Abstract

According to a first aspect of the invention, there is provided a coupling arrangement (10) of an electromechanical lock comprising a movable shaft (12), a coupling member (14) connected with the shaft (12) and a joint (16) arranged to interact with the shaft (12) and the coupling member (14) The coupling member (14) is configured to be moved by the shaft (12) between a first and a second position (P1, P2), and wherein the coupling member (14) in the second position (P2) is configured to interact with its counterpart (14_C), and wherein the joint (16) is configured to enable deviation in a parallelism between a central axis of the shaft (12_A1) and a central axis the coupling member (14_A1) at least in the second position (P1). According to a second aspect of the invention, there is provided an electromechanical lock comprising the coupling arrangement (10).

IPC Classes  ?

• E05B 47/06 - Controlling mechanically-operated bolts by electromagnetically-operated detents
• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means

Abstract

Door lock systems are disclosed. More particularly, virtual keys in door lock systems of properties such as houses and apartments, and public properties such as parking garages, or sports facilities, are disclosed. This includes managing virtual key based access of temporary users, to a property or a vehicle sealed by a self-powered lock, from the mobile phone of a permanent user. This is achieved by virtual configurable software keys which are operable with a mobile application, and configurable from the mobile application of the permanent user. These virtual configurable software keys are typically text strings with a data footprint sufficiently small to be transmitted over NFC.

IPC Classes  ?

• G07C 9/00 - Individual registration on entry or exit

Abstract

An electromechanical lock arrangement (10) comprising a core body (30), and a core (50) arranged to interact with the core body (30). The core (50) is movable at least between a first position (P1) and a second position (P2) in relation with the core body (30). A position indicating element (70) is arranged to indicate the position of the core (50) in relation with the core body (30). The position indicating element (70) in the first position (P1) of the core (50) is at a first state and in the second position (P2) of the core (50) in a second state. Change of the state of the position indicating element (70) triggers an indication signal for indicating the position of the core (50).

IPC Classes  ?

• E05B 29/00 - Cylinder locks with plate tumblers that are set by pushing the key in
• E05B 39/00 - Locks giving indication of unauthorised unlocking
• E05B 67/24 - Padlocks with sliding shackles, with or without rotary or pivotal movement with built-in cylinder locks
• E05B 47/06 - Controlling mechanically-operated bolts by electromagnetically-operated detents
• E05B 27/00 - Cylinder locks with tumbler pins or balls that are set by pushing the key in
• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means

Abstract

According to the invention, there is provided a lock cylinder arrangement 10 comprising at least a first shell 12A having an inner space 14A comprising a first groove 16A, at least a first core 18A arranged within the inner space 14A and rotatably in relation to the first shell 12A, a bolt 20 arranged rotatably in relation to the first shell 12A comprising an opening 22 with a slot 24, and at least a first coupling arrangement 26A comprising a first coupling member 28A A first end of the first coupling arrangement 26A_E1 is in contact with a first end of the first core 18A_E1 to enable the first core 18A to rotate the first coupling arrangement 26A between a first and a second state 26A_S1, 26A_S2, and a second end of the coupling arrangement 26A_E2 extends into the opening of the bolt 22. Rotation of the first coupling arrangement 26A from the first to the second state 26A_S1, 26A_S2 is configured to misalign the first coupling member 28A with the first groove 16A and to move in the first direction D1 enabling the first coupling member 28A to enter the slot 24 that couples the first coupling arrangement 26A with the bolt 20 to enable transferring of the rotational movement of the first core 18A to the bolt 20.

IPC Classes  ?

• E05B 17/04 - Devices for coupling the turning cylinder of a single or double cylinder lock with the bolt-operating member

Abstract

According to the invention, there is provided an arrangement of an electromechanical lock (100) comprising a rotor (102) comprising at least one movable magnet (104) and at least one actuation element (106), at least one stationary magnet (108) with a coil (110), wherein the coil (110) is configured, under control of a processing circuitry (122), to change a polarity of the stationary magnet (108) between a first and a second magnetization configuration (MC1, MC2), wherein the first magnetization configuration (MC1) is configured to turn the movable magnet (104) with the rotor (102) to a first position (P1), and the second magnetization configuration (MC2) is configured to turn the movable magnet (104) with the rotor (102) to a second position (P2), and a coupling element (112), wherein in the first position of the rotor (P1) the actuation element (106) is positioned to enable moving of the coupling element (112) towards the rotor (102) to set the coupling element (112) to an uncoupled state (US), and in the second position of the rotor (P2) the actuation element (106) is positioned to limit moving of the coupling element (112) towards the rotor (102) such that the coupling element (112) stays in a coupled state (CS).

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• H01F 7/122 - Guiding or setting position of armatures, e.g. retaining armatures in their end position by permanent magnet
• H01F 7/14 - Pivoting armatures

Abstract

An electromechanical lock includes a lock cylinder having core front and back ends, and an operation knob, coupled with the core front end, enabling a user to rotate the operation knob from an initial knob position so the core front end rotates with the core back end from a locked rear position to a unlocked rear position in an unlocked state of the electromechanical lock. The electromechanical lock further includes a return force mechanism rotating the operation knob towards the initial position after the user first has rotated the operation knob away from the initial knob position and then released the operation knob. The return force mechanism includes first and second magnetic parts coupled with the operation knob and a lock cylinder core body, respectively. An interaction between first and second magnetic force fields of the first and second magnetic parts, respectively, is configured to rotate the operation knob.

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means

Abstract

A charging system of an electromechanical lock comprises a direct-current-direct-current converter (100) that receives electric power from one electric source of electric sources (SOURCE 1, SOURCE 2, SOURCE 3) of different types, the electric source (SOURCE 1, SOURCE 2, SOURCE 3) varying. A data processing unit (204) receives information relating to electric power intaken from the one of the sources (SOURCE 1, SOURCE 2, SOURCE 3) by DC-DC converter (100), the DC-DC converter (100) feeding electric power to an electric energy storage (206) of the electromechanical lock for charging the electric energy storage (206) to be used for operation of the electromechanical lock. The data processing unit (204) forms repeatedly control signals based on the information on the electric power intaken by the DC-DC converter (100), and feed the control signals to a feedback input (FB) of the DC-DC converter (100) in order to control the intake of the electric power of the DC-DC converter (100) from said one of the sources (SOURCE 1, SOURCE 2, SOURCE 3).

IPC Classes  ?

• H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries

Abstract

According to the invention, there is provided a padlock arrangement (100), comprising a body (102) with a shackle (104) and a linearly movable blocker (106) having a first position (106_P1) to disenable the shackle (104) to enter an open state (104_OS) and a second position (106_P2) to enable the shackle (104) to enter the open state (104_OS) The padlock arrangement further comprises a tilter (108) having a first position (108_P1) and a second position (108_P2), wherein moving of the tilter (108) from the first position (108_P1) to the second position (108_P2) is configured to move the blocker (106) from the first position (106_P1) to the second position (106_P2), and a clutch pin (110) having a first state (110_S1) to disable moving of the tilter (108) to the second position (108_P2), and a second state (110_S2) to enable moving of the tilter (108) to the second position (108_P2). The padlock arrangement further comprises a processing circuitry (112) configured, when authorized, to provide a control signal to set the clutch pin (110) to the second state (110_S2) to enable moving of the tilter (108) to the second position (108_P2) to open the shackle (104).

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• E05B 67/22 - Padlocks with sliding shackles, with or without rotary or pivotal movement

Abstract

According to the invention, there is provided a padlock arrangement (100), comprising a body (102) with a shackle (104) and a linearly movable blocker (106) having a first position (106_P1) to disenable the shackle (104) to enter an open state (104_OS) and a second position (106_P2) to enable the shackle (104) to enter the open state (104_OS) The padlock arrangement further comprises a tilter (108) having a first position (108_P1) and a second position (108_P2), wherein moving of the tilter (108) from the first position (108_P1) to the second position (108_P2) is configured to move the blocker (106) from the first position (106_P1) to the second position (106_P2), and a clutch pin (110) having a first state (110_S1) to disable moving of the tilter (108) to the second position (108_P2), and a second state (110_S2) to enable moving of the tilter (108) to the second position (108_P2). The padlock arrangement further comprises a processing circuitry (112) configured, when authorized, to provide a control signal to set the clutch pin (110) to the second state (110_S2) to enable moving of the tilter (108) to the second position (108_P2) to open the shackle (104).

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• E05B 67/22 - Padlocks with sliding shackles, with or without rotary or pivotal movement

Goods & Services

Design services related to wireless power transmission and device-to-device communication (d2d) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (wireless personal area network and nfc); computers, computer systems, computer software, technology solutions, wireless and wired network devices - and application design and development in the field of access control, access control and security, including identity security solutions; design and development of devices and instruments for access control, access management and security; advice and information related to the aforementioned services; architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; consulting services regarding the energy efficiency of buildings; web application services (saas); consulting services related to web application services (saas), open software interfaces (apis) and functions related to interfaces and software and tools (sdk); microservices (software) related to user identification, communication and customer service maintenance; providing temporary use of web-based applications.

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; locks and keys, of metal. Electric, electronic and electromechanical locks and lock goods, also including electronic lock cylinders, electric striking plates, door magnets, electronic keys, key cards, also including electronic or magnetic access control cards and smart cards, and key card readers, also including electronic or magnetic access control card readers and smart card readers; units for programming locks, lock cylinders, keys, key cards, key card readers and safes; electric and electromechanical door and window hardware; electronic and magnetic sensors; CCTV systems and devices; electric, electronic and electromechanical access control apparatus and systems; security or alarm apparatus and systems; apparatus and systems for providing identification and authentication data for near field communication (NFC) tags, digital keys and identity data; apparatus and systems for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; apparatus and systems for managing mini bars and energy consumption in hotels, homes, companies, public establishments; apparatus and instruments for recording, monitoring, signaling and checking, also including checking and/or controlling people's movement within, entrance to and exit from buildings and through doors and gates and/or for use with locks; magnetic and electronic identity cards; magnetic data carriers and computer software; downloadable computer software platforms. Design services related to wireless power transmission and device-to-device communication (D2D) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (wireless personal area network and NFC); computers, computer systems, computer software, technology solutions, wireless and wired network devices - and application design and development in the field of access control, access control and security, including identity security solutions; design and development of devices and instruments for access control, access management and security; advice and information related to the aforementioned services; architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; consulting services regarding the energy efficiency of buildings; web application services (Saas); consulting services related to web application services (Saas), open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); microservices (software) related to user identification, communication and customer service maintenance; providing temporary use of web-based applications. Security services for the protection of property and individuals.

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; locks and keys, of metal. Electric, electronic and electromechanical locks and lock goods, also including electronic lock cylinders, electric striking plates, door magnets, electronic keys, key cards, also including electronic or magnetic access control cards and smart cards, and key card readers, also including electronic or magnetic access control card readers and smart card readers; units for programming locks, lock cylinders, keys, key cards, key card readers and safes; electric and electromechanical door and window hardware; electronic and magnetic sensors; CCTV systems and devices; electric, electronic and electromechanical access control apparatus and systems; security or alarm apparatus and systems; apparatus and systems for providing identification and authentication data for near field communication (NFC) tags, digital keys and identity data; apparatus and systems for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; apparatus and systems for managing mini bars and energy consumption in hotels, homes, companies, public establishments; apparatus and instruments for recording, monitoring, signaling and checking, also including checking and/or controlling people's movement within, entrance to and exit from buildings and through doors and gates and/or for use with locks; magnetic and electronic identity cards; magnetic data carriers and computer software; downloadable computer software platforms. Design services related to wireless power transmission and device-to-device communication (D2D) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (wireless personal area network and NFC); computers, computer systems, computer software, technology solutions, wireless and wired network devices - and application design and development in the field of access control, access control and security, including identity security solutions; design and development of devices and instruments for access control, access management and security; advice and information related to the aforementioned services; architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; consulting services regarding the energy efficiency of buildings; web application services (Saas); consulting services related to web application services (Saas), open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); microservices (software) related to user identification, communication and customer service maintenance; providing temporary use of web-based applications. Security services for the protection of property and individuals.

Abstract

An electromechanical lock comprises a data processing unit (204), at least two capacitors (206, 206(1), 206(2)), an electric switch arrangement (402) and an electric energy receiver (400). The electric switch arrangement (402), for enabling repeated charging and discharging of the at least two capacitors (206, 206(1), 206(2)) performs the following. Couples the at least two capacitors (206, 206(1), 206(2)) in parallel for charging the at least two capacitors (206, 206(1), 206(2)) with electric energy of the electric energy receiver (400). Couples the at least two capacitors (206, 206(1), 206(2)), which are charged with electric energy, in series. Couple the at least two capacitors (206, 206(1), 206(2)) in series with the data processing unit (204), the at least two capacitors (206, 206(1), 206(2)) in series discharging electric energy for electric operation of the electromechanical lock.

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means

Abstract

The invention relates to locks. More particularly, the invention relates to a lock (200) that can be used to lock a door, and which features multiple modes to access the lock in order to open or close the lock. The inventive lock combines different power sources with different access technologies resulting in a lock that will remain functional for a very long time without maintenance.

IPC Classes  ?

• G07C 9/00 - Individual registration on entry or exit
• H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries
• E05B 15/00 - Other details of locksParts for engagement by bolts of fastening devices

IPC Classes  ?

• E05B 15/00 - Other details of locksParts for engagement by bolts of fastening devices
• G07C 9/00 - Individual registration on entry or exit
• H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries

Goods & Services

(1) Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; locks and keys, of metal. (2) Electric, electronic and electromechanical locks and lock goods, also including electronic lock cylinders, electric striking plates, door magnets, electronic keys, key cards, also including electronic or magnetic access control cards and smart cards, and key card readers, also including electronic or magnetic access control card readers and smart card readers; units for programming locks, lock cylinders, keys, key cards, key card readers and safes; electric and electromechanical door and window hardware; electronic and magnetic sensors; CCTV systems and devices; electric, electronic and electromechanical access control apparatus and systems; security or alarm apparatus and systems; apparatus and systems for providing identification and authentication data for near field communication (NFC) tags, digital keys and identity data; apparatus and systems for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; apparatus and systems for managing mini bars and energy consumption in hotels, homes, companies, public establishments; apparatus and instruments for recording, monitoring, signaling and checking, also including checking and/or controlling people's movement within, entrance to and exit from buildings and through doors and gates and/or for use with locks; magnetic and electronic identity cards; magnetic data carriers and computer software; downloadable computer software platforms. (1) Design services related to wireless power transmission and device-to-device communication (D2D) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (wireless personal area network and NFC); design and development of computers, computer systems, computer software, technology solutions, wireless and wired network devices and applications in the field of access management, access control, access control and security, including identity security solutions; design and development of devices and instruments for access control, access management and security; advice and information related to the aforementioned services; architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; consulting services regarding the energy efficiency of buildings; web application services (SaaS); consulting services related to web application services (SaaS), open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); microservices (software) related to user identification, communication and customer service maintenance; providing temporary use of web-based applications. (2) Security services for the protection of property and individuals.

Goods & Services

Non-electric cables and wires of common metal; pipes and tubes of metal; locks and keys for locks, of metal Electric, electronic and electromechanical locks and lock goods, namely, electronically operated lock cylinders, electronically operated strike plates, door magnets, Closed circuit TV, electronic and magnetic access key control cards, encoded smart cards containing programming used for opening locks, and key card readers, electronic and magnetic access control key card readers and smart card readers; computers for programming electronic locks, electronic lock cylinders, electronic key cards, encoded key cards, key card readers and electronic safes; electric and electromechanical door and window hardware being locks; electronic and magnetic sensors for sensing movement; Closed circuit TV (CCTV) systems for security and surveillance, namely, cameras, switchers, monitors, microphones, and recorders; electric, electronic and electromechanical access control apparatus and systems, namely, locks and electronic key cards, encoded key cards; Security products, namely, entry door systems comprising touch pads and security doors and alarm monitoring systems; electronic key cards, encoded key cards, and key card readers for providing identification and authentication data for near field communication (NFC) tags, digital keys and identity data; electronic key cards, encoded key cards, and key card readers for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; electronic key cards, encoded key cards, and key card readers for managing access to mini bars and monitoring use of energy consumption in hotels, homes, companies, public establishments; electronic key cards, encoded key cards, key card readers for recording, monitoring, signaling and checking, and controlling people's movement within, entrance to and exit from buildings and through doors and gates and for use with electronic locks; magnetic and electronically encoded key cards for identification purposes; blank magnetic data carriers and downloadable computer software for managing and operating locks; downloadable computer software platforms for managing and operating locks Design of devices for wireless power transmission and device-to-device communication between computer servers, computer databases, distributed computer systems, embedded computer systems, cloud-based computer servers, cloud-based software programs, mobile phones, mobile phone software programs, and near-field radio technologies being wireless personal area networks and NFC; computers, computer hardware and technology solutions comprised of hardware and software for physical location access control and management, for physical location security and for identify verification; design and development of devices and instruments for physical location access control and management, and for physical location security; providing technical advice and information related to the aforementioned services; architecture design and technical design services for doors, boom barriers, metal gates, pneumatic valve actuators, protected cabinets, computer server racks, motor vehicles, deck structures intended for loading, and parts and components for all the foregoing; consulting services for the design of doors, boom barriers, metal gates, deck structures intended for loading, and parts and components for all the foregoing; Computer security services for others, namely, restricting unauthorized network access by issuing, authenticating and revoking digital signatures and digital rights by identity for network users via physical and digital access control systems; engineering consulting services regarding the energy efficiency of designs of buildings; Software as a service (SAAS) services featuring software for managing and operating locks and physical location access control and management and for identification verification; providing temporary use of on-line non-downloadable software and applications for managing and operating locks and physical location access control and management and for identification verification; consulting services for software as a service (SAAS) software, application programming interface (API) software and software functions for software user interfaces and software development kits (SDKs); Software as a service (SAAS) services featuring software for computer network user identification, communication of electronic messages between customers and service providers for use in customer service management, all related to the use of electronic locks

Goods & Services

Non-electric cables and wires of common metal; pipes and tubes of metal; locks and keys for locks, of metal Electric, electronic and electromechanical locks and lock goods, namely, electronically operated lock cylinders, electronically operated strike plates, door magnets, Closed circuit TV, electronic and magnetic access key control cards, encoded smart cards containing programming used for opening locks, and key card readers, electronic and magnetic access control key card readers and smart card readers; computers for programming electronic locks, electronic lock cylinders, electronic key cards, encoded key cards, key card readers and electronic safes; electric and electromechanical door and window hardware being locks; electronic and magnetic sensors for sensing movement; Closed circuit TV (CCTV) systems for security and surveillance, namely, cameras, switchers, monitors, microphones, and recorders; electric, electronic and electromechanical access control apparatus and systems, namely, locks and electronic key cards, encoded key cards; Security products, namely, entry door systems comprising touch pads and security doors and alarm monitoring systems; electronic key cards, encoded key cards, and key card readers for providing identification and authentication data for near field communication (NFC) tags, digital keys and identity data; electronic key cards, encoded key cards, and key card readers for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; electronic key cards, encoded key cards, and key card readers for managing access to mini bars and monitoring use of energy consumption in hotels, homes, companies, public establishments; electronic key cards, encoded key cards, key card readers for recording, monitoring, signaling and checking, and controlling people's movement within, entrance to and exit from buildings and through doors and gates and for use with electronic locks; magnetic and electronically encoded key cards for identification purposes; blank magnetic data carriers and downloadable computer software for managing and operating locks; downloadable computer software platforms for managing and operating locks Design of devices for wireless power transmission and device-to-device communication between computer servers, computer databases, distributed computer systems, embedded computer systems, cloud-based computer servers, cloud-based software programs, mobile phones, mobile phone software programs, and near-field radio technologies being wireless personal area networks and NFC; computers, computer hardware and technology solutions comprised of hardware and software for physical location access control and management, for physical location security and for identify verification; design and development of devices and instruments for physical location access control and management, and for physical location security; providing technical advice and information related to the aforementioned services; architecture design and technical design services for doors, boom barriers, metal gates, pneumatic valve actuators, protected cabinets, computer server racks, motor vehicles, deck structures intended for loading, and parts and components for all the foregoing; consulting services for the design of doors, boom barriers, metal gates, deck structures intended for loading, and parts and components for all the foregoing; Computer security services for others, namely, restricting unauthorized network access by issuing, authenticating and revoking digital signatures and digital rights by identity for network users via physical and digital access control systems; engineering consulting services regarding the energy efficiency of designs of buildings; Software as a service (SAAS) services featuring software for managing and operating locks and physical location access control and management and for identification verification; providing temporary use of on-line non-downloadable software and applications for managing and operating locks and physical location access control and management and for identification verification; consulting services for software as a service (SAAS) software, application programming interface (API) software and software functions for software user interfaces and software development kits (SDKs); Software as a service (SAAS) services featuring software for computer network user identification, communication of electronic messages between customers and service providers for use in customer service management, all related to the use of electronic locks

Goods & Services

(1) Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; locks and keys, of metal. (2) Electric, electronic and electromechanical locks and lock goods, also including electronic lock cylinders, electric striking plates, door magnets, electronic keys, key cards, also including electronic or magnetic access control cards and smart cards, and key card readers, also including electronic or magnetic access control card readers and smart card readers; units for programming locks, lock cylinders, keys, key cards, key card readers and safes; electric and electromechanical door and window hardware; electronic and magnetic sensors; CCTV systems and devices; electric, electronic and electromechanical access control apparatus and systems; security or alarm apparatus and systems; apparatus and systems for providing identification and authentication data for near field communication (NFC) tags, digital keys and identity data; apparatus and systems for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; apparatus and systems for managing mini bars and energy consumption in hotels, homes, companies, public establishments; apparatus and instruments for recording, monitoring, signaling and checking, also including checking and/or controlling people's movement within, entrance to and exit from buildings and through doors and gates and/or for use with locks; magnetic and electronic identity cards; magnetic data carriers and computer software; downloadable computer software platforms. (1) Design services related to wireless power transmission and device-to-device communication (D2D) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (wireless personal area network and NFC); design and development of computers, computer systems, computer software, technology solutions, wireless and wired network devices and applications in the field of access management, access control, access control and security, including identity security solutions; design and development of devices and instruments for access control, access management and security; advice and information related to the aforementioned services; architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; consulting services regarding the energy efficiency of buildings; web application services (SaaS); consulting services related to web application services (SaaS), open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); microservices (software) related to user identification, communication and customer service maintenance; providing temporary use of web-based applications. (2) Security services for the protection of property and individuals.

Goods & Services

(1) Design services related to wireless power transmission and device-to-device communication (d2d) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (wireless personal area network and nfc); design and development of computers, computer systems, computer software, technology solutions, wireless and wired network devices and applications in the field of access management, access control, access control and security, including identity security solutions; design and development of devices and instruments for access control, access management and security; advice and information related to the aforementioned services; architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; consulting services regarding the energy efficiency of buildings; web application services (saas); consulting services related to web application services (saas), open software interfaces (apis) and functions related to interfaces and software and tools (sdk); microservices (software) related to user identification, communication and customer service maintenance; providing temporary use of web-based applications.

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; locks and keys, of metal. Electric, electronic and electromechanical locks and lock goods, also including electronic lock cylinders, electric striking plates, door magnets, electronic keys, key cards, also including electronic or magnetic access control cards and smart cards, and key card readers, also including electronic or magnetic access control card readers and smart card readers; units for programming locks, lock cylinders, keys, key cards, key card readers and safes; electric and electromechanical door and window hardware; electronic and magnetic sensors; CCTV systems and devices; electric, electronic and electromechanical access control apparatus and systems; security or alarm apparatus and systems; apparatus and systems for providing identification and authentication data for near field communication (NFC) tags, digital keys and identity data; apparatus and systems for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; apparatus and systems for managing mini bars and energy consumption in hotels, homes, companies, public establishments; apparatus and instruments for recording, monitoring, signaling and checking, also including checking and/or controlling people's movement within, entrance to and exit from buildings and through doors and gates and/or for use with locks; magnetic and electronic identity cards; magnetic data carriers and computer software; downloadable computer software platforms. Design services related to wireless power transmission and device-to-device communication (D2D) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (Wireless personal area network and NFC); Design and development of computers, computer systems, computer software, technology solutions, wireless and wired network devices and applications in the field of access management, access control, access control and security, including identity security solutions; Design and development of devices and instruments for access control, access management and security; Advice and information related to the aforementioned services; Architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; Consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; Information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; Consulting services regarding the energy efficiency of buildings; Web application services (Saas); Consulting services related to web application services (Saas), Open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); Microservices (software) related to user identification, communication and customer service maintenance; providing temporary use of web-based applications. Security services for the protection of property and individuals.

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; locks and keys, of metal. Electric, electronic and electromechanical locks and lock goods, also including electronic lock cylinders, electric striking plates, door magnets, electronic keys, key cards, also including electronic or magnetic access control cards and smart cards, and key card readers, also including electronic or magnetic access control card readers and smart card readers; units for programming locks, lock cylinders, keys, key cards, key card readers and safes; electric and electromechanical door and window hardware; electronic and magnetic sensors; CCTV systems and devices; electric, electronic and electromechanical access control apparatus and systems; security or alarm apparatus and systems; apparatus and systems for providing identification and authentication data for near field communication (NFC) tags, digital keys and identity data; apparatus and systems for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; apparatus and systems for managing mini bars and energy consumption in hotels, homes, companies, public establishments; apparatus and instruments for recording, monitoring, signaling and checking, also including checking and/or controlling people's movement within, entrance to and exit from buildings and through doors and gates and/or for use with locks; magnetic and electronic identity cards; magnetic data carriers and computer software; downloadable computer software platforms. Design services related to wireless power transmission and device-to-device communication (D2D) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (Wireless personal area network and NFC); Design and development of computers, computer systems, computer software, technology solutions, wireless and wired network devices and applications in the field of access management, access control, access control and security, including identity security solutions; Design and development of devices and instruments for access control, access management and security; Advice and information related to the aforementioned services; Architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; Consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; Information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; Consulting services regarding the energy efficiency of buildings; Web application services (Saas); Consulting services related to web application services (Saas), Open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); Microservices (software) related to user identification, communication and customer service maintenance; providing temporary use of web-based applications. Security services for the protection of property and individuals.

Goods & Services

Design services related to wireless power transmission and device-to-device communication (D2D) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (Wireless personal area network and NFC); Design and development of computers, computer systems, computer software, technology solutions, wireless and wired network devices and applications in the field of access management, access control, access control and security, including identity security solutions; Design and development of devices and instruments for access control, access management and security; Advice and information related to the aforementioned services; Architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; Consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; Information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; Consulting services regarding the energy efficiency of buildings; Web application services (Saas); Consulting services related to web application services (Saas), Open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); Microservices (software) related to user identification, communication and customer service maintenance; providing temporary use of web-based applications.

Goods & Services

Lock cylinders of metal Programmable locking systems, consisting of electronic cylindrical locksets and keypads; Electronic lock assemblies; Downloadable software for using electronic locks and lock assemblies

Goods & Services

Lock cylinders of metal Programmable locking systems, consisting of electronic cylindrical locksets and keypads; Electronic lock assemblies; Downloadable software for using electronic locks and lock assemblies

Abstract

The method includes: switching (1202), in a magnetically-operated actuator, between a first mechanical state and a second mechanical state using either a first internal magnetization configuration or a second internal magnetization configuration; after the switching (1202), measuring (1204), by a magnetic sensor, a prevailing magnetic field caused by the magnetically-operated actuator, testing (1206) the prevailing magnetic field against a predetermined condition, and based on the testing (1206), detecting (1208) whether the switching between the first mechanical state and the second mechanical state was completed or not completed.

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• E05B 47/06 - Controlling mechanically-operated bolts by electromagnetically-operated detents

Abstract

The invention relates to locks. More particularly, aspects of the invention relate to a lock that can be used to lock a door, and which features multiple modes to access the lock in order to open or close the lock. The disclosed lock combines different power sources with different access technologies resulting in a lock that will remain functional for a very long time without maintenance.

IPC Classes  ?

• G07C 9/00 - Individual registration on entry or exit
• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means

Abstract

According to a first aspect of the invention, there is provided a lock arrangement comprising a lock cylinder having a housing with an external thread to couple the lock cylinder with a lock case, wherein the housing further comprises a flange and at least one groove extending in a longitudinal direction of the lock cylinder. The lock cylinder further comprises an escutcheon having a through hole configured to receive the lock cylinder such that the flange compresses the escutcheon against a counter surface, wherein the through hole comprise at least one projection extending towards the lock cylinder, wherein the escutcheon, when assembled with the lock cylinder, comprises a coupled state in which the projection is in the groove to prevent rotational movement of the escutcheon in relation to the lock cylinder around the longitudinal direction of the lock cylinder, and an uncoupled state in which the projection is at least partly out of the groove to enable rotational movement of the escutcheon in relation to the lock cylinder.

IPC Classes  ?

• E05B 9/00 - Lock casings or latch-mechanism casings
• E05B 9/08 - Fastening the casings of latch-bolt locks or cylinder locks to the wing

IPC Classes  ?

• E05B 9/04 - Lock casings or latch-mechanism casings of cylinder locks
• E05B 15/02 - Striking-platesKeepersBolt staplesEscutcheons

Abstract

According to a first aspect of the invention, there is provided a lock arrangement comprising a lock cylinder having a housing with an external thread to couple the lock cylinder with a lock case, wherein the housing further comprises a flange and at least one groove extending in a longitudinal direction of the lock cylinder The lock cylinder further comprises an escutcheon having a through hole configured to receive the lock cylinder such that the flange compresses the escutcheon against a counter surface, wherein the through hole comprise at least one projection extending towards the lock cylinder, wherein the escutcheon, when assembled with the lock cylinder, comprises a coupled state in which the projection is in the groove to prevent rotational movement of the escutcheon in relation to the lock cylinder around the longitudinal direction of the lock cylinder, and an uncoupled state in which the projection is at least partly out of the groove to enable rotational movement of the escutcheon in relation to the lock cylinder.

IPC Classes  ?

• E05B 9/04 - Lock casings or latch-mechanism casings of cylinder locks
• E05B 15/02 - Striking-platesKeepersBolt staplesEscutcheons
• E05B 17/00 - Accessories in connection with locks

Abstract

This document discloses a solution for configuring access rights in a locking system comprising a plurality of electromechanical locks and a plurality of keys to users of the system. Each key stores encrypted data defining an opening right to a particular subset of the plurality of electromechanical lock, the subset of locks assigned to the respective user. The system further comprises a service key storing, as a default, no encrypted data to any of the subsets of locks. The system further comprises a computer program product configured to receive, via a user interface of a personal electronic device of a user, a write authorization from the user of a specific subset of the plurality of electromechanical locks that are assigned to the user; in response to the write authorization, an opening right of the service key is generated for the specific subset of the plurality of electromechanical locks as the encrypted data, and the generated encrypted data containing the opening right to the specific subset of the plurality of electromechanical locks is written to the service key after checking the user has access rights to the specific subset of the plurality of electromechanical locks. Thereafter, the service can be used to open the subset of the plurality of electromechanical locks.

IPC Classes  ?

• G07C 9/00 - Individual registration on entry or exit

IPC Classes  ?

• G07C 9/00 - Individual registration on entry or exit
• G07C 9/27 - Individual registration on entry or exit involving the use of a pass with central registration
• H04B 5/00 - Near-field transmission systems, e.g. inductive or capacitive transmission systems
• H04L 9/40 - Network security protocols
• H04W 4/80 - Services using short range communication, e.g. near-field communication [NFC], radio-frequency identification [RFID] or low energy communication
• H04W 12/00 - Security arrangementsAuthenticationProtecting privacy or anonymity

Abstract

Door lock systems are disclosed. More particularly, virtual keys in door lock systems of properties such as houses and apartments, and public properties such as parking garages, or sports facilities, are disclosed. This includes managing virtual key based access of temporary users, to a property or a vehicle sealed by a self-powered lock, from the mobile phone of a permanent user. This is achieved by virtual configurable software keys which are operable with a mobile application, and configurable from the mobile application of the permanent user. These virtual configurable software keys are typically text strings with a data footprint sufficiently small to be transmitted over NFC.

IPC Classes  ?

• G07C 9/00 - Individual registration on entry or exit

Abstract

The invention relates to door lock systems. More particularly, the invention relates to virtual keys (109) in door lock systems of properties such as houses and apartments, and public properties such as parking garages, or sports facilities. The invention under study is directed towards a system and a method for managing virtual key based access of temporary users, to a property or a vehicle sealed by a self-powered lock, from the mobile phone of a permanent user (105). This is achieved by virtual configurable software keys which are operable with a mobile application (108, 113), and configurable from the mobile application (108) of the permanent user (105). These virtual configurable software keys are typically text strings with a data footprint sufficiently small to be transmitted over NFC.

IPC Classes  ?

• G07C 9/00 - Individual registration on entry or exit
• G07C 9/27 - Individual registration on entry or exit involving the use of a pass with central registration
• H04W 4/80 - Services using short range communication, e.g. near-field communication [NFC], radio-frequency identification [RFID] or low energy communication
• H04B 5/00 - Near-field transmission systems, e.g. inductive or capacitive transmission systems
• H04L 9/40 - Network security protocols
• H04W 12/00 - Security arrangementsAuthenticationProtecting privacy or anonymity

Abstract

One or more embodiments describe a magnetic actuator including one or more magnets, and at least one of the magnets induces mechanical movement by the magnetic actuator. The magnetic actuator is controlled by a mobile application associated with a mobile computing device, and the magnetic actuator is configured to open or close based on identifying a user at the mobile application. The mobile application is configured to identify the user based on biometric identification at the mobile computing device, including at least one of: (i) fingerprint identification or (ii) identification using an image of the user generated using a camera associated with the mobile computing device. Identification data associated with the identification of the user at the mobile application is configured to be transmitted via NFC or Bluetooth to the magnetic actuator.

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• G07C 9/00 - Individual registration on entry or exit

IPC Classes  ?

• E05B 9/04 - Lock casings or latch-mechanism casings of cylinder locks
• E05B 47/06 - Controlling mechanically-operated bolts by electromagnetically-operated detents

IPC Classes  ?

• E05B 17/04 - Devices for coupling the turning cylinder of a single or double cylinder lock with the bolt-operating member

Abstract

According to a first aspect of the invention, there is provided a tailpiece attaching arrangement (100) comprising a cylindrical frame (102), a cylindrical attaching member (104) and a locking member (106) wherein the cylindrical attaching member (104) is configured to attach the tailpiece (108) into the cylindrical frame (102), and the locking member (106) is configured to lock the attaching member (104) According to a second aspect of the invention, there is provided a lock arrangement (126) comprising the tailpiece attaching arrangement (100) and a lock cylinder (128).

IPC Classes  ?

• E05B 17/04 - Devices for coupling the turning cylinder of a single or double cylinder lock with the bolt-operating member
• E05B 63/00 - Locks with special structural characteristics

Abstract

According to a first aspect of the invention, there is provided a doorknob (108) with a fixing mechanism (100) comprising at least a first locking member (102A) and at least a first spring element (104A) coupled with the first locking member (102A), wherein the spring element (104A) is configured to move the locking member (102A) to be in contact with a lock cylinder (106) to prevent movement of the doorknob in relation to the lock cylinder (106) in a longitudinal direction (CL) According to a second aspect of the invention, there is provided a lock arrangement comprising the doorknob (108) with a fixing mechanism (100) and the lock cylinder (106). According to a third aspect of the invention, there is provided an opening tool (110) for the doorknob (108) with the fixing mechanism (100).

IPC Classes  ?

• E05B 47/06 - Controlling mechanically-operated bolts by electromagnetically-operated detents
• E05B 9/04 - Lock casings or latch-mechanism casings of cylinder locks
• E05B 3/00 - Fastening handles to lock or latch parts

Abstract

According to a first aspect of the invention, there is provided a doorknob (108) with a fixing mechanism (100) comprising at least a first locking member (102A) and at least a first spring element (104A) coupled with the first locking member (102A), wherein the spring element (104A) is configured to move the locking member (102A) to be in contact with a lock cylinder (106) to prevent movement of the doorknob in relation to the lock cylinder (106) in a longitudinal direction (CL). According to a second aspect of the invention, there is provided a lock arrangement comprising the doorknob (108) with a fixing mechanism (100) and the lock cylinder (106). According to a third aspect of the invention, there is provided an opening tool (110) for the doorknob (108) with the fixing mechanism (100).

IPC Classes  ?

• E05B 3/00 - Fastening handles to lock or latch parts
• E05B 3/04 - Fastening the handle shank to the spindle by screws, springs, or snap bolts

Abstract

According to a first aspect of the invention, there is provided a tailpiece attaching arrangement (100) comprising a cylindrical frame (102), a cylindrical attaching member (104) and a locking member (106) wherein the cylindrical attaching member (104) is configured to attach the tailpiece (108) into the cylindrical frame (102), and the locking member (106) is configured to lock the attaching member (104). According to a second aspect of the invention, there is provided a lock arrangement (126) comprising the tailpiece attaching arrangement (100) and a lock cylinder (128).

IPC Classes  ?

• E05B 9/08 - Fastening the casings of latch-bolt locks or cylinder locks to the wing
• E05B 17/04 - Devices for coupling the turning cylinder of a single or double cylinder lock with the bolt-operating member

Abstract

A locking system is described. The locking system, includes a lock. The lock includes a semi-hard magnet and a hard magnet. The hard magnet is configured to move to open or close the lock, the lock is self-powered using near field communication (NFC), and the lock is digitally controlled using a mobile application.

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• G07C 9/00 - Individual registration on entry or exit

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; locks and keys, of metal. Electric, electronic and electromechanical locks and lock goods, also including electronic lock cylinders, electric striking plates, door magnets, electronic keys, key cards, also including electronic or magnetic access control cards and smart cards, and key card readers, also including electronic or magnetic access control card readers and smart card readers; programming units for electronic locks, lock cylinders, keys, key cards, key card readers and locking mechanisms for safes; computer software for management and use of minibars; electric and electromechanical panels for doors, gates, windows to be used in connection with electric keys and user information; electronic and magnetic sensors; devices and systems for the implementation of the access control function to identify the authentication and use or prohibition of use of digital data, physical spaces or computer networks; apparatus and systems for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; apparatus and systems for managing mini bars and energy consumption in hotels, homes, companies, public establishments; apparatus and instruments for recording, monitoring, signaling and checking, also including checking and/or controlling people's movement within, entrance to and exit from buildings and through doors and gates and/or for use with locks; magnetic and electronic identity cards; magnetic data carriers and computer software. Wholesale and retail services relating to locks, door and gates, access control, security goods; customer information services in connection with the sale of aforesaid goods; business advisory and consultancy services relating to the establishment and operation of franchises and re-sale services; systemization, processing and maintenance of information into computer databases; retrieval of data and documents. Education and providing of training and instruction services in relation to installation, maintenance and repair of locks, locking mechanisms, access control and security apparatus, systems and installations and related products and devices. Design services related to wireless power transmission and device-to-device communication (D2D) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (wireless personal area network and NFC); computers, computer systems, computer software, technology solutions, wireless and wired network devices and wired network devices and application design and development in the field of access control, access control and security, including identity security solutions; design and development of devices and instruments for access control, access management and security; advice and information related to the aforementioned services; architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; consulting services regarding the energy efficiency of buildings; web application services (SaaS); consulting services related to web application services (SaaS), open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); microservices (software) related to user identification, communication and customer service maintenance. Security services for the protection of property and individuals.

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; safes; ores. Electronic and electromechanical locks and lock cylinders; electronic keys; electronic lock plates and counter plates; process control units [electronic] for programming the above-mentioned locks, cylinders and keys; electronic components included in all the above-mentioned items; software for using the above-mentioned items. Security services for the protection of property and individuals.

Abstract

An electromechanical lock cylinder (100). The cylinder (100) includes a core front end (122), a core back end (140) coupled with a tailpiece (152), an actuator mechanism (126, 128, 132), switchable between a locked state and an unlocked state, to keep the core front end (122) uncoupled with the core back end (140) in the locked state, to couple the core front end (122) with the core back (140) end in the unlocked state to enable the core front end (122) to rotate the core back end (140) from a locked rear position to an unlocked rear position, and to return to keep the core front end (122) uncoupled with the core back end (140) in the locked state; an enforced coupling (124, 142, 146, 148, 150) to couple the core front end (122) with the core back end (140) as the core front end (122) starts to rotate the core back end (140) away from the locked rear position in the unlocked state, and decouple the core front end (122) from the core back end (140) as the core back end (140) returns to the locked rear position; an operation knob (104), coupled with the core front end (122), to enable a user to rotate the operation knob (104) from an initial knob position so that the core front end (122) rotates the core back end (140) from the locked rear position to the unlocked rear position in the unlocked state; and a return force mechanism (114, 118) to rotate the operation knob (104) further after the user first has rotated the operation knob (104) away from the initial knob position and then released the operation knob (104), whereby the core back end (140) is rotated to the locked rear position by the core front end (122) due to the coupled enforced coupling (124, 142, 146, 148, 150).

IPC Classes  ?

• E05B 15/00 - Other details of locksParts for engagement by bolts of fastening devices
• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• E05B 47/06 - Controlling mechanically-operated bolts by electromagnetically-operated detents

Abstract

An electromechanical lock cylinder. The cylinder includes a core front end, a core back end coupled with a tailpiece, an actuator mechanism, switchable between a locked state and an unlocked state, to keep the core front end uncoupled with the core back end in the locked state, to couple the core front end with the core back end in the unlocked state to enable the core front end to rotate the core back end from a locked rear position to an unlocked rear position, and to return to keep the core front end uncoupled with the core back end in the locked state; an enforced coupling to couple the core front end with the core back end as the core front end starts to rotate the core back end away from the locked rear position in the unlocked state, and decouple the core front end from the core back end as the core back end returns to the locked rear position; an operation knob, coupled with the core front end, to enable a user to rotate the operation knob from an initial knob position so that the core front end rotates the core back end from the locked rear position to the unlocked rear position in the unlocked state; and a return force mechanism to rotate the operation knob further after the user first has rotated the operation knob away from the initial knob position and then released the operation knob, whereby the core back end is rotated to the locked rear position by the core front end due to the coupled enforced coupling.

IPC Classes  ?

• E05B 47/06 - Controlling mechanically-operated bolts by electromagnetically-operated detents
• E05B 1/00 - Knobs or handles for wingsKnobs, handles, or press buttons for locks or latches on wings
• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means

Abstract

An electromechanical lock cylinder (100). The cylinder (100) includes a core front end (122), a core back end (140) coupled with a tailpiece (152), an actuator mechanism (126, 128, 132), switchable between a locked state and an unlocked state, to keep the core front end (122) uncoupled with the core back end (140) in the locked state, to couple the core front end (122) with the core back (140) end in the unlocked state to enable the core front end (122) to rotate the core back end (140) from a locked rear position to an unlocked rear position, and to return to keep the core front end (122) uncoupled with the core back end (140) in the locked state; an enforced coupling (124, 142, 146, 148, 150) to couple the core front end (122) with the core back end (140) as the core front end (122) starts to rotate the core back end (140) away from the locked rear position in the unlocked state, and decouple the core front end (122) from the core back end (140) as the core back end (140) returns to the locked rear position; an operation knob (104), coupled with the core front end (122), to enable a user to rotate the operation knob (104) from an initial knob position so that the core front end (122) rotates the core back end (140) from the locked rear position to the unlocked rear position in the unlocked state; and a return force mechanism (114, 118) to rotate the operation knob (104) further after the user first has rotated the operation knob (104) away from the initial knob position and then released the operation knob (104), whereby the core back end (140) is rotated to the locked rear position by the core front end (122) due to the coupled enforced coupling (124, 142, 146, 148, 150).

IPC Classes  ?

• E05B 15/00 - Other details of locksParts for engagement by bolts of fastening devices
• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• E05B 47/06 - Controlling mechanically-operated bolts by electromagnetically-operated detents

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; locks and keys, of metal. Electric, electronic and electromechanical locks and lock goods, also including electronic lock cylinders, electric striking plates, door magnets, electronic keys, key cards, also including electronic or magnetic access control cards and smart cards, and key card readers, also including electronic or magnetic access control card readers and smart card readers; units for programming locks, lock cylinders, keys, key cards, key card readers and safes; electric and electromechanical door and window hardware in the nature of electromechanical door and window locks; electronic and magnetic sensors; CCTV systems and devices; electric, electronic and electromechanical access control apparatus and systems; security or alarm apparatus and systems; apparatus and systems for providing identification and authentication data for near field communication (NFC) tags, digital keys and identity data; apparatus and systems for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; apparatus and systems for managing mini bars and energy consumption in hotels, homes, companies, public establishments; apparatus and instruments for recording, monitoring, signaling and checking, also including checking and/or controlling people's movement within, entrance to and exit from buildings and through doors and gates and/or for use with locks; magnetic and electronic identity cards; magnetic data carriers and computer software. Wholesale and retail services relating to locks, door and gates, access control, security goods; customer information services in connection with the sale of afore said goods; business advisory and consultancy services relating to the establishment and operation of franchises and re-sale services; systemization, processing and maintenance of information into computer databases; retrieval of data and documents. Education and providing of training and instruction services in relation to installation, maintenance and repair of locks, locking mechanisms, access control and security apparatus, systems and installations and related products and devices. Development and design of wireless power transmission and device-to-device communication (D2D) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (bluetooth low energy and NFC); computers, computer systems, computer software, technology solutions, wireless and wired network devices - and application design and development in the field of access control, access control and security, including identity security solutions; design and development of devices and instruments for access control, access management and security; advice and information related to the aforementioned services; architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; consulting services regarding the energy efficiency of buildings; web application services (SaaS); consulting services related to web application services (SaaS), open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); microservices (software) related to user identification, communication and customer service maintenance. Security services for the protection of property and individuals.

Abstract

The method includes: switching (1202), in a magnetically-operated actuator, between a first mechanical state and a second mechanical state using either a first internal magnetization configuration or a second internal magnetization configuration; after the switching (1202), measuring (1204), by a magnetic sensor, a prevailing magnetic field caused by the magnetically-operated actuator, testing (1206) the prevailing magnetic field against a predetermined condition, and based on the testing (1206), detecting (1208) whether the switching between the first mechanical state and the second mechanical state was completed or not completed.

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• E05B 47/06 - Controlling mechanically-operated bolts by electromagnetically-operated detents
• H01F 7/16 - Rectilinearly-movable armatures
• H01F 7/18 - Circuit arrangements for obtaining desired operating characteristics, e.g. for slow operation, for sequential energisation of windings, for high-speed energisation of windings

Abstract

This document discloses a solution for configuring access rights in a locking system comprising a plurality of electro-mechanical locks and a plurality of keys to users of the system. Each key stores encrypted data defining an opening right to a particular subset of the plurality of electromechanical lock, the subset of locks assigned to the respective user. The system further comprises a service key storing, as a default, no encrypted data to any of the subsets of locks. The system further comprises a computer program product configured to receive, via a user interface of a personal electronic device of a user, a write authorization from the user of a specific subset of the plurality of electromechanical locks that are assigned to the user; in response to the write authorization, an opening right of the service key is generated for the specific subset of the plurality of electromechanical locks as the encrypted data, and the generated encrypted data containing the opening right to the specific subset of the plurality of electromechanical locks is written to the service key after checking the user has access rights to the specific subset of the plurality of electromechanical locks. Thereafter, the service can be used to open the subset of the plurality of electromechanical locks.

IPC Classes  ?

• G07C 9/00 - Individual registration on entry or exit

Abstract

This document discloses a solution for configuring access rights in a locking system comprising a plurality of electromechanical locks and a plurality of keys to users of the system. Each key stores encrypted data defining an opening right to a particular subset of the plurality of electromechanical lock, the subset of locks assigned to the respective user. The system further comprises a service key storing, as a default, no encrypted data to any of the subsets of locks. The system further comprises a computer program product configured to receive, via a user interface of a personal electronic device of a user, a write authorization from the user of a specific subset of the plurality of electromechanical locks that are assigned to the user; in response to the write authorization, an opening right of the service key is generated for the specific subset of the plurality of electromechanical locks as the encrypted data, and the generated encrypted data containing the opening right to the specific subset of the plurality of electromechanical locks is written to the service key after checking the user has access rights to the specific subset of the plurality of electromechanical locks. Thereafter, the service can be used to open the subset of the plurality of electromechanical locks.

IPC Classes  ?

• G07C 9/00 - Individual registration on entry or exit

Goods & Services

(1) Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; locks and keys, of metal. (2) Electric, electronic and electromechanical locks and lock goods, also including electronic lock cylinders, electric striking plates, door magnets, electronic keys, key cards, also including electronic or magnetic access control cards and smart cards, and key card readers, also including electronic or magnetic access control card readers and smart card readers; units for programming locks, lock cylinders, keys, key cards, key card readers and safes; electric and electromechanical door and window hardware; electronic and magnetic sensors; CCTV systems and devices; electric, electronic and electromechanical access control apparatus and systems; security or alarm apparatus and systems; apparatus and systems for providing identification and authentication data for near field communication (NFC) tags, digital keys and identity data; apparatus and systems for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; apparatus and systems for managing mini bars and energy consumption in hotels, homes, companies, public establishments; apparatus and instruments for recording, monitoring, signaling and checking, also including checking and/or controlling people's movement within, entrance to and exit from buildings and through doors and gates and/or for use with locks; magnetic and electronic identity cards; magnetic data carriers and computer software. (1) Wholesale and retail services relating to locks, door and gates, access control, security goods; customer information services in connection with the sale of afore said goods; business advisory and consultancy services relating to the establishment and operation of franchises and re-sale services; systemization, processing and maintenance of information into computer databases; retrieval of data and documents. (2) Education and providing of training and instruction services in relation to installation, maintenance and repair of locks, locking mechanisms, access control and security apparatus, systems and installations and related products and devices. (3) Design services related to wireless power transmission and device-to-device communication (D2D) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (wireless personal area network and NFC); computers, computer systems, computer software, technology solutions, wireless and wired network devices - and application design and development in the field of access control, access control and security, including identity security solutions; design and development of devices and instruments for access control, access management and security; advice and information related to the aforementioned services; architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; consulting services regarding the energy efficiency of buildings; Web application services (Saas); consulting services related to web application services (Saas), open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); microservices (software) related to user identification, communication and customer service maintenance. (4) Security services for the protection of property and individuals.

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; locks and keys, of metal.. Electric, electronic and electromechanical locks and lock goods, also including electronic lock cylinders, electric striking plates, door magnets, electronic keys, key cards, also including electronic or magnetic access control cards and smart cards, and key card readers, also including electronic or magnetic access control card readers and smart card readers; units for programming locks, lock cylinders, keys, key cards, key card readers and safes; electric and electromechanical door and window hardware; electronic and magnetic sensors; CCTV systems and devices; electric, electronic and electromechanical access control apparatus and systems; security or alarm apparatus and systems; apparatus and systems for providing identification and authentication data for near field communication (NFC) tags, digital keys and identity data; apparatus and systems for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; apparatus and systems for managing mini bars and energy consumption in hotels, homes, companies, public establishments; apparatus and instruments for recording, monitoring, signaling and checking, also including checking and/or controlling people's movement within, entrance to and exit from buildings and through doors and gates and/or for use with locks; magnetic and electronic identity cards; magnetic data carriers and computer software.. Wholesale and retail services relating to locks, door and gates, access control, security goods; customer information services in connection with the sale of afore said goods; business advisory and consultancy services relating to the establishment and operation of franchises and re-sale services; systemization, processing and maintenance of information into computer databases; retrieval of data and documents.. Education and providing of training and instruction services in relation to installation, maintenance and repair of locks, locking mechanisms, access control and security apparatus, systems and installations and related products and devices.. Design services related to wireless power transmission and device-to-device communication (D2D) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (Wireless personal area network and NFC); Computers, computer systems, computer software, technology solutions, wireless and wired network devices - and application design and development in the field of access control, access control and security, including identity security solutions; Design and development of devices and instruments for access control, access management and security; Advice and information related to the aforementioned services; Architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; Consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; Information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; Consulting services regarding the energy efficiency of buildings; Web application services (Saas); Consulting services related to web application services (Saas), Open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); Microservices (software) related to user identification, communication and customer service maintenance. Security services for the protection of property and individuals..

Goods & Services

Non-electric cables and wires of common metal; ironmongery, namely, mounting screws, washers, escutcheons for lock cylinders and other mounting hardware for metal lock cylinders in the nature of metal mounting brackets for general use adapted for use with metal lock cylinders and hinges of metal; pipes and tubes of metal Electronic and electromechanical locks, namely, electronically operated high security lock cylinders, keytubes and padlocks; electronic keys, namely, electromechanical keys in the nature of electronic key cards; recorded and downloadable computer software using the above-mentioned items, namely, for managing locking information for keys, locks and their access rights in a locking plan Wholesale and retail store services featuring locks, doors and gates, access control, security goods; customer information services in connection with the sale of afore said goods; business advisory and consultancy services relating to the establishment and operation of franchises and re-sale services; systemization, processing and maintenance of information into computer databases; retrieval of data and documents Education services, namely, conducting training and courses of instruction in the field of installation, maintenance and repair of locks, locking mechanisms, access control and security apparatus, systems and installations and related products and devices Development and design of wireless power transmission servers, device-to device communication (D2D) servers, databases, distributed computer systems, embedded computer systems, cloud software technologies, cloud-based software, mobile software technologies, mobile software, near radio frequency wireless technologies, low energy and near field communications (NFC) technologies; design and development of computers, computer systems, computer software, technology solutions in the field of access control, access control and security, including identity security solutions, wireless and wired network devices, and design and development of software applications in the field of access control, access control and security, including identity security solutions; design and development of devices and instruments for access control, access management and security; providing advice and information related to the aforementioned services; technical architecture design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; engineering and architectural technical consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; information lifecycle management for others, namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions, being computer security services in the nature of providing authentication, issuance, validation and revocation of digital certificates; web application software services being software as a service (SAAS) services featuring software for building access control and controlling building security systems; computer software consulting services that are delivered through the internet on a subscription basis as Software as a Service (SaaS), open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); microservices related to user identification, communication and customer service maintenance, namely, software as a service (SAAS) services featuring software for building and controlling building security systems Security services for the protection of property and individuals, namely, surveillance services relating to the security of tangible property, security threat analysis for protecting personal property, monitoring of security alarms and home security systems for protecting personal property

Abstract

One or more embodiments describe a magnetic actuator including at least two magnets. One magnet is a semi hard magnet and the other magnet is a hard magnet. The hard magnet is configured to open or close the magnetic actuator. The semi hard magnet and the hard magnet are placed adjacent to each other. A change in magnetization polarization of the semi hard magnet is configured to push or pull the hard magnet) to open or close a digital lock realised with the magnetic actuator. The magnetic actuator can also be used to realise a valve.

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• G07C 9/00 - Individual registration on entry or exit

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; locks and keys, of metal.. Electric, electronic and electromechanical locks and lock goods, also including electronic lock cylinders, electric striking plates, door magnets, electronic keys, key cards, also including electronic or magnetic access control cards and smart cards, and key card readers, also including electronic or magnetic access control card readers and smart card readers; Units for programming locks, lock cylinders, keys, key cards, key card readers and safes; Computer software for management and use of minibars; Electric and electromechanical panels for doors, gates, windows to be used in connection with electric keys and user information; electronic and magnetic sensors; Devices and systems for the implementation of the access control function to identify the authentication and use or prohibition of use of digital data, physical spaces or computer networks; Apparatus and systems for implementing access control functionality for identity verification and access or denial of access to digital data, physical premises or computer networks; Apparatus and systems for managing mini bars and energy consumption in hotels, homes, companies, public establishments; Aapparatus and instruments for recording, monitoring, signaling and checking, also including checking and/or controlling people's movement within, entrance to and exit from buildings and through doors and gates and/or for use with locks; magnetic and electronic identity cards; magnetic data carriers and computer software.. Wholesale and retail services relating to locks, door and gates, access control, security goods; customer information services in connection with the sale of afore said goods; business advisory and consultancy services relating to the establishment and operation of franchises and re-sale services; systemization, processing and maintenance of information into computer databases; retrieval of data and documents. Education and providing of training and instruction services in relation to installation, maintenance and repair of locks, locking mechanisms, access control and security apparatus, systems and installations and related products and devices.. Design services related to wireless power transmission and device-to-device communication (D2D) of servers, databases, distributed systems, embedded systems, cloud technologies, cloud-based software, mobile technologies, mobile software, near radio technologies (Wireless personal area network and NFC); Computers, computer systems, computer software, technology solutions, wireless and wired network devices - and application design and development in the field of access control, access control and security, including identity security solutions; Design and development of devices and instruments for access control, access management and security; Advice and information related to the aforementioned services; Architecture-related and technical design services related to doors, booms, gates, technical actuators, protected cabinets, racks, vehicles, deck structures intended for loading and their parts and components; Consulting services related to the design of doors, booms, gates, deck structures intended for loading and their parts and components; Information lifecycle management (for others), namely, issuing, authenticating and revoking digital signatures and digital rights in the field of physical and logical access control systems and identity security solutions; Consulting services regarding the energy efficiency of buildings; Web application services (Saas); Consulting services related to web application services (Saas), Open software interfaces (APIs) and functions related to interfaces and software and tools (SDK); Microservices (software) related to user identification, communication and customer service maintenance. Security services for the protection of property and individuals..

Abstract

A locking system is described. The locking system, includes a lock. The lock includes a semi-hard magnet and a hard magnet. The hard magnet is configured to move to open or close the lock, the lock is self-powered using near field communication (NFC), and the lock is digitally controlled using a mobile application.

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• G07C 9/00 - Individual registration on entry or exit

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; safes; ores.. Electronic and electromechanical locks and lock cylinders; electronic keys; electronic lock plates and counter plates; units for programming the above-mentioned locks, cylinders and keys; components included in all the above-mentioned items; software for using the above-mentioned items.. Security services for the protection of property and individuals..

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; safes; ores.. Electronic and electromechanical locks and lock cylinders; electronic keys; electronic lock plates and counter plates; units for programming the above-mentioned locks, cylinders and keys; components included in all the above-mentioned items; software for using the above-mentioned items.. Security services for the protection of property and individuals.

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; safes; ores.. Electronic and electromechanical locks and lock cylinders; electronic keys; electronic lock plates and counter plates; units for programming the above-mentioned locks, cylinders and keys; components included in all the above-mentioned items; software for using the above-mentioned items.. Security services for the protection of property and individuals..

Abstract

Electromechanical lock and method are disclosed. The lock includes: a movable permanent magnet to move between a first position and a second position; a stationary permanent semi-hard magnet; and an electrically powered magnetization coil positioned adjacent to the stationary permanent semi-hard magnet to switch a polarity of the stationary permanent semi-hard magnet between a first magnetization configuration and a second magnetization configuration. The first magnetization configuration of the stationary permanent semi-hard magnet moves the movable permanent magnet to the first position. The second magnetization configuration of the stationary permanent semi-hard magnet moves the movable permanent magnet to the second position. A magnetic axis of the movable permanent magnet is side by side with a magnetic axis of the stationary permanent semi-hard magnet.

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• H01F 7/02 - Permanent magnets
• H01F 7/06 - ElectromagnetsActuators including electromagnets
• H01F 7/20 - ElectromagnetsActuators including electromagnets without armatures

Abstract

A mobile phone can be used to open doors of buildings and vehicles, instead of a dedicated physical key. For example, the mobile phone can provide the operating power to the lock without a power cord. A mobile station app can communicate with the lock via a short-range wireless communication connection, and open and close the lock.

IPC Classes  ?

• G07C 9/00 - Individual registration on entry or exit
• G06F 21/31 - User authentication
• H04B 5/48 - Transceivers
• H04B 5/79 - Near-field transmission systems, e.g. inductive or capacitive transmission systems specially adapted for specific purposes for data transfer in combination with power transfer
• H04W 4/02 - Services making use of location information
• H04W 4/029 - Location-based management or tracking services
• H04W 4/12 - MessagingMailboxesAnnouncements
• H04W 4/80 - Services using short range communication, e.g. near-field communication [NFC], radio-frequency identification [RFID] or low energy communication
• H04W 12/06 - Authentication

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; safes; ores. Electronic and electromechanical locks and lock cylinders; electronic keys; electronic lock plates and counter plates; units for programming the above-mentioned locks, cylinders and keys; components included in all the above-mentioned items; software for using the above-mentioned items. Security services for the protection of property and individuals.

Goods & Services

Electronic and electromechanical locks and lock cylinders; electronic keys; electronic lock plates and counter plates; units for programming the above-mentioned locks, cylinders and keys; parts and fittings thereof; software for using the above-mentioned items; mobile application software. The bringing together, for the benefit of others, of a variety of security services for protecting of property and individuals, enabling customers to conveniently purchase and compare those services; marketing services, namely marketing of security services for protecting of property and individuals. Security services for the protection of property and individuals.

Goods & Services

Software and applications for mobile devices.

Abstract

Electromechanical lock and method are disclosed. The lock includes: a movable permanent magnet to move between a first position and a second position; a stationary permanent semi-hard magnet; and an electrically powered magnetization coil positioned adjacent to the stationary permanent semi-hard magnet to switch a polarity of the stationary permanent semi-hard magnet between a first magnetization configuration and a second magnetization configuration. The first magnetization configuration of the stationary permanent semi-hard magnet attracts the movable permanent magnet to the first position. The second magnetization configuration of the stationary permanent semi-hard magnet repels the movable permanent magnet to the second position. A magnetic axis of the movable permanent magnet is side by side with a magnetic axis of the stationary permanent semi-hard magnet.

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means

Abstract

A method and a tag for opening a powerless electromechanical lock are provided. The tag comprises a power source, a near field communication transceiver, an antenna connected to the transceiver, an proximity switch and a controller. The switch is configured to wake up the controller from a low power mode upon a detection of a predetermined signal. The controller is configured after the wake up to activate the near field communication transceiver and control the transceiver to transmit via the antenna wirelessly first operating power to the lock for communication and authentication, perform authentication with the lock and, provided that the authentication is successful, control the transceiver to transmit wirelessly second operating power to the lock for the lock to be set into an openable state.

IPC Classes  ?

• G07C 9/00 - Individual registration on entry or exit

Goods & Services

(1) Downloadable software and applications for mobile devices for managing and controlling electronic locking systems and electronic keys.

Goods & Services

downloadable and recorded software for managing and controlling electronic locking systems and electronic keys; downloadable operating system software

Abstract

Electromechanical lock and method are disclosed. The lock includes: a movable permanent magnet (100) to move between a first position (120) and a second position (140); a stationary permanent semi-hard magnet (102); and an electrically powered magnetization coil (104) positioned adjacent to the stationary permanent semi-hard magnet (102) to switch a polarity of the stationary permanent semi- hard magnet (102) between a first magnetization configuration (S-N) and a second magnetization configuration (N-S). The first magnetization configuration (S-N) of the stationary permanent semi-hard magnet (102) attracts (122) the movable permanent magnet (100) to the first position (120). The second magnetization configuration (N-S) of the stationary permanent semi-hard magnet (102) repels (142) the movable permanent magnet to the second position (140). A magnetic axis (108) of the movable permanent magnet (100) is side by side with a magnetic axis (110) of the stationary permanent semi-hard magnet (102).

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• H01F 7/02 - Permanent magnets
• H01F 7/122 - Guiding or setting position of armatures, e.g. retaining armatures in their end position by permanent magnet
• H01F 7/16 - Rectilinearly-movable armatures

Abstract

Electromechanical lock and method are disclosed. The lock includes: a movable permanent magnet (100) to move between a first position (120) and a second position (140); a stationary permanent semi-hard magnet (102); and an electrically powered magnetization coil (104) positioned adjacent to the stationary permanent semi-hard magnet (102) to switch a polarity of the stationary permanent semi- hard magnet (102) between a first magnetization configuration (S-N) and a second magnetization configuration (N-S). The first magnetization configuration (S-N) of the stationary permanent semi-hard magnet (102) attracts (122) the movable permanent magnet (100) to the first position (120). The second magnetization configuration (N-S) of the stationary permanent semi-hard magnet (102) repels (142) the movable permanent magnet to the second position (140). A magnetic axis (108) of the movable permanent magnet (100) is side by side with a magnetic axis (110) of the stationary permanent semi-hard magnet (102).

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• H01F 7/02 - Permanent magnets
• H01F 7/122 - Guiding or setting position of armatures, e.g. retaining armatures in their end position by permanent magnet
• H01F 7/16 - Rectilinearly-movable armatures

Abstract

The invention relates to methods and systems where a mobile phone (200, 500, 800) is used to open doors of buildings and vehicles instead of a dedicated physical key. In the invention, the mobile station (200, 500, 800) is configured to provide the operating power to the lock (224, 524) without a power chord. A mobile station app (300, 600, 900) is then configured to communicate with the lock (224, 524) via a short-range wireless communication connection, and open and close the lock (224, 524). The object of the invention is to provide an electronic software-based key and lock system that is cheaper and easier to use than the physical key.

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• E05B 67/00 - PadlocksDetails thereof
• G07C 9/00 - Individual registration on entry or exit
• H02J 50/00 - Circuit arrangements or systems for wireless supply or distribution of electric power
• H04W 4/02 - Services making use of location information
• H04W 12/00 - Security arrangementsAuthenticationProtecting privacy or anonymity

Abstract

A mobile station is used to open doors of buildings and vehicles instead of a dedicated physical key. The mobile station is configured to provide the operating power to the lock without a power cord. A mobile station app is then configured to communicate with the lock via a short-range wireless communication connection, and open and close the lock. This can provide an electronic software-based key and lock system that is cheaper and easier to use than the physical key.

IPC Classes  ?

• G07C 9/26 - Individual registration on entry or exit involving the use of a pass in combination with an identity check of the pass holder using biometric data, e.g. fingerprints, iris scans or voice recognition using a biometric sensor integrated in the pass
• G07C 9/28 - Individual registration on entry or exit involving the use of a pass the pass enabling tracking or indicating presence
• G07C 9/00 - Individual registration on entry or exit

Abstract

The invention provides a digital lock (100, 1001, 1002) including at least two magnets. One magnet is a semi hard magnet (310) and the other magnet is a hard magnet (320). The hard magnet (320) is configured to open or close the digital lock (100, 1001, 1002). The semi hard magnet (310) and the hard magnet (320) are placed adjacent to each other. A change in magnetisation polarisation of the semi hard magnet (310) is configured to push or pull the hard magnet (320) to open or close the digital lock (100, 1001, 1002).

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• G07C 9/00 - Individual registration on entry or exit

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; safes; ores. Electronic and electromechanical locks and lock cylinders; electronic keys; electronic lock plates and counter plates; units for programming the above-mentioned locks, cylinders and keys; parts and fittings thereof; software for using the above-mentioned items; mobile application software. Security services for the protection of property and individuals.

Abstract

The invention provides a magnetic actuator (100, 1001, 1002) including at least two magnets. One magnet is a semi hard magnet (310) and the other magnet is a hard magnet (320). The hard magnet (320) is configured to open or close the magnetic actuator (100, 1001, 1002). The semi hard magnet (310) and the hard magnet (320) are placed adjacent to each other. A change in magnetization polarization of the semi hard magnet (310) is configured to push or pull the hard magnet (320) to open or close a digital lock realised with the magnetic actuator 100, 1001, 1002. The magnetic actuator of the invention can also be used to realise a valve.

IPC Classes  ?

• E05B 47/00 - Operating or controlling locks or other fastening devices by electric or magnetic means
• G07C 9/00 - Individual registration on entry or exit

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; safes; ores. Electronic and electromechanical locks and lock cylinders; electronic keys; electronic lock plates and counter plates; units for programming the above-mentioned locks, cylinders and keys; components included in all the above-mentioned items; software for using the above-mentioned items. Security services for the protection of property and individuals.

Abstract

Techniques for using a mobile station to open the doors of buildings and vehicles, instead of a dedicated physical key. The mobile station is configured to provide the operating power to a lock without a power cord. A mobile station app is then configured to communicate with the lock via a short-range wireless communication connection, and open and close the lock. This can provide an electronic software-based key and lock system that is cheaper and easier to use than the physical key.

IPC Classes  ?

• G07C 9/00 - Individual registration on entry or exit
• H04B 5/00 - Near-field transmission systems, e.g. inductive or capacitive transmission systems
• H04B 5/02 - Near-field transmission systems, e.g. inductive loop type using transceiver
• H04W 4/80 - Services using short range communication, e.g. near-field communication [NFC], radio-frequency identification [RFID] or low energy communication
• H04W 4/029 - Location-based management or tracking services
• H04W 4/02 - Services making use of location information
• G06F 21/31 - User authentication
• H04W 12/06 - Authentication
• H04W 4/12 - MessagingMailboxesAnnouncements

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; safes; ores. Electronic and electromechanical locks and lock cylinders; electronic keys; electronic lock plates and counter plates; units for programming the above-mentioned locks, cylinders and keys; parts and fittings thereof; software for using the above-mentioned items; mobile application software. Security services for the protection of property and individuals.

Goods & Services

Software and applications for mobile devices.

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; safes; ores. Electronic and electromechanical locks and lock cylinders; electronic keys; electronic lock plates and counter plates; units for programming the above-mentioned locks, cylinders and keys; parts and fittings thereof; software for using the above-mentioned items; mobile application software. Security services for the protection of property and individuals.

Goods & Services

(1) Non-electric cables and wires of common metal being ironmongery, small items of metal hardware, namely, mounting screws, washers, escutcheons and other mounting hardware for lock cylinders; metal tubes for machinery; metal safes. (2) Electronic and electromechanical locks, namely digital and mobile lock cylinders, keytube lock cylinders and electronic padlocks; electronic keys, namely electromechanical keys and electronic key fobs, plates and counterplates for electronic door locks; computer programming software for programming locks, lock cylinders; electric programming devices, namely programming adapters, keys and tokens for programming locks, lock cylinders, keys, keycards, card reading equipment and safes, electronic programming devices namely programing keys and tokens for programming locks, lock cylinders, keys, keycards, card reading equipment and safes. (1) Security services for the protection of property and individuals.

Goods & Services

Non-electric cables and wires of common metal being ironmongery, small items of metal hardware, namely, mounting screws, washers, escutcheons for lock cylinders and other mounting hardware for metal lock cylinders in the nature of metal mounting brackets for general use adapted for use with metal lock cylinders and hinges of metal; pipes and tubes of metal; metal safes; ores, namely, metal ores and iron ores Electronic and electromechanical locks, namely, electronically operated high security lock cylinders, keytubes and padlocks; electronic keys, namely, electromechanical keys in the nature of electronic key cards; electronic key fobs being remote control apparatus; electronic lock assemblies, namely, electronic lock plates and counter plates; computer hardware units for programming the above mentioned locks, cylinders and keys; structural parts therefor; recorded and downloadable computer software for using the above-mentioned items, namely, for managing locking information for keys, locks and their access rights in a locking plan Security services for the protection of property and individuals, namely, security guarding for facilities and providing physical access to properties via a remote call-in locking device by means of a subscription plan

Goods & Services

Non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; safes; ores. Electronic and electromechanical locks and lock cylinders; electronic keys; electronic lock plates and counter plates; units for programming the above-mentioned locks, cylinders and keys; parts and fittings thereof; software for using the above-mentioned items. Security services for the protection of property and individuals.

Goods & Services

(1) Non-electric cables and wires of common metal being ironmongery, small items of metal hardware, namely, mounting screws, washers, escutcheons and other mounting hardware for lock cylinders; metal tubes for machinery; metal safes. (2) Electronic and electromechanical locks, namely digital and mobile lock cylinders, keytube lock cylinders and electronic padlocks; electronic keys, namely electromechanical keys and electronic key fobs, plates and counterplates for electronic door locks; computer programming software for programming locks, lock cylinders; electric programming devices, namely programming adapters, keys and tokens for programming locks, lock cylinders, keys, keycards, card reading equipment and safes, electronic programming devices namely programing keys and tokens for programming locks, lock cylinders, keys, keycards, card reading equipment and safes. (1) Security services for the protection of property and individuals.

Goods & Services

(1) Non-electric cables and wires of common metal being ironmongery, small items of metal hardware, namely, mounting screws, washers, escutcheons and other mounting hardware for lock cylinders; metal tubes for machinery; metal safes. (2) Electronic and electromechanical locks, namely digital and mobile lock cylinders, keytube lock cylinders and electronic padlocks; electronic keys, namely electromechanical keys and electronic key fobs, plates and counterplates for electronic door locks; computer programming software for programming locks, lock cylinders; electric programming devices, namely programming adapters, keys and tokens for programming locks, lock cylinders, keys, keycards, card reading equipment and safes, electronic programming devices namely programing keys and tokens for programming locks, lock cylinders, keys, keycards, card reading equipment and safes. (1) Security services for the protection of property and individuals.
