Abstract

The present utility model relates to a swirling flushing-type ceramic body and a toilet, comprising an excrement storage area, a flushing annular channel provided on the upper portion of the excrement storage area in a circumferential direction, a water division cavity communicated with the flushing annular channel, and a main water channel communicated with the middle of the water division cavity by means of a water hole. A water dividing member is fixedly connected to the position in the a water division cavity close to the main water channel; the water division cavity is divided into a primary flushing water channel and a secondary flushing water channel by the water dividing member; a primary flushing hole is formed in an end portion of the primary flushing water channel; a secondary flushing hole is formed in an end portion of the secondary flushing water channel; the primary flushing hole and the secondary flushing hole are respectively provided towards the flushing annular channel. According to the present utility model, the water dividing member is provided in the water division cavity, so that flushing water in the main water channel is guided for drainage, the water distribution of the primary flushing water channel and the secondary flushing water channel is ensured to be reasonable, and a large amount of flushing water is distributed to the primary flushing water channel, thereby effectively avoiding a phenomenon that the primary flushing hole cannot be flushed clean due to insufficient flushing strength, incomplete flushing etc., and achieving good application and popularization value.

IPC Classes  ?

• E03D 11/08 - Bowls with means producing a flushing water swirl
• E03D 11/06 - Bowls with downwardly-extending flanges

Abstract

A self-locking water level adjusting mechanism includes a partition plate, an adjusting clamping structure arranged on one side of the partition plate, and an adjusting lock. The adjusting clamping structure is slidably connected with the partition plate in a vertical direction. The adjusting lock is elastically connected with the partition plate through an elastic piece. The adjusting lock is clamped with the adjusting clamping structure under restoring force of the elastic piece.

IPC Classes  ?

• E03D 1/34 - Flushing valves for outletsArrangement of outlet valves

Abstract

A synchronous switch valve core with a voltage stabilizing function, comprising: a valve core housing (1), a valve core base (2), a flow regulating module, and a balancing hydraulic module. The flow regulating module is capable of cutting off a cold/hot water path before water enters a pressure balancing module, thus preventing high-temperature water from immersing the valve core, preventing the building of lime scale, protecting the valve core, and extending the service life; moreover, water flow can enter the pressure balancing module only after flowing through the flow regulating module, thus preventing the channeling of hot and cold, and obviating the need to install a check valve at a water intake elbow. By means of an optimized design with respect to the parts of the synchronous switch valve core, the synchronous valve core is transformed from a switch capable only of regulating flow into a switch not only capable of regulating flow but also capable of synchronized switching, and also capable of balancing the pressures within two channels, thus transforming a product equipped with the vale core from a complex channel into a simple channel, and obviating the need for separately providing a balancing module part; a valve body is structurally simple, has a shortened water path, and is inexpensive.

IPC Classes  ?

• F16K 17/26 - Excess-flow valves actuated by the difference of pressure between two places in the flow line acting directly on the cutting-off member operating in either direction
• F16K 11/00 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid
• F16K 11/074 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid with all movable sealing faces moving as one unit comprising only sliding valves with pivoted closure members with flat sealing faces
• F16K 39/04 - Devices for relieving the pressure on the sealing faces for sliding valves

Abstract

A water flow rate automatic control module includes a base, a valve body, a thermosensitive assembly, a diaphragm, wherein a temperature sensing part senses the temperature of passing cold water in real time; when the temperature of cold water is too low, the mixed water flow rate is slowed down, and more hot water is supplied to a thermostatic valve core assembly for mixing; when the temperature of cold water is too high, the mixed water flow rate is increased, and more cold water is supplied to the thermostatic valve core assembly for mixing. Therefore, the mixed water temperature range of the thermostatic valve core assembly can be ensured, and the problem of temperature adjustment failure or beyond the temperature difference caused by matching the thermostatic shower with a gas water heater is solved.

IPC Classes  ?

• G05D 23/02 - Control of temperature without auxiliary power with sensing element expanding and contracting in response to changes of temperature
• F16K 11/04 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid with all movable sealing faces moving as one unit comprising only lift valves
• F16K 31/00 - Operating meansReleasing devices
• G05D 23/13 - Control of temperature without auxiliary power by varying the mixing ratio of two fluids having different temperatures

Abstract

The invention relates to a water level adjusting mechanism having a self-locking function, comprising a partition, an adjusting engaging plate provided on one side of the partition, and an adjusting lock. The adjusting engaging plate is slidably connected to the partition in the longitudinal direction. The adjusting lock is flexibly connected to the partition via a flexibly element. The adjusting lock is engagedly connectedthe adjusting engaging plate under the rebound force of the flexible element. The structural design of the present invention is scientific and reasonable, convenient to operate, and stable in terms of performance, and allows the adjusting lock to be in a locked state with the adjusting engaging plate in the absence of an external force, so that the adjusting engaging plate is always located in a set position and cannot slide by escaping from the lock of the adjusting lock, thus preventing the adjusting engaging plate from being "dislodged" when not being used by a person, while working, and during transport, and ensuring a drainage valve to be precise and accurate in terms of water volume.

IPC Classes  ?

• E03D 1/34 - Flushing valves for outletsArrangement of outlet valves

Abstract

A water flow rate automatic control module, relating to the field of constant-temperature shower parts. The water flow rate automatic control module comprises: a base (1), a valve body (2), a heat-sensitive component (20), and a diaphragm (3); a temperature sensing unit (10) senses the temperature of passing cold water in real time; when the cold water temperature is low, a mixed water flow rate is slowed and more hot water is supplied to a constant-temperature valve core assembly (17) for mixing; when the cold water temperature is high, a mixed water flow rate is increased and more cold water is supplied to the constant-temperature valve core assembly for mixing. Therefore, the mixed water temperature range of the constant-temperature valve core assembly can be ensured, and the problem of a temperature adjustment failure or temperature out-of-tolerance generated by matching a constant-temperature shower with a gas water heater is solved.

IPC Classes  ?

• F16K 31/64 - Operating meansReleasing devices responsive to temperature variation
• F16K 11/04 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid with all movable sealing faces moving as one unit comprising only lift valves

Abstract

A synchronous switch valve core having a voltage regulating function, comprising: a valve core housing (1), a valve core base (2), a flow regulating module, and a balancing hydraulic module. The flow regulating module is capable of cutting off a cold/hot water path before water enters a pressure balancing module, thus preventing high-temperature water from immersing the valve core, preventing the buildup of lime scale, protecting the valve core, and extending the service life; moreover, water flow can enter the pressure balancing module only after flowing through the flow regulating module, thus preventing the channeling of hot and cold waters, and obviating the need to install a check valve at a water intake elbow. By means of an optimized design with respect to the parts of the synchronous switch valve core, the synchronous valve core is transformed from a switch capable only of regulating flow into a switch not only capable of regulating flow but also capable of synchronized switching, and also capable of balancing the pressures within two channels, thus transforming a product equipped with the vale core from a complex channel into a simple channel, and obviating the need for separately providing a balancing module part; a valve body is structurally simple, has a shortened water path, and is inexpensive.

IPC Classes  ?

• F16K 11/10 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid with two or more closure members not moving as a unit
• F16K 17/26 - Excess-flow valves actuated by the difference of pressure between two places in the flow line acting directly on the cutting-off member operating in either direction

Goods & Services

Flushing apparatus; water closets; toilets, portable; showers; hand-held showers; tap water faucets; level controlling valves in tanks; sanitary apparatus and installations; bath tubs for sitz baths; urinals [sanitary fixtures]; bath plumbing fixtures; bath installations; bath tubs; hydromassage bath apparatus; wash-hand bowls [parts of sanitary installations]; wash-hand basins [parts of sanitary installations]; heating lamps for bathing; toilet seats; toilet bowls. Bricks; ceramic tile; tiles, not of metal; tiles, not of metal, for building; wall tiles, not of metal, for building; floor tiles, not of metal. Showcases [furniture]; sideboards; cupboards; meat safes; covers for clothing [wardrobe]; washstands [furniture]; chests of drawers; kitchen cupboards.

Goods & Services

(1) Flushing tanks; water closets; toilets; showers; hand showers; tap water faucets; level controlling valves in tanks; bathroom fixtures; bath tubs for sitz baths; urinals; bath plumbing fixtures; bath installations; bath tubs; hydromassage bath apparatus; bathroom sinks; vanity top sinks; ceiling lights; heaters for baths; toilet seat; toilet bowls; refrigerating or freezing showcases (2) Bricks; ceramic tiles; paving tiles; fireproof tiles; glass tiles; ceramic wall tiles; ceramic floor tiles; floor tiles of wood; terra-cotta floor tiles; marble tile flooring. (3) Sideboards; cupboards; meat safes; wardrobes; bathroom furniture; chests of drawers; kitchen cabinets.

Goods & Services

Flushing apparatus; water closets; toilets, portable; showers; hand-held showers; tap water faucets; level controlling valves in tanks; sanitary apparatus and installations; bath tubs for sitz baths; urinals [sanitary fixtures]; bath plumbing fixtures; bath installations; bath tubs; hydromassage bath apparatus; wash-hand bowls [parts of sanitary installations]; wash-hand basins [parts of sanitary installations]; heating lamps for bathing; toilet seats; toilet bowls. Bricks; ceramic tile; tiles, not of metal; tiles, not of metal, for building; wall tiles, not of metal, for building; floor tiles, not of metal. Showcases [furniture]; sideboards; cupboards; meat safes; covers for clothing [wardrobe]; washstands [furniture]; chests of drawers; kitchen cupboards. Clothing stretchers; clothes-pins; drying racks for laundry; toilet paper holders.

Goods & Services

Flushing apparatus; water closets; toilets, portable; showers; hand-held showers; tap water faucets; level controlling valves in tanks; sanitary apparatus and installations; bath tubs for sitz baths; urinals [sanitary fixtures]; bath plumbing fixtures; bath installations; bath tubs; hydromassage bath apparatus; wash-hand bowls [parts of sanitary installations]; wash-hand basins [parts of sanitary installations]; heating lamps for bathing; toilet seats; toilet bowls. Bricks; ceramic tile; tiles, not of metal; tiles, not of metal, for building; wall tiles, not of metal, for building; floor tiles, not of metal. Showcases [furniture]; sideboards; cupboards; meat safes; covers for clothing [wardrobe]; washstands [furniture]; chests of drawers; kitchen cupboards.

Goods & Services

Flushing apparatus; water closets; toilets, portable; showers; hand-held showers; tap water faucets; level controlling valves in tanks; sanitary apparatus and installations; bath tubs for sitz baths; urinals [sanitary fixtures]; bath plumbing fixtures; bath installations; bath tubs; hydromassage bath apparatus; wash-hand bowls [parts of sanitary installations]; wash-hand basins [parts of sanitary installations]; heating lamps for bathing; toilet seats; toilet bowls. Bricks; ceramic tile; tiles, not of metal; tiles, not of metal, for building; wall tiles, not of metal, for building; floor tiles, not of metal.

Goods & Services

Flushing apparatus; water closets; toilets, portable; showers; hand-held showers; tap water faucets; level controlling valves in tanks; sanitary apparatus and installations; bath tubs for sitz baths; urinals [sanitary fixtures]; bath plumbing fixtures; bath installations; bath tubs; hydromassage bath apparatus; wash-hand bowls [parts of sanitary installations]; wash-hand basins [parts of sanitary installations]; heating lamps for bathing; toilet seats; toilet bowls.

Goods & Services

Flushing apparatus; water closets; toilets, portable; showers; hand-held showers; tap water faucets; level controlling valves in tanks; sanitary apparatus and installations; bath tubs for sitz baths; urinals [sanitary fixtures]; bath plumbing fixtures; bath installations; bath tubs; hydromassage bath apparatus; wash-hand bowls [parts of sanitary installations]; wash-hand basins [parts of sanitary installations]; heating lamps for bathing; toilet seats; toilet bowls. Bricks; ceramic tile; tiles, not of metal; tiles, not of metal, for building; wall tiles, not of metal, for building; floor tiles, not of metal. Showcases [furniture]; sideboards; cupboards; meat safes; covers for clothing [wardrobe]; washstands [furniture]; chests of drawers; kitchen cupboards.

Goods & Services

Flushing apparatus, namely, flush levers, automatic flush valves for toilets, flush cistern tank being toilet cisterns, flush fittings being flush handles for toilets; Water closets; Toilets, portable; Showers; Hand-held showers; Tap water faucets; plumbing fittings, namely, level controlling valves in tanks; Sanitary apparatus and installations, namely, toilet pans being structural parts of toilets, toilet cistern tank, bidet, wash basin being parts of sanitary installations, sink pedestal, urinal; bath tubs for sitz baths; urinals being sanitary fixtures; Bath plumbing fixtures, namely, spouts for affixing on walls for baths, bath tub jets, shower column being shower panels, shower sprayers; bath installations; Bath tubs; hydromassage bath apparatus; Wash-hand bowls in the nature of basins being parts of sanitary installations; wash-hand basins being parts of sanitary installations; Heating installations, namely, heating lamps for bath; Toilet seats; toilet bowls Bricks; ceramic tiles; Tiles, not of metal; Tiles, not of metal, for building; Wall tiles, not of metal; floor tiles, not of metal Furniture, namely, showcases; Sideboards; Cupboards; meat safes; Covers for clothing, namely, wardrobes; Washstands; Chests of drawers; Kitchen cabinets

Abstract

Disclosed is a toilet, comprising a toilet body (1), a flow-splitting plate (2) fixed at a front end of a main water channel outlet of the toilet body (1), and a flow-blocking plate (3) fixed at a front end of the flow-splitting plate (2), wherein a water inlet (4) is provided in the middle of the flow-splitting plate (2), and an inner side of the flow-blocking plate (3) is provided, at positions close to two sides of the flow-splitting plate (2), with water-blocking protruding blocks (5) which extend from a top end to a bottom end of the flow baffle (3).

IPC Classes  ?

• E03D 11/06 - Bowls with downwardly-extending flanges
• E03D 9/00 - Sanitary or other accessories for lavatories
• E03D 11/13 - Parts or details of bowlsSpecial adaptations of pipe joints or couplings for use with bowls

Goods & Services

(1) Water flushing installations, namely, flushing toilet tanks, flushing levers, cistern, valves for controlling water level in toilet tanks, toilet tank covers; bath and shower fittings; bath tubs; plumbing fixtures; urinals; basins, namely, hand basins, wash basins; toilets; bidets; showers; toilet seats; toilet bowls; valves for controlling water level in toilet tanks; hydrants.

Goods & Services

Toilets; portable toilets; toilet seats; flushing toilet tanks; level controlling valves in toilet tanks; toilet bowls; bath tubs; lavatory basins; washbasins; bath fittings and installations, namely, bath tub jets; hot air bath fittings, namely, hot air blowers; sanitary apparatus and installations, namely, pipes being parts of sanitary facilities; showers; bath tubs for sitz baths; flushing apparatus, namely, flushing levers
