Abstract

A trigger device for a bolt action firearm is described. The trigger device includes a housing, including a trigger, a safety coupled to the housing; and a bolt-lock plate. A coupling removably couples the bolt-lock plate to the housing. When the bolt-lock plate is coupled to the housing it is moveable between a locked position and an unlocked position. A spring couplable between the safety and the bolt-lock plate biases the bolt-lock plate in the locked position.

IPC Classes  ?

• F41A 19/30 - Mechanical firing mechanisms having only slidably-mounted striker elements, i.e. percussion or firing pins the percussion or firing pin being movable relative to the breech-block propelled by a spring under tension in bolt-action guns
• F41A 17/46 - Trigger safeties, i.e. means for preventing trigger movement

Abstract

A trigger device is described comprising a string hook, a trigger, a sear, and a flexible latch. The string hook is configured to retain a bowstring. The sear is coupled to the trigger and configured to release the string hook in response to actuation of the trigger. A flexible latch is coupled between the string hook and the sear. The flexible latch has a flexure design configured to flex in response to a holding weight applied by the bowstring, wherein flexure of the flexible latch reduces a pull weight of the trigger.

IPC Classes  ?

• F41B 5/14 - Details of bowsAccessories for arc shooting
• F41B 5/12 - Crossbows

Abstract

An archery release aid is described. A trigger device for the archery release aid comprises a trigger pivotally mounted on a trigger pivot pin, the trigger movable between a cocked position and a fired position. A sear is pivotally mounted on a sear pivot pin and configured to interface with the trigger. A cocking spring is configured to bias the sear and the trigger in the cocked position. A string hook is pivotally mounted on a pivot pin. A reset spring is configured to bias the string hook in the cocked position. A roller is configured to rotate about its axis. In the cocked position the roller is retained between the sear and the string hook and in the fired position, the sear is rotated away from the roller, which allows the roller to translate and the string hook to release.

IPC Classes  ?

• F41B 5/14 - Details of bowsAccessories for arc shooting

Abstract

A trigger insert for a striker fired firearm is described. The trigger insert comprises an articulated sear, a sear spring, and a trip bar. The articulated sear is coupled to the trigger insert and configured to engage a firing pin of the firearm. The sear spring is configured to bias the articulated sear in a position to hold the firing pin. The trip bar is coupled to the articulated sear and comprises a lip extending away from and transverse to the trigger insert. When a force is applied to the lip of the trip bar, it is translated to the articulated sear, which is configured to release the firing pin. A trigger module and a backing plate module are also described. A trigger assembly comprising the trigger insert, the backing plate module, and a transfer bar are also described.

IPC Classes  ?

• F41A 19/29 - Mechanical firing mechanisms having only slidably-mounted striker elements, i.e. percussion or firing pins the percussion or firing pin being movable relative to the breech-block propelled by a spring under tension
• F41A 17/72 - Firing-pin safeties, i.e. means for preventing movement of slidably-mounted strikers trigger-operated, i.e. the movement of the trigger bringing a firing-pin safety into inoperative position during the firing
• F41A 19/31 - Sear arrangements therefor

Abstract

A disc brake rotor adaptor for bicycle hub is described. The adaptor includes an adaptor ring and a collet ring. The adaptor ring includes a plurality of holes extending through the adaptor ring, the holes configured to align with corresponding holes in a disc brake rotor. A first face shaped to interface with the disc brake rotor. A plurality of teeth are positioned on the inner circumferential surface of the adaptor ring proximal the first face. A second face includes an inner circumferential recess. The collet ring includes a body and a plurality of posts extending there from. The posts are configured to align with the holes extending through the adaptor ring. The collet ring is shaped to nest within the inner circumferential recess of the second face of the adaptor ring.

IPC Classes  ?

• B62L 1/00 - BrakesArrangements thereof
• F16D 65/12 - DiscsDrums for disc brakes

Abstract

A de-cocking mechanism for a trigger device is described. The de-cocking mechanism comprises an articulated latch and a bi-stable camming detent mechanism. The articulated latch comprises a string hook and a latch arm. The bi-stable camming detent mechanism is movable between a ready position and a primed position. When the bi-stable camming detent mechanism is in the ready position, a first cocking motion applied to the string hook engages the articulated latch and the latch arm moves the bi-stable camming detent mechanism to the primed position. When the bi-stable camming detent mechanism is in the primed position, a second cocking motion applied to the string hook causes the bi-stable camming detent mechanism to disengage the articulated latch and return to the ready position.

IPC Classes  ?

• F41B 5/14 - Details of bowsAccessories for arc shooting
• F41B 5/12 - Crossbows

Abstract

A trigger device for activating a firing mechanism is described. The trigger device comprises a housing, a sear, and a trigger. The sear is pivotally mounted on the housing via a sear pivot pin. The trigger is pivotally mounted on the housing via a trigger pivot pin. The trigger comprises a trigger extender. The trigger extender inhibits unloading the sear until the trigger is rotated from a ready position.

IPC Classes  ?

• F41A 19/16 - Adjustable firing mechanismsTrigger mechanisms with adjustable trigger pull
• F41A 19/10 - TriggersTrigger mountings
• F41A 19/12 - SearsSear mountings

Abstract

A trigger device is disclosed. The trigger device comprises a housing, a trigger, a reverser, and a first pull weight adjustment mechanism. The trigger is rotatably mounted in the housing via a trigger pivot pin. The trigger comprises a trigger tooth. The reverser is rotatably mounted in the housing via a reverser pivot pin. The reverser comprises a reverser tooth. The first pull weight adjustment mechanism is coupled between the trigger and the reverser to bias the trigger in a first direction and the reverser in an opposite direction. Actuation of the trigger causes the trigger to rotate in the opposite direction, the trigger tooth to engage the reverser tooth, and the reverser to rotate in the first direction.

IPC Classes  ?

• F41A 19/16 - Adjustable firing mechanismsTrigger mechanisms with adjustable trigger pull
• F41A 19/10 - TriggersTrigger mountings
• F41A 19/12 - SearsSear mountings

Abstract

A safety selector comprises a first hub portion, a second hub portion, and a cam portion connecting the first hub portion with the second hub portion. The first hub portion is generally cylindrical in shape, having opposing faces and an longitudinal surface extending therebetween. Further, the first hub portion is segmented in it opposing faces, creating a first plane in the longitudinal surface. The first hub portion further comprises a pair of spaced apart detent sockets in the longitudinal surface face, a connecting groove extending between the detent sockets, and a detent notch in an outer one of the circular faces exposing one of the detent sockets. The cam portion comprises a recessed face and a cam face. The first plane is substantially parallel with the recessed face.

IPC Classes  ?

• F41A 17/46 - Trigger safeties, i.e. means for preventing trigger movement
• F41A 35/06 - Adaptation of guns to both right and left hand use

Goods & Services

Triggers and safety catches for firearms; levers for use in firearms; firearms; loaders, grips, cocks, frames, barrels, cylinders and piston heads for use in firearms; archery products, crossbow triggers. Wholesale of accessories and parts of firearms and crossbows.

Abstract

A trigger device for a bolt action firearm is disclosed. The trigger device comprises a trigger, a housing, a bolt pin, and a bolt pin arm. The trigger is rotatably coupled in the housing via a trigger pivot pin and comprises a trigger stop arm. The bolt pin is moveable between a bolt open position and a bolt closed position in response to positioning of a bolt. The bolt pin arm is rotatably coupled proximal one end to the housing and at another end to the bolt pin. The bolt pin arm comprises an over travel stop configured to selectively engage with the trigger stop arm. In the bolt closed position, the over travel stop is positioned within a travel path of the trigger stop arm. In the bolt open position, the over travel stop is positioned outside of the travel path of the trigger stop arm.

IPC Classes  ?

• F41A 19/16 - Adjustable firing mechanismsTrigger mechanisms with adjustable trigger pull
• F41A 19/31 - Sear arrangements therefor

Abstract

A slidable trigger assembly for a firearm is described. The slidable trigger comprises a main body housing a trigger and a sear and a slider, slidably coupled with the main body. The slidable trigger assembly may include a slide adjuster configured to set the sear at a target position with respect to the slider. Alternatively, the slider moves laterally in response to physical manipulation of the slidable trigger assembly to set the sear at a target position with respect to the slider.

IPC Classes  ?

• F41A 19/16 - Adjustable firing mechanismsTrigger mechanisms with adjustable trigger pull
• F41A 19/12 - SearsSear mountings
• F41A 19/10 - TriggersTrigger mountings

Abstract

A trigger device is disclosed. The trigger device comprises a housing, a trigger, a reverser, and a first pull wight adjustment mechanism. The trigger is rotatably mounted in the housing via a trigger pivot pin. The trigger comprises a trigger tooth. The reverser is rotatably mounted in the housing via a reverser pivot pin. The reverser comprises a reverser tooth. The first pull weight adjustment mechanism is coupled between the trigger and the reverser to bias the trigger in a first direction and the reverser in an opposite direction. Actuation of the trigger causes the trigger to rotate in the opposite direction, the trigger tooth to engage the reverser tooth, and the reverser to rotate in the first direction.

IPC Classes  ?

• F41A 19/10 - TriggersTrigger mountings
• F41A 19/16 - Adjustable firing mechanismsTrigger mechanisms with adjustable trigger pull

Abstract

A safety selector comprises a first hub portion, a second hub portion, and a cam portion connecting the first hub portion with the second hub portion. The first hub portion is generally cylindrical in shape, having opposing faces and an longitudinal surface extending therebetween. Further, the first hub portion is segmented in it opposing faces, creating a first plane in the longitudinal surface. The first hub portion further comprises a pair of spaced apart detent sockets in the longitudinal surface face, a connecting groove extending between the detent sockets, and a detent notch in an outer one of the circular faces exposing one of the detent sockets. The cam portion comprises a recessed face and a cam face. The first plane is substantially parallel with the recessed face.

IPC Classes  ?

• F41A 17/00 - Safety arrangements, e.g. safeties
• F41A 11/02 - Modular concepts, e.g. weapon-family concepts
• F41A 17/46 - Trigger safeties, i.e. means for preventing trigger movement

Goods & Services

Triggers and safety catches for firearms; levers for use in firearms; firearms; loaders, grips, cocks, frames, barrels, cylinders and piston heads for use in firearms. Wholesale of accessories and parts of firearms.

Goods & Services

Triggers and safety catches for firearms; levers for use in firearms; firearms; component parts for firearms, namely, loaders, grips, cocks, frames, barrels, cylinders and piston heads for use in firearms

Goods & Services

Triggers and safety catches for firearms; levers for use in firearms; firearms; component parts for firearms, namely, loaders, grips, cocks, frames, barrels, cylinders and piston heads for use in firearms Wholesale store services featuring accessories and parts of firearms

Goods & Services

Triggers and safety catches for firearms; levers for use in firearms; firearms; component parts for firearms, namely, loaders, grips, cocks, frames, barrels, cylinders and piston heads for use in firearms Wholesale store services featuring accessories and parts of firearms

Goods & Services

(1) Triggers and safety catches for firearms; levers for use in firearms (2) Firearms; loaders, grips, cocks, frames, barrels, cylinders and piston heads for use in firearms (3) Hats (4) Clothing, namely t-shirts, pants, shorts (1) Wholesale of accessories and parts of firearms (2) Repair and maintenance of firearms and parts and accessories of firearms

Goods & Services

(1) Triggers and safety catches for firearms; levers for use in firearms (2) Firearms; loaders, grips, cocks, frames, barrels, cylinders and piston heads for use in firearms (3) Hats (4) Clothing, namely t-shirts, pants, shorts (1) Wholesale of accessories and parts of firearms (2) Repair and maintenance of firearms and parts and accessories of firearms

Abstract

A trigger device for activating a firing mechanism, the trigger device comprising a housing, a trigger pivotally mounted on the housing via a trigger pivot pin, a sear arm comprising a first sear surface, a ticker extending generally from the trigger to the sear arm, the ticker pivotable about a ticker pivot pin, the ticker comprising spaced apart flanges, each of which comprises an aperture defining at least a first contact surface, and a captured roller positioned at least partially within the apertures, wherein in a captured position the first sear surface and the first contact surfaces engage the captured roller and in a released position the first contact surfaces disengage from the captured roller to allow the captured roller to move within the aperture.

IPC Classes  ?

• F41A 19/10 - TriggersTrigger mountings
• F41A 19/12 - SearsSear mountings
• F41B 5/12 - Crossbows
• F41B 5/14 - Details of bowsAccessories for arc shooting

Abstract

A trigger assembly for activating a firing mechanism. The trigger assembly includes a trigger having a sear arm with a first sear surface, and a firing element including a body portion with a second sear surface and an engagement portion for engagement with the firing mechanism, for activating the firing mechanism. The trigger assembly also includes a captured roller positioned for engagement with the first and second sear surfaces. The trigger is pivotable between a load position, in which the captured roller is held between the first and second sear surfaces, and a release position, in which the second sear surface is disengaged from the captured roller and the firing element is released. The firing element is pivotable between a first position, in which the firing element is held by the captured roller, and a second position, in which the firing element is disengaged from the captured roller.

IPC Classes  ?

• F41B 5/12 - Crossbows
• F41A 17/46 - Trigger safeties, i.e. means for preventing trigger movement
• F41A 19/10 - TriggersTrigger mountings
• F41A 19/12 - SearsSear mountings
• F41A 19/17 - Hair-trigger mechanisms
• F41A 19/42 - Mechanical firing mechanisms having at least one hammer

Abstract

A trigger assembly for activating a firing mechanism. The trigger assembly includes a trigger having a sear arm with a first sear surface, and a firing element including a body portion with a second sear surface and an engagement portion for engagement with the firing mechanism, for activating the firing mechanism. The trigger assembly also includes a captured roller positioned for engagement with the first and second sear surfaces. The trigger is pivotable between a load position, in which the captured roller is held between the first and second sear surfaces, and a release position, in which the second sear surface is disengaged from the captured roller and the firing element is released. The firing element is pivotable between a first position, in which the firing element is held by the captured roller, and a second position, in which the firing element is disengaged from the captured roller.

IPC Classes  ?

• F41A 19/12 - SearsSear mountings
• F41A 17/46 - Trigger safeties, i.e. means for preventing trigger movement
• F41A 19/10 - TriggersTrigger mountings
• F41A 19/17 - Hair-trigger mechanisms
• F41A 19/42 - Mechanical firing mechanisms having at least one hammer
• F41B 5/18 - Bow-string drawing or releasing devices

Abstract

A trigger assembly for activating a firing mechanism. The trigger assembly includes a trigger having a sear arm with a first sear surface, and a firing element including a body portion with a second sear surface and an engagement portion for engagement with the firing mechanism, for activating the firing mechanism. The trigger assembly also includes a captured roller positioned for engagement with the first and second sear surfaces. The trigger is pivotable between a load position, in which the captured roller is held between the first and second sear surfaces, and a release position, in which the second sear surface is disengaged from the captured roller and the firing element is released. The firing element is pivotable between a first position, in which the firing element is held by the captured roller, and a second position, in which the firing element is disengaged from the captured roller.

IPC Classes  ?

• F41A 17/46 - Trigger safeties, i.e. means for preventing trigger movement
• F41A 19/10 - TriggersTrigger mountings
• F41A 19/12 - SearsSear mountings
• F41A 19/17 - Hair-trigger mechanisms
• F41A 19/42 - Mechanical firing mechanisms having at least one hammer
• F41B 5/18 - Bow-string drawing or releasing devices

Abstract

A trigger device for activating a firing mechanism, the trigger device comprising a housing, a trigger pivotally mounted on the housing via a trigger pivot pin, a sear arm comprising a first sear surface, a ticker extending generally from the trigger to the sear arm, the ticker pivotable about a ticker pivot pin, the ticker comprising spaced apart flanges, each of which comprises an aperture defining at least a first contact surface, and a captured roller positioned at least partially within the apertures, wherein in a captured position the first sear surface and the first contact surfaces engage the captured roller and in a released position the first contact surfaces disengage from the captured roller to allow the captured roller to move within the aperture.

IPC Classes  ?

• F41A 19/10 - TriggersTrigger mountings
• F41A 19/12 - SearsSear mountings
• F41B 5/12 - Crossbows
• F41B 5/14 - Details of bowsAccessories for arc shooting

Abstract

A safety selector comprises a first hub portion, a second hub portion, and a cam portion connecting the first hub portion with the second hub portion. The first hub portion is generally cylindrical in shape, having opposing faces and an longitudinal surface extending therebetween. Further, the first hub portion is segmented in it opposing faces, creating a first plane in the longitudinal surface. The first hub portion further comprises a pair of spaced apart detent sockets in the longitudinal surface face, a connecting groove extending between the detent sockets, and a detent notch in an outer one of the circular faces exposing one of the detent sockets. The cam portion comprises a recessed face and a cam face. The first plane is substantially parallel with the recessed face.

IPC Classes  ?

• F41A 11/02 - Modular concepts, e.g. weapon-family concepts
• F41A 17/00 - Safety arrangements, e.g. safeties
• F41A 17/46 - Trigger safeties, i.e. means for preventing trigger movement

Abstract

A trigger device is disclosed. The trigger device comprises a housing, a trigger, a reverser, and a first pull weight adjustment mechanism. The trigger is rotatably mounted in the housing via a trigger pivot pin. The trigger comprises a trigger tooth. The reverser is rotatably mounted in the housing via a reverser pivot pin. The reverser comprises a reverser tooth. The first pull weight adjustment mechanism is coupled between the trigger and the reverser to bias the trigger in a first direction and the reverser in an opposite direction. Actuation of the trigger causes the trigger to rotate in the opposite direction, the trigger tooth to engage the reverser tooth, and the reverser to rotate in the first direction.

IPC Classes  ?

• F41A 19/10 - TriggersTrigger mountings
• F41A 19/16 - Adjustable firing mechanismsTrigger mechanisms with adjustable trigger pull

IPC Classes  ?

• B62L 1/00 - BrakesArrangements thereof
• F16D 65/12 - DiscsDrums for disc brakes

IPC Classes  ?

• F41B 5/12 - Crossbows
• F41B 5/14 - Details of bowsAccessories for arc shooting
