The present disclosure relates to systems and methods for ionizing a surface. In one implementation, an ionization source may include a microhollow cathode plasma or micro cavity plasma (MCP)-based ion source having a cavity and generating a plasma. A gas stream may pass through the cavity and transport the plasma. The source may further include one or more conductive electrodes located downstream from the MCP and configured to have a potential relative to the MCP such that positive and negative ions included in the plasma are carried through the electrodes by the gas stream. In another implementation, a mixer may mix a dopant (e.g. water) with the gas stream (e.g. air) entering the discharge. The disclosure also relates to a surface ionization probe.
The present disclosure relates to systems and methods for transferring ions to a mass spectrometer. In one implementation, the system includes an ion source; a device for generating a solvent vapor; a unit for mixing the ions and the vapor; and a transfer tube coupled to the mass spectrometer. The mixing may cause solvent clusters to nucleate on the ions, and the transfer tube may couple the ion source and the mass spectrometer. Furthermore, the transfer tube may be configured to transfer the ions by using a gas flow and prevent the solvent clusters from contacting the tube wall by using thermophoresis.
H01J 49/04 - Arrangements for introducing or extracting samples to be analysed, e.g. vacuum locksArrangements for external adjustment of electron- or ion-optical components
10.
MASS SPECTROMETERS HAVING REAL TIME ION ISOLATION SIGNAL GENERATORS
Apparatuses, systems, and methods for performing mass analysis are disclosed. One such apparatus may include an ion trap device for use in a mass analysis system. The ion trap device may comprise a ring electrode, a pair of endcaps, and a signal generator for applying a trapping signal to the ring electrode. The trapping signal may be configured to cause the ring electrode to generate an electric field. The signal generator may include a plurality of oscillators each configured to selectively generate a corresponding sinusoid signal to be selectively combined to form the trapping signal.
An ion trap for a mass spectrometer is disclosed. The ion trap includes a ring electrode and first and second electrodes which are arranged on opposite sides of the ring electrode. The ring electrode and the first and second electrodes are configured to generate an electric field based on the received RF signal. The first electrode defines a first aperture and the second electrode defines a second aperture, the first aperture and the second aperture being asymmetric relative to each other and configured to generate a hexapole field.
A mass spectrometer comprises an ion trap configured to trap ions and to eject ions. The ion trap comprises an e!ectrode. The mass spectrometer further comprises a detector configured to detect ions ejected from the ion trap, a radio frequency (RF) generator electrically coupled to the electrode and configured to generate an RF signal, a sampling circuit electrically coupled to electrode and configured to measure a voltage of the RF signal at the electrode, and a signal processor electrically coupled to the sampling circuit and the detector. The signal processor is configured to receive outputs from the detector and the sampling circuit and to correct the output from the detector based on the output from the sampling circuit.
A mass spectrometer for analyzing a sample utilizing an ion trap comprises an entrance end cap defining an entrance aperture configured to receive the sample entering the ion trap; a ring electrode defining a ring cavity configured to generate, based on a radio frequency (RF) voltage applied to the ring electrode, an electric field configured to trap the sample received through the entrance aperture; an exit end cap defining an exit aperture configured to receive sample ions exiting the ion trap; and an end cap controller configured to generate a bias control voltage for applying a DC bias potential to at least one of the entrance end or the exit end cap, wherein a value of the bias control voltage is based on an operational parameter of the mass spectrometer.
A mass spectrometer comprising a controller configured to generate an RF signal to be applied to an electrode during the mass scan, wherein the electrode generates, based on the RF signal, an electric field to be applied to sample ions during a mass scan; an ion detector configured to detect sample ions passing through the electric field and generate a corresponding ion detection signal; and a sampling circuit configured to sample the ion detection signal; wherein the controller is configured to adjust a phase of the at least one RF signal relative to a sample timing of the sampling circuit and average successive mass scans to cancel a portion of the RF signal present in the ion detection signal.
In mass spectrometry, the number of ionized sample molecules affects various performance specifications of the resulting spectrum, including resolution, sensitivity, dynamic range, and scan speed. A voltage-controlled lens is used to control the number of electrons emitted from an electron source that enter the ion trap and ionize the target sample molecules. By monitoring a feature of the resulting spectrum, such as the resolution, total ion current, or a combination of these features, the lens voltage may be adjusted to create the optimal number of ions in the trap for a particular sample spectrum scan. Generally, for low concentration samples, the number of electrons introduced to the trap is increased, hence creating more ions in the trap, which in turn increases the intensity of the output signal improving the probability of detecting a sufficient number of ions by raising the intensity well above the noise floor. For higher concentration samples, the number of electrons is reduced, thus reducing interactions in the trap which in turn reduces peak broadening and improves resolution, as well as avoids saturating the detector. Several methods for adjusting the lens voltage may be used. First, the lens voltage may be repeatedly adjusted until the resulting spectrum reaches a desired trade-off between resolution and sensitivity. The lens voltage may also be incrementally increased until the resulting spectrum begins to exhibit space charge effects. Finally, all lens voltages in a list of usable voltage settings may be applied, and all the resulting spectra are compared. The optimal voltage setting is selected and used for subsequent scans.
A mass spectrometer is disclosed. The mass spectrometer may include an ion trap configured to trap and analyze an ionized sample. A first aperture may be provided having a first diameter, and a second aperture may be provided having a second diameter. The first aperture may be configured to receive electrons for the purpose of ionizing sample ions within the ion trap. The second aperture may be configured to receive photons for the purpose of ionizing sample ions within the ion trap.
A mass spectrometer system is disclosed. The mass spectrometer includes a vacuum chamber defining an enclosed evacuated space and an ion trap disposed in the enclosed space. The ion trap is configured to trap an ionized sample. The mass spectrometer further includes an son detector coupled to the chamber at a location external to the chamber such that sample ions may exit the evacuated space and into the externally-coupled detector without loss of vacuum pressure.
Apparatuses and methods for performing mass analysis are disclosed. One such apparatus may include an ion trap device. The ion trap device may comprise a first end cap having a first aperture and a second end cap having a second aperture, wherein the first aperture and the second aperture may define an ejection axis. The ion trap device may also comprise a ring electrode substantially coaxially aligned between the first and second end caps. The ring electrode may include an opening extending along a radial direction of the ring electrode, wherein the radial direction is substantially perpendicular to the ejection axis. One such method may include ionizing a sample in an ion trap through an opening separating at least part of first and second ring sections of the ion trap and detecting ions ejected though an aperture on an end cap of the ion trap.
H01J 49/42 - Stability-of-path spectrometers, e.g. monopole, quadrupole, multipole, farvitrons
H01J 49/00 - Particle spectrometers or separator tubes
H01J 49/04 - Arrangements for introducing or extracting samples to be analysed, e.g. vacuum locksArrangements for external adjustment of electron- or ion-optical components
09 - Scientific and electric apparatus and instruments
Goods & Services
(1) Portable chemical detector capable of sensing residues and vapors from a wide range of chemicals including explosives, chemical warfare agents, toxic chemicals, and volatile organic compounds.
09 - Scientific and electric apparatus and instruments
10 - Medical apparatus and instruments
41 - Education, entertainment, sporting and cultural services
Goods & Services
Portable chemical detector capable of detecting residues and vapors from a wide range of chemicals including explosives, chemical warfare agents, toxic chemicals, and volatile organic compounds; scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; analyzers, other than for medical purposes; detectors, other than for medical purposes; chemical detectors, other than for medical purposes; portable chemical detector capable of detecting residues and vapors from a wide range of chemicals including explosives, chemical warfare agents, toxic chemicals, and volatile organic compounds; spectrometers, other than for medical purposes; apparatus for recording, transmission or reproduction of data, sound or images; magnetic data carriers, recording discs; sound, video and data recordings; data processing equipment and computers; computer hardware; computer software; parts and spare parts of the aforementioned goods, as far as included in this class. Surgical, medical, dental and veterinary apparatus and Instruments; analyzers for medical purposes; detectors for medical purposes; chemical detectors for medical purposes; portable chemical detectors capable of detecting residues and vapors from a wide range of chemicals including explosives, chemical warfare agents, toxic chemicals, and volatile organic compounds, for medical purposes; spectrometers for medical purposes; parts and spare parts of the aforementioned goods, as far as included in this class. Education; providing of training; publication and rental of books, magazines, journals, newspapers, catalogues and of printed publications; arranging and conducting conferences, discussion forums, exhibitions, programs, seminars, symposiums and workshops; all aforementioned services related to analyzers, detectors, and spectrometers; information and advice regarding the aforementioned services.
Processing a liquid sample (204) having an analyte (206) by reducing a pressure in a container (200) including the liquid sample to less than atmospheric pressure and maintaining a reduced pressure in the container. Reducing the pressure in the container (200) and optionally agitating the liquid sample increases an amount of vapor-phase analyte (206) above the liquid sample. In some cases, a concentration of the vapor-phase analyte is further increased, for example, with a chemical trap (502). The vapor-phase analyte can be provided to a chemical analyzer (302).
A chemical preconcentrator (100) includes a conduit (200) defining a flow path (106) between two ends (108A, 108B) and having a heating element (102) disposed within the conduit, such that the heating element has at least one sorbent material (115) deposited directly on at least a portion of a conductive surface of the heating element. Some such heating elements (102) are in the form of electrically conductive strips defining both a plurality of apertures (112, 710) through the strip and a series of undulations (114) spaced along the flow path (106).
In one general aspect, a sample is transferred into a mass spectrometer (150) by capturing a sample on a collector (125), inserting the collector (125) into a sample chamber (110) coupled to the mass spectrometer (150) and a vacuum pump (342, 344), evacuating the sample chamber (110) using the vacuum pump (342, 344) to reduce an internal pressure of the sample chamber (110) to a level less than atmospheric pressure, heating the collector (125) to release the sample from the collector, and introducing the sample into the mass spectrometer (150) from the evacuated sample chamber (110).
H01J 49/04 - Arrangements for introducing or extracting samples to be analysed, e.g. vacuum locksArrangements for external adjustment of electron- or ion-optical components
09 - Scientific and electric apparatus and instruments
Goods & Services
(1) Portable chemical detector capable of detecting residues and vapors from a wide range of chemicals including explosives, chemical warfare agents, toxic chemicals, and volatile organic compounds.
09 - Scientific and electric apparatus and instruments
10 - Medical apparatus and instruments
41 - Education, entertainment, sporting and cultural services
Goods & Services
Portable chemical detectors, namely mass spectrometers, capable of detecting residues and vapors from a wide range of chemicals including explosives, chemical warfare agents, toxic chemicals, and volatile organic compounds, but not for the detection of metals, semiconductors or coatings in solid or liquid form. Surgical, medical, dental and veterinary apparatus and instruments; analyzers for medical purposes; detectors for medical purposes; chemical detectors for medical purposes; portable chemical detectors capable of detecting residues and vapors from a wide range of chemicals including explosives, chemical warfare agents, toxic chemicals, and volatile organic compounds, for medical purposes; spectrometers for medical purposes; parts and spare parts of the aforementioned goods, as far as included in this class. Education; providing of training; publication and rental of books, magazines, journals, newspapers, catalogues and of printed publications; arranging and conducting conferences, discussion forums, exhibitions, programs, seminars, symposiums and workshops; all aforementioned services related to analyzers, detectors, and spectrometers; information and advice regarding the aforementioned services.
09 - Scientific and electric apparatus and instruments
Goods & Services
(1) Portable chemical detector capable of detecting residues and vapors from a wide range of chemicals including explosives, chemical warfare agents, toxic chemicals, and volatile organic compounds.
09 - Scientific and electric apparatus and instruments
Goods & Services
(1) Portable chemical detector capable of detecting residues and vapors from a wide range of chemicals including explosives, chemical warfare agents, toxic chemicals, and volatile organic compounds.
A computer-implemented method includes receiving data at a processing device, the data having been transferred over a secure connection from a transceiver coupled to a chemical detector and comprising a detection signal generated by the chemical detector, processing the data using the processing device to generate a human readable message, displaying the human readable message on a user interface of the processing device, receiving user input at the processing device, generating a control signal based on the user input, and transmitting the control signal to the chemical detector.
G08C 17/02 - Arrangements for transmitting signals characterised by the use of a wireless electrical link using a radio link
H04Q 9/00 - Arrangements in telecontrol or telemetry systems for selectively calling a substation from a main station, in which substation desired apparatus is selected for applying a control signal thereto or for obtaining measured values therefrom
09 - Scientific and electric apparatus and instruments
Goods & Services
portable chemical detector capable of detecting residues and vapors from a wide range of chemicals including explosives, chemical warfare agents, toxic chemicals, and volatile organic compounds
09 - Scientific and electric apparatus and instruments
Goods & Services
portable chemical detector capable of detecting residues and vapors from a wide range of chemicals including explosives, chemical warfare agents, toxic chemicals, and volatile organic compounds
09 - Scientific and electric apparatus and instruments
Goods & Services
portable chemical detector capable of detecting residues and vapors from a wide range of chemicals including explosives, chemical warfare agents, toxic chemicals, and volatile organic compounds
A chemical analysis system is disclosed wherein, in evacuating a preconcentrator housing (2) prior to desorption, a pump system (13) reduces an internal pressure of the preconcentrator housing to a level substantially equal to an internal pressure of a chemical analyzer such that flow restrictors and/or membranes (15) between the chemical analyzer (7) and the preconcentrator housing (2) may be omitted. The chemical analysis system includes a chemical analyzer (7), a preconcentrator housing (2) coupled to the chemical analyzer, the preconcentrator housing enclosing a temperature control element (5, 18) and a sorbent material (1), the temperature control element configured to heat the sorbent material to adsorb or desorb a chemical of interest; and a pump system (13) coupled to the preconcentrator housing and the chemical analyzer, the pump system configured to evacuate the preconcentrator housing prior to desorption of the chemical of interest.
A radio frequency (RF) drive system and method for driving the ion trap or mass filter of a mass spectrometer has a programmable RF frequency source coupled to a RF gain stage. The RF gain stage is transformer coupled to a tank circuit formed with the ion trap or mass filter. The power of the RF gain stage driving the ion trap or mass filter is measured using a sensing circuit and a power circuit. A feedback value is generated by the power circuit that is used to adjust the RF frequency source. The frequency of the RF frequency source is adjusted until the power of the RF gain stage is at a minimum level.
