A support arrangement for the removable attachment of an additional unit to a support region of a construction machine includes a first support assembly to be fixedly attached to the support region of the construction machine, a second support assembly pivotable about a pivot axis and displaceable in a displacement direction on the first support assembly for movement between an additional unit operating position and an additional unit mounting position, and a coupling assembly for removably coupling an additional unit to the second support assembly on a support body of the second support assembly.
B60R 11/02 - Arrangements for holding or mounting articles, not otherwise provided for for radio sets, television sets, telephones, or the likeArrangement of controls thereof
B60R 11/00 - Arrangements for holding or mounting articles, not otherwise provided for
E01C 19/26 - Rollers thereforSuch rollers usable also for compacting soil self-propelled or fitted to road vehicles
A ground compactor comprises a head-up display (54) associated with at least one substrate observation window (36), wherein the head-up display (54) is designed to display processing condition information representing a processing condition of the region (26) of the substrate (24) to be compacted lying in front of the ground compactor (10) in the direction of movement (B) of the ground compactor,
wherein the processing condition information comprises:
a perspective projection of passes (58, 58′) already made and/or still to be made by the ground compactor (10) over the substrate (24) to be compacted, in the region (26) of the substrate (24) to be compacted, which region lies in front of the ground compactor (10) in the direction of movement (B) of the ground compactor,
or/and
a perspective projection of the region (26) of the substrate (24) to be compacted that lies in front of the ground compactor (10) in the direction of movement (B) of the ground compactor with a representation distinguishing regions (62, 62′) with a different condition of the substrate (24) to be compacted.
E01C 19/28 - Vibrated rollers or rollers subjected to impacts, e.g. hammering blows
E01C 23/01 - Devices or auxiliary means for setting-out or checking the configuration of new surfacing, e.g. templates, screed supportsApplications of apparatus for measuring, indicating, or recording the surface configuration of existing surfacing, e.g. profilographs
A hydraulic drive system 24, in particular for a self-propelled construction machine, comprises at least one hydraulic pump (28) drivable by a drive unit (26) for conveying hydraulic fluid, a hydraulic circuit (30) receiving hydraulic fluid conveyed by the at least one hydraulic pump (28) and returning hydraulic fluid to the at least one hydraulic pump, at least one hydraulic motor (32, 34) supplied via the hydraulic circuit (30) with hydraulic fluid conveyed by the at least one hydraulic pump (28), a discharge line arrangement (52) for discharging hydraulic fluid from the hydraulic circuit (30) to a hydraulic fluid reservoir (42), at least one flushing line (64) supplied from the hydraulic circuit (30) for flushing at least one hydraulic component of the hydraulic drive system (40) with hydraulic fluid, wherein at least one flushing line (64) branches off from the discharge line arrangement (52) and/or forms a line region of the discharge line arrangement (52).
F15B 15/18 - Combined units comprising both motor and pump
F15B 13/02 - Fluid distribution or supply devices characterised by their adaptation to the control of servomotors
F15B 21/00 - Common features of fluid actuator systemsFluid-pressure actuator systems or details thereof, not covered by any other group of this subclass
4.
GROUND COMPACTION SYSTEM FOR COMPACTING ASPHALT MATERIAL AND METHOD FOR COMPACTING ASPHALT MATERIAL
A ground compaction system for compacting asphalt material includes at least one ground compactor to be moved on the asphalt material to be compacted and at least one display unit with a display for displaying compaction operation information related to a ground compaction process to be performed. The at least one display unit is configured to display on the display at least one reversal limit related to a movement of the at least one ground compactor on the asphalt material to be compacted, and the at least one reversal limit indicates a limit for the movement of the at least one ground compactor in a direction of movement.
A ground crushing machine for crushing a solid ground comprises a machine frame (12) that can be moved on the ground (38) to be crushed by means of a chassis and a crushing unit (24) supported on the machine frame (12), comprising a crushing assembly (42) to be brought into contact with the ground (38) in order to crush the ground (38), and a crushing assembly drive (52) for generating a crushing force acting on the crushing assembly (42) for crushing the ground (38). The crushing assembly drive (52) is configured to generate a crushing force with a periodically varying force magnitude and a substantially unchangeable force direction.
E01C 23/12 - Devices or arrangements for working the finished surfaceDevices for repairing the surface of damaged paving for taking-up, tearing-up, or breaking-up paving
A method for compacting asphalt material (A) by means of at least one soil compactor (10) having at least one compactor roller with a motion generation arrangement assigned to the same, comprising the measures:
a) detection of an asphalt temperature of the asphalt material (A) to be compacted,
b) static compaction of the asphalt material (A) with a deactivated motion generation arrangement of the at least one compactor roller, if the asphalt temperature lies above an upper threshold temperature (O),
c) static compaction of the asphalt material (A) with a deactivated motion generation arrangement of the at least one compactor roller, if the asphalt temperature lies below a lower threshold temperature (U),
wherein the upper threshold temperature (O) and/or the lower threshold temperature (U) is/are set depending on at least one surroundings parameter (T) influencing the cooling behavior of the asphalt material to be compacted.
