A control system for controlling extraction of landfill gas from a landfill via a gas extraction system comprising well piping, the landfill gas having a first temperature when extracted, the control system comprising: a gas composition chamber coupled to the well piping and comprising at least one sensor configured to measure one or more characteristics of a landfill gas sample in the gas composition chamber; a temperature control mechanism configured to heat the landfill gas sample in the gas composition chamber to a second temperature at least a threshold amount greater than the first temperature; and a controller configured to control the at least one sensor to measure the one or more characteristics of the landfill gas sample in the gas composition chamber when a temperature of the landfill gas sample in the gas composition chamber is at least the threshold amount greater than the first temperature.
According to some aspects, there is provided systems and methods for monitoring extraction of landfill gas from a landfill having a plurality of wells by using a communication system configured to transmit information using a low-power wide area networking (LPWAN) protocol, the communication system comprising one or more gateway devices including a first gateway device and a plurality of communication node devices including a first communication node device. Further, there is provided methods for configuring a communication system comprising one or more gateway devices including a first gateway device and multiple communication node devices including a first communication node device.
According to some aspects, there is provided systems and methods for monitoring extraction of landfill gas from a landfill having a plurality of wells by using a communication system configured to transmit information using a low-power wide area networking (LPWAN) protocol, the communication system comprising one or more gateway devices including a first gateway device and a plurality of communication node devices including a first communication node device. Further, there is provided methods for configuring a communication system comprising one or more gateway devices including a first gateway device and multiple communication node devices including a first communication node device.
H04L 67/125 - Protocols specially adapted for proprietary or special-purpose networking environments, e.g. medical networks, sensor networks, networks in vehicles or remote metering networks involving control of end-device applications over a network
H04W 4/38 - Services specially adapted for particular environments, situations or purposes for collecting sensor information
H04W 4/70 - Services for machine-to-machine communication [M2M] or machine type communication [MTC]
A system for extracting landfill gas from a landfill is provided. According to some embodiments, a control system for landfill gas extraction is provided. The control system uses a throttle to control flow of landfill gas extracted from the landfill. The throttle is actuated in use to vary the flow of gas between a well and a gas collection system, in accordance with a control algorithm that adjusts flow as a parameter in controlling gas extraction. The throttle is configured to ensure that there is at least some flow of landfill gas from the landfill to a gas output throughout operation. The extraction system provides an efficient system for landfill gas extraction, while mitigating a risk of creating undesired or unpleasant conditions and/or of violating regulations during operation.
Systems and methods for controlling extraction of landfill gas from a landfill via a gas extraction system are provided herein. According to some aspects of the technology, there is provided site-level control methods for globally controlling one or more wells based on one or more characteristics of aggregate landfill gas collected from a plurality of wells at a gas output. According to some aspects of the technology, there is provided well-level control methods for locally controlling a first well based on or more characteristics of landfill gas collected from the first well. According to further aspects of the technology, there is provided hybrid control methods for making adjustments to a respective well based on both site-level and well-level control methods.
A control system for controlling extraction of landfill gas, comprising: at least one sensor configured to measure one or more characteristics of landfill gas; at least one flow control mechanism disposed in well piping and configured to control flow of the landfill gas through the well piping; and at least one processor configured to: obtain a measured concentration of a first gas in landfill gas; determine whether the measured concentration of the first gas is either less than a first threshold concentration or greater than a second threshold concentration; when it is determined that the measured concentration is less than the first threshold concentration, control the at least one flow control mechanism to reduce flow rate of landfill gas; and when it is determined that the concentration is greater than the second threshold concentration, control the at least one flow control mechanism to increase the flow rate of landfill gas.
Systems and methods for controlling extraction of landfill gas from a landfill via a gas extraction system are provided herein. According to some aspects of the technology, there is provided site-level control methods for globally controlling one or more wells based on one or more characteristics of aggregate landfill gas collected from a plurality of wells at a gas output. According to some aspects of the technology, there is provided well-level control methods for locally controlling a first well based on or more characteristics of landfill gas collected from the first well. According to further aspects of the technology, there is provided hybrid control methods for making adjustments to a respective well based on both site-level and well-level control methods.
A control system for controlling extraction of landfill gas from a landfill via a gas extraction system, the gas extraction system comprising well piping for coupling a plurality of wells to a gas output. The control system comprises a controller configured to: obtain a value indicating measured energy content of landfill gas collected at the gas output from the plurality of wells; determine whether the measured energy content is different from a target energy content; and in response to determining that the measured energy content is different from the target energy content: control a plurality of valves disposed in the well piping to change flow rates of landfill gas being extracted from at least some of the plurality of wells at least in part by changing degrees to which the plurality of valves are open.
Devices and techniques related to landfill gas extraction are disclosed. A technique for controlling extraction of landfill gas from a landfill through a gas extraction system is described. The method may include measuring a plurality of values indicating conditions associated with the landfill; computing, based at least in part on the plurality of values and on a model of the landfill, a predicted future state of the landfill; determining, based at least in part on the predicted future state of the landfill, one or more control parameters for one or more respective control devices configured to control operation of the gas extraction system; applying the one or more control parameters to the one or more respective control, and with 10 the one or more control devices, controlling extraction of the landfill gas from the landfill based, at least in part, on the one or more respective control parameters.
Devices and techniques related to landfill gas extraction are disclosed. A technique for controlling extraction of landfill gas from a landfill through a gas extraction system is described. The method may include measuring a plurality of values indicating conditions associated with the landfill; computing, based at least in part on the plurality of values and on a model of the landfill, a predicted future state of the landfill; determining, based at least in part on the predicted future state of the landfill, one or more control parameters for one or more respective control devices configured to control operation of the gas extraction system; applying the one or more control parameters to the one or more respective control, and with the one or more control devices, controlling extraction of the landfill gas from the landfill based, at least in part, on the one or more respective control parameters.
There is provided techniques for determining an estimate of gas emissions in a landfill. Some techniques provide for obtaining a plurality of measures and determining an estimate of methane emissions by using a gas emissions model to process the plurality of measures, and outputting the estimate of methane emissions. The plurality of measures may include emissions measurements such as methane emissions and/or measures of at least one environmental characteristic such as wind speed and/or direction, turbulence, and/or atmospheric stability. The estimate of gas emissions may be displayed and/or used to determine whether to cause a corrective action to be performed, such as adjusting a flow rate of landfill gas being extracted from the landfill.
G05B 19/416 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by control of velocity, acceleration or deceleration
G01M 3/04 - Investigating fluid tightness of structures by using fluid or vacuum by detecting the presence of fluid at the leakage point
There is provided techniques for determining an estimate of gas emissions in a landfill. Some techniques provide for obtaining a plurality of measures and determining an estimate of methane emissions by using a gas emissions model to process the plurality of measures, and outputting the estimate of methane emissions. The plurality of measures may include emissions measurements such as methane emissions and/or measures of at least one environmental characteristic such as wind speed and/or direction, turbulence, and/or atmospheric stability. The estimate of gas emissions may be displayed and/or used to determine whether to cause a corrective action to be performed, such as adjusting a flow rate of landfill gas being extracted from the landfill.
An apparatus for sampling landfill gas from a landfill flowing through a pipe. The apparatus may comprise: an enclosure configured to receive a section of the pipe; a gas sampling port in the section of the pipe; at least one sensor device disposed in a region of the enclosure, the at least one sensor being coupled to the section of the pipe through the gas sampling port; and thermal insulation positioned to retain heat from the section of the pipe in the region of the enclosure. A method of operating a landfill gas recovery system. The method may comprise: flowing gas from a well riser pipe through a sampling subsystem to a collection system; and heating a portion of the sampling subsystem with the gas flowing from the well riser pipe to the collection system.
A control system for controlling extraction of landfill gas from a landfill via a gas extraction system comprising well piping, the landfill gas having a first temperature when extracted, the control system comprising: a gas composition chamber coupled to the well piping and comprising at least one sensor configured to measure one or more characteristics of a landfill gas sample in the gas composition chamber; a temperature control mechanism configured to heat the landfill gas sample in the gas composition chamber to a second temperature at least a threshold amount greater than the first temperature; and a controller configured to control the at least one sensor to measure the one or more characteristics of the landfill gas sample in the gas composition chamber when a temperature of the landfill gas sample in the gas composition chamber is at least the threshold amount greater than the first temperature.
A method for use by a system coupled to at least one sensor and at least one flow control mechanism of a gas extraction system, the system comprising at least one controller and configured for use in connection with a landfill gas extraction process for extraction of landfill gas from a landfill via the gas extraction system, the method comprising: using the at least one controller to perform: obtaining, based on at least one measurement made by the at least one sensor, at least one current value indicative of a selected characteristic of the landfill gas extraction process, determining, at discrete time intervals, whether the at least one current value satisfies at least one compliance criterion for the selected characteristic, and when it is determined that the at least one current value does not satisfy the at least one compliance criterion for the selected characteristic, performing a corrective action.
Devices and techniques related to landfill gas extraction are disclosed. A technique for controlling extraction of landfill gas from a landfill through a gas extraction system is described. The method may include measuring a plurality of values indicating conditions associated with the landfill; computing, based at least in part on the plurality of values and on a model of the landfill, a predicted future state of the landfill; determining, based at least in part on the predicted future state of the landfill, one or more control parameters for one or more respective control devices configured to control operation of the gas extraction system; applying the one or more control parameters to the one or more respective control, and with the one or more control devices, controlling extraction of the landfill gas from the landfill based, at least in part, on the one or more respective control parameters.
Systems and methods for controlling extraction of landfill gas from a landfill via a gas extraction system comprising a plurality of wells are provided herein. In some embodiments, the method comprises obtaining a concentration of a greenhouse gas measured a distance above a surface of a region comprising the plurality of wells; determining whether the measure of the concentration of the greenhouse gas is greater than a first threshold; and in response to determining that the measure of the concentration of the greenhouse gas is greater than the first threshold, increasing a flow rate of landfill gas being extracted from at least one well of the plurality of wells.
Techniques are provided for controlling extraction of landfill gas from a landfill. The techniques include receiving user input indicating an upper methane concentration threshold and a lower methane concentration threshold, and obtaining a measurement of the concentration of methane in the sample of landfill gas. At least one processor may be used to determine whether to control an actuator to control the flow control mechanism to adjust the flow rate of the landfill gas being extracted from the landfill. The determining whether to adjust the flow rate may be performed by determining whether the measurement of the concentration of methane in the sample is greater than the upper methane concentration threshold and determining whether the measurement of the concentration of methane in the sample is less than the lower methane concentration threshold. The flow rate of landfill gas being extracted from the landfill may be adjusted based on the determining.
Techniques are provided for controlling extraction of landfill gas from a landfill. The techniques include obtaining a measurement of concentrations of oxygen, carbon, and methane in a sample of landfill gas. At least one processor may be used to determine based on the measurement of the concentration of oxygen in the sample, the measurement of the concentration of methane in the sample, and the measurement of the concentration of carbon dioxide in the sample, a balance gas concentration in the sample. Further, the at least one processor may be used to determine whether the determined balance gas concentration in the sample is greater than a balance gas concentration threshold. Responsive to determining that the determined balance gas concentration in the sample is greater than the balance gas concentration threshold, an actuator controls the flow control mechanism to decrease the flow rate of the landfill gas being extracted from the landfill.
Systems and methods for controlling extraction of landfill gas from a landfill via a gas extraction system are provided herein. According to some aspects of the technology, there is provided site-level control methods for globally controlling one or more wells based on one or more characteristics of aggregate landfill gas collected from a plurality of wells at a gas output. According to some aspects of the technology, there is provided well-level control methods for locally controlling a first well based on or more characteristics of landfill gas collected from the first well. According to further aspects of the technology, there is provided hybrid control methods for making adjustments to a respective well based on both site-level and well-level control methods.
An apparatus for sampling landfill gas from a landfill flowing through a pipe. The apparatus may comprise: an enclosure configured to receive a section of the pipe; a gas sampling port in the section of the pipe; at least one sensor device disposed in a region of the enclosure, the at least one sensor being coupled to the section of the pipe through the gas sampling port; and thermal insulation positioned to retain heat from the section of the pipe in the region of the enclosure. A method of operating a landfill gas recovery system. The method may comprise: flowing gas from a well riser pipe through a sampling subsystem to a collection system; and heating a portion of the sampling subsystem with the gas flowing from the well riser pipe to the collection system.
A system for extracting landfill gas from a landfill is provided. According to some embodiments, a control system for landfill gas extraction is provided. The control system uses a throttle to control flow of landfill gas extracted from the landfill. The throttle is actuated in use to vary the flow of gas between a well and a gas collection system, in accordance with a control algorithm that adjusts flow as a parameter in controlling gas extraction. The throttle is configured to ensure that there is at least some flow of landfill gas from the landfill to a gas output throughout operation. The extraction system provides an efficient system for landfill gas extraction, while mitigating a risk of creating undesired or unpleasant conditions and/or of violating regulations during operation.
A control system for controlling extraction of landfill gas, comprising: at least one sensor configured to measure one or more characteristics of landfill gas; at least one flow control mechanism disposed in well piping and configured to control flow of the landfill gas through the well piping; and at least one processor configured to: obtain a measured concentration of a first gas in landfill gas; determine whether the measured concentration of the first gas is either less than a first threshold concentration or greater than a second threshold concentration; when it is determined that the measured concentration is less than the first threshold concentration, control the at least one flow control mechanism to reduce flow rate of landfill gas; and when it is determined that the concentration is greater than the second threshold concentration, control the at least one flow control mechanism to increase the flow rate of landfill gas.
A control system for controlling extraction of landfill gas, comprising: at least one sensor configured to measure one or more characteristics of landfill gas; at least one flow control mechanism disposed in well piping and configured to control flow of the landfill gas through the well piping; and at least one processor configured to: obtain a measured concentration of a first gas in landfill gas; determine whether the measured concentration of the first gas is either less than a first threshold concentration or greater than a second threshold concentration; when it is determined that the measured concentration is less than the first threshold concentration, control the at least one flow control mechanism to reduce flow rate of landfill gas; and when it is determined that the concentration is greater than the second threshold concentration, control the at least one flow control mechanism to increase the flow rate of landfill gas.
Techniques are provided for controlling extraction of landfill gas from a landfill. The techniques include obtaining a measure of pressure in the gas extraction system upstream of a flow control mechanism, wherein the measure of pressure is obtained at a point between at least one well and the at least one flow control mechanism. Further, at least one processor may be used to determine that the measure of pressure in the gas extraction system relative to a measure of atmospheric pressure outside of the gas extraction system is not negative. In response to determining that the measure of pressure in the gas extraction system relative to the measure of atmospheric pressure is not negative, the flow rate of landfill gas being extracted from the at least one well is adjusted using the at least one flow control mechanism to achieve a negative pressure in the gas extraction system.
Devices and techniques related to landfill gas extraction are disclosed. A technique for controlling extraction of landfill gas from a landfill through a gas extraction system is described. The method may include measuring a plurality of values indicating conditions associated with the landfill; computing, based at least in part on the plurality of values and on a model of the landfill, a predicted future state of the landfill; determining, based at least in part on the predicted future state of the landfill, one or more control parameters for one or more respective control devices configured to control operation of the gas extraction system; applying the one or more control parameters to the one or more respective control, and with the one or more control devices, controlling extraction of the landfill gas from the landfill based, at least in part, on the one or more respective control parameters.
A control system for controlling extraction of landfill gas from a landfill via a gas extraction system, the gas extraction system comprising well piping for coupling a plurality of wells to a gas output. The control system comprises a controller configured to: obtain a value indicating measured energy content of landfill gas collected at the gas output from the plurality of wells; determine whether the measured energy content is different from a target energy content; and in response to determining that the measured energy content is different from the target energy content: control a plurality of valves disposed in the well piping to change flow rates of landfill gas being extracted from at least some of the plurality of wells at least in part by changing degrees to which the plurality of valves are open.
Systems and methods for controlling extraction of landfill gas from a landfill (502) via a gas extraction system comprising a plurality of wells (508A-C) are provided herein. In some embodiments, the method comprises obtaining a concentration of a greenhouse gas measured a distance above a surface of a region comprising the plurality of wells; determining whether the measure of the concentration of the greenhouse gas is greater than a first threshold; and in response to determining that the measure of the concentration of the greenhouse gas is greater than the first threshold, increasing a flow rate of landfill gas being extracted from at least one well of the plurality of wells.
Systems and methods for controlling extraction of landfill gas from a landfill (502) via a gas extraction system comprising a plurality of wells (508A-C) are provided herein. In some embodiments, the method comprises obtaining a concentration of a greenhouse gas measured a distance above a surface of a region comprising the plurality of wells; determining whether the measure of the concentration of the greenhouse gas is greater than a first threshold; and in response to determining that the measure of the concentration of the greenhouse gas is greater than the first threshold, increasing a flow rate of landfill gas being extracted from at least one well of the plurality of wells.
Systems and methods for controlling extraction of landfill gas from a landfill via a gas extraction system comprising a plurality of wells are provided herein. In some embodiments, the method comprises obtaining a concentration of a greenhouse gas measured a distance above a surface of a region comprising the plurality of wells; determining whether the measure of the concentration of the greenhouse gas is greater than a first threshold; and in response to determining that the measure of the concentration of the greenhouse gas is greater than the first threshold, increasing a flow rate of landfill gas being extracted from at least one well of the plurality of wells.
Devices and techniques related to landfill gas extraction are disclosed. A technique for controlling extraction of landfill gas from a landfill through a gas extraction system is described. The method may include measuring a plurality of values indicating conditions associated with the landfill; computing, based at least in part on the plurality of values and on a model of the landfill, a predicted future state of the landfill; determining, based at least in part on the predicted future state of the landfill, one or more control parameters for one or more respective control devices configured to control operation of the gas extraction system; applying the one or more control parameters to the one or more respective control, and with the one or more control devices, controlling extraction of the landfill gas from the landfill based, at least in part, on the one or more respective control parameters.
A control system for controlling extraction of landfill gas, comprising: at least one sensor configured to measure one or more characteristics of landfill gas; at least one flow control mechanism disposed in well piping and configured to control flow of the landfill gas through the well piping; and at least one processor configured to: obtain a measured concentration of a first gas in landfill gas; determine whether the measured concentration of the first gas is either less than a first threshold concentration or greater than a second threshold concentration; when it is determined that the measured concentration is less than the first threshold concentration, control the at least one flow control mechanism to reduce flow rate of landfill gas; and when it is determined that the concentration is greater than the second threshold concentration, control the at least one flow control mechanism to increase the flow rate of landfill gas.
Systems and methods for controlling extraction of landfill gas from a landfill via a gas extraction system are provided herein. According to some aspects of the technology, there is provided site-level control methods for globally controlling one or more wells based on one or more characteristics of aggregate landfill gas collected from a plurality of wells at a gas output. According to some aspects of the technology, there is provided well-level control methods for locally controlling a first well based on or more characteristics of landfill gas collected from the first well. According to further aspects of the technology, there is provided hybrid control methods for making adjustments to a respective well based on both site-level and well-level control methods.
Systems and methods for controlling extraction of landfill gas from a landfill via a gas extraction system are provided herein. According to some aspects of the technology, there is provided site-level control methods for globally controlling one or more wells based on one or more characteristics of aggregate landfill gas collected from a plurality of wells at a gas output. According to some aspects of the technology, there is provided well-level control methods for locally controlling a first well based on or more characteristics of landfill gas collected from the first well. According to further aspects of the technology, there is provided hybrid control methods for making adjustments to a respective well based on both site-level and well-level control methods.
Systems and methods for controlling extraction of landfill gas from a landfill via a gas extraction system are provided herein. According to some aspects of the technology, there is provided site-level control methods for globally controlling one or more wells based on one or more characteristics of aggregate landfill gas collected from a plurality of wells at a gas output. According to some aspects of the technology, there is provided well-level control methods for locally controlling a first well based on or more characteristics of landfill gas collected from the first well. According to further aspects of the technology, there is provided hybrid control methods for making adjustments to a respective well based on both site-level and well-level control methods.
Systems and methods for controlling extraction of landfill gas from a landfill via a gas extraction system are provided herein. According to some aspects of the technology, there is provided site-level control methods for globally controlling one or more wells based on one or more characteristics of aggregate landfill gas collected from a plurality of wells at a gas output. According to some aspects of the technology, there is provided well-level control methods for locally controlling a first well based on or more characteristics of landfill gas collected from the first well. According to further aspects of the technology, there is provided hybrid control methods for making adjustments to a respective well based on both site-level and well-level control methods.
Systems and methods for controlling extraction of landfill gas from a landfill via a gas extraction system are provided herein. According to some aspects of the technology, there is provided site-level control methods for globally controlling one or more wells based on one or more characteristics of aggregate landfill gas collected from a plurality of wells at a gas output. According to some aspects of the technology, there is provided well-level control methods for locally controlling a first well based on or more characteristics of landfill gas collected from the first well. According to further aspects of the technology, there is provided hybrid control methods for making adjustments to a respective well based on both site-level and well-level control methods.
Systems and methods for controlling extraction of landfill gas from a landfill via a gas extraction system are provided herein. According to some aspects of the technology, there is provided site-level control methods for globally controlling one or more wells based on one or more characteristics of aggregate landfill gas collected from a plurality of wells at a gas output. According to some aspects of the technology, there is provided well-level control methods for locally controlling a first well based on or more characteristics of landfill gas collected from the first well. According to further aspects of the technology, there is provided hybrid control methods for making adjustments to a respective well based on both site-level and well-level control methods.
An apparatus for sampling landfill gas from a landfill flowing through a pipe. The apparatus may comprise: an enclosure configured to receive a section of the pipe; a gas sampling port in the section of the pipe; at least one sensor device disposed in a region of the enclosure, the at least one sensor being coupled to the section of the pipe through the gas sampling port; and thermal insulation positioned to retain heat from the section of the pipe in the region of the enclosure. A method of operating a landfill gas recovery system. The method may comprise: flowing gas from a well riser pipe through a sampling subsystem to a collection system; and heating a portion of the sampling subsystem with the gas flowing from the well riser pipe to the collection system.
A method for use of a system coupled to at least one sensor and at least one flow control mechanism of a gas extraction system, the system comprising at least one controller and configured for use in connection with a landfill gas extraction process for extraction of landfill gas from a landfill via the gas extraction system, the method comprising: using the at least one controller to perform: obtaining, based on at least one measurement made by the at least one sensor, at least one current value indicative of a selected characteristic of the landfill gas extraction process, such as oxygen concentration, gas temperature, gas pressure or methane concentration, determining, at discrete time intervals, whether the at least one current value satisfies at least one compliance criterion for the selected characteristic, and when it is determined that the at least one current value does not satisfy the at least one compliance criterion for the selected characteristic, performing a corrective action.
A method for use of a system coupled to at least one sensor and at least one flow control mechanism of a gas extraction system, the system comprising at least one controller and configured for use in connection with a landfill gas extraction process for extraction of landfill gas from a landfill via the gas extraction system, the method comprising: using the at least one controller to perform: obtaining, based on at least one measurement made by the at least one sensor, at least one current value indicative of a selected characteristic of the landfill gas extraction process, such as oxygen concentration, gas temperature, gas pressure or methane concentration, determining, at discrete time intervals, whether the at least one current value satisfies at least one compliance criterion for the selected characteristic, and when it is determined that the at least one current value does not satisfy the at least one compliance criterion for the selected characteristic, performing a corrective action.
A method for use by a system coupled to at least one sensor and at least one flow control mechanism of a gas extraction system, the system comprising at least one controller and configured for use in connection with a landfill gas extraction process for extraction of landfill gas from a landfill via the gas extraction system, the method comprising: using the at least one controller to perform: obtaining, based on at least one measurement made by the at least one sensor, at least one current value indicative of a selected characteristic of the landfill gas extraction process, determining, at discrete time intervals, whether the at least one current value satisfies at least one compliance criterion for the selected characteristic, and when it is determined that the at least one current value does not satisfy the at least one compliance criterion for the selected characteristic, performing a corrective action.
A control system for controlling extraction of landfill gas from a landfill via a gas extraction system comprising well piping, the landfill gas having a first temperature when extracted, the control system comprising: a gas composition chamber coupled to the well piping and comprising at least one sensor configured to measure one or more characteristics of a landfill gas sample in the gas composition chamber; a temperature control mechanism configured to heat the landfill gas sample in the gas composition chamber to a second temperature at least a threshold amount greater than the first temperature; and a controller configured to control the at least one sensor to measure the one or more characteristics of the landfill gas sample in the gas composition chamber when a temperature of the landfill gas sample in the gas composition chamber is at least the threshold amount greater than the first temperature.
A system for extracting landfill gas from a landfill is provided. According to some embodiments, a control system for landfill gas extraction is provided. The control system uses a throttle to control flow of landfill gas extracted from the landfill. The throttle is actuated in use to vary the flow of gas between a well and a gas collection system, in accordance with a control algorithm that adjusts flow as a parameter in controlling gas extraction. The throttle is configured to ensure that there is at least some flow of landfill gas from the landfill to a gas output throughout operation. The extraction system provides an efficient system for landfill gas extraction, while mitigating a risk of creating undesired or unpleasant conditions and/or of violating regulations during operation.
Described herein are embodiments of a control system that automatically (1) determines whether a gas extraction system is in a state in which landfill gas is being released into the atmosphere, and (2) automatically controls landfill gas flow to mitigate, prevent and/or stop the release of landfill gas. The control system may control a valve to control flow of landfill gas through well piping of the gas extraction system. The pressure of landfill gas in the well piping at a location upstream of the valve may indicate whether there is a risk of landfill gas being released into the atmosphere. The control system may adjust a position of the valve in response to determining that the pressure at the location upstream of the valve indicates that there is a risk of landfill gas being released into the atmosphere.
A control system for controlling extraction of landfill gas from a landfill via a gas extraction system, the gas extraction system comprising well piping for coupling a plurality of wells to a gas output. The control system comprises a controller configured to: obtain a value indicating measured energy content of landfill gas collected at the gas output from the plurality of wells; determine whether the measured energy content is different from a target energy content; and in response to determining that the measured energy content is different from the target energy content: control a plurality of valves disposed in the well piping to change flow rates of landfill gas being extracted from at least some of the plurality of wells at least in part by changing degrees to which the plurality of valves are open.
A control system for controlling extraction of landfill gas from a landfill via a gas extraction system, the gas extraction system comprising well piping for coupling a plurality of wells to a gas output. The control system comprises a controller configured to: obtain a value indicating measured energy content of landfill gas collected at the gas output from the plurality of wells; determine whether the measured energy content is different from a target energy content; and in response to determining that the measured energy content is different from the target energy content: control a plurality of valves disposed in the well piping to change flow rates of landfill gas being extracted from at least some of the plurality of wells at least in part by changing degrees to which the plurality of valves are open.
Devices and techniques related to landfill gas extraction are disclosed. A technique for controlling extraction of landfill gas from a landfill through a gas extraction system is described. The method may include measuring a plurality of values indicating conditions associated with the landfill; computing, based at least in part on the plurality of values and on a model of the landfill, a predicted future state of the landfill; determining, based at least in part on the predicted future state of the landfill, one or more control parameters for one or more respective control devices configured to control operation of the gas extraction system; applying the one or more control parameters to the one or more respective control, and with the one or more control devices, controlling extraction of the landfill gas from the landfill based, at least in part, on the one or more respective control parameters.
A control system for controlling extraction of landfill gas, comprising: at least one sensor configured to measure one or more characteristics of landfill gas; at least one flow control mechanism disposed in well piping and configured to control flow of the landfill gas through the well piping; and at least one processor configured to: obtain a measured concentration of a first gas in landfill gas; determine whether the measured concentration of the first gas is either less than a first threshold concentration or greater than a second threshold concentration; when it is determined that the measured concentration is less than the first threshold concentration, control the at least one flow control mechanism to reduce flow rate of landfill gas; and when it is determined that the concentration is greater than the second threshold concentration, control the at least one flow control mechanism to increase the flow rate of landfill gas.
Devices and techniques related to landfill gas extraction are disclosed. A technique for controlling extraction of landfill gas from a landfill through a gas extraction system is described. The method may include measuring a plurality of values indicating conditions associated with the landfill; computing, based at least in part on the plurality of values and on a model of the landfill, a predicted future state of the landfill; determining, based at least in part on the predicted future state of the landfill, one or more control parameters for one or more respective control devices configured to control operation of the gas extraction system; applying the one or more control parameters to the one or more respective control, and with the one or more control devices, controlling extraction of the landfill gas from the landfill based, at least in part, on the one or more respective control parameters.
Described herein are embodiments of a control system that automatically (1) determines whether a gas extraction system is in a state in which landfill gas is being released into the atmosphere, and (2) automatically controls landfill gas flow to mitigate, prevent and/or stop the release of landfill gas. The control system may control a valve to control flow of landfill gas through well piping of the gas extraction system. The pressure of landfill gas in the well piping at a location upstream of the valve may indicate whether there is a risk of landfill gas being released into the atmosphere. The control system may adjust a position of the valve in response to determining that the pressure at the location upstream of the valve indicates that there is a risk of landfill gas being released into the atmosphere.
Described herein are embodiments of a control system that automatically (1) determines whether a gas extraction system is in a state in which landfill gas is being released into the atmosphere, and (2) automatically controls landfill gas flow to mitigate, prevent and/or stop the release of landfill gas. The control system may control a valve to control flow of landfill gas through well piping of the gas extraction system. The pressure of landfill gas in the well piping at a location upstream of the valve may indicate whether there is a risk of landfill gas being released into the atmosphere. The control system may adjust a position of the valve in response to determining that the pressure at the location upstream of the valve indicates that there is a risk of landfill gas being released into the atmosphere.
A control system for controlling extraction of landfill gas from a landfill via a gas extraction system, the gas extraction system comprising well piping for coupling a plurality of wells to a gas output. The control system comprises a controller configured to: obtain a value indicating measured energy content of landfill gas collected at the gas output from the plurality of wells; determine whether the measured energy content is different from a target energy content; and in response to determining that the measured energy content is different from the target energy content: control a plurality of valves disposed in the well piping to change flow rates of landfill gas being extracted from at least some of the plurality of wells at least in part by changing degrees to which the plurality of valves are open.
Described herein are embodiments of a control system that automatically (1) determines whether a gas extraction system is in a state in which landfill gas is being released into the atmosphere, and (2) automatically controls landfill gas flow to mitigate, prevent and/or stop the release of landfill gas. The control system may control a valve to control flow of landfill gas through well piping of the gas extraction system. The pressure of landfill gas in the well piping at a location upstream of the valve may indicate whether there is a risk of landfill gas being released into the atmosphere. The control system may adjust a position of the valve in response to determining that the pressure at the location upstream of the valve indicates that there is a risk of landfill gas being released into the atmosphere.
Devices and techniques related to landfill gas extraction are disclosed. A technique for controlling extraction of landfill gas from a landfill through a gas extraction system is described. The method may include measuring a plurality of values indicating conditions associated with the landfill; computing, based at least in part on the plurality of values and on a model of the landfill, a predicted future state of the landfill; determining, based at least in part on the predicted future state of the landfill, one or more control parameters for one or more respective control devices configured to control operation of the gas extraction system; applying the one or more control parameters to the one or more respective control, and with the one or more control devices, controlling extraction of the landfill gas from the landfill based, at least in part, on the one or more respective control parameters.
A system for extracting landfill gas from a landfill is provided. According to some embodiments, a control system for landfill gas extraction is provided. The control system uses a throttle to control flow of landfill gas extracted from the landfill. The throttle is actuated in use to vary the flow of gas between a well and a gas collection system, in accordance with a control algorithm that adjusts flow as a parameter in controlling gas extraction. The throttle is configured to ensure that there is at least some flow of landfill gas from the landfill to a gas output throughout operation. The extraction system provides an efficient system for landfill gas extraction, while mitigating a risk of creating undesired or unpleasant conditions and/or of violating regulations during operation.
E21B 34/00 - Valve arrangements for boreholes or wells
F16K 3/00 - Gate valves or sliding valves, i.e. cut-off apparatus with closing members having a sliding movement along the seat for opening and closing
A system for extracting landfill gas from a landfill is provided. According to some embodiments, a control system for landfill gas extraction is provided. The control system uses a throttle to control flow of landfill gas extracted from the landfill. The throttle is actuated in use to vary the flow of gas between a well and a gas collection system, in accordance with a control algorithm that adjusts flow as a parameter in controlling gas extraction. The throttle is configured to ensure that there is at least some flow of landfill gas from the landfill to a gas output throughout operation. The extraction system provides an efficient system for landfill gas extraction, while mitigating a risk of creating undesired or unpleasant conditions and/or of violating regulations during operation.
E21B 34/00 - Valve arrangements for boreholes or wells
E21B 43/12 - Methods or apparatus for controlling the flow of the obtained fluid to or in wells
F16K 3/00 - Gate valves or sliding valves, i.e. cut-off apparatus with closing members having a sliding movement along the seat for opening and closing
A system for extracting landfill gas from a landfill is provided. According to some embodiments, a control system for landfill gas extraction is provided. The control system uses a throttle to control flow of landfill gas extracted from the landfill. The throttle is actuated in use to vary the flow of gas between a well and a gas collection system, in accordance with a control algorithm that adjusts flow as a parameter in controlling gas extraction. The throttle is configured to ensure that there is at least some flow of landfill gas from the landfill to a gas output throughout operation. The extraction system provides an efficient system for landfill gas extraction, while mitigating a risk of creating undesired or unpleasant conditions and/or of violating regulations during operation.
E21B 43/12 - Methods or apparatus for controlling the flow of the obtained fluid to or in wells
G01F 1/36 - Measuring the volume flow or mass flow of fluid or fluent solid material wherein the fluid passes through a meter in a continuous flow by using mechanical effects by measuring pressure or differential pressure the pressure or differential pressure being created by the use of flow constriction
A control system for controlling extraction of landfill gas from a landfill via a gas extraction system comprising well piping, the landfill gas having a first temperature when extracted, the control system comprising: a gas composition chamber coupled to the well piping and comprising at least one sensor configured to measure one or more characteristics of a landfill gas sample in the gas composition chamber; a temperature control mechanism configured to heat the landfill gas sample in the gas composition chamber to a second temperature at least a threshold amount greater than the first temperature; and a controller configured to control the at least one sensor to measure the one or more characteristics of the landfill gas sample in the gas composition chamber when a temperature of the landfill gas sample in the gas composition chamber is at least the threshold amount greater than the first temperature.
A control system for controlling extraction of landfill gas from a landfill via a gas extraction system comprising well piping, the landfill gas having a first temperature when extracted, the control system comprising: a gas composition chamber coupled to the well piping and comprising at least one sensor configured to measure one or more characteristics of a landfill gas sample in the gas composition chamber; a temperature control mechanism configured to heat the landfill gas sample in the gas composition chamber to a second temperature at least a threshold amount greater than the first temperature; and a controller configured to control the at least one sensor to measure the one or more characteristics of the landfill gas sample in the gas composition chamber when a temperature of the landfill gas sample in the gas composition chamber is at least the threshold amount greater than the first temperature.
A control system for controlling extraction of landfill gas from a landfill via a gas extraction system comprising well piping, the landfill gas having a first temperature when extracted, the control system comprising: a gas composition chamber coupled to the well piping and comprising at least one sensor configured to measure one or more characteristics of a landfill gas sample in the gas composition chamber; a temperature control mechanism configured to heat the landfill gas sample in the gas composition chamber to a second temperature at least a threshold amount greater than the first temperature; and a controller configured to control the at least one sensor to measure the one or more characteristics of the landfill gas sample in the gas composition chamber when a temperature of the landfill gas sample in the gas composition chamber is at least the threshold amount greater than the first temperature.
A control system for controlling extraction of landfill gas, the system comprising: at least one sensor; at least one flow control mechanism; and at least one processor configured to perform: obtaining a first measure of energy content in a first portion of landfill gas; controlling the at least one flow control mechanism to increase a flow rate of landfill gas; after the controlling, obtaining a second measure of energy content in a second portion of landfill gas; when it is determined that the second measure of energy content is greater than the first measure of energy content, controlling the at least one flow control mechanism to increase the flow rate of landfill gas; and when it is determined that the second measure of energy content is less than the first measure of energy content, controlling the at least one flow control mechanism to decrease the flow rate of landfill gas.
B09C 1/08 - Reclamation of contaminated soil chemically
E21B 43/12 - Methods or apparatus for controlling the flow of the obtained fluid to or in wells
G01N 29/44 - Processing the detected response signal
G05D 11/08 - Controlling ratio of two or more flows of fluid or fluent material with auxiliary non-electric power by sensing concentration of mixture, e.g. by measuring pH-value
68.
Devices and techniques relating to landfill gas extraction
Devices and techniques related to landfill gas extraction are disclosed. A technique for controlling extraction of landfill gas from a landfill through a gas extraction system is described. The method may include measuring a plurality of values indicating conditions associated with the landfill; computing, based at least in part on the plurality of values and on a model of the landfill, a predicted future state of the landfill; determining, based at least in part on the predicted future state of the landfill, one or more control parameters for one or more respective control devices configured to control operation of the gas extraction system; applying the one or more control parameters to the one or more respective control, and with the one or more control devices, controlling extraction of the landfill gas from the landfill based, at least in part, on the one or more respective control parameters.
A control system for controlling extraction of landfill gas, the system comprising: at least one sensor; at least one flow control mechanism; and at least one processor configured to perform: obtaining a first measure of energy content in a first portion of landfill gas; controlling the at least one flow control mechanism to increase a flow rate of landfill gas; after the controlling, obtaining a second measure of energy content in a second portion of landfill gas; when it is determined that the second measure of energy content is greater than the first measure of energy content, controlling the at least one flow control mechanism to increase the flow rate of landfill gas; and when it is determined that the second measure of energy content is less than the first measure of energy content, controlling the at least one flow control mechanism to decrease the flow rate of landfill gas.
B09C 1/08 - Reclamation of contaminated soil chemically
E21B 43/12 - Methods or apparatus for controlling the flow of the obtained fluid to or in wells
G01N 29/44 - Processing the detected response signal
G05D 11/08 - Controlling ratio of two or more flows of fluid or fluent material with auxiliary non-electric power by sensing concentration of mixture, e.g. by measuring pH-value
70.
DESIGNS FOR ENHANCED RELIABILITY AND CALIBRATION OF LANDFILL GAS MEASUREMENT AND CONTROL DEVICES
An apparatus for sampling landfill gas from a landfill flowing through a pipe. The apparatus may comprise: an enclosure configured to receive a section of the pipe; a gas sampling port in the section of the pipe; at least one sensor device disposed in a region of the enclosure, the at least one sensor being coupled to the section of the pipe through the gas sampling port; and thermal insulation positioned to retain heat from the section of the pipe in the region of the enclosure. A method of operating a landfill gas recovery system. The method may comprise: flowing gas from a well riser pipe through a sampling subsystem to a collection system; and heating a portion of the sampling subsystem with the gas flowing from the well riser pipe to the collection system.
An apparatus for sampling landfill gas from a landfill flowing through a pipe. The apparatus may comprise: an enclosure configured to receive a section of the pipe; a gas sampling port in the section of the pipe; at least one sensor device disposed in a region of the enclosure, the at least one sensor being coupled to the section of the pipe through the gas sampling port; and thermal insulation positioned to retain heat from the section of the pipe in the region of the enclosure. A method of operating a landfill gas recovery system. The method may comprise: flowing gas from a well riser pipe through a sampling subsystem to a collection system; and heating a portion of the sampling subsystem with the gas flowing from the well riser pipe to the collection system.
An apparatus for sampling landfill gas from a landfill flowing through a pipe. The apparatus may comprise: an enclosure configured to receive a section of the pipe; a gas sampling port in the section of the pipe; at least one sensor device disposed in a region of the enclosure, the at least one sensor being coupled to the section of the pipe through the gas sampling port; and thermal insulation positioned to retain heat from the section of the pipe in the region of the enclosure. A method of operating a landfill gas recovery system. The method may comprise: flowing gas from a well riser pipe through a sampling subsystem to a collection system; and heating a portion of the sampling subsystem with the gas flowing from the well riser pipe to the collection system.
An apparatus for sampling landfill gas from a landfill flowing through a pipe. The apparatus may comprise: an enclosure configured to receive a section of the pipe; a gas sampling port in the section of the pipe; at least one sensor device disposed in a region of the enclosure, the at least one sensor being coupled to the section of the pipe through the gas sampling port; and thermal insulation positioned to retain heat from the section of the pipe in the region of the enclosure. A method of operating a landfill gas recovery system. The method may comprise: flowing gas from a well riser pipe through a sampling subsystem to a collection system; and heating a portion of the sampling subsystem with the gas flowing from the well riser pipe to the collection system.
An apparatus for sampling landfill gas from a landfill flowing through a pipe. The apparatus may comprise: an enclosure configured to receive a section of the pipe; a gas sampling port in the section of the pipe; at least one sensor device disposed in a region of the enclosure, the at least one sensor being coupled to the section of the pipe through the gas sampling port; and thermal insulation positioned to retain heat from the section of the pipe in the region of the enclosure. A method of operating a landfill gas recovery system. The method may comprise: flowing gas from a well riser pipe through a sampling subsystem to a collection system; and heating a portion of the sampling subsystem with the gas flowing from the well riser pipe to the collection system.
Devices and techniques related to landfill gas extraction are disclosed. A technique for controlling extraction of landfill gas from a landfill through a gas extraction system is described. The method may include measuring a plurality of values indicating conditions associated with the landfill; computing, based at least in part on the plurality of values and on a model of the landfill, a predicted future state of the landfill; determining, based at least in part on the predicted future state of the landfill, one or more control parameters for one or more respective control devices configured to control operation of the gas extraction system; applying the one or more control parameters to the one or more respective control, and with the one or more control devices, controlling extraction of the landfill gas from the landfill based, at least in part, on the one or more respective control parameters.
Devices and techniques related to landfill gas extraction are disclosed. A technique for controlling extraction of landfill gas from a landfill through a gas extraction system is described. The method may include measuring a plurality of values indicating conditions associated with the landfill; computing, based at least in part on the plurality of values and on a model of the landfill, a predicted future state of the landfill; determining, based at least in part on the predicted future state of the landfill, one or more control parameters for one or more respective control devices configured to control operation of the gas extraction system; applying the one or more control parameters to the one or more respective control, and with the one or more control devices, controlling extraction of the landfill gas from the landfill based, at least in part, on the one or more respective control parameters.
A control system for controlling extraction of landfill gas, the system comprising: at least one sensor; at least one flow control mechanism; and at least one processor configured to perform: obtaining a first measure of energy content in a first portion of landfill gas; controlling the at least one flow control mechanism to increase a flow rate of landfill gas; after the controlling, obtaining a second measure of energy content in a second portion of landfill gas; when it is determined that the second measure of energy content is greater than the first measure of energy content, controlling the at least one flow control mechanism to increase the flow rate of landfill gas; and when it is determined that the second measure of energy content is less than the first measure of energy content, controlling the at least one flow control mechanism to decrease the flow rate of landfill gas.
Devices and techniques related to landfill gas extraction are disclosed. A technique for controlling extraction of landfill gas from a landfill through a gas extraction system is described. The method may include measuring a plurality of values indicating conditions associated with the landfill; computing, based at least in part on the plurality of values and on a model of the landfill, a predicted future state of the landfill; determining, based at least in part on the predicted future state of the landfill, one or more control parameters for one or more respective control devices configured to control operation of the gas extraction system; applying the one or more control parameters to the one or more respective control, and with the one or more control devices, controlling extraction of the landfill gas from the landfill based, at least in part, on the one or more respective control parameters.
A control system for controlling extraction of landfill gas, comprising: at least one sensor configured to measure one or more characteristics of landfill gas; at least one flow control mechanism disposed in well piping and configured to control flow of the landfill gas through the well piping; and at least one processor configured to: obtain a measured concentration of a first gas in landfill gas; determine whether the measured concentration of the first gas is either less than a first threshold concentration or greater than a second threshold concentration; when it is determined that the measured concentration is less than the first threshold concentration, control the at least one flow control mechanism to reduce flow rate of landfill gas; and when it is determined that the concentration is greater than the second threshold concentration, control the at least one flow control mechanism to increase the flow rate of landfill gas.
A control system for controlling extraction of landfill gas, the system comprising: at least one atmospheric pressure sensor configured to measure atmospheric pressure; at least one flow control mechanism disposed in well piping and configured to control flow of the landfill gas through the well piping; and at least one processor configured to perform: obtaining a first atmospheric pressure; obtaining a second atmospheric pressure value; determining whether the second atmospheric pressure value is greater than the first atmospheric pressure value; when it is determined that the second atmospheric pressure value is greater than the first atmospheric pressure value, controlling the at least one flow control mechanism to decrease the flow rate of landfill gas; and when it is determined that the second atmospheric pressure value is less than the first atmospheric pressure value, controlling the at least one flow control mechanism to increase the flow rate of landfill gas.
09 - Scientific and electric apparatus and instruments
Goods & Services
Software for an environmental monitoring and automated
control system for landfill gas collection systems,
comprised of meters and sensors that measure pressure, flow,
humidity, gas composition, temperature, flow control
devices, and includes alarm and reporting functions, not for
use in connection with solar energy systems.
09 - Scientific and electric apparatus and instruments
Goods & Services
(1) Software for an environmental monitoring and automated control system for landfill gas collection systems, comprised of meters and sensors that measure pressure, flow, humidity, gas composition, temperature, flow control devices, and includes alarm and reporting functions, not for use in connection with solar energy systems
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Environmental monitoring system for landfills comprised of
meters and sensors that measure pressure, humidity,
temperature and includes alarm and reporting functions, not
for use in connection with solar energy systems; water
testing instrumentation for monitoring and detecting
contamination in landfills. Electronic monitoring and reporting of landfill gas
collection systems using computers or sensors, not for use
in connection with solar energy systems; monitoring of
greenhouse gas emissions for scientific research purposes,
not for use in connection with solar energy systems;
monitoring landfill gas collection systems to ensure proper
functioning.
09 - Scientific and electric apparatus and instruments
Goods & Services
software for an environmental monitoring and automated control system for landfill gas collection systems, comprised of meters and sensors that measure pressure, flow, (( humidity, )) gas composition, temperature, flow control devices, and includes alarm and reporting functions, not for use in connection with solar energy systems
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
(1) Environmental monitoring system for landfills comprised of meters and sensors that measure pressure, humidity, temperature and includes alarm and reporting functions, not for use in connection with solar energy systems; Water testing instrumentation for monitoring and detecting contamination in landfills (1) Electronic monitoring and reporting of landfill gas collection systems using computers or sensors, not for use in connection with solar energy systems; Monitoring of greenhouse gas emissions for scientific research purposes, not for use in connection with solar energy systems; Monitoring landfill gas collection systems to ensure proper functioning
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Environmental monitoring system for landfills comprised of meters and sensors that measure pressure, humidity, temperature and includes alarm and reporting functions, not for use in connection with solar energy systems (( ; Water testing instrumentation for monitoring and detecting contamination in landfills )) Electronic monitoring and reporting of landfill gas collection systems using computers or sensors, not for use in connection with solar energy systems; (( Monitoring of greenhouse gas emissions for scientific research purposes, not for use in connection with solar energy systems; )) Monitoring landfill gas collection systems to ensure proper functioning
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Environmental monitoring system for landfills comprised of meters and sensors that measure pressure, humidity, temperature and includes alarm and reporting functions, not for use in connection with solar energy systems; (( Water testing instrumentation for monitoring and detecting contamination in landfills )) Electronic monitoring and reporting of landfill gas collection systems using computers or sensors, not for use in connection with solar energy systems; (( Monitoring of greenhouse gas emissions for scientific research purposes, not for use in connection with solar energy systems; )) Monitoring landfill gas collection systems to ensure proper functioning
An eccentric, smoothly tapered body for installation into cylindrical pipe to cause a constriction in the pipe to facilitate measuring the flow of fluid through the pipe. The body defines a flow constrictor having a smoothly tapered inner surface having a leading edge and a trailing edge and an apex therebetween. A bore extends through the flow constrictor at the apex. Pressure is measured at the bore at the apex and upstream of the flow constrictor and flow rate is calculated from the pressure differential therebetween.
