The invention relates to a flow sensor comprising:—a housing (100), wherein the housing (100) has an inlet channel (110) for receiving the fluid measuring medium, an outlet channel (120) for discharging the fluid measuring medium, a measuring channel (130) extending between the inlet channel (110) and outlet channel (120) and at least one secondary channel (140) extending between the inlet channel (110) and the outlet channel (120), and more particularly connected in parallel to the measuring channel (130);-a sensor element (200) arranged in the measuring channel (130) for sensing a physical measurement variable with regard to a flow of the fluid measuring medium; and -a first more particularly bolt-shaped closure element (300), wherein the first closure element (300) is designed and attached to the housing (100) such that the first closure element (300) can be moved in relation to a first fluid transfer (150) or a second fluid transfer (160) into at least one first position (P1) and a second position (P2), wherein the first closure element (300), in the second position (P2), closes the first fluid transfer (150) or the fluid transfer (160), and wherein the first fluid transfer (150) or the second fluid transfer (160) is not closed in the first position (P1) of the first closure element (300), as well as a system that contains the flow sensor according to the invention.
A first variant of a sensor element for ascertaining at least one physical or chemical measurement variable, includes: a planar substrate having a first surface and a second surface opposite the first side; one or more sensor structures, which are applied to the first surface of the substrate or on an insulation layer applied to the first surface of the substrate; a passivation layer that at least partially covers the sensor structure or the sensor structures; at least two electrical contact surfaces that are each connected to the sensor structure; a spacer layer applied to one or more first portions of the second surface of the substrate; and a sinterable and/or solderable metal layer applied to one or more second portions of the second surface of the substrate and/or on the spacer layer, wherein a layer thickness of the spacer layer is greater than or equal to a layer thickness of the sinterable and/or solderable metal layer. The present disclosure also relates to a second variant of a sensor element and to a sensor arrangement which comprises at least one sensor element of this kind.
G01K 1/143 - SupportsFastening devicesArrangements for mounting thermometers in particular locations for measuring surface temperatures
G01K 7/18 - Measuring temperature based on the use of electric or magnetic elements directly sensitive to heat using resistive elements the element being a linear resistance, e.g. platinum resistance thermometer
A sensor element comprises a carrier element; a sensor structure applied to the carrier element for detecting a measured variable, wherein the sensor structure has first and second electrical contact points and is operable by applying a voltage between the first and second electrical contact points; and an overvoltage protection element applied to the carrier element and comprising a first conductor track and a first pad and a second conductor track and a second pad spaced apart from the first pad. The first conductor track electrically connects the first electrical contact point to the first pad and the second electrical conductor track connects the second electrical contact point to the second pad. The first pad and the second pad are arranged at a distance from each other on the carrier element forming a spark gap between the first pad and the second pad.
G01K 1/14 - SupportsFastening devicesArrangements for mounting thermometers in particular locations
G01K 7/18 - Measuring temperature based on the use of electric or magnetic elements directly sensitive to heat using resistive elements the element being a linear resistance, e.g. platinum resistance thermometer
H05K 9/00 - Screening of apparatus or components against electric or magnetic fields
4.
SENSOR ELEMENT FOR DETECTING AT LEAST ONE MEASUREMENT VARIABLE, METHOD FOR PRODUCING SAME AND A MEASURING POINT
The invention discloses a sensor element (1) for detecting measurement variables in a medium (110), wherein the sensor element (1) is designed to be introduced into an opening (101) to a container (100) containing the medium (110), the sensor element (1) comprising at least one first film (2) having a first side (2.1) and a second side (2.2), wherein the first film (2) has a significantly greater extent in the direction of the x- and y-axis than in the direction of the z-axis; a sensor structure (4) which is arranged on the first side (2.1) of the first film (2), having a passivation layer on the sensor structure (4); a first metallised final layer (5) which is arranged on the passivation layer at least in the region of the sensor element (1) which is arranged level with the opening (101) during operation of the sensor element (1); a second metallised final layer (6) which is arranged on the second side (2.2) of the first film (2) at least in the region of the sensor element (1) which is arranged level with the opening (101) during operation of the sensor element (1); and at least one deep metallisation (7) along the z-axis, at least in the region of the sensor element (1) which is arranged level with the opening (101) during operation of the sensor element (1). The invention discloses a method for producing such a sensor element (1) and for producing a measuring point (200).
A device for transferring an active substance to a gas phase, which active substance contains at least one organic component, includes: a reservoir, which is designed to receive the active substance; and a heating element, which is made from a film of a nickel-chromium alloy or a refractory metal, wherein the heating element is designed to emit thermal radiation, and wherein the heating element is arranged with respect to the reservoir such that the active substance is heated at least by the thermal radiation emitted from the heating element.
A24F 40/46 - Shape or structure of electric heating means
B32B 1/00 - Layered products having a non-planar shape
B32B 3/26 - Layered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a particular shape of the outline of the cross-section of a continuous layerLayered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a layer with cavities or internal voids
B32B 5/02 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by structural features of a layer comprising fibres or filaments
B32B 15/14 - Layered products essentially comprising metal next to a fibrous or filamentary layer
H05B 3/26 - Heating elements having extended surface area substantially in a two-dimensional plane, e.g. plate-heater non-flexible heating conductor mounted on insulating base
6.
SYSTEM AND MANIPULATION PATH FOR MONITORING THE FLOW PROFILE AT THE INLET OF A FLOW SENSOR
A manipulation path for monitoring the flow profile at the inlet of a flow sensor, the manipulation path designed to conduct a fluid measuring medium, includes a first end region and a second end region, between which a manipulation section is located that is designed such that secondary flows are formed in the measuring medium as a result of the measuring medium flowing through the manipulation section. Two different variants of a system, each including a flow sensor and the manipulation path according to the present disclosure, are disclosed.
The invention relates to a method for producing a receiving device for an aerosol-generating device, said receiving device being designed to receive a product to be converted to the gas phase. The method has the steps of: - providing at least two partial shells, in particular partial shells which have identical dimensions and which form a substantially cylindrical body in the assembled state, each of the partial shells being injection molded and consisting of a plastic which can be injection molded; - applying one or more functional elements, in particular a temperature sensor and/or a heating element, onto the partial shells by means of a printing method, wherein each of the functional elements is printed onto at least one sub-region of the concave inner face of the corresponding partial shell in a flowable state; - thermally fixing the functional elements which are printed onto the partial shells in the flowable state; and - connecting the partial shells in a form-fitting, force-fitting, and/or bonded manner. The invention also relates to a receiving device for an aerosol-generating device and to an aerosol-generating device which comprises a receiving device according to the invention.
H05B 3/14 - Heating elements characterised by the composition or nature of the materials or by the arrangement of the conductor characterised by the composition or nature of the conductive material the material being non-metallic
H05B 3/44 - Heating elements having the shape of rods or tubes non-flexible heating conductor arranged within rods or tubes of insulating material
H05B 3/46 - Heating elements having the shape of rods or tubes non-flexible heating conductor mounted on insulating base
A24F 40/46 - Shape or structure of electric heating means
The invention relates to a heating device (1) comprising: - at least one heating element (100, 100') which comprises: i. a substrate (110); ii. a heating layer (120) which is applied onto the substrate (110); and iii. an expansion layer (130) which is applied onto the substrate (110) and covers the heating layer (120); and - an object (140) to be heated which is arranged with respect to the heating element (100, 100') such that in the deactivated state of the heating element (100, 100'), the object (140) is spaced from the expansion layer (130) or the substrate (110), wherein a second thermal expansion coefficient of the expansion layer (130) deviates from a first thermal expansion coefficient of the substrate (110), and the relative thicknesses of the substrate (110) and the expansion layer (130) are selected such that in the activated state of the heating element (100, 100'), an expansion (130) and/or a bending of the heating element (100, 100') occurs such that the spacing between the expansion layer (130), or the substrate (110), and the object (140) is overcome and a thermally-conductive contact is produced between the heating element (100, 100') and the object (140). The invention also relates to a method for operating a heating device (1) according to the invention and to a steam-generating device (2) which comprises the heating device (1) according to the invention.
G01F 1/684 - Structural arrangementsMounting of elements, e.g. in relation to fluid flow
G01F 1/69 - Structural arrangementsMounting of elements, e.g. in relation to fluid flow using a particular type of heating, cooling or sensing element of resistive type
G01F 1/696 - Circuits therefor, e.g. constant-current flow meters
G01F 1/698 - Feedback or rebalancing circuits, e.g. self heated constant temperature flowmeters
