The corrugated cardboard production line comprises, in one or more critical positions of the line, where jamming of the corrugated cardboard is more likely to occur, one or more video cameras. The video camera frames the area at risk of jamming and captures images of the corrugated cardboard. In case of jamming, this is detected by processing the captured images, with a process that highlights the generation of creases or abnormal distortions of the corrugated cardboard.
B31F 1/28 - Making webs in which the channel of each corrugation is transverse to the web feed by interengaging toothed cylinders combined with uniting the corrugated webs to flat webs
2.
CORRUGATED BOARD PRODUCTION LINE WITH VIDEO CAMERAS FOR DETECTING A STOCK OF CORRUGATED BOARD, AND METHOD
A corrugated board production line is described, comprising at least one corrugator and a double facer. A feeding bridge of single faced corrugated board from the corrugator towards the double facer is arranged between the corrugator and the double facer. A video camera frames at least one portion of the bridge. A stock of single faced corrugated board forms on the bridge, in the form of festoons, which move along the bridge. The amount of stock of corrugated board is a function of the number of festoons on the bridge, and hence of the location of the festoon in the most advanced position along the bridge, in the direction of feed from the corrugator to the double facer. Through images captured by the video camera it is possible to obtain information on the location of the most advanced front of the stock and hence on the amount of single faced corrugated board found on the bridge.
B31F 1/28 - Making webs in which the channel of each corrugation is transverse to the web feed by interengaging toothed cylinders combined with uniting the corrugated webs to flat webs
3.
CORRUGATED BOARD PRODUCTION LINE WITH VIDEO CAMERAS FOR DETECTING THE COLLECTION OF BOARD SCRAPS, AND METHOD
Images of a basket associated with a cross cutter of a corrugated cardboard production line are captured through a video camera. The basket is configured and positioned to collect trimmings of corrugated cardboard cut by means of the cross cutter from a continuous corrugated cardboard that advances along the production line. By processing the captured images, the level of filling of the basket is detected to notify an operator when it is necessary to remove the accumulated trimmings.
B31F 1/28 - Making webs in which the channel of each corrugation is transverse to the web feed by interengaging toothed cylinders combined with uniting the corrugated webs to flat webs
An in-line corrugated cardboard laminating plant may include: a first corrugating group; a second corrugating group; a gluing unit; a double backer unit; a trimming unit; a transverse cutting unit; and a laminating machine. The first corrugating group may include: a first corrugator; and first continuous paper web magazines configured to form a first canneté. The second corrugating group may include: a second corrugator; and second continuous paper web magazines configured to form a second canneté. The laminating machine may include: laminated sheets; and a coupling unit configured to couple the laminated sheets to the first and/or second cannetés so as to form laminated corrugated cardboard. The trimming unit may be configured to trim to predefined widths in a continuous manner the first and/or second cannetés coupled together. The transverse cutting unit may be configured to cut transversely the first and/or second cannetés coupled together.
B32B 39/00 - Layout of apparatus or plants, e.g. modular laminating systems
B32B 3/28 - Layered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a particular shape of the outline of the cross-section of a continuous layerLayered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a layer with cavities or internal voids characterised by a layer comprising a deformed thin sheet, e.g. corrugated, crumpled
B32B 38/00 - Ancillary operations in connection with laminating processes
5.
PLANT AND METHOD FOR MANUFACTURING CORRUGATED BOARD WITH AN ORDER CHANGE DETECTOR
The plant comprises includes a visual inspection system provided with one or more vision units. The vision units detect and recognize, through adequate electronic processing, the images printed on at least one face of the corrugated board web. Based on the image recognition, the control system recovers, from a lookup table, information for setting the converting line to produce the subsequent order of sheets.
B31F 1/28 - Making webs in which the channel of each corrugation is transverse to the web feed by interengaging toothed cylinders combined with uniting the corrugated webs to flat webs
B65H 35/04 - Delivering articles from cutting or line-perforating machinesArticle or web delivery apparatus incorporating cutting or line-perforating devices, e.g. adhesive tape dispensers from or with transverse cutters or perforators
