Abstract

The present invention relates to a lifting system (1) comprising a tower (3), a jib (4) for lifting components to an elongated structure (2), a plurality of securing members (5) for securing the tower (3) to the elongated structure (2), and a lifting device (6) for lifting the securing members (5) and moving the securing members (5) up and down along the tower (3). The lifting device (6) comprises a platform (7) attached to an upper portion of the tower (3), protruding on two opposite sides of the tower (3) so that a first portion (7a) of the platform is protruding on a first side of the tower (3) and a second portion (7b) of the platform is protruding on a second side of the tower, a crane (10) arranged on the first portion (7a) of the platform, and a winch (12) for operating the crane arranged on the second portion (7b) of the platform. The crane (10) is arranged movable along the first portion (7a) of the platform so that the horizontal distance between the tower (3) and the crane (10) can be adjusted.

IPC Classes  ?

• B66C 23/18 - Cranes comprising essentially a beam, boom or triangular structure acting as a cantilever and mounted for translatory or swinging movements in vertical or horizontal planes or a combination of such movements, e.g. jib cranes, derricks or tower cranes specially adapted for use in particular locations or for particular purposes
• B66C 1/28 - Duplicate, e.g. pivoted, members engaging the loads from two sides
• B66C 1/34 - Crane hooks

Abstract

The present invention relates to a securing assembly (1) for securing service equipment, such as a support tower of a crane, to a wind turbine tower. The securing assembly (1) comprises two arms (6) arranged movable relative to each other so that the arms can embrace the wind turbine tower (3), and each arm (6) comprises an outer part (6b) including an elongated plate (7) arranged such that the plate can adapt to the curvature of the wind turbine tower. Each of the plates (7) comprises a self-regulating heater (12) arranged to heat the plate.

IPC Classes  ?

• B66C 23/20 - Cranes comprising essentially a beam, boom or triangular structure acting as a cantilever and mounted for translatory or swinging movements in vertical or horizontal planes or a combination of such movements, e.g. jib cranes, derricks or tower cranes specially adapted for use in particular locations or for particular purposes with supporting couples provided by walls of buildings or like structures
• F03D 80/40 - Ice detectionDe-icing means

Abstract

A securing assembly for securing a support tower to a wind turbine tower. The securing assembly includes a base part and a fastening module for securing the support tower to the wind turbine tower. The fastening module includes a rope for surrounding the wind turbine tower, and an arm including an inner portion attached to the base part and an outer portion provided with a rope sliding element arranged to slidably hold the rope. Each end of the rope is provided with an eye end. The arm is provided with a plurality of knobs arranged spaced apart along the arm for receiving the eye ends of the rope and for supporting the rope.

IPC Classes  ?

• F03D 13/20 - Arrangements for mounting or supporting wind motorsMasts or towers for wind motors

Abstract

The present invention relates to a connecting device (1) for securing two beams to each other end to end. The connecting device comprises a pin (2), a shaft (4), and at least one a splice element (6) provided with a first through hole (8) for receiving the shaft (4), and a second through hole (10) spaced apart from the first through hole (8) for receiving the pin (2). There is a gap between the pin (2) and the splice element (6) when the pin is inserted in the second through hole (10). The shaft (4) is rotatable with respect to splice element (6) about a rotational axis (A) when the shaft is inserted in the first through hole (8). The connecting device comprises an eccentric ring (16) arranged in the first through hole (8) so that the eccentric ring (16) is rotatable with respect to the first through hole (8). The eccentric ring (16) has an opening (18) for receiving the shaft (4), and the eccentric ring (16) is rotatable upon rotation of the shaft (4) when the shaft is inserted into the opening. The centre of the eccentric ring is offset from the rotational axis (A) of the shaft so that the splice element (6) is moved with respect to the pin (2) upon rotation of the shaft (4) and by that closes the gap on one side of the pin.

IPC Classes  ?

• F16B 7/04 - Clamping or clipping connections
• B66C 23/28 - Cranes comprising essentially a beam, boom or triangular structure acting as a cantilever and mounted for translatory or swinging movements in vertical or horizontal planes or a combination of such movements, e.g. jib cranes, derricks or tower cranes specially adapted for use in particular locations or for particular purposes for use on building sitesCranes comprising essentially a beam, boom or triangular structure acting as a cantilever and mounted for translatory or swinging movements in vertical or horizontal planes or a combination of such movements, e.g. jib cranes, derricks or tower cranes specially adapted for use in particular locations or for particular purposes constructed, e.g. with separable parts, to facilitate rapid assembly or dismantling, for operation at successively higher levels, for transport by road or rail constructed to operate at successively higher levels
• E04H 12/34 - Arrangements for erecting or lowering towers, masts, poles, chimney stacks, or the like

Abstract

The present invention relates to a lifting system (1) comprising a tower (3), a jib (4) for lifting components to an elongated structure (2), a plurality of securing members (5) for securing the tower (3) to the elongated structure (2), and a lifting device (6) for lifting the securing members (5) and moving the securing members (5) up and down along the tower (3). The lifting device (6) comprises a platform (7) attached to an upper portion of the tower (3), protruding on two opposite sides of the tower (3) so that a first portion (7a) of the platform is protruding on a first side of the tower (3) and a second portion (7b) of the platform is protruding on a second side of the tower, a crane (10) arranged on the first portion (7a) of the platform, and a winch (12) for operating the crane arranged on the second portion (7b) of the platform. The crane (10) is arranged movable along the first portion (7a) of the platform so that the horizontal distance between the tower (3) and the crane (10) can be adjusted.

IPC Classes  ?

• B66C 23/20 - Cranes comprising essentially a beam, boom or triangular structure acting as a cantilever and mounted for translatory or swinging movements in vertical or horizontal planes or a combination of such movements, e.g. jib cranes, derricks or tower cranes specially adapted for use in particular locations or for particular purposes with supporting couples provided by walls of buildings or like structures
• B66C 23/18 - Cranes comprising essentially a beam, boom or triangular structure acting as a cantilever and mounted for translatory or swinging movements in vertical or horizontal planes or a combination of such movements, e.g. jib cranes, derricks or tower cranes specially adapted for use in particular locations or for particular purposes
