Provided is a connector that keeps a potting material from entering through an engagement hole. A connector according to the present invention includes a housing and a terminal. The housing includes a first part that supports the terminal and a second part that is provided on one side in a first direction of the first part and includes an accommodation part. The accommodation part is open on the one side in the first direction and includes a wall part on one side in a second direction that is substantially orthogonal to the first direction. The wall part stands in the first direction and includes an engagement hole that passes in the second direction. The housing includes a turn part on the other side in the first direction of the engagement hole. The turn part includes a first end surface that faces the one side in the second direction, a turn surface that is connected to the first end surface and faces the other side in the first direction, and a first wall surface that is connected to the turn surface and faces the one side in the second direction.
A connector including an electrically conductive shell with a generally tubular shell body, a body insert-molded inside the shell body, a terminal entirely disposed inside the shell body, and a cable. The shell body extends in a first direction. The body is entirely housed inside the shell body, is exposed from inside the shell body to one side in the first direction, and includes a housing hole extending through the body in the first direction. An intermediate portion of the terminal is at least partly retained in the housing hole. A rear portion of the terminal is disposed in the housing hole, or alternatively protrudes from the housing hole to the other side in the first direction. The cable is partly received inside the shell body from the other side in the first direction and connected to the rear portion of the terminal inside the shell body.
H01R 13/405 - Securing in non-demountable manner, e.g. moulding, riveting
H01R 24/40 - Two-part coupling devices, or either of their cooperating parts, characterised by their overall structure having concentrically or coaxially arranged contacts specially adapted for high frequency
H01R 43/24 - Assembling by moulding on contact members
A detection sensor including a sensor unit and a holder. The unit includes a vibratable film and a case. The case accommodates the film and includes an opening disposed on one side in a first direction relative to the film. The holder includes a holding portion holding the unit, a front portion disposed on the one side in the first direction relative to the case, a transmissive part, a sound hole for sound-wave input, and a sound path extending from the sound hole to the opening. The transmissive part is configured to transmit at least infrared rays, provided at the front portion, disposed on the one side in the first direction relative to the opening and the film, and opposed to the film. The sound hole is provided in a portion around the transmissive part of the front portion and open to the one side in the first direction.
G01J 5/34 - Radiation pyrometry, e.g. infrared or optical thermometry using electric radiation detectors using capacitors, e.g. pyroelectric capacitors
G01H 11/08 - Measuring mechanical vibrations or ultrasonic, sonic or infrasonic waves by detecting changes in electric or magnetic properties by electric means using piezoelectric devices
4.
HYBRID CONNECTOR AND CONNECTION STRUCTURE OF HYBRID CONNECTORS INCLUDING THE SAME
A hybrid connector including a housing constituted by an insulating material, a first connecting portion protruding from the housing to one side in a first direction, at least one first terminal inside the first connecting portion, a second connecting portion protruding from the housing to the one side in the first direction and being disposed on one side in a second direction relative to and in spaced relation to the first connecting portion, at least one second terminal inside the second connecting portion, and at least one anti-misinsertion projection provided at the second connecting portion such as to project to the other side in the second direction and disposed between the first and second connecting portions in the second direction. The second direction is substantially orthogonal to the first direction.
This sensor device (100) acquires a measurement value of an instrument (G1) having: a magnet (G18) that rotates together with a pointer (G14) around an axis (AX) of a shaft member (G17) orthogonal to a scale-marked scale surface (G16a) of a scale plate (G16); and a transparent plate (G15) that covers the scale plate (G16), the pointer (G14), and the magnet (G18). The sensor device (100) comprises: a sensor device body (D1) that is disposed so as to overlap the axis (AX) when viewed in a direction along an axial direction (Z) of the axis (AX), has a sensor unit (21) for acquiring position information about the magnet (G18), and acquires a measurement value on the basis of the position information; and an attachment unit (A1) for attaching the sensor device body (D1) to the instrument (G1).
G01D 5/12 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means
A speaker includes a speaker unit having a diaphragm, an attachment member attached to an attachment object of the speaker unit, and an elastic body interposed between the speaker unit and the attachment member. The elastic body has a thin plate structure and connects the speaker unit and the attachment member at both ends of the elastic body in a state where a plate thickness direction is aligned with a vibration direction of the diaphragm.
H04R 1/28 - Transducer mountings or enclosures designed for specific frequency responseTransducer enclosures modified by provision of mechanical or acoustic impedances, e.g. resonator, damping means
This sensor device system is provided with a sensor device (D1) that is used by being attached to an instrument (G1) provided with a scale plate (G16), a shaft member (G17), a pointer (G14), and a magnet (G18), and that acquires, in a non-contact manner, a measurement value measured by the instrument (G1). The pointer (G14) has an axial center part that is attached to the shaft member (G17), and an indication part that extends radially outward from the axial center part and that points to the scale when viewed in the axial direction (Z). In the magnet (G18), one N pole and one S pole are arranged one by one along the circumferential direction of the shaft member (G17). The sensor device (D1) is provided with a sensor circuit (2) and a case (1) that accommodates the sensor circuit (2). The sensor circuit (2) detects a magnetic pole boundary direction parallel to a boundary surface between the N pole and the S pole to generate a magnetic pole boundary direction value, and corrects the magnetic pole boundary direction value by a correction value to generate a meter reading value. The correction value is calculated on the basis of the extension direction of the pointer (G14) and the angle formed by the magnetic pole boundary direction and the reference direction for the magnetic pole boundary direction.
A sensor device (D1) is used by being attached to an instrument (G1) that has a scale plate (G16) with scales (G161), a pointer (G14) that rotates above the scale plate (G16), and a shaft member that rotates the pointer (G14), allowing measurements of the instrument (G1) to be acquired in a non-contact manner. The sensor device (D1) comprises a main body (M1) and a battery unit (B1). The main body (M1) comprises a main body case (1) that houses a sensor circuit for acquiring measurements, and the battery unit (B1) comprises a battery case (5) that houses a battery for supplying power to the sensor circuit. The main body (M1) and the battery unit (B1) can be assembled by stacking the main body case (1) and the battery case (5).
H01M 50/216 - Racks, modules or packs for multiple batteries or multiple cells characterised by their shape adapted for button or coin cells
H01M 50/244 - Secondary casingsRacksSuspension devicesCarrying devicesHolders characterised by their mounting method
H01M 50/284 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders with incorporated circuit boards, e.g. printed circuit boards [PCB]
H01M 50/293 - MountingsSecondary casings or framesRacks, modules or packsSuspension devicesShock absorbersTransport or carrying devicesHolders characterised by spacing elements or positioning means within frames, racks or packs characterised by the material
A sensor module (100) comprises a sensor unit (20) and a lens unit (32), and is accommodated in a housing (10) and disposed outside a cap (3) attached to an opening (2) of a container (1) containing a content. The sensor unit (20) has a transmission/reception section (21) and a computation section. The transmission/reception section (21) has a transmission part (21a) that transmits a radio wave and a reception part (21b) that receives the radio wave. The transmission part (21a) transmits a radio wave that passes through the cap (3) and reaches an inner space (1a) of the container. The reception part (21b) receives a reflected wave resulting from the radio wave reflected by the content (5) in the inner space (1a). The lens unit (32) is opposed to the transmission/reception section (21). The computation section computes the remaining amount of the content (5) on the basis of a period of time between when the radio wave is transmitted by the transmission part (21a) and when the reflected wave is received by the reception part (21b).
A connector including a body and first to fourth terminals partly held therein. Connecting portions of the first and second terminals are arranged and spaced along a second direction; ditto for connecting portions of the third and fourth terminals. The connecting portions of the first and third terminals are arranged and spaced along a third direction; ditto for the connecting portions of the second and fourth terminals. Main portions of the first and second terminals each extend from the corresponding connecting portion in a direction including a component of one side in the third direction. Main portions of the third and fourth terminals each extend from the corresponding connecting portion in a direction including a component of the other side in the third direction. Distal portions of the first to fourth terminals each extend from the corresponding main portion and are arranged and spaced along the second direction.
A connection unit has a shaft-form terminal, a cylindrical shell (12), an insulator that is positioned between the terminal and the shell (12), and a shield (14) that is electrically connected to the shell (12). The shell (12) includes a flange-form part (12c) that protrudes radially outward, and the shield (14) includes a through-hole (14c). In a state in which a portion of the shell (12) is inserted into the through hole (14c), there is a conductive bonding part (S) where the shield (14) and the flange-form part (12c) are electrically connected through thermal fusion.
H01R 13/6591 - Specific features or arrangements of connection of shield to conductive members
H01R 13/03 - Contact members characterised by the material, e.g. plating or coating materials
H01R 24/38 - Two-part coupling devices, or either of their cooperating parts, characterised by their overall structure having concentrically or coaxially arranged contacts
13.
RX ELECTRODE FOR CAPACITIVE TOUCH SENSOR, CAPACITIVE TOUCH SENSOR, AND NOISE REDUCTION METHOD
An RX electrode for a capacitive touch sensor including an electrode body, which includes first to fourth conductors, one of which includes a connecting portion. The first and second conductors are arrayed and located close to each other with a gap therebetween in a first direction, extend in a second direction. Application of external noise to the electrode body induces current flows in opposite directions through the first and second conductors, so that an electric field generated in the first conductor and an electric field generated in the second conductor offset each other. The third conductor, located on the one side in the second direction relative to the gap, connects first end portions of the first and second conductors. The fourth conductor, located on the other side in the second direction relative to the gap, connects second end portions of the first and second conductors.
A connector module includes: a connector unit; and a case holding the connector unit. The connector unit includes: a shaft-shaped terminal made of an electrically conductive material; a cylindrical shell made of an electrically conductive material; and a holder made of an electrically insulative resin material and disposed around the shaft-shaped terminal. The case is made of an electrically conductive material and includes a wall with an insertion hole, and holding the connector unit through the insertion hole. The shell includes a plurality of radially outward protrusions at an outer surface. The protrusions are press-fitted through the insertion hole and in contact with the inner surface of the wall for electric connection between the shell to the case.
H01R 13/504 - BasesCases composed of different pieces different pieces being moulded, cemented, welded, e.g. ultrasonic, or swaged together
H01R 9/05 - Connectors arranged to contact a plurality of the conductors of a multiconductor cable for coaxial cables
H01R 13/405 - Securing in non-demountable manner, e.g. moulding, riveting
H01R 13/50 - BasesCases formed as an integral body
H01R 24/76 - Two-part coupling devices, or either of their cooperating parts, characterised by their overall structure with sockets, clips or analogous contacts and secured to apparatus or structure, e.g. to a wall
An electrically drivable device includes a device body including an actuator and a handle attachable to and detachable from the device body. The handle includes a connector separably connectable with the device body, a pressure receiver displaceable in response to a gripping force with which the user grips the handle, a magnet control mechanism configured to operate a permanent magnet in conjunction with the displacement of the pressure receiver, and a frame holding the pressure receiver in such a manner that the pressure receiver is displaceable, and containing the magnet control mechanism. The device body includes a magnetic sensor configured to, in response to the pressure receiver being displaced with the handle attached to the device body, detect magnetism that the permanent magnet applies through the connector.
A distance sensor module includes a distance sensor and a housing. The distance sensor includes a sensor body and a transmission and reception section connected to the sensor body and configured to emit a detection signal toward a measurement target and receive the detection signal as reflected by the measurement target. The distance sensor is configured such that the sensor body is configured to measure the distance between the distance sensor and the measurement target as a result of the transmission and reception section receiving the detection signal. The housing includes a sensor container section containing the distance sensor, and an attachment section configured to attach the sensor container section to an external attachment target. The sensor container section is configured to keep the transmission and reception section so oriented due to gravity as to have a vertically downward detection direction with the attachment section attached to the attachment target.
A connector including a body having an insulating property, at least one terminal, a circuit board fixed to the body, and at least one current sensor mounted on the circuit board. The or each terminal includes a distal portion, an externally connectable lead portion, and a body portion therebetween. The distal portion protrudes from the body to one side in the first direction or is exposed from the body. The body portion is at least partly held by the body, and includes a measurement target extending in first and second directions and being disposed inside the body. The circuit board is spaced from the measurement target or targets of the at least one terminal in a third direction. The or each current sensor is disposed near the or a corresponding measurement target and configured to perform a non-contact detection of a current flowing through the or a corresponding terminal.
H01R 13/66 - Structural association with built-in electrical component
H01R 12/72 - Coupling devices for rigid printing circuits or like structures coupling with the edge of the rigid printed circuits or like structures
H01R 13/6594 - Specific features or arrangements of connection of shield to conductive members the shield being mounted on a PCB and connected to conductive members
An electric device includes: an electric circuit; a power supply circuit configured to feed electric power to the electric circuit and stop the feed; and a housing containing the electric circuit and the power supply circuit. The power supply circuit is configured to, in response to a first operation performed from outside the housing while the power supply circuit is in an OFF state, the OFF state being a state in which the battery feeds no electric power to the electric circuit, transition to an ON state, the ON state being a state in which the battery continuously feeds electric power to the electric circuit even after an end of the first operation, and in response to a second operation performed while the power supply circuit is in the ON state, transition to the OFF state.
G01D 5/14 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing the magnitude of a current or voltage
A lens including a lens body and a support. The lens body includes at least one lens portion and at least one holding hole for holding at least one optical fiber. A central axis of the or each holding hole is positioned on a phantom line extending through an optical axis of the or a corresponding lens portion. The support includes a support body fixed to the lens body. With a first portion of the or each optical fiber securely received in the or a corresponding holding hole, a bottom face of the or each holding hole abuts an end face of the first portion of the or a corresponding optical fiber, a peripheral face of the or each holding hole partly abuts an outer peripheral face of the first portion of the or a corresponding optical fiber, and the support body supports a second portion of the or each optical fiber.
A sensor unit is attachable to an attachment target so as to be partly accommodated, from one side in a first direction, in a hole opening out at least in the one side in a first direction of the attachment target. The unit includes a detection sensor capable of detecting approach of a detection target from the other side in the first direction, and at least one cushion covering the detection sensor at least partly from the other side in the first direction and may be at least partly accommodated in the hole. The at least one cushion is at least partly accommodated in the hole of the attachment target in a state where the sensor unit is attached to the attachment target from the one side in the first direction.
G01D 5/24 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing the magnitude of a current or voltage by varying capacitance
B60N 2/90 - Details or parts not otherwise provided for
To provide a connector module with stable EMC, a connector module includes: a receptacle on a substrate; and a plug electrically connected to the receptacle and electrically connectable to a communication cable, the plug including: a connector including an outer conductor electrically connectable to the communication cable; and a connection member connecting the connector to the receptacle and electrically connected to a ground line on the substrate, the outer conductor including: a cylindrical conductor body; and an annular flange extending from the conductor body to a radially outward side, the flange including a step on a facing side facing the connection member, the connection member being in contact with an upper level portion or a lower level portion. [Selected Figure] FIG. 12
H01R 24/50 - Two-part coupling devices, or either of their cooperating parts, characterised by their overall structure having concentrically or coaxially arranged contacts specially adapted for high frequency mounted on a PCB [Printed Circuit Board]
H01R 13/652 - Protective earth or shield arrangements on coupling devices with earth pin, blade or socket
H01R 13/502 - BasesCases composed of different pieces
A connector including an insulating body, at least one terminal, and a shell. Each terminal of the at least one terminal includes a main body partly held at least by the body, a distal portion, and a mounting portion. The distal portion extends from the main body to the one side in the first direction. The mounting portion extends from the main body to the other side in the first direction or to the one side in the second direction, and is located outside the body. The shell includes a generally tubular shell body securely accommodating the body and accommodating the main body(s) and the distal portion(s) of the at least one terminal. The shell includes two legs, which are ridges elongated in the first direction, extend from the shell body to the one side in the second direction, and are disposed on one and the sides, respectively, in a third direction relative to the at least one terminal.
H01R 13/514 - BasesCases formed as a modular block or assembly, i.e. composed of co-operating parts provided with contact members or holding contact members between them
H01R 13/506 - BasesCases composed of different pieces assembled by snap action of the parts
A circuit element connection structure includes: a plate-shaped base made of an insulating material and having an opening through the entire base in a thickness direction thereof; a circuit element made of an electrically conductive material and disposed on a first side of the base in the thickness direction thereof; and a connector made of an electrically conductive material and disposed on a second side of the base in the thickness direction thereof, the circuit element and the connector being in contact with each other at the opening as viewed in the thickness direction of the base.
A multi-directional input device includes an operating member that can be tilted and pushed in, a metal dome that functions as a push-in operation detector that detects a push-in operation of the operating member, a magnet holding member that is relatively movable with respect to the operating member only in a direction along a push-in direction and is interlocked only in a tilting direction, a magnet held by the magnet holding member, and a magnetic sensor that is disposed at a position facing the magnet and detects a movement of the magnet.
G06F 3/046 - Digitisers, e.g. for touch screens or touch pads, characterised by the transducing means by electromagnetic means
G05G 9/047 - Manually-actuated control mechanisms provided with one single controlling member co-operating with two or more controlled members, e.g. selectively, simultaneously the controlling member being movable in different independent ways, movement in each individual way actuating one controlled member only in which movement in two or more ways can occur simultaneously the controlling member being movable by hand about orthogonal axes, e.g. joysticks
A multi-directional input device includes an operating member that protrudes from a case and can be tilted, a compression coil spring that returns the operating member to an initial state before a tilting operation, a magnet holding member that is relatively movable with respect to the operating member only in a direction along a protruding direction and is interlocked only in a tilting direction, a magnet arranged in the magnet holding portion, and magnetic sensors that are each disposed at a position facing the magnet and detect a movement of the magnet. The magnetic sensors are each disposed on a side of the magnet and can detect magnetic components in three axial directions orthogonal to one another.
G05G 9/047 - Manually-actuated control mechanisms provided with one single controlling member co-operating with two or more controlled members, e.g. selectively, simultaneously the controlling member being movable in different independent ways, movement in each individual way actuating one controlled member only in which movement in two or more ways can occur simultaneously the controlling member being movable by hand about orthogonal axes, e.g. joysticks
G01B 7/30 - Measuring arrangements characterised by the use of electric or magnetic techniques for measuring angles or tapersMeasuring arrangements characterised by the use of electric or magnetic techniques for testing the alignment of axes
G05G 5/05 - Means for returning or tending to return controlling members to an inoperative or neutral position, e.g. by providing return springs or resilient end-stops
A microphone unit includes: an audio data acquisition unit that acquires speech as audio data; an audio data registration unit that registers verification audio data obtained by extracting a feature point from the audio data; an evaluation audio data acquisition unit that acquires speech that is input to a first microphone as evaluation audio data; a verification unit that verifies whether or not a speaker who uttered speech that is based on the evaluation audio data is a speaker who uttered speech that is based on the verification audio data, based on the verification audio data and a feature point extracted from the evaluation audio data; and a verification result output unit that outputs a result of verification performed by the verification unit.
G10L 17/00 - Speaker identification or verification techniques
G10L 15/02 - Feature extraction for speech recognitionSelection of recognition unit
G10L 15/28 - Constructional details of speech recognition systems
G10L 17/02 - Preprocessing operations, e.g. segment selectionPattern representation or modelling, e.g. based on linear discriminant analysis [LDA] or principal componentsFeature selection or extraction
A multiple coaxial connector includes a contact pair that is composed of a first contact and a second contact, a body that accommodates each contact, a shell that accommodates the body, a shield cover that covers a portion of the shell, and a board mounting portion. The first contact includes a first main body portion that is extended in a first direction, a first contact portion that is formed on one end of the first main body portion and is to be brought into contact with a contact of the mating multiple coaxial connector, and a first leading portion that is extended from the other end of the first main body portion in a direction that is orthogonal to the first direction and directs toward a second direction. A plurality of the contact pairs are arranged in a third direction.
H01R 24/50 - Two-part coupling devices, or either of their cooperating parts, characterised by their overall structure having concentrically or coaxially arranged contacts specially adapted for high frequency mounted on a PCB [Printed Circuit Board]
H01R 25/00 - Coupling parts adapted for simultaneous co-operation with two or more identical counterparts, e.g. for distributing energy to two or more circuits
A plug includes a housing, a plurality of plug shells that are accommodated in the housing in a manner to protrude from the housing by a predetermined length A, a plurality of plug bodies that are accommodated in the plug shells respectively, and a plurality of plug contacts that are fixed to the plug bodies respectively. A receptacle includes a receptacle shell, a receptacle body, and a receptacle contact. The receptacle shell includes: an accommodation portion that entirely accommodates ends of the plurality of plug shells protruding from the housing, and whose insertion-direction length B satisfies B
H01R 24/38 - Two-part coupling devices, or either of their cooperating parts, characterised by their overall structure having concentrically or coaxially arranged contacts
H01R 13/642 - Means for preventing, inhibiting or avoiding incorrect coupling by position or shape of contact members
A shell assembly includes a shell including a depression and a flange, which go around a circumference of the shell, and the shell assemblies are arranged in N rows×M columns and fixed to a housing. The housing includes: N×M pieces of insertion holes into which respective ends of the shell assemblies are inserted; an engagement portion that is formed on an inner surface of each of the insertion holes on a position, which is closer to an obliquely-adjacent insertion hole of the insertion holes, and is engaged with the depression; and a slit that is formed by cutting the housing in a direction orthogonal to an extension direction of the insertion holes and includes a first groove and a second groove formed on an inner surface thereof.
H01R 13/506 - BasesCases composed of different pieces assembled by snap action of the parts
H01R 13/436 - Securing a plurality of contact members by one locking piece
H01R 24/40 - Two-part coupling devices, or either of their cooperating parts, characterised by their overall structure having concentrically or coaxially arranged contacts specially adapted for high frequency
H01R 25/00 - Coupling parts adapted for simultaneous co-operation with two or more identical counterparts, e.g. for distributing energy to two or more circuits
A coaxial connector includes a plug and a receptacle that are electrically connectable to each other. The plug includes a first contact, a holder, a first tubular shell, and a shield member. The receptacle includes a second contact, a case, and a second tubular shell. The second contact includes a bottom portion, a pair of standing portions, and an extension. The pair of standing portions include respective contact portions having a wide shape and can clamp an end portion of the first contact. The extension includes a tip portion that is to be fixed to a substrate, a hold that is held by the case, and an elastic portion that is elastically deformable. The elastic portion can undergo elastic deformation in a direction orthogonal to a direction in which the contact portions extend.
H01R 24/40 - Two-part coupling devices, or either of their cooperating parts, characterised by their overall structure having concentrically or coaxially arranged contacts specially adapted for high frequency
H01R 13/426 - Securing in a demountable manner by separate resilient retaining piece supported by base or case, e.g. collar
H01R 13/6584 - Shield structure with resilient means for engaging mating connector with separate conductive resilient members between mating shield members formed by conductive elastomeric members, e.g. flat gaskets or O-rings
A seat belt attachment/detachment detection switch including a printed circuit board including a circuit for detecting attachment/detachment of a seat belt; a movable plate configured to slidably move along with insertion of a tongue plate of the seat belt; a rotor including a lever coupled to the movable plate, the rotor being rotatably attached to the printed circuit board to rotate as the tongue plate is pushed into a buckle; and an electric brush attached to the surface of the rotor that faces the printed circuit board, the electric brush having leg parts that change a state of contact/non-contact with a conductive part of the circuit in accordance with a rotating state of the rotor.
H01H 19/18 - Operating parts, e.g. turn knob adapted for actuation at a limit or other predetermined position in the path of a body, the relative movement of switch and body being primarily for a purpose other than the actuation of the switch, e.g. door switch, limit switch, floor-levelling switch of a lift
B60R 22/48 - Control systems, alarms, or interlock systems, for the correct application of the belt or harness
H01H 15/14 - Operating parts adapted for actuation at a limit or other predetermined position in the path of a body, the relative movement of switch and body being primarily for a purpose other than the actuation of the switch, e.g. door switch, limit switch, floor-levelling switch of a lift
A microphone assembly comprises a circuit board, a microphone element connected to the circuit board, an external connection interface connected to the circuit board, and hot melt that is formed to cover the circuit board, the microphone element, and the external connection interface and has a hole formed to expose a part of the back side of the circuit board or the sound receiving part of the microphone element.
A contactless power supply device includes a handle attachable and detachable with respect to a main body case at least partially covering a main body part including an electric unit, a power transmission module to be provided to protrude from the main body case, and having a power transmission coil electrified based on power supplied to the main body part, a power reception module housed in the handle to face the power transmission module when the handle is fixed to the main body case, and having a power reception coil contactlessly supplied with power via the power transmission coil, and a detection unit provided in the handle, driven based on the power supplied via the power reception module, and configured to detect whether the handle is being gripped.
H02J 50/10 - Circuit arrangements or systems for wireless supply or distribution of electric power using inductive coupling
H02J 50/00 - Circuit arrangements or systems for wireless supply or distribution of electric power
H02J 50/60 - Circuit arrangements or systems for wireless supply or distribution of electric power responsive to the presence of foreign objects, e.g. detection of living beings
A control apparatus that bidirectionally communicates with a control unit based on a preset time-sharing method includes: a plurality of devices each installed on a different substrate; a communication controller daisy-chained to the control unit via a bus line through which bidirectional communication of communication data is performed, the communication data having a data structure having a band in which data to be communicated between the plurality of devices is superimposable; and a cable configured to connect at least one device of the plurality of devices to the communication controller.
B60R 16/023 - Electric or fluid circuits specially adapted for vehicles and not otherwise provided forArrangement of elements of electric or fluid circuits specially adapted for vehicles and not otherwise provided for electric for transmission of signals between vehicle parts or subsystems
B60R 11/02 - Arrangements for holding or mounting articles, not otherwise provided for for radio sets, television sets, telephones, or the likeArrangement of controls thereof
H04R 3/12 - Circuits for transducers for distributing signals to two or more loudspeakers
G06F 13/42 - Bus transfer protocol, e.g. handshakeSynchronisation
A microphone includes a tubular case having a bottom surface, a side surface and an opened top, a substrate which is fixed so as to block an opening portion of the opened top of the case, and has an electrode portion on an upper surface thereof, and a side-surface sound hole formed in the side surface of the case.
2 or more, the waterproof film being fixed to the bottom of the case so as to block an opening part of the bottom of the case, a substrate arranged in the case, a microphone mounted on the substrate, and a sealing member that seals an opening part of the top of the case.
The present invention provides a substrate that is highly resistant to ESD, on which a reverse sound hole type MEMS microphone can be mounted. The substrate has one surface connected to a MEMS microphone, and comprises a substrate sound hole that penetrates through the substrate and communicates with a sound hole of the MEMS microphone, and a GND pad disposed around the substrate sound hole on another surface of the substrate.
A method for manufacturing a three-dimensional structure including: preparing a first structure including a fixing face; fixing a plastic layer to the fixing face of the first structure; preparing a conductive wire; and operating an ultrasonic head to apply ultrasonic waves to the conductive wire and to press the conductive wire against the plastic layer, and thereby partly embedding the conductive wire into the plastic layer.
B29C 65/64 - Joining a non-plastics element to a plastics element, e.g. by force
B29C 45/00 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor
B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
B60R 13/00 - Elements for body-finishing, identifying, or decoratingArrangements or adaptations for advertising purposes
B60R 13/04 - Ornamental or guard stripsOrnamental inscriptive devices
B29L 31/30 - Vehicles, e.g. ships or aircraft, or body parts thereof
45.
Electrical connector with a receptacle in a first case and a mating plug integrated with a second case
A connector includes a receptacle attached to a rear substrate accommodated in a front case, and a plug attached to one end of a coaxial cable, integrated with a rear case assembled to the front case, and fitted to the receptacle. A separate cable different from the coaxial cable integrated with the rear case together with the plug is integrated with the rear case.
H01R 13/516 - Means for holding or embracing insulating body, e.g. casing
H01R 13/405 - Securing in non-demountable manner, e.g. moulding, riveting
H01R 24/50 - Two-part coupling devices, or either of their cooperating parts, characterised by their overall structure having concentrically or coaxially arranged contacts specially adapted for high frequency mounted on a PCB [Printed Circuit Board]
H01R 13/512 - BasesCases composed of different pieces assembled by screw or screws
H01R 13/518 - Means for holding or embracing insulating body, e.g. casing for holding or embracing several coupling parts, e.g. frames
H01R 13/52 - Dustproof, splashproof, drip-proof, waterproof, or flameproof cases
An electronic device charger includes: a lower case that is a housing with an upper surface thereof opened, the lower case including a pair of projecting portions and raised portions, the pair of projecting portions being provided at positions facing each other on inner side surfaces, the raised portions being formed by extending, in an upper direction, parts of the inner side surfaces at positions of the projecting portions; a board housed in the lower case, the board being clamped by the pair of projecting portions; and a heat sink that functions as an upper case covering the board and in which an arrangement pitch of heat dissipation fins disposed on an upper surface of the heat sink is an integral fraction of a predefined width of a heat generating component in an arrangement direction of the heat dissipation fins.
A touch sensing device including a housing, a movable part, a covering, and a lifting actuator. The movable part is relatively movable within an opening of the housing relative to an edge portion of the opening, between first and second heights. The covering includes a flexible layer covering at least the edge portion and the movable part. The flexible layer includes first and second portions directly or indirectly fixed to the edge portion and to the movable part, respectively. The flexible layer can partly flex and stretch or partly shrink in accordance with a relative movement of the second portion relative to the first portion, from a third height to a fourth height, or vice versa. The lifting actuator can move the movable part or the edge portion to relatively move the movable part, from the first height to the second height, or vice versa, relative to the edge portion.
Provided is an inexpensive charger which is compact and which yet provides favorable heat dissipation performance. The charger includes a charging circuit board comprised of an input/output interface component and a charging circuit component mounted on a substrate having a first face and a second face which are in parallel and front/back relationship with each other and a housing including a first housing body to which the charging circuit board is fixed and a second housing body engageable with the first housing body to form together an inner space in which the charging circuit board is to be accommodated. The second face of the substrate mounts thereon a heat generating component included in the circuit component. A heat dissipation pattern is formed at a part of the first face overlapped with at least a part of the heat generating component mounted on the second face as seen in a direction perpendicular to the first face.
An ultrasonic speaker comprises a case that has an opened top surface and includes a plurality of protrusions protruding inward on an inner side surface of the case, a piezoelectric element fixed to a bottom surface in the case, and a substrate that is inserted in the case and placed on upper surfaces of the plurality of protrusions.
A sensor that includes a switch unit and that detects a pressure applied from the front side to the switch unit or a finger approaching the switch unit from the front side is located on the back side of upholstery. A base member has a protruding portion on its surface. The upholstery includes: a light-transmitting region that is located over a light guide portion of the base member and the switch unit of the sensor and that allows light from a light source to transmit therethrough to the front side; and a non-light-transmitting region that blocks the light from the light source. A raised portion that is raised on the front side of the upholstery is located near the light-transmitting region in the non-light-transmitting region of the upholstery. The protruding portion of the base member is placed in the raised portion from the back side of the upholstery.
B60R 11/02 - Arrangements for holding or mounting articles, not otherwise provided for for radio sets, television sets, telephones, or the likeArrangement of controls thereof
B60R 16/02 - Electric or fluid circuits specially adapted for vehicles and not otherwise provided forArrangement of elements of electric or fluid circuits specially adapted for vehicles and not otherwise provided for electric
H01H 36/00 - Switches actuated by change of magnetic field or of electric field, e.g. by change of relative position of magnet and switch, by shielding
A connector includes: a contact batch that is composed of two or more groups of contacts; an inner shield that electrically separates the two or more groups of contacts from each other; a body in which the contact batch and the inner shield are press-fitted and fixed; and a shell that covers the contact batch, the inner shield, and the body.
H01R 13/6471 - Means for preventing cross-talk by special arrangement of ground and signal conductors, e.g. GSGS [Ground-Signal-Ground-Signal]
H01R 13/6585 - Shielding material individually surrounding or interposed between mutually spaced contacts
H01R 13/6586 - Shielding material individually surrounding or interposed between mutually spaced contacts for separating multiple connector modules
H01R 24/20 - Coupling parts carrying sockets, clips or analogous contacts and secured only to wire or cable
H01R 13/646 - Details of coupling devices of the kinds covered by groups or specially adapted for high-frequency, e.g. structures providing an impedance match or phase match
53.
Electrical connector with water evacuation features and connector device using the same
A connector and a connector device that are small and have a drainage function are provided. A connector includes: a contact; a first insulator; a first shield member; a second shield member having a tubular portion; and a second insulator. A first communicating portion that is in communication with the outside is formed in a lower wall of the tubular portion of the second shield member, the lower wall facing the second insulator. A second communicating portion that is in communication with the outside and the first communicating portion is formed in the second insulator. The first shield member has a facing wall that faces the first communicating portion, and a bent wall that is bent toward the second insulator from an end portion of the facing wall on an opposite side to the opening side.
H01R 24/60 - Contacts spaced along planar side wall transverse to longitudinal axis of engagement
H01R 13/502 - BasesCases composed of different pieces
H01R 13/6594 - Specific features or arrangements of connection of shield to conductive members the shield being mounted on a PCB and connected to conductive members
A touch sensing device including a sensor and a water shielding layer. The sensor is a capacitive, resistive, or optical touch sensor and is configured to detect a detection target approaching the sensor from one side in a first direction. The first direction is a thickness direction of the sensor. The water shielding layer is composed of waterproof elastic substance, is disposed on the one side in the first direction relative to the sensor, and covers at least part of the sensor.
G06F 3/044 - Digitisers, e.g. for touch screens or touch pads, characterised by the transducing means by capacitive means
B32B 1/00 - Layered products having a non-planar shape
B32B 5/18 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by features of a layer containing foamed or specifically porous material
B32B 27/06 - Layered products essentially comprising synthetic resin as the main or only constituent of a layer next to another layer of a specific substance
G06F 3/041 - Digitisers, e.g. for touch screens or touch pads, characterised by the transducing means
55.
SENSOR UNIT, AND ATTACHING STRUCTURE OF SENSOR UNIT AND ATTACHMENT OBJECT
[Problem] The present invention obtains a sensor unit that can be easily attached to an attachment object to which the sensor unit is to be attached. [Configuration] A sensor unit U1 can be attached to an attachment object T such that the sensor unit U1 is partially accommodated from a Z'-direction side within a hole H in the attachment object T that opens in at least the Z' direction. The unit U1 comprises a detection sensor 100 capable of detecting the approach of a detection object from the Z-direction side, and at least one cushion part 200 that covers at least a portion of the detection sensor 100 from the Z-direction side and that can be accommodated at least partially in the hole H. The at least one cushion part 200 is accommodated at least partially within the hole H in the attachment object T while the sensor unit U1 is attached to the attachment object T from the Z'-direction side.
A detection sensor according to an aspect of the invention includes a vibratable film constituted by a piezoelectric film, a case accommodating the vibratable film, and a circuit board. The vibratable film is configured to be irradiated with infrared rays and thereby generate first electric signals through a pyroelectric effect, and configured to be vibrated by sound waves and thereby generate second electric signals through a piezoelectric effect. The case includes a transmissive part. The transmissive part is configured to transmit at least infrared rays and disposed on one side in a first direction relative to the vibratable film to face the vibratable film. The first direction is a thickness direction of the vibratable film. The circuit board is fixed to the case and disposed on the other side in the first direction relative to the vibratable film. The circuit board has a sound hole to input therethrough sound waves.
G01H 11/08 - Measuring mechanical vibrations or ultrasonic, sonic or infrasonic waves by detecting changes in electric or magnetic properties by electric means using piezoelectric devices
G01J 5/34 - Radiation pyrometry, e.g. infrared or optical thermometry using electric radiation detectors using capacitors, e.g. pyroelectric capacitors
58.
High frequency transmission device and high frequency signal transmission method
A polycrystal having a physical property that enables an AC resistance value to drop sharply is used to reduce transmission loss of a high frequency signal being transmitted. A high frequency transmission device D1 is provided that includes a dielectric 100 and a transmission line 200 adapted for transmitting therethrough high frequency signals. At least part of the transmission line 200 is located on or inside the dielectric 100. At least part of the transmission line 200 is composed of a polycrystal composed of conductor fine particles. The polycrystal has a physical property such that, when a high frequency signal to be transmitted through the transmission line 200 is of frequencies within one or more specific frequency bands, the AC resistance value drops sharply.
A connector mounted on a substrate includes: a plurality of contacts; and a housing, wherein the plurality of contacts include a plurality of first contacts arranged next to one another in a first row and a plurality of second contacts arranged next to one another in a second row parallel to and apart from the first row, the connector further including: for the first row, at least one electrically conductive first bar-shaped member which is present further outward than a first outermost one of the first contacts, which is fixed to the substrate, and which is supported by the housing; and for the second row, at least one electrically conductive second bar-shaped member which is present further outward than a first outermost one of the second contacts, which is fixed to the substrate, and which is supported by the housing.
H01R 12/00 - Structural associations of a plurality of mutually-insulated electrical connecting elements, specially adapted for printed circuits, e.g. printed circuit boards [PCB], flat or ribbon cables, or like generally planar structures, e.g. terminal strips, terminal blocksCoupling devices specially adapted for printed circuits, flat or ribbon cables, or like generally planar structuresTerminals specially adapted for contact with, or insertion into, printed circuits, flat or ribbon cables, or like generally planar structures
A unidirectional microphone includes: a case having a shape of a bottomed cylinder and including a sound hole in a bottom thereof; a ring-shaped diaphragm fixed to the bottom in the case; a vibrating membrane stretched on the diaphragm; a backplate which has a shape of a bottomed cylinder and is housed in the case in a nested manner such that an air gap to serve as a sound propagation path is formed between the backplate and an inner surface of the case, the backplate including an aperture serving as a sound propagation path in a side face thereof; a spacer positioned between the diaphragm and the backplate to fix the diaphragm and the backplate, and including a notch serving as a sound propagation path in a portion thereof; and a base plate covering a top opening of the case and including a hole serving as a sound propagation path.
H04R 1/34 - Arrangements for obtaining desired frequency or directional characteristics for obtaining desired directional characteristic only by using a single transducer with sound reflecting, diffracting, directing or guiding means
H04R 1/04 - Structural association of microphone with electric circuitry therefor
The shield member includes a plurality of first elastic portions made of a conductive material and arranged annularly in a plate shape at an inner circumferential part of the shield member; a plurality of second elastic portions arranged annularly at an outer circumferential part of the shield member; and an intermediate portion between the plurality of first elastic portions and the plurality of second elastic portions. The plurality of first elastic portions are defined by a plurality of first slits each extending from an inner circumferential edge of the shield member in a radial direction of the shield member. The plurality of second elastic portions are defined by a plurality of second slits each extending from an outer circumferential edge of the shield member in the radial direction.
H01R 24/54 - Intermediate parts, e.g. adapters, splitters or elbows
H01R 13/516 - Means for holding or embracing insulating body, e.g. casing
H01R 13/502 - BasesCases composed of different pieces
H04N 23/52 - Elements optimising image sensor operation, e.g. for electromagnetic interference [EMI] protection or temperature control by heat transfer or cooling elements
H01R 13/6585 - Shielding material individually surrounding or interposed between mutually spaced contacts
H01R 13/533 - Bases or cases made for use in extreme conditions, e.g. high temperature, radiation, vibration, corrosive environment, pressure
H04N 23/57 - Mechanical or electrical details of cameras or camera modules specially adapted for being embedded in other devices
A capacitive sensor including a substrate, detection and drive electrodes, and a controller. The substrate includes one or a plurality of insulating layers including first and second faces. The detection electrode includes mutually electrically connected detection lines arrayed at spaced intervals on the first face. The drive electrode includes mutually electrically connected drive lines each arranged on the first or second face and located between adjacent two of the detection lines. When a target approaches the detection electrode being charged and discharged by the controller, the approach causes a change in a first capacitance between the detection electrode and the target. When a target approaches the detection and drive electrodes while the controller is supplying drive pulses to the drive electrode, the approach causes a change in a second capacitance between the detection electrode and the drive electrode. The controller detects the target referring to changes in the first and second capacitances.
G01D 5/24 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing the magnitude of a current or voltage by varying capacitance
G01R 27/26 - Measuring inductance or capacitanceMeasuring quality factor, e.g. by using the resonance methodMeasuring loss factorMeasuring dielectric constants
G06F 3/044 - Digitisers, e.g. for touch screens or touch pads, characterised by the transducing means by capacitive means
63.
Electromagnetic actuator and vibration generator including the same
An electromagnetic actuator including a coil; a non-movable part constituted by a magnetic substance and disposed on one side relative to the coil; and a movable part including a permanent magnet on the other side relative to the coil. Applying a current to the coil alternately generates first and third driving forces to move the magnet and the movable part to one and the other sides in a first direction relative to the coil and the non-movable part. As the movable part moves from a neutral position to the one side in the first direction, a portion of the magnet positioned on the one side in the first direction relative to the first end of the first non-movable part gradually enlarges and is magnetically attracted toward the non-movable part. As the movable part moves from the neutral position to the other side in the first direction, a portion of the magnet positioned on the other side in the first direction relative to the second end of the first non-movable part gradually enlarges and is magnetically attracted toward the non-movable part.
H02K 33/16 - Motors with reciprocating, oscillating or vibrating magnet, armature or coil system with polarised armatures moving in alternate directions by reversal or energisation of a single coil system
A sound collecting device that is located in a first space and collects sounds generated in a second space isolated from the first space by a predetermined plate, comprising a metal plate, a piezoelectric element fixed on an upper surface of the metal plate, a housing that has a tubular shape having opened upper and lower surfaces, and has an upper end surface adhesively attached to a lower surface of the metal plate and a lower end surface adhesively attached to the predetermined plate, and a vibration pickup terminal that is accommodated in the housing, and comprises a leg part adhesively attached to the lower surface of the metal plate, a shaft part extending downward from the leg part, and a tip part which is formed at a tip of the shaft part in the downward direction and comes into contact with the predetermined plate when the housing is adhesively attached to the predetermined plate.
H04R 1/34 - Arrangements for obtaining desired frequency or directional characteristics for obtaining desired directional characteristic only by using a single transducer with sound reflecting, diffracting, directing or guiding means
H04R 1/46 - Special adaptations for use as contact microphones, e.g. on musical instrument, on stethoscope
A sensor unit attachable to a hole of a housing, closed by an overlay on one side in the first direction, from the other side in the first direction. The sensor unit includes a body, a sensor, a vibration generator, a vibration damper, and a fixable part. The body includes a first portion and a second portion on the other side in the first direction relative to the first portion. The sensor provided at the body detects a contact of a detection target with the overlay. The vibration generator can vibrate the body and sensor. The fixable part is provided at the second portion of the body. With the first portion accommodated in the hole, the fixable part is fixed to the housing from the other side in the first direction via the vibration damper, and the vibration damper is at least partly interposed between the fixable part and housing.
A seat belt fastened/unfastened state detection switch includes: a printed substrate that includes a circuit for detecting a fastened/unfastened state of a seat belt; a rotor that is rotatably attached to the printed substrate, includes a contact portion, the contact portion coming into contact with a tongue of the seat belt, and rotates in a forward direction in accordance with pushing of the tongue into a buckle; a spring that makes the rotor, the rotor being in a rotated state in the forward direction, rotate in a reverse direction in accordance with pulling of the tongue from the buckle; and an electric brush that is attached to a surface of the rotor, the surface facing the printed substrate, and includes a leg portion whose contact/non-contact state with respect to a conductive part of the circuit changes depending on a rotation state of the rotor.
Provided is a connector module that is highly durable and that also allows easy position alignment with a connection target instrument while maintaining high shielding performance. The connector module includes a connector case and a connector inserted in the connector case. The connector includes a contact, a holder, a conductive tubular shell, a housing and a conductive shield case. The shield case includes a first member having an elastic portion and a second member in the form of a bottomed tube. The first member forms an elastic piece contactable with the second member. Fixing of the connector case to a main body case via a fastener member causes, in the connector, elastic deformation of the elastic piece, resulting in decrease in a gap between the first member and the second member, consequently in establishment of electrical connection between the first member and the second member.
H01R 13/432 - Securing in a demountable manner by resilient locking means on the contact membersSecuring in a demountable manner by locking means on resilient contact members by stamped-out resilient tongue snapping behind shoulder in base or case
H01R 13/512 - BasesCases composed of different pieces assembled by screw or screws
H01R 13/52 - Dustproof, splashproof, drip-proof, waterproof, or flameproof cases
H01R 13/6596 - Specific features or arrangements of connection of shield to conductive members the conductive member being a metal grounding panel
H01R 24/40 - Two-part coupling devices, or either of their cooperating parts, characterised by their overall structure having concentrically or coaxially arranged contacts specially adapted for high frequency
H01R 13/6583 - Shield structure with resilient means for engaging mating connector with separate conductive resilient members between mating shield members
H01R 13/639 - Additional means for holding or locking coupling parts together after engagement
H01R 13/6582 - Shield structure with resilient means for engaging mating connector
H01R 13/6597 - Specific features or arrangements of connection of shield to conductive members the conductive member being a contact of the connector
H01R 12/91 - Coupling devices allowing relative movement between coupling parts e.g. floating or self aligning
H01R 13/74 - Means for mounting coupling parts to apparatus or structures, e.g. to a wall for mounting coupling parts in openings of a panel
H01R 13/631 - Additional means for facilitating engagement or disengagement of coupling parts, e.g. aligning or guiding means, levers, gas pressure for engagement only
A linking structure including an interlocking member pivotable in a second direction, and a lever tiltably linked to the interlocking member. The interlocking member includes a blind elongated hole extending in a first direction; first to fourth edges of the elongated hole; a bottom closing the elongated hole and being contiguous with the edges; and first and second shaft holes in the first and second edges to extend communicatingly from the elongated hole to opposite sides in the second direction. The lever includes a base in the elongated hole; first and second juts extending from the base, being swingably received in the elongated hole, and being in abutment with, or opposed with a narrow clearance to, the first and second edges; and first and second rotation shafts extending from the base and being supported in the first and second shaft holes such as to be rotatable in the first direction.
G05G 1/04 - Controlling members for hand-actuation by pivoting movement, e.g. levers
G05G 5/05 - Means for returning or tending to return controlling members to an inoperative or neutral position, e.g. by providing return springs or resilient end-stops
09 - Scientific and electric apparatus and instruments
Goods & Services
Electric jacks Electric switches; electric plugs; electric connectors; electric wire connectors; USB (universal serial bus) hardware; USB cables; micro USB cables; USB charging ports; cable connectors; plug connectors; plug-in connectors; electric sockets; electromagnetic relays; solenoid valves, electromagnetic switches; circuit breakers; microphones; headphones; earphones; display units for computers, namely, computer screens and computer monitors; telephone apparatus; telephone sets; remote controls for automotive audio systems; remote controls for operative vehicle alarms; remote controls for televisions, radios, stereos; remote controls for home security systems; computer mouse; computer keyboards; acceleration sensors; flowmeters; surveying machines and instruments; personal digital assistants; radios; radio beacon machines and apparatus; touch sensors for touch screens used in mobile phones, automobile in-dash control monitors, and computer monitors; capacitive touch sensors for touch screens used in mobile phones, automobile in-dash control monitors, and computer monitors; touch screens; interactive touch screen terminals; capacitive styluses for touch screen devices; piezoelectric sensors; proximity sensors; ultrasonic sensors; vibration sensors
09 - Scientific and electric apparatus and instruments
Goods & Services
Electric jacks Electric switches; electric plugs; electric connectors; electric wire connectors; USB (universal serial bus) hardware; USB cables; micro USB cables; USB charging ports; cable connectors; plug connectors; plug-in connectors; electric sockets; electromagnetic relays; solenoid valves, electromagnetic switches; circuit breakers; microphones; headphones; earphones; display units for computers, namely, computer screens and computer monitors; telephone apparatus; telephone sets; remote controls for automotive audio systems; remote controls for operative vehicle alarms; remote controls for televisions, radios, stereos; remote controls for home security systems; computer mouse; computer keyboards; acceleration sensors; flowmeters; surveying machines and instruments; personal digital assistants; radios; radio beacon machines and apparatus; touch sensors for touch screens used in mobile phones, automobile in-dash control monitors, and computer monitors; capacitive touch sensors for touch screens used in mobile phones, automobile in-dash control monitors, and computer monitors; touch screens; interactive touch screen terminals; capacitive styluses for touch screen devices; piezoelectric sensors; proximity sensors; ultrasonic sensors; vibration sensors
09 - Scientific and electric apparatus and instruments
Goods & Services
Electric jacks Electric switches; electric plugs; electric connectors; electric wire connectors; USB (universal serial bus) hardware; USB cables; micro USB cables; USB charging ports; cable connectors; plug connectors; plug-in connectors; electric sockets; electromagnetic relays; solenoid valves, electromagnetic switches; circuit breakers; microphones; headphones; earphones; display units for computers, namely, computer screens and computer monitors; telephone apparatus; telephone sets; remote controls for automotive audio systems; remote controls for operative vehicle alarms; remote controls for televisions, radios, stereos; remote controls for home security systems; computer mouse; computer keyboards; acceleration sensors; flowmeters; surveying machines and instruments; personal digital assistants; radios; radio beacon machines and apparatus; touch sensors for touch screens used in mobile phones, automobile in-dash control monitors, and computer monitors; capacitive touch sensors for touch screens used in mobile phones, automobile in-dash control monitors, and computer monitors; touch screens; interactive touch screen terminals; capacitive styluses for touch screen devices; piezoelectric sensors; proximity sensors; ultrasonic sensors; vibration sensors
09 - Scientific and electric apparatus and instruments
Goods & Services
Electric jacks Electric switches; electric plugs; electric connectors; electric wire connectors; USB (universal serial bus) hardware; USB cables; micro USB cables; USB charging ports; cable connectors; plug connectors; plug-in connectors; electric sockets; electromagnetic relays; solenoid valves, electromagnetic switches; circuit breakers; microphones; headphones; earphones; display units for computers, namely, computer screens and computer monitors; telephone apparatus; telephone sets; remote controls for automotive audio systems; remote controls for operative vehicle alarms; remote controls for televisions, radios, stereos; remote controls for home security systems; computer mouse; computer keyboards; acceleration sensors; flowmeters; surveying machines and instruments; personal digital assistants; radios; radio beacon machines and apparatus; touch sensors for touch screens used in mobile phones, automobile in-dash control monitors, and computer monitors; capacitive touch sensors for touch screens used in mobile phones, automobile in-dash control monitors, and computer monitors; touch screens; interactive touch screen terminals; capacitive styluses for touch screen devices; piezoelectric sensors; proximity sensors; ultrasonic sensors; vibration sensors
09 - Scientific and electric apparatus and instruments
Goods & Services
Electric switches; electric plugs; connectors [electricity]; wire connectors [electricity]; connectors for telecommunication apparatus; electric sockets; electromagnetic relays; solenoid valves [electromagnetic switches]; circuit breakers; microphones; headphones; earphones; display units for computers; telephone apparatus; telephone sets; remote control apparatus; mouse [computer peripheral]; computer keyboards; sensors; measuring or testing machines and instruments; derived-unit measuring machines and apparatus; accelerometers; flowmeters; precision measuring machines and instruments; surveying machines and instruments; personal digital assistants; radio machines and apparatus; radio beacon machines and apparatus; touch sensors; capacitive touch sensors; piezoelectric sensors; proximity sensors; ultrasonic sensors; vibration sensors.
09 - Scientific and electric apparatus and instruments
Goods & Services
Electric switches; electric plugs; connectors [electricity]; wire connectors [electricity]; connectors for telecommunication apparatus; electric sockets; electromagnetic relays; solenoid valves [electromagnetic switches]; circuit breakers; microphones; headphones; earphones; display units for computers; telephone apparatus; telephone sets; remote control apparatus; mouse [computer peripheral]; computer keyboards; sensors; measuring or testing machines and instruments; derived-unit measuring machines and apparatus; accelerometers; flowmeters; precision measuring machines and instruments; surveying machines and instruments; personal digital assistants; radio machines and apparatus; radio beacon machines and apparatus; touch sensors; capacitive touch sensors; piezoelectric sensors; proximity sensors; ultrasonic sensors; vibration sensors.
09 - Scientific and electric apparatus and instruments
Goods & Services
Electric switches; electric plugs; connectors [electricity]; wire connectors [electricity]; connectors for telecommunication apparatus; electric sockets; electromagnetic relays; solenoid valves [electromagnetic switches]; circuit breakers; microphones; headphones; earphones; display units for computers; telephone apparatus; telephone sets; remote control apparatus; mouse [computer peripheral]; computer keyboards; sensors; measuring or testing machines and instruments; derived-unit measuring machines and apparatus; accelerometers; flowmeters; precision measuring machines and instruments; surveying machines and instruments; personal digital assistants; radio machines and apparatus; radio beacon machines and apparatus; touch sensors; capacitive touch sensors; piezoelectric sensors; proximity sensors; ultrasonic sensors; vibration sensors.
09 - Scientific and electric apparatus and instruments
Goods & Services
Electric switches; electric plugs; connectors [electricity]; wire connectors [electricity]; connectors for telecommunication apparatus; electric sockets; electromagnetic relays; solenoid valves [electromagnetic switches]; circuit breakers; microphones; headphones; earphones; display units for computers; telephone apparatus; telephone sets; remote control apparatus; mouse [computer peripheral]; computer keyboards; sensors; measuring or testing machines and instruments; derived-unit measuring machines and apparatus; accelerometers; flowmeters; precision measuring machines and instruments; surveying machines and instruments; personal digital assistants; radio machines and apparatus; radio beacon machines and apparatus; touch sensors; capacitive touch sensors; piezoelectric sensors; proximity sensors; ultrasonic sensors; vibration sensors.
78.
Transmission antenna module, non-contact transmission module, non-contact communication system provided therewith and non-contact communication method
An electromagnetic actuator including an attractor to exert a magnetic attractive force in one side in a first direction, a frame, and a lever. The frame includes a frame body fixed to the attractor, and a support on an oblique-direction side relative to the attractor. The lever includes a fulcrum portion pivotally supported by the support, a first displaceable portion arranged on the other side in the second direction relative to the fulcrum portion and on the other side in the first direction relative to the attractor and magnetically attractable by the attractor to be displaced to the one side in the first direction, and a second displaceable portion arranged on the one side in the first direction relative to the fulcrum portion and on the one side in the second direction relative to the attractor and/or the frame and displaceable away from the attractor and/or the frame by the pivot of the lever.
H02K 33/16 - Motors with reciprocating, oscillating or vibrating magnet, armature or coil system with polarised armatures moving in alternate directions by reversal or energisation of a single coil system
A ground terminal including a first ring of a C-shape or a ring shape and contact springs. The contact springs extend from the first ring in a first direction and are spaced from each other in a circumferential direction of the first ring. Each contact spring curves or bends such as to project to an inner side in a corresponding one of second directions. The first direction is an axial direction of the first ring. The second directions are substantially orthogonal to the first direction. The inner side in each second direction is a side nearer an axial center of the first ring. Each contact spring includes a first end portion on a side nearer the first ring, and a wide portion including at least an apex portion of the contact spring and having a width dimension that is larger than a width dimension of the first end portion.
H01R 13/648 - Protective earth or shield arrangements on coupling devices
H01R 24/40 - Two-part coupling devices, or either of their cooperating parts, characterised by their overall structure having concentrically or coaxially arranged contacts specially adapted for high frequency
To provide a waterproof cable that is easily manufactured and improves waterproofness.
The waterproof cable includes: a first cable; a second cable, an end of which is connected with an end of the first cable; a first resin member that coats a connecting part and is formed by insert-molding; a second resin member that coats the first resin member and is formed by insert-molding; and a third resin member that coats the second resin member and is formed by insert-molding.
H01R 13/40 - Securing contact members in or to a base or caseInsulating of contact members
H01B 7/282 - Preventing penetration of fluid into conductor or cable
H01R 13/52 - Dustproof, splashproof, drip-proof, waterproof, or flameproof cases
H01R 43/00 - Apparatus or processes specially adapted for manufacturing, assembling, maintaining, or repairing of line connectors or current collectors or for joining electric conductors
82.
Method of manufacturing cellulose nanofiber compact
A method of manufacturing a cellulose nanofiber compact includes a supporting step of supporting a plate-like first precursor containing cellulose nanofibers in a heating vessel, a preliminary molding step of heating the first precursor supported in the heating vessel with infrared rays to obtain a plate-like second precursor and a molding step of molding the second precursor, with heating and pressurizing the second precursor in a mold.
[Problem] The present invention enables suitable and simultaneous contactless communication using a plurality of communication antennas. [Configuration] A module M1 is provided with first, second communication antennas 200a that are arranged substantially concentrically. A digital signal can be inputted to at least one of terminal parts 221a, 222a of each of the first, second communication antennas 200a. The terminal parts 221a, 222a of the first communication antenna 200a and the terminal parts 221a, 222a of the second communication antenna 200a are arranged such that a first virtual region between a pair of virtual first half-lines which radially extend, from a center C of the first communication antenna 200a by passing at least one portion of the inner ends of the terminal parts 221a, 222a of the first communication antenna 200a, and a second virtual region between a pair of virtual second half-lines which extend, from the center C of the first or second communication antenna 200a by passing at least one portion of the inner ends of the terminal parts 221a, 222a of the second communication antenna 200a, do not overlap with each other in a plan view.
H04B 5/02 - Near-field transmission systems, e.g. inductive loop type using transceiver
H01Q 1/24 - SupportsMounting means by structural association with other equipment or articles with receiving set
H01Q 1/52 - Means for reducing coupling between antennas Means for reducing coupling between an antenna and another structure
H01Q 7/00 - Loop antennas with a substantially uniform current distribution around the loop and having a directional radiation pattern in a plane perpendicular to the plane of the loop
H01Q 21/28 - Combinations of substantially independent non-interacting antenna units or systems
A microphone unit 1 is provided with: a sound data acquisition unit 11 for acquiring a voice as sound data; a sound data registration unit 12 for registering collation sound data obtained by extracting feature points from the sound data; an evaluation sound data acquisition unit 13 for acquiring voice that is input to a first microphone 10 as evaluation sound data; a collation unit 14 for performing a collation on the basis of the collation sound data and feature points extracted from the evaluation sound data to determine whether or not a speaker of the voice based on the evaluation sound data is the speaker of the voice based on the collation sound data; and a collation result output unit 15 for outputting the collation results from the collation unit 14.
H01R 43/20 - Apparatus or processes specially adapted for manufacturing, assembling, maintaining, or repairing of line connectors or current collectors or for joining electric conductors for assembling or disassembling contact members with insulating base, case or sleeve
A control apparatus (1) which performs bi-directional communication with a control unit (2) on the basis of a preset time division is provided with: a plurality of devices (10) that are mounted on different substrates (40); a communication control unit (20) that is connected in a daisy-chain fashion to the control unit (2) via a bus line (3) for bi-directional communication of communication data comprising a data structure with a bandwidth in which data to be communicated from/to the plurality of devices (10) can be overlaid; and a cable (30) that connects at least one of the plurality of devices (10) to the communication control unit (20).
B60R 16/023 - Electric or fluid circuits specially adapted for vehicles and not otherwise provided forArrangement of elements of electric or fluid circuits specially adapted for vehicles and not otherwise provided for electric for transmission of signals between vehicle parts or subsystems
B60R 11/02 - Arrangements for holding or mounting articles, not otherwise provided for for radio sets, television sets, telephones, or the likeArrangement of controls thereof
B60R 16/02 - Electric or fluid circuits specially adapted for vehicles and not otherwise provided forArrangement of elements of electric or fluid circuits specially adapted for vehicles and not otherwise provided for electric
H04L 12/28 - Data switching networks characterised by path configuration, e.g. LAN [Local Area Networks] or WAN [Wide Area Networks]
H04R 3/12 - Circuits for transducers for distributing signals to two or more loudspeakers
A speaker housing of the present invention is a speaker housing for housing a speaker unit, wherein a first rib and/or a second rib whose distance from the speaker unit continuously changes is provided inside the speaker housing, so that the distance from the speaker unit to the first rib and/or the second rib is not constant, resonance is dispersed, no remarkable resonance occurs, and deterioration of distortion can be reduced.
This disclosure provides a waterproof electronic component having good waterproofness and a method for assembling the waterproof electronic component. A repeater as a waterproof electronic component includes (i) a substrate having first through holes, (ii) a socket fixed to the substrate, (iii) a housing containing the substrate, (iv) a pin held by the housing and having a first end connected to the substrate, and (v) a sealing section with which an area surrounded by the substrate and the housing is filled, the housing including a support including a supportive wall section capable of supporting a fixation portion of the socket and a seat section having a seating surface on which the substrate is placed, the substrate being placed on the seat section, the socket being oriented in such a manner that at least a portion of an outer surface of the fixation portion is close to and faces the supportive wall section.
A sensor (11) that has a switch (11f) and that detects pressing or the proximity of a finger from the front side toward the switch (11f) is provided on the rear side of a covering (15), and protuberances (9a, 9b) are provided on the front surface of a base (9). The covering (15) is provided with translucent regions (R1) that transmit light (L) from a light source (23) to the front side, a non-translucent region (R2) that blocks the light (L) from the light source (23), said regions (R1, R2) overlapping a light guide of the base (9) and the switch (11f) of the sensor (11). Bulging parts (15a, 15b) that bulge to the front side are formed near the translucent regions (R1) in the non-translucent region (R2) of the covering (15), and the protuberances (9a, 9b) on the base (9) are accommodated from the rear side in the bulging parts (15a, 15b).
H01H 36/00 - Switches actuated by change of magnetic field or of electric field, e.g. by change of relative position of magnet and switch, by shielding
B60R 16/02 - Electric or fluid circuits specially adapted for vehicles and not otherwise provided forArrangement of elements of electric or fluid circuits specially adapted for vehicles and not otherwise provided for electric
The present invention provides a substrate on which a reverse sound hole type MEMS microphone can be mounted, and which has high ESD resistance. This substrate has one surface connected to an MEMS microphone, and comprises a substrate sound hole that penetrates the substrate and communicates with a sound hole of the MEMS microphone, and a GND pad that is disposed around the substrate sound hole of the other surface of the substrate.
An electronic component assembly including a fixing part fixable to a first face on a first-direction side of an adherend, an electronic component, and a housing. The adherend has a housing hole opening in the first face. The housing includes a fixed portion fixed to the fixing part and a housing body to house the electronic component. The housing body includes a first portion disposed on a second-direction side relative to the fixing part. The second direction is opposite to the first direction. The first portion of the housing body has a dimension in the second direction that is equal to, or smaller than, a dimension in the second direction of the housing hole of the adherend. The first portion of the housing body is configured to be housed in the housing hole of the adherend.
H05K 1/18 - Printed circuits structurally associated with non-printed electric components
H05K 7/14 - Mounting supporting structure in casing or on frame or rack
B60R 11/02 - Arrangements for holding or mounting articles, not otherwise provided for for radio sets, television sets, telephones, or the likeArrangement of controls thereof
H05K 13/00 - Apparatus or processes specially adapted for manufacturing or adjusting assemblages of electric components
94.
Electronic component module, combination of electronic component module and casing, and control device including the combination
An electronic component module including a fixing part, a function part housed in, or fixed to, the fixing part, at least one connection line, and at least one protrusion on the function part or the fixing part. The fixing part includes an abutting face, an outer face extending from an end of the abutting face in a direction including a component of a first direction, and an edge line along which the abutting and outer faces meet. The connection line is flexible, electrically connected to the function part, positioned on a second direction side relative to the abutting face, and configured to be led out in a third direction from an inside to an outside relative to the edge line. The protrusion extends at least partly in the third direction and is positioned at least partly on the first direction side relative to the connection line in the led-out state.
A vibratable element for loudspeaker use including a coil bobbin, a voice coil attached thereto, and a main body being constituted by a single thin plate and including a fixing portion, a damper portion, a vibrating portion, and an edge portion. The fixing portion is a part of the plate to which the coil bobbin is fixed from one side in a first direction being the axial direction of the voice coil. The damper portion is a part of the plate located inside the fixing portion. The vibrating portion is a part of the plate located outside the fixing portion. The inside refers to a side toward the center of the plate, and the outside refers to a side away from the center of the plate. The edge portion is a part of the plate outside the vibrating portion and includes an outer perimeter portion of the plate.
H04R 1/28 - Transducer mountings or enclosures designed for specific frequency responseTransducer enclosures modified by provision of mechanical or acoustic impedances, e.g. resonator, damping means
H04R 9/04 - Construction, mounting, or centering of coil
A sensor control device includes a plurality of drive units for oscillating respective transducers included in a plurality of ultrasonic sensors, a driving signal generation section for generating driving signals capable of oscillating the respective plurality of transducers, a control unit having a control signal output section for outputting, to each one of the plurality of drive units, a control signal as an input command for the driving signal to the respective transducer and a bus line configured to connect the control unit to the plurality of drive units in form of a daisy-chain, the bus line being used for bidirectional communication of communication data between the control unit and the plurality of drive units based on preset time-division, the communication data being comprised of a data structure having a first band that allows superimposition of audio data thereon. Control data based on the control signal is included in the first band.
A sound producing device in which an adhesive layer between a piezoelectric element and a metal plate has sufficient electrical conductivity includes: a metal plate; a piezoelectric ceramic including a first adhesion surface, the first adhesion surface being a surface bonded to the metal plate; an alternating current power supply that applies an alternating voltage to the piezoelectric ceramic; and an adhesive layer formed from conductive adhesive and thermosetting adhesive which are spread over the first adhesion surface, the conductive adhesive being applied in a center portion of the first adhesion surface and the thermosetting adhesive being applied at three or more locations in a periphery of the first adhesion surface. An adhesion surface of the metal plate that is bonded to the piezoelectric ceramic is a second adhesion surface, and the first adhesion surface and the second adhesion surface are bonded together by the adhesive layer.
H01L 41/313 - Applying piezo-electric or electrostrictive parts or bodies onto an electrical element or another base by laminating or bonding of piezo-electric or electrostrictive bodies by metal fusing or with adhesives
H10N 30/073 - Forming of piezoelectric or electrostrictive parts or bodies on an electrical element or another base by laminating or bonding of piezoelectric or electrostrictive bodies by fusion of metals or by adhesives
A proximity sensor including a first substrate, a second substrate, a first connecting member, at least one first electrode, and a detection part. The first substrate is disposed in the vicinity of a first detection space. The second substrate is disposed on an opposite side of the first substrate to the first detection space. The second substrate faces the first substrate. The first connecting member connects the first substrate and the second substrate. The at least one first electrode is provided on the first substrate and configured such that a signal from the at least one first electrode changes in response to a change in a first capacitance caused by a detection target approaching to the first detection space. The detection part is provided on the second substrate and configured to detect the approach of the detection target based on the signal from the at least one first electrode.
