An actuation and blocking system of a joint for use in a piece of furniture or other furnishing item for perpendicularly interconnecting a shoulder with a shelf, base or top includes a pin with a fixing element to the shoulder and the shelf, base or top and adapted to be at least partially inserted in a hole of the shoulder and of the shelf, base or top. The pin has a side hole for receiving a shaped stem, which extends from an actuation and blocking group of the joint positioned on the shelf, base or top parallel to the floor or the ceiling, which are close to the furniture or other furnishing item when assembled, the actuation and blocking group providing for a 90° transmission between a maneuvering point, accessible from the front or side of the furniture, and the shaped stem, inserted in the side hole of the pin.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
2.
ADJUSTABLE SUPPORT DEVICE FOR HANGING FURNITURE FROM A WALL
An adjustable support device (10, 110, 210) for hanging furniture on a wall comprises a shaped plate (11, 111, 211), provided with two coplanar wings (12, 13, 112, 113, 212, 213) intended for constraining the device to the furniture, and an intermediate zone (14, 114, 214), recessed with respect to a fixing plane identified by the two coplanar wings. The intermediate zone is intended to be housed in a recess (47) in a shoulder of the furniture. The intermediate zone (14, 114, 214) houses the body of a hooked hanging arm (15, 115, 215) and a kinematic mechanism for adjusting the position of the arm with respect to the shaped plate. The hooked hanging arm has a hooked end which is offset with respect to the body of the arm so as to be in a hooking plane which is spaced, in the direction opposite the recess formed by the intermediate zone, from the fixing plane identified by said two coplanar wings.
A shelf-supporting device suitable for creating a reversible connection of a shelf with an opposite shoulder of a piece of furniture includes a shelf bracket having a main body with a solid section in its front area, from a front surface of which a connection pin protrudes, and a profile shaped so that at least a portion of the upper surface of the main body does not come into contact with the upper internal wall of the seat, in which the main body is housed, and which is defined within the shelf when the shelf-supporting device is assembled into the shelf.
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
A shelf-supporting device configured to create a reversible connection of a shelf with an opposite shoulder of a piece of furniture includes a shelf bracket having a main body with a shaped profile that includes, on its outer surface, one or more projecting elements extending toward the outside of the main body so as to optimize the load distribution in an area of the shelf of maximum thickness.
A shelf-supporting device configured to create a reversible connection of a shelf with an opposite shoulder of a piece of furniture includes a shelf bracket having a main body, which has a shaped profile and a solid section at its front area, with a pin protruding from the front area so that forces can be transferred from the pin to an area of the main body in having greater resistance to the loads carried by the device.
A compact support and fixing device for furniture shelves arranged between opposite sides comprising: a casing (16, 17) that contains a pin (11) pushed at one end by a spring (24) and movable within it either freely or in an externally controlled manner to compress the cited spring (24), said spring (11) being movable between a position of maximum extraction and a position of maximum retraction inside the casing; a cam element (25, 125, 125' ) for controlling the movement of said pin from said position of maximum extraction to said position of maximum retraction inside the casing, wherein said pin (11) is free to move under the action of the spring between said position of maximum extraction and said position of maximum retraction inside the casing when said cam element (25, 125, 125' ) is arranged in a rest position; wherein said casing comprises a first half-shell (16) and a second half-shell (17) closed one over the other, associated and snap- connected with each other, wherein said first half-shell (16) has an essentially cylindrical general shape and a wall (19) of which of one end is provided with a through hole (20) for the passage of a free terminal end (21) of the pin (11) that slides internally in an axial direction; said pin (11) comprises a cylindrical end portion (21) with smaller diameter, an intermediate section (28), in which said cam element (25, 125, 125' ) is arranged, and a section with reduced diameter at the other end, a wall (29) of which acts as a centring and abutment for said spring (24); said intermediate section (28) of said pin (11) has a flat surface (30), which is contained in the larger diameter of the pin (11) and is provided with a longitudinal slot-shaped recess (33) in which is arranged an eccentric lobed element (46) of said cam element (25, 125, 125' ) which acts on an engagement surface (35) of a through opening (54) of said slot-shaped recess (33), thus determining the movement of said pin (11) between said position of maximum extraction and said position of maximum retraction inside the casing by rotation of the cam element (25, 125, 125' ).
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 5/06 - Joining sheets or plates to one another or to strips or bars parallel to them by means of clamps or clips
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
7.
RIGID SUPPORT AND FIXING DEVICE FOR FURNITURE SHELVES
A rigid support and fixing device for furniture shelves arranged between opposite sides comprising: a casing (16, 116) which contains a pin (11, 111) pushed at one end by a spring (24) and movable within it either freely or in an externally controlled manner to compress the cited spring (24), said pin (11, 111) being movable between a position of maximum extraction and a position of maximum retraction inside the casing; a cam element (25, 125) for controlling the movement of said pin from said position of maximum extraction to said position of maximum retraction inside the casing, wherein said pin (11, 111) is free to move under the action of the spring between said position of maximum extraction and said position of maximum retraction inside the casing when said cam element (25, 125) is arranged in a rest position; wherein said casing comprises a hollow body (16, 116), an end wall (19, 119) of which is provided with a through hole (20, 120) for the passage of a free terminal end (21, 121) of the pin (11, 111) that slides internally in an axial direction and the other end has an opening (18, 118) that receives the closing plug (17, 117) of the opening (18, 118); said pin (11) comprises a cylindrical end portion (21, 121) with smaller diameter and an intermediate section (28, 128), in which said cam element (25, 125) is arranged; said intermediate section (28, 128) of said pin (11, 111) has a flat surface (30, 130), which is provided with a longitudinal slot-shaped recess (33, 133) in which an eccentric lobed element (46, 146) of said cam element (25, 125) is arranged, acting on an engagement surface (35, 35', 135) of a through opening (54, 154) of said slot-shaped recess (33, 133), thus determining the movement of said pin (11, 111) between said position of maximum extraction and said position of maximum retraction inside the casing by rotation of the cam element (25, 125); retaining means or elements (40, 44; 60; 65; 157) for retaining the cam element (25, 125) inside the hollow body (16, 116) of the casing in an operating position, once inserted, are also provided.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
F16B 5/06 - Joining sheets or plates to one another or to strips or bars parallel to them by means of clamps or clips
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
8.
RIGID SUPPORT AND FIXING DEVICE FOR FURNITURE SHELVES
A rigid support and fixing device for furniture shelves arranged between opposite sides comprising: a casing (16, 116) which contains a pin (11, 111) pushed at one end by a spring (24) and movable within it either freely or in an externally controlled manner to compress the cited spring (24), said pin (11, 111) being movable between a position of maximum extraction and a position of maximum retraction inside the casing; a cam element (25, 125) for controlling the movement of said pin from said position of maximum extraction to said position of maximum retraction inside the casing, wherein said pin (11, 111) is free to move under the action of the spring between said position of maximum extraction and said position of maximum retraction inside the casing when said cam element (25, 125) is arranged in a rest position; wherein said casing comprises a hollow body (16, 116), an end wall (19, 119) of which is provided with a through hole (20, 120) for the passage of a free terminal end (21, 121) of the pin (11, 111) that slides internally in an axial direction and the other end has an opening (18, 118) that receives the closing plug (17, 117) of the opening (18, 118); said pin (11) comprises a cylindrical end portion (21, 121) with smaller diameter and an intermediate section (28, 128), in which said cam element (25, 125) is arranged; said intermediate section (28, 128) of said pin (11, 111) has a flat surface (30, 130), which is provided with a longitudinal slot-shaped recess (33, 133) in which an eccentric lobed element (46, 146) of said cam element (25, 125) is arranged, acting on an engagement surface (35, 35', 135) of a through opening (54, 154) of said slot-shaped recess (33, 133), thus determining the movement of said pin (11, 111) between said position of maximum extraction and said position of maximum retraction inside the casing by rotation of the cam element (25, 125); retaining means or elements (40, 44; 60; 65; 157) for retaining the cam element (25, 125) inside the hollow body (16, 116) of the casing in an operating position, once inserted, are also provided.
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 5/06 - Joining sheets or plates to one another or to strips or bars parallel to them by means of clamps or clips
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
9.
COMPACT SUPPORT AND FIXING DEVICE FOR FURNITURE SHELVES
A compact support and fixing device for furniture shelves arranged between opposite sides comprising: a casing (16, 17) that contains a pin (11) pushed at one end by a spring (24) and movable within it either freely or in an externally controlled manner to compress the cited spring (24), said spring (11) being movable between a position of maximum extraction and a position of maximum retraction inside the casing; a cam element (25, 125, 125' ) for controlling the movement of said pin from said position of maximum extraction to said position of maximum retraction inside the casing, wherein said pin (11) is free to move under the action of the spring between said position of maximum extraction and said position of maximum retraction inside the casing when said cam element (25, 125, 125' ) is arranged in a rest position; wherein said casing comprises a first half-shell (16) and a second half-shell (17) closed one over the other, associated and snap- connected with each other, wherein said first half-shell (16) has an essentially cylindrical general shape and a wall (19) of which of one end is provided with a through hole (20) for the passage of a free terminal end (21) of the pin (11) that slides internally in an axial direction; said pin (11) comprises a cylindrical end portion (21) with smaller diameter, an intermediate section (28), in which said cam element (25, 125, 125' ) is arranged, and a section with reduced diameter at the other end, a wall (29) of which acts as a centring and abutment for said spring (24); said intermediate section (28) of said pin (11) has a flat surface (30), which is contained in the larger diameter of the pin (11) and is provided with a longitudinal slot-shaped recess (33) in which is arranged an eccentric lobed element (46) of said cam element (25, 125, 125' ) which acts on an engagement surface (35) of a through opening (54) of said slot-shaped recess (33), thus determining the movement of said pin (11) between said position of maximum extraction and said position of maximum retraction inside the casing by rotation of the cam element (25, 125, 125' ).
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
F16B 5/06 - Joining sheets or plates to one another or to strips or bars parallel to them by means of clamps or clips
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
10.
Tool for adjusting feet for furniture items and the like
A tool for controlling a controlled element of a height adjustable foot of a furnishing item and the like includes an engagement portion and a handle coupled to the engagement portion and having two arms shaped to embrace an outer edge of the height-adjustable foot and keep the engagement portion associated laterally with the adjustable foot. The engagement portion is arranged between the two arms and includes a toothed section that extends over a rounded area of the surface between the two arms of the handle so as to engage radial septa or seats defined in the controlled element and converging toward a central axis of the adjustable foot. The toothed section is shaped as an arched and rounded tooth extending toward one of its free ends in the direction from one arm to the other.
A tool for controlling a controlled element of a height adjustable foot of a furnishing item and the like includes an engagement portion and a handle coupled to the engagement portion and having two arms shaped to embrace an outer edge of the height-adjustable foot and keep the engagement portion associated laterally with the adjustable foot. The engagement portion is arranged between the two arms and includes a toothing with a toothed section that extends over a rounded area of the surface between the two arms of the handle so as to engage at least one toothing on the controlled element of the adjustable foot. The teeth of the toothed section and the teeth of the at least one toothing of the controlled element are asymmetrical and angled, enveloping, curved teeth that follow the circular shape of the controlled element.
A compact joint for connecting a first panel to a second panel of furniture and other furnishing items, positioned perpendicular to each other, includes a plurality of interconnection and blocking components for joining and firmly blocking the two panels together. The plurality of components of interconnection and blocking components lies on the same plane, which is perpendicular to the first and second panels and which contains a coupling axis between the first and second panels that travels inside the first panel. The joint also defines an actuation axis that is perpendicular to the coupling axis and lies on a plane parallel and interspaced with respect to the first panel and perpendicular with respect to the second panel.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A shelf-supporting device for the reversible connection of a shelf with shoulders of a piece of furniture includes a main body having a movable engagement system, to which a pin is connected. The movable engagement system slides with respect to the main body between a first non-operating position, in which the pin does not protrude from the shelf, and a second operating position, in which the pin protrudes outwardly from a transverse edge of the shelf. The movable engagement system has two distinct parts, coupled together, and the connection between the slide and the pin may be an interference coupling, a shape coupling, or another type of coupling. This shelf-supporting device makes it possible to miniaturize the pin by drastically reducing its diameter, thus improving the aesthetic impact of the housing hole in the shoulders, and may be made modular by using pins of different diameters and materials.
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
F16B 12/26 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using snap-action elements
A supporting device for furniture shelves configured to provide a reversible connection of a shelf with an opposite shoulder of a piece of furniture includes a main body, with which a movable engagement system is slidingly associated, coupled to a pin. The movable engagement system slides with respect to the main body along a sliding direction between a first non-operating position, in which the pin does not protrude from the shelf, and a second operating position, in which the pin projects outwardly from a transverse edge of the shelf. The supporting device further includes an actuation system of the engagement system and a movement-transmission system configured to transform the movement of the actuation system into a translational movement along the sliding direction of the movable engagement system.
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
A47B 57/48 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions with means for adjusting the height of detachable shelf supports consisting of tongues, pins or similar projecting means coacting with openings
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
15.
SHELF-SUPPORTING DEVICE FOR REMOVABLY AND SAFELY SUPPORTING FURNITURE SHELVES
The present invention relates to a shelf-supporting device (10,10') for the reversible connection of a shelf (200) to the opposite shoulders (300) of a piece of furniture, of the type suitable for being inserted inside a seat (201) formed within the thickness of said shelf (200) and comprising a main body (12) with which a pin (11,11') is slidingly associated, movable along a longitudinal axial direction (X) against the action of opposing means (M). The device according to the invention is configured so that, in order to couple the shelf with the shoulders of the piece of furniture, a simple movement is sufficient, that allows the pins to be brought in correspondence with the corresponding housing seats (301) formed in the shoulders (300), whereas in order to remove the shelf from the furniture, a double movement of the shelf must be effected, a first upward pushing movement and a second extraction movement in a horizontal direction, or a first movement in a horizontal direction and a second upward pushing movement, depending on how the pin (11,11') is configured and oriented inside the seat (201) formed in the shelf (200), according to the present invention.
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
F16B 12/26 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using snap-action elements
16.
ROTATING SHELF-SUPPORTING DEVICE FOR REMOVABLY SUPPORTING FURNITURE SHELVES
The present invention relates to a shelf-supporting device (30) for the reversible connection of a shelf (200) to the opposite shoulders (300) of a piece of furniture, said device (30) being configured for being inserted inside a seat (201) formed within the thickness of said shelf (200) and comprising a main body (12) with which a pin (11) is slidingly associated, movable along a longitudinal axial direction (X) against the action of opposing means (M) between an advanced operating position wherein said pin (11) protrudes from said main body (12) and, when the device is assembled, from said shelf (200), so as to be able to be inserted into a housing seat (301) formed on one of said shoulders (300), and a retracted non-operating position wherein said pin (11) does not protrude from said main body (12) and from said shelf (200) when the device is assembled, or protrudes so as to be able to be in any case released from said housing seat (301) of said shoulder (300), wherein said pin (11) terminates with a free end or tip (P) comprising a tilted surface (Pa) suitable for cooperating with the entry edge of said seat (301), characterized in that it further comprises a bush (20) which can be fixedly inserted into said seat (201) formed within the thickness of said shelf (200), said main body (12) being in turn inserted into the axial cavity (22) of said bush (20) and being rotatable with respect to the same between a first operating position (A) which allows the coupling and uncoupling of the shelf (200) with respect to the shoulders (300) of the furniture, and a second blocking position (B) suitable for preventing the accidental disengagement of the shelf from the shoulders.
A47B 57/20 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions with means for adjusting the height of the shelves consisting of tongues, pins or similar projecting means coacting with openings
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
F16B 12/26 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using snap-action elements
17.
SUPPORT DEVICE FOR FURNITURE SHELVES WITH OPTIMISED LOAD TRANSFER
The present invention relates to a shelf-supporting device (1, 1', 1") suitable for creating the reversible connection of a shelf (200) with the opposite shoulders (300) of a piece of furniture. According to the invention, the shelf bracket (1, 1', 1") comprises a main body (12, 12', 12") which has a shaped profile comprising, on its outer surface, one or more projecting elements (13) which extend towards the outside of said main body (12, 12', 12") in order to optimize the load distribution in an area of the shelf having a maximum thickness.
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
18.
SUPPORTING DEVICE FOR FURNITURE SHELVES WITH OPTIMIZED LOAD TRANSFER
The present invention relates to a shelf-supporting device (1,1',1") suitable for creating the reversible connection of a shelf (200) with the opposite shoulders (300) of a piece of furniture. According to the invention, the shelf bracket (1,1',1") comprises a main body (12,12',12") which has a shaped profile comprising a solid section in correspondence with its front area (14) from whose surface (14a) said pin (11) protrudes so that the forces are transferred from the pin to the main body in correspondence with an area having greater resistance to the loads of the device.
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
19.
COMBINATION OF A SUPPORT DEVICE WITH A SEAT OF A SHELF FOR FURNITURE SHELVES WITH OPTIMISED LOAD TRANSFER
The present invention relates to a shelf-supporting device (1,1',1") suitable for creating the reversible connection of a shelf (200) with the opposite shoulders (300) of a piece of furniture. According to the invention, the shelf bracket (1,1',1") comprises a main body (12,12',12") which has a solid section in correspondence with its front area (14), corresponding to the area from whose front surface (14a) the connection pin (11) protrudes, and a shaped profile so that at least a portion of the upper surface (12c,12c',12c") of the main body (12,12',12") does not come into contact with the upper internal wall (201') of the housing seat (201) of said main body (12,12',12") formed within said shelf (200) when the device is assembled to the shelf.
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
20.
SUPPORT DEVICE FOR FURNITURE SHELVES WITH OPTIMISED LOAD TRANSFER
The present invention relates to a shelf-supporting device (1, 1', 1") suitable for creating the reversible connection of a shelf (200) with the opposite shoulders (300) of a piece of furniture. According to the invention, the shelf bracket (1, 1', 1") comprises a main body (12, 12', 12") which has a shaped profile comprising, on its outer surface, one or more projecting elements (13) which extend towards the outside of said main body (12, 12', 12") in order to optimize the load distribution in an area of the shelf having a maximum thickness.
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
21.
SUPPORTING DEVICE FOR FURNITURE SHELVES WITH OPTIMIZED LOAD TRANSFER
The present invention relates to a shelf-supporting device (1,1',1") suitable for creating the reversible connection of a shelf (200) with the opposite shoulders (300) of a piece of furniture. According to the invention, the shelf bracket (1,1',1") comprises a main body (12,12',12") which has a shaped profile comprising a solid section in correspondence with its front area (14) from whose surface (14a) said pin (11) protrudes so that the forces are transferred from the pin to the main body in correspondence with an area having greater resistance to the loads of the device.
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
22.
COMBINATION OF A SUPPORT DEVICE WITH A SEAT OF A SHELF FOR FURNITURE SHELVES WITH OPTIMISED LOAD TRANSFER
The present invention relates to a shelf-supporting device (1,1',1") suitable for creating the reversible connection of a shelf (200) with the opposite shoulders (300) of a piece of furniture. According to the invention, the shelf bracket (1,1',1") comprises a main body (12,12',12") which has a solid section in correspondence with its front area (14), corresponding to the area from whose front surface (14a) the connection pin (11) protrudes, and a shaped profile so that at least a portion of the upper surface (12c,12c',12c") of the main body (12,12',12") does not come into contact with the upper internal wall (201') of the housing seat (201) of said main body (12,12',12") formed within said shelf (200) when the device is assembled to the shelf.
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
23.
MAGNETIC SHELF BRACKET FOR THE REMOVABLE CONNECTION OF SHELVES TO THE SHOULDERS OF A PIECE OF FURNITURE
The present invention relates to a shelf-supporting device (10,10') for the reversible connection of a shelf (100) to the shoulders (200) of a piece of furniture, of the type configured for being inserted into a seat (101) formed within the thickness of said shelf (100), and comprising a main body (12) which is slidingly associated with a connection pin (11) movable between an advanced operating position in which said pin (11) protrudes from said shelf (100) so as to be able to be inserted into a housing seat (201) formed on one of said shoulders (200), and a retracted non-operating position in which said pin (11) does not protrude from said shelf (100) or protrudes so as to be able to be released from said housing seat (201). The device is characterized in that said pin (11) is associated with axial movement means (30) of said pin (11) which can be actuated by the user by means of the magnetic interaction between said movement means (30) and an external actuation device (60).
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
24.
Telescopic foot for furniture and/or furnishing items with simplified assembly and system using said foot
A telescopic foot for furniture and/or furnishing items includes a hollow body housing a supporting foot designed for telescopically sliding therein using an internal control or kinematic mechanism, which is actuated by a control transmission bevel gear positioned between a first actuation opening of the bevel gear and a second telescopically sliding opening of the supporting foot, both defined in the body of the foot, one laterally and the other one axially and in orthogonal positions to each other, so as to each receive an element of the bevel gear. Sliding elements enable the sliding of the supporting foot with respect to the body of the foot, and engagement and retention elements engage the supporting foot and the hollow body of the foot.
03 - Cosmetics and toiletries; cleaning, bleaching, polishing and abrasive preparations
14 - Precious metals and their alloys; jewelry; time-keeping instruments
18 - Leather and imitations of leather
24 - Textiles and textile goods
35 - Advertising and business services
Goods & Services
Eau de Cologne; Perfumes; Air fragrancing preparations; Oils for perfumes and scents; Perfumery, essential oils; Air fragrance reed diffusers; Bath foam; Bath oil; Shampoos; Hair balsam; Toilet soap; Body and facial creams [cosmetics]; Facial cleansers [cosmetic]; Cosmetic facial lotions; Facial masks; Body and facial oils; Make-up for the face; Make-up removing preparations; Make-up; Sun care preparations for cosmetic use; Deodorants for personal use [perfumery]; Nail varnish. Jewellery; Jewellery; Paste jewellery; Time instruments; Imitation jewellery ornaments; Cases for watches [presentation]; Rings [jewellery]; Bracelets; Earrings; Pendants; Necklaces [jewellery]; Pins [jewellery]; Articles of jewellery with ornamental stones; Boxes of precious metal; Chronographs [watches]; Chronometers; Watches; Alarm clocks; Watch bands; Watch chains. Suitcases; Key cases; Luggage; Carry-on bags; Trunks [luggage]; Bags; Handbags; Briefcases [leather goods]; Bags made of imitation leather; Handbags; Shoulder bags; Cross-body bags; Bags; Work bags; Bags for sports; Travel baggage; Canvas bags; Small purses; Pocket wallets; School book bags; Credit-card holders; Bumbags; Haversacks; Travelling sets; Cosmetic cases sold empty; Attaché cases; Valises; Rucksacks; Daypacks; Umbrellas and parasols; Collars for animals; Leads for animals; Clothing for pets. Textiles for making up into articles of clothing; Kashmir fabric; Apparel fabrics; Self-adhesive cloth labels; Printed textile labels; Textiles made of cotton; Woollen cloth; Textiles made of satin; Silk [cloth]; Textiles made of velvet; Textiles made of synthetic materials; Textiles and substitutes for textiles; Linens; Curtains of textile or plastic; Household textile articles; Bed linen and blankets; Bath linen; Kitchen and table linens; Towels of textile; Place mats of textile; Table napkins of textile; Woolen blankets; Blankets for household pets; Bed throws; Mattress covers; Quilt covers; Pillowcases; Sheets [textile]; Duvets; Throws; Textiles for furnishings; Furnishing fabrics; Curtains for showers; Upholstery fabrics; Woven fabrics; Canvas; Rubberized textile fabrics. Retailing and wholesaling, also via internet, in relation to the following goods: Cosmetic preparations, Perfumery, Jewellery,clocks and watches, Panniers, Luggage, textile items, Household linen, Clothing, Headgear and footwear; arranging presentations for advertising and trade purposes; Organisation of exhibitions and trade fairs for business and promotional purposes; Presentation of goods and services on communication media, for sales purposes; Product demonstrations and product display services; Administration of business affairs; Business management for shops; Commercial intermediation services; Consultancy and assistance in setting up and managing commercial franchises; Support in the marketing of goods within a franchising system; Administrative processing of purchase orders; Import-export agency services; Sales management services; Marketing; Advertising; Advertising and sales promotion in relation to goods and services provided and ordered via telecommunications or electronic media.
A tool for controlling a controlled element (14) of a height- adjustable foot (13) of a furnishing item and the like (M) comprising : an engagement or control means (20) and a handle (12) for rotating said engagement or control means (20), said handle (12) comprising two arms (23) that embrace a diameter of said height-adjustable foot to keep the tool and the engagement or control means (20) associated laterally with the adjustable foot, said engagement or control means (20) being arranged between said two arms (23) to face each other and become engaged with said controlled element (14) for rotating said adjustable foot, wherein said engagement or control means comprises a toothing consisting of a toothed section (20) which extends distributed over a rounded area (19) of the surface between said two arms (23) of said handle (12) which engages with at least one toothing (17, 18) formed peripherally on said controlled element (14) of said adjustable foot (13), wherein the teeth of said toothed section (20) and the teeth of said at least one toothing (17, 18) of said controlled element (14) are asymmetrical and angled, enveloping, curved teeth that follow the circular trend of said controlled element (14).
A tool for controlling a controlled element (22) of a height- adjustable foot (14) of a furnishing item and the like (M) comprising : an engagement or control means (12) and a handle (15) for rotating said engagement or control means (12), said handle (15) comprising two arms (16) that embrace said controlled element (22) of said height-adjustable foot to keep the tool and the engagement or control means (12) laterally associated with the adjustable foot, said engagement or control means (12) being arranged between said two arms (16) to embrace and become engaged with said controlled element (22) for rotating said adjustable foot, wherein said engagement or control means comprises a toothed section (12) which extends distributed within an area between said two arms (16) of said handle (15) which becomes engaged within radial septa or seats (21) formed in said controlled element (22) converging towards a central axis (X) of said adjustable foot (14), wherein said toothed section is in the form of an arched and rounded tooth (12) rising towards one of its free ends in the direction from one arm (16) to the other.
A tool for controlling a controlled element (22) of a height- adjustable foot (14) of a furnishing item and the like (M) comprising : an engagement or control means (12) and a handle (15) for rotating said engagement or control means (12), said handle (15) comprising two arms (16) that embrace said controlled element (22) of said height-adjustable foot to keep the tool and the engagement or control means (12) laterally associated with the adjustable foot, said engagement or control means (12) being arranged between said two arms (16) to embrace and become engaged with said controlled element (22) for rotating said adjustable foot, wherein said engagement or control means comprises a toothed section (12) which extends distributed within an area between said two arms (16) of said handle (15) which becomes engaged within radial septa or seats (21) formed in said controlled element (22) converging towards a central axis (X) of said adjustable foot (14), wherein said toothed section is in the form of an arched and rounded tooth (12) rising towards one of its free ends in the direction from one arm (16) to the other.
A tool for controlling a controlled element (14) of a height- adjustable foot (13) of a furnishing item and the like (M) comprising : an engagement or control means (20) and a handle (12) for rotating said engagement or control means (20), said handle (12) comprising two arms (23) that embrace a diameter of said height-adjustable foot to keep the tool and the engagement or control means (20) associated laterally with the adjustable foot, said engagement or control means (20) being arranged between said two arms (23) to face each other and become engaged with said controlled element (14) for rotating said adjustable foot, wherein said engagement or control means comprises a toothing consisting of a toothed section (20) which extends distributed over a rounded area (19) of the surface between said two arms (23) of said handle (12) which engages with at least one toothing (17, 18) formed peripherally on said controlled element (14) of said adjustable foot (13), wherein the teeth of said toothed section (20) and the teeth of said at least one toothing (17, 18) of said controlled element (14) are asymmetrical and angled, enveloping, curved teeth that follow the circular trend of said controlled element (14).
A joint for use in a piece of furniture or other furnishing item with a shoulder and a shelf, stably interconnected by the joint perpendicularly to each other, is maneuvered with an actuation and blocking system. The joint includes a pin with a fixing element, which becomes at least partially inserted in holes defined in the shoulder and the shelf, the pin having a side hole for receiving a shaped stem that extends from the actuation and blocking group of the joint. The actuation and blocking group has a 90° transmission between a maneuvering point, which is accessible from the front of the furniture, and the shaped stem, which is inserted in the side hole of the pin. Reciprocal retention elements, provided between the pin and the actuation and blocking group, withhold the pin in the hole of the shelf housing the pin.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
32.
Attachment for furniture feet adjustable in height
An attachment for furniture feet adjustable in height with respect to a piece of furniture includes a body having a seat adapted to firmly receive an upper end of a foot adjustable in height, four pass-through openings for the passage of a maneuvering tool of an adjustment mechanism of at least one additional foot adjustable in height, the openings being arranged at 90° with respect to each other and lying along two symmetry axes, orthogonal to each other, of the body.
An actuation and blocking system of a joint for use in a piece of furniture or other furnishing item for perpendicularly interconnecting a shoulder with a shelf, base or top includes a pin with a fixing element to the shoulder and the shelf, base or top and adapted to be at least partially inserted in a hole of the shoulder and of the shelf, base or top. The pin has a side hole for receiving a shaped stem, which extends from an actuation and blocking group of the joint positioned on the shelf, base or top parallel to the floor or the ceiling, which are close to the furniture or other furnishing item when assembled, the actuation and blocking group providing for a 90° transmission between a maneuvering point, accessible from the front or side of the furniture, and the shaped stem, inserted in the side hole of the pin.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
34.
Joining and levelling system for parts of furniture and furnishing items
A joining and leveling system for parts of furniture and furnishing items having a bottom or base and a shoulder includes, in combination, a front foot unit and a rear foot unit, wherein each of the front and rear foot units includes a maneuverable connection group with a constraining element and a leveling group with a height adjustment mechanism, wherein both the maneuverable connection group and the leveling group of the front foot and the rear foot unit can be actuated from the front with respect to the furniture through the space between the bottom or base and the floor, and wherein the connection group and the leveling group of the rear foot unit can be actuated from the front using actuation or transmission rods, of which a front end is positioned adjacent to actuation holes of the connection group and the leveling group of the front foot unit.
A foot system for parts of furniture and furnishing items with front adjustment levelling, wherein a foot (11) is positioned between a base or bottom (12) of a piece of furniture and a floor (P) in a space reduced in height (H), said foot (11) containing in its interior a height adjustment mechanism actuated from a hole or actuating point (13) by means of a maneuvering tool (14), the hole or actuating point (13) being positioned, in the system, at a lower free end of the foot (11) resting on the floor (P).
A joint for firmly interconnecting a first panel and a second panel of furniture and other furnishing items positioned perpendicular to each other is provided with at least one fixing element coupled to the first panel and includes a plurality of interconnection and blocking components for joining and firmly blocking the two panels together, wherein, in the joint, the plurality of components lie on the same plane, which is parallel and interspaced with respect to the first panel and perpendicular with respect to the second panel.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
F16B 5/00 - Joining sheets or plates to one another or to strips or bars parallel to them
F16B 12/14 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using threaded bolts or screws
A barrel for a barrel joint for parts of furniture and furnishing items includes a hollow cylindrical body containing a blocking element and having at least one hole on one of its side surfaces for the passage of a tip of a tool that actuates the blocking element, the hollow cylindrical body also having at least another hole for receiving a pin of the barrel joint.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A47B 47/04 - Cabinets, racks or shelf units, characterised by features related to dismountability or building-up from elements made mainly of wood or plastics
A joining device with minimum visibility for parts of furniture and furnishing items, in particular connecting a first panel to a second panel, which must be moved towards each other in an approach direction to bring the edge of one panel buffered in a tightening position against a surface of the other panel, includes a blocking group and a connection group assembled on the panels. The blocking group is inserted inside a seat contained in the thickness of the panel on which the blocking group is applied, and the seat has a longitudinal axis perpendicular to the approach direction, and extending from an edge towards the inside of the panels.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
F16B 12/10 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like
The present invention relates to a shelf-supporting device (1,1') suitable for effecting the reversible connection of a shelf (100) with the opposite shoulders (200) of a piece of furniture. According to the invention, the device (1, 1') comprises a main body (12) with which movable engagement means (15', 15 '') are slidingly associated to which a pin (11, 11', 11'') is connected. The movable engagement means (15', 15'') slide with respect to the main body (12) along a sliding direction (Y) between a first non-operating position wherein said pin (11) does not protrude from said shelf (100), and a second operating position in which said pin (11) protrudes outwardly from a transverse edge (B) of said shelf (100). The shelf-supporting device (1, 1') according to the invention is characterized in that said movable engagement means (15', 15''), comprising a slide, and said pin (11, 11', 11'') consist of two distinct parts, coupled together. The connection between said slide (15', 15'') and said pin (11, 11', 11'' ) can advantageously be an interference coupling, i.e. an interlocking, or a shape coupling, or another type of coupling. The advantages that the invention offers relate to both the possibility of miniaturizing the pin by drastically reducing its diameter, thus improving the aesthetic impact of the housing hole in the shoulders, and also the possibility of making the system modular with respect to the possibility of associating pins having different diameters and materials with the same device.
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
F16B 12/26 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using snap-action elements
The present invention relates to a shelf-supporting device (1,1') suitable for effecting the reversible connection of a shelf (100) with the opposite shoulders (200) of a piece of furniture. According to the invention, the device (1, 1') comprises a main body (12) with which movable engagement means (15', 15 '') are slidingly associated to which a pin (11, 11', 11'') is connected. The movable engagement means (15', 15'') slide with respect to the main body (12) along a sliding direction (Y) between a first non-operating position wherein said pin (11) does not protrude from said shelf (100), and a second operating position in which said pin (11) protrudes outwardly from a transverse edge (B) of said shelf (100). The shelf-supporting device (1, 1') according to the invention is characterized in that said movable engagement means (15', 15''), comprising a slide, and said pin (11, 11', 11'') consist of two distinct parts, coupled together. The connection between said slide (15', 15'') and said pin (11, 11', 11'' ) can advantageously be an interference coupling, i.e. an interlocking, or a shape coupling, or another type of coupling. The advantages that the invention offers relate to both the possibility of miniaturizing the pin by drastically reducing its diameter, thus improving the aesthetic impact of the housing hole in the shoulders, and also the possibility of making the system modular with respect to the possibility of associating pins having different diameters and materials with the same device.
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/24 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using separate pins, dowels, or the like
F16B 12/26 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using snap-action elements
The present invention relates to a supporting device (10, 10', 10'', 10''', 10'''', 10''''') for furniture shelves suitable for providing the reversible connection of a shelf (100) with the opposite shoulders (200) of a piece of furniture. According to the invention, the device (10, 10', 10'', 10''', 10'''', 10''''') comprises a main body (12) with which movable engagement means (15, 15', 15'', 15''') are slidingly associated, associated with a pin (11). The movable engagement means (15, 15', 15'', 15''') slide with respect to the main body (12) along a sliding direction (Y) between a first non-operating position in which said pin (11) does not protrude from said shelf (100), and a second operating position in which said pin (11) projects outwardly from a transverse edge (B) of said shelf (100). The supporting device (10) further comprises actuation means (13, 21, 32) of said engagement means (15, 15', 15'', 15''') and movement-transmission means (13b, 15c, 15b, 15c'', 20, 21b, 31) suitable for transforming the movement of said actuation means (13, 21, 32) into a translational movement along the sliding direction (Y) of said movable engagement means (15, 15', 15'', 15''').
A47B 57/20 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions with means for adjusting the height of the shelves consisting of tongues, pins or similar projecting means coacting with openings
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
The present invention relates to a supporting device (10, 10', 10'', 10''', 10'''', 10''''') for furniture shelves suitable for providing the reversible connection of a shelf (100) with the opposite shoulders (200) of a piece of furniture. According to the invention, the device (10, 10', 10'', 10''', 10'''', 10''''') comprises a main body (12) with which movable engagement means (15, 15', 15'', 15''') are slidingly associated, associated with a pin (11). The movable engagement means (15, 15', 15'', 15''') slide with respect to the main body (12) along a sliding direction (Y) between a first non-operating position in which said pin (11) does not protrude from said shelf (100), and a second operating position in which said pin (11) projects outwardly from a transverse edge (B) of said shelf (100). The supporting device (10) further comprises actuation means (13, 21, 32) of said engagement means (15, 15', 15'', 15''') and movement-transmission means (13b, 15c, 15b, 15c'', 20, 21b, 31) suitable for transforming the movement of said actuation means (13, 21, 32) into a translational movement along the sliding direction (Y) of said movable engagement means (15, 15', 15'', 15''').
A47B 57/20 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions with means for adjusting the height of the shelves consisting of tongues, pins or similar projecting means coacting with openings
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A levelling device (10,110,210) for levelling a piece of furniture (M), or parts of a piece of furniture, with respect to a supporting plane or floor (P), said piece of furniture (M) being composed of at least one horizontal element or base (11, 111, 211) and at least one vertical element or shoulder (12, 112, 212) which are firmly joined together, perpendicular to each other, with the lower or underlying surface (S) of said base (11, 111, 211) which is substantially coplanar with the lower edge (B) of said shoulder (12, 112, 212) and with the edge (B1) of said base (11, 111, 211) which is abutted against the inner surface (SI) of said shoulder (12, 112, 212), said levelling device being adjustable from above by means of a manoeuvring tool (25, 125, 215) which passes through a pass- through hole (26, 126, 226) formed through said base (11, 111, 211). According to the invention, the levelling device consists of a plate (13, 113,213) fixed to said surface (S) of the base (11, 111, 211) with a section or flap (24, 124, 224) which extends beyond said edge (B1), so as to support said shoulder (12, 112, 212) which rests on said section or flap (24, 124, 224), a sleeve or seat (15, 115, 215) also extends integrally and downwardly from said plate (13, 113, 213), where it houses movably, backwards and forwards, an adjustable foot (16,116,216) that can be manoeuvred by said tool (25,125, 225).
A joining and levelling system adapted for use in furniture and furnishing items having a bottom and a shoulder positionable with respect to a floor includes, in combination, a front foot unit and a rear foot unit, each having a connection group and a blocking group of a joining device for stably interconnecting the bottom and the shoulder. The connection group and the blocking group can be actuated from the front with respect to the furniture, the front and rear foot units being positioned beneath the bottom and facing the shoulder, and the bottom and the shoulder not resting on the floor. The front and rear foot units are disposed in an identical body for both the front and the rear foot units, and actuation rods of the joining device are arranged in the rear foot unit and positioned between the front and the rear foot units.
F16B 12/14 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using threaded bolts or screws
A joining device between two panels of furniture or other furnishing items, one (11) positioned perpendicular to the other (12), wherein a pin or plug extends from a first panel (11 or 12) and is inserted in a complementary seat of a second panel (12 or 11), a stable connection and blocking system (114) of said pin or plug being provided within said seat, with an edge (B) of a panel (11) firmly abutted against a surface (C) of the other panel (12), wherein said pin or plug is divided into two sections (521, 522), a first section provided on the first panel (11 or 12) and a second section provided on the second panel (12 or 11), releasably intercoupled with each other on a plane parallel to one of said panels (11 or 12).
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
47.
JOINING DEVICE FOR TWO PANELS OF FURNITURE OR OTHER FURNISHING ITEMS
A perfected joining device between two panels of furniture or other furnishing items, one (11) positioned perpendicular to the other (12), wherein a pin or plug extends from a first panel (11 or 12) and is inserted in a complementary seat of a second panel (12 or 11), a stable connection and blocking system (114) of said pin or plug being provided inside said seat, with an edge (B) of a panel (11) firmly abutted against a surface (C) of the other panel (12), characterized in that said pin or plug is divided into two sections (621, 622), a first section provided on the first panel (11 or 12) and a second section provided on the second panel (12 or 11), releasably intercoupled with each other with a translation movement to create a coupling between the parts followed by a 90° rotation movement on a plane (H) parallel to one of said panels (11 or 12) so as to reciprocally engage the two sections (621, 622) of the pin.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A joining device between two panels of furniture or other furnishing items, one (11) positioned perpendicular to the other (12), wherein a pin or plug extends from a first panel (11 or 12) and is inserted in a complementary seat of a second panel (12 or 11), a stable connection and blocking system (14, 114) of said pin or plug being provided within said seat, with an edge (B) of a panel (11) firmly abutted against a surface (C) of the other panel (12), wherein said pin or plug is divided into two sections (21, 22; 121, 122; 221, 222; 321, 322), a first section provided on the first panel (11 or 12) and a second section provided on the second panel (12 or 11), which can be releasably and axially intercoupled (X) with each other.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
49.
Concealed tear-resistant hanging-bracket group with precise depth adjustment
A concealed tear-resistant hanging-bracket group with precise depth adjustment for assembling a wall cupboard to a wall includes a plate and a hooking element. The plate has a plurality of fixing pins for engagement to a shoulder of the wall cupboard, and the hooking element couples the hanging-bracket group to a supporting element fixed to the wall. The hanging-bracket group is adjustable in depth and height by action of horizontal and vertical movement members. The horizontal movement member includes a threaded hole formed in a protrusion in the plate and a grub screw received in the threaded hole, a rotation of the grub screw causing a depth adjustment A guiding member for a screwdriver is coupled to the plate and includes a guiding element positioned in a pass-through opening of the plate, below and adjacent to the protrusion.
A compact front regulation system for leveling feet of furniture pieces having a bottom and shoulders includes, in combination, at least one front foot and at least one rear foot, the at least one rear foot having a regulation mechanism in height which is accessible from the outside and which can be maneuvered using a regulation tool. The at least one front foot has a pass-through hole for the regulation tool of the rear foot, the pass-through hole acting as a support and a guide for the regulation tool.
A joining and levelling system for furniture and furnishing items with a bottom and a shoulder positionable on a floor includes a front body and a rear body each having a connection group and a blocking group, adapted to stably interconnect the bottom and the shoulder, and a levelling group. The connection group, the blocking group and the levelling group can be actuated from the front of the furniture, the front body and the rear body being each positionable in lateral contact with the shoulder and beneath the bottom, actuation points of the connection group, the blocking group and the levelling group of the front and rear bodies being positionable on a horizontal plane parallel to the floor and to the bottom, adjacent to each other. A symmetry axis of the connection group coincides with or is substantially close to a center line of the front and rear bodies.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
52.
IMPROVED ACTUATION AND BLOCKING SYSTEM OF A JOINT BETWEEN A SHOULDER AND A SHELF OF A PIECE OF FURNITURE OR OTHER FURNISHING ITEMS
An improved actuation and blocking system (27) of a joint (G,G') suitable for being used in a piece of furniture or other furnishing item (M) with at least one shoulder ill) and at least one shelf or base (12) or top (13) that can be positioned for stably interconnecting by means of said joint (G,G'), said at least one shoulder (11) and at least one shelf or base (12) or top (13) arranged perpendicular to each other, said joint (G,G') comprising a pin (17) provided with fixing elements (16) to said at least one shoulder (11) and at least one shelf or base (12) or top (13) and at least partially inserted in holes (14, 23) of the shoulder (11) and of the shelf or base (12) or top (13), wherein said pin (17) comprises a side hole (31) suitable for receiving a shaped stem (30) which extends from an actuation and blocking group of the joint (27) positioned on said shelf, or base (12), or top (13) parallel to said floor (P) or said ceiling (S), said floor (P) or said ceiling (S) both being close to said furniture or other furnishing item (M) when assembled, said actuation and blocking group (27) of the joint (G,G') comprising a 90° transmission between a manoeuvring point (A), which is accessible from the front of the furniture, and said shaped stem (30), which is inserted in said side hole (31) of said pin (17), wherein reciprocal retention means (63,64) are provided between said pin (17) and said actuation and blocking group (27) of the joint (G,G'), for withholding said pin (17) in a hole (23) of the shelf or base (12) or top (13) that houses said pin (17).
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
53.
IMPROVED ACTUATION AND BLOCKING SYSTEM OF A JOINT BETWEEN A SHOULDER AND A SHELF OF A PIECE OF FURNITURE OR OTHER FURNISHING ITEMS
An improved actuation and blocking system (27) of a joint (G,G') suitable for being used in a piece of furniture or other furnishing item (M) with at least one shoulder ill) and at least one shelf or base (12) or top (13) that can be positioned for stably interconnecting by means of said joint (G,G'), said at least one shoulder (11) and at least one shelf or base (12) or top (13) arranged perpendicular to each other, said joint (G,G') comprising a pin (17) provided with fixing elements (16) to said at least one shoulder (11) and at least one shelf or base (12) or top (13) and at least partially inserted in holes (14, 23) of the shoulder (11) and of the shelf or base (12) or top (13), wherein said pin (17) comprises a side hole (31) suitable for receiving a shaped stem (30) which extends from an actuation and blocking group of the joint (27) positioned on said shelf, or base (12), or top (13) parallel to said floor (P) or said ceiling (S), said floor (P) or said ceiling (S) both being close to said furniture or other furnishing item (M) when assembled, said actuation and blocking group (27) of the joint (G,G') comprising a 90° transmission between a manoeuvring point (A), which is accessible from the front of the furniture, and said shaped stem (30), which is inserted in said side hole (31) of said pin (17), wherein reciprocal retention means (63,64) are provided between said pin (17) and said actuation and blocking group (27) of the joint (G,G'), for withholding said pin (17) in a hole (23) of the shelf or base (12) or top (13) that houses said pin (17).
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
54.
IMPROVED ATTACHMENT FOR FURNITURE FEET ADJUSTABLE IN HEIGHT
An improved attachment (11) for furniture feet adjustable in height with respect to a piece of furniture, of the type comprising: a body (12) provided with a seat (13) suitable for firmly receiving an upper end of a foot adjustable in height (15,15'), characterized in that it also comprises four pass- through openings (22) for the passage of a manoeuvring tool (23) of an adjustment mechanism of at least one further foot adjustable in height (15'), said openings (22) being arranged at 90° with respect to each other and lying along two symmetry axes (X,Y) orthogonal to each other, of said body (12).
An improved attachment (11) for furniture feet adjustable in height with respect to a piece of furniture, of the type comprising: a body (12) provided with a seat (13) suitable for firmly receiving an upper end of a foot adjustable in height (15,15'), characterized in that it also comprises four pass- through openings (22) for the passage of a manoeuvring tool (23) of an adjustment mechanism of at least one further foot adjustable in height (15'), said openings (22) being arranged at 90° with respect to each other and lying along two symmetry axes (X,Y) orthogonal to each other, of said body (12).
A telescopic foot for furniture and/or furnishing items comprising a hollow body of the foot which houses in its interior a supporting foot conceived for telescopically sliding in a lowering or lifting position with respect to said body of the foot by means of an internal control mechanism or kinematic mechanism, characterized in that said internal control mechanism or kinematic mechanism is actuated by means of a control transmission bevel gear (29, 30, 31) positioned between a first actuation opening (35) of said bevel gear and a second telescopically sliding opening (54) of said supporting foot (21, 121, 221, 321), said first and second opening (35, 54) being obtained in said body of the foot (20, 120, 220, 320), one lateral and the other axial to the body of the foot and being positioned orthogonally to each other, to each receive an element of said bevel gear V29,30,31), means being provided which allow the sliding of the supporting foot (21, 121, 221, 321) with respect to the body of the foot (20, 120, 220, 320), engagement and retention means (40) between said supporting toot (21, 121, 221, 321) and said hollow body of the toot (20, 120, 220, 320), also being provided.
A telescopic foot for furniture and/or furnishing items comprising a hollow body of the foot which houses in its interior a supporting foot conceived for telescopically sliding in a lowering or lifting position with respect to said body of the foot by means of an internal control mechanism or kinematic mechanism, characterized in that said internal control mechanism or kinematic mechanism is actuated by means of a control transmission bevel gear (29, 30, 31) positioned between a first actuation opening (35) of said bevel gear and a second telescopically sliding opening (54) of said supporting foot (21, 121, 221, 321), said first and second opening (35, 54) being obtained in said body of the foot (20, 120, 220, 320), one lateral and the other axial to the body of the foot and being positioned orthogonally to each other, to each receive an element of said bevel gear V29,30,31), means being provided which allow the sliding of the supporting foot (21, 121, 221, 321) with respect to the body of the foot (20, 120, 220, 320), engagement and retention means (40) between said supporting toot (21, 121, 221, 321) and said hollow body of the toot (20, 120, 220, 320), also being provided.
A joining and levelling system for parts of furniture and furnishing items comprising a bottom or base (12) and at least one shoulder (11) of the type comprising, in combination, at least one front foot unit (15) and at least one rear foot unit (16), wherein each front and rear foot unit (15,16) comprises a maneuverable connection group with a constraining element and a levelling group with a height adjustment mechanism, wherein both said connection group and said levelling group of said front foot and rear foot unit (15,16) can be actuated from the front with respect to the furniture through the space between the base and the floor, wherein in said system, said connection group and levelling group of said at least one rear foot unit (16) can be actuated from the front by means of actuation or transmission rods (35,36) of which a front end (37,38) is positioned adjacent to actuation holes (28,29) of said connection group and levelling group of said at least one front foot unit (15).
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
59.
SUPPORTING DEVICE FOR A CANTILEVERED TUBULAR STRUCTURE
A supporting device for a cantilevered tubular structure (11), comprising a tubular structure (11) in turn comprising at least one tubular element (13) facing a supporting wall (12) wherein said at least one tubular element (13) provides an opening (14) facing said supporting wall (12), the device comprising in combination: a first hook portion (15) fixed to said at least one tubular element (13) and a second positionable supporting portion (16) fixed to said supporting wall (12), adjustment mechanisms of the positions in depth (horizontal) and height (vertical) of said first hook portion (15) with respect to said second supporting portion (16), being associated with said first hook portion (15), characterized in that said first hook portion (15) can be positioned inside said at least one tubular element (13) and is constrained in correspondence with said opening (14).
An actuation and blocking system of a joint suitable for being used in a piece of furniture or other furnishing item (M) with at least one shoulder (11) and at least one shelf or base (12) or top (13) that can be positioned for stably interconnecting, by means of a joint (G), said at least one shoulder (11) and at least one shelf or base (12) or top (13) arranged perpendicular to each other, said joint (G) providing a pin (17) equipped with fixing elements to said at least one shoulder (11) and at least one shelf or base (12) or top (13) and at least partially inserted in holes (14, 23) of the shoulder (11) and of the shelf or base (12) or top (13), characterized in that said pin (17) provides a side hole (31) suitable for receiving a shaped stem (30) which extends from an actuation and blocking group (27) of the joint (G) positioned on said shelf, or base (12), or top (13) parallel to said floor (P) or said ceiling (S), said floor (P) or said ceiling (S) both being close to said furniture or other furnishing item (M) when assembled, said actuation and blocking group (27) of the joint (G) providing a 90° transmission between a maneuvering point (A), which is accessible from the front or side of the furniture, and said shaped stem (30), which is inserted in said side hole (31, 18) of said pin (17).
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
61.
Front adjustment system for leveling feet for furniture
F16M 7/00 - Details of attaching or adjusting engine beds, frames, or supporting-legs on foundation or baseAttaching non-moving engine parts, e.g. cylinder blocks
The present invention relates to a cable tube (10) for furniture (18). The cable tube is composed of the combination of a foldable and extensible helical cylindrical spring (11), whose coils (13) are applied and constrained to a sleeve (12) made of flexible material, said tube (10) being provided at opposite ends with a ballasted base (15) for resting on the floor, and connection means (17) to said furniture (18).
F16L 3/015 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets for supporting or guiding the pipes, cables or protective tubing, between relatively movable points, e.g. movable channels using articulated- or supple-guiding elements
A47B 21/06 - Tables or desks specially adapted for use at individual computer workstations, e.g. for word processing or other manual data entryTables or desks specially adapted for typingAuxiliary devices for attachment to such tables or desks characterised by means for holding, fastening or concealing cables
H02G 3/04 - Protective tubing or conduits, e.g. cable ladders or cable troughs
A47B 97/00 - Furniture or accessories for furniture, not provided for in other groups of this subclass
63.
Joint for the firm interconnection of a first and a second panel of furniture and other furnishing items
A joint for firmly interconnecting a first panel and a second panel of furniture and other furnishing items positioned perpendicular to each other is provided with at least one fixing element coupled to the first panel and includes a plurality of interconnection and blocking components for joining and firmly blocking the two panels together, wherein, in the joint, the plurality of components lie on the same plane, which is parallel and interspaced with respect to the first panel and perpendicular with respect to the second panel.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
F16B 5/00 - Joining sheets or plates to one another or to strips or bars parallel to them
F16B 12/14 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using threaded bolts or screws
A compact joint for connecting a first panel to a second panel of furniture and other furnishing items, positioned perpendicular to each other, includes a plurality of interconnection and blocking components for joining and firmly blocking the two panels together. The plurality of components of interconnection and blocking components lies on the same plane, which is perpendicular to the first and second panels and which contains a coupling axis between the first and second panels that travels inside the first panel. The joint also defines an actuation axis that is perpendicular to the coupling axis and lies on a plane parallel and interspaced with respect to the first panel and perpendicular with respect to the second panel.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
65.
Foot system for parts of furniture and furnishing items with front adjustment levelling
A foot system for parts of furniture and furnishing items with front adjustment levelling, wherein a foot (11) is positioned between a base or bottom (12) of a piece of furniture and a floor (P) in a space reduced in height (H), said foot (11) containing in its interior a height adjustment mechanism actuated from a hole or actuating point (13) by means of a manoeuvring tool (14), the hole or actuating point (13) being positioned, in the system, at a lower free end of the foot (11) resting on the floor (P).
A hidden joining system with front activation for a bottom of a piece of furniture and furnishing items includes a front joining unit and a rear joining unit positioned between a bottom and a shoulder of the furniture, wherein each front and rear joining unit is attached beneath the thickness of the bottom of the furniture, wherein symmetry axes of the two front and rear joining units lie on a plane external and parallel to a center plane of the bottom and the front joining unit has a transmission element toward the rear joining unit.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A47B 47/04 - Cabinets, racks or shelf units, characterised by features related to dismountability or building-up from elements made mainly of wood or plastics
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
67.
Concealed hanging-bracket group with anti-disengagement having easy access to adjustments
A concealed hanging-bracket group (10) with anti-disengagement having easy access to adjustments for the wall assembly of a wall cupboard (M) comprising a plate element (11), provided with a plurality of fixing pins (12,12′,12″) that can be coupled in holes produced on a shoulder (S) of the wall cupboard (M) which extend from at least one side of the plate element (11), and a hooking element (14) of the hanging bracket with a supporting element (50) fixed to the wall, adjustably coupled in the front with the plate element (11) in depth (K) and in height (H) and provided with an upper hook-shaped portion (15), means (16,17) for horizontally and vertically moving the hooking element (14) with respect to the plate element (11) and anti-disengagement means (18) of the hanging bracket also being provided, wherein an element (24,57) is provided in the plate element (11) having a threaded hole (25,58) for an adjustment grub screw (26) in depth, a guide (47) for a screwdriver and a stop (48) for a tip of the screwdriver (42) also being provided in the element (24,57).
A joining system for use in furniture and furnishing items with a bottom and a shoulder has a front actuation axis under the bottom and includes a front joining unit and a rear joining unit positioned between the bottom and the shoulder of the furniture or furnishing item. A connection group is inserted in each front and rear joining unit and is aligned with a symmetry axis of the bottom, and a blocking group of the front and rear joining units is attached beneath the thickness of the bottom. The front joining unit provides an actuation and supporting member toward the rear joining unit, and the blocking group provides a grub screw inserted in a casing and caused to slide by way of a conical rack and pinion system, to be received in a bevel in the pin.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
An anti-disengagement system that can be automatically activated for a hidden hanging bracket of a wall cupboard is employed to prevent the disengagement of a wall cupboard hooked to a support, fixed to a wall, with a movable hook having a curved hooking tooth forming part of a hanging bracket coupled to the wall cupboard at the rear. Elastically yielding engagement elements are automatically snap-activated upon insertion of the curved hooking tooth into a housing of the support.
A joining system with a leveller for parts of furniture and furnishing items with a bottom (12) and shoulders (11) of the type comprising, in combination: at least one unit with a front foot (14) and at least one unit with a rear foot (15), wherein each front- and rear-foot unit (14, 15) comprises a connection group (GC) and a blocking group (GB) and a levelling group (GL) that can be maneuvered by means of tools, wherein the connection group (GC) and blocking group (GB) of the front- and rear-foot units (14, 15) can be actuated from the front with respect to the piece of furniture through the space between the bottom (12) and the floor, where as the levelling group (GL) of each front- and rear-foot unit (14, 15) can be maneuvered by means of a tool (35) that can be inserted in a small hole (34) formed in the bottom (12) above, and aligned with each front foot and rear foot (14, 15).
F16M 7/00 - Details of attaching or adjusting engine beds, frames, or supporting-legs on foundation or baseAttaching non-moving engine parts, e.g. cylinder blocks
71.
CONCEALED TEAR-RESISTANT HANGING-BRACKET GROUP WITH PRECISE DEPTH ADJUSTMENT
A concealed tear-resistant hanging-bracket group with precise depth adjustment for the wall assembly of a wall cupboard (M), comprising a plate element (11), provided with a plurality of fixing pins (12, 12 ', 12"), which can be coupled in holes formed on a shoulder (SP) of a wall cupboard (M), and a hooking element (14) of the hanging bracket with a supporting element (SU) fixed to the wall (P) adjustable in depth (K) and height (H) and provided with an upper hook-shaped portion (15). Horizontal and vertical movement means (16,17) of the hooking element (14) are also provided with respect to the plate element (11), wherein it is also provided that the horizontal movement means (16) comprise a threaded hole (20) for a grub screw (21) for adjustment in depth and that guiding means for a screwdriver are associated with said movement means, wherein the threaded hole (20) is formed in a deep- drawn protrusion (19) obtained by deep-drawing in the plate (11) and the guiding means for a screwdriver comprise a moulded guiding element (38) positioned by means of riveting in a pass-through opening (37) of the plate (11), wherein the guiding element (38) is positioned beneath the protrusion (19) and above supports (27) of the vertical movement means (17).
A joining system between a supporting plane (11) and a tubular element (12, 112, 212, 312) of the type comprising, in combination: a first male part (13, 113, 213, 313) and a female part (14, 114, 214, 314) suitable for being intercoupled, and fixing means acting between said two male and female parts to make the junction between said plane and tubular element stable. According to the invention said second female part (14, 114, 214, 314) is fixed beneath said supporting plane (11) and is provided with an annular collar (20) in which said fixing means are housed with an arrangement concealed from sight.
A joining and levelling system suitable for being used in furniture and furnishing items (M) with a bottom (12) and at least one shoulder (11) positionable with respect to a floor (P) comprising, in combination, at least one front foot unit (14,114) and at least one rear foot unit (15,115), wherein each front and rear foot unit (14,15; 114,115) comprises at least one connection group (GC) and a blocking group (GB) of a joining device for stably interconnecting the bottom (12) and the at least one shoulder, wherein the connection group (GC) and the blocking group (GB) of the joining device can be actuated from the front with respect to the furniture, wherein the at least one front foot unit (14,114) and the at least one rear foot unit (15,115) are positioned beneath the bottom (12) and facing the at least one shoulder (11), wherein the bottom (12) and the at least one shoulder (11) do not rest on the floor, wherein the at least one front foot unit (14,114) and the at least one rear foot unit (15,115) are positioned in an identical body (16,116) for both the at least one front foot unit (14,114) and the at least one rear foot unit (15,115), and actuation rods (36) of the joining device are provided, arranged in the at least one rear foot unit (15,115), positioned between the at least one front foot unit (14,114) and the at least one rear foot unit (15,115).
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A tool guiding device suitable for being used in the assembly and adjustment step of furniture or furnishing items that provide at least one shoulder (12) and a bottom (13), wherein front bodies (14) and rear bodies (15) each containing at least one joining group (35,37) between the shoulder (12) and the bottom (13), are positioned beneath the bottom (13), the device comprising a parallelepiped body (18) in which at least two housings (A, B, C and D) are formed for guiding a rod with a tip (19) of a tool (20), a channel (21, 22, 23 and 24) extends in each of the at least two housings (A, B, C and D), hollowed in the upper part of the body (18), which protrudes from a rear surface (25) of the body (18) in correspondence with respective openings (26, 27, 28 and 29) positionable towards said front bodies (14) and rear bodies (15) containing said at least one joining group, at least one transmission rod (34) being provided between said front body (14) and said at least one joining group (37) of said rear body (15)
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A joining and levelling system suitable for being used in furniture and furnishing items (M) with a bottom (12) and at least one shoulder (11) positionable with respect to a floor (P), said system comprising, in combination, at least a front body (14) and at least a rear body (15), wherein each front and rear body (14,15) comprises at least one connection group (GC) and a blocking group (GB) of a joining device, suitable for stably interconnecting said bottom (12) and said at least one shoulder and a levelling group (21), wherein said connection group (GC), said blocking group (GB) of the joining device and said levelling group (21) can be actuated from the front of the furniture, wherein said front body (14) and said rear body (15) are positionable with its short side in lateral contact with said shoulder (11) and beneath said bottom (12) and actuation points of said connection group (GC), blocking group (GB) and levelling group (21) of said front and rear bodies (14,15) are positionable on a horizontal plane parallel to said floor and to said bottom (12), adjacent to each other, in which in said system a symmetry axis (X) of said connection group (GC) coincides with or is substantially close to a centre line of said bodies (14,15).
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
76.
JOINING AND LEVELLING SYSTEM FOR PARTS OF FURNITURE AND FURNISHING ITEMS WITH MINIMUM ENCUMBRANCE
A joining and levelling system suitable for being used in furniture and furnishing items (M) with a bottom (12) and at least one shoulder (11) positionable with respect to a floor (P), said system comprising, in combination, at least one front foot unit (14,114) and at least one rear foot unit (15,115), wherein each front and rear foot unit (14,15; 114,115) comprises at least one connection group (GC) and a blocking group (GB) of a joining device for stably interconnecting said bottom (12) and said at least one shoulder (11), wherein said connection group (GC) and said blocking group (GB) of the joining device can be actuated from the front of the furniture, wherein said at least one front foot unit (14,114) and said at least one rear foot unit (15,115) are positionable beneath both said bottom (12) and said at least one shoulder (11), wherein said bottom (12) and said at least one shoulder (11) do not rest on the floor, in which in said system each front and rear foot unit (14,15) also comprises a levelling device (GL) with a height adjustment mechanism manoeuvrable by means of a tool, wherein said levelling device (GL) of said front and rear foot units (14,15) can be actuated from the front of the furniture.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A system for the assembly of wall panels, in particular panels with a vertical development, comprising at least two uprights (12) spaced apart from each other and at least one panel with a vertical development (11), wherein : - each of the uprights (12) provides slots (13) having narrow extensions or slits (14, 14') in a vertical direction, spaced apart from each other, fixing elements (19, 20) of the upright to a vertical wall (PV) and a lower levelling group (GLM) of the upright ( 12 ), - the at least one panel with a vertical development (11) provides, on its rear surface (26), facing the uprights (12) and the vertical wall (PV), a series of supporting pins (25, 25'), protruding from said rear surface (26) and which are inserted in slots (13) and/or narrow extensions or slits (14, 14') of the uprights (12), and, at one of its lower ends, levelling groups of the panel (GLP) which allow an adjustment of the position of the panel (11) in a vertical direction and a stable housing of the supporting pins (25, 25') in narrow extensions or slits (14, 14') of the uprights (12).
E04F 13/08 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements
A47B 57/10 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions with means for adjusting the height of the shelves consisting of grooved or notched ledges, uprights or side walls the grooved or notched parts being the side walls or uprights themselves
A47B 57/20 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions with means for adjusting the height of the shelves consisting of tongues, pins or similar projecting means coacting with openings
E04B 2/74 - Removable non-load-bearing partitionsPartitions with a free upper edge
78.
Compact joining and leveling system for parts of furniture and furnishing items
A compact joining and leveling system for parts of furniture and furnishing items with a bottom and a shoulder includes, in combination, a front-foot unit and a rear-foot unit, wherein each front- and rear-foot unit includes a leveling group with a regulation mechanism in height that can be maneuvered with tools, wherein the leveling group of the front-and rear-foot units can be actuated from the front with respect to the piece of furniture through the space between the base and the floor, wherein the system also includes a connection group for stably interconnecting the bottom and the shoulder through a blocking element, and wherein the connection group can be actuated from the front with respect to the piece of furniture through the space between the bottom and the floor.
A47B 96/07 - Brackets or similar supporting means for cabinets, racks or shelves adjustable in themselves
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
79.
Barrel for a barrel joint for parts of furniture and furnishing items
A barrel for a barrel joint for parts of furniture and furnishing items includes a hollow cylindrical body containing a blocking element and having at least one hole on one of its side surfaces for the passage of a tip of a tool that actuates the blocking element, the hollow cylindrical body also having at least another hole for receiving a pin of the barrel joint.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A47B 47/04 - Cabinets, racks or shelf units, characterised by features related to dismountability or building-up from elements made mainly of wood or plastics
80.
Compact front regulation system for leveling feet for furniture
A compact front regulation system for leveling feet of furniture pieces having a bottom and shoulders includes, in combination, at least one front foot and at least one rear foot, the at least one rear foot having a regulation mechanism in height which is accessible from the outside and which can be maneuvered using a regulation tool. The at least one front foot has a pass-through hole for the regulation tool of the rear foot, the pass-through hole acting as a support and a guide for the regulation tool.
A hidden joining device for parts of furniture and furnishing items, in particular between a first panel, such as a shoulder of a piece of furniture, and a second panel, such as a base or shelf or top of a piece of furniture, which must be moved toward each other along an approach direction to bring the edge of one panel abutted in a tightening position against a surface of the other panel, includes a blocking group and a connection group coupled to those panels The blocking group is inserted inside a seat that is contained in the thickness of the panel on which the blocking group is applied. The seat has an axis perpendicular to the approach direction and extends from a rear edge of the panels toward the interior of the panels, forming a single visible hole in the two panels when connected.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
A compact front adjustment system for leveling feet for furniture (M) with a bottom (12) and shoulders (11), comprising: at least two front feet, a right foot (13d) and a left foot (13s) and at least two rear feet, a right foot (14d) and a left foot (14s), wherein each of said rear feet (14d,14s) comprises an adjustment mechanism in height, which is accessible from outside the foot through respective holes (21d,21s) and which can be maneuvered by means of a maneuvering tool (18). According to the invention, a respective supporting and guiding unit (17d,17s; 22;25) for said maneuvering tool (18) is provided in combination with said rear feet (14d,14s), said unit being assembled on said bottom (12) of the furniture (M) in an intermediate position between said front feet (13d,13s) according to an axis X which is aligned with said holes (21d,21s) for access to the adjustment mechanism in height of the respective rear foot (14d,14s).
The present invention relates to a cable tube (10) for furniture (18). The cable tube is composed of the combination of a foldable and extensible helical cylindrical spring (11), whose coils (13) are applied and constrained to a sleeve ( 12 ) made of flexible material, said tube (10) being provided at opposite ends with a ballasted base (15) for resting on the floor, and connection means ( 17 ) to said furniture (18).
A47B 21/06 - Tables or desks specially adapted for use at individual computer workstations, e.g. for word processing or other manual data entryTables or desks specially adapted for typingAuxiliary devices for attachment to such tables or desks characterised by means for holding, fastening or concealing cables
A47B 97/00 - Furniture or accessories for furniture, not provided for in other groups of this subclass
F16L 3/015 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets for supporting or guiding the pipes, cables or protective tubing, between relatively movable points, e.g. movable channels using articulated- or supple-guiding elements
A joining device with wide accessibility for parts of furniture and furnishing items, of a first panel to a second panel to be moved towards each other to bring an edge of the second panel abutted in a tightening position against a surface of the first panel, includes a blocking group and a connection group. The blocking group is inserted inside a seat defined within the first panel and receiving the blocking group, and includes a toothed crown, which is housed in a casing positioned in a first holing in the first panel and which controls the movement of a grub screw engaging a pin of the connection group. The casing includes a pair of half-shells that can be coupled with each other and that each contain a hole that is aligned on the two half-shells and with an additional holing of the shoulder intersecting the first holing.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
85.
IMPROVED FRONT ADJUSTMENT SYSTEM FOR LEVELING FEET FOR FURNITURE
A compact front adjustment system for leveling feet for furniture (M) with a bottom (12) and shoulders (11), comprising: at least two front feet, a right foot (13d) and a left foot (13s) and at least two rear feet, a right foot (14d) and a left foot (14s), wherein each of said rear feet (14d,14s) comprises an adjustment mechanism in height, which is accessible from outside the foot through respective holes (21d,21s) and which can be maneuvered by means of a maneuvering tool (18). According to the invention, a respective supporting and guiding unit (17d,17s; 22;25) for said maneuvering tool (18) is provided in combination with said rear feet (14d,14s), said unit being assembled on said bottom (12) of the furniture (M) in an intermediate position between said front feet (13d,13s) according to an axis X which is aligned with said holes (21d,21s) for access to the adjustment mechanism in height of the respective rear foot (14d,14s).
The present invention relates to a cable tube (10) for furniture (18). The cable tube is composed of the combination of a foldable and extensible helical cylindrical spring (11), whose coils (13) are applied and constrained to a sleeve ( 12 ) made of flexible material, said tube (10) being provided at opposite ends with a ballasted base (15) for resting on the floor, and connection means ( 17 ) to said furniture (18).
F16L 3/015 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets for supporting or guiding the pipes, cables or protective tubing, between relatively movable points, e.g. movable channels using articulated- or supple-guiding elements
H02G 11/00 - Arrangements of electric cables or lines between relatively-movable parts
A47B 21/06 - Tables or desks specially adapted for use at individual computer workstations, e.g. for word processing or other manual data entryTables or desks specially adapted for typingAuxiliary devices for attachment to such tables or desks characterised by means for holding, fastening or concealing cables
H02G 3/04 - Protective tubing or conduits, e.g. cable ladders or cable troughs
An adjustable anchoring group for the wall assembly of wall-cupboards includes a hanging bracket device, provided with an anchoring base to a wall-cupboard and a hooking element; an anchoring support to a wall; a regulation system; and an actuation system of the reciprocal position between the hanging bracket device, the hooking element and the anchoring support to effect a regulation in the position of the wall-cupboard with respect to the wall, according to two directions perpendicular to each other. Both the regulation member and the actuation member are accessible from both below and above for controlling both the regulation member and the actuation member from both sides.
F16H 1/16 - Toothed gearings for conveying rotary motion without gears having orbital motion involving only two intermeshing members with non-parallel axes comprising worm and worm-wheel
88.
Joining device with minimum visibility for parts of furniture and furnishing items
A joining device with minimum visibility for parts of furniture and furnishing items, in particular connecting a first panel to a second panel, which must be moved towards each other in an approach direction to bring the edge of one panel buffered in a tightening position against a surface of the other panel, includes a blocking group and a connection group assembled on the panels. The blocking group is inserted inside a seat contained in the thickness of the panel on which the blocking group is applied, and the seat has a longitudinal axis perpendicular to the approach direction, and extending from an edge towards the inside of the panels.
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
F16B 12/10 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like
89.
CONCEALED HANGING-BRACKET GROUP WITH ANTI-DISENGAGEMENT HAVING EASY ACCESS TO ADJUSTMENTS
A concealed hanging-bracket group with anti-disengagement having easy access to adjustments for a wall assembly of a wall cupboard is provided. The hanging bracket group includes a plate element having an appendix. The appendix comprises a threaded hole for receiving an adjustment grub screw in depth, a guide configured for guiding a screwdriver, and a stop configured for stopping a tip of said screwdriver. The appendix extends from an end of a window formed in said plate element in a half blanking process and is box-folded on a front part of the plate element to form a containment casing of at least part of both the movement means for horizontally and vertically moving said hooking element with respect to said plate element.
A foot system for parts of furniture and furnishing items with front adjustment levelling, wherein a foot (11) is positioned between a base or bottom (12) of a piece of furniture and a floor (P) in a space reduced in height (H), said foot (11) containing in its interior a height adjustment mechanism actuated from a hole or actuating point (13) by means of a manoeuvring tool (14), the hole or actuating point (13) being positioned, in the system, at a lower free end of the foot (11) resting on the floor (P).
A concealed hanging-bracket group (10) with easy access to adjustments for the wall assembly of a wall cupboard (M) comprising a plate element (11), provided with a plurality of fixing pins (12, 12', 12"), that can be coupled in holes formed, on a shoulder (S) of the wall cupboard (M) which extend from a side of the plate element (11), and. a hooking element (14) of the hanging bracket with a supporting element (50) fixed, to the wall, adjustably coupled in the front with, the plate element (11) in depth (K) and in height (H) and provided with an upper hook-shaped portion (15), means (16,17) for horizontally and vertically moving the hooking element (14) with respect to the plate element (11) also being provided, wherein an appendix (24) is provided in the plate element (11), produced by means of a half-blanking phase of a window (23) in the plate (11), the appendix (24) being box- folded to form a containment casing of at least part of adjustments of the movement means (16,17).
A concealed hanging-bracket group (10) with anti-disengagement having easy access to adjustments for the wall assembly of a wall cupboard (M) comprising a plate element (11), provided with a plurality of fixing pins (12, 12', 12") that can be coupled in holes produced on a shoulder (S) of the wall cupboard (M) which extend from at least one side of the plate element (11), and a hooking element (14) of the hanging bracket with a supporting element (50) fixed to the wall, adjustably coupled in the front with the plate element (11) in depth (K) and in height (H) and provided with an upper hook-shaped portion (15), means (16, 17) for horizontally and vertically moving the hooking element (14) with respect to the plate element (11) and anti-disengagement means (18) of the hanging bracket also being provided, wherein an element (24, 57) is provided in the plate element (11) having a threaded hole (25, 58) for an adjustment grub screw (26) in depth, a guide (47) for a screwdriver and a stop (48) for a tip of the screwdriver (42) also being provided in the element (24, 57).
A foot system for parts of furniture and furnishing items with front adjustment levelling, wherein a foot (11) is positioned between a base or bottom (12) of a piece of furniture and a floor (P) in a space reduced in height (H), said foot (11) containing in its interior a height adjustment mechanism actuated from a hole or actuating point (13) by means of a manoeuvring tool (14), the hole or actuating point (13) being positioned, in the system, at a lower free end of the foot (11) resting on the floor (P).
A joining system suitable for being used in furniture and furnishing items with a bottom (12) and a shoulder (11) with a front actuation axis under said bottom (12) of a piece of furniture and furnishing items comprising, in combination: at least one front joining unit (UGA) and at least one rear joining unit (UGP) positioned between said bottom (12) and at least one shoulder (11) of the furniture (M), wherein a connection group (GC) is inserted in each front and rear joining unit (UGA, UGP) aligned with a symmetry axis (X) of said bottom (12) and a blocking group (GB) of each front and rear joining unit (UGA, UGP) is arranged attached beneath the thickness of said bottom (12) of the furniture, said at least one front joining unit (UGA) providing actuation and supporting means (40'; 13, 14; 213, 214) towards said at least one rear joining unit (UGP), said blocking group (GB) provides a grub screw (24) inserted in a casing (38) and caused to slide by means of a pinion-toothed crown bevel (23) of a pin (21) forming part of said connection group (GC).
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
95.
HIDDEN JOINING SYSTEM WITH FRONT ACTIVATION FOR A BOTTOM OF FURNITURE AND FURNISHING ITEMS
A hidden joining system with front activation for a bottom of a piece of furniture and furnishing items comprising, in combination: at least one front joining unit (UGA) and at least one rear joining unit (UGP) positioned between a bottom (12) and at least one shoulder (11) of the furniture(M), wherein each front and rear joining unit (UGA, UGP)is arranged attached beneath the thickness of the bottom (12) of the furniture, wherein symmetry axes (X) of the two front and rear joining units (UGA, UGP)of the bottom (12) to the shoulder (11) lie on a plane (A) external and parallel to a centre plane of the bottom (12) and at least one front joining unit (UGA) provides a transmission element (13, 14; 114) towards the at least one rear joining unit (UGP).
A47B 47/04 - Cabinets, racks or shelf units, characterised by features related to dismountability or building-up from elements made mainly of wood or plastics
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A hidden joining system with front activation for a bottom of a piece of furniture and furnishing items comprising, in combination: at least one front joining unit (UGA) and at least one rear joining unit (UGP) positioned between a bottom (12) and at least one shoulder (11) of the furniture(M), wherein each front and rear joining unit (UGA, UGP)is arranged attached beneath the thickness of the bottom (12) of the furniture, wherein symmetry axes (X) of the two front and rear joining units (UGA, UGP)of the bottom (12) to the shoulder (11) lie on a plane (A) external and parallel to a centre plane of the bottom (12) and at least one front joining unit (UGA) provides a transmission element (13, 14; 114) towards the at least one rear joining unit (UGP).
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
A47B 47/04 - Cabinets, racks or shelf units, characterised by features related to dismountability or building-up from elements made mainly of wood or plastics
A47B 96/06 - Brackets or similar supporting means for cabinets, racks or shelves
97.
JOINING SYSTEM WITH FRONT ACTUATION AXIS FOR FURNITURE
A joining system suitable for being used in furniture and furnishing items with a bottom (12) and a shoulder (11) with a front actuation axis under said bottom (12) of a piece of furniture and furnishing items comprising, in combination: at least one front joining unit (UGA) and at least one rear joining unit (UGP) positioned between said bottom (12) and at least one shoulder (11) of the furniture (M), wherein a connection group (GC) is inserted in each front and rear joining unit (UGA, UGP) aligned with a symmetry axis (X) of said bottom (12) and a blocking group (GB) of each front and rear joining unit (UGA, UGP) is arranged attached beneath the thickness of said bottom (12) of the furniture, said at least one front joining unit (UGA) providing actuation and supporting means (40'; 13, 14; 213, 214) towards said at least one rear joining unit (UGP), said blocking group (GB) provides a grub screw (24) inserted in a casing (38) and caused to slide by means of a pinion-toothed crown bevel (23) of a pin (21) forming part of said connection group (GC).
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
98.
JOINING SYSTEM WITH LEVELLER FOR PARTS OF FURNITURE AND FURNISHING ITEMS
A joining system with a leveller for parts of furniture and furnishing items with a bottom (12) and shoulders (11) of the type comprising, in combination: at least one unit with a front foot (14) and at least one unit with a rear foot (15), wherein each front-and rear-foot unit (14, 15) comprises a connection group (GC) and a blocking group (GB)and a levelling group (GL) that can be maneuvered by means of tools, wherein the connection group (GC) and blocking group (GB)of the front-and rear-foot units (14, 15) can be actuated from the front with respect to the piece of furniture through the space between the bottom (12) and the floor, where as the levelling group (GL) of each front-and rear-foot unit(14, 15) can be maneuvered by means of a tool(35) that can be inserted in a small hole (34) formed in the bottom (12) above, and aligned with each front foot and rear foot (14, 15).
A compact joint for connecting a first panel (12) and a second panel (11) of furniture and other furnishing items, positionedperpendicular to each other, wherein said joint comprises a plurality of interconnection and blocking components for joining and firmly blocking said two panels (11,12)together,wherein said plurality of components lies on the same plane (B) which is perpendicular to said first panel (12) and said second panel (11) and which contains a coupling axis (X) between said panels (12,11),said coupling axis (X) being inside said first panel (12), said joint also providing an actuation axis (Z). According to the invention,the actuation axis of the joint (Z) is perpendicular to the axis (X) and lies on a plane (P) which is parallel and interspaced with respect to the first panel (12) and perpendicular with respect to the second panel (11).
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
100.
JOINT FOR THE FIRM INTERCONNECTION OF A FIRST AND A SECOND PANEL OF FURNITURE AND OTHER FURNISHING ITEMS
A joint for firmly interconnecting a first panel (12) and a second panel (11) of furniture and other furnishing items positioned perpendicular to each other, wherein said joint is provided with at least one fixing element ( 18) to the first panel ( 12) and comprises a plurality of interconnection and blocking components for joining and firmly blocking the two panels (11, 12) together, wherein, in the joint, the plurality of components lie on the same plane (A) which is parallel and interspaced with respect to the first panel (12) and perpendicular with respect to the second panel (11).
F16B 12/20 - Jointing of furniture or the like, e.g. hidden from exterior using pegs, bolts, tenons, clamps, clips, or the like for non-metal furniture parts, e.g. made of wood, of plastics using clamps, clips, wedges, sliding bolts, or the like
