Abstract

A grinding machine includes a working grinder and a holding unit. The working grinder includes a grinding wheel mounting section and a power mechanism. A grinding wheel is mounted on the grinding wheel mounting section. The holding unit includes a base, a movable seat, a holding device, and a grinding wheel trimming module. The grinding wheel trimming module includes a transmission shaft box, a motor, a holding claw, and a clamping cylinder. The holding claw is used for holding a trimming grinding wheel. The holding unit further includes a pedestal, and a clamping arm. The clamping arm is provided with a holding end. Thus, the holding end grips and moves the trimming grinding wheel to the holding claw which is driven by the clamping cylinder to clamp the trimming grinding wheel. Then, the holding end releases the trimming grinding wheel.

IPC Classes  ?

• B24B 53/14 - Dressing tools equipped with rotary rollers or cuttersHolders therefor
• B24B 53/053 - Devices or means for dressing or conditioning abrasive surfaces of cylindrical or conical surfaces on abrasive tools or wheels using a rotary dressing tool
• B24B 53/00 - Devices or means for dressing or conditioning abrasive surfaces
• B24B 49/18 - Measuring or gauging equipment for controlling the feed movement of the grinding tool or workArrangements of indicating or measuring equipment, e.g. for indicating the start of the grinding operation taking regard of the presence of dressing tools

Abstract

A grinding machine includes a plane grinding mechanism carrying a workpiece, an electrically controlled device mounted on the plane grinding mechanism, a grinder unit rotatably mounted on the plane grinding mechanism to grind the workpiece, and a smart working control system mounted on the plane grinding mechanism and electrically coupled to the electrically controlled device. The smart working control system includes a smart coder and a smart driver. When a load and a cutting force produced between the grinder unit and the workpiece reach preset parameters during the grinding process, the smart driver executes the working sequence or parameter setting program edited by the smart coder, to shorten a movement distance of the workbench of the plane grinding mechanism along the X-axis (leftward and rightward), and to produce an optimum lapping path.

IPC Classes  ?

• B24B 7/02 - Machines or devices designed for grinding plane surfaces on work, including polishing plane glass surfacesAccessories therefor involving a reciprocatingly-moved work-table
• B24B 47/02 - Drives or gearings for grinding machines or devicesEquipment therefor for performing a reciprocating movement of carriages or work-tables
• B24B 49/16 - Measuring or gauging equipment for controlling the feed movement of the grinding tool or workArrangements of indicating or measuring equipment, e.g. for indicating the start of the grinding operation taking regard of the load
• B24B 49/12 - Measuring or gauging equipment for controlling the feed movement of the grinding tool or workArrangements of indicating or measuring equipment, e.g. for indicating the start of the grinding operation involving optical means
• B24B 55/00 - Safety devices for grinding or polishing machinesAccessories fitted to grinding or polishing machines for keeping tools or parts of the machine in good working condition
• B24B 41/04 - HeadstocksWorking-spindlesFeatures relating thereto
• G05B 19/18 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form

Abstract

A grinding machine control method and a control system employing the method is disclosed. The grinding machine control method includes the step of providing a plurality of sub processing procedures each dominating a grinding machine to execute a respective processing step, the step of providing a processing scheduling processing to link the sub processing procedures into a main processing procedure, and the step of executing the main processing procedure to enable the grinding machine to run subject to the processing steps executed by the respective sub processing procedures.

IPC Classes  ?

• B24B 51/00 - Arrangements for automatic control of a series of individual steps in grinding a workpiece
• B24B 37/005 - Control means for lapping machines or devices
• B24B 37/04 - Lapping machines or devicesAccessories designed for working plane surfaces

Goods & Services

Power operated lathes, grinders, sawing machines and milling machines. CD-ROM (compact disc-rom), DVD-ROM (digital video DISC-ROM), DVD player (digital video disc-player), digital camera, DVD for car navigator, scanner, printer, video phone, digital viewcam, set-top-box.

Goods & Services

(1) Surface grinders, and cutter grinders. (2) Lathes, drilling machines, milling machines, and sawing machines.

Goods & Services

(1) Surface grinders, cutter grinders, drilling machines, and milling machines. (2) Lathes, and sawing machines.

Goods & Services

Power-Operated Lathes, Grinders and Milling Machines
