainage tube; a first quick connector, configured on one end of the cold drainage tube far away from the water cooling device; a second quick connector, configured on one end of the hot drainage tube far away from the water cooling device; and a fixing structure, configured on one side of the interface card for the fixation of the hot and cold drainage tubes in position. Whereby, a user uses the fixing structure to fix the hot and cold drainage tubes in position, and the water cooling device can then be installed on the interface card conveniently.
An interface card adapting device structure, mainly includes an outer frame body, transmission conductors, a connector and fixing elements, where the transmission conductors are accommodated in the outer frame body, each of them comprises a first contact portion and second contact portion; the connector is in electric connection with the first contact portion selectively at a predetermined position thereof and fixed by the fixing elements. whereby, when the plugging-in position of an external connector is to be changed, the outer frame body is fixed to the interface card, the connector is inserted in the interface card connector, and the fixing elements is used to fix it and the second first contact portion together; at this time, the external connector can then be plugged into the second contact portion. Thus, the insertion direction and position can be changed without being bound by smaller space, being more extensive.
H01R 12/00 - Structural associations of a plurality of mutually-insulated electrical connecting elements, specially adapted for printed circuits, e.g. printed circuit boards [PCB], flat or ribbon cables, or like generally planar structures, e.g. terminal strips, terminal blocksCoupling devices specially adapted for printed circuits, flat or ribbon cables, or like generally planar structuresTerminals specially adapted for contact with, or insertion into, printed circuits, flat or ribbon cables, or like generally planar structures
H01R 12/72 - Coupling devices for rigid printing circuits or like structures coupling with the edge of the rigid printed circuits or like structures
The heat dissipation device is for a display card and includes an air cooling member on a power supply circuit of the display card, a water cooling member on a processing element of the display card, and an auxiliary member disposed to a side of the water cooling member adjacent to the display card. The auxiliary member has at least an opening corresponding to the processing element and an extension piece extended away from the opening corresponding to a memory of the display card. As such, the heat from power supply circuit, the processing element, and the memory is respectively dissipated by the air cooling member, the water cooling member, and the auxiliary member and its extension piece, thereby achieving significantly enhanced heat dissipation performance.
A detachable keyboard structure includes a keyboard assembly selectively mounted to a notebook computer, a movable cover movably mounted to one side of the keyboard assembly, at least one flexible bendable section connecting the keyboard assembly and the movable cover to each other, and a positioning member rotatably mounted to one side of the movable cover that is distant from the flexible bendable section to fix the movable cover to one side of the keyboard assembly. With such a structure, a user is provided, on a detachable keyboard assembly of a notebook computer, with a movable cover that offers functions of protection and is fixable by a positioning member to prevent undesired detachment during movement of the keyboard assembly. In addition, in use, the movable cover may be folded in a reversed direction through the flexible bendable section to serve as a wrist support for the keyboard assembly.
The computer performance control system includes a performance management unit, a performance integration unit, and an activation unit. A user initiates the activation unit through keyboard and the activation unit activates the performance management unit and the performance integration unit simultaneously. The performance management unit displays the operation statuses of the hardware parts of the computer, and provides a number of modes for a user to set operation frequencies of the hardware parts. The performance integration unit executes a performance integration parameter corresponding a selected mode so as to adjust the performance of the computer. As such, a user can conveniently adjust the performance of the CPU, GPU, and RAM of a multi-tasking computer simultaneously and synchronously through some simple key strokes.
An interface card adapting device includes an adaptor body, a first adapting portion, and a second adapting portion. The adaptor body is positionable against one side of an interface card to allow the first adapting portion to connect to a power connection port, so as to have an output direction of the power connection port changed by the second adapting portion to one side that is different from the first adapting portion. Thus, the second adapting portion may take the place of the power connection port in respect of the functionality thereof. As such, the power cable can be collected at the same side, making it easy to organize the cable and also improve interior aesthetics and heat dissipation effect of an enclosure.
