1.

SINGLE HEIGHT ADJUSTMENT AND CONTROL ASSEMBLY FOR WALK-BEHIND OUTDOOR POWER EQUIPMENT


Application Number 19306618
Status Pending
Filing Date 2025-08-21
First Publication Date 2025-12-25
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Laurin, Robert S.
  • Lynch, E. Mark
  • Camenga, Derrick R.

Abstract

Outdoor power equipment includes a frame, a power head, a rear wheel, a front wheel coupled to a front wheel bracket, and a wheel height adjustment mechanism. The wheel height adjustment mechanism includes a rear bell crank pivotably coupled between the frame and the rear wheel, a front bell crank pivotably coupled between the frame and the front wheel bracket, a linkage extending between the rear bell crank and the front bell crank, and a front pivoting linkage coupled between the frame and the front wheel bracket.

IPC Classes  ?

  • A01D 34/74 - Cutting-height adjustment
  • A01D 34/68 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis hand-guided by a walking operator with motor driven cutters or wheels
  • A01D 34/69 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis hand-guided by a walking operator with motor driven cutters or wheels with motor driven wheels
  • A01D 101/00 - Lawn-mowers

2.

BATTERY SYSTEM WITH PARALLEL JOINING PROTECTION


Application Number 19308826
Status Pending
Filing Date 2025-08-25
First Publication Date 2025-12-25
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Marshall, Michael
  • Schmalz, Jacob

Abstract

A battery pack includes a housing having a positive terminal and a negative terminal. Battery cells are located within the housing and are selectively coupled to the positive terminal and coupled to the negative terminal. A battery management system is located within the housing and is configured to operate a first switch within the housing to selectively couple the battery cells and the positive terminal. A bleed circuit is electrically coupled between the positive terminal and the negative terminal. The bleed circuit includes a resistor and a second switch to selectively couple the positive terminal to the negative terminal. The battery management system is configured to open the first switch and close the second switch and measure a voltage drop across the resistor to detect a presence and type of voltage source connected to the positive terminal.

IPC Classes  ?

  • H01M 10/42 - Methods or arrangements for servicing or maintenance of secondary cells or secondary half-cells
  • H01M 10/48 - Accumulators combined with arrangements for measuring, testing or indicating the condition of cells, e.g. the level or density of the electrolyte
  • H01M 50/296 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders characterised by terminals of battery packs
  • H01M 50/505 - Interconnectors for connecting terminals of adjacent batteriesInterconnectors for connecting cells outside a battery casing comprising a single busbar
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries
  • H02J 7/34 - Parallel operation in networks using both storage and other DC sources, e.g. providing buffering

3.

Battery pack connector


Application Number 29884298
Grant Number D1106072
Status In Force
Filing Date 2023-02-09
First Publication Date 2025-12-16
Grant Date 2025-12-16
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Schneiker, John
  • Busse, James M.
  • Eernisse, Ross
  • Zeidler, Nick

4.

BATTERY RETROFIT KIT


Application Number 19222907
Status Pending
Filing Date 2025-05-29
First Publication Date 2025-12-04
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Avery, Stephen Bryan
  • Jasinski, Nathan

Abstract

A battery retrofit kit for a golf cart includes a base having a mounting surface, a lithium-ion battery supported on the mounting surface, a battery charger coupled to the base, and a retrofit controller coupled to the base.

IPC Classes  ?

  • B60L 50/64 - Constructional details of batteries specially adapted for electric vehicles
  • B60R 16/02 - Electric or fluid circuits specially adapted for vehicles and not otherwise provided forArrangement of elements of electric or fluid circuits specially adapted for vehicles and not otherwise provided for electric
  • H01M 10/0525 - Rocking-chair batteries, i.e. batteries with lithium insertion or intercalation in both electrodesLithium-ion batteries
  • H01M 10/46 - Accumulators structurally combined with charging apparatus
  • H01M 50/249 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders specially adapted for aircraft or vehicles, e.g. cars or trains
  • H01M 50/298 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders characterised by the wiring of battery packs

5.

SYSTEMS AND METHODS FOR AN ELECTRIC DRIVE MOTOR ASSEMBLY


Application Number CN2025098759
Publication Number 2025/247409
Status In Force
Filing Date 2025-06-03
Publication Date 2025-12-04
Owner BRIGGS & STRATTON, LLC (USA)
Inventor Zeiler, Jeffery

Abstract

An electric drive motor assembly includes a housing assembly a motor housing and a gearbox cover. The electric drive motor assembly further includes an electric motor at least partially received within the motor housing and including a motor shaft, an output shaft, a gear train arranged within the gearbox cover, and coupled between the motor shaft and the output shaft. The gear train includes driving gear rotatably coupled to the motor shaft. An inspection cap is removably coupled to the gearbox cover so that when the inspection cap is removed, the driving gear is externally visible.

IPC Classes  ?

  • H02K 7/116 - Structural association with clutches, brakes, gears, pulleys or mechanical starters with gears

6.

Oil filter


Application Number 29796711
Grant Number D1103333
Status In Force
Filing Date 2021-06-25
First Publication Date 2025-11-25
Grant Date 2025-11-25
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Hellman, Adam J.
  • Schneiker, John

7.

Motor


Application Number 29905334
Grant Number D1100829
Status In Force
Filing Date 2023-10-19
First Publication Date 2025-11-04
Grant Date 2025-11-04
Owner Briggs & Stratton, LLC (USA)
Inventor Zeidler, Nicholas

8.

Motor


Application Number 29905333
Grant Number D1100828
Status In Force
Filing Date 2023-10-19
First Publication Date 2025-11-04
Grant Date 2025-11-04
Owner Briggs & Stratton, LLC (USA)
Inventor Zeidler, Nicholas

9.

BATTERY SYSTEM AND RELATED MANAGEMENT SYSTEM


Application Number 19261602
Status Pending
Filing Date 2025-07-07
First Publication Date 2025-10-30
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Harvey, Kyle
  • Johnson, Todd
  • Noller, Mark
  • Schmalz, Jacob
  • Zeidler, Nick

Abstract

A battery pack includes a battery housing, a plurality of battery cells enclosed within the battery housing, a battery connector including a plurality of terminals, a near-field communication (NFC) tag reader, and a battery management system in communication with the NFC tag reader. The battery management system is configured to detect, via the NFC tag reader, a type of equipment connected to the battery connector, and change a battery electrical output parameter based on the type of equipment.

IPC Classes  ?

  • B60L 50/60 - Electric propulsion with power supplied within the vehicle using propulsion power supplied by batteries or fuel cells using power supplied by batteries
  • H01M 50/509 - Interconnectors for connecting terminals of adjacent batteriesInterconnectors for connecting cells outside a battery casing characterised by the type of connection, e.g. mixed connections
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries

10.

ZERO TURN RADIUS MOWER WITH CUTTING BLADE CONTROL


Application Number 19261803
Status Pending
Filing Date 2025-07-07
First Publication Date 2025-10-30
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Koenen, Robert J.

Abstract

A zero turn radius (ZTR) mower includes a pair of rear drive wheels, a mowing deck including a plurality of cutting blades, an electric storage battery, a pair of electric wheel motors each configured to rotate one of the rear drive wheels, a plurality of electric blade motors each configured to rotate one of the plurality of cutting blades, and a master controller configured to control a rotational speed of each of the pair of wheel motors and each of the plurality of blade motors, the master controller configured send voltage pulses to the plurality of blade motors and to adjust the rotational speeds of the plurality of blade motors separately such that the cutting blades selectively rotate at different rotational speeds.

IPC Classes  ?

  • A01D 34/00 - MowersMowing apparatus of harvesters
  • A01D 34/66 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis mounted on a vehicle, e.g. a tractor, or drawn by an animal or a vehicle with two or more cutters
  • A01D 34/78 - Driving mechanisms for the cutters electric
  • A01D 34/82 - Other details
  • A01D 69/02 - Driving mechanisms or parts thereof for harvesters or mowers electric
  • A01D 101/00 - Lawn-mowers

11.

MULTI-BAY BATTERY CHARGER


Application Number US2025026499
Publication Number 2025/227107
Status In Force
Filing Date 2025-04-25
Publication Date 2025-10-30
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Steadman, Jason
  • Jaskowiak, Ryan
  • Metcalf, Bryce
  • Moore, Nick
  • Hillenbrand, Emma
  • Mergener, Matthew
  • Siegler, David

Abstract

A battery charger includes a first charging bay including a first charging dock configured to be physically and electrically coupled to a first battery, a second charging bay including a second charging dock configured to be physically and electrically coupled to a second battery, and a first junction box electrically coupled to and separating the first charging dock and the second charging dock. A first front side of the first charging dock is configured to couple to the first battery, a second front side of the second charging dock is configured to couple to the second battery, and the first junction box is directly coupled to a first back side of the first charging dock and a second back side of the second charging dock.

IPC Classes  ?

  • H01M 50/204 - Racks, modules or packs for multiple batteries or multiple cells
  • B60L 53/30 - Constructional details of charging stations
  • H01M 10/44 - Methods for charging or discharging
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries

12.

VANGUARD


Application Number 019265668
Status Pending
Filing Date 2025-10-24
Owner Briggs & Stratton, LLC (USA)
NICE Classes  ? 04 - Industrial oils and greases; lubricants; fuels

Goods & Services

Engine oils; automotive engine oils; lubricating oils; motor oils; lubricants; mineral oils; synthetic oils; industrial oils; gear oils; industrial greases, waxes and fluids.

13.

OUTDOOR POWER EQUIPMENT SUSPENSION SYSTEM


Application Number 19258158
Status Pending
Filing Date 2025-07-02
First Publication Date 2025-10-23
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Krajewski, Christopher
  • Laurin, Robert S.
  • Lynch, E. Mark

Abstract

A front independent suspension assembly for outdoor power equipment includes a first joint, a first wheel coupled to the joint, a first longitudinal arm pivotably coupled to the joint, a first lateral arm pivotably coupled to the joint, and a second lateral arm pivotably coupled to the joint. The second lateral suspension arranged substantially parallel to the first lateral suspension arm. The pivotal coupling between the joint and each of the first longitudinal arm, the first lateral arm, and the second lateral arm enables the first wheel to independently displace about a vertical axis

IPC Classes  ?

  • B60G 3/20 - Resilient suspensions for a single wheel with two or more pivoted arms, e.g. parallelogram all arms being rigid
  • A01D 34/66 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis mounted on a vehicle, e.g. a tractor, or drawn by an animal or a vehicle with two or more cutters
  • A01D 34/82 - Other details
  • A01D 67/00 - Undercarriages or frames specially adapted for harvesters or mowersMechanisms for adjusting the framePlatforms
  • A01D 101/00 - Lawn-mowers
  • B60G 3/26 - Means for maintaining substantially-constant wheel camber during suspension movement
  • B60G 15/06 - Resilient suspensions characterised by arrangement, location, or type of combined spring and vibration- damper, e.g. telescopic type having mechanical spring and fluid damper

14.

MURRAY


Serial Number 99455940
Status Pending
Filing Date 2025-10-22
Owner BRIGGS & STRATTON, LLC ()
NICE Classes  ? 07 - Machines and machine tools

Goods & Services

Multi-purpose high pressure washers and replacement parts therefor

15.

LAWN MOWER WITH PIVOTAL ROCKER ARM ASSEMBLY


Application Number 19234816
Status Pending
Filing Date 2025-06-11
First Publication Date 2025-10-02
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Johnson, Todd
  • Krajewski, Christopher
  • Zeidler, Nicholas
  • Schmalz, Jacob
  • Dandridge, Bryan Keith
  • Jaskowiak, Ryan
  • Zurawski, Matthew Steven
  • Hahn, Ryan

Abstract

An outdoor power equipment device, such as a lawn mower, includes a main chassis having first and second pivot joints, a first rocker arm having a caster wheel on a first end portion and a drive wheel on a second end portion, and a second rocker arm having a caster wheel on a first end portion and a drive wheel on a second end portion, wherein the first rocker arm and the second rocker arm are independently pivotally coupled to the respective first and second pivot joints of the main chassis at a location between the caster wheels and the drive wheels.

IPC Classes  ?

  • A01D 34/66 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis mounted on a vehicle, e.g. a tractor, or drawn by an animal or a vehicle with two or more cutters
  • A01D 34/00 - MowersMowing apparatus of harvesters
  • A01D 34/71 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis with means for discharging mown material
  • A01D 34/78 - Driving mechanisms for the cutters electric
  • A01D 34/82 - Other details
  • A01D 67/04 - Seats
  • A01D 101/00 - Lawn-mowers
  • B60G 15/06 - Resilient suspensions characterised by arrangement, location, or type of combined spring and vibration- damper, e.g. telescopic type having mechanical spring and fluid damper
  • B60K 1/02 - Arrangement or mounting of electrical propulsion units comprising more than one electric motor
  • B60K 7/00 - Disposition of motor in, or adjacent to, traction wheel
  • B60K 35/00 - Instruments specially adapted for vehiclesArrangement of instruments in or on vehicles
  • B60K 35/10 - Input arrangements, i.e. from user to vehicle, associated with vehicle functions or specially adapted therefor
  • B60K 35/22 - Display screens
  • B60N 2/015 - Attaching seats directly to vehicle chassis
  • B62D 1/04 - Hand wheels
  • B62D 15/02 - Steering position indicators
  • B62D 21/02 - Understructures, i.e. chassis frame on which a vehicle body may be mounted comprising longitudinally or transversely arranged frame members
  • B62D 21/11 - Understructures, i.e. chassis frame on which a vehicle body may be mounted with resilient means for suspension
  • E01H 5/06 - Apparatus propelled by animal or engine powerApparatus propelled by hand with driven dislodging or conveying elements, e.g. conveying pneumatically dislodging essentially by non-driven elements, e.g. scraper blades

16.

ELECTRIC MOWER


Application Number 19233459
Status Pending
Filing Date 2025-06-10
First Publication Date 2025-09-25
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Dandridge, Bryan Keith
  • Funke, Scott
  • Schmalz, Jacob
  • Noller, Mark

Abstract

A lawnmower includes an electric motor configured to operate a component of the lawnmower, a user interface configured to display operational parameters of the lawnmower, and a controller configured to receive input from an operator of the lawnmower via the user interface, the input comprising a selection of an operational mode of a plurality of operational modes, and control the electric motor differently in response to a selection of each operational mode, wherein the electric motor is connected to the controller via a network communication bus.

IPC Classes  ?

17.

ENGINE COOLING SYSTEM


Application Number US2025019777
Publication Number 2025/193950
Status In Force
Filing Date 2025-03-13
Publication Date 2025-09-18
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Martinek, Matthew
  • Paul, Brian
  • Balzar, Rodney
  • Martinek, Christopher

Abstract

An engine includes an engine block including a first cylinder and a crankshaft defining a crankshaft axis, a first cylinder head coupled to the first cylinder and a blower assembly coupled to the engine block. The blower assembly includes a blower housing and a fan configured to draw air into a blower housing. The blower housing includes a first duct extending in a direction substantially tangential to an outer end of the fan, the first duct comprising a lower surface and an upper surface and configured to receive air from the fan, and a second duct fluidly coupled to the first duct and extending substantially parallel to the crankshaft axis, the second duct configured to direct air from the first duct toward the first cylinder head.

IPC Classes  ?

  • F01P 5/06 - Guiding or ducting air to or from ducted fans
  • F02F 1/06 - Shape or arrangement of cooling finsFinned cylinders
  • F01P 1/08 - Arrangements for cooling other engine or machine parts for cooling intake or exhaust valves
  • F02F 1/04 - CylindersCylinder heads having cooling means for air cooling
  • F02F 1/34 - Finned cylinder heads with means for directing or distributing cooling medium
  • F01P 5/04 - Pump-driving arrangements
  • F01P 1/02 - Arrangements for cooling cylinders or cylinder heads, e.g. ducting cooling-air from its pressure source to cylinders or along cylinders
  • F02F 1/00 - CylindersCylinder heads
  • F02F 1/28 - Cylinder heads having cooling means for air cooling
  • F02F 1/32 - Finned cylinder heads the cylinder heads being of overhead-valve type

18.

CELL MODULE ASSEMBLIES AND METHODS OF MANUFACTURING CELL MODULE ASSEMBLIES


Application Number 19202877
Status Pending
Filing Date 2025-05-08
First Publication Date 2025-08-21
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zeiler, Jeffrey M.
  • Busse, James Michael
  • Schmalz, Jacob

Abstract

A cell module assembly includes a first frame having a first plurality of pockets, a second frame spaced apart from the first frame and having a second plurality of pockets, a plurality of lithium-ion battery cells coupled to and extending between the second frame and the first frame, a first collector plate electrically connected to the plurality of lithium-ion battery cells and coupled to the first frame by a first curable adhesive, and a second collector plate electrically connected to the plurality of lithium-ion battery cells and coupled to the second frame by a second curable adhesive. Each one of the plurality of lithium-ion battery cells is received within a respective one of the first plurality of pockets and a respective one of the second plurality of pockets.

IPC Classes  ?

  • H01M 50/213 - Racks, modules or packs for multiple batteries or multiple cells characterised by their shape adapted for cells having curved cross-section, e.g. round or elliptic
  • H01M 50/264 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders with fastening means, e.g. locks for cells or batteries, e.g. straps, tie rods or peripheral frames
  • H01M 50/502 - Interconnectors for connecting terminals of adjacent batteriesInterconnectors for connecting cells outside a battery casing
  • H01M 50/503 - Interconnectors for connecting terminals of adjacent batteriesInterconnectors for connecting cells outside a battery casing characterised by the shape of the interconnectors
  • H01M 50/512 - Connection only in parallel

19.

HYBRID LIGHT TOWER


Application Number 19054338
Status Pending
Filing Date 2025-02-14
First Publication Date 2025-08-14
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Grasz, Andy
  • Joestgen, Andrew
  • Shoemaker, Tony
  • Erickson, Melissa
  • Metcalf, Bryce
  • Behrendt, Eric
  • Dooley, David
  • Mcdermott, Ryan

Abstract

A hybrid light tower includes an engine, a mast, a generator configured to be driven by the engine, a battery coupled to the generator, a light assembly having a light, and a controller in communication with the battery, the engine, and the light assembly. The controller is configured to operate in a hybrid mode where the controller is configured to monitor a cell voltage of the battery, determine if the cell voltage of the battery is below a charging threshold, upon determining that the cell voltage of the battery is below the charging threshold, start the engine and charge the battery in a constant current mode, while charging in the constant current mode, determine if the cell voltage is above a constant voltage threshold, and upon determining that the cell voltage is above a constant voltage threshold, charge the battery in a constant voltage mode.

IPC Classes  ?

  • F21L 13/00 - Electric lighting devices with built-in electric generators
  • F21L 4/08 - Electric lighting devices with self-contained electric batteries or cells characterised by means for in situ recharging of the batteries or cells
  • F21L 14/04 - Electric lighting devices without a self-contained power source, e.g. for mains connection carried on wheeled supports
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries
  • H02J 7/16 - Regulation of the charging current or voltage by variation of field

20.

VERTICALLY STORABLE ENGINE AND MOWER


Application Number 19182899
Status Pending
Filing Date 2025-04-18
First Publication Date 2025-07-31
Owner BRIGGS & STRATTON, LLC (USA)
Inventor Schmalz, Jacob J.

Abstract

A gasoline powered engine configured to operate in a substantially horizontal orientation and to be stored in a generally vertical orientation without leaking of fluid contained in the gasoline powered engine may include an oil sump and a first oil drain port extending in a first direction through a first wall of the sump. The first wall forms a bottom of the sump when the engine is in the vertical orientation.

IPC Classes  ?

  • F01M 11/04 - Filling or draining lubricant of or from machines or engines
  • A01D 34/68 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis hand-guided by a walking operator with motor driven cutters or wheels
  • A01D 34/81 - CasingsHousings
  • A01D 34/82 - Other details
  • A01D 69/12 - Lubrication
  • A01D 101/00 - Lawn-mowers
  • F01M 11/00 - Component parts, details, or accessories, not provided for in, or of interest apart from, groups
  • F01M 11/06 - Means for keeping lubricant level constant or for accommodating movement or position of machines or engines
  • F02B 63/02 - Adaptations of engines for driving pumps, hand-held tools or electric generatorsPortable combinations of engines with engine-driven devices for hand-held tools
  • F02B 77/00 - Component parts, details, or accessories, not otherwise provided for

21.

MOTOR CONTROLLER MODULE


Application Number 19025514
Status Pending
Filing Date 2025-01-16
First Publication Date 2025-07-24
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Schulenberg, David
  • Schmalz, Jacob

Abstract

A controller module includes an enclosure including an inner wall defining a volume, a plurality of motor controllers, each motor controller comprising a printed circuit board (PCB) having a first side and a second side opposite the first side, a plurality of transistors located on the first side, and a plurality of outputs located on the second side. The first side of the PCB is positioned adjacent to the inner wall of the enclosure to allow heat generated by the motor controller to dissipate via the enclosure.

IPC Classes  ?

  • H02P 5/52 - Arrangements specially adapted for regulating or controlling the speed or torque of two or more electric motors for speed regulation of two or more dynamo-electric motors in relation to one another additionally providing control of relative angular displacement
  • G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]
  • H02P 4/00 - Arrangements specially adapted for regulating or controlling the speed or torque of electric motors that can be connected to two or more different electric power supplies
  • H02P 6/14 - Electronic commutators

22.

CO GUARD


Application Number 241110600
Status Pending
Filing Date 2025-07-11
Owner Briggs & Stratton, LLC (USA)
NICE Classes  ? 09 - Scientific and electric apparatus and instruments

Goods & Services

(1) Carbon monoxide detectors, alarms, and automatic shutdown systems for shutting down the generator when harmful levels of carbon monoxide are detected, all sold as an integral component of electric generators.

23.

HYBRID LIGHT TOWER


Application Number 19038103
Status Pending
Filing Date 2025-01-27
First Publication Date 2025-05-29
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Avery, Stephen Bryan
  • Brunelli, Brian
  • Jones, Dave
  • Grasz, Andrew
  • Booth, Cole

Abstract

A hybrid light tower includes an engine, a generator configured to be driven by the engine, a battery pack, a mast, a light assembly having a plurality of lights, and a controller. The generator is configured to produce electrical power. The battery pack is electrically coupled to the generator to receive the electrical power from the generator to charge the battery pack. The light assembly is coupled to the mast and the lights are electrically coupled to the battery pack to receive electrical power from the battery pack. The controller is configured to receive a commanded power load of the light assembly, determine if the commanded power load is greater than the electrical power output by the generator, and in response to determining that the commanded power load is greater than the electrical power output by the generator, instruct the engine to increase speed.

IPC Classes  ?

  • F21L 14/04 - Electric lighting devices without a self-contained power source, e.g. for mains connection carried on wheeled supports
  • F21V 21/22 - Adjustable mountings telescopic
  • F21W 131/10 - Outdoor lighting

24.

USER-SCALABLE POWER UNIT INCLUDING REMOVABLE BATTERY PACKS


Application Number 19029964
Status Pending
Filing Date 2025-01-17
First Publication Date 2025-05-22
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Koenen, Robert John
  • Schmalz, Jacob
  • Liu, Albert
  • Zeidler, Nick
  • Funke, Scott
  • Procknow, David

Abstract

A riding lawn mower includes a pair of rear drive wheels, a pair of front wheels, a deck positioned between the pair of front wheels and the pair of rear drive wheels, a rotatable cutting blade. a plurality of battery packs removably coupled to the riding lawn mower and structured to provide power to the riding lawn mower, and a battery management system configured to control a plurality of switching elements associated with the plurality of battery packs. The plurality of switching elements configured to control a current flow from each of the plurality of battery packs. The battery management system comprises a master battery management system configured to issue control commands to a plurality of slave battery management systems. Each of the plurality of slave battery management systems is configured to internally control operation of one of the plurality of battery packs.

IPC Classes  ?

  • B60K 1/04 - Arrangement or mounting of electrical propulsion units of the electric storage means for propulsion
  • A01D 69/02 - Driving mechanisms or parts thereof for harvesters or mowers electric
  • B60L 50/60 - Electric propulsion with power supplied within the vehicle using propulsion power supplied by batteries or fuel cells using power supplied by batteries
  • B60L 53/80 - Exchanging energy storage elements, e.g. removable batteries
  • B60L 58/22 - Balancing the charge of battery modules
  • H01M 10/42 - Methods or arrangements for servicing or maintenance of secondary cells or secondary half-cells
  • H01M 10/44 - Methods for charging or discharging
  • H01M 50/213 - Racks, modules or packs for multiple batteries or multiple cells characterised by their shape adapted for cells having curved cross-section, e.g. round or elliptic
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries
  • H02J 7/14 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries for charging batteries from dynamo-electric generators driven at varying speed, e.g. on vehicle

25.

ROBOTIC LAWN MOWER INCLUDING REMOVABLE RECHARGEABLE BATTERY MODULE


Application Number 19030031
Status Pending
Filing Date 2025-01-17
First Publication Date 2025-05-22
Owner Briggs & Stratton, LLC (USA)
Inventor Pjevach, Robert

Abstract

Outdoor power equipment includes a battery pack, a receptacle configured to receive the battery pack, a wheel motor, a chore motor, a gyroscopic sensor configured to detect an orientation of the outdoor power equipment, a location sensor configured to detect a location of the outdoor power equipment, and a controller in communication with the wheel motor, the chore motor, the gyroscopic sensor, and the location sensor. The controller is configured to provide additional power from the battery pack to the wheel motor based on (a) detection of a deviation by the outdoor power equipment from a desired path to maintain the outdoor power equipment on the desired path based on the location of the outdoor power equipment as determined by the location sensor, or (b) detection of the orientation exceeding a predetermined threshold value.

IPC Classes  ?

  • G05D 1/00 - Control of position, course, altitude or attitude of land, water, air or space vehicles, e.g. using automatic pilots
  • A01D 34/00 - MowersMowing apparatus of harvesters
  • A01D 34/416 - Flexible line cutters
  • A01D 34/78 - Driving mechanisms for the cutters electric
  • A01D 69/02 - Driving mechanisms or parts thereof for harvesters or mowers electric
  • A01D 101/00 - Lawn-mowers
  • A01G 3/053 - Apparatus for trimming hedges, e.g. hedge shears portable motor-driven
  • A01G 20/47 - Vacuum or blower devices
  • B60L 15/20 - Methods, circuits or devices for controlling the propulsion of electrically-propelled vehicles, e.g. their traction-motor speed, to achieve a desired performanceAdaptation of control equipment on electrically-propelled vehicles for remote actuation from a stationary place, from alternative parts of the vehicle or from alternative vehicles of the same vehicle train for control of the vehicle or its driving motor to achieve a desired performance, e.g. speed, torque, programmed variation of speed
  • B60L 50/60 - Electric propulsion with power supplied within the vehicle using propulsion power supplied by batteries or fuel cells using power supplied by batteries
  • B60L 53/30 - Constructional details of charging stations
  • B60L 53/80 - Exchanging energy storage elements, e.g. removable batteries
  • H01M 10/0525 - Rocking-chair batteries, i.e. batteries with lithium insertion or intercalation in both electrodesLithium-ion batteries
  • H01M 10/42 - Methods or arrangements for servicing or maintenance of secondary cells or secondary half-cells
  • H01M 10/46 - Accumulators structurally combined with charging apparatus
  • H01M 50/204 - Racks, modules or packs for multiple batteries or multiple cells
  • H01M 50/244 - Secondary casingsRacksSuspension devicesCarrying devicesHolders characterised by their mounting method
  • H01M 50/247 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders specially adapted for portable devices, e.g. mobile phones, computers, hand tools or pacemakers
  • H01M 50/249 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders specially adapted for aircraft or vehicles, e.g. cars or trains
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries

26.

INTEGRATED TRANSAXLE FOR A STANDING MOWER WITH AN OPERATOR PLATFORM


Application Number 19031196
Status Pending
Filing Date 2025-01-17
First Publication Date 2025-05-22
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Laurin, Robert S.
  • Lynch, E. Mark
  • Camenga, Derrick R.

Abstract

A standing ride on mower includes a frame, a right drive wheel, a left drive wheel, a prime mover, a right side integrated transaxle operating under influence of the prime mover to drive rotation of the right drive wheel and having a housing, hydraulic pump, and hydraulic motor, a left side integrated transaxle operating under influence of the prime mover to drive rotation of the left drive wheel, having a housing, hydraulic pump, and hydraulic motor, and an operator platform to support a standing operator of the mower extending beneath the left housing and beneath the right housing such that a distance between an innermost portion of the right side integrated transaxle and an innermost portion of the left side integrated transaxle is less than a width of the operator platform.

IPC Classes  ?

  • A01D 69/03 - Driving mechanisms or parts thereof for harvesters or mowers fluid
  • A01D 34/64 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis mounted on a vehicle, e.g. a tractor, or drawn by an animal or a vehicle
  • A01D 34/68 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis hand-guided by a walking operator with motor driven cutters or wheels
  • A01D 34/82 - Other details
  • A01D 101/00 - Lawn-mowers
  • B60T 7/12 - Brake-action initiating means for automatic initiationBrake-action initiating means for initiation not subject to will of driver or passenger

27.

ELECTRIC POWERHEAD


Application Number 19031358
Status Pending
Filing Date 2025-01-18
First Publication Date 2025-05-22
Owner Briggs & Stratton, LLC (USA)
Inventor Schulenberg, David

Abstract

An electric powerhead includes an electric motor including an output shaft configured to rotate about an axis of rotation, a battery including a plurality of lithium-ion battery cells, the battery coupled to the electric motor, a housing having a cross-sectional footprint substantially the same as 174.5 in2, and a base plate configured to be fastened to a mounting surface, the base plate including a plurality of openings arranged in an engine support pattern.

IPC Classes  ?

  • H02K 7/00 - Arrangements for handling mechanical energy structurally associated with dynamo-electric machines, e.g. structural association with mechanical driving motors or auxiliary dynamo-electric machines
  • E01H 5/09 - Apparatus propelled by animal or engine powerApparatus propelled by hand with driven dislodging or conveying elements, e.g. conveying pneumatically dislodging essentially by driven elements the elements being rotary or moving along a closed circular path, e.g. rotary cutter, digging wheels
  • H02K 5/22 - Auxiliary parts of casings not covered by groups , e.g. shaped to form connection boxes or terminal boxes
  • H02K 11/00 - Structural association of dynamo-electric machines with electric components or with devices for shielding, monitoring or protection

28.

CYCLONIC AIR FILTER ASSEMBLY FOR AN ENGINE


Application Number 19025349
Status Pending
Filing Date 2025-01-16
First Publication Date 2025-05-15
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Gleixner, Steven G.
  • Johnson, Robert

Abstract

An air filter assembly includes a housing defining an interior volume, an air intake formed in the housing, a debris outlet formed in the housing, a filtered air outlet formed in the housing, and a filter element positioned within the interior volume. The filter element includes a first end portion including a first body and a boss extending outward away from the first body, a second end portion including a second body and defining an opening formed through the second body, and a filter media positioned between the first end portion and the second end portion. The first end portion is formed from a first material having a first hardness, and the second end portion is formed from a second material having a second hardness less than the first hardness. The second body is in engagement with the filtered air outlet.

IPC Classes  ?

  • B01D 45/16 - Separating dispersed particles from gases or vapours by gravity, inertia, or centrifugal forces by centrifugal forces generated by the winding course of the gas stream
  • B01D 46/00 - Filters or filtering processes specially modified for separating dispersed particles from gases or vapours
  • B01D 46/24 - Particle separators, e.g. dust precipitators, using rigid hollow filter bodies
  • B01D 46/48 - Removing dust other than cleaning filters
  • B01D 50/20 - Combinations of devices covered by groups and
  • F02M 35/02 - Air cleaners
  • F02M 35/022 - Air cleaners acting by gravity, by centrifugal, or by other inertial forces, e.g. with moistened walls
  • F02M 35/024 - Air cleaners using filters, e.g. moistened
  • F02M 35/08 - Air cleaners with means for removing dust from cleanersAir cleaners with means for indicating cloggingAir cleaners with by-pass means

29.

SYSTEMS AND DEVICES FOR LAWN CARE


Application Number 19025615
Status Pending
Filing Date 2025-01-16
First Publication Date 2025-05-15
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zeiler, Jeffrey M.
  • Hahn, Ryan T.
  • Harvey, Kyle
  • Johnson, Todd
  • Pjevach, Robert
  • Schmalz, Jacob
  • Shears, Peter D.
  • Zeidler, Nicholas

Abstract

A service vehicle for storing and transporting outdoor power equipment includes a charging bay configured to charge a rechargeable battery pack mounted on a first piece of outdoor power equipment, a spare battery charging station configured to store and selectively charge a spare rechargeable battery pack, a user interface having a display, and a controller in communication with the user interface and having a processing circuit with a charging module. The controller is configured to receive a charge level of the rechargeable battery pack and the spare rechargeable battery pack from the charging module and instruct the user interface to display the charge levels.

IPC Classes  ?

30.

SMART SWITCHING PANEL FOR SECONDARY POWER SUPPLY


Application Number 19025572
Status Pending
Filing Date 2025-01-16
First Publication Date 2025-05-15
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Northway, Brian
  • Miller, Michael

Abstract

A smart switching panel includes a plurality of switching elements each connected to both a primary power supply and a secondary power supply and to at least one electric load, a controller operatively connected to each of the plurality of switching elements, and a plurality of current sensors each in communication with the controller. Each of the plurality of switching elements is operable in a first condition and a second condition. The controller is operable to independently control a condition of each of the switching elements. Each of the current sensors is positioned between one of the switching elements and the at least one electric load associated with the switching element.

IPC Classes  ?

  • H02J 3/14 - Circuit arrangements for ac mains or ac distribution networks for adjusting voltage in ac networks by changing a characteristic of the network load by switching loads on to, or off from, network, e.g. progressively balanced loading
  • H02J 3/00 - Circuit arrangements for ac mains or ac distribution networks
  • H02J 3/38 - Arrangements for parallelly feeding a single network by two or more generators, converters or transformers
  • H02J 9/06 - Circuit arrangements for emergency or stand-by power supply, e.g. for emergency lighting in which the distribution system is disconnected from the normal source and connected to a standby source with automatic change-over
  • H02J 13/00 - Circuit arrangements for providing remote indication of network conditions, e.g. an instantaneous record of the open or closed condition of each circuitbreaker in the networkCircuit arrangements for providing remote control of switching means in a power distribution network, e.g. switching in and out of current consumers by using a pulse code signal carried by the network

31.

RIDE-ON SPREADER/SPRAYER


Application Number 19011098
Status Pending
Filing Date 2025-01-06
First Publication Date 2025-05-01
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • King, Brandon
  • Longmeyer, Steve

Abstract

A ride-on spreader/sprayer including a hopper configured to receive expel dry material, a user platform configured to receive and support a user of the ride-on spreader/sprayer, a fluid storage tank providing a fluid storage volume and including an inlet for adding fluid to the fluid storage volume, an exit by which the fluid exits the fluid storage volume, a first fluid passage, and a drain channel defining a second fluid passage separate from the first fluid passage, wherein the fluid may reach the exit through at least one of the first fluid passage and the second fluid passage, a pump fluidly coupled to the exit of the fluid storage tank, and multiple spray nozzles fluidly coupled to the pump.

IPC Classes  ?

  • A01C 7/06 - Seeders combined with fertilising apparatus
  • A01C 7/08 - Broadcast seedersSeeders depositing seeds in rows
  • A01C 15/00 - Fertiliser distributors
  • A01C 23/00 - Distributing devices specially adapted for liquid manure or other fertilising liquid, including ammonia, e.g. transport tanks or sprinkling wagons
  • A01C 23/04 - Distributing under pressureDistributing mudAdaptation of watering systems for fertilising-liquids
  • B05B 13/00 - Machines or plants for applying liquids or other fluent materials to surfaces of objects or other work by spraying, not covered by groups

32.

POWER EQUIPMENT HAVING A SWAPPABLE BATTERY PACK


Application Number US2024051301
Publication Number 2025/085384
Status In Force
Filing Date 2024-10-14
Publication Date 2025-04-24
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Jasinski, Nathan
  • Avery, Stephen Bryan
  • Henkel, Steven
  • Wolf, Ray
  • Lozano, Josue Pimentel

Abstract

Power equipment includes a base, a swappable battery pack, an electric motor powered by the swappable battery pack, a motor controller electrically coupled to the electric motor, and a battery holder or bracket coupled to the base. The battery holder includes a dock connector. The swappable battery pack is coupled to the dock connector and arranged within or on the battery holder so that the swappable battery pack is arranged at an angle relative to the base.

IPC Classes  ?

  • B25F 5/02 - Construction of casings, bodies or handles
  • H01M 10/42 - Methods or arrangements for servicing or maintenance of secondary cells or secondary half-cells
  • H01M 50/202 - Casings or frames around the primary casing of a single cell or a single battery
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries

33.

POWER EQUIPMENT HAVING A SWAPPABLE BATTERY PACK


Application Number 18915307
Status Pending
Filing Date 2024-10-14
First Publication Date 2025-04-17
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Jasinski, Nathan
  • Avery, Stephen Bryan
  • Henkel, Steven
  • Wolf, Ray
  • Lozano, Josue Pimentel

Abstract

Power equipment includes a base, a swappable battery pack, an electric motor powered by the swappable battery pack, a motor controller electrically coupled to the electric motor, and a battery holder or bracket coupled to the base. The battery holder includes a dock connector. The swappable battery pack is coupled to the dock connector and arranged within or on the battery holder so that the swappable battery pack is arranged at an angle relative to the base.

IPC Classes  ?

  • H01M 50/244 - Secondary casingsRacksSuspension devicesCarrying devicesHolders characterised by their mounting method
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries

34.

ENGINE WITH CLOSELY-COUPLED CATALYST


Application Number US2024047726
Publication Number 2025/064841
Status In Force
Filing Date 2024-09-20
Publication Date 2025-03-27
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Paul, Brian
  • Erickson, Melissa
  • Martinek, Matt
  • Pitcel, Michael
  • Martinek, Christopher

Abstract

An engine assembly includes an engine block including a first cylinder and an exhaust outlet, a crankshaft extending from the engine block and defining a crankshaft axis, a blower assembly coupled to the engine block and configured to provide cooling air to the engine block, and an exhaust assembly. The exhaust assembly includes a catalytic converter assembly coupled to the exhaust outlet, and a muffler arranged downstream of the catalytic converter assembly. The catalytic converter assembly includes a catalytic converter body that defines a converter axis, and the muffler defines a muffler axis that is parallel to the converter axis.

IPC Classes  ?

  • F01N 3/28 - Construction of catalytic reactors
  • F01N 13/00 - Exhaust or silencing apparatus characterised by constructional features
  • F01P 1/02 - Arrangements for cooling cylinders or cylinder heads, e.g. ducting cooling-air from its pressure source to cylinders or along cylinders
  • F02B 75/10 - Engines with means for rendering exhaust gases innocuous
  • F02F 7/00 - Casings, e.g. crankcases

35.

QUICK OIL CHANGE FILTER AND ASSEMBLY


Application Number 18954794
Status Pending
Filing Date 2024-11-21
First Publication Date 2025-03-13
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Woytach, Elizabeth
  • Metcalf, Bryce
  • Ammentorp, Randall
  • Martinek, Chris
  • Balzar, Rodney
  • Stroik, Glen

Abstract

An internal combustion engine includes a blower housing and a filtration system positioned in a path of cooling air from the blower housing. The filtration system includes a filter housing comprising a base that defines a series of radially extending fins extending circumferentially around the base, and a filter cartridge defining a longitudinal axis and being removably arranged within the filter housing. The base includes a drain and a channel formed radially between a first raised surface and a second raised surface, and the drain is in fluid communication with the channel. The filter cartridge includes a bottom endplate in engagement with both the first raised surface and the second raised surface so that fluid flow is inhibited through the channel and to the drain, and a filter media extending axially from the bottom endplate.

IPC Classes  ?

  • B01D 27/08 - Construction of the casing
  • B01D 27/10 - Safety devices, e.g. by-passes
  • B01D 27/14 - Cartridge filters of the throw-away type having more than one filtering element
  • B01D 35/18 - Heating or cooling the filters
  • B01D 35/30 - Filter housing constructions
  • F01M 5/00 - Heating, cooling, or controlling temperature of lubricantLubrication means facilitating engine starting
  • F01M 11/03 - Mounting or connecting of lubricant purifying means relative to the machine or engineDetails of lubricant purifying means

36.

Battery


Application Number 29853572
Grant Number D1065046
Status In Force
Filing Date 2022-09-16
First Publication Date 2025-03-04
Grant Date 2025-03-04
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Eernisse, Ross
  • Busse, James M.
  • Schneiker, John
  • Zeidler, Nick

37.

MODULAR BATTERY ASSEMBLY FOR BATTERY POWERED EQUIPMENT


Application Number 18919729
Status Pending
Filing Date 2024-10-18
First Publication Date 2025-01-30
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zeiler, Jeff
  • Krajewski, Christopher
  • Harvey, Kyle
  • Jaskowiak, Ryan
  • Zeidler, Nicholas
  • Noller, Mark
  • Johnson, Todd

Abstract

A battery pack includes a housing defining an upper portion and a lower portion, a first protector portion coupled to a first corner of the housing, a second protector portion coupled to a second corner of the housing, a plurality of battery cells disposed within the housing, and a mating feature including a plurality of ports electrically connected to the plurality of battery cells and structured to supply power from the plurality of battery cells through the ports.

IPC Classes  ?

  • H01M 10/655 - Solid structures for heat exchange or heat conduction
  • B60L 50/64 - Constructional details of batteries specially adapted for electric vehicles
  • B60L 53/80 - Exchanging energy storage elements, e.g. removable batteries
  • B60L 58/22 - Balancing the charge of battery modules
  • B60L 58/26 - Methods or circuit arrangements for monitoring or controlling batteries or fuel cells, specially adapted for electric vehicles for monitoring or controlling batteries for controlling the temperature of batteries by cooling
  • H01M 10/46 - Accumulators structurally combined with charging apparatus
  • H01M 10/48 - Accumulators combined with arrangements for measuring, testing or indicating the condition of cells, e.g. the level or density of the electrolyte
  • H01M 10/613 - Cooling or keeping cold
  • H01M 50/20 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders
  • H01M 50/204 - Racks, modules or packs for multiple batteries or multiple cells
  • H01M 50/256 - Carrying devices, e.g. belts
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries

38.

ELECTRIC ZERO-TURN RADIUS MOWER


Application Number US2024033820
Publication Number 2024/259108
Status In Force
Filing Date 2024-06-13
Publication Date 2024-12-19
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Metcalf, Bryce
  • Jaskowiak, Ryan
  • Prunty, Alex
  • Zeidler, Nick

Abstract

A zero-turn radius lawnmower includes a chassis, a mower deck assembly, a wheel, a drive wheel, and a suspension system. The mower deck assembly is supported by the chassis. The suspension system is coupled to the chassis and includes a first rocker arm, a front suspension assembly, and a rear suspension assembly. The first rocker arm is pivotally coupled to a first side of the chassis and is configured to pivot about a first pivot axis. The first rocker arm spans between a first end and a second end. The front suspension assembly is coupled to the first end and pivotally supports the wheel. The rear suspension assembly is coupled to the second end and pivotally supports the drive wheel.

IPC Classes  ?

  • A01D 34/86 - MowersMowing apparatus of harvesters specially adapted for particular purposes for use on sloping ground, e.g. on embankments
  • A01D 67/00 - Undercarriages or frames specially adapted for harvesters or mowersMechanisms for adjusting the framePlatforms
  • A01D 34/66 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis mounted on a vehicle, e.g. a tractor, or drawn by an animal or a vehicle with two or more cutters
  • A01D 34/76 - Driving mechanisms for the cutters
  • A01D 75/28 - Control mechanisms for harvesters or mowers when moving on slopesDevices preventing lateral pull

39.

BRIGGS & STRATTON


Serial Number 98896923
Status Pending
Filing Date 2024-12-11
Owner Briggs & Stratton, LLC ()
NICE Classes  ?
  • 04 - Industrial oils and greases; lubricants; fuels
  • 07 - Machines and machine tools
  • 09 - Scientific and electric apparatus and instruments
  • 12 - Land, air and water vehicles; parts of land vehicles

Goods & Services

Engine lubricants, fuels, non-chemical fuel additives, and industrial oils and greases Electric motors for industrial applications, turf equipment, agricultural equipment, and machinery; spark plugs; oil filters for engines; carburetors; alternators; metal gaskets for engines; starters for motors and engines; electrical power generators Batteries for use in outdoor power equipment, industrial applications, turf equipment, agricultural equipment, golf carts, and machinery; battery chargers; electric motor controllers Electric motors for golf carts

40.

Miscellaneous Design


Serial Number 98896972
Status Pending
Filing Date 2024-12-11
Owner Briggs & Stratton, LLC ()
NICE Classes  ?
  • 07 - Machines and machine tools
  • 09 - Scientific and electric apparatus and instruments
  • 12 - Land, air and water vehicles; parts of land vehicles

Goods & Services

Electric motors for industrial applications, turf equipment, agricultural equipment, and machinery; spark plugs; oil filters for engines; carburetors; alternators; metal gaskets for engines; starters for motors and engines; electrical power generators Batteries for use in outdoor power equipment, industrial applications, turf equipment, agricultural equipment, golf carts, and machinery; battery chargers; electric motor controllers Electric motors for golf carts

41.

BATTERY SYSTEM FOR POWER EQUIPMENT


Application Number 18787477
Status Pending
Filing Date 2024-07-29
First Publication Date 2024-11-21
Owner Briggs & Stratton, LLC (USA)
Inventor Zeiler, Jeffrey

Abstract

A battery system for power equipment includes a battery configured to removably connect to a receptacle, and a processing circuit of the battery configured to communicably interface with a processing circuit of the receptacle, wherein the battery and the receptacle are configured to electrically connect and transfer power from the battery through the receptacle to the power equipment, wherein the processing circuits of the battery and the receptacle are configured to transfer information between the battery and the receptacle, and wherein the processing circuits of the battery and the receptacle are configured to allow the transfer of power from the battery through the receptacle to the power equipment based on the information transferred between the battery and the receptacle.

IPC Classes  ?

  • H01M 10/42 - Methods or arrangements for servicing or maintenance of secondary cells or secondary half-cells
  • H01M 50/244 - Secondary casingsRacksSuspension devicesCarrying devicesHolders characterised by their mounting method
  • H01M 50/296 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders characterised by terminals of battery packs

42.

BATTERY PACK CHARGER ASSEMBLY


Application Number US2024029306
Publication Number 2024/238564
Status In Force
Filing Date 2024-05-14
Publication Date 2024-11-21
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Bieksza, Garrett
  • Melone, Mark
  • Kowalski, Joshua
  • Camenga, Derrick
  • Brown, Lee

Abstract

A battery charger assembly can include a battery charger and a housing at least partially surrounding the battery charger. The housing can include a handle, a first latch arm, a second latch arm, a first multiple mounting brackets, and a first sidewall. The handle is arranged on a top side of the housing. The first plurality of mounting brackets extend from a bottom side of the housing. The first sidewall extends between the top side and the bottom side. The first sidewall defines a second plurality of mounting brackets. The first latch arm and the second latch arm are coupled to the first sidewall proximate the top side.

IPC Classes  ?

  • H01M 50/20 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders
  • F02N 11/08 - Circuits specially adapted for starting of engines
  • F02N 11/14 - Starting of engines by means of electric starters with external current supply

43.

SYSTEMS AND METHODS OF MANUFACTURING A CHASSIS


Application Number US2024028850
Publication Number 2024/238353
Status In Force
Filing Date 2024-05-10
Publication Date 2024-11-21
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Metcalf, Bryce
  • Johnson, Todd
  • Zeiler, Jeffrey

Abstract

A method of manufacturing a chassis includes casting a first frame member and casting a second frame member. The first frame member and the second frame member are fabricated from a nonferrous metal. The method further includes fastening the first frame member to the second frame member with a fastener. The fastener is fabricated from a different material than the nonferrous metal.

IPC Classes  ?

  • B62D 21/12 - Understructures, i.e. chassis frame on which a vehicle body may be mounted assembled from readily-detachable parts
  • B62D 21/03 - Understructures, i.e. chassis frame on which a vehicle body may be mounted comprising longitudinally or transversely arranged frame members transverse members providing body support

44.

STANDBY BATTERY-METER SOCKET ADAPTER


Application Number 18779532
Status Pending
Filing Date 2024-07-22
First Publication Date 2024-11-14
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Miller, Michael
  • Perea, Kyle

Abstract

An electrical system operable to supply power from at least one of a primary power source or a standby power source to one or more electrical loads. The electrical system is configured to be provided between an electricity meter and a meter socket. The electrical system includes a housing, a plurality of contacts configured to be coupled with the meter, the meter socket, and a transfer switch. The transfer switch includes a first switch configured to selectively connect the primary power source to the one or more electrical loads, a second switch configured to selectively connect the standby power source to the one or more electrical loads, and an electrical control logic.

IPC Classes  ?

  • H02J 9/06 - Circuit arrangements for emergency or stand-by power supply, e.g. for emergency lighting in which the distribution system is disconnected from the normal source and connected to a standby source with automatic change-over
  • G06Q 50/06 - Energy or water supply
  • H02J 3/38 - Arrangements for parallelly feeding a single network by two or more generators, converters or transformers
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries

45.

POWER UNIT INCLUDING MULTIPLE BATTERY PACKS FOR USE WITH OUTDOOR POWER EQUIPMENT


Application Number 18767341
Status Pending
Filing Date 2024-07-09
First Publication Date 2024-10-31
Owner Briggs & Stratton, LLC (USA)
Inventor Jan, Numan Mohammad

Abstract

A power unit operable to power equipment, the power unit including an electric motor, multiple removable and rechargeable battery packs, multiple switching elements, and a control unit. Each of the switching elements is connected between one of the battery packs and the electric motor and operate in one of an open position or a closed position. The control unit is operable to manage the position of the switching elements. The control unit is configured to determine whether one or more battery packs are supplying power for the electric motor, measure a voltage of each of the battery packs, determine whether each of the voltage measurements is within a predetermined value to each other, calculate a pulse width modulated (PWM) signal for each of the switching elements, assign each PWM signal to one of the switching elements, and apply each of the PWM signals to the assigned switching element.

IPC Classes  ?

  • G01R 31/3835 - Arrangements for monitoring battery or accumulator variables, e.g. SoC involving only voltage measurements
  • G01R 31/36 - Arrangements for testing, measuring or monitoring the electrical condition of accumulators or electric batteries, e.g. capacity or state of charge [SoC]
  • H01M 10/42 - Methods or arrangements for servicing or maintenance of secondary cells or secondary half-cells
  • H01M 10/44 - Methods for charging or discharging
  • H01M 10/48 - Accumulators combined with arrangements for measuring, testing or indicating the condition of cells, e.g. the level or density of the electrolyte
  • H01M 50/20 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders
  • H01M 50/247 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders specially adapted for portable devices, e.g. mobile phones, computers, hand tools or pacemakers

46.

BATTERY CHARGING SYSTEMS AND METHODS


Application Number 18290057
Status Pending
Filing Date 2022-05-13
First Publication Date 2024-09-26
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Gigot, Michael
  • Noller, Mark
  • Marshall, Michael D.
  • Tripi, Jonathan M.

Abstract

A battery pack assembly which includes a battery pack. The battery pack includes a housing receiving a plurality of rechargeable battery cells, a battery management system (BMS) in communication with the rechargeable battery cells and configured to monitor one or more operating characteristics of the rechargeable battery cells, a plurality of terminals to transmit electrical power between the rechargeable battery cells and a piece of equipment coupled with the plurality of terminals, a communication interface in communication with BMS and configured to transmit the operating characteristics of the rechargeable battery cells over a communication protocol and receive information from the piece of equipment coupled with the plurality of terminals over the communication protocol.

IPC Classes  ?

  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries
  • H01M 10/42 - Methods or arrangements for servicing or maintenance of secondary cells or secondary half-cells
  • H01M 10/46 - Accumulators structurally combined with charging apparatus
  • H01M 50/204 - Racks, modules or packs for multiple batteries or multiple cells

47.

Electric powerhead


Application Number 18418569
Grant Number 12328055
Status In Force
Filing Date 2024-01-22
First Publication Date 2024-08-22
Grant Date 2025-06-10
Owner Briggs & Stratton, LLC (USA)
Inventor Schulenberg, David

Abstract

2, and a base plate configured to be fastened to a mounting surface, the base plate including a plurality of openings arranged in an engine support pattern.

IPC Classes  ?

  • H02K 7/00 - Arrangements for handling mechanical energy structurally associated with dynamo-electric machines, e.g. structural association with mechanical driving motors or auxiliary dynamo-electric machines
  • E01H 5/09 - Apparatus propelled by animal or engine powerApparatus propelled by hand with driven dislodging or conveying elements, e.g. conveying pneumatically dislodging essentially by driven elements the elements being rotary or moving along a closed circular path, e.g. rotary cutter, digging wheels
  • H02K 5/22 - Auxiliary parts of casings not covered by groups , e.g. shaped to form connection boxes or terminal boxes
  • H02K 11/00 - Structural association of dynamo-electric machines with electric components or with devices for shielding, monitoring or protection

48.

BATTERY POWERED LIGHT TOWER


Application Number 18603942
Status Pending
Filing Date 2024-03-13
First Publication Date 2024-07-04
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Avery, Stephen Bryan
  • Brunelli, Brian Todd
  • Jones, Dave
  • Grasz, Andrew
  • Booth, Cole

Abstract

A light tower includes a base, an extendible mast coupled to the base, a battery pack supported on the base and including a plurality of lithium-ion battery cells, a light assembly including a plurality of light emitting diodes electrically coupled to the battery pack, a user device configured to receive an input runtime, and a controller in communication with the battery pack, the light assembly, and the user device. The is configured to receive the input runtime from the user device, determine an available power output of the battery pack, and determine a light intensity of the light assembly based on the input runtime and the available power output of the battery pack to ensure the light assembly operates for the input runtime.

IPC Classes  ?

  • F21S 8/08 - Lighting devices intended for fixed installation with a standard
  • F21S 9/02 - Lighting devices with a built-in power supplySystems employing lighting devices with a built-in power supply the power supply being a battery or accumulator
  • F21V 21/15 - Adjustable mountings specially adapted for power operation, e.g. by remote control

49.

COMMERCIAL FLEXIBLE BATTERY PACK WITH SECONDARY OUTPUT CONTROL


Application Number 18418573
Status Pending
Filing Date 2024-01-22
First Publication Date 2024-06-20
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Schmalz, Jacob
  • Ziedler, Nicholas

Abstract

A battery pack includes a housing, a cell module assembly enclosed within the housing and having a plurality of battery cells, a positive terminal extending through the housing, a negative terminal extending through the housing, and a connector arranged between the positive terminal and the negative terminal. The connector is in the form of a cylindrical boss that extends outwardly from the housing. The connector includes a plurality of pins arranged within the cylindrical boss. The plurality of pins includes a communication pin that enables the communication over a CAN network.

IPC Classes  ?

  • H01M 50/20 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders
  • H01M 10/0525 - Rocking-chair batteries, i.e. batteries with lithium insertion or intercalation in both electrodesLithium-ion batteries
  • H01M 10/42 - Methods or arrangements for servicing or maintenance of secondary cells or secondary half-cells
  • H01M 50/502 - Interconnectors for connecting terminals of adjacent batteriesInterconnectors for connecting cells outside a battery casing
  • H01M 50/529 - Intercell connections through partitions, e.g. in a battery casing
  • H01M 50/557 - Plate-shaped terminals

50.

BATTERY PACK FOR POWERING AND CONTROLLING OUTDOOR POWER EQUIPMENT


Application Number 18394138
Status Pending
Filing Date 2023-12-22
First Publication Date 2024-05-30
Owner Briggs & Stratton, LLC (USA)
Inventor Koenen, Robert

Abstract

A battery pack battery pack for powering a motor on outdoor power equipment includes an outer housing, a plurality of battery cells enclosed within the outer housing, and a plurality of terminals electrically coupled to the plurality of battery cells. The plurality of terminals includes a positive terminal, a negative terminal, an enable input terminal, and an auxiliary terminal. The auxiliary terminal is configured to supply auxiliary power from the plurality of battery cells to an auxiliary device in response to a signal being received at the enable input terminal.

IPC Classes  ?

  • F02N 11/08 - Circuits specially adapted for starting of engines
  • F02D 31/00 - Use of non-electrical speed-sensing governors to control combustion engines, not otherwise provided for
  • F02D 41/06 - Introducing corrections for particular operating conditions for engine starting or warming up
  • F02D 41/30 - Controlling fuel injection
  • F02N 11/14 - Starting of engines by means of electric starters with external current supply
  • H01M 50/213 - Racks, modules or packs for multiple batteries or multiple cells characterised by their shape adapted for cells having curved cross-section, e.g. round or elliptic
  • H01M 50/284 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders with incorporated circuit boards, e.g. printed circuit boards [PCB]
  • A01D 34/64 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis mounted on a vehicle, e.g. a tractor, or drawn by an animal or a vehicle
  • A01D 69/02 - Driving mechanisms or parts thereof for harvesters or mowers electric
  • A01D 101/00 - Lawn-mowers
  • H04L 67/12 - Protocols specially adapted for proprietary or special-purpose networking environments, e.g. medical networks, sensor networks, networks in vehicles or remote metering networks

51.

ELECTRIC MOWER


Application Number 18430823
Status Pending
Filing Date 2024-02-02
First Publication Date 2024-05-30
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Dandridge, Bryan Keith
  • Funke, Scott
  • Schmalz, Jacob
  • Noller, Mark

Abstract

A lawnmower includes a cutting deck including an aperture extending through the cutting deck, the aperture comprising a first motor portion, a second motor portion, and a central portion joining the first motor portion and the second motor portion. The lawnmower further includes a first electric motor received within the first motor portion and coupled to a first cutting blade positioned below the cutting deck and a second electric motor received within the second motor portion and coupled to a second cutting blade positioned below the cutting deck.

IPC Classes  ?

52.

Hybrid light tower


Application Number 18424353
Grant Number 12209717
Status In Force
Filing Date 2024-01-26
First Publication Date 2024-05-23
Grant Date 2025-01-28
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Avery, Stephen Bryan
  • Brunelli, Brian
  • Jones, Dave
  • Grasz, Andrew
  • Booth, Cole

Abstract

A hybrid light tower includes an engine, a generator configured to be driven by the engine, a battery pack, a mast, and a light assembly including a plurality of light emitting diodes. The generator is configured to produce a first DC power. The battery pack is directly electrically coupled to the generator to receive the first DC power from the generator to charge the battery pack. The light assembly is coupled to the mast and the light emitting diodes electrically coupled to the battery pack to receive a second DC power from the battery pack.

IPC Classes  ?

  • F21V 21/22 - Adjustable mountings telescopic
  • F21L 14/04 - Electric lighting devices without a self-contained power source, e.g. for mains connection carried on wheeled supports
  • F21W 131/10 - Outdoor lighting

53.

EQUIPMENT TRACKING SYSTEM


Application Number 18422808
Status Pending
Filing Date 2024-01-25
First Publication Date 2024-05-23
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Bernier, Kevin
  • Divis, Mario
  • Shears, Peter Douglas

Abstract

An outdoor power equipment system includes outdoor power equipment, a battery configured to supply electrical power to the outdoor power equipment, an endpoint coupled to the battery, and a near-field communication transceiver configured to facilitate communication with the outdoor power equipment and the endpoint. The battery is coupled to a sensor that is configured to provide information indicative of a battery status. The endpoint includes a transmitter configured to transmit an endpoint location and the battery status.

IPC Classes  ?

  • H04W 64/00 - Locating users or terminals for network management purposes, e.g. mobility management
  • G06F 16/901 - IndexingData structures thereforStorage structures
  • G07C 3/02 - Registering or indicating working or idle time only
  • H04W 4/029 - Location-based management or tracking services
  • H04W 88/16 - Gateway arrangements

54.

ROTARY CUTTING BLADE


Application Number US2023077488
Publication Number 2024/086839
Status In Force
Filing Date 2023-10-20
Publication Date 2024-04-25
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Metcalf, Bryce
  • Joestgen, Andrew
  • Marshall, James

Abstract

A rotary cutting blade includes a cutting edge, a lift wing that arcs or angles upwardly from the cutting edge and defines a leading end from which the cutting edge extends and a trailing end, and a wing tail that extends from the trailing end of the lift wing in a direction away from the cutting edge.

IPC Classes  ?

  • A01D 34/73 - Cutting apparatus
  • A01D 34/63 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis
  • A01D 34/82 - Other details
  • A01D 101/00 - Lawn-mowers

55.

POWER MANAGEMENT SYSTEM FOR A STANDBY GENERATOR


Application Number 18392403
Status Pending
Filing Date 2023-12-21
First Publication Date 2024-04-18
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Miller, Michael
  • Gracyalny, Gary
  • Kratz, David A.
  • Gilpatrick, Richard
  • Weigand, Dean
  • Lim, Sie Teong
  • Demos, Nicholas

Abstract

A power management system includes a relay connected to an electrical load, a power management module configured to receive electrical power from each of a battery and a utility source, and in communication with the relay, and a controller in communication with the battery and the power management module. The controller monitors a battery load on the battery and communicates to the power management module to selectively disconnect the relay connected to the electrical load based on the battery load.

IPC Classes  ?

  • H02B 1/03 - Boards, panels, desksParts thereof or accessories therefor for energy meters
  • H01H 9/54 - Circuit arrangements not adapted to a particular application of the switching device and for which no provision exists elsewhere
  • H02B 1/015 - Boards, panels, desksParts thereof or accessories therefor
  • H02B 1/24 - Circuit arrangements for boards or switchyards
  • H02B 1/30 - Cabinet-type casingsParts thereof or accessories therefor

56.

DRIVE MOTOR MOUNTING ON ELECTRIFIED CHORE PRODUCT


Application Number US2023035098
Publication Number 2024/081397
Status In Force
Filing Date 2023-10-13
Publication Date 2024-04-18
Owner BRIGGS & STRATTON, LLC (USA)
Inventor Joehnk, Steven

Abstract

A chore product includes a chassis, an energy storage device supported by the chassis, a left drive assembly, and a right drive assembly. Each of the left drive assembly and the right drive assembly includes a drive motor coupled to the energy storage device, an axle coupled to a left tractive element or a right tractive element, and a transmission positioned between the drive motor and the axle. The transmission includes a housing having a first end and a second end. The housing defines a first interface positioned at the first end and engaging with the drive motor, a second interface positioned at the second end and receiving the axle, a third interface positioned proximate the second end and extending from the housing in a first direction, and a fourth interface positioned proximate the second end and extending from the housing in a second direction generally opposite the first direction.

IPC Classes  ?

  • A01D 34/64 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis mounted on a vehicle, e.g. a tractor, or drawn by an animal or a vehicle
  • A01D 34/76 - Driving mechanisms for the cutters
  • A01D 34/78 - Driving mechanisms for the cutters electric
  • A01D 69/02 - Driving mechanisms or parts thereof for harvesters or mowers electric
  • B60K 17/04 - Arrangement or mounting of transmissions in vehicles characterised by arrangement, location or kind of gearing
  • A01D 34/00 - MowersMowing apparatus of harvesters
  • A01D 34/01 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus
  • A01D 34/412 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters
  • A01D 34/63 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis
  • A01D 69/00 - Driving mechanisms or parts thereof for harvesters or mowers
  • B62D 11/00 - Steering non-deflectable wheelsSteering endless tracks or the like

57.

SYSTEMS AND METHODS FORAN ELECTRIC CHORE MOTOR WITHAN INTEGRATED MOTOR CONTROLLER


Application Number US2023035190
Publication Number 2024/081440
Status In Force
Filing Date 2023-10-16
Publication Date 2024-04-18
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Joehnk, Steven

Abstract

An electric chore motor assembly includes a chore motor having a rotor, a stator, a base housing, an outer housing, and a drive shaft rotationally coupled to the rotor and extending through the base housing. The electric chore motor assembly includes a motor controller enclosed between the base housing and the outer housing. The motor controller is connected to the stator by phase wires that are enclosed between the base housing and the outer housing.

IPC Classes  ?

  • A01D 34/30 - Driving mechanisms for the cutters
  • A01D 34/37 - Driving mechanisms for the cutters electric
  • A01D 34/58 - Driving mechanisms for the cutters electric
  • A01D 34/78 - Driving mechanisms for the cutters electric
  • A01D 69/02 - Driving mechanisms or parts thereof for harvesters or mowers electric
  • A01D 34/01 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus
  • A01D 34/412 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters
  • A01D 34/47 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a horizontal axis, e.g. cutting-cylinders hand-guided by a walking operator with motor driven cutters or wheels
  • A01D 34/52 - Cutting apparatus

58.

INTEGRATERD CHARGER ONBOARD ELECTRIFIED CHORE PRODUCT


Application Number US2023035100
Publication Number 2024/081399
Status In Force
Filing Date 2023-10-13
Publication Date 2024-04-18
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Joehnk, Steven

Abstract

An electrified chore product includes a chassis, an energy storage device supported by the chassis, an implement, a tractive element, one or more electric motors powered by the energy storage device, a charging port configured to facilitate connecting the energy storage device to an external power source, and an integrated charger. The one or more electric motors are positioned to drive at least one of the implement or the tractive element. The integrated charger is connected between the energy storage device and the charging port.

IPC Classes  ?

  • A01D 34/78 - Driving mechanisms for the cutters electric
  • A01D 34/58 - Driving mechanisms for the cutters electric
  • A01D 69/02 - Driving mechanisms or parts thereof for harvesters or mowers electric

59.

CHORE PRODUCT WITH INTEGRATED BRAKE AND LOCK PEDALS


Application Number US2023035200
Publication Number 2024/081441
Status In Force
Filing Date 2023-10-16
Publication Date 2024-04-18
Owner BRIGGS & STRATTON, LLC (USA)
Inventor Ricciardi, Matthew

Abstract

A brake assembly includes a brake pedal pivotally coupled to a base plate at a first rotation point and including a first pedal portion, the brake pedal configured to pivot from a first disengaged configuration to a first engaged configuration. The brake assembly further includes a lock pedal including a second pedal portion, the lock pedal rotatably coupled to the brake pedal and configured to move from a second disengaged configuration to a second engaged configuration when force is applied to the second pedal portion, wherein the brake pedal is configured to pivot from the first disengaged configuration to the first engaged configuration when the force is applied to the second pedal portion. The lock pedal is configured to remain in the second engaged configuration and the brake pedal is configured to remain in the first engaged configuration when the force on the second pedal portion is removed.

IPC Classes  ?

  • A01D 69/10 - Brakes
  • B60T 7/04 - Brake-action initiating means for personal initiation foot-actuated
  • G05G 1/30 - Controlling members actuated by foot
  • A01D 69/00 - Driving mechanisms or parts thereof for harvesters or mowers

60.

BATTERY PACK AND BATTERY RECEPTACLE


Application Number US2023033002
Publication Number 2024/059329
Status In Force
Filing Date 2023-09-18
Publication Date 2024-03-21
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Eernisse, Ross
  • Busse, James, M.
  • Schneiker, John
  • Mergener, Matthew
  • Ladeinde, Yomi
  • Duch, David

Abstract

A battery pack assembly includes a battery pack and a dock assembly. The battery pack includes a plurality of battery cells, a plurality of collector plates each connected to a subset of the plurality of battery cells, a PCB sense board coupled to the plurality of collector plates through a plurality of wires, an outer housing configured to enclose the plurality of cells, a handle extending from the outer housing, an electrical receptacle located on a side of the outer housing, the electrical receptacle comprising a plurality of ports, and a rail coupled to the outer housing and including a mounting aperture. The dock assembly includes a body and an electrical connector configured to connect to the electrical receptacle. The dock assembly is configured to couple to the outer housing via a fastener extending through the body and into the mounting aperture.

IPC Classes  ?

  • H01M 50/10 - Primary casingsJackets or wrappings
  • H01M 50/172 - Arrangements of electric connectors penetrating the casing
  • H01M 50/244 - Secondary casingsRacksSuspension devicesCarrying devicesHolders characterised by their mounting method
  • H01M 50/262 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders with fastening means, e.g. locks
  • H01M 50/296 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders characterised by terminals of battery packs
  • H01M 50/103 - Primary casingsJackets or wrappings characterised by their shape or physical structure prismatic or rectangular
  • H01M 50/20 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders
  • H01M 50/204 - Racks, modules or packs for multiple batteries or multiple cells
  • H01M 50/50 - Current conducting connections for cells or batteries

61.

Outdoor power equipment with single handed controls


Application Number 18516328
Grant Number 12208843
Status In Force
Filing Date 2023-11-21
First Publication Date 2024-03-14
Grant Date 2025-01-28
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Laurin, Robert
  • Camenga, Derrick
  • Marshall, James
  • Ferris, Joe
  • Burkard, Tom

Abstract

Outdoor power equipment includes a frame including a handle, a prime mover mounted to the frame, a transmission coupling the prime mover to a wheel, and a user interface coupled to the transmission and including a static link rigidly coupled to the handle, a forward link coupled to a forward lever and to the static link, a reverse link coupled to a reverse lever and to the static link, and a joining link coupled between the forward link and the reverse link. The user interface is actuatable between a forward configuration and a reverse configuration.

IPC Classes  ?

  • B62D 51/00 - Motor vehicles characterised by the driver not being seated
  • A01D 34/69 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis hand-guided by a walking operator with motor driven cutters or wheels with motor driven wheels
  • A01D 34/82 - Other details
  • B62D 51/04 - Motor vehicles characterised by the driver not being seated the driver walking
  • A01D 34/68 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis hand-guided by a walking operator with motor driven cutters or wheels
  • A01D 101/00 - Lawn-mowers

62.

Dethatcher systems and methods


Application Number 18517729
Grant Number 12246431
Status In Force
Filing Date 2023-11-22
First Publication Date 2024-03-14
Grant Date 2025-03-11
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Harvey, Kyle
  • Jaskowiak, Ryan
  • Zurawski, Matthew S.

Abstract

A method of stacking dethatchers includes pivoting an upper portion of a handle on a first dethatcher toward a front end of a frame on the first dethatcher, upon pivoting the upper portion of the handle toward the front end of the frame, exposing a rear support point defined by a lower portion of the handle, and stacking a second dethatcher on the first dethatcher so that the second dethatcher is supported on the rear support point defined by the lower portion of the handle and a front support point defined by the upper portion of the handle.

IPC Classes  ?

  • B25G 3/38 - Hinged, pivoted, swivelling, or folding joints
  • A01B 45/02 - Machines for treating meadows or lawns for aerating
  • A01D 43/14 - Mowers combined with apparatus performing additional operations while mowing with dispensing apparatus, e.g. for fertilisers, herbicides or preservatives
  • A01B 1/06 - HoesHand cultivators
  • A01B 33/10 - Structural or functional features of the tools
  • A01B 33/14 - Attaching the tools to the rotating shaft, e.g. resiliently-attached tools
  • A01B 45/00 - Machines for treating meadows or lawns
  • A01D 34/47 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a horizontal axis, e.g. cutting-cylinders hand-guided by a walking operator with motor driven cutters or wheels
  • A01D 34/67 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis hand-guided by a walking operator
  • A01D 34/82 - Other details
  • A01D 43/063 - Mowers combined with apparatus performing additional operations while mowing with means for collecting, gathering or loading mown material in or into a container carried by the mowerContainers therefor
  • A01D 75/00 - Accessories for harvesters or mowers
  • A01D 101/00 - Lawn-mowers
  • A01G 20/47 - Vacuum or blower devices
  • A47J 37/07 - Roasting devices for outdoor useBarbecues
  • B25F 5/02 - Construction of casings, bodies or handles

63.

Battery assembly for battery powered equipment


Application Number 18508153
Grant Number 12444961
Status In Force
Filing Date 2023-11-13
First Publication Date 2024-03-07
Grant Date 2025-10-14
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Krajewski, Christopher
  • Harvey, Kyle
  • Jaskowiak, Ryan S.
  • Zeidler, Nicholas
  • Noller, Mark
  • Johnson, Todd

Abstract

A battery charging system includes a charging rack comprising multiple receptacle, multiple battery assemblies. Each of the battery assemblies includes a housing having a handle, rechargeable battery cells disposed within the housing, and a mating feature protruding away from the housing, wherein the mating feature is configured to selectively connect the battery assembly with the receptacle of the charging rack and includes multiple ports electrically connected to the battery cells and configured receive power from the charging rack to charge the battery cells, and wherein the handle comprises a release button configured to selectively disengage the battery assembly from the receptacle of the charging rack.

IPC Classes  ?

  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries
  • B25F 5/00 - Details or components of portable power-driven tools not particularly related to the operations performed and not otherwise provided for
  • B60L 53/80 - Exchanging energy storage elements, e.g. removable batteries
  • H01M 10/42 - Methods or arrangements for servicing or maintenance of secondary cells or secondary half-cells
  • H01M 10/46 - Accumulators structurally combined with charging apparatus
  • H01M 10/48 - Accumulators combined with arrangements for measuring, testing or indicating the condition of cells, e.g. the level or density of the electrolyte
  • H01M 50/204 - Racks, modules or packs for multiple batteries or multiple cells
  • H01M 50/244 - Secondary casingsRacksSuspension devicesCarrying devicesHolders characterised by their mounting method
  • H01M 50/256 - Carrying devices, e.g. belts

64.

Battery pack for power equipment


Application Number 18508157
Grant Number 12196167
Status In Force
Filing Date 2023-11-13
First Publication Date 2024-03-07
Grant Date 2025-01-14
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Harvey, Kyle Michael
  • Dandridge, Bryan Keith

Abstract

A battery pack is configured to be coupled to outdoor power equipment and includes a battery positioned in a housing, the housing comprising an interface surface, a plurality of high current pins electrically connected to the battery and accessible through the interface surface, a plurality of low current pins electrically connected to the battery and accessible through the interface surface, and a battery controller electrically coupled to the battery, the plurality of low current pins, and the plurality of high current pins.

IPC Classes  ?

  • H04W 4/00 - Services specially adapted for wireless communication networksFacilities therefor
  • F02N 11/08 - Circuits specially adapted for starting of engines
  • G06F 3/147 - Digital output to display device using display panels
  • H01M 10/42 - Methods or arrangements for servicing or maintenance of secondary cells or secondary half-cells
  • H01M 50/204 - Racks, modules or packs for multiple batteries or multiple cells
  • H01M 50/251 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders specially adapted for stationary devices, e.g. power plant buffering or backup power supplies
  • H01M 50/284 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders with incorporated circuit boards, e.g. printed circuit boards [PCB]
  • H04W 4/48 - Services specially adapted for particular environments, situations or purposes for vehicles, e.g. vehicle-to-pedestrians [V2P] for in-vehicle communication
  • H05K 1/18 - Printed circuits structurally associated with non-printed electric components
  • H05K 5/00 - Casings, cabinets or drawers for electric apparatus
  • H04W 4/80 - Services using short range communication, e.g. near-field communication [NFC], radio-frequency identification [RFID] or low energy communication

65.

Outdoor power equipment suspension system


Application Number 18387359
Grant Number 12370849
Status In Force
Filing Date 2023-11-06
First Publication Date 2024-02-29
Grant Date 2025-07-29
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Krajewski, Christopher
  • Laurin, Robert S.
  • Lynch, E. Mark

Abstract

A front independent suspension assembly for outdoor power equipment includes a first joint, a first wheel coupled to the joint, a first longitudinal arm pivotably coupled to the joint, a first lateral arm pivotably coupled to the joint, and a second lateral arm pivotably coupled to the joint. The second lateral suspension arranged substantially parallel to the first lateral suspension arm. The pivotal coupling between the joint and each of the first longitudinal arm, the first lateral arm, and the second lateral arm enables the first wheel to independently displace about a vertical axis.

IPC Classes  ?

  • B60G 3/20 - Resilient suspensions for a single wheel with two or more pivoted arms, e.g. parallelogram all arms being rigid
  • A01D 34/66 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis mounted on a vehicle, e.g. a tractor, or drawn by an animal or a vehicle with two or more cutters
  • A01D 34/82 - Other details
  • A01D 67/00 - Undercarriages or frames specially adapted for harvesters or mowersMechanisms for adjusting the framePlatforms
  • B60G 3/26 - Means for maintaining substantially-constant wheel camber during suspension movement
  • B60G 15/06 - Resilient suspensions characterised by arrangement, location, or type of combined spring and vibration- damper, e.g. telescopic type having mechanical spring and fluid damper
  • A01D 101/00 - Lawn-mowers

66.

OUTDOOR POWER EQUIPMENT CHARGING TRAILER


Application Number 18231016
Status Pending
Filing Date 2023-08-07
First Publication Date 2024-02-08
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Mergener, Matthew
  • Metcalf, Bryce
  • Zeidler, Nicholas Joseph

Abstract

A trailer includes a storage space configured to store outdoor power equipment and a plurality of equipment battery packs, each being configured to power the outdoor power equipment, a hitch tongue, a plurality of wheels, and a plurality of receptacles each configured to receive a primary battery pack. The plurality of receptacles are electrically coupled to a wiring system configured to deliver electricity from the primary battery packs to the plurality of equipment battery packs.

IPC Classes  ?

  • B60L 1/00 - Supplying electric power to auxiliary equipment of electrically-propelled vehicles
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries
  • H02J 50/10 - Circuit arrangements or systems for wireless supply or distribution of electric power using inductive coupling
  • B60L 58/12 - Methods or circuit arrangements for monitoring or controlling batteries or fuel cells, specially adapted for electric vehicles for monitoring or controlling batteries responding to state of charge [SoC]
  • B60R 16/033 - Electric or fluid circuits specially adapted for vehicles and not otherwise provided forArrangement of elements of electric or fluid circuits specially adapted for vehicles and not otherwise provided for electric for supply of electrical power to vehicle subsystems characterised by the use of electrical cells or batteries

67.

BATTERY SYSTEM WITH LOW POWER AUXILIARY OUTPUT


Application Number US2023029413
Publication Number 2024/030557
Status In Force
Filing Date 2023-08-03
Publication Date 2024-02-08
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Marshall, Michael D.
  • Schmalz, Jacob
  • Mergener, Matthew

Abstract

A battery system includes a battery pack, a load circuit comprising a switch configured to selectively couple the battery pack to a load, an auxiliary bus electrically coupled to the battery pack, a voltage sensor configured to provide voltage data indicating a voltage at the auxiliary bus and a controller operatively coupled to the voltage sensor. The controller is configured to determine, based on the voltage data, whether a power source other than the battery pack is supplying electrical energy to the auxiliary bus.

IPC Classes  ?

  • H02J 7/04 - Regulation of the charging current or voltage
  • H02J 7/06 - Regulation of the charging current or voltage using discharge tubes or semiconductor devices
  • H02J 7/10 - Regulation of the charging current or voltage using discharge tubes or semiconductor devices using semiconductor devices only
  • H02J 7/34 - Parallel operation in networks using both storage and other DC sources, e.g. providing buffering
  • H01M 10/44 - Methods for charging or discharging
  • H01M 10/46 - Accumulators structurally combined with charging apparatus
  • H02J 7/02 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries for charging batteries from AC mains by converters

68.

CHARGING AND DISCHARGING SYSTEMS FOR BATTERY SYSTEMS INCLUDING MULTIPLE BATTERY PACKS


Application Number US2023029417
Publication Number 2024/030560
Status In Force
Filing Date 2023-08-03
Publication Date 2024-02-08
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Marshall, Michael D.
  • Schmalz, Jacob
  • Mergener, Matthew
  • Avery, Stephen Bryan
  • Ryer, Rick
  • Tripi, Jonathan
  • Depons, Daniel
  • Beam, Nicholas

Abstract

Power equipment includes a chassis, an implement coupled to the chassis, and a battery system coupled to the chassis. The battery system includes a first battery pack, a second battery pack, a circuit including a first switch configured to selectively couple the first battery pack to the implement and a second switch configured to selectively couple the second battery pack to the implement; and a controller operatively coupled to the circuit. The controller controls the first switch and the second switch according to a first control strategy in response to an indication that the power equipment is a first type of power equipment. The controller controls the first switch and the second switch according to a second control strategy in response to an indication that the power equipment is a second type of power equipment.

IPC Classes  ?

  • A01D 69/02 - Driving mechanisms or parts thereof for harvesters or mowers electric
  • B60L 50/50 - Electric propulsion with power supplied within the vehicle using propulsion power supplied by batteries or fuel cells
  • B60L 53/80 - Exchanging energy storage elements, e.g. removable batteries
  • H01M 10/44 - Methods for charging or discharging
  • H01M 50/204 - Racks, modules or packs for multiple batteries or multiple cells
  • A01D 34/37 - Driving mechanisms for the cutters electric
  • A01D 34/58 - Driving mechanisms for the cutters electric
  • B60L 50/52 - Electric propulsion with power supplied within the vehicle using propulsion power supplied by batteries or fuel cells characterised by DC-motors
  • B60L 50/60 - Electric propulsion with power supplied within the vehicle using propulsion power supplied by batteries or fuel cells using power supplied by batteries
  • H01M 50/20 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders

69.

POWER LOAD MANAGEMENT SYSTEMS AND METHODS


Application Number US2023028566
Publication Number 2024/025873
Status In Force
Filing Date 2023-07-25
Publication Date 2024-02-01
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Noller, Mark
  • Barrows, Robert

Abstract

A power management system includes a first power source, a second power source, a first electrical load, a second electrical load, a load management module configured to selectively connect power to the fist electrical load and the second electrical load, a wireless gateway communicably coupled to the first power source, the second power source, and the load management module, and a controller. The controller is configured to determine a power configuration based on an energy profile and a load profile and control operation of the load management module to provide or inhibit a connection between the first power source and the first electrical load and the second electrical load. The power configuration prioritizes the first power source over the second power source.

IPC Classes  ?

  • H02J 3/46 - Controlling the sharing of output between the generators, converters, or transformers
  • H02H 3/027 - Emergency protective circuit arrangements for automatic disconnection directly responsive to an undesired change from normal electric working condition, with or without subsequent reconnection Details with automatic disconnection after a predetermined time

70.

BATTERY PACK WITH INTEGRATED BATTERY CHARGER


Application Number US2023027802
Publication Number 2024/015593
Status In Force
Filing Date 2023-07-14
Publication Date 2024-01-18
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Mergener, Matthew
  • Jaskowiak, Ryan
  • Metcalf, Bryce

Abstract

A battery pack includes a battery housing defining an internal cavity, a first positive terminal extending through the housing, a first negative terminal extending through the housing, a plurality of battery cells within the internal cavity, and a battery charger within the internal cavity. The plurality of battery cells are electrically coupled to the first positive terminal and the first negative terminal. The battery charger is configured to charge the plurality of battery cells and includes a second positive terminal electrically coupled to the first positive terminal within the housing, and a second negative terminal electrically coupled to the first negative terminal within the housing.

IPC Classes  ?

  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries
  • H01M 10/6551 - Surfaces specially adapted for heat dissipation or radiation, e.g. fins or coatings

71.

BATTERY AND LOAD CONTROL SYSTEMS AND METHODS


Application Number US2023027898
Publication Number 2024/015629
Status In Force
Filing Date 2023-07-17
Publication Date 2024-01-18
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Schmalz, Jacob
  • Avery, Stephen Bryan
  • Marshall, Michael D.
  • Mergener, Matthew

Abstract

A lawn mower includes a drive wheel, a mowing deck including a cutting blade, a wheel motor operable to rotate the drive wheel, a cutting blade motor operable to rotate the cutting blade, and a battery system. The battery system includes a battery configured to power the wheel motor and the cutting blade motor and a battery controller communicably coupled to the battery. The battery controller includes one or more processors and memory storing instructions that, when executed by the one or more processors, cause the one or more processors to determine an electric current threshold for the battery, broadcast a message comprising the electric current threshold, compare an actual electric current of the battery to the electric current threshold, and adjust an operation of the battery system in response in response to determining that the actual electric current of the battery exceeds the electric current threshold for a predetermined amount of time.

IPC Classes  ?

  • A01D 34/00 - MowersMowing apparatus of harvesters
  • A01D 34/78 - Driving mechanisms for the cutters electric
  • A01D 69/02 - Driving mechanisms or parts thereof for harvesters or mowers electric
  • B60L 15/20 - Methods, circuits or devices for controlling the propulsion of electrically-propelled vehicles, e.g. their traction-motor speed, to achieve a desired performanceAdaptation of control equipment on electrically-propelled vehicles for remote actuation from a stationary place, from alternative parts of the vehicle or from alternative vehicles of the same vehicle train for control of the vehicle or its driving motor to achieve a desired performance, e.g. speed, torque, programmed variation of speed
  • A01D 101/00 - Lawn-mowers
  • B60R 16/033 - Electric or fluid circuits specially adapted for vehicles and not otherwise provided forArrangement of elements of electric or fluid circuits specially adapted for vehicles and not otherwise provided for electric for supply of electrical power to vehicle subsystems characterised by the use of electrical cells or batteries
  • H01M 10/48 - Accumulators combined with arrangements for measuring, testing or indicating the condition of cells, e.g. the level or density of the electrolyte
  • A01D 34/58 - Driving mechanisms for the cutters electric
  • A01D 34/64 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis mounted on a vehicle, e.g. a tractor, or drawn by an animal or a vehicle

72.

V-TWIN ENGINE ASSEMBLY


Application Number 18372502
Status Pending
Filing Date 2023-09-25
First Publication Date 2024-01-11
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zuehl, Jacob
  • Pitcel, Michael

Abstract

One embodiment of the invention relates to an internal combustion engine including an engine block having a first cylinder and a second cylinder, a crankshaft configured to rotate about a crankshaft axis, a flywheel coupled to the crankshaft, a throttle body, an air filter assembly, a first electric fan coupled to a first duct, and a second electric fan coupled to a second duct. The first duct is configured to direct cooling air directly over the first cylinder. The second duct is configured to direct cooling air directly over the second cylinder. The first cylinder is at least partially within the first duct. The second cylinder is at least partially within the second duct.

IPC Classes  ?

  • F01P 5/02 - Pumping cooling-airArrangements of cooling-air pumps, e.g. fans or blowers
  • F01P 1/02 - Arrangements for cooling cylinders or cylinder heads, e.g. ducting cooling-air from its pressure source to cylinders or along cylinders
  • F02D 9/02 - Controlling engines by throttling air or fuel-and-air induction conduits or exhaust conduits concerning induction conduits

73.

Internal combustion engine with reduced oil maintenance


Application Number 18369662
Grant Number 12276235
Status In Force
Filing Date 2023-09-18
First Publication Date 2024-01-11
Grant Date 2025-04-15
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zuehl, Jacob
  • Sebzda, Richard
  • Moss, Vernon

Abstract

An internal combustion engine includes an engine block, a piston, and a cylinder head. The engine block includes a cylinder block having a cylinder bore, a crankcase defining a crankcase chamber with a crankshaft positioned within the crankcase chamber, and a cylinder sleeve fabricated from a self-lubricating plastic material. The cylinder head is coupled to the cylinder block to form a combustion chamber. The piston includes a piston top adjacent the combustion chamber, a piston body including a wrist pin hole configured to receive a wrist pin, a first piston ring positioned on the piston body, and a non-metallic gasket positioned on the piston body closer to the combustion chamber than the first piston ring and structured to prevent combustion gases from escaping the combustion chamber. The crankcase chamber is oilless.

IPC Classes  ?

  • F02P 1/06 - Generator drives, e.g. having snap couplings
  • F01L 1/14 - TappetsPush-rods
  • F01L 1/18 - Rocking arms or levers
  • F01L 3/02 - Selecting particular materials for valve members or valve seatsValve members or valve seats composed of two or more materials
  • F01P 1/00 - Air cooling
  • F02F 1/00 - CylindersCylinder heads
  • F02F 3/00 - Pistons
  • F02F 7/00 - Casings, e.g. crankcases
  • F16J 9/28 - Piston-rings, seats thereforRing sealings of similar construction in general characterised by the use of particular materials of non-metals
  • F16C 7/02 - Constructions of connecting-rods with constant length

74.

MOTOR CONTROLLER MODULE


Application Number 18243998
Status Pending
Filing Date 2023-09-08
First Publication Date 2024-01-04
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Schulenberg, David
  • Schmalz, Jacob

Abstract

A controller module includes an enclosure including an inner wall defining a volume, a plurality of motor controllers, each motor controller comprising a printed circuit board (PCB) having a first side and a second side opposite the first side, a plurality of transistors located on the first side, and a plurality of outputs located on the second side. The first side of the PCB is positioned adjacent to the inner wall of the enclosure to allow heat generated by the motor controller to dissipate via the enclosure.

IPC Classes  ?

  • H02P 5/52 - Arrangements specially adapted for regulating or controlling the speed or torque of two or more electric motors for speed regulation of two or more dynamo-electric motors in relation to one another additionally providing control of relative angular displacement
  • G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]
  • H02P 6/14 - Electronic commutators
  • H02P 4/00 - Arrangements specially adapted for regulating or controlling the speed or torque of electric motors that can be connected to two or more different electric power supplies

75.

Turf aerators and assemblies for same


Application Number 18229935
Grant Number 12193346
Status In Force
Filing Date 2023-08-03
First Publication Date 2023-11-30
Grant Date 2025-01-14
Owner Briggs & Stratton, LLC (USA)
Inventor
  • King, Brandon
  • Coates, William

Abstract

A turf aerator includes a frame, a tine shaft rotatably supported by the frame, a plurality of tines coupled to the tine shaft, a swing arm supporting the plurality of tines, and an input. The swing arm being rotatably supported by the frame and configured to rotate the plurality of tines between an operating position and a retracted position. Actuation of the input (i) actuates the swing arm to transition the plurality of tines from the retracted position to the operating position and (ii) activates the tine shaft to move the plurality of tines.

IPC Classes  ?

  • A01B 45/02 - Machines for treating meadows or lawns for aerating

76.

BLUEVOLT


Application Number 018956648
Status Registered
Filing Date 2023-11-28
Registration Date 2024-05-15
Owner Briggs & Stratton, LLC (USA)
NICE Classes  ?
  • 07 - Machines and machine tools
  • 12 - Land, air and water vehicles; parts of land vehicles

Goods & Services

Electric powered lawn and garden tools, namely, lawn mowers and snow blowers and parts therefor; accessories for electric powered lawn mowers, namely, grass catchers and collection system, tire chains, headlight kits, hitch kits, blades, and dump carts. Electric powered tractors and parts and accessories therefor, namely, dump carts, tractor cabs, tractor hitches, tractor balancing counterweights for tractor wheels, and balancing weights for tractor wheels.

77.

BLUEVOLT


Application Number 018956735
Status Registered
Filing Date 2023-11-28
Registration Date 2024-05-15
Owner Briggs & Stratton, LLC (USA)
NICE Classes  ?
  • 07 - Machines and machine tools
  • 12 - Land, air and water vehicles; parts of land vehicles

Goods & Services

Electric powered lawn and garden tools, namely, lawn mowers and snow blowers and parts therefor; accessories for electric powered lawn mowers, namely, grass catchers and collection system, tire chains, headlight kits, hitch kits, blades, and dump carts. Electric powered tractors and parts and accessories therefor, namely, dump carts, tractor cabs, tractor hitches, tractor balancing counterweights for tractor wheels, and balancing weights for tractor wheels.

78.

BLUEVOLT


Application Number 018956626
Status Registered
Filing Date 2023-11-28
Registration Date 2024-05-15
Owner Briggs & Stratton, LLC (USA)
NICE Classes  ?
  • 07 - Machines and machine tools
  • 12 - Land, air and water vehicles; parts of land vehicles

Goods & Services

Electric powered lawn and garden tools, namely, lawn mowers and snow blowers and parts therefor; accessories for electric powered lawn mowers, namely, grass catchers and collection system, tire chains, headlight kits, hitch kits, blades, and dump carts. Electric powered tractors and parts and accessories therefor, namely, dump carts, tractor cabs, tractor hitches, tractor balancing counterweights for tractor wheels, and balancing weights for tractor wheels.

79.

Inverter generator


Application Number 18222894
Grant Number 12074503
Status In Force
Filing Date 2023-07-17
First Publication Date 2023-11-23
Grant Date 2024-08-27
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Cirillo, Joshua Thurnbauer
  • Helwig, Philip
  • Lim, Sie Teong
  • Molinski, Mark Thomas
  • Stair, Kenny Jalmas
  • Townsend, Robert
  • Whitmore, Jeffrey H.
  • Byaliy, Svetlana

Abstract

A generator includes an internal combustion engine including an engine block including a cylinder including a piston, a crankshaft configured to rotate about a crankshaft axis in response to movement by the piston, and a spark plug configured to periodically generate a spark to ignite fuel in the cylinder to control the movement of the piston. The generator further includes an alternator including a rotor and a stator, the rotor configured to rotate with the rotation of the crankshaft to generate alternating current electrical power, a controller configured to control a rate of fuel supply to the internal combustion engine, and a switch configured to selectively enable the flow of a first type of fuel into the cylinder and disable the flow of a second type of fuel, wherein the controller is configured to receive an indication of a fuel type based on a position of the switch.

IPC Classes  ?

  • H02K 7/18 - Structural association of electric generators with mechanical driving motors, e.g.with turbines
  • F02B 63/04 - Adaptations of engines for driving pumps, hand-held tools or electric generatorsPortable combinations of engines with engine-driven devices for electric generators
  • F02B 69/04 - Internal-combustion engines convertible into other combustion-engine type, not provided for in group Internal-combustion engines of different types characterised by constructions facilitating use of same main engine-parts in different types for different fuel types, other than engines indifferent to fuel consumed, e.g. convertible from light to heavy fuel for gaseous and non-gaseous fuels
  • F02P 5/15 - Digital data processing
  • H02K 5/22 - Auxiliary parts of casings not covered by groups , e.g. shaped to form connection boxes or terminal boxes
  • H02K 9/06 - Arrangements for cooling or ventilating by ambient air flowing through the machine having means for generating a flow of cooling medium with fans or impellers driven by the machine shaft
  • H02K 13/12 - Arrangements for producing an axial reciprocation of the rotor and its associated current collector part, e.g. for polishing commutator surfaces
  • H02P 1/12 - Switching devices centrifugally operated by the motor
  • H02P 6/08 - Arrangements for controlling the speed or torque of a single motor
  • H02P 9/00 - Arrangements for controlling electric generators for the purpose of obtaining a desired output
  • H02P 9/04 - Control effected upon non-electric prime mover and dependent upon electric output value of the generator
  • H02P 27/06 - Arrangements or methods for the control of AC motors characterised by the kind of supply voltage using variable-frequency supply voltage, e.g. inverter or converter supply voltage using DC to AC converters or inverters
  • H02P 101/25 - Special adaptation of control arrangements for generators for combustion engines

80.

ELECTRIC MOTOR FOR OUTDOOR POWER EQUIPMENT


Application Number 18227630
Status Pending
Filing Date 2023-07-28
First Publication Date 2023-11-16
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zeiler, Jeffrey M.
  • Funke, Scott A.
  • Noller, Mark
  • Zeidler, Nick Joseph
  • Krajewski, Christopher
  • Kowalski, Joshua

Abstract

A lawn mower includes a chassis supporting a wheel, a cutting deck supported by the chassis and defining a cutting chamber, a battery supported by the chassis, and a chore motor electrically coupled to the battery. The chore motor includes a housing with a coil assembly, a rotor, and a drive shaft extending out of the housing. The chore motor is attached to the cutting deck so that at least a portion of the housing and the drive shaft are positioned in the cutting chamber. The lawn mower further includes a blade coupled to the drive shaft so that the blade rotates within the cutting chamber when the chore motor rotates the drive shaft, and a spring washer coupled between the drive shaft and the blade. Relative rotation between the blade and the drive shaft occurs in response to a torque on the blade exceeding a threshold value.

IPC Classes  ?

81.

PORTABLE LIGHTING SYSTEM INCLUDING LIGHT TOWER AND INVERTER HAVING REMOVABLE BATTERY PACK


Application Number 18225455
Status Pending
Filing Date 2023-07-24
First Publication Date 2023-11-16
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Harvey, Kyle
  • Zeidler, Nicholas

Abstract

A light tower includes a base having a plurality of wheels, an extendible mast coupled to the base, a battery pack positioned between the wheels and the extendible mast, a housing coupled to the base and having a main battery receiver and a supplemental battery receiver, a light assembly coupled to the extendible mast and electrically coupled to the battery pack, and an inverter configured to receive and convert a direct current power from the battery pack into an alternating current power. The main battery receiver defines an internal cavity having an open top side, and the supplemental battery receiver defines a slot arranged on an exterior of the housing.

IPC Classes  ?

  • F21L 4/04 - Electric lighting devices with self-contained electric batteries or cells characterised by provision of a light source housing portion adjustably fixed to the remainder of the device
  • F21L 14/04 - Electric lighting devices without a self-contained power source, e.g. for mains connection carried on wheeled supports
  • F21V 21/06 - Bases for movable standing lampsFixing standards to the bases
  • F21V 21/14 - Adjustable mountings
  • F21V 21/26 - Pivoted arms
  • H02M 7/44 - Conversion of DC power input into AC power output without possibility of reversal by static converters
  • F21V 21/22 - Adjustable mountings telescopic
  • H05B 47/10 - Controlling the light source

82.

Vehicle for transporting and charging outdoor power equipment


Application Number 18225557
Grant Number 12500440
Status In Force
Filing Date 2023-07-24
First Publication Date 2023-11-16
Grant Date 2025-12-16
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Koenen, Robert J.
  • Funke, Scott A.
  • Johnson, Todd
  • Noller, Mark
  • Ziedler, Nicholas Joseph
  • Zuehl, Jacob

Abstract

A trailer includes a first power equipment having an equipment battery pack, a charging device having a primary battery pack, and a docking station electrically connected to the primary battery pack. When the first power equipment is positioned in the docking station, the docking station supplies power from the primary battery pack to the equipment battery pack to recharge the equipment battery pack.

IPC Classes  ?

  • B60R 16/033 - Electric or fluid circuits specially adapted for vehicles and not otherwise provided forArrangement of elements of electric or fluid circuits specially adapted for vehicles and not otherwise provided for electric for supply of electrical power to vehicle subsystems characterised by the use of electrical cells or batteries
  • B60L 1/00 - Supplying electric power to auxiliary equipment of electrically-propelled vehicles
  • B60P 1/43 - Vehicles predominantly for transporting loads and modified to facilitate loading, consolidating the load, or unloading using a loading ramp mounted on the vehicle
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries
  • H02J 7/34 - Parallel operation in networks using both storage and other DC sources, e.g. providing buffering

83.

Cyclonic air filter assembly for an engine


Application Number 18227641
Grant Number 12251655
Status In Force
Filing Date 2023-07-28
First Publication Date 2023-11-16
Grant Date 2025-03-18
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Gleixner, Steven G.
  • Johnson, Robert

Abstract

An air filter assembly includes a housing having an interior surface that defines an interior volume, a filter element positioned within the interior volume and having a filter media, an air intake formed in the housing, a debris outlet formed in the housing, a filtered air outlet formed in the housing, and a plurality of ribs. The filter element is spaced from the interior surface so that a gap is formed between the filter element and the interior surface to allow air to flow between the filter element and the interior surface. The plurality of ribs extend into the interior volume of the housing so that air flowing from the air intake is directed into the gap and around the filter element to complete a cyclonic filtering pass before flowing along a second airflow pass through the filter element. The outlet passage is configured to direct filtered air into a third airflow pass in a direction opposite to the second airflow pass.

IPC Classes  ?

  • B01D 46/00 - Filters or filtering processes specially modified for separating dispersed particles from gases or vapours
  • B01D 45/16 - Separating dispersed particles from gases or vapours by gravity, inertia, or centrifugal forces by centrifugal forces generated by the winding course of the gas stream
  • B01D 46/16 - Particle separators, e.g. dust precipitators, using filter plates, sheets or pads having plane surfaces arranged on non-filtering conveyors
  • B01D 46/24 - Particle separators, e.g. dust precipitators, using rigid hollow filter bodies
  • B01D 46/48 - Removing dust other than cleaning filters
  • B01D 50/20 - Combinations of devices covered by groups and
  • F02M 35/02 - Air cleaners
  • F02M 35/022 - Air cleaners acting by gravity, by centrifugal, or by other inertial forces, e.g. with moistened walls
  • F02M 35/024 - Air cleaners using filters, e.g. moistened
  • F02M 35/08 - Air cleaners with means for removing dust from cleanersAir cleaners with means for indicating cloggingAir cleaners with by-pass means

84.

Ignition coil for internal combustion engine


Application Number 18135439
Grant Number 12067817
Status In Force
Filing Date 2023-04-17
First Publication Date 2023-10-26
Grant Date 2024-08-20
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Clasen, Kyle
  • Roche, Daniel

Abstract

An ignition coil includes an ignition circuit having a first winding and a second winding, a controller in communication with the ignition circuit, and a light. The ignition circuit is configured to output an ignition timing signal. The controller is configured to establish a rule that limits an engine speed to a maximum engine speed to be provided by the ignition timing signal. The light is configured to illuminate and indicate the maximum engine speed in response to an output signal from the controller.

IPC Classes  ?

  • F02P 5/00 - Advancing or retarding electric ignition sparkControl therefor
  • F02P 3/04 - Layout of circuits
  • F02P 5/15 - Digital data processing
  • G07C 5/08 - Registering or indicating performance data other than driving, working, idle, or waiting time, with or without registering driving, working, idle, or waiting time

85.

DEBRIS-COLLECTING APPARATUS AND METHOD OF COLLECTING DEBRIS


Application Number 18217300
Status Pending
Filing Date 2023-06-30
First Publication Date 2023-10-26
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Lauer, G. Kent
  • Morton, Iii, William Jackson

Abstract

A debris-collecting apparatus includes a mobile frame, an input portion configured to receive incoming air and debris, and a bagging system having a porous bag and a dust skirt surrounding the porous bag.

IPC Classes  ?

  • A01G 20/47 - Vacuum or blower devices
  • A01D 43/077 - Mowers combined with apparatus performing additional operations while mowing with means for collecting, gathering or loading mown material with auxiliary means, e.g. fans, for transporting the mown crop
  • A01D 43/063 - Mowers combined with apparatus performing additional operations while mowing with means for collecting, gathering or loading mown material in or into a container carried by the mowerContainers therefor
  • A47L 9/14 - Bags or the likeAttachment of, or closures for, bags
  • A47L 9/16 - Arrangement or disposition of cyclones or other devices with centrifugal action
  • E01H 1/08 - Pneumatically dislodging or taking-up undesirable matterDrying by heat only, or by streams of gasCleaning by projecting abrasive particles

86.

Cooling system for air-cooled engine


Application Number 18210782
Grant Number 12203426
Status In Force
Filing Date 2023-06-16
First Publication Date 2023-10-19
Grant Date 2025-01-21
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Sullivan, Ryan A.
  • Johnson, Gary S.

Abstract

A method of operating a fan for an air-cooled internal combustion engine includes starting the air-cooled internal combustion engine, operating the fan in a first operating mode in which the fan rotates in a first direction, and operating the fan in a second operating mode in which the fan rotates in a second direction.

IPC Classes  ?

  • F01P 1/00 - Air cooling
  • F01P 1/02 - Arrangements for cooling cylinders or cylinder heads, e.g. ducting cooling-air from its pressure source to cylinders or along cylinders
  • F01P 5/02 - Pumping cooling-airArrangements of cooling-air pumps, e.g. fans or blowers
  • F01P 5/04 - Pump-driving arrangements
  • F01P 11/12 - Filtering, cooling, or silencing cooling-air
  • F02B 75/00 - Other engines, e.g. single-cylinder engines
  • F02B 75/22 - Multi-cylinder engines with cylinders in V-, fan-, or star-arrangement
  • F02F 7/00 - Casings, e.g. crankcases
  • F02B 75/18 - Multi-cylinder engines

87.

SYSTEMS AND DEVICES FOR LAWN CARE


Application Number 18209959
Status Pending
Filing Date 2023-06-14
First Publication Date 2023-10-12
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zeiler, Jeffrey M.
  • Hahn, Ryan T.
  • Harvey, Kyle
  • Johnson, Todd
  • Pjevach, Robert
  • Schmalz, Jacob
  • Shears, Peter D.
  • Zeidler, Nicholas

Abstract

A service vehicle for storing and transporting outdoor power equipment includes a loading/unloading ramp, a charging bay configured to charge a rechargeable battery pack mounted on a first piece of outdoor power equipment, a spare battery charging station configured to store and selectively charge a spare rechargeable battery pack, a user interface having a display, and a controller in communication with the user interface and having a processing circuit with a charging module. The controller is configured to receive a charge level of the rechargeable battery pack and the spare rechargeable battery pack from the charging module and instruct the user interface to display the charge levels.

IPC Classes  ?

  • A01D 34/00 - MowersMowing apparatus of harvesters
  • G05D 1/00 - Control of position, course, altitude or attitude of land, water, air or space vehicles, e.g. using automatic pilots
  • B65G 67/02 - Loading or unloading land vehicles
  • G05D 1/02 - Control of position or course in two dimensions

88.

Battery pack with cell module assemblies


Application Number 18210375
Grant Number 12500281
Status In Force
Filing Date 2023-06-15
First Publication Date 2023-10-12
Grant Date 2025-12-16
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Schmalz, Jacob
  • Zeidler, Nick

Abstract

A battery pack includes a housing and a plurality of cell module assemblies arranged within the housing. Each of the cell module assemblies includes a positive collector plate, a negative collector plate, and a plurality of battery cells. Each of the plurality of battery cells includes a positive terminal connected to the positive collector plate and a negative terminal connected to the negative collector plate. A number of the plurality of the cell module assemblies within the housing defines a capacity of the battery pack.

IPC Classes  ?

  • H01M 10/48 - Accumulators combined with arrangements for measuring, testing or indicating the condition of cells, e.g. the level or density of the electrolyte
  • H01M 50/204 - Racks, modules or packs for multiple batteries or multiple cells
  • H01M 50/213 - Racks, modules or packs for multiple batteries or multiple cells characterised by their shape adapted for cells having curved cross-section, e.g. round or elliptic
  • H01M 50/296 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders characterised by terminals of battery packs
  • H01M 50/298 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders characterised by the wiring of battery packs
  • H01M 50/509 - Interconnectors for connecting terminals of adjacent batteriesInterconnectors for connecting cells outside a battery casing characterised by the type of connection, e.g. mixed connections
  • H01M 50/512 - Connection only in parallel
  • A01D 69/02 - Driving mechanisms or parts thereof for harvesters or mowers electric
  • A01D 101/00 - Lawn-mowers
  • A47L 11/40 - Parts or details of machines not provided for in groups , or not restricted to one of these groups, e.g. handles, arrangements of switches, skirts, buffers or levers
  • B60R 16/033 - Electric or fluid circuits specially adapted for vehicles and not otherwise provided forArrangement of elements of electric or fluid circuits specially adapted for vehicles and not otherwise provided for electric for supply of electrical power to vehicle subsystems characterised by the use of electrical cells or batteries
  • B66F 9/075 - Constructional features or details
  • B66F 11/04 - Lifting devices specially adapted for particular uses not otherwise provided for for movable platforms or cabins, e.g. on vehicles, permitting workmen to place themselves in any desired position for carrying out required operations

89.

SMALL AIR-COOLED ENGINE WITH CATALYTIC CONVERTER WITH RUTHENIUM CATALYST


Application Number 17925979
Status Pending
Filing Date 2021-05-21
First Publication Date 2023-10-05
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Zuehl, Jacob
  • Pitcel, Michael D.

Abstract

A small-air cooled internal combustion engine includes an engine block including a cylinder, a piston within the cylinder, a crankshaft configured to be driven by the piston, a blower system including a fan that is configured to pull air over the engine block, a fuel system for supplying an air-fuel mixture to the cylinder, and an exhaust system for removing exhaust from the cylinder. The exhaust system comprises an exhaust inlet, a muffler and, a catalytic converter including a catalyst. The catalyst comprises a precious metal loading having ruthenium as a primary element by mass.

IPC Classes  ?

  • F01N 3/10 - Exhaust or silencing apparatus having means for purifying, rendering innocuous, or otherwise treating exhaust for rendering innocuous by thermal or catalytic conversion of noxious components of exhaust
  • F01P 1/02 - Arrangements for cooling cylinders or cylinder heads, e.g. ducting cooling-air from its pressure source to cylinders or along cylinders
  • F01P 1/06 - Arrangements for cooling other engine or machine parts
  • F01P 5/04 - Pump-driving arrangements
  • B01J 23/46 - Ruthenium, rhodium, osmium or iridium
  • B01J 23/42 - Platinum

90.

Towable heater


Application Number 18207231
Grant Number 12215894
Status In Force
Filing Date 2023-06-08
First Publication Date 2023-10-05
Grant Date 2025-02-04
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Hahn, Ryan
  • Sabatka, Paul
  • Booth, Cole

Abstract

A portable heater includes a housing having an air inlet and an air outlet, one or more burners housing within the housing and configured to heat air passing through the housing from the air inlet to the air outlet, and a duct positioned in a storage compartment of the housing. The duct includes a first end coupled to the storage compartment and a second end extendable from the housing when a door of the storage compartment is in an open position.

IPC Classes  ?

  • F24H 9/06 - Arrangement of mountings or supports
  • B60P 3/00 - Vehicles adapted to transport, to carry or to comprise special loads or objects
  • B62D 21/20 - Understructures, i.e. chassis frame on which a vehicle body may be mounted characterised by the vehicle type and not provided for in groups trailer type, i.e. a frame specifically constructed for use in a non-powered vehicle
  • B62D 63/08 - Component parts or accessories
  • F24H 9/18 - Arrangement or mounting of grates or heating means

91.

Lawn mower with pivotal rocker arm assembly


Application Number 18204699
Grant Number 12329062
Status In Force
Filing Date 2023-06-01
First Publication Date 2023-09-28
Grant Date 2025-06-17
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Johnson, Todd
  • Krajewski, Christopher
  • Zeidler, Nicholas
  • Schmalz, Jacob
  • Dandridge, Bryan Keith
  • Jaskowiak, Ryan
  • Zurawski, Matthew Steven
  • Hahn, Ryan

Abstract

An outdoor power equipment device, such as a lawn mower, includes a main chassis having first and second pivot joints, a first rocker arm having a caster wheel on a first end portion and a drive wheel on a second end portion, and a second rocker arm having a caster wheel on a first end portion and a drive wheel on a second end portion, wherein the first rocker arm and the second rocker arm are independently pivotally coupled to the respective first and second pivot joints of the main chassis at a location between the caster wheels and the drive wheels.

IPC Classes  ?

  • A01D 34/00 - MowersMowing apparatus of harvesters
  • A01D 34/66 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis mounted on a vehicle, e.g. a tractor, or drawn by an animal or a vehicle with two or more cutters
  • A01D 34/71 - MowersMowing apparatus of harvesters characterised by features relating to the type of cutting apparatus having rotating cutters having cutters rotating about a vertical axis with means for discharging mown material
  • A01D 34/78 - Driving mechanisms for the cutters electric
  • A01D 34/82 - Other details
  • A01D 67/04 - Seats
  • B60G 15/06 - Resilient suspensions characterised by arrangement, location, or type of combined spring and vibration- damper, e.g. telescopic type having mechanical spring and fluid damper
  • B60K 1/02 - Arrangement or mounting of electrical propulsion units comprising more than one electric motor
  • B60K 7/00 - Disposition of motor in, or adjacent to, traction wheel
  • B60K 35/00 - Instruments specially adapted for vehiclesArrangement of instruments in or on vehicles
  • B60N 2/015 - Attaching seats directly to vehicle chassis
  • B62D 1/04 - Hand wheels
  • B62D 15/02 - Steering position indicators
  • B62D 21/02 - Understructures, i.e. chassis frame on which a vehicle body may be mounted comprising longitudinally or transversely arranged frame members
  • B62D 21/11 - Understructures, i.e. chassis frame on which a vehicle body may be mounted with resilient means for suspension
  • E01H 5/06 - Apparatus propelled by animal or engine powerApparatus propelled by hand with driven dislodging or conveying elements, e.g. conveying pneumatically dislodging essentially by non-driven elements, e.g. scraper blades
  • A01D 101/00 - Lawn-mowers
  • B60K 35/10 - Input arrangements, i.e. from user to vehicle, associated with vehicle functions or specially adapted therefor
  • B60K 35/22 - Display screens

92.

Stand-on outdoor power equipment for aerating soil


Application Number 18195228
Grant Number 11963471
Status In Force
Filing Date 2023-05-09
First Publication Date 2023-08-31
Grant Date 2024-04-23
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Harvey, Kyle
  • Burkard, Thomas
  • Lucier, Peter
  • Longmeyer, Stephen

Abstract

A stand-on aerator includes a chassis, an operator platform extending from a rear portion of the chassis, an aerator assembly coupled to the chassis and having a plurality of reciprocating tines configured to extend from and retract into the aerator assembly, and an object detection sensor. At least a portion of the plurality of reciprocating tines are configured to retract in response to the object detection sensor detecting an object in a path of the aerator assembly.

IPC Classes  ?

  • A01B 45/02 - Machines for treating meadows or lawns for aerating
  • A01B 75/00 - Carriers for supporting persons when working in the field, e.g. while thinning beet

93.

VANGUARD


Application Number 018914185
Status Registered
Filing Date 2023-08-16
Registration Date 2024-01-30
Owner Briggs & Stratton, LLC (USA)
NICE Classes  ? 07 - Machines and machine tools

Goods & Services

Electric motors for industrial applications, turf equipment, agricultural equipment, golf carts, and machinery; electric motor controllers.

94.

VANGUARD


Serial Number 98133014
Status Pending
Filing Date 2023-08-15
Owner Briggs & Stratton, LLC ()
NICE Classes  ?
  • 07 - Machines and machine tools
  • 09 - Scientific and electric apparatus and instruments
  • 12 - Land, air and water vehicles; parts of land vehicles

Goods & Services

Electric motors for industrial applications, namely, electric motors for power tools and construction machinery; Electric motors for turf and agricultural machines Electronic controls for motors Electric motors for industrial applications, namely, electric motors for land vehicles in the nature of golf carts

95.

F


Application Number 227358400
Status Pending
Filing Date 2023-08-04
Owner Briggs & Stratton, LLC (USA)
NICE Classes  ? 07 - Machines and machine tools

Goods & Services

(1) Lawn mowers; Riding lawn mowers; Gasoline lawn mowers; Electric lawn mowers; Ride-on lawn mowers; Power machines for mowing; Containers for use with mechanical spreaders, namely, cartridges, bags, and pouches for seed, lawn fertilizers, pesticides and other chemicals; Lawn mower blades; Mechanical spreaders; Power-operated sprayers; Spraying machines; Power operated blowers; Power blowers for lawn debris; Fertilizer distributing machines, other than hand-operated implements; Agricultural machinery and attachments, namely, fertilizer spreaders; Lawn and yard maintenance machinery, commercial mowing equipment; Attachments and accessories of the foregoing

96.

Miscellaneous Design


Application Number 018910296
Status Registered
Filing Date 2023-08-04
Registration Date 2024-01-27
Owner Briggs & Stratton, LLC (USA)
NICE Classes  ? 07 - Machines and machine tools

Goods & Services

Lawn mowers; Riding lawn mowers; Gasoline lawn mowers; Electric lawn mowers; Ride-on lawn mowers; Power machines for mowing; Containers for use with mechanical spreaders, namely, cartridges, bags, and pouches for seed, lawn fertilizers, pesticides and other chemicals; Lawn mower blades; Mechanical spreaders; Power-operated sprayers; Spraying machines; Power operated blowers; Power blowers for lawn debris; Fertilizer distributing machines, other than hand-operated implements; Agricultural machinery and attachments, namely, fertilizer spreaders; Lawn and yard maintenance machinery, commercial mowing equipment; Attachments and accessories of the foregoing.

97.

FERRIS


Application Number 018910315
Status Pending
Filing Date 2023-08-04
Owner Briggs & Stratton, LLC (USA)
NICE Classes  ? 07 - Machines and machine tools

Goods & Services

Lawn mowers; Riding lawn mowers; Gasoline lawn mowers; Electric lawn mowers; Ride-on lawn mowers; Power machines for mowing; Containers for use with mechanical spreaders, namely, cartridges, bags, and pouches for seed, lawn fertilizers, pesticides and other chemicals; Lawn mower blades; Mechanical spreaders; Power-operated sprayers; Spraying machines; Power operated blowers; Power blowers for lawn debris; Fertilizer distributing machines, other than hand-operated implements; Agricultural machinery and attachments, namely, fertilizer spreaders; Attachments and accessories of the foregoing.

98.

FERRIS F


Application Number 227358600
Status Pending
Filing Date 2023-08-04
Owner Briggs & Stratton, LLC (USA)
NICE Classes  ? 07 - Machines and machine tools

Goods & Services

(1) Lawn mowers; Riding lawn mowers; Gasoline lawn mowers; Electric lawn mowers; Ride-on lawn mowers; Power machines for mowing; Containers for use with mechanical spreaders, namely, cartridges, bags, and pouches for seed, lawn fertilizers, pesticides and other chemicals; Lawn mower blades; Mechanical spreaders; Power-operated sprayers; Spraying machines; Power operated blowers; Power blowers for lawn debris; Fertilizer distributing machines, other than hand-operated implements; Agricultural machinery and attachments, namely, fertilizer spreaders; Attachments and accessories of the foregoing

99.

User-scalable power unit including removable battery packs


Application Number 18128548
Grant Number 12291091
Status In Force
Filing Date 2023-03-30
First Publication Date 2023-07-27
Grant Date 2025-05-06
Owner Briggs & Stratton, LLC (USA)
Inventor
  • Zeiler, Jeffrey
  • Koenen, Robert John
  • Schmalz, Jacob
  • Liu, Albert
  • Zeidler, Nick
  • Funke, Scott
  • Procknow, David

Abstract

A riding lawn mower comprising, a pair of rear drive wheels, a pair of front wheels, a deck positioned between the pair of front wheels and the pair of rear drive wheels, a rotatable cutting blade, and multiple battery packs removably coupled to the riding lawn mower and structured to provide power to the riding lawn mower, each battery pack graspable and removable by a user, wherein the multiple battery packs sequentially provide power to the riding lawn mower.

IPC Classes  ?

  • B60K 1/04 - Arrangement or mounting of electrical propulsion units of the electric storage means for propulsion
  • A01D 69/02 - Driving mechanisms or parts thereof for harvesters or mowers electric
  • B60L 50/60 - Electric propulsion with power supplied within the vehicle using propulsion power supplied by batteries or fuel cells using power supplied by batteries
  • B60L 53/80 - Exchanging energy storage elements, e.g. removable batteries
  • B60L 58/22 - Balancing the charge of battery modules
  • H01M 10/42 - Methods or arrangements for servicing or maintenance of secondary cells or secondary half-cells
  • H01M 10/44 - Methods for charging or discharging
  • H01M 50/213 - Racks, modules or packs for multiple batteries or multiple cells characterised by their shape adapted for cells having curved cross-section, e.g. round or elliptic
  • H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries
  • H02J 7/14 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries for charging batteries from dynamo-electric generators driven at varying speed, e.g. on vehicle

100.

ENGINE CALIBRATION SYSTEMS AND METHODS


Application Number US2023010939
Publication Number 2023/141100
Status In Force
Filing Date 2023-01-17
Publication Date 2023-07-27
Owner BRIGGS & STRATTON, LLC (USA)
Inventor
  • Braun, Michael Paul
  • Brunelli, Brian Todd
  • Cavness, Darren E.
  • Divis, Mario
  • Jury, Brett William
  • Noller, Mark
  • Piechowski, John A.

Abstract

A method for recalibrating an engine includes querying an engine for a unique engine identifier, sending the unique engine identifier to a cloud-based server, determining one or more engine calibration settings available to the engine based on the unique engine identifier sent to the cloud-based server, presenting the one or more engine calibration settings to a user through a user interface so that the user may select a desired engine calibration setting, sending the desired engine calibration setting as selected by the user to an electronic control unit of the engine, and replacing a current engine calibration with the desired engine calibration setting in the electronic control unit of the engine.

IPC Classes  ?

  • F02D 41/24 - Electrical control of supply of combustible mixture or its constituents characterised by the use of digital means
  1     2     3     ...     7        Next Page
