Goods & Services

Games; Sporting articles; Sporting and physical exercise equipment.

Abstract

The invention relates to a launching head for launching two or more sports shooting targets, where each target is of a generally disc-shaped configuration. The launching head is of a generally tubular configuration defined by a longitudinally extending rotational axis and includes an outer circumferential support surface portion formed to fit into and support the respective targets. The launching head is provided with a plurality of retaining claw members configured to be able to pivot in a plane containing the longitudinal axis and pivot an angle relative to a plane extending perpendicularly to the longitudinal axis. The invention also relates to a launching device applying the head of the invention and to a sports shooting target that can be used for the launching head of the invention.

IPC Classes  ?

• F41J 9/18 - Traps or throwing-apparatus therefor

Abstract

A launching device for launching a sports shooting target made of a biodegradable material includes a launching head configured such that a hub portion of the target can be positioned on the launching head. The launching head includes a plurality of pivotally mounted retaining, claw members that are configured to be able to pivot between a first state, in which the claw members retain the hub portion of the target to the launching head and a second state, in which the claw members release the hub portion of the target from the launching head, where the device is provided with a longitudinally displaceable shaft or rod that is functionally connected to the claw members such that a longitudinal displacement (B, D) of the shaft results in said pivotal movement of the claw members. Launching head rotating means is configured to rotate the launching head and to accelerate the launching head from substantially zero rotational speed to a maximum rotational speed, at which maximum rotational speed of the launching head, the hub portion of the target is released from the launching head.

IPC Classes  ?

• F41J 9/32 - Traps or throwing-apparatus therefor characterised by means for obviating the anticipation of the flight path
• A63H 33/18 - Throwing or slinging toys
• F41J 1/01 - Target discs characterised by their material, structure or surface
• F41J 9/30 - Traps or throwing-apparatus therefor characterised by using a magazine of targets

Abstract

1233), both of the retaining portions (16, 17) are in a radial position inside the support surface portion (9') where they do not attach the respective target (11, 12) to the support surface (9) of the launching head. The invention also relates to a launching device applying the head of the invention and to a sports shooting target that can be used for the launching head of the invention.

IPC Classes  ?

• F41J 9/18 - Traps or throwing-apparatus therefor

Abstract

The invention relates to a launching head for launching two or more sports shooting targets, where each target (11, 12) is of a generally disc-shaped configuration, where the target (11, 12) is defined by a rotational axis and a central hub portion extending perpendicularly to the rotational axis, which hub portion comprises a radially inward facing surface (13, 14) formed for releasable attachment of the targets (11, 12) to the launching head (10), where the launching head (10) is of a generally tubular comfiguration defined by a longitudinally extending rotational axis (z) and where the launching head (10) is provided with an outer circumferential support surface portion (9') formed to fit into and support said radially inward facing surface of the hub portion of the respective targets (11, 12). The launching head (10) is provided with a plurality of retaining claw members (15) configured to be able to pivot in a plane containing the longitudinal axis (z) and pivot an angle (?) relative to a plane (x, y) extending perpendicularly to the longitudinal axis (z). Each of the retaining claw members (15) is provided with two longitudinally spaced-apart retaining portions (16, 17) configured such that when the retaining claw member (15) is in a first pivotal position (? = ?1), both of the retaining portions (16, 17) are in a radial position outside the support surface portion (9'), in which position they attach the hub portion of the respective targets (11, 12) to the support surface (9') of the launching head, and the retaining claw member (15) is in a second pivotal position (? = ?2), the retaining portion (17) closest to the pivot point (B) is at a radial position outside the support surface portion (9'), in which position it attaches the corresponding target (12) to the launching head (10) whereas the other retaining portion (16) is at a radial position inside the support surface portion (9'), in which position it does not attach the corresponding target (11) to the launching head, and the retaining daw member (15) is in a third pivotal position (? = ?3), both of the retaining portions (16, 17) are in a radial position inside the support surface portion (9') where they do not attach the respective target (11, 12) to the support surface (9) of the launching head. The invention also relates to a launching device applying the head of the invention and to a sports shooting target that can be used for the launching head of the invention.

IPC Classes  ?

• F41J 9/18 - Traps or throwing-apparatus therefor

Goods & Services

Power operated tools; electric driving motors for machines; electric motors, and their parts, not for land vehicles; motors, electric, other than for land vehicles; electric motors for machines with a digital servo drive controller; couplings for machines; machine parts, in particular couplings for fixings; power transmission couplings for machines; spring powered machines.

Goods & Services

Sporting articles; sports equipment; clay pigeons [targets]; clay pigeon traps. Retail and wholesale services, the aforesaid services whether or not online, namely in the field of the following goods: sporting goods, and equipment, clay pigeons [targets], clay pigeon traps.

Goods & Services

(1) Launchers for clay pigeons; target launchers for clay pigeons; clay pigeons [targets]; clay pigeon traps. (1) Retail and wholesale services, the aforesaid services whether or not online, namely in the field of the following goods: sporting goods, and equipment, clay pigeons [targets], clay pigeon traps.

Goods & Services

(1) Power operated tools; electric driving motors for machines; electric motors and parts thereof, other than for land vehicles, for launchers for clay pigeons and for machines; electric motors for machines with a digital servo drive controller; couplings for machines; machine parts, in particular couplings for fixings; power transmission couplings for machines; spring powered machines for launchers for clay pigeons;

Abstract

7) from the rotational axis (z) and outside the hub portion (2) The stabilizing means comprises first fan blades (3′) that extend radially from the hub portion (2, 15) to the ring member (7, 14) provided at the largest distance from the rotational axis (z) and second fan blades (3″) that extend radially between two adjacent ring members. The invention further relates to a launching device for launching the target, launching apparatuses comprising the launching device of the invention as well as a method of launching targets for skeet shooting and similar sport shooting activities.

IPC Classes  ?

• F41J 1/01 - Target discs characterised by their material, structure or surface
• A63H 33/18 - Throwing or slinging toys
• F41J 9/30 - Traps or throwing-apparatus therefor characterised by using a magazine of targets
• F41J 9/32 - Traps or throwing-apparatus therefor characterised by means for obviating the anticipation of the flight path

Goods & Services

Launchers for clay pigeons; target launchers for skeet and clay pigeon shooting

Goods & Services

Power operated tools; Electric driving motors for machines; Electric motors, and their parts, not for land vehicles; Motors, electric, other than for land vehicles; Electric motors for machines with a digital servo drive controller; Couplings for machines; Machine parts, in particular Couplings for fixings; Power transmission couplings for machines; Spring powered machines.

Goods & Services

Clay pigeons; Launchers for clay pigeons Wholesale and retail store services featuring clay pigeons and launchers for clay pigeons; On-line wholesale and retail store services featuring clay pigeons and launchers for clay pigeons

Goods & Services

Sporting articles; Sports equipment; Clay pigeons [targets]; Clay pigeon traps. Retail and wholesale services, The aforesaid services whether or not online, Namely in the field of the following goods: Sporting goods, And equipment, Clay pigeons [targets], Clay pigeon traps.

Abstract

A sports shooting target made of a biodegradable material has a rotational axis and attachment means for releasable attachment to a launching device. The target comprises trajectorystabilizing means that are configured to stabilize the trajectory of the target by gyro effect. The stabilizing means cause forward movement of the target along the trajectory by rotation about said rotational axis. A fan comprising fan blades that rotate in unison with the target. The target comprises a hub portion configured for releasable attachment to a corresponding portion of a launching device and a plurality of concentric ring members arranged about the rotational axis of the target at different distances from the rotational axis and outside the hub portion. First fan blades extend radially from the hub portion to the ring member provided at the largest distance from the rotational axis and second fan blades extend radially between two adjacent ring members.

IPC Classes  ?

• F41J 9/16 - Clay-pigeon targetsClay-disc targets
• F41J 9/18 - Traps or throwing-apparatus therefor
• F41J 9/32 - Traps or throwing-apparatus therefor characterised by means for obviating the anticipation of the flight path

Abstract

A launching device for launching a target has a launching head configured for positioning a hub portion of the target thereon. The launching head comprises a plurality of pivotally mounted retaining claw members pivotable between a first state, in which the claw members retain the hub portion to the launching head, and a second state in which the claw members release the hub portion of the target from the launching head. A longitudinally displaceable shaft is functionally connected to the claw members such that longitudinal displacement of the shaft results in pivotal movement of the claw members between the first state and second states. A shaft operating means displaces the shaft to launch head rotating means that rotates and accelerates the launching head from substantially zero rotational speed to a maximum rotational speed. At the maximum rotational speed, the hub portion of the target is released from the launchnig head.

IPC Classes  ?

• F41J 1/01 - Target discs characterised by their material, structure or surface
• F41J 9/16 - Clay-pigeon targetsClay-disc targets
