Abstract

The invention relates to above-ground supporting structures suited for use in electrical grids, in the support of rail transport overhead contact lines, in lighting arrangements and corresponding applications. Instead of using a single pole of a large diameter, a structure is assembled from several, essentially vertical poles (1) of a smaller diameter and horizontal brackets (5) connecting the poles. The structure provides significantly better properties in terms of strength and flexibility relative to the single pole.

IPC Classes  ?

• E04H 12/02 - Structures made of specified materials
• H02G 7/20 - Spatial arrangements or dispositions of lines or cables on poles, posts or towers
• E04H 12/24 - Cross-arms

Abstract

Post, particularly a fibre-reinforced reinforced-plastic post (1), which is formed of a hollow casing (2). In the cavity inside the casing (2) there is a belt (5), which is attache at one end in the vicinity of the lower end of the post and at the opposite end as a loop in the vicinity of the upper end of the post, with the aid of pin-like elements (3, 4) penetrating the casing of the post.

IPC Classes  ?

• E01F 9/018 - specially adapted for breaking, disengaging, collapsing or permanent deformation upon deflection or displacement, e.g. upon vehicle impact
• E01F 9/011 - Upright bodies, e.g. marker posts or bollards; Supports for road signs (posts or poles in general E04H 12/00; means for attaching signs to a supporting structure in general G09F 7/18)

Goods & Services

(1) Common metals and their alloys; materials of metals for railway tracks; safes; ores; asphalt, pitch and bitumen; light post luminaries; non-metallic rigid pipes for building, namely utility poles made of reinforced plastic materials used as supports for traffic lights and road signage. (1) Travel arrangement.

Goods & Services

Common metals and their alloys; metal building materials; transportable buildings of metal; materials of metal for railway tracks; non-electric cables and wires of common metal; ironmongery, small items of metal hardware; pipes and tubes of metal; safes; goods of common metal not included in other classes; ores. Apparatus for lighting, heating, steam generating, cooking, refrigerating, drying, ventilating, water supply and sanitary purposes. Building materials (non-metallic); non-metallic rigid pipes for building; asphalt, pitch and bitumen; non-metallic transportable buildings; monuments, not of metal.
