A socket structure includes a socket body and a polygonal driving structure. The socket body includes a first fitting hole and a second fitting hole. The first fitting hole and the second fitting hole are respectively located at two ends of the socket body along a central axis of the socket structure, and the first fitting hole is communicated with the second fitting hole. The polygonal driving structure is disposed around an outer peripheral wall of the socket body and surrounds the first fitting hole. The socket structure has a maximum height along the central axis, the polygonal driving structure has an axial height along the central axis, and the axial height is smaller than or equal to half of the maximum height.
A toothed structure includes a body, two tooth parts and two recessed spaces. The body includes an inner surface and an outer surface, wherein the inner surface is disposed relatively to the outer surface. The two tooth parts are disposed on two ends of the inner surface. The two recessed spaces are disposed on the body, and corresponding to the two tooth parts, respectively.
A swing wrench includes a driving head, a handle, a pressing element and a positioning element. The driving head has a first protruding ear structure, wherein an inner surface of the first protruding ear structure has a smooth portion and a toothed portion. The handle has two second protruding ear structures, wherein the first protruding ear structure is disposed between the second protruding ear structures. The positioning element is engaged with the pressing element, and the pressing element and the positioning element are disposed through the first protruding ear structure and the second protruding ear structures.
A hand tool includes a handle, a driving head and a stopping member. The driving head is pivotally connected to one end of the handle. The stopping member is disposed on the end of the handle. The handle includes a stepping structure located on the end of the handle. The driving head includes a positioning portion located on one end of the driving head facing towards the handle. The stopping member includes a stopping structure, wherein when the stopping member is pushed by the stepping structure towards the driving head, the stopping structure is positioned on the positioning portion so as to position the driving head and the handle with a preset angle.
A socket-driven lighting connector is configured to connect with a socket and includes a connector main body, a light bulb, a switch, and a positioning ball. The connector main body includes an enclosing wall and a radial through hole. The enclosing wall surrounds and forms a through space. The radial through hole penetrates the enclosing wall and is in communication with the through space. The light bulb is disposed in the through space. The switch is provided in the through space and is electrically connected to the light bulb. The positioning ball is movably provided in the radial through hole. The switch and the positioning ball are so structured that by mounting the socket on the connector main body, the light bulb can be turned on to enhance the efficiency with which the socket can be operated in the dark.
B25B 23/18 - Devices for illuminating the head of the screw or the nut
F21K 9/232 - Retrofit light sources for lighting devices with a single fitting for each light source, e.g. for substitution of incandescent lamps with bayonet or threaded fittings specially adapted for generating an essentially omnidirectional light distribution, e.g. with a glass bulb
F21V 23/04 - Arrangement of electric circuit elements in or on lighting devices the elements being switches
F21V 23/06 - Arrangement of electric circuit elements in or on lighting devices the elements being coupling devices
09 - Scientific and electric apparatus and instruments
Goods & Services
Downloadable computer programs and mobile phone applications featuring software for data storage, namely, for storing digital electronic data received from hand tools, hand tool testing apparatuses, and calibration devices for hand tools; Downloadable computer programs and mobile phone applications featuring software for data exchange, namely, for transmitting and receiving data between hand tools, hand tool testing apparatuses and calibration apparatuses for hand tools; Downloadable computer programs and mobile phone applications featuring software for calibration processing, namely, for processing electronic data received from hand tools, apparatuses for testing hand tools, and calibration apparatuses for hand tools; Computer software applications, downloadable, featuring software for verifying hand tools are in proper working condition; Recorded computer software for providing a database for tracking and monitoring the location, lifecycle, durability, discard, and the frequency of calibration of hand tools, including the generation of notifications and reports of the noted data; Electronic numeric displays; Precision measuring apparatus, namely, protractors; Pressure indicators; Sensors, namely, piezoelectric sensors; Pressure gauges; Precision measuring apparatus, namely, digital force gauges; Ergometers not for medical purposes; Circuit testers; Precision measuring apparatus, namely, digital torque gauges; Tensile test device, namely, tension testers; Tensile resistance tester, namely, resistance measuring instruments.
09 - Scientific and electric apparatus and instruments
Goods & Services
Downloadable computer programs and mobile phone applications featuring software for data storage, namely, for storing digital electronic data received from hand tools, hand tool testing apparatuses, and calibration devices for hand tools; Downloadable computer programs and mobile phone applications featuring software for data exchange, namely, for transmitting and receiving data between hand tools, hand tool testing apparatuses and calibration apparatuses for hand tools; Downloadable computer programs and mobile phone applications featuring software for calibration processing, namely, for processing electronic data received from hand tools, apparatuses for testing hand tools, and calibration apparatuses for hand tools; Computer software applications, downloadable, featuring software for verifying hand tools are in proper working condition; Recorded computer software for providing a database for tracking and monitoring the location, lifecycle, durability, discard, and the frequency of calibration of hand tools, including the generation of notifications and reports of the noted data; Electronic numeric displays; Precision measuring apparatus, namely, protractors; Pressure indicators; Sensors, namely, piezoelectric sensors; Pressure gauges; Precision measuring apparatus, namely, digital force gauges; Ergometers not for medical purposes; Circuit testers; Precision measuring apparatus, namely, digital torque gauges; Tensile test device, namely, tension testers; Tensile resistance tester, namely, resistance measuring instruments
A ratchet wrench structure includes a handle portion, a head portion, a ratchet hole, a ratchet portion, an extending rod and a driving portion. The head portion is connected to the handle portion. The ratchet hole penetrates the head portion and includes a plurality of first tooth portions, and the ratchet hole has a driving axis. The ratchet portion is detachably disposed at the ratchet hole, the ratchet portion includes a plurality of second tooth portions, and the second tooth portions correspond to the first tooth portions. A first end of the extending rod is integrally connected to the ratchet portion, and the extending rod extends along the driving axis. The driving portion is integrally connected to a second end of the extending rod and detachably connected to a workpiece.
B25B 13/46 - SpannersWrenches of the ratchet type, for providing a free return stroke of the handle
B25B 23/00 - Details of, or accessories for, spanners, wrenches, screwdrivers
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
A wrench shaft structure includes a working head, a shaft, and a through hole unit. The working head has a pivotal connection portion at one end. The pivotal connection portion has a through bore. The shaft has a lug portion at one end and a body portion. The lug portion has a connection hole pivotally connected to the through bore such that the working head is pivotally connected to the shaft. The through hole unit has a layout length along the body portion and penetrates the body portion in the same direction as that in which the connection hole penetrates the lug portion. While the through hole unit is configured to reduce the weight of the shaft, the body portion still has a continuous structure along the moment arm of the force applied to the shaft during operation so that the shaft can apply a force of the expected magnitude.
Air tools and air tool accessories, namely, air operated impact screwdrivers, hammers, drills, impact sockets, wrenches, socket wrenches, adjustable wrenches, chisels, metal shears, riveters, impact socket sets and parts therefor; Power operated tools and power operated tool accessories, namely, power operated impact screwdrivers, wrenches, hammers, drills, socket wrenches, adjustable wrenches, chisels, metal shears, riveters, air regulators, impact sockets, impact socket sets and parts therefor.
An elastic element includes an inner annular wall, at least one outer annular wall, and a groove. The at least one outer annular wall connects with the inner annular wall and surrounds the inner annular wall. The groove is formed between the inner annular wall and the at least one outer annular wall. The structural designs of the inner annular wall, the at least one outer annular wall, and the groove are such that when the elastic element is applied to a hand tool, the groove provides a space that allows the inner annular wall to be deformed, making it easier for a user to fit a to-be-operated object securely in the hand tool to enhance work efficiency.
B25B 23/10 - Arrangements for handling screws or nuts for holding or positioning screw or nut prior to or during its rotation using mechanical gripping means
B25B 13/06 - SpannersWrenches with rigid jaws of socket type
A socket includes a body, a through hole, an accommodating base and an abutting element. The body includes an outer wall and an operating inner surface. The operating inner surface surrounds an operating space, and the operating space is configured for a tool to insert therein. The through hole penetrates the outer wall and the operating inner surface radially, and the through hole is communicated with the operating space. The accommodating base is accommodated in the through hole and includes a bottom portion and a surrounding wall. The bottom portion is located at an outer end of the through hole and covers the through hole. The surrounding wall is connected to the bottom portion and located in the through hole. The surrounding wall and the bottom portion surround an accommodating space. The abutting element is disposed in the accommodating space.
B25B 23/10 - Arrangements for handling screws or nuts for holding or positioning screw or nut prior to or during its rotation using mechanical gripping means
B25B 13/06 - SpannersWrenches with rigid jaws of socket type
A wrench sound seat lubrication structure includes: a seat member having an oil receiving space formed at a hollow internal thereof, a top end of the seat member having an opening formed thereon; one or a plurality of through holes formed to penetrate through a side wall of the seat member and fluidly connected to the oil receiving space; an actuating member pivotally attached to the opening on the top end of the seat member. The user is able to store a lubricant oil inside the oil accommodating space in advance. During use, the lubricant oil is slowly released from the through holes and the top opening, allowing the outer side of the seat member to be lubricated for a long period of time, thereby prolonging its useful lifetime.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
F16N 1/00 - Constructional modifications of parts of machines or apparatus for the purpose of lubrication
F16N 7/02 - Arrangements for supplying oil or unspecified lubricant from a stationary reservoir or the equivalent in or on the machine or member to be lubricated with gravity feed or drip lubrication
A socket includes a main body. The main body includes an output surface, an outer annular wall, and a resistance structure. The output surface is located at one end of the main body, surrounds an opening of the main body, and is perpendicular to a driving axis of the socket. The outer annular wall is connected with the output surface and includes an operating portion. The resistance structure is located on, and extends annularly along, the output surface. When an operator tries to remove the socket from a hand tool, the socket provides increased friction between the operator's hand and the output surface and therefore can be securely gripped.
An anti-vibration ratchet wrench includes a main body, a ratchet member and an elastic member. The main body includes a driving portion. The driving portion has a through hole and a driving axis. The ratchet member is sleeved in the through hole of the driving portion, and includes a ratchet tooth portion and an outer groove. The ratchet tooth portion is disposed around an inner annular surface of the ratchet member. The outer groove is disposed around an outer annular surface of the ratchet member. The elastic member is disposed in the outer groove, and located between the ratchet member and the driving portion. The ratchet member has a height along a direction parallel to the driving axis, and a disposed position of the outer groove is located between one third to two third of the height.
A wrench with a movable mallet platform is proposed. The wrench with a movable mallet platform includes a wrench main body and a mallet platform. The wrench main body includes a shaft. The shaft includes at least one abutment surface. The mallet platform is slidably sleeved on the wrench main body, and includes at least one striking portion and two holding portions. An engagement surface extends toward the shaft from at least one striking portion, and the engagement surface abuts against the at least one abutment surface. The two holding portions are disposed opposite to each other, and each of the two holding portions is connected to the at least one striking portion. Thus, the wrench with a movable mallet platform of the present disclosure can be struck by a striking tool, thereby fastening or releasing a fastening member.
A hand tool includes a handle, at least one driving head, at least one groove and at least one abutting element. The at least one driving head is connected with at least one end of the handle. The at least one groove is disposed on an inner edge of the at least one driving head, and includes an inner wall and at least one margin structure. The at least one margin structure extends from an end of the inner wall, and an angle is between the at least one margin structure and the inner wall. The at least one abutting element is disposed on the at least one groove.
B25B 23/10 - Arrangements for handling screws or nuts for holding or positioning screw or nut prior to or during its rotation using mechanical gripping means
B25B 13/08 - SpannersWrenches with rigid jaws of open jaw type
A sleeve structure includes a sleeve body, a tooth structure, a stopping structure, an elastic component and a resisting component. The sleeve body includes an opening hole. The tooth structure is disposed around an inner wall of the sleeve body, and includes a first groove and a second groove. The first groove and the second groove are disposed around the tooth structure, and the first groove is closer to the opening hole than the second groove. The stopping structure is disposed around the inner wall of the sleeve body, and the stopping structure is farther from the opening hole than the tooth structure. The stopping structure includes a through hole and an inner surrounding wall. The elastic component is disposed in the first groove and slightly protruded from the first groove. The resisting component is disposed in the second groove.
B25B 13/06 - SpannersWrenches with rigid jaws of socket type
B25B 23/00 - Details of, or accessories for, spanners, wrenches, screwdrivers
B25B 23/10 - Arrangements for handling screws or nuts for holding or positioning screw or nut prior to or during its rotation using mechanical gripping means
A threaded fastener capable of torque detection includes: a head and a shank connected together, wherein the shank has a threaded peripheral surface; a neck formed at the junction between one end of the shank and the head; and at least one sensing element and a sealing element, both provided on the neck, wherein the sensing element is configured to detect deformation of the neck, and the sealing element seals the sensing element. The threaded fastener may further include a covering element that covers the sealing element. The threaded fastener can be deformed consistently, allowing the sensing element to obtain relatively accurate detection values.
F16B 31/02 - Screwed connections specially modified in view of tensile loadBreak-bolts for indicating or limiting tensile load
G01L 5/24 - Apparatus for, or methods of, measuring force, work, mechanical power, or torque, specially adapted for specific purposes for determining value of torque or twisting moment for tightening a nut or other member which is similarly stressed
A structure for mounting a cover plate in a head portion of a wrench is disclosed. An end surface of the head portion is concavely provided with a receiving chamber. The head portion is also concavely provided with a recess at the opening of the receiving chamber. The cover plate is mounted in the recess to close the receiving chamber, and the cover plate is fixed in the recess by the peripheral wall of the recess itself. In other words, the cover plate is mounted in the head portion of the wrench without using any connecting element and is fixed by the head portion of the wrench itself. The cover plate, once fixed, is kept from coming off so that the components mounted in the receiving chamber of the head portion will not fall out.
A socket includes a socket body, a detent rod, and a pushing element. The socket body includes an opening, a teeth structure disposed on, and along the circumference of, the inner wall of the socket body, and an abutting structure farther away from the opening than is the teeth structure and including a first and a second through hole. The first through hole penetrates two sides of the abutting structure and is perpendicular to the axial direction of the socket body. The second through hole is at the center of the abutting structure and communicates with the first through hole. The detent rod is movably disposed through the first through hole and has a diminishing portion that tapers from two ends of the detent rod toward the center. The pushing element is movably disposed through the second through hole and has one end abutting against the diminishing portion.
A socket includes a socket body, a teeth structure, and a stopping structure and is engageable with a tool member. The socket body has an opening and an inner wall. The teeth structure is disposed on, and along the circumference of, the inner wall of the socket body and includes alternating inner teeth and concave portions. The stopping structure is disposed on, and along the circumference of, the inner wall of the socket body, is farther away from the opening than is the teeth structure, and includes a through hole and an inner surrounding wall. The through hole corresponds to the opening and is surrounded by the inner surrounding wall, which has a thickness. The distance from each concave portion to the hole wall surface of the through hole is defined as a stopping distance to be considered in relation to the thickness of the inner surrounding wall.
A C-clip includes a C-shaped clip body and two peripherally open holes. The clip body can be opened and closed elastically. The peripherally open holes are provided on two lateral sides of the clip body respectively and are adjacent to or located at the two ends of the clip body respectively. The peripherally open holes are provided in the clip body and each have a communication opening and a closed end. A wall between the communication opening and the closed end of each peripherally open hole forms a stop edge for preventing a tip of a retaining ring plier from moving out of the peripherally open hole. The outer diameter of the clip body can be changed by applying forces to the clip body via the peripherally open holes respectively. As the clip body does not have any particularly protruding portion, the C-clip can be used in various situations.
B25B 27/20 - Hand tools or bench devices, specially adapted for fitting together or separating parts or objects whether or not involving some deformation, not otherwise provided for for assembling objects other than by press fit or detaching same inserting or withdrawing split pins or circlips
F16B 21/18 - Means without screw-thread for preventing relative axial movement of a pin, spigot, shaft, or the like and a member surrounding itStud-and-socket releasable fastenings without screw-thread by separate parts with grooves or notches in the pin or shaft with circlips or like resilient retaining devicesMeans without screw-thread for preventing relative axial movement of a pin, spigot, shaft, or the like and a member surrounding itStud-and-socket releasable fastenings without screw-thread by separate parts with grooves or notches in the pin or shaft Details
F16L 21/08 - Joints with sleeve or socket with additional locking means
An anti-rolling socket includes a socket body, a groove, a through hole, and a stopper. The socket body has an inner peripheral surface and an outer peripheral surface. The groove is disposed in, and along the circumference of, the inner peripheral surface. The through hole is disposed between the inner peripheral surface and the outer peripheral surface and communicates with the groove. The stopper includes a stop ring and a stop section. The stop ring is fitted in the groove. The stop section is connected to the stop ring. The stop section projects from the through hole and protrudes from the outer peripheral surface. The stop section can abut against a flat surface to prevent the socket body from rolling on the flat surface.
A hand tool includes a first driving element, a second driving element and at least one connecting element. The first driving element includes a first driving portion and a first staggered portion. The first driving portion is connected to the first staggered portion integrally. The second driving element does not contact the first driving element and includes a second driving portion and a second staggered portion. The second driving portion is connected to the second staggered portion integrally. The connecting element connects the first staggered portion and the second staggered portion, wherein the connecting element is made of insulating material.
A socket structure includes a body, a first fitting hole, a second fitting hole, and at least one elastic engaging member. The first fitting hole is disposed at one end of the body. The second fitting hole is disposed at another end of the body. The at least one elastic engaging member is disposed in the first fitting hole and protrudes toward an inner portion of the first fitting hole along a radial direction of the first fitting hole. When a tool is inserted into the first fitting hole, the at least one elastic engaging member is pressed and deformed by the tool and is thus engaged with the tool. The configuration of the at least one elastic engaging member makes it easier to connect a tool to and remove the tool from the socket structure.
The present invention provides a cover plate structure of ratchet wrench comprising: a main body, inside a head portion thereof has an accommodating space, a peripheral wall is formed in the accommodating space, and the accommodating space is formed with at least one opening; a ratchet mechanism provided in the accommodating space; a cover plate having a cover portion and a snap-abut portion, the cover plate is placed in the opening of the accommodating space, and the snap-abut portion is stuck against the peripheral wall of the accommodating space. an elastic fastener member is disposed between the head portion and the cover plate, the fastener member applies an elastic force to the cover plate, so that the snap-abut portion of the cover plate elastically snaps against the peripheral wall of the accommodating space. The cover plate is capable of bearing the load during operation, increasing the withstand strength of the head portion.
An alerting structure of an electronic torque tool includes a tool body and an electronic module. The electronic module includes a sensing unit, a processing unit, and at least one display unit. The sensing unit senses an operational value of the tool body. The processing unit sends the operational value sensed by the sensing unit to the display unit. The display unit has at least one display block. When the operational value sensed by the sensing unit reaches a predetermined value, the processing unit generates a rotation signal in order for the contents displayed by the display block of the display unit to rotate back and forth through a predetermined angle and thereby produce a conspicuous alerting effect.
B25B 23/14 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
A wrench structure with a variable driving state includes a rod and a sleeve connected to the rod. An outer surface of the rod includes an accommodating slot, an engaging block, an elastic element, and a connecting portion. The engaging block and the elastic element are disposed in the accommodating slot. The connecting portion is adjacent to the accommodating slot and surrounds the outer surface of the rod. The sleeve includes a first ratchet portion, a second ratchet portion, and a non-ratchet portion located between the two ratchet portions. The sleeve can be selectively displaced relative to the rod to a first position, where the connecting portion is connected with the second ratchet portion, or a second position, where the connecting portion is adjacent to the non-ratchet portion. By controlling the relative positions of the rod and the sleeve, the driving state of the wrench structure can be switched.
A socket wrench with a reversible structure includes a rod, a sleeve, a first ratchet block and a second ratchet block. The rod has a columnar surface, and includes a first slot and a second slot. The first slot and the second slot are disposed on different positions along an axis direction of the rod. The sleeve is slidably sleeved on the rod, and includes an accommodating end and a driving end. The accommodating end includes a toothed segment which is protruded radially inward from an inner wall of the accommodating end. The first ratchet block is movably disposed in the first slot and includes a first ratchet portion. The second ratchet block is movably disposed in the second slot and includes a second ratchet portion. The toothed segment of the sleeve is selectively engaged with one of the first ratchet block and the second ratchet block.
A telescopic socket includes an outer sleeve, an inner sleeve, and a jointing ring. The outer sleeve includes at least one abutting ball, plural first concave portions, and plural first protruding portions. The inner sleeve is sleeved by and slidably connected to the outer sleeve and includes at least two engaging holes, plural second concave portions, and plural second protruding portions. The second protruding portions are slidably connected to the first concave portions respectively, and the first protruding portions are slidably connected to the second concave portions respectively. The jointing ring is movably connected to the outer sleeve and includes an abutting part and an accommodating part, and the abutting part optionally abuts against the abutting ball. By controlling the jointing ring, the inner sleeve can be slid or positioned relative to the outer sleeve, and the length of the telescopic socket can be changed.
A pushing lever structure of a ratchet wrench is provided. The ratchet wrench has a head portion. A ratchet gear, a toothed element, and a pushing lever are mounted in a receiving space of the head portion. A rear peripheral surface portion of the toothed element is provided with a recess. A pushing block extending forward from the pushing lever extends into the recess of the toothed element. When rotated, the pushing lever can move the toothed element effectively because it is the pushing block of the pushing lever that drives the toothed element into displacement. The bottom side of the head portion is mounted with a cover plate, and the bottom end of the pushing lever is pivotally provided on the cover plate to enhance the rotation stability of the pushing lever.
A dustproof structure of a hand tool includes a tool body and a dustproof element. The tool body has a shank. A predetermined portion of the shank is concavely provided with a through hole. The dustproof element is flexible, is provided at the through hole of the shank, and can be opened and closed. The dustproof element closes the through hole when not subjected to an applied force and is elastically deformed to render the through hole into an open state when subjected to the applied force. In normal conditions, therefore, the dustproof element can block foreign matter from entering the through hole. When it is desired to perform a lubricating or adjusting operation on a component in the through hole of the hand tool, the operation can be carried out after directly applying a force to, and thus deforming, the dustproof portion, without having the dustproof element removed.
B25B 13/46 - SpannersWrenches of the ratchet type, for providing a free return stroke of the handle
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
A magnetically assisted direction-changeable roller wrench has a main body, a driving member, a direction changing knob, plural rollers, a magnetic balancing member, and a magnetic positioning unit. The driving member, the rollers, and the direction changing knob are mounted in a head portion of the main body. The magnetic positioning unit includes a first and a second magnetic member located respectively on the driving member and the direction changing knob. The corresponding surfaces of the first and the second magnetic members have the same magnetic polarity, so a predetermined distance can be maintained between the first and the second magnetic members to secure the direction changing knob in position. The direction changing knob can displace each roller into contact with an engaging surface of the corresponding side of the driving member. The magnetic balancing member and the magnetic positioning unit lie in opposite directions to enable balanced magnetic attraction.
A ratchet wrench allowing easy change of rotation direction includes a main body, a ratchet gear, a pawl, a sideways pushing member, and a direction changing device. The main body has a shaft connected with a head portion. The head portion has a receiving chamber housing the ratchet gear, the pawl, and the sideways pushing member and connected to a channel in the shaft. The direction changing device has a rotating rod in the channel, a sideways pushing button for rotating the rotating rod, an engaging member at the rear end of the sideways pushing member, and an engaging groove at the front end of the rotating rod and engaged with the engaging member, which is axially offset from the rotating rod. The rotating rod can rotate the sideways pushing member and thereby displace the pawl so that a different portion of the pawl meshes with the ratchet gear.
A prying head is provided in the present disclosure. The prying head, which is used in cooperation with a hand tool, includes a prying portion, a supporting portion and an assembling portion. The prying portion includes a ground-abutting surface and an article-abutting surface. The article-abutting surface is connected to the ground-abutting surface to form a sharp edge. The supporting portion is connected to the prying portion and includes a curved surface. The curved surface is connected to the ground-abutting surface and the article-abutting surface, so as to make an end of the supporting portion away from the sharp edge into a curved form. The assembling portion is connected to the supporting portion and includes a blind hole. The blind hole is recessed from an end of the assembling portion away from the sharp edge.
The invention provides a torque wrench capable of maintaining accuracy of torque value, comprising a tube; and a rod, a trip mechanism, an elastic element, and an adjustment mechanism installed on the tube. The adjustment mechanism has a handle and a moving member, when the handle is rotated, the moving member can be driven to displace along a longitudinal direction of the tube, so as to change an elastic force exerted by the elastic element to the trip mechanism; an adjustment rod is threadedly connected into the moving member, rotating the adjustment rod is capable of displacing the adjustment rod relative to the moving member, so that a front end of the adjustment rod protrudes from the moving member and exerts pressure on the elastic element. Thereby, the torque wrench can be restored to a correct torque value by simply rotating the adjustment rod.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
B25B 23/14 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers
An electronic wrench includes a main body, at least one sensing element, a processor and at least one prompting unit. The sensing element is configured to sense a working status of a working head to generate a sensing signal, and the sensing signal includes at least one sensing information value. The processor includes a first prompt lower limit value and a second prompt lower limit value. The prompting unit is configured to provide at least one working status prompt. When the sensing information value is less than or equal to the first prompt lower limit value, the working status prompt is visible in a first numeric display format. When the sensing information value is greater than the first prompt lower limit value and less than or equal to the second prompt lower limit value, the working status prompt is visible in a second numeric display format.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
A roller wrench including a body with a circular chamber; a driving member with multiple sides capable of rotating in the chamber; a plurality of rollers installed in the chamber and located between a side of the driving member and a peripheral wall of the chamber; and a reversing knob capable of driving the rollers to move. Each of the sides of the driving member has a central area, a concave latching surface is respectively provided on two sides of the central area, and a concave state of each of the latching surfaces is gradually concaved inwardly from an inner side to an outer side. When each of the rollers is located on one edge of each of the sides, a peripheral surface of the roller contacts with the latching surface and the peripheral wall of the chamber; the body, rollers and driving member are latched with one another.
The invention relates to a roller wrench comprising: a body with a circular chamber; a driving member being a regular polygonal component capable of rotating in the chamber; and a plurality of rollers installed in the chamber, Each of the rollers is located between a side of the driving member and a peripheral wall of the chamber; one end of each of the rollers is pivotally connected to an end surface of a reversing knob, so that the reversing knob drives the rollers to displace simultaneously. Thereby, the components of the roller wrench can be effectively latched with one another, and a torque value of the roller wrench will not be reduced.
A roller wrench having a body with a circular chamber; a driving member being a regular polygonal component capable of rotating in the chamber; a plurality of rollers installed in the chamber, each of the rollers is located between a side of the driving member and a peripheral wall of the chamber; a reversing knob capable of driving the rollers to move in the chamber so that each of the rollers moves between two edges of each of sides of the driving member; and at least one elastic positioning component installed on one of the sides of the driving member, and capable of elastically moving into the driving member or protruding from a peripheral surface of the driving member. The elastic positioning component is moved into the driving member when being compressed; and is protruded from the driving member when not being acted on by an external force.
A battery holder structure is disposed on an electric wrench which includes a battery unit, and the battery holder structure includes a back cover assembly. The back cover assembly is assembled on an end of the electric wrench, and the back cover assembly includes a cover, a supporting member, a first elastic member and a second elastic member. The cover has an accommodating space. The supporting member is disposed in the accommodating space. The first elastic member is assembled on an end of the supporting member, an end of the first elastic member contacts with the cover, and another end of the first elastic member contacts with the supporting member. The second elastic member is assembled on another end of the supporting member, an end of the second elastic member contacts with the supporting member, and another end of the second elastic member contacts with the battery unit.
H01M 50/213 - Racks, modules or packs for multiple batteries or multiple cells characterised by their shape adapted for cells having curved cross-section, e.g. round or elliptic
B25F 5/02 - Construction of casings, bodies or handles
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
A display protecting device is disposed on an electric wrench which has an opening. The display protecting device includes a printed circuit board, a display, a cover and a protection member. The printed circuit board is disposed in the opening. The display is disposed on the printed circuit board. The cover is located above the printed circuit board and covers on the opening. The protection member is assembled with the cover. The protection member includes a body and two wing portions. The body covers on the display. The two wing portions are connected to two sides of the body and cover on two sides of the display.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
A toggler structure for a ratchet wrench includes an elongated toggler arranged between a locking member and a direction switch member of the ratchet wrench. The rear side of the toggler includes at least two connecting portions. At least two elastic elements are arranged between the connecting portions of the direction switch member and the toggler in order to provide an elastic force to push the toggler to abut against the locking member. The elongated toggler can be applied to a ratchet structure of a greater thickness in order to increase the structural strength and operational torque of the ratchet wrench. Furthermore, the elastic elements can provide a uniform elastic force in the length direction of the toggler, thereby allowing the locking member to engage with the ratchet structure properly.
The invention is a hand tool with an operating head, which comprises: a main body having two parallel ears spaced apart at a front end; and a working head having a body; a column connected to one side of the body; another side of the body is provided with a pivotal block and two flaps to pivotally connect the two ears of the main body between the pivotal block and the two flaps respectively. The two flaps are capable of assisting in supporting outer sides of the two ears to relatively strengthen a structure of the ear, thereby enhancing a torsion exerted by the column on a workpiece, and enhancing durability and strength of the column.
The invention is a hand tool for enhancing strength of a working head, which comprises: a main body with two parallel ears spaced apart at a front end; a working head with a pivotal portion pivotally connected between the ears of the main body; a column with one end connected to a periphery of the pivotal portion; and a strengthening portion extending from the periphery of the pivotal portion toward the column, and disposing at a junction of the pivotal portion and the column. An outer diameter of the strengthening portion is greater than an outer diameter of the column, the strengthening portion is capable of enhancing a strength of the column, relatively improving a torsion applied by the column to a workpiece, and enhancing durability and strength of the column.
The present invention relates to a three-piece wrench comprising: a wrench body with a working head and a shaft, the working head is located at a front end of the shaft, the shaft has a length; a first extension rod with a length; and a second extension rod with a length; the lengths of the first extension rod and the second extension rod are greater than the length of the shaft; combination of the wrench body, the first extension rod and the second extension rod provides various usage lengths of the wrench, so that different connection types can be used to form required lengths according to requirements.
A driving head structure of a socket wrench includes an assembling base and a joint portion. The assembling base includes a plurality of convex curved surfaces. The joint portion is disposed on the assembling base. The assembling base is cylinder-shaped, and the joint portion is cuboid-shaped. Each of the convex curved surfaces is contacted with each side of the joint portion.
The present invention provides an extendable wrench comprising: a wrench having a head portion and a shaft connected to a rear end of the head portion; an insertion hole recessed at a rear end of the shaft; a cover to dismountably close the insertion hole; an extension rod with a front end formed with a plug to be plug-connected with or separated from the insertion hole of the wrench; and an elastic positioning member provided between the plug of the extension rod and the insertion hole of the wrench, when the plug of the extension rod is plug-connected with the insertion hole, the elastic positioning member keeps the plug in position. Thereby, the wrench can be operated independently; when application of larger operating torque is required, the extension rod can be combined with a rear end of the wrench to form a longer operating arm of force to meet the requirements of large torque.
A high strength wrench includes a head portion, a shaft and a handle. A length of the shaft is multiple times of a length of the handle. At least one slot extends along a longitudinal direction of the shaft and is formed at a circumferential surface of the shaft. A cross section shape of the shaft has a structural profile of an outer side with a relatively greater thickness and an inner portion of a relatively smaller thickness. Accordingly, the shaft has a greater structural strength to allow the wrench to bear operations of high torque.
An electronic torque wrench with double display screens includes a main body having a shank. A front end of the shank has a working head. The shank is defined with a central vertical face in the longitudinal direction. The electronic torque wrench further includes a display unit having two display screens. The two display screens are respectively disposed on two sides of the central vertical face. The two display screens are disposed by an inclination and directed upward and outward, whereby a user can easily observe the torque value displayed on the display screens.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
An inertial rotation device includes: a central member with an axial direction, a first engaging portion on the peripheral surface of the central member, an inertia member with a mounting hole, and a second engaging portion on the wall of the mounting hole. The inertia member is mounted around the central member and can be displaced between an engaging position and a released position along the axial direction of the central member. The inertia member can rotate together with the central member when at the engaging position, where the two engaging portions are engaged with each other, and cannot rotate together with the central member when at the released position, where the two engaging portions are disengaged from each other. The magnitude of the torque of the inertial rotation device can be changed by switching the inertia member to the engaging position or the released position.
A bendable torque wrench includes: a shank; a tubular body whose front end is angularly displaceable with respect to the shank about an axis defined by a first pivotal connection end of the shank; an abutting block located on one side of the tubular body, a the front end of the abutting block has a convexly curved abutting surface; and a detent member whose front end is pivotally connected to a second pivotal connection end of the shank and whose rear end forms a convexly curved contact surface in elastic contact with the curved abutting surface of the abutting block. The torque wrench bends, or collapses, rapidly when the torque applied to the torque wrench reaches a preset torque value.
B25B 23/00 - Details of, or accessories for, spanners, wrenches, screwdrivers
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
A vibrating wrench includes a housing, a driving head, a handle and a vibrating structure. The housing includes a hollow space. The driving head is disposed at one end of the housing. The handle is disposed at the other end of the housing and includes an inner wall and a containing space. The containing space is communicated with the hollow space. The vibrating structure is disposed in the containing space of the handle and includes a vibrating motor and a medium element. The medium element is fully connected or partially connected to an outer surface of the vibrating motor. The inner wall of the handle is fully connected or partially connected to the medium element.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
A rotary fastening device includes a rotating axial member and an inertia member. The rotating axial member includes a base body, an input end, an output end and an engaging portion. The input end is disposed at one end of the base body and selectively connected to a wrench. The output end is disposed at the other end of the base body. The engaging portion is disposed on the base body. The inertia member is detachably connected to the rotating axial member, and includes a gravity portion and an engaging hole. The gravity portion is extended toward the output end of the rotating axial member so as to form an annular space. The engaging hole is communicated to the annular space.
A torque tool with a segmented warning effect includes: a tool body having a sensing unit, a processing unit for receiving a sensed value of the sensing unit and comparing the sensed value with a predetermined value to output a comparison value; at least two warning intervals formed by the comparison value of at least two different warning ranges; a warning assembly for providing warning by a primary warning unit and at least one secondary warning unit; the primary warning unit uses at least two colors for different warning intervals, and at least two illuminators of each secondary warning unit to warn at least two stages, the primary warning unit provides a primary warning for the warning interval, and the secondary warning unit at each warning interval forms secondary warnings to let users know about the operating torque quickly.
B25B 23/00 - Details of, or accessories for, spanners, wrenches, screwdrivers
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
A setting method for an electronic torque tool is disclosed. The electronic torque tool includes a tool body that stores at least one operation set. The operation set includes at least one adjustable operation parameter of the electronic torque tool. The setting method can be used to adjust the operation parameter in the operation set and includes a setting step and a storing step. The setting step includes entering the operation set and adjusting the operation parameter therein. The storing step includes storing the adjusted operation parameter in the operation set directly after an operator quits the operation set or turns off the electronic torque tool during the setting step. The setting method allows the operation parameter in the operation set to be easily and rapidly set or adjusted, thereby making the electronic torque tool easy to use and operate.
B25B 23/00 - Details of, or accessories for, spanners, wrenches, screwdrivers
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
A tubular body for an electronic torque wrench is integrally formed and includes a small diameter portion, a bridge portion, and a large diameter portion connected along the longitudinal direction of the tubular body. The bridge portion has a small diameter end connected to the rear end of the small diameter portion and an opposite large diameter end connected to the front end of the large diameter portion. As there is no gap at the junction between the large diameter portion and the small diameter portion, the tubular body is dustproof, has a lower production cost and higher structural strength, and makes an electronic torque wrench a better appearance.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
B25G 1/10 - Handle constructions characterised by material or shape
B25B 23/00 - Details of, or accessories for, spanners, wrenches, screwdrivers
81.
ELECTRONIC WRENCH AND PROMPTING METHOD OF ELECTRONIC WRENCH
An electronic wrench includes a base body, at least one sensing element, a processor and at least one prompting unit. The base body includes a working head, and the sensing element is disposed at the base body to detect a working status of the working head so as to provide a sensing signal. The sensing signal includes at least one sensing value. The processor is electrically connected to the sensing element, and the processor includes at least one prompting lower limit value. The prompting unit is electrically connected to the processor and provides a working status prompt. When the sensing value is less than the prompting lower limit value or the sensing value is equal to the prompting lower limit value, the working status prompt is a first nonnumeric prompt.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
82.
Jointing structure more tightly engaged with a forcing tool through abutting members
A jointing structure includes a jointing member and at least two abutting members. The at least two abutting members are disposed on the jointing member. The jointing member includes a surface and a plurality of side surfaces surrounding the surface, and the at least two abutting members are disposed on at least two of the side surfaces respectively.
B25B 23/14 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers
B25B 23/00 - Details of, or accessories for, spanners, wrenches, screwdrivers
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
G01L 3/04 - Rotary-transmission dynamometers wherein the torque-transmitting element comprises a torsionally-flexible shaft
F16D 7/04 - Slip couplings, e.g. slipping on overload, for absorbing shock of the ratchet type
83.
Torque tool for identifying locking state of torque adjustment mechanism
A torque tool for identifying locking state of torque adjustment mechanism includes: a tubular body; a tool head having a stem body fitted in the tubular body, a torque adjustment mechanism being used to adjust the torque of the torque tool, a handle with at least one display window being fitted around the tubular body; a locking mechanism for selectively locking the torque adjustment mechanism; a push unit positioned behind the locking mechanism; and a first identification area and a second identification area respectively formed on the locking mechanism and the push unit. When the locking mechanism is not pushed by the push unit, the first identification area is displayed through the display window. When the push unit pushes the locking mechanism to lock the torque adjustment mechanism, it is impossible to adjust the torque of the torque tool and the second identification area is displayed through the display window.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
B25B 23/00 - Details of, or accessories for, spanners, wrenches, screwdrivers
A torque wrench with torque adjustment mechanism includes a tubular body and a torque adjustment mechanism disposed in the tubular body. The torque adjustment mechanism includes an abutting member, an adjustment member and an adjustment button. The abutting member has a first slope disposed at rear end of the abutting member in contact with a second slope disposed at a front end of the adjustment member. When adjusting the set torque value of the torque wrench, the adjustment button is rotated to drive the adjustment member to displace in a transverse direction of the tubular body. By means of the cooperation between the first and second slopes, the abutting member is displaced in a longitudinal direction of the tubular body to compress or release an elastic member positioned in front of the abutting member.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
A torque wrench with elastic member includes a tubular body in which an elastic member is disposed for adjusting the torque value of the torque wrench. The elastic member is in the form of a plate body having a front connection section, a rear connection section and at least one bent section positioned between the front and rear connection sections. The front and rear connection sections of the elastic member respectively abut against a click mechanism disposed in front of the elastic member and an adjustment mechanism disposed behind the elastic member, whereby the elastic member can be compressed or released to adjust the torque value of the torque wrench. The elastic member has a novel structure and can ensure the stability of the torque wrench in use and enhance the utility of the torque wrench.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
A detachable fastening device includes a socket, a hollow disk and a positioning mechanism. The socket includes an external mounted base and at least one first depression located at the external mounted base. The hollow disk is detachably connected to the socket and includes an inner engaged wall coordinated with the external mounted base and at least one second depression located at the inner engaged wall. The positioning mechanism is received between the at least one first depression and the at least one second depression to position the socket and the hollow disk.
B25B 23/00 - Details of, or accessories for, spanners, wrenches, screwdrivers
F16B 21/16 - Means without screw-thread for preventing relative axial movement of a pin, spigot, shaft, or the like and a member surrounding itStud-and-socket releasable fastenings without screw-thread by separate parts with grooves or notches in the pin or shaft
B25B 13/06 - SpannersWrenches with rigid jaws of socket type
F16B 23/00 - Specially-shaped heads of bolts or screws for rotations by a tool
A one-way inertial rotational device includes: a rotary seat; an inertial member pivotally rotatably disposed on the circumference of the rotary seat via a pivot hole, a circumference of the rotary seat and a hole wall of the pivot hole of the inertial member being defined as a first circumferential face and a second circumferential face; and a one-way transmission mechanism having at least one one-way transmission tooth, at least one elastic member and multiple engagement teeth. The engagement teeth are annularly disposed on the second circumferential face. The transmission tooth is displaceably disposed on the first circumferential face. The elastic member keeps the transmission tooth engaged with the engagement teeth. Each engagement tooth has a tooth crest and a tooth height. The width of the tooth crest is larger than the tooth height so that the loss of the rotational energy is reduced to achieve greater rotational torque.
F16D 41/12 - Freewheels or freewheel clutches with hinged pawl co-operating with teeth, cogs, or the like
B25B 23/00 - Details of, or accessories for, spanners, wrenches, screwdrivers
B25B 23/14 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers
B25B 13/06 - SpannersWrenches with rigid jaws of socket type
B25B 21/02 - Portable power-driven screw or nut setting or loosening toolsAttachments for drilling apparatus serving the same purpose with means for imparting impact to screwdriver blade or nut socket
B25B 23/145 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for fluid operated wrenches or screwdrivers
F16D 41/18 - Freewheels or freewheel clutches with non-hinged detent
88.
Folding torque wrench with fast adjustable torque value
A folding torque wrench includes a bar body, a connection rod the front end of which is pivotally connected with the bar body, a tubular body fitted on the connection rod and a torque adjustment mechanism having at least one elastic member and an adjustment member. A threaded section of rear end of the connection rod is screwed in a threaded hole of the adjustment member. The threaded section of the connection rod and the threaded hole of the adjustment member are formed as a first threaded section and a second threaded section. The first threaded section is at least double-start threads. When rotating the adjustment member by one circle, the adjustment member is moved in the longitudinal direction of the connection rod by a travel, which is over two time the pitch of the first threaded section. The torque value of the wrench can be quickly greatly adjusted only by means of rotating the adjustment member by few circles.
B25B 13/46 - SpannersWrenches of the ratchet type, for providing a free return stroke of the handle
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
B25B 23/00 - Details of, or accessories for, spanners, wrenches, screwdrivers
A hand tool includes a handle, a press member, a shank body and multiple latch assemblies. The handle is formed with a receiving cavity and a locating hole in communication with the receiving cavity. The press member is movably disposed in the locating hole. The shank body is fitted in the receiving cavity and movable relative to the handle. The shank body is formed with multiple sockets. The latch assemblies are respectively mounted in the sockets. When the shank body is moved, (for example, slid or rotated) relative to the handle to make one of the sockets aligned with the locating hole, the latch assembly latches the shank body with the handle. When pressing the press member, the latch assembly unlatches the shank body from the handle, the shank body is movable relative to the handle.
An inertial rotational tightening device includes: a rotationally drivable main body, an annular engagement section being disposed on a circumference of the main body; an inertial member having an engagement hole axially formed through the inertial member, the engagement hole of the inertial member being detachably engaged with the engagement section of the main body, a retaining groove being formed on a circumference of the engagement section or a hole wall of the engagement hole, an insertion groove being formed on the hole wall of the engagement hole or the circumference of the engagement section; and an elastic retainer member inlaid and buckled in the retaining groove and the insertion groove. The inertial member is detachably connected with the main body. Different inertial members with different mass can be selectively mounted on the main body to change the moment of inertia and the rotational torque of the rotational tightening device.
B25B 21/00 - Portable power-driven screw or nut setting or loosening toolsAttachments for drilling apparatus serving the same purpose
B25B 23/00 - Details of, or accessories for, spanners, wrenches, screwdrivers
B25B 21/02 - Portable power-driven screw or nut setting or loosening toolsAttachments for drilling apparatus serving the same purpose with means for imparting impact to screwdriver blade or nut socket
B25B 13/06 - SpannersWrenches with rigid jaws of socket type
B25B 23/14 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers
B25B 23/145 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for fluid operated wrenches or screwdrivers
An electronic torque wrench with sensing structure includes a tubular body, a working head and at least one sensing element. The working head includes a head section and a connection section secured in the front end of the tubular body. The head section is positioned at the front end of the tubular body. The sensing element is disposed on an outer circumference of the tubular body. Accordingly, the length of the connection section of the working head is greatly shortened and the internal structure of the tubular body is simplified to lower the material cost and manufacturing cost. In addition, the weight of the torque wrench is reduced and the sensing precision of the sensing element is enhanced, whereby a user can more easily hold the torque wrench and more smoothly use the torque wrench to enhance the whole benefit of the torque wrench.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
B25B 13/46 - SpannersWrenches of the ratchet type, for providing a free return stroke of the handle
A torque socket is provided. The torque socket includes a release mechanism that can be released when a torque thereof reaches a pre-determined value. The torque socket also includes a transmission module. The transmission module includes transmission members and a transmission shaft that are coupled with the release mechanism. The transmission members are cooperated with the release mechanism to determine the transmission shaft transfer torque or not to automatically release the torque.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
B25B 17/02 - Hand-driven gear-operated wrenches or screwdrivers providing for torque amplification
B25B 23/14 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers
A rotatable fastening device includes a rotatable base and an impact member. The rotatable base rotates along a pivoting axis, and the rotatable base is removably connected with and driving a rotatable member. The impact member is removably connected to an outside of the rotatable base, and the impact member has at least one gravity unit projected outwardly therefrom. The gravity unit is driven by the rotatable base to rotate around the pivoting axis for generating a tangent impact force.
B25B 21/02 - Portable power-driven screw or nut setting or loosening toolsAttachments for drilling apparatus serving the same purpose with means for imparting impact to screwdriver blade or nut socket
B25B 13/06 - SpannersWrenches with rigid jaws of socket type
B25B 23/147 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for electrically operated wrenches or screwdrivers
94.
Rotatable fastening device and application method thereof
A rotatable fastening device disclosed in the present disclosure includes a rotating seat and an impact element. The impact element is one-way pivoted at the rotating seat. The rotating seat is rotated along a rotation axis and detachably connected between a driving tool and an element to be rotated. The weight and kinetic energy of the impact element will provide a one-way tangential impact force around the rotation axis with of rotation.
B25B 21/02 - Portable power-driven screw or nut setting or loosening toolsAttachments for drilling apparatus serving the same purpose with means for imparting impact to screwdriver blade or nut socket
B25B 23/147 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for electrically operated wrenches or screwdrivers
B25B 13/06 - SpannersWrenches with rigid jaws of socket type
A wrench with quickly angularly adjustable handle includes a head section and a handle. The head section and the handle are pivotally connected with each other via a first and a second pivoted ends, whereby the handle can be up and down swung relative to the head section. The first and second pivoted ends respectively have a first and a second end faces facing each other. The first end face is formed with an upper and a lower contact sections. The second end face is formed with an upper and a lower abutment sections. The lower abutment section abuts against the lower contact section as a lower dead end of angular displacement of the handle. The upper abutment section abuts against the upper contact section as an upper dead end of angular displacement of the handle.
A lock threaded assembly includes a bolt including a shank formed with a bolt head and having a threaded portion; at least one groove formed on the threaded portion; a nut including a threaded hole configured to secure to the threaded portion of the bolt; at least one trough formed on the threaded hole; and at least one engagement member being an elongated elastic strip body having a securing section and a received section, the securing section and the received section being able to elastically get closer to each other or move away from each other. When the groove is not aligned with the trough, the bolt and the nut are not locked by the engagement member; when the groove is aligned with the trough, the bolt and the nut are elastically locked by the engagement member.
F16B 39/06 - Locking of screws, bolts, or nuts in which the locking takes place after screwing down with a member penetrating the screw-threaded surface of at least one part, e.g. a pin, wedge, cotter-pin, screw with a pin or staple parallel to the bolt axis
F16B 5/02 - Joining sheets or plates to one another or to strips or bars parallel to them by means of fastening members using screw-thread
An impact spinning hand tool includes a hollow body, a first lever and a first elastic member. The hollow body includes a first position-limiting structure. The first lever includes a driving end exposed outside the hollow body, a spinning structure and a forcing end contained in the hollow body. The forcing end has a second position-limiting structure that is detachably limited by the first position-limiting structure. The first elastic member is pushed against the forcing end and the first position-limiting structure through two ends thereof. The first lever is located at a first position and presses the first elastic member to store an elastic restoring force when being connected with the hollow body. When the second position-limiting structure is released, the elastic restoring force drives the first lever to move to a second position so as to allow the spinning structure to perform an impact spinning action.
A wrench with multiple display windows includes a body, two side display window lighting modules and a main display window lighting module. The two side display window lighting modules are illuminated synchronously with each other. The two side display window lighting modules are corresponding to each other. The two side display window lighting modules, are illuminated toward a first optical axis and a second optical axis. The side display window lighting module includes side display window lighting elements configured to generate side display window colors which are turned on or turned off according to the torque. The main display window lighting module is connected to the body and illuminated toward the first optical axis. The main display window lighting module includes main display window lighting elements configured to generate main display window colors which are turned on or turned off according to the torque.
B25B 23/142 - Arrangement of torque limiters or torque indicators in wrenches or screwdrivers specially adapted for hand operated wrenches or screwdrivers
