A cabinet including a cabinet box, at least one door coupled to the cabinet box to form a storage compartment and an accessory system comprising a track and an adjustable mirror, wherein the track is mounted to an inner surface of the at least one door and the adjustable mirror is configured to slidably engage the track.
A cabinet including a cabinet box, at least one door coupled to the cabinet box to form a storage compartment and an accessory system comprising a track and an adjustable mirror, wherein the track is mounted to an inner surface of the at least one door and the adjustable mirror is configured to slidably engage the track.
G02B 7/182 - Mountings, adjusting means, or light-tight connections, for optical elements for prismsMountings, adjusting means, or light-tight connections, for optical elements for mirrors for mirrors
A47B 67/00 - ChestsDressing-tablesMedicine cabinets or the likeCabinets characterised by the arrangement of drawers
A47B 67/02 - Cabinets for shaving tackle, medicines, or the like
A mirror assembly (10) including a mirror (100) having a fixed mirror portion (105) and an adjustable mirror portion (103), a frame (30) having a shape that corresponds to at least a portion of the fixed mirror portion and configured to be attached to a structure, the fixed mirror portion being attached to the frame and an adjustable member (37 comprising a proximal end attached to the frame and a distal end attached to the adjustable mirror portion.
A mirror assembly that includes a mirror having one or more box openings, a frame shaped to correspond to the shape of the mirror, a wire management assembly and a power supply assembly. The wire management assembly has one or more electrical boxes that are secured to the frame and positioned adjacent to the one or more corresponding box openings in the mirror. The wire management assembly also has at least one raceway that extends between the one or more electrical boxes and the frame. The wire management assembly provides electrical wires between the power supply assembly and one or more electrical fixtures attached to the one or more electrical boxes so that the one or more electrical fixtures are on a face side of the mirror. The power supply assembly provides electrical power to the one or more electrical fixtures.
A mirror assembly that includes a mirror having one or more box openings, a frame shaped to correspond to the shape of the mirror, a wire management assembly and a power supply assembly. The wire management assembly has one or more electrical boxes that are secured to the frame and positioned adjacent to the one or more corresponding box openings in the mirror. The wire management assembly also has at least one raceway that extends between the one or more electrical boxes and the frame. The wire management assembly provides electrical wires between the power supply assembly and one or more electrical fixtures attached to the one or more electrical boxes so that the one or more electrical fixtures are on a face side of the mirror. The power supply assembly provides electrical power to the one or more electrical fixtures.
A mirror assembly including a mirror having a fixed mirror portion and an adjustable mirror portion, a frame having a shape that corresponds to at least a portion of the fixed mirror portion and configured to be attached to a structure, the fixed mirror portion being attached to the frame and an adjustable member comprising a proximal end attached to the frame and a distal end attached to the adjustable mirror portion.
A45D 42/16 - Shaving mirrors with other suspending or supporting means
A47G 1/16 - Devices for hanging or supporting pictures, mirrors, or the like
G02B 7/198 - Mountings, adjusting means, or light-tight connections, for optical elements for prismsMountings, adjusting means, or light-tight connections, for optical elements for mirrors for mirrors with means for adjusting the mirror relative to its support
A mirror assembly including a mirror comprising a face and a reflective layer located on a rear side of the mirror, wherein the reflective layer is partitioned to have at least one touch area in a predefined location of the reflective layer and the touch area defined by the reflective layer being removed from the rear side of the mirror in a predefined shape. The mirror assembly further includes a touch controller adhered to the rear side of the mirror and comprising at least one light source, wherein the touch controller is configured to be positioned over the at least one touch area and be responsive to user touch and light emitted by the at least one source light passes through the at least one touch area such that the light is visible and usable to the user.
A mirror assembly including a mirror comprising a face (102) and a reflective layer (104) located on a rear side of the mirror, wherein the reflective layer (104) is partitioned to have at least one touch area (108,110) in a predefined location of the reflective layer and the touch area defined by the reflective layer being removed from the rear side of the mirror in a predefined shape. The mirror assembly further includes a touch controller (154) adhered to the rear side of the mirror and comprising at least one light source (158), wherein the touch controller is configured to be positioned over the at least one touch area and be responsive to user touch and light emitted by the at least one source light passes through the at least one touch area such that the light is visible and usable to the user.
A bladeless fan including a housing, an impeller within the housing, a motor within the housing for rotatably driving the impeller, an outlet device having an at least partially circular outlet, and a diffuser configured to receive air from the impeller and direct the air into the outlet device, the diffuser at least partially changing a direction of the air being directed into the outlet device.
A recessed luminaire includes a housing supporting a light emitter, an intumescent material coupled to an outer surface of the housing, and a plate coupled to the housing and to the intumescent material. The housing configured to be positioned at least partially through a ceiling. The housing also includes a stepped surface. The intumescent material has a shape complementary to a shape of the housing. The plate is positioned adjacent to the stepped surface and to an upper surface of the intumescent material.
A switch includes a first terminal, a second terminal, and a third terminal. The switch includes an output node coupled to the second terminal and the third terminal. The switch includes a contactor coupled to the first terminal and movable between at least a first position and a second position. The first terminal is coupled to the second terminal when the contactor is in the first position. The first terminal is coupled to the third terminal when the contactor is in the second position. When the contactor is in the first position, the switch is configured to provide direct current power at the output node. When the contactor is in the second position, the switch is configured to provide alternating current power at the output node.
H02M 1/10 - Arrangements incorporating converting means for enabling loads to be operated at will from different kinds of power supplies, e.g. from AC or DC
G08B 5/38 - Visible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electric transmissionVisible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electromagnetic transmission using visible light sources using flashing light
G08B 17/117 - Actuation by presence of smoke or gases by using a detection device for specific gases, e.g. combustion products, produced by the fire
H05B 47/105 - Controlling the light source in response to determined parameters
G08B 5/36 - Visible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electric transmissionVisible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electromagnetic transmission using visible light sources
G08B 25/08 - Alarm systems in which the location of the alarm condition is signalled to a central station, e.g. fire or police telegraphic systems characterised by the transmission medium using communication transmission lines
An adjustable light fixture includes a frame configured to rotatably connect to a support and rotate about a first axis. A lamp assembly is connected to the frame. The lamp assembly includes a housing defining a cavity. A light emitter is supported in the cavity. A lens is connected to the housing. A pivot assembly rotatably couples the lamp assembly to the frame about a second axis offset from the first axis.
An adjustable light fixture includes a frame configured to connect to a support. A lamp assembly is connected to the frame. The lamp assembly includes a housing, a light emitter connected to the housing, and a lens connected to the housing. The lamp assembly is rotatably connected to the frame about an axis offset from an axis of the frame.
A ceiling fan is provided. The ceiling fan includes one or more fan blades. The ceiling fan further includes a motor. The motor is operatively coupled to the one or more fan blades. The motor is configured to drive rotation of the one or more fan blades. The ceiling fan further includes a light kit. The light kit includes a panel. The panel has an edge extending between a top surface of the panel and a bottom surface of the panel. The light kit further includes at least one light source positioned to illuminate the edge.
A lighting fixture includes a fixture housing. A circuit board is positioned in the fixture housing. The circuit board includes a driver circuit. A plurality of light emitters are disposed on the circuit board. The light emitters are operatively connected to the driver circuit to produce a light output. A temperature sensor is disposed on the circuit board, the temperature sensor configured to measure a temperature of the circuit board and output a signal. The driver circuit is configured to reduce the light output in response to the signal from the temperature sensor.
F21S 8/00 - Lighting devices intended for fixed installation
F21V 29/00 - Protecting lighting devices from thermal damageCooling or heating arrangements specially adapted for lighting devices or systems
F21V 29/503 - Cooling arrangements characterised by the adaptation for cooling of specific components of light sources
G01K 7/22 - Measuring temperature based on the use of electric or magnetic elements directly sensitive to heat using resistive elements the element being a non-linear resistance, e.g. thermistor
H05B 45/18 - Controlling the intensity of the light using temperature feedback
A light fixture includes a housing for supporting a light source and an enclosure for supporting a driver in electrical communication with the light source. The enclosure is selectively supported in one of a first position and a second position while maintaining electrical communication between the driver and the light source in both positions. The enclosure is directly coupled to the housing in the first position, and the enclosure is supported separately from the housing in the second position.
A lighting fixture is provided. The lighting fixture includes a sensor, a first power circuit configured to produce a first driving current for the sensor, a second power circuit a first power circuit configured to produce a second driving current for the sensor, and a switching device connected to the power supply. The switching device is configured to move between a first position and a second position, and to connect the first power circuit to a power supply in the first position, and connect the second power circuit to the power supply in the second position.
G08B 7/06 - Signalling systems according to more than one of groups Personal calling systems according to more than one of groups using electric transmission
G08B 17/10 - Actuation by presence of smoke or gases
H02J 9/06 - Circuit arrangements for emergency or stand-by power supply, e.g. for emergency lighting in which the distribution system is disconnected from the normal source and connected to a standby source with automatic change-over
F21V 23/04 - Arrangement of electric circuit elements in or on lighting devices the elements being switches
F21V 33/00 - Structural combinations of lighting devices with other articles, not otherwise provided for
An adjustable light fixture includes a frame configured to rotatably connect to a support and rotate about a first axis. A lamp assembly is connected to the frame. The lamp assembly includes a housing defining a cavity. A light emitter is supported in the cavity. A lens is connected to the housing. A pivot assembly rotatably couples the lamp assembly to the frame about a second axis offset from the first axis.
A ceiling fan is provided. The ceiling fan includes one or more fan blades. The ceiling fan further includes a motor. The motor is operatively coupled to the one or more fan blades. The motor is configured to drive rotation of the one or more fan blades. The ceiling fan further includes a light kit. The light kit includes a panel. The panel has an edge extending between a top surface of the panel and a bottom surface of the panel. The light kit further includes at least one light source positioned to illuminate the edge.
A recessed luminaire includes a housing supporting a light emitter, an intumescent material coupled to an outer surface of the housing, and a plate coupled to the housing and to the intumescent material. The housing configured to be positioned at least partially through a ceiling. The housing also includes a stepped surface. The intumescent material has a shape complementary to a shape of the housing. The plate is positioned adjacent to the stepped surface and to an upper surface of the intumescent material.
A switch includes a first terminal, a second terminal, and a third terminal. The switch includes an output node coupled to the second terminal and the third terminal. The switch includes a contactor coupled to the first terminal and movable between at least a first position and a second position. The first terminal is coupled to the second terminal when the contactor is in the first position. The first terminal is coupled to the third terminal when the contactor is in the second position. When the contactor is in the first position, the switch is configured to provide direct current power at the output node. When the contactor is in the second position, the switch is configured to provide alternating current power at the output node.
H02M 1/10 - Arrangements incorporating converting means for enabling loads to be operated at will from different kinds of power supplies, e.g. from AC or DC
G08B 17/117 - Actuation by presence of smoke or gases by using a detection device for specific gases, e.g. combustion products, produced by the fire
G08B 5/38 - Visible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electric transmissionVisible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electromagnetic transmission using visible light sources using flashing light
H05B 47/105 - Controlling the light source in response to determined parameters
G08B 25/08 - Alarm systems in which the location of the alarm condition is signalled to a central station, e.g. fire or police telegraphic systems characterised by the transmission medium using communication transmission lines
G08B 5/36 - Visible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electric transmissionVisible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electromagnetic transmission using visible light sources
24.
LED circuit board layout for low profile lighting fixture
Light emitting device (LED) circuit board layouts for low profile lighting fixtures are provided. In some embodiments, the lighting fixture can include a fixture housing. The lighting fixture can include one or more LED devices disposed on a circuit board. The lighting fixture can include one or more electronic components associated with at least one of a driver circuit or a filter circuit (e.g., as part of a flicker reducing circuit) disposed on the circuit board. The one or more LED devices are disposed on a first portion of the circuit board and the electronic components are disposed on a second portion of the circuit board. The second portion of the circuit board can be spaced radially apart from a center point of the circuit board relative to the first portion.
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
F21S 8/00 - Lighting devices intended for fixed installation
F21S 8/04 - Lighting devices intended for fixed installation intended only for mounting on a ceiling or like overhead structure
F21V 15/01 - Housings, e.g. material or assembling of housing parts
F21V 19/00 - Fastening of light sources or lamp holders
F21V 21/08 - Devices for easy attachment to a desired place
F21V 29/70 - Cooling arrangements characterised by passive heat-dissipating elements, e.g. heat-sinks
F21V 31/00 - Gas-tight or water-tight arrangements
F21Y 105/18 - Planar light sources comprising a two-dimensional array of point-like light-generating elements characterised by the overall shape of the two-dimensional array annularPlanar light sources comprising a two-dimensional array of point-like light-generating elements characterised by the overall shape of the two-dimensional array polygonal other than square or rectangular, e.g. for spotlights or for generating an axially symmetrical light beam
H05B 45/59 - Circuit arrangements for operating light-emitting diodes [LED] responsive to malfunctions or undesirable behaviour of LEDsCircuit arrangements for operating light-emitting diodes [LED] responsive to LED lifeProtective circuits for reducing or suppressing flicker or glow effects
An adjustable light fixture includes a frame configured to connect to a support. A lamp assembly is connected to the frame. The lamp assembly includes a housing, a light emitter connected to the housing, and a lens connected to the housing. The lamp assembly is rotatably connected to the frame about an axis offset from an axis of the frame.
Light bars for vehicles, namely, cars and trucks; Light bulbs for directional signals for vehicles; Lights for vehicles; Backup lights for land vehicles; LED light bulbs; Rear lights for vehicles; Running lights for land vehicles; Tail lights for vehicles; Vehicle brake lights; Vehicle turn-signal light bulbs
27.
LED circuit board layout for low profile lighting fixture
Light emitting device (LED) circuit board layouts for low profile lighting fixtures are provided. In some embodiments, the lighting fixture can include a fixture housing. The lighting fixture can include one or more LED devices disposed on a circuit board. The lighting fixture can include one or more electronic components associated with at least one of a driver circuit or a filter circuit (e.g., as part of a flicker reducing circuit) disposed on the circuit board. The one or more LED devices are disposed on a first portion of the circuit board and the electronic components are disposed on a second portion of the circuit board. The second portion of the circuit board can be spaced radially apart from a center point of the circuit board relative to the first portion.
H05B 45/50 - Circuit arrangements for operating light-emitting diodes [LED] responsive to malfunctions or undesirable behaviour of LEDsCircuit arrangements for operating light-emitting diodes [LED] responsive to LED lifeProtective circuits
F21Y 105/18 - Planar light sources comprising a two-dimensional array of point-like light-generating elements characterised by the overall shape of the two-dimensional array annularPlanar light sources comprising a two-dimensional array of point-like light-generating elements characterised by the overall shape of the two-dimensional array polygonal other than square or rectangular, e.g. for spotlights or for generating an axially symmetrical light beam
F21V 29/70 - Cooling arrangements characterised by passive heat-dissipating elements, e.g. heat-sinks
A lighting fixture is provided. The lighting fixture includes a light source and an environmental detection system. The environmental detection system is coupled to a continuous supply of electrical power. The environmental detection system includes one or more sensors operable to detect a parameter associated with a space in which the lighting fixture is located.
G08B 7/06 - Signalling systems according to more than one of groups Personal calling systems according to more than one of groups using electric transmission
F21V 33/00 - Structural combinations of lighting devices with other articles, not otherwise provided for
G08B 17/10 - Actuation by presence of smoke or gases
H02J 9/06 - Circuit arrangements for emergency or stand-by power supply, e.g. for emergency lighting in which the distribution system is disconnected from the normal source and connected to a standby source with automatic change-over
F21V 23/04 - Arrangement of electric circuit elements in or on lighting devices the elements being switches
A lighting fixture includes a fixture housing. A circuit board is positioned in the fixture housing. The circuit board includes a driver circuit. A plurality of light emitters are disposed on the circuit board. The light emitters are operatively connected to the driver circuit to produce a light output. A temperature sensor is disposed on the circuit board, the temperature sensor configured to measure a temperature of the circuit board and output a signal. The driver circuit is configured to reduce the light output in response to the signal from the temperature sensor.
F21S 8/00 - Lighting devices intended for fixed installation
F21V 29/00 - Protecting lighting devices from thermal damageCooling or heating arrangements specially adapted for lighting devices or systems
H05B 45/18 - Controlling the intensity of the light using temperature feedback
G01K 7/22 - Measuring temperature based on the use of electric or magnetic elements directly sensitive to heat using resistive elements the element being a non-linear resistance, e.g. thermistor
F21V 29/503 - Cooling arrangements characterised by the adaptation for cooling of specific components of light sources
A ceiling fan is provided. The ceiling fan includes one or more fan blades. The ceiling fan further includes a motor. The motor is operatively coupled to the one or more fan blades. The motor is configured to drive rotation of the one or more fan blades. The ceiling fan further includes a light kit. The light kit includes a panel. The panel has an edge extending between a top surface of the panel and a bottom surface of the panel. The light kit further includes at least one light source positioned to illuminate the edge.
Light emitting device (LED) circuit board layouts for low profile lighting fixtures are provided. In some embodiments, the lighting fixture can include a fixture housing. The lighting fixture can include one or more LED devices disposed on a circuit board. The lighting fixture can include one or more electronic components associated with at least one of a driver circuit or a filter circuit (e.g., as part of a flicker reducing circuit) disposed on the circuit board. The one or more LED devices are disposed on a first portion of the circuit board and the electronic components are disposed on a second portion of the circuit board. The second portion of the circuit board can be spaced radially apart from a center point of the circuit board relative to the first portion.
F21Y 105/18 - Planar light sources comprising a two-dimensional array of point-like light-generating elements characterised by the overall shape of the two-dimensional array annularPlanar light sources comprising a two-dimensional array of point-like light-generating elements characterised by the overall shape of the two-dimensional array polygonal other than square or rectangular, e.g. for spotlights or for generating an axially symmetrical light beam
F21V 29/70 - Cooling arrangements characterised by passive heat-dissipating elements, e.g. heat-sinks
A light emitting diode (LED) lighting fixture is provided. The lighting fixture includes a first LED engine and second LED engine. The first LED engine is configured to emit light corresponding to a first correlated color temperature. The second LED engine is configured to emit light corresponding to a second correlated color temperature that is different than the first correlated color temperature. When the first LED engine is hardwired to a power source, a light output of the lighting fixture corresponds to the first correlated color temperature. When the second LED engine is hardwired to the power source, the light output of the lighting fixture corresponds to the second correlated color temperature.
A bladeless ceiling fan is provided. The bladeless ceiling fan includes a housing configured to accommodate an electric motor. The housing can define one or more vents through which air enters an interior of the housing. The bladeless ceiling fan can further include an airfoil defining an interior passage. In addition, the bladeless ceiling fan includes one or more conduits. The one or more conduits extend from the housing to the airfoil such that air within the interior of the housing flows through the one or more conduits and into the interior passage defined by the airfoil.
F04D 25/08 - Units comprising pumps and their driving means the working fluid being air, e.g. for ventilation
F04D 17/04 - Radial-flow pumps specially adapted for elastic fluids, e.g. centrifugal pumpsHelico-centrifugal pumps specially adapted for elastic fluids having non-centrifugal stages, e.g. centripetal of transverse-flow type
F04D 29/00 - Details, component parts, or accessories
F04D 29/42 - CasingsConnections for working fluid for radial or helico-centrifugal pumps
An enclosure for a luminaire includes a plastic elongated main body that extents along an axis between a first end and a second end. A first compartment is disposed proximate the first end and a second compartment is disposed proximate the second end. A wall extends orthogonal to the axis and partitions the first compartment from the second compartment. The wall includes an aperture that provides communication between the first compartment and the second compartment.
A switch includes a first terminal, a second terminal, and a third terminal. The switch includes an output node coupled to the second terminal and the third terminal. The switch includes a contactor coupled to the first terminal and movable between at least a first position and a second position. The first terminal is coupled to the second terminal when the contactor is in the first position. The first terminal is coupled to the third terminal when the contactor is in the second position. When the contactor is in the first position, the switch is configured to provide direct current power at the output node. When the contactor is in the second position, the switch is configured to provide alternating current power at the output node.
H02M 1/10 - Arrangements incorporating converting means for enabling loads to be operated at will from different kinds of power supplies, e.g. from AC or DC
H05B 47/105 - Controlling the light source in response to determined parameters
G08B 17/117 - Actuation by presence of smoke or gases by using a detection device for specific gases, e.g. combustion products, produced by the fire
G08B 5/38 - Visible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electric transmissionVisible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electromagnetic transmission using visible light sources using flashing light
G08B 25/08 - Alarm systems in which the location of the alarm condition is signalled to a central station, e.g. fire or police telegraphic systems characterised by the transmission medium using communication transmission lines
G08B 5/36 - Visible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electric transmissionVisible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electromagnetic transmission using visible light sources
A mirror assembly includes a frame, a mirror platform, a light emitting element, a light guide, an interior reflective surface, and a back plate. The mirror platform includes a central reflective portion and a translucent portion. The light emitting element is retained within the frame and driven by a driver. The light guide plate is disposed adjacent the light emitting element and includes two opposed major surfaces that propagate light along the light guide plate. The interior reflective surface is disposed adjacent a rear major surface of the light guide plate. The back plate is affixed to the frame, securing the mirror platform, the light emitting element, the driver, the light guide, and the interior reflective surface therebetween.
A lighting fixture is provided. The lighting fixture includes a light source and an environmental detection system. The environmental detection system is coupled to a continuous supply of electrical power. The environmental detection system includes one or more sensors operable to detect a parameter associated with a space in which the lighting fixture is located.
G08B 7/00 - Signalling systems according to more than one of groups Personal calling systems according to more than one of groups
G08B 7/06 - Signalling systems according to more than one of groups Personal calling systems according to more than one of groups using electric transmission
F21V 33/00 - Structural combinations of lighting devices with other articles, not otherwise provided for
G08B 17/10 - Actuation by presence of smoke or gases
H02J 9/06 - Circuit arrangements for emergency or stand-by power supply, e.g. for emergency lighting in which the distribution system is disconnected from the normal source and connected to a standby source with automatic change-over
F21V 23/04 - Arrangement of electric circuit elements in or on lighting devices the elements being switches
Lighting system control based on lighting playlist(s) is disclosed. In one example implementation, a method includes obtaining, by one or more computing devices, data indicative of a user request for a selected lighting playlist from a plurality of lighting playlists. The user request can be implemented via a user interaction a user interface. In response to the request, the method can include obtaining, by the one or more computing devices, data associated with the selected lighting playlist from one or more memory devices. The method can include communicating, by the one or more computing devices, the data associated with the selected lighting playlist for control of a lighting system in accordance with the lighting playlist.
H05B 33/08 - Circuit arrangements for operating electroluminescent light sources
G06F 3/0482 - Interaction with lists of selectable items, e.g. menus
G06F 3/0484 - Interaction techniques based on graphical user interfaces [GUI] for the control of specific functions or operations, e.g. selecting or manipulating an object, an image or a displayed text element, setting a parameter value or selecting a range
H05B 45/10 - Controlling the intensity of the light
H05B 47/12 - Controlling the light source in response to determined parameters by determining the presence or movement of objects or living beings by detecting audible sound
H05B 47/155 - Coordinated control of two or more light sources
41.
Ceiling fan that controls thermostat based on presence information
A ceiling fan comprising an image capture device. The image capture device operable to capture one or more images depicting at least a portion of a room or area in which the ceiling fan is located.
F24F 3/00 - Air-conditioning systems in which conditioned primary air is supplied from one or more central stations to distributing units in the rooms or spaces where it may receive secondary treatmentApparatus specially designed for such systems
F24F 11/52 - Indication arrangements, e.g. displays
G10L 25/78 - Detection of presence or absence of voice signals
F04D 29/00 - Details, component parts, or accessories
A light fixture includes a housing for supporting a light source and an enclosure for supporting a driver in electrical communication with the light source. The enclosure is selectively supported in one of a first position and a second position while maintaining electrical communication between the driver and the light source in both positions. The enclosure is directly coupled to the housing in the first position, and the enclosure is supported separately from the housing in the second position.
A luminaire includes a first housing portion having a first knockout, a second housing portion having a second knockout, first and second apertures formed in one of the first and second housing portions, and at least one protrusion formed in the other of the first and second housing portions. The first housing portion and the second housing portion are selectively connectable to one another in a first configuration by the at least one protrusion received within the first aperture, and a second configuration by the at least one protrusion received within the second aperture. An upper surface of the first housing portion and a lower surface of the second housing portion are spaced apart by a first distance in the first configuration with the knockouts forming a first shape, and by a second distance in the second configuration with the knockouts forming a second shape.
F21V 17/02 - Fastening of component parts of lighting devices, e.g. shades, globes, refractors, reflectors, filters, screens, grids or protective cages with provision for adjustment
F21S 2/00 - Systems of lighting devices, not provided for in main groups or , e.g. of modular construction
F21V 15/01 - Housings, e.g. material or assembling of housing parts
A light fixture assembly includes a base including a recessed surface, an outer wall, and a base connecting member extending from the outer wall. A light emitter is connectable to the recessed surface of the base. An inner lens is connectable to the base over the light emitter. An outer lens is configured to be selectively connected to the base. The outer lens includes a lens connecting member configured to connect to the base connecting member. An accessory mount is configured to be selectively connected to the base. The accessory mount includes an accessory mount connecting member configured to connect to the base connecting member.
F21V 17/00 - Fastening of component parts of lighting devices, e.g. shades, globes, refractors, reflectors, filters, screens, grids or protective cages
F21V 21/02 - Wall, ceiling, or floor basesFixing pendants or arms to the bases
F21V 17/08 - Fastening of component parts of lighting devices, e.g. shades, globes, refractors, reflectors, filters, screens, grids or protective cages onto the supporting or suspending arrangements of the lighting device, e.g. power cords, standards
Lighting fixtures for use with a can downlight are provided. In some embodiments, The lighting fixture includes a fixture housing having a recess. The fixture housing has a shape adapted to fit at least partially within a can housing. The lighting fixture includes one or more light sources disposed within the recess of the fixture housing. The lighting fixture includes an adjustable mounting bracket attached to the fixture housing. The adjustable mounting bracket is movable between a plurality of different positions to adapt the adjustable mounting bracket for engaging can housings of a plurality of different sizes.
Light emitting device (LED) circuit board layouts for low profile lighting fixtures are provided. In some embodiments, the lighting fixture can include a fixture housing. The lighting fixture can include one or more LED devices disposed on a circuit board. The lighting fixture can include one or more electronic components associated with at least one of a driver circuit or a filter circuit (e.g., as part of a flicker reducing circuit) disposed on the circuit board. The one or more LED devices are disposed on a first portion of the circuit board and the electronic components are disposed on a second portion of the circuit board. The second portion of the circuit board can be spaced radially apart from a center point of the circuit board relative to the first portion.
F21S 4/00 - Lighting devices or systems using a string or strip of light sources
F21V 21/00 - Supporting, suspending, or attaching arrangements for lighting devicesHand grips
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
F21S 8/00 - Lighting devices intended for fixed installation
F21V 19/00 - Fastening of light sources or lamp holders
H05B 33/08 - Circuit arrangements for operating electroluminescent light sources
F21Y 105/18 - Planar light sources comprising a two-dimensional array of point-like light-generating elements characterised by the overall shape of the two-dimensional array annularPlanar light sources comprising a two-dimensional array of point-like light-generating elements characterised by the overall shape of the two-dimensional array polygonal other than square or rectangular, e.g. for spotlights or for generating an axially symmetrical light beam
F21V 29/70 - Cooling arrangements characterised by passive heat-dissipating elements, e.g. heat-sinks
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
Goods & Services
Illuminated exit signs, lighting controls and lighting
control systems, electric door chime kits consisting
primarily of electric door chimes, door chime housing and
push button housing. Lighting fixtures, ceiling fans, light bulbs, lamp
reflectors, globes for lamps, recessed housing for lighting
fixtures, lighting mounting frames, and mounting
accessories, namely, wall brackets for lighting fixtures,
mounting clips, ceiling gaskets, channels and rings for
mounting lighting fixtures and ceiling fans.
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
Goods & Services
Illuminated exit signs, lighting controls and lighting
control systems, electric door chime kits consisting
primarily of electric door chimes, door chime housing and
push button housing. Lighting fixtures, ceiling fans, light bulbs, lamp
reflectors, globes for lamps, recessed housing for lighting
fixtures, lighting mounting frames, and mounting accessories
including wall brackets for lighting fixtures, mounting
clips, ceiling gaskets, channels and rings.
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
Goods & Services
(1) Illuminated exit signs, electric lighting controls and electric lighting power controllers, electric door chime kits consisting primarily of electric door chimes, door chime housing and push button housing
(2) Lighting fixtures, light bulbs, lamp reflectors, globes for lamps, recessed housing for lighting fixtures, lighting mounting frames, and wall mounting brackets, mounting clips, ceiling gaskets, channels and rings, all for lighting fixtures
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
Goods & Services
(1) Illuminated exit signs, electric lighting controls and electric lighting power controllers, electric door chime kits consisting primarily of electric door chimes, door chime housing and push button housing
(2) Lighting fixtures, ceiling fans, light bulbs, recessed housing for lighting fixtures, lighting mounting frames, and wall mounting brackets, mounting clips, ceiling gaskets, channels and rings, all for lighting fixtures
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
Goods & Services
Illuminated exit signs, lighting controls and lighting control systems comprised primarily of lighting control apparatus and lighting control panels, electric door chime kits consisting primarily of electric door chimes, door chime housing and push button housing Lighting fixtures, ceiling fans, light bulbs, recessed housing for lighting fixtures, lighting mounting frames, and mounting accessories, namely, wall brackets for lighting fixtures, mounting clips, ceiling gaskets, channels and rings for mounting lighting fixtures and ceiling fans
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
Goods & Services
Lighting controls and lighting control systems comprised primarily of lighting control apparatus and lighting control panels Lighting fixtures, ceiling fans, light bulbs, lamp reflectors, globes for lamps, recessed housing for lighting fixtures, lighting mounting frames, and mounting accessories, namely, wall brackets for lighting fixtures, channels and rings for mounting lighting fixtures and ceiling fans
55.
Occupancy sensor with dimmer feature and night light and method of lighting control using the same
System and method are provided where an occupancy sensor with a time delay function designed to dim the lights, for example as a warning, after a first period of time has expired without detecting room occupancy. The lights remain dimmed for a second period of time, and then are turned off after a third period of time has expired without detecting room occupancy. If occupancy is detected during the first period of time, the lights will remain on. If occupancy is detected during the second or third period of time, the lights will be turned on to, for example, previous brightness. A night light can be added to, and/or incorporated in, an occupancy sensor which includes the dimmer feature.
System and method are provided where an occupancy sensor with a time delay function designed to dim the lights, for example as a warning, after a first period of time has expired without detecting room occupancy. The lights remain dimmed for a second period of time, and then are turned off after a third period of time has expired without detecting room occupancy. If occupancy is detected during the first period of time, the lights will remain on. If occupancy is detected during the second or third period of time, the lights will be turned on to, for example, previous brightness. A night light can be added to, and/or incorporated in, an occupancy sensor which includes the dimmer feature.
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
Goods & Services
Electric door chime kits consisting primarily of electric door chimes, door chime housing and push button housing Lighting fixtures; lamp reflectors; light bulbs; globes for lamps; lighting mounting frames; ceiling fans; bathroom fans; recessed housing for lighting fixtures; lighting accessories, namely, mounting clips, wall brackets, ceiling gaskets, channels and rings for mounting lighting fixtures
A wallwash reflector assembly includes a downlight body mounted within a wallwash body, the wallwash body being of multi-piece construction including an active body having an upper wallwash reflector for illuminating a first portion of a wall and a wallside body having a lower wallwash reflector for illuminating for a second portion of the wall. The upper and lower wallwash reflectors are optically optimized to provide a smooth, imperceptible transition between the illumination provided to the wall by the upper wallwash reflector and the illumination provided to the wall by the lower wallwash reflector.
F21V 17/02 - Fastening of component parts of lighting devices, e.g. shades, globes, refractors, reflectors, filters, screens, grids or protective cages with provision for adjustment
System and method are provided where an occupancy sensor with a time delay function designed to dim the lights, for example as a warning, after a first period of time has expired without detecting room occupancy. The lights remain dimmed for a second period of time, and then are turned off after a third period of time has expired without detecting room occupancy. If occupancy is detected during the first period of time, the lights will remain on. If occupancy is detected during the second or third period of time, the lights will be turned on to, for example, previous brightness. A night light can be added to, and/or incorporated in, an occupancy sensor which includes the dimmer feature.
