Abstract

Provided is a paintbrush cleaning device having: a container arranged to hold a cleaning liquid; a first twisted-in-wire brush rotatably arranged in the container; a second twisted-in-wire brush rotatably arranged in the container; and a drivetrain arranged to rotate the brushes in contra-rotational sync. Each of the first and second brushes comprises: twisted stem wires defining a central longitudinal axis of rotation of the brush, and a plurality of bristles of equal length held by the twisted stem wires. The first and second brushes are arranged such that the axes of rotation are fixed in relation to the container and parallel to each other such that a paintbrush can be moved through an opening at a top of the container and in between the axes of rotation to be cleaned by the brushes when rotating.

IPC Classes  ?

• B44D 3/00 - Accessories or implements for use in connection with painting or artistic drawing, not otherwise provided forMethods or devices for colour determination, selection, or synthesis, e.g. use of colour tables
• A46B 3/16 - Brushes characterised by the way in which the bristles are fixed or joined in or on the brush body or carrier by wires or other anchoring means, specially for U-shaped bristle tufts
• A46B 13/00 - Brushes with driven brush bodies
• A46B 13/04 - Brushes with driven brush bodies power-driven with reservoir or other means for supplying substances
• A46B 17/06 - Devices for cleaning brushes after use

IPC Classes  ?

• A46B 17/06 - Devices for cleaning brushes after use
• B44D 3/00 - Accessories or implements for use in connection with painting or artistic drawing, not otherwise provided forMethods or devices for colour determination, selection, or synthesis, e.g. use of colour tables

Abstract

The present disclosure relates to a paintbrush cleaning device (10), comprising: a container (1) arranged to hold a cleaning liquid; a first twisted-in-wire brush (2a), rotatably arranged in the container; a second twisted-in-wire brush (2b), rotatably arranged in the container; and a drivetrain (3) arranged to rotate the brushes (2) in contra-rotational sync. Each of the first and second brushes comprises: twisted stem wires (4) defining a central longitudinal axis (L) of rotation of the brush, and a plurality of bristles of equal length held by the twisted stem wires. The first and second brushes are arranged such that the axes of rotation are fixed in relation to the container and parallel to each other such that a paintbrush can be moved through an opening (6) at a top (7) of the container and in between the axes of rotation to be cleaned by the brushes when rotating.

IPC Classes  ?

• B44D 3/00 - Accessories or implements for use in connection with painting or artistic drawing, not otherwise provided forMethods or devices for colour determination, selection, or synthesis, e.g. use of colour tables
• A46B 17/06 - Devices for cleaning brushes after use

Goods & Services

Cutting, drilling, grinding, sharpening and surface treatment hand tools. Containers adapted for paintbrushes.

Goods & Services

Hand-operated cleaning tool, namely, sanding blocks and paint scrapers for the surface treatment of paintbrushes Containers adapted for paintbrushes

Goods & Services

Cutting, drilling, grinding, sharpening and surface treatment hand tools. Containers adapted for brushes for use in washing.
