01 - Chemical and biological materials for industrial, scientific and agricultural use
Goods & Services
Chemical additives for fuel; Chemical additives for fuel treatment; Chemical engine treatments and additives for engine oils, gasoline and diesel fuels, transmission fluids and cooling systems
01 - Chemical and biological materials for industrial, scientific and agricultural use
Goods & Services
Chemical additives for fuel; Chemical additives for fuel treatment; Chemical engine treatment preparations and additives for engine oils, gasoline and diesel fuels, transmission fluids and cooling systems
01 - Chemical and biological materials for industrial, scientific and agricultural use
Goods & Services
Chemical additives for fuel; Chemical additives for fuel treatment; Chemical engine treatment preparations and additives for engine oils, gasoline and diesel fuels, transmission fluids and cooling systems
A magnetic ball joint press apparatus has first and second receivers at opposite ends of a clamp of the apparatus that employ permanent magnets to hold respective first and second ball joint adapters to the opposite ends of the apparatus. The permanent magnets holding the ball joint adapters to the opposite ends of the clamp of the apparatus significantly facilitate use of the apparatus.
B25B 27/02 - Hand tools or bench devices, specially adapted for fitting together or separating parts or objects whether or not involving some deformation, not otherwise provided for for connecting objects by press fit or detaching same
B25B 27/00 - Hand tools or bench devices, specially adapted for fitting together or separating parts or objects whether or not involving some deformation, not otherwise provided for
This invention is a sensor probe, generally used in the oil fracking business, and includes structurally a pair of tube members, concentrically assembled, an inner housing tube, and an outer spout tube, affixed to a cap and adaptor, with the inner housing holding one or more sensors, to detect the level of fuel within the fuel tank of the fracking truck. The adaptor has a first aperture for attachment of the fuel line, for delivery of fuel in the space between the tube members, and the adaptor has a second aperture for connection of an electrical receptacle, for attachment with the electric lines leading from the various sensors, to the adaptor, for connection with a circuit line from a remote monitor.
G01F 23/30 - Indicating or measuring liquid level or level of fluent solid material, e.g. indicating in terms of volume or indicating by means of an alarm by floats
G01F 23/60 - Indicating or measuring liquid level or level of fluent solid material, e.g. indicating in terms of volume or indicating by means of an alarm by floats using elements rigidly fixed to, and rectilinearly moving with, the floats as transmission elements using electrically actuated indicating means
B60K 15/077 - Fuel tanks with means modifying or controlling distribution or motion of fuel, e.g. to prevent noise, surge, splash or fuel starvation
8.
Integral tilted poppet valve for controlled flow of fuel from fuel dispensing nozzle
An integral tilted poppet valve for controlled flow of fuel from a fuel dispensing nozzle, including a poppet skirt, embodied within the poppet valve accessory of this invention, the poppet skirt cooperates with the poppet stem, and the poppet holder and its seal disc, to furnish a sealing of the nozzle, through the poppet valve, when the fuel nozzle is not in use, but that upon actuation of the nozzle lever, elevating its poppet stem, the poppet skirt includes an upper inclined surface for biasing against the poppet holder and its seal disc, to tilt the opening of the nozzle to provide for a minor or trickle flow of fuel through the nozzle to furnish a more precise dispensing of the quantity and value of the fuel being delivered to a vehicle.
A pressure vacuum vent is disclosed which has a pressure plate having an opening, a diaphragm positioned on the pressure plate, a sealing ring for holding the diaphragm to the pressure plate, a sealing plate positioned on the diaphragm, a retaining ring for retaining the sealing ring, a screw having a cap having a vent opening, and a spring positioned between the cap and the sealing plate.
A hand-held tool for straightening tubing such as brake fluid lines in vehicles, the tool provides a housing having an outer covering, internally thereof, a series of sets of rollers, that are adjustable radially, supported by end frames, and intermediate the rollers and the outer covering is an adjuster ring, shiftable longitudinally within the housing, operatively associated with the rollers, such that when the adjuster ring is pulled outwardly, longitudinally, from the tool housing, the rollers shift radially outwardly, for accommodating larger tubing, and when the adjuster ring is pushed inwardly of the housing, the rollers are forced inwardly against smaller diameter tubing, in preparation for its straightening. A sector of the tool, usually along a quadrant, is opened from one end to the other of the tool, so as to allow the tool to be applied to the tubing to be straightened, anywhere along its length, and not only at its ends.
B21D 3/05 - Straightening or restoring form of metal rods, metal tubes, metal profiles, or specific articles made therefrom, whether or not in combination with sheet metal parts by rollers arranged on axes rectangular to the path of the work
B21D 3/04 - Straightening or restoring form of metal rods, metal tubes, metal profiles, or specific articles made therefrom, whether or not in combination with sheet metal parts by rollers arranged on axes skew to the path of the work
A co-fueling nozzle incorporating dual spouts, having a nozzle housing, a pair of fuel flow paths provided through the housing, a separate poppet and automatic shut off valve operatively associated with each flow path, such that when fuel or additive flows through the various flow paths, it is dispensed out of separate nozzle spouts, when fuel dispensing is initiated. A single actuating lever operates to open or close the poppet valves of the nozzle, and the actuating lever connects with a pair of independent actuators, that engage with their respective poppet valves and automatic shut off valves, to provide for simultaneous or independent opening and closing of the poppet valves, to allow for simultaneous or separate flow of fuel or additives through the nozzle for co-fueling of a vehicle fuel tank or tanks.
An auxiliary or additive fluid for associated use with the primary diesel or related fuel, for application for reduction of exhaust pollution, and for motor or truck vehicle, or the like, includes the nozzle, the nozzle having its spout extending from its forward end, the spout having an outer sleeve, an inner sleeve through which the fluid flows during dispensing, a lower sleeve capable of shifting within the outer sleeve, and integrated with a safety valve sleeve, and biased axially inwardly of the spout when it is inserted into the fluid intake pipe of a vehicle intake for a fluid tank. A primary safety valve extends through the lower spout sleeve, and the integral safety valve sleeve is maintained in a fixed position, and normally is sealed into closure within the lower end of the lower spout sleeve. But, when the lower spout sleeve is forced axially inwardly, it unseats the safety valve from its sealing therewith, to open the spout for the dispensing of the fuel when the nozzle is actuated to allow fluid flow. In addition, a flow path for air that is normally closed by a check valve, is likewise opened, to allow for the passage of air to maintain the inoperativeness of the automatic shut-off, until such time as the fluid flow closes off the lower end said passage, initiating the automatic shut-off of the fluid dispensing nozzle, when the intake of air is blocked.
B67D 7/52 - Filling nozzles automatically closing and provided with additional flow-controlling valve means
B67D 7/34 - Means for preventing unauthorised delivery of liquid
B67D 7/04 - Apparatus or devices for transferring liquids from bulk storage containers or reservoirs into vehicles or into portable containers, e.g. for retail sale purposes for transferring fuels, lubricants or mixed fuels and lubricants
B67D 7/50 - Filling nozzles automatically closing and provided with an additional hand lever
A custom blending hose for manifold mixing of various fuels for a fuel dispensing system, including a pair of fuel dispensing hoses, generally concentrically or coaxially arranged, for passing at least a pair of fuels into a manifold assembly, for blending and intermixing of said fuels, for further delivery through a dispensing hose assembly, to a nozzle, for refueling of a vehicle. The manifold includes a housing, incorporating internally a series of apertures, through which the fuels are passed, and blended, for delivery as a uniform fuel to a vehicle during dispensing. A vapor return line may locate through the manifold.
B67D 7/74 - Devices for mixing two or more different liquids to be transferred
B67D 7/04 - Apparatus or devices for transferring liquids from bulk storage containers or reservoirs into vehicles or into portable containers, e.g. for retail sale purposes for transferring fuels, lubricants or mixed fuels and lubricants
06 - Common metals and ores; objects made of metal
Goods & Services
Fuel dispensing equipment sold as a unit, namely, metal non-automatic fuel dispensing nozzles and guards therefore, breakaway metal couplings for fuel dispensing lines, fuel flow equalizers, swivels, and vents and parts therefore
A fuel dispensing nozzle, incorporating a uniquely shaped gasket for the poppet valve, generally of truncated shape, enhances the flow of fuel through the nozzle when actuated. A handle lever for the nozzle, which is designed having an elongated and enlarged end, includes elongated slots, that are pivotally pinned through both the latch plate, and the handle link, in order to reduce the space between the interconnection between the front of the latch plate to the bottom of the automatic shutoff stem, such that by lessening the distance between these components, thereby reducing the fulcrum point for the calculation of the force necessary to open the nozzle by raising its handle lever, and reduces the force necessary to achieve nozzle opening and actuation, to less than 5 lbs pressure during usage and application.
B67D 7/04 - Apparatus or devices for transferring liquids from bulk storage containers or reservoirs into vehicles or into portable containers, e.g. for retail sale purposes for transferring fuels, lubricants or mixed fuels and lubricants
A tank monitor control device is disclosed which comprises a monitoring device for insertion into a day tank to monitor a level of fluid stored in the day tank, a shutoff valve connected between a main storage tank and a diaphragm pump, a solenoid valve connected between an air supply and the diaphragm pump, and a control device connected to the monitoring device for receiving a signal indicative of the level of fluid in the day tank, the control device connected to the shutoff valve and the solenoid valve.
F16K 21/18 - Self-closing valves, i.e. closing automatically after operation closed when a rising liquid reaches a predetermined level
F16K 31/20 - Operating meansReleasing devices actuated by fluid actuated by a float actuating a lift valve
F16K 31/26 - Operating meansReleasing devices actuated by fluid actuated by a float actuating a lift valve with a transmission with parts linked together from a single float to a single valve with the valve guided for rectilinear movement and the float attached to a pivoted arm
G05D 9/12 - Level control, e.g. controlling quantity of material stored in vessel characterised by the use of electric means
G05D 9/00 - Level control, e.g. controlling quantity of material stored in vessel
G01F 23/74 - Indicating or measuring liquid level or level of fluent solid material, e.g. indicating in terms of volume or indicating by means of an alarm by floats of the free float type using magnetically actuated indicating means for sensing changes in level only at discrete points
A safety interlock nozzle for use with a safety interlock mechanism is disclosed which comprises a base having an interlock contact surface at a first end and alternating tabs at a second end, a body having alternating tabs at a first end that mate with the alternating tabs of the base, a channel within the body positioned at a second end, a ring clamp for connecting the tabs of the base to the tabs of the body, a splash guard having a first end for contacting with a filler neck housing and a second end having a slot formed therein, the second end capable of fitting within the channel of the second end of the body, and a spring for being captured within the channel in the body and the slot within the splash guard, the spring for connecting the splash guard to the body.
B67D 7/54 - Filling nozzles with means for preventing escape of liquid or vapour or for recovering escaped liquid or vapour
B67D 7/00 - Apparatus or devices for transferring liquids from bulk storage containers or reservoirs into vehicles or into portable containers, e.g. for retail sale purposes
B67D 7/32 - Arrangements of safety or warning devicesMeans for preventing unauthorised delivery of liquid
Modularized components assembled dispensing nozzle, including operating components in the category of a poppet valve assembly, an automatic shutoff device, a hand operating lever for providing a turn on or shutoff of the dispensing of fluid through the nozzle, and a connected spout that delivers fluid to the fill pipe and fuel tank for a vehicle or fluid accepting container. Each of the identified components having been redesigned for assembly in modularized form, such as a modular cartridge for the poppet valve, a modular cartridge for the automatic shutoff device, a modularized operating hand lever, and a spout and its gland and retaining nut that provide for high speed interconnection with the nozzle body, during assembly, or servicing. Each of these modularized components can be installed, during assembly of the manufactured nozzle, or can be replaced, out in the field, by a service person, as a modularized component or cartridge assembly.
B67D 7/04 - Apparatus or devices for transferring liquids from bulk storage containers or reservoirs into vehicles or into portable containers, e.g. for retail sale purposes for transferring fuels, lubricants or mixed fuels and lubricants
27.
Magnetic breakaway coupling with swivel connection
A breakaway coupling including a pair of sleeves, one sleeve fitting within the other, each sleeve provided with a connector body, and a hose connector secured with one of the connector bodies. The first sleeve holds a metal annulus, while the second sleeve secures a ring separator, counterbored, to secure a series of round magnets therein, so that when the sleeves and their connector bodies are brought together, they are secured by the magnets into connection. When excessive force is encountered, the breakaway will separate, to prevent further discharge of fuel from the nozzle. A swivel connector secures with one of the connector bodies.
F16L 37/32 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in each of two pipe-end fittings at least one of two lift valves being opened automatically when the coupling is applied
01 - Chemical and biological materials for industrial, scientific and agricultural use
Goods & Services
Chemical additives for fuel treatment; Chemical engine treatments and additives for engine oils, gasoline and diesel fuels, transmission fluids and cooling systems
A high pressure dispensing nozzle for providing fuel from a reserve to a connector of an outlet receptacle, having a generally tubular nozzle construction, with an outer sleeve, an internal passageway constructed within the sleeve, a plurality of jaw members provided near the distal end of the tubular construction and provided for engagement to lock the connector to establish a fuel passageway through the nozzle for delivery of fuel therethrough and to the receiving tank. The nozzle includes a slidable piston that operates the various components for locking the jaws in position and aligning the fuel passageway with the fuel tank.
06 - Common metals and ores; objects made of metal
Goods & Services
(1) Metal non-automated fuel dispensing nozzles and guards therefor, breakaway metal couplings for fuel dispensing lines, fuel flow equalizers, swivels, vents and parts therefor, sold as a unit.
A threaded inline swivel has a first nut and an opposite second nut each having the form of a generally hollow cylinder with an open end to receive fuel. Each nut has a collar that has a common nominal diameter. A collar provides at least two faces for gripping by a wrench. Each nut has threading for connection to a hose or other fitting. To further seal the swivel to a hose or a fitting, at least one O-ring and at least one gasket are provided as alternative embodiments. In a further alternate embodiment, the swivel has a threaded second nut and an opposite barbed end on the first nut with a clip. The first nut has its chamber that constricts in diameter through a throat as it enters the second nut. The swivel in all embodiments provides for flow of fluid through it with little turbulence.
F16L 21/04 - Joints with sleeve or socket with elastic sealing rings between pipe and sleeve or between pipe and socket, e.g. with rolling or other prefabricated profiled rings in which sealing rings are compressed by axially-movable members
F16L 15/00 - Screw-threaded jointsForms of screw-threads for such joints
F16L 27/08 - Adjustable jointsJoints allowing movement allowing adjustment or movement only about the axis of one pipe
F16L 33/207 - Undivided rings, sleeves, or like members contracted on the hose or expanded inside the hose by means of toolsArrangements using such members only a sleeve being contracted on the hose
B67D 7/32 - Arrangements of safety or warning devicesMeans for preventing unauthorised delivery of liquid
F16L 27/00 - Adjustable jointsJoints allowing movement
01 - Chemical and biological materials for industrial, scientific and agricultural use
Goods & Services
Chemical additives for fuel; Chemical additives for fuel treatment; Chemical engine treatments and additives for engine oils, gasoline and diesel fuels, transmission fluids and cooling systems
01 - Chemical and biological materials for industrial, scientific and agricultural use
Goods & Services
Chemical additives for fuel; Chemical additives for fuel treatment; Chemical engine treatments and additives for engine oils, gasoline and diesel fuels, transmission fluids and cooling systems
An improvement in a vapor recovery line in the form of a vortex shedding flow meter installable within such vapor recovery line to monitor the flow rate of vapor being returned through the vapor recovery line, such flow meter including a housing having an inlet flange with an associated inlet connectable to the upstream portion of the vapor recovery line, an outlet flange with an outlet connectable to the downstream portion of the vapor recovery line, a housing for a passageway extending between the inlet and outlet, with a vortex strut extending into the passageway nearer the outlet to generate shed flow vortices and a transmitter-receiver transducer pair positioned nearer the outlet to subject the shed vortices to a sonic beam to effect modulation thereof, and an electronics package within an electronic housing portion for determining from such modulation the flow rate of the vapor passing through the vapor recovery line.
A high pressure dispensing nozzle for providing fuel from an inlet reserve to a connector of an outlet receptacle, including a generally tubular nozzle construction having an outer sleeve extending from adjacent a proximal end towards a distal end of the nozzle construction, an internal passageway construction disposed within the outer sleeve, and a plurality of radially movable jaw members disposed between the internal passageway construction and the outer sleeve extending to near the distal end of the tubular construction, wherein the internal passageway construction includes interacting components responsive to insertion of the connector into the distal end and engagement thereof with the internal passageway construction to effect movement of the jaws to lock the connector in engagement and to establish a fuel passageway through the nozzle construction for the delivery of fuel therethrough and wherein the internal passageway construction components include a pistonably slideable outlet tube construction that not only serves as part of the fuel delivery passageway through the nozzle construction but also both as a control for locking the jaws and the outer sleeve in a fueling configuration and as a valve construction for allowing and preventing fuel flow through the nozzle construction. The nozzle preferably is also responsive to the introduction of fuel thereinto to pressure lock the outer sleeve in a fueling configuration and additionally operates to prevent the dispensing of fuel in the event that a proper and correct connector is not locked into engagement for fuel dispensing.
F17C 5/06 - Methods or apparatus for filling pressure vessels with liquefied, solidified, or compressed gases for filling with compressed gases
F16L 37/084 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members combined with automatic locking
36.
Fuel line breakaway connector secured by plurality of individually spaced magnets
A breakaway coupling including a pair of sleeves, one sleeve fitting within the other, each sleeve having a hose connector secured therethrough, the first sleeve holding a metal annulus, the second sleeve securing a continuous magnetic annulus, so when the sleeves are brought together the magnetic annulus secures onto the metal annulus to hold the coupler in its connected position. The continuous metallic annulus includes a metal base, a spacer that holds a series of standard round magnets equally spaced around the approximate perimeter of the spacer and its base.
F16L 37/32 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in each of two pipe-end fittings at least one of two lift valves being opened automatically when the coupling is applied
An ORVR valve assembly operative of relatively few movable components includes a valve body, having conduits to provide for routine passage of vapors therethrough through operations of a vacuum assist system. This is when a non-ORVR vehicle is being replenished with fuel. But, when a vehicle equipped with ORVR vapor recovery is being fueled, vacuum is generated above a piston supported diaphragm, attracts the diaphragm upwardly, plugs off the vapor passage conduits, and allows the ORVR system of the automobile to exclusively treat the generated vapors at the location of the vehicle and its fuel tank. Simultaneously, air is vented into the valve body, below its diaphragm, and into the vapor return line of the vacuum assist system, to prevent it from being subject to excessive vacuuming. Thus, vapor recovery or treatment can be achieved through the use of the ORVR valve assembly of this invention, regardless whether the automobile being refueled is an ORVR equipped vehicle, or one that is not equipped with vapor recovery.
B67D 7/04 - Apparatus or devices for transferring liquids from bulk storage containers or reservoirs into vehicles or into portable containers, e.g. for retail sale purposes for transferring fuels, lubricants or mixed fuels and lubricants
A safety breakaway connector begins with a body that receives a cooperating insert providing a coaxial flow path. The body has threads, a collar leading to an extension, and a hollow interior. The insert also has threads, a collar that leads to an inner wall, and a hollow interior. The inner wall fits snugly within the extension of the body. Generally, the insert simply slides into and interconnects with the body for quick installation. Two spaced apart biased check valves remain slightly outwardly from the narrow portions of the body and insert. A guard covers the body. Upon the application of the minimum force, the insert separates from the body, and the check valves abruptly close preventing further leakage of fuel. Alternatively, a strategically located O-ring or gasket seals the various components and withstands pressure variations.
F16K 17/14 - Safety valvesEqualising valves opening on surplus pressure on one sideSafety valvesEqualising valves closing on insufficient pressure on one side with fracturing member
F16K 17/40 - Safety valvesEqualising valves with fracturing member, e.g. fracturing diaphragm, fusible joint
E03B 1/00 - Methods or layout of installations for water supply
F16L 37/32 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in each of two pipe-end fittings at least one of two lift valves being opened automatically when the coupling is applied
A threaded adaptor has a first end and an opposite second end of a generally hollow cylinder. At least one end has threading for connection to a hose or fitting and the ends form the male half of the connection. Centered upon the adaptor, a collar provides at least two faces for gripping of the adaptor by a tool. Within the adaptor, the two ends open into a smooth chamber that allows for uninterrupted fluid flow. To further seal the adaptor, at least one O-ring and at least one gasket are provided as alternate embodiments. In another alternate embodiment, the adaptor has one threaded end, an opposite barbed end with a clamp, and a collar with six faces. These two ends open into a chamber with a stepped diameter. The adaptor provides for flow of fluid with little turbulence.
F16L 17/00 - Joints with packing adapted to sealing by fluid pressure
F16L 15/04 - Screw-threaded jointsForms of screw-threads for such joints with additional sealings
F16L 25/14 - Joints for pipes of different diameters or cross-section
F16L 33/207 - Undivided rings, sleeves, or like members contracted on the hose or expanded inside the hose by means of toolsArrangements using such members only a sleeve being contracted on the hose
Crushing machines for industrial purposes, namely, oil filter crushers; tank-monitoring alarm systems composed of floats and vapor monitors connected with alarms that are used primarily in above ground storage tanks, liquid level tank gauges and oil filters for use in automotive, truck, for industrial or commercial applications sold as unit with the oil filter crushers
06 - Common metals and ores; objects made of metal
Goods & Services
Metal non-automated fuel dispensing nozzles and guards therefor, breakaway metal couplings for fuel dispensing lines, fuel flow equalizers, swivels, vents and parts therefor, sold as a unit
17 - Rubber and plastic; packing and insulating materials
Goods & Services
Aviation fueling products, namely, rubber hoses for fueling, and accessories in the nature of non-metal couplings for use with rubber hoses for fueling, non-metal fueling and defueling hoses, non-metal couplings and adaptors sold as a unit for aviation rubber hoses for fueling assemblies
Modularized components assembled dispensing nozzle, including operating components in the category of a poppet valve assembly, an automatic shutoff device, a hand operating lever for providing a turn on or shutoff of the dispensing fluid through the nozzle, and a connected spout that delivers fluid to the fill pipe and fuel tank for a vehicle or fluid accepting container. Each of the identified components having been redesigned for assembly in modularized form, such as a modular cartridge for the poppet valve, a modular cartridge for the automatic shutoff device, a modularized operating hand lever, and a spout and its gland and retaining nut that provide for high speed interconnection with the nozzle body, during assembly, or servicing. Each of these modularized components can be installed, during assembly of the manufactured nozzle, or can be replaced, out in the field, by a service person, as a modularized component or cartridge assembly.
B65D 3/00 - Rigid or semi-rigid containers having bodies or peripheral walls of curved or partially-curved cross-section made by winding or bending paper without folding along defined lines
A carbon canister as utilized relative to underground fuel storage tank vapor recovery, including for the capture and purging of hydrocarbon vapors as air is introduced into and released from an underground storage tank, and wherein, in one form intended primarily for use in Stage II Vapor Recovery systems, the carbon canister includes a valve activated by weight of saturated carbon and wherein, in another form intended primarily for use in Stage I Vapor Recovery systems, the carbon canister is a free breathing carbon canister with a surge protection device.
B01D 53/02 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by adsorption, e.g. preparative gas chromatography
06 - Common metals and ores; objects made of metal
Goods & Services
Metal breakaway connector for use with a fuel dispensing hose for stopping dispensing of fuel in the event of inadvertent drive-away from a gasoline dispenser with the nozzle still located in the vehicle fuel tank
A cup for draining residual fuel from a breakaway hose coupling. The cup features a substantially cylindrical rigid stem extending upward from the floor of the cup reservoir, said stem featuring a cavity for receiving the pin of a breakaway hose valve. When the stem is pressed against the valve pin, the valve is opened, relieving pressure within the hose and releasing residual fuel within the hose. The residual fuel drains directly from the hose into the cup, facilitating safe and convenient disposal of the fuel, which may be poured using an integral pour spout in the cup rim.
A safety breakaway connector has a male fitting and a female fitting inserted into one another. The female fitting includes a swivel that rotates about an angle to a breakaway portion of the invention. The swivel has a female portion connected to the breakaway portion and a male portion that pivotally connects to a nozzle. The male portion has an axis spaced apart from the axis of the breakaway portion. The male portion rotates or pivots about the female portion subject to a biased cam. The biased cam has a ball bearing that travels within a race formed in the male swivel. The biased cam provides an offset to the connector so that a fuel line in communication therewith avoids an orientation perpendicular to the direction of travel of a vehicle. The breakaway portion then detaches the fuel line cleanly from the swivel that remains with the fuel nozzle.
F16L 37/32 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in each of two pipe-end fittings at least one of two lift valves being opened automatically when the coupling is applied
A tool for servicing a fuel dispensing nozzle, said tool comprising a substantially semicircular base plate with two uprights protruding from the top to receive a fuel pump nozzle therein; said base plate being formed to fit on the mouth of a bucket and substantially cover the mouth of said bucket, while leaving open a portion of the bucket; said base plate having on its bottom surface protruding guides to ensure a snug fit on the mouth of said bucket; so that a fuel dispensing nozzle may be easily secured for separation from a hose and residual fuel may be easily drained from said nozzle and said hose.
A safety breakaway connector has a male fitting and a female fitting inserted into one another. The female fitting includes a swivel that rotates about an angle to a breakaway portion of the invention. The swivel has a female portion connected to the breakaway portion and a male portion that pivotally connects to a nozzle. The male portion has an axis spaced apart from the axis of the breakaway portion. The male portion rotates or pivots about the female portion subject to a biased cam. The biased cam has a ball bearing that travels within a race formed in the male swivel. The biased cam provides an offset to the connector so that a fuel line in communication therewith avoids an orientation perpendicular to the direction of travel of a vehicle. The breakaway portion then detaches the fuel line cleanly from the swivel that remains with the fuel nozzle.
F16L 27/08 - Adjustable jointsJoints allowing movement allowing adjustment or movement only about the axis of one pipe
F16L 29/04 - Joints with fluid cut-off means with a cut-off device in each of the two pipe ends, the cut-off devices being automatically opened when the coupling is applied
F16L 37/32 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in each of two pipe-end fittings at least one of two lift valves being opened automatically when the coupling is applied
A nozzle display for use for holding advertising is integrated into the structure of the nozzle guard, is elevated therefrom, but secured by tabs integrally into the plastisol forming the guard, with an expansive transparent cover holding the advertising material or placard in place upon the display base, and firmly adhering the ad to the base by means of the expandable lip of the cover as it tightly embraces the edges of the display base.
06 - Common metals and ores; objects made of metal
Goods & Services
Swivel component of non-automatic fuel dispensing equipment, namely, metal fittings for a nozzle and a safety breakaway coupling for the dispensing hose during dispensing of gasoline
A disposable breakaway hose connector for a fuel line prevents untimely decoupling, and avoids unnecessary leakage. The breakaway connector includes a pair of fittings, for connecting to the fuel line, an inner sleeve provided for limited sliding movement upon one of the fittings, with each fitting incorporating a poppet valve, to provide for closure when decoupling occurs, or other unseating, from within the respect fittings, during normal aggregate and usage. Detents are provided within one of the fittings for interconnecting to normally retain the connector as assembled, but various O-rings arranged within an inner sleeve and upon one of the fittings, provide for limited movement when tensioning force is exerted and clearance for disconnection. A fluid chamber is provided intermediate of the O-rings, to equalize and counterbalance fluid pressures that occasionally spike within the connector and hose line.
F16L 37/32 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in each of two pipe-end fittings at least one of two lift valves being opened automatically when the coupling is applied
56.
VAPOR TRAPPING CANISTER VAPOR PRESSURE MANAGEMENT SYSTEM
An underground fuel tank releases vapors depending upon air pressure. A vapor pressure management system has a canister for a vapor recovery system that connects with piping from an underground tank and has carbon therein along with appurtenant pipes and valves. When an ORVR vehicle refuels, the pressure lowers in an underground tank that draws air through the valves into the canister. After refueling an ORVR vehicle, environmental conditions generate hydrocarbon vapors. Barometric pressure drops and evaporated fuel during long refueling lulls produce hydrocarbon vapors at an increased pressure. Those hydrocarbon rich vapors then return to the canister of the system where the carbon binds the hydrocarbons while releasing air to the atmosphere. The refueling of the next ORVR vehicle draws in atmospheric air to purge the hydrocarbons retained in the canister of the system.
An underground fuel tank releases vapors depending upon air pressure. A vapor pressure management system has a canister for a vapor recovery system that connects with piping from an underground tank and has carbon therein along with appurtenant pipes and valves. When an ORVR vehicle refuels, the pressure lowers in an underground tank that draws air through the valves into the canister. After refueling an ORVR vehicle, environmental conditions generate hydrocarbon vapors. Barometric pressure drops and evaporated fuel during long refueling lulls produce hydrocarbon vapors at an increased pressure. Those hydrocarbon rich vapors then return to the canister of the system where the carbon binds the hydrocarbons while releasing air to the atmosphere. The refueling of the next ORVR vehicle draws in atmospheric air to purge the hydrocarbons retained in the canister of the system.
B01D 53/02 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by adsorption, e.g. preparative gas chromatography
An interconnect for a fuel dispensing nozzle which provides for sustained shut off of a nozzle when its spout is not inserted into the fill pipe of a fuel tank. When the spout inserts within the fill pipe its bellows or splashguard is forced rearwardly, for urging an interconnecting rod to move rearwardly, against the bias of a spring, to force a pivotal link to disengage from the automatic shut-off diaphragm, to allow it to function normally. But when the nozzle is removed from the fuel tank, the pivotal link contacts against the diaphragm structure, of the automatic shut-off, and prevents the nozzle from dispensing or delivering any fuel from the dispenser.
An interconnect for a fuel dispensing nozzle which provides for sustained shut off of a nozzle when its spout is not inserted into the fill pipe of a fuel tank. When the spout inserts within the fill pipe its bellows or splashguard is forced rearwardly, for urging an interconnecting rod to move rearwardly, against the bias of a spring, to force a pivotal link to disengage from the automatic shut-off diaphragm, to allow it to function normally. But when the nozzle is removed from the fuel tank, the pivotal link contacts against the diaphragm structure, of the automatic shut-off, and prevents the nozzle from dispensing or delivering any fuel from the dispenser.
A dripless means for a fuel dispensing nozzle begins with a nozzle for dispensing fuel into automobile tanks. Regulations limit drainage of the spout to within ten seconds, met by the present invention that prevents fuel drops from exiting the spout. First, the spout retains fuel drops behind a dam made of a series of fins upon the interior of the spout. Second, the present invention has a bushing with a weir that works in combination with the damming. Third, the nozzle has a vent tube within the spout where a plug constricts its diameter to limit the fuel drawn into the vent tube. With proper use, the present invention retains fuel drops in the spout to meet the regulations.
An interconnect for a fuel dispensing nozzle which provides for sustained shut off of a nozzle when its spout is not inserted into the fill pipe of a fuel tank. When the spout inserts within the fill pipe its bellows or splashguard is forced rearwardly, for urging an interconnecting rod to move rearwardly, against the bias of a spring, to force a pivotal link to disengage from the automatic shut-off diaphragm, to allow it to function normally. But when the nozzle is removed from the fuel tank, the pivotal link contacts against the diaphragm structure, of the automatic shut-off, and prevents the nozzle from dispensing or delivering any fuel from the dispenser.
A fuel dispensing nozzle having a dripless spout has a nozzle for placement in a tank. The nozzle has a housing with an air bleed device, an attitude support device extends from the housing, a gland joined to the attitude support device and then the spout attaches to the gland. At fuel shutoff, fuel remains in the gland and the spout. Fuel drops exit the gland then the spout. Regulations limit the drops to three or less. Smooth tubes have little if any capillary action while tubes with roughened interior surfaces retain fluid. The dripless spout has a texture applied to the interior surface of the gland, the spout, or both by way of a screen; a hole in the attitude support device; and the air bleed device located in the vapor path to reduce negative vacuum.
