1.
|
Device for the internal bending of pipes for pipelines
| Application Number |
18682757 |
| Grant Number |
12453998 |
| Status |
In Force |
| Filing Date |
2022-08-11 |
| First Publication Date |
2024-10-17 |
| Grant Date |
2025-10-28 |
| Owner |
Bendforce GmbH (Germany)
|
| Inventor |
Baum, Oliver
|
Abstract
The invention relates to a device for the internal bending of pipes (100), in particular of coated pipes, for pipelines with a base body (11) which can be positioned in the pipe and which has on at least one side (12), preferably the underside, at least one support surface (13) with an inner wall (101) of a pipe (100) to be bent, wherein the base body (11) has a support surface (13) opposite, preferably the upper side, on which at least one tool for introducing a bending force into the pipe (100) is movably provided, wherein the tool is movable relative to the base body (11) via at least one actuator (18, 20) for introducing the bending force. The invention provides that the tool is provided as a tool element (21) which has at least two bending force introduction sections (28, 29) for introducing the bending force into the pipe (100), which are each movable relative to the base body (11) by at least one actuator (18, 20).
IPC Classes ?
- B21D 9/03 - Bending tubes using mandrels or the like the mandrel being flexible and engaging the entire tube length and built-up from loose elements, e.g. series of balls
|
2.
|
DEVICE FOR THE INTERNAL BENDING OF PIPES FOR PIPELINES
| Application Number |
EP2022072586 |
| Publication Number |
2023/017129 |
| Status |
In Force |
| Filing Date |
2022-08-11 |
| Publication Date |
2023-02-16 |
| Owner |
BENDFORCE GMBH (Germany)
|
| Inventor |
Baum, Oliver
|
Abstract
The invention relates to a device for the internal bending of pipes (100), more particularly coated pipes, for pipelines, the device comprising a main body (11), which can be positioned in the pipe and which has, on at least one side (12), preferably the bottom side, at least one contact surface (13) for contacting an inner wall (101) of a pipe (100) to be bent, wherein the main body (11) has a side opposite from the contact surface (13), preferably the top side, on which at least one tool for applying a bending force to the pipe (100) is movably provided, which tool can be moved relative to the main body (11) by means of at least one actuator (18, 20) in order to apply the bending force. According to the invention, the tool is provided as a tool element (21) which has at least two bending-force application portions (28, 29) for applying the bending force to the pipe (100), which bending-force application portions can be moved relative to the main body (11) by means of at least one actuator (18, 20) each.
IPC Classes ?
- B21D 9/03 - Bending tubes using mandrels or the like the mandrel being flexible and engaging the entire tube length and built-up from loose elements, e.g. series of balls
|
3.
|
BENDFORCE
| Application Number |
1690666 |
| Status |
Registered |
| Filing Date |
2022-09-20 |
| Registration Date |
2022-09-20 |
| Owner |
Bendforce GmbH (Germany)
|
| NICE Classes ? |
- 07 - Machines and machine tools
- 37 - Construction and mining; installation and repair services
- 40 - Treatment of materials; recycling, air and water treatment,
|
Goods & Services
Machines and machine tools for treatment of materials and
for manufacturing; bending machines for tubes. Pipeline maintenance; laying and construction of pipelines;
pipeline installation and repair. Treating [shaping] of metal; metal treating; molding of
plastic materials; treatment and processing of plastics.
|
4.
|
BEND FORCE
| Application Number |
221711200 |
| Status |
Registered |
| Filing Date |
2022-09-20 |
| Registration Date |
2025-08-01 |
| Owner |
Bendforce GmbH (Germany)
|
| NICE Classes ? |
- 07 - Machines and machine tools
- 37 - Construction and mining; installation and repair services
- 40 - Treatment of materials; recycling, air and water treatment,
|
Goods & Services
(1) Machines and machine tools for treatment of materials and for manufacturing, namely bending machines for tubes. (1) Pipeline maintenance; laying and construction of pipelines; pipeline installation and repair.
(2) Metalworking, namely shaping metal to the specification of others; plastics processing, namely custom molding of plastic materials to the specification of others; plastics processing.
|
5.
|
BENDFORCE
| Serial Number |
79352993 |
| Status |
Registered |
| Filing Date |
2022-09-20 |
| Registration Date |
2024-06-04 |
| Owner |
Bendforce GmbH (Germany)
|
| NICE Classes ? |
- 40 - Treatment of materials; recycling, air and water treatment,
- 07 - Machines and machine tools
- 37 - Construction and mining; installation and repair services
|
Goods & Services
Treating and shaping of metal; metal treating; molding of plastic materials; treatment and processing of plastics Machines and machine tools for treatment of materials and for manufacturing, namely, bending machines for tubes Pipeline maintenance; laying and construction of pipelines; pipeline installation and repair
|
6.
|
Bendforce
| Application Number |
018676729 |
| Status |
Registered |
| Filing Date |
2022-03-24 |
| Registration Date |
2022-07-14 |
| Owner |
Bendforce GmbH (Germany)
|
| NICE Classes ? |
- 07 - Machines and machine tools
- 37 - Construction and mining; installation and repair services
- 40 - Treatment of materials; recycling, air and water treatment,
|
Goods & Services
Machines and machine tools for treatment of materials and for manufacturing; Bending machines for tubes. Pipeline maintenance; Laying and construction of pipelines; Pipeline installation and repair. Treating [shaping] of metal; Metal treating; Molding of plastic materials; Treatment and processing of plastics.
|
7.
|
DEVICE FOR THE INTERNAL BENDING OF PIPES FOR PIPELINES
| Document Number |
03229118 |
| Status |
Pending |
| Filing Date |
2022-08-11 |
| Owner |
BENDFORCE GMBH (Germany)
|
| Inventor |
Baum, Oliver
|
Abstract
The invention relates to a device for the internal bending of pipes (100), more particularly coated pipes, for pipelines, the device comprising a main body (11), which can be positioned in the pipe and which has, on at least one side (12), preferably the bottom side, at least one contact surface (13) for contacting an inner wall (101) of a pipe (100) to be bent, wherein the main body (11) has a side opposite from the contact surface (13), preferably the top side, on which at least one tool for applying a bending force to the pipe (100) is movably provided, which tool can be moved relative to the main body (11) by means of at least one actuator (18, 20) in order to apply the bending force. According to the invention, the tool is provided as a tool element (21) which has at least two bending-force application portions (28, 29) for applying the bending force to the pipe (100), which bending-force application portions can be moved relative to the main body (11) by means of at least one actuator (18, 20) each.
IPC Classes ?
- B21D 9/03 - Bending tubes using mandrels or the like the mandrel being flexible and engaging the entire tube length and built-up from loose elements, e.g. series of balls
|
|
