The present invention relates to a fitting assembly for doors or windows and for lift and slide elements such as, for example, lift and slide doors or lift and slide windows, having a cover rail for covering a fitting groove formed in a door or window and a connecting rod translationally movably guided along the cover rail. The connecting rod comprises a first portion, which rests against a surface of the cover rail, and a second portion, which projects beyond an end of the cover rail. The fitting assembly furthermore comprises a sensor board which is at least indirectly coupled to the cover rail and has at least one sensor, which operates in a non-contact manner, for sensing the position of the connecting rod, and the sensor board is located in continuation of the cover rail and at the end of same and flanks the second portion of the connecting rod. The at least one sensor is located on the side of the sensor board which faces the second portion of the drive rod.
A floor sill system for a door or window comprises a sill element which has an underside which is to be turned towards a building structure, and at least one adjustment profile which, for adjusting the height of the floor sill system, is arranged on the underside of the sill element and via which the sill element is to be supported on the building structure, wherein the sill element and the adjustment profile each have coupling portions via which the adjustment profile is releasably coupled to the sill element, and wherein the sill element has a main body and a separate adapter profile fastened to the main body, and the coupling portion of the sill element is formed on the separate adapter profile.
Pneumatic door openers and closers [parts of machines]; Hydraulic door openers and closers [parts of machines]; Electric motors for use with doors; Electronic door closing system; Window openers, electric; Window closers, electric; Electric motor drives for use with ventilation openings or other openings in buildings.
Pneumatic door openers and closers [parts of machines]; Hydraulic door openers and closers [parts of machines]; Electric motors for use with doors; Electronic door closing system; Window openers, electric; Window closers, electric; Electric motor drives for use with ventilation openings or other openings in buildings.
Pneumatic door openers and closers [parts of machines]; Hydraulic door openers and closers [parts of machines]; Electric motors for use with doors; Electronic door closing system; Window openers, electric; Window closers, electric; Electric motor drives for use with ventilation openings or other openings in buildings.
Pneumatic door openers and closers [parts of machines]; Hydraulic door openers and closers [parts of machines]; Electric motors for use with doors; Electronic door closing system; Window openers, electric; Window closers, electric; Electric motor drives for use with ventilation openings or other openings in buildings.
The invention relates to a socket for the gearing of a fitting assembly of a window, door or the like, in particular a lifting-sliding door or a lifting-sliding window, which has a receptacle for an actuation element, said receptacle extending along a central axis of the socket, and which has a coupling portion, eccentric with respect to the central axis, for drive-effective coupling of the socket to an adjustment element of the fitting assembly, characterised in that the socket is formed from a plurality of parts and comprises a first socket plate, a second socket plate and at least one spacer arranged between the two socket plates.
A ground sill for supporting a frame and a fixed leaf or casement of a door or window on a building structure comprises an elongate sill body which is intended to be directly or indirectly secured to the building structure and has a surface, and at least one connecting element to be inserted between the surface of the sill body and an underside of the frame or of the fixed leaf or casement, wherein the connecting element has an underside designed to be placed on the surface of the sill body, wherein, in the underside of the connecting element, a groove is formed which extends along a peripheral region of the underside, wherein a sealing element made of an elastic material has been injected into the groove, and wherein the sealing element adheres in the groove and projects out of the groove at least in an uncompressed state.
A floor threshold for supporting a fixed leaf of a door or of a window on a construction element comprises: an elongate threshold part for fastening to the construction element, the threshold part having a surface from which a stop step protrudes, the stop step extending along a longitudinal axis of the threshold part; and a connecting element to be installed between the surface of the threshold part and a bottom side of the fixed leaf, the connecting element comprising an a bottom side, a top side, a step contact portion defining a contact axis, and a front side facing away from the step contact portion. The step contact portion has a sealing portion for fluid-tight contact with the stop step. By means of a cutout in the step contact portion, water can be led away from the top side, through a drain channel formed in the connecting element, to the front side. The connecting element comprises a main part and a separate contact part forming the sealing portion, the main part having two mutually spaced coupling portions, and the separate contact part being releasably fastened to one of the two coupling portions.
The invention relates to a floor sill for supporting a frame and a fixed-panel leaf of a door or window on a building structure, said floor sill comprising: an elongate sill body which is designed to be directly or indirectly attached to the building structure and has a surface from which a stop step protrudes that extends along a longitudinal axis of the sill body; and at least one connection element to be inserted between the surface of the sill body and a bottom side of the frame or of the fixed-panel leaf. The connection element has: a bottom side designed to be placed on the surface of the sill body; a top side intended to face the frame or the fixed-panel leaf; and a lateral contact surface designed to contact the stop step of the sill body. A receptacle for a sealing element is formed in the connection element and is open toward the lateral contact surface. The connection element also contains an injection channel for injecting a sealant, said injection channel having an access opening, that is not located in the lateral contact surface, and opening into the receptacle.
The present invention relates to a bogie assembly for displaceable mounting of a lifting/sliding element on a running rail and for raising and lowering same. The bogie assembly comprises a bogie and a base part attachable to the lifting/sliding element, which base part is coupled to the bogie and has a position raised relative to the bogie and a position lowered relative to the bogie. The bogie assembly has a predefined position between the raised and lowered positions, wherein, in the predefined position, a fixing means made of a plastics material is active between the base part and the bogie that maintains the predefined position.
The present invention relates to a cover for a milled recess, formed in a door frame, for accommodating a locking bolt of a door lock. The milled cover comprises: a housing having an opening for a locking bolt; and a sensor board which is attached to the housing and has a contactless sensor for detecting a locking bolt that engages into the housing through the opening.
A sill for a door or window comprises a sill element that is provided for direct or indirect fastening to a structural body. The sill element has a solid-material profile made of a closed-pore foam material and at least one covering profile lying on top of the solid-material profile.
The present invention relates to a fitting arrangement for raising and lowering a lift-and-slide element. The fitting arrangement comprises: a gearbox which contains an actuation gear mechanism; and a cover rail to which the gearbox is attached and along which a drive rod, which is operatively coupled to the actuation gear mechanism, is translationally displaceably guided. The gearbox is detachably secured to the cover rail perpendicular to the longitudinal extension of said cover rail exclusively by means of at least one clip connection.
E05D 15/56 - Suspension arrangements for wings with successive different movements
E05B 9/08 - Fastening the casings of latch-bolt locks or cylinder locks to the wing
E05B 65/08 - Locks for special use for sliding wings
E05C 9/02 - Arrangement of simultaneously-actuated bolts or other securing devices at well-separated positions on the same wing with one sliding bar for fastening when moved in one direction and unfastening when moved in opposite directionArrangement of simultaneously-actuated bolts or other securing devices at well-separated positions on the same wing with two sliding bars moved in the same direction when fastening or unfastening
